HP Jetdirect pn1050 Network Projector Manager
Administrator’s Guide
© Copyright 2005 Hewlett-Packard Development Company, L.P.
Reproduction, adaptation, or translation without prior written permission is prohibited, except as
allowed under the copyright laws.
The information contained in this document is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained
herein.
Edition 1, 8/2005
Trademark Credits
Microsoft®, MS-DOS®, Windows®, are U.S. registered trademarks of Microsoft Corporation.
NetWare® and Novell® are registered trademarks of Novell Corporation. Ethernet is a registered
trademark of Xerox Corporation. PostScript is a trademark of Adobe Systems, Incorporated.
UNIX® is a registered trademark of the Open Group.
Table of Contents
1. Introducing the HP Jetdirect
Network Projector Manager
Introduction.......................................................................................... 5
Security Protocols ................................................................................5
Supplied Manuals.................................................................................7
HP Support............................................... ............................................7
Product Registration.............................................................................8
2. HP Web Jetadmin
Introduction.......................................................................................... 9
3. TCP/IP Configuration
Introduction........................................................................................ 12
Default IP Address.............................................................................13
Using BOOTP/TFTP..........................................................................17
Using DHCP ......................................................................................32
Using RARP.......................................................................................40
Using the arp and ping Commands....................................................42
Using the Embedded Web Server......................................................44
Moving to Another Network..............................................................44
4. Using the Embedded Web Server
Introduction........................................................................................ 45
Requirements .....................................................................................47
Viewing the Embedded Web Server..................................................48
HP Jetdirect Home Tab........................................ ..............................50
Networking Tab .................................................................................52
Projector Tab......................................................................................77
Other Links ........................................................................................79
5. Security Features
Introduction........................................................................................ 80
Using Security Features .....................................................................83
6. Troubleshooting the HP Jetdirect
Projector Server
Introduction........................................................................................ 84
Resetting to Factory Defaults.............................................................85
General Troubleshooting....................................................................86
ENWW 3
A. TCP/IP Overview
Introduction........................................................................................ 90
IP Address..........................................................................................91
Configuring IP Parameters.................................................................93
Subnets...............................................................................................94
Gateways............................................................................................95
Syslog Server .....................................................................................95
B. OpenSSL Statements
Index
ENWW 4
1
Introducing the HP Jetdirect Network Projector Manager
Introduction
The HP Jetdirect network projector manager is a server that connects a
projector directly to a network, so that you can manage it from anywhere on
the network.
Throughout this manual, this product is called a projector server.
Security Protocols
SNMP
SNMP (Simple Network Management Protocol) is used by network
management applications for device management. HP Jetdirect projector
servers support SNMP and standard MIB-II (Management Information Base)
objects on IP networks.
HP Jetdirect projector servers support an SNMP v1/v2c agent, and an
SNMP v3 agent for enhanced security.
HTTPS
HP Jetdirect projector servers support HTTPS (Secure Hyper Text Transfer
Protocol) for secure, encrypted management communications between their
embedded Web servers and your Web browser.
ENWW 5
Authentication
EAP/802.1X Server-Based Authentication
As a network client, the HP Jetdirect projector server support network access
using the Extensible Authentication Protocol (EAP) on an IEEE 802.1X
network. The IEEE 802.1X standard provides a port-based authentication
protocol where a port can allow or block access depending on client
authentication results.
When using an 802.1X connection, the projector server supports Extensible
Authentication Protocol (EAP) with an authentication server, such as a
RADIUS (Remote Authentication Dial In User Service, RFC 2138) server.
Projector servers support the following EAP/802.1X method:
● PEAP (Protected Extensible Authentication Protocol). PEAP is a mutual
authentication protocol that uses digital certificates for network server
authentication and passwords for client authentication. For additional
security, the authentication exchanges are encapsulated within TLS
(Transport Layer Security). Dynamic encryption keys are used for secure
communications.
The network infrastructure device that connects the projector server to the
network (such as an HP Procurve switch) must also support the EAP/802.1X
method used. In conjunction with the authentication server, the infrastructure
device can control the degree of network access and services available to the
server client.
To configure the server for EAP/802.1X authentication, you must access the
embedded Web server through your Web browser. For more information, see
Chapter 4
ENWW Introducing the HP Jetdirect Network Projector Manager 6
.
Supplied Manuals
The manuals listed below are supplied with your projector server on the
Documentation CD.
● This Administrator’s Guide.
● The Setup Guide.
HP Support
HP Online Support
Click your way to a quick solution! The HP Web site:
http://www.hp.com/support
is a great place to start for answers to questions about your HP Jetdirect
projector server — 24 hours a day, 7 days a week.
Firmware Upgrades
Hewlett-Packard offers downloadable firmware upgrades for HP Jetdirect
projector servers that contain upgradeable memory. The upgrades are
available from the World Wide Web at:
http://www.hp.com/go/
Firmware Installation Tools
Firmware upgrades for supported HP Jetdirect projector servers may be
installed over a network using one of the following firmware installation tools:
● HP Jetdirect Download Manager (Windows). HP Jetdirect Download
Manager can be downloaded from HP online support at:
http://www.hp.com/go/dlm_sw
● HP Web Jetadmin may be used on supported systems. For more
information on HP Web Jetadmin, visit:
http://www.hp.com/go/webjetadmin/
proj_firmware
ENWW Introducing the HP Jetdirect Network Projector Manager 7
● The embedded Web server resident on the projector server provides a
firmware upgrade feature using your Web browser. For more information
see Chapter 4
● FTP (File Transfer Protocol) may be used to transfer a firmware upgrade
.
image file to the projector server. To start an FTP session, use the device
IP address or host name. If a password is set, it must be entered to log into
the device. After user login, typical FTP commands to upgrade the device
are illustrated below:
ftp> bin
ftp> hash
ftp> cd /download
ftp> put <firmware image filename; specify full pathname>
ftp>######### <Wait for FTP to complete the download>
ftp> bye
HP Support By Phone
Highly trained technicians are ready to take your call. For the most recent
HP support telephone numbers and available services worldwide, visit:
http://www.hp.com/support
Note For toll-free support in the USA and Canada, call
1-800-HPINVENT or 1-800-474-6836.
Note Telephone fees are the responsibility of the caller. Rates
may vary. Contact your local telephone company for current
rates.
Product Registration
To register your HP Jetdirect projector server, use the following
HP Web page:
http://www.
ENWW Introducing the HP Jetdirect Network Projector Manager 8
register.hp.com
2
HP Web Jetadmin
Introduction
HP Web Jetadmin is an enterprise management tool that allows you to
remotely install, configure, and manage a wide variety of HP and non-HP
network printers and HP projectors simply through a standard Web browser.
HP Web Jetadmin can be used to proactively manage both individual or groups
of devices.
To use HP Web Jetadmin, see the online help and documentation supplied
with the software.
System Requirements
HP Web Jetadmin software runs on Microsoft Windows 2000, Windows XP
Professional, and Windows Server 2003 systems. For information on
supported operating systems, clients, and compatible browser versions, visit
HP online support at http://www.hp.com/go/webjetadmin
.
To manage digital projectors, HP Web Jetadmin version 7.8 or greater and the
HP Web Jetadmin plug-in for digital projectors are required. We recommend
using the latest version, which may provide enhanced functionality.
Note When installed on a supported host server,
HP Web Jetadmin can be accessed from any client
through a compatible Web browser by browsing to the
HP Web Jetadmin host.
ENWW 9
Installing HP Web Jetadmin
Before installing the HP Web Jetadmin software, you must have administrator
or root privileges on the local system:
1. Downlo ad the installation files from HP online support at
http://www.hp.com/go/webjetadmin
2. Follow the instructions on the screen to install the HP Web Jetadmin
software.
Note Installation instructions are also contained in the HP Web
Jetadmin install file.
Verifying Installation and Providing Access
● Verify that the HP Web Jetadmin software is correctly installed by
navigating to it with your browser as shown in the following example:
http://systemname.domain:port/
where systemname.domain is the host name of your Web server and
port is the port number assigned during installation. By default, the port
number is 8000.
.
● Provide users access to HP Web Jetadmin software by adding a link to your
Web server’s home page that is addressed to HP Web Jetadmin’s URL. For
example:
http://systemname.domain:port/
ENWW HP Web Jetadmin 10
Configuring and Modifying a Device
Using your browser, navigate to HP Web Jetadmin’s URL. For example:
http://systemname.domain:port/
Note. In place of systemname.domain, the IP address of the
host computer on which HP Web Jetadmin is installed can
be used.
Follow the instructions on the appropriate home page to find and manage your
printers and projectors.
Removing HP Web Jetadmin Software
To remove HP Web Jetadmin software from your Web server, use the uninstall
program provided with the software package.
ENWW HP Web Jetadmin 11
3
TCP/IP Configuration
Introduction
To operate properly on a TCP/IP network, the HP Jetdirect projector server
must be configured with valid TCP/IP network configuration parameters, such
as an IP address that is valid for your network. For general information on
TCP/IP networks, see Appendix A
Server-Based and Manual TCP/IP Configuration
When in a factory-default state and powered on, the HP Jetdirect projector
server will try to obtain its TCP/IP configuration using a server-based method,
such as BOOTP/TFTP, DHCP/TFTP, or RARP. These server-based methods
are described later in this chapter. Depending on the server model, up to two
minutes may be used for these methods. If configuration is not successful, a
default IP address will be assigned.
The server may also be configured manually. Manual-based tools include a
Web browser, arp and ping commands (when the default IP address is
192.0.0.192), or SNMP-based management software. TCP/IP configuration
values assigned manually will be retained when powered off/on.
.
The server can be reconfigured to use either server-based or manual
configuration of TCP/IP settings at any time.
To identify the IP address that is configured on the projector server at any
time, see the IP address displayed in the projector’s on-screen Help menu.
ENWW 12
Default IP Address
When in a factory-default state (for example, when shipped from the factory
or after a cold-reset), the HP Jetdirect projector server has no IP address. A
default IP address may or may not be assigned depending on the network
environment.
Default IP Address Will Not Be Assigned
A default IP address will not be assigned if a server-based method (such as
BOOTP or DHCP) is successful. And if the server is powered off/on, the same
method will again be used to retrieve IP configuration settings. If this method
now fails to retrieve the IP configuration settings (for example, the BOOTP
or DHCP server is no longer available), a default IP address will not be
assigned. Instead, the server will continue to send IP configuration requests
indefinitely. You must cold-reset the server to change this behavior.
In addition, a default IP address will not be assigned if a network cable is not
attached.
Default IP Address Will Be Assigned
A default IP address will be assigned if the factory-default methods fail, or if
the server has just been reconfigured by an administrator to use a server-based
method (such as BOOTP or DHCP) that fails.
If a default IP address is assigned, the address will depend on the network to
which the server is connected. The server senses broadcast packets on the
network to determine the appropriate default IP settings:
● On small private networks that adhere to automated, standards-based IP
address assignments, the server uses a link-local addressing technique to
assign a unique IP address. Link-local addressing is limited to a local IP
subnet (not routed) and may be referenced as Au to IP. The IP address
assigned will be in the range of 169.254.1.0 to 169.254.254.255
(commonly referenced as 169.254/16). However, it can be further
modified for your network using supported TCP/IP configuration tools if
necessary.
With link-local addresses, subnetting is not used. The subnet mask will
be 255.255.0.0, and cannot be changed.
ENWW TCP/IP Configuration 13
Link-local addresses will not route off the local link, and access to or from
the Internet will not be available. The default gateway address will be the
same as the link-local address.
If a duplicate address is sensed, the HP Jetdirect server will automatically
reassign its address, if necessary, in accordance with standard link-local
addressing methods.
● On large or enterprise IP networks, a temporary address of 192.0.0.192
will be assigned until it is reconfigured with a valid address through
supported TCP/IP configuration tools. We refer to this address as Legacy
Default IP.
● On mixed-environment networks, the self-assigned default IP address
may be either 169.254/16 or 192.0.0.192. In this case, you should verify
through the projector’s on-screen Help menu that the assigned default IP
address is as expected.
The IP address configured on your projector server can be found on the
projector’s on-screen Help menu.
Default IP Address Configuration Options
Default IP Parameter
A Default IP configuration parameter on the projector server controls how the
default IP address is assigned. Whenever the server is unable to obtain an IP
address during a forced TCP/IP reconfiguration (for example, when manually
configured to use BOOTP or DHCP), this parameter will determine the default
IP address to use.
When the server is in a factory-default state, this parameter is undefined.
If the server is initially configured with a default IP address (either a link-local
IP address or the legacy default 192.0.0.192 IP address), the Default IP
parameter will be set to either Auto IP or Legacy Default IP to match.
The Default IP parameter can be changed through a supported configuration
tool, such as a Web browser and SNMP management applications.
ENWW TCP/IP Configuration 14
DHCP Requests Enable/Disable
When a default IP address is assigned, you can configure the projector server
to send, or not send, periodic DHCP requests. DHCP requests are used to
retrieve IP configuration settings from a DHCP server on the network. By
default, this parameter is enabled, allowing DHCP requests to be transmitted.
However, this parameter may be disabled through supported configuration
tools such as a Web browser, and SNMP management applications.
TCP/IP Configuration Tools
When a network connection has been established, an HP Jetdirect projector
server can be configured with valid TCP/IP parameters for your network in
the following ways:
● Using Software. You can use installation, setup, and management
software running on supported systems. For more information see
Chapter 2
● BOOTP/TFTP. You can download the data from a network-based server
using BOOTP (Bootstrap Protocol) and TFTP (Trivial File Transfer
Protocol) each time the projector is turned on. For more information, see
“U
The BOOTP daemon, bootpd, must be running on a BOOTP server that
is accessible by the projector.
, “HP Web Jetadmin”.
sing BOOTP/TFTP”.
● DHCP/TFTP. You can use Dynamic Host Configuration Protocol
(DHCP) and TFTP (Trivial File Transfer Protocol) each time the projector
is turned on. These protocols are supported on HP-UX, Solaris, Linux,
Windows NT/2000/Server 2003, NetWare and Mac OS systems. (Refer
to your network operating system manuals to verify that your server
operating system supports DHCP.) For more information, see “Using
DHCP”.
ENWW TCP/IP Configuration 15
Note Linux and UNIX systems: For more information, see the
bootpd “man” page.
On HP-UX systems, a sample DHCP configuration file
(dhcptab) may be located in the /etc directory.
Since HP-UX presently does not provide Dynamic Domain
Name Services (DDNS) for its DHCP implementations,
HP recommends that you set all projector server lease
durations to infinite. This ensures that server IP addresses
remain static until such time as Dynamic Domain Name
Services are provided.
● RARP. A network-based server can use RARP (Reverse Address
Resolution Protocol) to answer the projector server’s RARP request and
supplying the server with the IP address. The RARP method only allows
you to configure the IP address. For more information, see “U
● arp and ping commands. (For projector servers configure with Legacy
sing RARP.”
default IP address 192.0.0.192 only) You can use the arp and ping
commands from your system. For more information, see “Using the arp
and ping Commands.”
● Embedded Web server. You can browse to the embedded Web server
on the HP Jetdirect projector server to set configuration parameters. For
more information, see Chapter 4
.
ENWW TCP/IP Configuration 16
Using BOOTP/TFTP
BOOTP (Bootstrap Protocol) and TFTP (Trivial File Transfer Protocol)
provide a convenient way to automatically configure the HP Jetdirect
projector server for TCP/IP network operation. When powered on, the
Jetdirect server sends a BOOTP request message onto the network. A properly
configured BOOTP server on the network will respond with a message that
contains basic network configuration data for the Jetdirect server. The BOOTP
server’s response may also identify a file that contains extended configuration
data for the server. The Jetdirect server downloads this file using TFTP. This
TFTP configuration file may be located on the BOOTP server, or a separate
TFTP server.
BOOTP/TFTP servers are typically UNIX or Linux systems. Windows
NT/2000/Server 2003 and NetWare servers can respond to BOOTP requests.
Windows NT/2000/Server 2003 servers are configured through Microsoft
DHCP services (see “Using DHC
2003 systems may require third-party software for TFTP support. For setup
of NetWare BOOTP servers, refer to your NetWare documentation.
Note If the Jetdirect projector server and BOOTP/DHCP server
are located on different subnets, IP configuration may fail
unless the routing device supports “BOOTP Relay” (allows
the transfer of BOOTP requests between subnets).
P”). However, Windows NT/2000/Server
Why Use BOOTP/TFTP?
Using BOOTP/TFTP to download configuration data has the following
benefits:
● Enhanced configuration control of the HP Jetdirect projector server.
Configuration by other methods are limited to select parameters.
● Ease of configuration management. Network configuration parameters for
the entire network can be in one location.
● Ease of HP Jetdirect projector server configuration. Complete network
configuration can be automatically downloaded each time the server is
powered on.
ENWW TCP/IP Configuration 17
Note BOOTP operation is similar to DHCP, but the resulting IP
parameters will be the same when powered off/on. In
DHCP, IP configuration parameters are leased and may
change over time.
When in its factory-default state and powered on, the HP Jetdirect projector
server will attempt to automatically configure itself using several dynamic
methods, one of which is BOOTP.
BOOTP/TFTP on UNIX
This section describes how to configure the projector server using BOOTP
(Bootstrap Protocol) and TFTP (Trivial File Transfer Protocol) services on
UNIX servers. BOOTP and TFTP are used to download network
configuration data from a server to the HP Jetdirect projector server over the
network.
Systems That Use Network Information Service (NIS)
If your system uses NIS, you may need to rebuild the NIS map with the
BOOTP service before performing the BOOTP configuration steps. Refer to
your system documentation.
Configuring the BOOTP Server
For the HP Jetdirect projector server to obtain its configuration data over the
network, the BOOTP/TFTP servers must be set up with the appropriate
configuration files. BOOTP is used by the projector server to obtain entries
in the /etc/bootptab file on a BOOTP server, while TFTP is used to
obtain additional configuration information from a configuration file on a
TFTP server.
When the HP Jetdirect projector server is powered on, it broadcasts a BOOTP
request that contains its MAC (hardware) address. A BOOTP server daemon
searches the /etc/bootptab file for a matching MAC address, and if
successful, sends the corresponding configuration data to the Jetdirect
projector server as a BOOTP reply. The configuration data in the
/etc/bootptab file must be properly entered. For a description of entries,
see “Bootptab File Entries
ENWW TCP/IP Configuration 18
.”
The BOOTP reply may contain the name of a configuration file containing
enhanced configuration parameters. If the HP Jetdirect projector server finds
such a file, it will use TFTP to download the file and configure itself with
these parameters. For a description of entries, see “TFTP Configuration File
Entries.” Configuration parameters retrieved through TFTP are optional.
Note HP recommends that the BOOTP server be located on the
same subnet as the projectors it serves. BOOTP broadcast
packets may not be forwarded by routers unless the
routers are properly configured.
Bootptab File Entries
An example of a /etc/bootptab file entry for an HP Jetdirect projector
server is provided below:
picasso:\
:hn:\
:ht=ether:\
:vm=rfc1048:\
:ha=0001E6123456:\
:ip=192.168.40.39:\
:sm=255.255.255.0:\
:gw=192.168.40.1:\
:lg=192.168.40.3:\
:T144=“hpnp/picasso.cfg”:
Note that the configuration data contains “tags” to identify the various
HP Jetdirect parameters and their settings. Entries and tags supported by the
HP Jetdirect projector server are listed in Table 3.1
ENWW TCP/IP Configuration 19
.
Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (1 of 3)
Item RFC
2132
Option
nodename -- The name of the peripheral. This name identifies an entry
ht -- The hardware type tag. For the HP Jetdirect projector
Description
point to a list of parameters for a specific peripheral.
nodename must be the first field in an entry. (In the
example above, nodename is “picasso”.)
server, set this to ether (for Ethernet). This tag must
precede the ha tag.
vm -- The BOOTP report format tag (required). Set this
parameter to rfc1048.
ha -- The hardware address tag. The hardware (MAC) address
is the link-level, or station address of the HP Jetdirect
projector server. It is printed on a label attached to the
server, and displayed by the embedded web server.
ip -- The IP address tag (required). This address will be the
HP Jetdirect projector server’s IP address.
sm 1 The subnet mask tag. The subnet mask will be used by
the HP Jetdirect projector server to identify the portions of
an IP address that specify the network/subnetwork
number and the host address.
gw 3 The gateway IP address tag. This address identifies the
IP address of the default gateway (router) that the
HP Jetdirect projector server will use for communications
with other subnets.
ds 6 DNS (Domain Name System) server’s IP address tag.
Only a single name server can be specified.
lg 7 The syslog server’s IP address tag. It specifies the server
that the HP Jetdirect projector server sends syslog
messages to. For more information, see Appendix A
.
ENWW TCP/IP Configuration 20
Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (2 of 3)
Item RFC
2132
Option
hn 12 The host name tag. This tag does not take a value but
dn 15 Domain name tag. Specifies the domain name for the
Description
causes the BOOTP daemon to download the host name
to the HP Jetdirect projector server. The host name will be
returned on an SNMP sysName request by a network
application.
HP Jetdirect projector server (for example,
support.hp.com). It does not include the host name; it is
not the Fully Qualified Domain Name (such as
projector1.support.hp.com).
ef 18 Extensions file tag that specifies the relative path name of
the TFTP configuration file.
Note: This tag is similar to the vendor-specific tag T144,
described below.
na 44 Tag for IP addresses of the NetBIOS-over-TCP/IP Name
Server (NBNS). A primary and secondary server may be
specified in order of preference.
lease-time 51 DHCP IP address lease duration time (seconds).
tr 58 DHCP T1 timeout, specifying the DHCP lease renewal
time (seconds).
tv 59 DHCP T2 timeout, specifying the DHCP lease rebind time
(seconds).
T144 -- An HP-proprietary tag that specifies the relative path name
of the TFTP configuration file. Long path names may be
truncated. The path name must be in double quotes (for
example, “pathname”). For file format information, refer to
“TFTP Configuration File Entries
.”
Note: Standard BOOTP option 18 (extensions file path)
also allows a standard tag (ef) to specify the relative path
name of the TFTP configuration file.
T145 -- Idle Timeout option. An HP-proprietary tag to set the idle
timeout (seconds), which is the amount of time that a data
connection may remain idle before being closed. The
range is 1 - 3600 seconds.
ENWW TCP/IP Configuration 21
Table 3.1 Tags Supported in a BOOTP/DHCP Boot file (3 of 3)
Item RFC
2132
Option
T146 -- Buffer Packing option. An HP-proprietary tag to set buffer
T147 -- Write Mode option. An HP-proprietary tag that controls the
T148 -- IP Gateway Disable option. An HP-proprietary tag to
T149 -- Interlock Mode option. An HP-proprietary tag that specifies
Description
packing for TCP/IP packets.
0 (default): Normal data buffers are packed before sending
to the projector.
1: Disable buffer packing. Data is sent to the projector
when received.
TCP PSH flag setting for device-to-client data transfers.
0 (default): disables this option, flag not set.
1: all-push option. The push bit is set in all data packets.
prevent configuration of a Gateway IP address.
0 (default): allows an IP address.
1: prevents a Gateway IP address to be configured.
whether an acknowledgement (ACK) on all TCP packets
is required before the projector is allowed to close a Port
9100 connection. A Port Number and Option value are
specified, in the form:
<Port Number><Option>
<Port Number>: For supported HP Jetdirect projector
servers, the Port Number is 1 (default).
<Option>: Option value 0 (default) disables interlock, 1
enables.
Example: 1 1 specifies <Port 1>, <interlock enabled>
T150 -- TFTP server’s IP address option. An HP-proprietary tag to
specify the TFTP server’s IP address where the TFTP
configuration file is located.
T151 -- Network Configuration option. An HP-proprietary tag to
specify either “BOOTP-ONLY” or “DHCP-ONLY” requests
be sent.
ENWW TCP/IP Configuration 22
A colon (:) indicates the end of a field, and a backslash (\) indicates that the
entry is continued on the next line. Spaces are not allowed between the
characters on a line. Names, such as host names, must begin with a letter and
can contain only letters, numbers, periods (for domain names only), or
hyphens. The underline character (_) is not allowed. Refer to your system
documentation or online help for more information.
TFTP Configuration File Entries
To provide additional configuration parameters for your HP Jetdirect
projector server, such as SNMP (Simple Network Management Protocol) or
non-default settings, an additional configuration file can be downloaded using
TFTP. This TFTP configuration file’s relative path name is specified in the
BOOTP reply using the /etc/bootptab file’s T144 vendor-specific tag
(or the “ef” standard BOOTP tag) entry. An example of a TFTP configuration
file is provided below (the symbol ‘#’ denotes a remark and is not included in
the file).
# Example of an HP Jetdirect TFTP Configuration File
#
# Allow only Subnet 192.168.10 access to peripheral.
# Up to 10 ‘allow’ entries can be written through TFTP.
# Up to 10 ‘allow’ entries can be written through
# embedded Web server.
#
# ‘allow’ may include single IP addresses.
allow: 192.168.10.0 255.255.255.0
#
# Enable the embedded Web server
ews-config: 1
#
# Detect SNMP unauthorized usage
auth-trap: on
#
# Send Traps to 192.168.10.1
trap-dest: 192.168.10.1
#
# Specify the Set Community Name
set-cmnty-name: 1homer2
#
# End of file
ENWW TCP/IP Configuration 23
Table 3.2 lists supported TFTP commands.
Table 3.3
describes the TFTP parameters.
Table 3.2 List of Supported TFTP Commands
General
● passwd:
● sys-location:
● sys-contact:
TCP/IP Main
● host-name:
● domain-name:
● pri-dns-svr:
TCP/IP Access Control
● allow: netnum [mask]
TCP/IP Other Settings
● syslog-config:
● syslog-svr:
● syslog-max:
● syslog-priority:
● syslog-facility:
● slp-config:
● slp-keep-alive:
● ttl-slp:
● ipv4-multicast:
● idle-timeout:
SNMP
● snmp-config:
● get-cmnty-name:
● set-cmnty-name:
Other Settings
● link-type: ● upgrade:
Support
● support-name:
● support-number:
● ssl-state:
● security-reset:
● tftp-parameter-attribute:
● sec-dns-svr:
● pri-wins-svr:
● sec-wins-svr:
● user-timeout:
● ews-config:
● tcp-mss:
● tcp-msl:
● default-ip:
● default-ip-dhcp:
● dhcp-arbitration:
● phone-home-config:
● web-refresh:
● auth-trap:
● trap-dest:
● support-url:
● tech-support-url:
ENWW TCP/IP Configuration 24
Table 3.3 TFTP Configuration File Parameters (1 of 7)
General
passwd:
(passwd-admin:)
A password (up to 16 alphanumeric characters) that allows administrators to
control changes of HP Jetdirect projector server configuration parameters through
HP Web Jetadmin or embedded Web server. The password may be cleared by a
cold reset.
sys-location:
(host-location:, location:)
Identifies the physical location of the projector (SNMP sysLocation object). Only
printable ASCII characters are allowed. The maximum length is 64 characters. The
default location is undefined. (Example: 1st floor, south wall)
sys-contact:
(host-contact:, contact:)
ASCII character string (up to 64 characters) that identifies the person who
administers or services the projector (SNMP sysContact object). This may include
how to contact this person. The default contact is undefined.
ssl-state:
Sets the projector server’s security level for Web communications:
1 (default): Forced redirection to the HTTPS port. Only HTTPS (secure HTTP)
communications can be used.
2: Disable forced redirection to HTTPS. Both HTTP and HTTPS communications
can be used.
security-reset:
Reset security settings on the projector server to factory default values. 0 (default)
does not reset, 1 resets the security settings.
tftp-parameter-attribute:
Specifies whether TFTP parameters can be manually overwritten on the projector
server after it has been configured by TFTP.
tftp-ro (default): Do not allow TFTP parameters to be manually changed, and
always overwrite manual configurations.
tftp-rw: Allow TFTP parameters to be manually changed, and always overwrite
manual configurations.
manual-ro: Do not allow TFTP parameters to overwrite manually configured
parameters.
ENWW TCP/IP Configuration 25
Table 3.3 TFTP Configuration File Parameters (2 of 7)
TCP/IP Main
host-name:
(sys-name:, name:)
Specifies the node name. Default is NPIxxxxxx, where xxxxxx is the last six digits
of the LAN hardware address.
domain-name:
The domain name for the device (for example, support.hp.com). It does not
include the host name; it is not the Fully Qualified Domain Name (such as
projector1.support.hp.com).
pri-dns-svr:
(dns-srv)
The IP address of the DNS (Domain Name System) server.
sec-dns-svr:
The IP address of a secondary DNS server to use if the primary DNS server is
unavailable.
pri-wins-svr:
(pri-wins-srv:)
The IP address of the primary Windows Internet Naming Service (WINS) server.
sec-wins-svr:
(sec-wins-srv:)
The IP address of the secondary Windows Internet Naming Service (WINS) server.
TCP/IP Access Control
allow: netnum [mask]
Makes an entry into the host access list stored on the HP Jetdirect projector server.
Each entry specifies a host or network of hosts that are allowed to connect to the
projector. The format is “allow: netnum [mask]” where netnum is a network number
or host IP address, and mask is an address mask of bits applied to the network
number and host address to verify access. Up to 10 access list entries are allowed.
If there are no entries, all hosts are permitted access. For example,
allow: 192.0.0.0 255.0.0.0 allows hosts on network 192.
allow: 192.168.1.2 allows a single host. In this case, the default mask
255.255.255.255 is assumed and is not required.
allow: 0 This entry clears the host access list.
For additional information, see Chapter 5
.
ENWW TCP/IP Configuration 26
Table 3.3 TFTP Configuration File Parameters (3 of 7)
TCP/IP Other Settings
syslog-config:
Enables or disables syslog server operation on the projector server: 0 disables,
1 (default) enables.
syslog-svr:
(syslog-srv:)
The syslog server’s IP address. It specifies the server that the HP Jetdirect
projector server sends syslog messages to. For more information, see Appendix A
syslog-max:
Specifies the maximum number of syslog messages that can be sent by the
HP Jetdirect projector server on a per-minute basis. This setting allows
administrators to control the log file size. The default is 10 per minute. If set to zero,
the number of syslog messages is not restricted.
syslog-priority:
Controls the filtering of syslog messages sent to the syslog server. The filter
range is 0 to 8, with 0 being the most specific and 8 the most general. Only
messages that are lower than the filter level specified (or higher in priority) are
reported. The default is 8, messages of all priorities are sent. If 0, all syslog
messages are disabled.
syslog-facility:
A code used to identify the source facility of a message (for example, to identify
the source of selected messages during troubleshooting). By default, the
HP Jetdirect projector server uses local user values of local0 through local7 to
isolate individual or groups of projector servers. The default is local0.
slp-config:
Enables or disables the Service Location Protocol (SLP) operation on the projector
server: 0 disables, 1 (default) enables.
slp-keep-alive:
Specifies a time period for the projector server to send multicast packets on the
network to prevent being deleted from network device tables. Some infrastructure
devices, such as switches, may delete active devices from their device tables due
to inactivity on the network. To enable this feature, set a value from 1 to 1440
minutes. Set 0 to disable this feature.
ttl-slp:
Specifies the IP multicast “Time To Live” (TTL) setting for Service Location Protocol
(SLP) packets. The default value is 4 hops (the number of routers from the local
network). The range is 1-15. When set to a -1, multicast capability is disabled.
ipv4-multicast:
Enables or disables the receipt and transmission of IP version 4 multicast packets
by the projector server. 0 disables, 1 (default) enables.
.
ENWW TCP/IP Configuration 27
Table 3.3 TFTP Configuration File Parameters (4 of 7)
idle-timeout:
The number of seconds that an idle data connection is allowed to remain open.
The acceptable values range from 0 to 3600 (1 hour). If “0” is typed, the timeout
mechanism is disabled. The default is 270 seconds.
user-timeout:
An integer (1..3600) that specifies the number of seconds that your FTP session
can be idle before it will be automatically disconnected. The default is 900 seconds.
0 disables the timeout.
ews-config:
(web:)
Enables or disables the projector server’s embedded Web server to change
configuration values: 0 disables, 1 (default) enables.
tcp-mss:
(subnets-local:)
Specifies the maximum segment size (MSS) that the HP Jetdirect projector server
will advertise for use when communicating with local subnets (Ethernet MSS=1460
bytes or more) or remote subnets (MSS=536 bytes):
0 (default): All networks are assumed to be local (Ethernet MSS=1460 bytes or
more).
1: Use MSS=1460 bytes (or more) for subnets, and MSS=536 bytes for remote
networks.
2: All networks are assumed to be remote (MSS=536 bytes), except the local
subnet.
MSS affects performance by helping to prevent IP fragmentation that may result
in data retransmission.
tcp-msl:
Specifies the maximum segment life (MSL) in seconds. The range is 5 - 120
seconds. The default is 15 seconds.
ENWW TCP/IP Configuration 28
Table 3.3 TFTP Configuration File Parameters (5 of 7)
default-ip:
Specifies the IP address to use when the projector server is unable to obtain an
IP address from the network during a forced TCP/IP reconfiguration (for example,
when powered off/on or manually configured to use BOOTP/DHCP).
DEFAULT_IP: sets the legacy default IP address 192.0.0.192.
AUTO_IP: sets a link-local IP address 169.254.x.x.
The initial setting is determined by the IP address obtained when first powered on.
default-ip-dhcp:
Specifies whether DHCP requests will be periodically transmitted when a legacy
default IP address 192.0.0.192 or link-local IP address 169.254.x.x has been
automatically assigned.
0: Disables DHCP requests.
1 (default): Enables DHCP requests.
dhcp-arbitration:
Specifies the amount of time, in seconds, that the projector server will wait for
DHCP configuration offers. A value from 1 to 10 may be set. The default is 5
seconds.
phone-home-config:
Specifies privacy settings on the projector server during embedded Web server
access. This command controls whether statistical data on product use may be
sent to HP. For HP to collect data, Internet access is required.
2: Prompt the user to allow sending data on initial access to the Networking tab of
the embedded Web server. This is the factory-default and cold-reset value. Once
changed, this value cannot be re-selected.
1: Allows the sending of data to HP without prompting the user.
0: Disables sending data to HP without prompting the user.
web-refresh:
Specifies the time interval (1 – 99999 seconds) for embedded Web server
diagnostic page updates. If set to 0, the refresh rate is disabled.
ENWW TCP/IP Configuration 29
Table 3.3 TFTP Configuration File Parameters (6 of 7)
SNMP
snmp-config:
Enables or disables SNMP operation on the projector server. 0 disables, 1 (default)
enables SNMP.
CAUTION: Disabling SNMP will disable all SNMP agents (SNMP v1, v2, v3) as
well as communications with HP Web Jetadmin. In addition, firmware upgrades
through current HP downloading utilities will be disabled.
get-cmnty-name:
(get-community-name:)
Specifies a password that determines which SNMP GetRequests the HP Jetdirect
projector server will respond to. This is optional. If a user-specified get community
name is set, the server will respond to either a user-specified community name or
the factory-default. The community name must be ASCII characters. The
maximum length is 255 characters.
set-cmnty-name:
(set-community-name:)
Specifies a password that determines which SNMP SetRequests (control
functions) the HP Jetdirect projector server will respond to. The community name
of an incoming SNMP SetRequest must match the server’s “set community name”
for the server to respond. (For additional security, you may limit configuration
access through the server’s host access list). Community names must be ASCII
characters. The maximum length is 255 characters.
auth-trap:
(authentication-trap:)
Configures the projector server to send (on) or not send (off) SNMP authentication
traps. Authentication traps indicate that an SNMP request was received, but the
community name check failed. The default is “on.”
trap-dest:
(trap-destination:)
Enters a host’s IP address into the HP Jetdirect projector server’s SNMP trap
destination list. The command format is:
trap-dest: ip-address [community name] [port number]
The default community name is “public”; the default SNMP port number is “162”.
The port number cannot be specified without a community name.
If a “trap-community-name” command is followed by “trap-dest” commands, the
trap community name will be assigned to those entries unless a different
community name is specified in each “trap-dest” command.
To delete the table, use “trap-dest: 0”.
If the list is empty, the server does not send SNMP traps. The list may contain up
to three entries. The default SNMP Trap Destination List is empty. To receive
SNMP traps, the systems listed on the SNMP trap destination list must have a trap
daemon to listen to those traps.
ENWW TCP/IP Configuration 30
Table 3.3 TFTP Configuration File Parameters (7 of 7)
Other Settings
link-type:
(10/100 Fast Ethernet) Sets the projector server’s link speed (10 or 100 Mbps) and
communication mode (Full- or Half-Duplex). Selections are AUTO, 100FULL,
100HALF, 10FULL, 10HALF.
For AUTO (default), the server uses autonegotiation to determine the link speed
and mode. If autonegotiation fails, then 100HALF is set.
upgrade:
To configure one or more Jetdirect projector servers with the name and location
of a firmware upgrade file.
CAUTION: Ensure that command parameters are properly entered and that the
upgrade file is a higher version than the currently installed version. The server will
attempt to upgrade when the upgrade file contains a higher version than the
installed version.
The command format is:
upgrade: <TFTP server IP> <Version> <Product Number> <Filename>
where,
TFTP Server IP is the IP address of the TFTP server,
Version specifies the firmware version of the upgrade file,
Product Number specifies and must match the product number of the server,
Filename is the path and filename of the firmware upgrade file.
Support
support-name:
(support-contact:)
Typically used to identify the name of a person to contact for support of this device.
support-number:
Typically used to specify a phone number or extension to call for support of this
device.
support-url:
A Web URL for product information on this device over the Internet or an intranet.
tech-support-url:
A Web URL for technical support over the Internet or an intranet.
ENWW TCP/IP Configuration 31
Using DHCP
Dynamic Host Configuration Protocol (DHCP, RFC 2131/2132) is one of
several auto configuration mechanisms that the HP Jetdirect projector server
uses. If you have a DHCP server on your network, the HP Jetdirect projector
server automatically obtains its IP address from that server and registers its
name with any RFC 1001 and 1002-compliant dynamic name services as long
as a WINS (Windows Internet Naming Service) server IP address has been
specified.
A TFTP (Trivial File Transfer Protocol) configu r ation file may also be used
with DHCP to configure extended parameters. For more information on TFTP
parameters, see “U
Note DHCP services must be available on the server. Refer to
Note If the Jetdirect projector server and BOOTP/DHCP server
sing BOOTP/TFTP.”
your system documentation or online help to install or
enable DHCP services.
are located on different subnets, IP configuration may fail
unless the routing device allows the transfer of DHCP
requests between subnets.
ENWW TCP/IP Configuration 32
UNIX Systems
For more information on setting up DHCP on UNIX systems, see the bootpd
man page.
On HP-UX systems, a sample DHCP configuration file (dhcptab) may be
located in the /etc directory.
Since HP-UX presently does not provide Dynamic Domain Name Services
(DDNS) for its DHCP implementations, HP recommends that you set all
projector server lease durations to “infinite”. This ensures that server IP
addresses remain static until dynamic domain name services are provided.
Windows Systems
HP Jetdirect projector servers support IP configuration from a supported
Windows DHCP server. This section describes how to set up a pool, or
“scope,” of IP addresses that the Windows server can assign or lease to any
requester. When configured for BOOTP or DHCP operation and powered on,
the HP Jetdirect projector server automatically sends a BOOTP or DHCP
request for its IP configuration. If properly set up, a Windows DHCP server
will respond with the projector server’s IP configuration data.
Note This information is provided as an overview. For specific
information or for additional support, see the information
supplied with your DHCP server software.
Note To avoid problems resulting from IP addresses that change,
HP recommends that all projectors be assigned IP addresses
with infinite leases or reserved IP addresses.
ENWW TCP/IP Configuration 33
Windows NT 4.0 Server
To set up a DHCP scope on a Windows NT 4.0 server, perform the following
steps:
1. At the Windows NT server, open the Program Manager window and
double-click the Network Administrator icon.
2. Double-click the DHCP Manager icon to open this window.
3. Select Server and select Server Add.
4. Type the server IP address, then click OK to return to the DHCP Manager
window.
5. In the list of DHCP servers, click on the server you have just added, then
select Scope and select Create.
6. Select Set up the IP Address Pool. In the IP Address Pool section, set
up the IP address range by typing the beginning IP address in the Start
Address box and the ending IP address in the End Address box. Also type
the subnet mask for the subnet to which the IP address pool applies.
The starting and ending IP addresses define the end points of the address
pool assigned to this scope.
Note If desired, you can exclude ranges of IP addresses within a
scope.
7. In the Lease Duration section, select Unlimited, then select OK.
HP recommends that all projectors be assigned infinite leases to avoid
problems resulting from IP addresses that change. Be aware, however,
that selecting an unlimited lease duration for the scope causes all clients
in that scope to have infinite leases.
If you want clients on your network to have finite leases, you can set the
duration to a finite time, but you should configure all projectors as
reserved clients for the scope.
ENWW TCP/IP Configuration 34
8. Skip this step if you have assigned unlimited leases in the previous step.
Otherwise, select Scope and select Add Reservations to set up your
projectors as reserved clients. For each projector, perform the following
steps in the Add Reserved Clients window to set up a reservation for that
projector:
a. Type the selected IP address.
b. Obtain the MAC address or hardware address from the label on the
server, embedded web server, or on-screen Help menu, and type this
address in the Unique Identifier box.
c. Type the client name (any name is acceptable).
d. Select Add to add the reserved client. To delete a reservation, in the
DHCP Manager window, select Scope and select Active Leases.
In the Active Leases window, click on the reservation you want to
delete and select Delete.
9. Select Close to return to the DHCP Manager window.
10. Skip this step if you are not planning to use WINS (Windows Internet
Naming Service). Otherwise perform the following steps when
configuring your DHCP server:
a. From the DHCP Manager window, select DHCP Options and
select one of the following:
Scope — if you want Name Services only for the selected scope.
Global — if you want Name Services for all scopes.
b. Add the server to the Active Options list. From the DHCP Options
window, select WINS/NBNS Servers (044) from the Unused
Options list. Select Add, then select OK.
A warning may appear requesting that you set the node type. You
do this in step 10d.
ENWW TCP/IP Configuration 35
c. You must now provide the IP address of the WINS server by doing
the following:
● Select Value, then Edit Array.
● From the IP Address Array Editor, select Remove to delete any
undesired addresses previously set. Then type in the IP address
of the WINS server and select Add.
● Once the address appears in the list of IP addresses, select OK.
This returns you to the DHCP Options window. If the address
you have just added appears in the list of IP addresses (near the
bottom of the window) return to step 10d. Otherwise, repeat step
10c.
d. In the DHCP Options window, select WINS/NBT Node Type
(046) from the Unused Options list. Select Add to add the node
type to the Active Options list. In the Byte box, type 0x4 to indicate
a mixed node, and select OK.
11. Click Close to exit to Program Manager.
Windows 2000 Server/Server 2003
To set up a DHCP scope on a Windows 2000 server or Server 2003 system,
perform the following steps:
1. Run the Windows DHCP manager utility.
■ Windows 2000: Click Start, then select Settings and Control Panel.
Open the Administrative Tools folder and run the DHCP utility.
■ Server 2003: Click Start, then select Control Panel. Open the
Administrative Tools folder and run the DHCP utility.
2. In the DHCP window, locate and select your Windows server in the
DHCP tree.
If your server is not listed in the tree, select DHCP and click the Action
menu to add the server.
3. After selecting your server in the DHCP tree, click the Action menu and
select New Scope. This runs the Add New Scope Wizard.
4. In the Add New Scope Wizard, click Next.
5. Enter a Name and Description for this scope, then click Next.
ENWW TCP/IP Configuration 36
6. Enter the range of IP addresses for this scope (beginning IP address and
ending IP address). Also, enter the subnet mask. then click Next.
Note If subnetting is used, t he subnet mask defines which port ion
of an IP address specifies the subnet and which portion
specifies the client device. For more information, see
Appendix A
.
7. If applicable, enter the range of IP addresses within the scope to be
excluded by the server. Then click Next.
8. Set the IP address lease duration for your DHCP clients. Then click Next.
HP recommends that all projectors be assigned reserved IP addresses.
This can be accomplished after you set up the scope (see step 11
).
9. Select No to configure DHCP options for this scope later. Then click Next.
To configure DHCP options now, select Yes and click Next.
a. If desired, specify the IP address of the router (or default gateway)
to be used by clients. Then click Next.
b. If desired, specify the Domain Name and DNS (Domain Name
System) servers for clients. Click Next.
c. If desired, specify WINS server names and IP addresses. Click Next.
d. Select Yes to activate the DHCP options now, and click Next.
10. You have successfully set up the DHCP scope on this server. Click Finish
to close the wizard.
ENWW TCP/IP Configuration 37
11. Configure your projector with a reserved IP address within the DHCP
scope:
a. In the DHCP tree, open the folder for your scope and select
Reservations.
b. Click the Action menu and select New Reservation.
c. Enter the appropriate information in each field, including the
reserved IP address for your projector. (Note: the MAC address for
your HP Jetdirect-connected projector is available on the label on
the server, embedded web server, or on-screen Help menu.)
d. Under “Supported types”, select DHCP only, then click Add.
(Note: Selecting Both or BOOTP only will result in a configuration
through BOOTP due to the sequence in which HP Jetdirect projector
servers initiate configuration protocol requests.)
e. Specify another reserved client, or click Close. The reserved clients
added will be displayed in the Reservations folder for this scope.
12. Close the DHCP manager utility.
To Discontinue DHCP Configuration
CAUTION Changes to an IP address on your HP Jetdirect projector
server may require updates to device or system
configurations for clients or servers.
If you do not want your HP Jetdirect projector server configured through
DHCP, you must reconfigure the server to use a different configuration
method.
● You can manually modify the TCP/IP parameters through a supported
Web browser using the Jetdirect embedded Web server or HP Web
Jetadmin.
If you change to BOOTP configuration, the DHCP-configured parameters are
released and the TCP/IP protocol is initialized.
ENWW TCP/IP Configuration 38
If you change to Manual configuration, the DHCP-configured IP address is
released and the user-specified IP parameters are used. Therefore, if you
manually provide the IP address, you should also manually set all of the
configuration parameters, such as subnet mask, default gateway, and
idle timeout.
Note If you choose to re-enable a DHCP configuration, the
projector server will acquire its configuration information
from a DHCP server. This means that when you choose
DHCP and complete your configuration session, the TCP/IP
protocol for the projector server is re-initialized and all
current configuration information is deleted. The projector
server then attempts to acquire new configuration
information by sending DHCP requests on the network to a
DHCP server.
ENWW TCP/IP Configuration 39
Using RARP
This section describes how to configure the projector server using the Reverse
Address Resolution Protocol (RARP) on UNIX and Linux systems.
This setup procedure enables the RARP daemon running on your system to
respond to a RARP request from the HP Jetdirect projector server and to
supply the IP address to the server.
1. Turn the projector off.
2. Log onto your UNIX or Linux system as a superuser.
3. Make sure the RA RP daem on is running on your system by typing the
following command at the system prompt:
ps -ef | grep rarpd (Unix)
ps ax | grep rarpd (BSD or Linux)
4. The system response should be simil ar to the following:
861 0.00.2 24 72 5 14:03 0:00 rarpd -a
860 0.00.5 36 140 5 14:03 0:00 rarpd -a
5. If the system does not display a process number for the RARP daemon,
see the rarpd man page for instructions on starting the RARP daemon.
6. Edit the /etc/hosts file to add your designated IP address and node
name for the HP Jetdirect projector server. For example:
192.168.45.39 projector1
7. Edit the /etc/ethers file (/etc/rarpd.conf file in
HP-UX 10.20) to add the LAN hardware address/station address (from
the label on the server, embedded web server, or on-screen Help menu)
and the node name for the HP Jetdirect projector server. For example:
00:01:E6:a8:b0:00 projector1
ENWW TCP/IP Configuration 40
Note If your system uses Network Information Service (NIS),
you need to incorporate changes to the NIS host and ethers
databases.
8. Turn the projector on.
9. To verify that the card is configured with the correct IP address, use the
ping utility. At the prompt, type:
ping <IP address>
where <IP address> is the assigned address from RARP.
10. If ping does not respond, see Chapter 6
.
ENWW TCP/IP Configuration 41
Using the arp and ping Commands
You can configure an HP Jetdirect projector server with an IP address using
an ARP (Address Resolution Protocol) command from a supported system.
The protocol is not routable, that is, the workstation from which the
configuration is made must be located on the same network segment as the
HP Jetdirect projector server.
Using the arp and ping commands with HP Jetdirect projector servers requires
the following:
● Windows NT/2000/XP/Server 2003 or UNIX system configured for
TCP/IP operation
● A legacy default IP address 192.0.0.192 has been set on the projector
server
● The LAN hardware (MAC) address of the HP Jetdirect projector server
(specified on the label on the server, embedded web server, or on-screen
Help menu)
Note On some systems, superuser rights may be required for the
arp command.
After an IP address is assigned through arp and ping commands, use other
tools (such as embedded Web server or HP Web Jetadmin software) to
configure other IP parameters.
To configure a Jetdirect projector server, use the following commands:
arp -s <IP address> <LAN hardware address>
ping <IP address>
where <IP address> is the desired IP address to be assigned to the
projector server. The arp command writes the entries to the arp cache on the
workstation, and the ping command configures the IP address on the server.
ENWW TCP/IP Configuration 42
Depending on the system, the LAN hardware address may require a specific
format.
For example:
● For Windows NT 4.0, 2000, XP, Server 2003
arp -s 192.168.45.39 00-01-E6-a2-31-98
ping 192.168.45.39
● For UNIX
arp -s 192.168.45.39 00:01:E6:a2:31:98
ping 192.168.45.39
Note Once the IP address has been set on the projector server,
additional arp and ping commands will be ignored. Once
the IP address is configured, arp and ping cannot be used
unless the server is reset to factory values (see Chapter6
On UNIX systems, the arp -s command may vary
between different systems.
Some BSD-based systems expect the IP address (or host
name) in reverse order. Other systems may require
additional parameters. See your system documentation for
specific command formats.
).
ENWW TCP/IP Configuration 43
Using the Embedded Web Server
You can set IP parameters on HP Jetdirect projector servers that support the
embedded Web server. For more information, refer to Chapter 4
.
Moving to Another Network
When moving an HP Jetdirect projector server that is configured with an IP
address to a new network, make sure that the IP address does not conflict with
addresses on the new network. You may change the IP address of the server
to one that can be used on the new network, or erase the current IP address
and configure another address after it is installed on the new network. See
Chapter 6
instructions to reset the server to factory default settings.
If the current BOOTP server is not reachable, you may need to locate a
different BOOTP server and configure the projector to this server.
If the server was configured using BOOTP, DHCP or RARP, edit the
appropriate system files with updated settings. If the IP address was manually
set, reconfigure IP parameters as described in this chapter.
, “Troubleshooting the HP Jetdirect Projector Server,” for
ENWW TCP/IP Configuration 44
4
Using the Embedded Web Server
Introduction
HP Jetdirect projector servers contain an embedded Web server that can be
accessed from a compatible Web browser over an intranet. The embedded
Web server provides access to configuration and management pages for the
HP Jetdirect projector server and the attached projector.
Tabs across the upper portion of your browser window provide access to
device and networking pages.
Typical Home, Networking, and Projector tabs served by the HP Jetdirect
projector server are illustrated in Figure 4.1
respectively. For more information, see “H
“N
etworking Tab,” and “Projector Tab.”
, Figure 4.2, and Figure 4.3,
P Jetdirect Home Tab,”
HP Jetdirect Home
Tab
Figure 4.1 Typical HP Jetdirect Home Tab
ENWW 45
Networking Tab
Menu items in left
margin
Figure 4.2 HP Jetdirect Networking Tab
For network parameter descriptions, see “Networking Tab”.
Projector Tab
Menu items in left
margin
Figure 4.3 Typical HP Jetdirect Projector Tab
ENWW Using the Embedded Web Server 46
Requirements
Compatible Web Browsers
To access the embedded Web server, you must use a compatible Web browser.
In general, the embedded Web server can be used with Web browsers that
support HTML 4.01 and cascading style sheets.
Hewlett-Packard tests a number of current and older browsers using a variety
of systems. In general, we recommend using the following browsers:
● Microsoft Internet Explorer 5.0 or greater
● Netscape Navigator 6.0 or greater
Browser Exceptions
Due to known problems experienced during testing, we recommend that you
do not use the following browsers:
● Netscape Navigator 6.2.x with SSL
Supported HP Web Jetadmin Version
HP Web Jetadmin is a browser-based, enterprise management tool for network
devices. It is available from HP online support at the following URL:
http://www.hp.com/go/webjetadmi
To manage digital projectors, HP Web Jetadmin version 7.8 or greater and the
HP Web Jetadmin plug-in for digital projectors are required. We recommend
using the latest version, which may provide enhanced functionality.
A link to HP Web Jetadmin will be displayed on the embedded Web server if
HP Web Jetadmin has discovered this device through an Integration URL.
Currently, browser support between HP Web Jetadmin and the embedded Web
server may differ. For supported browsers with HP Web Jetadmin, visit
http://www.hp.com/go/webjetadmin
ENWW Using the Embedded Web Server 47
n
.
Viewing the Embedded Web Server
Before you can use the embedded Web server, the HP Jetdirect projector
server must be configured with an IP address. For a description of an IP address
and an overview of TCP/IP networking, see Appendix A
There are many ways to configure an IP address on the server. For example,
you can automatically configure IP parameters over the network using
BOOTP (Bootstrap Protocol) or DHCP (Dynamic Host Configuration
Protocol) each time the server is turned on. Or, you can manually configure
IP parameters using the “arp” and “ping” commands, HP Web Jetadmin, or
other management software. For more information on TCP/IP configuration
options, see Chapter 3
When powered on, an HP Jetdirect server that is unable to retrieve a valid IP
address from the network will automatically assign itself either a legacy
default IP address 192.0.0.192 or a link-local address in the range 169.254.1.0
to 169.254.254.255. The IP address configured on your server can be
determined by inspecting the IP address shown in the projector’s on-screen
menus. See Chapter 3
If the legacy default IP address 192.0.0.192 has been assigned, you must
temporarily set up your computer with the same IP network number or
establish a route to the server before you can gain access to the embedded Web
server.
To access the embedded Web server, perform the following steps:
.
for more information.
.
1. Run a supported We b browser.
2. Enter the IP address of the projector server as the URL.
Figure 4.4 Entering the IP Address
ENWW Using the Embedded Web Server 48
3. If prompted with security alerts, click Yes to proceed.
For initial access, the embedded Web server uses standard HTTP.
However, it can be configured to appear as a secure site, using an
X.509-compliant certificate installed on the projector server for
identification. When properly configured, encrypted browser
communications through HTTPS (secure HTTP) may be used for secure
access.
Although not recommended, you can use your Internet Options menu to
configure your browser to ignore security warnings if the projector server
is configured to operate through HTTPS. See “Mgmt. Protocols
.”
4. An embedded We b server page will be di splayed.
Operating Notes
● If you enter or change a configuration parameter value, click Apply to
enable your change, or click Cancel to erase your change.
● Changes to the IP address will close the connection to the embedded Web
server. To re-establish a connection, use the new IP address.
ENWW Using the Embedded Web Server 49
HP Jetdirect Home Tab
The HP Jetdirect projector server’s product model, firmware version, and
network addresses are displayed along with any device information that can
be retrieved. Table 4.1
HP Jetdirect home page.
Table 4.1 HP Jetdirect Home Page Items (1 of 2)
Item Description
provides a summary of the items displayed on the
Home tab Provides access to server/projector information and
Networking tab Provides access to network configuration, security, and
Projector tab Provides control of projector power, selection of the input
Device Info Displays information about the projector and the Jetdirect
Select Language Appears if the HP Jetdirect Web pages support multiple
Device Displays the projector model or series.
Status Displays the projector’s power status.
Projector Serial
Number
Firmware Version The version of the operating instructions installed on the
Current Lamp Hours Displays the cumulative number of hours that the lamp has
language selection for the embedded web server.
diagnostic parameters. For more information, see
N
etworking Tab.
source, and setup of alerts for specific conditions.
server.
languages. Supported languages may also be selected
through language preference settings in your browser.
To display supported non-English languages, the use of
cookies must be enabled in your browser settings.
Displays the projector’s serial number.
HP projector.
been on.
Current Input Source Displays the input port currently selected on the projector.
The signal on this port is projected on the screen.
Host Name Specifies the IP host name assigned to the device and
stored on the HP Jetdirect projector server. See TCP/IP on
the N
etworking Tab.
ENWW Using the Embedded Web Server 50
Table 4.1 HP Jetdirect Home Page Items (2 of 2)
Item Description
System Up Time The length of time since either the HP Jetdirect projector
server or the network device was last powered off/on.
System Contact A text string (stored on the HP Jetdirect projector server)
for the name of a person to contact for this device. See
TCP/IP on the N
etworking Tab.
System Location A text string (stored on the HP Jetdirect projector server)
that identifies the physical location of this device. See the
Networking TCP/IP configuration pages.
HP Jetdirect The product number of the HP Jetdirect projector server
(for example HP L2130A).
Firmware Version The versions of the operating instructions installed on the
HP Jetdirect projector server.
IP Address The Internet Protocol address configured on the
HP Jetdirect projector server. For general information on
IP addresses, see Appendix A
.
Hardware Address The LAN hardware (or MAC, Media Access Control)
address of the HP Jetdirect projector server. This unique
address is assigned by Hewlett-Packard, but can be locally
administered.
LAA A Locally Administered Address (LAA) that replaces the
LAN Hardware (MAC) address. The LAA may be
configured under local control by a network administrator.
By default, the LAA is the factory-assigned LAN Hardware
address.
Admin Password Specifies whether or not an administrator password has
been set. This password may also be configured from HP
Web Jetadmin.
Use the Admin Password page to set or clear
administrator passwords.
If an administrator password has been set, you will be
prompted for a User Name and Password to access
network parameters. For more information, see “Admin.
Account.”
ENWW Using the Embedded Web Server 51
Networking Tab
The Networking tab provides access to HP Jetdirect network configuration
parameters and status. The menu items in the left margin provide access to
configuration and status pages.
Table 4.2 Networking Menu Items
CONFIGURATION section
● Network Settings
● Other Settings
SECURITY section
● Settings
● Authorization
DIAGNOSTICS section
● Network Statistics Protocol Info
● Privacy Settings
● Select Language
● Mgmt. Protocols
● 802.1x Authentication
Sending Product Information to HP
The first time that you access the Networking tab in the embedded Web
server, you will be prompted to allow the sending of product information to
HP using the Internet. Product id entif ication and usage da ta collected by HP
will be used to improve product features and services. Personal data is not
collected in accordance with HP privacy policies. See the Hewlett-Packard
Online Privacy Statement.
If you choose to decline by pressing No, a log entry to record this choice may
be sent to HP. To prevent HP from making a log entry that data collection was
refused, do one of the following:
● Disable access to the Internet before pressing No.
You can disable Internet access on your browser, for example, by disabling
the Web Proxy server. After pressing No, simply re-enable Internet access.
● Use an SNMP management utility or an SNMP command line utility to
disable this functionality before pressing No. The object identifier (OID)
is .1.3.6.1.4.1.11.2.4.3.7.31.0 and needs to be set to zero (0).
You can choose to enable or disable this feature at any time using the Privacy
Settings page under the Networking tab.
ENWW Using the Embedded Web Server 52
Network Settings
The Network Settings pages allow you to set or change configuration
parameters for T
enter the desired value and click Apply.
TCP/IP
The TCP/IP page provides configuration parameters summarized in
Table 4.3
Table 4.3 TCP/IP Settings (1 of 3)
Item Description
CP/IP and SNMP protocols. To assign a parameter setting,
.
IP Configuration
Method
Host Name Specifies a readable IP name (the SNMP SysName object) for
IP Address Use this field to manually assign the Internet Protocol address on
Subnet Mask If subnetting is used, use this field to manually assign a subnet
Selects the method that the HP Jetdirect projector server will use
for its IP configuration parameters: BOOTP (default), DHCP,
Manual, or Auto IP.
For BOOTP or DHCP, the IP parameters will be automatically
configured by a BOOTP or DHCP server each time the projector
server is powered on.
If you select Manual, then basic IP parameters can be manually
entered using this Web page, or using other available tools.
If you select Auto IP, then a unique link-local address 169.254.x.x
will be assigned.
For more information, see Chapter 3
the network device. The name must start with a letter and can
end in a letter or number, up to 32 ASCII characters. The default
name is NPIxxxxxx, where xxxxxx is the last six digits of the LAN
hardware (MAC) address.
the HP Jetdirect projector server. The IP address is a four byte
(32-bit) address in the form “n.n.n.n”, where ‘n’ is a number from
0 to 255.
An IP address uniquely identifies a node on a TCP/IP network.
Duplicate IP addresses on a TCP/IP network are not allowed. For
more information on IP addresses, see Appendix A
mask. A subnet mask is a 32-bit number that, when applied to an
IP address, determines which bits specify the network and
subnet, and which bits uniquely specify the node.
For more information on subnet masks, see Appendix A
.
.
.
ENWW Using the Embedded Web Server 53
Table 4.3 TCP/IP Settings (2 of 3)
Item Description
Default Gateway Identifies the IP address of a router or computer that is used to
connect to other networks or subnetworks.
Domain Name Specifies the name of the Domain Name System (DNS) domain
that the HP Jetdirect projector server resides in (for example,
support.hp.com). It does not include the host name; it is not the
Fully Qualified Domain Name (such as
projector1.support.hp.com).
Primary WINS
Server
Specifies the IP address of the primary Windows Internet Naming
Service (WINS) server. The WINS server provides IP address
and name resolution services for network computers and devices.
Secondary WINS
Server
Specifies the IP Address to be used for WINS if the primary WINS
Server is unavailable.
Syslog Server Specifies the IP address of a host computer that is configured to
receive syslog messages from the HP Jetdirect projector server.
If a Syslog Server is not specified, syslog messages are disabled.
Syslog Maximum
Messages
For more information, see Appendix A
Specifies the maximum number of syslog messages that can be
sent by the HP Jetdirect projector server on a per-minute basis.
.
This setting allows administrators to control the log file size. The
default is 10 per minute. If set to zero, no maximum number is
defined.
Syslog Priority Controls the filtering of syslog messages that are sent to the
syslog server. The filter range is 0 to 8, with 0 being the most
specific and 8 being the most general. Only messages that are
lower than the filter level specified (that is, higher in priority) are
reported. The default value is 8 which reports all syslog
messages. A value of zero effectively disables syslog reporting.
Idle Timeout Specifies the number of seconds that an idle connection is
allowed to remain open. Up to 3600 seconds can be set. 270 is
the default value. If set to 0, the timeout is disabled and TCP/IP
connections will remain open until closed by the device at the
other end of the network (for example, a workstation).
ENWW Using the Embedded Web Server 54
Table 4.3 TCP/IP Settings (3 of 3)
Item Description
TTL/SLP Specifies the IP multicast Time To Live (TTL) discovery setting
for Service Location Protocol (SLP) packets. The default value is
4 hops (the number of routers from the local network). The range
is 1-15. If set to -1, multicast capability is disabled.
For projector servers configured for Auto IP (link-local)
addresses, this field will be ignored. TTL on outbound packets
will always be set to 255 and limited to the link-local network.
System Contact Identifies a person who is assigned to administer or service this
device. This field may include a phone number or similar
information.
When configured, this parameter will be displayed on the
HP Jetdirect home page.
System Location Specifies the physical location of the device or related
information. Only printable ASCII characters are allowed, up to 64
characters.
When configured, this parameter will be displayed on the
HP Jetdirect home page.
Default IP Specifies the IP address to use when the projector server is
unable to obtain an IP address from the network during a forced
TCP/IP reconfiguration (for example, when manually configured
to use BOOTP/DHCP).
LEGACY DEFAULT_IP: sets the legacy default IP address
192.0.0.192.
AUTO_IP: sets a link-local IP address 169.254.x.x.
The initial setting is determined by the IP address obtained when
first powered on.
Send DHCP
requests
A checkbox is used to specify whether DHCP requests will be
periodically transmitted when a legacy default IP address
192.0.0.192 or link-local IP address 169.254.x.x has been
automatically assigned.
Clear the checkbox to disable DHCP requests.
Check the checkbox (default) to enable DHCP requests.
ENWW Using the Embedded Web Server 55
SNMP
You can specify or change the SNMP (Simple Network Management
Protocol) parameters provided. See Table 4.4
.
CAUTION If you use HP Web Jetadmin to manage your devices, you
should use HP Web Jetadmin to seamlessly configure
SNMP v3 and other security settings on the projector server.
Using the embedded Web server to create the SNMP v3
account will erase any existing SNMP v3 accounts. In
addition, the SNMP v3 account information will need to be
implemented on the SNMP management application. For
more information, see “SNMP v3
Table 4.4 SNMP Settings (1 of 2)
Item Description
.”
Enable SNMPv1/v2
read-write access
Enable SNMPv1/v2
read-only access
This option enables the SNMP v1/v2c agents on the
projector server. Custom community names can be
configured to control management access to the server.
An SNMP Set Community Name is a password to be able
to configure (or “write”) SNMP information on the
HP Jetdirect projector server.
An SNMP Get Community Name is a password to retrieve
(or “read”) SNMP information on the HP Jetdirect projector
server.
An incoming SNMP SetRequest or GetRequest command
must contain the appropriate Set or Get community name
before the server will respond.
A community name must be ASCII characters and can be
up to 255 characters long.
The default Get community name is “public”, which can be
disabled to restrict access by checking the checkbox
provided.
Note: If “public” is disabled, some discovery utilities
may not operate properly.
This option enables the SNMP v1/v2c agents on the
projector server, but limits access to read-only.
Write-access is disabled. The default Get community name
“public” is automatically enabled.
ENWW Using the Embedded Web Server 56
Table 4.4 SNMP Settings (2 of 2)
Item Description
Disable SNMPv1/v2 This option disables the SNMP v1/v2c agents on the
Enable SNMPv3 This option enables (check) or disables (clear) the SNMP
projector server, which is recommended for secure
environments. If SNMP v1/v2c is disabled, some discovery
utilities may not operate properly.
v3 agent on the projector server.
When enabled, an SNMP v3 account must be created on
the server, and the account information must be
implemented on the SNMP v3 management application.
You may create an account by providing the following
information:
User Name: the SNMP v3 account user name.
Authentication Key: a 16-byte hexadecimal value for
authenticating the SNMP packet contents using the
Message Digest Algorithm 5 (MD5, RFC 1321).
Privacy Key: a 16-byte hexadecimal value for encrypting
the data portion of the SNMP packet using the Data
Encryption Standard (DES) algorithm.
Context Name: the view context in which this user can
access SNMP objects. It is always “Jetdirect”.
Other Settings
This item provides access to a variety of management and configuration
options. The following tabs are provided:
● Misc. Settings: for enabling miscellaneous advanced protocols and
functions
● Firmware Upgrade: to update your HP Jetdirect projector server with new
features and enhancements
● Support Info: to set up the Support link located under Other Links in the
left margin
● Refresh Rate: to set the time interval (in seconds) for embedded Web
diagnostic page updates
ENWW Using the Embedded Web Server 57
Misc. Settings
The Miscellaneous Settings parameters allow you to set a variety of advanced
protocols and features, as described below. See Table 4.5
Table 4.5 Miscellaneous Settings (1 of 2)
Item Description
SLP Config Enable or disable SLP (Service Location Protocol), used by
selected client application software to automatically discover and
identify the HP Jetdirect projector server.
Multicast IPv4 Enable or disable the receipt and transmission of IP version 4
multicast packets by the projector server.
NOTE: If this parameter is disabled, other protocols that use
multicast protocols, such as SLP, may also be disabled
without notification.
.
Link settings (For wired 10/100TX networks only) Set the network link
speed(10 or 100 Mbps) and communication mode (full- or
half-duplex) for HP Jetdirect projector servers. The available
settings are listed below.
CAUTION: If you change the link setting, network
communications with the server and network device may be
lost.
● AUTO: (Default) The server uses autonegotiation to match
the network’s link speed and communication mode. If
autonegotiation fails, 100TXHALF is set.
● 10TXFULL: 10 Mbps, full-duplex operation
● 10TXHALF: 10 Mbps, half-duplex operation
● 100TXFULL: 100 Mbps, full-duplex operation
● 100TXHALF: 100 Mbps, half-duplex operation
Primary DNS
Server
Secondary DNS
Server
Locally
Administered
Address
Specify the IP address of the primary DNS (Domain Name
System) server.
Specify the IP address of a secondary DNS server to use if the
primary DNS server is unavailable.
Specifies a locally administered address (LAA) that replaces the
factory-assigned LAN Hardware (MAC) address. If LAA is used,
a user-specified string of exactly 12 hexadecimal digits must be
entered.
The LAA address must start with hexadecimal X2, X6, XA, or XE,
where X is any hexadecimal digit 0 through F.
The default address is the factory assigned address.
ENWW Using the Embedded Web Server 58
Table 4.5 Miscellaneous Settings (2 of 2)
Item Description
Syslog Facility Specify the encoded source facility of a message (for example,
to identify the source of selected messages during
troubleshooting). By default, the HP Jetdirect projector server
uses local user values of local0 through local7 to isolate individual
or groups of projector servers.
Firmware Upgrade
This page allows you to upgrade the projector server with new features.
The firmware upgrade file for the server must be available on your system.
To identify and retrieve the appropriate upgrade file, visit HP online support at:
h
ttp://www.hp.com/go/proj_firmware
On that page, do the following:
1. Locate the projector server model and the upgrade file.
2. Check the upgrade file version and verify that it is more recent than the
server’s installed version. If it is, then download the file. If not, then you
do not need to upgrade.
To upgrade the projector server using the embedded Web server:
1. Enter the path to the upgrade file or click Browse to locate it.
2. Then click Upgrade Firmware.
Support Info
Use this page to configure links for Support assistance. You can designate a
Support person and phone number of an administrator for this device, as well
as URL addresses for Web-based product and technical support.
Refresh Rate
The refresh rate is the time period (in seconds) that the diagnostic pages will
be automatically updated. The value ‘0’ disables the refresh rate.
ENWW Using the Embedded Web Server 59
Privacy Settings
On the Privacy Settings page, you can allow the embedded Web server to
collect product identification and use information and then send the
information to HP (Internet access is required). Product use information assists
HP in improving product features and services. The default setting for this
page will depend on the user’s selection on initial access to the Networking tab.
To enable this feature, check the checkbox and click Apply.
To disable this feature, clear the checkbox and click Apply.
Select Language
This link appears if the HP Jetdirect Web pages support multiple languages.
Supported languages may also be selected through language preference
settings in your browser (see your browser’s Help).
To display supported non-English languages, the use of cookies must be
enabled in your browser settings.
Settings
In the SECURITY section, the Settings menu provides access to the
following tabs: Status (default), Wizard, Rest ore Defaults.
Status
The Status page displays the current security configuration settings of the
server.
ENWW Using the Embedded Web Server 60
Wizard
Note If you use HP Web Jetadmin to manage your devices, you
should not use this wizard. Instead, use HP Web Jetadmin
to configure your network security settings to ensure they
are properly set for your network.
The Wizard page allows you to run the HP Jetdirect Security Configuration
Wizard. This wizard will guide you through the projector server’s security
configuration needed for your network. Click Start Wizard to run the wizard.
This opens the Security Level page.
The optional configuration parameters presented by the wizard will depend
on your choice of security level. For an overview, see Table 4.6
.
Note If you improperly exit the wizard (for example, by failing
to use the Cancel button), an Operation Failed screen may
appear. If so, wait approximately two minutes before
entering the wizard again.
Restore Defaults
This page is used to restore security configuration settings to factory defaults.
The default settings displayed depend on the features supported by the
projector server.
Only the security settings listed are restored to factory defaults, other
configuration settings are not affected.
ENWW Using the Embedded Web Server 61
Table 4.6 Wizard Security Levels (1 of 2)
Security Level Description
Basic Security This option requires that you configure an administrator
password for configuration management. The administrator
password is shared with other management tools, such as
SNMP applications. However, some management tools use
plain-text communications and are not secure.
The Administrator Account page is used to enter the
administrator password. The Administrator Password will
also be used as the SNMP v1/v2 Set Community Name for
SNMP management applications.
The Configuration Review page displays all the current
settings that may affect security. Click Finish to set your
basic security selections.
Enhanced Security
(Recommended)
This option adds to Basic Security by automatically
disabling management protocols that are do not use secure,
encrypted communications (such as FTP firmware updates,
RCFG, SNMP v1/v2c). To change individual protocol
settings, see “Mgmt. Protocols
.”
The Administrator Account page is used to enter the
administrator password.
SNMP Configuration pages are used to configure specific
SNMP settings:
● Enable SNMPv3: Enable SNMP v3 and create an SNMP
v3 account. Creating an SNMP v3 account is not
recommended if you manage devices using HP Web
Jetadmin. See “S
● Enable SNMPv1/v2 read-only access: Enable this
NMP.”
option to allow support of current tools that rely on SNMP
v1/v2 for device discovery and status.
The Configuration Review page displays all the current
settings that may affect security. Click Finish to set your
basic security selections.
ENWW Using the Embedded Web Server 62
Table 4.6 Wizard Security Levels (2 of 2)
Security Level Description
Custom Security This option proceeds through all available security settings
supported by your projector server. For more information on
specific parameters and selections, see the tabs on the
802.1x Authentication
Authorization
menu pages under SECURITY.
, Mgmt. Protocols, and
The Administrator Account page is used to enter the
administrator password.
The Web Mgmt. page is used for HTTPS (secure HTTP)
configuration, including certificates and encryption levels.
The Management Tools page allows configuration of
management protocols that are not secure (such as FTP
firmware updates).
SNMP Configuration pages are used to configure specific
SNMP settings:
● Enable SNMPv1/v2: Enable this option to allow
management software that use SNMP v1/v2. If selected
the SNMPv1/v2 Configuration page is displayed to
configure SNMP community names.
● Enable SNMPv3: Enable this option to create an SNMP
v3 account. Creating an SNMP v3 account is not
recommended if you manage devices using HP Web
Jetadmin. See S
NMP.
The Access Control page is used to set up an Access
Control List, if desired to control host access to the device.
The Protocols and Services page is used to enable or
disable network services, and device discovery protocols
that may affect security.
The 802.1x Authentication page configures the server as
required for client authentication on your network.
The Configuration Review page displays all the current
settings that may affect security. Click Finish to set your
basic security selections.
ENWW Using the Embedded Web Server 63
Authorization
The Authorization page provides tabs that allow you to control access to the
device, as well as to device configuration and management features. In
addition, you may configure certificates for client and server authentication.
Admin. Account
Use this page to set an administrator password for controlled access to Jetdirect
configuration and status information. The administ rator password is shared
by Jetdirect configuration tools, such as the embedded Web server and HP
Web Jetadmin.
If a password is set and you attempt to access Jetdirect projector server
settings, you will be prompted for a user name and this password before you
are allowed access.
Note The administrator password may be cleared by a cold reset
of the projector server, which resets the server to factory
default settings.
A checkbox allows you to synchronize HP Web Jetadmin and the SNMP
v1/v2c Set Community Name.If you enable this feature (the checkbox is
checked), the administrator password will also be used as the SNMP Set
Community Name for SNMP v1/v2c management applications.
Note If you subsequently change the SNMP Set Community
Name (for example, using the SNMP tab on the Network
Settings page or from Web Jetadmin), the two settings will
no longer be synchronized.
ENWW Using the Embedded Web Server 64
Certificates
This tab provides access to installation, configuration and management
services for X.509 digital certificates. A digital certificate is an electronic
message typically containing, among other things, a key (a short string used
for encryption and decryption) and a digital signature. Certificates may be
issued and signed by a trusted third party (commonly called a Certificate
Authority, or CA), which may exist internal or external to the organization.
Or certificates may be “self-signed”, which is similar to validating your own
identity.
Note While self-signed certificates are permitted and allow data
encryption, they do not ensure valid authentication.
The Certificates page provides the status of the certificates installed on the
HP Jetdirect projector server:
● Jetdirect certificate. The Jetdirect certificate is used to validate the
identity of the Jetdirect device to clients and to network authentication
servers.
By factory default, a self-signed Jetdirect certificate is preinstalled. This
allows the embedded Web server to use HTTPS and appear as a secure site
when accessed by a Web browser.
Click View to view the contents of an installed Jetdirect certificate, or click
Configure to update or install a new one. See “Configuring Certificates
.”
When installed, a Jetdirect certificate will be saved across a cold-reset,
which is used to restore the projector server to factory-default values.
● CA Certificate. A certificate from a trusted third party, or Certificate
Authority (CA), is used to validate the identity of a network authentication
server during 802.1X authentication methods that use EAP (Extensible
Authentication Protocol). The authentication server’s identity is validated
when information on the CA certificate matches the information on a
certificate received from the authentication server.
A CA certificate for the projector server is a certificate that was used to
sign the authentication server’s certificate. Therefore, the Certificate
Authority for the authentication server’s certificate must also be used for
the CA certificate.
ENWW Using the Embedded Web Server 65
Click View to view the contents of an installed Jetdirect certificate, or click
Configure to update or install a new one. See “Configuring Certificates
.”
A CA certificate is not saved when the projector server is reset to
factory-default values.
The maximum certificate size that can be installed on the HP Jetdirect
projector server is 3072 bytes.
Configuring Certificates
When you click Configure, a certificate management wizard will help you
update or install a certificate. The screens displayed will depend on the type
of certificate (Jetdirect or CA) and your selections. Table 4.7
provides a
description of the screens and configuration parameters that may appear.
Note If you improperly exit Certificates configuration (for
example, by failing to use the Cancel button), an Operation
Failed screen may appear. If so, wait approximately two
minutes before entering the wizard again.
Table 4.7 Certificate Configuration Screens (1 of 4)
Certificate Options
Choose from the options listed.
Update Pre-Installed Certificate. Use this option to update the preinstalled,
self-signed certificate. When updated, the preinstalled certificate is
overwritten.You may update the following item:
● Certificate Validity Period
With self-signed certificates, the browser will identify the certificate as self-signed
for each new Web session and may cause a security alert message. This
message can be bypassed if the user adds it to their browser’s certificate store
or disables browser alerts (not recommended).
Self-signed certificates are not necessarily secure because the certificate owner
is merely confirming his own identity instead of verification by a trusted third party.
Certificates from a trusted third party are considered more secure.
ENWW Using the Embedded Web Server 66
Table 4.7 Certificate Configuration Screens (2 of 4)
Create Certificate Request. Using this option, you are prompted for specific
device and organizational information in the following screen:
● Certificate Information
This option may be used, for example, when an authentication protocol requires
that a Jetdirect certificate issued by a trusted third party or Certificate Authority
be installed.
Install Certificate. This option is displayed only if there is a Jetdirect certificate
request (to a trusted third party) pending. When received, the certificate is installed
using this option. Once installed, this certificate overwrites the preinstalled
certificate.
Using this option, you are prompted for information in the following screen:
● Install Certificate
The certificate to be installed must be associated with a previous certificate
request generated by the embedded Web server.
Install CA Certificate. This option is provided when you click Configure for a
CA certificate, which must be installed for selected authentication protocols. Using
this option, you are prompted for information in the following screen:
● Install Certificate
Import Certificate and Private Key. This option allows you to import a previously
acquired and known certificate as the Jetdirect certificate. If you import a
certificate, the currently installed certificate will be overwritten. Using this option,
you are prompted by the following screen:
● Import Certificate and Private Key
Export Certificate and Private Key. This option allows you to export the Jetdirect
certificate currently installed on the projector server for use on other projector
servers. Using this option, you are prompted by the following screen:
● Export the Jetdirect certificate and private key
Delete CA Certificate. This option is used to remove the CA certificate installed
on the Jetdirect projector server. This option appears when a CA certificate for
EAP authentication has been installed.
CAUTION: If the CA Certificate is deleted, EAP authentication will be disabled
and network access will be denied.
The CA Certificate will also be removed on a cold-reset of the server, where
factory-default settings are restored.
ENWW Using the Embedded Web Server 67
Table 4.7 Certificate Configuration Screens (3 of 4)
Certificate Validity
Use this screen to specify how long the Jetdirect self-signed certificate will be valid.
This screen appears only when a self-signed certificate is preinstalled and you
click Edit Settings to update the validity period. It specifies the current
Coordinated Universal Time (UTC). UTC is a time scale maintained by the
International Bureau of Weights and Measures. It adjusts for differences between
Greenwich Mean Time and atomic time. It is set at 0 degrees longitude on the
prime meridian.
The Validity Start Date is calculated from the PC’s clock settings.
The Validity Period specifies the number of days (1 to 3650) that the certificate
is valid, starting from the Validity Start Date. A valid entry (1 to 3650) is required.
The default is 5 years.
Certificate Information
Use this page to enter information for requesting a certificate from a Certificate
Authority.
Common Name. (Required)
For HP Jetdirect projector servers, specify the fully qualified domain name or a
valid IP address for the device.
Examples:
● Domain Name: myprojector.mydepartment.mycompany.com
● IP address: 192.168.2.116
The Common Name will be used to uniquely identify the device. For HP Jetdirect
projector servers using EAP authentication, some authentication servers may
need to be configured with the Common Name as specified on the certificate.
If the default IP address 192.0.0.192 is configured on the Jetdirect projector
server, it will not likely be valid for your network. You should not use this default
address to identify your device.
Organization. (Required) Specify the full legal name for your company.
Organizational Unit. (Optional) Specify your department, division, or other
subgroup of your organization.
City/Locality. (Required) Enter the city or locality in which your organization is
located.
State/Province. (Required for all countries/regions) Must contain at least three
characters. (required)
Country/Region. Two-character ISO 3166 country/region code. For example,
use “gb” Great Britain or “us” for USA (required).
ENWW Using the Embedded Web Server 68
Table 4.7 Certificate Configuration Screens (4 of 4)
Install Certificate, or Install CA Certificate
Use the Install Certificate screen to install a Jetdirect certificate.
Use the Install CA Certificate screen to install a trusted Certificate Authority (CA)
certificate for use during EAP authentication.
Install a PEM/Base64 (Privacy Enhanced Mail) encoded certificate.
To install a certificate, specify the name and path of the file that contains the
certificate. Or, click Browse to browse your system for the file.
Click Finish to complete the installation.
To install a certificate, it must be associated with a pending certificate request by
the embedded Web server. The Install Certificate option will not be presented if
there is no pending request.
A Jetdirect or CA certificate size is limited to 3 KBytes.
Import Certificate and Private Key
Use this screen to import a Jetdirect certificate and private key.
Import a Jetdirect certificate and private key. When imported, the existing
certificate and private key will be overwritten.
The file format must be PKCS#12 encoded (.pfx) and cannot exceed 4 KBytes.
To import a certificate and private key, specify the name and path of the file that
contains the certificate and private key. Or, click Browse to browse your system
for the file. Then enter the password that was used to encrypt the private key.
Click Finish to complete the installation.
Export the Jetdirect certificate and private key
Use this screen to export the installed Jetdirect certificate and private key to a file.
To export a certificate and private key, enter a password that will be used to
encrypt the private key. You must enter the password again to confirm it. Then
click Save As to save the certificate and private key in a file on your system. The
file format will be PKCS#12 encoded (.pfx).
ENWW Using the Embedded Web Server 69
Access Control
Use this tab to display the Access Control List (ACL) on the HP Jetdirect
projector server. An access control list (or host access list) specifies individual
host systems, or networks of host systems, that will be allowed to access the
server and the attached network device. Up to 10 entries can be included on
the list. If the list is empty (no hosts are listed), any supported system can
access the server.
CAUTION Use caution when using this feature. You may lose your
ability to communicate with the HP Jetdirect projector
server if your system is not properly specified in the list, or
access through HTTP is disabled.
For use of the host access list as a security feature, see
Chapter 5
.
Note By default, hosts with HTTP connections (for example,
through the embedded Web server) are allowed access to
the projector server regardless of access control list entries.
To disable access by HTTP hosts, clear the Allow Web
Server (HTTP) access checkbox at the bottom of the list.
Host systems are specified by their IP addresses or network number. If the
network contains subnets, an address mask may be used to identify whether
the IP address designates an individual host system or a group of host systems.
Examples. See the table of sample entries below:
IP Address Mask Description
192.0.0.0 255.0.0.0 Allow all hosts with network number 192.
192.1.0.0 255.1.0.0 Allow all hosts on network 192, subnet 1.
192.168.1.2 Allow the host with IP address 192.168.1.2.
The mask 255.255.255.255 is assumed and is
not required.
ENWW Using the Embedded Web Server 70
To add an entry into the access control list, use the IP Address and Mask
fields to specify a host, and click (check) the Save checkbox for that entry.
Then click Apply.
To delete an entry from the list, clear the Save checkbox for that entry. Then
click Apply.
To clear the entire access control list, clear all Save checkboxes, and click
Apply.
Mgmt. Protocols
This link provides access to management communications and other protocols
that affect security.
Web Mgmt.
Use this tab to manage communications with the embedded Web server from
Web browsers.
Secure, encrypted Web-based communication is provided through the Secure
HTTP (HTTPS) protocol. If configured to require HTTPS, the embedded Web
server routes HTTPS communications through port 443, the well-known port
for HTTPS traffic. Other non-secure communications (HTTP) are redirected
to HTTPS. Redirection of your browser to use HTTPS may be transparent
depending on your browser’s capabilities.
By factory default, the projector server is configured to allow HTTPS or
HTTP.
Although not recommended, you may choose to accept both HTTPS and
HTTP communications that are not secure by disabling (clearing) the Encrypt
All Web Communication checkbox.
To support the use of HTTPS communications, a Jetdirect certificate must be
installed. A factory-default, self-signed certificate is preinstalled for initial
use. Click the Configure button to update the preinstalled certificate, or to
install a new one. For more information, see “Configuring Certificates
.”
The minimum encryption strength that will be allowed must be specified when
using a Jetdirect certificate. You may select Low (default), Medium, or High
encryption strength. For example, selecting Low will allow medium or high
encryption levels to be used whereas selecting High will onl y allow high
encryption levels.
For each encryption strength, ciphers are specified to identify the weakest
cipher allowed. Early browsers may only support 40-bit (Low) encryption
levels.
ENWW Using the Embedded Web Server 71
Note Cipher suites support different levels of encryption strength.
The cipher suites currently supported for encryption and
decryption are DES (Data Encryption Standard, 56-bit),
RC4 (40-bit or 128-bit), and 3DES (168-bit).
SNMP
Use this tab to enable or disable SNMP v1, v2c and v3 agents on the server.
For a description of SNMP selections, see Table 4.4
.
SNMP v3. HP Jetdirect projector servers include an SNMP v3 (Simple
Network Management Protocol, version 3) agent, for enhanced SNMP
security. The SNMP v3 agent employs a User-based Security Model for
SNMP v3 (RFC 2574), which features user-authentication and data privacy
through encryption.
The SNMP v3 agent is enabled when an initial SNMP v3 account on the server
is created. Once the account is created, any SNMP management application,
if properly configured, can access or disable the account.
CAUTION If you use HP Web Jetadmin to manage your devices, you
should use HP Web Jetadmin to seamlessly configure
SNMP v3 and other security settings on the projector server.
Using the embedded Web server to create the SNMP v3
account will erase any existing SNMP v3 accounts. In
addition, the SNMP v3 account information will need to be
implemented on the SNMP management application.
You may create the initial account by specifying the HMAC-MD5
authentication and CBC-DES data privacy encryption keys used by your
SNMP v3 management application.
ENWW Using the Embedded Web Server 72
CAUTION You should ensure secure embedded Web communications
through HTTPS is enabled before creating the initial SNMP
v3 account. This will help to prevent access or interception
of account information over a connection that is not secure.
SNMP v1 and v2c agents can coexist with the SNMP v3
agent. However, to fully secure SNMP access, you should
disable SNMP v1 and v2c.
Other
Use this tab to enable or disable various protocols supported by the projector
server for services and management. See Table 4.8
Table 4.8 Other Protocols
Item Description
.
Enable Device
Discovery
Enable Management
Protocols
Enable or disable device discovery protocols supported by
the projector server:
SLP (Service Location Protocol).
If enabled (checked), the server sends SLP packets,
which are used by system applications for automated
discovery and installation.
If disabled (cleared), SLP packets are not sent.
Multicast IPv4.
If enabled (checked), the server will send and receive
IP version 4 multicast packets.
Enable or disable the use of FTP to upgrade firmware on
the server. FTP is not a secure protocol, and device
passwords may be intercepted.
Disabling FTP firmware upgrades is recommended.
ENWW Using the Embedded Web Server 73
802.1x Authentication
This page allows you to configure 802.1X authentication settings on the
Jetdirect projector server as required for client authentication on your network.
In addition, you can reset the 802.1X authentication settings to factory-default
values.
CAUTION Use caution when changing the 802.1X authentication
settings; you may lose your connection. If communication
with the projector is lost, you may need to reset the projector
server to a factory-default state and then reinstall the device.
For most 802.1X networks, the infrastructure components (such as LAN
switches) must use 802.1X protocols to control a port’s access to the network.
If these ports do not allow partial or guest access, the projector server may
need to be configured with your 802.1X parameters prior to connection.
To configure initial 802.1X settings before connecting to your network, you
can use an isolated LAN, or a direct computer connection using a cross-over
cable.
The supported 802.1X authentication protocols and associated configuration
depend on the server model and firmware version. Available configuration
settings are listed in Table 4.9
.
ENWW Using the Embedded Web Server 74
Table 4.9 802.1X Configuration Settings (1 of 2)
Item Description
Enable Protocols Enable (check) the supported protocols used for 802.1X
authentication on your network.
● PEAP: (Protected Extensible Authentication Protocol).
PEAP uses digital certificates for network server
authentication and passwords for client authentication.
PEAP requires an EAP User Name, EAP Password,
and CA Certificate. Dynamic encryption keys are also
used.
User Name Specify an EAP/802.1X user name (up to 128 characters
maximum) for this device. The default user name is the
default host name of the projector server, NPIxxxxxx, where
xxxxxx are the last six digits of the LAN hardware (MAC)
address.
Password,
Confirm Password
Specify an EAP/802.1X password (up to 128 characters
maximum) for this device. Enter the password again in the
Confirm Password field to ensure it was properly entered.
Server ID Specify the Server ID validation string that identifies and
validates the authentication server. The Server ID string is
specified on the digital certificate issued by a trusted
Certificate Authority (CA) for the authentication server. The
entry may be a partial string unless the Require Exact
Match checkbox is enabled.
Encryption Strength Specify the minimum encryption strength that can be used
during communications with the authentication server. You
may select Low, Medium, or High encryption strength. For
each encryption strength, ciphers are specified to identify
the weakest cipher allowed.
Early browsers may only support 40-bit (Low) encryption
levels.
CA Certificate To validate the authentication server’s identity, a CA (or
“Root”) certificate must be installed on the projector server.
This CA certificate must be issued by the Certificate
Authority who signed the authentication server’s certificate.
To configure or install a CA certificate, click Configure.
ENWW Using the Embedded Web Server 75
Table 4.9 802.1X Configuration Settings (2 of 2)
Item Description
Authentication
Behavior:
Reauthenticate on
Apply
Enable (check) or disable (clear) this checkbox to control
authentication when you click Apply on this page,
assuming valid configuration entries have been made.
Note: This parameter does not apply to security or other
configuration wizards. Changes to parameters through
a wizard will always cause the server to reauthenticate.
If disabled (default), the server will not attempt
reauthentication unless configuration changes cause the
server to disconnect and reconnect to the network.
If enabled, the server will always try to reauthenticate using
the configuration values set.
Network Statistics
This page is used to display counter values and other status information
currently stored on the HP Jetdirect projector server. This information is often
useful to diagnose performance and operational problems associated with the
network or network device.
Protocol Info
This page provides a list of various network configuration settings on the
HP Jetdirect projector server for each protocol. Use these lists to validate your
desired settings.
ENWW Using the Embedded Web Server 76
Projector Tab
The Projector tab provides control of projector power, selection of the input
source, and setup of alerts for specific conditions. The menu items in the left
margin provide access to configuration pages.
Power
On the Power page, Power Status displays the projector’s current power state.
To turn the projector on or off, click the Power button.
Input
The Input page displays the current input sou rce and provides controls for
selecting a new input source and changing certain input settings.
Table 4.10 Input Page Items
Item Description
Current Source Displays the input port currently selected on the projector.
The signal on this port is projected on the screen.
Requested Source Selects an input port to be scanned for a valid input signal
(which if found is projected on the screen). To activate a
source, select the source and click Apply.
Source Auto-Search Enables (or disables) the projector to automatically search
for the next input port with a valid signal, then display that
signal. Searching starts whenever the projector is not
displaying a valid signal.
Auto Sync (VGA sources only) Forces the projector to resynchronize
with the signal from the VGA source. Mark this option and
click Apply to resynchronize. This option automatically
clears after each use.
ENWW Using the Embedded Web Server 77
Alerts
The Alerts page specifies certain projector conditions that cause an email
notification to be sent. These notifications allow recipients to take appropriate
action to prevent or fix a projector problem.
Table 4.11 Alerts Page Items
Item Description
Enable Enables (or disables) e-mail notifications set up on this
menu. This provides a quick way to turn alerts on and off.
Events Selects the events that trigger e-mail notifications. When a
Send Email Alert To Specifies each alert recipient’s In ternet e-mail address with
Email (SMTP) Server Specifies the IP address of the Simple Mail Transfer
Send Test Email Sends a message to recipients to test the e-mail setup.
selected event occurs, the Jetdirect server sends an e-mail
message to each recipient.
the @ symbol. Separate multiple addresses with commas.
Protocol server that relays outgoing e-mail from the
Jetdirect server.
ENWW Using the Embedded Web Server 78
Other Links
Help
The Help page in the Networking tab provides a quick summary of the
HP Jetdirect embedded Web server features. This Administrator’s Guide
contains detailed information about all features.
Support
The information displayed on the Support page depends on the values
configured in the S
information may include the name and telephone number of a Support person,
or Web links to Product and Technical Support pages. The default Web links
include HP online support and HP product information Web pages (Internet
access is required).
HP Home
HP Home provides a link to Hewlett-Packard’s home page on the HP Web
site (Internet access is required). This link may also be accessed by clicking
on the HP logo.
upport Info tab in the Other Settings menu. Support
HP Web Jetadmin
HP Web Jetadmin is HP’s premier network peripheral management software
tool.
A link to HP Web Jetadmin will be displayed only if HP Web Jetadmin has
discovered this device through an “Integration URL.” You can then use
HP Web Jetadmin to provide enhanced management capabilities for this and
other HP Jetdirect-connected devices on your network.
ENWW Using the Embedded Web Server 79
5
Security Features
Introduction
Security features are provided that can help to minimize unauthorized access
to network configuration parameters and other data stored on HP Jetdirect
projector servers. The features may differ depending on the version of
firmware resident on the server.
CAUTION Although these features can help to minimize unauthorized
access to stored data and configuration parameters on
HP Jetdirect projector servers, the prevention of
unauthorized access cannot be guaranteed.
For advanced security needs, contact HP Consulting
services.
Table 5.1 summarizes the basic security features provided with HP Jetdirect
projector servers.
ENWW 80
Table 5.1 Summary of HP Jetdirect Security Features (1 of 2)
Secure Embedded Web Server Management
● A preinstalled, self-signed digital certificate provides HTTPS (secure HTTP)
access to the embedded Web server from your Web browser. HTTPS (secure
HTTP) provides secure, encrypted communications with your browser.
● Digital certificates issued by a trusted third party can be installed on the
projector server, allowing it to be configured as a trusted site.
● Using HTTPS, the embedded Web server provides configuration and
management of network parameters and protocols through a secure channel.
● An HP Jetdirect Security Configuration Wizard provides an easy-to-use
interface to configure security settings.
● Projector servers can be configured with EAP/802.1X server-based
authentication.
Network Protocol Control
● Device discovery and management protocols on the HP Jetdirect projector
server can be enabled or disabled. By disabling unused or unnecessary
protocols, unauthorized access through applications that use these protocols
can be prevented.
● Protocols may be enabled or disabled through the embedded Web server and
HP Web Jetadmin.
IP Administrator Password
● Used by HP Web Jetadmin and the embedded Web server to control access
to HP Jetdirect configuration parameters.
● Up to 16 alphanumeric characters may be used.
● Configured on the HP Jetdirect projector server using TFTP (Chapter 3), the
embedded Web server (Chapter 4
alphanumeric characters are allowed.
● If configured through the embedded Web server, may be synchronized as the
SNMP Set Community Name used in HP Web Jetadmin SNMP v1/v2c Set
commands.
● Cleared by cold reset of the projector server to factory default settings.
IP Access Control List
● Specifies up to 10 host systems, or networks of host systems, that are allowed
access to the HP Jetdirect projector server and the attached network device.
● Access is generally limited to host systems specified in the list.
● By factory default, host systems that use HTTP (for example, using the
embedded Web server) are not checked against entries in the Access List and
are allowed access. However, HTTP host access can be disabled through the
embedded Web server.
● If the list is empty, then all hosts are allowed access.
● Configured on the HP Jetdirect projector server using TFTP (Chapter 3),
embedded Web server (Chapter 4
) services, or HP Web Jetadmin. Up to 16
), or management software.
ENWW Security Features 81
Table 5.1 Summary of HP Jetdirect Security Features (2 of 2)
Authentication and Encryption
● Certificate management for X.509 digital certificates is provided through the
embedded Web server, for both client-based and server-based authentication.
(Installed certificates are limited to 3KB. A single Certificate Authority (CA)
certificate may be installed.)
SNMP v1/v2c Set Community Name
(SNMP v1/v2c only)
● A password on the HP Jetdirect projector server that allows incoming SNMP
Set commands (for example, from management software) to write (or set)
HP Jetdirect configuration parameters.
● For a user-assigned Set Community Name, SNMP Set commands must
contain the user-assigned name, which is authenticated by the server before
the command is performed.
● On IP networks, authentication of SNMP Set commands may be further
restricted to systems identified on the access control list.
● Configured on the HP Jetdirect projector server using TFTP (Chapter 3), the
embedded Web server (Chapter 4
● SNMP v1/v2c uses plain text and can be disabled.
SNMP v3
● An SNMP v3 agent on the HP Jetdirect projector server provides secure,
encrypted communications with an SNMP v3 management application, such
as HP Web Jetadmin.
● The projector server supports creation of an SNMP v3 account when it is
enabled through the embedded Web server. The account information can be
integrated on SNMP v3 management applications.
● The projector server supports seamless SNMP v3 account creation and
management from HP Web Jetadmin.
HP Web Jetadmin Password and Profiles
● Access control to Jetdirect configuration parameters through the Jetdirect IP
Administrator password, which may be configured from HP Web Jetadmin or
embedded Web server. For instructions, refer to the HP Web Jetadmin online
help.
● HP Web Jetadmin provides access control through User Profiles. User Profiles
allow password protection for individual profiles and controlled access to
HP Jetdirect and projector features. For more information, refer to the HP Web
Jetadmin online help.
● HP Web Jetadmin can seamlessly enable the SNMP v3 agent on the projector
server, and create an SNMP v3 account for secure, encrypted management.
), or Management application services.
ENWW Security Features 82
Using Security Features
Access to HP Jetdirect configuration parameters can be controlled through
combined use of the available security features. Table 5.2
of various settings and the associated level of access control.
Table 5.2 Settings for Access Control
Settings Level of Access Control
● Accessible through HTTP
(embedded Web server) or
SNMP v1/v2c applications
● Administrator password
not set
● Default SNMP v1/v2c
community names used
● No authentication or
encryption
● Access control list empty
● Administrator password set
● User-specified SNMP v1/v2
Set Community Name set
● The Access Control List
contains host entries and
checks HTTP connections
● Non-secure protocols
disabled.
Low
Best suited for trusted environments.
Any system can access the HP Jetdirect
configuration parameters through the embedded
Web server or SNMP management software.
Passwords are not required.
Medium
Limited security for non-trusted environment.
If the Administrator password and SNMP v1/v2c
Set Community Name are known, access is
limited to:
● systems listed in the Access Control List, and
● SNMP v1/v2c management applications
provides examples
● Unused protocols disabled
● HTTPS access enabled using
certificates issued by trusted
sources
● Configured for EAP/802.1x
server-based authentication
and encryption
● SNMP v3 enabled, SNMP
v1/v2c disabled
● Passwords set
● The Access Control List
High
High security for non-trusted, professionally
managed environments.
Access is limited to authenticated hosts that are
specified in the Access Control List. Encryption
provides data privacy; network communication in
plain-text is not used.
CAUTION: Power-on settings (for example,
configurations from a BootP/TFTP or
DHCP/TFTP server) may change the server’s
settings when it is power-cycled. Be sure to
confirm your intended power-on settings.
contains specified entries and
HTTP connections are
checked
ENWW Security Features 83
6
Troubleshooting the HP Jetdirect Projector Server
Introduction
This chapter describes how to diagnose and correct problems associated with
the HP Jetdirect projector server.
A flowchart guides you to the correct procedures for troubleshooting the
following:
● HP Jetdirect hardware installat ion and connection problems
● Network-related problems
To troubleshoot your HP Jetdirect projector server, you may need the
following items:
● Documentation that came with your HP projector
● Documentation that came with your HP Jetdirect projector server
● The diagnostics tools and utilities provided with your network software
(for example, TCP/IP utilities, or network device management applications
such as HP Web Jetadmin)
ENWW 84
Resetting to Factory Defaults
Parameters on the HP Jetdirect projector server (for example, the IP address)
can be reset to factory default values using the following procedures:
● Reset the HP Jetdirect external projector server by holding down the Reset
button on the server while connecting the power cord.
After a cold reset, your network systems may lose their connection to the
projector.
ENWW Troubleshooting the HP Jetdirect Projector Server 85
General Troubleshooting
Troubleshooting Chart - Assessing the Problem
Projector
connected to power
and operating
properly?
Yes
Projector server
status light flickering
and USB light
steady?
No
No
• Check the power cord and
power source.
• See the projector’s user
manual.
See “Resolving Problems with
the Indicator Lights,” below.
Yes
Projector server
communicating with
network?
Yes
See your network documentation.
No
esolving Communication
See “R
Problems with the Network,”
below.
Figure 6.1 Assessing the Problem
ENWW Troubleshooting the HP Jetdirect Projector Server 86
Resolving Problems with the Indicator Lights
Check the following items to see whether the projector server is operating
properly.
1. Power/status light:
◆ If the light is flickering green, network activity is normal. No problem
indicated.
◆ If the light is off, power is not connected. Check the power module
and power source.
◆ If the light is on steady, there is no network activity. Go to “Resolving
Communication Problems with the Network,” below.
◆ If the light slowly blinks green more than 15 seconds after startup,
no network is detected. Go to “R
with the Network,” below.
◆ If the light blinks orange, disconnect and reconnect power at the
Jetdirect server. If the condition persists, the server is faulty.
2. USB/projector light :
◆ If the light is on steady, the USB connection is good. No problem
indicated.
◆ If the light is off more than 15 seconds after startup, no USB
connection is detected. This is normal if no projector is connected.
Disconnect and reconnect power at the Jetdirect server. Make sure a
USB cable connects to a projector and the projector is connected to
power. Try a different USB cable. If the condition persists, the server
or projector is faulty. If possible, repeat with a different server or
projector.
◆ If the light blinks green, the projector is not compatible with the
Jetdirect server. Check for Jetdirect compatibility in the
specifications for the projector model and firmware version — or go
to www.hp.com/support
and look up the model number of your
Jetdirect server.
◆ If the light blinks orange, a hardware problem exists. Disconnect and
reconnect power at the Jetdirect server. If the condition persists,
disconnect and reconnect power in each of the following conditions:
❑ No USB cable (blinking orange indicates the server is faulty),
then —
❑ USB cable plugged into onl y the server (blinki ng orange
indicates the cable is faulty), then —
❑ USB cable plugged into the server and projector (blinking orange
indicates the projector is faulty).
esolving Communication Problems
ENWW Troubleshooting the HP Jetdirect Projector Server 87
3. LAN 10/100 lights:
◆ If one light is on, a network connection is established at 10 Mbps or
100 Mbps. No problem indicated.
◆ If both lights are off, no network is detected. See “Resolving
Communication Problems with the Network,” below.
Resolving Communication Problems with the Network
Check the following items to verify that the projector server is communicating
with the network.
1. Are there any physical connection problems between the workstation or
file server and the HP Jetdirect projector server?
◆ Verify network cabling, connections, and router configurations.
◆ Verify that network cable lengths meet network specifications.
◆ Verify that network settings have been properly configured.
2. Are your network cables connect ed properly?
Make sure that the projector is attached to the network using the
appropriate HP Jetdirect projector server port and cable. Check each cable
connection to make sure it is secure and in the right place. If the problem
continues, try a different cable or network port on the hub or switch.
3. Is autonegotiati on properly configured?
The speed and communication mode on the projector server must match
the network for proper operation.
The server’s RJ-45 network connector
has indicator lights to identify the
10 Mbps
100 Mbps
connection speed. Verify that either the
10 Mbps or 100 Mbps light is on.
4. Is the projector server connected to an
802.1X network and properly configured
for EAP/802.1X operation?
The network must support the Extensible Authentication Protocol (EAP)
method configured for use on the server.
Verify the configuration of the network’s 802.1X port. If it does not allow
guest or temporary access, you may need to preconfigure the Jetdirect
projector server for 802.1X operation before connection to your network.
This is done using an isolated LAN, or through a direct computer-to-Jetdirect
server connection using a cross-over cable.
ENWW Troubleshooting the HP Jetdirect Projector Server 88
5. Are other users able to access the projector embedded Web server?
The problem may be workstation-specific. Check the workstation network
drivers.
6. If other users can access the projector’s embedded Web server, are they
using the same network operating system?
Check your system for proper network operating system setup.
7. Is your protocol enabled on the HP Jetdirect projector server?
Check the status of the network protocols on the Jetdirect server. Use the
embedded Web server to check status of network protocols. See
Chapter 4
.)
8. Does the projector appear in HP Web Jetadmin or other management
application?
◆ Verify the projector’s IP address in the projector’s on-screen Help
menu.
◆ See the troubleshooting section in the online help included with the
HP Web Jetadmin software.
ENWW Troubleshooting the HP Jetdirect Projector Server 89
A
TCP/IP Overview
Introduction
This appendix is intended to provide information to help you gain a basic
understanding of TCP/IP.
Similar to a common language that people use to communicate with each
other, TCP/IP (Transmission Control Protocol/Internet Protocol) is a suite of
protocols designed to define the way computers and other devices
communicate with each other over a network.
TCP/IP is rapidly becoming the most used set of protocols. The main reason
this is happening is the fact that the Internet is based on TCP/IP. If you have
a network that you wish to connect to the internet, you must be using TCP/IP
to communicate.
Internet Protocol (IP)
When information is sent across the network, the data is broken down into
small packets. Each packet is sent independently of one another. Each packet
is encoded with IP information, such as the IP address of the sender and
receiver. IP packets can be routed over routers and gateways, devices that
connect a network with other networks.
IP communications is connectionless. When IP packets are sent, there is no
guarantee that they arrive at their destination in the proper sequence. That task
can be performed by higher level protocols and applications thereby allowing
IP communications to be efficient.
Each node or device that will communicate directly onto the network requires
an IP address, including HP Jetdirect-connected devices.
ENWW 90
Transmission Control Protocol (TCP)
TCP handles breaking the data into packets and recombining the packets on
the receiving end by providing a connection-oriented, reliable, and guaranteed
delivery service to another node on the network. When data packets are
received at their destination, TCP calculates a checksum for each packet to
verify the data is not corrupt. If the data in the packet has been corrupted during
transmission, TCP discards the packet and requests that the packet be resent.
User Datagram Protocol (UDP)
UDP provides similar services to TCP. However, UDP does not acknowledge
data receipt and supports request/reply transactions with no added reliability
or guarantee of delivery. UDP is used when acknowledgment and reliability
are not required, such as during a “discovery broadcast.”
IP Address
Every host (workstation or node) on an IP network requires a unique IP address
for each network interface. This address is a software address that is used to
identify both the network and specific hosts located on that network. Each IP
address can be divided into two separate parts: the network portion and the
host portion. It is possible for a host to query a server for a dynamic IP address
each time the device boots-up (for example, using DHCP and BootP).
Note When assigning IP addresses, always consult the IP address
administrator. Setting the wrong address can disable other
equipment operating on the network or interfere with
communications.
IP Address: (Network Portion)
Network addresses are managed by an organization in Norfolk, Virginia
recognized as InterNIC. InterNIC has been contracted by the National Science
Foundation to manage the Internet addresses and domains. Network addresses
are distributed to organizations that are in turn responsible for making sure all
attached devices or hosts on the network are properly numbered. For more
information on the network portion of an IP address, see “IP Address Structure
and Class” and “Subnets” later in this appendix.
NWW TCP/IP Overview 91
IP Address: (Host Portion)
Host addresses numerically identify specific network interfaces on an IP
network. Usually a host has only one network interface; thus, only one IP
address. Because no two devices can share the same number at the same time,
administrators typically maintain address tables to assure correct assignment
of addresses in the host network.
IP Address Structure and Class
An IP address is comprised of 32 bits of information and divided into 4 sections
containing 1 byte each section or 4 bytes total: xxx.xxx.xxx.xxx
For efficiency in routing, networks were broken down into three classes, so
routing can begin simply by identifying the leading byte of information in the
IP address. The three IP addresses that InterNIC assigns are class A, B, and
C. The network class determines what each of the four IP address sections
identify as shown in Table A.1
Table A.1 IP Address Class Format
:
Class First Address
Byte xxx.
A Network. Host. Host. Host
B Network. Network. Host. Host
C Network. Network. Network. Host
As illustrated in Table A.2
Second
Address
Byte xxx.
Third Address
Byte xxx.
Fourth
Address
Byte xxx
, each network class differs by the leading bit
identifier, the address range, the number of each type available, and the
maximum number of hosts each class allows.
Table A.2 Network Class Characteristics
Class Leading
Bit
Identifier
A 0 0.0.0.0 to
B 10 128.0.0.0 to
C 110 192.0.0.0 to
Address Range Maximum
Number of
Networks in the
Class
126 Over 16 Million
127.255.255.255
16,382 65,534
191.255.255.255
Over 2 Million 254
223.255.255.255
Maximum
Hosts in the
Network
ENWW TCP/IP Overview 92
Configuring IP Parameters
TCP/IP configuration parameters (such as IP address, subnet mask, default
gateway) can be configured on the HP Jetdirect projector server in a variety
of ways. These values can be configured manually (for example, through the
embedded Web server, the arp and ping commands, and HP management
software), or they can be automatically downloaded using DHCP or BOOTP
each time the server is turned on. For configuration methods, see Chapter 3
When powered on, a new HP Jetdirect projector server that is unable to retrieve
a valid IP address from the network will automatically assign itself a default
IP address. The default IP address will depend on the type of network to which
the server is connected. On a small private network, a technique called
link-local addressing is used to assign a unique IP address in the range of
169.254.1.0 to 169.254.254.255, which should be valid. On a large or
enterprise network, a temporary address of 192.0.0.192 will be assigned until
it is properly configured for your network. The IP address configured on your
projector server may be determined by inspecting the projector’s on-screen
Help menu.
Dynamic Host Configuration Protocol (DHCP)
DHCP allows a group of devices to use a set of IP addresses that are
maintained by a DHCP server. The device or host sends a request to the server,
and if an IP address is available, the server assigns it to that device.
.
BOOTP
BOOTP is a bootstrap protocol used to download configuration parameters
and host information from a network server. BOOTP uses UDP for its
transport. In order for devices to boot and load configuration information into
RAM, they must communicate through the bootstrap protocol BOOTP as a
client with their server.
To configure the device, the client broadcasts a boot request packet containing
at least the hardware address of the device (HP Jetdirect projector server
hardware address). The server answers with a boot reply packet containing
the information the device needs to configure.
NWW TCP/IP Overview 93
Subnets
When an IP network address for a particular network class is assigned to an
organization, no provision is made for more than one network being present
at that location. Local network administrators use subnets to partition a
network into several different subnetworks. Splitting a network into subnets
can result in better performance and improved use of limited network
address space.
Subnet Mask
The subnet mask is a mechanism used to divide a single IP network into several
different subnetworks. For a given network class, a portion of an IP address
that would normally be used to identify a node is used, instead, to identify a
subnetwork. A subnet mask is applied to each IP address to specify the portion
used for subnetworks, and the portion used to identify the node. For example,
see Table A.3
Table A.3 Example: Subnet Mask 255.255.0.0 Applied to Class A
Class A Network Address 15 xxx xxx xxx
Subnet Mask 255 255 0 0
IP Address fields with Subnet
Mask applied
Example of a node’s IP Address
on Subnet 1
Example of a node’s IP Address
on Subnet 254
.
Network
Network
15
15
Subnet Host Host
1 25 7
254 64 2
As illustrated in Table A.3
, the Class A IP network address “15” has been
assigned to company ABC. To allow additional networks at company ABC’s
site, the subnet mask of 255.255.0.0 is used. This subnet mask specifies that
the second byte of the IP address will be used to identify up to 254 subnets.
Using this designation, each device is uniquely identified on its own subnet,
but company ABC can incorporate up to 254 subnetworks without violating
their assigned address space.
ENWW TCP/IP Overview 94
Gateways
Gateways (routers) are used to connect networks together. Gateways are
devices that act as translators between systems that do not use the same
communication protocols, data formatting, structures, languages, or
architectures. Gateways repackage the data packets and change the syntax to
match that of the destination system. When networks are divided into subnets,
gateways are required to connect one subnet to another.
Default Gateway
The Default Gateway is the gateway or router that, if not specified, will be
used to move packets between networks. It is specified by an IP address.
If multiple gateways or routers exist, then the default gateway is typically the
address of the first, or nearest, gateway or router. If no gateways or routers
exist, then the default gateway will typically assume the IP address of the
network node (such as the workstation or HP Jetdirect projector server).
Syslog Server
A syslog server is a system on the network (typically a UNIX system) that can
receive and log syslog messages from other devices on the network. Syslog
messages allow administrators to monitor status or troubleshoot network
devices.
A syslog server requires software that provides syslog capabilities running on
the server. UNIX systems provide a daemon, syslogd, that monitors User
Datagram Protocol (UDP) port 514 for incoming messages. The messages are
processed depending on their priority and on how syslogd is set up to operate.
You can configure the HP Jetdirect projector server with the syslog server’s
IP address. When a syslog server is configured, both the HP Jetdirect projector
server and attached device can send syslog messages using UDP.
NWW TCP/IP Overview 95
The syslog server may not receive all syslog events from the HP Jetdirect
projector server:
● UDP does not guarantee delivery of messages.
● The HP Jetdirect projector server attempts to eliminate duplicate messages
(to minimize unnecessary network traffic).
● The volume of messages sent by the HP Jetdirect projector server is
configurable.
Methods to configure HP Jetdirect syslog parameters include BOOTP, DHCP,
the embedded Web server, and management software. The syslog
configuration command or parameter entries may vary depending on the
method used. For more information, see the applicable sections in this guide.
Selected syslog parameters on the HP Jetdirect projector server are listed in
Table A.4
Table A.4 HP Jetdirect Syslog Parameters
Item Description
Syslog Server
IP address
Syslog Maximum
Messages
Syslog Priority A method for filtering syslog messages that are sent to the
Syslog Facility A code used to identify the source facility of a message (for
.
IP address of a syslog server for sending syslog messages. If
zero (0.0.0.0) or not specified, syslog messages are disabled.
The number of syslog messages that can be sent by the
HP Jetdirect projector server on a per-minute basis, from 0 to
1000. This parameter helps to control the syslog file size. The
default is 10 messages per minute. If 0, the number of syslog
messages is not restricted.
syslog server. The range is 0 through 8, with 0 the most specific
and 8 the most general. Only messages that are lower than the
specified filter level (or higher in priority) are reported. The
default is 8, messages of all priorities are sent. If 0, all syslog
messages are disabled.
example, to identify the source of selected messages during
troubleshooting). By default, the HP Jetdirect projector server
uses local user values of local0 through local7 to isolate
individual or groups of projector servers.
ENWW TCP/IP Overview 96
B
OpenSSL Statements
OpenSSL License
Copyright © 1998-2004 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are permitted
provided that the following conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions
and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions
and the following disclaimer in the documentation and/or other materials provided with the
distribution.
3. All advertising materials mentioning features or use of this software must display the following
acknowledgment:
“This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit. (http://www.openssl.org/)”
4. The names “OpenSSL Toolkit” an d “OpenSSL Project” must not be used to endorse or promote
products derived from this software without prior written permission. For written permission,
please contact openssl-core@openssl.org.
5. Products derived from this software may not be called “OpenSSL” nor may “OpenSSL” appear
in their names without prior written permission of the OpenSSL Project.
6. Redistributions of any form whatsoever must retain the following acknowledgment:
“This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit (http://www.openssl.org/)”
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND ANY
EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED W ARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PAR TICULAR
PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR ITS
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY
OF LIABILITY , WHETHER IN CONTRACT, STRICT LIABILITY, OR TOR T (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
This product includes cryptographic software written by Eric Y oung (eay@cryptsoft.com). This
product includes software written by Tim Hudson (tjh@cryptsoft.com).
ENWW 97
Original SSLeay License
Copyright © 1995-1998 Eric Young (eay@cryptsoft.com). All rights reserved.
This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The
implementation was written so as to conform with Netscape’s SSL.
This library is free for commercial and non-commercial use as long as the following conditions
are adhered to. The following conditions apply to all code found in this distribution, be it the
RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with
this distribution is covered by the same copyrigh t terms except that the holder is Tim Hudson
(tjh@cryptsoft.com).
Copyright remains Eric Young’s, and as such any Copyright notices in the code are not to be
removed.
If this package is used in a product, Eric Young should be given attribution as the author of the
parts of the library used.
This can be in the form of a textual message at program startup or in documentation (online or
textual) provided with the package.
Redistribution and use in source and binary forms, with or without modification, are permitted
provided that the following conditions are met:
1. Redistributions of source code must retain the copyright notice, this list of conditions and the
following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions
and the following disclaimer in the documentation and/or other materials provided with the
distribution.
3. All advertising materials mentioning features or use of this software must display the following
acknowledgement:
“This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)”
The word ‘cryptographic’ can be left out if the routines from the library being used are not
cryptographic related.
4. If you include any Windows specific code (or a derivative thereof) from the apps directory
(application code) you must include an acknowledgement:
“This product includes software written by Tim Hudson (tjh@cryptsoft.com)”
THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EXPRESS OR
IMPLIED WARRA NTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
W ARRANTIES OF MERCHANT ABILITY AND FITNESS FOR A PARTICULAR PURPOSE
ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT
OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR
BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
The licence and distribution terms for any publicly available version or derivative of this code
cannot be changed, i.e., this code cannot simply be copied and put under another distribution
license [including the GNU Public Licence.]
ENWW OpenSSL Statements 98
Index
A
Access List
embedded Web server 70
security features 81
TFTP configuration file 26
Administrator Password
embedded Web server 51, 64
Security features 81
TFTP configuration file 25
arp command 42
Authentication 74
802.1X 6, 74
Auto IP 13, 14
See also, Default IP address
embedded Web server 53
B
BOOTP
embedded Web server 53
overview 93
using 17
BOOTP Server 18
configuration 18
browsers
embedded web server 47
HP Web Jetadmin 9
C
CA certificate 65
embedded Web server 75
Certificate Authority, See CA certificate
Certificates 65
validity period 68
cold-reset 85
Community name
embedded Web server 56
security features 82
TFTP configuration 30
configuration
HP Web Jetadmin 11
TCP/IP networks 13
TFTP parameters 25
D
Default IP address 13
defaults, See factory defaults
DHCP
enabling or disabling 38
IP addresses 93
UNIX systems 33
using 32
Windows servers 33
DNS server 33
Boot file tag 20
embedded Web server 58
TFTP configuration 26
Domain name
Boot file tag 21
embedded Web server 54
TFTP configuration 26
E
EAP
CA certificates 65
embedded Web server
HP Web Jetadmin 47
HTTPS security 71, 81
TFTP configuration file 28
upgrading firmware 59
using 45
viewing 48
web browsers 47
Encryption
SNMP v3 72
supported ciphers 72
F
factory defaults, resetting 85
cold-reset 85
security parameters 25, 61
firmware upgrades 7
embedded Web server 59
obtaining 7
TFTP configuration 31
ENWW 99
Index
G
gateway
bootptab file 20
description 95
embedded Web server 54
H
hardware address
arp command 42
Bootptab file 20
embedded Web server 51
in default user name 75
RARP 40
Host Access List, See Access List
HOST NAME
BOOTP tag 21
embedded Web server 53
TFTP file 26
HP Jetdirect
cold-reset 85
HP Support, Online 7
HP Web Jetadmin 9
installing 10
removing 11
HTTPS
embedded Web server 49, 71
redirection from TFTP 25
I
idle timeout
embedded Web server 54
TFTP configuration file 28
IEEE 802.1X 6
Configuration 74
installing
HP Web Jetadmin software 10
IP address
Bootptab file 20
configuring 93
default 13
embedded Web server 48, 53
resetting 85
TCP/IP overview 91
IP, See TCP/IP
ipv4-multicast
embedded Web server 58, 73
TFTP configuration file 27
J
Jetdirect certificate 65
L
link configuration
embedded Web server 58
TFTP 31
locally administered address (LAA) 58
M
MAC address, See hardware address
N
network
TCP/IP overview 90
NIS (Network Information Service) 18
P
PEAP 6
PEM (Privacy Enhanced Mail) 69
ping command 42
privacy settings
embedded Web server 52
Protected Extensible Authentication
Protocol, See PEAP
protocols
embedded Web server 57, 71
R
RARP, using 40
refresh rate
embedded Web server 59
web-refresh 29
requirements
embedded web server 47
ENWW 100
Loading...
