HP Pavilion LCD HDTV

HP Pavilion LC3700N 37-Inch (94-Centimeter) LCD High-Definition Television HP Pavilion LC3200N 32-Inch (81-Centimeter) LCD High-Definition Television HP Pavilion LC2600N 26-Inch (66-Centimeter) LCD High-Definition Television

User’s Guide

mb5ltvsh.book Page ii Monday, June 27, 2005 1:58 PM

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

HP assumes no responsibility for the use or reliability of its software on equipment that is not furnished by HP.

This document contains proprietary information that is protected by copyright. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of HP.

Hewlett-Packard Company P.O. Box 4010 Cupertino, CA 95015-4010 USA

and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license from BBE Sound, Inc. Licensed by BBE

Sound, Inc. under USP4638258, 5510752 and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

CableCARD™ is a trademark of Cable Television Laboratories, Inc. i.LINK and the i.LINK logo are registered trademarks of Sony

Electronics, Inc. This product incorporates copyright protection technology that is

protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. Apparatus Claims of U. S. Patent Nos. 4,631,603, 4,577,216, 4,819,098, 4,907,093, 5,315,448, 6,381,747, and 6,516,132.

This digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator's enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

HP supports lawful use of technology and does not endorse or encourage the use of our products for purposes other than those permitted by copyright law.

The information in this document is subject to change without notice.

Text set off in this manner indicates information you need.

Text set off in this manner indicates important information you need.

CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information.

WARNING: This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

DANGEROUS VOLTAGE: Text set off in this manner indicates the presence of uninsulated voltages within the product enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons.

mb5ltvsh.book Page iii Monday, June 27, 2005 1:58 PM

Important Safeguards

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

e CAUTION: RISK OF ELECTRICAL SHOCK w

DO NOT OPEN

CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT USE THIS POLARIZED AC PLUG WITH AN

CAUTION: TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE OR PLUG TO WIDE SLOT, FULLY

CAUTION: DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD,

THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED

“DANGEROUS VOLTAGES” WITHIN THE PRODUCT’S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRICAL SHOCK TO PERSONS. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT

OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

INSERT.

BRACKET, OR TABLE. THE PRODUCT MAY FALL CAUSING SERIOUS PERSONAL INJURY AND SERIOUS DAMAGE TO THE PRODUCT. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE RECOMMENDED BY THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE MANUFACTURER’S INSTRUCTIONS WHEN INSTALLING THE PRODUCT AND USE MOUNTING ACCESSORIES RECOMMENDED BY THE MANUFACTURER. A PRODUCT AND CART COMBINATION SHOULD BE MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND UNEVEN SURFACES MAY CAUSE THE PRODUCT AND CART COMBINATION TO OVERTURN.

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not

expressly approved by the manufacturer could void the user’s authority to operate this equipment.

iii

mb5ltvsh.book Page iv Monday, June 27, 2005 1:58 PM

CAUTION: This product satisfies FCC regulations when shielded cables and connectors are used to connect

the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■ Reorient or relocate the receiving antenna.

■ Increase the separation between the equipment and receiver.

■ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

■ Consult the dealer or an experienced radio/TV technician for help.

RESPONSIBLE PARTY: Hewlett-Packard Company

Digital TV Solutions Attn: Product Regulations Manager 10435 N. Tantau Avenue CAC 07, MS 4295 Cupertino, CA 95014 USA

Important Safety Instructions

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating, and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully before using the product.

1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with dry cloth. 7 Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8 Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9 Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

iv HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page v Monday, June 27, 2005 1:58 PM

Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by

the manufacturer.

12 Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or

when unused for long periods of time.

14 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15 Power Sources — This product should be

operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

16 Overloading — Do not overload wall outlets,

extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

17 Object and Liquid Entry — Never push objects of

any kind into this product through openings as they may touch dangerous voltage points or shortout parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18 Damage Requiring Service — Unplug this product

from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a When the AC cord or plug is damaged, b If liquid has been spilled, or objects have

fallen into the product,

c If the product has been exposed to rain or

water,

d If the product does not operate normally by

following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation,

e If the product has been dropped or damaged

in any way, and

f When the product exhibits a distinct change in

performance – this indicates a need for service.

19 Replacement Parts — When replacement parts

are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

20 Safety Check — Upon completion of any service

or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

21 The apparatus shall not be exposed to dripping or

splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus.

22 WARNING: Plug the power cord into a power

outlet where access to the power cord connector is readily accessible in case power disconnection is required.

23 Servicing: The user should not attempt to service

the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

mb5ltvsh.book Page vi Monday, June 27, 2005 1:58 PM

■ Water and Moisture — Do not use this product near water; for example, near a bath tub, wash bowl, kitchen sink,

or laundry tub; in a wet basement; or near a swimming pool; and the like.

■ Stand — Do not place the product on an unstable cart, stand, tripod, or table. Placing the product on an unstable

base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.

■ Selecting the location — Select a place with no direct sunlight and good ventilation.

■ Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block

these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug, or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed.

■ The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the product is

dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.

■ Heat — The product should be situated away from heat sources such as fireplaces, chimneys, radiators, heat

registers, stoves, or other products (including amplifiers) that produce heat.

■ The Liquid Crystal panel is a very high technology product with 3,147,264 thin film transistors, giving you fine

picture details. Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green, or red. Please

note that this does not affect the performance of your product.

■ Cautions regarding use in high and low temperature environments:

When the unit is used in low-temperature space (e.g., room, office), the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction. Storage

temperature: –4

■ Precautions when transporting the TV — When transporting the TV, never carry it by holding onto the speaker. Be

F to +140o F (–20o C to +60o C)

sure to always carry the TV by two people holding it with two hands — one hand on each side of the Display.

■ Lightning — For added protection for this television equipment during a lightning storm, or when it is left

unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

■ Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other

electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

vi HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page vii Monday, June 27, 2005 1:58 PM

■ Outdoor Antenna Grounding — If an outside

antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Antenna Grounding

Reference

Antenna Grounding

Grounding Component

Electric Service Equipment

Power Service Grounding Electrode System (NEC Art 250, Part H)

Ground Clamps

Grounding Conductors (NEC Section 810-21)

Antenna Discharge Unit (NEC Section 810-20)

Ground Clamp

Antenna Lead in Wire

■ To prevent fire, never place any type of candle or flames on the top or near the TV set.

■ To prevent fire or shock hazard, do not expose this product to dripping or splashing. No objects filled with liquids,

such as vases, should be placed on the product.

■ To prevent fire or shock hazard, do not place the AC power cord under the TV set or other heavy items.

■ Turn off the main power and unplug the AC cord from the wall outlet before handling.

■ Use a soft cloth and gently wipe the surface of the TV panel. Using a hard cloth may scratch the panel surface.

■ Use a soft damp cloth to gently wipe the panel when it is really dirty. (It may scratch the panel surface when

wiped strongly.)

■ If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.

■ To protect the panel, do not use a dirty cloth, liquid cleaners, or chemical cloth to clean it; such materials may

damage the panel surface.

■ Do not display a still picture for a long time, as this could cause an afterimage to remain.

vii

mb5ltvsh.book Page viii Monday, June 27, 2005 1:58 PM

Important Information

The TV must be serviced by an authorized service technician. The TV is not user serviceable.

Changes can damage your TV and void your warranty. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

Your TV supports use of a CableCARD, provided by your cable company, when using a direct digital connection to a cable system providing encrypted digital programming. Note that some interactive or ondemand services may still require use of a set-top box provided by the cable company. For more information, contact your cable company.

Recycling Information

For information about how to recycle this product through HP, see:

http://www.hp.com/recycle

Other recycling options may also be available in your area. If located within the U.S. and Canada, you may also call (1) (888) 485-1849.

Materials disposal

This HP product contains the following materials that might require special handling at end-of-life:

■ Mercury in the fluorescent lamp in the LCD.

Disposal of mercury may be regulated because of environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance (EIA) (http://www.eia.org).

Cleaning precautions

Unplug the TV before cleaning the screen. A special antiglare coating is applied to the screen of

your TV. Using solvents, such as alcohol, or abrasive material, such as a premoistened or chemically treated towel, may affect the screen coating or bezel paint.

Do not expose the product to volatile gas or fluid such as a pesticide.

Do not put the TV in contact with vinyl or rubber products for a long period of time. Extended contact may result in the removal of the coating or degradation of the surface.

Lifting precautions

The TV is heavy; be sure to use ergonomically correct lifting procedures when moving the TV.

Due to the size and weight of the TV, it is recommended that a minimum of two people move it.

For transport, grasp the display in the area under and above the screen.

If speakers are attached to the display, do not lift the display by the speakers; instead, use the area under and above the screen.

Never place the display with the glass screen facing downward, unless it is protected with pads.

viii HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page ix Monday, June 27, 2005 1:58 PM

Table of Contents

Important Safeguards..................................... iii

Important Safety Instructions.............................iv

Important Information ....................................viii

Getting to Know Your TV................. 1

Identifying Items in the Box .................................... 1

Locating TV Buttons and Connectors........................ 2

Cleaning ............................................................. 6

Cleaning precautions ...................................... 6

Cleaning the TV.............................................. 6

Setting Up....................................... 7

Selecting a Good Location..................................... 7

Unpacking..................................................... 7

Lifting the TV .................................................. 8

Removing or attaching the stand.......................8

Setting Up the TV................................................ 10

Attaching and connecting

the display speakers ..................................... 10

Connecting the TV signal sources.................... 11

Connecting the cable TV or the air

broadcast antenna........................................12

Using a CableCARD ..................................... 13

Connecting cable or satellite

with a set-top box ......................................... 15

Connecting a DVD player, VCR, DVR,

game console, or camcorder.......................... 17

Connecting a VCR for recording.....................23

Connecting a PC .......................................... 23

Connecting an external sound system..............24

Connecting power to the TV........................... 25

Turning On the TV ......................... 27

Turning the TV On and Off (Standby).................... 27

Using the Remote Control ..............31

Operating the TV or the Selected Device................31

Installing or replacing remote

control batteries............................................31

Identifying the remote control buttons...............32

Adjusting the Volume ..........................................34

Muting the sound ..........................................34

Changing Channels ............................................35

Selecting the last channel...............................35

Operating a DVD or other device ...................35

Displaying program information......................35

Selecting the Input Source....................................35

Changing the View with the Aspect Button .............35

Turning On Captions...........................................36

Setting SAP/MTS stereo mode..............................36

Turning On Dolby Virtual .....................................36

Setting the Sleep Timer ........................................36

Adjusting TV Settings...........................................36

Opening and exiting the OSD ........................36

Operating an i.LINK device .................................37

About i.LINK ................................................37

Setting the recording mode (i.LINK).................37

Setting the standby mode (i.LINK) ...................37

Selecting an i.LINK device .............................38

Disabling the TV’s operation of

an i.LINK device ...........................................38

Deleting registered i.LINK devices...................39

Controlling an i.LINK device...........................39

Automatic input switching to i.LINK .................41

Recording digital programs with a

D-VHS deck (i.LINK) ......................................42

Recording digital programs with an

AV-HDD recorder or Blu-ray Disc recorder..............42

Playing back using Rec List (i.LINK) .......................43

Table of Contents

Using the First-Time Setup Wizard. 29

Initial Setup........................................................ 29

Table of Contents ix

mb5ltvsh.book Page x Monday, June 27, 2005 1:58 PM

Selecting a Device to Control............................... 43

Programming the remote control for a

home entertainment device ............................44

Programming the device code........................ 44

Searching for the device code........................ 44

HP MCPC and HP DEC PCs........................... 54

Changing the TV Settings...............55

Using the OSD Menus......................................... 55

Using the Picture Menu........................................ 55

Adjusting the picture settings.......................... 56

Using the Audio Menu ........................................57

Adjusting the audio....................................... 57

Using the Power Control Menu............................. 58

Adjusting Power Control for an

AV video source........................................... 58

Adjusting Power Control for a PC source ......... 58

Using the Setup Menu......................................... 58

Starting EZ Setup.......................................... 59

Using CH Setup............................................ 59

Using Antenna Setup – Digital........................59

Using Parental CTRL...................................... 60

Setting Position............................................. 60

Using Input Signal ........................................60

Using Auto Sync........................................... 60

Using Fine Sync............................................ 60

Setting Input Label ........................................61

Setting Picture Flip ........................................61

Setting Standby Mode...................................61

Setting Language..........................................61

Using the Options Menu...................................... 61

Using the Digital Setup Menu............................... 62

Using the CableCARD Menu.......................... 62

Using the Video Setup................................... 62

Using Audio Setup........................................ 63

Using the i.LINK Setup................................... 63

Viewing TV Identification information .............. 63

Selecting the view aspect............................... 63

Using Closed Caption .........................................64

Using Parental Controls .......................................65

Secret number setting for parental

control (AV input mode only) ..........................65

Setting Parental Control V-Chip level ...............66

How to temporarily release

the V-Chip BLOCK.........................................69

Reactivating the temporarily released

V-Chip BLOCK..............................................69

Returning to Factory Presets..................................69

Finding Answers to Questions ....... 71

Understanding TV Terms......................................71

What are Analog TV, Digital TV, and

high-definition (HDTV)?..................................71

What is the difference between progressive and interlaced signal

formats for digital TVs? ..................................71

What is variable aspect ratio?........................71

What is HDMI?.............................................71

What is CableCARD, and how

does it work?................................................72

Identifying Cable Usage ......................................72

Specifications................................ 75

PC Compatibility Chart........................................77

RS-232C Port Specifications.................................78

PC control of the TV ......................................78

Troubleshooting ............................ 79

FCC Notice .................................... 83

Federal Communications Commission

Notice.........................................................83

Modifications ...............................................83

Cables.........................................................83

Recording your secret number ..............................83

x HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 1 Monday, June 27, 2005 1:58 PM

Getting to Know Your TV

Thank you for purchasing an HP Pavilion LCD Highdefinition Television. The HP Pavilion LCD HDTV is designed to deliver a fantastic image for an immersive home theater experience.

Features:

■ Premium LCD panel technology delivers up to

800:1 contrast for rich detail, fast response time for no-smear motion video, and ultrawide viewing angles with a minimum of color shift.

■ Built-in digital and analog tuning receives and

decodes HDTV, digital, and analog broadcasts received from off-air antennas and cable providers.

■ Digital cable readiness enables use of an

authorized CableCARD (certain countries/regions only) to receive digital cable television systems services directly from the cable operator without requiring a separate cable box. (Contact your local cable company for information regarding acquiring CableCARD.)

■ HDMI interface offers pure digital video and

audio quality through a lossless digital interface to DVD players, cable and satellite receivers, and AV receivers.

■ Dual i.LINK interfaces offer bi-directional digital

video, audio, and control of digital VHS players and audio/visual hard disk drive (AV HDD).

■ Dolby Digital 5.1 channel optical digital output

enables a full home theater sound experience when attached to an external Dolby Digital decoder and a multi-channel amplifier.

■ Dolby Virtual Surround delivers a compelling

virtual surround sound experience.

■ Illuminated universal remote control works with

additional components, including HP Media Center PC and HP Digital Entertainment Centers.

Identifying Items in the Box

Televisi on

TV DVD STB PVR

AUX VCR AUDIO

DEV

i.Link INPUT

MEDIA

EXIT

VOL

PAGE+

SELECT

PAGE--

VOL

INFOMUTE GUIDE RECORD

8 9

LAST

AIR

CABLE

ASPECT

MODE

SAP

DOLBY

SLEEP

MTS

VIRTUAL

Basic Setup

Connect your syste

Your connector loc

m to the bac

ations

a nd system

k panel.

compo

nents may var

Remote control unit

AC cord

Cable clamp (select models only)

Cable tie

Documentation

Display speakers with mounting hardware (most models have speakers attached)

Getting to Know Your TV

Getting to Know Your TV 1

mb5ltvsh.book Page 2 Monday, June 27, 2005 1:58 PM

Locating TV Buttons and Connectors

The TV contains controls, tuners, connectors, and the

Front TV

CableCARD slot. The TV indicators are located on the front of the TV,

and the controls are located on the top.

Item TV Front item Description

A OPC sensor Optical Picture Control (OPC) senses the surrounding light and

automatically adjusts the backlight brightness. Make sure no object obstructs the OPC sensor, which could affect its ability to sense surrounding light.

B Remote control sensor Location where to point the remote control unit.

C Power indicator Shows whether the TV is on or off/standby. Light is blue when turned on,

and is off when TV is in off/standby mode.

D OPC indicator Indicates that the OPC is on. For information on the OPC, refer to “Turning

On the TV” on page 27.

Top TV controls

–

VOLUME +CHANNEL INPUT

2 HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 3 Monday, June 27, 2005 1:58 PM

Item TV Top Control Description

A Left arrow and

right arrow buttons (volume)

B Down arrow and

up arrow buttons (channel)

C Input button Selects an LCD TV input source.

D Power button Turns on the TV or places it in standby mode.

Press the left arrow button to lower the sound, and press the right arrow to raise the sound.

Press the up and down buttons to select the next lower or higher channel.

Rear TV connectors

The connectors are located on the side of the TV. They are located in sections by the following types of connections: tuners (digital and analog inputs), S-video, component, and AV inputs (Inputs 1, 2, 3), i.LINK, CableCARD, RS-232, DVI (Input 5), HDMI (Input 4), and power.

Item TV (Rear) Description

A S-video or

Video, with Audio left and right (Input 3)

Getting to Know Your TV

Connect an S-video cable and left-right audio cables from optional equipment. Or, connect composite video and left-right audio cables. Audio connectors are shared.

B Component

Video or Video with Audio left and right (Input 1)

Connect Component Video cables and leftright audio cables from optional equipment. Supports standard inputs 480i, 480p, 720p, and 1080i. The TV automatically determines what has been connected. Some set-top boxes must be set for a specific resolution out. Or, connect composite video and left-right audio cables. Audio connectors are shared.

Getting to Know Your TV 3

mb5ltvsh.book Page 4 Monday, June 27, 2005 1:58 PM

Item TV (Rear) Description

C Monitor

Out/Rec Out terminals

D Component

Video or Video with Audio left and right (Input 2)

Output for monitoring or recording video. Connect an S-video cable and left-right audio cables. Or, connect composite video and left-right audio cables. Audio connectors are shared.

Identical to Input 1.

Item TV (Rear) Description

E Digital

Audio Output

F Analog Air/

Cable TV In

G Digital Air

TV In

H Digital

Cable TV In

I System

Reset

J Reset Press if TV cannot return

Press Reset (J) if the TV cannot return to its original state after performing various operations; the resulting values are:

Optical connection for external audio system.

Connect an analog air TV or analog cable.

Connect a digital air TV antenna cable.

Connect a digital cable TV signal cable.

Press if TV does not operate after starting up.

to its original state after performing an option.

■ AV Mode resets to Dynamic (fixed)

■ TV channel returns to initial channel (Air: channel

2, Cable: channel 1 or 2)

■ Audio setting initializes

■ Dolby Virtual resets to off

■ Image position initializes

Press System Reset (I) if the TV does not operate after starting up.

■ Pressing Reset will not work if the TV is

in standby mode.

■ Pressing Reset will not delete channel

preset or secret number. See “Secret number setting for parental control (AV input mode only)” on page 65. See “Returning to Factory Presets” on page 69 for initializing to the factory preset values when you forget your secret number.

4 HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 5 Monday, June 27, 2005 1:58 PM

Rear TV connectors (continued)

Item TV (Rear) Description

AA i.LINK Connect a 4-pin i.LINK cable from optional digital equipment in your

home theater system.

AB CableCARD (certain

countries/regions only)

Insert a cable company-provided card to receive standard definition or high-definition programs instead of using a separate set-top box.

Getting to Know Your TV

AC RS-232 Terminal Used for industrial control applications.

AE/ AD

AF High-Definition Multimedia

Input 5 terminal (DVI-I with audio)

Connect a PC using DVI video and audio (3.5 mm stereo mini-jack). Can connect VGA by using an RGB-to-DVI conversion cable or adapter.

Connect an HDMI cable for digital, high-definition optional equipment. Interface (HDMI) Input (Input 4)

AG AC in (power) cord Connect the included power cord. Note: Use only the provided power

cord.

Getting to Know Your TV 5

mb5ltvsh.book Page 6 Monday, June 27, 2005 1:58 PM

Cleaning

Cleaning precautions

Unplug the TV before cleaning the screen. A special antiglare coating is applied to the screen of

your TV. Using solvents, such as alcohol, or abrasive material, such as a premoistened or chemically treated towel, may affect the screen coating or bezel paint.

Do not expose the product to volatile gas or fluid such as a pesticide.

Do not put the TV in contact with vinyl or rubber products for a long period of time. Extended contact may result in the removal of the coating or degradation of the surface.

Cleaning the TV

Clean the screen by spraying a soft lint free cloth with water to lightly moisten it. Gently wipe the screen and avoid pressing on the screen.

To clean the outer cabinet, use the same method. Do not use liquid or aerosol cleaners.

6 HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 7 Monday, June 27, 2005 1:58 PM

HP recommends professional installation from an authorized installer to ensure maximum enjoyment of your HP Pavilion LCD HDTV. Be sure to read all the safety information and precautions before starting installation. See these topics:

Setting Up

■ “Important Safeguards” on page iii

■ “Important Safety Instructions” on page iv

Selecting a Good Location

Select the location for your HP Pavilion LCD HDTV. To position the TV, consider:

■ Power cord length: Choose a location with easy

access to an AC power outlet.

■ Cable lengths and distances to attached units:

Check that cables can reach the TV.

■ Do not install the TV on an unstable cart or stand;

the unit may fall over and cause injury.

■ Do not install the TV where it has a protruding

edge, such as on a small table where the display overhangs the table surface.

■ Do not hang the TV from the ceiling; the unit may

fall and cause injury.

■ Avoid direct sunlight that may damage the display

or interfere with the operation of the remote control.

■ Avoid areas of high humidity or damp conditions

that may cause fire or electrical shock.

■ Do not install TV near appliances, such as a

microwave, or near a heat source, such as a fireplace or radiator.

■ Provide adequate ventilation clearance around

the TV.

■ “Important Information” on page viii

A 1.4 in (3.5 cm) minimum above TV

Setting Up

B 1.4 in (3.5 cm) minimum at sides C 1.4 in (3.5 cm) minimum behind TV

Unpacking

Be sure to read through “Lifting the display” for important information.

Setting Up 7

mb5ltvsh.book Page 8 Monday, June 27, 2005 1:58 PM

Unpack the TV and put it on a stable surface:

1 Use the cardboard holders on either side of the TV

to remove it from the box.

2 Remove the cardboard; however, keep the

wrapping on the TV to protect it while moving.

3 Lift the TV onto the installation location.

Lifting the TV

The TV is heavy; be sure to use ergonomically correct lifting procedures when moving the TV.

Due to the size and weight of the TV, it is recommended that a minimum of two people move it.

To transport the TV, grasp the display in the area under and above the screen.

Removing or attaching the stand

Your TV comes with a stand already attached to the display.

Removing the stand

Before removing the stand, unplug the AC cord from the AC input terminal.

1 Place a pad or foam (A) on a stable table. 2 Carefully place the TV with the glass screen facing

downward on the pad. Position it with the stand hanging over the edge of the table; hold the stand in place.

WARNING: The stand is heavy. Do not drop the stand.

If speakers are attached to the TV, do not lift the TV by the speakers; instead, use the area under and above the screen.

Move the product gently. Never place the TV with the glass screen facing downward, unless it is protected with pads.

3 Proceed with the steps for your type TV stand:

■ For a paddle-type stand, continue with step 4.

■ For a pedestal-cover stand, continue with

step 5.

8 HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 9 Monday, June 27, 2005 1:58 PM

For the TV with a paddle-type stand, hold the stand

in place and remove the four screws that secure the stand to the TV. Lift the stand off the TV. This completes stand removal for this type of stand.

A: Pad protecting TV with paddle-type stand

6 Four screws (D) secure the pedestal to the TV

chassis in the mounting area. The tabs (C) in the mounting area form the slot for the pedestal leading edge. Remove the four screws (D), and then slide the pedestal straight out of the TV.

5 For the TV with a pedestal-cover stand, remove the

retaining screw from the stand pedestal cover (B in next figure). Remove the cover.

A: Pad protecting TV with pedestal-cover stand B: Pedestal cover

Setting Up

Installing the stand

Before attaching the stand, unplug the AC cord from the AC input terminal.

Setting Up 9

mb5ltvsh.book Page 10 Monday, June 27, 2005 1:58 PM

1 Carefully place the TV with the glass screen facing

downward on a padded, stable table. Position the bottom of the TV near the edge of the table.

Refer to the figures in “Removing or attaching the stand” on page 8.

WARNING: The stand is heavy. Do not drop the stand onto the TV.

2 Proceed with the steps for your type TV stand:

■ For a paddle-type stand, continue with step 3.

■

For a pedestal-cover stand, continue with step 5.

3 For the TV with a paddle-type stand, position the

stand on the TV and align the four screw holes. (Refer to the figure in step 4 of the previous procedure.) Insert the four screws to secure the stand to the TV.

4 Carefully lift the TV and set it upright. This

completes stand installation for this type stand.

5 For the TV with a pedestal-cover stand, the tabs

(C) in the mounting area of the TV from the slot for the pedestal leading edge. (Refer to the figure in step 6 of the previous procedure.) Hold the stand with the front (thin) edge pointing down and the pedestal horizontal. Lower the stand onto the TV with the pedestal in the mounting area. Then, slide the stand forward until the leading edge is underneath the tabs (C) and the screw holes (D) align.

6 Insert the screws into the four holes (D). 7 Position the pedestal cover (B) over the pedestal,

tip the cover to place the top edge into the mounting area, and then lower the cover onto the pedestal. (Refer to the figure in step 5 of the previous procedure.) Move the cover to align the cover with the screw hole, and insert the retaining screw.

8 Carefully lift the TV and set it upright. This

completes stand installation for this type stand.

Setting Up the TV

Set up the TV by attaching and connecting the display speakers, connecting cables, and connecting the power cord. Some TV models come with speakers attached.

10 HP Pavilion LCD HDTV User’s Guide

Attaching and connecting the display speakers

Speakers with speaker cables attach to each side of the display. The right speaker is located on the right side of the display when it is viewed from the front.

The TV has a digital audio output that you can connect to a separate external amplifier.

mb5ltvsh.book Page 11 Monday, June 27, 2005 1:58 PM

To use a separate external amplifier or a stereo system, refer to “Connecting an external sound system” on page 24.

CAUTION: Unplug power for the TV and all connected components before attaching or connecting speakers.

1 Position the TV display upright on its stand. 2 Place a speaker onto the TV display and insert the

screws to secure it. Use the long screws for the top and bottom, and the short screw in the middle. Select models use only two screws.

Connecting the TV signal sources

The following is an explanation of the types of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set.

3 Plug the speaker into the TV. 4 Repeat these steps for the other speaker.

Setting Up

■ A 75-ohm system is generally a round cable with

an F-type connector that can easily be attached to a terminal without tools (sold separately).

■ A 300-ohm system is a flat, twin-lead cable that

can be attached to a 75-ohm terminal through a 300/75-ohm adapter (sold separately).

Setting Up 11

mb5ltvsh.book Page 12 Monday, June 27, 2005 1:58 PM

An F-type connector should be fingertightened only. When connecting the RF cable to the TV set, do not use tools to tighten the F-type connector, as it may cause damage to your TV set.

Connect the input sources to the TV according to the type of connection:

■

Antenna or basic cable (TV cable or satellite) without using a set-top box: see “Connecting the cable TV or the air broadcast antenna” on page 12.

■ Cable with a CableCARD (U.S. only): see “Using

a CableCARD” on page 13.

■ Cable or satellite with a separate set-top box: see

“Connecting cable or satellite with a set-top box” on page 15.

A: 75-ohm coaxial cable, round B: 300-ohm twin-lead cable, flat C: F-type connector

D: Use fingers to tighten F-type connector.

Connecting the cable TV or the air broadcast antenna

Use standard 75-ohm coaxial cable to connect a ground antenna or cable TV input source to the TV. Use shielded coaxial cable to reduce radio frequency (RF) interference.

Optional equipment, cable TV service, splitters, combiners, and all cables are sold separately.

CAUTION: Unplug power for the TV and all connected components before connecting the antenna or cable.

■ To connect an external sound system, see

“Connecting an external sound system” on page 24.

■ To connect a device that records TV, use

Terminal 3 (Monitor Out/Record Out) for a VCR or use the i.LINK Terminal. (Note that i.LINK records only digital programs.)

1 Connect the input source coaxial cable to the

Analog Air In (A), Digital Air In (B), or Digital Cable In (C) connectors on the back of the TV.

■

For broadcast signals, you can use a combiner to add together your VHF antenna, UHF antenna, and digital antenna. Then, use a splitter (

) to connect the signal cable to both the Analog

Air In and Digital Air In connectors (

■

For cable without a CATV converter, use a combiner to add together your broadcast antenna signals (see previous bullet) and the cable signal. Then, use a splitter ( the signal cable to both the Analog Air In and Digital Air In connectors (

■

For cable with a CATV converter, use a splitter (

) to connect the signal cable to both the Analog Air In and Digital Cable In connectors (

) on the TV.

) to connect

12 HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 13 Monday, June 27, 2005 1:58 PM

You can use either Digital Cable In or Digital Air In, or use both. To view low numbered cable channels, be sure to connect your cable TV source to the Analog In connector.

A: Analog Air In connector B: Digital Air In connector

E: Splitter F: Analog In and Digital Air In

C: Digital Cable In connector D: Antenna (air analog or air digital signal

source)

2 Connect power to the TV; see “Connecting power

to the TV” on page 25.

Using a CableCARD

Use these steps when you have a CableCARD (certain countries/regions only) for premium digital cable service and you do not want to use a set-top box from the cable provider.

To use a digital set-top box, refer to “Connecting cable or satellite with a set-top box” on page 15.

If you change your address, return the CableCARD to your cable company. Obtain a new CableCARD from your new cable provider.

G: Cable at wall (cable analog or cable

digital signal source)

H: Analog In and Digital Cable In

3 Turn on the TV; see “Turning the TV On and Off

(Standby)” on page 27.

Your TV supports use of a CableCARD, provided by the cable company, when using a direct digital connection to a cable system providing encrypted digital programming. Note that some interactive or on-demand services may still require use of a set-top box provided by the cable company. For more information, contact your cable company.

Setting Up

Setting Up 13

mb5ltvsh.book Page 14 Monday, June 27, 2005 1:58 PM

About Emergency Alert System (EAS)

■ In the case of a national emergency, natural

disaster, or other emergency situation, an EAS message broadcasts. When this unit receives an EAS message, if the level of emergency is comparatively low, an alert text message displays on screen. If the level of emergency is high, the receiver is forced-tuned to a details channel.

■ Alert text messages display, and forced tuning

occurs, even during paid programming. Even when forced tuning is active, the user can still change the channel.

■ If the unit is forced-tuned to a channel that has

been blocked by Parental Control, the Parental Control setting is given priority, and the EAS message is not broadcast.

■ If you have a digital cable antenna connected,

you can receive EAS messages whether CableCARD is inserted or not.

■ EAS messages may be broadcast not only through

digital cable, but also through analog cable or over-the-air Analog transmission.

■ When forced tuning occurs, video output from the

Monitor Out terminal is also switched to the details channel.

■ An alert text message does not output from

Monitor Out terminal.

Connecting and initiating CableCARD

Optional equipment and all cables are sold separately.

1 Connect the cable TV input source using the

Digital Cable In connector, as described in the previous procedure, “Connecting cable TV or the air broadcast antenna.”

AB: CableCARD slot with dust cover

3 With the TV on, insert the CableCARD provided

by your cable company into the card slot (AB) on the back of the TV. Insert the card with the upper side facing right. Wait for the CableCARD message to appear; it may take several minutes to do so.

2 Remove the dust cover from the CableCard

slot (AB).

14 HP Pavilion LCD HDTV User’s Guide

CAUTION: DO NOT remove the power cord while the CableCARD is inserted.

4 When the message appears, read it and contact

your cable provider to enable the card.

mb5ltvsh.book Page 15 Monday, June 27, 2005 1:58 PM

Removing CableCARD

Disconnecting the cable antenna when using CableCARD

1 Turn on the TV; see “Turning the TV On and Off

(Standby)” on page 27.

2 Check that the CableCARD upgrade screen is not

displayed. If it is displayed, wait until it disappears.

3 Check that the OPC light on the front of the TV is

NOT red; see “Turning the TV On and Off (Standby)” on page 27. If it is red, wait for the OPC light to change or go out.

1 Turn on the TV; see “Turning the TV On and Off

(Standby)” on page 27.

2 Check that the CableCARD upgrade screen is not

displayed. If it is displayed, wait until it disappears.

3 Check that the OPC light on the front of the TV is

NOT red. If it is, wait for it to change or go out.

4 Disconnect the cable antenna.

4 Remove the CableCARD.

For more information about CableCARD, refer to “Using the CableCARD Menu” on page 62.

Connecting cable or satellite with a set-top box

Connecting your TV directly to the audio and video output of your set-top box assures a more vivid picture and enhances your viewing enjoyment.

Optional equipment and all cables are sold separately. You can connect a digital TV set-top box (air or cable)

and other audiovisual equipment by using:

1 Connect the set-top box input source cable(s) to

the back of the TV using one of the terminals sets.

■ Input 1 (A) or Input 2 (E) using component

connections. (Input 1 shown.)

■ Input 1 terminals with either component or

composite video connections

■ Input 2 terminals with either component or

composite video connections

■ Input 4 terminals with HDMI connection

■ Input 5 terminals with DVI connections

If your cable TV company has CableCARD available, you can also use the CableCARD to receive HDTV programs. See “Using a CableCARD” on page 13.

CAUTION: Unplug power for the TV and all connected components before connecting the set-top box.

Setting Up

Setting Up 15

mb5ltvsh.book Page 16 Monday, June 27, 2005 1:58 PM

A: Input 1, with component, composite video,

and audio connectors B: Component video cable C: Audio cable D: Digital TV set-top box output connectors E: Input 2, with component, composite video,

and audio connectors

■ Input 1 (A) or Input 2 (D) using composite

video connections. (Input 1 shown in figure.)

■ Input 4 using HDMI connection

Refer to “Connecting an HDMI device” on page 18 for connecting a digital TV set-top box or other device using the HDMI terminal.

■ Input 5 using DVI connections

A: Input 1, with component, composite video,

and audio connectors B: Composite video cable with video and

audio connectors C: Digital TV set-top box output connectors D: Input 2, with component, composite video,

and audio connectors

A: Input 5, with DVI-I video, and audio (C)

connectors B: DVI-I video cable C: Input 5 audio connector D: Audio cable E: Digital TV set-top box output connectors

2 Connect the cables to the set-top box. 3 Turn on the set-top box. 4 Connect power to the TV (see page 25). Turn on

the TV; see “Turning the TV On and Off (Standby)” on page 27.

5 Select the input source and scan for channels; see

“Using the First-Time Setup Wizard” on page 29.

16 HP Pavilion LCD HDTV User’s Guide

mb5ltvsh.book Page 17 Monday, June 27, 2005 1:58 PM

Connecting a DVD player, VCR, DVR, game console, or camcorder

You can connect optional equipment (sold separately), such as a DVD player, VCR, DVR, and so on, to the TV by using the AV input connectors.

Optional equipment, including an external sound system, and all cables are sold separately.

You can connect a DVD by using:

■ Input 1 terminals with either component or

composite video connections.

■ Input 2 terminals with either component or

composite video connections.

■ Input 3 terminals with either S-video or composite

video connections.

Choosing the AV connection to use

When connecting optional equipment as signal sources, the connectors on the equipment may limit the type of connection you can use.

When your optional equipment has more than one type of output connector, choose the connection that provides the best quality play back image.

■ Input 4 terminals with HDMI connection.

■ Input 5 terminals with DVI connections.

You can connect a VCR by using Input 3 terminals with either S-video or composite video connections for playback, and by using Monitor Out/Rec Out terminals for recording (input to the VCR). See “Connecting a VCR for recording” on page 23 to use the Monitor Out/Rec Out terminals.

You can connect a game console, camcorder, and some other AV equipment by using Input 3 terminals with either S-video or composite video connections.

You can connect HDMI equipment by using Input 4 terminal with an HDMI connection.

You can connect DVI equipment by using the Input 5 terminals with an DVI-I connection.

You can connect i.LINK equipment by using one of the i.LINK terminals.

For best results, choose the best quality connection type that is supported by your optional equipment.

The following table lists the available optional AV equipment connections on the TV.

Setting Up

AV connection to use, listed from best to good video playback

Connection Description TV Connector Cable Plug

HDMI transmits an all digital signal and is the

recommended choice for playback from a digital DVD or DVR.

DVI transmits an all digital video signal for playback from a digital DVD or DVR.

i.LINK transmits an all digital signal. Multiple

4-pin devices can be connected using an i.LINK connector. A device connected using i.LINK can be set up to record high-definition television. The TV has two S400 (4-pin) i.LINK connectors. See “Connecting an i.LINK device” on page 19.

Setting Up 17

mb5ltvsh.book Page 18 Monday, June 27, 2005 1:58 PM

AV connection to use, listed from best to good video playback (Continued)

Connection Description TV Connector Cable Plug

Component (Y, Pb, Pr) transmits video as separate

red, green, and blue signals. Use this connection for high-definition video signals in 480i, 480p, 720p, or 1080i format from a progressive scan DVD or other equipment.

S-video transmits video in separate color and black-and-white image signals and delivers a sharper image than a composite video connection.

AV In video (composite) transmits video as a single signal.

The procedures that follow, presented in the order listed in the table, describe connecting optional equipment including the audio connections when applicable.

CAUTION: Unplug power for the TV and all connected components before connecting optional equipment. Ensure that the optional equipment is powered off.

Connecting an HDMI device

This is the recommended connection for video and audio. The HDMI cable is sold separately.

1 Connect the HDMI cable to INPUT 4 (A). (There

are no separate audio inputs for HDMI.)

18 HP Pavilion LCD HDTV User’s Guide

A: Input 4, with HDMI digital video with

audio connector B: HDMI cable C: HDMI device output connectors

mb5ltvsh.book Page 19 Monday, June 27, 2005 1:58 PM

Connect the cable to the HDMI device (C).

2 3 Turn on the device, and start play. 4 Connect power to the TV (see page 25). 5 Turn on the TV; see “Turning the TV On and Off

(Standby)” on page 27.

6 Select the input source by pressing the Input button

on the remote control or on the TV.

7 Define the HDMI Setup items under Options in the

Menu screen displays; refer to “Using the Options Menu” on page 61.

Connecting a DVI device

The DVI cable and the audio cable are sold separately.

1 Connect the DVI-I cable (B) and an audio cable

(D) to the Input 5 connectors.

2 Connect the cables to the DVI device (E). 3 Turn on the device, and start play. 4 Connect power to the TV (see page 25). 5 Turn on the TV; see “Turning the TV On and Off

(Standby)” on page 27.

6 Select the input source by pressing the Input button

on the remote control or on the TV.

7 Define the type of device connected to Input 5

(DVI) by using Input Select under Options in the Menu screen displays; refer to “Using the Options Menu” on page 61.

Connecting an i.LINK device

This is an all-digital connection for video. The i.LINK cables are sold separately.

Only D-VHS decks, AV HDD recorders, and Blu-ray Disc recorders can be connected to this TV with i.LINK. Device recognition, control, recording, and playback operations may not be possible on some devices. Other devices such as DVD recorders, digital video cameras, PCs, or PC peripheral devices do not meet the specifications for this TV and cannot be connected with i.LINK.

A: Input 5, with DVI-I video, and audio (C)

connectors B: DVI-I video cable C: Input 5 audio connector D: Audio cable E: DVI device output connectors

Only digital programs can be recorded by an i.LINK devices connected to this TV using the i.LINK. (Analog broadcasts or external input signals from Input terminals 1 through 5 cannot be recorded by i.LINK.)

DO NOT connect a PC using i.LINK. Instead, refer to “Connecting a PC” on page 23.

Setting Up

Setting Up 19

mb5ltvsh.book Page 20 Monday, June 27, 2005 1:58 PM

Connecting two or more i.LINK devices

Up to 16 i.LINK devices can be connected using a daisy-chain connection with i.LINK cables.

When 3 or more i.LINK devices are connected, branch connection can be used. With branch connections, up to 62 i.LINK devices can be connected.

Cautions regarding i.LINK connection

■ Use S400 type i.LINK cables.

■ Some i.LINK devices may not relay data if their

power is off. In this case the device should be connected at the end of any series of connections.

■ This TV can relay data during power off, by

selecting Active in the Standby Mode option in i.LINK Setup menu. See “Setting the standby mode (i.LINK)” on page 37.

■ Do NOT use a loop connection as shown in the

diagram.

■ When using i.LINK, do not turn off the power of or

pull the cable from i.LINK devices, even if those i.LINK devices are not in use. This may affect the picture and the sound from an i.LINK device in use.

■ If devices such as a DVD recorders, digital video

cameras, PCs, and PC peripheral devices that are not compatible with this TV, are connected to the TV using i.LINK, other i.LINK connections may be disrupted.

■ When device recognition, control, recording, or

playback, on an i.LINK connected device does not function correctly, correct operation may be restored by disconnecting and reconnecting the i.LINK cable.

■ When connecting multiple i.LINK devices,

depending on the specifications and the interoperability of the connected devices, their operation may not be stable.

In that case, disconnecting all devices not in use and changing the method of connection may result in stable operation.

20 HP Pavilion LCD HDTV User’s Guide

+ 292 hidden pages
