HP Pavilion a387x User Manual
user’s guide
The information in this document is subject to change without notice.
Hewlett-Packard® Company makes no warranty of any kind with regard to this material, including,
but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
HP shall not be liable for errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this material.
THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE EXTENT
LAWFULLY PERMITTED, DO NOT EXCLUDE, RESTRICT OR MODIFY AND ARE IN ADDITION
TO ANY MANDATORY STATUATORY RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT
OR SERVICE TO YOU.
HP assumes no responsibility for the use or reliability of its software on equipment that is not
furnished by HP.
This document contains proprietary information that is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced, or translated to another
language without the prior written consent of HP.
Hewlett-Packard Company
P.O. Box 4010
Cupertino, CA 95015-4010
USA
© 2000, 2003 Hewlett-Packard Development Company, L.P. All rights reserved.
Hewlett-Packard is a registered trademark of Hewlett-Packard Company in the United States of
America and other countries/regions.
This product incorporates copyright protection technology that is protected by method claims of
certain U.S. patents and other intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection technology must be authorized by
Macrovision Corporation, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098, and 4,907,093 licensed for
limited viewing uses only.
Other brand or product names are trademarks of their respective holders.
HP supports lawful use of technology and does not endorse or encourage the use of our products for
purposes other than those permitted by national copyright law.
table of contents
finding answers to commonly asked questions .............................. 1
safety information .........................................................................................2
setting up your pc .......................................................................... 3
putting your pc together ................................................................................3
safety and comfort ....................................................................................4
pc back ...................................................................................................5
pc front....................................................................................................7
connecting the modem ..................................................................................8
upgrading your 56k modem ......................................................................9
setting up the ethernet connection ...................................................................9
turning on your pc for the first time ...............................................................10
registering your pc......................................................................................11
turning off the pc ........................................................................................11
standby mode ........................................................................................12
hibernation mode ...................................................................................12
automatic standby or hibernation .............................................................13
making recovery cds/dvds ..........................................................................14
installing software and hardware devices ......................................................14
transferring your old pc information and files to your new pc .......................14
learning the basics ....................................................................... 15
beginning to use your software ....................................................................15
using the desktop........................................................................................16
using the start menu ................................................................................16
using hp organize software......................................................................17
learning to use your pc............................................................................17
using the all programs menu ....................................................................18
organizing your all programs list ..............................................................18
using pc help & tools...............................................................................19
table of contents
iii
using the mouse .........................................................................................19
scrolling ................................................................................................20
autoscrolling ..........................................................................................20
panning ................................................................................................20
switching mouse button functions ..............................................................21
changing mouse pointer speed................................................................. 21
using the keyboard ..................................................................................... 21
about your keyboard ..............................................................................21
wireless keyboard set.............................................................................. 24
standard keyboard features .....................................................................24
customizing the buttons ...........................................................................29
adjusting the monitor ..................................................................................29
using a printer............................................................................................ 30
using the internet ......................................................................... 31
about the internet .......................................................................................31
setting up your internet account ....................................................................32
signing up for a new or an existing isp account using easy internet sign-up ... 33
using a browser .........................................................................................33
searching the internet.................................................................................. 34
restricting internet content ............................................................................ 34
sending and receiving e-mail .......................................................................35
if using outlook express ........................................................................... 35
if your isp provides the e-mail program .....................................................36
getting help.................................................................................. 37
help and support center .............................................................................. 37
instant support ........................................................................................... 37
using updates from hp................................................................................. 38
getting messages ....................................................................................38
turning off messages ...............................................................................38
re-enabling messages.............................................................................. 39
resolving problems .....................................................................................39
upgrading and servicing the pc................................................................ 39
warranty & support guide........................................................................ 39
online guides .........................................................................................40
web sites about your pc ..........................................................................40
microsoft windows xp operating system .................................................... 40
working with sound, pictures, and video ..................................... 41
using speakers ...........................................................................................41
adjusting speaker volume ........................................................................42
connecting a multi-channel speaker system to your pc ................................. 42
iv user’s guide
using a microphone ....................................................................................44
adjusting microphone volume...................................................................45
using the microphone with multi-channel audio...........................................45
working with digital images .........................................................................46
using hp image zone ..............................................................................46
about the 7-in-1 memory card reader........................................................48
using your cd, dvd, and diskette drives .........................................................50
handling cds/dvds..................................................................................51
inserting and removing cds and dvds ........................................................51
using the combo drive .............................................................................52
using the diskette (floppy) drive ................................................................53
playing cds and dvds..................................................................................53
playing music cds with musicmatch jukebox...............................................53
playing cds and dvds with windows media player......................................54
playing dvd movies with the intervideo windvd player ................................55
creating (burning) cds with recordnow! .........................................................57
creating (burning) music cds with windows media player ................................59
creating (burning) data cds using windows xp program ..................................59
creating (burning) dvds using the dvd writer drive ..........................................60
using a tv as a monitor................................................................................60
cables you may need ..............................................................................60
connecting to a tv set ..............................................................................61
viewing the pc image on your tv screen.....................................................62
disabling the tv option.............................................................................63
disconnecting the tv ................................................................................63
using your multi-storage bay ........................................................................63
storing cds, dvds, or memory ...................................................................64
docking a peripheral device ....................................................................64
placing a peripheral device on the multi-storage bay (top)...........................65
using the optional camera station pc top ...................................................66
taking care of your pc .................................................................. 69
protecting your pc from power surges ...........................................................69
using virus protection programs....................................................................69
increasing available hard disk drive space ....................................................70
unavailable hard disk drive space ............................................................70
emptying the recycle bin..........................................................................71
uninstalling programs..............................................................................71
removing desktop icons ...........................................................................72
cleaning up your hard disk drive ..............................................................72
troubleshooting............................................................................ 73
table of contents
v
using application recovery and system recovery .......................... 85
creating recovery cds/dvds ......................................................................... 88
using recovery cd-dvd creator ...................................................................... 89
using the recovery tools cd ..........................................................................90
system restore ............................................................................................90
application recovery ................................................................................... 91
system recovery..........................................................................................92
starting system recovery if the pc is responding.......................................... 92
starting system recovery if the pc is not responding .................................... 93
system recovery using recovery discs ........................................................93
starting system recovery using recovery discs.............................................93
upgrading and servicing the pc .................................................... 95
upgrading and servicing the pc (1) ............................................... 97
opening and closing the pc .........................................................................98
preparing the pc ....................................................................................98
before opening the pc............................................................................. 98
after closing the pc .................................................................................98
removing the side panel ..........................................................................99
replacing the side panel.......................................................................... 99
locating components inside the pc .......................................................... 100
removing the front panel........................................................................ 100
replacing the front panel .......................................................................101
removing and replacing drives................................................................... 102
removing an optical drive...................................................................... 103
installing an optical drive ......................................................................103
removing the 7-in-1 memory card reader or the diskette (floppy) drive ........105
installing the 7-in-1 memory card reader or the diskette (floppy) drive......... 106
removing the preinstalled hard drive .......................................................107
replacing the preinstalled hard drive....................................................... 109
installing a second hard drive ................................................................ 110
removing a second hard drive ...............................................................113
adding memory........................................................................................ 114
about installing ddr dimms..................................................................... 114
removing a memory module ..................................................................115
installing a memory module ...................................................................115
add-in cards ............................................................................................116
removing an add-in card ....................................................................... 117
installing an add-in card........................................................................ 117
replacing the battery.................................................................................118
vi user’s guide
upgrading and servicing the pc (2) ............................................. 119
chassis features of the pc ...........................................................................119
opening the computer ...............................................................................120
before you begin ..................................................................................120
removing the side panel ........................................................................121
removing the fan duct............................................................................122
removing the drive cage........................................................................123
adding memory........................................................................................125
dimms .................................................................................................125
ddr dimms ...........................................................................................126
installing a memory module ...................................................................126
removing a memory module...................................................................127
installing add-in cards ...............................................................................128
what is plug and play?..........................................................................130
if the new card or device isn’t working....................................................130
adding and removing drives ......................................................................131
installing a second hard drive ................................................................131
removing the preinstalled hard drive .......................................................132
replacing the diskette drive ....................................................................132
replacing the optical drive .....................................................................134
replacing the battery.................................................................................139
closing the computer .................................................................................140
replacing the drive cage........................................................................141
replacing the fan duct ...........................................................................143
replacing the side panel ........................................................................144
index ......................................................................................... 145
table of contents
vii
viii user’s guide
finding answers to commonly asked
questions
In this User’s Guide, you can find answers to questions about the following
topics:
• Connecting to the Internet, page 32
• Registering your product, page 11
• Creating a CD, page 57
Saving documents, photos, and videos on a CD, page 57
Recording a music CD, page 58
Copying a CD, page 57
Backing up your files to a CD, page 58
• Watching movies on your PC, page 55
• Connecting to a TV, page 60
• Getting digital pictures onto your PC, page 46
• Connecting a printer, page 30
• Finding help if something doesn’t work, page 37
• Keeping your PC healthy, page 69
• Going back a day (System Restore), page 90
• Recovering your PC, page 85
• Adding memory, page 95
NOTE: This guide contains details on options that may not be included with
your PC. Your PC may look different from the illustrations in this guide. The
monitor and the speakers are sold separately. Speakers may be included with
the monitor (select models only).
finding answers to commonly asked questions
1
w
safety information
This product has not been evaluated for connection to an “IT” power system
(an AC distribution system with no direct connection to earth, according to
IEC 60950).
ac power safety warnings
WARNING: Install the PC near an AC outlet. The AC power cord
is your PC’s main AC disconnecting device and must be easily
accessible at all times. For your safety, the power cord provided
ith your system has a grounded plug. Always use the power cord
with a properly grounded wall outlet to avoid the risk of
electrical shock.
WARNING: To reduce the possibility of an electric shock from the
telephone network, plug your PC into the AC outlet before
connecting it to the telephone line. Also, disconnect the telephone
line before unplugging your PC from the AC power outlet.
WARNING: Your system is provided with a voltage select switch
for use in a 115 or 230 VAC power system. The voltage select
switch has been pre-set to the correct voltage setting for use in the
particular country/region where it was initially sold. Changing the
voltage select switch to the incorrect position can damage your PC
and void any implied warranty.
WARNING: Always disconnect the modem cord from the telephone
system before installing or removing your PC cover.
WARNING: Do not operate the PC with the cover removed.
WARNING: The power supply is not user-serviceable. To prevent
damage to the power supply, have a qualified person repair or
replace it. All other components are user-serviceable.
WARNING: Electrostatic discharge (ESD) can damage disk drives,
add-in cards, and other components. If an ESD station is not
available, wear a wrist strap attached to a metal part of the PC.
Place cards on a conductive foam pad or inside the card wrapper, if
possible, but never on the card wrapper.
2 user’s guide
setting up your pc
putting your pc together
Follow the quick setup poster to set up your PC.
Look in the PC box for printed details or updates regarding your model PC.
When placing your PC, consider an ergonomic arrangement of the PC and your
work area to maintain your comfort and productivity. Refer to “safety and
comfort” on page 4.
WARNING: The power supply is pre-set for the country/region in
which you purchased your PC. If you move, please check the
voltage requirements before plugging your PC into an AC power
outlet.
setting up your pc
NOTE: Refer to “protecting your pc from power surges” on page 69 for
information on protecting your PC.
Put your PC together in this order:
1 Position the PC chassis and connect the power cord to the chassis and to the
power outlet, but do not turn on the PC.
2 Position the monitor (sold separately) and connect the power cord to the
power outlet, but do not turn on the monitor. Connect the monitor cable to
the PC.
3 Position the keyboard and the mouse and connect each to the PC.
NOTE: Your PC uses active speakers only. Active speakers have a power cord
and connect to the green Audio Out connector on the back of the PC. Passive
speakers have no power cord or power switch.
4 Position speakers (select monitor models include speakers), connect them to
the PC, and then connect the speaker power cord to the power outlet, but do
not turn on the speakers.
3
5 Connect the modem cable to the telephone line wall jack and to the modem
(select models only) on the back of the PC. Refer to “connecting the modem”
on page 8 for details.
6 Turn on the monitor. Turn on the PC. Turn on the speakers. Follow the
onscreen instructions and complete the initial windows until you see the
desktop. Refer to “turning on your pc for the first time” on page 10 for details.
7 Restart the PC: Click the Start button on the taskbar, click Turn Off
Computer, and then click Restart. The PC turns off and then starts again. This
completes the initial startup process.
safety and comfort
After assembling your PC, but before you begin using it, arrange the PC and
your work area to maintain your comfort and productivity. Refer to the Safety &
Comfort Guide for important ergonomic information.
0–15˚
50–70 cm
(20–28 inches)
0–15˚
4 user’s guide
Your PC features and
connector positions may
vary.
A PS/2 keyboard
B PS/2 mouse
C Serial port
D Parallel port
E Audio Out
F Audio In
G Microphone
H USB 2.0
K Monitor
L Tele p hon e
M Ethernet (network
interface)
N TV out
P Modem (to telephone
line wall jack)
computer safety warning
WARNING: To reduce the risk of serious injury, read the Safety &
Comfort Guide. It describes proper workstation setup, posture, and
health and work habits for computer users. It also provides
important electrical and mechanical safety information.
To view the Safety & Comfort Guide:
• Click Start, choose All Programs, choose PC Help & Tools, and then click
Safety & Comfort Guide.
Or
• Ty pe
http://www.hp.com/ergo/
into your Web browser address box, and then press Enter on the keyboard.
pc back
Connect your main hardware devices like the monitor, keyboard, and mouse at
the back of the PC. Other peripheral devices like a printer, scanner, camera, or
other equipment also plug into connectors on the back of your computer. Some
PC models also have connectors on the front of the PC.
A
B
C
D
E
F
G
H
K
SERIAL
SERIAL
OUT
IN
M
N
L
P
setting up your pc
5
NOTE: PCs use software drivers to control peripheral devices. When you add a
Plug and Play (ready to use) peripheral, memory, or add-in card, the PC
automatically loads the correct driver for the device.
NOTE: For peripherals that are not Plug and Play, follow the instructions that
came with your peripheral device to load the appropriate driver.
Connector
Symbol
Description
Mouse (PS/2)
Keyboard (PS/2)
Universal Serial Bus (USB) for mouse, keyboard, digital cameras, or
other devices with USB connectors
serial
OUT
IN
Printer (parallel)
Monitor
Serial port for digital cameras or other serial devices
Audio Line Out (powered speakers)
Audio Line In
Headphones
Microphone
®
(IEEE 1394) for video cameras or other devices with very fast
FireWire
transfer rates.
6 user’s guide
Your PC features and
connector positions may
vary.
A CD storage
B CD-ROM or CD-RW
drive
C DVD-ROM or DVD
Writer drive
D Diskette (floppy) drive
E 7-In-1 memory card
reader
F FireWire (IEEE 1394)
G USB 2.0 (two shown)
H Audio line in
I Microphone
K On button/indicator
M Hard disk drive
activity indicator light
N Door opened to show
connectors
pc front
The front of your computer has the drives, the On button and hard disk drive
activity indicator light. Some PC models also have connectors on the front of
the PC.
A
B
C
D
E
N
H
I
K
F
G
M
setting up your pc
7
connecting the modem
The modem is used for connecting to an ISP that provides telephone dial-up
connection to the Internet.
NOTE: Your PC may not come with a modem.
other ways to
connect
There are other ways to
connect to the ISP that
do not use the telephone
modem, such as a
LAN (Local Area
Network) or DSL (Digital
Subscriber Line). Check
with your ISP for
specifics on your
connection.
See “setting up the
ethernet connection”
on page 9 if you are
connecting through
a LAN.
A Modem connector
(select models only)
B Telephone connector
(select models only)
C Back of PC
D Modem/telephone
cable
E Wall jack
F Telephone (not
provided)
Check with your ISP for specifics on your connection.
Before you can connect to the Internet and send or receive e-mail and faxes using
telephone dial-up, you must connect your telephone service line to the modem,
which is inside the PC. The quick setup poster shows you how to plug in a
modem/telephone cable to the PC modem connector and to your telephone
service line wall jack connector. To identify the modem connector, look at the
back panel of the PC. The modem connector looks similar to one of the following
illustrations.
NOTE: Your PC may have only one modem/telephone connection.
A
B
C
A
C
A
B
C
D
8 user’s guide
E
F
To connect the cable between the modem and the telephone service line:
1 Plug one end of a modem cable (D) into the modem connector (A) on the back
of the PC (C). This connector may be labeled with either Line or a modem
connector symbol.
2 Plug the other end of the cable (D) into the telephone service line jack (E) on
the wall.
You can also connect a telephone (F) to the other connector (B) on the modem
(select models only). By connecting a telephone to the modem, you can make
regular (voice) telephone calls when you are not using the modem — even if the
PC is turned off.
upgrading your 56k modem
Your modem driver can be upgraded to enable certain V.92 features. For
information, go to the Support Web site listed in the Warranty & Support Guide,
click the support link, type modem upgrade into the search box, and then click the
arrow to the right of the box. Follow the instructions provided.
NOTE: Your ISP must support the V.92 standard to use any of the V.92 features.
A Ethernet connector
(RJ-45 port)
B Ethernet indicator
lights
setting up the ethernet connection
The Ethernet connection (may be called a network interface adapter, a Network
Interface Card, or NIC) provides a high-speed, or broadband, connection to an
Ethernet (10BaseT) or Fast Ethernet (100BaseT) network. After this interface is
connected to a network such as a LAN (local area network), you can connect to
the Internet through the LAN. This network connection also allows you to share
printers, data, and other devices among your PCs.
NOTE: Your PC may not come with an Ethernet connector.
Locate the Ethernet connector (a RJ-45 port) on the back of the PC.
B
A
setting up your pc
9
To connect the Ethernet connector to the network:
1 Plug the network cable into the Ethernet connector (A) on the back of the PC.
WARNING: Do not plug the telephone service line cable or modem
cable into the Ethernet connector. Although the plug looks similar to
the plug on the Ethernet cable, they are not the same.
2 Plug the other end of the Ethernet cable into a 10BaseT or a 100BaseT port on
the network hub.
NOTE: Hubs are devices that can connect PCs to a network.
3 With the PC turned on, check the lights next to the Ethernet connector for
status:
• ACTIVITY — Lit yellow during network data transfer activity
• LINK — Lit green with valid network connection
turning on your pc for the first time
After you have completed the steps on the quick setup poster, you are ready to
turn on your PC.
1 Press the Power button on the monitor.
2 Press the On button (A) on the front of the PC (see the following figure).
3 Press the Power button on the speakers, if they are present.
A
4 Click an option to select your language (if applicable for your model). Click
OK and then confirm your selection by clicking Ye s. Wait until the PC makes
preparations. (It may take up to 30 minutes to set up the language on the PC.)
5 Set up Microsoft
®
Windows® by following the onscreen instructions.
10 user’s guide
6 Refer to the following section, “registering your pc,” for information on
completing the registration process (select models only).
7 Double-click the large Internet Access icon on your desktop, if it is present.
Wait until the PC displays the Easy Internet Sign-up window, and then follow
the onscreen instructions.
8 Restart the PC: Click Start on the taskbar, click Turn Off Computer, and then
click Restart.
registering your pc
You may be prompted to register the PC (select models only). Register so you
can receive changes, updates, and support. You can register any of these ways:
• Double-click the registration icon on your desktop, and follow the onscreen
instructions.
• Register online at http://register.hp.com
turning off the pc
For best results, turn off the PC without pressing any buttons on the PC chassis.
1 Close any open software programs. To close programs, click X in the
upper-right corner of each window.
2 Click Start on the taskbar.
3 Click Turn Off Computer, at the bottom of the menu.
4 Click Turn Off.
5 Turn off the monitor.
As an alternative to turning off the PC, you can put the PC in either standby or
hibernation mode. To conserve power, you can set the power management
timers to put the PC automatically into standby and then hibernation. See the
following sections for more information on putting your PC in standby or
hibernation mode.
setting up your pc
11
standby mode
When the PC is in standby mode, it goes into a low-power state and the monitor
is blank as if it is turned off. The advantages of using standby mode include:
• You save time and electricity without having to wait for the PC to go through
the normal startup routine when you wake it again. The next time you use the
PC, any programs, folders, and documents that were open before you put the
PC in standby will be available.
• Your PC can receive faxes while in standby mode, if you set it to do so.
• Your PC can retrieve e-mail messages and download information from the
Internet automatically, if you set it to do so.
To put the PC in standby mode manually:
1 Press the Standby button on the keyboard, if it is present.
The screen goes dark, and the PC goes into standby mode.
2 When you want to use the PC again, press the Esc key on the keyboard, or
press the Standby button. The screen display reappears just as you left it.
Another way to put the PC into standby mode is to:
1 Click Start on the taskbar.
2 Click Turn Off Computer.
3 Click Stand By.
4 To wake the PC from standby, press the Standby button or press the Esc key
on the keyboard.
If the PC does not work properly when you wake it from standby, restart the PC:
1 Press and hold the On button on the front of the PC for approximately 5
seconds until the PC turns off.
NOTE: Using the On button to restart the PC is not recommended and should
be used only as a last resort. Instead, click Start, click Turn Off Computer,
and then click Restart.
2 Turn on the PC again.
hibernation mode
12 user’s guide
When the PC is in hibernation mode, it saves everything that is in PC memory to
the hard disk drive, turns off the monitor and the hard disk drive, and then
turns itself off. When you turn on the PC again, your programs, folders, and
documents are restored to the screen.
To put the PC into hibernation manually:
1 Click Start on the taskbar.
2 Click Turn Off Computer.
3 Press and hold down the Shift key on the keyboard, and click Hibernate.
NOTE: If Hibernate is not present, you can set up your PC for hibernation;
refer to steps 1 through 6 of “automatic standby or hibernation” on page 13.
4 When you want to use the PC again after hibernation, press the On button on
the front of the PC.
If the PC does not work properly when you wake it from hibernation, follow
these steps to restart the PC:
1 Click Start on the taskbar.
2 Click Turn Off Computer.
3 Click Restart.
automatic standby or hibernation
You can set your PC to go into standby or hibernation mode automatically when
it is idle for some number of minutes. To put the PC into standby or hibernation
mode automatically, modify the power management settings:
1 Click Start on the taskbar.
2 Click Control Panel.
3 Click Performance and Maintenance, if it is present.
4 Double-click Power Options.
5 Click the Hibernate tab and check the hibernation feature. If necessary, enable
the feature by clicking the Enable hibernation box so that a check mark appears
in it.
6 If you changed the Enable hibernation check box, click Apply.
7 Click the Power Schemes tab to set the timers for standby and hibernation. In
the Power Schemes box, select a power scheme from the drop-down list.
Choose the settings.
• To turn on automatic standby for the PC, click the time to elapse before
standby (such as After 20 mins) in the System standby list.
• To set the timer for automatic hibernation, click the time to elapse before
hibernation (such as After 1 hour) in the System hibernates list.
NOTE: If both standby and hibernation timers are set, the system hibernation
timer must be set for a longer time than the system standby timer.
8 Click OK.
setting up your pc
13
making recovery cds/dvds
Now is a good time to make your recovery discs; see “creating recovery
cds/dvds” on page 88.
installing software and hardware devices
After you turn on the PC the first time and restart it (see page 10), you can install
any software programs that came on CDs or DVDs included in the PC box
(select models only).
You may wish to install additional software programs or hardware devices on
your PC. Restart the PC after installation.
Choose software that is compatible with your PC — check the operating system,
memory, and other requirements listed for the new software for compatibility
with your PC.
Install the new software according to the directions provided by the software
manufacturer. Check the manufacturer’s documentation or customer service
information for help if you need it.
hp products work better together
HP computers include pre-loaded software for select HP All-In-One, camera,
scanner, and printer peripheral products. Pre-loaded software simplifies and
speeds product setup for HP peripherals. Simply connect the HP peripheral
product, turn it on, and your HP PC automatically configures it so it is ready
to use.
14 user’s guide
transferring your old pc information and files to
your new pc
See the built-in Microsoft Windows Help and Support Center, described on
page 37; search for transfer wizard, and select the overview article, Files and
Settings Transfer Wizard overview. This information describes a Microsoft solution
for moving your files onto your new PC.
Or, as an alternative, double-click the Protect My PC icon on your desktop and
review the products and services offered under Move My Data.
learning the basics
NOTE: To use your software, you must know how to use the mouse and
keyboard. If necessary, see “using the mouse” on page 19 or see “using the
keyboard” on page 21.
beginning to use your software
The operation of your PC is controlled by two kinds of software:
• The Microsoft Windows XP operating system, which displays the desktop on
the monitor and controls your PC’s hardware, peripherals, and software
applications.
• Software programs, such as a word processing program, which performs
specific functions.
Information about using software and about the Microsoft Windows XP
operating system is in the printed manuals and online Help. For Microsoft
Windows, you can also press the Help button, labeled with a question mark icon
on your keyboard (select models only), to open the built-in Help and Support
Center. For help with specific software, refer to the onscreen Help within the
program.
Software programs included with the PC may vary by model and by
country/region.
learning the basics
15
A
using the desktop
The desktop has shortcut icons that make it easy to find the things you need.
Icon Opens Use it to
Help and Support (select
models only)
Easy Internet Sign-up Set up a new or an existing Internet
Recovery Start Application or System Recovery.
HP Image Zone Manage and protect your still photos,
using the start menu
Click the Start button to open the start menu and:
View onscreen Help information
about your PC.
account.
scanned images, and video clips.
Start button on the
taskbar
B Log Off button
C Turn Off Computer
button
D All Programs
• Select programs or documents.
• Open the Help and Support Center.
• Start a search.
• Run a program.
• Open the Control Panel to view or change settings.
D
A
B
C
Click About my HP PC to view information about your PC. (See
“learning to use your pc” on page 17.)
The Start menu also displays the buttons Log Off and Turn Off Computer:
• Click the Log Off button to end your current PC session and to switch
between users.
• Click the Turn Off Computer button to turn off the PC or to restart it.
16 user’s guide
using hp organize software
HP Organize software is a desktop tool you use to organize both your PC
shortcuts and your favorite Internet destination links. You use it to organize the
important things you do on the PC and the Internet, and to arrange it the way
you want. HP Organize makes all your information available with just a few
mouse-clicks.
HP Organize looks like a window with multiple category frames. Each category
has links to Internet destinations or shortcuts to software programs or files on
your PC. Use the player area for viewing pictures, for listening to your MP3
music files stored on your computer, or for watching streaming video news
clips. For searching, there is a search bar at the top of HP Organize where you
can select the search engine you want to use.
To open HP Organize:
1 Click Start on the taskbar.
2 Choose All Programs.
3 Choose PC Help & Tools.
4 Click HP Organize.
learning to use your pc
Click the Start button and select About my HP PC (select models only). A
window opens with a welcoming message. Click an item on the left of the
message to view information about your PC, including:
• Locations of drives and connectors on the front of the PC chassis.
• Descriptions and uses of software programs included with your PC.
• Access to the Internet.
• Help and Support.
• Recovery of the operating system and software programs.
For detailed instructions and information about your PC (select models only):
1 Click Start.
2 Choose Help and Support.
3 Choose HP Pavilion PC Help.
For onscreen instructions to run tests for PC-related problems or to get help from
a Support analyst, open Instant Support (select models only):
1 Click Start on the taskbar, and click Help and Support.
2 Click HP Instant Support.
3 Click Request Help.
4 Follow the onscreen instructions to run a test or to submit a problem. You can
run tests anytime; however, your PC must be connected to the Internet to
submit a problem.
learning the basics
17
using the all programs menu
To find the software programs on your PC:
1 Choose Start.
2 Choose All Programs.
organizing your all programs list
You see folders organized according to task (select models only) when you:
1 Click Start.
2 Choose All Programs.
A folder contains a list of items. Each item is actually a shortcut, or link, to a
program, document, or another folder. The Music folder, for example, contains
shortcuts to the programs you use to play music CDs.
To change the name of an item:
1 Right-click the item.
2 Select Rename.
3 Type the new name and press Enter on the keyboard.
To move an item by using the drag-and-drop technique:
1 Select the item in All Programs or in a folder.
2 Left-click the item and hold down the mouse button.
3 Move the mouse pointer to where you want the item, and then release the
mouse button.
(If you have problems dropping the item into a folder, drag it to your
desktop, and then drag it to the folder.)
To copy an item:
1 Right-click the item.
2 Select Create Shortcut. The shortcut appears in the folder.
3 Drag the item into the All Programs list or into another folder.
If you use Add or Remove Programs in the Control Panel to delete a software
program, the shortcut in All Programs may not be removed. To remove a
shortcut:
1 Click Start.
2 Choose All Programs.
3 Select the folder.
4 Right-click the shortcut, and then select Delete. Click Delete Shortcut to
confirm you want to delete the shortcut.
18 user’s guide
using pc help & tools
The PC Help & Tools folder (select models only) in the All Programs menu
contains special utilities for PC owners. This folder also contains any onscreen
guides included with your PC.
To see the items in the PC Help & Tools folder:
1 Click Start on the taskbar.
2 Choose All Programs.
3 Choose PC Help & Tools.
4 Click an item to view it or use it.
NOTE: If there are no guide titles listed in PC Help & Tools, your PC has no
onscreen guides.
using the mouse
Your PC includes a mouse for directing the cursor (pointer) on the Windows
desktop. The mouse uses a roller ball or optics (a light and sensor) to sense
movement and cause the cursor on the screen to move. Use the mouse on a flat
surface.
NOTE: The optical mouse cannot work on a glass, translucent, or reflective
surface.
A wireless mouse (select models only) is an optical mouse that uses a
receiver/transmitter, instead of a connector cable, to communicate with your
PC. A light on the receiver indicates receiver activity. Refer to “wireless
keyboard set” on page 24 for receiver indicator information.
NOTE: The wireless mouse goes into a sleep or suspend mode after 20 minutes of
inactivity. Click a button on the mouse to wake it. (Moving the wireless mouse
does not wake it.)
The mouse has two or three buttons on the top:
• Click the left mouse button to position the cursor or to select an item.
• Click the right mouse button to display a menu of commands for the item you
clicked.
• On select models, use the scroll wheel button in the center for scrolling and
panning.
learning the basics
19
A
Left button
B Scroll wheel button
(scrolling mouse only)
C Right button
Double-click means to press the left button on the mouse
two times in a row. To double-click, you click the button
A
B
(press it and then release it), and then quickly click it
again.
NOTE: Your mouse may look different from the one shown
here.
You can switch the function of the left and right buttons
for left-handed use. Refer to “switching mouse button
functions” on page 21.
If your mouse does not work properly, refer to
“troubleshooting” on page 73.
scrolling
Click the left mouse button to place the cursor in a document, and then:
• To scroll toward the beginning of a document, roll the scroll wheel button up
(away from you).
• To scroll toward the end of a document, roll the scroll wheel button down
(toward you).
autoscrolling
C
1 Place the cursor anywhere in the text, and press the scroll wheel button once.
An autoscroll icon appears.
2 Move the mouse in the direction you want to scroll. The farther you move the
mouse from the starting point, the faster the document scrolls.
3 To stop autoscrolling, press the scroll wheel button again.
NOTE: Autoscrolling does not work with some software programs.
panning
1 Press and hold down the center scroll wheel button.
2 Slowly move the mouse in the direction you want to pan. The farther you
move the pointer from the starting point, the faster the document pans.
3 To stop panning, release the scroll wheel button.
NOTE: Panning only works if the window’s horizontal scroll bar is active.
Panning does not work with some software programs.
20 user’s guide
switching mouse button functions
To switch the functions of the right and left mouse buttons:
1 Click the Start button.
2 Click Control Panel.
3 Click Printers and Other Hardware, if it is present.
4 Double-click Mouse.
5 Check Switch primary and secondary buttons on the Buttons tab.
6 Click Apply (using the new primary button), and then click OK.
changing mouse pointer speed
To change the speed of the cursor on the screen relative to the motion of the
mouse:
1 Click the Start button.
2 Click Control Panel.
3 Click Printers and Other Hardware, if it is present.
4 Double-click Mouse.
5 Click the Pointer Options tab.
6 In the area, Motion, use the slider to adjust the pointer speed.
7 Click Apply, and then click OK.
using the keyboard
about your keyboard
Your keyboard has an arrangement of standard keys, indicator lights, and
special buttons (select models only). Locate your keyboard among the following
illustrations and read the feature list for it. Your keyboard may vary from the
illustrations.
internet keyboards
Internet keyboards may connect directly to your PC or may be wireless. (See
“wireless keyboard set” on page 24 for a description of the wireless set.)
Some keyboards do not have the Internet buttons shown here at the top of the
keyboard, and some use a different layout on the top right.
Find your keyboard among the following illustrations to read about its features.
learning the basics
21
internet keyboard 1
l
l
This keyboard enables you to:
• Adjust speaker volume.
• Connect to the Internet (if you have an established Internet account).
• Search for information on the Internet.
• Place the PC into standby to save power.
• Start, pause, and stop playing a CD or DVD, skip to the previous or next
track, record, and eject the disc tray (for two drives).
• Mute speaker sound.
• Customize the buttons to open programs and connect to Internet Web sites.
• Get support information.
• Find a file or program on the hard disk drive.
internet keyboard 2
22 user’s guide
This keyboard enables you to:
• Mute speaker sound.
• Search for information on the Internet.
• Customize the buttons to open programs and connect to Internet Web sites.
• Find a file or program on the hard disk drive.
• Place the PC into standby to save power.
• Get support information.
• Connect to the Internet (if you have an established Internet account).
Loading...
