HP Pavilion 15 Laptop PC User Guide

HP Pavilion 15 Laptop PC (model numbers
15-cc000 through 15-cc099 and 15-cc500
through 15-cc599)

Maintenance and Service Guide
IMPORTANT! This document is intended for
HP authorized service providers only.

© Copyright 2017 Hewlett-Packard
Development Company, L.P.

Bluetooth is a trademark owned by its
proprietor and used by HP Inc. under license.
Intel, Core, and Pentium are U.S. registered
trademarks of Intel Corporation. . Microsoft
and Windows are either registered trademarks
or trademarks of Microsoft Corporation in
the United States and/or other countries. SD
Logo is a trademark of its proprietor.

The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in
the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors or
omissions contained herein.

First Edition: April 2017

Document Part Number: 924962-001

Product notice

This guide describes features that are common
to most models. Some features may not be
available on your computer.

Not all features are available in all editions of
Windows 10. This computer may require
upgraded and/or separately purchased
hardware, drivers and/or software to take full
advantage of Windows 10 functionality. See for

http://www.microsoft.com details.

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not place

the device directly on your lap or obstruct the device air vents. Use the device only on a hard, at surface. Do
not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs
or clothing, to block airow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as
pillows or rugs or clothing, during operation. The device and the AC adapter comply with the user-accessible
surface temperature limits dened by the International Standard for Safety of Information Technology
Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description ....................................................................................................................................... 1

2 Getting to know your computer ...................................................................................................................... 5

Locating hardware ................................................................................................................................................. 5

Locating software .................................................................................................................................................. 5

Display .................................................................................................................................................................... 6

Buttons and speakers ............................................................................................................................................ 7

Lights ...................................................................................................................................................................... 8

Special keys ............................................................................................................................................................ 9

TouchPad .............................................................................................................................................................. 10

Left side ............................................................................................................................................................... 11

Right side ............................................................................................................................................................. 12

Bottom ................................................................................................................................................................. 13

3 Illustrated parts catalog .............................................................................................................................. 14

Locating the serial number, model number, product number, and warranty information ............................... 14

Computer components ........................................................................................................................................ 15

Display assembly components ............................................................................................................................ 27

Miscellaneous parts ............................................................................................................................................. 29

4 Removal and replacement preliminary requirements ..................................................................................... 30

Tools required ...................................................................................................................................................... 30

Service considerations ......................................................................................................................................... 30

Plastic parts ....................................................................................................................................... 30

Cables and connectors ...................................................................................................................... 31

Drive handling ................................................................................................................................... 31

Grounding guidelines ........................................................................................................................................... 32

Electrostatic discharge damage ........................................................................................................ 32

Packaging and transporting guidelines .......................................................................... 33

Workstation guidelines ................................................................................ 33

5 Removal and replacement procedures ........................................................................................................... 35

Component replacement procedures .................................................................................................................. 35

Optical drive ....................................................................................................................................... 35

Bottom cover ..................................................................................................................................... 36

Battery ............................................................................................................................................... 38

v

Hard drive .......................................................................................................................................... 39

WLAN module .................................................................................................................................... 41

Solid-state drive ................................................................................................................................ 43

Memory module ................................................................................................................................ 44

USB port board .................................................................................................................................. 45

TouchPad cable .................................................................................................................................. 47

TouchPad ........................................................................................................................................... 48

Fan ..................................................................................................................................................... 49

System board .................................................................................................................................... 50

Heat sink ............................................................................................................................................ 54

USB port board cable ......................................................................................................................... 57

Display assembly ............................................................................................................................... 58

Speakers ............................................................................................................................................ 64

Power connector cable ...................................................................................................................... 66

6 Computer Setup (BIOS), TPM, and HP Sure Start ............................................................................................. 67

Using Computer Setup ......................................................................................................................................... 67

Starting Computer Setup .................................................................................................................. 67

Navigating and selecting in Computer Setup ................................................................................... 67

Restoring factory settings in Computer Setup ................................................................................. 68

Updating the BIOS ............................................................................................................................. 69

Determining the BIOS version ......................................................................................... 69

Downloading a BIOS update ........................................................................................... 69

Changing the boot order using the f9 prompt .................................................................................. 70

TPM BIOS settings (select products only) ........................................................................................................... 71

Using HP Sure Start (select products only) ......................................................................................................... 71

7 HP PC Hardware Diagnostics (UEFI) ............................................................................................................... 72

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................................... 73

8 Specications .............................................................................................................................................. 74

9 Backing up and recovering ............................................................................................................................ 75

Creating recovery media and backups ................................................................................................................ 75

Creating HP Recovery media (select products only) ......................................................................... 76

Using Windows tools ........................................................................................................................................... 77

Restore and recovery ........................................................................................................................................... 77

Recovering using HP Recovery Manager ........................................................................................... 78

What you need to know before you get started ............................................................. 78

Using the HP Recovery partition (select products only) ................................................. 79

vi

Using HP Recovery media to recover .............................................................................. 79

Changing the computer boot order ................................................................................ 80

Removing the HP Recovery partition (select products only) ......................................... 80

10 Power cord set requirements ...................................................................................................................... 81

Requirements for all countries ............................................................................................................................ 81

Requirements for specic countries and regions ................................................................................................ 81

11 Recycling .................................................................................................................................................. 83

Index ............................................................................................................................................................. 84

vii

viii

1 Product description

Category Description

Product Name HP Pavilion 15 Laptop PC (model numbers 15-cc000 through 15-cc099 and 15-cc500 through 15-cc599)

Processors

Chipset Integrated soldered-on-circuit (SoC)

Graphics Hybrid graphics:

●

Intel® Core™ i7-7500U 2.70-GHz (turbo up to 3.50-GHz) dual core processor (2133-MHz FSB, 4.0-GB L3
cache, 15-W)

●

Intel Core i5-7200U 2.50-GHz (turbo up to 3.10-GHz) dual core processor (2133-MHz FSB, 3.0-GB L3
cache, 15-W

●

Intel Core i3-7100U 2.40-GHz dual core processor (2133-MHz FSB, 3.0-GB L3 cache, 15-W

●

Intel Pentium™ 4415U 2.30-GHz dual core processor (2133-MHz FSB, 2.0-GB L3 cache, 15-W

NVIDIA™ N16S-GTR (GeForce 940MX) graphics subsystem with up to 4096-MB of discrete video memory
(256-MB×16 DDR3×8 pieces, 1.5V/1-GHz; available only on computer models equipped with an Intel Core i7
or Intel Core i5 processor)

NVIDIA N16S-GTR (GeForce 940MX) graphics subsystem with up to 2048-MB of discrete video memory (256­MB×16 DDR3×4 pieces, 1.5V/1-GHz; available only on computer models equipped with an Intel Core i7 or
Intel Core i5 processor)

Internal graphics:

Intel HD Graphics 620 graphics subsystem with UMA video memory (available only on computer models
equipped with an Intel Core i3 or Intel Pentium processor)

Intel HD Graphics 610 graphics subsystem with UMA video memory (available only on computer models
equipped with an Intel Core i3 or Intel Pentium processor)

Support for HD decode, DX12, and high-denition multimedia interface (HDMI)

Support for Optimus

Support for GPU Performance Scaling (GPS)

Panel

Memory Two SODIMM memory module slots, non-customer-accessible/non-upgradable

●

15.6-in, full high-denition (FHD), white light-emitting (WLED), BrightView (1920×1080), slim-at (3.2­mm), UWVA, eDP, 220 nits, 16:9 ultra wide aspect ratio, TouchScreen display assembly

●

15.6-in, high-denition (HD), WLED, BrightView (1366×768), slim-at (3.2-mm), SVA, eDP, 200 nits,
16:9 ultra wide aspect ratio, TouchScreen display assembly

●

15.6-in, FHD, WLED, AntiGlare (1920×1080), slim-at (3.2-mm), UWVA, eDP, 220 nits, 16:9 ultra wide
aspect ratio non-TouchScreen display assembly

●

15.6-in, FHD, WLED, BrightView (1920×1080), slim-at (3.2-mm), UWVA, eDP, 220 nits, 16:9 ultra wide
aspect ratio non-TouchScreen display assembly

●

15.6-in, FHD, WLED, AntiGlare (1920×1080), slim-at (3.2-mm), SVA, eDP, 220 nits, 16:9 ultra wide
aspect ratio non-TouchScreen display assembly

●

15.6-in, HD, WLED, AntiGlare (1366×768), slim-at (3.2-mm), SVA, eDP, 220 nits, 16:9 ultra wide aspect
ratio non-TouchScreen display assembly

●

15.6-in, HD, WLED, BrightView (1366×768), slim-at (3.2-mm), SVA, eDP, 220 nits, 16:9 ultra wide
aspect ratio non-TouchScreen display assembly

1

Category Description

Memory (continued) Supports up to 16-GB of system memory

DDR4-2133 single channel support (DDR4-2400 downgrade to DDR4-2133)

Supports the following congurations:

●

16384-MB (8192-MB × 2)

●

12288-MB (8192-MB + 4096-MB)

●

8192-MB (8192-MB × 1 or 4096-MB × 2)

●

6144-MB (4096-MB × 1 + 2048-MB × 1)

●

4096-MB (4096-MB × 1 or 2048-MB × 2)

Storage Support for hard drive and solid-state drive

Hard drive:

Support for 6.35-cm (2.5-in) hard drives in 7.2-mm (.28 in) and 9.5-mm (.37 in) thicknesses (all hard drives
use the same bracket)

Support for Accelerometer hard drive protection

Support for the following single hard drive congurations:

●

2-TB, 5400-rpm, 9.5-/7.2-mm

●

1-TB, 5400-rpm, 9.5-/7.2-mm

●

500-GB, 5400-rpm, 7.0-mm

Solid-state drive:

●

512-GB, 2280 M.2 SATA-3 solid-state drive with triple-level cell (TLC)

●

256-GB, 2280 M.2 SATA-3 solid-state drive with TLC

●

128-GB, 2280 M.2 SATA-3 solid-state drive with TLC

●

256-GB, 2280 M.2 SATA-3 solid-state drive

●

128-GB, 2280 M.2 SATA-3 solid-state drive

Dual-storage congurations:

●

2-TB, 5400-rpm, 9.5-/7.2-mm hard drive + 128-GB, 2280 M.2 SATA-3 solid-state drive

●

1-TB, 5400-rpm, 9.5-/7.2-mm hard drive + 256-GB, 2280 M.2 SATA-3 solid-state drive

●

1-TB, 5400-rpm, 9.5-/7.2-mm hard drive + 128-GB, 2280 M.2 SATA-3 solid-state drive

Solid-state hard drive: 1-TB, 5400-rpm, Hybrid 8-GB, 9.5-/7.2-mm

Optical drive

Audio and video Support for the following cameras:

2 Chapter 1 Product description

●

Support for 9.0-mm tray load, SATA, xed (not modular)

●

Support for DVD±RW DL SuperMulti Drive

●

Support for M-disc

●

Support for zero-power optical drive

HP Wide Vision FHD infrared camera with indicator light and 2 infrared lights, USB 2.0, FHD hybrid BSI sensor,
f2.2, WDR, 88° wide eld of vision, 1080p by 30 frames per second

HP Wide Vision HD camera with indicator light, USB 2.0, HD BSI sensor, f2.0, WDR, 88° wide eld of vision,
720p by 30 frames per second

Category Description

Audio and video

(continued)

Ethernet Integrated 10/100/1000 network interface card (NIC)

Wireless WLAN:

Support for wide dynamic range (WDR)

Support for B&O Play

Support for B&O Play Audio Control

Support for dual speakers

Support for HP Audio Boost

Support for dual-array digital microphones with appropriate beam-forming, echo-cancellation, noise­suppression software.

Integrated wireless local area network (WLAN) options by way of wireless module

Single M.2/PCIe WLAN antenna built into display assembly

Integrated wireless personal area network (PAN) supported by Bluetooth® 4.2 combo card

Support for the following WLAN formats:

●

Intel Dual Band Wireless-AC 7265 802.11 AC 2×2 WiFi + Bluetooth 4.2 Combo Adapter (non-vPro)

●

Intel Dual Band Wireless-AC 3168 802.11AC 1×1 WiFi + Bluetooth 4.2 Combo Adapter (non-vPro)

●

Realtek RTL8723BE-VB 802.11 bgn 1×1 WiFi + Bluetooth 4.0 Combo Adapter

●

Realtek RTL8723DE 802.11 bgn 1×1 WiFi + Bluetooth 4.2 Combo Adapter

Compatible with Miracast-certied devices

External media cards Micro-Secure Digital (SD®) media reader slot

Ports

Keyboard/pointing
devices

Power requirements Support for a 3-cell, 41-WHr, 3.6-AHr, Li-ion battery

●

AC Smart Pin adapter plug

●

Audio-out (headphone)/audio-in (microphone) combo jack

●

HDMI v1.4 supporting up to 1920×1080 @ 60Hz

●

RJ-45 network

●

USB 3.x ports (2)

●

USB Type-C port

Full-sized, island-style keyboard

TouchPad requirements:

●

ClickPad with image sensor

●

MultiTouch gestures enabled

●

Support for Modern TrackPad gestures

●

Taps enabled as default

Support for the following AC adapters:

●

65-W HP Smart AC adapter (non-PFC, EM, RC, 4.5-mm)

●

65-W AC adapter (non-PFC, S-3P, 4.5-mm)

●

45-W HP Smart AC adapter (non-PFC, RC, 4.5-mm, non-slim)

Support for a 1.00-m power cord with a C5 connector in 16 countries/regions.

3

Category Description

Security Security cable lock slot

Support for Trusted Platform Module (TPM) 2.0

Operating system Preinstalled: Windows 10 and Windows 10 Professional

For developed market (ML): Windows 10 Home ML and Windows 10 Home Plus ML

For emerging market (EM/SL):

●

Windows 10 Home EM/SL

●

Windows 10 Home Plus EM/SL

●

Windows 10 Home Value Notebook EM/SL

●

Windows 10 Home Value Notebook Select Geo EM/SL

For China market: CPPP Windows 10 Home China Language Edition and CPPP Windows 10 Home China High­End Language Edition

For Asia SEAP market (EM/SL): SEAP Windows 10 Home EM/SL and SEAP Windows 10 Home Plus

FreeDOS 2.0

Serviceability End user replaceable part: AC adapter and optical drive

4 Chapter 1 Product description

2 Getting to know your computer

Locating hardware

To nd out what hardware is installed on the computer:

▲

Type device manager in the taskbar search box, and then select the Device Manager app.

A list displays all the devices installed on the computer.

For information about system hardware components and the system BIOS version number, press fn+esc
(select products only).

Locating software

To nd out what software is installed on your computer:

▲

Select the Start button.

– or –

Right-click the Start button, and then select Programs and Features.

Locating hardware 5

Display

Item Component Description

(1) WLAN antennas (2)* Send and receive wireless signals to communicate with WLANs.

(2) Internal microphones (2) Record sound.

(3) Camera light On: One or more cameras are in use.

(4) Camera Allow you to video chat, record video, and record still images.

Some cameras allow a facial recognition logon to Windows,
instead of a password logon.

NOTE: Camera functions vary depending on the camera

hardware and software installed on the computer model.

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around
the antennas free from obstructions.

For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country
or region.

To access this guide:

▲

Select the Start button, select HP Help and Support, and then select HP Documentation.

6 Chapter 2 Getting to know your computer

Buttons and speakers

Item Icon Component Description

(1) Power button

(2) Speakers Produce sound.

●

When the computer is o, press the button to turn on
the computer.

●

When the computer is on, press the button briey to
initiate Sleep.

●

When the computer is in the Sleep state, press the button
briey to exit Sleep.

●

When the computer is in Hibernation, press the button
briey to exit Hibernation.

CAUTION: Pressing and holding down the power button results

in the loss of unsaved information.

If the computer has stopped responding and shutdown
procedures are ineective, press and hold the power button down
for at least 5 seconds to turn o the computer.

To learn more about your power settings, see your power options.

▲

Type power in the taskbar search box, and then select
Power & sleep options.

– or –

Right-click the Start button, and then select Power Options.

Buttons and speakers 7

Lights

Item Icon Component Description

(1) Power light

(2) Caps lock light On: Caps lock is on, which switches the key input to all

(3) Mute light

●

On: The computer is on.

●

Blinking: The computer is in the Sleep state, a power-saving
state. The computer shuts o power to the display and other
unneeded components.

●

O: The computer is o or in Hibernation. Hibernation is a
power-saving state that uses the least amount of power.

capital letters.

●

On: Computer sound is o.

●

O: Computer sound is on.

8 Chapter 2 Getting to know your computer

Special keys

Item Icon Component Description

(1) esc key Displays system information when pressed in combination with

(2) fn key Displays system information when pressed in combination with

the fn key.

another key.

(3) Windows key Opens the Start menu.

NOTE: Pressing the Windows key again will close

the Start menu.

(4) Action keys Execute frequently used system functions.

NOTE: On select computer models, the f5 action key turns

the keyboard backlight feature o or on.

(5) num lock key Alternates between the navigational and numeric functions on the

integrated numeric keypad.

(6) Integrated numeric keypad A separate keypad to the right of the alphabet keyboard. When

num lock is pressed, the keypad can be used like an external

numeric keypad.

NOTE: If the keypad function is active when the computer is

turned o, that function is reinstated when the computer is
turned back on.

Special keys 9

TouchPad

Item Component Description

(1) TouchPad zone Reads your nger gestures to move the pointer or activate items

(2) Left TouchPad button Functions like the left button on an external mouse.

on the screen.

(3) Right TouchPad button Functions like the left button on an external mouse.

10 Chapter 2 Getting to know your computer

Left side

Item Icon Component Description

(1) Security cable slot Attaches an optional security cable to the computer.

(2) RJ-45 (network) jack/status lights Connects a network cable.

(3) HDMI port Connects an optional video or audio device, such as a high-

NOTE: The security cable is designed to act as a deterrent, but it

may not prevent the computer from being mishandled or stolen.

●

White: The network is connected.

●

Amber: Activity is occurring on the network.

denition television, any compatible digital or audio component,
or an HDMI device.

(4) USB 3.x SuperSpeed port Connects USB devices, such as a cell phone, camera, activity

tracker, or smartwatch, and provides high-speed data transfer.

(5) USB Type-C SuperSpeed port When the computer is on, connects and charges a USB device that

has a Type-C connector, such as a cell phone, camera, activity
tracker, or smartwatch, and provides high-speed data transfer.

NOTE: Cables and/or adapters (purchased separately) may

be required.

(6) Audio-out (headphone)/Audio-in

(microphone) jack

Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also connects an
optional headset microphone. This jack does not support optional
standalone devices.

WARNING! To reduce the risk of personal injury, adjust

the volume before putting on headphones, earbuds, or a headset.
For additional safety information, refer to the Regulatory, Safety,
and Environmental Notices.

To access this guide:

▲

Select the Start menu, select HP Help and Support, and
then select HP Documentation.

NOTE: When a device is connected to the jack, the computer

speakers are disabled.

Left side 11

Right side

Item Icon Component Description

(1) Power light

(2) Drive light Blinking white: The hard drive is being accessed.

(3) Memory card reader Reads optional memory cards that enable you to store, manage,

(4) USB 3.x SuperSpeed port Connects USB devices, such as a cell phone, camera, activity

●

On: The computer is on.

●

Blinking: The computer is in the Sleep state, a power-saving
state. The computer shuts power o to the display and other
unneeded components.

●

O: The computer is o or in Hibernation. Hibernation is a
power-saving state that uses the least amount of power.

Amber: HP 3D DriveGuard has temporarily parked the hard drive.

share, or access information.

To insert a card:

1. Hold the card label-side up, with the connectors facing

the computer.

2. Insert the card into the memory card reader, and then press

the card until it is rmly seated.

To remove a card:

▲

Press in on the card, and then remove it from the memory
card reader.

tracker, or smartwatch, and provides high-speed data transfer.

(5) Optical drive (select products only) Depending on your computer model, reads an optical disc or reads

(6) Optical drive eject button

(select products only)

(7) AC adapter and battery light

12 Chapter 2 Getting to know your computer

and writes to an optical disc.

Releases the optical drive disc tray.

●

White: The AC adapter is connected and the battery is
fully charged.

●

Blinking white: The AC adapter is disconnected and the
battery has reached a low battery level.

●

Amber: The AC adapter is connected and the battery
is charging.

Item Icon Component Description

Bottom

(7) AC adapter and battery light (continued)

(8) Power connector Connects an AC adapter.

●

O: The battery is not charging.

Component Description

Vent Enables airow to cool internal components.

NOTE: The computer fan starts up automatically to cool internal

components and prevent overheating. It is normal for the internal
fan to cycle on and o during routine operation.

Bottom 13

3 Illustrated parts catalog

NOTE: HP continually improves and changes product parts. For complete and current information on

supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.

Locating the serial number, model number, product number, and warranty information

The serial number (1), model number (2), product number (3), and warranty information (4) are located on
the bottom of the computer. This information may be needed when travelling internationally or when
contacting support.

14 Chapter 3 Illustrated parts catalog

Computer components

Computer components 15

Item Component Spare part number

(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part

information, see Display assembly components on page 27.

(2) Keyboard/top cover in empress red nish with speaker grille in natural silver nish with backlight (includes

backlight cable and keyboard cable):

For use in Belgium 928507-A41

For use in Bulgaria 928507-261

For use in Canada 928507-DB1

For use in the Czech Republic and Slovakia 928507-FL1

For use in Denmark, Finland, and Norway 928507-DH1

For use in France 928507-051

For use in Germany 928507-041

For use in Greece 928507-151

For use in Hungary 928507-211

For use in India 928507-002

For use in Israel 928507-BB1

For use in Italy 928507-061

For use in Latin America 928507-161

For use in the Netherlands 928507-B31

For use in Northwest Africa 928507-FP1

For use in Portugal 928507-131

For use in Romania 928507-271

For use in Russia 928507-251

For use in Saudi Arabia 928507-171

For use in Slovenia 928507-BA1

For use in South Korea 928507-AD1

For use in Spain 928507-071

For use in Switzerland 928507-BG1

For use in Taiwan 928507-AB1

For use in Thailand 928507-281

For use in Turkey 928507-141

For use in the United Kingdom 928507-031

For use in the United States 928507-001

Keyboard/top cover in empress red nish with speaker grille in natural silver nish (includes keyboard cable):

For use in Belgium 928506-A41

For use in Bulgaria 928506-261

16 Chapter 3 Illustrated parts catalog

Item Component Spare part number

For use in Canada 928506-DB1

For use in the Czech Republic and Slovakia 928506-FL1

For use in Denmark, Finland, and Norway 928506-DH1

For use in France 928506-051

For use in Germany 928506-041

For use in Greece 928506-151

For use in Hungary 928506-211

For use in India 928506-002

For use in Israel 928506-BB1

For use in Italy 928506-061

For use in Latin America 928506-161

For use in the Netherlands 928506-B31

For use in Northwest Africa 928506-FP1

For use in Portugal 928506-131

For use in Romania 928506-271

For use in Russia 928506-251

For use in Saudi Arabia 928506-171

For use in Slovenia 928506-BA1

For use in South Korea 928506-AD1

For use in Spain 928506-071

For use in Switzerland 928506-BG1

For use in Taiwan 928506-AB1

For use in Thailand 928506-281

For use in Turkey 928506-141

For use in the United Kingdom 928506-031

For use in the United States 928506-001

Keyboard/top cover in mineral silver nish with speaker grille in natural silver nish with backlight (includes

backlight cable and keyboard cable):

For use in Belgium 926859-A41

For use in Bulgaria 926859-261

For use in Canada 926859-DB1

For use in the Czech Republic and Slovakia 926859-FL1

For use in Denmark, Finland, and Norway 926859-DH1

For use in France 926859-051

For use in Germany 926859-041

Computer components 17

Item Component Spare part number

For use in Greece 926859-151

For use in Hungary 926859-211

For use in India 926859-002

For use in Israel 926859-BB1

For use in Italy 926859-061

For use in Latin America 926859-161

For use in the Netherlands 926859-B31

For use in Northwest Africa 926859-FP1

For use in Portugal 926859-131

For use in Romania 926859-271

For use in Russia 926859-251

For use in Saudi Arabia 926859-171

For use in Slovenia 926859-BA1

For use in South Korea 926859-AD1

For use in Spain 926859-071

For use in Switzerland 926859-BG1

For use in Taiwan 926859-AB1

For use in Thailand 926859-281

For use in Turkey 926859-141

For use in the United Kingdom 926859-031

For use in the United States 926859-001

Keyboard/top cover in mineral silver nish with speaker grille in natural silver nish (includes keyboard cable):

For use in Belgium 926858-A41

For use in Bulgaria 926858-261

For use in Canada 926858-DB1

For use in the Czech Republic and Slovakia 926858-FL1

For use in Denmark, Finland, and Norway 926858-DH1

For use in France 926858-051

For use in Germany 926858-041

For use in Greece 926858-151

For use in Hungary 926858-211

For use in India 926858-002

For use in Israel 926858-BB1

For use in Italy 926858-061

18 Chapter 3 Illustrated parts catalog

Item Component Spare part number

For use in Latin America 926858-161

For use in the Netherlands 926858-B31

For use in Northwest Africa 926858-FP1

For use in Portugal 926858-131

For use in Romania 926858-271

For use in Russia 926858-251

For use in Saudi Arabia 926858-171

For use in Slovenia 926858-BA1

For use in South Korea 926858-AD1

For use in Spain 926858-071

For use in Switzerland 926858-BG1

For use in Taiwan 926858-AB1

For use in Thailand 926858-281

For use in Turkey 926858-141

For use in the United Kingdom 926858-031

For use in the United States 926858-001

Keyboard/top cover in opulent blue nish with speaker grille in natural silver nish with backlight (includes

backlight cable and keyboard cable):

For use in Belgium 928440-A41

For use in Bulgaria 928440-261

For use in Canada 928440-DB1

For use in the Czech Republic and Slovakia 928440-FL1

For use in Denmark, Finland, and Norway 928440-DH1

For use in France 928440-051

For use in Germany 928440-041

For use in Greece 928440-151

For use in Hungary 928440-211

For use in India 928440-002

For use in Israel 928440-BB1

For use in Italy 928440-061

For use in Latin America 928440-161

For use in the Netherlands 928440-B31

For use in Northwest Africa 928440-FP1

For use in Portugal 928440-131

For use in Romania 928440-271

Computer components 19

Item Component Spare part number

For use in Russia 928440-251

For use in Saudi Arabia 928440-171

For use in Slovenia 928440-BA1

For use in South Korea 928440-AD1

For use in Spain 928440-071

For use in Switzerland 928440-BG1

For use in Taiwan 928440-AB1

For use in Thailand 928440-281

For use in Turkey 928440-141

For use in the United Kingdom 928440-031

For use in the United States 928440-001

Keyboard/top cover in opulent blue nish with speaker grille in natural silver nish (includes keyboard cable):

For use in Belgium 928439-A41

For use in Bulgaria 928439-261

For use in Canada 928439-DB1

For use in the Czech Republic and Slovakia 928439-FL1

For use in Denmark, Finland, and Norway 928439-DH1

For use in France 928439-051

For use in Germany 928439-041

For use in Greece 928439-151

For use in Hungary 928439-211

For use in India 928439-002

For use in Israel 928439-BB1

For use in Italy 928439-061

For use in Latin America 928439-161

For use in the Netherlands 928439-B31

For use in Northwest Africa 928439-FP1

For use in Portugal 928439-131

For use in Romania 928439-271

For use in Russia 928439-251

For use in Saudi Arabia 928439-171

For use in Slovenia 928439-BA1

For use in South Korea 928439-AD1

For use in Spain 928439-071

20 Chapter 3 Illustrated parts catalog

Item Component Spare part number

For use in Switzerland 928439-BG1

For use in Taiwan 928439-AB1

For use in Thailand 928439-281

For use in Turkey 928439-141

For use in the United Kingdom 928439-031

For use in the United States 928439-001

Keyboard/top cover in orchid pink nish with speaker grille in natural silver nish with backlight (includes

backlight cable and keyboard cable):

For use in Belgium 928509-A41

For use in Bulgaria 928509-261

For use in Canada 928509-DB1

For use in the Czech Republic and Slovakia 928509-FL1

For use in Denmark, Finland, and Norway 928509-DH1

For use in France 928509-051

For use in Germany 928509-041

For use in Greece 928509-151

For use in Hungary 928509-211

For use in India 928509-002

For use in Israel 928509-BB1

For use in Italy 928509-061

For use in Latin America 928509-161

For use in the Netherlands 928509-B31

For use in Northwest Africa 928509-FP1

For use in Portugal 928509-131

For use in Romania 928509-271

For use in Russia 928509-251

For use in Saudi Arabia 928509-171

For use in Slovenia 928509-BA1

For use in South Korea 928509-AD1

For use in Spain 928509-071

For use in Switzerland 928509-BG1

For use in Taiwan 928509-AB1

For use in Thailand 928509-281

For use in Turkey 928509-141

For use in the United Kingdom 928509-031

Computer components 21
