HP Mini 210-2087dx PC User Manual

HP Notebook User Guide

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: August 2010

Document Part Number: 623229-001

Product notice

This guide describes features that are common to most models. Some features may not be available on your computer.

To obtain the latest information in this guide, go to the HP Web site at

http://www.hp.com/support.

Software terms

By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a refund subject to the refund policy of your place of purchase.

For any further information or for requesting a full refund of the computer, please contact your local point of sale (the seller).

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Welcome .......................................................................................................................................................... 1

Finding information ............................................................................................................................... 2

2 Getting to know your computer ..................................................................................................................... 3

Top ....................................................................................................................................................... 3

TouchPad ............................................................................................................................ 3

Lights ................................................................................................................................... 4

Keys ..................................................................................................................................... 5

Front ..................................................................................................................................................... 5

Right side ............................................................................................................................................. 6

Left side ................................................................................................................................................ 7

Display .................................................................................................................................................. 8

Bottom .................................................................................................................................................. 9

3 Networking .................................................................................................................................................... 10

Using an Internet service provider (ISP) ............................................................................................ 10

Identifying wireless and network status icons .................................................................................... 10

Creating a wireless connection .......................................................................................................... 11

Turning wireless devices on and off .................................................................................. 11

Using the wireless key ...................................................................................... 11

Using the Network Panel ................................................................................... 11

Using a WLAN .................................................................................................................................... 12

Setting up a new WLAN ..................................................................................................... 12

Connecting to a WLAN ...................................................................................................... 12

Protecting your WLAN ....................................................................................................... 13

Roaming to another network .............................................................................................. 13

Using Bluetooth wireless devices (select models only) ...................................................................... 13

Connecting to a wired network ........................................................................................................... 13

4 Keyboard and pointing devices ................................................................................................................... 15

Using the keyboard ............................................................................................................................ 15

Identifying the hotkey ......................................................................................................... 15

Identifying the action keys ................................................................................................. 16

Using keypads ................................................................................................................... 16

Using the TouchPad ........................................................................................................................... 17

Setting pointing device preferences ................................................................................... 17

5 Multimedia ..................................................................................................................................................... 18

Using the media activity action keys .................................................................................................. 18

Audio .................................................................................................................................................. 18

Adjusting the volume ......................................................................................................... 18

Checking your audio functions ........................................................................................... 19

Webcam ............................................................................................................................................. 19

Video .................................................................................................................................................. 19

6 Power management ...................................................................................................................................... 21

Shutting down the computer ............................................................................................................... 21

Setting power options ......................................................................................................................... 21

Using power-saving states ................................................................................................. 21

Initiating and exiting Sleep ................................................................................ 22

Using power management ................................................................................................. 22

Viewing and changing the current power management settings ....................... 22

Using battery power ........................................................................................................................... 22

Displaying the remaining battery charge ........................................................................... 23

Inserting the battery ........................................................................................................... 24

Removing the battery ......................................................................................................... 24

Charging a battery ............................................................................................................. 25

Conserving and maximizing battery life ............................................................................. 26

Managing low battery levels .............................................................................................. 26

Identifying low battery levels ............................................................................. 26

Resolving a low battery level ............................................................................. 27

Resolving a low battery level when external power is available ....... 27

Resolving a low battery level when a charged battery is available ... 27

Resolving a low battery level when no power source is available .... 27

Resolving a low battery level when the computer cannot exit

Sleep ................................................................................................ 27

Storing a battery ................................................................................................................ 27

Disposing of a used battery ............................................................................................... 27

Replacing the battery ......................................................................................................... 28

Using external AC power .................................................................................................................... 28

Testing an AC adapter ....................................................................................................... 28

7 Drives ............................................................................................................................................................. 29

Handling drives ................................................................................................................................... 29

Replacing the hard drive .................................................................................................................... 30

Removing the hard drive .................................................................................................... 30

Installing a hard drive ......................................................................................................... 32

8 External cards and devices .......................................................................................................................... 34

Using Digital Media Slot cards ........................................................................................................... 34

Inserting a digital card ........................................................................................................ 34

Removing a digital card ..................................................................................................... 35

Using a USB device ........................................................................................................................... 35

Connecting a USB device .................................................................................................. 36

Removing a USB device .................................................................................................... 36

Using optional external devices .......................................................................................................... 36

Using optional external drives ............................................................................................ 37

9 Memory modules .......................................................................................................................................... 38

10 Security ........................................................................................................................................................ 41

Protecting the computer ..................................................................................................................... 41

Using passwords ................................................................................................................................ 41

Setting a password in the operating system ...................................................................... 41

Setting passwords in Setup Utility ..................................................................................... 42

Managing an administrator password ............................................................... 42

Entering an administrator password .................................................................. 43

Managing a power-on password ....................................................................... 43

Entering a power-on password ......................................................................... 43

Installing an optional security cable .................................................................................................... 43

11 Backup and recovery .................................................................................................................................. 45

Performing a system recovery ............................................................................................................ 45

12 Setup Utility (BIOS) ..................................................................................................................................... 46

Starting Setup Utility ........................................................................................................................... 46

Using Setup Utility .............................................................................................................................. 46

Changing the language of Setup Utility ............................................................................. 46

Navigating and selecting in Setup Utility ............................................................................ 46

Displaying system information ........................................................................................... 47

Restoring factory default settings in Setup Utility .............................................................. 47

Exiting Setup Utility ............................................................................................................ 47

Updating the BIOS ............................................................................................................................. 48

Determining the BIOS version ........................................................................................... 48

Downloading a BIOS update ............................................................................................. 48

Appendix A Troubleshooting and support .................................................................................................... 50

Troubleshooting .................................................................................................................................. 50

The computer is unable to start up .................................................................................... 50

The computer screen is blank ............................................................................................ 50

Software is functioning abnormally .................................................................................... 50

The computer is on but not responding ............................................................................. 51

vii

The computer is unusually warm ....................................................................................... 51

An external device is not working ...................................................................................... 51

The wireless network connection is not working ................................................................ 51

Contacting customer support ............................................................................................................. 52

Labels ................................................................................................................................................. 53

Appendix B Routine care ................................................................................................................................ 54

Cleaning the display ........................................................................................................................... 54

Cleaning the TouchPad and keyboard ............................................................................................... 54

Appendix C Specifications .............................................................................................................................. 55

Input power ......................................................................................................................................... 55

Operating environment ....................................................................................................................... 55

Appendix D Electrostatic discharge .............................................................................................................. 56

Index ................................................................................................................................................................... 57

viii

1Welcome

Finding information

●

After you set up and register the computer, take the following steps:

Connect to the Internet—Set up your wired or wireless network so that you can connect to the

●

Internet. For more information, refer to

Networking on page 10.

Get to know your computer—Learn about your computer features. Refer to

●

your computer on page 3 and Keyboard and pointing devices on page 15 for additional

information.

Find installed software—Access the software that is preinstalled on the computer. Select the

●

Applications icon on the MeeGo panel.

NOTE: For details about using the software included with the computer, refer to the software

manufacturer's instructions, which may be provided with the software or on the manufacturer's Web site.

Update programs and drivers—Update your programs and drivers with the latest versions on a

●

regular basis. When your computer is registered, it will automatically be updated with the latest versions. When you register, you can choose to receive automatic notifications when updates become available. The automatic notifications for operating system updates are available for 90 days. You can also go to

Create recovery discs—Allows you to recover the operating system and software to factory

●

settings in case of system instability or failure. You should create them soon after setting up the computer. For instructions, refer to

http://www.hp.com/support to download updates from HP.

Backup and recovery on page 45.

Getting to know

Finding information

The computer comes with several resources to help you perform various tasks.

Resources For information about

Quick Setup poster

MeeGo Help

To access the MeeGo Help, click the MeeGo Help icon in your Myzone Favorites, or click the Applications icon on the MeeGo panel.

Regulatory, Safety, and Environmental Notices

To access the notices, click the Applications icon on the MeeGo panel, and then click Help and Support.

Safety & Comfort Guide

To access this guide:

Click the Applications icon on the MeeGo panel, and then click Help and Support.

– or –

Go to

http://www.hp.com/ergo.

Worldwide Telephone Numbers booklet

This booklet is provided with your computer.

HP Web site

To access this Web site, go to

support.

http://www.hp.com/

Setting up the computer

●

Identifying computer components

●

Computer software

●

Computer settings

●

Connecting to the Internet

●

Computer utilities

●

Regulatory and safety information

●

Battery disposal information

●

Proper workstation setup, posture, health, and work habits

●

Electrical and mechanical safety information

●

HP support telephone numbers

Support information

●

Ordering parts and finding additional help

●

Software, driver, and BIOS (Setup Utility) updates

●

Accessories available for the device

●

Limited Warranty*

To access the warranty:

Click the Applications icon on the MeeGo panel, and then click Help and Support.

– or –

Go to

http://www.hp.com/go/orderdocuments.

*You may find the expressly provided HP Limited Warranty applicable to your product located with the electronic guides on your computer and/or on the CD/DVD provided in the box. Some countries/regions may provide a printed HP Limited Warranty in the box. In countries/regions where the warranty is not provided in printed format, you may request a printed copy at

http://www.hp.com/go/orderdocuments or write to:

North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd, Boise, ID 83714, USA

●

Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy

●

Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

●

Please include your product number, warranty period (found on your serial number label), name and postal address.

2 Chapter 1 Welcome

Warranty information

2 Getting to know your computer

Top

●

Front

●

Right side

●

Left side

●

Display

●

Bottom

●

Top

TouchPad

Component Description

(1)

(2) Left TouchPad button Functions like the left button on an external mouse.

(3) Right TouchPad button Functions like the right button on an external mouse.

(4) TouchPad zone Moves the pointer and selects or activates items on the

TouchPad light Turns the TouchPad on and off. Quickly double-tap the

TouchPad light to turn the TouchPad on and off.

screen.

Top 3

Lights

Component Description

(1)

(2) Caps lock light

(3)

(4)

TouchPad light

Mute light

Wireless light

On: The TouchPad is off.

●

Off: The TouchPad is on.

●

On: Caps lock is on.

●

Off: Caps lock is off.

●

On: Computer sound is off.

●

Off: Computer sound is on.

●

White: An integrated wireless device, such as a

●

wireless local area network (WLAN) device and/or a Bluetooth® device, is on.

Amber: All wireless devices are off.

●

4 Chapter 2 Getting to know your computer

Keys

Component Description

(1) esc key Displays system information when pressed in combination

with the fn key.

(2) fn key Displays system information when pressed in combination

with the esc key.

Front

(3) action keys Execute frequently used system functions.

Component Description

Speakers (2) Produce sound

Front 5

Right side

Component Description

(1) Digital Media Slot Supports the following digital card formats:

Memory Stick

●

Memory Stick Pro

●

MultiMediaCard

●

Secure Digital (SD) Card

●

Secure Digital High Capacity (SDHC) Memory Card

●

Secure Digital Extended Capacity (SDxC) Memory

●

Card

(2)

(3) Power switch

(4)

(5)

(6)

Power light

USB ports (2) Connect optional USB devices.

Security cable slot Attaches an optional security cable to the computer.

RJ-45 (network) jack Connects a network cable.

White: The computer is on.

●

Blinking white: The computer is in the Sleep state.

●

Off: The computer is off.

●

When the computer is off, slide the switch to turn on

●

the computer.

When the computer is in the Sleep state, slide the

●

switch briefly to exit Sleep.

If the computer has stopped responding and operating system shutdown procedures are ineffective, slide and hold the power switch for at least 5 seconds to turn off the computer.

To learn more about your power settings, select the

Devices icon on the MeeGo panel, and then click All settings. Click the Power and brightness icon.

NOTE: The security cable is designed to act as a

deterrent, but it may not prevent the computer from being mishandled or stolen.

6 Chapter 2 Getting to know your computer

Left side

Component Description

(1)

(2) Battery light

(3)

(4) Vent Enables airflow to cool internal components.

(5)

(6)

(7)

Power connector Connects an AC adapter.

Off: The computer is running on battery power.

●

Blinking white: The battery has reached a low or

●

critical battery level.

Amber: A battery is charging.

●

White: The computer is connected to external power

●

and the battery is fully charged.

External monitor port Connects an external VGA monitor or projector.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

Drive light Blinking white: The hard drive is being accessed.

USB port Connects an optional USB device.

Audio-out (headphone) jack/Audio-in (microphone) jack

Connects optional powered stereo speakers, headphones, earbuds, a headset, or television audio. Also connects an optional headset microphone.

WARNING! To reduce the risk of personal injury, adjust

the volume before putting on headphones, earbuds, or a headset. For additional safety information, refer to the Regulatory, Safety, and Environmental Notices.

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

Left side 7

Display

Component Description

(1) WLAN antennas (2)* Send and receive wireless signals to communicate with wireless

local area networks (WLAN).

(2) Internal microphone Records sound.

(3) Webcam Records video and captures still photographs.

(4) Webcam light On: The webcam is in use.

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. To see wireless regulatory notices, refer to the section of the Regulatory, Safety, and Environmental Notices that applies to your country or region.

8 Chapter 2 Getting to know your computer

Bottom

Component Description

(1)

(2) Battery bay Holds the battery.

(3)

Battery locking latch Locks the battery into the battery bay.

Battery release latch Releases the battery from the battery bay.

Bottom 9

3Networking

Using an Internet service provider (ISP)

●

Identifying wireless and network status icons

●

Creating a wireless connection

●

Using a WLAN

●

Using Bluetooth wireless devices (select models only)

●

Connecting to a wired network

●

Your computer may support one or both of the following types of Internet access:

Wireless—For mobile Internet access, you can use a wireless connection. Refer to

●

to a WLAN on page 12 or Setting up a new WLAN on page 12.

Wired—You can access the Internet by connecting to a wired network. For information on

●

connecting to a wired network, refer to

NOTE: Internet hardware and software features vary depending on computer model and your

location.

Connecting to a wired network on page 13.

Using an Internet service provider (ISP)

Before you can connect to the Internet, you must establish an ISP account. Contact a local ISP to purchase Internet service and a modem. The ISP can help set up the modem, install a network cable to connect your wireless computer to the modem, and test the Internet service.

NOTE: Your ISP will give you a user ID and password to access the Internet. Record this

information and store it in a safe place.

Identifying wireless and network status icons

Icon Name Description

Wireless Connection (connected)

Indicates that one or more wireless devices are connected and active.

Connecting

10 Chapter 3 Networking

Network Connection (connected)

Indicates that a wired network is connected and active.

Network Connection (disconnected)

Creating a wireless connection

Your computer may be equipped with one or more of the following wireless devices:

Wireless local area network (WLAN) device

●

Bluetooth device

●

Turning wireless devices on and off

Using the wireless key

Use the wireless key to turn both the wireless network controller and the Bluetooth controller off or on simultaneously. They can be controlled individually through the MeeGo Network panel or Setup Utility.

NOTE: Refer to Identifying the action keys on page 16 for information on identifying the location of

the wireless key on your computer.

Indicates that wired and wireless networks are not connected.

Using the Network Panel

To enable or disable a wireless and/or wired network device:

1. Click the Networks icon on the right side of the MeeGo panel.

2. To enable a device, drag the control button for the device to the right, or to disable a device,

drag the control button for the device to the left. You can also click the blue “I” or black “0” to enable or disable a device. The color of the button indicates the status of the device. Blue is on and white is disabled.

The following devices may be supported:

Wi-Fi

●

Wired

●

3G (additional hardware required)

●

Bluetooth

●

Offline mode (all network devices)

●

Creating a wireless connection 11

Using a WLAN

A wireless connection connects the computer to Wi-Fi networks, or WLANs. A WLAN is composed of other computers and accessories that are linked by a wireless router or a wireless access point.

Setting up a new WLAN

Required equipment:

A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from

●

an Internet service provider (ISP)

A wireless router (purchased separately) (2)

●

The wireless computer (3)

●

The illustration below shows an example of a wireless network installation that is connected to the Internet.

NOTE: Some cable modems include a built-in router. Check with your ISP to see if you need a

separate router.

NOTE: When setting up a wireless connection, be sure that your computer and wireless router are

synchronized. To synchronize your computer and wireless router, turn your computer and wireless router off and then back on.

As your network grows, additional wireless and wired computers can be connected to the network to access the Internet.

For help in setting up your WLAN, refer to the information provided by your router manufacturer or your ISP.

Connecting to a WLAN

1. Be sure that the WLAN device is on.

NOTE: Refer to Identifying the action keys on page 16 and Getting to know your computer

on page 3 for information on identifying the location of the wireless key and the wireless light on

your computer.

2. Click the Networks icon on the MeeGo panel.

3. Click the wireless network you want to connect to.

If the network is a security-enabled WLAN, you are prompted to enter a password. Type the password, and then click Connect to complete the connection.

NOTE: To connect to a network that is not automatically detected, click the Add new

connection button. Enter the ESSID information, and set encryption parameters, and then click the Connect button.

NOTE: If no WLANs are listed, and your network is not hidden, you are out of range of a

wireless router or access point.

12 Chapter 3 Networking

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always enable security features to protect your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and airports may not provide any security. If you are concerned about the security of your computer in a hotspot, limit your network activities to e-mail that is not confidential and basic Internet surfing.

Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected signals. You can protect your WLAN by using wireless encryption, which is Wi-Fi Protected Access (WPA and WPA2) that encrypts and decrypts data transmitted over the network.

WPA uses Temporal Key Integrity Protocol (TKIP) to dynamically generate a new key for every packet. It also generates different sets of keys for each computer on the network.

Wired Equivalent Privacy (WEP) encrypts data before it is transmitted using a WEP key. Without the correct key, others will not be able to use the WLAN.

Roaming to another network

When you move your computer within range of another WLAN, the operating system attempts to connect to that network. If the attempt is successful, your computer is automatically connected to the new network. If the operating system does not recognize the new network, follow the same procedure you used initially to connect to your WLAN.

Using Bluetooth wireless devices (select models only)

A Bluetooth device provides short-range wireless communications that replace the physical cable connections that traditionally link electronic devices such as the following:

Computers

●

Phones

●

Audio devices

●

The strength of Bluetooth is in synchronizing information transfers between your computer and wireless devices. The inability to consistently connect two or more computers to share the Internet through Bluetooth is a limitation of Bluetooth and the operating system.

Bluetooth devices provide peer-to-peer capability that allows you to set up a personal area network (PAN) of Bluetooth devices. For information on configuring and using Bluetooth devices, refer to the Bluetooth software Help.

Connecting to a wired network

Connecting to a local area network (LAN) requires an 8-pin, RJ-45 network cable (purchased separately). If the network cable contains noise suppression circuitry (1), which prevents interference from TV and radio reception, orient the circuitry end of the cable (2) toward the computer.

Using Bluetooth wireless devices (select models only) 13

+ 46 hidden pages
