HP Mini 210, HP Mini 110, Compaq
Mini CQ10
Maintenance and Service Guide
© Copyright 2012 Hewlett-Packard
Development Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel and Atom are
trademarks or registered trademarks of Intel
Corporation in the United States and other
countries. Microsoft and Windows are U.S.
registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its
proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: January 2012
Document Part Number: 655762-001
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not
place the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat
surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface,
such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the
skin or a soft surface, such as pillows or rugs or clothing, during operation. The device and the AC
adapter comply with the user accessible surface temperature limits defined by the International
Standard for Safety of Information Technology Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Product description ........................................................................................................... 1
2 External component identification ..................................................................................... 6
Keys ....................................................................................................................................... 6
Display ................................................................................................................................... 7
Buttons .................................................................................................................................... 8
Lights ...................................................................................................................................... 9
TouchPad .............................................................................................................................. 10
Left side ................................................................................................................................ 11
Right side .............................................................................................................................. 12
Bottom .................................................................................................................................. 13
3 Illustrated parts catalog .................................................................................................. 14
Service tag ............................................................................................................................ 15
Computer major components ................................................................................................... 16
Display assembly subcomponents ............................................................................................. 26
Mass storage devices ............................................................................................................. 28
Miscellaneous parts ................................................................................................................ 29
Sequential part number listing .................................................................................................. 30
4 Removal and replacement procedures ............................................................................ 43
Preliminary replacement requirements ....................................................................................... 43
Tools required ......................................................................................................... 43
Service considerations ............................................................................................. 43
Plastic parts ............................................................................................. 43
Cables and connectors ............................................................................. 43
Drive handling ......................................................................................... 44
Grounding guidelines .............................................................................................. 44
Electrostatic discharge damage .................................................................. 44
Packaging and transporting guidelines ........................................ 46
Component replacement procedures ........................................................................................ 48
v
Service tag ............................................................................................................. 48
Computer feet ......................................................................................................... 49
Battery ................................................................................................................... 50
SIM (select models only) ........................................................................................... 51
WLAN module ........................................................................................................ 52
WWAN module ..................................................................................................... 55
Memory module ...................................................................................................... 57
RTC battery ............................................................................................................ 58
Hard drive ............................................................................................................. 59
Keyboard ............................................................................................................... 61
Top cover ............................................................................................................... 67
Speakers ................................................................................................................ 73
System board ......................................................................................................... 74
Fan ....................................................................................................................... 77
Heat sink ................................................................................................................ 79
Display assembly .................................................................................................... 81
5 Setup Utility (BIOS) and System Diagnostics .................................................................... 87
Using Setup Utility .................................................................................................................. 87
Starting Setup Utility ................................................................................................ 87
Changing the language of Setup Utility ...................................................................... 87
Navigating and selecting in Setup Utility .................................................................... 88
Displaying system information ................................................................................... 88
Restoring factory settings in Setup Utility ..................................................................... 89
Exiting Setup Utility ................................................................................................. 89
Updating the BIOS .................................................................................................. 89
Determining the BIOS version .................................................................... 90
Downloading a BIOS update ..................................................................... 90
Using System Diagnostics ........................................................................................................ 91
6 Specifications ................................................................................................................. 92
Computer specifications .......................................................................................................... 92
10.1-inch WSVGA display specifications .................................................................................. 93
Hard drive specifications ........................................................................................................ 94
7 Backup and recovery ...................................................................................................... 95
Backing up your information .................................................................................................... 96
Performing a system recovery .................................................................................................. 97
Using the Windows recovery tools ............................................................................ 97
Using f11 recovery tools .......................................................................................... 98
vi
Using a Windows 7 operating system DVD (purchased separately) ............................... 98
8 Power cord set requirements ........................................................................................ 100
Requirements for all countries ................................................................................................ 100
Requirements for specific countries and regions ....................................................................... 101
9 Recycling ...................................................................................................................... 103
Index ............................................................................................................................... 104
vii
viii
1 Product description
Category Description HP Mini
210
Product Name HP Mini 210 √
HP Mini 110 √
Compaq Mini CQ10 √
Processors
Chipset Intel NM10 Express Chipset √√√
Graphics Internal graphics:
●
Intel® Atom N2800 1.86-GHz processor, dual
core, 1.0-MB L2 cache, 1066-MHz front-side
bus (FSB), 6.5 W
●
Intel Atom N2600 1.60-GHz processor, dual
core, 1.0-MB L2 cache, 800-MHz FSB, 3.5 W
Processor is soldered to the system board
●
Intel Graphics Media Accelerator 3650 on
computer models equipped with an Intel Atom
N2800 processor (shared memory with up to
256-MB supported via Intel DVMT)
●
Intel Graphics Media Accelerator 3600 on
computer models equipped with an Intel Atom
N2600 processor (shared memory with up to
256-MB supported via Intel DVMT)
√√√
√√√
HP Mini
110
Compaq
Mini CQ10
Supports MPEG2/AVC/H.264/VC1/WMV9, and
Microsoft DX9
Panel 10.1-in, light-emitting diode (LED), WSVGA,
AntiGlare (1024×600) display; typical brightness:
200 nits
All display assemblies include 2 wireless local area
network (WLAN) antenna cables
Supports 16:9 wide aspect ratio
Lighted logo on top bezel
√√√
1
Category Description HP Mini
210
HP Mini
110
Compaq
Mini CQ10
Memory One customer-accessible/upgradable memory
module slot
DDR3-1066-MHz single channel support (on
computer models equipped with an Intel Atom
N2800 processor), DDR3-800-MHz single channel
support (on computer models equipped with an Intel
Atom N2600 processor)
Supports up to 2-GB of system RAM (2048×1 or
1024×2)
NOTE: 2-GB of system memory is not supported on
computer models equipped with Windows 7 Starter
or Windows 7 Home Basic in the People's Republic
of China.
Hard drives Supports 6.35-cm (2.5-in) hard drives in 9.5-mm
(.37-in) and 7.0-mm (.28-in) thicknesses
Customer-accessible √√√
Serial ATA √√√
Supports Accelerometer hard drive protection √√√
Supports the following configurations:
●
500 GB, 5400 rpm, 9.5 mm
√√√
√√√
√√√
NOTE: A 500-GB hard drive is not supported
on computer models equipped with Windows 7
Starter or Windows 7 Home Basic in the
People's Republic of China.
●
320 GB, 7200 rpm, 7.0 mm
●
320 GB, 5400 rpm, 9.5 and 7.0 mm
●
250 GB, 7200 rpm, 7.0 mm
●
250 GB, 5400 rpm, 9.5 and 7.0 mm
Audio and video Single digital microphone √√√
HD audio √√
Beats Audio with Beats logo √
Beats hotkey (fn+b) √√√
2 integrated, boxed stereo speakers, 1.5 W max √√√
HP VGA webcam (fixed, no tilt with activity LED, F/
2.8, 640×480 by 30 frames per second)
Ethernet Integrated 10/100 RTL8105T-VC-CG network
interface card (NIC)
√√√
√√√
2 Chapter 1 Product description
Category Description HP Mini
210
HP Mini
110
Compaq
Mini CQ10
Wireless Integrated wireless local area network (WLAN)
options by way of wireless module
Two WLAN antennas built into display assembly √√√
Support for the following WLAN formats:
●
Atheros 9485GN 802.11b/g/n 1×1 WiFi and
3012 Bluetooth 4.0 Combo Adapter
●
Broadcom 4313GN 802.11b/g/n 1×1 WiFi
and 20702 Bluetooth 4.0 Combo Adapter
●
Intel Centrino Advanced-N 6230
WLAN module
●
Ralink 5390GN 802.11b/g/n 1×1
WiFi Adapter
Integrated wireless wide area network (WWAN)
options by way of wireless module
Two WWAN antennas built into display assembly √√√
Support for the following WLAN formats:
●
HP hs2340 HSPA+ Mobile Broadband Module
●
HP lc2000 HSPA Mobile Broadband Module
√√√
√√√
√√√
√√√
External media
cards
●
HP lc2010 HSPA Mobile Broadband Module
Digital Media Slot with push-push technology,
supporting:
●
MultiMediaCard
●
Secure Digital (SD) Memory Card
●
Secure Digital High Capacity (SDHC)
Memory Card
●
Secure Digital Extended Capacity (SDxC)
Supports mini versions by use of an adapter (adapter
is not included).
√√√
3
Category Description HP Mini
210
HP Mini
110
Compaq
Mini CQ10
Ports
Keyboard/
pointing devices
Textured, pocket-style keyboard √√
TouchPad with capacitive multi-touch gestures, 2-
Taps enabled by default √√√
Power
requirements
●
3-pin AC power
●
Audio-in (mono microphone)
●
Audio-out (stereo headphone)
●
RJ-45 (Ethernet, includes link and activity lights)
●
USB 2.0 (3 ports)
●
VGA (Dsub 15 pin) supporting 1920 ×1200
external resolution @ 60Hz, hot plug and
unplug and auto-detection for correct output to
wide-aspect vs. standard aspect video
93%-size, Island-style, spill-resistant, keyboard with
full numeric keypad
finger scrolling, and pinch-zoom enabled
40W AC adapter with localized cable plug support
(3-wire plug with ground pin, supports 3-pin
DC connector)
√√√
√
√√√
√√√
Support for the following batteries:
●
6-cell, 55-Whr, 2.55-Ah Li-ion battery
●
3-cell, 28-Whr, 2.55-Ah Li-ion battery
Security Supports security lock √√√
Operating system Preinstalled:
●
Windows 7 Home Basic 32-bit
●
Windows 7 Home Premium 32-bit
●
Windows 7 Professional 32-bit
●
Windows 7 Starter 32-bit
●
USB key recovery support for service, refurbish
centers, and repair centers
√√√
√√√
4 Chapter 1 Product description
Category Description HP Mini
210
HP Mini
110
Compaq
Mini CQ10
Serviceability End-user replaceable parts:
●
Free DOS (does not support Beats Audio,
EnergyStar 5.0, QuickWeb, or
WWAN functionality)
●
AC adapter
●
Battery
●
Hard drive
●
Memory module
●
WLAN module
●
WWAN module
√√
√√√
5
2 External component identification
Keys
Item Component Description
(1) Action keys Execute frequently used system functions.
(2) fn key Executes frequently used system functions when pressed
(3) Windows logo key Displays the Windows Start menu.
(4) Windows applications key Displays a shortcut menu for items beneath the pointer.
6 Chapter 2 External component identification
in combination with a function key, the num lk key, or the
esc key.
Display
Item Component Description
(1) WLAN antennas (2)* Send and receive wireless signals to communicate
with WLANs.
(2) WWAN antennas (2)* Send and receive wireless signals to communicate
with WWANs.
(3) Internal microphone Records sound.
(4) Webcam Records video and captures still photographs.
To use the webcam, double-click the ArcSoft Camera
Suite icon on the desktop, or select Start > All
Programs > ArcSoft Camera Suite > Launch
WebCam Companion.
(5) Webcam light On: The webcam is in use.
*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around
the antennas free from obstructions. To see wireless regulatory notices, refer to the section of the Regulatory, Safety, and
Environmental Notices that applies to your country or region. These notices are located in Help and Support.
Display
7
Buttons
Item Component Description
(1) Power button
(2) Web browser button When the computer is in Microsoft Windows, press the
●
When the computer is off, press the button to turn on
the computer.
●
When the computer is on, press the button briefly to
initiate Sleep.
●
When the computer is in the Sleep state, press the
button briefly to exit Sleep.
●
When the computer is in Hibernation, press the
button briefly to exit Hibernation.
If the computer has stopped responding and Windows
shutdown procedures are ineffective, press and hold the
power button for at least 5 seconds to turn off
the computer.
To learn more about your power settings, select Start >
Control Panel > System and Security > Power
Options, or refer to the HP Notebook Reference Guide.
button to open the default Web browser.
8 Chapter 2 External component identification
Lights
Item Component Description
(1) Power light
(2) Mute light
(3) Wireless light
(4) Caps lock light On: Caps lock is on.
(5) TouchPad light
●
White: The computer is on.
●
Blinking white: The computer is in the Sleep state.
●
Off: The computer is off or in Hibernation.
●
Amber: Computer sound is off.
●
Off: Computer sound is on.
●
White: An integrated wireless device, such as a
WLAN device and/or a Bluetooth device, is on.
●
Amber: All wireless devices are off.
●
Off: The TouchPad is on.
●
Amber: The TouchPad is off.
Lights
9
TouchPad
Item Component Description
(1) TouchPad light
(2) TouchPad on/off button Quickly double-tap the TouchPad on/off button to turn the
(3) TouchPad zone Moves the pointer and selects or activates items on
(4) Left TouchPad button Functions like the left button on an external mouse.
(5) Right TouchPad button Functions like the right button on an external mouse.
●
On: The TouchPad is on.
●
Amber: The TouchPad is off.
TouchPad off and on.
the screen.
10 Chapter 2 External component identification
Left side
Item Component Description
(1) External monitor port Connects an external VGA monitor or projector.
(2) Power connector Connects an AC adapter.
(3) AC adapter/battery light
(4) Vents Enables airflow to cool internal components.
(5) USB 2.0 port Connect an optional USB 2.0 device.
(6) Hard drive light On : The hard drive is being accessed.
●
Amber: The computer is connected to external
power, and the battery is charging.
●
White: The computer is connected to external
power, and the battery is fully charged.
●
Blinking white: The computer is in the Sleep state, or
the battery charge level is 10% or less (recharge the
battery as soon as possible).
●
Off: The computer is not connected to
external power.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during
routine operation.
Left side
11
Right side
Item Component Description
(1) Digital Media Slot Supports the following digital card formats:
●
MultiMediaCard
●
Secure Digital (SD) Memory Card
●
Secure Digital High Capacity (SDHC) Memory Card
●
Secure Digital Extended Capacity (SDxC)
Supports mini versions by use of an adapter (adapter is
not included).
(2) Audio-out (headphone) jack Produce sound when connected to optional powered
stereo speakers, headphones, ear buds, a headset, or
television audio.
WARNING! To reduce the risk of personal injury,
adjust the volume before putting on headphones,
earbuds, or a headset. For additional safety information,
refer to the Regulatory, Safety, and Environmental
Notices.
When a device is connected to the jack, the computer
speakers are disabled.
(3) Audio-in (microphone) jack Connects an optional computer headset microphone,
stereo array microphone, or monaural microphone.
(4) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
(5) USB 2.0 ports (2) Connects optional USB 2.0 devices.
(6) RJ-45 (network) jack Connects a network cable.
12 Chapter 2 External component identification
Bottom
Item Component Description
(1) Battery bay Holds the battery and the subscriber identity module
(SIM) slot.
(2) Battery/service cover release latch Releases the battery from the battery bay and the service
cover from the computer.
(3) Service cover Provides access to the hard drive bay, the memory
module slot, the WLAN module, and the WWAN module
(select models only).
Bottom
13
3 Illustrated parts catalog
14 Chapter 3 Illustrated parts catalog
Service tag
When ordering parts or requesting information, provide the computer serial number and model
description provided on the service tag.
Item Description Function
(1) Product name This is the product name affixed to the front of
the computer.
(2) Serial number (s/n) This is an alphanumeric identifier that is unique to
each product.
(3) Part number/Product number (p/n) This number provides specific information about the
product's hardware components. The part number
helps a service technician to determine what
components and parts are needed.
(4) Warranty period This number describes the duration of the warranty
period for the computer.
(5) Model description This is the alphanumeric identifier used to locate
documents, drivers, and support for the computer.
Service tag
15
Computer major components
16 Chapter 3 Illustrated parts catalog
Item Component Spare part number
(1) Display assembly, 10.1-in (includes display panel cable, 2 WLAN antenna transceivers and cables, and
webcamera/microphone module and cable):
BrightView, WSVGA display assembly for use only on Compaq Mini CQ10
computer models
BrightView, WSVGA display assembly in black finish for use only on HP Mini 110
computer models equipped with WWAN capability (includes WWAN antenna cables
and transceivers)
BrightView, WSVGA display assembly in black finish for use only on HP Mini 110
computer models
BrightView, WSVGA display assembly in Pacific blue finish for use only on HP Mini
110 computer models
BrightView, WSVGA display assembly in Sonora red finish for use only on HP Mini
110 computer models
FlushGlass, HD display assembly in charcoal finish for use only on HP Mini 210
computer models equipped with WWAN capability (includes WWAN antenna cables
and transceivers)
FlushGlass, HD display assembly in charcoal finish for use only on HP Mini 210
computer models
FlushGlass, HD display assembly in crimson red finish for use only on HP Mini 210
computer models
FlushGlass, HD display assembly in luminous rose finish for use only on HP Mini 210
computer models
664894-001
668166-001
658507-001
658510-001
658508-001
650712-001
668156-001
668159-001
668158-001
FlushGlass, HD display assembly in ocean drive finish for use only on HP Mini 210
computer models
FlushGlass, HD display assembly in sweet purple finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in charcoal finish for use only on HP Mini 210
computer models equipped with WWAN capability (includes WWAN antenna cables
and transceivers)
WSVGA, HD display assembly in charcoal finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in crimson red finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in luminous rose finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in ocean drive finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in sweet purple finish for use only on HP Mini 210
computer models
NOTE: For more display assembly spare part information, see
(2) Keyboard (includes keyboard cable):
Display assembly subcomponents on page 26.
668157-001
668160-001
650719-001
668161-001
668164-001
668163-001
668162-001
668165-001
Computer major components
17
Item Component Spare part number
Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models:
For use in Belgium 658517-A41
For use in Bulgaria 658517-261
For use in Canada 658517-121
For use in the Czech Republic and Slovakia 658517-FL1
For use in Denmark, Finland, and Norway 658517-DH1
For use in France 658517-051
For use in Germany 658517-041
For use in Greece 658517-DJ1
For use in Hungary 658517-211
For use in Israel 658517-BB1
For use in Italy 658517-061
For use in Japan 658517-291
For use in Latin America 658517-161
For use in the Netherlands 658517-B31
For use in Portugal 658517-131
For use in Russia 658517-251
For use in Saudi Arabia 658517-171
For use in Slovenia 658517-BA1
For use in South Korea 658517-AD1
For use in Spain 658517-071
For use in Switzerland 658517-BG1
For use in Taiwan 658517-AB1
For use in Thailand 658517-281
For use in Turkey 658517-141
For use in the United Kingdom and Singapore 658517-031
For use in the United States 658517-001
Keyboard in charcoal finish for use only on HP Mini 210 computer models:
For use in Belgium 665962-A41
For use in Bulgaria 665962-261
For use in Canada 665962-121
For use in the Czech Republic and Slovakia 665962-FL1
18 Chapter 3 Illustrated parts catalog
Item Component Spare part number
For use in Denmark, Finland, and Norway 665962-DH1
For use in France 665962-051
For use in Germany 665962-041
For use in Greece 665962-DJ1
For use in Hungary 665962-211
For use in India 665962-D61
For use in Israel 665962-BB1
For use in Italy 665962-061
For use in Japan 665962-291
For use in Latin America 665962-161
For use in the Netherlands 665962-B31
For use in Portugal 665962-131
For use in Russia 665962-251
For use in Saudi Arabia 665962-171
For use in Slovenia 665962-BA1
For use in South Korea 665962-AD1
For use in Spain 665962-071
For use in Switzerland 665962-BG1
For use in Taiwan 665962-AB1
For use in Thailand 665962-281
For use in Turkey 665962-141
For use in the United Kingdom and Singapore 665962-031
For use in the United States 665962-001
Keyboard in crimson red finish for use only on HP Mini 210 computer models:
For use in Belgium 665965-A41
For use in Bulgaria 665965-261
For use in Canada 665965-121
For use in the Czech Republic and Slovakia 665965-FL1
For use in Denmark, Finland, and Norway 665965-DH1
For use in France 665965-051
For use in Germany 665965-041
For use in Greece 665965-DJ1
Computer major components
19
Item Component Spare part number
For use in Hungary 665965-211
For use in India 665965-D61
For use in Israel 665965-BB1
For use in Italy 665965-061
For use in Japan 665965-291
For use in Latin America 665965-161
For use in the Netherlands 665965-B31
For use in Portugal 665965-131
For use in Russia 665965-251
For use in Saudi Arabia 665965-171
For use in Slovenia 665965-BA1
For use in South Korea 665965-AD1
For use in Spain 665965-071
For use in Switzerland 665965-BG1
For use in Taiwan 665965-AB1
For use in Thailand 665965-281
For use in Turkey 665965-141
For use in the United Kingdom and Singapore 665965-031
For use in the United States 665965-001
Keyboard in luminous rose finish for use only on HP Mini 210 computer models:
For use in Belgium 665964-A41
For use in Bulgaria 665964-261
For use in Canada 665964-121
For use in the Czech Republic and Slovakia 665964-FL1
For use in Denmark, Finland, and Norway 665964-DH1
For use in France 665964-051
For use in Germany 665964-041
For use in Greece 665964-DJ1
For use in Hungary 665964-211
For use in India 665964-D61
For use in Israel 665964-BB1
For use in Italy 665964-061
20 Chapter 3 Illustrated parts catalog
Item Component Spare part number
For use in Japan 665964-291
For use in Latin America 665964-161
For use in the Netherlands 665964-B31
For use in Portugal 665964-131
For use in Russia 665964-251
For use in Saudi Arabia 665964-171
For use in Slovenia 665964-BA1
For use in South Korea 665964-AD1
For use in Spain 665964-071
For use in Switzerland 665964-BG1
For use in Taiwan 665964-AB1
For use in Thailand 665964-281
For use in Turkey 665964-141
For use in the United Kingdom and Singapore 665964-031
For use in the United States 665964-001
Keyboard in ocean drive finish for use only on HP Mini 210 computer models:
For use in Belgium 665963-A41
For use in Bulgaria 665963-261
For use in Canada 665963-121
For use in the Czech Republic and Slovakia 665963-FL1
For use in Denmark, Finland, and Norway 665963-DH1
For use in France 665963-051
For use in Germany 665963-041
For use in Greece 665963-DJ1
For use in Hungary 665963-211
For use in India 665963-D61
For use in Israel 665963-BB1
For use in Italy 665963-061
For use in Japan 665963-291
For use in Latin America 665963-161
For use in the Netherlands 665963-B31
For use in Portugal 665963-131
Computer major components
21
Item Component Spare part number
For use in Russia 665963-251
For use in Saudi Arabia 665963-171
For use in Slovenia 665963-BA1
For use in South Korea 665963-AD1
For use in Spain 665963-071
For use in Switzerland 665963-BG1
For use in Taiwan 665963-AB1
For use in Thailand 665963-281
For use in Turkey 665963-141
For use in the United Kingdom and Singapore 665963-031
For use in the United States 665963-001
Keyboard in sweet purple finish for use only on HP Mini 210 computer models:
For use in Belgium 665966-A41
For use in Bulgaria 665966-261
For use in Canada 665966-121
For use in the Czech Republic and Slovakia 665966-FL1
For use in Denmark, Finland, and Norway 665966-DH1
For use in France 665966-051
For use in Germany 665966-041
For use in Greece 665966-DJ1
For use in Hungary 665966-211
For use in India 665966-D61
For use in Israel 665966-BB1
For use in Italy 665966-061
For use in Japan 665966-291
For use in Latin America 665966-161
For use in the Netherlands 665966-B31
For use in Portugal 665966-131
For use in Russia 665966-251
For use in Saudi Arabia 665966-171
For use in Slovenia 665966-BA1
For use in South Korea 665966-AD1
22 Chapter 3 Illustrated parts catalog
Item Component Spare part number
For use in Spain 665966-071
For use in Switzerland 665966-BG1
For use in Taiwan 665966-AB1
For use in Thailand 665966-281
For use in Turkey 665966-141
For use in the United Kingdom and Singapore 665966-031
For use in the United States 665966-001
(3) Top cover (includes TouchPad board and bracket):
In black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models 663677-001
In charcoal finish for use only on HP Mini 210 computer models 650747-001
In crimson red finish for use only on HP Mini 210 computer models 650752-001
In luminous rose finish for use only on HP Mini 210 computer models 650751-001
In ocean drive finish for use only on HP Mini 210 computer models 650748-001
In Pacific blue finish for use only on HP Mini 110 computer models 658515-001
In Sonora red finish for use only on HP Mini 110 computer models 658513-001
In sweet purple finish for use only on HP Mini 210 computer models 654204-001
(4) Speakers (include cables) 650736-001
(5) System board (includes processor and replacement thermal material):
For use only with Beats Edition computer models equipped with an Intel Atom N2800
1.86-GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 6.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom
N2800 1.86-GHz processor and WWAN capability (1.0-MB L2 cache,
dual core, 6.5 W)
For use only with Beats Edition computer models equipped with an Intel Atom N2800
1.86-GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 6.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom
N2800 1.86-GHz processor, but not WWAN capability (1.0-MB L2 cache,
dual core, 6.5 W)
For use only with Beats Edition computer models equipped with an Intel Atom N2600
1.60-GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 3.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom
N2600 1.60-GHz processor and WWAN capability (1.0-MB L2 cache,
dual core, 3.5 W)
667753-001
676912-001
667752-001
676911-001
667751-001
676910-001
For use only with Beats Edition computer models equipped with an Intel Atom N2600
1.60-GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 3.5 W)
Computer major components
667750-001
23
Item Component Spare part number
For use only with non-Beats Edition computer models equipped with an Intel Atom
N2600 1.60-GHz processor, but not WWAN capability (1.0-MB L2 cache,
dual core, 3.5 W)
(6) Heat sink (includes replacement thermal material) 651898-001
(7) Fan 651897-001
(8) Power connector cable 656095-001
(9) Battery:
6-cell, 55-Wh, 2.55-Ah, Li-ion battery 646757-001
3-cell, 28-Wh, 2.55-Ah, Li-ion battery 646755-001
(10) Base enclosure:
For use only with Beats Edition computer models 650710-001
For use only with non-Beats Edition computer models 663675-001
(11) 2-GB memory module (PC3, 10600, 1333-MHz): 621565-001
(12) WWAN module:
HP hs2340 HSPA+ Mobile Broadband Module 632155-001
HP lc2000 HSPA Mobile Broadband Module 612599-001
676909-001
HP lc2010 HSPA Mobile Broadband Module 612600-001
(13) RTC battery 599516-001
(14) WLAN module:
Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 655795-001
Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0
Combo Adapter
Intel Centrino Advanced-N 6230 WLAN module 631956-001
Ralink 5390GN 802.11b/g/n 1×1 WiFi Adapter 630703-001
(15) Hard drive (2.5-in, 7.0-mm, SATA; does not include hard drive bracket, hard drive connector cable, hard drive
rubber isolators, screws):
500-GB, 5400-rpm 634932-001
320-GB, 5400-rpm 645193-001
250-GB, 5400-rpm 645191-001
Hard Drive Hardware Kit (not illustrated, includes hard drive bracket, hard drive
connector cable, hard drive rubber isolators, and screws)
(16) Service cover:
Service cover in black finish for use only on Compaq Mini CQ10 and HP Mini 110
computer models
657325-001
664913-001
663676-001
Service cover in charcoal finish for use only on HP Mini 210 computer models 650727-001
24 Chapter 3 Illustrated parts catalog
Item Component Spare part number
Service cover in crimson red finish for use only on HP Mini 210 computer models 650732-001
Service cover in luminous rose for use only on HP Mini 210 computer models 650731-001
Service cover in ocean drive for use only on HP Mini 210 computer models 650728-001
Service cover in sweet purple finish for use only on HP Mini 210 computer models 654203-001
(17) Corner covers 652308-001
Rubber Kit (includes 2 rubber feet) 650734-001
Computer major components
25
Display assembly subcomponents
Item Component Spare part number
(1) Display bezel:
For use only on Compaq Mini CQ10 computer models 658504-001
For use only on HP Mini 110 computer models 658503-001
(2) Webcam/microphone module 658516-001
(3) 10.1-in, LED, BrightView, WSVGA display panel 658511-001
(4) Display Hinge Kit (includes left and right display hinges and brackets) 650711-001
(5) Display Cable Kit (includes display panel cable and webcamera/microphone
module cable)
(6) Antenna Kit (includes left and right wireless antenna cables and transceivers) 658498-001
(7) Display enclosure
26 Chapter 3 Illustrated parts catalog
658505-001
Item Component Spare part number
For use only on Compaq Mini CQ10 computer models 658518-001
In black finish for use only on HP Mini 110 computer models 658499-001
In Pacific blue finish for use only on HP Mini 110 computer models 658502-001
In Sonora red finish for use only on HP Mini 110 computer models 658500-001
Display assembly subcomponents
27
Mass storage devices
Item Component Spare part number
(1) Hard drive (2.5-in, 7.0-mm, SATA; does not include hard drive connector cable, hard drive bracket, or screws):
500-GB, 5400-rpm 634932-001
320-GB, 5400-rpm 645193-001
250-GB, 5400-rpm 645191-001
Hard Drive Hardware Kit, includes: 664913-001
(2a) Hard drive bracket
(2b) Hard drive connector cable
(2c) Hard drive rubber isolators (2)
Screws (not illustrated)
(3) USB external DVD±RW DL SuperMulti Drive 659940-001
28 Chapter 3 Illustrated parts catalog
Miscellaneous parts
Component Spare part number
40-W HP Smart AC adapter (RC/V 2-wire) 624502-001
HP mobile optical wireless 2.4-GHz mouse 597587-001
HP protective mini sleeve:
In charcoal finish 631188-001
In crimson red finish 628348-001
In luminous rose finish 628344-001
In ocean drive finish 628346-001
Power cord (3-pin, black, 1.83-m):
For use in Argentina 490371-D01
For use in Australia 490371-011
For use in Denmark 490371-081
For use in Europe 490371-021
For use in India 490371-D61
For use in Israel 490371-BB1
For use in Italy 490371-061
For use in Japan 490371-291
For use in North America 490371-001
For use in the People's Republic of China 490371-AA1
For use in South Africa 490371-AR1
For use in South Korea 490371-AD1
For use in Switzerland 490371-111
For use in Taiwan 490371-AB1
For use in Thailand 490371-201
For use in the United Kingdom and Singapore 490371-031
Screw Kit 650735-001
Miscellaneous parts
29
Sequential part number listing
Spare part number Description
490371-001 Power cord for use in North America (3-pin, black, 1.83-m)
490371-011 Power cord for use in Australia (3-pin, black, 1.83-m)
490371-021 Power cord for use in Europe (3-pin, black, 1.83-m)
490371-031 Power cord for use in the United Kingdom and Singapore (3-pin, black, 1.83-m)
490371-061 Power cord for use in Italy (3-pin, black, 1.83-m)
490371-081 Power cord for use in Denmark (3-pin, black, 1.83-m)
490371-111 Power cord for use in Switzerland (3-pin, black, 1.83-m)
490371-201 Power cord for use in Thailand (3-pin, black, 1.83-m)
490371-291 Power cord for use in Japan (3-pin, black, 1.83-m)
490371-AA1 Power cord for use in the People's Republic of China (3-pin, black, 1.83-m)
490371-AB1 Power cord for use in Taiwan (3-pin, black, 1.83-m)
490371-AD1 Power cord for use in South Korea (3-pin, black, 1.83-m)
490371-AR1 Power cord for use in South Africa (3-pin, black, 1.83-m)
490371-BB1 Power cord for use in Israel (3-pin, black, 1.83-m)
490371-D01 Power cord for use in Argentina (3-pin, black, 1.83-m)
490371-D61 Power cord for use in India (3-pin, black, 1.83-m)
597587-001 HP 2.4-GHz wireless optical mouse
599516-001 RTC battery
612599-001 HP lc2000 HSPA Mobile Broadband Module
612600-001 HP lc2010 HSPA Mobile Broadband Module
621565-001 2-GB memory module (PC3, 10600, 1333-MHz)
624502-001 40-W HP Smart AC adapter (RC/V 2-wire)
628344-001 HP mini sleeve in luminous rose finish
628346-001 HP mini sleeve in ocean drive finish
628348-001 HP mini sleeve in crimson red finish
630703-001 Ralink 5390GN 802.11b/g/n 1×1 WiFi Adapter
631188-001 HP mini sleeve in charcoal finish
631956-001 Intel Centrino Advanced-N 6230 WLAN module
632155-001 HP hs2340 HSPA+ Mobile Broadband Module
30 Chapter 3 Illustrated parts catalog
Spare part number Description
634932-001 500-GB, 5400-rpm, 7.0-mm hard drive (does not include hard drive bracket, hard drive connector
cable, hard drive rubber isolators, or screws)
NOTE: The hard drive bracket, hard drive connector cable, hard drive rubber isolators, and
screws are included in the Hard Drive Hardware Kit, spare part number 664913-001.
645191-001 250-GB, 5400-rpm, 7.0-mm hard drive (does not include hard drive bracket, hard drive connector
cable, hard drive rubber isolators, or screws)
NOTE: The hard drive bracket, hard drive connector cable, hard drive rubber isolators, and
screws are included in the Hard Drive Hardware Kit, spare part number 664913-001.
645193-001 320-GB, 5400-rpm, 7.0-mm hard drive (does not include hard drive bracket, hard drive connector
cable, hard drive rubber isolators, or screws)
NOTE: The hard drive bracket, hard drive connector cable, hard drive rubber isolators, and
screws are included in the Hard Drive Hardware Kit, spare part number 664913-001.
646755-001 3-cell, 28-Wh, 2.55-Ah, Li-ion battery
646757-001 6-cell, 55-Wh, 2.55-Ah, Li-ion battery
650710-001 Base enclosure for use only with Beats Edition computer models
650711-001 Display hinges (includes left and right display hinges)
650712-001 10.1-in, FlushGlass, HD display assembly in charcoal finish for use only on HP Mini 210
computer models with WWAN capability (includes display panel cable, webcamera/microphone
module, WLAN antenna cables and transceivers, and WWAN antenna cables and transceivers)
650719-001 10.1-in, WSVGA, HD display assembly in charcoal finish for use only on HP Mini 210
computer models with WWAN capabilty (includes display panel cable, webcamera/microphone
module, WLAN antenna cables and transceivers, and WWAN antenna cables and transceivers)
650727-001 Service cover in charcoal finish
650728-001 Service cover in ocean drive finish
650731-001 Service cover in luminous rose finish
650732-001 Service cover in crimson red finish
650734-001 Rubber Kit (includes 2 base enclosure rubber feet)
650735-001 Screw Kit
650736-001 Speakers (includes left and right speakers and cables)
650747-001 Top cover in charcoal finish for use only on HP Mini 210 computer models (includes TouchPad
board and bracket)
650748-001 Top cover in ocean drive finish for use only on HP Mini 210 computer models (includes TouchPad
board and bracket)
650751-001 Top cover in luminous rose finish for use only on HP Mini 210 computer models (includes TouchPad
board and bracket)
650752-001 Top cover in crimson red finish for use only on HP Mini 210 computer models (includes TouchPad
board and bracket)
651897-001 Fan
Sequential part number listing
31
Spare part number Description
651898-001 Heat sink (includes replacement thermal material)
652308-001 Corner covers (includes left and right corner covers)
654203-001 Service cover in sweet purple finish
654204-001 Top cover in sweet purple finish for use only on HP Mini 210 computer models (includes TouchPad
board and bracket)
655795-001 Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter
656095-001 Power connector cable
657325-001 Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo Adapter
658498-001 Antenna Kit (includes WLAN antenna cables and transceivers and WWAN antenna cables
and transceivers)
658499-001 Display enclosure in black finish
658500-001 Display enclosure in Sonora red finish
658502-001 Display enclosure in Pacific blue finish
658503-001 Display bezel for use only on HP Mini 110 computer models
658504-001 Display bezel for use only on Compaq Mini CQ10 computer models
658505-001 Display panel cable (includes display panel cable and webcamera/microphone module cable)
658507-001 10.1-in, BrightView, WSVGA display assembly in black finish for use only on HP Mini 110
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
658508-001 10.1-in, BrightView, WSVGA display assembly in Sonora Red finish for use only on HP Mini 110
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
658510-001 10.1-in, BrightView, WSVGA display assembly in Pacific Blue finish for use only on HP Mini 110
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
658511-001 10.1-in, WSVGA, display panel
658513-001 Top cover in Sonora Red finish for use only on HP Mini 110 computer models (includes TouchPad
board and bracket)
658515-001 Top cover in Pacific Blue finish for use only on HP Mini 110 computer models (includes TouchPad
board and bracket)
658516-001 Webcamera/microphone module (includes double-sided tape)
658517-001 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in the United States (includes keyboard cable)
658517-031 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in the United Kingdom and Singapore (includes keyboard cable)
658517-041 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Germany (includes keyboard cable)
32 Chapter 3 Illustrated parts catalog
Spare part number Description
658517-051 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in France (includes keyboard cable)
658517-061 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Italy (includes keyboard cable)
658517-071 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Spain (includes keyboard cable)
658517-121 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Canada (includes keyboard cable)
658517-131 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Portugal (includes keyboard cable)
658517-141 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Turkey (includes keyboard cable)
658517-161 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Latin America (includes keyboard cable)
658517-171 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Saudi Arabia (includes keyboard cable)
658517-211 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
use in Hungary (includes keyboard cable)
658517-251 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Russia (includes keyboard cable)
658517-261 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Bulgaria (includes keyboard cable)
658517-281 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Thailand (includes keyboard cable)
658517-291 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Japan (includes keyboard cable)
658517-A41 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Belgium (includes keyboard cable)
658517-AB1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Taiwan (includes keyboard cable)
658517-AD1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in South Korea (includes keyboard cable)
658517-B31 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in the Netherlands (includes keyboard cable)
658517-BA1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Slovenia (includes keyboard cable)
658517-BB1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Israel (includes keyboard cable)
658517-BG1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Switzerland (includes keyboard cable)
Sequential part number listing
33
Spare part number Description
658517-D61 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in India (includes keyboard cable)
658517-DH1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Denmark, Finland, and Norway (includes keyboard cable)
658517-DJ1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in Greece (includes keyboard cable)
658517-FL1 Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
in the Czech Republic and Slovakia (includes keyboard cable)
658518-001 Display enclosure for use only on Compaq Mini CQ10 computer models
659940-001 External USB DVD±RW DL SuperMulti Drive
663675-001 Base enclosure for use only with non-Beats Edition computer models
663676-001 Service door for use only on Compaq Mini CQ10 computer models
663677-001 Top cover in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models
(includes TouchPad board and bracket)
664894-001 10.1-in, BrightView, WSVGA display assembly for use only on Compaq Mini CQ10
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
664913-001 Hard Drive Hardware Kit (includes hard drive bracket, hard drive connector cable, hard drive
rubber isolators, and screws)
665962-001 Keyboard in charcoal finish for use only on HP Mini 210 computer models in the United States
(includes keyboard cable)
665962-031 Keyboard in charcoal finish for use only on HP Mini 210 computer models in the United Kingdom
and Singapore (includes keyboard cable)
665962-041 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Germany (includes
keyboard cable)
665962-051 Keyboard in charcoal finish for use only on HP Mini 210 computer models in France (includes
keyboard cable)
665962-061 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Italy (includes
keyboard cable)
665962-071 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Spain (includes
keyboard cable)
665962-121 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Canada (includes
keyboard cable)
665962-131 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Portugal (includes
keyboard cable)
665962-141 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Turkey (includes
keyboard cable)
665962-161 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Latin America
(includes keyboard cable)
665962-171 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Saudi Arabia
(includes keyboard cable)
34 Chapter 3 Illustrated parts catalog
Spare part number Description
665962-211 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Hungary (includes
keyboard cable)
665962-251 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Russia (includes
keyboard cable)
665962-261 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Bulgaria (includes
keyboard cable)
665962-281 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Thailand (includes
keyboard cable)
665962-291 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Japan (includes
keyboard cable)
665962-A41 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Belgium (includes
keyboard cable)
665962-AB1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Taiwan (includes
keyboard cable)
665962-AD1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in South Korea (includes
keyboard cable)
665962-B31 Keyboard in charcoal finish for use only on HP Mini 210 computer models in the Netherlands
(includes keyboard cable)
665962-BA1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Slovenia (includes
keyboard cable)
665962-BB1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Israel (includes
keyboard cable)
665962-BG1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Switzerland (includes
keyboard cable)
665962-D61 Keyboard in charcoal finish for use only on HP Mini 210 computer models in India (includes
keyboard cable)
665962-DH1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Denmark, Finland,
and Norway (includes keyboard cable)
665962-DJ1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in Greece (includes
keyboard cable)
665962-FL1 Keyboard in charcoal finish for use only on HP Mini 210 computer models in the Czech Republic
and Slovakia (includes keyboard cable)
665963-001 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in the United States
(includes keyboard cable)
665963-031 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in the United
Kingdom and Singapore (includes keyboard cable)
665963-041 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Germany (includes
keyboard cable)
665963-051 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in France (includes
keyboard cable)
Sequential part number listing
35
Spare part number Description
665963-061 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Italy (includes
keyboard cable)
665963-071 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Spain (includes
keyboard cable)
665963-121 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Canada (includes
keyboard cable)
665963-131 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Portugal (includes
keyboard cable)
665963-141 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Turkey (includes
keyboard cable)
665963-161 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Latin America
(includes keyboard cable)
665963-171 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Saudi Arabia
(includes keyboard cable)
665963-211 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Hungary (includes
keyboard cable)
665963-251 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Russia (includes
keyboard cable)
665963-261 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Bulgaria (includes
keyboard cable)
665963-281 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Thailand (includes
keyboard cable)
665963-291 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Japan (includes
keyboard cable)
665963-A41 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Belgium (includes
keyboard cable)
665963-AB1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Taiwan (includes
keyboard cable)
665963-AD1 Keyboard in ocean drive for use only on HP Mini 210 computer models in South Korea (includes
keyboard cable)
665963-B31 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in the Netherlands
(includes keyboard cable)
665963-BA1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Slovenia (includes
keyboard cable)
665963-BB1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Israel (includes
keyboard cable)
665963-BG1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Switzerland
(includes keyboard cable)
665963-D61 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in India (includes
keyboard cable)
36 Chapter 3 Illustrated parts catalog
Spare part number Description
665963-DH1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Denmark, Finland,
and Norway (includes keyboard cable)
665963-DJ1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in Greece (includes
keyboard cable)
665963-FL1 Keyboard in ocean drive finish for use only on HP Mini 210 computer models in the Czech
Republic and Slovakia (includes keyboard cable)
665964-001 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in the United States
(includes keyboard cable)
665964-031 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in the United
Kingdom and Singapore (includes keyboard cable)
665964-041 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Germany
(includes keyboard cable)
665964-051 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in France (includes
keyboard cable)
665964-061 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Italy (includes
keyboard cable)
665964-071 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Spain (includes
keyboard cable)
665964-121 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Canada
(includes keyboard cable)
665964-131 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Portugal
(includes keyboard cable)
665964-141 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Turkey (includes
keyboard cable)
665964-161 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Latin America
(includes keyboard cable)
665964-171 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Saudi Arabia
(includes keyboard cable)
665964-211 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Hungary
(includes keyboard cable)
665964-251 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Russia (includes
keyboard cable)
665964-261 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Bulgaria
(includes keyboard cable)
665964-281 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Thailand
(includes keyboard cable)
665964-291 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Japan (includes
keyboard cable)
665964-A41 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Belgium (includes
keyboard cable)
Sequential part number listing
37
Spare part number Description
665964-AB1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Taiwan (includes
keyboard cable)
665964-AD1 Keyboard in luminous rose for use only on HP Mini 210 computer models in South Korea (includes
keyboard cable)
665964-B31 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in the Netherlands
(includes keyboard cable)
665964-BA1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Slovenia
(includes keyboard cable)
665964-BB1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Israel (includes
keyboard cable)
665964-BG1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Switzerland
(includes keyboard cable)
665964-D61 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in India (includes
keyboard cable)
665964-DH1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Denmark,
Finland, and Norway (includes keyboard cable)
665964-DJ1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in Greece (includes
keyboard cable)
665964-FL1 Keyboard in luminous rose finish for use only on HP Mini 210 computer models in the Czech
Republic and Slovakia (includes keyboard cable)
665965-001 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in the United States
(includes keyboard cable)
665965-031 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in the United
Kingdom and Singapore (includes keyboard cable)
665965-041 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Germany
(includes keyboard cable)
665965-051 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in France (includes
keyboard cable)
665965-061 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Italy (includes
keyboard cable)
665965-071 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Spain (includes
keyboard cable)
665965-121 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Canada (includes
keyboard cable)
665965-131 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Portugal (includes
keyboard cable)
665965-141 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Turkey (includes
keyboard cable)
665965-161 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Latin America
(includes keyboard cable)
38 Chapter 3 Illustrated parts catalog
Spare part number Description
665965-171 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Saudi Arabia
(includes keyboard cable)
665965-211 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Hungary (includes
keyboard cable)
665965-251 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Russia (includes
keyboard cable)
665965-261 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Bulgaria (includes
keyboard cable)
665965-281 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Thailand (includes
keyboard cable)
665965-291 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Japan (includes
keyboard cable)
665965-A41 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Belgium (includes
keyboard cable)
665965-AB1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Taiwan (includes
keyboard cable)
665965-AD1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in South Korea
(includes keyboard cable)
665965-B31 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in the Netherlands
(includes keyboard cable)
665965-BA1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Slovenia (includes
keyboard cable)
665965-BB1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Israel (includes
keyboard cable)
665965-BG1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Switzerland
(includes keyboard cable)
665965-D61 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in India (includes
keyboard cable)
665965-DH1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Denmark, Finland,
and Norway (includes keyboard cable)
665965-DJ1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in Greece (includes
keyboard cable)
665965-FL1 Keyboard in crimson rose finish for use only on HP Mini 210 computer models in the Czech
Republic and Slovakia (includes keyboard cable)
665966-001 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in the United States
(includes keyboard cable)
665966-031 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in the United
Kingdom and Singapore (includes keyboard cable)
665966-041 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Germany
(includes keyboard cable)
Sequential part number listing
39
Spare part number Description
665966-051 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in France (includes
keyboard cable)
665966-061 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Italy (includes
keyboard cable)
665966-071 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Spain (includes
keyboard cable)
665966-121 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Canada (includes
keyboard cable)
665966-131 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Portugal (includes
keyboard cable)
665966-141 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Turkey (includes
keyboard cable)
665966-161 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Latin America
(includes keyboard cable)
665966-171 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Saudi Arabia
(includes keyboard cable)
665966-211 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Hungary (includes
keyboard cable)
665966-251 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Russia (includes
keyboard cable)
665966-261 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Bulgaria (includes
keyboard cable)
665966-281 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Thailand (includes
keyboard cable)
665966-291 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Japan (includes
keyboard cable)
665966-A41 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Belgium (includes
keyboard cable)
665966-AB1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Taiwan (includes
keyboard cable)
665966-AD1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in South Korea
(includes keyboard cable)
665966-B31 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in the Netherlands
(includes keyboard cable)
665966-BA1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Slovenia (includes
keyboard cable)
665966-BB1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Israel (includes
keyboard cable)
665966-BG1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Switzerland
(includes keyboard cable)
40 Chapter 3 Illustrated parts catalog
Spare part number Description
665966-D61 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in India (includes
keyboard cable)
665966-DH1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Denmark,
Finland, and Norway (includes keyboard cable)
665966-DJ1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in Greece (includes
keyboard cable)
665966-FL1 Keyboard in sweet purple finish for use only on HP Mini 210 computer models in the Czech
Republic and Slovakia (includes keyboard cable)
667750-001 System board for use only with Beats Edition computer models equipped with an Intel Atom N2600
1.60-GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 3.5 W; includes
processor and replacement thermal material)
667751-001 System board for use only with Beats Edition computer models equipped with an Intel Atom N2600
1.60-GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 3.5 W; includes
processor and replacement thermal material)
667752-001 System board for use only with Beats Edition computer models equipped with an Intel Atom N2800
1.86-GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 6.5 W; includes
processor and replacement thermal material)
667753-001 System board for use only with Beats Edition computer models equipped with an Intel Atom N2800
1.86-GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 6.5 W; includes
processor and replacement thermal material)
668156-001 10.1-in, FlushGlass, HD display assembly in charcoal finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668157-001 10.1-in, FlushGlass, HD display assembly in ocean drive finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668158-001 10.1-in, FlushGlass, HD display assembly in luminous rose finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668159-001 10.1-in, FlushGlass, HD display assembly in crimson red finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668160-001 10.1-in, FlushGlass, HD display assembly in sweet purple finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668161-001 10.1-in, WSVGA, HD display assembly in charcoal finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668162-001 10.1-in, WSVGA, HD display assembly in ocean drive finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668163-001 10.1-in, WSVGA, HD display assembly in luminous rose finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
Sequential part number listing
41
Spare part number Description
668164-001 10.1-in, WSVGA, HD display assembly in crimson red finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668165-001 10.1-in, WSVGA, HD display assembly in sweet purple finish for use only on HP Mini 210
computer models (includes display panel cable, webcamera/microphone module, and WLAN
antenna cables and transceivers)
668166-001 10.1-in, BrightView, WSVGA display assembly in black finish for use only on HP Mini 110
computer models with WWAN capability (includes display panel cable, webcamera/microphone
module, WLAN antenna cables and transceivers, and WWAN antenna cables and transceivers)
676909-001 System board for use only with non-Beats Edition computer models equipped with an Intel Atom
N2600 1.60-GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 3.5 W;
includes processor and replacement thermal material)
676910-001 System board for use only with non-Beats Edition computer models equipped with an Intel Atom
N2600 1.60-GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 3.5 W;
includes processor and replacement thermal material)
676911-001 System board for use only with non-Beats Edition computer models equipped with an Intel Atom
N2800 1.86-GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 6.5 W;
includes processor and replacement thermal material)
676912-001 System board for use only with non-Beats Edition computer models equipped with an Intel Atom
N2800 1.86-GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 6.5 W;
includes processor and replacement thermal material)
42 Chapter 3 Illustrated parts catalog
4 Removal and replacement
procedures
Preliminary replacement requirements
Tools required
You will need the following tools to complete the removal and replacement procedures:
●
Flat-bladed screwdriver
●
Magnetic screwdriver
●
Phillips P0 and P1 screwdrivers
Service considerations
The following sections include some of the considerations that you must keep in mind during
disassembly and assembly procedures.
NOTE: As you remove each subassembly from the computer, place the subassembly (and all
accompanying screws) away from the work area to prevent damage.
Plastic parts
CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts. Use
care when handling the plastic parts. Apply pressure only at the points designated in the
maintenance instructions.
Cables and connectors
CAUTION: When servicing the computer, be sure that cables are placed in their proper locations
during the reassembly process. Improper cable placement can damage the computer.
Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat
or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In
all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that
they cannot be caught or snagged by parts being removed or replaced. Handle flex cables with
extreme care; these cables tear easily.
Preliminary replacement requirements
43
Drive handling
CAUTION: Drives are fragile components that must be handled with care. To prevent damage to
the computer, damage to a drive, or loss of information, observe these precautions:
Before removing or inserting a hard drive, shut down the computer. If you are unsure whether
the computer is off or in Hibernation, turn the computer on, and then shut it down through the
operating system.
Before handling a drive, be sure that you are discharged of static electricity. While handling a drive,
avoid touching the connector.
Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and
be sure that the optical drive tray is closed.
Handle drives on surfaces covered with at least one inch of shock-proof foam.
Avoid dropping drives from any height onto any surface.
After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.
Avoid exposing an internal hard drive to products that have magnetic fields, such as monitors
or speakers.
Avoid exposing a drive to temperature extremes or liquids.
If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective
packaging and label the package “FRAGILE.”
Grounding guidelines
Electrostatic discharge damage
Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure
determine the degree of sensitivity. Networks built into many integrated circuits provide some
protection, but in many cases, ESD contains enough power to alter device parameters or melt
silicon junctions.
A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.
An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a
normal cycle. Or the device may function normally for a while, then degrade in the internal layers,
reducing its life expectancy.
44 Chapter 4 Removal and replacement procedures
CAUTION: To prevent damage to the computer when you are removing or installing internal
components, observe these precautions:
Keep components in their electrostatic-safe containers until you are ready to install them.
Before touching an electronic component, discharge static electricity by using the guidelines described
in this section.
Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.
If you remove a component, place it in an electrostatic-safe container.
The following table shows how humidity affects the electrostatic voltage levels generated by
different activities.
CAUTION: A product can be degraded by as little as 700 V.
Typical electrostatic voltage levels
Relative humidity
Event 10% 40% 55%
Walking across carpet 35,000 V 15,000 V 7,500 V
Walking across vinyl floor 12,000 V 5,000 V 3,000 V
Motions of bench worker 6,000 V 800 V 400 V
Removing DIPS from plastic tube 2,000 V 700 V 400 V
Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V
Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V
Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V
Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V
Preliminary replacement requirements
45
Packaging and transporting guidelines
Follow these grounding guidelines when packaging and transporting equipment:
●
To avoid hand contact, transport products in static-safe tubes, bags, or boxes.
●
Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.
●
Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
●
Place items on a grounded surface before removing items from their containers.
●
Always be properly grounded when touching a component or assembly.
●
Store reusable ESD-sensitive parts from assemblies in protective packaging or
nonconductive foam.
●
Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that
mechanized equipment used for moving materials is wired to ground and that proper materials
are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate
electric charges.
Workstation guidelines
Follow these grounding workstation guidelines:
●
Cover the workstation with approved static-shielding material.
●
Use a wrist strap connected to a properly grounded work surface and use properly grounded tools
and equipment.
●
Use conductive field service tools, such as cutters, screwdrivers, and vacuums.
●
When fixtures must directly contact dissipative surfaces, use fixtures made only of staticsafe materials.
●
Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids
and Styrofoam.
●
Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle
these items only at static-free workstations.
●
Avoid contact with pins, leads, or circuitry.
●
Turn off power and input signals before inserting or removing connectors or test equipment.
46 Chapter 4 Removal and replacement procedures
Equipment guidelines
Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.
●
When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps
with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground,
wear a strap snugly against the skin at all times. On grounded mats with banana-plug connectors,
use alligator clips to connect a wrist strap.
●
When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps)
can be used at standing workstations and are compatible with most types of shoes or boots. On
conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one
megohm resistance between the operator and ground. To be effective, the conductive must be
worn in contact with the skin.
The following grounding equipment is recommended to prevent electrostatic damage:
●
Antistatic tape
●
Antistatic smocks, aprons, and sleeve protectors
●
Conductive bins and other assembly or soldering aids
●
Nonconductive foam
●
Conductive tabletop workstations with ground cords of one megohm resistance
●
Static-dissipative tables or floor mats with hard ties to the ground
●
Field service kits
●
Static awareness labels
●
Material-handling packages
●
Nonconductive plastic bags, tubes, or boxes
●
Metal tote boxes
●
Electrostatic voltage levels and protective materials
The following table lists the shielding protection provided by antistatic bags and floor mats.
Material Use Voltage protection level
Antistatic plastics Bags 1,500 V
Carbon-loaded plastic Floor mats 7,500 V
Metallized laminate Floor mats 5,000 V
Preliminary replacement requirements
47
Component replacement procedures
This chapter provides removal and replacement procedures.
There are as many as 41 screws that must be removed, replaced, or loosened when servicing
the computer. Make special note of each screw size and location during removal and replacement.
Service tag
When ordering parts or requesting information, provide the computer serial number and model number
provided on the service tag. It is necessary to remove the battery to obtain these numbers. See
on page 50 for battery removal instructions.
Battery
Item Component Description
(1) Product name This is the product name affixed to the front of
(2) Serial number (s/n) This is an alphanumeric identifier that is unique to
(3) Part number/Product number (p/n) This number provides specific information about the
48 Chapter 4 Removal and replacement procedures
the computer.
each product.
product’s hardware components. The part number helps
a service technician determine what components and
parts are needed.
Item Component Description
(4) Warranty period This number describes the duration of the warranty
(5) Model description This is the alphanumeric identifier used to locate
Computer feet
The computer feet are adhesive-backed rubber pads. There are 2 rubber feet that attach to the corner
covers in the locations illustrated below. These rubber feet are available in the Rubber Kit, spare part
number 650734-001.
period for the computer.
documents, drivers, and support for the computer.
Component replacement procedures
49
Battery
Description Spare part number
6-cell, 55-Wh, 2.55-Ah, Li-ion battery 646757-001
3-cell, 28-Wh, 2.55-Ah, Li-ion battery 646755-001
Before disassembling the computer, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
Remove the battery:
1. Slide the battery/service cover release latch (1) to release the battery.
2. Pivot the front edge of the battery (2) up and back.
3. Remove the battery (3) from the computer.
To insert the battery:
1. Align the tabs on the rear edge of the battery with the notches on the rear edge of the battery bay.
2. Pivot the front edge of the battery down into the battery bay until it is seated. (The battery release
latch will automatically lock into place.)
50 Chapter 4 Removal and replacement procedures
SIM (select models only)
NOTE: The SIM is provided by the end-user as a security measure for the WWAN module. The SIM
should be removed, placed into a static-dissipative container, and then replaced when the computer
is reassembled.
Before removing the SIM, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Remove the SIM:
1. Press in on the SIM (1) to release it from the SIM slot.
2. Remove the SIM (2) from the SIM slot.
Battery on page 50).
Insert the SIM into the SIM slot, and gently push the SIM into the slot until it is firmly seated.
Component replacement procedures
51
WLAN module
Description Spare part number
Atheros 9485GN 802.11b/g/n 1×1 WiFi and 3012 Bluetooth 4.0 Combo Adapter 655795-001
Broadcom 4313GN 802.11b/g/n 1×1 WiFi and 20702 Bluetooth 4.0 Combo Adapter 657325-001
Intel Centrino Advanced-N 6230 WLAN module 631956-001
Ralink 5390GN 802.11b/g/n 1×1 WiFi Adapter 630703-001
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless
module authorized for use in the computer by the governmental agency that regulates wireless devices
in your country or region. If you replace the module and then receive a warning message, remove the
module to restore device functionality, and then contact technical support.
Before removing the WLAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 50).
Remove the WLAN module:
1. Slide the battery/service cover latch (1) to release the service cover.
2. Slide the service cover (2) toward the front of the computer, and then remove the
service cover (3).
NOTE: It is normal for the service cover to flex slightly when it is released. You may also hear
some popping noises as the service cover tabs disengage from the base enclosure slots.
52 Chapter 4 Removal and replacement procedures
The service cover is available using the following spare part numbers:
●
663676-001—In black finish for use only on Compaq Mini CQ10 and HP Mini 110
computer models
●
650727-001—In charcoal finish for use only on HP Mini 210 computer models
●
650732-001—In crimson red finish for use only on HP Mini 210 computer models
●
650731-001—In luminous rose for use only on HP Mini 210 computer models
●
650728-001—In ocean drive for use only on HP Mini 210 computer models
●
654203-001—In sweet purple finish for use only on HP Mini 210 computer models
3. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The #1 WLAN antenna cable is connected to the WLAN module “Main” terminal.
The #2 WLAN antenna cable is connected to the WLAN module “Aux” terminal.
4. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the system board.
(The WLAN module tilts up.)
Component replacement procedures
53
5.
Remove the WLAN module by pulling the module away from the slot at an angle (3).
NOTE: The WLAN module is designed with a notch (4) to prevent incorrect installation into the
WLAN module socket.
NOTE: If the WLAN antennas are not connected to the terminals on the WLAN module, the protective
sleeves must be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
54 Chapter 4 Removal and replacement procedures
WWAN module
Description Spare part number
HP hs2340 HSPA+ Mobile Broadband Module 632155-001
HP lc2000 HSPA Mobile Broadband Module 612599-001
HP lc2010 HSPA Mobile Broadband Module 612600-001
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless
module authorized for use in the computer by the governmental agency that regulates wireless devices
in your country or region. If you replace the module and then receive a warning message, remove the
module to restore device functionality, and then contact technical support.
Before removing the WWAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
5. Remove the service cover (see
Battery on page 50).
WLAN module on page 52).
Remove the WWAN module:
1. Disconnect the WWAN antenna cables (1) from the terminals on the WWAN module.
NOTE: The #1 WWAN antenna cable is connected to the WWAN module “Main” terminal.
The #2 WWAN antenna cable is connected to the WWAN module “Aux” terminal.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the WWAN module to the system board.
(The WWAN module tilts up.)
Component replacement procedures
55
3.
Remove the WWAN module by pulling the module away from the slot at an angle (3).
NOTE: The WWAN module is designed with a notch (4) to prevent incorrect installation into
the WWAN module socket.
NOTE: If the WWAN antennas are not connected to the terminals on the WWAN module, the
protective sleeves must be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WWAN module.
56 Chapter 4 Removal and replacement procedures
Memory module
Description Spare part number
2-GB (PC3, 10600, 1333-MHz) 621565-001
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the service cover (see
Battery on page 50).
WLAN module on page 52).
Remove the memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The memory module tilts up.)
2. Remove the memory module (2) by pulling it away from the slot at an angle.
Reverse this procedure to install the memory module.
Component replacement procedures
57
RTC battery
Description Spare part number
RTC battery 621565-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the service cover (see
Battery on page 50).
WLAN module on page 52).
Remove the RTC battery:
1. Insert a non-conductive, flat-tip, tool (1) into the notch (2) on the side of the RTC battery socket.
2. Remove the RTC battery (3) from the socket on the system board.
Reverse this procedure to install the RTC battery. When installing the RTC battery, be sure the “+” sign
faces up.
58 Chapter 4 Removal and replacement procedures
Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket, connector cable, rubber
isolators, or screws. These components are included in the Hard Drive Hardware Kit, spare part
number 664913-001.
Description Spare part number
500-GB, 5400-rpm 634932-001
320-GB, 5400-rpm 645193-001
250-GB, 5400-rpm 645191-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the service cover (see
Battery on page 50).
WLAN module on page 52).
Remove the hard drive:
1. Disconnect the hard drive connector cable (1) from the system board.
2. Remove the Phillips PM 2.0×5.0 screw (2) that secures the hard drive to the computer.
3. Use the pull tab (3) to lift the left side of the hard drive until it rests at an angle.
Component replacement procedures
59
4.
Remove the hard drive (4) by sliding it up and to the left at an angle.
5. If it is necessary to replace the hard drive connector cable (1), the hard drive screws (2), the hard
drive bracket (3), or the rubber isolators (4), remove and replace the components.
Reverse this procedure to reassemble and install the hard drive.
60 Chapter 4 Removal and replacement procedures
Keyboard
NOTE: The keyboard spare part kit includes a keyboard cable.
Description Spare part number Description Spare part number
For use in Belgium 658517-A41 For use in the Netherlands 658517-B31
For use in Bulgaria 658517-261 For use in Portugal 658517-131
For use in Canada 658517-121 For use in Russia 658517-251
Keyboard in black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models:
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 658517-051 For use in South Korea 658517-AD1
For use in Germany 658517-041 For use in Spain 658517-071
For use in Greece 658517-DJ1 For use in Switzerland 658517-BG1
For use in Hungary 658517-211 For use in Taiwan 658517-AB1
For use in Israel 658517-BB1 For use in Thailand 658517-281
For use in Italy 658517-061 For use in Turkey 658517-141
For use in Japan 658517-291 For use in the United Kingdom
For use in Latin America 658517-161 For use in the United States 658517-001
Keyboard in charcoal finish for use only on HP Mini 210
computer models:
For use in Belgium 665962-A41 For use in the Netherlands 665962-B31
For use in Bulgaria 665962-261 For use in Portugal 665962-131
658517-FL1 For use in Saudi Arabia 658517-171
658517-DH1 For use in Slovenia 658517-BA1
658517-031
and Singapore
For use in Latin America 665962-161
For use in Canada 665962-121 For use in Russia 665962-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 665962-051 For use in South Korea 665962-AD1
For use in Germany 665962-041 For use in Spain 665962-071
For use in Greece 665962-DJ1 For use in Switzerland 665962-BG1
For use in Hungary 665962-211 For use in Taiwan 665962-AB1
For use in India 665962-D61 For use in Thailand 665962-281
For use in Israel 665962-BB1 For use in Turkey 665962-141
665962-FL1 For use in Saudi Arabia 665962-171
665962-DH1 For use in Slovenia 665962-BA1
Component replacement procedures
61
Description Spare part number Description Spare part number
For use in Italy 665962-061 For use in the United Kingdom
and Singapore
For use in Japan 665962-291 For use in the United States 665962-001
Keyboard in crimson red finish for use only on HP Mini 210
computer models:
For use in Belgium 665965-A41 For use in the Netherlands 665965-B31
For use in Bulgaria 665965-261 For use in Portugal 665965-131
For use in Canada 665965-121 For use in Russia 665965-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 665965-051 For use in South Korea 665965-AD1
For use in Germany 665965-041 For use in Spain 665965-071
For use in Greece 665965-DJ1 For use in Switzerland 665965-BG1
For use in Hungary 665965-211 For use in Taiwan 665965-AB1
For use in India 665965-D61 For use in Thailand 665965-281
665965-FL1 For use in Saudi Arabia 665965-171
665965-DH1 For use in Slovenia 665965-BA1
For use in Latin America 665965-161
665962-031
For use in Israel 665965-BB1 For use in Turkey 665965-141
For use in Italy 665965-061 For use in the United Kingdom
and Singapore
For use in Japan 665965-291 For use in the United States 665965-001
Keyboard in luminous rose finish for use only on HP Mini 210
computer models:
For use in Belgium 665964-A41 For use in the Netherlands 665964-B31
For use in Bulgaria 665964-261 For use in Portugal 665964-131
For use in Canada 665964-121 For use in Russia 665964-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 665964-051 For use in South Korea 665964-AD1
For use in Germany 665964-041 For use in Spain 665964-071
For use in Greece 665964-DJ1 For use in Switzerland 665964-BG1
For use in Hungary 665964-211 For use in Taiwan 665964-AB1
665964-FL1 For use in Saudi Arabia 665964-171
665964-DH1 For use in Slovenia 665964-BA1
For use in Latin America 665964-161
665965-031
For use in India 665964-D61 For use in Thailand 665964-281
For use in Israel 665964-BB1 For use in Turkey 665964-141
62 Chapter 4 Removal and replacement procedures
Description Spare part number Description Spare part number
For use in Italy 665964-061 For use in the United Kingdom
and Singapore
For use in Japan 665964-291 For use in the United States 665964-001
Keyboard in ocean drive finish for use only on HP Mini 210
computer models:
For use in Belgium 665963-A41 For use in the Netherlands 665963-161
For use in Bulgaria 665963-261 For use in Portugal 665963-B31
For use in Canada 665963-121 For use in Russia 665963-131
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 665963-051 For use in South Korea 665963-BA1
For use in Germany 665963-041 For use in Spain 665963-AD1
For use in Greece 665963-DJ1 For use in Switzerland 665963-071
For use in Hungary 665963-211 For use in Taiwan 665963-BG1
For use in India 665963-D61 For use in Thailand 665963-AB1
665963-FL1 For use in Saudi Arabia 665963-251
665963-DH1 For use in Slovenia 665963-171
For use in Latin America 665963-291
665964-031
For use in Israel 665963-BB1 For use in Turkey 665963-281
For use in Italy 665963-061 For use in the United Kingdom
and Singapore
For use in Japan 665963-291 For use in the United States 665963-031
Keyboard in sweet purple finish for use only on HP Mini 210
computer models:
For use in Belgium 665966-A41 For use in the Netherlands 665966-B31
For use in Bulgaria 665966-261 For use in Portugal 665966-131
For use in Canada 665966-121 For use in Russia 665966-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 665966-051 For use in South Korea 665966-AD1
For use in Germany 665966-041 For use in Spain 665966-071
For use in Greece 665966-DJ1 For use in Switzerland 665966-BG1
For use in Hungary 665966-211 For use in Taiwan 665966-AB1
665966-FL1 For use in Saudi Arabia 665966-171
665966-DH1 For use in Slovenia 665966-BA1
For use in Latin America 665966-161
665963-141
For use in India 665966-D61 For use in Thailand 665966-281
For use in Israel 665966-BB1 For use in Turkey 665966-141
Component replacement procedures
63
Description Spare part number Description Spare part number
For use in Italy 665966-061 For use in the United Kingdom
and Singapore
For use in Japan 665966-291 For use in the United States 665966-001
665966-031
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the service cover (see
Battery on page 50).
WLAN module on page 52).
Remove the keyboard:
1. Remove the two Phillips PM2.0×5.0 screws that secure the keyboard to the computer.
2. Rest and secure the computer on its left side.
3. Partially open the computer.
64 Chapter 4 Removal and replacement procedures
4.
Insert a screw driver or similar thin tool into the keyboard release area, and then press on the
back of the keyboard until the keyboard disengages from the computer.
5. Turn the computer right-side up with the front toward you.
6. Open the computer as far as it will open.
Component replacement procedures
65
7.
Lift the rear edge of the keyboard (1), and then swing the keyboard (2) up and forward until it
rests upside down on the palm rest.
8. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and
then disconnect the keyboard cable (2) from the system board.
9.
Remove the keyboard (3).
Reverse this procedure to install the keyboard.
66 Chapter 4 Removal and replacement procedures
Top cover
NOTE: The top cover spare part kit includes the TouchPad and TouchPad cable.
Description Spare part number
In black finish for use only on Compaq Mini CQ10 and HP Mini 110 computer models 663677-001
In charcoal finish for use only on HP Mini 210 computer models 650747-001
In crimson red finish for use only on HP Mini 210 computer models 650752-001
In luminous rose finish for use only on HP Mini 210 computer models 650751-001
In ocean drive finish for use only on HP Mini 210 computer models 650748-001
In Pacific blue finish for use only on HP Mini 110 computer models 658515-001
In Sonora red finish for use only on HP Mini 110 computer models 658513-001
In sweet purple finish for use only on HP Mini 210 computer models 654204-001
Before removing the top cover, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
5.
Remove the service cover (see
6. Remove the keyboard (see
Battery on page 50).
WLAN module on page 52).
Keyboard on page 61).
NOTE: When replacing the top cover, be sure to remove the speakers from the defective top cover
and install them on the replacement top cover. See
Speakers on page 73 for speaker removal and
replacement instructions.
Remove the top cover:
1. Close the computer.
2. Turn the computer upside down, with the front toward you.
Component replacement procedures
67
3.
Release the ZIF connector (1) to which the TouchPad cable is connected, and then disconnect the
TouchPad cable (2) from the system board.
NOTE: Additional slight force may be needed when releasing the TouchPad cable from the
top cover. Double-sided adhesive is used to attach the TouchPad cable to the top cover surface.
4. Remove the two rubber feet (1) on the rear corners of the base enclosure. (The rubber feet are
available in the Rubber Kit, spare part number 650734-001.)
68 Chapter 4 Removal and replacement procedures
5.
Remove the seven Phillips PM2.0×5.0 screws (2) that secure the top cover and the corner covers
to the base enclosure.
NOTE: The rubber feet are notched differently. The rubber foot (1) that fits on the left side has a
rectangular alignment notch. The rubber foot (2) that fits on the right side has an “L”-shaped
alignment notch. When installing the rubber feet, align them according to the side of the computer
on which they should be installed.
Component replacement procedures
69
6.
Remove the corner covers.
7. Release the wireless antenna cables from the clips (1) and routing channel built into the
base enclosure.
8. Disconnect the display panel cable (2) from the system board.
70 Chapter 4 Removal and replacement procedures
9.
Remove the two Phillips PM2.0×5.0 screws that secure the top cover to the base enclosure.
10. Turn the computer right side up, with the front toward you.
11.
Open the computer as far as it will open.
12. Release the ZIF connector (1) to which the power button board cable is connected, and then
disconnect the power button board cable (2) from the system board.
13. Disconnect the speaker cable (3) from the system board.
Component replacement procedures
71
14.
Remove the five Phillips PM2.0×5.0 screws that secure the top cover to the base enclosure.
15. Lift the front edge of the top cover (1) until the left and right sides disengage from the
base enclosure.
16. Remove the top cover (2).
Reverse this procedure to install the top cover.
72 Chapter 4 Removal and replacement procedures
Speakers
Description Spare part number
Speakers (include cable) 650736-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
the computer on, and then shut it down through the operating system.
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Service cover (see
●
Keyboard (see
●
Top cover (see
Battery on page 50), and then remove the following components:
WLAN module on page 52)
Keyboard on page 61)
Top cover on page 67)
Remove the speakers:
1. Release the speaker cable from the clip (1) built into the top cover.
2. Remove the speakers (2) from the top cover.
Reverse this procedure to install the speakers.
Component replacement procedures
73
System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part number
For use only with Beats Edition computer models equipped with an Intel Atom N2800 1.86-GHz
processor and WWAN capability (1.0-MB L2 cache, dual core, 6.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom N2800 1.86GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 6.5 W)
For use only with Beats Edition computer models equipped with an Intel Atom N2800 1.86-GHz
processor, but not WWAN capability (1.0-MB L2 cache, dual core, 6.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom N2800 1.86GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 6.5 W)
For use only with Beats Edition computer models equipped with an Intel Atom N2600 1.60-GHz
processor and WWAN capability (1.0-MB L2 cache, dual core, 3.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom N2600 1.60GHz processor and WWAN capability (1.0-MB L2 cache, dual core, 3.5 W)
For use only with Beats Edition computer models equipped with an Intel Atom N2600 1.60-GHz
processor, but not WWAN capability (1.0-MB L2 cache, dual core, 3.5 W)
For use only with non-Beats Edition computer models equipped with an Intel Atom N2600 1.60GHz processor, but not WWAN capability (1.0-MB L2 cache, dual core, 3.5 W)
667753-001
676912-001
667752-001
676911-001
667751-001
676910-001
667750-001
676909-001
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Service cover (see
●
Hard drive (see
●
Keyboard (see
●
Top cover (see
Battery on page 50), and then remove the following components:
WLAN module on page 52)
Hard drive on page 59)
Keyboard on page 61)
Top cover on page 67)
When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:
●
SIM (see
●
WLAN module (see
SIM (select models only) on page 51)
WLAN module on page 52)
74 Chapter 4 Removal and replacement procedures
●
WWAN module (see
WWAN module on page 55)
●
RTC battery (see
●
Memory module (see
●
Power connector cable (see
●
Fan (see
●
Heat sink (see
Fan on page 77)
RTC battery on page 58)
Memory module on page 57)
System board on page 74)
Heat sink on page 79)
Remove the system board:
1. Remove the two Phillips PM2.0×5.7 screws that secure the system board to the base enclosure.
2. Release the power connector (1) from the clip built into the base enclosure.
3. Flex the right side of the base enclosure (2) until the jacks and ports on the right side of the
system board are clear of the openings in the base enclosure.
4. Lift the right side of the system board (3) until it rests at an angle.
Component replacement procedures
75
5.
Remove the system board (4) by sliding it up and to the right at an angle.
NOTE: If it is necessary to replace the power connector cable, turn the system board upside
down with the rear toward you, and then disconnect the power connector cable from the
system board. The power connector cable is available using spare part number 656095-001.
Reverse this procedure to install the system board and the power connector cable.
76 Chapter 4 Removal and replacement procedures
Fan
Description Spare part number
Fan 651897-001
NOTE: To properly ventilate the computer, allow at least 7.6 cm (3 in) of clearance on the left side of
the computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature
sensor and is designed to turn on automatically when high temperature conditions exist. These
conditions are affected by high external temperatures, system power consumption, power
management/battery conservation configurations, battery fast charging, and software requirements.
Exhaust air is displaced through the ventilation grill located on the left side of the computer.
Before removing the fan, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Service cover (see
●
Keyboard (see
●
Top cover (see
●
System board (see
Battery on page 50), and then remove the following components:
WLAN module on page 52)
Keyboard on page 61)
Top cover on page 67)
System board on page 74)
Remove the fan:
1. Turn the system board upside down, with the rear toward you.
2.
Disconnect the fan cable (1) from the system board.
3.
Remove the Phillips PM2.0×4.6 screw (2) that secures the fan to the system board.
4.
Disengage the tab (3) on the fan from the slot on the system board.
Component replacement procedures
77
5.
Remove the fan (4).
78 Chapter 4 Removal and replacement procedures
Heat sink
Description Spare part number
Heat sink (includes replacement thermal material) 651898-001
Before removing the heat sink, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
the computer on, and then shut it down through the operating system.
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Service cover (see
●
Keyboard (see
●
Top cover (see
●
System board (see
●
Fan (see
Fan on page 77)
Battery on page 50), and then remove the following components:
WLAN module on page 52)
Keyboard on page 61)
Top cover on page 67)
System board on page 74)
Remove the heat sink:
1. Remove the two Phillips PM2.0×4.6 screws (1) that secure the heat sink to the system board.
Component replacement procedures
79
2.
Remove the heat sink (2).
NOTE: Due to the adhesive quality of the thermal material located between the heat sink and
system board components, it may be necessary to move the heat sink from side to side to
detach it.
The thermal material must be thoroughly cleaned from the surfaces of the heat sink and the
system board components each time the heat sink is removed. Replacement thermal material is included
with the heat sink and system board spare part kits.
NOTE: The following illustration shows the replacement thermal material locations. Thermal paste is
used on the processor (1) and the heat sink section (2) that services it.
Reverse this procedure to install the heat sink.
80 Chapter 4 Removal and replacement procedures
Display assembly
Description Spare part number
Display assembly 10.1-in (includes display panel cable, 2 WLAN antenna transceivers and cables, and webcamera/
microphone module and cable)
BrightView, WSVGA display assembly for use only on Compaq Mini CQ10 computer models 664894-001
BrightView, WSVGA display assembly in black finish for use only on HP Mini 110
computer models equipped with WWAN capability (includes WWAN antenna cables
and transceivers)
BrightView, WSVGA display assembly in black finish for use only on HP Mini 110
computer models
BrightView, WSVGA display assembly in Pacific blue finish for use only on HP Mini 110
computer models
BrightView, WSVGA display assembly in Sonora red finish for use only on HP Mini 110
computer models
FlushGlass, HD display assembly in charcoal finish for use only on HP Mini 210 computer models
equipped with WWAN capability (includes WWAN antenna cables and transceivers)
FlushGlass, HD display assembly in charcoal finish for use only on HP Mini 210 computer models 668156-001
FlushGlass, HD display assembly in crimson red finish for use only on HP Mini 210
computer models
FlushGlass, HD display assembly in luminous rose finish for use only on HP Mini 210
computer models
FlushGlass, HD display assembly in ocean drive finish for use only on HP Mini 210
computer models
FlushGlass, HD display assembly in sweet purple finish for use only on HP Mini 210
computer models
668166-001
658507-001
658510-001
658508-001
650712-001
668159-001
668158-001
668157-001
668160-001
WSVGA, HD display assembly in charcoal finish for use only on HP Mini 210 computer models
equipped with WWAN capability (includes WWAN antenna cables and transceivers)
WSVGA, HD display assembly in charcoal finish for use only on HP Mini 210 computer models 668161-001
WSVGA, HD display assembly in crimson red finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in luminous rose finish for use only on HP Mini 210
computer models
WSVGA, HD display assembly in sweet purple finish for use only on HP Mini 210
computer models
650719-001
668164-001
668163-001
668165-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
Component replacement procedures
81
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
●
Service cover (see
●
Keyboard (see
●
Top cover (see
Battery on page 50), and then remove the following components:
WLAN module on page 52)
Keyboard on page 61)
Top cover on page 67)
Remove the display assembly:
1. Position the computer upside down, with the front toward you.
CAUTION: Support the open display assembly when removing the following screws. Failure to
support the display assembly can result in damage to the display assembly and other computer
components.
2.
Remove the two Phillips PM2.0×5.7 screws (1) that secure the display assembly to the computer.
3.
Remove the display assembly (2).
NOTE: Steps 4 through 9 apply only to Compaq Mini CQ10 and HP Mini 110 computer
models.
4. If it is necessary to replace the display bezel or any of the display assembly subcomponents:
a. Flex the inside edges of the top edge (1), the left and right sides (2), and the
bottom edge (3) of the display bezel until the bezel disengages from the display enclosure.
82 Chapter 4 Removal and replacement procedures
b.
Remove the display bezel (4). The display bezel is available using the following spare
part numbers:
●
658504-001 — For use only on Compaq Mini CQ10 computer models
●
658503-001 — For use only on HP Mini 110 computer models
5. If it is necessary to replace the webcamera/microphone module:
a.
Detach and release the module (1) as far as the module cable allows. (The module is
attached to the display enclosure with double-sided tape.)
b.
Disconnect the module cable (2) from the module.
c. Remove the webcamera/microphone module. The webcamera/microphone module is
available using spare part number 658516-001.
Component replacement procedures
83
6.
If it is necessary to replace the display panel:
a. Remove the six Phillips PM2.0×4.6 screws (1) that secure the display panel to the
display enclosure.
b. Lift the top edge of the display panel (2) and swing it up and forward until it rests at
an angle.
c. Remove the display panel. The display panel is available using spare part number
658511-001.
7. If it is necessary to replace the display hinges:
a. Remove the four Phillips PM2.0×3.7 screws (1) that secure the display hinges to the
display panel.
b. Remove the display hinges (2). The display hinges include the display hinges and brackets
and are available using spare part number 650711-001.
84 Chapter 4 Removal and replacement procedures
8.
If it is necessary to replace the display panel cable:
CAUTION: Make sure the work surface is free of any foreign objects before turning the display
panel upside down. Failure to clear the work surface can result in scratches and damage to the
display panel surface.
a. Turn the display panel upside down with the bottom edge toward you.
b.
Release the tabs (1) built into the shielding on the back of the display panel that conceal the
display panel connector and secure the display panel cable.
c. Release the adhesive strip (2) that secures the display panel cable to the display panel, and
then disconnect the display panel cable (3) from the display panel.
d. Remove the display panel cable. The display panel cable includes the webcamera/
microphone module cable and is available in the Display Cable Kit, spare part number
658505-001.
9. If it is necessary to replace the wireless antenna cables and transceivers:
a. Release the WLAN antenna transceivers (1) and the WWAN antenna transceivers (2) from
the display enclosure. (The antenna transceivers are attached to the display enclosure with
double-sided tape.)
Component replacement procedures
85
b.
Release the wireless antenna cables from the clips (3) built into the display enclosure.
c.
Remove the wireless antenna cables and transceivers. The wireless antenna cables
and transceivers are available in the Antenna Kit, spare part number 658498-001.
Reverse this procedure to reassemble and install the display assembly.
86 Chapter 4 Removal and replacement procedures
5 Setup Utility (BIOS) and System
Diagnostics
Using Setup Utility
Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and
output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility
includes settings for the types of peripherals installed, the startup sequence of the computer, and the
amount of system and extended memory.
NOTE: Use extreme care when making changes in Setup Utility. Errors can prevent the computer from
operating properly.
Starting Setup Utility
NOTE: An external keyboard or mouse connected to a USB port can be used with Setup Utility only if
USB legacy support is enabled.
To start Setup Utility, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
2.
Press f10 to enter Setup Utility.
Changing the language of Setup Utility
1. Start Setup Utility.
2. Use the arrow keys to select System Configuration > Language, and then press enter.
3. Use the arrow keys to select a language, and then press enter.
4. When a confirmation prompt with your language selected is displayed, press enter.
5. To save your change and exit Setup Utility, use the arrow keys to select Exit > Exit Saving
Changes, and then press enter.
Your change takes effect immediately.
Using Setup Utility
87
Navigating and selecting in Setup Utility
To navigate and select in Setup Utility, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
●
To select a menu or a menu item, use the tab key and the keyboard arrow keys and then
press enter, or use a pointing device to click the item.
●
To scroll up and down, click the up arrow or the down arrow in the upper-right corner of the
screen, or use the up arrow key or the down arrow key.
●
To close open dialog boxes and return to the main Setup Utility screen, press esc, and then
follow the on-screen instructions.
2. Press f10 to enter Setup Utility.
To exit Setup Utility menus, choose one of the following methods:
●
To exit Setup Utility menus without saving your changes, press the esc key, and then follow the onscreen instructions.
– or –
Use the arrow keys to select Exit > Exit Discarding Changes, and then press enter.
●
To save your changes and exit Setup Utility menus, press f10, and then follow the onscreen instructions.
– or –
Use the tab key and the arrow keys to select Exit > Exit Saving Changes, and then
press enter.
Your changes go into effect when the computer restarts.
Displaying system information
1. Start Setup Utility.
2. Select the Main menu. System information such as the system time and date, and identification
information about the computer is displayed.
3. To exit Setup Utility without changing any settings, use the arrow keys to select Exit > Exit
Discarding Changes, and then press enter.
88 Chapter 5 Setup Utility (BIOS) and System Diagnostics
Restoring factory settings in Setup Utility
NOTE: Restoring defaults will not change the hard drive mode.
To return all settings in Setup Utility to the values that were set at the factory, follow these steps:
1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
2. Press f10 to enter Setup Utility.
3. Use the arrow keys to select Exit > Load Setup Defaults.
4. Follow the on-screen instructions.
5. To save your changes and exit, press f10, and then follow the on-screen instructions.
– or –
Use the arrow keys to select Exit > Exit Saving Changes, and then press enter.
Your changes go into effect when the computer restarts.
NOTE: Your password settings and security settings are not changed when you restore the
factory settings.
Exiting Setup Utility
●
To exit Setup Utility and save your changes from the current session:
If the Setup Utility menus are not visible, press esc to return to the menu display. Then use the
arrow keys to select Exit > Exit Saving Changes, and then press enter.
●
To exit Setup Utility without saving your changes from the current session:
If the Setup Utility menus are not visible, press esc to return to the menu display. Then use the
arrow keys to select Exit > Exit Discarding Changes, and then press enter.
Updating the BIOS
Updated versions of the BIOS may be available on the HP Web site.
Most BIOS updates on the HP Web site are packaged in compressed files called SoftPaqs.
Some download packages contain a file named Readme.txt, which contains information regarding
installing and troubleshooting the file.
Using Setup Utility
89
Determining the BIOS version
To determine whether available BIOS updates contain later BIOS versions than those currently installed
on the computer, you need to know the version of the system BIOS currently installed.
BIOS version information (also known as ROM date and System BIOS) can be displayed by pressing fn
+esc (if you are already in Windows) or by using Setup Utility.
1. Start Setup Utility (BIOS).
2. Use the arrow keys to select Main.
3. To exit Setup Utility (BIOS) without saving your changes, use the tab key and the arrow keys to
select Exit > Exit Discarding Changes, and then press enter.
Downloading a BIOS update
CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download
and install a BIOS update only when the computer is connected to reliable external power using the AC
adapter. Do not download or install a BIOS update while the computer is running on battery power,
docked in an optional docking device, or connected to an optional power source. During the
download and installation, follow these instructions:
Do not disconnect power from the computer by unplugging the power cord from the AC outlet.
Do not shut down the computer or initiate Sleep or Hibernation.
Do not insert, remove, connect, or disconnect any device, cable, or cord.
1. Windows 7—Select Start > Help and Support > Maintain.
Windows XP—Select Start > Help and Support, and then select the software and
drivers update.
2.
Follow the on-screen instructions to identify your computer and access the BIOS update you want
to download.
3. At the download area, follow these steps:
a. Identify the BIOS update that is later than the BIOS version currently installed on your
computer. Make a note of the date, name, or other identifier. You may need this information
to locate the update later, after it has been downloaded to your hard drive.
b.
Follow the on-screen instructions to download your selection to the hard drive. Make a note
of the path to the location on your hard drive where the BIOS update is downloaded. You
will need to access this path when you are ready to install the update.
NOTE: If you connect your computer to a network, consult the network administrator before
installing any software updates, especially system BIOS updates.
90 Chapter 5 Setup Utility (BIOS) and System Diagnostics
BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the
download is complete. If no instructions are displayed, follow these steps:
1. Windows 7—Open Windows Explorer by selecting Start > Computer.
Windows XP—Open Windows Explorer by selecting Start > My Computer.
2. Double-click your hard drive designation. The hard drive designation is typically Local Disk (C:).
3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains
the update.
4. Double-click the file that has an .exe extension (for example, filename.exe). The BIOS
installation begins.
5. Complete the installation by following the on-screen instructions.
NOTE: After a message on the screen reports a successful installation, you can delete the
downloaded file from your hard drive.
Using System Diagnostics
System Diagnostics allows you to run diagnostic tests to determine if the computer hardware is
functioning properly. The following diagnostic tests are available in System Diagnostics:
●
Start-up test—This test analyzes the main computer components that are required to start
the computer.
●
Run-in test—This test repeats the start-up test and checks for intermittent problems that the start-up
test does not detect.
●
Hard disk test—This test analyzes the physical condition of the hard drive, and then checks all
data in every sector of the hard drive. If the test detects a damaged sector, it attempts to move the
data to a good sector.
●
Memory test—This test analyzes the physical condition of the memory modules. If it reports an
error, replace the memory modules immediately.
●
Battery test—This test analyzes the condition of the battery. If the battery fails the test, contact HP
support to report the issue and purchase a replacement battery.
You can also view system information and error logs in the System Diagnostics window.
To start System Diagnostics:
1. Turn on or restart the computer. While the “Press the ESC key for Startup Menu” message is
displayed in the lower-left corner of the screen, press esc. When the Startup Menu is displayed,
press f2.
2.
Click the diagnostic test you want to run, and then follow the on-screen instructions.
NOTE: If you need to stop a diagnostics test while it is running, press esc.
Using System Diagnostics
91
6 Specifications
Computer specifications
Metric U.S.
Dimensions
Width 26.8 cm 10.55 in
Depth 19.1 cm 7.52 in
Height (front to back) 2.3 to 3.3 cm 0.91 to 1.29 in
Weight 1.26 kg (with 3-cell battery),
1.40 kg (with 6-cell battery)
Input power
Operating voltage and current 19.5 V dc @ 2.05 A - 40W
Temperature
Operating 5°C to 35°C 41°F to 95°F
Nonoperating -20°C to 60°C -4°F to 140°F
Relative humidity (noncondensing)
Operating 10% to 90%
Nonoperating 5% to 95%
Maximum altitude (unpressurized)
Operating -15 m to 3,048 m -50 ft to 10,000 ft
Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The device operates well within this
range of temperatures.
2.77 lb (with 3-cell battery),
3.09 lb (with 6-cell battery)
92 Chapter 6 Specifications
Loading...
