HP M232e, M237e Reference Guide
Reference Guide
HP LaserJet MFP M232e-M237e series
Control panel
Copy Options
Copy button/light
ID Card Copy button/light
Information button/light
Press to print a summary of
printer settings and status.
Resume button/light
Press when lit to continue a job.
Cancel button/light
Power button
Wireless button
English
Status lights
Pulsing purple
Wireless setup mode. Lasts for
2 hours after rst turning on
printer. See "Trouble with Wi-Fi
setup?" for help.
Pulsing blue
Connecting to network
Paper light
Blinks when out of paper or paper
is jammed.
Cartridge light
Blinks when cartridge needs
attention.
Open Lid light
Open lid and turn over ID card to
copy second side.
For more information on lights and errors, visit hp.com/support/ljM232eMFP
Solid light blue
Connected/ready for use
Solid amber
Problem. Check the HP Smart
app for troubleshooting
information.
Pulsing green
Updating or busy
Trouble with Wi-Fi setup?
If the app or software is unable to nd your printer, restart wireless setup mode. You might need
to do this if the printer has been turned on for more than two hours without being connected to
a wireless network.
English
1. Press and hold for 3 seconds, and then release the button.
All control panel buttons will light up.
2. Press and at the same time.
The status light pulses purple.
3. Open HP Smart and try connecting again.
Do not use USB for setup
Printers with a label covering the USB port must be set up with HP Smart and a network
connection. After setup, you can print using a USB cable if needed.
Copy
1. Place the original on the scanner glass.
2. Use to change options and to select settings.
3. Press to start the copy.
Print/Scan
The printer prints professional-quality documents at a great value. Up to 29 pages per minute (ppm)
A4 size and 30 ppm letter size.
Print from or scan to many iOS, Android, Microsoft® Windows®, and macOS devices.
Visit 123.hp.com from your devices to get started.
Introducing
Printing that gives
you more
Enjoy 1 year of extra warranty and 6 months of free toner.
For your HP+ printer to operate, you agree to:
• Sign in or create an HP account
• Connect your printer to the Internet
• Use only Original HP toner
Help and Support
For printer information, troubleshooting,
and videos, visit the printer support website.
The information contained herein is subject to change without notice.
2
hp.com/support/ljM232eMFP
Manuel de référence
Imprimante multifonction HP LaserJet
Série M232e-M237e
Panneau de commande
Options de Copie.
Bouton/Voyant Copie.
Bouton/Voyant Copie ID.
Bouton/Voyant Informations
Appuyez sur le bouton pour imprimer
un résumé des paramètres et de l'état
de l'imprimante.
Bouton/Voyant Reprendre
Appuyez sur le bouton lorsqu'il est
allumé pour poursuivre un travail.
Bouton/Voyant Annuler.
Bouton Alimentation.
Bouton Sans l.
Français
Voyants d'état
Violet clignotant
Mode Conguration sans l. Dure
2 heures après la première sous
tension de l'imprimante. Consultez
la section «Des problèmes avec la
conguration Wi-Fi?» pour en savoir
plus.
Bleu clignotant
Connexion au réseau.
Voyant Papier
Clignote en cas de papier épuisé
ou de bourrage papier.
Voyant Cartouche
Clignote lorsqu'une cartouche
nécessite votre attention.
Voyant Capot ouvert
Ouvrez le capot et retournez la carte
d'identité pour copier le verso.
Pour plus d'informations sur les voyants et les erreurs, visitez le site hp.com/support/ljM232eMFP
Bleu clair xe
Connecté/prêt à fonctionner.
Orange continu
Problème. Consultez l'application
HP Smart pour obtenir des
informations de dépannage.
Vert pulsé
Mise à jour en cours ou occupé.
