User Guide
© 2014 Hewlett-Packard Development
Company, L.P.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: November 2014
Document Part Number: 799886-001
About This Guide
This guide provides information on monitor features, setting up the monitor, and technical
specifications.
WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily
harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in
damage to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
iii
iv About This Guide
Table of contents
1 Product features ................................................................................................................................................ 1
HP ProDisplay Monitors ....................................................................................................................... 1
2 Safety and maintenance guidelines .................................................................................................................. 3
Important safety information ................................................................................................................. 3
Maintenance guidelines ........................................................................................................................ 4
Cleaning the monitor ............................................................................................................ 4
Shipping the monitor ............................................................................................................ 4
3 Setting up the monitor ....................................................................................................................................... 5
Use caution when setting up the monitor ............................................................................................. 5
Attaching the stand base ...................................................................................................................... 6
Identifying rear components ................................................................................................................. 7
Connecting the cables .......................................................................................................................... 8
Identifying front panel controls ........................................................................................................... 10
Adjusting the monitor .......................................................................................................................... 11
Turning on the monitor ....................................................................................................................... 11
Removing the monitor stand .............................................................................................................. 12
Mounting the monitor ......................................................................................................... 12
Locating the rating label ..................................................................................................................... 14
Installing a cable lock ......................................................................................................................... 14
4 Operating the monitor ..................................................................................................................................... 15
Software and utilities .......................................................................................................................... 15
The Information file ............................................................................................................ 15
The Image Color Matching file ........................................................................................... 15
Installing the .INF and .ICM files ........................................................................................................ 16
Installing from the disc ....................................................................................................... 16
Downloading from the web ................................................................................................ 16
Using the On-Screen Display (OSD) menu ........................................................................................ 17
Using Auto-Sleep Mode ..................................................................................................................... 18
v
Appendix A Technical specifications .................................................................................................................. 19
50,8 cm (20 in) models specifications ................................................................................................ 19
54,6 cm (21.5 in) model specifications ............................................................................................... 20
Preset display resolutions .................................................................................................................. 21
50,8 cm (20 in) models factory preset modes .................................................................... 21
54,6 cm (21.5 in) model factory preset modes .................................................................. 21
Entering user modes .......................................................................................................................... 22
Energy saver feature .......................................................................................................................... 22
Appendix B Support and troubleshooting .......................................................................................................... 23
Solving common problems ................................................................................................................. 23
Using the Auto-Adjustment Function (Analog Input) .......................................................................... 24
Optimizing Image Performance (Analog Input) .................................................................................. 25
Button lockouts ................................................................................................................................... 26
Product support .................................................................................................................................. 26
Preparing to call technical support ..................................................................................................... 27
Appendix C Accessibility .................................................................................................................................... 28
Supported assistive technologies ....................................................................................................... 28
Contacting support ............................................................................................................................. 28
vi
1 Product features
HP ProDisplay Monitors
The LCD (liquid crystal display) monitors have an active matrix, thin-film transistor (TFT) panel. The
monitor models and features include:
50,8 cm (20 in) diagonal viewable area display with 1600 x 900 resolution, plus full-screen
●
support for lower resolutions; includes custom scaling for maximum image size while preserving
original aspect ratio
54,6 cm (21.5 in) diagonal viewable area display with 1920 x 1080 resolution, plus full-screen
●
support for lower resolutions; includes custom scaling for maximum image size while preserving
original aspect ratio
Non-glare panel with an LED backlight that consumes less energy
●
Wide viewing angle to allow viewing from a sitting or standing position, or moving from side-to-
●
side
Tilt capability
●
Removable stand for flexible monitor panel mounting solutions
●
Video signal input to support VGA analog with VGA signal cable provided
●
Video signal input to support DisplayPort digital with DisplayPort signal cable provided (select
●
models)
Integrated speakers and audio cable (select models)
●
Plug-and-play capability if supported by the operating system
●
Security slot provision on rear of monitor for optional cable lock
●
Cable management feature for placement of cables and cords
●
On-Screen Display (OSD) adjustments in several languages for easy setup and screen
●
optimization
HP Display Assistant software for adjusting monitor settings and enabling theft deterrence
●
features (refer to the
HDCP copy protection on DisplayPort input
●
HP Display Assistant User Guide
included on the disc with your monitor)
Software and documentation disc that includes monitor drivers and product documentation
●
Energy saver feature to meet requirements for reduced power consumption
●
HP ProDisplay Monitors 1
Supports an optional HP Integrated Work Center Stand
●
Supports an optional HP ProDisplay Sheltie Stand
●
Supports an optional HP Quick Release to enable mounting to an optional HP monitor arm or
●
attaching an optional HP Chromebox, HP Thin Client (select models), or HP Desktop Mini
Business PC
Privacy filter slots to insert filters (purchased separately) to block side screen viewing
●
NOTE: For safety and regulatory information, refer to the
disc, if one is included, or in your documentation kit. To locate updates to the user guide for your
product, go to http://www.hp.com/support, and select your country. Select Drivers & Downloads, and
then follow the on-screen instructions.
Product Notices
provided on your media
2 Chapter 1 Product features
2 Safety and maintenance guidelines
Important safety information
A power cord is included with the monitor. If another cord is used, use only a power source and
connection appropriate for this monitor. For information on the correct power cord set to use with the
monitor, refer to the
documentation kit.
WARNING! To reduce the risk of electric shock or damage to the equipment:
• Plug the power cord into an AC outlet that is easily accessible at all times.
• Disconnect power from the computer by unplugging the power cord from the AC outlet.
• If provided with a 3-pin attachment plug on the power cord, plug the cord into a grounded (earthed)
3-pin outlet. Do not disable the power cord grounding pin, for example, by attaching a 2-pin adapter.
The grounding pin is an important safety feature.
Product Notices
provided on your media disc, if one is included, or in your
For your safety, do not place anything on power cords or cables. Arrange them so that no one may
accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging from the
electrical outlet, grasp the cord by the plug.
To reduce the risk of serious injury, read the
workstation, setup, posture, and health and work habits for computer users, and provides important
electrical and mechanical safety information. This guide is located on the web at http://www.hp.com/
ergo.
CAUTION: For the protection of the monitor, as well as the computer, connect all power cords for
the computer and its peripheral devices (such as a monitor, printer, scanner) to some form of surge
protection device such as a power strip or Uninterruptible Power Supply (UPS). Not all power strips
provide surge protection; the power strips must be specifically labeled as having this ability. Use a
power strip whose manufacturer offers a Damage Replacement Policy so you can replace the
equipment, if surge protection fails.
Use the appropriate and correctly sized furniture designed to properly support your HP LCD monitor.
WARNING! LCD monitors that are inappropriately situated on dressers, bookcases, shelves, desks,
speakers, chests, or carts may fall over and cause personal injury.
Care should be taken to route all cords and cables connected to the LCD monitor so that they cannot
be pulled, grabbed, or tripped over.
NOTE: This product is suitable for entertainment purposes. Consider placing the display in a
controlled luminous environment to avoid interference from surrounding light and bright surfaces that
may cause disturbing reflections from the screen.
Safety and Comfort Guide
. It describes proper
Important safety information 3
Maintenance guidelines
To enhance the performance and extend the life of the monitor:
Do not open the monitor cabinet or attempt to service this product yourself. Adjust only those
●
controls that are covered in the operating instructions. If the monitor is not operating properly or
has been dropped or damaged, contact an authorized HP dealer, reseller, or service provider.
Use only a power source and connection appropriate for this monitor, as indicated on the label/
●
back plate of the monitor.
Be sure the total ampere rating of the products connected to the outlet does not exceed the
●
current rating of the electrical outlet, and the total ampere rating of the products connected to the
cord does not exceed the rating of the cord. Look on the power label to determine the ampere
rating (AMPS or A) for each device.
Install the monitor near an outlet that you can easily reach. Disconnect the monitor by grasping
●
the plug firmly and pulling it from the outlet. Never disconnect the monitor by pulling the cord.
Turn the monitor off when not in use. You can substantially increase the life expectancy of the
●
monitor by using a screen saver program and turning off the monitor when not in use.
NOTE: Monitors with a “burned-in image” are not covered under the HP warranty.
Slots and openings in the cabinet are provided for ventilation. These openings must not be
●
blocked or covered. Never push objects of any kind into cabinet slots or other openings.
Do not drop the monitor or place it on an unstable surface.
●
Do not allow anything to rest on the power cord. Do not walk on the cord.
●
Keep the monitor in a well-ventilated area, away from excessive light, heat or moisture.
●
When removing the monitor stand, you must lay the monitor face down on a soft area to prevent
●
it from getting scratched, defaced, or broken.
Cleaning the monitor
1. Turn off the monitor and unplug the power cord from the back of the unit.
2. Dust the monitor by wiping the screen and the cabinet with a soft, clean antistatic cloth.
3. For more difficult cleaning situations, use a 50/50 mix of water and Isopropyl alcohol.
CAUTION: Spray the cleaner onto a cloth and use the damp cloth to gently wipe the screen surface.
Never spray the cleaner directly on the screen surface. It may run behind the bezel and damage the
electronics.
CAUTION: Do not use cleaners that contain any petroleum based materials such as benzene,
thinner, or any volatile substance to clean the monitor screen or cabinet. These chemicals may
damage the monitor.
Shipping the monitor
Keep the original packing box in a storage area. You may need it later if you move or ship the
monitor.
4 Chapter 2 Safety and maintenance guidelines
3 Setting up the monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Use caution when setting up the monitor
To prevent damage to the monitor, do not touch the surface of the LCD panel. Pressure on the panel
may cause non-uniformity of color or disorientation of the liquid crystals. If this occurs the screen will
not recover to its normal condition.
If installing a stand, lay the monitor face down on a flat surface covered with a protective sheet foam
or non-abrasive cloth. This prevents the screen from getting scratched, defaced or broken as well as
damage to the front panel buttons.
NOTE: Your monitor may look different from the monitor in this illustration.
Use caution when setting up the monitor 5
Attaching the stand base
1. Remove the stand/base assembly, and then lift the monitor from the box and place it face down
on a flat surface.
2. Position the stand over the base, and press down firmly to lock it in place.
3. Insert the two tabs on the stand into the bracket on the back of the display head until they click
into place.
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-
uniformity of color or disorientation of the liquid crystals. If this occurs the screen will not recover to its
normal condition.
6 Chapter 3 Setting up the monitor
Identifying rear components
Component Function
1 AC Power Connector Connects the AC power cord to the monitor.
2 DisplayPort (select
models)
3 VGA Connects the VGA cable to the monitor.
4 Audio Connector (select
models)
Connects the DisplayPort cable to the monitor.
Connects the audio cable to the monitor.
Identifying rear components 7
Connecting the cables
1. Place the monitor in a convenient, well-ventilated location near the computer or source device.
2. Remove the cable management clip from the stand by pulling outward on the two sides of the
clip (1), then lifting the clip off the stand (2).
3. Connect a VGA signal cable or DisplayPort signal cable (select models).
NOTE: The monitor is capable of supporting either analog or digital input (select models). The
video mode is determined by the video cable used. The monitor will automatically determine
which inputs have valid video signals. The inputs can be selected by pressing the +/source
button on the front panel or through the On-Screen Display (OSD) feature by pressing the Menu
button.
For analog operation, use the VGA signal cable provided. Connect the VGA signal cable to
●
the VGA connector on the rear of the monitor and the other end to the VGA connector on
the computer.
For DisplayPort digital operation, use the DisplayPort signal cable provided. Connect the
●
DisplayPort signal cable to the DisplayPort connector on the rear of the monitor and the
other end to the DisplayPort connector on the computer.
4. Connect one end of the provided audio cable to the audio connector on the monitor (select
models) and connect the other end of the cable to an audio output connector on the rear panel
of the computer.
8 Chapter 3 Setting up the monitor
5. Connect one end of the power cord to the AC power connector on the back of the monitor, and
the other end to an electrical wall outlet.
WARNING! To reduce the risk of electric shock or damage to the equipment:
Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
Disconnect power from the equipment by unplugging the power cord from the electrical outlet.
For your safety, do not place anything on power cords or cables. Arrange them so that no one
may accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging from
the electrical outlet, grasp the cord by the plug.
6. Secure the cables in place with the cable management clip. Press the clip straight down on the
stand ensuring that the tabs on the sides of the clip snap into the slots on the stand.
Connecting the cables 9
Identifying front panel controls
Control Function
1 Menu Opens, selects or exits the OSD menu.
2
or
3 Plus/source If the OSD menu is on, press to navigate forward through
4 OK/auto If the OSD menu is on, press to select the highlighted
5 Power Turns the monitor on or off.
6 Power LED White = Fully powered.
Minus
or
Minus/volume
(P202m)
If the OSD menu is on, press to navigate backward through
the OSD menu and decrease adjustment levels.
If the OSD menu is inactive, press to activate the volume
adjustment bar. Press - or + to adjust the volume (select
models).
the OSD menu and increase adjustment levels.
If the OSD menu is inactive, press to activate the source
button that chooses the video signal input (VGA or
DisplayPort).
menu item.
If the OSD menu is inactive, press to activate the auto
adjustment feature to optimize the screen image.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
NOTE: To view an OSD menu simulator, visit the HP Customer Self Repair Services Media Library
at http://www.hp.com/go/sml.
10 Chapter 3 Setting up the monitor
Adjusting the monitor
Tilt the monitor panel forward or backward to set it to a comfortable eye level. The monitor can be
tilted from -5° to +22°.
Turning on the monitor
1. Press the power button on the computer to turn on the computer.
2. Press the power button on the front of the monitor to turn on the monitor.
CAUTION: Burn-in image damage may occur on monitors that display the same static image on
screen for a prolonged period of time.* To avoid burn-in image damage on the monitor screen, you
should always activate a screen saver application or turn off the monitor when it is not in use for a
prolonged period of time. Image retention is a condition that may occur on all LCD screens. Monitors
with a “burned-in image” are not covered under the HP warranty.
* A prolonged period of time is 12 consecutive hours of non-use.
NOTE: If pressing the power button has no effect, the power button lockout feature may be enabled.
To disable this feature, press and hold the monitor power button for 10 seconds.
NOTE: You can disable the power LED in the OSD menu. Press the Menu button on the front of the
monitor, then select Management > Power LED > Off.
When the monitor is powered on, a monitor status message is displayed for five seconds. The
message shows which input (DisplayPort or VGA) is the current active signal, the status of the autoswitch source setting (on or off; factory default is on), the current preset display resolution, and the
recommended preset display resolution.
Adjusting the monitor 11
Removing the monitor stand
You can remove the monitor panel from the stand to install the panel on a wall, a swing arm, or other
mounting fixture.
CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and the
power and signal cables are both disconnected.
1. Disconnect and remove the signal and power cables from the monitor.
2. Lay the monitor face down on a flat surface covered by a clean, dry cloth.
3. Press down on the release latch (1) with a screwdriver and slide the stand out of the slot on the
display head (2).
Mounting the monitor
The monitor panel can be attached to a wall, swing arm, or other mounting fixture.
NOTE: This apparatus is intended to be supported by UL or CSA Listed wall mount bracket.
1. Remove the stand from the monitor. See Removing the monitor stand on page 12.
CAUTION: This monitor supports the VESA industry standard 100 mm mounting holes. To
attach a third-party mounting solution to the monitor, four 4 mm, 0.7 pitch, and 10 mm long
screws are required. Longer screws must not be used because they may damage the monitor. It
is important to verify that the manufacturer’s mounting solution is compliant with the VESA
standard and is rated to support the weight of the monitor display panel. For best performance, it
is important to use the power and video cables provided with the monitor.
12 Chapter 3 Setting up the monitor
2. To attach the monitor to a swing arm (sold separately), insert four 10mm screws through the
holes on the swing arm plate and into the mounting holes on the monitor.
To attach the monitor to other mounting fixtures, follow the instructions included with the
mounting fixture to ensure that the monitor is safely attached.
3. Reconnect the cables to the monitor panel.
Removing the monitor stand 13
Locating the rating label
The rating label on the monitor provides the product number and serial number. You may need these
numbers when contacting HP about the monitor model. The rating label is located on the bottom of
the monitor.
Installing a cable lock
You can secure the monitor to a fixed object with an optional cable lock available from HP (sold
separately).
14 Chapter 3 Setting up the monitor
4 Operating the monitor
Software and utilities
The disc that comes with the monitor contains files you can install on the computer:
an .INF (Information) file
●
ICM (Image Color Matching) files (one for each calibrated color space)
●
The Information file
The .INF file defines monitor resources used by Microsoft Windows operating systems to ensure
monitor compatibility with the computer’s graphics adapter.
This monitor is Microsoft Windows Plug and Play compatible and the monitor will work correctly
without installing the .INF file. Monitor Plug and Play compatibility requires that the computer’s
graphic card is VESA DDC2–compliant and that the monitor connects directly to the graphics card.
Plug and Play does not work through separate BNC type connectors or through distribution buffers/
boxes.
The Image Color Matching file
The .ICM files are data files that are used in conjunction with graphics programs to provide consistent
color matching from monitor screen to printer, or from scanner to monitor screen. This file is activated
from within graphics programs that support this feature.
NOTE: The ICM color profile is written in accordance with the International Color Consortium (ICC)
Profile Format specification.
Software and utilities 15
Installing the .INF and .ICM files
After you determine that you need to update, you can install the .INF and .ICM files from the disc or
download them.
Installing from the disc
To install the .INF and .ICM files on the computer from the disc:
1. Insert the disc in the computer optical drive. The disc menu is displayed.
2. View the HP Monitor Software Information file.
3. Select Install Monitor Driver Software.
4. Follow the on-screen instructions.
5. Ensure that the proper resolution and refresh rates appear in the Windows Display control panel.
NOTE: You may need to install the digitally signed monitor .INF and .ICM files manually from the
disc in the event of an installation error. Refer to the HP Monitor Software Information file on the disc.
Downloading from the web
If you do not have a computer with an optical drive, you can download the latest version of .INF
and .ICM files from the HP monitors support website:
1. Go to http://www.hp.com/support and select the appropriate country and language.
2. Select Drivers & Downloads, type your monitor model in the Find my product search field, and
click Go.
3. If necessary, select your monitor from the list.
4. Select your operating system, and then click Next.
5. Click Driver - Display/Monitor to open the list of drivers.
6. Click on the driver.
7. Click the System Requirements tab, and then verify that your system meets the program
minimum requirements.
8. Click Download and follow the on-screen instructions to download the software.
16 Chapter 4 Operating the monitor
Using the On-Screen Display (OSD) menu
Use the On-Screen Display (OSD) to adjust the monitor settings screen image based on your
preferences. You can access and make adjustments in the OSD using the buttons on the monitor's
front panel.
To access the OSD and make adjustments, do the following:
1. If the monitor is not already on, press the power button to turn on the monitor.
2. Press the Menu button to open the OSD.
3. Use the menu options to navigate, select, and adjust the menu choices. The options are variable
depending on the menu or sub-menu that is active.
The following table lists the menu selections in the main menu.
Main Menu Description
Brightness Adjusts the brightness level of the screen.
Contrast Adjusts the contrast level of the screen
Input Control Selects the video input signal.
Color Control Selects and adjusts the screen color.
Image Control Adjusts the screen image.
Power Control Adjusts the power settings.
OSD Control Adjusts the on-screen display (OSD) and Function button controls.
Management Enables/disables DDC/CI support and returns all OSD menu settings to the factory default
settings.
Language Selects the language in which the OSD menu is displayed. The factory default is English.
Information Displays important information about the monitor.
Exit Exits the OSD menu screen.
Using the On-Screen Display (OSD) menu 17
Using Auto-Sleep Mode
The display supports an OSD (On-Screen Display) option called Auto-Sleep Mode that allows you to
enable or disable a reduced power state for the display. When Auto-Sleep Mode is enabled (enabled
by default), the monitor will enter a reduced power state when the host PC signals low power mode
(absence of either horizontal or vertical sync signal).
Upon entering this reduced power state sleep mode, the monitor screen is blanked, the backlight is
turned off and the power LED indicator turns amber. The monitor draws less than 0.5W of power
when in this reduced power mode. The monitor will wake from the sleep mode when the host PC
sends an active signal to the monitor (for example, if you activate the mouse or keyboard).
You can disable the Auto-Sleep Mode in the OSD. Press one of the five front bezel buttons to activate
the buttons, and then press the Menu button to open the OSD. In the OSD press Power Control >
Auto-Sleep Mode > Off.
18 Chapter 4 Operating the monitor
A Technical specifications
NOTE: All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary.
50,8 cm (20 in) models specifications
Maximum Weight (Unpacked) 3.5 kg 7.7 lbs
Dimensions (include stand)
Height
Depth
Width
Maximum Graphic Resolution 1600 x 900 (60 Hz) analog input
Optimum Graphic Resolution 1600 x 900 (60 Hz) analog input
Power Source 100 – 240 VAC 50/60 Hz
Input Terminal One VGA connector with cable included;
Tilt -5° to +22°
Operating Temperature 5° to 35° C 41° to 95° F
Operating Altitude Up to 5,000 m above sea level Up to 16,404 ft above sea
NOTE: For more information, go to http://www.hp.com/go/productbulletin and search for your specific display model to find
the model-specific QuickSpecs.
35.92 cm
15.11 cm
48.20 cm
1600 x 900 (60 Hz) digital input
1600 x 900 (60 Hz) digital input
one DisplayPort connector with cable
included; one audio connector with cable
included (P202m only)
14.14 in
5.95 in
18.98 in
level
50,8 cm (20 in) models specifications 19
54,6 cm (21.5 in) model specifications
Maximum Weight (Unpacked) 4.0 kg 8.8 lbs
Dimensions (include stand)
Height
Depth
Width
Maximum Graphic Resolution 1920 x 1080 (60 Hz) analog input
Optimum Graphic Resolution 1920 x 1080 (60 Hz) analog input
Power Source 100 – 240 VAC 50/60 Hz
Input Terminal One VGA connector with cable included;
Tilt -5° to +22°
Operating Temperature 0° to 35° C 32° to 95° F
Operating Altitude Up to 5,000 m above sea level Up to 16,404 ft above sea
NOTE: For more information, go to http://www.hp.com/go/productbulletin and search for your specific display model to find
the model-specific QuickSpecs.
37.9 cm
18.7 cm
51.8 cm
1920 x 1080 (60 Hz) digital input
1920 x 1080 (60 Hz) digital input
one DisplayPort connector with cable
included
14.92 in
7.4 in
20.39 in
level
20 Appendix A Technical specifications
Preset display resolutions
The display resolutions listed below are the most commonly used modes and are set as factory
defaults. This monitor automatically recognizes these preset modes and they will appear properly
sized and centered on the screen.
50,8 cm (20 in) models factory preset modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 × 480 31.469 59.940
2 800 × 600 37.879 60.317
3 1024 × 768 48.363 60.004
4 1280 × 720 45.00 59.94
5 1280 x 800 60.00 60.00
6 1280 × 1024 63.98 60.02
7 1440 × 900 55.93 59.88
8 1600 × 900 60.00 60.00
54,6 cm (21.5 in) model factory preset modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 × 480 31.469 59.940
2 800 × 600 37.879 60.317
3 1024 × 768 48.363 60.004
4 1280 × 720 45.00 60.00
5 1280 x 800 60.00 60.00
6 1280 × 1024 63.981 60.02
7 1440 × 900 55.935 59.887
8 1600 × 900 60.00 60.00
9 1680 × 1050 65.29 59.954
10 1920 x 1080 67.50 60.00
Preset display resolutions 21
Entering user modes
The video controller signal may occasionally call for a mode that is not preset if:
You are not using a standard graphics adapter.
●
You are not using a preset mode.
●
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognizes the new mode just as it does a preset mode. In
addition to the factory preset modes, there are at least 10 user modes that can be entered and
stored.
Energy saver feature
The monitors support a reduced power state. The reduced power state will be entered into if the
monitor detects the absence of either the horizontal sync signal and/or the vertical sync signal. Upon
detecting the absence of these signals, the monitor screen is blanked, the backlight is turned off, and
the power light is turned amber. When the monitor is in the reduced power state, the monitor will
utilize .5 watts of power. There is a brief warm up period before the monitor will return to its normal
operating mode.
Refer to the computer manual for instructions on setting energy saver features (sometimes called
power management features).
NOTE: The above power saver feature only works when connected to computers that have energy
saver features.
By selecting the settings in the monitor's Energy Saver utility, you can also program the monitor to
enter into the reduced power state at a predetermined time. When the monitor's Energy Saver utility
causes the monitor to enter the reduced power state, the power light blinks amber.
22 Appendix A Technical specifications
B Support and troubleshooting
Solving common problems
The following table lists possible problems, the possible cause of each problem, and the
recommended solutions.
Problem Possible Cause Solution
Screen is blank or video is
flashing.
Video card compatibility. Open the OSD menu and select the Input Control menu.
Image appears blurred,
indistinct, or too dark.
Check Video Cable is
displayed on screen.
Input Signal Out of Range
is displayed on screen.
The monitor is off but it did
not seem to enter into a
low-power sleep mode.
Power cord is disconnected. Connect the power cord.
Power button is turned off. Press the front panel power button.
NOTE: If pressing the power button has no effect, press
and hold the power button for 10 seconds to disable the
power button lockout feature.
Video cable is improperly
connected.
System is in sleep mode. Press any key on the keyboard or move the mouse to
Brightness is too low. Open the OSD menu and select Brightness to adjust the
Monitor video cable is
disconnected.
Video resolution and/or refresh
rate are set higher than what the
monitor supports.
The monitor's power saving control
is disabled.
Connect the video cable properly. See Connecting the
cables on page 8 for more information.
inactivate the screen blanking utility.
Set Auto-Switch Input to Off and manually select the
input.
brightness scale as needed.
Connect the appropriate video signal cable between the
computer and monitor. Be sure that the computer power
is off while connecting the video cable.
Change the settings to a supported setting (see Preset
display resolutions on page 21).
Open the OSD menu and select Power Control > AutoSleep Mode and set auto-sleep to On.
OSD Lockout is displayed. The monitor's OSD Lockout
function is enabled.
Power Button Lockout is
displayed.
The monitor's Power Button
Lockout function is enabled.
Press and hold the Menu button on the front panel for 10
seconds to disable the OSD Lockout function.
Press and hold the power button for 10 seconds to
unlock the power button function.
Solving common problems 23
Using the Auto-Adjustment Function (Analog Input)
When first setting up the monitor, when conducting a Factory Reset of the computer, or whenever you
change the resolution of the monitor, the Auto-Adjustment feature will automatically engage, and
attempt to optimize your screen for you.
You may also optimize the screen performance for the VGA (analog) input at any time by using the
Auto button on the monitor (see your model's user guide for the specific button name) and the auto-
adjustment pattern software utility on the disc provided (select models only).
Do not use this procedure if the monitor is using an input other than VGA. If the monitor is using a
VGA (analog) input, this procedure can correct the following image quality conditions:
Fuzzy or unclear focus
●
Ghosting, streaking or shadowing effects
●
Faint vertical bars
●
Thin, horizontal scrolling lines
●
An off-center picture
●
To use the auto-adjustment feature:
1. Allow the monitor to warm up for 20 minutes before adjusting.
2. Press the Auto button on the monitor front panel.
You can also press the Menu button, then select Image Control > Auto-Adjustment from the
●
OSD Main Menu.
If the result is not satisfactory, continue with the procedure.
●
3. Insert the disc in the disc drive. The disc menu is displayed.
4. Select Open Auto-Adjustment Software. The setup test pattern is displayed.
5. Press the Auto button on the monitor front panel to produce a stable, centered image.
6. Press the ESC key or any other key on the keyboard to exit the test pattern.
NOTE: The auto-adjustment test pattern utility can be downloaded from http://www.hp.com/support.
24 Appendix B Support and troubleshooting
Optimizing Image Performance (Analog Input)
Two controls in the on-screen display can be adjusted to improve image performance: Clock and
Phase (available in the main menu).
NOTE: The Clock and Phase controls are adjustable only when using an analog (VGA) input. These
controls are not adjustable for digital inputs.
The Clock must first be set correctly since the Phase settings are dependent on the main Clock
setting. Use these controls only when the auto-adjustment function does not provide a satisfactory
image.
Clock—Increases/decreases the value to minimize any vertical bars or stripes visible on the
●
screen background.
Phase—Increases/decreases the value to minimize video flickering or blurring.
●
NOTE: When using the controls, you will obtain the best results by using the auto-adjustment
pattern software utility provided on the disc.
When adjusting the Clock and Phase values, if the monitor images become distorted, continue
adjusting the values until the distortion disappears. To restore the factory settings, select Yes from
the Factory Reset menu in the on-screen display.
To eliminate vertical bars (Clock):
1. Press the Menu button on the monitor's front panel to open the OSD Menu, and then select
Image Control > Clock.
2. Press the + (Plus) or – (Minus) buttons on the monitor's front panel to eliminate vertical bars.
Press the buttons slowly so that you do not miss the optimum adjustment point.
3. After adjusting the Clock, if blurring, flickering, or bars appear on the screen, proceed to adjust
the Phase.
To remove flickering or blurring (Phase):
1. Press the Menu button on the monitor's front panel to open the OSD Menu, and then select
Image Control > Phase.
2. Press the + (Plus) or – (Minus) buttons on the monitor's front panel to eliminate flickering or
blurring. Flicking or blurring may not be eliminated depending on your computer or graphics
controller card installed.
To correct screen position (Horizontal Position or Vertical Position):
Optimizing Image Performance (Analog Input) 25
1. Press the Menu button on the monitor's front panel to open the OSD Menu, and then select
Image Control > Horizontal Position and/or Vertical Position.
2. Press the + (Plus) or – (Minus) buttons on the monitor's front panel to properly adjust the
position of the image in the display area of the monitor. The Horizontal Position shifts the image
left or right; the Vertical Position shifts the image up and down.
Button lockouts
Holding down the power button or Menu button for ten seconds will lock out the functionality of that
button. You can restore the functionality by holding the button down again for ten seconds. This
functionality is only available when the display is powered on, displaying an active signal, and the
OSD is not active.
Product support
For additional information on using your monitor, go to http://www.hp.com/support. Select your
country or region, select Troubleshooting, and then enter your model in the search window and click
the Go button.
NOTE: The monitor user guide, reference material, and drivers are available at http://www.hp.com/
support.
If the information provided in the guide does not address your questions, you can contact support. For
U.S. support, go to http://www.hp.com/go/contactHP. For worldwide support, go to
http://welcome.hp.com/country/us/en/wwcontact_us.html.
Here you can:
Chat online with an HP technician
●
NOTE: When support chat is not available in a particular language, it is available in English.
Find support telephone numbers
●
Locate an HP service center
●
26 Appendix B Support and troubleshooting
Preparing to call technical support
If you cannot solve a problem using the troubleshooting tips in this section, you may need to call
technical support. Have the following information available when you call:
Monitor model number
●
Monitor serial number
●
Purchase date on invoice
●
Conditions under which the problem occurred
●
Error messages received
●
Hardware configuration
●
Name and version of the hardware and software you are using
●
Preparing to call technical support 27
C Accessibility
HP designs, produces, and markets products and services that can be used by everyone, including
people with disabilities, either on a stand-alone basis or with appropriate assistive devices.
Supported assistive technologies
HP products support a wide variety of operating system assistive technologies and can be configured
to work with additional assistive technologies. Use the Search feature on your device to locate more
information about assistive features.
NOTE: For additional information about a particular assistive technology product, contact customer
support for that product.
Contacting support
We are constantly refining the accessibility of our products and services and welcome feedback from
users. If you have an issue with a product or would like to tell us about accessibility features that have
helped you, please contact us at (888) 259-5707, Monday through Friday, 6 a.m. to 9 p.m. Mountain
Time. If you are deaf or hard-of-hearing and use TRS/VRS/WebCapTel, contact us if you require
technical support or have accessibility questions by calling (877) 656-7058, Monday through Friday, 6
a.m. to 9 p.m. Mountain Time.
28 Appendix C Accessibility
Loading...
