HP J855 Model Number and Description

H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s M o d e l N u m b e r a n d D e s c r i p t i o n
Model Number and Description
HP DeskJet 855C Series Printers
Printer Name Model Numbers Availability Description
HP DeskJet 855C Printer
HP DeskJet 855Cxi Printer
C4551A US Only Fast black and color personal
printer for professionals.
C4575A US Only Fast black and color personal
printer with additional software bundle for professionals.
C4576A US Only Fast black and color personal
printer with additional bundle for professionals.
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s F r o n t V i e w
Access Door
Resume Button & Light
Print Cartridge Latches
Print Cartridge Cradles
Single Sheet Feeder
IN Tray
Paper Width Adjuster
Paper Length Adjuster
Power Button & Light
Front View
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s R e a r V i e w
Macintosh Interface Port
IEEE-1284 Interface Port (MS DOS/Windows)
Rear View
Note
When looking at the rear, the power plug is on the left side of the printer.
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s O r d e r i n g P r i n t e r O p t i o n s
Ordering Printer Options
Localized Printer Options (HP DeskJet 855C Printer)
User’s
Region or
Country
United States English C4551A ABA 8120-6177 C4551-60201
Documentation
Language
Printer
Option
Numbers
Power
Cable Part
Numbers
User’s
Documentation
Kit Part Numbers
Localized Printer Options (HP DeskJet 855Cse Printer)
User’s
Region or
Country
United States English C4575A ABA 8120-6177 C4551-60201
Documentation
Language
Printer
Option
Numbers
Power
Cable Part
Numbers
User’s
Documentation
Kit Part Numbers
Localized Printer Options (HP DeskJet 855Cxi Printer)
User’s
Region or
Country
United States English C4576A ABA 8120-6177 C4551-60201
Documentation
Language
Printer
Option
Numbers
Power
Cable Part
Numbers
User’s
Documentation
Kit Part Numbers
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s I t e m s I n c l u d e d
Items Included
HP DeskJet 855C
HP DeskJet 855C Printer with power cord User's Guide and DOS Printing Guide Printer software (diskettes) One black and one color print cartridge Media Sample Kit
HP DeskJet 855Cse
HP DeskJet 855Cse Printer with power cord User's Guide, User’s Guide Errata Booklet, and DOS Printing
Guide Printer software (diskettes) One black and one color print cartridge Media Sample Kit Microsoft Publisher (Publisher 95) Version 3.0 (see below) MS Shell (see below) Kodak Promotion (see below)
HP DeskJet 855Cxi
HP DeskJet 855C Series Printer with power cord User's Guide, User’s Guide Errata Booklet, and DOS Printing
Guide Printer software (diskettes) One black and one color print cartridge Media Sample Kit Kodak Promotion (see below) Transparency Kit (see below)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s I t e m s I n c l u d e d
Microsoft Publisher (Publisher 95), Version 3.0 (HP DeskJet 855Cse)
CD ROM for MS Windows 95 (no support for MS Windows 3.1) Support provided by Microsoft
MS Shell (HP DeskJet 855Cse)
Getting started (printer setup, registration, what to do if you need help)
HP Supplies (ink and media information) Install Publisher Using Color (tutorial for using color with Publisher) Template Pack (predesigned brochures, flyers, leterhead, etc. for
use in Publisher. User adds their own text and prints, or modifies the layout if they wish).
MS Product Sampler (MS product info, including MS Office information)
Kodak Promotion (HP DeskJet 855Cse and 855Cxi)
Pre-paid film mailer 5 sheets glossy media 5 sheets premium paper Information packet to explain the promotion and photo contest.
(The customer sends their exposed film to Kodak in the pre-paid mailer, Kodak sends the pictures back on CD-ROM along with Kodak manipulation software. The photo contest may be entered by printing a photo on a DeskJet 855 printer using glossy paper and mailing it to Kodak.)
Transparency Kit (HP DeskJet 855Cxi)
A 20 sheet pack of transperancy films.
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s F o n t s I n c l u d e d
Fonts Included
Scalable TrueType® Fonts For MS Windows
Scalable TrueType® Fonts For Macintosh
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s I n t e r n a l F o n t s
Internal Fonts
All fonts included with the HP DeskJet 855C series printers are scalable fonts. These fonts are available in portrait and landscape orientation. There are no bitmapped fonts installed in the printer.
Internal Fonts (Scalable) Technology Treatment
Courier Intellifont Roman, Bold, Italic, Bold Italic
Letter Gothic Intellifont Roman, Bold, Italic, Bold Italic
CG Times Convergent Roman, Bold, Italic, Bold Italic
Univers Intellifont Text, Bold, Italic, Bold Italic
Times New Roman Convergent Text, Bold, Italic, Bold Italic
Arial Intellifont (TT) Text, Bold, Italic, Bold Italic
Symbol TrueType Symbol
Wingdings TrueType Symbol
Symbol Sets
PC-8 HP Roman-8 Danish/Norwegian (60) PC-8 Danish/Norwegian PC-8 Turkish ANSI/ASCII (06) United Kingdom (04) French (69) German (21) Italian (15) Spanish (17) Swedish (11) PC-850 Multilingual PC-852 Latin 2 ECMA-94 Latin 1 (8859/1) Legal Windows Latin 1 ECMA-94 Latin 2 (8859/2) Windows Latin 2 Windows Latin 5 ECMA-128 Latin 5 (8859/5)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P a r t N u m b e r s
Part Numbers
Item Description Part Number
Interface Cables DOS/MS Windows HP IEEE-1284 Parallel Interface
Cable (2 meter length) DOS/MS Windows HP IEEE-1284 Parallel Interface
Cable (3 meter length) Macintosh RS-422 Serial Cable 92215S Macintosh AppleTalk Network Cable 92215N HP Centronics Parallel Interface Cable C2912B or
Print Cartridges Black Inkjet Print Cartridge 51645A
Color Inkjet Print Cartridge 51641A
Media Premium Transparency Film (U.S. letter, 50 sheets) C3834A
Premium Transparency Film (U.S. letter, 20 sheets) C3828A Premium Transparency Film (European A4, 50 sheets) C3835A Premium Transparency Film (European A4, 20 sheets) C3832A Premium Glossy Paper (U.S. letter, 50 sheets) C3836A Premium Glossy Paper (U.S. letter, 10 sheets) C3833A Premium Glossy Paper (European A4, 50 sheets) C3837A Premium Glossy Paper (European A4, 10 sheets) C3831A Premium InkJet Paper (U.S. letter, 200 sheets) 51634Y Premium InkJet Paper (European A4, 200 sheets) 51634Z
Accessories HP PrinterPal Accessory C2970A
HP SupportPack Contact your local
C2950A
C2951A
HP24542D
dealer
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s U s e r R e p l a c e a b l e C o m p o n e n t s
Service Station Assembly (C2145-67901)
Paper Tray Assembly (C2145-67902)
Access Door (Top Cover) Assembly (C2145-67903)
Base Foot Assembly (4 ea.) (C2162-60098) (Shown below printer)
User Replaceable Components
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s H o s t / S y s t e m R e q u i r e m e n t s
Host/System Requirements
DOS/MS Windows
80386 or faster (MS Windows 3.1), 80286 or faster (DOS) MS Windows 3.1 or MS Windows 95, or later MS DOS, Version 3.3 or later 4 MB RAM
7.5 MB free hard disk space (1.5 MB - printer driver, 6.0 MB - fonts)
Macintosh QuickDraw Operation
System 7.0 or later 68020 16 MHZ or faster processor, 60040 25 Mhz recommended At least 4 MB of RAM, 8 MB recommended At least 10 MB free hard disk space
Macintosh QuickDraw GX Operation
System 7.5 or later 68020 16 MHZ or faster processor, 60040 25 Mhz recommended At least 8 MB RAM, 12 MB recommended At least 10 MB free hard disk space
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s D r i v e r I n s t a l l a t i o n
Driver Installation
For the printer to operate properly, a printer driver must be installed in your computer. Refer to “Printer Driver Information/Installing the Printer Driver” for more detailed information.
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s I n t e r f a c e S p e c i f i c a t i o n s
Interface Specifications
HP DeskJet 855C series printers have two interface connectors to support both DOS and Macintosh computers. The 36-pin Centronics style connector is used with DOS/MS Windows based computers. The 8-pin mini-circular DIN connector is used with Macintosh computers.
Note that only one connector can be active at a time. At power-up, the first connector that senses active incoming data will be the dedicated I/O port. The other connector will remain inactive.
Category DOS I/O Connector Macintosh I/O Connector
Communication Modes Available
Supported Macintosh Protocols
Compatible (standard Centronics) is the default communication mode
Compatible (Centronics) Nibble Byte Extended Capabilities Port
(ECP)
RS-422 Serial (57.6 Kbaud) AppleTalk (230.4 Kbaud) High-Speed Externally-Clocked Serial
Mode
Serial Pacing Protocol (SPP) AppleTalk Transaction Protocol (ATP) AppleTalk Link Access Protocol (ALAP) Datagram Delivery Protocol (DDP) Echo Protocol (EP) Name Binding Protocol (NBP) Printer Access Protocol (PAP) Routing Table Maintenance Protocol
(RTMP)
Printer Memory
Category Specification
Built-In ROM 2 MB Built-In RAM 1 MB
Receive Buffer 32 Kbytes
Note For a complete description of your printer’s interface, see
“Printer Interface Information.”
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
Product Performance Specifications
HP DeskJet 855C series printers print a true 600 DPI dot size. In the Normal mode, 300x300 data is sent which the printer REts to 600x600. This happens very quickly because the conversion uses a hard-coded table to convert to 600x600 rather than an on-the-fly algorithm.
In the Best mode, 600x600 data is sent to the printer and used directly. Although somewhat slower than the Normal mode, this approach produces the highest quality.
In either case, internal fonts are stored as outlines which are rendered directly to 600x600 or 300x300 depending upon print mode.
Print Speed
Print Mode
Best 4 ppm 1 ppm 0.3 ppm Normal 6 ppm 1.5 ppm 0.6 ppm EconoFast 7 ppm 3 ppm 1 ppm
Black Printing (No Graphics)
Color Printing (Mixed
Text and Graphics)
Color Printing
(Full-Page
Graphics)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
Print Modes
Print
Mode
EconoFast 300 x 300
Normal
Best 600 x 600
1. In the Normal mode, a special Text/Lines mode is supported that optimizes performance and quality when only text and lines are present on the page. The printer uses this mode on a page­by-page basis if the following are true:
All text (of any color) is less than 24 pt. All lines (of any color) are less than 4 pt. (including framed objects) There are no more than 75 lines on the page Only lines and text occur on the page.
Plain Paper HP Premium Glossy Paper Transparency
N/A N/A N/A
1 Pass Color 1 Pass Black
1
300x300 Black (REt to 600x600)
300x300 Color (with CREt)
2 Pass Color 1 Pass Black
Black 300 x 300
Color 4 Pass Color
3 Pass Black
300x300 Black (REt to 600x600)
300x300 Color (with CREt)
4 Pass Color 3 Pass Black
600 x 600 Black
300 x 300 Color
8 Pass Color 4 Pass Black
300x300 Black (REt to 600x600)
300x300 Color (with CREt)
4 Pass Color 3 Pass Black
600 x 600 Black
300 x 300 Color
8 Pass Color 4 Pass Black
300x300 Black (REt to 600x600)
300x300 Color (with CREt)
4 Pass Color 3 Pass Black
600 x 600 Black
300 x 300 Color
8 Pass Color 4 Pass Black
DOS Graphics Resolution
75 dpi 150 dpi 300 dpi
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P a p e r H a n d l i n g
Paper Handling
Category Specification
Paper Grain Long Grain Only Paper Weight 16 to 36 lb (60 to 135 g/m2) Envelope Weight 20 to 24 lb (75to 90 g/m2) Card Stock Weight 110 lb Maximum, 8.5 pt Maximum Thickness
(110 to 200 g/m2) IN Tray Capacity 150 Sheets of 20 lb Paper Envelope Feeder Capacity Up to 15 Envelopes OUT Tray Paper Capacity Up to 50 Sheets of 20 lb Paper OUT Tray Envelope Capacity Up to 20 Single Sheet Capacity 1 Sheet at a Time Card Stock Capacity Up to 30 Cards Label Capacity Up to 25 Sheets
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P a p e r H a n d l i n g
Supported Media/Sizes
Media English Size Metric Size
U.S. Letter 8 1/2 in. x 11 in. 215.9 mm x 279.4 mm U.S. Legal 8 1/2 in. x 14 in. 215.9 mm x 355.6 mm U.S. Executive 7 1/4 in. x 10 1/2 in. 184.1 mm x 266.7 mm ISO & JIS A4 8.27 in. x 11.69 in. 210 mm x 297 mm ISO & JIS A5 5.85 in. x 8.27 in. 148.5 mm x 210 mm JIS B5 7.17 in. x 10.12 in. 182 mm x 257 mm U.S. No. 10 Envelope 4 1/8 in. x 9 1/2 in. 104.8 mm x 241.3 mm International DL Envelope 4.33 in. x 8.66 in. 110 mm x 220 mm International C6 Envelope 4.49 in. x 6.38 in. 114 mm x 162 mm U.S. Size Card Stock 4 in. x 6 in. 101.6 mm x 152.4 mm U.S. Size Card Stock 5 in. x 8 in. 127 mm x 203.2 mm ISO & JIS A6 Postcard 4.13 in. x 5.85 in. 105 mm x 148.5 mm Japanese Hagaki Postcard 3.94 in. x 5.83 in. 100 mm x 148 mm Custom Minimum Size 3.94 in. x 5.83 in. 100 mm x 148 mm Custom Maximum Size 8.5 in. x 14 in. 216 mm x 356 mm U.S. Transparency 8 1/2 in. x 11 in. 215.9 mm x 279.4 mm European Transparency 8.27 in. x 11.69 in. 210 mm x 297 mm U.S. glossy 8 1/2 in. x 11 in. 215.9 mm x 279.4 mm European A4 glossy 8.27 in. x 11.69 in. 210 mm x 297 mm Special U.S. 8 1/2 in. x 11 in. 215.9 mm x 279.4 mm Special A4 8.27 in. x 11.69 in. 210 mm x 297 mm U.S. lables 8 1/2 in. x 11 in. 215.9 mm x 279.4 mm European lables 8.27 in. x 11.69 in. 210 mm x 297 mm
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r i n t a b l e A r e a s
Printable Areas
U.S. Paper
Supported Media
Media Media Size Printable Area
U.S. Letter 8.5 in. X 11 in.
(215.9 mm X 279.4 mm)
U.S. Legal 8.5 in. X 14 in.
(215.9 mm X 355.6 mm)
U.S. Executive 7.25 in. X 10.5 in.
(184.1 mm X 266.7 mm)
8.0 in. X 10.50 in. (203.2 mm X 266.7 mm)
8.0 in. X 13.50 in. (203.2 mm X 342.9 mm)
6.75 in. X 10.00 in. (172.5 mm X 254.0 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
U.S. Letter 0.04 in.
(1.0 mm)
U.S. Legal 0.04 in.
(1.0 mm)
U.S. Executive
0.04 in. (1.0 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.25 in. (6.3 mm)
0.25 in. (6.3 mm)
0.25 in. (6.3 mm)
0.25 in. (6.3 mm)
0.25 in. (6.3 mm)
0.25 in. (6.3 mm)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r i n t a b l e A r e a s
A4, A5, B5 Paper
Supported Media
Media Media Size Printable Area
ISO & JIS A4 8.27 in. X 11.69 in.
(210mm X 297 mm)
ISO & JIS A5 5.83 in. X 8.27 in.
(148mm X 210 mm)
JIS B5 7.17 in. X 10.12 in.
(182 mm X 257mm)
8.0 in. X 11.19 in. (203.2 mm X 284.3 mm)
5.57 in. X 7.77 in. (141.6 mm X 197.3 mm)
6.91 in. X 9.62 in. (175.6 mm X 244.3 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
ISO & JIS A4
ISO & JIS A5
JIS B5 0.04 in.
0.04 in. (1.0 mm)
0.04 in. (1.0 mm)
(1.0 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.13 in. (3.44 mm)
0.13 in. (3.44 mm)
0.13 in. (3.44 mm)
0.13 in. (3.44 mm)
0.13 in. (3.44 mm)
0.13 in. (3.44 mm)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r i n t a b l e A r e a s
Card Stock
Supported Media
Media Media Size Printable Area
U.S. Card Stock 4 in. X 6 in.
(101.6 mm X 152.4mm
U.S. Card Stock 5 in. X 8 in.
(127.0 mm X 203.2 mm)
ISO & JIS A6 Cards 4.13 in. X 5.83 in.
(105 mm X 148 mm)
Japanese Hagaki Postcard 3.94 in. X 5.85 in.
(100 mm X 148.5 mm)
3.75 in. X5.50 in.
95.3 mm X 139.7 mm)
4.75 in. 7.50 in. (120.7 mm X 190.5 mm)
3.88 in. X 5.34 in. (98.6 mm X 135.3 mm)
3.69 in. X 5.33 in. (93.6 mm X 135.3 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
U.S. Card Stock 0.04 in.
(1.0 mm)
U.S. Card Stock 0.04 in.
(1.0 mm)
ISO & JIS A6 Cards 0.04 in.
(1.0 mm)
Japanese Hagaki Postcard
0.04 in. (1.0 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.46 in. (11.7 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r i n t a b l e A r e a s
Envelopes
Supported Media
Media Media Size Printable Area
No. 10 Envelope 4.125 in. X 9.5 in.
(104.8 mm X 241.3 mm)
International DL Envelope 4.33 in. X 8.66 in.
(110 mm X 220 mm)
International C6 Envelope 4.49 in. X 6.38 in.
(114 mm X 162 mm)
3.88 in. X 8.59 in. (98.4mm X 218.3 mm)
4.08 in. X 7.76 in. (103.6 mm X 197.0 mm)
4.24 in. X 5.47 in. (107.6 mm X 139.0 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
No. 10 Envelope 0.125 in.
(3.2 mm)
International DL Envelope
International C6 Envelope
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.125 in. (3.2 mm)
0.87 in. (22.0 mm)
0.87 in. (22.0 mm)
0.87 in. (22.0 mm)
0.04 in. (1.0 mm)
0.04 in. (1.0 mm)
0.04 in. (1.0 mm)
Note The bottom margin is the left side (return address side) of the
envelope.
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P r i n t a b l e A r e a s
Custom Page
Minimum Page Size Margins Width Length Top Bottom Left Right
3.94 in. (100 mm)
5.83 in. (148mm)
0.04 in. (1.0 mm)
0.46 in. (11.7 mm)
0.13 in.
(3.44 mm)
0.13 in. (3.44 mm)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P h y s i c a l S p e c i f i c a t i o n s
Physical Specifications
Weight: 6.5 kg (14.3 lb.)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s E l e c t r i c a l S p e c i f i c a t i o n s
Electrical Specifications
Category Specification
Input Voltage 100 VAC-240 VAC ± 10% Frequency 50/60 Hz ± 3 Hz Power consumption 0.25 Watts (Off)
5.25 Watts (Idle) 48 Watts Maximum (Printing)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s E n v i r o n m e n t a l S p e c i f i c a t i o n s
Environmental Specifications
Attributes Specification
Operating temperature Optimum temperature Storage temperature Operating humidity
(noncondensing) Storage humidity
(noncondensing) Noise Levels ISO 9296
Sound Power, LWAd: Sound Pressure, LPAm:
Altitude Operating Nonoperating
Mechanical vibration Frequency range Operating (random) Nonoperating (random) Swept sine
Thermal output 164 BTU/hour (maximum)
1. Bystander position
1
5 °C to 40 °C (41 °F to 104 °F) 15 °C to 35 °C (59 °F to 95 °F)
40 °C to 60 °C (−40 °F to 140 °F) 20% to 80% relative humidity,
maximum wet bulb 35 °C (95 °F) 15% to 80% relative humidity,
maximum wet bulb 60 °C (140 °F) Best Mode EconoFast Mode
6.4 B(A) 6.4 B(A) 51 dB(A) 52 dB(A)
3,048 m (10,000 ft) maximum 4,572 m (15,000 ft) maximum
5 to 500 Hz Approximately 0.21 G rms Approximately 2.09 G rms
0.5 G (0 to peak)
Optimal Operating Conditions
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s S a f e t y a n d E M I S p e c i f i c a t i o n s
Safety and EMI Specifications
Category Specification
Safety certifications
EMI certifications
UL, CSA, ETL, KEMA, TUV, SEMKO, NEMKO, FIMKO, DEMKO, NOM
USA: FCC Part 15, Class B, when used with a Class B computing Device Japan: VCCI Class 2
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s R e l i a b i l i t y S p e c i f i c a t i o n s
Reliability Specifications
Category Specification
Printer usage rate 1,000 Pages per Month (Black)
160 Pages per Month (Color)
Mean time between failures (MTBF)
Mechanism life 60,000 Pages
20,000 hours (2,000 hours Power On and 12,000 Printed Pages per Year)
H P D e s k J e t 8 5 5 C S e r i e s P r i n t e r s P a c k a g i n g S p e c i f i c a t i o n s
Packaging Specifications
Weight: 8.432 kg (18.59 lb.)
Loading...
