H P D e s k J e t 8 5 0 C P r i n t e r M o d e l N u m b e r a n d D e s c r i p t i o n
Model Number and Description
HP DeskJet 850C Printer
Printer Name Model Number Status Description
HP DeskJet 850C
Printer
1. All printers except C2145A ABJ (Japan) are discontinued
C2145A Available
worldwide
Fast black and color personal
1
printer for professionals
H P D e s k J e t 8 5 0 C P r i n t e r F r o n t V i e w
Front View
Access Door
Resume Button & Light
Print Cartridge Latches
Print Cartridge Cradles
Single Sheet Feeder
IN Tray
Paper Width Adjuster
Paper Length Adjuster
Power Button & Light
2145001
H P D e s k J e t 8 5 0 C P r i n t e r R e a r V i e w
Rear View
IEEE-1284 Interface Port (MS
DOS/Windows)
Macintosh Interface
Port
Note
When looking at the rear, the power plug is on the left side of
the printer.
H P D e s k J e t 8 5 0 C P r i n t e r O r d e r i n g P r i n t e r O p t i o n s
Ordering Printer Options
Localized Printer Options (850C5)
User’s
Region or
Country
Argentina Spanish C2145A AC8 8120-6175 C2145-60215
Asia English C2145A ARS 8120-6173 C2145-60201
Asia, North English C2145A ART 8120-6174 C2145-60201
Australia English C2145A ABG 8120-6175 C2145-60201
Brazil Portuguese C2145A AC4 8120-6177 C2145-60214
Canada English/French C2145A ABC 8120-6177 C2145-60207
Caribbean English C2145A ARV 8120-6174 C2145-60200
Czechoslovakia Czech. C2145A AKB 8120-6174 C2145-60203
Denmark Danish/English C2145A ABY 8120-6178 C2145-60204
Europe-Dutch Dutch C2145A ACU 8120-6174 C2145-60205
Europe-English English C2145A ABB 8120-6174 C2145-60201
Europe-French French C2145A ACS 8120-6174 C2145-60207
Europe-German German C2145A ACT 8120-6174 C2145-60208
Europe-Italian Italian C2145A ARP 8120-6174 C2145-60210
Finland Finnish/English C2145A ABX 8120-6174 C2145-60206
Greece English C2145A AR2 8120-6174 C2145-60201
Hong Kong English C2145A AB5 8120-6173 C2145-60201
Hungary Hungarian C2145A AKC 8120-6174 C2145-60209
India English C2145A ACJ 8120-6180 C2145-60201
Israel English C2145A AKJ 8120-5181 C2145-60201
Japan Japanese C2145A ABJ 8120-6176 C2145-60211
Jordan Arabic/English C2145A ARW 8120-6174 C2145-60202
Latin America Spanish C2145A ABM 8120-6177 C2145-60215
Middle East Arabic/English C2145A ARU 8120-6173 C2145-60202
Norway Norwegian/
Poland Polish C2145A AKD 8120-6174 C2145-60213
Portugal Portuguese C2145A AB9 8120-6174 C2145-60214
Russia English C2145A AR3 8120-6174 C2145-60201
Continued on next page
Documentation
Language
English
Printer
Option
Numbers
C2145A ABN 8120-6174 C2145-60212
1
Power
Cable Part
Numbers
User’s
Documentation
Kit Part Numbers
H P D e s k J e t 8 5 0 C P r i n t e r O r d e r i n g P r i n t e r O p t i o n s
Localized Printer Options (850C5)(Cont.)
User’s
Region or
Country
Saudi Arabia Arabic/English C2145A ARG 8120-6177 C2145-60202
Sinapore English C2145A AB4 8120-6173 C2145-60201
South Africa English C2145A ACQ 8120-6180 C2145-60201
South America Spanish C2145A AKV 8120-6174 C2145-60215
Spain Spanish C2145A ABE 8120-6174 C2145-60215
Sweden Swedish C2145A ABS 8120-6174 C2145-60216
Switzerland-
English
Switzerland-
French
Switzerland-
German
Switzerland-
Italian
Taiwan Chinese/English C2145A AB0 8120-6177 C2145-60217
U.S. English C2145A ABA 8120-6177 C4551-60201
United Kingdom English C2145A ABU 8120-6173 C2145-60201
1. Macintosh, v 9.01
2. MS Windows (English)
3. PC98, v 9.0 (Japanese)
4. DOS V, v 9.0 (Japanese)
5. All HP DeskJet 850C printers except C2145A ABJ are discontinued
Documentation
Language
English C2145A ACD 8120-6179 C2145-60201
French C2145A ABQ 8120-6179 C2145-60207
German C2145A ABP 8120-6179 C2145-60208
Italian C2145A ACN 8120-6179 C2145-60210
Printer
Option
Numbers
1
Power
Cable Part
Numbers
User’s
Documentation
Kit Part Numbers
H P D e s k J e t 8 5 0 C P r i n t e r I t e m s I n c l u d e d
Items Included
HP DeskJet 850C Printer
Power cord
User's Guide
Printer software (diskettes)
One black print cartridge
One color print cartridge
MediaSample Kit
DOS Printing Guide
H P D e s k J e t 8 5 0 C P r i n t e r F o n t s I n c l u d e d
Fonts Included
Scalable TrueType Fonts For MS Windows
Scalable TrueType Fonts For Macintosh
H P D e s k J e t 8 5 0 C P r i n t e r I n t e r n a l F o n t s
Internal Fonts
All of the fonts included with the HP DeskJet 850C Printer are scalable
fonts. These fonts are available in Portrait and Landscape orientation.
There are no bitmapped fonts installed in the printer.
Internal Fonts (Scalable) Technology Treatment
Courier Intellifont Roman, Bold, Italic, Bold Italic
Letter Gothic Intellifont Roman, Bold, Italic, Bold Italic
CG Times Convergent Roman, Bold, Italic, Bold Italic
Univers Intellifont Text, Bold, Italic, Bold Italic
Times New Roman Convergent Text, Bold, Italic, Bold Italic
Arial Intellifont (TT) Text, Bold, Italic, Bold Italic
Symbol TrueType Symbol
Wingdings TrueType Symbol
Symbol Sets
PC-8 HP Roman-8 Danish/Norwegian (60)
PC-8 Danish/Norwegian PC-8 Turkish ANSI/ASCII (06)
United Kingdom (04) French (69) German (21)
Italian (15) Spanish (17) Swedish (11)
PC-850 Multilingual PC-852 Latin 2 ECMA-94 Latin 1 (8859/1)
Legal Windows Latin 1 ECMA-94 Latin 2 (8859/2)
Windows Latin 2 Windows Latin 5 ECMA-128 Latin 5 (8859/5)
H P D e s k J e t 8 5 0 C P r i n t e r I n t e r n a l F o n t s
Additional Fonts in Region Specific Printers
Additional fonts and symbol sets are available in region specific printers
such as: Hebrew, Arabic, and Greek. These fonts and symbol sets are
added to the existing ones, and no other fonts are removed.
Identifying Printers with Flash Memory
With Flash Memory
Without Flash Memory
To identify a printer with flash memory, look for the lightning bolt symbol
on the serial number label located on the back of the printer. The flash
font code found directly below the lightning bolt can be used to identify the
language of fonts downloaded into flash memory.
H P D e s k J e t 8 5 0 C P r i n t e r I n t e r n a l F o n t s
Use the following tables to identify the fonts and symbol set(s) loaded into
flash memory.
Fonts and Symbol Sets for Flash Codes
Flash
Codes
ARB Arabic Jordan C2145A ARW
ARB Arabic Middle East C2145A ARU
ARB Arabic Saudi Arabia C2145A ARG
CYR Cyrillic Russia C2145A AR3
GRK Greek Greece C2145A AB7
HBR Hebrew Israel C2145A AKJ
Name of Font and
Symbol Set
Country or
Region
Printer
Model
H P D e s k J e t 8 5 0 C P r i n t e r I n t e r n a l F o n t s
Arabic (Flash Font Code ARB)
Spacing Font Name Treatments
Koufi
2
1,2
1,2
Regular and Bold
Regular and Bold
Regular and Bold
2
Proportional Ryadh
Fixed Naskh
Symbol Sets: HP Arabic-8 (available in fixed-space fonts only)1, PC Arabic (CP-864)
Cyrillic (Flash Font Code CYR)
Spacing Font Name Treatments
Proportional CG Times
Univers
Fixed Courier
Letter Gothic
Symbol Sets: PC Cyrillic (CP-886)1, Latin/Cyrillic (ISO-8859/5)(available in fixed-space fonts only)
1
1
1,2
1,2
Regular, Bold, Italic and Bold Italic
Regular, Bold, Italic and Bold Italic
Regular, Bold, Italic and Bold Italic
Regular, Bold, Italic and Bold Italic
2
Hebrew (Flash Font Code HBR)
Spacing Font Name Treatments
Proportional David PS
Narkis Tam
Miyram PS
Fixed Courier
Miyram
2
2
2
1,2
1,2
Regular and Bold
Regular and Bold
Regular, Bold and Italic
Regular, Bold and Italic
Regular, Bold and Italic
Symbol Sets: Latin Hebrew (ISO-8859/8) (available in fixed-space fonts only)1, PC Hebrew (CP-862)
Greek (Flash Font Code GRK)
Spacing Font Name Treatments
Proportional CG Tirnes
Univers
Fixed Courier
Letter Gothic
Symbol Sets: PC-8 Greek1, Latin/Greek (ISO-8859/7) (Available in fixed-space fonts only)
1
1
1,2
1,2
Regular, Bold, Italic and Bold Italic
Regular, Bold, Italic and Bold Italic
Regular, Bold, Italic and Bold Italic
Regular, Bold, Italic and Bold Italic
2
2
H P D e s k J e t 8 5 0 C P r i n t e r P a r t N u m b e r s
Part Numbers
Item Description Part Number
Interface Cables DOS/MS Windows HP IEEE-1284 Parallel Interface
Cable (2 meter length)
DOS/MS Windows HP IEEE-1284 Parallel Interface
Cable (3 meter length)
Macintosh RS-422 Serial Cable 92215S
Macintosh AppleTalk Network Cable 92215N
HP Centronics Parallel Interface Cable C2912B or
Print Cartridges Black Inkjet Print Cartridge 51645A
Color Inkjet Print Cartridge 51641A
Media Premium Transparency Film (U.S. letter, 50 sheets) C3834A
Premium Transparency Film (U.S. letter, 20 sheets) C3828A
Premium Transparency Film (European A4, 50 sheets) C3835A
Premium Transparency Film (European A4, 20 sheets) C3832A
Premium Glossy Paper (U.S. letter, 50 sheets) C3836A
Premium Glossy Paper (U.S. letter, 10 sheets) C3833A
Premium Glossy Paper (European A4, 50 sheets) C3837A
Premium Glossy Paper (European A4, 10 sheets) C3831A
Premium InkJet Paper (U.S. letter, 200 sheets) 51634Y
Premium InkJet Paper (European A4, 200 sheets) 51634Z
Accessories HP PrinterPal Accessory C2970A
HP SupportPack Contact your local
C2950A
C2951A
HP24542D
dealer
H P D e s k J e t 8 5 0 C P r i n t e r U s e r R e p l a c e a b l e C o m p o n e n t s
User Replaceable Components
Access Door (Top Cover) Assembly (C2145-67903)
Base Foot Assembly (4 ea.)
(C2162-60098) (Shown below
printer)
Paper Tray Assembly (C2145-67902)
Service Station Assembly (C2145-67901)
H P D e s k J e t 8 5 0 C P r i n t e r H o s t / S y s t e m R e q u i r e m e n t s
Host/System Requirements
DOS/MS Windows
80386 or faster (MS Windows), 80286 or faster (DOS)
MS Windows 3.1 or later
MS DOS, Version 3.3 or later
4 MB RAM
7.5 MB free hard disk space (1.5 MB - printer driver, 6.0 MB - fonts)
VGA monitor (minimum)
Macintosh QuickDraw Operation
System 7.0 or later
68020 16 MHZ or faster processor, 60040 25 Mhz recommended
At least 4 MB of RAM, 8 MB recommended
At least 10 MB free hard disk space
Macintosh QuickDraw GX Operation
System 7.5 or later
68020 16 MHZ or faster processor, 60040 25 Mhz recommended
At least 8 MB RAM, 12 MB recommended
At least 10 MB free hard disk space
H P D e s k J e t 8 5 0 C P r i n t e r D r i v e r I n s t a l l a t i o n
Driver Installation
For the printer to operate properly, a printer driver must be installed in your
computer. Refer to “Printer Driver Information/Installing the Printer Driver”
for more detailed information.
H P D e s k J e t 8 5 0 C P r i n t e r I n t e r f a c e S p e c i f i c a t i o n s
Interface Specifications
The HP DeskJet 850C Printer has two interface connectors to support both
DOS and Macintosh computers. The 36-pin Centronics style connector is
used with DOS/MS Windows based computers. The 8-pin mini-circular
DIN connector is used with Macintosh computers.
Note that only one connector can be active at a time. At power-up, the first
connector that senses active incoming data will be the dedicated I/O port.
The other connector will remain inactive.
Category DOS I/O Connector Macintosh I/O Connector
Communication Modes
Available
Supported Macintosh
Protocols
Compatible (standard Centronics) is the default communication mode
Compatible (Centronics)
Nibble
Byte
Extended Capabilities Port
(ECP)
RS-422 Serial (57.6 Kbaud)
AppleTalk (230.4 Kbaud)
High-Speed Externally-Clocked Serial
Mode
Serial Pacing Protocol (SPP)
AppleTalk Transaction Protocol (ATP)
AppleTalk Link Access Protocol (ALAP)
Datagram Delivery Protocol (DDP)
Echo Protocol (EP)
Name Binding Protocol (NBP)
Printer Access Protocol (PAP)
Routing Table Maintenance Protocol
(RTMP)
Printer Memory
Category Specification
Built-In ROM 2 MB
Built-In RAM 1 MB
Receive Buffer 32 Kbytes
Note For a complete description of your printer’s interface, see
“Printer Interface Information.”
H P D e s k J e t 8 5 0 C P r i n t e r P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
Product Performance Specifications
The HP DeskJet 850C prints a true 600 DPI dot size. In the Normal mode,
300x300 data is sent which the printer REts to 600x600. This happens
very quickly because the conversion uses a hard-coded table to convert to
600x600 rather than an on-the-fly algorithm.
In the Best mode, 600x600 data is sent to the printer and used directly.
Although somewhat slower than the Normal mode, this approach
produces the highest quality.
In either case, internal fonts are stored as outlines which are rendered
directly to 600x600 or 300x300 depending upon print mode.
Print Speed
Print
Mode
Best 4 ppm 1 ppm 0.3 ppm
Normal 6 ppm 1.5 ppm 0.6 ppm
EconoFast 6 ppm 2 ppm 1 ppm
Black Printing
(No Graphics)
Color Printing (Mixed
Text and Graphics)
Color Printing
(Full-Page
Graphics)
H P D e s k J e t 8 5 0 C P r i n t e r P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
Print Modes
Print
Mode
EconoFast 300 x 300
Normal
Best 600 x 600
1. In the Normal mode, a special Text/Lines mode is supported that optimizes performance and
quality when only text and lines are present on the page. The printer uses this mode on a pageby-page basis if the following are true:
All text (of any color) is less than 24 pt.
All lines (of any color) are less than 4 pt. (including framed objects)
There are no more than 75 lines on the page
Only lines and text occur on the page.
Plain Paper HP Premium Glossy Paper Transparency
N/A N/A N/A
1 Pass Color
1 Pass Black
1
300x300
Black (REt to
600x600)
300x300
Color (with CREt)
2 Pass Color
1 Pass Black
Black
300 x 300
Color
4 Pass Color
3 Pass Black
300x300
Black (REt to
600x600)
300x300
Color (with CREt)
4 Pass Color
3 Pass Black
600 x 600
Black
300 x 300
Color
8 Pass Color
4 Pass Black
300x300
Black (REt to
600x600)
300x300
Color (with CREt)
4 Pass Color
3 Pass Black
600 x 600
Black
300 x 300
Color
8 Pass Color
4 Pass Black
300x300
Black (REt to
600x600)
300x300
Color (with CREt)
4 Pass Color
3 Pass Black
600 x 600
Black
300 x 300
Color
8 Pass Color
4 Pass Black
DOS Graphics Resolution
75 dpi
150 dpi
300 dpi
H P D e s k J e t 8 5 0 C P r i n t e r P a p e r H a n d l i n g
Paper Handling
Category Specification
Paper Grain Long Grain Only
Paper Weight 16 to 36 lb (60 to 135 g/m2)
Envelope Weight 20 to 24 lb (75to 90 g/m2)
Card Stock Weight 110 lb Maximum, 8.5 pt Maximum Thickness
(110 to 200 g/m
IN Tray Capacity 150 Sheets of 20 lb Paper
Envelope Feeder Capacity Up to 15 Envelopes
OUT Tray Paper Capacity Up to 50 Sheets of 20 lb Paper
OUT Tray Envelope Capacity Up to 20
Single Sheet Capacity 1 Sheet at a Time
Card Stock Capacity Up to 30 Cards
Label Capacity Up to 25 Sheets
2
)
Supported Media/Sizes
Media English Size Metric Size
U.S. Letter 8 1/2 in. x 11 in. 215.9 mm x 279.4 mm
U.S. Legal 8 1/2 in. x 14 in. 215.9 mm x 355.6 mm
U.S. Executive 7 1/4 in. x 10 1/2 in. 184.1 mm x 266.7 mm
ISO & JIS A4 8.27 in. x 11.69 in. 210 mm x 297 mm
ISO & JIS A5 5.85 in. x 8.27 in. 148.5 mm x 210 mm
JIS B5 7.17 in. x 10.12 in. 182 mm x 257 mm
U.S. No. 10 Envelope 4 1/8 in. x 9 1/2 in. 104.8 mm x 241.3 mm
International DL Envelope 4.33 in. x 8.66 in. 110 mm x 220 mm
International C6 Envelope 4.49 in. x 6.38 in. 114 mm x 162 mm
U.S. Size Card Stock 4 in. x 6 in. 101.6 mm x 152.4 mm
U.S. Size Card Stock 5 in. x 8 in. 127 mm x 203.2 mm
ISO & JIS A6 Postcard 4.13 in. x 5.85 in. 105 mm x 148.5 mm
Japanese Hagaki Postcard 3.94 in. x 5.83 in. 100 mm x 148 mm
Custom Minimum Size 3.94 in. x 5.83 in. 100 mm x 148 mm
H P D e s k J e t 8 5 0 C P r i n t e r P r i n t a b l e A r e a s
Printable Areas
U.S. Paper
Supported Media
Media Media Size Printable Area
U.S. Letter 8.5 in. X 11 in.
(215.9 mm X 279.4 mm)
U.S. Legal 8.5 in. X 14 in.
(215.9 mm X 355.6 mm)
U.S. Executive 7.25 in. X 10.5 in.
(184.1 mm X 266.7 mm)
8.0 in. X 10.50 in.
(203.2 mm X 266.7 mm)
8.0 in. X 13.50 in.
(203.2 mm X 342.9 mm)
6.75 in. X 10.00 in.
(172.5 mm X 254.0 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
U.S. Letter 0.04 in.
(1.0 mm)
U.S. Legal 0.04 in.
(1.0 mm)
U.S.
Executive
0.04 in.
(1.0 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.25 in.
(6.3 mm)
0.25 in.
(6.3 mm)
0.25 in.
(6.3 mm)
0.25 in.
(6.3 mm)
0.25 in.
(6.3 mm)
0.25 in.
(6.3 mm)
H P D e s k J e t 8 5 0 C P r i n t e r P r i n t a b l e A r e a s
A4, A5, B5 Paper
Supported Media
Media Media Size Printable Area
ISO & JIS A4 8.27 in. X 11.69 in.
(210mm X 297 mm)
ISO & JIS A5 5.83 in. X 8.27 in.
(148mm X 210 mm)
JIS B5 7.17 in. X 10.12 in.
(182 mm X 257mm)
8.0 in. X 11.19 in.
(203.2 mm X 284.3 mm)
5.57 in. X 7.77 in.
(141.6 mm X 197.3 mm)
6.91 in. X 9.62 in.
(175.6 mm X 244.3 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
ISO &
JIS A4
ISO &
JIS A5
JIS B5 0.04 in.
0.04 in.
(1.0 mm)
0.04 in.
(1.0 mm)
(1.0 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.13 in.
(3.44 mm)
0.13 in.
(3.44 mm)
0.13 in.
(3.44 mm)
0.13 in.
(3.44 mm)
0.13 in.
(3.44 mm)
0.13 in.
(3.44 mm)
H P D e s k J e t 8 5 0 C P r i n t e r P r i n t a b l e A r e a s
Card Stock
Supported Media
Media Media Size Printable Area
U.S. Card Stock 4 in. X 6 in.
(101.6 mm X 152.4mm
U.S. Card Stock 5 in. X 8 in.
(127.0 mm X 203.2 mm)
ISO & JIS A6 Cards 4.13 in. X 5.83 in.
(105 mm X 148 mm)
Japanese Hagaki Postcard 3.94 in. X 5.85 in.
(100 mm X 148.5 mm)
3.75 in. X5.50 in.
95.3 mm X 139.7 mm)
4.75 in. 7.50 in.
(120.7 mm X 190.5 mm)
3.88 in. X 5.34 in.
(98.6 mm X 135.3 mm)
3.69 in. X 5.33 in.
(93.6 mm X 135.3 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
U.S. Card Stock 0.04 in.
(1.0 mm)
U.S. Card Stock 0.04 in.
(1.0 mm)
ISO & JIS A6 Cards 0.04 in.
(1.0 mm)
Japanese
Hagaki Postcard
0.04 in.
(1.0 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.46 in.
(11.7 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
H P D e s k J e t 8 5 0 C P r i n t e r P r i n t a b l e A r e a s
Envelopes
Supported Media
Media Media Size Printable Area
No. 10 Envelope 4.125 in. X 9.5 in.
(104.8 mm X 241.3 mm)
International DL Envelope 4.33 in. X 8.66 in.
(110 mm X 220 mm)
International C6 Envelope 4.49 in. X 6.38 in.
(114 mm X 162 mm)
3.88 in. X 8.59 in.
(98.4mm X 218.3 mm)
4.08 in. X 7.76 in.
(103.6 mm X 197.0 mm)
4.24 in. X 5.47 in.
(107.6 mm X 139.0 mm)
Margins (Portrait Orientation)
Media Top Bottom Left Right
No. 10 Envelope 0.125 in.
(3.2 mm)
International
DL Envelope
International
C6 Envelope
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.125 in.
(3.2 mm)
0.87 in.
(22.0 mm)
0.87 in.
(22.0 mm)
0.87 in.
(22.0 mm)
0.04 in.
(1.0 mm)
0.04 in.
(1.0 mm)
0.04 in.
(1.0 mm)
Note The bottom margin is the left side (return address side) of the
envelope.
H P D e s k J e t 8 5 0 C P r i n t e r P r i n t a b l e A r e a s
Custom Page
Minimum Page Size Margins
Width Length Top Bottom Left Right
3.94 in.
(100 mm)
5.83 in.
(148mm)
0.04 in.
(1.0 mm)
0.46 in.
(11.7 mm)
0.13 in.
(3.44 mm)
0.13 in.
(3.44 mm)
H P D e s k J e t 8 5 0 C P r i n t e r P h y s i c a l S p e c i f i c a t i o n s
Physical Specifications
Weight: 6.5 kg (14.3 lb.)
H P D e s k J e t 8 5 0 C P r i n t e r E l e c t r i c a l S p e c i f i c a t i o n s
Electrical Specifications
Category Specification
Input Voltage 100 VAC-240 VAC ± 10%
Frequency 50/60 Hz ± 3 Hz
Power consumption 0.25 Watts (Off)
5.25 Watts (Idle)
48 Watts Maximum (Printing)
H P D e s k J e t 8 5 0 C P r i n t e r E n v i r o n m e n t a l S p e c i f i c a t i o n s
Environmental Specifications
Attributes Specification
Operating temperature 5 ∞ C to 40 ∞ C (41 ∞ F to 104 ∞ F)
Optimum temperature 15 ∞ C to 35 ∞ C (59 ∞ F to 95 ∞ F)
Storage temperature -40 ∞ C to 60 ∞ C (-40 ∞ F to 140 ∞ F)
Operating humidity
(noncondensing)
Storage humidity
(noncondensing)
Am:
P
1
Noise Levels ISO 9296
Sound Power, LWAd:
Sound Pressure, L
Altitude
Operating
Nonoperating
Mechanical vibration
Frequency range
Operating (random)
Nonoperating (random)
Swept sine
Thermal output 164 BTU/hour (maximum)
1. Bystander position
15% to 80% relative humidity,
maximum wet bulb 35 ∞ C (95 ∞ F)
15% to 80% relative humidity,
maximum wet bulb 60 ∞ C (140 ∞ F)
Best Mode EconoFast Mode
6.4 B(A) 6.4 B(A)
51 dB(A) 52 dB(A)
3,048 m (10,000 ft) maximum
4,572 m (15,000 ft) maximum
5 to 500 Hz
Approximately 0.21 G rms
Approximately 2.09 G rms
0.5 G (0 to peak)
Optimal Operating Conditions
H P D e s k J e t 8 5 0 C P r i n t e r S a f e t y a n d E M I S p e c i f i c a t i o n s
Safety and EMI Specifications
Category Specification
Safety
certifications
EMI
certifications
UL, CSA, ETL, KEMA, TUV, SEMKO, NEMKO, FIMKO, DEMKO, NOM
USA: FCC Part 15, Class B, when used with a Class B computing Device
Japan: VCCI Class 2
H P D e s k J e t 8 5 0 C P r i n t e r R e l i a b i l i t y S p e c i f i c a t i o n s
Reliability Specifications
Category Specification
Printer usage rate 1,000 Pages per Month (Black)
160 Pages per Month (Color)
Mean time between failures
(MTBF)
Mechanism life 60,000 Pages
20,000 hours
(2,000 hours Power On and 12,000 Printed Pages per Year)
H P D e s k J e t 8 5 0 C P r i n t e r P a c k a g i n g S p e c i f i c a t i o n s
Packaging Specifications
Weight: 8.432 kg (18.59 lb.)
Loading...
