Europe (Dutch)DutchC2184A ACU9100-5132C2184-60206
Europe (English)EnglishC2184A ABB9100-5132C2184-60202
Europe (French)FrenchC2184A ACS9100-5132C2184-60208
Europe (German)GermanC2184A ACT9100-5132C2184-60209
Europe (Italian)ItalianC2184A ARP9100-5132C2184-60212
1. For additional information on power modules, see “Power Module Information.”
Documentation
Language
Chinese/EnglishC2184A AB29100-5129C2184-60222
Printer
Option
Numbers
Power
Module Part
Numbers
1
User’s
Documentation
Kit Part Numbers
H P D e s k J e t 6 0 0 P r i n t e r O r d e r i n g P r i n t e r O p t i o n s
Available Power Modules
Region or CountryPower RequirementsPower Module Part Number
Argentina220V/50 Hz9100-5129 (C2179A)
Australia240V/50 Hz9100-5127 (C2181A)
Brazil, Philippines220V/50 Hz9100-5391
Canada120V/60 Hz9100-5124 (C2175A)
Caribbean220V/50 Hz9100-5346
China220V/50 Hz9100-5129 (C2179A)
Europe (Except U.K.)230V/50 Hz9100-5132 (C2176A)
Hong Kong220V/50 Hz9100-5348
Japan100V/50/60 Hz9100-5130 (C2178A)
Korea220V/60 Hz9100-5126 (C2182A)
Mexico120V/60 Hz9100-5124 (C2175A)
South Africa220V/50 Hz9100-5128 (C2180A)
U. K.240V/50 Hz9100-5131 (C2177A)
U. S.120V/60 Hz9100-5124 (C2175A)
H P D e s k J e t 6 0 0 P r i n t e r I t e m s I n c l u d e d
Items Included
HP DeskJet 600 Printer
Power Module
User's Guide
Printer software
on diskette
One black print cartridge
H P D e s k J e t 6 0 0 P r i n t e r F o n t s I n c l u d e d
Fonts Included
Scalable TrueType® Fonts For MS Windows
H P D e s k J e t 6 0 0 P r i n t e r I n t e r n a l F o n t s a n d S y m b o l S e t s
Internal Fonts and Symbol Sets
Symbol Sets
PC-8 Danish/Norwegian (60) PC-8 Danish/Norwegian
PC-8 Turkish ANSI/ASCII (06) United Kingdom (04)
French (69) German (21) Italian (15)
Spanish (17) Swedish (11) PC-850
PC-852 ECMA-94 Latin 1 (8859/1) Legal
Latin 2 (8859/2) Latin 5 (8859/9)
H P D e s k J e t 6 0 0 P r i n t e r I n t e r n a l F o n t s a n d S y m b o l S e t s
Additional Fonts in Region Specific Printers
Some HP DeskJet 600 printers contain flash memory. Flash memory
provides the capability to install fonts and symbol sets for specific regions.
The following figure shows how to identify printers with flash memory by
observing the serial number label on the back of the printer.
Identifying Printers with Flash Memory
With Flash Memory
No Flash Memory
To identify a printer with flash memory, look for the lightning bolt symbol on
the serial number label located on the back of the printer. The flash font
code found directly below the lightning bolt can be used to identify the
language of fonts downloaded into flash memory. Use the following tables
to identify the fonts and symbol set(s) loaded into flash memory.
H P D e s k J e t 6 0 0 P r i n t e r I n t e r n a l F o n t s a n d S y m b o l S e t s
Flash Fonts Information
Fonts and Symbol Sets for Flash Codes
Name of Font and
Flash Codes
THAThaiThailandC2184A AB3
Symbol SetCountry/RegionPrinter Model
Flash Fonts and Symbol Sets
Thai (Flash Font Code THA)
SpacingFont NamePoint SizesPitches
FixedThai Courier1012
1210
246
Thai Courier Bold1012
1210
246
Thai Courier Italic1012
1210
246
Thai Courier Bold Italic1210
Thai Line Printer8.516
Symbol Set: TIS (TAPIC23)
NoteTAPIC23 is the registration name for Hewlett-Packard’s Thai
HP DeskJet symbol set.
H P D e s k J e t 6 0 0 P r i n t e r P a r t N u m b e r s
Part Numbers
ItemDescriptionPart Number
Color Kits
Interface CablesHP IEEE-1284 Parallel Interface Cable (2 meter length)C2950A
MediaPremium Transparency Film (U.S. letter, 50 sheets)C3834A
1. For color kit information, see “Color Kit Information.”
1
Contains color print cartridge and storage garage. The
color print cartridge replaces the black cartridge to allow
color printing.
U.S.
Europe
Asia
Japan, Inter-America
HP IEEE-1284 Parallel Interface Cable (3 meter length)C2951A
HP Centronics Parallel Interface CableC2912B or
Color Inkjet Print Cartridge51649A
Premium Transparency Film (U.S. letter, 20 sheets)C3828A
Premium Transparency Film (European A4, 50 sheets)C3835A
Premium Transparency Film (European A4, 20 sheets)C3832A
Premium Glossy Paper (U.S. letter, 50 sheets)C3836A
Premium Glossy Paper (U.S. letter, 10 sheets)C3833A
Premium Glossy Paper (European A4, 50 sheets)C3837A
Premium Glossy Paper (European A4, 10 sheets)C3831A
Premium InkJet Paper (U.S. letter, 200 sheets)51634Y
Premium InkJet Paper (European A4, 200 sheets)51634Z
C4533A
C4534A
C4535A
C4536A
HP24542D
H P D e s k J e t 6 0 0 P r i n t e r C o l o r K i t I n f o r m a t i o n
Color Kit Information
Color Kit
The optional Color Kit which includes a color print cartridge and a print
cartridge storage container, provides color output printing capability from
an HP DeskJet 600 printer. The printer comes from the factory as color
capable, it does not require any modifications. Color features, however,
need to be turned on in the printer driver dialog box in MS Windows. For
more information, refer to the HP DeskJet 600 printer user documentation
or to the information included with the Color Kit.
NotesThe print cartridge storage container will hold one black or
one color print cartridge. To obtain maximum print quality and
print cartridge life, always store the open print cartridge that is
not in the printer in the print cartridge storage container.
When printing a color page with the color print cartridge, you
cannot print true black. The printer will print composite black,
made up of cyan, magenta, and yellow inks.
H P D e s k J e t 6 0 0 P r i n t e r U s e r R e p l a c e a b l e C o m p o n e n t s
User Replaceable Components
Access Door
Base Foot
Paper Tray
DescriptionPart Number
Access Door (Top Cover) AssemblyC2164-67816
Base Foot AssemblyC2162-60098
Paper Tray AssemblyC2164-67807
H P D e s k J e t 6 0 0 P r i n t e r H o s t / S y s t e m R e q u i r e m e n t s
Host/System Requirements
MS Windows
MS Windows 3.1 or later
80386 or faster processor
At least 2 MB of RAM to print in black or at least 4 MB of RAM to
print in color
At least 10 MB free hard disk space
DOS
DOS, Version 3.3 or later
80286 or faster processor
At least 2 MB of RAM to print in black or at least 4 MB of RAM to
print in color
H P D e s k J e t 6 0 0 P r i n t e r D r i v e r I n s t a l l a t i o n
Driver Installation
For the printer to operate properly, a printer driver must be installed in your
computer. Refer to “Printer Driver Information/Installing the Printer Driver”
for more detailed information.
H P D e s k J e t 6 0 0 P r i n t e r I n t e r f a c e S p e c i f i c a t i o n s
Interface Specifications
CategorySpecification
InterfaceIEEE-1284 Compatible
Communication Modes AvailableCompatible (Centronics)
NoteFor a complete description of your printer’s interface, see
“Printer Interface Information.”
H P D e s k J e t 6 0 0 P r i n t e r P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
Product Performance Specifications
The HP DeskJet 600 prints a 600x300 dot size. Dots are placed on a
600x300 grid. Depletion is used to remove approximately 10% of the dots
to prevent laying too much ink on the page.
In the Best mode, the paper advances at 600 DPI increments and places
dots on a true 600x600 grid. Depletion in the Best mode removes
approximately 43% of the dots.
To conserve memory, DOS fonts are stored at 300x300. REt is used to
convert them to 600x300.
When printing from MS Windows, resolution determinations are made in
the PC and then sent to the printer.
MS Windows Print Speed
EconoFast ModeNormal ModeBest Mode
Black Print Speed 14 pages per minute2.5 pages per minute1 page per minute
Color Print Speed 11.0 minutes per page2.0 minutes per page4 minutes per page
1. Approximate figures. Exact speed will vary depending upon the system configuration, software
program, and document complexity.
MS DOS Print Speed (Black Mechanism)
EconoFast ModeNormal Mode
Black Print Speed
1. Approximate figures. Exact speed will vary depending upon the system configuration, software
program, and document complexity.
1
270 CPS at 10 CPI134 CPS at 10 CPI
Resolution
EconoFast ModeNormal ModeBest Mode
Black Resolution
MS Windows
(text and graphics)
DOS (text only)300 x 300 DPI600 x 300 DPI600 x 600 DPI
Color Resolution
Plain & Premium Papers300 x 300 DPI300 x 300 DPI300 x 300 DPI
Glossy Paper and
Transparency Film
(black and color)
DOS (graphics)Full-page 75, 150,
300 x 300 DPI600 x 300 DPI600 x 600 DPI
N/A600 x 300 DPI600 x 300 DPI
300 DPI
Full-page 75, 150,
300 DPI
Full-page 75, 150,
300 DPI
H P D e s k J e t 6 0 0 P r i n t e r P r o d u c t P e r f o r m a n c e S p e c i f i c a t i o n s
NoteDPI is measured in addressable raster points per inch.
H P D e s k J e t 6 0 0 P r i n t e r P a p e r H a n d l i n g S p e c i f i c a t i o n s
Paper Handling Specifications
CategorySpecification
Paper GrainLong Grain Only
Paper60 to 135 g/m2 (16 to 36 lb.)
Envelopes75 to 90 g/m2 (20 to 24 lb.)
Cards110 to 200 g/m2 (29 to 53 lb., 61 to 110 lb. index
max.; 8.5 pt max thickness)
2
Labels
IN Tray CapacityUp to 100 Sheets (<1/2 in.)
OUT Tray CapacityUp to 50 Sheets
Multiple Envelopes
Card CapacityUp to 30 Cards
1. Envelope capacity is dependent upon the manufacturer, the type of envelope and its
construction.
2. Use only U.S. letter or A4 size sheets. Use only Avery paper labels specifically designed for use
with HP InkJet Printers.
1
Up to 25 Sheets of Avery Paper Labels
Up to 20 Envelopes (<1/2 in.)
NoteThe HP DeskJet 600 Printer works well with most types of
paper although variables in paper composition may affect
print quality and paper handling. Bond paper, such as
letterhead, gives excellent quality. Paper should be tested to
ensure best performance.
H P D e s k J e t 6 0 0 P r i n t e r P a p e r H a n d l i n g S p e c i f i c a t i o n s
Supported Media/Sizes
CategorySpecification
US Letter215.9 x 279.4 mm (8.5 x 11 in.)
US Legal215.9 x 355.6 mm (8.5 x 14 in.)
U.S. Executive184.1 x 266.7 mm ( 7.25 x 10.5 in.)
ISO & JIS A4210 x 297 mm (8.27 x 11.69 in.)
ISO & JIS A5148.5 x 210 mm (5.83 x 8.27 in.)
ISO & JIS B5182 x 257 mm (7.17 x 10.12 in.)
U.S. No. 10 Envelope
U.S. A2 Envelope (5.5)111 x 146 mm (4.375 x 5.75 in.)
European DL Envelope
European C6 Envelope
U.S. 4 x 6 Card101.6 x 152.4 mm (4 x 6 in.)
U.S. 5 x 8 Card127 x 203.2 mm (5 x 8 in.)
European A6 Card105 x 148.5 mm (4.13 x 5.83 in.)
Japanese Hagaki Postcard100 x 148 mm (3.94 x 5.83 in.)
Custom Size (user defined)
Width127 to 216 mm (5 to 8.5 in.)
Length148 to 356 mm (5.83 to 14 in.)
1. To minimize print skew, use envelopes with rectangular flaps rather than triangular flaps.
1
1
1
104.7 x 241.3 mm (4.12 x 9.5 in.)
110 x 220 mm (4.33 x 8.66 in.)
114 x 162 mm (4.49 x 6.38 in.)
H P D e s k J e t 6 0 0 P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
Printable Area Specifications
U.S. Paper and Transparency
DOS Black Printing
Page SizeTop Margin
U.S. Executive
184.1 x 266.7 mm
(7.25 x 10.5 in.)
U.S. Letter
215.9 x 279.4 mm
(8.5 x 11 in.)
U.S. Legal
215.9 x 355.6 mm
(8.5 x 14 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
DOS Color Printing
Page SizeTop Margin
U.S. Executive
184.1 x 266.7 mm
(7.25 x 10.5 in.)
U.S. Letter
215.9 x 279.4 mm
(8.5 x 11 in.)
U.S. Legal
215.9 x 355.6 mm
(8.5 x 14 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
Bottom
Margin
11.7 mm
(0.46 in.)
11.7 mm
(0.46 in.)
11.7 mm
(0.46 in.)
Bottom
Margin
14.9 mm
(0.59 in.)
14.9 mm
(0.59 in.)
14.9 mm
(0.59 in.)
Left and Right
MarginsPrintable Area
6.3 mm
(0.25 in.)
6.3 mm
(0.25 in.)
6.3 mm
(0.25 in.)
Left and Right
MarginsPrintable Area
6.3 mm
(0.25 in.)
6.3 mm
(0.25 in.)
6.3 mm
(0.25 in.)
171.5 mm x 255.0 mm
(6.75 x 10.04 in.)
203.2 mm x 267.7 mm
(8.00 x 10.54 in.)
203.2 mm x 343.9 mm
(8.00 x 13.54 in.)
171.5 mm x 251.7 mm
(6.75 x 10.04 in.)
203.2 mm x 264.4 mm
(8.00 x 10.41 in.)
203.2 mm x 340.6 mm
(8.00 x 13.41 in.)
H P D e s k J e t 6 0 0 P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
International Paper and Transparency
DOS Black Printing
Page SizeTop Margin
International
A4
210 x 297 mm
(8.27 x 11.69 in.)
International
A5
148.5 x 210 mm
(6.00 x 8.27 in.)
International
B5
182 x 257 mm
(7.17 x 10.12 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
DOS Color Printing
Page SizeTop Margin
International
A4
210 x 297 mm
(8.27 x 11.69 in.)
International
A5
148.5 x 210 mm
(6.00 x 8.27 in.)
International
B5
182 x 257 mm
(7.17 x 10.12 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
Bottom
Margin
11.7 mm
(0.46 in.)
18.0 mm
(0.71 in.)
11.7 mm
(0.46 in.)
Bottom
Margin
14.9 mm
(0.59 in.)
21.3 mm
(0.84 in.)
14.9 mm
(0.59 in.)
Left and Right
MarginsPrintable Area
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
4.2 mm
(0.17 in.)
Left and Right
MarginsPrintable Area
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
4.2 mm
(0.17 in.)
203.2 mm x 285.3 mm
(8.00 x 11.23 in.)
141.6 mm x 192.0 mm
(5.58 x 7.56 in.)
173.6 mm x 245.4 mm
(6.83 x 9.66 in.)
203.2 mm x 282.0 mm
(8.00 x 11.10 in.)
141.6 mm x 188.7 mm
(5.58 x 7.43 in.)
173.6 mm x 242.1 mm
(6.83 x 9.53 in.)
H P D e s k J e t 6 0 0 P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
Envelopes
DOS Black Printing
Top & Bottom
Envelope Size
U.S. #10
Envelope
104.7 x 241.3 mm
(4.12 x 9.5 in.)
International DL
110 x 220 mm
(4.33 x 8.66 in.)
International C6
114 x 162 mm
(4.49 x 6.38 in.)
MarginsLeft MarginRight Margin Printable Area
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
18.0 mm
(0.71 in.)
18.0 mm
(0.71 in.)
18.0 mm
(0.71 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
98.4 mm x 223.3 mm
(3.88 x 8.79 in.)
103.6 mm x 201.9 mm
(4.08 x 7.95 in.)
107.6 mm x 144.0 mm
(4.24 x 5.67 in.)
DOS Color Printing
Top & Bottom
Envelope Size
U.S. #10
Envelope
104.7 x 241.3 mm
(4.12 x 9.5 in.)
International DL
110 x 220 mm
(4.33 x 8.66 in.)
International C6
114 x 162 mm
(4.49 x 6.38 in.)
MarginsLeft MarginRight Margin Printable Area
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
21.3 mm
(0.84 in.)
21.3 mm
(0.84 in.)
21.3 mm
(0.84 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
98.4 mm x 220.0 mm
(3.88 x 8.66 in.)
103.6 mm x 198.6 mm
(4.08 x 7.82 in.)
107.6 mm x 140.7mm
(4.24 x 5.54 in.)
H P D e s k J e t 6 0 0 P r i n t e r P r i n t a b l e A r e a S p e c i f i c a t i o n s
Cards
DOS Black Printing
Card SizeTop Margin
U.S. 4 x 6
101.6 x 152.4 mm
(4 x 6 in.)
U.S. 5 x 8
127 x 203.2 mm
(5 x 8 in.)
International A6
105 mm x 148.5 mm
(4.13 x 6.00 in.)
Japanese Hagaki
Postcard
100 mm x 148 mm
(3.94 x 5.83 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
DOS Color Printing
Card SizeTop Margin
U.S. 4 x 6
101.6 x 152.4 mm
(4 x 6 in.)
U.S. 5 x 8
127 x 203.2 mm
(5 x 8 in.)
International A6
105 mm x 148.5 mm
(4.13 x 6.00 in.)
Japanese Hagaki
Postcard
100 mm x 148 mm
(3.94 x 5.83 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
0.0 mm
(0.0 in.)
Bottom
Margin
18.0 mm
(0.71 in.)
18.0 mm
(0.71 in.)
18.0 mm
(0.71 in.)
18.0 mm
(0.71 in.)
Bottom
Margin
21.3 mm
(0.84 in.)
21.3 mm
(0.84 in.)
21.3 mm
(0.84 in.)
21.3 mm
(0.84 in.)
Left and Right
MarginsPrintable Area
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
4.2 mm
(0.17 in.)
Left and Right
MarginsPrintable Area
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
3.2 mm
(0.13 in.)
4.2 mm
(0.17 in.)
95.2 x 134.4 mm
(3.75 x 5.29 in.)
120.6 x 185.2 mm
(4.75 x 7.29 in.)
98.6 mm x 130.0 mm
(3.88 x 5.12 in.)
91.6 mm x 130.0 mm
(3.60 x 5.12 in.)
.
95.2 x 131.6 mm
(3.75 x 5.16 in.)
120.6 x 181.9 mm
(4.75 x 7.16 in.)
98.6 mm x 126.7 mm
(3.88 x 4.99 in.)
91.6 mm x 130.0 mm
(3.60 x 4.99 in.)
H P D e s k J e t 6 0 0 P r i n t e r P h y s i c a l S p e c i f i c a t i o n s
Physical Specifications
Weight: 5.3 Kg (11.6 lb.)
H P D e s k J e t 6 0 0 P r i n t e r E l e c t r i c a l S p e c i f i c a t i o n s
H P D e s k J e t 6 0 0 P r i n t e r R e l i a b i l i t y S p e c i f i c a t i o n s
Reliability Specifications
CategorySpecification
Mechanism Life60,000 pages
Mean Time Between Failures (MTBF)20,000 hours
Printer Usage Rate
Power On Per Year2,000 hours
Printed Pages Per Year12,000 pages
Black Pages Per Month1,000 pages total maximum
Color Pages Per Month160 pages total maximum
H P D e s k J e t 6 0 0 P r i n t e r P a c k a g i n g S p e c i f i c a t i o n s
Packaging Specifications
Weight = 8.137 kg (17.94 lb.)
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
