HP G60-Intel Schematics

5

4

3

2

1

SYSTEM DC/DC

HBU16-1.2 Intel UMA Block Diagram

Intel CPU

D D

C C

SD/MMC MS/MS Pro/xD

25

RJ45 CONN

B B

RJ11 CONN

27

28

LINE OUT

MIC IN

INTERNAL MIC

A A

2CH SPEAKER

5

Clock Generator

ICS9LPRS355

DDRII 667/800

Slot 0

Slot 1

Realtek

RTS5159

Realtek

RTL8103T

10/100

AMOM

MODEM

CX20548-11Z

HD AUDIO CODEC

CX20583-11Z

16

Penryn SV

3,4,5

FSB 800/1066MHz

DDRII 667/800 Channel A

12

DDR II 667/800 Channel B

13

USB 2.0

25

PCIE

23

HD AUDIO

28

http://laptop-motherboard-schematic.blogspot.com/

4

Cantiga-GM/GL

AGTL+ CPU I/F INTEGRATED GRAHPICS LVDS, CRT I/F

DMIx4

12 USB 2.0/1.1 ports

High Definition Audio

PCIE+USB 2.0

Mini-Card

802.11a/b/g/n

DDR I/F

6,7,8,9,10,11

C-LINK

INTEL

ICH9-M

(10/100/1000Mb)ETHERNET

4 SATA ports 6 PCIE ports

ACPI 1.1 LPC I/F

PCI/PCI BRIDGE

17,18,19,20,21

SPI

Flash ROM

64KB

26 31 30 24

19

3

Project code : 91.4FQ01.001 PCB P/N : 09233 Revision : 1

14

CRT

1600X1200@75

LCD

WXGA+

HDMI

29

2

15

26

WEBCAM

BLUETOOTH

USB x 3

HDD

ODD

Thermal & Fan

GMT G7921

SPI

Flash ROM

2MB

RGB CRT

LVDS(Dual Channel)

PCIE

USB 2.0

SATA

LPC Bus

WINBOND

WPCE773L

Touch PAD

30

KBC

Int. KB

SYSTEM DC/DC

APL5912

15

22

OUTPUTS

+1.5VS

40

Block Diagram

HBU16 1.2

INPUTS

+1.8V

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

TPS51125

INPUTS

DCBATOUT

OUTPUTS

+5VALW

+3VALW

+3VL

SYSTEM DC/DC

TPS51116

INPUTS

DCBATOUT

OUTPUTS

+0.9VS

+1.8V

SYSTEM DC/DC

RT8209

INPUTS

+5VALW

OUTPUTS

+1.05V

MAXIM CHARGER

MAX8731

INPUTS

OUTPUTS

BT+

DCBATOUT

18V 3.0A

5V 100mA

CPU DC/DC

ISL6269CCRZ

INPUTS

DCBATOUT

OUTPUTS

+VCC_CORE

0.844~1.3V 22A

35,36

PCB LAYER

L1:

Signal 1

GND

L2:

Signal 2

L3:

Signal 3

L4:

VCC

L5:

Signal 4

L6:

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

141Monday, July 06, 2009

of

1

of

37

38

39

33

1

ICH9M Functional Strap Definitions ICH9 Integrated pull-up

A

ICH9 EDS 642879 Rev.1.5

Signal

HDA_SDOUT

4 4

HDA_SYNC PCIE config1 bit0,

GNT2#/ GPIO53

GPIO20 Reserved.

GNT1#/ GPIO51

GNT3#/ GPIO55

GNT0#: SPI_CS1#/ GPIO58

3 3

SPI_MOSI Integrated TPM Enable,

GPIO49 DMI Termination

SATALED# PCI Express Lane

SPKR

TP3

GPIO33/ HDA_DOCK _EN#

2 2

Usage/When Sampled

XOR Chain Entrance/ PCIE Port Config1 bit1, Rising Edge of PWROK.

Rising Edge of PWROK.

PCIE config2 bit2, Rising Edge of PWROK.

ESI Strap (Server Only) Rising Edge of PWROK.

Top-Block Swap override. Rising Edge of PWROK.

Boot BIOS Destination Selection 0:1. Rising Edge of PWROK.

Rising Edge of CLPWROK.

Voltage. Rising Edge of CLPWROK.

Reversal. Rising Edge of PWROK.

No Reboot. Rising Edge of PWROK.

XOR Chain Entrance. Rising Edge of PWROK.

Flash Descriptor Security Override Strap. Rising Edge of PWROK.

Allows entrance to XOR Chain testing when TP3

Comment

pulled low. When TP3 not pulled low at rising edge of PWROK, sets bit1 of RPC.PC (Cofig Registers: offset 224h). This signal has weak internal pull-down.

This signal has a weak internal pull-down. Sets bit0 of PRC.PC (Config Registers: Offset 224h).

This signal has a weak internal pull-up. Sets bit2 of PRC.PC2 (Config Registers: Offset 224h).

This signal should not be pulled high.

ESI compatible mode is for server platforms only. This signal should not be pulled low for desktop and mobile.

Sampled low: Top-Block Swap mode (inverts A16 for all cycles targeting FWH BIOS space). Note: Software will not be able to clear the Top-Swap bit until the system is rebooted without GNT3# being pulled down.

Controllable via Boot BIOS Destination bit (Config Registers: Offset 3410h:bit 11:10). GNT0# is MSB, 01-SPI, 10-PCI, 11-LPC

Sample low: the Integrated TPM will be disable. Sample high: the MCH TPM enable strap is sampled low and the TPM Disable bit is clear, the Integrated TPM will be enable.

The signal is required to be low for desktop applications and required to be high for mobile applications.

Signal has weak internal pull-up. Sets bit 27 of MPC.LR (Device 28: Function 0:Offset D8).

If sampled high, the system is strapped to the "No Reboot" mode (ICH9 will disable the TCO Timer system reboot feature). The status is readable via the NO REBOOT bit.

This signal should not be pull low unless using XOR Chain testing.

Sampled low: the Flash Descriptor Security will be overridden. If high, the security measures will be in effect. This should only be enabled in manufacturing environments using an external pull-up resister.

B

page 92

and pull-down Resistors

C

ICH9 EDS 642879 Rev.1.5 Montevina Platform Design guide 22339 0.5

SIGNAL Resistor Type/Value

CL_CLK[1:0]

CL_DATA[1:0]

CL_RST0#

DPRSLPVR/GPIO16

ENERGY_DETECT

HDA_BIT_CLK

HDA_DOCK_EN#/GPIO33

HDA_RST#

HDA_SDIN[3:0]

HDA_SDOUT

HDA_SYNC

GLAN_DOCK#

GNT[3:0]#/GPIO[55,53,51]

GPIO20

GPIO49

LDA[3:0]#/FHW[3:0]#

LAN_RXD[2:0]

LDRQ[0]

LDRQ[1]/GPIO23

PME#

PWRBTN#

SATALED#

SPI_CS1#/GPIO58/CLGPIO6

SPI_MOSI

SPI_MISO

SPKR

TACH_[3:0]

TP[3]

USB[11:0][P,N]

PULL-UP 20K

PULL-DOWN 20K

PULL-UP 20K

PULL-DOWN 20K

PULL-UP 20K

PULL-DOWN 20K

The pull-up or pull-down active when configured for native GLAN_DOCK# functionality and determined by LAN controller.

PULL-UP 20K

PULL-DOWN 20K

PULL-UP 20K

PULL-UP 15K

PULL-UP 20K

PULL-DOWN 20K

PULL-UP 20K

PULL-DOWN 20K

PULL-UP 20K

PULL-DOWN 15K

SMBus

Cantiga chipset and ICH9M I/O controller

D

E

Hub strapping configuration

page 218

Pin Name

CFG[2:0] FSB Frequency Select 000 = FSB1067

CFG[4:3] CFG8 CFG[15:14] CFG[18:17]

CFG5 DMI x2 Select 0 = DMI x2

CFG6 iTPM Host Interface

CFG7 Intel Management

CFG9

CFG10 PCIE Loopback enable 0 = Enable (Note 3)

CFG[13:12] XOR/ALL

CFG16 FSB Dynamic ODT 0 = Dynamic ODT Disabled

CFG19 DMI Lane Reversal

CFG20 Digital Display Port

SDVO _CTRLDATA

L_DDC_DATA Local Flat Panel (LFP)

NOTE:

1. All strap signals are sampled with respect to the leading edge of the (G)MCH Power OK (PWROK) signal.

2. iTPM can be disabled by a 'Soft-Strap' option in the Flash-decriptor section of the Firmware. This 'Soft-Strap' is activated only after enabling iTPM via CFG6. Only one of the CFG10/CFG12/CFG13 straps can be enabled at any time.

Strap Description Configuration

011 = FSB667 010 = FSB800

Reserved

engine crypto strap

PCIE Graphics Lane 0 = Reserved Lanes, 15->0, 14->1 ect..

(SDVO/DP/iHDMI) Concurrent with PCIe

SDVO Present

Present

others = Reserved

1 = DMI x4 (Default)

0 = The iTPM Host Interface is enabled (Note 2)

1 = The iTPM Host Interface is disabled (default)

0 = Transport Layer Security (TLS) cipher

suite with no confidentiality

1 = TLS cipher suite with confidentiality(Default)

1 = Normal operation (Default): Lane Numbered in

Order

1 = Disable (Default)

00 = Reserve 10 = XOR mode Enabled 01 = ALLZ mode Enable (Note 3)

11 = Disabled (Default)

1 = Dynamic ODT Enabled (Default)

0 = Normal operation (Default): Lane Numbered in

Order

1 = Reverse Lanes DMI x4 mode [MCH->ICH]: (3->0, 2->1, 1->2 and 0->3) DMI x2 mode [MCH->ICH]: (3->0, 2->1)

0 = Only Digital Display Port or PCIE is

operational (Default)

1 = Digital display Port and PCIe are operating

simulataneously via the PEG port

0 = No SDVO Card Present (Default)

1 = SDVO Card Present

0 = LFP Disabled (Default)

1 = LFP Card Present; PCIE disabled

page 19 page 19

LANE1

LANE2

LAN

MiniCard WLAN

1 1

A

USB TablePCIE Routing

Pair Device

0 1 2 3 4 5 6 7 8 9 10 11

USB3 FREE External USB3 FREE External USB2 FREE WLAN BLUETOOTH CARD_READER FREE CAMERA FREE

USB

KBC

ICH9M

Thermal

BATTERY

MINI

Clock Generator

http://laptop-motherboard-schematic.blogspot.com/

B

C

D

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

Table of Content

HBU16 1.2

241Tuesday, June 30, 2009

of

E

1

D D

A

C C

TEST7

B B

5

H_A#[35..3]6

H_ADSTB#06 H_REQ#[4..0]6

H_ADSTB#16

H_A20M#18

H_FERR#18

H_IGNNE#18

H_STPCLK#18

H_INTR18 H_NMI18 H_SMI#18

H_A#[35..3]

1 OF 4

U54A

H_A#3 H_A#4 H_A#5 H_A#6 H_A#7 H_A#8 H_A#9 H_A#10 H_A#11 H_A#12 H_A#13 H_A#14 H_A#15 H_A#16

H_REQ#0 H_REQ#1 H_REQ#2 H_REQ#3 H_REQ#4

H_A#17 H_A#18 H_A#19 H_A#20 H_A#21 H_A#22 H_A#23 H_A#24 H_A#25 H_A#26 H_A#27 H_A#28 H_A#29 H_A#30 H_A#31 H_A#32 H_A#33 H_A#34 H_A#35

RSVD_CPU_1

TP4TPAD14-GP TP4TPAD14-GP

1

RSVD_CPU_2

TP6TPAD14-GP TP6TPAD14-GP

1

RSVD_CPU_3

TP8TPAD14-GP TP8TPAD14-GP

1

RSVD_CPU_4

TP7TPAD14-GP TP7TPAD14-GP

1

RSVD_CPU_5

TP9TPAD14-GP TP9TPAD14-GP

1

RSVD_CPU_6

TP10TPAD14-GP TP10TPAD14-GP

1

RSVD_CPU_7

TP15TPAD14-GP TP15TPAD14-GP

1

RSVD_CPU_8

TP1TPAD14-GP TP1TPAD14-GP

1

RSVD_CPU_9

TP14TPAD14-GP TP14TPAD14-GP

1

RSVD_CPU_10

TP5TPAD14-GP TP5TPAD14-GP

1

RSVD_CPU_11

TP13TPAD14-GP TP13TPAD14-GP

1

U54A

J4

A3#

L5

A4#

L4

A5#

K5

A6#

M3

A7#

N2

A8#

J1

A9#

N3

A10#

P5

A11#

P2

A12#

L2

A13#

P4

A14#

P1

A15#

R1

A16#

M1

ADSTB0#

K3

REQ0#

H2

REQ1#

K2

REQ2#

J3

REQ3#

L1

REQ4#

Y2

A17#

U5

A18#

R3

A19#

W6

A20#

U4

A21#

Y5

A22#

U1

A23#

R4

A24#

T5

A25#

T3

A26#

W2

A27#

W5

A28#

Y4

A29#

U2

A30#

V4

A31#

W3

A32#

AA4

A33#

AB2

A34#

AA3

A35#

V1

ADSTB1#

A6

A20M#

A5

FERR#

C4

IGNNE#

D5

STPCLK#

C6

LINT0

B4

LINT1

A3

SMI#

M4

RSVD#M4

N5

RSVD#N5

T2

RSVD#T2

V3

RSVD#V3

B2

RSVD#B2

C3

RSVD#C3

D2

RSVD#D2

D22

RSVD#D22

D3

RSVD#D3

F6

RSVD#F6

B1

KEY_NC

BGA479-SKT6-GPU7

ADDR GROUP 0

ADDR GROUP 1

XDP/ITP SIGNALS CONTROL

XDP/ITP SIGNALS CONTROL THERMAL

THERMAL

PROCHOT#

ICH

THERMTRIP#

HCLK

RESERVED

ADS# BNR# BPRI#

DEFER#

DRDY#

DBSY#

BR0#

IERR#

INIT#

LOCK#

RESET#

RS0# RS1# RS2#

TRDY#

HIT#

HITM#

BPM0# BPM1# BPM2# BPM3# PRDY# PREQ#

TCK TDO

TMS

TRST#

DBR#

THRMDA THRMDC

BCLK0 BCLK1

TDI

1st: 62.10079.001 2nd: 62.10053.401

XDP_DBRESET#_R

XDP_TDI XDP_TMS XDP_TDO XDP_BPM#5

1 2

R66 54D9R2F-L1-GPR66 54D9R2F-L1-GP

1 2

R63 54D9R2F-L1-GPR63 54D9R2F-L1-GP

1 2

R65 54D9R2F-L1-GPR65 54D9R2F-L1-GP

1 2

R64 54D9R2F-L1-GPR64 54D9R2F-L1-GP

1 2

H1 E2 G5

H5 F21 E1

F1 D20

B3 H4 C1

F3 F4 G3 G2

G6 E4

AD4 AD3 AD1 AC4 AC2 AC1 AC5 AA6 AB3 AB5 AB6 C20

D21 A24 B25

C7

A22 A21

R287

1KR2J-1-GP

4

56R2J-4-GP

CPU_IERR#

H_RS#0 H_RS#1 H_RS#2

XDP_BPM#0 XDP_BPM#1 XDP_BPM#2 XDP_BPM#3 XDP_BPM#4 XDP_BPM#5

XDP_TCK

XDP_TDI

XDP_TDO XDP_TMS XDP_TRST# XDP_DBRESET#_R

PM_THRMTRIP# should connect to ICH9 and MCH without T-ing

( No stub)

H_ADS# 6 H_BNR# 6

H_BPRI# 6

H_DEFER# 6 H_DRDY# 6 H_DBSY# 6

H_BREQ#0 6

1 2

H_INIT# 18 H_LOCK# 6

H_TRDY# 6 H_HIT# 6

H_HITM# 6

R32

+1.05VS

H_CPURST# H_RS#[2..0] 6

1 2

R31 68R2-GPR31 68R2-GP

PM_THRMTRIP-A# 7,18

CLK_CPU_BCLK 16 CLK_CPU_BCLK# 16

+3VS

+1.05VS

3

Reserve for ITP, when install ITP connector, install R69.

+1.05VS

12

R69

R69 51R2F-2-GP

51R2F-2-GP

DY

H_CPURST# 6

H_THERMDA, H_THERMDC routing together, Trace width / Spacing = 10 / 10 mil

CPU_PROCHOT#_R 35

+1.05VS

H_THERMDA 24 H_THERMDC 24

C472

C472 SCD47U16V2ZY-GP

SCD47U16V2ZY-GP

2

1

DY

+1.05VS

DY

1 2

R292 1KR2J-1-GP

CLK_CPU_XDP#16

R292 1KR2J-1-GP

H_RESET#_RH_CPURST#

+1.05VS

12

0R2J-2-GP

XDP_TMS

R293

DY

ITP_VDD

2

ITP Connector

ITP1

29 30

1

2 3 5 7 9

11 13 15 17 19 21 23 25 27

31 32

MLX-CONN28A-4-GP

DY

XDP_DBRESET#_R XDP_DBRESET#

4

XDP_BPM#0

6

XDP_BPM#1

8

XDP_BPM#2

10

XDP_BPM#3

12

XDP_BPM#4

14

XDP_BPM#5

16

XDP_TCK

18

20

XDP_TDO_R

22

XDP_TCK

24

XDP_TRST#

26

XDP_TDI

28

R277

1 2

DY

1 2

DY

+1.05VS

0R2J-2-GP

1 2

DY

1 2

DY

1 2

DY

R281 0R2J-2-GP

R284 0R2J-2-GP

R284 0R2J-2-GP R283 0R2J-2-GP

R283 0R2J-2-GP R282 0R2J-2-GP

R282 0R2J-2-GP

XDP_TDO

1

XDP_DBRESET# 19 MCH_CLKSEL2 7,16

MCH_CLKSEL1 7,16 MCH_CLKSEL0 7,16

CLK_CPU_XDP 16

A

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

XDP_TRST# XDP_TCK

5

R71 54D9R2F-L1-GPR71 54D9R2F-L1-GP

1 2

R72 54D9R2F-L1-GPR72 54D9R2F-L1-GP

1 2

http://laptop-motherboard-schematic.blogspot.com/

4

3

2

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

CPU (1 of 2)

HBU16 1.2

1

341Thursday, July 09, 2009

1

of

5

A

D D

C C

Layout notes Z= 55 Ohm 0.5" MAX for GTLREF

+1.05VS

1KR2F-3-GP

1KR2F-3-GP R19

R19

1 2 12

R18

2KR2F-3-GP

B B

1 2

DY

R26 1KR2J-1-GP

1 2

DY

R228 1KR2J-1-GP

DY

CPU_BSEL016 CPU_BSEL116 CPU_BSEL216

TEST1

TEST2

12

H_DSTBN#06 H_DSTBP#06 H_DINV#06

H_DSTBN#16 H_DSTBP#16 H_DINV#16

CPU_GTLREF0

C46

SC1KP50V2KX-1GP

R25

1KR2J-1-GP

DY

1 2

4

2 OF 4

U54B

H_D#0

E22

H_D#1 H_D#2 H_D#3 H_D#4 H_D#5 H_D#6 H_D#7 H_D#8

H_D#9 H_D#10 H_D#11 H_D#12 H_D#13 H_D#14 H_D#15

H_D#16 H_D#17 H_D#18 H_D#19 H_D#20 H_D#21 H_D#22 H_D#23 H_D#24 H_D#25 H_D#26 H_D#27 H_D#28 H_D#29 H_D#30 H_D#31

TEST1 TEST2

CPU_TEST3

CPU_TEST5

R70

1KR2J-1-GP

DY

1 2

Route the TEST3 and TEST5 signals through

a ground referenced Zo = 55-ohm trace

that ends in a via that is near a GND via

and is accessible through an oscilloscope connection.

D0#

F24

D1#

E26

D2#

G22

D3#

F23

D4#

G25

D5#

E25

D6#

E23

D7#

K24

D8#

G24

D9#

J24

D10#

J23

D11#

H22

D12#

F26

D13#

K22

D14#

H23

D15#

J26

DSTBN0#

H26

DSTBP0#

H25

DINV0#

N22

D16#

K25

D17#

P26

D18#

R23

D19#

L23

D20#

M24

D21#

L22

D22#

M23

D23#

P25

D24#

P23

D25#

P22

D26#

T24

D27#

R24

D28#

L25

D29#

T25

D30#

N25

D31#

L26

DSTBN1#

M26

DSTBP1#

N24

DINV1#

AD26

GTLREF

C23

TEST1

D25

TEST2

C24

TEST3

AF26

TEST4

AF1

TEST5

A26

TEST6

B22

BSEL0

B23

BSEL1

C21

BSEL2

BGA479-SKT6-GPU7

MISC

DATA GRP0 DATA GRP1

DATA GRP2DATA GRP3

DSTBN2# DSTBP2#

DINV2#

DSTBN3# DSTBP3#

DINV3# COMP0

COMP1 COMP2 COMP3

DPRSTP#

DPSLP#

DPWR#

PWRGOOD

D32# D33# D34# D35# D36# D37# D38# D39# D40# D41# D42# D43# D44# D45# D46# D47#

D48# D49# D50# D51# D52# D53# D54# D55# D56# D57# D58# D59# D60# D61# D62# D63#

SLP#

PSI#

Y22 AB24 V24 V26 V23 T22 U25 U23 Y25 W22 Y23 W24 W25 AA23 AA24 AB25 Y26 AA26 U22

AE24 AD24 AA21 AB22 AB21 AC26 AD20 AE22 AF23 AC25 AE21 AD21 AC22 AD23 AF22 AC23 AE25 AF24 AC20

R26 U26 AA1 Y1

E5 B5 D24 D6 D7 AE6

H_D#32 H_D#33 H_D#34 H_D#35 H_D#36 H_D#37 H_D#38 H_D#39 H_D#40 H_D#41 H_D#42 H_D#43 H_D#44 H_D#45 H_D#46 H_D#47

H_D#48 H_D#49 H_D#50 H_D#51 H_D#52 H_D#53 H_D#54 H_D#55 H_D#56 H_D#57 H_D#58 H_D#59 H_D#60 H_D#61 H_D#62 H_D#63

COMP0

R23 27D4R2F-L1-GPR23 27D4R2F-L1-GP

COMP1

R24 54D9R2F-L1-GPR24 54D9R2F-L1-GP

COMP2

R67 27D4R2F-L1-GPR67 27D4R2F-L1-GP

COMP3

R68 54D9R2F-L1-GPR68 54D9R2F-L1-GP

H_DSTBN#2 6 H_DSTBP#2 6 H_DINV#2 6

H_DSTBN#3 6 H_DSTBP#3 6 H_DINV#3 6

1 2 1 2 1 2 1 2

H_DPRSTP# 7,18,35 H_DPSLP# 18 H_DPWR# 6 H_PWRGD 18 H_CPUSLP# 6 PSI# 35

Connect to V Core

3

H_DINV#[3..0] H_DSTBN#[3..0] H_DSTBP#[3..0] H_D#[63..0]

Layout Note: Comp0, 2 connect with Zo=27.4 ohm, make trace length shorter than 0.5" . Comp1, 3 connect with Zo=55 ohm, make trace length shorter than 0.5" .

H_DINV#[3..0] 6 H_DSTBN#[3..0] 6 H_DSTBP#[3..0] 6 H_D#[63..0] 6

2

1

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

http://laptop-motherboard-schematic.blogspot.com/

5

4

3

2

Date: Sheet of

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

CPU (3 of 2 )

HBU16 1.2

1

of

441Thursday, July 09, 2009

A

1

5

Please these inside socket cavity on L8(North side Secondary)

D D

+VCC_CORE

3 OF 4

U54C

A7

VCC

A9

VCC

A10

VCC

A12

VCC

A13

VCC

A15

VCC

A17

VCC

A18

VCC

A20

VCC

B7

VCC

B9

VCC

B10

VCC

B12

VCC

B14

VCC

B15

VCC

B17

VCC

B18

VCC

B20

VCC

C9

VCC

C10

VCC

C12

VCC

C13

C C

B B

A A

VCC

C15

VCC

C17

VCC

C18

VCC

D9

VCC

D10

VCC

D12

VCC

D14

VCC

D15

VCC

D17

VCC

D18

VCC

E7

VCC

E9

VCC

E10

VCC

E12

VCC

E13

VCC

E15

VCC

E17

VCC

E18

VCC

E20

VCC

F7

VCC

F9

VCC

F10

VCC

F12

VCC

F14

VCC

F15

VCC

F17

VCC

F18

VCC

F20

VCC

AA7

VCC

AA9

VCC

AA10

VCC

AA12

VCC

AA13

VCC

AA15

VCC

AA17

VCC

AA18

VCC

AA20

VCC

AB9

VCC

AC10

VCC

AB10

VCC

AB12

VCC

AB14

VCC

AB15

VCC

AB17

VCC

AB18

VCC

BGA479-SKT6-GPU7

5

VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC VCC

VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP VCCP

VCCA VCCA

VID0 VID1 VID2 VID3 VID4 VID5 VID6

VCCSENSE

VSSSENSE

AB20 AB7 AC7 AC9 AC12 AC13 AC15 AC17 AC18 AD7 AD9 AD10 AD12 AD14 AD15 AD17 AD18 AE9 AE10 AE12 AE13 AE15 AE17 AE18 AE20 AF9 AF10 AF12 AF14 AF15 AF17 AF18 AF20

G21 V6 J6 K6 M6 J21 K21 M21 N21 N6 R21 R6 T21 T6 V21 W21

B26 C26

AD6 AF5 AE5 AF4 AE3 AF3 AE2

AF7

AE7

+VCC_CORE

H_VID0 H_VID1 H_VID2 H_VID3 H_VID4 H_VID5 H_VID6

H_VID[6..0] 35

+VCC_CORE

12

R56

R56 100R2F-L1-GP-U

100R2F-L1-GP-U

12

R57

100R2F-L1-GP-U

http://laptop-motherboard-schematic.blogspot.com/

4

+VCC_CORE

12

DY

C408

12

C403

C442

SC22U6D3V5MX-2GP

12

C426

C435

SC22U6D3V5MX-2GP

DY

12

C409

C417

SC22U6D3V5MX-2GP

DY

3

12

C404

SC22U6D3V5MX-2GP

Please these inside socket cavity on L8(South side Secondary)

+VCC_CORE

12

C414

SC22U6D3V5MX-2GP

+VCC_CORE

12

C436

SC22U6D3V5MX-2GP

+1.05VS

12

TC14

DY

ST220U2D5VBM-LGP

layout note: "1D5V_VCCA_S0" as short as possible

+1.5V_VCCA_S0

12

C383

SCD01U16V2KX-3GP

4

12

C416

C441

C114

VCC_SENSE 35

VSS_SENSE 35

SC22U6D3V5MX-2GP

DY

Please these inside socket cavity on L8(North side Primary)

12

C126

C430

SC22U6D3V5MX-2GP

12

C381

SC22U6D3V5MX-2GP

R225

1 2

0R0603-PAD

SC10U6D3V5MX-3GP

Layout Note:

Place as close as possible to the CPU VCCA pin.

12

C425

SC22U6D3V5MX-2GP

DY

12

C133

C422

SC22U6D3V5MX-2GP

+1.5VS

Connect to V Core

Layout Note:

VCCSENSE and VSSSENSE lines should be of equal length.

Layout Note: Provide a test point (with no stub) to connect a differential probe between VCCSENSE and VSSSENSE at the location where the two 54.9ohm resistors terminate the 55 ohm transmission line.

Please these inside socket cavity on L8(North side Secondary)

C434

SC22U6D3V5MX-2GP

3

Please these outside socket cavity on L8(North side Secondary)

+VCC_CORE

12

C147

SC22U6D3V5MX-2GP

DY

+VCC_CORE

Please these outside socket cavity on L8(South side Secondary)

Please these inside socket cavity on L8(South side Primary)

+VCC_CORE

12

C125

C132

SC22U6D3V5MX-2GP

+1.05VS

1

2

SC22U6D3V5MX-2GP

C145

DY

C97

C128

SC22U6D3V5MX-2GP

12

C83

C93

SC22U6D3V5MX-2GP

DY

12

C113

C103

SC22U6D3V5MX-2GP

1

C144

C69

SCD47U16V2ZY-GP

2

4 OF 4

U54D

A4

VSS

A8

VSS

A11

VSS

A14

C77

SC22U6D3V5MX-2GP

12

C104

SC22U6D3V5MX-2GP

DY

12

C82

C92

SC22U6D3V5MX-2GP

1

C146

SCD47U16V2ZY-GP

2

1

C68

C70

SCD47U16V2ZY-GP

2

SCD47U16V2ZY-GP

2

VSS

A16

VSS

A19

VSS

A23

VSS

AF2

VSS

B6

VSS

B8

VSS

B11

VSS

B13

VSS

B16

VSS

B19

VSS

B21

VSS

B24

VSS

C5

VSS

C8

VSS

C11

VSS

C14

VSS

C16

VSS

C19

VSS

C2

VSS

C22

VSS

C25

VSS

D1

VSS

D4

VSS

D8

VSS

D11

VSS

D13

VSS

D16

VSS

D19

VSS

D23

VSS

D26

VSS

E3

VSS

E6

VSS

E8

VSS

E11

VSS

E14

VSS

E16

VSS

E19

VSS

E21

VSS

E24

VSS

F5

VSS

F8

VSS

F11

VSS

F13

VSS

F16

VSS

F19

VSS

F2

VSS

F22

VSS

F25

VSS

G4

VSS

G1

VSS

G23

VSS

G26

VSS

H3

VSS

H6

VSS

H21

VSS

H24

VSS

J2

VSS

J5

VSS

J22

VSS

J25

VSS

K1

VSS

K4

VSS

K23

VSS

K26

VSS

L3

VSS

L6

VSS

L21

VSS

L24

VSS

M2

VSS

M5

VSS

M22

VSS

M25

VSS

N1

VSS

N4

VSS

N23

VSS

N26

VSS

P3

VSS

BGA479-SKT6-GPU7

Title

Size Document Number Rev

Date: Sheet of

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

CPU (3 of 3 )

HBU16 1.2

1

P6 P21 P24 R2 R5 R22 R25 T1 T4 T23 T26 U3 U6 U21 U24 V2 V5 V22 V25 W1 W4 W23 W26 Y3 Y6 Y21 Y24 AA2 AA5 AA8 AA11 AA14 AA16 AA19 AA22 AA25 AB1 AB4 AB8 AB11 AB13 AB16 AB19 AB23 AB26 AC3 AC6 AC8 AC11 AC14 AC16 AC19 AC21 AC24 AD2 AD5 AD8 AD11 AD13 AD16 AD19 AD22 AD25

CPU_GND1

AE1 AE4 AE8 AE11 AE14 AE16 AE19 AE23 AE26 A2 AF6 AF8 AF11 AF13 AF16 AF19 AF21 A25 AF25

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., H s ic hih,

21F, 88, Sec.1, Hsin Tai Wu Rd., H s ic hih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

CPU_GND2 CPU_GND3

CPU_GND4

1

1 1

1

541Thursday, July 09, 2009

TP11 TPAD14-GPTP11 TPAD14-GP

NCTF PIN

TP44 TPAD14-GPTP44 TPAD14-GP TP12 TPAD14-GPTP12 TPAD14-GP

TP43 TPAD14-GPTP43 TPAD14-GP

1

5

A

4

3

2

1

D D

H_SWING routing Trace width and Spacing use 10 / 20 mil

H_SWING Resistors and Capacitors close MCH 500 mil ( MAX )

C C

H_RCOMP routing Trace width and Spacing use 10 / 20 mil

Place them near to the chip ( < 0.5")

B B

1 2

R233

H_SWING

12

C391

SCD1U10V2KX-4GP

H_RCOMP

24D9R2F-L-GP

+1.05VS

12

R234

R234 221R2F-2-GP

221R2F-2-GP

+1.05VS

R235

R235 100R2F-L1-GP-U

100R2F-L1-GP-U

R236

R236 1KR2F-3-GP

1KR2F-3-GP

1 2

12

R237

R237 2KR2F-3-GP

2KR2F-3-GP

H_D#[63..0]4

H_AVREF H_AVREF

H_D#[63..0]

1 OF 10

U53A

AD14

AA13 AA11

AD11 AD10 AD13 AE12

AE14

AE11

M11

N12

P13

N10

Y10 Y12 Y14

AA8

AA9

AE9 AA2 AD8 AA3 AD3 AD7

AF3 AC1 AE3 AC3

AE8 AG2 AD6

C12 E11

A11 B11

F2

G8

F8

E6 G2 H6 H2

F6 D4 H3 M9

J1

J2

J6

P2

L2 R2 N9

L6 M5

J3 N2 R1 N5 N6

N8

L7 M3

Y3

Y6

Y7

W2

Y9

C5

E3

U53A

H_D#_0 H_D#_1 H_D#_2 H_D#_3 H_D#_4 H_D#_5 H_D#_6 H_D#_7 H_D#_8 H_D#_9 H_D#_10 H_D#_11 H_D#_12 H_D#_13 H_D#_14 H_D#_15 H_D#_16 H_D#_17 H_D#_18 H_D#_19 H_D#_20 H_D#_21 H_D#_22 H_D#_23 H_D#_24 H_D#_25 H_D#_26 H_D#_27 H_D#_28 H_D#_29 H_D#_30 H_D#_31 H_D#_32 H_D#_33 H_D#_34 H_D#_35 H_D#_36 H_D#_37 H_D#_38 H_D#_39 H_D#_40 H_D#_41 H_D#_42 H_D#_43 H_D#_44 H_D#_45 H_D#_46 H_D#_47 H_D#_48 H_D#_49 H_D#_50 H_D#_51 H_D#_52 H_D#_53 H_D#_54 H_D#_55 H_D#_56 H_D#_57 H_D#_58 H_D#_59 H_D#_60 H_D#_61 H_D#_62 H_D#_63

H_SWING H_RCOMP

H_CPURST# H_CPUSLP#

H_AVREF H_DVREF

CANTIGA-GM-GP-U-NF

HOST

H_D#0 H_D#1 H_D#2 H_D#3 H_D#4 H_D#5 H_D#6 H_D#7 H_D#8 H_D#9 H_D#10 H_D#11 H_D#12 H_D#13 H_D#14 H_D#15 H_D#16 H_D#17 H_D#18 H_D#19 H_D#20 H_D#21 H_D#22 H_D#23 H_D#24 H_D#25 H_D#26 H_D#27 H_D#28 H_D#29 H_D#30 H_D#31 H_D#32 H_D#33 H_D#34 H_D#35 H_D#36 H_D#37 H_D#38 H_D#39 H_D#40 H_D#41 H_D#42 H_D#43 H_D#44 H_D#45 H_D#46 H_D#47 H_D#48 H_D#49 H_D#50 H_D#51 H_D#52 H_D#53 H_D#54 H_D#55 H_D#56 H_D#57 H_D#58 H_D#59 H_D#60 H_D#61 H_D#62 H_D#63

H_SWING H_RCOMP

H_CPURST#3 H_CPUSLP#4

12

C400

DY

1 OF 10

H_A#_3 H_A#_4 H_A#_5 H_A#_6 H_A#_7 H_A#_8

H_A#_9 H_A#_10 H_A#_11 H_A#_12 H_A#_13 H_A#_14 H_A#_15 H_A#_16 H_A#_17 H_A#_18 H_A#_19 H_A#_20 H_A#_21 H_A#_22 H_A#_23 H_A#_24 H_A#_25 H_A#_26 H_A#_27 H_A#_28 H_A#_29 H_A#_30 H_A#_31

H_A#_32 H_A#_33 H_A#_34 H_A#_35

H_ADS# H_ADSTB#_0 H_ADSTB#_1

H_BNR# H_BPRI#

H_BREQ#

H_DEFER#

H_DBSY#

HPLL_CLK

HPLL_CLK#

H_DPWR#

H_DRDY#

H_HIT#

H_HITM#

H_LOCK#

H_TRDY#

H_DINV#_0 H_DINV#_1 H_DINV#_2 H_DINV#_3

H_DSTBN#_0 H_DSTBN#_1 H_DSTBN#_2 H_DSTBN#_3

H_DSTBP#_0 H_DSTBP#_1 H_DSTBP#_2 H_DSTBP#_3

H_REQ#_0 H_REQ#_1 H_REQ#_2 H_REQ#_3 H_REQ#_4

H_RS#_0 H_RS#_1 H_RS#_2

A14 C15 F16 H13 C18 M16 J13 P16 R16 N17 M13 E17 P17 F17 G20 B19 J16 E20 H16 J20 L17 A17 B17 L16 C21 J17 H20 B18 K17 B20 F21 K21 L20

H12 B16 G17 A9 F11 G12 E9 B10 AH7 AH6 J11 F9 H9 E12 H11 C9

J8 L3 Y13 Y1

L10 M7 AA5 AE6

L9 M8 AA6 AE5

B15 K13 F13 B13 B14

B6 F12 C8

H_A#3 H_A#4 H_A#5 H_A#6 H_A#7 H_A#8 H_A#9 H_A#10 H_A#11 H_A#12 H_A#13 H_A#14 H_A#15 H_A#16 H_A#17 H_A#18 H_A#19 H_A#20 H_A#21 H_A#22 H_A#23 H_A#24 H_A#25 H_A#26 H_A#27 H_A#28 H_A#29 H_A#30 H_A#31 H_A#32 H_A#33 H_A#34 H_A#35

H_DINV#0 H_DINV#1 H_DINV#2 H_DINV#3

H_DSTBN#0 H_DSTBN#1 H_DSTBN#2 H_DSTBN#3

H_DSTBP#0 H_DSTBP#1 H_DSTBP#2 H_DSTBP#3

H_REQ#0 H_REQ#1 H_REQ#2 H_REQ#3 H_REQ#4

H_RS#0 H_RS#1 H_RS#2

H_A#[35..3]

H_ADS# 3 H_ADSTB#0 3 H_ADSTB#1 3 H_BNR# 3

H_BPRI# 3

H_BREQ#0 3

H_DEFER# 3

H_DBSY# 3

CLK_MCH_BCLK 16 CLK_MCH_BCLK# 16

H_DPWR# 4

H_DRDY# 3 H_HIT# 3 H_HITM# 3

H_LOCK# 3 H_TRDY# 3

H_DINV#[3..0]

H_DSTBN#[3..0]

H_DSTBP#[3..0]

H_A#[35..3] 3

H_DINV#[3..0] 4

H_DSTBN#[3..0] 4

H_DSTBP#[3..0] 4

H_REQ#[4..0] 3

H_RS#[2..0] 3

SCD1U16V2ZY-2GP

http://laptop-motherboard-schematic.blogspot.com/

5

4

3

2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., H s ichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., H s ichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

Cantiga (1 of 6)

HBU16 1.2

641Thursday, July 09, 2009

of

641Thursday, July 09, 2009

of

641Thursday, July 09, 2009

1

A

1

D

DCCBBAA

+3VS

5

+1.8V

R274 2K21R2F-GP

1 2

DY

R266 2K21R2F-GP

1 2

DY

R271 4K02R2F-GP

1 2

DY

R272 4K02R2F-GP

1 2

DY

R45 2K21R2F-GP

1 2

DY

R245 2K21R2F-GP

1 2

DY

R43 2K21R2F-GP

1 2

DY

R36 2K21R2F-GP

1 2

DY

R35 4K02R2F-GP

1 2

DY

R37 2K21R2F-GP

1 2

DY

R39 2K21R2F-GP

1 2

DY

R38 2K21R2F-GP

1 2

DY

R34 2K21R2F-GP

1 2

DY

Cantiga = 2.2K

PCI Express Graphics Lane MCH_CFG_9 Low = Normal (default)

CFG18

CFG11 CFG19

CFG20

CFG6 CFG5 CFG7 CFG8 CFG9 CFG12 CFG13 CFG16 CFG10

DMI Lane Reversal MCH_CFG_19 Low = Normal (default)

High = Lanes Reversed

Cantiga = 2.2K

+3VS

RN24

1 2 3

SRN2K2J-1-GP

5

12

R243

R243 80D6R2F-L-GP

80D6R2F-L-GP

12

R242

R242 80D6R2F-L-GP

80D6R2F-L-GP

DDC2_CLK

4

DDC2_DATA

M_RCOMPP

M_RCOMPN

PM_SYNC#19

H_DPRSTP#4,18,35 PM_EXTTS#012 PM_EXTTS#113

PM_PWROK19,32

PLT_RS T#17,23,26,27,29

PM_THRMTRIP-A#3,18

PM_DPRSLPVR19,35

Connect to V Core

FSB setting

MCH_CLKSEL03,16 MCH_CLKSEL13,16 MCH_CLKSEL23,16

CFG11 CFG12 CFG13

CFG16 CFG18

CFG19 CFG20

PM_EXTTS#0 PM_EXTTS#1 PWROK_R

R59 0R0402-PADR59 0R0402-PAD

1 2

SC100P50V2JN-3GP

RSTIN#

12

R30100R2J-2-GP R30100R2J-2-GP

12

C73

DY

+1.05VS

12

R552

R552 56R2J-4-GP

56R2J-4-GP

R239

TSATN#TSATN# TSATN#_B

1 2

0R0402-PAD

Please Close to U22

http://laptop-motherboard-schematic.blogspot.com/

CFG5 CFG6 CFG7 CFG8 CFG9 CFG10

4

U53B

M36

RESERVED#M36

N36

RESERVED#N36

R33

RESERVED#R33

T33

RESERVED#T33

AH9

RESERVED#AH9

AH10

RESERVED#AH10

AH12

RESERVED#AH12

AH13

RESERVED#AH13

K12

RESERVED#K12

AL34

RESERVED#AL34

AK34

RESERVED#AK34

AN35

RESERVED#AN35

AM35

RESERVED#AM35

T24

RESERVED#T24

B31

RESERVED#B31

B2

RESERVED#B2

M1

RESERVED#M1

AY21

RESERVED#AY21

BG23

RESERVED#BG23

BF23

RESERVED#BF23

BH18

RESERVED#BH18

BF18

RESERVED#BF18

T25

CFG_0

R25

CFG_1

P25

CFG_2

P20

CFG_3

P24

CFG_4

C25

CFG_5

N24

CFG_6

M24

CFG_7

E21

CFG_8

C23

CFG_9

C24

CFG_10

N21

CFG_11

P21

CFG_12

T21

CFG_13

R20

CFG_14

M20

CFG_15

L21

CFG_16

H21

CFG_17

P29

CFG_18

R28

CFG_19

T28

CFG_20

R29

PM_SYNC#

B7

PM_DPRSTP#

N33

PM_EXT_TS#_0

P32

PM_EXT_TS#_1

AT40

PWROK

AT11

RSTIN#

T20

THERMTRIP#

R32

DPRSLPVR

BG48

NC#BG48

BF48

NC#BF48

BD48

NC#BD48

BC48

NC#BC48

BH47

NC#BH47

BG47

NC#BG47

BE47

NC#BE47

BH46

NC#BH46

BF46

NC#BF46

BG45

NC#BG45

BH44

NC#BH44

BH43

NC#BH43

BH6

NC#BH6

BH5

NC#BH5

BG4

NC#BG4

BH3

NC#BH3

BF3

NC#BF3

BH2

NC#BH2

BG2

NC#BG2

BE2

NC#BE2

BG1

NC#BG1

BF1

NC#BF1

BD1

NC#BD1

BC1

NC#BC1

F1

NC#F1

A47

NC#A47

CANTIGA-GM-GP-U-NF

+3VS

DY

B

4

RSVD

CFG

PM

NC

Please Close GMCH

12

R542

R542 10KR2J-3-GP

10KR2J-3-GP

TSATN#_KBC

DY

C

Q38

Q38 MMBT3904WT1G-GP

MMBT3904WT1G-GP

E

SM_RCOMP

SM_RCOMP#

SM_RCOMP_VOH

SM_RCOMP_VOL

SM_PWROK

SM_DRAMRST#

DPLL_REF_CLK

DDR CLK/ CONTROL/COMPENSATIONCLKDMI

DPLL_REF_CLK#

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

GFX_VR_EN

GRAPHICS VIDMEHDA

CL_PWROK

DDPC_CTRLCLK

DDPC_CTRLDATA

SDVO_CTRLCLK

SDVO_CTRLDATA

ICH_SYNC#

MISC

TSATN#_KBC 29

2 OF 10

SA_CK_0 SA_CK_1 SB_CK_0 SB_CK_1

SA_CK#_0 SA_CK#_1 SB_CK#_0 SB_CK#_1

SA_CKE_0 SA_CKE_1 SB_CKE_0 SB_CKE_1

SA_CS#_0 SA_CS#_1 SB_CS#_0 SB_CS#_1

SA_ODT_0 SA_ODT_1 SB_ODT_0 SB_ODT_1

SM_VREF SM_REXT

PEG_CLK

PEG_CLK#

DMI_RXN_0 DMI_RXN_1 DMI_RXN_2 DMI_RXN_3

DMI_RXP_0 DMI_RXP_1 DMI_RXP_2 DMI_RXP_3

DMI_TXN_0 DMI_TXN_1 DMI_TXN_2 DMI_TXN_3

DMI_TXP_0 DMI_TXP_1 DMI_TXP_2 DMI_TXP_3

GFX_VID_0 GFX_VID_1 GFX_VID_2 GFX_VID_3 GFX_VID_4

CL_CLK

CL_DATA CL_RST#

CL_VREF

CLKREQ#

TSATN#

HDA_BCLK

HDA_RST#

HDA_SDI

HDA_SDO

HDA_SYNC

AP24

M_CLK_DDR0 12

AT21

M_CLK_DDR1 12

AV24

M_CLK_DDR2 13

AU20

M_CLK_DDR3 13

AR24

M_CLK_DDR#0 12

AR21

M_CLK_DDR#1 12

AU24

M_CLK_DDR#2 13

AV20

M_CLK_DDR#3 13

BC28

M_CKE0 12

AY28

M_CKE1 12

AY36

M_CKE2 13

BB36

M_CKE3 13

BA17

M_CS0# 12

AY16

M_CS1# 12

AV16

M_CS2# 13

AR13

M_CS3# 13

BD17

M_ODT0 12

AY17

M_ODT1 12

BF15

M_ODT2 13

AY13

M_ODT3 13

M_RCOMPP

BG22

M_RCOMPN

BH21

SM_RCOMP_VOH

BF28

SM_RCOMP_VOL

BH28 AV42

AR36

SM_REXT

BF17 BC36

B38 A38 E41 F41

F43 E43

AE41 AE37 AE47 AH39

AE40 AE38 AE48 AH40

AE35 AE43 AE46 AH42

AD35 AE44 AF46 AH43

B33 B32 G33 F33 E33

C34

AH37 AH36 AN36 AJ35 AH34

N28 M28 G36 E36 K36 H36

B12

B28 B30 B29 C29 A28

R240 499R2F-2-GPR240 499R2F-2-GP

Use DDR3 need enable

DREFCLK DREFCLK# DREFSSCLK DREFSSCLK#

CLK_MCH_3GPLL 16

CLK_MCH_3GPLL# 16

DMI_TXN0 DMI_TXN1 DMI_TXN2 DMI_TXN3

DMI_TXP0 DMI_TXP1 DMI_TXP2

DMI_TXP3

DMI_RXN0 DMI_RXN1 DMI_RXN2 DMI_RXN3

DMI_RXP0 DMI_RXP1 DMI_RXP2 DMI_RXP3

MCH_CLVREF

TSATN#

HDA_SDIN2_NB

1 2

DREFCLK 16

DREFCLK# 16

DREFSSCLK 16

DREFSSCLK# 16

DMI_TXN0 19 DMI_TXN1 19 DMI_TXN2 19 DMI_TXN3 19

DMI_TXP0 19 DMI_TXP1 19 DMI_TXP2 19 DMI_TXP3 19

DMI_RXN0 19 DMI_RXN1 19 DMI_RXN2 19 DMI_RXN3 19

DMI_RXP0 19 DMI_RXP1 19 DMI_RXP2 19 DMI_RXP3 19

GMCH_HDMI_CLK 26 GMCH_HDMI_DATA 26 MCH_CLK_REQ# 16 MCH_ICH_SYNC# 19

DDPC/SDVO for HDMI used

R590

R590 33R2J-2-GP

33R2J-2-GP

CRT Termination/EMI Filter

M_RED M_RED_M

NBQ160808T-470Y-N-GP

M_GREEN

NBQ160808T-470Y-N-GP

M_BLUE

NBQ160808T-470Y-N-GP

3

DDR_VREF_S3

M_PWROK 19 CL_RST#0 19

3

+1.8V

DY

+1.05VS

CL_CLK0 19 CL_DATA0 19

12

C139

SCD1U10V2KX-4GP

HDA_BITCLK_CODEC 18,28 HDA_RST#_CODEC 18,28 HDA_SDIN2 18 HDA_SDOUT_CODEC 18,28 HDA_SYNC_CODEC 18,28

L18

1 2

L14

1 2

L12

1 2

12

R62

R62 1KR2F-3-GP

1KR2F-3-GP

12

R61

R61 1KR2F-3-GP

1KR2F-3-GP

+3VS

1

23

4

DDC1_CLK14 DDC1_DATA14

M_HSYNC14 M_VSYNC14

R52

R52 1KR2F-3-GP

1KR2F-3-GP

1 2

CL_VREF ~= 0.35V

12

R55

R55 499R2F-2-GP

499R2F-2-GP

M_GREEN_M

M_BLUE_M

12

C28

SC22P50V2JN-4GP

L_BK LTCTL15 L_BKLT_EN29

DDC2_CLK15 DDC2_DATA15

L_VDD_EN15

TP48TPAD14-GP TP 48TPAD14-GP

RN46

RN46 SRN2K2J-1-GP

SRN2K2J-1-GP

R252

R251 1KR2F-3-GPR251 1KR2F-3-GP

12

1 2

LCTLA_CLK LCTLB_ DATA

LIBG

LVDS_VBG

1

TXCLKA_L-15 TXCLKA_L+15 TXCLKB_L-15 TXCLKB_L+15

TXOUTA_L0-15 TXOUTA_L1-15 TXOUTA_L2-15

TXOUTA_L0+15 TXOUTA_L1+15 TXOUTA_L2+15

TXOUTB_L0-15 TXOUTB_L1-15 TXOUTB_L2-15

TXOUTB_L0+15 TXOUTB_L1+15 TXOUTB_L2+15

TV_DA CA

TP67TPAD14-GP TP67TPAD14-GP

1

TV_DA CB

TP68TPAD14-GP TP68TPAD14-GP

1

TV_DA CC

TP69TPAD14-GP TP69TPAD14-GP

1

TV_DCONSEL0 TV_DCONSEL1

M_BLUE M_GREEN M_RED

DDC1_CLK DDC1_DATA

GMCH_HS

1 2

R54 33R2 J-2-GPR54 33R2 J-2-GP

GMCH_VS

1 2

R53 33R2 J-2-GPR53 33R2 J-2-GP

CRT_IREF

1 2

1K02R2F-1-GP

FOR Cantiga: 1.02k_1% ohm

CRT_IREF routing Trace width use 20 mil

+1.8V

12

C437

R248

R248 3K01R2F-3-GP

3K01R2F-3-GP

SCD01U16V2KX-3GP

12

C431

R244

SCD01U16V2KX-3GP

1KR2F-3-GP

Place Close Connector

R548

1 2

0R0603-PAD

R549

1 2

0R0603-PAD

R550

1 2

0R0603-PAD

12

C34

C42

SC22P50V2JN-4GP

U53C

L32

L_BKLT_CTRL

G32

L_BKLT_EN

M32

L_CTRL_CLK

M33

L_CTRL_DATA

K33

L_DDC_CLK

J33

L_DDC_DATA

M29

L_VDD_EN

C44

LVDS_IBG

B43

LVDS_VBG

E37

LVDS_VREFH

E38

LVDS_VREFL

C41

LVDSA_CLK#

C40

LVDSA_CLK

B37

LVDSB_CLK#

A37

LVDSB_CLK

H47

LVDSA_DATA#_0

E46

LVDSA_DATA#_1

G40

LVDSA_DATA#_2

A40

LVDSA_DATA#_3

H48

LVDSA_DATA_0

D45

LVDSA_DATA_1

F40

LVDSA_DATA_2

B40

LVDSA_DATA_3

A41

LVDSB_DATA#_0

H38

LVDSB_DATA#_1

G37

LVDSB_DATA#_2

J37

LVDSB_DATA#_3

B42

LVDSB_DATA_0

G38

LVDSB_DATA_1

F37

LVDSB_DATA_2

K37

LVDSB_DATA_3

F25

TVA_DAC

H25

TVB_DAC

K25

TVC_DAC

H24

TV_RTN

C31

TV_DCONSEL_0

E32

TV_DCONSEL_1

E28

CRT_BLUE

G28

CRT_GREEN

J28

CRT_RED

G29

CRT_IRTN

H32

CRT_DDC_CLK

J32

CRT_DDC_DATA

J29

CRT_HSYNC

E29

CRT_TVO_IREF

L29

CRT_VSYNC

CANTIGA-GM-GP-U-NF

SM_RCOMP_VOH

12

C127

C127 SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

SM_RCOMP_VOL

12

C121

C121 SC2D2U6D3V3MX-1-GP

SC2D2U6D3V3MX-1-GP

2

RED 14

GREEN 1 4

BLUE 14

2

3 OF 10

R58

PEG_CMP

T37 T36

H44 J46 L44 L40 N41 P48 N44 T43 U43 Y43 Y48 Y36 AA43 AD37 AC47 AD39

H43 J44 L43 L41 N40 P47 N43 T42 U42 Y42 W47 Y37 AA42 AD36 AC48 AD40

J41 M46 M47 M40 M42 R48 N38 T40 U37 U40 Y40 AA46 AA37 AA40 AD43 AC46

J42 L46 M48 M39 M43 R47 N37 T39 U36 U39 Y39 Y46 AA36 AA39 AD42 AD46

1 2

PEG_RXP3

HDMI_L_DATA2HDMI_L_DATA1HDMI_L_DATA0HDMI_L_CLK-

HDMI_L_DATA2+ HDMI_L_DATA1+ HDMI_L_DATA0+ HDMI_L_CLK+

49D9R2F-GP

PEG_COMPI

PEG_COMPO

PEG_RX#_0 PEG_RX#_1 PEG_RX#_2 PEG_RX#_3 PEG_RX#_4 PEG_RX#_5 PEG_RX#_6 PEG_RX#_7 PEG_RX#_8

PEG_RX#_9 PEG_RX#_10 PEG_RX#_11

LVDS

PEG_RX#_12 PEG_RX#_13 PEG_RX#_14 PEG_RX#_15

PEG_RX_0 PEG_RX_1 PEG_RX_2 PEG_RX_3 PEG_RX_4 PEG_RX_5 PEG_RX_6 PEG_RX_7 PEG_RX_8

PEG_RX_9 PEG_RX_10 PEG_RX_11 PEG_RX_12 PEG_RX_13 PEG_RX_14 PEG_RX_15

PEG_TX#_0 PEG_TX#_1 PEG_TX#_2 PEG_TX#_3 PEG_TX#_4 PEG_TX#_5

TV VGA

PEG_TX#_6 PEG_TX#_7 PEG_TX#_8 PEG_TX#_9

PEG_TX#_10 PEG_TX#_11 PEG_TX#_12

PCI-EXPRESS GRAPHICS

PEG_TX#_13 PEG_TX#_14 PEG_TX#_15

PEG_TX_0

PEG_TX_1

PEG_TX_2

PEG_TX_3

PEG_TX_4

PEG_TX_5

PEG_TX_6

PEG_TX_7

PEG_TX_8

PEG_TX_9 PEG_TX_10 PEG_TX_11 PEG_TX_12 PEG_TX_13 PEG_TX_14 PEG_TX_15

Place Close GMCH

R49

150R2F-1-GP

R49

1 2

R50

1 2

R48

1 2

M_BLUE

M_GREEN

M_RED

1

Place the 49D9 Ohm resistor within 500 mils (1.27 mm) of the (G)MCH.

+VCC_PEG

PEG_RXP3 26

HDMI

HDMI HDMI

HDMI

C560 SCD01U16V2KX-3GP

1 2

C561 SCD01U16V2KX-3GP

1 2

C562 SCD01U16V2KX-3GP

1 2

C563 SCD01U16V2KX-3GP

1 2

HDMI

Place Close GMCH

HDMI

HDMI HDMI

HDMI

C564 SCD01U16V2KX-3GP

1 2

C565 SCD01U16V2KX-3GP

1 2

C566 SCD01U16V2KX-3GP

1 2

C567 SCD01U16V2KX-3GP

1 2

HDMI

Place Close GMCH

HDMI

LCTLB_ DATA PM_EXTTS#0 LCTLA_CLK PM_EXTTS#1

HDMI_DATA2- 26 HDMI_DATA1- 26 HDMI_DATA0- 26 HDMI_CLK- 26

HDMI_DATA2+ 26 HDMI_DATA1+ 26 HDMI_DATA0+ 26 HDMI_CLK+ 26

LIBG

1 2

R257

R257 2K37R2F-GP

2K37R2F-GP

+3VS

RN25

1

8

2

7

3

6

4 5

SRN10KJ-6-GP

Place Close Connector

R14

M_BLUE

M_GREEN

M_RED

Title

Size Document Num ber Rev

Size Document Number Rev

Date: Sheet of

R14

1 2

150R2F-1-GP

R15

1 2

150R2F-1-GP

R17

1 2

150R2F-1-GP

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Cantiga (2 of 6)

HBU16 1.2

741Thursday, July 09, 2009

1

5

A

4

3

2

1

M_A_DQ[63..0]12

D D

C C

M_A_DQ[63..0]

M_A_DQ0 M_A_DQ1 M_A_DQ2 M_A_DQ3 M_A_DQ4 M_A_DQ5 M_A_DQ6 M_A_DQ7 M_A_DQ8 M_A_DQ9 M_A_DQ10 M_A_DQ11 M_A_DQ12 M_A_DQ13 M_A_DQ14 M_A_DQ15 M_A_DQ16 M_A_DQ17 M_A_DQ18 M_A_DQ19 M_A_DQ20 M_A_DQ21 M_A_DQ22 M_A_DQ23 M_A_DQ24 M_A_DQ25 M_A_DQ26 M_A_DQ27 M_A_DQ28 M_A_DQ29 M_A_DQ30 M_A_DQ31 M_A_DQ32 M_A_DQ33 M_A_DQ34 M_A_DQ35 M_A_DQ36 M_A_DQ37 M_A_DQ38 M_A_DQ39 M_A_DQ40 M_A_DQ41 M_A_DQ42 M_A_DQ43 M_A_DQ44 M_A_DQ45 M_A_DQ46 M_A_DQ47 M_A_DQ48 M_A_DQ49 M_A_DQ50 M_A_DQ51 M_A_DQ52 M_A_DQ53 M_A_DQ54 M_A_DQ55 M_A_DQ56 M_A_DQ57 M_A_DQ58 M_A_DQ59 M_A_DQ60 M_A_DQ61 M_A_DQ62 M_A_DQ63

B B

U53D

AJ38

SA_DQ_0

AJ41

SA_DQ_1

AN38

SA_DQ_2

AM38

SA_DQ_3

AJ36

SA_DQ_4

AJ40

SA_DQ_5

AM44

SA_DQ_6

AM42

SA_DQ_7

AN43

SA_DQ_8

AN44

SA_DQ_9

AU40

SA_DQ_10

AT38

SA_DQ_11

AN41

SA_DQ_12

AN39

SA_DQ_13

AU44

SA_DQ_14

AU42

SA_DQ_15

AV39

SA_DQ_16

AY44

SA_DQ_17

BA40

SA_DQ_18

BD43

SA_DQ_19

AV41

SA_DQ_20

AY43

SA_DQ_21

BB41

SA_DQ_22

BC40

SA_DQ_23

AY37

SA_DQ_24

BD38

SA_DQ_25

AV37

SA_DQ_26

AT36

SA_DQ_27

AY38

SA_DQ_28

BB38

SA_DQ_29

AV36

SA_DQ_30

AW36

SA_DQ_31

BD13

SA_DQ_32

AU11

SA_DQ_33

BC11

SA_DQ_34

BA12

SA_DQ_35

AU13

SA_DQ_36

AV13

SA_DQ_37

BD12

SA_DQ_38

BC12

SA_DQ_39

BB9

SA_DQ_40

BA9

SA_DQ_41

AU10

SA_DQ_42

AV9

SA_DQ_43

BA11

SA_DQ_44

BD9

SA_DQ_45

AY8

SA_DQ_46

BA6

SA_DQ_47

AV5

SA_DQ_48

AV7

SA_DQ_49

AT9

SA_DQ_50

AN8

SA_DQ_51

AU5

SA_DQ_52

AU6

SA_DQ_53

AT5

SA_DQ_54

AN10

SA_DQ_55

AM11

SA_DQ_56

AM5

SA_DQ_57

AJ9

SA_DQ_58

AJ8

SA_DQ_59

AN12

SA_DQ_60

AM13

SA_DQ_61

AJ11

SA_DQ_62

AJ12

SA_DQ_63

CANTIGA-GM-GP-U-NF

4 OF 10

BD21

SA_BS_0

BG18

SA_BS_1

AT25

SA_BS_2

BB20

SA_RAS#

BD20

SA_CAS#

AY20

SA_WE#

M_A_DM[7..0]

M_A_DM0

AM37

SA_DM_0 SA_DM_1 SA_DM_2 SA_DM_3 SA_DM_4 SA_DM_5 SA_DM_6 SA_DM_7

SA_DQS_0 SA_DQS_1 SA_DQS_2 SA_DQS_3 SA_DQS_4 SA_DQS_5 SA_DQS_6

SA_DQS_7 SA_DQS#_0 SA_DQS#_1 SA_DQS#_2 SA_DQS#_3 SA_DQS#_4 SA_DQS#_5 SA_DQS#_6 SA_DQS#_7

SA_MA_0 SA_MA_1 SA_MA_2 SA_MA_3 SA_MA_4 SA_MA_5 SA_MA_6 SA_MA_7 SA_MA_8

SA_MA_9 SA_MA_10 SA_MA_11 SA_MA_12 SA_MA_13 SA_MA_14

DDR SYSTEM MEMORY A

AT41 AY41 AU39 BB12 AY6 AT7 AJ5

AJ44 AT44 BA43 BC37 AW12 BC8 AU8 AM7 AJ43 AT43 BA44 BD37 AY12 BD8 AU9 AM8

BA21 BC24 BG24 BH24 BG25 BA24 BD24 BG27 BF25 AW24 BC21 BG26 BH26 BH17 AY25

M_A_DM1 M_A_DM2 M_A_DM3 M_A_DM4 M_A_DM5 M_A_DM6 M_A_DM7

M_A_DQS0 M_A_DQS1 M_A_DQS2 M_A_DQS3 M_A_DQS4 M_A_DQS5 M_A_DQS6

M_A_DQS7 M_A_DQS#0 M_A_DQS#1 M_A_DQS#2 M_A_DQS#3 M_A_DQS#4 M_A_DQS#5 M_A_DQS#6 M_A_DQS#7

M_A_A0 M_A_A1 M_A_A2 M_A_A3 M_A_A4 M_A_A5 M_A_A6 M_A_A7 M_A_A8

M_A_A9 M_A_A10 M_A_A11 M_A_A12 M_A_A13

M_A_A14

M_A_DQS[7..0]

M_A_DQS#[7..0]

M_A_A[14..0]

M_A_BS#0 12 M_A_BS#1 12 M_A_BS#2 12

M_A_RAS# 12

M_A_CAS# 12

M_A_WE# 12

M_A_DM[7..0] 12

M_A_DQS[7..0] 12

M_A_DQS#[7..0] 12

M_A_A[14..0] 12

M_B_DQ[63..0]13

M_B_DQ[63..0]

M_B_DQ0 M_B_DQ1 M_B_DQ2 M_B_DQ3 M_B_DQ4 M_B_DQ5 M_B_DQ6 M_B_DQ7 M_B_DQ8 M_B_DQ9 M_B_DQ10 M_B_DQ11 M_B_DQ12 M_B_DQ13 M_B_DQ14 M_B_DQ15 M_B_DQ16 M_B_DQ17 M_B_DQ18 M_B_DQ19 M_B_DQ20 M_B_DQ21 M_B_DQ22 M_B_DQ23 M_B_DQ24 M_B_DQ25 M_B_DQ26 M_B_DQ27 M_B_DQ28 M_B_DQ29 M_B_DQ30 M_B_DQ31 M_B_DQ32 M_B_DQ33 M_B_DQ34 M_B_DQ35 M_B_DQ36 M_B_DQ37 M_B_DQ38 M_B_DQ39 M_B_DQ40 M_B_DQ41 M_B_DQ42 M_B_DQ43 M_B_DQ44 M_B_DQ45 M_B_DQ46 M_B_DQ47 M_B_DQ48 M_B_DQ49 M_B_DQ50 M_B_DQ51 M_B_DQ52 M_B_DQ53 M_B_DQ54 M_B_DQ55 M_B_DQ56 M_B_DQ57 M_B_DQ58 M_B_DQ59 M_B_DQ60 M_B_DQ61 M_B_DQ62 M_B_DQ63

U53E

AK47

SB_DQ_0

AH46

SB_DQ_1

AP47

SB_DQ_2

AP46

SB_DQ_3

AJ46

SB_DQ_4

AJ48

SB_DQ_5

AM48

SB_DQ_6

AP48

SB_DQ_7

AU47

SB_DQ_8

AU46

SB_DQ_9

BA48

SB_DQ_10

AY48

SB_DQ_11

AT47

SB_DQ_12

AR47

SB_DQ_13

BA47

SB_DQ_14

BC47

SB_DQ_15

BC46

SB_DQ_16

BC44

SB_DQ_17

BG43

SB_DQ_18

BF43

SB_DQ_19

BE45

SB_DQ_20

BC41

SB_DQ_21

BF40

SB_DQ_22

BF41

SB_DQ_23

BG38

SB_DQ_24

BF38

SB_DQ_25

BH35

SB_DQ_26

BG35

SB_DQ_27

BH40

SB_DQ_28

BG39

SB_DQ_29

BG34

SB_DQ_30

BH34

SB_DQ_31

BH14

SB_DQ_32

BG12

SB_DQ_33

BH11

SB_DQ_34

BG8

SB_DQ_35

BH12

SB_DQ_36

BF11

SB_DQ_37

BF8

SB_DQ_38

BG7

SB_DQ_39

BC5

SB_DQ_40

BC6

SB_DQ_41

AY3

SB_DQ_42

AY1

SB_DQ_43

BF6

SB_DQ_44

BF5

SB_DQ_45

BA1

SB_DQ_46

BD3

SB_DQ_47

AV2

SB_DQ_48

AU3

SB_DQ_49

AR3

SB_DQ_50

AN2

SB_DQ_51

AY2

SB_DQ_52

AV1

SB_DQ_53

AP3

SB_DQ_54

AR1

SB_DQ_55

AL1

SB_DQ_56

AL2

SB_DQ_57

AJ1

SB_DQ_58

AH1

SB_DQ_59

AM2

SB_DQ_60

AM3

SB_DQ_61

AH3

SB_DQ_62

AJ3

SB_DQ_63

CANTIGA-GM-GP-U-NF

5 OF 10

BC16

SB_BS_0

BB17

SB_BS_1

BB33

SB_BS_2

AU17

SB_RAS#

BG16

SB_CAS#

BF14

SB_WE#

M_B_A0 M_B_A1 M_B_A2 M_B_A3 M_B_A4 M_B_A5 M_B_A6 M_B_A7 M_B_A8

M_B_A9 M_B_A10 M_B_A11 M_B_A12 M_B_A13

M_B_A14

M_B_DM[7..0]

M_B_DQS[7..0]

M_B_DQS#[7..0]

M_B_A[14..0]

SB_DM_0 SB_DM_1 SB_DM_2 SB_DM_3 SB_DM_4 SB_DM_5 SB_DM_6 SB_DM_7

SB_DQS_0 SB_DQS_1 SB_DQS_2 SB_DQS_3 SB_DQS_4 SB_DQS_5 SB_DQS_6

SB_DQS_7 SB_DQS#_0 SB_DQS#_1 SB_DQS#_2 SB_DQS#_3 SB_DQS#_4 SB_DQS#_5 SB_DQS#_6 SB_DQS#_7

SB_MA_0 SB_MA_1 SB_MA_2 SB_MA_3 SB_MA_4 SB_MA_5 SB_MA_6 SB_MA_7 SB_MA_8

SB_MA_9 SB_MA_10 SB_MA_11 SB_MA_12 SB_MA_13 SB_MA_14

DDR SYSTEM MEMORY B

AY47 BD40 BF35 BG11 BA3 AP1 AK2

AL47 AV48 BG41 BG37 BH9 BB2 AU1 AN6 AL46 AV47 BH41 BH37 BG9 BC2 AT2 AN5

AV17 BA25 BC25 AU25 AW25 BB28 AU28 AW28 AT33 BD33 BB16 AW33 AY33 BH15 AU33

M_B_DM1 M_B_DM2 M_B_DM3 M_B_DM4 M_B_DM5 M_B_DM6 M_B_DM7

M_B_DQS0 M_B_DQS1 M_B_DQS2 M_B_DQS3 M_B_DQS4 M_B_DQS5 M_B_DQS6 M_B_DQS7 M_B_DQS#0 M_B_DQS#1 M_B_DQS#2 M_B_DQS#3 M_B_DQS#4 M_B_DQS#5 M_B_DQS#6 M_B_DQS#7

M_B_DM0

AM47

M_B_RAS# 13 M_B_CAS# 13 M_B_WE# 13

M_B_DQS[7..0] 13

M_B_DQS#[7..0] 13

M_B_A[14..0] 13

M_B_BS#0 13 M_B_BS#1 13 M_B_BS#2 13

M_B_DM[7..0] 13

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

http://laptop-motherboard-schematic.blogspot.com/

5

4

3

2

Date: Sheet of

Taipei Hsien 221, Taiwan, R.O.C.

Cantiga (3 of 6)

HBU16 1.2

1

841Thursday, July 09, 2009

A

1

5

DCCBBAA

+1.05VS

7 OF 10

VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF

POWER

VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF

VCC GFX NCTF

VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF VCC_AXG_NCTF

VCC_SM_LF VCC_SM_LF VCC_SM_LF VCC_SM_LF VCC_SM_LF VCC_SM_LF VCC_SM_LF

VCC SM LF

7 OF 10

W28 V28 W26 V26 W25 V25 W24 V24 W23 V23 AM21 AL21 AK21 W21 V21 U21 AM20 AK20 W20 U20 AM19 AL19 AK19 AJ19 AH19 AG19 AF19 AE19 AB19 AA19 Y19 W19 V19 U19 AM17 AK17 AH17 AG17 AF17 AE17 AC17 AB17 Y17 W17 V17 AM16 AL16 AK16 AJ16 AH16 AG16 AF16 AE16 AC16 AB16 AA16 Y16 W16 V16 U16

AV44 BA37 AM40 AV21 AY5 AM10 BB13

SM_LF1_GMCH SM_LF2_GMCH SM_LF3_GMCH SM_LF4_GMCH SM_LF5_GMCH SM_LF6_GMCH SM_LF7_GMCH

U53G

+1.8V

D

+1.05VS

VCC_AXG_SENSE

TP3TPAD14-GP TP3TPAD14-GP

1

VSS_AXG_SENSE

TP2TPAD14-GP TP2TPAD14-GP

1

U53G

AP33

VCC_SM

AN33

VCC_SM

BH32

VCC_SM

BG32

VCC_SM

BF32

VCC_SM

BD32

VCC_SM

BC32

VCC_SM

BB32

VCC_SM

BA32

VCC_SM

AY32

VCC_SM

AW32

VCC_SM

AV32

VCC_SM

AU32

VCC_SM

AT32

VCC_SM

AR32

VCC_SM

AP32

VCC_SM

AN32

VCC_SM

BH31

VCC_SM

BG31

VCC_SM

BF31

VCC_SM

BG30

VCC_SM

BH29

VCC_SM

BG29

VCC_SM

BF29

VCC_SM

BD29

VCC_SM

BC29

VCC_SM

BB29

VCC_SM

BA29

VCC_SM

AY29

VCC_SM

AW29

VCC_SM

AV29

VCC_SM

AU29

VCC_SM

AT29

VCC_SM

AR29

VCC_SM

AP29

VCC_SM

BA36

VCC_SM/NC

BB24

VCC_SM/NC

BD16

VCC_SM/NC

BB21

VCC_SM/NC

AW16

VCC_SM/NC

AW13

VCC_SM/NC

AT13

VCC_SM/NC

Y26

VCC_AXG

AE25

VCC_AXG

AB25

VCC_AXG

AA25

VCC_AXG

AE24

VCC_AXG

AC24

VCC_AXG

AA24

VCC_AXG

Y24

VCC_AXG

AE23

VCC_AXG

AC23

VCC_AXG

AB23

VCC_AXG

AA23

VCC_AXG

AJ21

VCC_AXG

AG21

VCC_AXG

AE21

VCC_AXG

AC21

VCC_AXG

AA21

VCC_AXG

Y21

VCC_AXG

AH20

VCC_AXG

AF20

VCC_AXG

AE20

VCC_AXG

AC20

VCC_AXG

AB20

VCC_AXG

AA20

VCC_AXG

T17

VCC_AXG

T16

VCC_AXG

AM15

VCC_AXG

AL15

VCC_AXG

AE15

VCC_AXG

AJ15

VCC_AXG

AH15

VCC_AXG

AG15

VCC_AXG

AF15

VCC_AXG

AB15

VCC_AXG

AA15

VCC_AXG

Y15

VCC_AXG

V15

VCC_AXG

U15

VCC_AXG

AN14

VCC_AXG

AM14

VCC_AXG

U14

VCC_AXG

T14

VCC_AXG

AJ14

VCC_AXG_SENSE

AH14

VSS_AXG_SENSE

CANTIGA-GM-GP-U-NF

VCC SMVCC GFX

4

+1.05VS

C109

C110

C122

12

1

SCD47U16V2ZY-GP

2

Place on the Edge Coupling CAP

Place CAP where LVDS and DDR2 taps

C142

SCD47U16V2ZY-GP

C52

C76

C71

12

SCD1U10V2KX-4GP

C89

12

SCD01U16V2KX-3GP

SC10U10V5ZY-1GP

FOR VCC SM

1

2

C107

12

SCD22U10V2KX-1GP

12

DY

C154

C150

12

1

SCD47U6D3V2KX-GP

SCD22U10V2KX-1GP

SC1U10V3KX-3GP

2

3

+1.05VS

C90

BC1

TC18

C80

12

1

ST220U2VBM-3GP

2

12

C130

TC7

ST220U2VBM-3GP

SC22U6D3V5MX-2GP

DY

BC1

C78

12

SCD47U16V2ZY-GP

12

C151

SC10U10V5ZY-1GP

C78

12

1

SC22U6D3V5MX-2GP

SC1U10V3KX-3GP

SCD47U16V2ZY-GP

2

+1.8V

Place on the Edge

C155

12

SC1U10V3KX-3GP

FOR VCC CORE

C149

C135

C134

C141

12

SCD01U16V2KX-3GP

12

1

SCD47U16V2ZY-GP

2

1

SC22U6D3V5MX-2GP

SCD01U16V2KX-3GP

DY

2

Coupling CAP 370 mils from the Edge

C123

12

SC10U10V5ZY-1GP

Coupling CAP

C140

1

SCD47U16V2ZY-GP

2

C124

12

SCD01U16V2KX-3GP

C136

SCD47U16V2ZY-GP

1 2

0R0402-PAD

12

R51

C138

SCD01U16V2KX-3GP

VCC_GMCH_35

2

6 OF 10

VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF

POWER

VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF

VCC NCTF

VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF VCC_NCTF

6 OF 10

+1.05VS

AM32 AL32 AK32 AJ32 AH32 AG32 AE32 AC32 AA32 Y32 W32 U32 AM30 AL30 AK30 AH30 AG30 AF30 AE30 AC30 AB30 AA30 Y30 W30 V30 U30 AL29 AK29 AJ29 AH29 AG29 AE29 AC29 AA29 Y29 W29 V29 AL28 AK28 AL26 AK26 AK25 AK24 AK23

U53F

AG34

VCC

AC34

VCC

AB34

VCC

AA34

VCC

Y34

VCC

V34

VCC

U34

VCC

AM33

VCC

AK33

VCC

AJ33

VCC

AG33

VCC

AF33

VCC

AE33

VCC

AC33

VCC

AA33

VCC

Y33

VCC

W33

VCC

V33

VCC

U33

VCC

AH28

VCC

AF28

VCC

AC28

VCC

AA28

VCC

AJ26

VCC

AG26

VCC

AE26

VCC

AC26

VCC

AH25

VCC

AG25

VCC

AF25

VCC

AG24

VCC

AJ23

VCC

AH23

VCC

AF23

VCC

T32

VCC

CANTIGA-GM-GP-U-NF

VCC CORE

1

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Num ber Rev

http://laptop-motherboard-schematic.blogspot.com/

5

4

3

2

Size Document Num ber Rev

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

Cantiga (4 of 6)

HBU16 1.2

1

of

941Tuesday, June 30, 2009

of

941Tuesday, June 30, 2009

of

941Tuesday, June 30, 2009

A

+1.05VS

R263

0R0603-PAD

D D

R265

0R0603-PAD

+1.05VS

R223

R223 0R0603-PAD

0R0603-PAD

FCM1608KF-1-GP

1 2

L17

1 2

120ohm 100MHz

SC4D7U6D3V3MX-2GP

FCM1608KF-1-GP

FCM1608KF-1-GP L16

L16

1 2

120ohm 100MHz

C C

+1.05VS

L26

1 2

FCM1608CF-221T02-GP

220ohm 100MHz

SC10U6D3V5MX-3GP

+1.5VS

0R0603-PAD

B B

0R0603-PAD

SCD022U16V2KX-3GP

PBY160808T-181Y-GP

180ohm 100MHz

12

1

2

12

SC10U6D3V5MX-3GP

C476

DY

R291

12

L27

1 2

SC1U10V3ZY-6GP

+3VS_DAC_LDO

SC10U10V5ZY-1GP

5

C462

SCD47U16V2ZY-GP

C453

SCD01U16V2KX-3GP

DY

12

C382

DY

12

C41

DY

12

1D5VRUN_TVDAC

C471

12

C470

SCD01U16V2KX-3GP

C447

C445

C452

SCD01U16V2KX-3GP

12

DY

M_VCCA_DPLLB

C458

C463

SCD1U10V2KX-4GP

12

DY

M_VCCA_HPLL

12

C387

C387 SCD01U16V2KX-3GP

SCD01U16V2KX-3GP

M_VCCA_MPLL

12

C386

C386 SCD01U16V2KX-3GP

SCD01U16V2KX-3GP

1D05V_RUN_PEGPLL

12

C451

C451 SCD01U16V2KX-3GP

SCD01U16V2KX-3GP

12

C474

SCD1U10V2KX-4GP

+5VS

12

SCD1U10V2KX-4GP

+3VS_DAC_LDO

SCD1U10V2KX-4GP

1D5VRUN_QDAC

12

C473

SCD1U10V2KX-4GP

U57

1

EN

2

GND

3

VIN

4

VOUT

5

NC#5

G9091-330T12U-GP

M_VCCA_DPLLA

C457

C462

Reserved for TV ripple

5

+3VS_DAC_LDO

10mA

R249

0R0603-PAD

180ohm 100MHz

+1.5VS

+1.05VS

+1.5VS

R253

1 2

0R0402-PAD

4

3

2

80mA

R250

12

0R0603-PAD

12

180ohm 100MHz

M_VCCA_DAC_BG

C433

C432

12

SCD01U16V2KX-3GP

SC1KP50V2KX-1GP

R270

1 2

0R0402-PAD

R42

12

0R0603-PAD

12

DY

12

R46

R46 0R0603-PAD

0R0603-PAD

C119

SC10U10V5ZY-1GP

L22

PBY160808T-181Y-GP

12

C443

C443 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

+1.05VS

SCD01U16V2KX-3GP

3D3V_CRTDAC_S0

C438

SCD01U16V2KX-3GP

12

SCD1U10V2KX-4GP

C101

C88

SC22U6D3V5MX-2GP

12

3D3VTVDAC+3VS_DAC_LDO

12

VCC_HDA

12

R163

R163 0R0603-PAD

0R0603-PAD

+1.8V

C439

12

+1.8V

C456

DY

C91

SC10U10V5ZY-1GP

12

DY

12

C129

DY

C423

12

1D5VRUN_TVDAC 1D5VRUN_QDAC

C390

R60

0R0603-PAD

12

SCD1U10V2KX-4GP

M_VCCA_DAC_BG

R262

1 2

12

0R0402-PAD

VCCA_PEG_BG

12

C468

C468 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

1D05V_RUN_PEGPLL 1D05V_SM

C105

SC4D7U6D3V3KX-GP

12

1D05V_SM_CK

12

C137

SCD01U16V2KX-3GP

SC2D2U6D3V3MX-1-GP

SCD1U10V2KX-4GP

12

C418

SCD01U16V2KX-3GP

1D05V_RUN_HPLL

12

1D8V_SUS_DLVDS

12

C152

SCD1U10V2KX-4GP

DY

M_VCCA_DPLLA M_VCCA_DPLLB M_VCCA_HPLL M_VCCA_MPLL

1D8V_TXLVDS

SC1U10V3KX-3GP

VCC_HDA

1D05V_RUN_PEGPLL

12

C455

C455 SCD01U16V2KX-3GP

SCD01U16V2KX-3GP

U53H

B27

VCCA_CRT_DAC

A26

VCCA_CRT_DAC

A25

VCCA_DAC_BG

B25

VSSA_DAC_BG

F47

VCCA_DPLLA

L48

VCCA_DPLLB

AD1

VCCA_HPLL

AE1

VCCA_MPLL

J48

VCCA_LVDS

J47

VSSA_LVDS

AD48

VCCA_PEG_BG

AA48

VCCA_PEG_PLL

AR20

VCCA_SM

AP20

VCCA_SM

AN20

VCCA_SM

AR17

VCCA_SM

AP17

VCCA_SM

AN17

VCCA_SM

AT16

VCCA_SM

AR16

VCCA_SM

AP16

VCCA_SM

AP28

VCCA_SM_CK

AN28

VCCA_SM_CK

AP25

VCCA_SM_CK

AN25

VCCA_SM_CK

AN24

VCCA_SM_CK

AM28

VCCA_SM_CK_NCTF

AM26

VCCA_SM_CK_NCTF

AM25

VCCA_SM_CK_NCTF

AL25

VCCA_SM_CK_NCTF

AM24

VCCA_SM_CK_NCTF

AL24

VCCA_SM_CK_NCTF

AM23

VCCA_SM_CK_NCTF

AL23

VCCA_SM_CK_NCTF

B24

VCCA_TV_DAC

A24

VCCA_TV_DAC

A32

VCC_HDA

M25

VCCD_TVDAC

L28

VCCD_QDAC

AF1

VCCD_HPLL

AA47

VCCD_PEG_PLL

M38

VCCD_LVDS

L37

VCCD_LVDS

CANTIGA-GM-GP-U-NF

CRTPLLA PEGA SM

A LVDS

POWER

A CK

TV

HDA

D TV/CRT

LVDS

AXF

VCC_SM_CK VCC_SM_CK VCC_SM_CK VCC_SM_CK

SM CK

VCC_TX_LVDS

HV

PEG

DMI

8 OF 10

VTT

VCC_AXF VCC_AXF VCC_AXF

VCC_HV VCC_HV VCC_HV

VCC_PEG VCC_PEG VCC_PEG VCC_PEG VCC_PEG

VCC_DMI VCC_DMI VCC_DMI VCC_DMI

VTTLF VTTLF VTTLF

VTTLF

VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT VTT

U13 T13 U12 T12 U11 T11 U10 T10 U9 T9 U8 T8 U7 T7 U6 T6 U5 T5 V3 U3 V2 U2 T2 V1 U1

B22 B21 A21

BF21 BH20 BG20 BF20

K47 C35

B35 A35

V48 U48 V47 U47 U46

AH48 AF48 AH47 AG47

A8 L1 AB2

12

C51

SCD01U16V2KX-3GP

+1.05VS +3VS +3VS_HV

350mA

+3VS_HV

106mA

C454

1D05V_VCC_DMI

VTTLF1 VTTLF2 VTTLF3

1

C389

2

12

DY

1

2

SCD47U6D3V2KX-GP

D27

D27 BAT54-7-F-GP

BAT54-7-F-GP

1

3

1D05V_VCC_AXF

C411

SC1U10V3KX-3GP

1D8V_SM_CK

1

2

SC1KP50V2KX-1GP

1782mA

SC4D7U6D3V3KX-GP

C461

456mA

1

C388

2

SCD47U6D3V2KX-GP

http://laptop-motherboard-schematic.blogspot.com/

4

3

2

12

C75

C59

SC1U10V3KX-3GP

2

12

C406

DY

SC10U6D3V5MX-3GP

C108

SCD47U16V2ZY-GP

1D8V_TXLVDS_S3

C464

DY

SC10U10V5ZY-1GP

12

DY

12

C460

SCD1U10V2KX-4GP

C393

SCD47U6D3V2KX-GP

1

852mA

12

C72

SCD01U16V2KX-3GP

R261

R261 10R2J-2-GP

10R2J-2-GP

R307

R307 0R0603-PAD

0R0603-PAD

200mA

1 2

R40

R40 1R2F-GP

1R2F-GP

12

EC37

SC1U10V3KX-3GP

12

+1.05VS

12

C102

C102 SC10U6D3V5MX-3GP

SC10U6D3V5MX-3GP

1 2

12

TC15

TC15 ST220U2D5VBM-LGP

ST220U2D5VBM-LGP

DY

R259

R259 0R0402-PAD

0R0402-PAD

1 2

100mA

12

+VCC_PEG

C466

DY

Title

Size Document Number Rev

Date: Sheet

Date: Sheet of

12

C469

DY

SC22U6D3V5MX-2GP

R269

SC10U10V5ZY-1GP

12

R269

12

C465

C465 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

+VCC_PEG

R308

12

0R0603-PAD

Cantiga (5 of 6)

0R0603-PAD

+1.05VS

12

C446

C446 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

+1.8V

R440

R440 0R0805-PAD

0R0805-PAD

+1.8V

R264

12

0R0603-PAD

+1.05VS

12

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

of

10 41Tuesday, June 30, 2009

1

A

1

5

A

U53I

AU48

VSS

AR48

VSS

AL48

VSS

BB47

VSS

AW47

VSS

AN47

VSS

AJ47

VSS

D D

C C

B B

AF47

VSS

AD47

VSS

AB47

VSS

Y47

VSS

T47

VSS

N47

VSS

L47

VSS

G47

VSS

BD46

VSS

BA46

VSS

AY46

VSS

AV46

VSS

AR46

VSS

AM46

VSS

V46

VSS

R46

VSS

P46

VSS

H46

VSS

F46

VSS

BF44

VSS

AH44

VSS

AD44

VSS

AA44

VSS

Y44

VSS

U44

VSS

T44

VSS

M44

VSS

F44

VSS

BC43

VSS

AV43

VSS

AU43

VSS

AM43

VSS

J43

VSS

C43

VSS

BG42

VSS

AY42

VSS

AT42

VSS

AN42

VSS

AJ42

VSS

AE42

VSS

N42

VSS

L42

VSS

BD41

VSS

AU41

VSS

AM41

VSS

AH41

VSS

AD41

VSS

AA41

VSS

Y41

VSS

U41

VSS

T41

VSS

M41

VSS

G41

VSS

B41

VSS

BG40

VSS

BB40

VSS

AV40

VSS

AN40

VSS

H40

VSS

E40

VSS

AT39

VSS

AM39

VSS

AJ39

VSS

AE39

VSS

N39

VSS

L39

VSS

B39

VSS

BH38

VSS

BC38

VSS

BA38

VSS

AU38

VSS

AH38

VSS

AD38

VSS

AA38

VSS

Y38

VSS

U38

VSS

T38

VSS

J38

VSS

F38

VSS

C38

VSS

BF37

VSS

BB37

VSS

AW37

VSS

AT37

VSS

AN37

VSS

AJ37

VSS

H37

VSS

C37

VSS

BG36

VSS

BD36

VSS

AK15

VSS

AU36

VSS

CANTIGA-GM-GP-U-NF

Modification AJ6 to reserved Pin

VSS

http://laptop-motherboard-schematic.blogspot.com/

5

4

9 OF 10

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

4

AM36 AE36 P36 L36 J36 F36 B36 AH35 AA35 Y35 U35 T35 BF34 AM34 AJ34 AF34 AE34 W34 B34 A34 BG33 BC33 BA33 AV33 AR33 AL33 AH33 AB33 P33 L33 H33 N32 K32 F32 C32 A31 AN29 T29 N29 K29 H29 F29 A29 BG28 BD28 BA28 AV28 AT28 AR28 AJ28 AG28 AE28 AB28 Y28 P28 K28 H28 F28 C28 BF26 AH26 AF26 AB26 AA26 C26 B26 BH25 BD25 BB25 AV25 AR25 AJ25 AC25 Y25 N25 L25 J25 G25 E25 BF24 AD12 AY24 AT24 AJ24 AH24 AF24 AB24 R24 L24 K24 J24 G24 F24 E24 BH23 AG23 Y23 B23 A23 AJ6

R29

1 2

0R0402-PAD

3

10 OF 10

VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF VSS_NCTF

VSS NCTF

VSS_NCTF VSS_NCTF

VSS SCB

NC

10 OF 10

VSS_SCB VSS_SCB VSS_SCB VSS_SCB VSS_SCB

NC#A43 NC#A44 NC#B45 NC#C46 NC#D47 NC#B47 NC#A46 NC#F48 NC#E48 NC#C48 NC#B48

U53J

BG21

VSS

L12

VSS

AW21

VSS

AU21

VSS

AP21

VSS

AN21

VSS

AH21

VSS

AF21

VSS

AB21

VSS

R21

VSS

M21

VSS

J21

VSS

G21

VSS

BC20

VSS

BA20

VSS

AW20

VSS

AT20

VSS

AJ20

VSS

AG20

VSS

Y20

VSS

N20

VSS

K20

VSS

F20

VSS

C20

VSS

A20

VSS

BG19

VSS

A18

VSS

BG17

VSS

BC17

VSS

AW17

VSS

AT17

VSS

R17

VSS

M17

VSS

H17

VSS

C17

VSS

BA16

VSS

AU16

VSS

AN16

VSS

N16

VSS

K16

VSS

G16

VSS

E16

VSS

BG15

VSS

AC15

VSS

W15

VSS

A15

VSS

BG14

VSS

AA14

VSS

C14

VSS

BG13

VSS

BC13

VSS

BA13

VSS

AN13

VSS

AJ13

VSS

AE13

VSS

N13

VSS

L13

VSS

G13

VSS

E13

VSS

BF12

VSS

AV12

VSS

AT12

VSS

AM12

VSS

AA12

VSS

J12

VSS

A12

VSS

BD11

VSS

BB11

VSS

AY11

VSS

AN11

VSS

AH11

VSS

Y11

VSS

N11

VSS

G11

VSS

C11

VSS

BG10

VSS

AV10

VSS

AT10

VSS

AJ10

VSS

AE10

VSS

AA10

VSS

M10

VSS

BF9

VSS

BC9

VSS

AN9

VSS

AM9

VSS

AD9

VSS

G9

VSS

B9

VSS

BH8

VSS

BB8

VSS

AV8

VSS

AT8

VSS

CANTIGA-GM-GP-U-NF

VSS

3

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

VSS VSS VSS VSS

NC#E1 NC#D2 NC#C3 NC#B4 NC#A5 NC#A6

AH8 Y8 L8 E8 B8 AY7 AU7 AN7 AJ7 AE7 AA7 N7 J7 BG6 BD6 AV6 AT6 AM6 M6 C6 BA5 AH5 AD5 Y5 L5 J5 H5 F5 BE4

BC3 AV3 AL3 R3 P3 F3 BA2 AW2 AU2 AR2 AP2 AJ2 AH2 AF2 AE2 AD2 AC2 Y2 M2 K2 AM1 AA1 P1 H1

U24 U28 U25 U29

AF32 AB32 V32 AJ30 AM29 AF29 AB29 U26 U23 AL20 V20 AC19 AL17 AJ17 AA17 U17

BH48 BH1 A48 C1 A3

E1 D2 C3 B4 A5 A6 A43 A44 B45 C46 D47 B47 A46 F48 E48 C48 B48

2

GMCH_GND1 GMCH_GND2 GMCH_GND3 GMCH_GND4

1

TP49 TPAD14-GPTP49 TPAD14-GP

1

TP46 TPAD14-GPTP46 TPAD14-GP

1

TP50 TPAD14-GPTP50 TPAD14-GP

1

TP47 TPAD14-GPTP47 TPAD14-GP

1

Title

Size Document Number Rev

Date: Sheet of

NCTF PIN

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Cantiga (6 of 6)

HBU16 1.2

11 41Tuesday, June 30, 2009

1

A

1

5

M_A_DQS#[7..0]8

M_A_DQ[63..0]8 M_A_DM[7..0]8 M_A_DQS[7..0]8 M_A_A[14..0]8

D D

C C

B B

A A

Layout Note: Place near DM1

+1.8V

C87

C118

C74

C94

12

DY

SC4D7U6D3V3KX-GP

C55

C65

12

DY

SCD1U16V2ZY-2GP

RN44 SRN56J-4-GPRN44 SRN56J-4-GP

1 2 3

RN41 SRN56J-4-GPRN41 SRN56J-4-GP

1 2 3

RN6 SRN56J-4-GPRN6 SRN56J-4-GP

1 2 3

RN18 SRN56J-4-GPRN18 SRN56J-4-GP

1 2 3

RN40 SRN56J-4-GPRN40 SRN56J-4-GP

1 2 3

RN39 SRN56J-4-GPRN39 SRN56J-4-GP

1 2 3

RN21 SRN56J-4-GPRN21 SRN56J-4-GP

1 2 3

5

C94

DY

SC2D2U10V3ZY-1GP

C48

12

4

12

SC4D7U6D3V3KX-GP

Layout Note: Place one cap close to every 2 pullup resistors terminated to +0.9VS

+0.9VS

C84

12

DY

SCD1U16V2ZY-2GP

M_A_A12 M_A_BS#2

M_A_BS#0 M_A_A10

M_ODT0 M_CS0#

M_A_A14 M_A_A11

M_A_CAS# M_A_WE#

M_ODT1 M_CS1#

M_CKE1 M_A_A4 M_A_A7

12

DY

SCD1U16V2ZY-2GP

+0.9VS

C53

SC2D2U10V3ZY-1GP

C98

12

C87

12

DY

SC4D7U6D3V3KX-GP

C398

C405

12

DY

SCD1U16V2ZY-2GP

RN45 SRN56J-4-GPRN45 SRN56J-4-GP

1

4

23

RN43 SRN56J-4-GPRN43 SRN56J-4-GP

1

4

23

RN15 SRN56J-4-GPRN15 SRN56J-4-GP

1

4

23

RN42 SRN56J-4-GPRN42 SRN56J-4-GP

1

4

23

RN9 SRN56J-4-GPRN9 SRN56J-4-GP

1

4

23

RN3 SRN56J-4-GPRN3 SRN56J-4-GP

1

4

23

RN12 SRN56J-4-GPRN12 SRN56J-4-GP

1

4

23

C106

SCD1U16V2ZY-2GP

DY

SCD1U16V2ZY-2GP

M_CKE0

M_A_A8 M_A_A9

M_A_A6 M_A_A5

M_A_A1 M_A_A3

M_A_A2 M_A_A13

M_A_BS#1 M_A_RAS#

M_A_A0

12

C397

C111

1

2

SCD1U16V2ZY-2GP

4

M_A_BS#28 M_A_BS#08

M_A_BS#18

C58

TC2

C63

12

SCD1U16V2ZY-2GP

SCD47U16V2ZY-GP

C410

C419

12

DY

SCD1U16V2ZY-2GP

TC2

12

DY

ST220U2D5VBM-LGP

SCD1U16V2ZY-2GP

C115

C427

12

SCD1U16V2ZY-2GP

Layout Note: Place these resistors closely DM1,all trace length Max=1.5"

C392

SCD1U16V2ZY-2GP

DDR_VREF_S3

http://laptop-motherboard-schematic.blogspot.com/

4

3

M_ODT07

M_ODT17

12

C467

SCD1U16V2ZY-2GP

3

M_A_A0 M_A_A1 M_A_A2 M_A_A3 M_A_A4 M_A_A5 M_A_A6 M_A_A7 M_A_A8 M_A_A9 M_A_A10 M_A_A11 M_A_A12 M_A_A13 M_A_A14

M_A_BS#2 M_A_BS#0

M_A_BS#1 M_A_DQ0

M_A_DQ1 M_A_DQ2 M_A_DQ3 M_A_DQ4 M_A_DQ5 M_A_DQ6 M_A_DQ7 M_A_DQ8 M_A_DQ9 M_A_DQ10 M_A_DQ11 M_A_DQ12 M_A_DQ13 M_A_DQ14 M_A_DQ15 M_A_DQ16 M_A_DQ17 M_A_DQ18 M_A_DQ19 M_A_DQ20 M_A_DQ21 M_A_DQ22 M_A_DQ23 M_A_DQ24 M_A_DQ25 M_A_DQ26 M_A_DQ27 M_A_DQ28 M_A_DQ29 M_A_DQ30 M_A_DQ31 M_A_DQ32 M_A_DQ33 M_A_DQ34 M_A_DQ35 M_A_DQ36 M_A_DQ37 M_A_DQ38 M_A_DQ39 M_A_DQ40 M_A_DQ41 M_A_DQ42 M_A_DQ43 M_A_DQ44 M_A_DQ45 M_A_DQ46 M_A_DQ47 M_A_DQ48 M_A_DQ49 M_A_DQ50 M_A_DQ51 M_A_DQ52 M_A_DQ53 M_A_DQ54 M_A_DQ55 M_A_DQ56 M_A_DQ57 M_A_DQ58 M_A_DQ59 M_A_DQ60 M_A_DQ61 M_A_DQ62 M_A_DQ63

M_A_DQS#0 M_A_DQS#1 M_A_DQS#2 M_A_DQS#3 M_A_DQS#4 M_A_DQS#5 M_A_DQS#6 M_A_DQS#7

M_A_DQS0 M_A_DQS1 M_A_DQS2 M_A_DQS3 M_A_DQS4 M_A_DQS5 M_A_DQS6 M_A_DQS7

M_ODT0 M_ODT1

SC2D2U10V3ZY-1GP

12

C448

DM2

102

A0

101

A1

100

A2

99

A3

98

A4

97

A5

94

A6

92

A7

93

A8

91

A9

105

A10/AP

90

A11

89

A12

116

A13

86

A14

84

A15

85

A16/BA2

107

BA0

106

BA1

5

DQ0

7

DQ1

17

DQ2

19

DQ3

4

DQ4

6

DQ5

14

DQ6

16

DQ7

23

DQ8

25

DQ9

35

DQ10

37

DQ11

20

DQ12

22

DQ13

36

DQ14

38

DQ15

43

DQ16

45

DQ17

55

DQ18

57

DQ19

44

DQ20

46

DQ21

56

DQ22

58

DQ23

61

DQ24

63

DQ25

73

DQ26

75

DQ27

62

DQ28

64

DQ29

74

DQ30

76

DQ31

123

DQ32

125

DQ33

135

DQ34

137

DQ35

124

DQ36

126

DQ37

134

DQ38

136

DQ39

141

DQ40

143

DQ41

151

DQ42

153

DQ43

140

DQ44

142

DQ45

152

DQ46

154

DQ47

157

DQ48

159

DQ49

173

DQ50

175

DQ51

158

DQ52

160

DQ53

174

DQ54

176

DQ55

179

DQ56

181

DQ57

189

DQ58

191

DQ59

180

DQ60

182

DQ61

192

DQ62

194

DQ63

11

/DQS0

29

/DQS1

49

/DQS2

68

/DQS3

129

/DQS4

146

/DQS5

167

/DQS6

186

/DQS7

13

DQS0

31

DQS1

51

DQS2

70

DQS3

131

DQS4

148

DQS5

169

DQS6

188

DQS7

114

ODT0

119

ODT1

1

VREF

2

VSS

202

GND

DDR2-200P-36-GP-U1

1st: 62.10017.E11 2nd: 62.10017.691

DM2

3nd: 62.10017.891

/RAS /CAS

/CS0 /CS1

CKE0 CKE1

/CK0

/CK1 DM0

DM1 DM2 DM3 DM4 DM5 DM6 DM7

VDDSPD

NC#50 NC#69 NC#83

NC#120

NC#163/TEST

VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD

GND

2

108 109

/WE

113 110

115 79

80

M_CLK_DDR0

30

CK0

CK1

SDA SCL

SA0 SA1

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

32 164

166 10

26 52 67 130 147 170 185

195 197

199 198

200 50

69 83 120 163

81 82 87 88 95 96 103 104 111 112 117 118

3 8 9 12 15 18 21 24 27 28 33 34 39 40 41 42 47 48 53 54 59 60 65 66 71 72 77 78 121 122 127 128 132 133 138 139 144 145 149 150 155 156 161 162 165 168 171 172 177 178 183 184 187 190 193 196

201

2

M_CLK_DDR#0 M_CLK_DDR1

M_CLK_DDR#1 M_A_DM0

M_A_DM1 M_A_DM2 M_A_DM3 M_A_DM4 M_A_DM5 M_A_DM6 M_A_DM7

ICH_SMBDATA ICH_SMBCLK

RN2

1 2 3

+1.8V

M_CLK_DDR#1 7

SRN10KJ-11-GP-U

4

Title

Size Document Number Rev

Size Document Number Rev Custom

Custom

Custom Date: Sheet

Date: Sheet

M_CLK_DDR0 M_CLK_DDR#0

M_A_RAS# 8

M_A_WE# 8

M_A_CAS# 8 M_CS0# 7

M_CS1# 7 M_CKE0 7

M_CKE1 7 M_CLK_DDR0 7

M_CLK_DDR#0 7 M_CLK_DDR1 7

ICH_SMBDATA 13,16,21,26 ICH_SMBCLK 13,16,21,26

SCD1U16V2ZY-2GP

PM_EXTTS#0 7

DDRII-SODIMM SLOT1

C37

1 2

DUMMY-C2

C36

1 2

DUMMY-C2

12

C18

DY

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

1

C153

C153 DUMMY-C2

DUMMY-C2

12

put near connector

+3VS

12

C15

C15 SC2D2U10V3ZY-1GP

SC2D2U10V3ZY-1GP

of

12 41Thursday, July 09, 2009

of

12 41Thursday, July 09, 2009

of

12 41Thursday, July 09, 2009

1

C156

C156 DUMMY-C2

DUMMY-C2

1

5

M_B_DQS#[7..0]8

M_B_DQ[63..0]8 M_B_DM[7..0]8 M_B_DQS[7..0]8

12

SCD1U16V2ZY-2GP

+0.9VS

M_B_A[14..0]8

C112

C95

12

SC4D7U6D3V3KX-GP

C99

12

SCD1U16V2ZY-2GP

RN5

RN20

RN17

RN14

RN13

RN8

RN19

SRN56J-4-GP

C95

12

C116

12

SCD1U16V2ZY-2GP

1 23

SRN56J-4-GP

1 23

SRN56J-4-GP

1 23

SRN56J-4-GP

1 23

SRN56J-4-GP

1 23

SRN56J-4-GP

1 23

SRN56J-4-GP

1 23

12

DY

SCD1U16V2ZY-2GP

C67

12

M_B_RAS# M_B_A13

M_B_A14 M_B_A11

M_B_A6M_B_A8 M_B_A7

M_B_A2 M_B_A4

M_B_A10 M_B_BS#0

M_CS2# M_ODT2

M_B_BS#2M_CKE3 M_B_A12

C394

SCD1U16V2ZY-2GP

C79

SC4D7U6D3V3KX-GP

C85

12

SCD1U16V2ZY-2GP

4

D D

C C

B B

A A

Layout Note: Place near DM2

+1.8V

C407

C399

12

C49

SCD1U16V2ZY-2GP

5

C407

12

SC2D2U10V3ZY-1GP

C56

12

DY

SCD1U16V2ZY-2GP

1 2 3

SC4D7U6D3V3KX-GP

C66

12

4

C54

12

DY

SC4D7U6D3V3KX-GP

Layout Note: Place one cap close to every 2 pullup resistors terminated to +0.9VS

+0.9VS

C45

12

DY

SCD1U16V2ZY-2GP

RN4 SRN56J-4-GPRN4 SRN56J-4-GP

M_B_CAS# M_B_WE#

RN22 SRN56J-4-GPRN22 SRN56J-4-GP

M_B_A9 M_CKE2

RN16 SRN56J-4-GPRN16 SRN56J-4-GP

M_B_A5

RN11 SRN56J-4-GPRN11 SRN56J-4-GP

M_B_A0 M_B_BS#1

RN10 SRN56J-4-GPRN10 SRN56J-4-GP

M_B_A3 M_B_A1

RN7 SRN56J-4-GPRN7 SRN56J-4-GP

M_CS3# M_ODT3

RN23 SRN56J-4-GPRN23 SRN56J-4-GP

4

C421

C64

12

DY

SCD1U16V2ZY-2GP

C86

12

DY

SCD1U16V2ZY-2GP

12

TC8

ST220U2D5VBM-LGP

C100

C117

12

SCD1U16V2ZY-2GP

Layout Note: Place these resistors closely DM2,all trace length Max=1.5"

DDR_VREF_S3

12

SCD1U16V2ZY-2GP

C57

C50

12

DY

SCD1U16V2ZY-2GP

http://laptop-motherboard-schematic.blogspot.com/

4

M_B_BS#28 M_B_BS#08

M_B_BS#18

M_ODT27

M_ODT37

DDR_VREF_S3

C163

SCD1U16V2ZY-2GP

3

12

3

M_B_A0 M_B_A1 M_B_A2 M_B_A3 M_B_A4 M_B_A5 M_B_A6 M_B_A7 M_B_A8 M_B_A9 M_B_A10 M_B_A11 M_B_A12 M_B_A13 M_B_A14

M_B_BS#2 M_B_BS#0

M_B_BS#1 M_B_DQ0

M_B_DQ1 M_B_DQ2 M_B_DQ3 M_B_DQ4 M_B_DQ5 M_B_DQ6 M_B_DQ7 M_B_DQ8 M_B_DQ9 M_B_DQ10 M_B_DQ11 M_B_DQ12 M_B_DQ13 M_B_DQ14 M_B_DQ15 M_B_DQ16 M_B_DQ17 M_B_DQ18 M_B_DQ19 M_B_DQ20 M_B_DQ21 M_B_DQ22 M_B_DQ23 M_B_DQ24 M_B_DQ25 M_B_DQ26 M_B_DQ27 M_B_DQ28 M_B_DQ29 M_B_DQ30 M_B_DQ31 M_B_DQ32 M_B_DQ33 M_B_DQ34 M_B_DQ35 M_B_DQ36 M_B_DQ37 M_B_DQ38 M_B_DQ39 M_B_DQ40 M_B_DQ41 M_B_DQ42 M_B_DQ43 M_B_DQ44 M_B_DQ45 M_B_DQ46 M_B_DQ47 M_B_DQ48 M_B_DQ49 M_B_DQ50 M_B_DQ51 M_B_DQ52 M_B_DQ53 M_B_DQ54 M_B_DQ55 M_B_DQ56 M_B_DQ57 M_B_DQ58 M_B_DQ59 M_B_DQ60 M_B_DQ61 M_B_DQ62 M_B_DQ63

M_B_DQS#0 M_B_DQS#1 M_B_DQS#2 M_B_DQS#3 M_B_DQS#4 M_B_DQS#5 M_B_DQS#6 M_B_DQS#7

M_B_DQS0 M_B_DQS1 M_B_DQS2 M_B_DQS3 M_B_DQS4 M_B_DQS5 M_B_DQS6 M_B_DQS7

M_ODT2 M_ODT3

SC2D2U10V3ZY-1GP

12

C162

DY

DM1

102

A0

101

A1

100

A2

99

A3

98

A4

97

A5

94

A6

92

A7

93

A8

91

A9

105

A10/AP

90

A11

89

A12

116

A13

86

A14

84

A15

85

A16/BA2

107

BA0

106

BA1

5

DQ0

7

DQ1

17

DQ2

19

DQ3

4

DQ4

6

DQ5

14

DQ6

16

DQ7

23

DQ8

25

DQ9

35

DQ10

37

DQ11

20

DQ12

22

DQ13

36

DQ14

38

DQ15

43

DQ16

45

DQ17

55

DQ18

57

DQ19

44

DQ20

46

DQ21

56

DQ22

58

DQ23

61

DQ24

63

DQ25

73

DQ26

75

DQ27

62

DQ28

64

DQ29

74

DQ30

76

DQ31

123

DQ32

125

DQ33

135

DQ34

137

DQ35

124

DQ36

126

DQ37

134

DQ38

136

DQ39

141

DQ40

143

DQ41

151

DQ42

153

DQ43

140

DQ44

142

DQ45

152

DQ46

154

DQ47

157

DQ48

159

DQ49

173

DQ50

175

DQ51

158

DQ52

160

DQ53

174

DQ54

176

DQ55

179

DQ56

181

DQ57

189

DQ58

191

DQ59

180

DQ60

182

DQ61

192

DQ62

194

DQ63

11

/DQS0

29

/DQS1

49

/DQS2

68

/DQS3

129

/DQS4

146

/DQS5

167

/DQS6

186

/DQS7

13

DQS0

31

DQS1

51

DQS2

70

DQS3

131

DQS4

148

DQS5

169

DQS6

188

DQS7

114

ODT0

119

ODT1

1

VREF

2

VSS

202

GND

DDR2-200P-25-GP-U2

1st: 62.10017.B51

DM1

2nd: 62.10017.E81

CKE0 CKE1

VDDSPD

NC#50 NC#69 NC#83

NC#120

NC#163/TEST

/RAS /CAS /CS0

/CS1

/CK0

/CK1 DM0

DM1 DM2 DM3 DM4 DM5 DM6 DM7

SDA

VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD

GND

2

108 109

/WE

113 110

115 79

80

M_CLK_DDR2

30

CK0

CK1

SCL

SA0 SA1

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

M_CLK_DDR#2

32

M_CLK_DDR3

164

M_CLK_DDR#3

166

M_B_DM0

10

M_B_DM1

26

M_B_DM2

52

M_B_DM3

67

M_B_DM4

130

M_B_DM5

147

M_B_DM6

170

M_B_DM7

185

ICH_SMBDATA

195

ICH_SMBCLK

197 199

R12 10KR2J-3-GPR12 10KR2J-3-GP

198 200

50 69 83 120 163

81 82 87 88 95 96 103 104 111 112 117 118

3 8 9 12 15 18 21 24 27 28 33 34 39 40 41 42 47 48 53 54 59 60 65 66 71 72 77 78 121 122 127 128 132 133 138 139 144 145 149 150 155 156 161 162 165 168 171 172 177 178 183 184 187 190 193 196

201

1 2

R11 10KR2J-3-GPR11 10KR2J-3-GP

1 2

+1.8V

2

M_B_WE# 8

M_CS3# 7 M_CKE2 7

PM_EXTTS#1 7

Title

Size Document Number Rev

Size Document Number Rev Custom

Custom

Custom Date: Sheet

Date: Sheet

M_CLK_DDR2 M_CLK_DDR#2

M_B_RAS# 8 M_B_CAS# 8 M_CS2# 7

M_CKE3 7 M_CLK_DDR2 7

M_CLK_DDR#2 7 M_CLK_DDR3 7

M_CLK_DDR#3 7

ICH_SMBDATA 12,16,21,26

ICH_SMBCLK 12,16,21,26

C17

SCD1U16V2ZY-2GP

+3VS

12

EC45

SCD1U25V3ZY-1GP

DDRII-SODIMM SLOT2

1

12

C157

C157 DUMMY-C2

DUMMY-C2

put near connector

C33

1 2

DUMMY-C2

DUMMY-C2 C32

C32

1 2

DUMMY-C2

12

+3VS

12

C14

C14 SC2D2U10V3ZY-1GP

SC2D2U10V3ZY-1GP

DY

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

1

12

13 41Thursday, July 09, 2009

C158

C158 DUMMY-C2

DUMMY-C2

of

1

A

CRT I/F & CONNECTOR

4 4

3 3

+5VS_CRT1

D17

DDC_DATA_CON

D17

1

2

3 4

BAV99S-GP

DY

6

5

DDC_CLK_CON RED

Layout Note: * Must be a ground return path bet ween this ground and the ground on the VGA connector. Pi-filter & 150 Ohm pull-down resistors should be as close as to CRT CONN. RGB will hit 75 Ohm first, pi-filter, then CRT CONN.

+3VS

GREEN

B

D23

1

2

3 4

BAV99S-GP

D5

3

BAV99-7-F-GP

DY

2

1

DY

+3VS

BLUE

6

5

+5VS_CRT1

JVGA_VS

C

SCD1U25V3ZY-1GP

RED7

GREEN7 BLUE7

D4

1

2

3 4

BAV99S-GP

DY

6

5

EC55

DY

D

F2

12

C370

SCD01U16V2KX-3GP

RED

GREEN BLUE

1st: 69.50007.691 2nd: 69.50007.771

1st: 20.20326.015

F2FUSE-PAD-GP

CRT1

6 1

7 2 8 3 9 4

10

5

SYN-CONN15-GP

12

17

11

12 13 14 15 16

SC33P50V2JN-3GP

JVGA_HS JVGA_VS

DY

C25

12

D18

C593

12

DY

C27

C27 SC33P50V2JN-3GP

SC33P50V2JN-3GP

D18

DDC_DATA_CON

DDC_CLK_CON

SC22P50V2JN-4GP

CH501H-40PT-1-GP-U

SCD1U16V2ZY-2GP

2nd: 20.20764.015

JVGA_HS

+3VS

E

+5VS+5VS_CRT

12

+5VS_CRT1

1

4

1

2 3

4

12

C19

DY

RN1

SRN2K2J-1-GP

23

RN37

SRN2K2J-1-GP

12

C23

DY

SC22P50V2JN-4GP

12

DY

+3VS

U41

DDC1_DATA7

2 2

U69

1

OE#

VCC

M_HSYNC7

M_VSYNC7

1 1

A

http://laptop-motherboard-schematic.blogspot.com/

2

A GND3Y

74AHCT1G125GW-1-GP

U70

1

OE#

VCC

2

A GND3Y

74AHCT1G125GW-1-GP

B

+5VS_CRT1

12

C385

C385 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

5

4

5

4

HSYNC_5

VSYNC_5

RN38

2 3 1

SRN33J-5-GP-U

JVGA_HS JVGA_VS

4

C

DDC_CLK_CON

D

U41

5 6

DMN66D0LDW-7-GP

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

DDC_DATA_CON

34 2 1

CRT Connector

DDC1_CLK 7

5V @ ext. CRT side

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

14 41Thursday, July 09, 2009

of

E

of

1

+5VS

R33

1 2

DY

330R2J-3-GP

CAPS_LED_PWR

White LED: Lite-On 83.00191.D70 Everlight 83.19217.F70

LID_CLOSE#29,31

SATA_LED#18

USB20_N1019

USB20_P1019

+LCDVDD

L_VDD_EN7

Q33

R2

B

R1

PDTA124EU-1-GP

Layout 40 mil

R203

100KR2J-1-GP

1 2

LED1

A K

DY

LED-W-12-GP-U

+3VL

12

DY

12

DY

+3VS

E C

12

R547

R547 10KR2J-3-GP

10KR2J-3-GP

R545

1 2

100R2J-2-GP

C610

C610 SCD22U10V2KX-1GP

SCD22U10V2KX-1GP

12

R230

R230 100KR2J-1-GP

100KR2J-1-GP

R27

1 2

0R0402-PAD

R28

1 2

0R0402-PAD

+3VS

12

BC2

EC14

SCD1U16V2ZY-2GP

SC1U10V3ZY-6GP

LCD / INVERTER INTERFACE / CAMERA

CAPS_LED# 28,29

DY

SATA_BD_LED_C SATA_LED#_C

U43

1

IN#1

2

OUT

3

EN

4

GND

G5281RC1U-GP

LID_CLOSE# COVER_SW GND GND

12

DY

USB_10-

USB_10+

GND IN#8 IN#7 IN#6 IN#5

1 1 1 1

COVER_SWLID_CLOSE#

C609

C609 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

U48

1 2 3 4

DMN66D0LDW-7-GP

9 8 7 6 5

TP187 TP28-75-GPTP187 TP28-75-GP TP188 TP28-75-GPTP188 TP28-75-GP TP189 TP28-75-GPTP189 TP28-75-GP TP190 TP28-75-GPTP190 TP28-75-GP

6 5

CAM_PWR#29

SCD1U16V2ZY-2GP

+LCDVDD

SATA_BD_LED 28 SATA_LED 29

SCD1U25V3ZY-1GP

CAM_PWR#

+LCDVDD

+3VS

C341

12

C354

SC10U10V5ZY-1GP

DY

+5VS +5VS_CAMERA

12

EC50

DY

1 2

R232 10KR2J-3-GP

L_VDD_EN

1 2

R202 100R2J-2-GPR202 100R2J-2-GP

12

DY

12

C348

SCD1U25V3ZY-1GP

DY

12

EC33

EC33 SCD1U25V3ZY-1GP

SCD1U25V3ZY-1GP

SCD1U16V2ZY-2GP

+5VS_CAMERA

EC34

+5VS_CAMERA USB_10+ USB_10GND

R229

R229 100KR2J-1-GP

100KR2J-1-GP

1 2

CAM_PWR_G#

1 2 3 4

DMN66D0LDW-7-GP

SIZE_DET129

+3VS

EC_BLON29

DDC2_CLK7

DDC2_DATA7

12

R551

1 2

DY

Q20

Q20 AO3403-GP

AO3403-GP

S

G

U46

1 2

R238 100KR2J-1-GPR238 100KR2J-1-GP

1 1 1 1

0R0603-PAD

D

SCD1U16V2ZY-2GP

12

DY

+3VS

1 2

6 5

BRIGHTNESS_CONN

COVER_SW

USB_10+ USB_10-

TP138 TP28-75-GPTP138 TP28-75-GP TP139 TP28-75-GPTP139 TP28-75-GP TP140 TP28-75-GPTP140 TP28-75-GP TP141 TP28-75-GPTP141 TP28-75-GP

12

C379

SC4D7U10V5ZY-3GP

C380

SC1KP50V2KX-1GP

R208

R208 100KR2J-1-GP

100KR2J-1-GP

1st: 20.F1296.046 2nd: 20.F1270.046

C378

http://laptop-motherboard-schematic.blogspot.com/

LVDS1

23 22 21 20 19 18 17 16 15 14 13 12 11 10

9 8 7 6 5 4 3 2

1

ACES-CONN46C-2-GP-U

BRIGHTNESS_CONN

12

DY

12

C353

C353 SCD1U25V3KX-GP

SCD1U25V3KX-GP

48 24

25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47

R241 100KR2J-1-GPR241 100KR2J-1-GP

12

+3VS

SIZE_DET0 29

TXOUTB_L2+ 7 TXOUTB_L2- 7 TXOUTB_L1+ 7 TXOUTB_L1- 7 TXOUTB_L0+ 7 TXOUTB_L0- 7 TXCLKB_L+ 7 TXCLKB_L- 7

TXOUTA_L2+ 7 TXOUTA_L2- 7 TXOUTA_L1+ 7 TXOUTA_L1- 7 TXOUTA_L0+ 7 TXOUTA_L0- 7 TXCLKA_L+ 7 TXCLKA_L- 7

SIZE_DET0 SIZE_DET1 (Pin27) (Pin19)

15.4" 1 1

17.0" 0 1

15.6" 1 0

16.0" 0 0

0R0402-PAD

R222

R224

R220

DY

100KR2J-1-GP

1 2

R226

R226 100KR2J-1-GP

100KR2J-1-GP

1 2

C364 SC1KP50V2KX-1GPC364 SC1KP50V2KX-1GP

1 2

DY

C374 SC1KP50V2KX-1GP

Title

LCD/Inverter Connector/CAM/LED

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

12

DY

0R2J-2-GP

+3VS

D21

2

3

BAV99W-1-GP

EC_BLON

BRIGHTNESS_CONN

0630 -1

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

1

BAV99W-1-GP

15 41Thursday, July 09, 2009

DCBATOUT

BRIGHTNESS 29

L_BKLTCTL 7

D22

3

of

+3VS

2

1

+3VS +3VS_CK505

L3

1 2

SBK160808T-601Y-N-GP

D D

5

12

C214

SC10U10V5ZY-1GP

DY

12

C492

SCD1U16V2ZY-2GP

C495

12

C502

SCD1U16V2ZY-2GP

DY

12

C505

C507

SCD1U16V2ZY-2GP

4

12

C496

SCD1U16V2ZY-2GP

X1

1 2

X-14D31818M-37GP

12

C180

SC12P50V2JN-3GP

CLK_XTAL_OUTCLK_XTAL_IN

12

C174

SC12P50V2JN-3GP

3

+3VS_CK505_IO+3VS_CK505

23

16

46

9

U21

4

27

19

62

33

43

52

56

2

+3VS

L2

1 2

SBK160808T-601Y-N-GP

1

+3VS_CK505_IO

12

C512

12

C506

SCD1U16V2ZY-2GP

C191

SC10U10V5ZY-1GP

12

DY

C509

SCD1U16V2ZY-2GP

DY

C494

SCD1U16V2ZY-2GP

12

C493

SCD1U16V2ZY-2GP

DY

C217

SC10U10V5ZY-1GP

+3VS_CK505

12

R331

R331 10KR2J-3-GP

10KR2J-3-GP

DY

12

R332

R332 10KR2J-3-GP

10KR2J-3-GP

C C

+3VS

12

R326

R326 10KR2J-3-GP

10KR2J-3-GP

MCH_CLK_REQ#

B B

SRC-5_EN/PCI-3 PIN44,45

0 PCI_STOP#/CPU_STOP# 1 SRC5

SRC-5_EN/PCI-3

CLK_SATA_OE#19

MCH_CLK_REQ#7

PCLK_FWH27

CLK_PCI_KBC29 PCLK_ICH17

CLK_ICH1419

+3VS_CK505

12

R329

R329 10KR2J-3-GP

10KR2J-3-GP

PCI2_TME

12

R330

R330 10KR2J-3-GP

10KR2J-3-GP

DY

CLK_XTAL_IN

1 2 1 2

CLK_XTAL_OUT

FSA

PCI2_TME SRC-5_EN/PCI-3

27_SEL ITP_EN

FSB FSC

C522 SC4D7P50V2CN-1GP

1 2

DY

CLK48_ICH19 CLK48_515825

STP_PCI#19 STP_CPU#19

ICH_SMBCLK12,13,21,26

ICH_SMBDATA12,13,21,26

CK_PWRGD19

R325 475R2F-L1-GPR325 475R2F-L1-GP

1 2

R168 33R2J-2-GPR168 33R2J-2-GP

1 2

R112 33R2J-2-GPR112 33R2J-2-GP

1 2

R116 22R2J-2-GPR116 22R2J-2-GP

1 2

R99

1 2

33R2J-2-GP

12

DY

C202

SC4D7P50V2CN-1GP

12

DY

C203

C186

SC4D7P50V2CN-1GP

R352 22R2J-2-GPR352 22R2J-2-GP R351 22R2J-2-GPR351 22R2J-2-GP

ICS 71.09355.B03 Realtek 71.00875.003

3

X1

2

X2

17

USB_48MHZ/FSLA

45

PCI_STOP#

44

CPU_STOP#

7

SCLK

6

SDATA

63

CK_PWRGD/PD#

8

PCI0/CR#_A

10

PCI1/CR#_B

11

PCI2/TME

12

PCI3

13

PCI4/27_SELECT

14

PCI_F5/ITP_EN

64

FSLB/TEST_MODE

5

REF0/FSLC/TEST_SEL

55

NC#55

ICS9LPRS355BKLFT-GP-U

FS_C FS_B FS_A CPU

+1.05VS +1.05VS +1.05VS

+3VS_CK505

R354

DY

0R2J-2-GP

1 2

R367

1KR2J-1-GP

1 2

DY

1 2

DY

1KR2J-1-GP

1 2

DY

12

R340

R340 10KR2J-3-GP

10KR2J-3-GP

ITP_EN

12

R341

R341 10KR2J-3-GP

10KR2J-3-GP

DY

A A

ITP_EN Output

0 SRC8 1 CPU_ITP

CPU_BSEL24 CPU_BSEL14 CPU_BSEL04

1 2

R319 0R0402-PADR319 0R0402-PAD

1 2

R321 0R0402-PADR321 0R0402-PAD

1 2

R356 0R0402-PADR356 0R0402-PAD

Design Note:

1. All of Input pin didn't have internal pull up resistor.

2. Clock Request (CR) function are enable by registers.

3. CY28548 integrated serial resistor of differential clock, so put 0 ohm serial resistor in the schematic.

5

http://laptop-motherboard-schematic.blogspot.com/

4

DY

R328

R328 0R2J-2-GP

0R2J-2-GP

CLK_BSEL2 CLK_BSEL1 CLK_BSEL0

R324

DY

12

1KR2J-1-GP

1 2

1 0 1 100M 0 0 1 133M 0 1 1 166M 0 1 0 200M

R315

0 0 0 266M

56R2J-4-GP

1 2

R317 10KR2J-3-GPR317 10KR2J-3-GP

1 2

R320 0R0402-PADR320 0R0402-PAD

1 2

R353 2K2R2J-2-GPR353 2K2R2J-2-GP R318 1KR2J-1-GPR318 1KR2J-1-GP

1 2

R327 1KR2J-1-GPR327 1KR2J-1-GP

1 2

R357 2K2R2J-2-GPR357 2K2R2J-2-GP

1 2

R314

3

VDD48

VDDREF

GNDPCI

GND48

15

18

VDDPCI

VDDSRC

GNDREF

1

VDDCPU

VDDPLL3

GND

GNDSRC

22

30

36

49

FSC FSB FSA

MCH_CLKSEL2 3,7 MCH_CLKSEL1 3,7 MCH_CLKSEL0 3,7

VDD96_IO

VDDSRC_IO

VDDPLL3_IO

27MHZ_NONSS/SRCT1/SE1

GND

GNDSRC

GNDCPU

26

59

65

CPUT0

VDDCPU_IO

27MHZ_SS/SRCC1/SE2

GND

CPUC0

CPUT1_F

CPUC1_F

CPUT2_ITP/SRCT8

CPUC2_ITP/SRCC8

SRCT7/CR#_F

SRCC7/CR#_E

SRCT6 SRCC6

SRCT10 SRCC10

SRCT11/CR#_H SRCC11/CR#_G

SRCT9 SRCC9

SRCT4 SRCC4

SRCT3/CR#_C SRCC3/CR#_D

SRCT2/SATAT

SRCC2/SATAC

SRCT0/DOTT_96

SRCC0/DOTC_96

+3VS_CK505

12

R335

R335 10KR2J-3-GP

10KR2J-3-GP

DY

12

R336

R336 10KR2J-3-GP

10KR2J-3-GP

27_SEL

2

CLK_CPU_BCLK1

61

CLK_CPU_BCLK1#

60

CLK_MCH_BCLK1

58

CLK_MCH_BCLK1#

57

CLK_CPU_XDP1

54

CLK_CPU_XDP1#

53

CLK_PCIE_LAN1

51

CLK_PCIE_LAN1#

50

CLK_PCIE_MINI1_1

48

CLK_PCIE_MINI1_1#

47 41

42 40

39 37

38

CLK_MCH_3GPLL1

34

CLK_MCH_3GPLL1#

35

CLK_PCIE_ICH1

31

CLK_PCIE_ICH1#

32

CLK_PCIE_SATA1CLK_PCIE_SATA1

28

CLK_PCIE_SATA1#CLK_PCIE_SATA1#

29

MCH_SSCDREFCLK1

24

MCH_SSCDREFCLK1#

25

CLK_MCH_DREFCLK1

20

CLK_MCH_DREFCLK1#

21

1 2

R80 0R0402-PADR80 0R0402-PAD

1 2

R81 0R0402-PADR81 0R0402-PAD

1 2

R82 0R0402-PADR82 0R0402-PAD

1 2

R83 0R0402-PADR83 0R0402-PAD

1 2

R84 0R0402-PADR84 0R0402-PAD

1 2

R85 0R0402-PADR85 0R0402-PAD

1 2

R86 15R2J-GPR86 15R2J-GP

1 2

R87 15R2J-GPR87 15R2J-GP

1 2

R88 15R2J-GPR88 15R2J-GP

1 2

R91 15R2J-GPR91 15R2J-GP

1 2

R109 0R0402-PADR109 0R0402-PAD

1 2

R110 0R0402-PADR110 0R0402-PAD

1 2

R133 0R0402-PADR133 0R0402-PAD

1 2

R134 0R0402-PADR134 0R0402-PAD

1 2

R131 0R0402-PADR131 0R0402-PAD

1 2

R132 0R0402-PADR132 0R0402-PAD

1 2

R129 0R0402-PADR129 0R0402-PAD

1 2

R130 0R0402-PADR130 0R0402-PAD

1 2

R127 0R0402-PADR127 0R0402-PAD

1 2

R128 0R0402-PADR128 0R0402-PAD

CLK_CPU_BCLK 3 CLK_CPU_BCLK# 3

CLK_MCH_BCLK 6 CLK_MCH_BCLK# 6

CLK_CPU_XDP 3 CLK_CPU_XDP# 3

CLK_PCIE_LAN 23 CLK_PCIE_LAN# 23

CLK_PCIE_MINI1 26 CLK_PCIE_MINI1# 26

CLK_MCH_3GPLL 7 CLK_MCH_3GPLL# 7

CLK_PCIE_ICH 19 CLK_PCIE_ICH# 19

CLK_PCIE_SATA 18 CLK_PCIE_SATA# 18

DREFSSCLK 7 DREFSSCLK# 7

DREFCLK 7 DREFCLK# 7

27_SEL PIN 20 PIN 21 PIN 24 PIN 25

0 DOT96T DOT96C SRCT1/LCDT_100 SRCT1/LCDT_100 1 SRCT0 SRCC0 27M_NSS 27M_SS

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Clock Generator ICS9LPRS355

Size Document Number Rev

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

16 41Thursday, July 09, 2009

1

of

1

5

+3VS

RN34

RN53

RN54

RN30

RN31

PCI_TRDY#

8

PCI_FRAME#

7

INT_PIRQD#

6

PCI_REQ3#

PCI_PLOCK#

8

PCI_IRDY#

7

PCI_SERR#

6

INT_PIRQB#

PCI_PERR#

8

PCI_REQ0#

7

INT_PIRQG#

6

INT_PIRQH#

PCI_REQ2#

8

PCI_REQ1#

7

PCI_STOP#

6

PCI_DEVSEL#

INT_PIRQC#

8

INT_PIRQA#

7

INT_PIRQF#

6

INT_PIRQE#

1 2 3 4 5

SRN8K2J-4-GP

D D

C C

SRN8K2J-4-GP

1 2 3 4 5

SRN8K2J-4-GP

1 2 3 4 5

SRN8K2J-4-GP

1 2 3 4 5

SRN8K2J-4-GP

1 2 3 4 5

SRN8K2J-4-GP

4

2 OF 6

U60B

D11

AD0

INT_PIRQA# INT_PIRQB# INT_PIRQC# INT_PIRQD#

E12

E10

G11 F11

F10 D10

C8 D9

E9

C9

B7 C7 C5

F8

E7

A3 D2

D5

B3

F7 C3

F3

F4 C1 G7 H7 D1 G5 H6 G1 H3

J5

E1

J6

PCI

AD1 AD2 AD3 AD4 AD5 AD6 AD7 AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15 AD16 AD17 AD18 AD19 AD20 AD21 AD22 AD23 AD24 AD25 AD26 AD27 AD28 AD29 AD30 AD31

Interrupt I/F

PIRQA# PIRQB# PIRQC# PIRQD#C4PIRQH#/GPIO5

ICH9M-GP-NF

REQ1#/GPIO50 GNT1#/GPIO51 REQ2#/GPIO52 GNT2#/GPIO53 REQ3#/GPIO54 GNT3#/GPIO55

PIRQE#/GPIO2 PIRQF#/GPIO3

PIRQG#/GPIO4

REQ0# GNT0#

C/BE0# C/BE1# C/BE2# C/BE3#

IRDY#

PAR

PCIRST#

DEVSEL#

PERR#

PLOCK#

SERR#

STOP# TRDY#

FRAME#

PLTRST#

PCICLK

PME#

3

PCI_REQ0#

F1

PCI_GNT0#

G4

PCI_REQ1#

B6 A7

PCI_REQ2#

F13 F12

PCI_REQ3#

E6

PCI_GNT3#

F6 D8

B4 D6 A5

PCI_IRDY#

D3 E3 R1

PCI_DEVSEL#

C6

PCI_PERR#

E4

PCI_PLOCK#

C2

PCI_SERR#

J4

PCI_STOP#

A4

PCI_TRDY#

F5

PCI_FRAME#

D7

PCI_PLTRST#

C14 D4 R2

H4 K6 F2 G2

ICH_PME#

INT_PIRQE# INT_PIRQF# INT_PIRQG# INT_PIRQH#

1

PCLK_ICH 16

TP64 TPAD14-GPTP64 TPAD14-GP

2

1

PCI_GNT0#

B B

SPI_CS#119

PCI_GNT3#

BOOT BIOS Strap

0 1 SPI

A16 swap override strap

PCI_GNT#3

A A

5

1 2

DY

R148 1KR2J-1-GP

1 2

DY

R114 1KR2J-1-GP

1 2

DY

R146 1KR2J-1-GP

SPI_CS#1 BOOT BIOS LocationPCI_GNT#0

PCI

01

LPC(Default)

11

low = A16 swap override enable high = default

USE LPC

+3VALW

U23

DY

1

B

5

PCI_PLTRST#

http://laptop-motherboard-schematic.blogspot.com/

4

VCC

2

A

3

GND

74LVC1G08GW-1-GP

1 2

R141 0R0402-PADR141 0R0402-PAD

PLT_RST#

4

Y

3

PLT_RST# 7,23,26,27,29

2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., H s ic hih,

21F, 88, Sec.1, Hsin Tai Wu Rd., H s ic hih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

ICH9-M (1 of 5)

HBU16 1.2

1

of

17 41Thursday, July 09, 2009

of

17 41Thursday, July 09, 2009

of

17 41Thursday, July 09, 2009

1

5

4

3

2

1

ICH_RTCX1

1 2

R111

R111 10MR2J-L-GP

10MR2J-L-GP

X3

X3 X-32D768KHZ-38GPU

12

C195

X-32D768KHZ-38GPU

1

2 3

4

D D

SC12P50V2JN-3GP

ICH_RTCX2

12

C204

SC12P50V2JN-3GP

32.768Khz 12.5pf 10ppm 1st: 82.30001.691 (KDS)

+RTCVCC

R322

R322 20KR2J-L2-GP

20KR2J-L2-GP

+RTCVCC

R119

R119 20KR2J-L2-GP

20KR2J-L2-GP

1 2

SC1U10V3KX-3GP

1 2

C210

SC1U10V3KX-3GP

12

C497

12

21

G96

G96 GAP-OPEN

GAP-OPEN

2nd: 82.30001.861 (EPSON)

GLAN_COMP place within 500 mil of ICH9M

C C

0630 -1

1 2

RN32

1 2 3

12

HDA_SDIN028

TP35TPAD14-GP TP35TPAD14-GP

4

HDD

ODD

HDA_SDIN27

SATA_LED#15

SATA_RXN022

SATA_RXP022 SATA_TXN022 SATA_TXP022

SATA_RXN122

SATA_RXP122 SATA_TXN122 SATA_TXP122

HDA_BITCLK_CODEC7,28

HDA_RST#_CODEC7,28

HDA_SYNC_CODEC7,28 HDA_SDOUT_CODEC7,28

B B

R592 0R0402-PADR592 0R0402-PAD

R591 33R2J-2-GPR591 33R2J-2-GP

SRN33J-5-GP-U

+1.5VS

ACZ_BIT_CLK ACZ_SYNC_R

ACZ_RST#_R

1

ACZ_SDATAOUT_R

SATA_LED#

C236 SCD01U16V2KX-3GPC236 SCD01U16V2KX-3GP C230 SCD01U16V2KX-3GPC230 SCD01U16V2KX-3GP

C240 SCD01U16V2KX-3GPC240 SCD01U16V2KX-3GP C245 SCD01U16V2KX-3GPC245 SCD01U16V2KX-3GP

+RTCVCC

1 2

R334

R334 1MR2J-1-GP

1MR2J-1-GP

1 2

R339

R339 330KR2F-L-GP

330KR2F-L-GP

SRTCRST# new signal Pin

ICH_INTVRMEN

1 2

24D9R2F-L-GP

R100

1 2 1 2

SM_INTRUDER#

ICH_INTVRMEN

ICH_RTCX1 ICH_RTCX2

ICH_RTCRST#ICH_RTCRST#

SRTCRST#

SM_INTRUDER#

GLAN_COMP

SATA_TXN0_C SATA_TXP0_C

SATA_TXN1_C SATA_TXP1_C

U60A

C23

RTCX1

C24

RTCX2

A25

RTCRST#

F20

SRTCRST#

C22

INTRUDER#

B22

INTVRMEN

A22

LAN100_SLP

E25

GLAN_CLK

C13

LAN_RSTSYNC

F14

LAN_RXD0

G13

LAN_RXD1

D14

LAN_RXD2

D13

LAN_TXD0

D12

LAN_TXD1

E13

LAN_TXD2

B10

GLAN_DOCK#/GPIO56

B28

GLAN_COMPI

B27

GLAN_COMPO

AF6

HDA_BIT_CLK

AH4

HDA_SYNC

AE7

HDA_RST#

AF4

HDA_SDIN0

AG4

HDA_SDIN1

AH3

HDA_SDIN2

AE5

HDA_SDIN3

AG5

HDA_SDOUT

AG7

HDA_DOCK_EN#/GPIO33

AE8

HDA_DOCK_RST#/GPIO34

AG8

SATALED#

AJ16

SATA0RXN

AH16

SATA0RXP

AF17

SATA0TXN

AG17

SATA0TXP

AH13

SATA1RXN

AJ13

SATA1RXP

AG14

SATA1TXN

AF14

SATA1TXP

ICH9M-GP-NF

1 OF 6

FWH0/LAD0 FWH1/LAD1 FWH2/LAD2 FWH3/LAD3

FWH4/LFRAME#

RTCLAN / GLAN

LPCCPU

RTCLAN / GLAN

LPCCPU

LDRQ0#

LDRQ1#/GPIO23

A20GATE

A20M#

DPRSTP#

DPSLP#

FERR#

CPUPWRGD

IGNNE#

RCIN#

STPCLK#

THRMTRIP#

SATA4RXN

IHDA

SATA4RXP SATA4TXN

SATA4TXP

SATA5RXN SATA5RXP SATA5TXN

SATA5TXP

SATA_CLKN SATA_CLKP

SATA

SATARBIAS#

SATARBIAS

INIT#

INTR

SMI#

PECI

LPC_AD0

K5

LPC_AD1

K4

LPC_AD2

L6

LPC_AD3

K2 K3 J3

J1 N7

AJ27 AJ25

AE23 AJ26 AD22 AF25 AE22

AG25 L3

AF23

NMI

AF24 AH27 AG26 AG27

AH11 AJ11 AG12 AF12

AH9 AJ9 AE10 AF10

AH18 AJ18

SATARBIAS

AJ7 AH7

LPC_AD[0..3]

LPC_FRAME# 27,29

TPAD14-GP

1

H_THERMTRIP_R

CLK_PCIE_SATA# 16

24D9R2F-L-GP

TPAD14-GP TP61

TP61

H_A20M# 3

R103 56R2J-4-GPR103 56R2J-4-GP

H_PWRGD 4 H_IGNNE# 3 H_INIT# 3

H_INTR 3

H_NMI 3

H_STPCLK# 3

CLK_PCIE_SATA 16

GPIO23

H_DPRSTP#

H_FERR#_R

Place within 500 mils of ICH9 ball

1 2

12

R145

LPC_AD[0..3] 27,29

R375

1 2

10KR2J-3-GP

KA20GATE 29

H_DPRSTP# 4,7,35 H_DPSLP# 4

H_SMI# 3

1 2

R106

54D9R2F-L1-GP

+3VS

+1.05VS

12

R105

R105 56R2J-4-GP

56R2J-4-GP

+3VS

R359

10KR2J-3-GP

1 2

+1.05VS

R108

1 2

56R2J-4-GP

Placed Within 2" from ICH9

H_FERR# 3

KBRCIN# 29

PM_THRMTRIP-A# 3,7

C285

SC1U10V3ZY-6GP

+RTCVCC

1 2

R160 0R0402-PADR160 0R0402-PAD

W=20mils

12

W=20mils

RTC_PWR_L

U31

3

CH715FPT-GP

2

1

W=20mils

+3VL

RTC_PWR

R159

1 2

1KR2J-1-GP

BATT1.1

W=20mils

RTC1

3 2

1

ACES-CON3-GP-U1

5

4

1st: 20.F0714.003 2nd: 20.D0201.103

A A

integrated VccSus1_05,VccSus1_5,VccCL1_5

INTVRMEN

integrated VccLan1_05VccCL1_05

LAN100_SLP

5

http://laptop-motherboard-schematic.blogspot.com/

4

3

High=Enable Low=Disable

2

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

3nd: 20.F1000.003

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

ICH9-M (2 of 5)

HBU16 1.2

18 41Thursday, July 09, 2009

1

of

5

+3VS

D D

R448

SPI_WP#SPI_WP#

SPI_CS#0 SPI_MOSO

C C

LAN

PCIE_RXN123 PCIE_RXP123

C488 SCD1U10V2KX-5GPC488 SCD1U10V2KX-5GP

PCIE_TXN123

C487 SCD1U10V2KX-5GPC487 SCD1U10V2KX-5GP

PCIE_TXP123

WLAN

PCIE_RXN226 PCIE_RXP226

C486 SCD1U10V2KX-5GPC486 SCD1U10V2KX-5GP

PCIE_TXN226

C485 SCD1U10V2KX-5GPC485 SCD1U10V2KX-5GP

PCIE_TXP226

B B

R450 15R2J-GPR450 15R2J-GP

SPI_MOSI SPI_MOSO

R451 15R2J-GPR451 15R2J-GP

R452 15R2J-GPR452 15R2J-GP R453 15R2J-GPR453 15R2J-GP

SPI_CS#117

A A

R448

1 2

DY

1KR2J-1-GP

U75

DY

1

CS#

2

DO

3

WP# GND4DIO

W25X16VSSIG-GP

VCC

HOLD#

8

SPI_HOLD#

7 6

CLK

5

72.25X16.001 (2M Flash ROM)

PCIE_RXN1

1 2 1 2

1 2

5

PCIE_RXP1

PCIE_RXN2 PCIE_RXP2

R428

22D6R2F-L1-GP

TXN1

12

TXP1

12

TXN2

12

TXP2

12

SPI_CLK_RSPI_CLK SPI_CS#0_RSPI_CS#0 SPI_CS#1

SPI_MOSI_R SPI_MOSO_R

USB_OC#0 USB_OC#1 USB_OC#2 USB_OC#3 USB_OC#4 USB_OC#5 USB_OC#6 USB_OC#7 USB_OC#8 USB_OC#9 USB_OC#10 USB_OC#11

USB_RBIAS_PN

R449

1 2

DY

1KR2J-1-GP

U60D

N29

PERN1

N28

PERP1

P27

PETN1

P26

PETP1

L29

PERN2

L28

PERP2

M27

PETN2

M26

PETP2

J29

PERN3

J28

PERP3

K27

PETN3

K26

PETP3

G29

PERN4

G28

PERP4

H27

PETN4

H26

PETP4

E29

PERN5

E28

PERP5

F27

PETN5

F26

PETP5

C29

PERN6/GLAN_RXN

C28

PERP6/GLAN_RXP

D27

PETN6/GLAN_TXN

D26

PETP6/GLAN_TXP

D23

SPI_CLK

D24

SPI_CS0#

F23

SPI_CS1#/GPIO58/CLGPIO6

D25

SPI_MOSI

E23

SPI_MISO

N4

OC0#/GPIO59

N5

OC1#/GPIO40

N6

OC2#/GPIO41

P6

OC3#/GPIO42

M1

OC4#/GPIO43

N2

OC5#/GPIO29

M4

OC6#/GPIO30

M3

OC7#/GPIO31

N3

OC8#/GPIO44

N1

OC9#/GPIO45

P5

OC10#/GPIO46

P3

OC11#/GPIO47

AG2

USBRBIAS

AG1

USBRBIAS#

ICH9M-GP-NF

4 OF 6

4

RN48

DY

SRN10KJ-5-GP

1

2 3

STP_PCI# STP_CPU#

+3VALW

R169

1 2

+3VS

SPI_CLK

SPI_MOSI

12

C555

DY

SCD1U16V2ZY-2GP

DMI0RXN DMI0RXP DMI0TXN DMI0TXP

DMI1RXN DMI1RXP DMI1TXN DMI1TXP

DMI2RXN DMI2RXP DMI2TXN DMI2TXP

DMI3RXN DMI3RXP DMI3TXN DMI3TXP

DMI_CLKN

PCI-Express

DMI_CLKP

Direct Media Interface

DMI_ZCOMP

DMI_IRCOMP

USBP0N USBP0P USBP1N USBP1P USBP2N USBP2P USBP3N USBP3P USBP4N USBP4P USBP5N

SPI

USBP5P USBP6N

USB

USBP6P USBP7N USBP7P USBP8N USBP8P USBP9N USBP9P

USBP10N

USBP10P

USBP11N

USBP11P

PCIE_WAKE#

10KR2J-3-GP

PM_CLKRUN#29

CLK_SATA_OE#16

Norn connect to charger

V27 V26 U29 U28

Y27 Y26 W29 W28

AB27 AB26 AA29 AA28

AD27 AD26 AC29 AC28

T26 T25

AF29 AF28

AC5 AC4 AD3 AD2 AC1 AC2 AA5 AA4 AB2 AB3 AA1 AA2 W5 W4 Y3 Y2 W1 W2 V2 V3 U5 U4 U1 U2

4

+3VALW

+3VS

DMI_RXN0 7 DMI_RXP0 7 DMI_TXN0 7 DMI_TXP0 7

DMI_RXN1 7 DMI_RXP1 7 DMI_TXN1 7 DMI_TXP1 7

DMI_RXN2 7 DMI_RXP2 7 DMI_TXN2 7 DMI_TXP2 7

DMI_RXN3 7 DMI_RXP3 7 DMI_TXN3 7 DMI_TXP3 7

CLK_PCIE_ICH# 16 CLK_PCIE_ICH 16

DMI_IRCOMP_R

4

1

2 3

+3VS

12

1 2

R137

R137 8K2R2J-3-GP

8K2R2J-3-GP

USB20_N0 22 USB20_P0 22

USB20_N2 22 USB20_P2 22

USB20_N4 22 USB20_P4 22

USB20_N6 26 USB20_P6 26 USB20_N7 22 USB20_P7 22 USB20_N8 25 USB20_P8 25

USB20_N10 15 USB20_P10 15

RN52

RN52 SRN10KJ-5-GP

SRN10KJ-5-GP

ICH_SMB_CLK21

ICH_SMB_DATA21

R360

R360 8K2R2J-3-GP

8K2R2J-3-GP

10KR2J-3-GP

TP30TPAD14-GP TP30TPAD14-GP

+1.5VS

12

USB3

External USB3

External USB2

WLAN

Bluetooth

Card Reader

CAM

3

+3VALW

12

R140

R140 10KR2J-3-GP

10KR2J-3-GP

XDP_DBRESET#3

PM_SYNC#7

GPIO11 Reserved for future

STP_PCI#16 STP_CPU#16

PCIE_WAKE#23,26,29 SIRQ29

THERM_SCI#24

ICH_TP7

1 2

DY

0R2J-2-GP

R338

EC_SCI#29 EC_SWI#29

SB_PWR_LED31

+3VS

R430

12

1

SB_SPKR28

MCH_ICH_SYNC#7

R313

R313 24D9R2F-L-GP

24D9R2F-L-GP

GPIO22

3

ICH_SMB_CLK ICH_SMB_DATA

LINKALERT# ME_EC_CLK1 ME_EC_DATA1

ICH_RI#

XDP_DBRESET#

SMB_ALERT#

1

TP53TPAD14-GP TP53TPAD14-GP

STP_PCI# STP_CPU#

PCIE_WAKE# SIRQ

VRMPWRGD

EC_SCI# SB_PWR_LED

GPIO17

1

GPIO18

TP29TPAD14-GP TP29TPAD14-GP

1

GPIO20

TP62TPAD14-GP TP62TPAD14-GP

1

GPIO22

TP33TPAD14-GP TP33TPAD14-GP

1

GPIO27

TP23TPAD14-GP TP23TPAD14-GP

1

GPIO28

TP58TPAD14-GP TP58TPAD14-GP

1

TP27TPAD14-GP TP27TPAD14-GP

TP24TPAD14-GP TP24TPAD14-GP TP26TPAD14-GP TP26TPAD14-GP TP25TPAD14-GP TP25TPAD14-GP

TP28TPAD14-GP TP28TPAD14-GP

CLK_EN#35

R107 8K2R2J-3-GP

GPIO18 SIRQ

23

GPIO38

1 1 1

ICH_TP3

1

1 2

DY

RN55

4

SRN10KJ-5-GP

+3VALW

1

RN27

SRN2K2J-1-GP

4

U60C

G16

SMBCLK

A13

SMBDATA

E17

LINKALERT#/GPIO60/CLGPIO4

C17

SMLINK0

B18

SMLINK1

F19

RI#

R4

SUS_STAT#/LPCPD#

G19

SYS_RESET#

M6

PMSYNC#/GPIO0

A17

SMBALERT#/GPIO11

A14

STP_PCI#

E19

STP_CPU#

L4

CLKRUN#

E20

WAKE#

M5

SERIRQ

AJ23

THRM#

D21

VRMPWRGD

A20

SST

AG19

TACH1/GPIO1

AH21

TACH2/GPIO6

AG21

TACH3/GPIO7

A21

GPIO8

C12

LAN_PHY_PWR_CTRL/GPIO12

C21

ENERGY_DETECT/GPIO13

AE18

TACH0/GPIO17

K1

GPIO18

AF8

GPIO20

AJ22

SCLOCK/GPIO22

A9

GPIO27

D19

GPIO28

L1

SATACLKREQ#/GPIO35

AE19

SLOAD/GPIO38

AG22

SDATAOUT0/GPIO39

AF21

SDATAOUT1/GPIO48

AH24

GPIO49

A8

GPIO57/CLGPIO5

M7

SPKR

AJ24

MCH_SYNC#

B21

TP3

AH20

PWM0

AJ20

PWM1

AJ21

PWM2

ICH9M-GP-NF

Q7

G

S

2N7002E-1-GP

+3VS

1 23

2

3 OF 6

SATA0GP/GPIO21 SATA1GP/GPIO19 SATA4GP/GPIO36 SATA5GP/GPIO37

SATA

GPIO

SATA

GPIO

SMB

Clocks

SYS GPIO

Power MGTController Link

GPIO

GPIO10/SUS_PWR_ACK

MISC

+3VS

12

R311

R311 10KR2J-3-GP

10KR2J-3-GP

.....

D

CLK14 CLK48

SUSCLK

SLP_S3# SLP_S4# SLP_S5#

S4_STATE#/GPIO26

PWROK

DPRSLPVR/GPIO16

BATLOW# PWRBTN#

LAN_RST#

RSMRST#

CK_PWRGD

CLPWROK

SLP_M#

CL_CLK0 CL_CLK1

CL_DATA0 CL_DATA1

CL_VREF0 CL_VREF1

CL_RST0# CL_RST1#

GPIO24/MEM_LED

GPIO14/AC_PRESENT

GPIO9/WOL_EN

VRMPWRGD

USB

Pair

Device

USB3

0

1

FREE

2

External USB3

3

FREE

4 External USB2

FREE

5

WLAN

6

BLUETOOTH

7

CARD READER

8

9

FREE

CAMERA

10

11

FREE

2

SATA0GP

AH23

SATA1GP

AF19

SATA2GP

AE21

SATA3GP

AD20 H1

AF3

ICH_SUSCLK

P1 C16

E16

PM_SLP_S5#

G17 C10 G20 M2

PM_BATLOW#_R

B13 R3

LAN_RST#1

D20 D22 R5

M_PWROK

R6

PM_SLP_M#

B16 F24

B19 F22

C19 C25

A19 F21

D18

GPIO24

A16

GPIO10/SUS_PWR_ACK

C18 C11 C20

GPIO26

CLK_ICH14 16 CLK48_ICH 16

ICH_SUSCLK 24

PM_SLP_S3# 23,24,29,32,38,39,40

PM_SLP_S4# 29,30,32,38

1

TP180

TPAD14-GP

1

TP57

PM_PWROK

1 2

0R0402-PAD

0R0402-PAD R431

R431

PWRBTN#_SB 29

12

R139 0R0402-PADR139 0R0402-PAD

RSMRST#_SB 32

CK_PWRGD 16 M_PWROK 7

TPAD14-GP

1

TP55

CL_VREF0_ICH CL_VREF1_ICH

1 1

USB_OC#8 USB_OC#3 ICH_RI# XDP_DBRESET#

USB_OC#7

USB_OC#4

+3VALW

TP55

TP54 TPAD14-GPTP54 TPAD14-GP TP191 TPAD14-GPTP191 TPAD14-GP

ICH9-M (2 of 5)

CL_CLK0 7

CL_DATA0 7

CL_RST#0 7

+3VALW

Title

Size Document Number Rev

Date: Sheet

1

RN29

SATA1GP SATA3GP SATA2GP SATA0GP

R438

1 2

DY

100KR2J-1-GP

1 2

R142

12

C511

RP1

1 2 3 4 5 6

SRN10KJ-L3-GP

RP2

1 2 3 4 5 6

SRN10KJ-L3-GP

HBU16 1.2

RN29

1 2 3 4 5

SRN10KJ-6-GP

1 2

R138

R138 10KR2J-3-GP

10KR2J-3-GP

M_PWROK

DY

0R2J-2-GP

3K24R2F-GP

+3VALW

12

R348

12

3K24R2F-GP

R349

R349 453R2F-1-GP

453R2F-1-GP

SCD1U10V2KX-4GP

10

PM_BATLOW#_R

9

SMB_ALERT#

8

USB_OC#10

7

USB_OC#9

10

USB_OC#0USB_OC#11

9

USB_OC#1USB_OC#5

8

USB_OC#6

7

USB_OC#2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

1

+3VS

8 7 6

PM_PWROK 7,32

PM_DPRSLPVR 7,35

ALL_PWRGD 35,37,38,39

+3VS

12

R310

12

R309

R309 453R2F-1-GP

453R2F-1-GP

12

C484

SCD1U10V2KX-4GP

+3VALW

of

19 41Thursday, July 09, 2009

of

19 41Thursday, July 09, 2009

of

19 41Thursday, July 09, 2009

1

http://laptop-motherboard-schematic.blogspot.com/

5

+RTCVCC

6uA in G3

12

C501

SCD1U10V2KX-4GP

657mA

+1.5VS

D D

C C

1 2

R305

R305 0R0805-PAD

0R0805-PAD

SCD1U10V2KX-4GP

*Within a given well, 5VREF needs to be up before the corresponding 3.3V rail

+3VS

21

1mA

V5REF_S0

Layout Note: Place near ICH8

12

21

1mA

V5REF_S5

B B

+3VS

R539

R539 0R0603-PAD

0R0603-PAD

A A

12

C551

C551 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

18mA in S0;50mA in S3/S4/S5

12

C528

C525

SCD1U10V2KX-4GP

SC4D7U6D3V3MX-2GP

C197

D12

D12 CH751H-40PT

CH751H-40PT

C263

C263 SC1U10V3KX-3GP

SC1U10V3KX-3GP

D30

D30 CH751H-40PT

CH751H-40PT

SB_VCCLAN3_3

12

SCD1U10V2KX-4GP

+1.5VS

DY

+1.5VS

C234

5

+1.5VS_PCIE

12

C188

DY

IND-1D2UH-10-GP

+5VS

R147

R147 10R2J-2-GP

10R2J-2-GP

1 2

+5VALW+3VALW

R427

R427 10R2J-2-GP

10R2J-2-GP

1 2

+1.5VS

R144

R144 0R0603-PAD

0R0603-PAD

SCD1U10V2KX-4GP

23mA

L1

IND-1D2UH-10-GP

C187

SC2D2U6D3V3MX-1-GP

C187

80mA

12

C235

DY

SCD1U10V2KX-4GP

12

TC10

ST220U2D5VBM-LGP

SCD1U10V2KX-4GP

DY

47mA

L4

1 2

+1.5VS

R535

1 2

0R0805-PAD

+1.5VS

R537

0R0603-PAD

USBPLL=10mA

12

C266

C256

DY

12

C482

+1.5VS_APLL+1.5VS

12

C223

SC10U6D3V5MX-3GP

SATA+USB=1.56A

SB_SATA_USB_1_5_A

C252

SC1U10V3KX-3GP

12

C221

SCD1U10V2KX-4GP

12

C267

SCD1U10V2KX-4GP

12

C173

C173 SC10U6D3V5MX-3GP

SC10U6D3V5MX-3GP

http://laptop-motherboard-schematic.blogspot.com/

+3VS

12

C503

SCD1U10V2KX-4GP

12

C483

SC10U10V5ZY-1GP

12

C222

12

SB_VCC_1_5_A

C247

12

1mA

1 2

R306

R306 0R0603-PAD

0R0603-PAD

4

U60F

A23

AE1

AA24 AA25 AB24 AB25 AC24 AC25 AD24 AD25 AE25 AE26 AE27 AE28 AE29

G25 H24 H25

M24 M25 N23 N24 N25

R24 R25 R26 R27

U24 U25

U23 W24 W25

AJ19

AC16 AD15 AD16 AE15

AF15

AG15 AH15

AJ15

AC11 AD11 AE11

AF11

AG10 AG11 AH10

AJ10

AC9

AC18 AC19

AC21

G10

AC12 AC13 AC14

AA7

AB6

AB7

AC6

AC7

D28

D29

F25

J24

J25 K24 K25 L23 L24 L25

P24 P25

T24 T27 T28 T29

V24 V25

K23 Y24 Y25

G9

AJ5

A10 A11

A12 B12

A27

E26 E27

A26

VCCRTC

A6

V5REF V5REF_SUS VCC1_5_B

VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B VCC1_5_B

VCCSATAPLL VCC1_5_A

VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A

VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A

VCC1_5_A VCC1_5_A

VCC1_5_A VCC1_5_A VCC1_5_A

VCC1_5_A VCC1_5_A

VCCUSBPLL VCC1_5_A

VCC1_5_A VCC1_5_A VCC1_5_A VCC1_5_A

VCCLAN1_05 VCCLAN1_05

VCCLAN3_3 VCCLAN3_3

VCCGLANPLL VCCGLAN1_5

VCCGLAN1_5 VCCGLAN1_5 VCCGLAN1_5

VCCGLAN3_3

ICH9M-GP-NF

V5REF_S0 V5REF_S5

12

C199

SC2D2U6D3V3MX-1-GP

SC10U10V5ZY-1GP

SC1U10V3ZY-6GP

12

C238

SC1U10V3KX-3GP

12

SCD1U10V2KX-4GP

1D5V_USB_S0 VCCSUS1_05[3]

C254

VCCLAN1D05

12

SCD1U10V2KX-4GP

VCC_GLAN_PLL

3D3V_GLAN_S0

4

6 OF 6

CORE

VCCA3GP ATXARX USB CORE

VCCP_CORE

PCI

VCCPSUSVCCPUSB

GLAN POWER

VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05 VCC1_05

VCCDMIPLL

VCCDMI VCCDMI

V_CPU_IO V_CPU_IO

VCC3_3 VCC3_3 VCC3_3 VCC3_3

VCC3_3 VCC3_3 VCC3_3

VCC3_3 VCC3_3 VCC3_3 VCC3_3 VCC3_3 VCC3_3 VCC3_3

VCCHDA

VCCSUSHDA

VCCSUS1_05 VCCSUS1_05

VCCSUS1_5 VCCSUS1_5

VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3

VCCSUS3_3 VCCSUS3_3

VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3

VCCCL1_05

VCCCL1_5 VCCCL3_3

VCCCL3_3

3

A15 B15 C15 D15 E15 F15 L11 L12 L14 L16 L17 L18 M11 M18 P11 P18 T11 T18 U11 U18 V11 V12 V14 V16 V17 V18

R29 W23

Y23 AB23

AC23 AG29 AJ6 AC10 AD19

AF20 AG24 AC20

B9 F9 G3 G6 J2 J7 K7

AJ4 AJ3 AC8

F17 AD8 F18

A18 D16 D17 E22

AF1 T1

T2 T3 T4 T5 T6 U6 U7 V6 V7 W6 W7 Y6 Y7 T7

G22 G23 A24

B24

3

12

C231

SB_VCC_3_3_C

12

C491

C491 SC1U10V3ZY-6GP

SC1U10V3ZY-6GP

3D3V_VCCPCORE_ICH_S0

S/B_PCI_VCCP_CORE_S0

VCCSUS1_05[1]

VCCSUS1_05[2] VCCSUS1_5[1] VCCSUS1_5[2]

VCCSUS1_5[3]

12

C255

SCD1U10V2KX-4GP

12

SB_VCCCL3_3

12

1 2

DY

C259

SCD1U10V2KX-4GP

C268

SCD1U10V2KX-4GP

18mA

SCD01U16V2KX-3GP

1D5V_DMIPLL_ICH_S0

VCCDMI

SCD1U25V3ZY-1GP

12

C246

SCD1U10V2KX-4GP

C265

TP34TP34

1 1

TP31TP31

R143 0R3J-0-U-GP

12

C229

C229 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C260

DY

12

C550

R540

R540 0R0603-PAD

0R0603-PAD

12

C248

SCD01U16V2KX-3GP

SCD1U10V2KX-4GP

12

C209

DY

12

EC44

DY

+3VS

R533

12

0R0603-PAD

+1.5VS

SB_VCCSUS3_3

SCD1U10V2KX-4GP

DY

SCD1U10V2KX-4GP

+3VS

12

SC1U10V3KX-3GP

Place near ICH9MLayout Note:

12

C225

SCD1U10V2KX-4GP

DY

SCD01U16V2KX-3GP

SC4D7U6D3V3MX-2GP

SC10U10V5ZY-1GP

12

C213

12

C257

C257 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

R102

12

C198

SCD1U10V2KX-4GP

12

C258

C258 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

12

C549

C549 SCD022U16V2KX-3GP

SCD022U16V2KX-3GP

12

C207

DY

2

1.13A

12

C233

SCD1U10V2KX-4GP

DY

1D5V_DMIPLL_ICH_S0

12

C489

R135

12

C212

+3VS

R532

12

0R0603-PAD

VCC3_3=278mA

+3VS

12

0R0603-PAD

32mA

12

C273

C273 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

R536

12

0R0603-PAD

177mA

R538

12

0R0603-PAD

12

C206

C206 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

DY

2

1

R530

SB_VCC1_05

12

C239

SCD1U10V2KX-4GP

DY

23mA

C490

C490 SC10U6D3V5MX-3GP

SC10U6D3V5MX-3GP

12

0R0603-PAD

SCD01U16V2KX-3GP

SB_VCCHDA

+3VALW

12

Title

Size Document Number Rev

Date: Sheet

R530

12

L28IND-1D2UH-10-GP L28IND-1D2UH-10-GP

50mA

1mA

12

C205

12

C269

C269 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

C218

C218 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

+1.05VS

SB_V_CPU_IO

12

0R0603-PAD

+1.5VS

R534

+1.5VS

+1.05VS

R531

12

C208

C227

SCD1U10V2KX-4GP

DY

SC4D7U6D3V3MX-2GP

+1.5VS

12

0R0603-PAD

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221 , Taiwan, R.O.C.

Taipei Hsien 221 , Taiwan, R.O.C.

ICH9 (3/5)

HBU16 1.2

20 41Wednesday, July 01, 2009

1

0R0603-PAD

+1.05VS

12

1

of

5

5 OF 6

U60E

AA26

VSS

AA27

VSS

AA3

VSS

AA6

VSS

AB1

VSS

AA23

VSS

AB28

VSS

AB29

VSS

AB4

VSS

AB5

VSS

D D

C C

B B

A A

5

AC17 AC26 AC27

AC3

AD1 AD10 AD12 AD13 AD14 AD17 AD18 AD21 AD28 AD29

AD4

AD5

AD6

AD7

AD9 AE12 AE13 AE14 AE16 AE17

AE2 AE20 AE24

AE3

AE4

AE6

AE9 AF13 AF16 AF18 AF22 AH26 AF26 AF27

AG13 AG16 AG18 AG20 AG23

AG3

AG6

AG9 AH12 AH14 AH17 AH19

AH2 AH22 AH25 AH28

AH5

AH8

AJ12 AJ14 AJ17

C26

C27

G12

G14

G18

G21

G24

G26

G27

H23

H28

H29

AF5 AF7 AF9

AJ8 B11 B14 B17

B20 B23

E11 E14 E18

E21 E24

F16 F28 F29

G8 H2

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

B2

VSS VSS VSS

B5

VSS

B8

VSS VSS VSS VSS VSS VSS

E2

VSS VSS VSS

E5

VSS

E8

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

ICH9M-GP-NF

http://laptop-motherboard-schematic.blogspot.com/

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

4

H5 J23 J26 J27 AC22 K28 K29 L13 L15 L2 L26 L27 L5 L7 M12 M13 M14 M15 M16 M17 M23 M28 M29 N11 N12 N13 N14 N15 N16 N17 N18 N26 N27 P12 P13 P14 P15 P16 P17 P2 P23 P28 P29 P4 P7 R11 R12 R13 R14 R15 R16 R17 R18 R28 T12 T13 T14 T15 T16 T17 T23 B26 U12 U13 U14 U15 U16 U17 AD23 U26 U27 U3 V1 V13 V15 V23 V28 V29 V4 V5 W26 W27 W3 Y1 Y28 Y29 Y4 Y5 AG28 AH6 AF2 B25

A1 A2 A28 A29 AH1 AH29 AJ1 AJ2 AJ28 AJ29 B1 B29

4

ICH_GND1

ICH_GND2

ICH_GND3

ICH_GND4

1

TP60 TPAD14-GPTP60 TPAD14-GP

TP51 TPAD14-GPTP51 TPAD14-GP

NCTF PIN

TP63 TPAD14-GPTP63 TPAD14-GP

TP52 TPAD14-GPTP52 TPAD14-GP

3

+3VS

RN28

SRN2K2J-1-GP

ICH_SMBDATA12,13,16,26

ICH_SMB_CLK19

ICH_SMB_CLK

4

1

2 3

2

U17

1 2 3 4

DMN66D0LDW-7-GP

6 5

+3VS

ICH_SMB_DATA

1

ICH_SMB_DATA 19

ICH_SMBCLK 12,13,16,26

SMBUS

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Date: Sheet

Date: Sheet of

3

2

Date: Sheet of

Taipei Hsien 221, Taiwan, R.O.C.

ICH9-M (4 of 4)

HBU16 1.2

1

of

21 41Thursday, July 09, 2009

USB PORT

G114

1 2

GAP-CLOSE-PWR

G115

1 2

GAP-CLOSE-PWR

100 mil 100 mil

G117

1 2

GAP-CLOSE-PWR

G116

1 2

GAP-CLOSE-PWR

U59

USB20_P0 USB20_N0

U59

1

ESD I/O1

2

GND

3

ESD I/O2

IP4220CZ6-GP

BLUETOOTH

+3V_BT

BT1

7

1 2

3 4 5 6

8

JST-CON6-17-GP

21.D0220.106

USB20_N719

USB20_P719

BT_R_DET#

+5V_USB2+5V

12

C521

SCD1U16V2ZY-2GP

+5V_USB1+5V

12

C360

C360 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

ESD I/O4

VP

ESD I/O3

12

EC16

DY

SCD1U16V2ZY-2GP

1 2

DY

R594

R594 0R2J-2-GP

0R2J-2-GP

12

EC17

SCD1U16V2ZY-2GP

DY

1 2

R395 0R0402-PADR395 0R0402-PAD

1 2

R401 0R0402-PADR401 0R0402-PAD

1st: 22.10218.N21

+5V_USB2

2nd: 22.10218.N91 3nd: 22.10218.Z21

100 mil

U76

1 2 3

IP4220CZ6-GP

+3V_BT GND USB7+ USB7BT_LED

BT_R_DET#

1 1 1 1 1 1 1 1 1 1 1

ESD I/O1 GND ESD I/O2

USB20_N019 USB20_P019

TP168 TP28-75-GPTP168 TP28-75-GP TP99 TP28-75-GPTP99 TP28-75-GP TP98 TP28-75-GPTP98 TP28-75-GP TP100 TP28-75-GPTP100 TP28-75-GP TP97 TP28-75-GPTP97 TP28-75-GP TP103 TP28-75-GPTP103 TP28-75-GP TP102 TP28-75-GPTP102 TP28-75-GP TP104 TP28-75-GPTP104 TP28-75-GP TP101 TP28-75-GPTP101 TP28-75-GP TP105 TP28-75-GPTP105 TP28-75-GP TP169 TP28-75-GPTP169 TP28-75-GP

ESD I/O4 ESD I/O3

1 1 1 1 1

1

12

C518

DY

6 5 4

USB7+ USB7-

SC1KP50V2KX-1GP

12

DY

BT_LED 31 BT_DET# 29

12

TC19

ST100U10VCM-GP

+5V

C194

C194 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

+5V_USB1 +5V_USB1 USB20_N4 USB20_P4 USB20_N2 USB20_P2 GND +5VS NUMLK_LED_PWM GND GND

USB20_P2 USB20_N2

R381 0R0402-PADR381 0R0402-PAD

1 2

R380 0R0402-PADR380 0R0402-PAD

1 2

NUMLK_LED#29

USB20_N4

6 5

VP

USB20_P4

4

TP176 TP28-75-GPTP176 TP28-75-GP TP174 TP28-75-GPTP174 TP28-75-GP TP173 TP28-75-GPTP173 TP28-75-GP TP175 TP28-75-GPTP175 TP28-75-GP TP172 TP28-75-GPTP172 TP28-75-GP

TP179 TP28-75-GPTP179 TP28-75-GP

DY

12

USB0USB0+

C81

12

SCD1U16V2ZY-2GP

USB20_N419 USB20_P419 USB20_N219 USB20_P219

1 2

R469

R469 330R2J-3-GP

330R2J-3-GP

+5V

C377

C377 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

0630 -1

C12

12

SCD1U16V2ZY-2GP

DY

+5VS

SATA_TXP118

SATA_TXN118 SATA_RXP118 SATA_RXN118

MAX 150mA

Q29

Q29 AO3403-GP

AO3403-GP

S

D

G

BT_EN#_1

G

C590

SCD1U10V2KX-4GP

SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP C591

C591

12

DY

USB7-

USB7+

12

C588

DY

SC1U10V3KX-3GP

D31

BT_EN#29

http://laptop-motherboard-schematic.blogspot.com/

K A

1SS355PT-GP

DY

BT_EN#_C

R494

1 2

10KR2J-3-GP

R493

R493 100KR2J-1-GP

100KR2J-1-GP

SKT-USB-131-GP-U

+5V_USB1

TC21

12

ST100U6D3VBM-5GP

NUMLK_LED_PWMNUMLK_LED#

+3V_BT+3VALW

12

DY

USB3

8 6 1

2 3 4 5 7

SATA_TXP018 SATA_TXN018

USB1

1 2

3 4 5 6 7 8 9

10

ACES-CON10-5-GP-U1

1st: 20.F0735.010 2nd: 20.D0174.110 3nd: 20.F0984.010

+5VS

12

EC46

SCD1U25V3ZY-1GP

DY

SCD01U16V2KX-3GP

1 2 1 2

SCD01U16V2KX-3GP

C552

C552 C553

C553

C592

C592 SC4D7U10V5ZY-3GP

SC4D7U10V5ZY-3GP

SATA_RXN018 SATA_RXP018

11

12

DY

SATA_RXP1_C SATA_RXN1_C

SATA HDD Connector

SCD01U16V2KX-3GP

C220

1 2

C244

1 2

+5VS

12

C540

EC47

SCD1U16V2ZY-2GP

SCD1U25V3ZY-1GP

DY

SCD01U16V2KX-3GP

C541

SC10U10V5ZY-1GP

SATA_RXN0_C SATA_RXP0_C

ODD Connector

12

C548

TC20

SCD1U16V2ZY-2GP

SC10U10V5ZY-1GP

ODD1

P2

+5V

P3

+5V

S2

A+

S3

A-

S6

B+

S5

B-

NP1

NP2

SKT-SATA7P+6P-22-GP-U1

1st: 62.10065.351 2nd: 62.10065.421 3nd: 62.10065.521

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

P1

DP

P4

MD

S1

GND

S4

GND

S7

GND

P5

GND

P6

GND

8

GND

9

GND

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HDD/CDROM/USB/BT

HBU16 1.2

HDD1

23

NP1

1 2

3 4 5 6 7

8

9 10 11 12 13 14 15 16 17 18 19 20 21 22

NP2

24

SKT-SATA22P-20-GP

1st: 62.10065.261 2nd: 62.10065.511

ODD_DP ODD_MD

DY

R150

10KR2J-3-GP

22 41Thursday, July 09, 2009

TP59

1

TPAD14-GP

12

of

1

A

4 4

3 3

+3V_LAN

1 2

R267

R267 0R0603-PAD

0R0603-PAD

12

C264

SC10U10V5ZY-1GP

VDD12

12

C228

C228 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DVDD33

40 mils

12

C262

C262 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

DVDD33

12

C261

C261 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

B

40 mils

12

C242

C242 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C251

C251 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C215

C215 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

C211

C211 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

EEPROM LED OPTION USE '01' (DEFINED IN SPEC) => LED1 : LINK (Green) => LED2 : ACT (Yellow) (BOTH 10/100 AND GIGA CHIP)

12

C530

C530 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C

12

EC40

SCD1U25V3ZY-1GP

LAN_PWR_ON29

DY

Q24

Q24 2N7002E-1-GP

2N7002E-1-GP

G

S

.....

+3VALW

D

1 2

LAN_PY2

D

R288

R288 1MR2J-1-GP

1MR2J-1-GP

R285

R285 100KR2J-1-GP

100KR2J-1-GP

1 2

12

C475

LAN_PY1

SC1KP50V2KX-1GP

PM_SLP_S3#19,24,29,32,38,39,40

R441

1 2

DY

G

0R5J-5-GP

AO3413-GP

AO3413-GP Q23

Q23

E

+3V_LAN

DS

G

S

DY

Q37

Q37 2N7002E-1-GP

2N7002E-1-GP

.....

40 mils

LAN_PY2

D

U24

VDD12 PCIE_WAKE# VDD12 VDD12

DVDD33

1 2

12

R555

0R0402-PAD

2K49R2F-GP

DVDD33 VDD12

CTRL12 DVDD33 VDDTX

LAN_EECS

LAN_X1 LAN_X2

LAN_L_DSM#

R126

1 2

CTRL12

2 2

1 1

12

C834

C834 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

DVDD33

12

R390

R390 3K6R3-GP

3K6R3-GP

C237

1 2

C226

YELLOW_LED#

SC15P50V2JN-2-GP

A

12

X4

X4 XTAL-25MHZ-67GP

XTAL-25MHZ-67GP

SC1U10V3KX-3GP

LAN_X1

LAN_X2

C832

DY

12

C833

C833 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

DY

LAN_DSM#29

http://laptop-motherboard-schematic.blogspot.com/

GREEN_LED#27 YELLOW_LED #27

LAN_DSM#

B

R589

1KR2J-1-GP

U24

9

VDD1

23

VDD1

28

VDD1

22

VDD3

30

VDD3

1

LV_D

3

LV_A

4

HV33

14

VDDTX

24

EECS

27

LENPIN1/EESK

26

LEDPIN2/EEDI

25

LEDPIN3/EEDO

31

CKXTAL1

32

CKXTAL2

29

GPO

2

IBREF

RTL8103T-GR-GP

LANWAKE#

ISOLATE#

REFCLK_P REFCLK_M

HSIP

HSIN HSOP HSON

CLKREQB

PERST#

MDIP0 MDIN0 MDIP1 MDIN1

GNDTX

GND

19

ISOLATE#

21

CLK_PCIE_LAN

12

CLK_PCIE_LAN#

13

PCIE_TXP1

10

PCIE_TXN1

11

PCIE_HSOP

15 16

18 20

5 6 7 8

17 33

C

C243 SCD1U10V2KX-5GPC243 SCD1U10V2KX-5GP

PCIE_HSON

C249 SCD1U10V2KX-5GPC249 SCD1U10V2KX-5GP

PLT_RST#

MDIP0 MDIN0 MDIP1 MDIN1

PCIE_WAKE# 19,26,29

CLK_PCIE_LAN 16 CLK_PCIE_LAN# 16

1 2 1 2

PLT_RST# 7,17,26,27,29

MDIP0 27 MDIN0 27 MDIP1 27 MDIN1 27

PCIE_TXP1 19

PCIE_TXN1 19 PCIE_RXP1 19 PCIE_RXN1 19

D

+3VS

12

R556

R556 1KR2J-1-GP

1KR2J-1-GP

DY

R554

ISOLATE#

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

12

R398

R398 15KR2F-GP

15KR2F-GP

1 2

1KR2J-1-GP

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221 , Taiwan, R.O.C.

Taipei Hsien 221 , Taiwan, R.O.C.

RTL8103T

HBU16 1.2

E

DSM_ISOLATE# 29

23 41Thursday, July 09, 2009

1

of

+5VS

FAN1_VCC

*Layout* 15 mil

12

C330

+3VS

12

R207

R207 10KR2J-3-GP

10KR2J-3-GP

C330

SMBD_G792 SMBC_G792

5V_G792_S0

+3VS

SCD1U16V2ZY-2GP

+5VS

12

C376

C336

THERM_SCI#19

12

C336

V_DEGREE

R198

R198 10KR2J-3-GP

10KR2J-3-GP

G792_ALERT#

SC4D7U10V5ZY-3GP

+5VS

1 2

R206

R206 100R2F-L1-GP-U

100R2F-L1-GP-U

SCD1U16V2ZY-2GP

Setting T8 as 85 Degree

V_DEGREE =(((Degree-72)*0.02)+0.34)*VCC

EC_RST#29

D

12

C366

Q19

.....

2N7002E-1-GP

*Layout* 30 mil

12

R218

R218 66K5R3F-GP

66K5R3F-GP

12

R219

R219 100KR2F-L1-GP

100KR2F-L1-GP

+3VS

G

S

C376 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

C331

C331 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

U47

6

VCC

20

DVCC

7

DXP1

9

DXP2

11

DXP3

15

ALERT#

16

SDA

18

SCL

19

NC#19

G7921SF1U-GP

123

74.07921.079

1

FAN1

2

RESET#

4

FG1

14

CLK

13

THERM#

THERM_SET

3

8

SGND

10

SGND

12

SGND

5

DGND

17

DGND

DXP1:108 Degree DXP2:H/W Setting DXP3:88 Degree

DY

D14

D14 MMBD4148-F-GP

MMBD4148-F-GP

G792_SUSCLK G792_ALERT#

+5VS

4

RN36

RN36 SRN2K7J-3-GP

SRN2K7J-3-GP

1

2 3

G792_RST#

Place near chip as close as possible

12

R221

R221 100KR2J-1-GP

100KR2J-1-GP

G792_DXP3 G792_DXP2 G792_DXN2

G792_DXN3

R188

R188 10KR2J-3-GP

10KR2J-3-GP

C334

C334 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

G68

GAP-CLOSE

1 2

FAN1_FG1

FAN1_VCC

*Layout* 15 mil

G792_RST# 32

12

C424

C424 SC2200P50V2KX-2GP

SC2200P50V2KX-2GP

12

C357

C357 SC2200P50V2KX-2GP

SC2200P50V2KX-2GP

12

C359

C359 SC2200P50V2KX-2GP

SC2200P50V2KX-2GP

B

FAN1

5

3 2

1

4

ACES-CON3-4-GP-U

1st: 20.F1267.003 2nd: 20.D0209.103 3nd: 20.F0700.003

FAN1_FG1 FAN1_VCC GND

C

Q22

MMBT3904-3-GP

E

1 1 1

SENSE2 for System

SENSE3 for DIMM

C

Q4

B

MMBT3904-3-GP

E

SENSE1 for CPU

TP122 TP28-75-GPTP122 TP28-75-GP TP123 TP28-75-GPTP123 TP28-75-GP TP124 TP28-75-GPTP124 TP28-75-GP

H_THERMDA 3

H_THERMDC 3

DY

U42

+5VALW

KBC_SCL129

U10

PM_SLP_S3#19,23,29,32,38,39,40

ICH_SUSCLK19

1

A

2

B

3

GND

74AHCT1G08DCKR-1GP

VCC

5

G792_SUSCLK

4

Y

SMBD_G792

http://laptop-motherboard-schematic.blogspot.com/

U42

1

6

2

5

34

DMN66D0LDW-7-GP

1 2

R213 0R0402-PADR213 0R0402-PAD

1 2

R215 0R0402-PADR215 0R0402-PAD

SMBC_G792

KBC_SDA1 29

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev Custom

Custom

Custom Date: Sheet

Date: Sheet

Thermal/Fan Controllor

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

24 41Thursday, July 09, 2009

of

1

5

D D

C250

SC1U10V3KX-3GP

12

C544

1 2

DY

CR

C544

SCD1U16V2ZY-2GP

12

R407 0R0402-PADR407 0R0402-PAD

5158_VIN

+3VS_CARD

C272

SC4D7U10V5ZY-3GP

+3VS

C C

CR

VREG

1 2

CR

1 2

USB20_N819 USB20_P819

C253

C253 SC1U10V3KX-3GP

SC1U10V3KX-3GP

SCD1U16V2ZY-2GP

CLK48_515816

CR

C539

R391

SCD1U16V2ZY-2GP

0R0402-PAD

1 2

AV_PLL

12

RREF

12

CR

R403 6K19R2F-GP

VREG

+3VS_D

C534

1 2

CR

1 2 3 4 5 6 7 8

9 10 11 12

U26

CR

AV_PLL RREF AV33 DM DP AG33 A3V3_OUT 5V_IN CARD_3V3 VREG D3V3_OUT DGND

4

XD_CE#

XD_CLE

RST#

MODE_SEL

43

44

46

48

47

XTLI

XTLO

42

45

RST#

AG_PLL

MODE_SEL

XD_CLE/CF_D3

XD_CE#/CF_D11

SD_DAT4/XD_WP#

XD_R/B#

SD_DAT2/XD_RE#

SD_DAT3/XD_WE#

XD_ALE

41

38

37

39

40

XD_ALE/CF_D4

XD_RDY/CF_D13

SD_DAT4/XD_WP#/CF_D6

SD_DAT3/XD_WE#/CF_D5

SD_DAT2/XD_RE#/CF_D12

SD_DAT5/XD_D0/CF_D14

SD_CLK/XD_D1/MS_CLK/CF_D7

SD_DAT6/XD_D7/MS_D3/CF_D15

MS_INS#/CF_IORD#

SD_DAT7/XD_D2/MS_D2/CF_IOWR#

SD_DAT0/XD_D6/MS_D0/CF_RST#

SD_DAT1/XD_D3/MS_D1/CF_IORDY

XD_D5/MS_BS/CF_A2

SD_CMD

DGND

CF_CS0#

D3V3

SD_CMD

36

SD_DAT5/XD_D0

35

SD_CLK/XD_D1/MS_CLK

34 33 32

SD_DAT6/XD_D7/MS_D3

31 30

MS_INS#

29

SD_DAT7/XD_D2/MS_D2

28

SD_DAT0/XD_D6/MS_D0

27

SD_DAT1/XD_D3/MS_D1_R

26

XD_D5/MS_BS

25

3

+3VS

1 2

R397 0R0402-PADR397 0R0402-PAD

1 2

R400 0R0402-PADR400 0R0402-PAD

1 2

R388 0R0402-PADR388 0R0402-PAD

+3VS_D

12

CR

C537

SCD1U16V2ZY-2GP

5158_VIN

+3VS_A

+3VS_D

2

+3VS_A

12

R406

CR

100KR2J-1-GP

1 2

R557

R557 0R0402-PAD

0R0402-PAD

SC1U10V3KX-3GP

RST_1#

C274

12

R558

DY

CR

499KR2F-1-GP

RST#

1

CF_CD#13GPIO014CF_D1015CF_D916CF_D217CF_D8/SM_CD#18CF_D1/XD_CD#19CF_D0/SM_WPM#/SD_WP20CF_A0/SD_CD#21CF_DMACK#22CF_A1/XD_D423CF_DMARQ

12

DY

+3VS_D

1 2

R386

R386 0R0402-PAD

0R0402-PAD

CR

Q39

3

R1

2

R2

PDTC144EU-1-GP

SC4D7U10V5ZY-3GP

CRYSTAL_SEL

VBUS_LED#

+3VS

1

XD_CD#

4 IN1 CARD-READER (SD/SD IO/MMC/MMC4.0/MS/MS PRO/XD)

+3VS_CARD

12

C297

DY

C554

C554 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

CR

TP38TPAD14-GP TP 38TPAD14-GP

High is use 48MHz, NC is use Crystal.

+5VS

R439

VBUS_LED_L

1 2

CR

330R2J-3-GP

B B

3

LED2

AK

1 2

LED-Y-74-GP

CR

VBUS_LED#

VBUS_LED

R402

0R2J-2-GP

Place close to controler IC

R404

R404 0R0402-PAD

SD_CLK/XD_D1/MS_CLK

A A

0R0402-PAD

SD_CLK/XD_D1/MS_CLK_R

12

http://laptop-motherboard-schematic.blogspot.com/

5

4

XD_D4

SD_WP

SD_CD#

SD_DAT1/XD_D3/MS_D1_R

SD_CMD SD_CLK/XD_D1/MS_CLK

SD_DAT0/XD_D6/MS_D0 SD_DAT1 SD_DAT2/XD_RE# SD_DAT3/XD_WE#

SD_CD# SD_WP

SD_WP

XD_D5/MS_BS SD_DAT0/XD_D6/MS_D0 MS_INS# SD_CLK/XD_D1/MS_CLK_R

SD_DAT6/XD_D7/MS_D3 SD_DAT7/XD_D2/MS_D2

1

24

CARD1_SD_IO

RTS5159-GR-GP

71.05159.00G

1 2

R560 0R0402-PADR560 0R0402-PAD

1 2

R559 0R0402-PADR559 0R0402-PAD

XD_D4

+3VS_CARD

SD_CLK/XD_D1/MS_CLK_L

SD_CLK/XD_D1/MS_CLK_R_R

3

1 2

R387

R387 0R0402-PAD

0R0402-PAD

CARD1

31

SD_VCC

28

MS_VCC

38

MS_VCC

19

VCC

36

SD_CMD

27

SD_CLK

23

SD_DAT0

22

SD_DAT1

41

SD_DAT2

39

SD_DAT3

42

SD_CD_DETECT

21

SD_WP_PROTECT

45

SD_WP1

44

SD_WP2

26

MS_BS

30

MS_SDIO

34

MS_INS

37

MS_SCLK

35

MS_RESERVED#MS_7

32

MS_RESERVED#MS_5

29

SD_I/O

NP1

NP2

NP3

NP4

NP5

NP6

CARDBUS43P-SKT-GP

R389

R389 0R2J-2-GP

0R2J-2-GP

DY

CR

SD_DAT1SD_DAT1/XD_D3/MS_D1_R

12

20.I0030.021

SD_CO2 SD_CO1

SD_3P SD_6P SD_7P SD_8P

MS_VSS SD_VSS

SD_VSS

R/B#

WE# WP#

GND GND GND GND GND GND GND GND

2

CD

7

ALE

3 4

RE#

5

CE#

6

CLE

8 9

11

D0

12

D1

13

D2

14

D3

15

D4

16

D5

17

D6

18

D7

51 50

49 48 47 46

25 33

24 1

20 40 10 43 52 53 54

MODE_SEL

SC47P50V2JN-3GP

R405 C542

0YesNC NC Yes Yes NC NC No

If user remove memory card from socket, RTS5159 will terminate USB

*1. USB Auto De-link mode:

bus connection and enter power saving state. MSPRO, MSPRO DUO, MSPRO-HG or MSPRO-HG DUO card will be formatted as

*2. MS Formatt e r:

factory default setting if user formatted these card types under "Vista" OS.

XD_CD# XD_ALE

XD_R/B# SD_DAT2/XD_RE# XD_CE# XD_CLE SD_DAT3/XD_WE# SD_DAT4/XD_WP#

SD_DAT5/XD_D0 SD_CLK/XD_D1/MS_CLK SD_DAT7/XD_D2/MS_D2 SD_DAT1/XD_D3/MS_D1_R

XD_D4 XD_D5/MS_BS SD_DAT0/XD_D6/MS_D0 SD_DAT6/XD_D7/MS_D3

SD_CD#

SD_DAT0/XD_D6/MS_D0 SD_DAT1

USB Auto De-link (*1)

Install

2

12

DY

C542

MS Formatter (*2)

12

R405

CR

0R2J-2-GP

No Recommended

No

Title

USB CardReader Controller-RTS5159

Size Document Num ber Rev

Date: Sheet of

Description

Compatible with RTS5158E

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

1

25 41Thursday, July 09, 2009

1

A

+3VS

12

PC1 PC0 (dB)

4 4

0

1

R442 4K7R2J -2-GP

+3VS

R443 4K7R2J -2-GP

R455 499R2F-2-GP

3 3

2 2

1 1

R455 499R2F-2-GP R446 1KR2J-1-GP

R446 1KR2J-1-GP R454

R454

+3VS

HDMI_1_TXD1_1

HDMI_1_TXD1#_1

HDMI_1_TXC_1 HDMI_1_TXC

HDMI_1_TXC#_1

20KR2J-L2-GP

PEG_RXP37

Q43

Q43 2N7002K-1-GP

2N7002K-1-GP

8 41

121

0

HDMI_DATA2-7 HDMI_DATA2+7

HDMI_DATA1-7 HDMI_DATA1+7

HDMI_DATA0-7 HDMI_DATA0+7

HDMI_CLK-7 HDMI_CLK+7

DY

1 2 1 2

DY

1 2

HDMI

12

1KR2J-1-GP

DY

12

DY

HDMI

R459 1KR2J-1-GP

FILTER-123-GP

8

7

6

5

L29

DY

+3VS

12

R456

12

R457

R457 7K5R2J-GP

7K5R2J-GP

RUNCTRL_PWR

G

HDMI

D S

1 2

DY

R561 0R2J-2-GP

A

D

12

C557

C556

HDMI

HDMI_PC0 HDMI_PC1

HDMI_REXT HDMI_RT# HDMI_OE# HDMI_DDC

12

1

2

3

4

Q25

Q25 2N7002E-1-GP

2N7002E-1-GP

.....

HDMI

1 2

R567

R567 1KR3J-L1-GP

1KR3J-L1-GP

+5VS+5VS_HDMI

HDMI

SCD1U10V2KX-4GP

HDMI_1_TXD1

HDMI_1_TXD1# HDMI_1_TXD2#_1

HDMI_1_TXC#

G

S

HDMI

SCD01U16V2KX-3GP

38 39

41 42

44 45

47 48

3 4

6 10 25 32

PS8101-GP

IN_D1IN_D1+

IN_D2IN_D2+

IN_D3IN_D3+

IN_D4IN_D4+

PC0 PC1

REXT RT_EN# OE# DDC_EN

HDMI

U62

2

11

15

21

26

VCC

GND

1

5

12

18

24

HDMI_HPD

12

R458

R458 20KR2J-L2-GP

20KR2J-L2-GP

RUN_PWR_CTLR 32

http://laptop-motherboard-schematic.blogspot.com/

B

+3VS

12

R444

R445

4K7R2J-2-GP

HDMI

4K7R2J-2-GP

HDMI_34

HDMI_35

33

40

46

35

VCC

NC#3434NC#35

GND

GND36GND

GND

27

31

37

43

49

71.P8101.003 (R455=64.49905.6DL)

71.03300.003 (R455=64.82015.6DL)

HDMI_1_TXD2

HDMI_1_TXD2# HDMI_1_TXD1

HDMI_1_TXD1# HDMI_1_TXD0

HDMI_1_TXD0# HDMI_1_TXC

HDMI_1_TXC#

TP66TPAD14-GP TP66TPAD14-GP TP65TPAD14-GP TP65TPAD14-GP

+5VS_HDMI

C401

SCD1U16V2ZY-2GP

B

OUT_D1-

OUT_D1+

OUT_D2-

OUT_D2+

OUT_D3-

OUT_D3+

OUT_D4-

OUT_D4+

HPD_SINK SDA_SINK SCL_SINK

HDMI_CEC

1

HDMI_CNC

1

HDMI_SCL HDMI_SDA

23 22

20 19

17 16

14 13

8

SDA

9

SCL

7

HPD

30 29 28

HDMI_1_TXD2_1

HDMI_1_TXD0_1

HDMI_1_TXD0#_1

HDP

12

DY

HDMI_1_TXD2_1 HDMI_1_TXD2#_1 HDMI_1_TXD0_1 HDMI_1_TXD0#_1

HDMI_1_TXD1_1 HDMI_1_TXD1#_1 HDMI_1_TXC_1 HDMI_1_TXC#_1

HDMI_1_TXD2#_1 HDMI_1_TXD2_1

HDMI_1_TXD1#_1 HDMI_1_TXD1_1

HDMI_1_TXD0#_1 HDMI_1_TXD0_1

HDMI_1_TXC#_1 HDMI_1_TXC_1

HDMI

R447 1KR2J-1-GP

FILTER-123-GP

8

7

6

5

L30

DY

HDMI1

1 2

3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19

SKT-HDMI19P-25-GP

1st: 22.10296.061 2nd: 22.10296.011

HDMI

RN69

1 2 3 4 5

SRN0J-5-GP

HDMI

RN70

1 2 3 4 5

SRN0J-5-GP

RN57

2 3 1

SRN1K5J-GP

HDMI_HPDHDMI_HPD_L

12

HDMI_SDA HDMI_SCL

RN68

2 3 1

SRN1K5J-GP

HDMI

1

2

3

4

HDMI

C

HDMI_1_TXD2

8

HDMI_1_TXD2#

7

HDMI_1_TXD0

6

HDMI_1_TXD0#

HDMI_1_TXD1

8

HDMI_1_TXD1#

7

HDMI_1_TXC

6

HDMI_1_TXC#

+3VS

4

GMCH_HDMI_DATA 7 GMCH_HDMI_CLK 7

HDP

+5VS_HDMI

4

HDMI_1_TXD2

HDMI_1_TXD2#

HDMI_1_TXD0

HDMI_1_TXD0#

22 20

21 23

C

D

E

Mini Card Connector1(802.11a/b/g)HDMI Connector

+1.5VS

MINI1

PCIE_WAKE#19,23,29

TP56TPAD14-GP TP56TPAD14-GP TP193TPAD14-GP TP193TPAD14-GP

CLK_PCIE_MINI1#16

CLK_PCIE_MINI116

E51_RXD29 E51_TXD29

PCIE_RXN219 PCIE_RXP219

PCIE_TXN219 PCIE_TXP219

1 1

+3VS_MINI1

PCIE_WAKE#

TP45TPAD14-GP TP45TPAD14-GP

+VL

WL_PRI BT_PRI

1

53

1 3

5 7

9 11 13 15

17 19 21 23 25 27 29 31 33 35 37 39 41 43 45 47 49 51

54

SKT-MINI52P-22-GP-U

NP1 2 4

6 8 10 12 14 16

18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 NP2

PLT_RST# +3VS_P24

ICH_SMBCLK ICH_SMBDATA

1 1

1st: 62.10043.591 2nd: 62.10043.611

+3VS_MINI1 +1.5VS

12

C333

SCD1U16V2ZY-2GP

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

12

C339

12

C384

SC10U10V5ZY-1GP

SCD1U16V2ZY-2GP

MINI CARD/HDMI CONN .

DY

+VL

12

C337

C332

SCD1U16V2ZY-2GP

SC10U10V5ZY-1GP

D

+3VS_MINI1

L8

1 2

PBY201209T-601Y-N-GP

+3VALW

12

R562

R562 0R2J-2-GP

0R2J-2-GP

DY

WIFI_RF_EN 29 PLT_RST# 7,17,23,27,29

1 2

R563

0R0402-PAD

ICH_SMBCLK 12,13,16,21

ICH_SMBDATA 12,13,16,21

USB20_N6 19

TP42

TP42 TPAD14-GP

TPAD14-GP TP41

TP41 TPAD14-GP

TPAD14-GP

HBU16 1.2

USB20_P6 19

WLAN_LED# 31

+3VALW

12

C365

DY

SCD1U16V2ZY-2GP

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

26 41Thursday, July 09, 2009

of

E

of

+3VS

1

A

10/100M Lan Transformer

4 4

3 3

12

C500

XRF_RDC

SCD1U16V2ZY-2GP

MDIN023 MDIP023 MDIN123 MDIP123

12

C499

SCD1U16V2ZY-2GP

MDIN0 MDIP0

MDIN1 MDIP1

1st: 68.68167.30A(NS681676) 2nd: 68.HD081.30B(HD-081-A)

B

XF1

16 14 15

10 11

12 13

XFORM-16P-9-GP-U

C

LAN Connector

RJ45-2

1

XFR_CMT

3

RJ45-1

2

RJ45-6

7

XFR_RXC

6

RJ45-3

89 4

5

XFR_CMT_1

1 2

C586

C586 SCD01U100V5KX-1GP

SCD01U100V5KX-1GP

XFR_RXC_1

1 2

C587

C587 SCD01U100V5KX-1GP

SCD01U100V5KX-1GP

XFR_CMT_1

45

XFR_RXC_1

678

123

RN47

SRN75J-1-GP

RJ45-7

+3V_LAN

D

1.route on bottom as differential pairs.

2.Tx+/Tx- are pairs. Rx+/Rx- are pairs.

3.No vias, No 90 degree bends.

4.pairs must be equal lengths.

5.6mil trace width,12mil separation.

6.36mil between pairs and any other trace.

7.Must not cross ground moat,except RJ-45 moat.

R276 470R2J-2-GPR276 470R2J-2-GP

GREEN_LED#23

YELLOW_LED #23

Green : Link up Blinking : TX/RX activity

R258 470R2J-2-GPR258 470R2J-2-GP

1 2

RJ45-13P-4-GP

14

9

10

RJ45-1 RJ45-2 RJ45-3 RJ45-4

RJ45-6 RJ45-7RJ45-4

11

1 2 3 4 5 6 7 8

12 13

15

RJ1

1st: 22.10177.B81

E

PIN A1 : GREEN PIN A3 : ORANGE PIN B2 : YELLOW

2nd: 22.10177.C21

LAN_TERMINAL

C459 SC1500P2KV8KX-3GPC459 SC1500P2KV8KX-3GP

1 2

Remark: Add trace width to 20mils for RJ1 pin4, 5 and pin 7, 8.

Golden Finger for Debug Board

+5VS_LPC

TOP VIEW (A)

2 2

A15 (B1) A14 (B2)

...

A2 (B14) A1 (B15)

PLT_RST#_1 LPC_FRAME#_1 LPC_GND

LPC_AD3_1 LPC_AD2_1 LPC_AD1_1 LPC_AD2_1 LPC_AD0_1 EXT_FWH#_1

+3VS_LPC

BOTTOM VIEW (B)

Boot Device must have ID[3:0] = 0000 Has internal pull-down resistors All may be left floated FPET7 Elec. P3-46

+3VL

R460

1 2

DY

100KR2J-1-GP

1 1

A

CLOSE TO TRANSFORMER

100KR2J-1-GP

DEBUG1

A1

A2

A3

A4

A5

A6

A7

A8

A9

A10

A11

A12

A13

A14

A15

FOX-GF30

ZZ.GF030.XXX

B1

B2

B3

B4

B5

B6

B7

B8

B9

B10

B11

B12

B13

B14

B15

Please put near boa rd edge.

R461

EXT_FWH#_R EXT_FWH#

http://laptop-motherboard-schematic.blogspot.com/

R461

1 2

DY

1KR2J-1-GP

B

+5VS_LPC +3VS_LPC

PLT_RST#_1 LPC_FRAME#_1 LPC_GND PCLK_FWH_1 LPC_FRAME#

LPC_AD3_1 LPC_AD2_1 LPC_AD1_1 LPC_AD0_1 EXT_FWH#_1

+3VS_LPC

LPC_AD[0..3] 18,29

+5VS +5VS_LPC

LPC_AD3

LPC_AD2

LPC_AD1

LPC_AD0

C

G98

1 2

GAP-OPEN-PWR

G99

1 2

GAP-OPEN-PWR

G100

1 2

GAP-OPEN-PWR

G101

1 2

GAP-OPEN-PWR

G102

1 2

GAP-OPEN-PWR

G103

1 2

GAP-OPEN-PWR

+3VS

LPC_AD3_1

LPC_AD1_1 PCLK_FWH

LPC_AD0_1

LPC_GND

LPC_FRAME#18,29

PLT_RST#7,17,23,26,29

PCLK_FWH16

D

PLT_RST#

EXT_FWH#

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

G104

1 2

GAP-OPEN-PWR

G105

1 2

GAP-OPEN-PWR

G106

1 2

GAP-OPEN-PWR

G107

1 2

GAP-OPEN-PWR

G108

1 2

GAP-OPEN-PWR

LAN CONN/Debug

LPC_FRAME#_1PCLK_FWH_1

PLT_RST#_1

PCLK_FWH_1

EXT_FWH#_1

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

E

1

41Thurs day, July 09, 2009

of

27

A

PC BEEP GAIN CONTROL

+3VS

12

R568

R568 10KR2J-3-GP

10KR2J-3-GP

DY

SPDIF/BEEPGAIN is an input used t o set the PC Beep

BEEPGAIN

4 4

3 3

gain while the device is in reset.

Default gain is -46 dB without populat ing the 10-Kohm pull-up resistor.

Note: In order for the audio codec to Wake on Jack, the CODEC VAUX pin (VAUX_3.3, pin2&6) must be powered by a rail that is not removed unless AC power is removed.

TP71TP71

TP70TP70

Close to Modem

DY-MODEM

1 2

R582

R582 100KR2J-1-GP

R165

DY

AUD_AGND

SPKR_L-_C SPKR_L+_C SPKR_R-_C SPKR_R+_C

12

100KR2J-1-GP

AUD_GPIO2

AUD_GPIO1

12

R161

R161 10KR2J-3-GP

10KR2J-3-GP

DY

KBC_BEEP29

SB_SPKR19

1st: 83.R2003.E81 2nd: 83.BAT54.081 3nd: 83.00054.Q81

RC7

1 2 3 4 5

SRC100P50V-2-GP

1 1 1 1

AUD_AGND

10KR2J-3-GP

2 2

Close to SPKR1.

1 1

GAIN R568

-46 dB

-18 dB

HDA_RST#_CODEC7,18

HDA_BITCLK_CODEC7,18 HDA_SYNC_CODEC7,18 HDA_SDIN018 HDA_SDOUT_CODEC7,18

AMOM_DIPN

D36

1

2

BAT54CPT-GP

8 7 6

TP91 TP28-75-GPTP91 TP28-75-GP TP92 TP28-75-GPTP92 TP28-75-GP TP93 TP28-75-GPTP93 TP28-75-GP TP94 TP28-75-GPTP94 TP28-75-GP

A

+1.5VS

AUD_AGND

KBC_MUTE#29

3

Install

C629

12

SB_SPKR_C

AUD_AGND

DY

C628

12

SCD1U10V2KX-4GP

SC1U10V3KX-3GP

1 2

R152 33R2J-2-GPR152 33R2J-2-GP

C606

1 2

12

R528

R528 10KR2J-3-GP

10KR2J-3-GP

Speaker

+3VS

C632

C631

12

SCD1U10V2KX-4GP

AUD_AGND

+3VS

C627

C626

12

SCD1U10V2KX-4GP

SC10U10V5ZY-1GP

12

AUD_AGND

TP39TP39 TP40TP40

TPAD14-GP

1 2

R479

R479 0R0402-PAD

0R0402-PAD

AUD_AGND

HDA_SDATAIN0_CODEC HDA_SDOUT_CODEC

AMOM_DIPP AMOM_DIPN

AUD_PC_BEEP BEEPGAIN MICL

1

AUD_EAPD# AUD_GPIO1 AUD_GPIO2

+3VS

12

DY

R167

R167 47KR2J-2-GP

47KR2J-2-GP

TP192

0630 -1

0709 -1

AUD_PC_BEEP

SCD1U16V2ZY-2GP

SPKR_R-_C SPKR_R+_C SPKR_L-_C

SPKR_L+_C

1st: 20.D0197.104 2nd: 20.F0984.004 3nd: 20.D0209.104

http://laptop-motherboard-schematic.blogspot.com/

C630

12

SCD1U10V2KX-4GP

C625

SCD1U10V2KX-4GP

AUD_AGND

KBC_MUTE#_R

100KR2J-1-GP

0R2J-2-GP

0630 -1

AUD_AGND

SC10U10V5ZY-1GP

C624

12

+3VS_AUD

R593

R491

DY

AUD_AGND

SC10U10V5ZY-1GP

B

13

12 10

63 62

18 61 60

59 58

26

12

1 2

B

C634

12

FILT_1.8V

U32

9

8

3 4 5

1

DY

FILT_1.65V

C633

12

SC1U10V3KX-3GP

SCD1U10V2KX-4GP

RESET#

BIT_CLK SYNC SDATA_IN SDATA_OUT

DIB_P DIB_N

PC_BEEP SPDIF/BEEPGAIN GPIO0/EAPD

GPIO1/SPK_MUTE GPIO2/SPDIF2

DMIC_3/4 DMIC_CLK0 DMIC_1/2

AUXENABLE AUX_CLK

EXT_MUTE

14

12

C613

C613 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

4 3 2

1

SPKR1

SPKR1 ACES-CON4-1-GP-U2

ACES-CON4-1-GP-U2

5 6

6

11

VAUX_3_3

LEFT+

19

27

39

VDD_IO

AVDD_HP

DVDD_3_3

LEFT-21RIGHT-

SPKR_L-_C SPKR_L+_C SPKR_R-_C SPKR_R+_C

42

22

FILT_1_65

40

AVDD_3_3

RIGHT+

24

SPKR_R+ SPKR_R-

SPKR_LSPKR_L+

C649 SC1KP50V2KX-1GPC649 SC1KP50V2KX-1GP C650 SC1KP50V2KX-1GPC650 SC1KP50V2KX-1GP C651 SC1KP50V2KX-1GPC651 SC1KP50V2KX-1GP C652 SC1KP50V2KX-1GPC652 SC1KP50V2KX-1GP

2

7

FILT_1_8

VAUX_3_3

HPFILT

50

CODEC_HPFILT

Close to U32.

+3VS_AUD

12

AUD_AGND

12

R569

R569 D1R6F-GP-U

D1R6F-GP-U

12

C639

C639 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

CLASSDREF

20

25

41

23

AVDD_5V

LPWR_5_0

RPWR_5_0

CLASSDREF

SENSE_A SENSE_B

PORTF_R

PORTF_L

PORTB_R PORTB_L

PORTC_R PORTC_L

PORTE_R PORTE_L

PORTD_R PORTD_L

PORTA_R PORTA_L

15

AUD_AGND

R571 0R0603-PADR571 0R0603-PAD

1 2

R570 0R0603-PADR570 0R0603-PAD

1 2

R572 0R0603-PADR572 0R0603-PAD

1 2

R584 0R0603-PADR584 0R0603-PAD

1 2

Close to U32.

1 2 1 2 1 2 1 2

+3VS_AUD

C635

C636

12

SCD1U10V2KX-4GP

12

AUD_AGND

CLASSD_5V

B_BIAS C_BIAS

AVEE FLY_N FLY_P

EP_GND

GND49GND48GND34GND33GND32GND31GND17GND16GND

GND

CX20583-11Z-GP

65

64

0630 -1

MIC_INT_L AUD_AGND +5VS CAPS_LED#_17

C

AVDD_3.3 pin is output of internal LDO. Do NOT connect to external supply.

SC10U10V5ZY-1GP

+5VS_AUD

C638

C637

12

SCD1U10V2KX-4GP

SC10U10V5ZY-1GP

Layout Note: Path fro m +5VS_AUD to LPWR_5.0 and RPWR_5.0 must be very low resistance (<0.01 ohms).

CODEC5V_EN#29

Place bypass caps very close to device.

2.5A (100mils)

C643

C642

12

SCD1U10V2KX-4GP

SC10U10V5ZY-1GP

1 2

C647

C647 SC4D7U10V3KX-GP

SC4D7U10V3KX-GP

TP72 TPAD14-GPTP72 TPAD14-GP

1 2 1 2

SCD1U10V2KX-4GP

C643

12

SC10U10V5ZY-1GP

1 2

R155 39K2R2F-L-GPR155 39K2R2F-L-GP

1 2

R158 10KR2F-2-GPR158 10KR2F-2-GP

1 2

R154 5K11R2F-L1-GPR154 5K11R2F-L1-GP

MICR_M

R465 100R2J-2-GPR465 100R2J-2-GP

MICL_M

R466 100R2J-2-GPR466 100R2J-2-GP

HP_OUT_R HP_OUT_L

12

C622

AUD_AGND

C623

C623 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

C641

C640

12

SCD1U10V2KX-4GP

AUD_AGND

AUDIO_SENSE

57 56

55 54

53 52 51

47 46 45

44 43

38 37

36 35

30 29 28

+3VS

INT_MIC_L MIC_INT_L

BIASB

1

BIASC MIC_R

C289 SC2D2U10V3KX-1GPC289 SC2D2U10V3KX-1GP

MIC_L

C286 SC2D2U10V3KX-1GPC286 SC2D2U10V3KX-1GP

HP_R_OUT_R

R595 10R3F-GPR595 10R3F-GP

HP_L_OUT_L

R596 10R3F-GPR596 10R3F-GP

AVEEAVEEAVEEAVEE FLY_N FLY_P

12

C300

SC1U10V3ZY-6GP

0703 -1

MIC_INT_L

SPKR_R+_C

AUD_AGND

1 1 1 1

C

SPKR_R-_C SPKR_L-_C

SPKR_L+_C

CAPS_LED#15,29

TP96 TP28-75-GPTP96 TP28-75-GP TP95 TP28-75-GPTP95 TP28-75-GP TP170 TP28-75-GPTP170 TP28-75-GP TP171 TP28-75-GPTP171 TP28-75-GP

R543

R543 330R2J-3-GP

330R2J-3-GP

1 2

SC47P50V2JN-3GP

C596

1 2

MICR MICL

MIC_INT_L HP_OUT_L HP_OUT_R

MIC

CAPS_LED#_17 MIC_INT_L

C653

1 2

DY

SC1KP50V2KX-1GP

JACK_DETECT#

MIC_IN#

R573

12

2K2R2J-2-GP

1 2 1 2

EC13

1 2

DY

MLVG0402220NV09BP-GP

1 2

EC3 SCD01U16V2KX-3GP

1 2

EC2 SCD01U16V2KX-3GP

1 2

EC4 SCD01U16V2KX-3GPEC4 SCD01U16V2KX-3GP

1 2

EC7 SC100P50V2JN-3GP

1 2

EC6 SC100P50V2JN-3GP

+5VS

AUD_AGND

D

+5VS

12

R581

R581 1MR2J-1-GP

1MR2J-1-GP

DY

SC1KP50V2KX-1GP

1 2

DY

R583

R583 100KR2J-1-GP

100KR2J-1-GP

+3VS

+3VS_AUD

R162 3KR2J-2-GPR162 3KR2J-2-GP R166 3KR2J-2-GPR166 3KR2J-2-GP

+5VALW

1 2

C304 SCD1U16V2ZY-2GPC304 SCD1U16V2ZY-2GP

DY

DY DY

DY

DY DY

DY

4 3 2

1

ACES-CON4-1-GP-U2

ACES-CON4-1-GP-U2 MIC1

MIC1

5 6

1st: 20.D0197.104 2nd: 20.F0984.004 3nd: 20.F0689.004

D

R580 0R5J-5-GPR580 0R5J-5-GP

1 2

12

C648

DY

AUD_PWG2

MICR

1 2 1 2

SCD1U16V2ZY-2GP

CHG_LED#29 PWR_BD_LED#31 SATA_BD_LED15

1st: 20.K0320.015 2nd: 20.K0343.015

Title

Size Document Number Rev

Date: Sheet

E

Q46

Q46 AO3401A-GP

AO3401A-GP

G

C305

1 2

Custom

+5VS_AUD

DY

DS

G121

1 2

GAP-CLOSE-PWR

G122

1 2

GAP-CLOSE-PWR

G123

1 2

GAP-CLOSE-PWR

G124

1 2

GAP-CLOSE-PWR

G125

1 2

GAP-CLOSE-PWR

BIASC

+5VS

EC48

EC48 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

1 2

DY

MIC_IN# MICL

MICR HP_OUT_L HP_OUT_R JACK_DETECT#

AUD_AGND

+5VS +5VALW AUD_AGND MIC_IN# MICL MICR HP_OUT_L HP_OUT_R JACK_DETECT# AUD_AGND CHG_LED# PWR_BD_LED# SATA_BD_LED GND

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

AUDIO CODEC CX20583-11Z

HBU16 1.2

E

EC41

EC41 SCD1U50V3ZY-GP

SCD1U50V3ZY-GP

EC51

EC51 SCD1U50V3ZY-GP

SCD1U50V3ZY-GP

EC54

EC54 SCD1U50V3ZY-GP

SCD1U50V3ZY-GP

EC58

EC58 SCD1U50V3ZY-GP

SCD1U50V3ZY-GP

EC59

EC59 SCD1U50V3ZY-GP

SCD1U50V3ZY-GP

GAP-CLOSE-PWR

1 1 1 1 1 1 1 1 1 1 1 1 1 1

28 41Thursday, July 09, 2009

1 2

AUD_AGND

G126

1 2

G127

1 2

G128

1 2

G129

1 2

G130

1 2

AUD1

17 15

14 13 12 11 10

9 8 7 6 5 4 3 2

1

16

ACES-CON15-7-GP

TP108 TP28-75-GPTP108 TP28-75-GP TP109 TP28-75-GPTP109 TP28-75-GP TP114 TP28-75-GPTP114 TP28-75-GP TP111 TP28-75-GPTP111 TP28-75-GP TP112 TP28-75-GPTP112 TP28-75-GP TP113 TP28-75-GPTP113 TP28-75-GP TP115 TP28-75-GPTP115 TP28-75-GP TP116 TP28-75-GPTP116 TP28-75-GP TP117 TP28-75-GPTP117 TP28-75-GP TP118 TP28-75-GPTP118 TP28-75-GP TP119 TP28-75-GPTP119 TP28-75-GP TP120 TP28-75-GPTP120 TP28-75-GP TP121 TP28-75-GPTP121 TP28-75-GP TP110 TP28-75-GPTP110 TP28-75-GP

of

AUD_AGNDAUD_AGND

1

A

+3VL_KBC +3VS

L5

1 2

FCM1608KF-2-GP-U

C196

D D

LIMIT_SIGNAL

C C

+3VL_KBC

B B

12

C519

C504

SCD1U16V2ZY-2GP

SC2D2U10V3KX-1GP

R385

R385 140KR2F-1-GP

140KR2F-1-GP

48D7KR2F-GP

1 2

R575

R575 10KR2J-3-GP

10KR2J-3-GP

R344 10KR2J-3-GP

+3VALW

R104 10KR2J-3-GPR104 10KR2J-3-GP

+3VL

R157 10KR2J-3-GP

+3VL_KBC

PCB_VER0 PCB_VER1 PCB_VER2

12

C508

DY

SCD1U16V2ZY-2GP

1 2

R384

GPIO30

SRN10KJ-5-GP

4

RN51

DY

R369 4K7R2J-2-GPR369 4K7R2J-2-GP

1 2

DY

12

R347

R347 10KR2J-3-GP

10KR2J-3-GP

DY

12

R363

R363 10KR2J-3-GP

10KR2J-3-GP

12

C510

12

SCD1U16V2ZY-2GP

12

C498

SCD1U16V2ZY-2GP

12

EC_BLON

23

L_BKLT_EN

1

AD_OFF

12

E51_TxD

PM_RSMRST#

LID_CLOSE#

DY

12

D11

1N4148W-1-GP

PCIE_WAKE#19,23,26

12

R346

R346 10KR2J-3-GP

10KR2J-3-GP

12

R362

R362 10KR2J-3-GP

10KR2J-3-GP

KA

PM_SLP_S3#19,23,24,32,38,39,40 KBC_PWR_BTN#31 AD_IN#32,33 LID_CLOSE#15,31 TSATN#_KBC7 BT_DET#22

LAN_PWR_ON23

PWR_WLAN31

TP_LED_AMBER#30

CAPS_LED#15,28 AD_OFF34 PM_RSMRST#32

PM_SLP_S4#19,30,32,38

CHG_LED#28

LAN_DSM#23

CAM_PWR#15 SIZE_DET015 SIZE_DET115

EC_BLON15

USB_PWR_EN#32

PWR_LED31

TP_LED_WHITE#30

CAP close to VCC-GND pin pair

0703 -10703 -1

C241

C529

12

SC2D2U10V3KX-1GP

SCD1U16V2ZY-2GP

1 2

AD_IA33

TP32TPAD14-GP TP32TPAD14-GP

1

1 2

R546 0R2J-2-GP

TP36TPAD14-GP TP36TPAD14-GP

ADP_LIMIT GPIO92 AIRLINE_VOLT_RC

PCIE_L_WAKE#

DY

PCB_VER0 PCB_VER1 PCB_VER2

GPIO30

KBC_EAPD#

1

Planar ID[2,1,0]

SA: 0,0,0 SB: 0,0,1

DY

12

R345

R345 10KR2J-3-GP

10KR2J-3-GP

SC: 0,1,0

12

R361

R361 10KR2J-3-GP

10KR2J-3-GP

-1: 0,1,0

5

3D3V_KBC_AUX_VCC3D3V_KBC_AUX_VCC

R377

R377 0R0402-PAD

0R0402-PAD

U22A

104

VREF

97

GPI90/AD0

98

GPI91/AD1

99

GPI92/AD2

100

GPI93/AD3

108

GPIO05

96

GPIO04

101

GPI94

105

GPI95

106

GPI96

107

GPI97

64

GPIO01/TB2

95

GPIO03

93

GPIO06

94

GPIO07

119

GPIO23

6

GPIO24

109

GPIO30

120

GPIO31

65

GPIO32/D_PWM

66

GPIO33/H_PWM

16

GPIO40/F_PWM

17

GPIO42/TCK

20

GPIO43/TMS

21

GPIO44/TDI

22

GPIO45/E_PWM

23

GPIO46/TRST#

24

GPIO47

25

GPIO50/TDO

26

GPIO51

27

GPIO52/RDY#

28

GPIO53

73

GPIO70

74

GPIO71

75

GPIO72

110

GPO82/TRIS#

WPCE773LA0DG-GP

4

BT_TH# 32,34

SCD1U16V2ZY-2GP

80

115

VCC

88

A/D

D/A

GPIO

116

102

VCC19VCC46VCC76VCC

AVCC

LPC

SMB

SP

SPI

GPO83/SOUT_CR/BADDR1

SER/IR

GND5GND18GND45GND78GND89GND

4

VDD

GPIO41 GPIO10/LPCPD#

GPIO11/CLKRUN#

ECSCI#/GPIO54

GPIO67/PWUREQ#

GPIO66/G_PWM

GPIO87/SIN_CR GPO84/BADDR0

AGND

103

1 OF 2

LRESET#

LCLK

LFRAME#

LAD0 LAD1 LAD2 LAD3

SERIRQ KBRST#

GA20

GPIO65/SMI#

GPIO74/SDA2 GPIO73/SCL2 GPIO22/SDA1 GPIO17/SCL1

GPIO77

GPIO76/SHBM

GPIO75 GPIO81

GPIO16 GPIO34 GPIO36

VCORF

KBC_GPIO14

http://laptop-motherboard-schematic.blogspot.com/

5

4

SPI_SDI31 SPI_SDO31 SPI_CS#31 SPI_SCK31

ECSCI#_L

124 7 2 3 126 127 128 1 125 8 122 121 29 9 123

68 67 69 70

81

84 83 82 91

111 113 112

114 14 15

44

R316

C517

3

12

C219

C219 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

DY

LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3

ECSCI#_L EC_SWI#

SHBM

1 2

R337 4K7R2J-2-GPR337 4K7R2J-2-GP

BT_EN# 22

GPIO16GPIO16

2 GND connect at one point

1 2

R470 10KR2J-3-GPR470 10KR2J-3-GP

SPI_WP#2 31

PWR_S5_EN 37

KBC_VCORF

SPI_SDI SPI_SDO SPI_CS# SPI_SCK

+3VL_KBC

DY

10KR2J-3-GP

D7 1SS355PT-GPD7 1SS355PT-GP

K A

EC_SWI#

3

CODEC5V_EN# 28

PLT_RST# 7,17,23,26,27 CLK_PCI_KBC 16 LPC_FRAME# 18,27

SIRQ 19

PM_CLKRUN# 19 KBRCIN# 18 KA20GATE 18

L_BKLT_EN 7

KBC_SDA1 24 KBC_SCL1 24 KBC_SDA0 33,34 KBC_SCL0 33,34

NUMLK_LED# 22

E51_TxD 26

E51_RxD 26

1 2

R342

12

C181

C181 SC1U10V3KX-3GP

SC1U10V3KX-3GP

R350 33R2J-2-GPR350 33R2J-2-GP R358 33R2J-2-GPR358 33R2J-2-GP R366 33R2J-2-GPR366 33R2J-2-GP

EC_SCI#

AIRLINE_VOLT33

LPC_AD[0..3] 18,27

10KR2J-3-GP

PWRBTN#_SB19

1 2 1 2 1 2

+3VL_KBC

WIFI_RF_EN 26

KBC_MUTE#28

TP22TPAD14-GP TP22TPAD14-GP

DSM_ISOLATE#23 KBC_BEEP28 SATA_LED15 BRIGHTNESS15

WIRELESS_BTN#31 TP_BTN#30 TDATA_530 TCLK_530

1 2

R101 100KR2J-1-GPR101 100KR2J-1-GP

1 2

R368 100KR2J-1-GPR368 100KR2J-1-GP

2

1 2

R566

R566 0R0805-PAD

0R0805-PAD

AD_IA

AIRLINE_VOLT_RC

R364

1 2

10KR2J-3-GP

C193 SC15P50V2JN-2-G PC193 SC15P50V2JN-2-GP

1 2

23

1 2

C192 SC15P50V2JN-2-G PC192 SC15P50V2JN-2-GP

32.768Khz 12.5pf 10ppm 1st: 82.30001.691 (KDS)

+3VL

0701 -1

C527 SC D1U16V2ZY-2GPC527 SCD1U16V2ZY-2GP

1 2

C520 SC D1U16V2ZY-2GPC520 SCD1U16V2ZY-2GP

1 2

CAP near ADC

X2

1

X-32D768KHZ-38GPU

4

X3_1 KBC_32KX2

1 2

R118 33KR3-GPR118 33KR3-GP

KBC_32KX1

12

R115

R115 20MR3-GP

20MR3-GP

+3VL_KBC

1

1 2

R333 100KR2J-1-GPR333 100KR2J-1-GP

KBC_SDA0 KBC_SCL0

4

SRN4K7J-8-GP

KBC_SDA1

4

KBC_SCL1

SIRQ

1 2

R374 10KR2J-3-GPR374 10KR2J-3-GP

BT_TH#

RN50

TP near KB connector

RN49

SRN4K7J-8-GP

2nd: 82.30001.861 (EPSON)

2 OF 2

U22B

KBC_32KX1

KBC_32KX2

KBC_GPIO14

1

SPI_SDO_C KROW7 SPI_CS#_C SPI_SCK_C

117

118

+3VS

+3VALW

EC_SCI# 19

EC_SWI# 19

77

32KX1/32KCLKIN

79

32KX2

30

GPIO55/CLKOUT

63

GPIO14/TB1 GPIO20/TA2

31

GPIO56/TA1

32

GPIO15/A_PWM GPIO21/B_PWM

62

GPIO13/C_PWM

13

GPIO12/PSDAT3

12

GPIO25/PSCLK3

11

GPIO27/PSDAT2

10

GPIO26/PSCLK2

71

GPIO35/PSDAT1

72

GPIO37/PSCLK1

86

F_SDI

87

F_SDO

90

F_CS0#

92

F_SCK

WPCE773LA0DG-GP

KBC

KBSOUT15/GPIO61/XOR_OUT

PS/2

FIU

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet of

Date: Sheet

2

2 OF 2

KBSOUT0/JENK#

KBSOUT1/TCK

KBSOUT2/TMS

KBSOUT3/TDI

KBSOUT4/JEN0#

KBSOUT5/TDO

KBSOUT6/RDY#

KBSOUT12/GPIO64 KBSOUT13/GPIO63 KBSOUT14/GPIO62

GPIO60/KBSOUT16 GPIO57/KBSOUT17

KBC WPCE773L

53 52 51 50 49 48 47 43

KBSOUT7

42

KBSOUT8

41

KBSOUT9

40

KBSOUT10

39

KBSOUT11

38 37 36 35 34 33

54

KBSIN0

55

KBSIN1

56

KBSIN2

57

KBSIN3

58

KBSIN4

59

KBSIN5

60

KBSIN6

61

KBSIN7

85

VCC_POR#

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

1

KCOL1 KCOL2 KCOL3 KCOL4 KCOL5 KCOL6 KCOL7 KCOL8 KCOL9 KCOL10 KCOL11 KCOL12 KCOL13 KCOL14 KCOL15 KCOL16 KCOL17 KCOL18

KROW1 KROW2 KROW3 KROW4 KROW5 KROW6

KROW8

10KR2J-3-GP

29

+3VL_KBC

23 1

+3VS

1 23

+3VS

KCOL[1..18]30

KROW[1..8]30

12

R343

EC_RST# 24

of

+3VL_KBC

1

41Thurs day, July 09, 2009

A

Internal KeyBoard Connector

KROW[1..8]29 KCOL[1..18]29

Keyboard matrix ( from vendor )

Eur

C271

123

12

TDATA_5

KCOL9 KCOL8 KCOL5 KCOL3

678

RC4

RC4 SRC100P50V-2-GP

SRC100P50V-2-GP

4 5

0

3

BAV99W-1-GP

+5V_TP

10

00

+3VS

D28

2

1

2

3 4

MATRIXID1#

MATRIXID2#

TP_ON/OFF

SCD1U16V2ZY-2GP

JapUS

1

12

C617

D6

BAV99S-GP

678

123

SCD1U16V2ZY-2GP

6

5

KROW1 KCOL2 KCOL6 KROW4

RC3

RC3 SRC100P50V-2-GP

SRC100P50V-2-GP

4 5

KB1

ACES-CON26-7GP

TCLK_5

27

KROW2

1

KROW8

2

KROW7

3

KCOL10

4

KROW5

5

KROW6

6

KCOL1

7

KROW3

8

KROW4

9

KCOL6

10

KCOL2

11

KROW1

12

KCOL3

13

KCOL5

14

KCOL8

15

KCOL9

16

KCOL7

17

KCOL4

18

KCOL13

19

KCOL14

20

KCOL15

21

KCOL12

22

KCOL11

23

KCOL16

24

KCOL17

25

KCOL18

26 28

1st: 20.K0345.026 2nd: 20.K0201.026

GND GND

KCOL16 KCOL11 KCOL12 KCOL15

678

RC5

RC5 SRC100P50V-2-GP

SRC100P50V-2-GP

123

4 5

1 1

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

TP142 TP28-75-GPTP142 TP28-75-GP TP143 TP28-75-GPTP143 TP28-75-GP

TP144 TP28-75-GPTP144 TP28-75-GP TP145 TP28-75-GPTP145 TP28-75-GP TP146 TP28-75-GPTP146 TP28-75-GP TP147 TP28-75-GPTP147 TP28-75-GP TP148 TP28-75-GPTP148 TP28-75-GP TP149 TP28-75-GPTP149 TP28-75-GP TP150 TP28-75-GPTP150 TP28-75-GP TP151 TP28-75-GPTP151 TP28-75-GP TP152 TP28-75-GPTP152 TP28-75-GP TP153 TP28-75-GPTP153 TP28-75-GP TP154 TP28-75-GPTP154 TP28-75-GP TP155 TP28-75-GPTP155 TP28-75-GP TP156 TP28-75-GPTP156 TP28-75-GP TP157 TP28-75-GPTP157 TP28-75-GP TP158 TP28-75-GPTP158 TP28-75-GP TP159 TP28-75-GPTP159 TP28-75-GP TP160 TP28-75-GPTP160 TP28-75-GP TP161 TP28-75-GPTP161 TP28-75-GP TP162 TP28-75-GPTP162 TP28-75-GP TP163 TP28-75-GPTP163 TP28-75-GP TP164 TP28-75-GPTP164 TP28-75-GP TP165 TP28-75-GPTP165 TP28-75-GP TP166 TP28-75-GPTP166 TP28-75-GP TP167 TP28-75-GPTP167 TP28-75-GP

TP185 TP28-75-GPTP185 TP28-75-GP

1

TP186 TP28-75-GPTP186 TP28-75-GP

1

678

123

4 5

1st: 20.K0320.010 2nd: 20.K0343.010

+5V_TP TDATA_5 TCLK_5 GND TP_LED_AMBER# TP_LED_WHITE# GND TP_ON/OFF +5VS GND

Please populate close TPAD1

KCOL14 KCOL13 KCOL4 KCOL7

RC6

RC6 SRC100P50V-2-GP

SRC100P50V-2-GP

TouchPad Connector

12

DY

C160

SCD1U16V2ZY-2GP

SC1U10V3ZY-6GP

SCD1U16V2ZY-2GP

TPAD1

ACES-CON10-11-GP

TP83 TP28-75-GPTP83 TP28-75-GP

1

TP84 TP28-75-GPTP84 TP28-75-GP

1

TP85 TP28-75-GPTP85 TP28-75-GP

1

TP106 TP28-75-GPTP106 TP28-75-GP

1

TP86 TP28-75-GPTP86 TP28-75-GP

1

TP87 TP28-75-GPTP87 TP28-75-GP

1

TP107 TP28-75-GPTP107 TP28-75-GP

1

TP88 TP28-75-GPTP88 TP28-75-GP

1

TP89 TP28-75-GPTP89 TP28-75-GP

1

TP90 TP28-75-GPTP90 TP28-75-GP

1

PM_SLP_S4#19,29,32,38

12 10 9 8 7 6 5 4 3 2

1 11

C159

+5V_TP +5V_TP

12

4

RN26

RN26 SRN10KJ-11-GP-U

SRN10KJ-11-GP-U

1

2 3

C164 SC33P50V2JN-3GPC164 SC33P50V2JN-3GP

1 2

C161 SC33P50V2JN-3GPC161 SC33P50V2JN-3GP

1 2

TP_LED_AMBER# TP_LED_WHITE# TP_ON/OFF

+5VS

12

EC15

EC15 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

+5VALW

12

R520

DY

.....

D

100KR2J-1-GP

Q32

G

S

2N7002E-1-GP

TDATA_5 29

TCLK_5 29

DY

TP_SLP_S4

TP_LED_AMBER# 29 TP_LED_WHITE# 29

+5VALW

C598

SC1U10V3KX-3GP

12

1 2

DY

R519

R519 10KR2J-3-GP

10KR2J-3-GP

12

R518

R518 100KR2J-1-GP

100KR2J-1-GP

DY

R529

R529 0R0603-PAD

0R0603-PAD

TP_SLP_S4_C

1 2

R297

R297 100R2J-2-GP

100R2J-2-GP

1 2

S

G

+3VS

DY

D

Q31

AO3403-GP

DY

1 2

C599

C599 SCD1U16V2ZY-2GP

SCD1U16V2ZY-2GP

12

R299

R299 10KR2J-3-GP

10KR2J-3-GP

12

C481

C481 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

+5V_TP

12

C597

DY

SCD1U16V2ZY-2GP

TP_BTN# 29

for EMI for EMI

KCOL10 KROW7 KROW8 KROW6 KROW2

678

RC1

RC1 SRC100P50V-2-GP

SRC100P50V-2-GP

123

4 5

for EMI

http://laptop-motherboard-schematic.blogspot.com/

123

KROW3 KCOL1

KROW5

678

RC2

RC2 SRC100P50V-2-GP

SRC100P50V-2-GP

4 5

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

Date: Sheet of

Taipei Hsien 221, Taiwan, R.O.C.

KeyBoard-CONN

HBU16 1.2

30 41Thur sday, July 09, 2009

of

1

A

R393

R393 10KR2J-3-GP

4 4

SPI_CS#29 SPI_SDI29

SPI_WP#229

1 2

R370 33R2J-2-GPR370 33R2J-2-GP

12

R394

R394 10KR2J-3-GP

10KR2J-3-GP

1 2

SPI_CS#

SPI_SDO29 SPI_SCK29

SPI_WP#2 SPI_WP#2_C

G120

G120 GAP-OPEN

GAP-OPEN

U25

1

CS#

2

DO

3

WP# GND4DIO

W25X16VSSIG-GP

B

VCC

HOLD#

CLK

SPI_SDO SPI_SCK

C

EBC

R2

+3VL_KBC+3VL_KBC

21

8 7 6 5

1 2

R392

R392 1KR2J-1-GP

1KR2J-1-GP

R376

SPI_HOLD#_2SPI_SDI_C

R376

1 2

1KR2J-1-GP

12

C524

SCD1U16V2ZY-2GP

PWR_LED29

PDTC124EU-1-GP

R2

Q21

D

PWR_BD_LED# 28

R1

EBC

R2

DY

R1

PDTC124EU-1-GP

R1

Q26

E

PWR_BD_LED# 28

2M Flash ROM 1st: 72.25X16.A01

SB_PWR_LED19

2nd: 72.25165.A01

+5VALW

EC10

12

SCD1U16V2ZY-2GP

3 3

PWR1

ACES-CON10-11-GP

11 1

2 3 4 5 6 7 8 9 10 12

PWR_BD_LED# PWR_BT# WLAN_AMBER WLAN_WHITE# WLAN_BT#

LID_CLOSE#

1st: 20.K0320.010 2nd: 20.K0343.010

2 2

1 1

WIRELESS SWITCH

WLAN_BT#

12

C543

SCD1U16V2ZY-2GP

PWR_BT#

A

+5VS

12

SCD1U16V2ZY-2GP

+3VL

COVER SWITCH

LID_CLOSE# 15,29

12

C532

SCD1U16V2ZY-2GP

R191

1 2

100R2J-2-GP

+3VL

1

2

3 4

EC11

+5VALW

+5VS PWR_BD_LED# PWR_BT# WLAN_AMBER WLAN_WHITE# WLAN_BT# LID_CLOSE# GND GND +3VL

1 1 1 1 1 1 1 1 1 1 1

TP73 TP28-75-GPTP73 TP28-75-GP TP74 TP28-75-GPTP74 TP28-75-GP TP75 TP28-75-GPTP75 TP28-75-GP TP76 TP28-75-GPTP76 TP28-75-GP TP77 TP28-75-GPTP77 TP28-75-GP TP78 TP28-75-GPTP78 TP28-75-GP TP79 TP28-75-GPTP79 TP28-75-GP TP80 TP28-75-GPTP80 TP28-75-GP TP81 TP28-75-GPTP81 TP28-75-GP TP82 TP28-75-GPTP82 TP28-75-GP TP184 TP28-75-GPTP184 TP28-75-GP

WL_LED#

U64

BT_LED22

12

R497

R497 100KR2J-1-GP

100KR2J-1-GP

5 6

DMN66D0LDW-7-GP

Please populate close PWR1

+3VS

12

R187

R187 10KR2J-3-GP

10KR2J-3-GP

12

C335

C335 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

DY

D16

BAV99S-GP

6

5

http://laptop-motherboard-schematic.blogspot.com/

WIRELESS_BTN# 29

PWR_WLAN29

WLAN_BT#

PWR_BT#

B

WLAN LED ENABLE WLAN LED DISABLE

WLAN_WHITE# WLAN_AMBER

R1

PWR_WLAN PWR_WLAN

POWER SWITCH

1 2

12

EC9

SCD1U16V2ZY-2GP

C

WL_LED# WL_LED

EBC

PDTC124EU-1-GP

R2

PDTC124EU-1-GP

PDTC124EU-1-GP Q17

Q17

R372

R372 100R2J-2-GP

100R2J-2-GP

+3VL

12

R379

R379 10KR2J-3-GP

10KR2J-3-GP

12

C531

C531 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

DY

PDTC124EU-1-GP

KBC_PWR_BTN# 29

+5VS

R192

R192 100KR2J-1-GP

100KR2J-1-GP

1 2

34

WLAN_LED#_C

2 1

EBC

R2

Q16

R1

D

+3VS

Q18

R2

E C

12

R499

R499 100KR2J-1-GP

100KR2J-1-GP

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

B

R1

PDTA124EU-1-GP

Q28

D

2N7002E-1-GP

G

.....

S

FWH and CONN.

WLAN_LED# 26

WL_LED#

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

31 41Thursday, July 09, 2009

of

E

of

1

CORE_PWRGD35

G792_RST#24

PM_SLP_S3#19,23,24,29,38,39,40

R501

R501 470R2J-2-GP

470R2J-2-GP

+1.5VS

1 2

DY

PM_SLP_S3 PM_SLP_S3

U65

3 4 2 1

DMN66D0LDW-7-GP

1 2

R77 10KR2J-3-GPR77 10K R2J-3-GP

D35

K A

1SS355PT-GP

DY

5

1 2

6

G792_RST#_1

1 2 3

74LVC1G08GW -1-GP

Discharge Circuit

+3VL

R424

DY

100KR2J-1-GP

1 2

DY

R500

R500 470R2J-2-GP

470R2J-2-GP

+3VS

PM_SLP_S4 PM_SLP_S3

U20

B A GND

+3VALW

5

VCC

4

Y

3 4 2 1

DMN66D0LDW-7-GP

1 2

R113 0R0402-PADR113 0R0402-PAD

Q10

PMBS3906-GP

2

DY

1

DY

K A

DY

K A

DY

K A 12

PMBS3906-GP

3

DY

D8

D8 1SS355PT-GP

1SS355PT-GP

D9

D9 1SS355PT-GP

1SS355PT-GP

D10

D10 1SS355PT-GP

1SS355PT-GP

R117

R117 2K2R2J-2-GP

2K2R2J-2-GP

DY

12

R120

R120 10KR2J-3-GP

10KR2J-3-GP

RSMRST#_SB 19PM_RSMRST#29

AD_IN#29,33

PM_RSMRST#

BT_TH#29,34

+3VALW

R121

1 2

DY

Q44

2N7002E-1-GP

Q45

2N7002E-1-GP

S

DY

4K7R2J-2-GP

D

.

. .

.

S

G

D

.

. .

.

G

PM_PWROK 7,19

U27

DY

5 6

DY

R506

R506 470R2J-2-GP

470R2J-2-GP

12

+1.05VS

PM_SLP_S4# 19,29,30,38

R503

R503 470R2J-2-GP

470R2J-2-GP

+5VS

1 2

DY

USB_PWR_EN# PM_SLP_S3

0630 -1

DY

U66

3 4 2 1

DMN66D0LDW-7-GP

Run Power

+3VL

R425

100KR2J-1-GP

1 2

PM_SLP_S3

RUN_PWR_CTLR26

U28

3 4 2 1

DMN66D0LDW-7-GP

5 6

5

RUN_PWR_CTLR

6

1 2

DY

R502

R502 470R2J-2-GP

470R2J-2-GP

DCBATOUT

12

R433

330KR2J-L1-GP

PM_SLP_S3# 19,23,24,29,38,39,40

R505

R505 470R2J-2-GP

470R2J-2-GP

+0.9VS

+5V

1 2

DY

PM_SLP_S4 PM_SLP_S3

DY

U67

3 4 2

5

1

DMN66D0LDW-7-GP

6

1 2

DY

R504

R504 470R2J-2-GP

470R2J-2-GP

+1.8V

0523 SF

+5VALW to +5VS Transfer

+5VALW to +5V Transfer

G546B2P1 Low active, 1.5A per channel

+5VALW +5V

12

DY

C645

RUN_PWR_CTLR

D34

MMSZ5245BPT-GP

1st:83.15R03.F3F 2nd:83.15R03.G3F

+3VALW to +3VS Transfer

+5VS

12

EC49

SCD1U25V3ZY-1GP

U33

+3VS

12

EC43

U33

1

S

2

S

3

S

4 5

GD

SI4800BDY-T1

U29

1

S

2

S

3

S

4 5

GD

SI4800BDY-T1

SCD1U25V3ZY-1GP

1 2

C611

DY

SCD1U25V3ZY-1GP

1 2

C612

DY

SCD1U25V3ZY-1GP

KA

12

R429

R429 470R2J-2-GP

470R2J-2-GP

12

C558

C558 SCD01U50V2KX-1GP

SCD01U50V2KX-1GP

EC56

D

D D

D

D D

D

SCD1U25V2ZY-1GP

+5VALW

8 7 6

+3VALW

8 7 6

+3VS

12

DY

SC1U10V3ZY-6GP

USB_PWR_EN#29

12

EC57

SCD1U25V2ZY-1GP

http://laptop-motherboard-schematic.blogspot.com/

U34

1

GND

OC1#

2

IN

OUT1

3

EN1/EN1#

OUT2

EN2/EN2#4OC2#

G546B2P1UF-GP

+5VALW

1 2

R574

R574 10KR2J-3-GP

10KR2J-3-GP

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

PWM_OC#

8 7 6 5

12

C644

SCD1U16V2ZY-2GP

DY

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

PWRPLANE

HBU16 1.2

12

C646

DY

SC10U10V5ZY-1GP

32 41Thursday, July 09, 2009

1

of

5

4

3

2

1

AD+

D15

D D

+3VL

12

R6

100KR2J-1-GP

AD_IN#29,32

SC1U10V3KX-3GP

C C

B B

12

DY

C8

383KR3F-GP

49K9R2F-L-GP

SCD1U50V3ZY-GP

Q3

D

.....

2N7002E-1-GP

U3

3 4 2 1

DMN66D0LDW-7-GP

AD+

12

R217

12

R216

CHG_AGND

MAX8731_LDO

12

R4

R4 10KR2F-2-GP

10KR2F-2-GP

G

12

R5

R5 15K4R2F-GP

15K4R2F-GP

S

ACAV_IN

5 6

1 2

R194 0R0402-PADR194 0R0402-PAD

+3VL

12

C372

C372 SCD01U50V2ZY-1GP

SCD01U50V2ZY-1GP

ACAV_IN

DC_IN_D

1 2

12

C346

C346 SC1U25V5KX-1GP

SC1U25V5KX-1GP

1 2

R579

R579 0R0603-PAD

0R0603-PAD

KBC_SCL029,34

12

EC20

SCD1U50V3ZY-GP

NEAR KBC POWER

KBC_SDA029,34

AD_IA29

R214

1 2

R205

R205 10KR2F-2-GP

10KR2F-2-GP

A A

12

C355

SCD1U16V2ZY-2GP

MAX8731_CCV1

C375

C368

12

C368

12

SCD01U50V2ZY-1GP

C329 SCD1U25V3ZY-1GPC329 SCD1U25V3ZY-1GP

1 2

R186

R186 15K4R2F-GP

15K4R2F-GP

Layout Trace 250mil

R184

R184 10KR2J-3-GP

10KR2J-3-GP

DCIN_GATE1

4K7R2F-GP

12

C351

C351 SCD1U25V3KX-GP

SCD1U25V3KX-GP

CHG_AGND

C367

SCD01U50V2ZY-1GP

D

8

D

7

D

6

AO4407A-GP

MAX8731_DCIN MAX8731_ACIN MAX8731_VDD

ACAV_IN

MAX8731_CCV MAX8731_CCI MAX8731_CCS MAX8731_REF

C371

12

SC1U10V3KX-3GP

U2

S

S S

S GD

GD

R183

1 2

CHG_AGND

MAX8731_DAC

C369

12

SCD1U16V2ZY-2GP

CHG_AGND

12

1 2 3 45

49K9R2F-L-GP

R185

R185 100KR2F-L1-GP

100KR2F-L1-GP

NEAR

SCD1U25V3ZY-1GP

DCIN_GATE2

U44

22

DCIN

2

ACIN

11

VDD

13

ACOK

10

SCL

9

SDA

14

BATSEL

8

INP

6

CCV

5

CCI

4

CCS

3

REF

7

DAC

12

GND

MAX8731AETI-GP

AIRLINE_VOLT 29

AD<=17V, disable charger function

AD+_TO_SYS

12

EC21

R182

1 2

100KR2J-1-GP

12

CHG_AGND

CHG_AGND CHG_AGND

1

28

CSSP

ASNS

GND

29

27

CSSN

26

VCC

25

BST

21

LDO

24

DHI

23

LX

20

DLO

19

PGND

18

CSIP

17

CSIN

16

FBSB

15

FBSA

1 2

G61

G61 GAP-CLOSE-PWR

GAP-CLOSE-PWR

D15

2

3

1

BAV99W-1-GP

DY

Adaptor In Soft-Start Circuit

Layout Trace 250mil

1 2

R3

R3 D01R2512F-4-GP

D01R2512F-4-GP

1 2

G1

C362

C362 SCD1U25V3KX-GP

SCD1U25V3KX-GP

MAX8731_CSSP

MAX8731_VCC

MAX8731_BST MAX8731_LDO

MAX8731_DHI

R1971R3F-GPR1971R3F-GP

MAX8731_LX

MAX8731_DLO

MAX8731_CSIP MAX8731_CSIN

BAT_SENSE BT+SENSE

12

1 2

GAP-CLOSE-PWRG1GAP-CLOSE-PWR

MAX8731_CSSN

MAX8731_BST1

R201

1 2

0R0603-PAD

1 2

C352

1 2

SC220P50V2JN-3GP

1 2

100R2F-L1-GP-U

R193

C338

C338 SCD01U50V2ZY-1GP

SCD01U50V2ZY-1GP

Need Check MAXIM Sming Use MAX8731 or MAX8731A

5

http://laptop-motherboard-schematic.blogspot.com/

4

3

DCBATOUT DCBATOUT

12

EC32

EC31

SCD1U50V3ZY-GP

DY

AD+

12

R200

R200 470KR2J-2-GP

470KR2J-2-GP

NEAR INPUT AD+

C7

C6

12

SC10U25V6KX-1GPC7SC10U25V6KX-1GP

SC10U25V6KX-1GPC6SC10U25V6KX-1GP

CHG_PWR

L9

D01R2512F-4-GP

1 2

+3VL

G2

GAP-CLOSE-PWRG2GAP-CLOSE-PWR

12

EC22

EC23

SCD1U50V3ZY-GP

C361

C361 SCD1U25V3KX-GP

SCD1U25V3KX-GP

R204

33R2J-2-GP

D19

1SS400PT

1 2

12

EC24

SCD1U50V3ZY-GP

12

CHG_AGND

21

C349

C349 SCD1U25V3KX-GP

SCD1U25V3KX-GP

12

EC25

EC26

SCD1U50V3ZY-GP

1 2

G5

12

C358

C358 SC1U10V3KX-3GP

SC1U10V3KX-3GP

SI4800BDY-T1

C340

1 2

SC1U10V3KX-3GP

SI4800BDY-T1

12

EC27

SCD1U50V3KX-GP

DY

DCBATOUT

1 2

G6

GAP-CLOSE-PWRG5GAP-CLOSE-PWR

U4

MAX8731_LX1

U5

SCD1U50V3ZY-GP

12

EC28

SCD1U50V3ZY-GP

DY

1 2

G4

GAP-CLOSE-PWRG6GAP-CLOSE-PWR

PWR_MAX8731PW R_MAX8731

678

DDD

GD

4 5

EC30

EC29

SCD1U50V3ZY-GP

1 2

G3

GAP-CLOSE-PWRG3GAP-CLOSE-PWR

GAP-CLOSE-PWRG4GAP-CLOSE-PWR

C5

12

SC10U25V6KX-1GPC5SC10U25V6KX-1GP

SSS

123

12

2nd:FDS8884(84.8884.A37)

1 2

COIL-6D8UH-2-GP

SSS

123

COIL-6D8UH-2-GP

678

DDD

GD

4 5

2nd:FDS8884(84.8884.A37)

BT+SENSE 34

Title

Size Document Number Rev

A3

Date: Sheet

2

Date: Sheet

CHARGER MAX8731ETI

12

DY

Layout Trace 300mil

U7

S

1

S

2

S

3

GD

4 5

AO4407A-GP

C4

12

EC38

SCD1U25V3KX-GPC4SCD1U25V3KX-GP

SCD1U50V3KX-GP

DY

R10

Layout Trace 300mil

1 2

12

G10

G11

1 2

GAP-CLOSE-PWR

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221 , Taiwan, R.O.C.

Taipei Hsien 221 , Taiwan, R.O.C.

Warrior

DY

C343

12

EC53

EC52

DY

SCD1U50V3KX-GP

BT+

D

8

D

7

D

6

BT+

C344

SC10U25V6KX-1GP

1

SC10U25V6KX-1GP

33 41Thur sday, July 09, 2009

of

C344

C342

12

SC10U25V6KX-1GP

EC1

C345

12

SCD1U50V3ZY-GP

SC10U25V6KX-1GP

DY

1

5

4

3

2

1

Adaptor in to generate DCBATOUT

DCIN1

1 2

3 4

D D

ETY-CON6-8-GP-U

5 6

DCIN_LED

R181

1 2

4K7R2J-2-GP

LIMIT_SIGNALAD+

1st: 21.65005.106 2nd: 21.65012.106

DCIN_LED GND LIMIT_SIGNAL AD_JK AD_JK AD_JK GND

C C

1 1 1 1 1 1 1

TP125 TP28-75-GPTP125 TP28-75-GP TP126 TP28-75-GPTP126 TP28-75-GP TP127 TP28-75-GPTP127 TP28-75-GP TP128 TP28-75-GPTP128 TP28-75-GP TP181 TP28-75-GPTP181 TP28-75-GP TP183 TP28-75-GPTP183 TP28-75-GP TP129 TP28-75-GPTP129 TP28-75-GP

12

C328

SCD1U50V3ZY-GP

AD_OFF29

2

IN

12

C3

SCD1U50V3ZY-GP

Q1

3

R1

1

R2

DTC114EUA-1-GP

AD_JK

OUT

GND

D33

D33 P6SBMJ24APT-GP

P6SBMJ24APT-GP

1st: 83.P6SBM.AAG

A K

2nd: 83.P6SBM.CAG (TVS 600W)

PDTA124EU-1-GP

AD_OFF#

B

AD+_2

12

C2

R2

SC1U50V5ZY-1-GP

200KR2J-L1-GPR2200KR2J-L1-GP

R2

E

R1

C

Q2

12

R1

R1 100KR2J-1-GP

100KR2J-1-GP

U1

S

D

S

1 2 3 4 5

D

S

D

S

D

S

D

S

D

GD

AO4407A-GP

C1

1 2

SCD1U25V3ZY-1GP

AD+

8 7 6

BATTERY CONNECTOR

BT+

+3VL

D2

2

1

+3VL

2

1

+3VL

2

1

12

C614

SCD1U16V2ZY-2GP

12

C615

SCD1U16V2ZY-2GP

12

C616

SCD1U16V2ZY-2GP

G12

BT+SENSE33

http://laptop-motherboard-schematic.blogspot.com/

4

1 2

GAP-CLOSE

3

12

C16

C16 SCD1U25V3ZY-1GP

SCD1U25V3ZY-1GP

KBC_SCL0

B B

A A

KBC_SDA0

BT_TH#

5

3

BAV99W-1-GP

D1

3

BAV99W-1-GP

D3

3

BAV99W-1-GP

KBC_SDA029,33 KBC_SCL029,33

BT_TH#29,32

RN56

2 3 1

1 2

R9 100R2J-2-GPR9 100R2J-2-GP

12

C13

C13 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

2

4

SRN100J-3-GP

BAT_SDA0 BAT_SCL0

BAT_TH#

Title

Size Document Number Rev

A3

Date: Sheet

Date: Sheet of

BAT1

10

8 7 6 5 4 3 2

1 9

FOX-CON8-5-GP-U1

1st: 20.80979.008 2nd: 20.81036.008

BT+ BT+ BT+ GND GND BAT_SDA0 BAT_SCL0 BAT_TH# GND

AD/BATT CONN

1 1 1 1 1 1 1 1 1

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Warrior

1

TP182 TP28-75-GPTP182 TP28-75-GP TP130 TP28-75-GPTP130 TP28-75-GP TP131 TP28-75-GPTP131 TP28-75-GP TP132 TP28-75-GPTP132 TP28-75-GP TP133 TP28-75-GPTP133 TP28-75-GP TP134 TP28-75-GPTP134 TP28-75-GP TP135 TP28-75-GPTP135 TP28-75-GP TP136 TP28-75-GPTP136 TP28-75-GP TP137 TP28-75-GPTP137 TP28-75-GP

34 41Thursday, July 09, 2009

of

1

5

DCBATOUT DCBATOUT_6260_1

D D

C C

B B

A A

GAP-CLOSE-PWR

CPU_PROCHOT#_R3

6260_AGND

Close to phase 1 Inductor

G29

1 2

G28

1 2

G27

1 2

G26

1 2

G89

1 2

G90

1 2

G91

1 2

G92

1 2

H_DPRSTP#4,7,18

1 2

ALL_PWRGD19,37,38,39

PM_DPRSLPVR7,19

+1.05VS

1 2

C184

SCD015U50V3KX-GP

5

12

R94

R94 68R2-GP

68R2-GP

6260_AGND

R256

4K02R2F-GP

H_VID[6..0]5

CLK_EN#19

1 2

R97 180R2F-1-GPR97 180R2F-1-GP

6260_COMP_R

1 2

C190

SCD022U16V2KX-3GP

1 2

SC220P50V2KX-3GP

G95

1 2

GAP-CLOSE-PWR-2U

KBC reset Pin to IMVP PGD_IN(pin 2)

1 2

SC1U10V3KX-3GP

1 2

R301 0R0402-PADR301 0R0402-PAD

1 2

R92

R92 1KR2F-3-GP

1KR2F-3-GP

1 2

68K1R2F-1-GP

C185

PSI#4

1 2

C189

R254

NTC-470K-1-GP

H_VID0 H_VID1 H_VID2 H_VID3 H_VID4 H_VID5 H_VID6

C183

C183 SC1800P50V2KX-1GP

SC1800P50V2KX-1GP

R98

R90

R90 10KR2F-2-GP

10KR2F-2-GP

6260_AGND

GAP-CLOSE-PWR-2U

GAP-CLOSE-PWR-2U GAP-CLOSE-PWR-2U

GAP-CLOSE-PWR-2U

1 2

R296 1KR2J-1-GPR296 1KR2J-1-GP

1 2

R298 499R2F-2-GPR298 499R2F- 2-GP

1 2

C182 SC1KP50V2KX-1GPC182 SC1KP50V2KX-1GP

1 2

R96

R96 6K98R2-GP

6K98R2-GP

VSS_SENSE5

VCC_SENSE5

http://laptop-motherboard-schematic.blogspot.com/

10R3J-3-GP

6260_AGND

R89

1 2

0R0402-PAD

1 2

1 2 1 2 1 2 1 2 1 2 1 2 1 2

4

+5VALW

12

R295

12

6260_AGND

R93

147KR2F-GP

G33

G33 G32

G32 G31

G31 G30

G30 G34

G34 G35

G35 G36

G36

6260A_VR_ON

6260_AGND

4

SCD01U50V2KX-1GP

6260_VDD

C480

C480 SC1U10V3KX-3GP

SC1U10V3KX-3GP

6260_AGND

6260_PSI#

6260_RBIAS

6260_NTC 6260_SOFT 6260_VID0

6260_VID1 6260_VID2 6260_VID3 6260_VID4 6260_VID5 6260_VID6

6260_DPRSLPVR CLK_ENABLE#

H_DPRSTP#

6260_VDIFFVDIFF_C

6260_FB

6260_COMP

6260_VW

C177

1 2

SC1KP50V2KX-1GP

R300

1 2

0R0402-PAD

R302

1 2

0R0402-PAD

10R3J-3-GP

C479

6260_AGND

U19

19

VSS

41

GND

1

PSI#

2

PMON

3

RBIAS

4

VR_TT#

5

NTC

6

SOFT

28

VID0

29

VID1

30

VID2

31

VID3

32

VID4

33

VID5

34

VID6

35

VR_ON

36

DPRSLPVR

38

CLK_EN#

37

DPRSTP#

11

VDIFF

10

FB

9

COMP

8

VW

6260_RTN

12

C178

SCD01U50V2ZY-1GP

DCBATOUT_6260_1

12

R294

12

6260_VIN

18

20

VIN

VDD

VSEN

RTN

12

13

6260_VSEN

12

C179

C179 SC1KP50V2KX-1GP

SC1KP50V2KX-1GP

6260_AGND

+3.3V_6260

39

3V3

DROOP14DFB

6260_DROOP

1 2

0R0402-PAD

+3VS

12

R303

R303 1K91R2F-1-GP

1K91R2F-1-GP

40

PGOOD

FCCM

PWM1

ISEN1

PWM2

ISEN2

PWM3

ISEN3

OCSET

VSUM

VO

ISL6260CCRZ-T-GP

15

6260_DFB

R76

1 2

5K36R2F-GP

R312

1 2

3

24

27

23

26

22

25 21

7 17

16

3

6260_FCCM

6260_PWM1

6260_ISEN1

6260_PWM2

6260_ISEN2

6260_OCSET 6260_VSUM

+3VALW

CORE_PWRGD 32

6260_FCCM 36

6260_PWM2 36

6260_ISEN2 36

+5VALW

6260_AGND

SCD22U10V2KX-1GP

1 2

C167

6260_VO

12

R75

R75 1KR2F-3-GP

1KR2F-3-GP

6260_VO

C171

C171 SC330P50V3KX-GP

SC330P50V3KX-GP

84.04841.037 ON4841 POWERPAK Id=57A, Qg=11.5~17nc Rdson=9.2~11.4mOhm

SI7686DP-T1-GP

12

R74

12

6260_AGND

6208_UG1

6208_PH16260_PMON

SI7636DP

6208_LG1

4K53R2F-1-GP

C170

C170 SCD1U10V2KX-4GP

SCD1U10V2KX-4GP

6260_ISEN1 36

R95

12K7R3F-GP

1 2

12

C168

SCD068U10V2KX-1GP

12

C449

C449 SC1U10V3KX-3GP

SC1U10V3KX-3GP

6260_FCCM

DCBATOUT_6260_1

678

DDD

DY

U15

4 5

567

DDD

D

U16

SSS

123

84.04835.F37 ON4835 POWERPAK Id=104A, Qg=22~39nc Rdson=4.3~5mOhm

R73

R73 2K94R2F-GP

2K94R2F-GP

1 2

R255

R255 NTC-10K-9-GP

NTC-10K-9-GP

1 2

SSGD

123

8

G

4

2

S

2

6

678

DDD S

4 5

567

DDD

D

SSS

123

6260_VSUM 36

Close to phase 1 Inductor

1

+5VALW

R260

U58

PWM

FCCM

U55

SSGD

SI7686DP-T1-GP

123

8

U56

G

SI7636DP

4

R260

0R0402-PAD

5

1

VCC

BOOT PHASE

UGATE LGATE

GND

3

9

ISL6208CRZ-TGP-U

12

C148

SCD1U50V3KX-GP

12

7 8 4

12

C143

L25

IND-D36UH-9-GP

1 2

G94

1 2

GAP-CLOSE-PWR-2U

6260_ISEN1_G1

R278

1 2

10KR2F-2-GP

R273

5K11R3F-1-GP

1 2

6260_VSUM

1 2

C450

C450 SCD22U10V2KX-1GP

SCD22U10V2KX-1GP

6208_PH16260_PWM1 6208_UG1 6208_LG1

12

C131

SC10U25V6KX-1GP

1 2

C478

C478 SCD22U10V2KX-1GP

SCD22U10V2KX-1GP

6260_ISEN1

12

C440

SC10U25V6KX-1GP

CYNTEC 0.36uH Idc=30A 10*11.5*4 DCR=1.05mOhm

G93

GAP-CLOSE-PWR-2U

6260_ISEN1_G2

R280

10R2F-L-GP

Close to IC

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

ISL6266CCRZ_CPU_CORE(1/2)

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

35 41Thur sday, July 09, 2009

1

6260_VO

C444

12

6260_VO

SC10U25V6KX-1GP

12

EC35

DY

+VCC_CORE

1 2

6260_ISEN2

of

SCD1U50V3KX-GP

R279

10KR2F-2-GP

36

1

5

D D

+5VALW

R247

12

0R0402-PAD

12

C415

C415 SC1U10V3KX-3GP

SC1U10V3KX-3GP

6260_PWM235

6260_FCCM35

C C

B B

DCBATOUT DCBATOUT_6260_2

G82

1 2

GAP-CLOSE-PWR

G81

1 2

GAP-CLOSE-PWR

G80

1 2

GAP-CLOSE-PWR

G79

1 2

GAP-CLOSE-PWR

G86

1 2

GAP-CLOSE-PWR

G87

1 2

GAP-CLOSE-PWR

G84

1 2

GAP-CLOSE-PWR

G83

1 2

GAP-CLOSE-PWR

6260_FCCM

U52

2

PWM

6

FCCM

0R0402-PAD

5

1

VCC

BOOT PHASE

UGATE LGATE

GND

ISL6208CRZ-TGP-U

3

9

7 8 4

4

1 2

C420

C420 SCD22U10V2KX-1GP

SCD22U10V2KX-1GP

6208_PH26260_PWM2 6208_UG2 6208_LG2

84.04841.037 ON4841 POWERPAK Id=57A, Qg=11.5~17nc Rdson=9.2~11.4mOhm

84.04835.F37 ON4835 POWERPAK Id=104A, Qg=22~39nc Rdson=4.3~5mOhm

DY

U13

SI7686DP-T1-GP

6208_UG2

6208_PH2

U14

SI7636DP

6208_LG2

DCBATOUT_6260_2

678

DDD S

SSGD

123

4 5

567

8

DDD

D

SSS

G

SSS

G

123

4

6260_VSUM35

6260_ISEN235

3

C396

L20

IND-D36UH-9-GP

1 2

G85

GAP-CLOSE-PWR-2U

R290

1 2

C396

12

SC10U25V6KX-1GP

1 2

4 5

567

D

SSS

123

678

DDD

SSGD

S

SSGD

S

123

8

G

4

U50

U50 SI7686DP-T1-GP

SI7686DP-T1-GP

U51

U51 SI7636DP

SI7636DP

6260_VSUM

6260_ISEN2

C62

12

1 2

6260_ISEN2_G1

10KR2F-2-GP

R289

R289 5K11R3F-1-GP

5K11R3F-1-GP

1 2

SCD1U50V3KX-GP

2

C395

12

SC10U25V6KX-1GP

CYNTEC 0.36uH Idc=30A 10*11.5*4 DCR=1.05mOhm

G88

G88 GAP-CLOSE-PWR-2U

GAP-CLOSE-PWR-2U

6260_ISEN2_G2

1 2

C477

C477 SCD22U10V2KX-1GP

SCD22U10V2KX-1GP

6260_VO35

C60

12

SC10U25V6KX-1GP

R286

R286 10R2F-L-GP

10R2F-L-GP

6260_ISEN135

C61

12

SC10U25V6KX-1GP

R275

10KR2F-2-GP

1

+VCC_CORE

TC6

12

SE330U2VDM-L-GP

1 2

TC4

12

SE330U2VDM-L-GP

DY

Panasonic 330uF, 2V ESR=9mȍ, Iripple=3A

TC17

12

TC16

12

SE330U2VDM-6-GP

+VCC_CORE

12

SE330U2VDM-L-GP

TC5

DY

TC3

SE330U2VDM-L-GP

A A

5

http://laptop-motherboard-schematic.blogspot.com/

4

3

2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

ISL6260CCRZ_CPU_CORE(2/2)

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

36 41Thur sday, July 09, 2009

1

of

1

5

SI4800, SO-8 Id=9A, Qg=8.7~13nC Rdson=23~30mohm

12

C580

R481

R480

C579

C580

SC10U25V6KX-1GP

L7

1 2

IND-3D3UH-57GP

SI4800BDY-T1

G112

GAP-CLOSE-PWR-3-GP

12

C578

DY

3D3V_PWR

ST220U6D3VDM-20GP

3D3V_PWR

12

6K65R2F-GP

10KR2F-2-GP

DY

SCD01U50V2KX-1GP

D D

TC11

Sanyo 220uF 6.3V

C C

ESR=25mohm Iripple=2.4A

12

SC10U25V6KX-1GP

U36

12

R482

DY

0R2J-2-GP

12

C574

DY

SC18P50V2JN-1-GP

DCBATOUT_51125_2

678

DDD

SSS

GD

SSS

GD

123

4 5

678

DDD

SSS

GD

SSS

GD

123

4 5

+51125_VREF

Close to IC TPS51125

B B

A A

SKIPSEL

TONSEL

Design Current=6A OCP>8A

1 2

G42

G42 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G43

G43 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G44

G44 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G39

G39 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G40

G40 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G41

G41 GAP-CLOSE-PWR

GAP-CLOSE-PWR

GND

200k/CH1 300k/CH1 365k/CH1

5

VREF

AUTOSKIP

245k/CH1

12

EC42

SCD1U25V3ZY-1GP

00A AUTOSKIP

375k/CH2250k/CH2 305k/CH2

VREG3

DCBATOUT

U39

U39 SI4800BDY-T1

SI4800BDY-T1

1 2

R484 0R2J-2-GP

+3VL

R485 0R0402-PADR485 0R0402-PAD

+VL

R486 0R2J-2-GP

R486 0R2J-2-GP R487 0R2J-2-GP

R487 0R2J-2-GP

+3VL

+51125_VREF

00A AUTOSKIPPWM

460k/CH2

C572

SCD1U25V3KX-GP

1 2

DY

1 2 1 2

DY

1 2

DY

R488 0R0402-PADR488 0R0402-PAD R489 0R2J-2-GP

R489 0R2J-2-GP R490 0R2J-2-GP

R490 0R2J-2-GP

VREG5

http://laptop-motherboard-schematic.blogspot.com/

51125_VBST2_L

+51125_VREF

SCD22U10V2KX-1GP

1 2 1 2

DY

1 2

DY

PWR_S5_EN29

4

1 2

G60

G60 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G59

G59 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G58

G58 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G57

G57 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

R477 0R0603-PADR477 0R0603-PAD

1 2

R478 0R0603-PADR478 0R0603-PAD

1 2

12

C575

4

DCBATOUT

U30

VBST2 DRVH2 LL2 DRVL2

VO2 VFB2

EN0 ENTRIP2 VREF TONSEL

SKIPSEL

C577

12

R578

R578 0R0603-PAD

0R0603-PAD

51125_VIN

16

VIN

VBST1

DRVH1

DRVL1

PGOOD

ENTRIP1

VREG3

VREG5

8

17

51125_VREG3

51125_VREG5

12

51125_ENTRIP

LL1

VO1

VFB1

GND GND

VCLK

C576

C576 SC22U6D3V5MX-2GP

SC22U6D3V5MX-2GP

51125_ENTRIP1

51125_ENTRIP2

DCBATOUT_51125_2

51125_VBST2 51125_DRVH2 51125_LL2 51125_DRVL251125_DRVL2_L

51125_VO2 51125_VFB2

R483

51125_EN0

820KR2F-GP

51125_ENTRIP2

51125_TONSEL

51125_SKIPSEL

+3VL +VL

S

G

9 10 11 12

7

5

13

6

3

4

14

TPS51125RGER-GP

G118

1 2

GAP-CLOSE-PWR

SC4D7U10V5ZY-3GP

Q42

.....

D

2N7002E-1-GP

3

DCBATOUT

12

C568

C569

SC10U25V6KX-1GP

SCD01U50V2KX-1GP

51125_VBST1 51125_VBST1_L

22

51125_DRVH1

21

51125_LL1

20

51125_DRVL1 51125_DRVL1_L

19

51125_VO1

24

51125_VFB1

2

23

51125_ENTRIP1

1 15 25

18

G119

1 2

GAP-CLOSE-PWR

1 2

R471 0R0603-PADR471 0R0603-PAD

1 2

R472 0R0603-PADR472 0R0603-PAD

1 2

G53

G53 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G45

G45 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G52

G52 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G54

G54 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G111

G111 GAP-CLOSE-PWR

GAP-CLOSE-PWR

0630 -1

Q40

.....

Q41

.....

G

S

G

S

C608

C589

D

12

2N7002E-1-GP

SC18P50V2JN-1-GP

DY

12

SC18P50V2JN-1-GP

DY

3

R508

R508 160KR2F-GP

160KR2F-GP

12

R498

R498 160KR2F-GP

160KR2F-GP

2N7002E-1-GP

D

2N7002E-1-GP

3D3V_PWR

DY

+3VL

12

C570

1 2

SCD1U25V3KX-GP

12

R476

R476 100KR2J-1-GP

100KR2J-1-GP

R544

R544 100KR3J-L-GP

100KR3J-L-GP

2

DCBATOUT_51125_1

678

DDD

U35

SI4800BDY-T1

SSS

GD

SSS

GD

123

4 5

678

DDD

U38

SI4800BDY-T1

SSS

GD

SSS

GD

123

4 5

ALL_PWRGD 19,35,38,39

Close to IC TPS51125

5V_PWR

2

1

SC10U25V6KX-1GP

L6

0R2J-2-GP

12

C583

SC10U25V6KX-1GP

5V_PWR

G110

GAP-CLOSE-PWR-3-GP

12

Sanyo 220uF 6.3V ESR=25mohm Iripple=2.4A

12

R474

R474 30KR2F-GP

30KR2F-GP

12

R475

R475 20KR2F-L-GP

20KR2F-L-GP

12

TC12

ST220U6D3VDM-20GP

R473

C571

5V_PWR

12

DY

12

DY

12

C581

C582

SCD01U50V2KX-1GP

1 2

IND-3D3UH-57GP

SI4800, SO-8 Id=9A, Qg=8.7~13nC Rdson=23~30mohm

SC18P50V2JN-1-GP

Design Current=6A OCP design>8A

1 2

G46

G46 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G50

G50 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G49

G49 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G51

G51 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G48

G48 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G47

G47 GAP-CLOSE-PWR

GAP-CLOSE-PWR

1 2

G113

G113 GAP-CLOSE-PWR

GAP-CLOSE-PWR

Title

Size Document Number Rev

Date: Sheet of

Date: Sheet

TPA51125 +5VALW +3VALW

A3

+5VALW+3VALW3D3V_PWR

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221 , Taiwan, R.O.C.

Taipei Hsien 221 , Taiwan, R.O.C.

HBU16 1.2

37 41Thur sday, July 09, 2009

of

1

of

1

5

4

3

2

1

TI TPS51116 for 1D8V and 0D9V

+5VALW

12

R227

R227 5D1R3J-GP

R16

TPS51116_CS

R231

1 2

DY

1 2

7K68R2F-GP

1 2

SC1U10V3KX-3GP

D D

+3VALW

ALL_PWRGD19,35,37,39

+1.8V_RUN_P

C C

+1.8V_RUN_P

B B

10KR2F-2-GP

PM_SLP_S4#19,29,30,32 PM_SLP_S3#19,23,24,29,32,39,40

+0.9VP

51116_VDD

C35SC1KP50V2KX-1GP C35SC1KP50V2KX-1GP

16

14

ILIM PGD NC#12 EN/PSV VTTEN VTTIN

NC#7

PGND2 TON

VTT VTTS

GND

25

C96

VSSA

3

DY

VDDP

12

13 12 11 10 23

7

1 4

24

2

State S3 S5 VDDR VTTREF VTT

S0

S3

S4/S5

Hi Hi

Lo Lo

On

HiLo

On

Off Off Off

On

Off(Hi-Z)

5D1R3J-GP

12

C43

C43 SC1U10V3KX-3GP

SC1U10V3KX-3GP

+5VALW

TPS51116_VDDP

15

VDDP

PGND1 PGND1

VDDQS

VCCA

REF

TPS51116RGER-GP-U

5

TP51116_REF

1 2

0R0603-PAD

12

1 2

R577

R577 0R0603-PAD

0R0603-PAD

U12

TPS51116_VBST1 TPS51116_VBST

22

BST

TPS51116_UGT

21

DH

TPS51116_PHS

20

LX

TPS51116_LGT

19

DL

18 17

8 9

FB

+5VALW

14KR2F-GP

DDR_VREF_S3

12

DY

14KR2F-GP

C24

C24 SC10U6D3V5MX-3GP

SC10U6D3V5MX-3GP

6

R20

C47

C47 SCD033U50V3KX-1GP

SCD033U50V3KX-1GP

+1.8V_RUN_P

12

C38

C38 SC1U10V3KX-3GP

SC1U10V3KX-3GP

R13

1 2

+1.8V_RUN_P

R21

DY

0R0603-PAD

SC18P50V2JN-1-GP

12

C44

12

DY

1 2

R564

12

0R0402-PAD

R22

R22 10KR2F-2-GP

10KR2F-2-GP

ON NTMFS4841 Ultra SO-8 Id=57A, Qg=11.5~17nc Rdson=9.2~11.4mOhm

TPS51116_VBST TPS51116_PHS

+5VALW

DCBATOUT_51116

U11

SI7686DP-T1-GP

TPS51116_UGT

1 2

C29

SCD1U25V3KX-GP

U6

SI7636DP

TPS51116_LGT

ON NTMFS4841 Ultra SO-8

678

Id=57A, Qg=11.5~17nc

DDD

Rdson=9.2~11.4mOhm

SSGD

S

SSGD

S

123

4 5

567

8

DDD

D

SSS

G

SSS

G

123

4

1 2

C31 SC22U6D3V5MX-2GPC31 SC22U6D3V5MX-2GP

1 2

C39 SC10U6D3V5MX-3GP

DY

1 2

C30 S CD1U16V2ZY-2GPC30 SCD1U16V2ZY-2GP

1 2

C40 SC10U6D3V5MX-3GP

DY

12

DY

L10

1 2

+0.9VP

C21

C20

12

SCD1U50V3KX-GP

IND-1D5UH-34-GP

1 2

GAP-CLOSE-PWR

1 2

GAP-CLOSE-PWR

SC10U25V6KX-1GP

G24

G25

DY

DCBATOUT_51116

C22

12

SC10U25V6KX-1GP

C26

SCD1U16V2ZY-2GP

1 2

12

EC39

SCD1U25V3ZY-1GP

DY

+0.9VS

0.9VS Iomax=1A

G21

1 2

GAP-CLOSE-PWR

G22

1 2

GAP-CLOSE-PWR

G23

1 2

GAP-CLOSE-PWR

G20

1 2

GAP-CLOSE-PWR

+1.8V_RUN_P Iomax=12A OCP>18A

+1.8V_RUN_P

12

TC1

TC1 SE330U2D5VDM-LGP

SE330U2D5VDM-LGP

Sanyo 330uF 2.5V ESR=15mOhm

DCBATOUT

+1.8V_RUN_P

G18

1 2

GAP-CLOSE-PWR

G17

1 2

GAP-CLOSE-PWR

G16

1 2

GAP-CLOSE-PWR

G19

1 2

GAP-CLOSE-PWR

G14

1 2

GAP-CLOSE-PWR

G15

1 2

GAP-CLOSE-PWR

G64

1 2

GAP-CLOSE-PWR

G63

1 2

GAP-CLOSE-PWR

G65

1 2

GAP-CLOSE-PWR

G67

1 2

GAP-CLOSE-PWR

G66

1 2

GAP-CLOSE-PWR

G62

1 2

GAP-CLOSE-PWR

+1.8V

A A

5

http://laptop-motherboard-schematic.blogspot.com/

4

3

2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

TPS51116 1D8V/0D9V

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

38 41Thur sday, July 09, 2009

1

of

1

5

4

3

2

1

DCBATOUT DCBATOUT_SC412A_2

D D

+5VALW

12

R587

R587 0R0603-PAD

0R0603-PAD

C830

8209_VDDP 8209_1D8V_VFB

8209_VBST

VCCP_RUN_ON

12

DY

12

R423

R423 10R3F-GP

10R3F-GP

8209_V5FILT

12

1 2

R414

R414 249KR2F-GP

249KR2F-GP

8209_TON 8209_TRIP1

12

R408

R408 8K2R2F-1-GP

8K2R2F-1-GP

1 2

R492

R492 4D7R3F-L-GP

4D7R3F-L-GP

U45

4

VDD

10

VDDP

5

FB

14

BOOT

1

EN/DEM

2

TON

11

CS

RT8209BGQW-GP

UGATE

LGATE PHASE

VOUT

PGOOD

GND

PGND

NC#15

13 9

12 3

6 7 8 15

12

C812

SC1U10V2KX-1GP

C C

PM_SLP_S3#19,23,24,29,32,38,40

B B

+5VALW

D24

D24 CH551H-30PT-GP

CH551H-30PT-GP

DY

83.R5003.C8F

2 1

R415

R415 0R0402-PAD

0R0402-PAD

1 2

K A

D32

D32 1SS355PT-GP

1SS355PT-GP

SCD1U10V2KX-4GP

SC1U10V2KX-1GP

C363

1 2

GAP-CLOSE-PWR

1 2

GAP-CLOSE-PWR

1 2

GAP-CLOSE-PWR

8209_VBST_LL

8209_DRVH 8209_DRVL

8209_LL

G7

G8

G9

+3VS

12

C831

C831 SCD1U16V2KX-3GP

SCD1U16V2KX-3GP

+1.05V_VCCP_P

R209

R209 10KR2J-3-GP

10KR2J-3-GP

ALL_PWRGD 19,35,37,38

SI7686DP-T1-GP

ON NTMFS4841 Ultra SO-8 Id=57A, Qg=11.5~17nc Rdson=9.2~11.4mOhm

DCBATOUT_SC412A_2

U9

U8

SI7636DP

C11

SCD1U50V3KX-GP

678

DDD S

4 5

567

D

SSS

123

DDD S

DDD

SSGD

1 2

CYNTEC 0.82uH 7*7*3

123

DCR=13mOhm Idc=13A (68.R8210.10V)

L11

1 2

IND-D47UH-22-GP

R196

4K12R2F-GP

8209_1D8V_VFB

10K2R2F-GP

R196

R195

8

G

4

Close to IC RT8209

C10

12

C9

SC10U25V6KX-1GP

SC10U25V6KX-1GPC9SC10U25V6KX-1GP

12

+1.05V_VCCP Iomax=15A OCP>20A

+1.05V_VCCP_P

12

C347

SC33P50V2JN-3GP

12

C373

SCD1U10V2KX-4GP

DY

+1.05V_VCCP_P +1.05VS

12

EC36

SCD1U25V3ZY-1GP

TC13

SE330U2VDM-6-GP

77.C3371.13L NEC-TOKIN 330uF 2.5V 6mOhm Iripple=4.563A

G78

1 2

GAP-CLOSE-PWR

G77

1 2

GAP-CLOSE-PWR

G69

1 2

GAP-CLOSE-PWR

G75

1 2

GAP-CLOSE-PWR

G73

1 2

GAP-CLOSE-PWR

G70

1 2

GAP-CLOSE-PWR

G76

1 2

GAP-CLOSE-PWR

G74

1 2

GAP-CLOSE-PWR

G71

1 2

GAP-CLOSE-PWR

G72

1 2

GAP-CLOSE-PWR

A A

5

http://laptop-motherboard-schematic.blogspot.com/

4

3

2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221 , Taiwan, R.O.C.

Taipei Hsien 221 , Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

Taipei Hsien 221 , Taiwan, R.O.C.

RT8209 +1.05VS

HBU16 1.2

1

39 41Thur sday, July 09, 2009

of

1

5

+5VALW

D D

PM_SLP_S3#19,23,24,29,32,38,39

12

C169

C169 SC1U10V3ZY-6GP

SC1U10V3ZY-6GP

PM_SLP_S3# 5912_FB_1

4

+1.8V

12

R576

R576 0R0603-PAD

0R0603-PAD

VO#4

ADJ

GND

12

DY

C165

C165 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

4 3 2 1

12

DY

G972_VIN

C166

C166 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

U18

5

VIN

6

VPP POK7VO#3

8

VEN

9

GND

G972-120ADJF11U-GP

SO-8-P

Vo=0.8*(1+(R1/R2))

R79

69K8R2F-GP

SA 1010

12

R78

60K4R2F-GP

12

3

Vo(cal.)=1.5V

DY

12

TC9

C172

ST100U4VBM-L-GP

SC33P50V2JN-3GP

KEMET NTD:5.615 100uF, 4V, B2 Size Iripple=1.1A, ESR=70mohm

12

C175

C175 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

1 2

GAP-CLOSE-PWR

1 2

GAP-CLOSE-PWR

1 2

GAP-CLOSE-PWR

12

C176

C176 SC10U10V5ZY-1GP

SC10U10V5ZY-1GP

2

G109

G38

G37

OCP=6A

+1.5VS1D5V_LDO

Trace Length=3cm Trace Width=5mils Trace Resistance>80mohm

1

C C

B B

A A

5

1st: 74.00972.031(GMT) 2nd: 74.05912.A71(Anpac)

http://laptop-motherboard-schematic.blogspot.com/

4

3

2

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

Date: Sheet of

GMT_1D5V_LDO

Taipei Hsien 221, Taiwan, R.O.C.

HBU16 1.2

1

40 41Thur sday, July 09, 2009

of

1

A

4 4

H8

H12

H9

H13

H10

HOLE

HOLEH9HOLE

HOLE

1

3 3

H4

H1

HOLEH4HOLE

HOLEH1HOLE

1

H3

H2

HOLEH2HOLE

1

H16

HOLEH3HOLE

1

B

H14

H15

HOLE

HOLEH8HOLE

1

HOLE

1

HOLE

1

H18

HOLE

1

H6

HOLEH6HOLE

1

H21

H20

HOLE

1

C

H5

HOLEH5HOLE

1

H19

2

3

910

4

5

1 8

GEN8

6

7

H22

1

H24

HOLE

D

H25

H26

HOLE

1

HOLE

1

H28

H27

HOLE

1

H29

HOLE

1

E

H30

HOLE

1

SPR7

SPR6

SPRING-58-GP

SPR7

SPRING-U3

1

SPR1: 34.13B01.001, SPR3: 34.39S07.003, 34.39S07.101

SPR5

SPR4

SPRING-31-GP

SPR5

SPRING-6-GP

1

SPR3

SPR1

SPRING-6-GP

1

SPR3

SPRING-62-GP

1

SPR4: 34.49U24.001, SPR5: 34.13B01.001, SPR6: 34.4B312.002, 34.4B312.101

2 2

1 1

A

http://laptop-motherboard-schematic.blogspot.com/

B

SPR7: 34.40U07.001, 34.40U07.101

C

Wistron Corporation

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih,

21F, 88, Sec.1, Hsin Tai Wu Rd., Hsichih, Taipei Hsien 221, Taiwan, R.O.C.

Taipei Hsien 221, Taiwan, R.O.C.

Title

Size Document Number Rev

Size Document Number Rev A3

A3

A3 Date: Sheet

Date: Sheet

D

Date: Sheet

Taipei Hsien 221, Taiwan, R.O.C.

MISC

HBU16 1.2

41 41Tuesday, J une 30, 2009

E

1

of

HP G60-Intel Schematics

Specifications and Main Features

Frequently Asked Questions

User Manual
