HP G60-530, G60-530US Specifications

G60-530US Notebook PC

THE HP DIFFERENCE*

• Watch full-screen HD TV and movies with the 15.6” diagonal
display’s 16:9 aspect ratio.

(8)

• Enjoy your photos and videos on HD TVs with the HDMI port
(cable sold separately).

• Enter data quickly with the numeric keypad.

• Look good on the go with award-winning, high-gloss HP Imprint
finish.

• Get online more quickly with Window® 7 and high-speed wireless

(10b)

LAN.

• Create personalized, silkscreen-quality DVD and CD labels with
LightScribe.

• Chat face to face with the HP Webcam

(16a)

(15)

and mix it up with

YouCam’s fun special effects.

Windows®. Life without WallsTM.
HP recommends Windows 7.

TECH SPECS

• Intel® Pentium® Processor T4300 (Dual Core)

• Genuine Windows® 7 Home Premium 64-bit

• 15.6" Diagonal High Definition

• Intel Graphics Media Accelerator 4500M (shared) with up to 1309MB total available
graphics memory

• 3072MB DDR2 System Memory (2 Dimm)

• 320GB (5400RPM) Hard Drive (SATA)

• LightScribe SuperMulti 8X DVD±R/RW with Double Layer Support

• HP Webcam with integrated microphone

• Intel® WiFi Link 1000BGN

• 6-Cell Lithium-Ion battery

• 1-Year Free Hardware Technical Support

(6)

ELEMENTAL STYLE

The new HP G60 series is simply elegant. Its highly-polished reflective top cover and palm
rest area complement the matte finish everywhere else. The HP Imprint finish in piano
black on the top cover and in silver surrounding the keyboard provides greater durability
than traditional painted surfaces. HP's Design team has been recognized by distinguished
design institutions, including International CES, iF International Forum, ID Magazine, Good
Design and Red Dot International.

SIMPLY ENTERTAINING

The HP G60 series delivers easy-to-use entertainment. Enjoy full-screen HD TV and movie
playback on the crystal-clear 16:9 15.6" diagonal HP Brightview display.
PC content on your HD TV by connecting it through the HDMI port (cable sold separately).
Burn audio CDs and DVDs to share your favorite songs and video clips with friends and
family. Built-in Altec Lansing speakers bring your entertainment to life. And the 5:1 digital
media reader enables photo transfer in seconds for easy upload to Snapfish or printing on
your HP Photosmart printer.

RELAX WITH 24/7 SUPPORT. FOR LIFE.

HP Care Pack Support provides toll-free phone support while your PC is within Warranty
plus online support anytime throughout its life. There are three ways to reach us.

• From your desktop: HP Support Assistant includes preinstalled content and diagnostic
tools - just click the “HP Support Assistant” icon on the desktop and follow the prompts.

• Through the Internet: Visit www.hp.com/go/notebookcare in the United States.

• By telephone: In the U.S., just call 1.800.474.6836 (1.800.HP.INVENT).

Business Week ranked HP the number one technology company for customer service (April

2009). HP is the worldwide leader in PC sales (IDC WW PC Tracker, May 2009).

(8)

HP BrightView Display (1366x768)

(7)

(10b)

(2c)(3)(4b)
(1)

(6d)(16a)(16d)

(8)

Or view your

For those who want to connect and manage everyday computing tasks with an elegantly
minimalist notebook, the HP G60 series Notebook PC delivers balanced mainstream
performance at a great value. Powered by Intel processor and graphics technologies, the
G60 includes essential features to enhance your PC experience and life.

• Your PC, simplified. Windows 7 is the easiest, fastest, most secure and energy-efficient
version of Windows yet. Better ways to find and manage files, like Jump Lists and
improved taskbar previews, help you speed through everyday tasks. And great features
like HomeGroup make sharing files on home networks easier, while Snap lets you
quickly resize and compare windows on your desktop. Faster and more reliable
performance means your PC just works the way you want it to.

• Store more media. The 320GB hard drive has room for up to 51,000 photos
or 64,000 songs
recorded video “best” mode
where you do.

• Stay connected with the HP Webcam. Turn your next instant message into a live video
chat with the integrated webcam, omni directional microphone and an IM solution.
Optimized for low-light environments, it's great for capturing short videos to share on
your favorite social networking site. Personalize your videos with included YouCam
software from Cyberberlink.

• Personalized disc labels with LightScribe. Create custom laser-etched disc labels right in
the drive with LightScribe and preinstalled Cyberlink DVD Suite. Just burn data on the
disc, flip it over and burn the cover image using any scanned image and/or text. Visit
the LightScribe Web site for more information.

• Photo-ready with 5-in-1 media card reader. Transfer photos from your digital camera
in seconds and conveniently upload to Snapfish for editing, sharing, printing and use in
calendars, cards, flipbooks and more.

(30)

or 183 hours of recorded video in “fair” mode

(31)

so your entertainment and critical information goes

(15)

(16a)

(31)

or 72 hours of

(29)

IDEAL FOR:

• Going online (Web surfing, social networking, email, shopping, video streaming)

• Running multiple applications at the same time (dual-core CPU)

• Video chat and instant messaging

• Viewing and editing photos

• Listening to music, converting CDs to MP3s and burning discs

• Watching DVD movies

G60-530US Notebook PC

As a leader in environmental responsibility, HP is committed to reducing our impact on
the earth. Renew, recycle, rethink with HP.

• ENERGY STAR® qualified and EPEAT® Silver registered

• Advanced power management features and aggressive default power settings for
reduced energy consumption

• Exclusive use of EPA SmartWay carriers for fewer transportation-related emissions

• Recyclable packaging designed for minimal material usage

• Free recycling for your old computer hardware

Please recycle your computing hardware and printing supplies.
Find out how at our website.

DESIGNED FOR IDEAL VALUE

*All disclaimers are listed on second page.

G60-530US Notebook PC

Windows®. Life without WallsTM.
HP recommends Windows 7.

SPECIFICATIONS

OPERATING SYSTEM • Genuine Windows® 7 Home Premium 64-bit
PROCESSOR • Intel® Pentium® Processor T4300 (Dual Core)
PROCESSOR SPEED • 2.10 GHz

(4)

PROCESSOR CACHE • 1MB L2 Cache
BUS SPEED • 800MHz FSB

(4a)

MEMORY • 3072MB DDR2 System Memory (2 Dimm)

• Max supported =4096MB

ACCESSIBLE

• 2

MEMORY SLOTS
VIDEO GRAPHICS • Intel Graphics Media Accelerator 4500M (shared) with up to

1309MB total available graphics memory

HARD DRIVE • 320GB (5400RPM) Hard Drive (SATA)
FINISH AND

• HP Imprint finish & HP Webcam with integrated microphone

FEATURES
MULTIMEDIA DRIVE • LightScribe SuperMulti 8X DVD±R/RW with Double Layer

DISPLAY • 15.6" Diagonal High Definition

Support

(6d)(16a)(16d)

(8)

HP BrightView Display

(1366x768)

NETWORK CARD • Integrated 10/100BASE-T Ethernet LAN (RJ-45 connector)
WIRELESS OPTION • Intel® WiFi Link 1000BGN

(10b)

DIGITAL MEDIA • 5-in-1 integrated Digital Media Reader for Secure Digital cards,

MultiMedia cards, Memory Stick, Memory Stick Pro, or xD Picture

(17a)

cards

FAX/MODEM • High speed 56k modem

(11)

AUDIO • Altec Lansing
KEYBOARD • 101-key compatible with full size keyboard with integrated numeric

keypad

POINTING DEVICE • Touch Pad with On/Off button and dedicated vertical scroll

Up/Down pad

EXTERNAL
NOTEBOOK PORTS

• 3 Universal Serial Bus (USB) 2.0

• 1 Headphone out

• 1 microphone-in

• 1 HDMI

• 1 VGA (15-pin)

• 1 RJ-11 (modem)

• 1 RJ -45 (LAN)

DIMENSIONS • Unpackaged: 14.88" (L) x 9.9" (D) x 1.38" (min H)/1.72" (max H)

• Packaged: 20.5"(W) x 4.2"(D) x13.6"(H)

WEIGHT • Unpackaged: 6.57 lbs

(12)

• Packaged: 9.2 lbs

SECURITY • Kensington® MicroSaver lock slot

• Power-on password

• Accepts 3rd party security lock devices

POWER • 6-Cell Lithium-Ion battery

• 65W AC Adapter

(1)

(2c)(3)(4b)

(6)

(7)

(15)

(9)

OPTIONAL
ACCESSORIES

• HP Notebook 90W Smart AC Adapter with Dongle ­KG298AA#ABA

• HP Notebook 8-Cell Battery - KS525AA

• HP Wireless Optical Mobile Mouse US - KU916AA#ABA

WARRANTY AND
SUPPORT

• 1-Year Limited Hardware Warranty with Toll Free Support (NA)

• 1-Year Free Hardware Technical Support

• 30-Days Free Limited Software Support with 1-Year (from date of
purchase) Free Limited Software Support with Product Registration.

SOFTWARE

SECURITY AND
SUPPORT

PRODUCTIVITY AND
FINANCE

MULTIMEDIA • HP DVD Play

INTERNET
SOLUTIONS

• Symantec® Norton Internet Security™ 2009 (including 60 days
complimentary live update)

• HP Help & Support

• HP PC Recovery

• HP Advisor

• Microsoft® Works

• Microsoft® Office 2007 Home and Student Edition: 60 Day Trial

(19)

Version

• Cyberlink DVD Suite

• Adobe® Acrobat Reader

• HP Games Powered by Wild Tangent

• HP Set Up

(15)

• Microsoft® Internet Explorer

ADDITIONAL INFORMATION

PRODUCT NUMBER • VM084UA#ABA
AD EMBARGO DATE • 10/18/2009
SALES AND

FULFILLMENT
EMBARGO

UPC CODE • 884962533970
COUNTRY OF

ORIGIN
TARIFF NUMBER • 8471300000
PALLET

INFORMATION

• 10/22/2009

• CHINA

• Dimensions: 47.2" (L) x 39.4" (W) x 46."(H) approx.

• Total weight: 558.4 lbs

• Layers: 3

• Products per layer: 19

(15)(19b)

VISIT WWW.HP.COM FOR MORE DETAILS!

(1)

This system may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See http://www.microsoft.com/windows/windows-7/ for details.

(2c)

64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors will not operate (including 32-bit operation) without an Intel 64
architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. See www.intel.com/info/em64t for more information. Dual Core is designed to improve performance of certain software products. Check with the software
provider to determine suitability. Not all customers or software applications will necessarily benefit from use of this technology.
speed may impact system and application performance.
advantage of the 64-bit processing capabilities of AMD technology. Dual/quad/triple-core processing available with AMD technology is designed to improve performance of this system. Given the wide range of software applications available, performance of a system
including a 64-bit operating system and a dual-core processor will vary.
this disclaimer affects system memory and graphics.
system recovery software.
achievable download speeds are currently unknown, may not reach 56Kbps and will vary with line conditions. Upload speeds are less and also will vary.
Don’t copy copyright-protected materials. Double Layer is a new technology. Double Layer media compatibility will widely vary with some home DVD players and DVD-ROM drives.

(17a)

separately.
purchased adapter.

(29)

Capacity based on average compressed .jpg size of 5MB per image.
Actual product may vary from image shown on datasheet. ©2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty
statements accompanying such products and services. Nothing shall be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. 09/14_r3 rk Product Number: VM084UA#ABA

(8)

High-Definition content is required to view high-definition images.

Digital Media Slot supports MS, MSP, MMC, SD, XD formats. To avoid damaging the card or computer do not insert any type of adapter, or mini format memory card, into the Digital Media Slot. Mini/Reduced flash memory cards require separately

(19)

The Microsoft® Office Student and Teacher Edition 2008 is a trial version; functionality is reduced after 60 days. The full version is sold separately.

(4a)

Actual bus speed is less. Listed bus speed represents the equivalent effective throughput for data.

(6)

(6d)

Note that DVD-RAM cannot read or write to 2.6GB Single Sided/5.2 GB Double Sided – Version 1.0 media

Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video performance is not available for other use by other programs. Note:

(9)

Actual speeds may vary.

(30)

Capacity based on 4 minutes per song and 128 Kbps AAC encoding.

(3)

Intel's numbering is not a measurement of higher performance.

(10b)

Wireless access point and Internet service required and is not included. Availability of public wireless access points limited.

(4b)

This system requires a separately purchased 64-bit operating system and 64-bit software products to take

(7)

1 GB = 1 billion bytes. Actual formatted capacity is less. Up to 20GB of system disk is reserved for

(12)

Weight will vary by configuration.

(19b)

(31)

Capacity based on standard NTSC recording format. Actual recording times may vary.

Internet access required. First 60 days included. Subscription required for live updates afterwards.

(4)

GHz refers to internal clock speed of the processor. Other factors besides clock

(15)

Internet access required and sold separately.

(16d)

LightScribe creates a monochrome image. LightScribe media required and sold

(11)

Maximum

(16a)

Actual speeds may vary.
