QuickSpecs
Overview
HP Compaq dx7500 Business PC
HP recommends
Windows Vista® Business
Microtower
1.
(2) external 5.25” drive bays for optional optical drives; (2)
internal 3.5” hard drive drive bays
2.
300 watt PFC and non-PFC power supply
3.
(1) external 3.5” drive bay for optional media reader or
diskette drive
4.
Rear I/O: (4) USB 2.0 ports, (2) PS/2, (1) RJ-45, (1)
1394, (1) VGA, (1) DVI, (1) SPDIF in – (1) SPDIF out, (1)
audio in – (1) audio out – (1) MIC
Small Form Factor
5.
Front I/O: (3) USB 2.0 ports, (1MIC – (1) audio out
(Headphone), (1) 1394
6.
(3) PCIe x1 slots, (1) PCIe x16 slot
7.
PS/2 Scroll Mouse
8.
HP Standard Keyboard
9.
Monitor (sold separately)
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 1
QuickSpecs
Overview
HP Compaq dx7500 Business PC
1.
Monitor (sold separately)
2.
Rear I/O: (4) USB 2.0 ports, (2) PS/2, (1) RJ-45, (1) 1394,
(1) VGA, (1) DVI, (1) SPDIF in – (1) SPDIF out, (1) audio
in – (1) audio out – (1) MIC
3.
250 watt PFC power supply
4.
(1) external 5.25” drive bay for optional optical drives; (1)
internal 3.5” drive bay
5.
Front I/O: (2) USB 2.0 ports, (1) audio in – (1) audio out
6.
PS/2 Scroll Mouse
7.
HP Standard Keyboard
8.
(1) external 3.5” drive bay for optional media reader or
diskette drive
9.
(3) PCIe x1 slots, (1) PCIe x16 slot
At A Glance
Support for Intel® Core™ 2 Duo and Core™ 2 Quad processors, Intel Pentium® dual-core processors, Intel
Celeron® processors
Choice of operating systems:
Genuine Windows Vista Business 32
Genuine Windows Vista Business 64
Genuine Windows Vista Home Basic
Genuine Windows Vista Ultimate 32 (English only)
Genuine Windows Vista Business with downgrade to Windows XP Professional custom installed
FreeDOS (not available in China)
Intel G45 Express Chipset
Integrated dual monitor support with VGA and DVI-D connectors
Integrated 1394 port
Intel I/O Controller Hub 10 (ICH10R)
Intel Graphics Media Accelerator X4500HD with DX10 support
PCI Express I/O bus
Serial ATA controller
Intel Integrated WG82567V Gigabit Network Connection
Choice of hard drives and optical drives
Can be configured with multiple hard drives in a RAID array
DDR2 SDRAM system memory
Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 2
QuickSpecs
Standard Features and Configurable Components
HP Compaq dx7500 Business PC
Processor and Speed
One of the following
Intel Celeron Processors:
Intel Celeron 430 Processor (1.8-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron 440 Processor (2.0-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron 450 Processor (2.2-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron Dual-Core Processors
Intel Celeron E1200 Processor (1.6-GHz, 512K L2 cache, 800-MHz FSB)
Intel Celeron E1400 Processor (2.0-GHz, 512K L2 cache, 800-MHz FSB)
Intel Celeron E1500 Processor (2.2-GHz, 512K L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core Processors:
Intel Pentium E2200 Processor (2.2-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium E2220 Processor (2.4-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium E5200 Processor (2.5-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium E5300 Processor (2.6-GHz, 2MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo Processors:
Intel Core 2 Duo E7300 Processor (2.66-GHz, 3 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E7400 Processor (2.8-GHz, 3 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E8400 Processor (3.0-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8500 Processor (3.16-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8600 Processor (3.33-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Processors:
Intel Core 2 Quad Q6600 Processor (2.4-GHz, 8 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Quad Q8200 Processor (2.33-GHz, 4 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q8300 Processor (2.50-GHz, 4 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9400 Processor (2.66-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9550 Processor (2.83-GHz, 12 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9650 Processor (3.0-GHz, 12 MB L2 cache, 1333-MHz FSB)
NOTE:
differentiate features within each processor family, not across different processor families.
Intel processor numbers are not a measure of performance. Processor numbers
Operating Systems
and Application
Software
(availability varies by
region)
Genuine Windows Vista Business 32
Genuine Windows Vista Business 64
Genuine Windows Vista Home Basic
Genuine Windows Vista Ultimate 32* (English only)
Genuine Windows Vista Business downgrade to Windows XP Professional custom installed
Free DOS (not available in China)
* Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/getready/capable.mspx
Upgrade Advisor can help you determine which features of Windows Vista will run on your
computer. To download the tool, visit:
† Windows Vista Business disk may be included for future upgrade if desired. To qualify for this
downgrade an end user must be a business (including governmental or educational institutions)
and is expected to order annually at least 25 customer systems with the same custom image.
Microsoft Office 2007 Basic
Microsoft Office 2007 Small Business
Microsoft Office 2007 Professional
HP Backup and Recovery Manager
Intel Matrix Storage Manager
*
*
*
and
for details. Windows Vista
http://www.windowsvista.com/upgradeadvisor
*†
.
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 3
QuickSpecs
Standard Features and Configurable Components
Mozilla Firefox for HP Virtual Solutions
Roxio Easy Media Creator 10
Intervideo WinDVD 8
McAfee Total Protection Anti-Virus
PDF Complete
AOL Toolbar
** Supporting software available with certain optical drive configurations
*** 60 day trial period for McAfee Total Protection for Small Business software. Internet access
required to receive updates. First update included. Subscription required for updates thereafter.
**
**
***
HP Compaq dx7500 Business PC
Hard Drives (SATA)
System Memory
80 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
160 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
250 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
320 GB Hard Drive
8MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
500 GB Hard Drive
16MB cache, 7,200 RPM, 3.0 GB/s, NCQ, Smart IV
250-GB Pocket Media Drive
512-MB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 512MB)
1-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 1GB)
2-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 1GB)
3-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (3 x 1GB)
4-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (4 x 1GB)
4-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 4GB)
4-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 2GB)
8-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (4 x 2GB)
8-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 4GB)
16-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (4 x 4GB)
NOTE:
all memory may not be available due to system resource requirements. Addressing memory
above 4 GB requires a 64-bit operating system.
For systems configured with more than 3 GB of memory and a 32-bit operating system,
Storage
One or more of the
following (see Storage
section below)
–
Diskette Drive
1.44-MB Diskette Drive
Media Reader
HP 22-in-1 Media Reader and additional USB 2.0 port
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
SATA SuperMulti LightScribe DVD Writer Drive
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 4
QuickSpecs
Standard Features and Configurable Components
HP Compaq dx7500 Business PC
Input Devices
Audio
Communication
Graphics
Keyboard – One of the following
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
Mouse – One of the following
PS/2 2-Button Optical Scroll Mouse
USB 2-Button Optical Scroll Mouse
USB 2-Button Laser Mouse
Realtek ALC888S High Definition audio codec
3D audio compliant with AC'97 Rev. 2.3 and HD Audio compatible
Internal PC speaker
Integrated Intel WG82567V Gigabit Network Connection
Intel Gigabit CT Desktop NIC
LSI PCIe x1 56K International SoftModem
HP Wireless 802.11 b/g/n PCIe x1 Card (full height)
Intel Graphics Media Accelerator X4500HD
ATI Radeon HD 2400XT 256MB Dual Head graphics adapter (PCIe x16)
ATI Radeon HD 3470 256MB Single Head graphics adapter (PCIe x16)
ATI Radeon HD 3650 512MB Dual Head graphics adapter (PCIe x16) (MT only)
DisplayPort to DVI-D adapter (for use with ATI Radeon HD 3470 and 3650)
Miscellaneous
Belkin USB to serial adapter
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 5
QuickSpecs
System Details
HP Compaq dx7500 Business PC
Base Unit
Slots
MT: Micro ATX Microtower chassis, including power supply and front bezel; five (5) drive
bays and four expansion slots
SFF: Micro ATX Small Form Factor chassis, including power supply and front bezel; three
(3) drive bays and four expansion slots
Active type heatsink
92 x 92 x 25 mm chassis fan for Microtower chassis
No chassis fan for Small Form Factor chassis
System board with Intel G45 Express chipset, Intel I/O Controller Hub 10R (ICH10R), Intel
WG82567V Ethernet controller, Intel GMA X4500HD graphics, and Realtek audio, (3) PCI
Express x1 slots, (1) PCI Express x16 slot, (4) DDR2 DIMM memory slots, (4) Serial ATA
data connectors, (10) USB Ports (see USB support below), 1394 Firewire, SPDIF coaxial
In/Out
Power cord
PCI
Memory Expansion
NOTE:
all memory may not be available due to system resource requirements. Addressing memory
above 4 GB requires a 64-bit operating system.
For systems configured with more than 3 GB of memory and a 32-bit operating system,
PCI Express x1 slots
MT: (3) full-height (4.34”), length (6.6”), Max power per slot 10W
SFF: (3) low-profile (2.73”), length (6.6”), Max power per slot 10W
PCI Express x16 slot (for graphic cards)
MT: (1) full-height (4.34”), length (9.5”), Max power per slot 75W
SFF: (1) low-profile (2.73”), length (6.6”), Max power per slot 25W
Four (4) DDR2 SDRAM DIMM slots (16 GB maximum memory support)
Bays
USB Support
Other Ports
Internal
External
EHCI high-speed USB 2.0 controller
MT: Three (3) front ports; four (4) rear ports, three (3) internal ports on system board
SFF: Two (2) front ports; four (4) rear ports, four (4) internal ports on system board
Front
:
MT: (1) audio out; (1) microphone in, (1) 1394 port
SFF: (1) audio out; (1) microphone in
Rear
:
(2) PS/2 ports (keyboard and mouse)
(1) analog VGA video port
(1) DVI port
(1) SPDIF coaxial input
(1) SPDIF coaxial output
(1) audio in, (1) audio out; (1) microphone in
(1) RJ-45 network port
(1) 1394 port
MT: Two (2) 3.5-inch
SFF: One (1) 3.5-inch
MT: Two (2) 5.25-inch; One (1) 3.5-inch
SFF: One (1) 5.25-inch; One (1) 3.5-inch
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 6
QuickSpecs
System Details
HP Compaq dx7500 Business PC
Weight & Dimensions
(MT)
Weight & Dimensions
(SFF)
Technology and
Features
Chassis Dimensions
(H x W x D)
Packaged Dimensions
(L x W x H)
System Weight
Shipping Weight
Chassis Dimensions
(H x W x D)
Packaged Dimensions
(L x W x H)
System Weight
Shipping Weight
Memory Type
NOTE:
all memory may not be available due to system resource requirements. Addressing memory
above 4 GB requires a 64-bit operating system.
Hard Drive Interfaces
Supported
For systems configured with more than 3 GB of memory and a 32-bit operating system,
15.14 x 7.27 x 16.36 in
385 x 185 x 416 mm
19.13 x 21.875 x 10.13 in
490 x 556 x 257 mm
22.4 lb (10.2 kg)
30.8 lb (14.0 kg)
3.98 x 13.35 x 15.24 in
101 x 339 x 387 mm
23.38 x 19.68 x 9.0 in
593.8 x 500.0 x 228.6 mm
14.96 lb (6.79 kg)
23.00 lb (10.43 kg)
PC2-6400 DDR2 SDRAM (800MHz) non-ECC
Up to 16 GB system memory standard
Serial ATA
RAID
SMART Technology
(Self-Monitoring,
Analysis and Reporting
Technology)
* This feature is inoperable when a RAID configuration is enabled.
Redundant Array of Independent Drives
RAID 0,1 are the RAID configurations that HP Compaq dx7500 Business PC products offer as
factory configurations. The pre-configured systems:
Are only available on the MT form factor. The SFF does not support RAID, as it does not
allow for more than one hard disk drive.
Are complete RAID systems and have both drives installed.
Have the necessary Option ROM configuration.
Are pre-loaded and pre-installed with all required Intel software.
Include a preinstalled operating system that is in mirrored mode out of the box.
*
Allows hard drives to monitor their own health and to raise flags if imminent failures were
predicted
Predicts failures before they occur. Tracks fault prediction and failure indication parameters
such as re-allocated sector count, spin retry count, calibration retry count
By avoiding actual hard drive failures, SMART hard drives act as "insurance" against
unplanned user downtime and potential data loss from hard drive failure
IOEDC: I/O Error Detection Circuitry
Detects errors in Read/Write buffers on HDD cache RAM
Interface in F10 setup provides confirmation of SMART support.
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 7
QuickSpecs
System Details
HP Compaq dx7500 Business PC
Chassis
Front Panel
Cooling Solutions
Supported
Slots Supported
Front I/O
Rear I/O
Drive Bays (MT)
Drive Bays (SFF)
Internal Speaker
Security
Power Supply
Power button
Power On LED
HDD Activity LED
Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan (variable speed) (MT only)
(3) PCI Express x1 slots, (1) PCI Express x16 slot
MT: Three (3) USB 2.0 ports, 1394, Headphone, Mic
SFF: Two (2) USB 2.0 ports, Headphone, Mic
Standard Micro ATX I/O connectors, including four (4) USB 2.0 ports
Two (2) 5.25-inch (13.335 cm) half height external
One (1) 3.5-inch (8.89 cm) half height external
Two (2) 3.5-inch (8.89 cm) half height internal
One (1) 5.25-inch (13.335 cm) half height external
One (1) 3.5-inch (8.89 cm) half height external
One (1) 3.5-inch (8.89 cm) half height internal
Standard
Padlock loop
Kensington Lock Support
Optional USB Port Disable at factory (user configurable via BIOS)
MT: 300-watt ATX Power Supply – PFC/non-PFC with a 115v/230v line
switch (varies by country/region)
SFF: 250-watt Power Supply – PFC with a 115/230v line switch.
Unit Environment and
Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of
heat and cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required
airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that
they are subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the
computer. Lint, dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust
ventilation must be provided on the enclosure, and the same operating guidelines listed
above will still apply.
Temperature Range
(MT)
Relative Humidity (MT)
Maximum Altitude (MT)
(unpressurized)
Temperature Range
(SFF)
Relative Humidity
(SFF)
Maximum Altitude
(SFF)
(unpressurized)
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
41° to 95° F (5° to 35° C)
–22° to 140° F (–30° to 60° C)
15% to 80% (non-condensing at ambient)
90% (non-condensing at ambient)
7500 ft (2286 m)
15,000 ft (4572 m)
50° to 95° F (10° to 35° C)
–22° to 140° F (–30° to 60° C)
10% to 90% (non-condensing at ambient)
5% to 95% (non-condensing at ambient)
10,000 ft (3048 m)
30,000 ft (9000 m)
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 8
QuickSpecs
System Details
HP Compaq dx7500 Business PC
System Board
NOTE:
MT and 10000 ft (3000m) for SFF above sea level, no direct sustained sunlight. Maximum rate of
change is 7.5 deg C/Hr for MT and 10 deg C/Hr for SFF. The upper limit may be limited by the
type and number of options installed.
Processor
PWM
Chipset
Super I/O
Front Side Bus
Frequency
Memory
Clock Generator
Integrated Graphics
Audio
LOM
Storage
Expansion Slots
BIOS
Industrial Standard
Rear Side I/O Ports
On Board I/O
Interfaces
Board Size
Additional Features
Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 7500 ft (2286 m) for
Socket T; LGA775 industry standard Micro ATX form factor
Support single Intel Core 2 Duo and Core 2 Quad, Pentium dual-core,
or Celeron processors
ON – NCP5362 – 3 phase
Intel G45 Express
Intel I/O Controller Hub 10 (ICH10R)
Fintek F8000
800/1066/1333 MHz
DDR2 SDRAM
4 x DIMM slots
SLG8XP549T
Intel Graphics Media Accelerator (GMA) X4500HD
Realtek ALC888S HD Audio compatible codec with two channel audio
3D audio compliant with AC'97 rev. 2.3
Intel WG82567V PHY, Integrated MAC in ICH10R
Four Serial ATA interfaces
3 x PCI Express x1 slots
1 x PCI Express x16 slot
SPI FLASH ROM
PCIe compliant
USB 2.0
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
1 x RJ-45 10/100 port
1 x DVI-D port
1 x 1394 port
1 x SPDIF coaxial input port; 1 SPDIF coaxial output port
1 x DB 15-pin analog VGA port
3 x audio ports
1 x ATX power connector
1 x +12V power connector
1 x Floppy connector
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
2 x header (1 -2x5, 1-1x5) to support 3 USB 2.0 ports at front side
1 x header (1 - 2x5) to support USB Card Media Reader
1 x header (1 -1x5) to support an additional USB device
1 x header to support 2 front (Headphone/Mic) audio ports
Micro-ATX, PCB Size: 9.6 x 9.0 in (24.38 x 22.86 cm)
4-layer PCB with green color
Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 9
QuickSpecs
System Details
HP Compaq dx7500 Business PC
Support S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
Network Interface
Wireless
Power Supply
Power Conservation
‘Energy Saver‘
Integrated Intel WG82567LM Gigabit Network Connection
Intel Gigabit CT Desktop NIC (optional)
MT: Wireless 802.11b/g/n PCIe Card (full height bracket)
SFF: Wireless 802.11b/g/n PCIe Card (half height bracket)
MT: ATX Power Supply – Passive PFC
SFF: Custom Power Supply – Passive PFC
Passive Power Factor Correction (PFC/NPFC) – with line switch set to 230V – No PFC in
115V line switch position
90 to 140VAC, or 180 to 264VAC operating voltage range
100 to 127VAC, or 200 to 240VAC rated voltage range
50-60 Hz rated line frequency
47-63 Hz operating line frequency range
MT: 300 watt maximum rated power
SFF: 250 watt maximum rated power
80-mm power supply fan – variable speed for optimum acoustics
APM 1.2 support
Screen blanking
Hard drive 'Idle' mode
System Idle mode
~2 watt power consumption in ES mode - suspend to RAM (S3) (instantly available PC)
Processor/Cache memory power-down (S3)
System Environmental
Specs
Values are subject to change without notification and are for reference only.
Performance of system, options, and ancillary equipment will vary depending on the
system configuration.
Levels presented do not account for non-HP/Compaq installed hardware.
Ambient Air
Temperature
Humidity
Operating
Storage
Operating
MT: Operating 41° to 95°F (5 to 35°C) (Test 0
to 104°F (40°C));
SFF: 50° to 95°F (10° to 35°C) at sea level
with an altitude de-rating of 1.0°C per every
1000 ft (300 m) above sea level to a
maximum of 10000 ft (3000 m), no direct
sustained sunlight. Maximum rate of change
is 77°F/Hr (25°C/Hr). The upper limit may be
limited by the type and number of options
installed.
MT: Storage: 90% RH @ 60°C for 12 hours
(Non-condensing)
SFF: –22° to 140°F (–30° to 60°C) –
Maximum rate of change: 410°F/Hr
(210°C/Hr).
MT: 15% to 80% relative humidity (Rh), 35°C
non-condensing
SFF: 10% to 90% relative humidity (Rh), 86°F
(30°C) maximum wet bulb temperature, non-
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 10
QuickSpecs
System Details
Altitude
Shock
Vibration
Acoustic Noise
HP Compaq dx7500 Business PC
condensing
Storage
Operating
Non-Operating
Listed are the levels of shock the product can withstand with No
damage being incurred. The values represent peak input acceleration
during an 2~3 ms half-sine shock pulse, 11 ms trapezoidal shock
pulse.
Non-Operating
Listed are the levels of vibration the product can withstand with No
damage being incurred. The values represent a flat random vibration
input acceleration profile across the given frequency range.
Operating
Non-Operating
Listed are the declared A-WEIGHTED SOUND POWER LEVELS
(LWAd) and declared average desktop seated operator position AWEIGHTED SOUND PRESSURE LEVELS (LpAm) when the product is
operating in a 73.4°F (23°C) ambient environment. Noise emissions
were measured in accordance with ISO 7779 (ECMA 74) and declared
in accordance with ISO 9296 (ECMA 109).
MT
: IDLE (Fixed disk
drive spinning)
SFF
: IDLE (Fixed disk
drive spinning)
MT: 90% relative humidity (Rh), 60°C for
12 hours, non-condensing
SFF: 0 to 10,000 feet (0 to 3048 meters) This value may be limited by the type and
number of options installed. Maximum
allowable altitude change rate is 1,000 ft/min
(304.8 m/min).
MT: 0 to 7,500 feet (0 to 2286 meters) – This
value may be limited by the type and number
of options installed.
SFF: 0 to 10,000 feet (0 to 3048 meters) –
This value may be limited by the type and
number of options installed. Maximum
allowable altitude change rate is 1,000 ft/min
(304.8 m/min).
MT: 0 to 15,,000 feet (0 to 4572 meters)
SFF: 0 to 30,000 feet (0 to 9,144 meters) –
Maximum allowable altitude change rate is
1200 ft/min (365.76 m/min).
MT:
35G's (Half-sine Shock)
35G's (Trapezoidal Shock)
SFF:
35G's (Half-sine Shock)
40G's (Trapezoidal Shock)
MT: Random Operating: ~0.21Grms (5-500
Hz) Swept Sine: 0.5g (5-500Hz) 5 min. dwell
at 4 resonance's 5Hz to 300Hz, (0.25G's
nominal).
SFF: Random vibration at
5Hz@0.00025G2/Hz, 10Hz@0.01G2/Hz,
100Hz@0.01G2/Hz, 300Hz@0.00001G2/Hz
5Hz to 300Hz, (0.25G's nominal).
MT: ~2.09Grms (5-500Hz), Non-Operational
SFF: Random vibration at 0.008G²/Hz,
10Hz to 500Hz, (2 Grms nominal).
LWAd = 3.7 Bels,
Desktop Average LpAm = 25 dBA
LWAd = 4.3 Bels,
Desktop Average LpAm = 32 dBA
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 11
QuickSpecs
System Details
MT
: FIXED DISK
(Random write)
SFF
: FIXED DISK
(Random write)
MT
: CD-ROM
(Sequential Reads)
SFF
: CD-ROM
(Sequential Reads)
HP Compaq dx7500 Business PC
LWAd = 4.0 Bels,
Desktop Average LpAm = 30 dBA
LWAd = 4.8 Bels,
Desktop Average LpAm = 37dBA
LWAd = 5.2 Bels,
Deskside Average LpAm = 42 dBA
LWAd = 5.2 Bels,
Deskside Average LpAm = 41dBA
Service and Support
On-site Warranty1: One-year (1-1-1) limited warranty delivers one year of on-site, next businessday2 service for parts and labor and includes free telephone support3 24 x 7. Global coverage
ensures that any product purchased in one country and transferred to another non-restricted
country will remain fully covered under the original warranty and service offering. One-year onsite
and labor are not available in all countries.
1
Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other
warranty variations may be offered in your region.
2
On-site service may be provided pursuant to a service contract between HP and an authorized
HP third-party provider, and is not available in certain countries. Global service response times
are based on commercially reasonable best effort and may vary by country.
3
Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified
hardware and software. Toll-free calling and 24 x 7 support may not be available in some
countries.
2
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 12
QuickSpecs
After-Market Options
HP Compaq dx7500 Business PC
Communications
Hard Disk Drives
Removable Storage
Devices
Input Devices
NICs
I Intel Gigabit CT Desktop NIC (GbE PCIe x1 NIC)
Wireless LAN
HP Wireless 802.11/b/g/n PCIe x1
Modems
LSI PCIe x1 56K International SoftModem
HP 500-GB SATA 3.0-Gb/s Hard Drive
HP 320-GB SATA 3.0-Gb/s Hard Drive
HP 250-GB SATA 3.0-Gb/s Hard Drive
HP 160-GB SATA 3.0-Gb/s Hard Drive
HP 80-GB SATA 3.0-Gb/s Hard Drive
Diskette Drive
HP 1.44-MB Internal Diskette Drive
HP 1.44-MB USB Diskette Drive – External
22-in-1 Media Reader
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
HP 2.4 GHz Wireless Keyboard and Mouse
HP PS/2 2-Button Optical Scroll Mouse
HP USB 2-Button Optical Scroll Mouse
HP USB 2-Button Laser Mouse
FH969AA
FH971AA
FH970AA
PV943A
FH963AA
PY278AA
PY277AA
PY276AA
AG295AA
DC141B
FX273AA
DT527A
DT528A
NB896AA#xxx
EY703AA
DC172B
GW405AA
Memory
Audio
Graphics
Optical Drives
HP 1-GB PC2-6400 (DDR2 800-MHz) DIMM
HP 512-MB PC2-6400 (DDR2 800-MHz) DIMM
HP 2-GB PC2-6400 (DDR2 800-MHz) DIMM
HP 4-GB PC2-6400 (DDR2 800-MHz) DIMM
HP Satellite Speakers
ATI Radeon HD 2400 XT 256MB DH PCIe x16 Graphics Card
ATI Radeon HD 3470 256MB SH PCIe x16 Graphics Card
ATI Radeon HD 3650 512MB DH PCIe x16 Graphics Card (MT Only)
HP DisplayPort To DVI-D Adapter
* 1GB of system memory required. Graphics cards use part of the total system
memory to enhance graphics performance.
HP SATA DVD-ROM Drive
HP SATA SuperMulti LightScribe DVD Writer Drive
AH058AA
AH056AA
AH060AA
FH977AA
ZD929AA
KD060AA
FH972AA
KS505AA
FH973AA
AH047AA
GF343AA
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 13
QuickSpecs
After-Market Options
HP Compaq dx7500 Business PC
Security
Miscellaneous
Accessories
HP Business PC Security Lock Kit
Security Cable with Kensington Lock
Belkin Serial to USB adapter
PV606AA
PC766A
EM449AA
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 14
QuickSpecs
HP Compaq dx7500 Business PC
Memory
DDR SYNCH DRAM NON-ECC MEMORY
The Intel G45 Express chipset supports non-ECC DDR2 memory up to PC2-6400 (800-MHz). Memory upgrades are
accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible
memory configurations.
CAUTION:
Regardless of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in
to an active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable damage to the
memory modules or system board.
HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds. For dual-channel
symmetric performance, the total amount of memory in each channel must be equal. If speeds are mixed, speed will
default to the slowest DIMM.
STANDARD MEMORY
512-MB, 1-GB, 2-GB or 4GB DDR2 SYNCH DRAM
OPTIONAL MEMORY UPGRADES
Supports up to 16-GB of DDR2 SYNCH DRAM. Not all memory configurations possible are represented below.
NOTE:
available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
2-GB (dual-channel symmetric)
4-GB (dual-channel symmetric)
4-GB (dual-channel symmetric)
8-GB (dual-channel symmetric)
16-GB (dual-channel symmetric)
You must shut down the computer and disconnect the power cord before adding or removing memory modules.
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be
DIMM Size
512-MB 512-MB
1-GB 1-GB
Slot 1 (Blue)
1-GB 1-GB
1-GB 1-GB 1-GB 1-GB
2-GB 2-GB
2-GB 2-GB 2-GB 2-GB
4-GB 4-GB 4-GB 4-GB
Slot 2 (Black)
Slot 3 (Blue)
Slot 4 (Black)
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 15
QuickSpecs
Storage
HP Compaq dx7500 Business PC
HP Compaq dx7500 Microtower Business PC
Maximum Quantity
Supported
Drive Support
Diskette Drives
Media Reader
CD-ROM Drives
DVD-ROM Drives
DVD+/-RW Drives
3.5” Serial ATA Hard Drives
1 3
1 3
2
2
2
2
Position Supported
1, 2
1, 2
1, 2
4, 5
Controller
SIO
Internal USB 2.0 port
SATA
SATA
SATA
SATA
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 16
QuickSpecs
Storage
HP Compaq dx7500 Business PC
HP Compaq dx7500 Small Form Factor Business PC
Drive Support
Diskette Drives
Media Reader
CD-ROM Drives
DVD-ROM Drives
DVD+/-RW Drives
3.5” Serial ATA Hard Drives
Maximum Quantity
Supported
1 1
1 1
1 3
1 3
1 3
1 2
Position Supported
Controller
SIO
Internal USB 2.0 port
SATA
SATA
SATA
SATA
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 17
QuickSpecs
Technical Specifications - Audio
HP Compaq dx7500 Business PC
Integrated Realtek
ALC888S Audio
Type
HD Audio compatible
codec
Sampling
Audio Jacks
Power Support
Other
Integrated
Yes
Supports 48/96 KHz
Mic-In
Line-In
Line-Out / Headphone Out
Digital: 3.3V
Analog: 5V
Meets performance requirements for audio on PC99/2001 systems
High-performance DACs with 97dB SNR(A-Weighting)
ADCs with 90dB NR(A-Weighting)
2-channel
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 18
QuickSpecs
Technical Specifications - Communications
HP Compaq dx7500 Business PC
Integrated Intel
WG82567V Gigabit
Network Connection
Connector
Controller
Memory
Data rates supported
Compliance
Bus architecture
Data transfer mode
Hardware
certifications
Power requirement
Boot ROM support
Network transfer rate
Environmental
Dimensions
Management
capabilities
RJ-45
Intel WG82567V and ICH10R integrated MAC
Large 96kb receive and 8kb transmit on chip buffer
10/100/1000 Mbps
IEEE 802.3 compliant, 802.3x flow control
PCI Express 1.1
Bus-master DMA
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS
Mark for European Union
Aux 3.3V, 1.234 Watts in 1000base-T and 0.641 Watts in 100Base-T
Yes
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Operating temperature
Operating humidity
68Pin QFN (10mm x 10mm x 0.85mm)
WOL, PXE, (WOL supported from S1, S3, S4 states only. Not
supported from S5 state).
32° to 120°F (0° to 48.89° C)
85% at 120°F (48.89° C)
Intel Gigabit CT
Desktop NIC
Connector
Controller
Memory
Data rates supported
Compliance
Bus architecture
Data path width
Data transfer mode
Hardware
certifications
Power requirement
Boot ROM support
Network transfer rate
Environmental
Dimensions
Management
capabilities
RJ-45
Intel WG82574L Gigabit Ethernet Controller
Integrated Dual 48K configurable transmit receive FIFO Buffers
10/100/1000 Mbps
IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control
PCI-E 1.0a
X1, 250 MB/s, Bi-directional interface
Bus-master DMA
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS
Mark for European Union
Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Yes
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Operating temperature
Operating humidity
4.75 x 2.25 x 0.8 in (12.1 x 5.7 x 2.0 cm)
WOL, PXE, DMI, WFM 2.0
32° to 131°F (0° to 55° C)
85% at 131° F (55° C)
HP Wireless
802.11b/g/n PCIe
Dimensions (LxH)
Weight
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
3.3 x 4.7 inches (8.5 x 12 cm)
0.08 pounds (40 g)
Page 19
QuickSpecs
Technical Specifications - Communications
HP Compaq dx7500 Business PC
Controller
System interface
Network standard
Frequency band
Operating temperature
Storage temperature
Humidity
Operating voltage
Power consumption
Output power
(approximately)
Receive sensitivity
Data transfer rate
Ralink RT2790
PCIExpress x1
802.11 b/g/n
2.400 - 2.497 GHz
14° to 149°F, operating (-10° to 65°C, operating)
-40° to 176°F, non-operating (-40° to 80°C, non-operating)
10-90% operating
5-95% non-operating
3.3V +/- 9%
12V +/- 8%
Platform/WLAN Mode
Maximum Power
Consumption
Transmit Only
Transmit Packet or
Active Scanning
Receive Only Mode or
Idle without IEEE PSP
mode enabled
Idle, with IEEE PSP
mode enabled
Transmit Disabled
(turned off in software)
Platform in S3 or S4
(power removed from
Low Profile PCI Express
Card)
802.11b modes 802.11g modes
+19 dBm +/- 1.0 dB
maximum
Mode
802.11b
802.11b
802.11g
802.11g
802.11g
802.11g
EWC (2.4 GHz)
EWC (2.4 GHz)
EWC (2.4 GHz)
EWC (2.4 GHz)
EWC (2.4 GHz)
EWC (2.4 GHz)
Data Rate (MCS)
1 Mbps (802.11 b)
2 Mbps (802.11 b)
5.5 Mbps (802.11 b)
11 Mbps (802.11 b)
Power Consumption
10 Watts
4 Watts maximum averaged power over 1
second
1000 mA peak current for 100 microseconds
or longer
3 Watts maximum averaged over 1 second
1.0 Watts maximum averaged over 1 second
50 mW maximum, averaged over 1 second
5 mW maximum, averaged over 1 second
EWC modes
+17 dBm +/- 1.0 dB
maximum
Data rate
1 Mbps
11 Mbps
6 Mbps
18 Mbps
48 Mbps
54 Mbps
6.5 Mbps
54 Mbps
81 Mbps
162 Mbps
270 Mbps
300 Mbps
Minimum Throughput
700 kbps
1.4 Mbps
3.5 Mbps
5.9 Mbps
+17 dBm +/- 1.0 dB
maximum (total
power in all
transmit chains)
Sensitivity
-94 dBm
-85 dBm
-91 dBm
-85 dBm
-75 dBm
-72 dBm
-87 dBm
-82 dBm
-78 dBm
-74 dBm
-68 dBm
-64 dBm
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 20
QuickSpecs
Technical Specifications - Communications
HP Compaq dx7500 Business PC
Security
Antenna
Certifications
Certifications for use
by country
12 Mbps (802.11 g)
18 Mbps (802.11 g)
24 Mbps (802.11 g)
36 Mbps (802.11 g)
48 Mbps (802.11 g)
54 Mbps (802.11 g)
6.5 Mbps (20 MHz
EWC)
13 Mbps (20 MHz EWC)
19.5 Mbps (20 MHz
EWC)
26 Mbps (20 MHz EWC)
39 Mbps (20 MHz EWC)
52 Mbps (20 MHz EWC)
58.5 Mbps (20 MHz
EWC)
65 Mbps (20 MHz EWC)
78 Mbps (20 MHz EWC)
104 Mbps (20 MHz
EWC)
117 Mbps (20 MHz
EWC)
130 Mbps (20 MHz
EWC)
13.5 Mbps (40 MHz
EWC)
27 Mbps (40 MHz EWC)
40.5 Mbps (40 MHz
EWC)
54 Mbps (40 MHz EWC)
81 Mbps (40 MHz EWC)
108 Mbps (40 MHz
EWC)
121.5 Mbps (40 MHz
EWC)
135 Mbps (40 MHz
EWC)
IEEE and WiFi compliant 64 / 128 bit WEP encryption
AES: CCM
802.1x authentication
WPA: 802.1x. WPA-PSK and TKIP
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through V5
HP part number 497792-001
Wi-Fi certified
United States, Canada, Peru, Taiwan
6 Mbps
9 Mbps
12 Mbps
18 Mbps
21 Mbps
22.5 Mbps
4.5 Mbps
9 Mbps
13.5 Mbps
18 Mbps
27 Mbps
36 Mbps
40 Mbps
45 Mbps
54 Mbps
72 Mbps
81 Mbps
91 Mbps
8 Mbps
16 Mbps
24 Mbps
32 Mbps
48 Mbps
64 Mbps
72 Mbps
81 Mbps
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 21
QuickSpecs
Technical Specifications - Communications
HP Compaq dx7500 Business PC
LSI PCIe x1 56K
International
SoftModem
Data Transmission
Data Speeds
Data Standards
Fax Speeds
Fax Mode Capabilities
Error Correction and
Data Compression
Power Management
Upgradeability
Video
Other
Operating
Temperature
Operating Humidity
Power
Chipset
Dimensions
Connection
Other Features
Safety
EMC
Telecom
Other
(L X H)
Technology speeds: 56,000 Kbps maximum downstream data,
controllerless
NOTE:
requires compatible modems at server sites. Other conditions may limit
modem speed. FCC limitations allow a maximum of 53 Kbps during
download transmissions.
(Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/
16,800/14,400/12,000/9,600/7,200/4,800/2,400/1,200/300
ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell
212A, and Bell 103
14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s
ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
V.44, 42bis, V.42 and MNP2-5
PCI Bus Power Management Interface Specification (PCI-PM) Revision
1.2, Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in
D3cold. If the power management event (PME) feature is enabled in
D3cold, a modem can wake the system via WAKE# (WAKEN) or
beacon. Meets PCI Express 1.1 standard.
Driver upgradeable for future enhancements
ITU-T V.80 video ready interface
TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel
16550a UART-compatible interface
Optional ring wakeup signal
32° to 158° F (0° to 70° C)
20% to 90%, non-condensing
Requires a 3.3-V auxiliary power rail on PCI express bus
Uses only one PCI express load (i.e., one grant/request pair), one
shared IRQ, one electrical load
LSI SV92EX - Integrated PCI interface with 3.3-V tolerant buffers and
CardBus support
Complies with PCI express low profile specifications-6.7 x 2.3 in (17.0 x
5.8 cm) and supports high- and low-profile brackets
Single RJ-11 connector
Digital line protection, call progress monitoring via on-board piezo
device, support for high profile and low profile brackets, PnP ID support
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950
(TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO,
DEMKO, SEMKO, CE mark
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
The SV92EX device is packaged in a 32-pin micro leadless chip carrier
(MLCC). The SV92EX is fully compliant with the PCI Express revision
1.1 specification. WHQL approved; ASPM compliant.
56 Kbps technology refers to download speeds only and
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 22
QuickSpecs
Technical Specifications - Graphics
HP Compaq dx7500 Business PC
Integrated Intel
Graphics Media
Accelerator X4500HD
3D/2D Controller
VGA Controller
DVI
Bus Type
RAMDAC
Graphics Engine Clock
Memory
Microsoft DirectX® 10 based with support for Pixel Shader 3.0
Integrated
Integrated
PCI Express™ x16
Integrated, 350 MHz
667 MHz
Graphics memory is shared with system memory. Graphics memory
usage varies depending on the amount of system memory installed,
BIOS settings, operating system, and system load. 32 MB is preallocated for graphics use at system boot time. Additional memory can
be allocated at boot time by the BIOS for PAVP (Protected Audio Video
Playback) support for playback of protected video content. For Vista,
use of PAVP heavy mode pre-allocates an additional 96MB.
Additional memory is allocated for graphics as needed using Intel's
Dynamic Video Memory Technology (DVMT), to provide an optimal
balance between graphics and system memory use.
Windows XP Memory Usage:
Total System
Memory (GB)
0.5
1 512 32 480
1.5
=>2.0
Total Graphics
memory (MB)
128 32 96
256 32 224
768 32 736
1024 32 992
Pre-Allocated
(MB)
DVMT (MB)
Windows Vista Memory Usage
Support for DVMT 5.0. The graphics driver will determine DVMT
memory.
DVMT memory = Total GFX memory – Pre-allocated size and fixed
memory = Pre-allocated memory.
HW Video Decode
Maximum Color Depth
Maximum Vertical
Refresh Rate
Multi-display Support
Graphics/Video API
Support
Resolutions Supported
NOTE:
Other resolutions may be available but are not recommended as the may not have been tested and qualified by
HP.
Full Hardware Accelerated decode for MPEG2 encrypted video;
support for PAVP Lite (default) and Heavy ( or Paranoid) modes. Full
H.264 and VC1 Variable Length Decode Acceleration and Intel Clear
Video Technology Support.
32 bits/pixel
85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and
configuration. See table below.
Dual Independent monitor support facilitated via one VGA port and one
DVI integrated on the back plane of the system board and presented as
part of the rear I/O set of interfaces.
Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a
driver update)
:
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 23
QuickSpecs
Technical Specifications - Graphics
Resolution
640x480
800x600
1024x768
1280x720
1280x1024
1440x900
1600x1200
1680x1050
1920x1080
1920x1200
1920x1440
2048x1536
2560x1600
* Only supported when using a DisplayPort connection
NOTE:
60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
connections
Analog Connection
HP Compaq dx7500 Business PC
Maximum Refresh Rate (Hz)
Digital Connection
85 60
85 60
85 60
85 60
85 60
75 60
85 60
75 60
85
85
85
75
N/A
60-R
60-R
N/A
N/A
60
*
ATI Radeon HD 2400XT
(256MB DH) PCIe
Graphics Card
Bus type
Maximum vertical
refresh rate
Display support
Display max resolution
Board display options
Board configuration
Languages supported
Core power
Compliance standards
PCI Express (x16 lanes)
85 Hz
Integrated 400 MHz RAMDAC
1920 x 1200 digital, 2048 x 1536 analog
Supports two displays via included DMS-59 to dual VGA cable or 2 DVI
monitors via optional DMS-59 to dual DVI cable kit part number:
DL139A. 4-pin mini-DIN S-video connector for TV output
Specification
Graphics Chip
Core clock
Memory clock
Frame buffer
24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek,
Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, Spanish, Swedish, Thai, Turkish
21 W
EMC Emissions:
FCC Part 15, Subpart B - Unintentional Radiators, Class B
a.
Computing Devices for Home & Office Use
CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods
b.
of measurement of radio disturbance characteristics of
Information Technology Equipment
Canadian Standard ICES-003 is equivalent to CISPR22
c.
Taiwanese Standard BSMI
d.
Japanese VCCI
e.
Australian C-Tick
f.
Korean (MIC)
g.
Description
RV610
650 MHz
500 MHz
256 MB DDR2, 128 bit wide
EMC Immunity:
CISPR 24:1997/EN 55024:1998 - Information Technology Equipment Immunity Characteristics - Limits and Methods of Measurement.
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 24
QuickSpecs
HP Compaq dx7500 Business PC
Technical Specifications - Graphics
ATI Radeon HD 2400XT (256MB DH) PCIe Graphics Card display resolutions and refresh rates
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
Resolution
640x480
800x600
1024x768
1280x720
1280x1024
1440x900
1600x1200
1680x1050
1920x1080
1920x1200
1920x1440
2048x1536
2560x1600
* Only supported when using a dual-link DVI or DP connection
NOTE:
connections
60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
Analog Resolution
85 60
85 60
85 60
85 60
85 60
85 60
75 60
85 60
75 60
85
85
85
75
N/A
Maximum Refresh Rate (Hz)
Digital Connection
60-R
60-R
N/A
N/A
60
*
ATI Radeon HD 3650
(512MB DH) PCIe x16
Graphics Card
Bus type
Maximum vertical
refresh rate
Display support
Display max resolution
Board display options
Board configuration
Languages supported
Core power
Compliance standards
PCI Express (x16 lanes)
85 Hz
Integrated 400 MHz RAMDAC
2560 x 1600 digital, 2048 x 1536 analog
Supports two displays via included two DisplayPort and one Dual Link
DVI-I connectors.
Specification
Graphics Chip
Core clock
Memory clock
Frame buffer
24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek,
Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, Spanish, Swedish, Thai, Turkish
56 W
EMC Emissions:
FCC Part 15, Subpart B - Unintentional Radiators, Class B
a.
Computing Devices for Home & Office Use
CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods
b.
of measurement of radio disturbance characteristics of
Information Technology Equipment
Canadian Standard ICES-003 is equivalent to CISPR22
c.
Taiwanese Standard BSMI
d.
Japanese VCCI
e.
Australian C-Tick
f.
Korean (MIC)
g.
Description
RV635
600 MHz
500 MHz
512 MB DDR2, 128 bit wide
EMC Immunity:
CISPR 24:1997/EN 55024:1998 - Information Technology Equipment -
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 25
QuickSpecs
g.
Technical Specifications - Graphics
Immunity Characteristics - Limits and Methods of Measurement.
ATI Radeon HD 3650 (512MB DH) PCIe x16 Graphics Card display resolutions and refresh rates
NOTE
:Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
Resolution
640x480
800x600
1024x768
1280x720
1280x1024
1440x900
1600x1200
1680x1050
1920x1080
1920x1200
1920x1440
2048x1536
2560x1600
* Only supported when using a dual-link DVI or DisplayPort connection
NOTE:
connections
60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
Analog Resolution
85 60
85 60
85 60
85 60
85 60
85 60
75 60
85 60
75 60
85
85
85
75
N/A
Maximum Refresh Rate (Hz)
HP Compaq dx7500 Business PC
Digital Connection
60-R
60-R
N/A
N/A
60
*
ATI Radeon HD 3470
(256 SH) PCIe
Graphics Card
Bus type
Maximum vertical
refresh rate
Display support
Display max resolution
Board display options
Board configuration
Languages supported
Core power
Dimmensions
Compliance standards
PCI Express (x16 lanes)
85 Hz
Integrated 400 MHz RAMDAC
2560 x 1600 digital, 2048 x 1536 analog
Supports two displays via the DisplayPort and DVI connectors
Specification
Graphics Chip
Core clock
Memory clock
Frame buffer
24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek,
Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, Spanish, Swedish, Thai, Turkish
22
2.71 in x 6.60 in (68.90 mm x 167.65 mm)
EMC Emissions:
FCC Part 15, Subpart B - Unintentional Radiators, Class B
a.
Computing Devices for Home & Office Use
CISPR22: 1997/EN 55022:1998 - Class B - Limits and methods
b.
of measurement of radio disturbance characteristics of
Information Technology Equipment
Canadian Standard ICES-003 is equivalent to CISPR22
c.
Taiwanese Standard BSMI
d.
Japanese VCCI
e.
Australian C-Tick
f.
Korean (MIC)
g.
Description
RV620
750 MHz
500 MHz
256 MB DDR2, 128 bit wide
EMC Immunity:
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 26
QuickSpecs
f.
g.
Technical Specifications - Graphics
CISPR 24:1997/EN 55024:1998 - Information Technology Equipment Immunity Characteristics - Limits and Methods of Measurement.
ATI Radeon HD 3470 (256MB SH) PCIe Graphics Card display resolutions and refresh rates
NOTE:
* Only supported when using a dual-link DVI or DisplayPort connection
NOTE:
connections
Other resolutions may be available but are not recommended as they may not have been tested and qualified by
HP
Maximum Refresh Rate (Hz)
Analog Resolution
Resolution
640x480
800x600
1024x768
1280x720
1280x1024
1440x900
1600x1200
1680x1050
1920x1080
1920x1200
1920x1440
2048x1536
2560x1600
60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
85 60
85 60
85 60
85 60
85 60
85 60
75 60
85 60
75 60
85
85
85
75
N/A
HP Compaq dx7500 Business PC
Digital Connection
60-R
60-R
N/A
N/A
60
*
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 27
QuickSpecs
Technical Specifications - Input Devices
HP Compaq dx7500 Business PC
HP PS/2 or USB
Standard Keyboard
Physical
characteristics
Electrical
Mechanical
Environmental
Approvals
Ergonomic compliance
Keys
Dimensions
Weight
Operating voltage
Power consumption
ESD
EMI – RFI
Microsoft
Languages
Keycaps
Switch actuation
Switch life
Switch type
Key-leveling
mechanisms
Cable length
Microsoft PC 99 – 2001
Acoustics
Operating temperature
Non-operating
temperature
Operating humidity
Non-operating
humidity
Operating shock
Non-operating shock
Operating vibration
Non-operating
vibration
Drop
(out of box)
Drop
(in box)
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
ANSI HFS 100, ISO 9241-4, and TUVGS
(L x W x H)
PC 99 – 2001
104, 105, 106, 107, 109 layout (depending
upon country)
18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm)
2 lb (0.9 kg) minimum
+ 5VDC ± 5%
50-mA maximum (with three LEDs ON)
CE level 4, 15-kV air discharge
Conforms to FCC rules for a Class B
computing device
Functionally compliant
38 available
Low-profile design
55-g nominal peak force with tactile feedback
20 million keystrokes (using Hasco modified
tester)
Contamination-resistant switch membrane
For all double-wide and greater-length keys
6 ft (1.8 m)
Mechanically compliant
43-dBA maximum sound pressure level
50° to 122° F (10° to 50° C)
–22° to 140° F (–30° to 60° C)
10% to 90% (non-condensing at ambient)
20% to 80% (non-condensing at ambient)
40 g, six surfaces
80 g, six surfaces
2-g peak acceleration
4-g peak acceleration
26 in (66 cm) on carpet, six-drop sequence
42 in (107 cm) on concrete, 16-drop
sequence
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 28
QuickSpecs
Technical Specifications - Input Devices
HP Compaq dx7500 Business PC
HP 2-Button Scroll
Mouse
(PS/2)
Scroll Wheel
Maximum Rotation
Speed
Switch Type
Switch Life
Mechanical Life
Environmental
Electrical
Mechanical
Regulatory Approvals
8 mm
30 mm/s
Light force micro-switch
1 million operations
Minimum 200,000 revolutions
Operating
Temperature
Non-operating
Temperature
Operating Humidity
Non-operating
Humidity
Operating Shock
Non-operating Shock
Operating Vibration
Non-operating
Vibration
Operating Voltage
Power Consumption
System Consumption
ESD
EMI-RFI
PC98
Resolution
Tracking Speed
Acceleration
Switch Actuation
Switch Life
Cable Length
PC98-99
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C-Tick
50° to 122° F (10° to 50° C)
–22° to 140° F (–30° to 60° C)
10% to 90% (non condensing at ambient)
20% to 80% (non condensing at ambient)
40 g, 6 surfaces
80 g, 6 surfaces
2 g peak acceleration
4 g peak acceleration
+ 5VDC ± 10%
15mA
PS/2 mini-din connector
CE level 4, 15 kV air discharge
Conforms to FCC rules for a Class B
computing device
Functionally compliant
400 ± 20% DPI
10 in/s maximum
100 in/s
85 g nominal peak force
1,000,000 operations (using Hasco modified
tester)
2 m
Mechanically compliant
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 29
QuickSpecs
Technical Specifications - Hard Drives
HP Compaq dx7500 Business PC
Serial ATA Hard Drives
(7200 rpm)
80 GB
160 GB
250 GB
Capacity
Height
Width
Interface
Synchronous Transfer
Rate
(Maximum)
Buffer
Seek Time
reads, includes
controller overhead,
including settling)
Rotational Speed
Logical Blocks
Operating
Temperature
Capacity
Height
Width
Interface
Synchronous Transfer
Rate
Buffer
Seek Time
reads, includes
controller overhead,
including settling)
Rotational Speed
Logical Blocks
Operating
Temperature
Capacity
Height
Width
Interface
Synchronous Transfer
Rate
Buffer
Seek Time
reads, includes
controller overhead,
including settling)
Rotational Speed
Logical Blocks
Operating
Temperature
(typical
(Maximum)
(typical
(Maximum)
(typical
80,026,361,856 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.9 cm)
Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
Up to 3 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
156,301,488
32° to 140° F (0° to 60° C)
160,041,885,696 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.9 cm)
Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
Up to 3 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
312,581,808
32° to 140° F (0° to 60° C)
250,059,350,016 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.9 cm)
Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
Up to 3 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
488,397,168
41° to 131° F (5° to 55° C)
2.0 ms
11 ms
21 ms
2.0 ms
11 ms
21 ms
2.0 ms
11 ms
21 ms
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 30
QuickSpecs
Technical Specifications - Hard Drives
HP Compaq dx7500 Business PC
320 GB
500 GB
Capacity
Height
Width
Interface
Synchronous Transfer
Rate
(Maximum)
Buffer
Seek Time
reads, includes
controller overhead,
including settling)
Rotational Speed
Logical Blocks
Operating
Temperature
Capacity
Height
Width
Interface
Synchronous Transfer
Rate
Buffer
Seek Time
reads, includes
controller overhead,
including settling)
Rotational Speed
Logical Blocks
Operating
Temperature
(typical
(Maximum)
(typical
320,072,933,376 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.9 cm)
Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
Up to 3 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
625,142,448
41° to 131° F (5° to 55° C)
500,107,862,016 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.89 cm)
Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
Up to 3 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
976,773,168
41° to 131° F (5° to 55° C)
2.0 ms
11 ms
21 ms
2.0 ms
11 ms
21 ms
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 31
QuickSpecs
Technical Specifications - Optical Storage
HP Compaq dx7500 Business PC
SATA DVD-ROM Drive
Height
Orientation
Interface type
Disc capacity
Dimensions
Weight (max)
Read speeds
Removable Storage Media Compatibility DVD-ROM
Access times
(typical reads, including
setting)
Power
Environmental
(all conditions
non-condensing)
(W x H x D)
5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM)
Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
2.6 lb (1.2 kg)
DVD+R/-R/+RW/
-RW/+R DL /-R DL
DVD-ROM
DVD-RAM
CD-ROM, CD-R
CD-RW
Media
CD-ROM
CD-R
CD-RW
DVD-ROM
DVD-ROM DL
DVD-RAM
DVD+R
DVD+R DL
DVD+RW
DVD-R
DVD-RW
DVD-R DL
Random
Full Stroke
Cache Buffer
Data Transfer Modes
Source
DC Power
Requirement
DC Current
Temperature
Relative Humidity
Maximum Wet Bulb
Temperature
Up to 8X
Up to 16X
Up to 4X
Up to 48X
Up to 32X
Read
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DVD: < 140 ms (typical), CD: < 125 ms
(typical)
DVD: < 250 ms (seek), CD: < 210 ms (seek)
2 MB (minimum)
ATA PIO mode 4 (16.7 MB/s); ATA Multiword DMA mode 2 (16.7 MB/s); ATA
UltraDMA Mode 3 (44.4 MB/s -default)
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
5 VDC - <1000 mA typical, < 1600 mA
maximum
12 VDC -< 600 mA typical, < 1400 mA
maximum
41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)
Write
No
No
No
No
No
No
No
No
No
No
No
No
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 32
QuickSpecs
Technical Specifications - Optical Storage
HP Compaq dx7500 Business PC
SATA DVD+/-RW
LightScribe Drive
Height
Orientation
Interface type
Disc capacity
Dimensions
Weight (max)
Write speeds
Read speeds
Access times
(typical reads, including
setting)
Power
Environmental
(all conditions
non-condensing)
(W x H x D)
5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM)
Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
2.6 lb (1.2 kg)
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW
DVD-RAM
DVD+R/-R/+RW/
-RW/+R DL /-R DL
DVD-ROM
CD-ROM, CD-R
CD-RW
Random
Full Stroke
Source
DC Power
Requirement
DC Current
Temperature
Relative Humidity
Maximum Wet Bulb
Temperature
Up to 16X
Up to 8X
Up to 8X
Up to 4X
Up to 16X
Up to 6X
Up to 48X
Up to 32X
Up to 4X
Up to 8X
Up to 16X
Up to 48X
Up to 32X
DVD: < 130 ms (typical), CD: < 120 ms
(typical)
DVD: < 240 ms (seek), CD: < 200 ms (seek)
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
5 VDC - <1000 mA typical, < 1600 mA
maximum
12 VDC -< 600 mA typical, < 1400 mA
maximum
41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 33
QuickSpecs
Technical Specifications - Removable Storage
HP Compaq dx7500 Business PC
HP 1.44-MB Diskette
Drive
Size
LED Indicators
panel)
Read/Write Capacity
per Diskette
Drive Height
Drive Rotation
Transfer Rate
(high/low)
Bytes/Sector
Sectors/Track
(high/low)
Tracks/Side
Access Times
Cylinders
Read/Write Heads
(front
(high/low)
(high/low)
(high/low)
3.5 in (8.89 cm)
Green
1.44 MB/720 KB
One-third
300 rpm
500/250 KB/s
512
18/9
80/80
Track-to-Track
(high/low)
Average
(high/low)
Settling Time
Latency Average
80/80
Two
3/6 ms
94/173 ms
15 ms
100 ms
HP 22-in-1 Media Card
Reader
USB interface
Advance protocol
support
Supported media types
Mechanical
Environmental
USB 2.0 High-speed device via PCI card or pass -through via internal
USB port of system board
Supports hardware ECC (Error Correction Code) function
Supports hardware CRC (Cyclic Redundancy Check) function
Supports MS 4-bit parallel transfer mode
Supports MS-PRO 4-bit parallel transfer mode
Supports SD 4-bit parallel transfer mode
Supports high-speed 50 MHz SD 4-bit card (version 1.1)
Support high-speed 52 MHz MMC 8-bit card (version 4.x)
Supports CompactFlash Card Type I (CF I), CompactFlash Card
Type II (CF II), MicroDrive (MD)
Supports 3.3V SmartMedia Card (SM), SmartMedia ROM (SM
ROM), xD-Picture Card (xD)
Supports Secure Digital Card (SD), Secure Digital ROM Card
(SD ROM), miniSD, MultiMediaCard (MMC), Secure
MultiMediaCard (Secure MMC), ROM Type MultiMediaCard
(MMC ROM), Reduced Size MultiMediaCard (RS MMC),
MultiMediaCard 4.0 (MMC Plus), Reduced Size MultiMediaCard
4.0 (MMC Mobile)
Support Memory Stick (MS), Memory Stick ROM (MS ROM),
MagicGate Memory Stick (MG), Memory Stick Select, Memory
Stick Duo (MS Duo), Memory Stick PRO (MS-PRO), Memory
Stick PRO Duo (MS PRO Duo)
Length
Width
Height
Length
Width
Height
Operational
(3.5”)
(3.5”)
(3.5”)
(5.25”)
(5.25”)
(5.25”)
124.7 cm
101.6 cm
25.4 cm
171.6 cm
148.9 cm
42.7 cm
Test Parameters/Conditions – Power applied,
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 34
QuickSpecs
Technical Specifications - Removable Storage
HP Compaq dx7500 Business PC
Approvals
environmental
extremes
Storage environmental
extremes
USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only
Transport Specification Rev. 1.0, Compliant Intel Front Panel I/O
Connectivity Design Guide V. 1.2
FCC, CE, BSMI, C-Tick, VCCI, MIC, cUL, TUV-T
unit operating on system ±5%
nominal supply voltage.
10°C 10% R.H. ≥ 24 hours
10°C 90% R.H. ≥ 24 hours
20°C 90% R.H. ≥ 24 hours
30°C 90% R.H. ≥ 24 hours
40°C 90% R.H. ≥ 24 hours
50°C 90% R.H. ≥ 24 hours
50°C 10% R.H. ≥ 24 hours
Test Parameters/Conditions
60°C @ 80% R.H. for 96 hours
-30°C @ 20% R.H. for 48 hours
No power applied
Delta °C < 1.0°C/min
Delta % R.H. < 1.5% R.H./min
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 35
QuickSpecs
Technical Specifications - Environmental Data
HP Compaq dx7500 Business PC
Eco Data
Eco-Label
Certifications &
declarations
Microtower
System Configuration
Energy Consumption
(in accordance with US
Energy Star test method)
Normal Operation
Sleep
Off
Heat Dissipation
Normal Operation
Sleep
Off
Additional Information
*
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks
IT ECO declaration
Korea Eco-label
The configuration used for the Energy Consumption data for the
Microtower model is based on a typically configured product.
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
57.89W 57.53W 56.08W
4.53W 4.73W 4.73W
1.33W 1.12W 1.15W
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
198 BTU/hr 197 BTU/hr 192 BTU/hr
16 BTU/hr 16 BTU/hr 16 BTU/hr
5 BTU/hr 4 BTU/hr 4 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive – 2002/95/EC.
RoHS Compliance
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
Display meets the requirement for low frequency electromagnetic fields
per MPR-II and prEN50279 A/B/C
This product contains 0% recycled materials (by wt.)
This product is 93.0% recycle-able when properly disposed of at end of
life.
Packaging Materials
External:
Corrugated 2260g
Wood 13000g
Polyethylene low density 130g
Internal:
Hewlett-Packard is committed to compliance with all applicable
environmental laws and regulations, including the European Union
Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to
exceed compliance obligations by meeting the requirements of the
RoHS Directive on a worldwide basis. By July 1, 2006, RoHS
substances will be virtually eliminated (virtually = to levels below legal
limits) for all HP electronic products subject to the RoHS Directive,
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 36
QuickSpecs
Technical Specifications - Environmental Data
except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS
Directive).
Material Usage
Packaging
This product does not contain any of the following substances in excess
of regulatory limits (refer to the HP General Specification for the
Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
HP follows these guidelines to decrease the environmental impact of
product packaging:
HP Compaq dx7500 Business PC
):
End-of-life
Management and
Recycling
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
Hewlett-Packard offers end-of-life HP product return and recycling
programs in many geographic areas. To recycle your product, please
go to:
http://www.hp.com/go/reuse-recycle
sales office. Products returned to HP will be recycled, recovered or
disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to
provide treatment information for each product type for use by
treatment facilities. This information (product disassembly instructions)
is posted on the Hewlett Packard web site at:
or contact your nearest HP
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 37
QuickSpecs
Technical Specifications - Environmental Data
HP Compaq dx7500 Business PC
http://www.hp.com/go/recyclers
recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Hewlett-Packard
Corporate
Environmental
Information
© Copyright 2009 Hewlett-Packard Development Company, L.P.
All rights reserved.
The information contained herein is subject to change without notice.
Intel and Pentium are U.S. registered trademarks of Intel Corporation. Microsoft and Windows are U.S. registered
trademarks of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/
operations/envmanagement.html
. These instructions may be used by
DA - 13152 Worldwide QuickSpecs — Version 6 — 2.24.2009
Page 38
Loading...
