QuickSpecs
Button Scroll Mouse (PS/2) or Optical Scroll Mouse (PS/2
HP Standard Keyboard (PS/2 or USB) or HP USB Smartcard
Overview
HP Compaq dx7300 Business PC
HP Compaq dx7300 Business PC
HP recommends Windows® XP
Professional
Microtower
1. Monitor (sold separately) 6. (2) 5.25" external bays and (2) 3.5" internal bays
2. 2or USB)
3.
Keyboard
4. Front I/O: (2) USB 2.0, headphone and microphone 9. 365-watt Active Power Factor Correction (PFC) power
5. (2) 3.5" external bays for optional HP 16-in-1 Media Card
Reader, diskette drive, or other 3.5" device
7. (2) full-height PCI slots, (1) full-height PCI Express x1 slot,
(1) full-height PCI Express x16 slot
8. Rear I/O: (6) USB 2.0, (1) standard serial port, (1) optional
serial port, (1) parallel port, (2) PS/2, (1) RJ-45, (1) VGA,
audio in/out, mic in
supply
At A Glance
• Designed for customers desiring the latest Intel technology and maximum upgradeability
• Created using industry leading Design for Environment standards. Upgradeable, recyclable and energy efficient.
• Intel® Q965 Express chipset and Intel Graphics Media Accelerator 3000 integrated graphics
• Intel Core™ 2 Duo Processors, Intel Pentium D Processors, Intel Pentium 4 Processors, Intel Celeron D Processors
• Value-added software
o HP Client Manager (http://h18000.www1.hp.com/im/index.html)
o HP OpenView Configuration Management Solutions
o Altiris Deployment Solution Agent
o Symantec AntiVirus 10.0 with 60 day Live Update Subscription
o HP Insight Diagnostics software
• HP BIOS for better security, manageability and software image stability
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 1
QuickSpecs
HP Compaq dx7300 Business PC
Overview
• Tailored HP Factory Express deployment and lifecycle services available
(http://h71028.www7.hp.com/enterprise/cache/97688-0-0-225-121.aspx)
• Protected by HP Services, including standard warranties ranging from 90-0-0 to 3-3-3 (terms and conditions vary by
country; certain restrictions and exclusions apply)
• Security
o Redundant Array of Independent Disks (RAID) 1 configurations to protect data against hardware failures
o HP Backup and Recovery Manager to protect data against software corruption or incompatibilities due to
patching or upgrades
• Tool-less serviceability features for easier upgrades and repairs
• Choice of professional chassis form factors to accommodate the desired mix between expandability and size
NOTE: All models and features may not be available in all countries.
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 2
QuickSpecs
HP Compaq dx7300 Business PC
Configurable Components - Select Models (localized by Regions)
Model Key and Example
NOTE: This diagram is an example that illustrates how to read the model number. It is not intended to give every available
configuration choice specified in the body of this document and may include references to modules that are out of date and no
longer available.
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 3
QuickSpecs
added Services and
Configurable Components
HP Compaq dx7300 Business PC
Operating System –
One of the following
Value-added Software
(not included with
FreeDOS)
Genuine Windows XP Professional SP2
Genuine Windows XP Home SP2
FreeDOS
Windows Vista Capable – Not all Windows Vista features are available for use on all Windows
Vista Capable PCs. All Windows Vista Capable PCs will run the core experiences of Windows Vista,
such as innovations in organizing and finding information, security, and reliability. Some features
available in premium editions of Windows Vista -- like the new Windows Aero™ user interface -require advanced or additional hardware.
Check http://www.windowsvista.com/getready for details.
NOTE: Microsoft Windows NT 4.0 and Microsoft Windows 2000 are not available on these
systems. Some drivers for Windows 2000 are available for download from http://www.hp.com.
Altiris Deployment Solution Agent Microsoft Office 2003 Basic
HP OpenView Configuration Management
Solutions Agent (visit
http://www.hp.com/go/easydeploy)
HP Insight Diagnostics (on documentation CD) Microsoft Office 2003 Professional
Computer Setup Utility Microsoft Office 2003 Small Business
HP Backup and Recovery Manager Microsoft Works 8.5
Symantec AntiVirus 10.0 with 60 day Live Update
Subscription
PDF Complete Adobe Acrobat Reader
Microsoft Office 2003 Personal
Microsoft Internet Explorer with Google Toolbar
ValueFeatures
Service and Support
Chassis Dimensions (H x W x D) 14.4 x 6.88 x 16.55 in (36.6 x 17.5 x 42 cm)
HP Stable Platform Program Factory Express Deployment and Lifecycle
Services
Business-to-Business Portals Tool-less Serviceability
HP Global Series Services
On-site Warranty and Service
delivers three years of parts, labor and on-site repair. Response time is next business-day
includes free telephone support
purchased in one country and transferred to another non-restricted country will remain fully covered
under the original warranty and service offering. Some countries/regions do not offer one year onsite
and labor.
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an
authorized HP third-party provider, and is not available in certain countries. Global service response
times are based on commercially reasonable best effort and may vary by country.
NOTE 3: Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party
hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
Note 1
: This three-year (3-3-3), limited warranty and service offering
Note 3
24 x 7. Global coverage
Microtower
Note 2
ensures that any product
Note 2
and
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 4
QuickSpecs
HP Compaq dx7300 Business PC
Configurable Components
System weight 24.0 lb (10.89 kg)
System volume 1640 sq. in. (27.0 liters)
Shipping weight 34 lb (15.42 kg)
Shipping box dimensions
(H x W x D)
Power Supply 365W power supply – Active PFC
Ports
USB 2.0 8 (2 front, 6 rear)
Serial 1 standard with 2nd optional
Parallel 1
PS/2 1 keyboard, 1 mouse
Video analog for integrated graphics
DVI output available via ADD2 card, PCI-E x16 card, or PCI card
Support for Multi-Monitor available via ADD2 card, PCI-E x16 card, or PCI card
Audio Front – mic and headphone
NIC (RJ-45) Integrated Intel 82566DM Gigabit Network Connection Ethernet
22.25 x 19.63 x 15.13 in (56.52 x 49.86 x 38.43 cm)
Rear – line in, line out, mic in
Chipset Intel Q965 Express chipset
Processor and Speed*
One of the following
*NOTE: Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each
processor family, not across different processor families.
Intel Celeron D Processors:
Intel Celeron D 352 Processor (3.20-GHz, 512K L2 cache, 533-MHz FSB)
Intel Celeron D 360 Processor (3.46-GHz, 512K L2 cache, 533-MHz FSB)
Intel Pentium 4 Processors with Hyper Threading Technology:
Intel Pentium 4 524 Processor (3.06-GHz, 1-MB L2 cache, 533 -MHz FSB)
Intel Pentium 4 531 Processor (3.0-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium 4 541 Processor (3.2-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium 4 661 Processor (3.26-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium D Processors:
Intel Pentium D 820 Processor (2.8-GHz, 2x1MB L2 cache, 800-MHz FSB)
Intel Pentium D 915 Processor (2.8-GHz, 2x1MB L2 cache, 800-Mhz FSB
Intel Pentium D 925 Processor (3.0-GHz, 2x2MB L2 cache, 800-MHz FSB)
Intel Pentium D 945 Processor (3.4-GHz, 2x2MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo Processors:
Intel Core 2 Duo E6300 Processor (1.86-GHz, 2 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6400 Processor (2.13-GHz, 2 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6600 Processor (2.40-GHz, 4 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E6700 Processor (2.66-GHz, 4 MB L2 cache, 1066-MHz FSB)
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 5
QuickSpecs
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes.
Configurable Components
Memory DDR2 SYNCH DRAM NON-ECC MEMORY
This chart does not represent all possible memory configurations. The Intel Q965 Express chipsets
support non-ECC DDR2 PC2-5300 (667-MHz) and PC2-6400 (800-MHz) memory.
CAUTION: You must shut down the computer and disconnect the power cord before adding or
removing memory modules. Regardless of the power-on state, voltage is always supplied to the
memory modules as long as the computer is plugged in to an active AC outlet. Adding or removing
memory modules while voltage is present may cause irreparable damage to the memory modules or
system board.
HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds.
For dual-channel symmetric performance, the total amount of memory in each channel must be equal.
If speeds are mixed, speed will default to the slowest DIMM.
HP Compaq dx7300 Business PC
Microtower
Maximum Memory* Supports up to 4-GB of DDR2 SYNCH DRAM. Slot 1 is black and must always be populated. Not all
memory configurations possible are represented below.
NOTE: Above 3-GB, all memory may not be available due to system resource requirements.
DIMM Size Slot
Channel A Channel B
1 (black) 2 (white) 3 (white) 4 (white)
512-MB 512-MB
512-MB (dual-channel
symmetric)
1-GB 1-GB
1-GB (dual-channel
symmetric)
1-GB (dual-channel
symmetric)
2-GB (dual-channel
symmetric)
2-GB (dual-channel
symmetric)
4-GB maximum
(dual-channel symmetric)
*NOTE: The Intel Q965 Express chipset includes a built-in Management Engine (ME), which allocates memory for manageability
functions. Management Engine memory is shared with system memory. If the PC contains a single DIMM, 8 MB of memory is
pre-allocated for it at system startup. If the PC contains two DIMMs, 16 MB of memory is pre-allocated. This memory is not made
available to the operating system, just as pre-allocated video memory is not available.
256-MB 256-MB
512-MB 512-MB
256-MB 256-MB 512-MB
1-GB 512-MB 512-MB
512-MB 512-MB 512-MB 512-MB
1-GB 1-GB 1-GB 1-GB
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 6
QuickSpecs
Configurable Components
HP Compaq dx7300 Business PC
Memory Configurations
One of the following
Expandability MT
PCI slots 2 full-height (4.2"), length (13.4") standard
Max power per slot 25W
PCI Express x16 slot 1 full-height (4.2"), length (10.5")
Max power per slot 75W
External Bays 4
3.5" 1
5.25" 3 (2 – length 8.189", 1 – length 5.71")
Internal 3.5" HDD Bays 2
Hard Drive Controller
(PCI) Supported
Hard Drive Interfaces
Supported
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 512)
512-MB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 256)
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (1 x 1GB)
1-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 512)
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (2 x 1GB)
2-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 512)
3-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (3 x 1GB)
4-GB DDR2 Synch Dram PC2-5300 (667-MHz) Non ECC (4 x 1GB)
Serial ATA (support for SATA 1.5-Gb/s and 3.0-Gb/s hard drives)
4 Serial ATA interfaces
Storage – Drive Support
Microtower
MT
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 7
QuickSpecs
Configurable Components
HP Compaq dx7300 Business PC
Diskette Drive PCI Media Card Reader
(optional)
Quantity Supported 1 1 2 2
Position Supported
Controller Diskette Controller USB header on PCI card SATA SATA
Hard Drive
One or two of the
following
Removable Storage –
One or more of the
following depending on
form factor (see Storage
section below)
80-GB SATA 3.0-Gb/s Hard Drive (8MB Cache, 7200 rpm)
160-GB SATA 3.0-Gb/s Hard Drive (8MB Cache, 7200 rpm)
250-GB SATA 3.0-Gb/s Hard Drive (8MB Cache, 7200 rpm)
RAID 80-GB SATA 3.0-Gb/s Hard Drive (7200 rpm)
RAID 160-GB SATA 3.0-Gb/s Hard Drive (7200 rpm)
2nd hard drive, 80-GB SATA 3.0-Gb/s Hard Drive (8MB Cache, 7200 rpm)
2nd hard drive, 160-GB SATA 3.0-Gb/s Hard Drive (8MB Cache, 7200 rpm)
2nd hard drive, 250-GB SATA 3.0-Gb/s Hard Drive (8MB Cache, 7200 rpm)
1.44-MB Diskette Drive
Optical Drives
SATA CD-ROM Drive
SATA Combo CD-RW/DVD-ROM Drive
SATA DVD-ROM Drive
SATA DVD+/-RW (DL/DF) LightScribe Drive
, , , , ,
Storage Drive Bay 3.5" Serial ATA Hard
Drives
Media Card Reader –
One of the following
Security
HP 16-in-1 3.5" Media Card Reader w/ PCI card
Drive Lock
Serial, Parallel, USB Enable/Disable (via BIOS)
Removable Media Write/Boot Control
Power-On Password (via BIOS)
Setup Password (via BIOS)
Solenoid Hood Lock / Sensor
Intel 82566DM Gigabit Network Connection (integrated on system board)NIC
Intel PRO/1000 PT PCIe Gigabit NIC (full height bracket)
Broadcom NetXtreme Gigabit PCIe NIC (full height bracket)
Agere 2006 PCI 56K International SoftModem (full height) Modem
Agere 2006 PCI 56K International SoftModem (low profile)
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 8
QuickSpecs
Configurable Components
Graphics Integrated Intel Graphics Media Accelerator 3000
DVI ADD2 SDVO single head full-height Graphics Adapter (PCIe x16)
ATI RADEON X1300 256MB full-height PCIe Card, DVI w/TV
ATI RADEON X1600XT 256MB, full-height PCIe Card, dual DVI w/TV-out
NVIDIA Quadro NVS 280 64-MB PCI dual head VGA Card
NOTE: *Two NVIDIA Quadro NVS 280 PCI graphics cards can be installed to provide support for
four monitors.
HP Compaq dx7300 Business PC
Audio
Keyboard –
One of the following
Mouse –
One of the following
Integrated High Definition audio with Realtek 4-channel ALC262 codec (all ports are stereo)
Microphone and Headphone front ports
Microphone rear port*
Line-out and Line-In rear ports*
Multistreaming capable*
Internal Speaker
*NOTE: *Rear audio ports are re-taskable as Line-in, Line-out, or Microphone-in. External speakers
must be powered externally. Multistreaming can be enabled in the Realtek control panel to allow
independant audio streams to be sent to/from the front and rear jacks. This allows for different audio
applications to use separate audio ports on the system. For example, the front jacks could be used
with a headset for a communications application while the rear jacks are being used with external
speakers and a multimedia application.
HP PS/2 Standard Keyboard
HP USB BG1650 Keyboard
HP USB Standard Keyboard
HP USB Smartcard Keyboard
HP PS/2 2-Button Scroll Mouse
HP PS/2 2-Button Optical Scroll Mouse
HP USB 2-Button Optical Scroll Mouse
HP FireWire / IEEE 1394 PCI Card (full height)Miscellaneous
2nd serial port adapter (full height)
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 9
QuickSpecs
Market Options
After-Market Options (availability may vary by region)
Communications
Wireless
HP BT450 USB Bluetooth Wireless Printer and PC Adapter IPQ639A
NICs
Broadcom NetXtreme Gigabit Ethernet PCIe NIC Card EA833AA
Intel/PRO 1000 PT PCIe Gigabit NIC Card EH352AA
Modem
Agere 2006 PCI 56K International Modem EK694AA
HP Compaq dx7300 Business PC
After-
Part Number
Graphics
Hard Drives
Input/Output Devices
Single head solutions
Intel DVI ADD2 Graphics Adapter (PCIe x16) DY674A
ATI Radeon X1300 (256MB SH) PCIe Graphics Card AG392AA
Multi head solutions
NVIDIA Quadro NVS 280 PCI Graphics Card (DMS59 DVI Dual-head Connector
Cable)
NVIDIA Quadro NVS 285 with TurboCache Technology PCIe Graphics Card EE061AA
HP DMS59 DVI Dual-head Connector Cable (for NVIDIA Quadro NVS 280 PCI
Graphics)
Serial ATA Hard Drives
HP 80-GB SATA 3.0-Gb/s Hard Drive PY276AA
HP 160-GB SATA 3.0-Gb/s Hard Drive PY277AA
HP 250-GB SATA 3.0-Gb/s Hard Drive PY278AA
Keyboards
HP PS/2 Standard Keyboard DT527A
HP USB Standard Keyboard DT528A
Pointing Devices
HP PS/2 2-Button Scroll Mouse DD440B
HP PS/2 2-Button Optical Scroll Mouse EY703AA
HP USB 2-Button Optical Scroll Mouse DC172B
DY599A
DL139A
Memory (DIMMs)
PC2-5300 (DDR2, 667 MHz) DIMMs Non-ECC
HP 1 GB PC2-5300 (DDR2-667) DIMM PX976AA
HP 512 MB PC2-5300 (DDR2-667) DIMM PX975AA
HP 256 MB PC2-5300 (DDR2-667) DIMM PX974AA
TFTsMonitors
HP L1506 15 TFT Flat Panel Monitor – Analog only PX848AA#ABA
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 10
QuickSpecs
(use T3489AA
for 1000
HP Client Foundation Suite
EF117AA
HP Compaq dx7300 Business PC
After-Market Options (availability may vary by region)
HP L1706 17 TFT Flat Panel Monitor – Analog only PX849AA#ABA
HP L1740 17 TFT Flat Panel Display – Analog/Digital PL766AA#ABA
HP L1755 17 TFT Flat Panel Display – Analog/Digital PL777AA#ABA
HP L1906 19 TFT Flat Panel Display – Analog only PX850AA#ABA
HP L1940T 19 TFT Flat Panel Display – Analog/Digital EM869AA#ABA
HP L1955 19 TFT Flat Panel Display – Analog/Digital PD974AA#ABA
HP L2065 20 TFT Flat Panel Display – Analog/Digital EF227A4#ABA
HP LP2465 24 TFT Widescreen Flat Panel Display – Analog/Digital EF224A4#ABA
CRTs
HP s7540 17 (16.0 vis) CRT Monitor PF997AA#ABA
HP v7650 17 (16.0 vis) Flat-face CRT Monitor PF996AA#ABA
Multimedia HP USB Powered Speakers RD628AA
Optical Drives
Removable Storage
Security
DVD-ROM Drive
HP SATA DVD-ROM Drive AH047AA
Combo Drive
HP SATA CD-RW/DVD-ROM Combo Drive AH046AA
DVD+/-RW Drive
HP SATA DVD+/-RW (DL/DF) LightScribe Drive AH048AA
Drive Key Options
HP 512MB USB 2.0 Drive Key ED516AA
HP 1GB USB 2.0 Drive Key AG382AA
Diskette and Digital Drives
HP 1.44-MB External USB Diskette Drive DC141B
HP 1.44-MB Internal Diskette Drive DS710G
Multimedia
HP 16-in-1 Media Card Reader with PCI Card EM718AA
Kensington Lock PC766A
HP Business PC Security Lock PV606AA
HP USB Biometric Fingerprint Reader EM717AA
HP USB Smartcard Keyboard ED707AA
Software
HP OpenView Client Configuration Manager T3488AA
licenses)
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 11
QuickSpecs
A
for 1000+
After-Market Options (availability may vary by region)
HP Compaq dx7300 Business PC
Includes:
HP Client Manager
HP Systems Insight Manager Connector
Altiris Local Recovery Pro
Altiris Inventory Solution
Altiris Deployment Solution
HP 2nd Serial Port PA716AMiscellaneous Accessories
HP (50 Pk) 5.25" Blank Bezel Kit DC177B
HP FireWire / IEEE 1394 PCI Card PA997A
Belkin USB to Serial Adapter EM449AA
(use EF118A
licenses)
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 12
QuickSpecs
HP Compaq dx7300 Business PC
Technical Specifications
Unit Environment and Operating Conditions
General Unit Operating Guidelines
• Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit
is operated within the specified operating range.
• Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other that they are subject to each other's
re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other
foreign matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the
enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating: 50° to 95° F (10° to 35° C)*
Non-operating: -22° to 140° F(-30° to 60° C)
Relative Humidity Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude (unpressurized) Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
*NOTE: Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct
sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options
installed.
Power Supply Microtower
Power Supply 365 watt custom power supply – Active PFC
Operating Voltage Range 90 – 264 VAC
Rated Voltage Range 100 – 240 VAC
Rated Line Frequency 50/60 Hz
Operating Line Frequency Range 47 – 63 Hz
Rated Input Current 6A
System Heat Dissipation Typical 375 btu/hr
(95 kg-cal/hr)
Maximum 1916 btu/hr
(483 kg-cal/hr)
Power Supply Fan 92mm variable speed
Energy Star Compliant YES
Blue Angel Compliant
(<5w in S5 – Power Off)
FEMP Standby Power Compliant
(<2W in S5 – Power Off)**
Power Consumption in ES Mode –
Suspend to RAM (S3) (Instantly Available
PC)
YES
YES
< 3W
DA – 12583 EMEA • Version 1 • September 18, 2006 Page 13
Loading...
