QuickSpecs
HP Compaq dx2480 Microtower Business PC
Overview
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 1
HP Compaq dx2480 Microtower Business PC
HP recommends
Windows Vista®Business
1.Monitor (sold separately) 7.4 DDR2 DIMM Slots
2.2-Button Scroll Mouse 8.2 PCI 2.3 slots, 1 PCI-e x1 slot, 1 PCI-e x16 Slot
3.HP Standard Keyboard 9. 6 USB 2.0 ports, 1 serial port, 1 parallel port, 2 PS/2,
1 RJ-45, 1 VGA, 1 audio in, 1 audio out, 1 MIC
4.Front I/O – 2 USB 2.0 ports & MIC, Headset 10.300-watt max power supply
5.2 external 3.5" drive bays for optional diskette drive 11.2 external 5.25" drive bays for optional optical drives
6.2 internal 3.5" drive bays
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Overview
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 2
At A Glance
• Intel Quad Core™, Intel® Core™ 2 Duo , Intel Pentium Dual Core, Intel Celeron® -L and Intel Celeron Dual Core
Processors
• Choice of operating systems:
o Genuine Windows Vista Business 32 bit
o Genuine Windows Vista Home Basic 32 bit
o Genuine Windows Vista downgrade to XP Professional 32 bit
o Redhat Enterprise Linux
o Free DOS
• Intel G33 Express Chipset
• Intel I/O Controller Hub 9 (ICH9)
• Intel Graphics Media Accelerator 3100
• DDR2 SDRAM system memory
• 8 channel High Definition Audio
• PCI and PCI Express I/O buses
• Serial ATA controller
• USB 2.0 support
• Realtek 8111C Gigabit Ethernet controller
• Choice of hard drives and optical drives
• Protected by HP Services. Terms and conditions applicable for India only.
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Standard Features and Configurable Components
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 3
Intel Celeron Processors
Intel Celeron-Dual-Core Processor E1200 (1.6GHz/ 800MHz, 512KB)
Intel Celeron-Conroe-L 440 (2.0G/ 800MHz, 512KB)
Intel Celeron-Conroe-L 430 (1.8G/ 800MHz, 512KB)
Intel Celeron-Conroe-L 420 (1.6G/ 800MHz, 512KB)
Intel Pentium Dual Core Processors
Intel Pentium Dual-Core E2160 Processor (1.80-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core E2180 Processor (2.0-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core E2200 Processor (2.20-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core E2220Processor (2.40-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Core 2 Processors
Intel Core 2 Duo E4500 Processor (2.20-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E4600 Processor (2.40-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E4700 Processor (2.6-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E8500 Processor (3.16-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8400 Processor (3.00-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8200 Processor (2.66-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E6850 Processor (3.00-GHz, 4-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E6750 Processor (2.66-GHz, 4-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E6550 Processor (2.33-GHz, 4-MB L2 cache, 800-MHz FSB)
Intel Core 2 Quad Processors
Intel Core 2 Quad Q9550 Processor (2.83-GHz, 12-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9450 Processor (2.66-GHz, 12-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9300 Processor (2.50-GHz, 6-MB L2 cache, 1333-MHz FSB)
Processor and Speed
One of the following
* NOTE: Intel processor numbers are not a measure of performance. Processor numbers
differentiate features within each processor family, not across different processor families.
Genuine Windows Vista Business 32 bit*
Genuine Windows Vista Home Basic 32 bit*
Genuine Windows XP Professional 32 bit
Redhat Enterprise Linux
Free DOS
* Certain Windows Vista product features require advanced or additional hardware. See
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your
computer. To download the tool, visit http://www.windowsvista.com/upgradeadvisor.
Microsoft Office 2007 Basic
Microsoft Office 2007 Small Business
Microsoft Office 2007 Professional
Operating Systems
and Application
Software
(availability varies by
region)
Roxio Easy Media Creator 9.x
**
Intervideo WinDVD Player 5.x**
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Standard Features and Configurable Components
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 4
AntiVirus
**Supporting software available with certain optical drive configurations
80-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
160-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
Hard Drives
250-GB Serial ATA 3.0-Gb/s Hard Drive (7200 rpm)
512MB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 512MB)
1-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 512MB)
1-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 1GB)
2-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 1GB)
2-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 2GB)
3-GB DDR2 Sync DRAM PC2-6400 (800-MHz) (3x1GB)
4-GB DDR2 Sync DRAM PC2-6400 (800-Mhz) (2x2GB)
4-GB DDR2 Sync DRAM PC2-6400 (800-Mhz) (4x1GB)
System Memory
8-GB DDR2 Sync DRAM PC2-6400 (800-Mhz) (4x2GB)*
*8GB Memory supported only with Vista Business 64 bit or Free DOS OS
Diskette Drive
1.44 MB Diskette Drive
Media Reader
HP 16-in-1 Media Reader and additional USB 2.0 port
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
SATA CD-RW/DVD-ROM Combo Drive
Storage –
One or more of the
following (see Storage
section below)
SATA SuperMulti LightScribe DVD Writer Drive
Keyboard – One of the following
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
Mouse – One of the following
PS/2 2-Button Optical Scroll Mouse
Input Devices
USB 2-Button Optical Scroll Mouse
Realtek ALC883 High Definition audio codec
3D audio compliant with AC'97 and HD Audio compatible
Audio
Internal PC speaker (optional)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Standard Features and Configurable Components
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 5
Integrated Realtek 8111C GbE Ethernet Controller
Intel PRO Gigabit PCI-e x1 NIC Card (full height) – (optional)
Broadcom Gb PCI-e x1 NIC card – (optional)
Communication
Agere 56K PCI Modem – (optional)
Intel Graphics Media Accelerator 3100 – integrated
NVIDIA GeForce 8400 GS (256MB) Single Head PCI-e x16 – (optional)
Graphics
ATI Radeon HD 2400XT (256MB DH) PCI-e x16 – (optional)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 6
Base Unit
• Micro ATX microtower chassis, including power supply and front bezel
• Six (6) drive bays and four expansion slots
• Active type heat sink
• 92 x 92 x 25 mm chassis fan
• System board with Intel G33 Express chipset, Intel I/O Controller Hub 9 (ICH9), Realtek
RTL8111C GbE Ethernet controller, Intel GMA 3100 graphics, and Realtek High
Definition audio, (2) full-height PCI 2.3 slot, (1) PCI Express x1 slots, (1) PCI Express x16
slot, (4) DDR2 DIMM memory slots, (4) Serial ATA data connectors
• Product documentation on CD
• HP system restore DVD
• Power cord
PCI
Two (2) full-height PCI 2.3 slot on PCA
One (1) full-height PCI Express x1 slots on PCA
One (1) full-height PCI Express x16 slot on PCA (for graphic cards)
Memory
Expansion
Four (4) DDR2 SDRAM DIMM slots (8 GB maximum memory support)
Slots
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system,
all memory may not be available due to system resource requirements. Addressing memory above
4 GB requires a 64-bit operating system.
Internal
Two (2) 3.5”
Bays
External
Two (2) 5.25”
Two (2) 3.5”
EHCI high-speed USB 2.0 controller
USB Support
Two (2) front ports; Six (6) rear ports, 4 Optional USB ports
Interfaces (Legacy)
One (1) PS/2 keyboard port
One (1) PS/2 mouse port
One (1) analog VGA video port
One (1) line in; one (1) line out; one (1) mic in
One (1) RJ45 network port
Chassis Dimensions
(H x W x D)
14.37 x 7.09 (7.09 w/bezel) x 15.75 in
365 x 180 (180 w/bezel) x 400 mm
Packaged
Dimensions
(L x W x H)
23.2 x 19.6 x 10.9 in
589 x 499 x 278 mm
System Weight
26.45 lb (12 kg)
Weight &
Dimensions
Shipping Weight
30.8 lb (14.0 kg)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 7
Memory Type
PC2-6400 DDR2 SDRAM (800MHz) non-ECC
Up to 8-GB maximum system memory supported
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system,
all memory may not be available due to system resource requirements. Addressing memory above
4 GB requires a 64-bit operating system.
Technology and
Features
Hard Drive
Interfaces
Supported
Serial ATA
Front Panel
Power button
Power On LED
HDD Activity LED
Cooling Solutions
Supported
Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan (variable speed)
Slots Supported
Four (4) full-height expansion slots
Front I/O
Two (2) USB 2.0 ports
Rear I/O
Standard Micro ATX I/O connectors, including Six (6) USB 2.0 ports
Drive Bays
Two (2) 5-1/4” external
Two (2) 3-1/2” external
Two (2) 3-1/2” internal
Internal Speaker
Optional
Security
Chassis Intrusion switch
Kensington Lock Support (Optional)
Chassis
Power Supply
300-watt ATX Power Supply – non-PFC with a 230v
General Unit Operating Guidelines
• Keep the computer away from excessive moisture, direct moisture and the extremes of
heat and cold, to ensure that unit is operated within the specified operating range.
• Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the
required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other that
they are subject to each other's re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the
computer. Lint, dust and other foreign matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust
ventilation must be provided on the enclosure, and the same operating guidelines listed
above will still apply.
Operating
32° to 113° F (0° to 45° C)
Unit Environment
and Operating
Conditions
Temperature Range
Non-operating
-22° to 140° F( -30° to 60° C)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 8
Operating
10% to 90% (non-condensing at ambient)
Relative Humidity
Non-operating
5% to 95% (non-condensing at ambient)
Operating
10,000 ft (3048 m)
Maximum Altitude
(unpressurized)
Non-operating
30,000 ft (9000 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000
m) above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The
upper limit may be limited by the type and number of options installed.
Processor
Socket T; LGA775 industry standard Micro ATX form factor
Support Intel Pentium Dual Core, Core 2 Duo or Quad core, Celeron
4xx or Dual Core
PWM
ON NCP5387 – 3 Phase
Chipset
Intel G33 Express
Intel I/O Controller Hub 9 (ICH9)
Super I/O
ITE 8718F
Front Side Bus
Frequency
800/1066/1333 MHz
Memory
DDR2 SDRAM
4 DIMM slots
Clock Generator
RMT875T-605
Integrated Graphics
Intel Graphics Media Accelerator (GMA) 3100
Audio
Realtek ALC883 HD Audio compatible codec with eight channel audio
LOM
Realtek RTL8111C GbE Ethernet controller
Storage
Four Serial ATA interfaces
Expansion Slots
2 x PCI 2.3 slot
1 x PCI Express x1 slots
1 x PCI Express x16 slot
BIOS
Award Core 6
Industrial Standard
PCI 2.3 compliant
USB 2.0
Rear Side I/O Ports
1 x PS/2 Keyboard port
1 x PS/2 mouse port
6 x USB 2.0 ports
1 x RJ-45 10/100/1000 port
1 x D-sub 15 pin analog VGA port
3 x audio ports
System Board
On Board I/O
Interfaces
1 x ATX power connector
1 x +12V power connector
1 x Floppy connector
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
3 x Internal USB header
1 x header to support 2 front (Headphone/Mic) audio ports
QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 9
Board Size
Micro-ATX, PCB Size: 9.6’’ x 9.6’’ in (24.38 x 24.38 cm)
4-layer PCB with green color
Additional Features
• Bootable without keyboard, mouse or monitor
• Keyboard/mouse/USB wake up
• Support S3, S4 and S5
• ACPI status
• Hardware monitor capability
• CPU fan speed control
Hardware
Highlights
Integrated Realtek 8111C- GbE
Ethernet Controller
Features
Hardware
Highlights
PCI Express interface
Network
Interface
Intel PRO/1000 PT Gigabit PCIe
Adapter
Features
10-Mbps, 100-Mbps and 1000-Mbps
operation
Power Supply
• ATX Power Supply – Non-PFC with 230v
• 50–60 Hz rated line frequency
• 300 watt maximum rated power
• 80-mm power supply fan – variable speed for optimum acoustics
Power Conservation
‘Energy Saver‘
• APM 1.2 support
• Screen blanking
• System Idle mode
• Values are subject to change without notification and are for reference only.
• Performance of system, options, and ancillary equipment will vary depending on the
system configuration.
• Levels presented do not account for non-HP/Compaq installed hardware.
Operating
32° to 113°F (0° to 45°C) at sea level with
an altitude de-rating of 1.0°C per every
1000 ft (300 m) above sea level to a
maximum of 8000 ft (2500 m), no direct
sustained sunlight. Maximum rate of change
is 77°F/Hr (25°C/Hr). The upper limit may
be limited by the type and number of options
installed.
System
Environmental Specs
Ambient Air
Temperature
Storage
-
22° to 140°F (
-
30° to 60°C)
–
Maximum rate of change: 410°F/Hr
QuickSpecs
HP Compaq dx2480 Microtower Business PC
System Details
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 10
(210°C/Hr).
Operating
10% to 90% relative humidity (Rh), 86°F
(30°C) maximum wet bulb temperature, noncondensing
Humidity
Storage
5% to 95% relative humidity (Rh), 101.66°F
(38.7°C) maximum wet bulb temperature,
non-condensing
Operating
0 to 10,000 feet (0 to 3048 meters) – This
value may be limited by the type and number
of options installed. Maximum allowable
altitude change rate is 1,000 ft/min (304.8
m/min).
Altitude
Non-Operating
0 to 30,000 feet (0 to 9,144 meters) –
Maximum allowable altitude change rate is
1200 ft/min (365.76 m/min).
Listed are the levels of shock the product can withstand with NO
damage being incurred. The values represent peak input acceleration
during a 2 to 3 ms half-sine shock pulse, 11 ms trapezoidal shock
pulse.
Shock
Non-Operating
40G's (Half-sine Shock)
40G's (Trapezoidal Shock)
Listed are the levels of vibration the product can withstand with NO
damage being incurred. The values represent a flat random vibration
input acceleration profile across the given frequency range.
Operating
Random vibration at
5Hz@0.00025G²/Hz,
10Hz@0.01G²/Hz,
100Hz@0.01G²/Hz,
300Hz@0.00001G²/Hz
5Hz to 300Hz, (0.25G's nominal).
Vibration
Non-Operating
Random vibration at 0.008G²/Hz,
10Hz to 500Hz, (2 Grms nominal).
Listed are the declared A-WEIGHTED SOUND POWER LEVELS (LWAd)
and declared average desktop seated operator position A-WEIGHTED
SOUND PRESSURE LEVELS (LpAm) when the product is operating in a
73.4°F (23°C) ambient environment. Noise emissions were measured
in accordance with ISO 7779 (ECMA 74) and declared in accordance
with ISO 9296 (ECMA 109).
IDLE (Fixed disk drive
spinning)
LWAd = 4.3 Bels,
Desktop Average LpAm = 35 dBA
FIXED DISK (Random
write)
LWAd = 4.8 Bels,
Desktop Average LpAm = 40dBA
Acoustic Noise
CD-ROM (Sequential
Reads)
LWAd = 5.0 Bels,
Deskside Average LpAm = 42dBA
QuickSpecs
HP Compaq dx2480 Microtower Business PC
After-Market Options
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 11
NICs
Broadcom NetXtreme Gigabit Ethernet PCIe NIC Card EA833AA
Intel Pro 1000 GT PCI Gigabit NIC (FH) Card EH352AA
Modems
Communications
Agere 2006 PCI High-Speed 56K International SoftModem EK694AA
HP 80GB SATA 3.0Gb/s Hard Drive PY276AA
HP 160GB SATA 3.0Gb/s Hard Drive PY277AA
Hard Disk Drives
HP 250GB SATA 3.0Gb/s Hard Drive PY278AA
Diskette DriveRemovable Storage
Devices
HP CDC 1.44MB 3.5 Internal Floppy AH053AA
Keyboards
HP PS/2 Standard Keyboard DT527A#ABB
HP USB Standard Keyboard DT528A#ABB
Mice
HP PS/2 2-Button Optical Scroll Mouse EY703AA
Input Devices
HP USB 2-Button Optical Scroll Mouse DC172B
HP 512-MB PC2-6400 DIMM Memory AH056AA
HP 1-GB PC2-6400 DIMM Memory AH058AA
Memory
HP 2-GB PC2-6400 (DDR2 800 MHz) DIMM AH060AA
Audio
HP USB Powered Speakers RD628AA
ATI Radeon HD 2400 XT (256MB DH) PCIe x16 Graphics Card KD060AA
NVIDIA GeForce 8400 GS 256MB SH PCIe x16 Card GJ119AA
Graphics
* 1GB of system memory required. Graphics cards use part of the total system memory to enhance
graphics performance.
HP 48X/32X SATA Combo Drive (CDRW/DVD) AH046AA
HP 16X/48X SATA DVD-ROM Drive AH047AA
Optical Drives
HP 16X SATA SuperMulti LightScribe Drive GF343AA
Security
QuickSpecs
HP Compaq dx2480 Microtower Business PC
After-Market Options
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 12
CRTs
HP v7650 CRT Monitor ALL PF996AA#ACJ
HP s7540 CRT Monitor ALL PF997AA#ACJ
HP s5502 CRT Monitor ALL PQ560AA#ACJ
LCDs
HP w19 LCD Monitor EM885AA#ACJ
HP L1750 17” LCD Monitor GF904AA#ACJ
HP L1506s LCD Monitor ALL GL831AA#ACJ
HP L1908w Wide LCD Monitor GP536AA#ACJ
HP L1908wi Wide LCD Monitor GP537AA#ACJ
HP L1710 17-inch LCD Monitor ALL GS917AA#ACJ
HP L1910 19-inch LCD Monitor GS918AA#ACJ
HP w17e 17 Inch LCD Monitor GV537AA#ACJ
L1506 LCD Monitor ALL PX848AA#ACJ
HP L1706 LCD Monitor ALL PX849AA#ACJ
HP L1906 LCD Monitor ALL PX850AA#ACJ
HP LP1965 LCD Monitor ALL RA373AA#ACJ
Monitors
HP L2045w LCD Monitor ALL RB145AA#ACJ
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Memory
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 13
DDR SYNCH DRAM NON-ECC MEMORY
The Intel G33 Express chipset supports non-ECC DDR2 memory up to PC2-6400 (800-MHz). Memory upgrades are
accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible
memory configurations.
CAUTION: You must shut down the computer and disconnect the power cord before adding or removing memory
modules. Regardless of the power-on state, voltage is always supplied to the memory modules as long as the computer is
plugged in to an active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable
damage to the memory modules or system board.
HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds. For dual-channel
symmetric performance, the total amount of memory in each channel must be equal. If speeds are mixed, speed will default
to the slowest DIMM.
STANDARD MEMORY
512-MB, 1-GB or 2-GB DDR2 SYNCH DRAM
OPTIONAL MEMORY UPGRADES
Supports up to 8-GB of DDR2 SYNCH DRAM. Not all memory configurations possible are represented below.
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be
available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
Channel A Channel B
DIMM Size Slot 1 Slot 2 Slot 3 Slot 4
512-MB 512-MB
1-GB 1-GB
2-GB 2-GB
1-GB (dual-channel
symmetric)
512-MB 512-MB
2-GB (dual-channel
symmetric)
1-GB 1-GB
4-GB (dual-channel
symmetric)
1-GB 1-GB 1-GB 1-GB
4-GB (dual-channel
symmetric)
2-GB 2-GB
8-GB (dual-channel
symmetric)
2-GB 2-GB 2-GB 2-GB
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 14
Maximum Quantity
Supported
Position Supported Controller
Drive Support
Diskette Drives 1 3 SIO
Media Reader 1 4 Internal USB 2.0 port
DVD / DVD +/- RW / Combo Drives 2 1, 2 SATA
3.5” Serial ATA Hard Drives 2 5, 6 SATA
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Audio
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 15
Type
Integrated
High Definition
Stereo Codec
Yes
Sampling
Supports 44.1KHz to 96 Khz
Support 16/20/24 bit PCM format, 3D audio
Mic-In
Line-In
Audio Jacks
Line-Out
Digital: 3.3V
Power Support
Analog: 3.0 to ~5.0
V
Integrated Realtek
ALC883 Audio
Other
Meets performance requirements for audio on PC99/2001 systems
High quality differential CD input
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Communications
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 16
Controller
Realtek 8111C PCI LAN Controller
Memory
Data rates supported
10/100/1000 Mbps
Compliance
IEEE 802.3ab compliant, IEEE 802.3, 802.1Q, 802.3ab and
802.3u compliant, 802.3x flow control
Bus architecture
PCI 2.2
Data transfer mode
Bus-master DMA
Hardware
certifications
Power
requirement(LOM)
+3.3 Volt signaling.
Integrated Realtek
8111C-GR GbE
Ethernet Controller
Boot ROM support
Yes
56,000 Kbps maximum downstream data
Data Transmission
NOTE: 56 Kbps technology refers to download speeds only and
requires compatible modems at server sites. Other conditions may limit
modem speed. FCC limitations allow a maximum of 53 Kbps during
download transmissions.
Data Speeds
(Upload only)
33,600/31,200/28,800/26,400/21,600/19,200/16,800/14,400/
12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards
ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell
212A, and Bell 103
Fax Speeds
14,400/12,000/9,600/7,200/4,800/2,400/300 b/s
Fax Mode
Capabilities
ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and
Data Compression
V.44, 42bis, V.42 and MNP2-5
Power Management
ACPI; PPMI 1.1 and wake support with PME and Vaux; meets PCI 2.3
requirements and PC 2001 requirements
Upgradeability
Driver upgradeable for future enhancements
Video
Driver upgradeable for future enhancements
TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel
16550a UART-compatible interface
Other
Optional ring wakeup signal
Operating
Temperature
32° to 158° F (0° to 70° C)
Operating Humidity
20% to 90%, non-condensing
Requires a 3.3-V auxiliary power rail on PCI bus
Agere 56K PCI
Modem
Power
Uses only one PCI load (i.e., one grant/request pair), one shared IRQ,
one electrical load
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Communications
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 17
Chipset
Agere Systems SV92PL – Integrated PCI interface with 5-V tolerant
buffers and CardBus support
Dimensions (L X H)
Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8
cm) and supports high- and low-profile brackets
Connection
Single RJ-11 connector
Other Features
Digital line protection, call progress monitoring via on-board piezo
device, support for high profile and low profile brackets, PnP ID support
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950
(TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO,
DEMKO, SEMKO, CE mark
EMC
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A,
EN 61000-4-6, EN 61000-4-8
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Health
Bare PCB material compliant to 94V-0 or better (marked as such)
Other
PC 2001 compliant, PCI version 2.3, WHQL approved; ACPI compliant
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Graphics
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 18
3D/2D Controller
Microsoft DirectX® 9 based with support for Pixel Shader 2.0, 4:1
anisotropic filtering, Gaussian texture filtering, shadow maps,
volumetric textures, double-sided stencil buffers, and 4 pixel pipes.
VGA Controller
Integrated
Bus Type
PCI Express™ x16 (If an external graphics card is installed in a PCI
slot, the internal graphics can be enabled or disabled using the
system's BIOS setup utility. If an external graphics card is installed in
the PCI Express™ slot, the internal graphics cannot be enabled).
RAMDAC
Integrated, 400 MHz
Memory
Graphics memory is shared with system memory. Graphics memory
usage varies depending on the amount of system memory installed
and system load. 8 MB is pre-allocated for graphics use at system
boot time. Additional memory is allocated for graphics as needed
using Intel's Dynamic Video Memory Technology (DVMT), to provide
an optimal balance between graphics and system memory use.
System memory equal or greater than 512 MB
8 MB pre-allocated + 248 MB DVMT = max frame buffer of 256 MB
Controller Clock
Speed
400 MHz
Overlay Planes
Single overlay support with 5x3 filtering
Maximum Color
Depth
32 bits/pixel
Maximum Vertical
Refresh Rate
85 Hz at up to 1920x1440, 85 Hz at 2048x1536. Varies with
mode and configuration. See table below.
Multi-display Support
Support for one CRT via the motherboard's VGA connector. Support
for an additional DVI-D display via the optional DVI ADD2 card. Dual
independent displays and dual synchronous (Twin or Clone mode)
displays are supported.
Integrated Graphics
Media Accelerator
3100
Graphics/Video API
Support
Microsoft DirectX®9, DirectXVA®, VMR9, GDI/GDI+; OpenGL®
1.4.
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Input Devices
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 19
Keys
104 layout
Dimensions (L x W x
H)
18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5
cm)
Physical
characteristics
Weight
2 lb (0.9 kg) minimum
Operating voltage
+ 5VDC ± 5%
Power consumption
50-mA maximum (with three LEDs ON)
ESD
CE level 4, 15-kV air discharge
EMI – RFI
Conforms to FCC rules for a Class B
computing device
Electrical
MicrosoftPC 99 –
2001
Functionally compliant
Languages
38 available
Keycaps
Low-profile design
Switch actuation
55-g nominal peak force with tactile
feedback
Switch life
20 million keystrokes (using Hasco modified
tester)
Switch type
Contamination-resistant switch membrane
Key-leveling
mechanisms
For all double-wide and greater-length keys
Cable length
6 ft (1.8 m)
Microsoft PC 99 –
2001
Mechanically compliant
Mechanical
Acoustics
43-dBA maximum sound pressure level
Operating
temperature
50° to 122° F (10° to 50° C)
Non-operating
temperature
-22° to 140° F (-30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating
humidity
20% to 80% (non-condensing at ambient)
Operating shock
40 g, six surfaces
Non-operating
shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating
vibration
4-g peak acceleration
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Environmental
Drop (in box)
42 in (107 cm) on concrete, 16-drop
sequence
HP PS/2 or USB
Standard Keyboard
Approvals
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Input Devices
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 20
Ergonomic
compliance
ANSI HFS 100, ISO 9241-4, and TUVGS
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Hard Drives
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 21
Capacity
80,026,361,856 bytes
Height
1 in (2.54 cm)
Width
Media diameter: 3.5 in (8.89 cm)
Physical size: 4 in (10.2 cm)
Interface
Serial ATA (3.0 Gb/s)
Synchronous
Transfer Rate
(Maximum)
3.0 Gb/s
Buffer
8 MB
Single Track
2.0 ms
Average
11 ms
Seek Time (typical
reads, includes controller
overhead, including
settling)
Full-Stroke
21 ms
Rotational Speed
7,200 rpm
Logical Blocks
156,301,488
80 GB
Operating
Temperature
32° to 140° F (0° to 60° C)
Capacity
160,041,885,696 bytes
Height
1 in (2.54 cm)
Width
Media diameter: 3.5 in (8.89 cm)
Physical size: 4 in (10.2 cm)
Interface
Serial ATA (3.0 Gb/s)
Synchronous
Transfer Rate
(Maximum)
3.0 Gb/s
Buffer
8 MB
Single Track
2.0 ms
Average
11 ms
Seek Time (typical
reads, in
cludes controller
overhead, including
settling)
Full-Stroke
21 ms
Rotational Speed
7,200 rpm
Logical Blocks
312,581,808
160 GB
Operating
Temperature
32° to 140° F (0° to 60° C)
Capacity
250,059,350,016 bytes
Height
1 in (2.54 cm)
Width
Media diameter: 3.5 in (8.89 cm)
Physical size: 4 in (10.2 cm)
Interface
Serial ATA (3.0 Gb/s)
Serial ATA Hard
Drives (7200 rpm)
250 GB
Synchronous
3.0 Gb/s
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Hard Drives
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 22
Transfer Rate
(Maximum)
Buffer
8 MB
Single Track
2.0 ms
Average
11 ms
Seek Time (typical
reads, includes controller
overhead, including
settling)
Full-Stroke
21 ms
Rotational Speed
7,200 rpm
Logical Blocks
488,397,168
Operating
Temperature
41° to 131° F (5° to 55° C)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Optical Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 23
Height
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc capacity
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM)
Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
Dimensions (W x H x
D)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
Weight (max)
2.6 lb (1.2 kg)
DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 8X
DVD-ROM
Up to 16X
DVD-RAM
Up to 4X
CD-ROM, CD-R
Up to 48X
Read speeds
CD-RW
Up to 32X
Media Read Write
CD-ROM
Yes No
CD-R
Yes No
CD-RW
Yes No
DVD-ROM
Yes No
DVD-ROM DL
Yes No
DVD-RAM
Yes No
DVD+R
Yes No
DVD+R DL
Yes No
DVD+RW
Yes No
DVD-R
Yes No
DVD-RW
Yes No
Removable Storage
- Media
Compatibility - DVDROM
DVD-R DL
Yes No
Random
DVD: < 140 ms (typical), CD: < 125 ms
(typical)
Full Stroke
DVD: < 250 ms (seek), CD: < 210 ms (seek)
Cache Buffer
2 MB (minimum)
Access times
(typical reads, including
setting)
Data Transfer Modes
ATA PIO mode 4 (16.7 MB/s); ATA Multiword DMA mode 2 (16.7 MB/s); ATA
UltraDMA Mode 3 (44.4 MB/s -default)
Source
SATA DC power receptacle
DC Power
Requirement
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
SATA DVD-ROM
Drive
Power
DC Current
5 VDC - <1000 mA typical, < 1600 mA
maximum
12 VDC -< 600 mA typical, < 1400 mA
maximum
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Optical Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 24
Temperature
41° to 122° F (5° to 50° C)
Relative Humidity
10% to 90%
Environmental
(all conditions
non-condensing)
Maximum Wet Bulb
Temperature
86° F (30° C)
Height
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc capacity
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM)
Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
Dimensions (W x H x
D)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
Weight (max)
2.6 lb (1.2 kg)
CD-R
Up to 48X
Write speeds
CD-RW
Up to 32X
DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 8X
DVD-ROM
Up to 16X
CD-ROM, CD-R
Up to 48X
Read speeds
CD-RW
Up to 32X
Random
DVD: < 140 ms (typical), CD: < 125 ms
(typical)
Access times
(typical reads, including
setting)
Full Stroke
DVD: < 250 ms (typical), CD: < 210 ms
(typical)
Source
SATA DC power receptacle
DC Power
Requirement
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
Power
DC Current
5 VDC (<1000 mA typical, < 1600 mA
maximum)
12 VDC (< 600 mA typical, < 1400 mA
maximum)
Temperature
41° to 122° F (5° to 50° C)
Relative Humidity
10% to 90%
SATA Combo Drive
Environmental
(all conditions
non-condensing)
Maximum Wet Bulb
Temperature
86° F (30° C)
Height
5.25-inch, half-height, tray-load
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc capacity
8.5 GB DL or 4.7 GB standard
HP SATA SuperMulti
LightScribe DVD
Writer Drive
Dimensions (W x H x
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Optical Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 25
D)
Weight (max)
2.6 lb (1.2 kg)
DVD-RAM
Up to 12X
DVD+R
Up to 16X
DVD+RW
Up to 8X
DVD+R DL
Up to 8X
DVD-R DL
Up to 8X
DVD-R
Up to 16X
DVD-RW
Up to 6X
CD-R
Up to 48X
Write speeds
CD-RW
Up to 32X
DVD-RAM
Up to 12X
DVD+RW, DVD-RW,
DVD+R DL, DVD-R DL
Up to 8X
DVD-ROM DL
Up to 8X
DVD-ROM, DVD+R,
DVD-R
Up to 16X
CD-ROM, CD-R
Up to 48X
Read speeds
CD-RW
Up to 32X
Random
DVD: < 140 ms (typical), CD: < 125 ms
(typical)
Access times
(typical reads, including
setting)
Full Stroke
DVD: < 250 ms (seek), CD: < 210 ms (seek)
Source
SATA DC power receptacle
DC Power
Requirement
5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
Power
DC Current
5 VDC (< 1000 mA typical, 1600 mA
maximum)
12 VDC (< 600 mA typical, 1400 mA
maximum)
Temperature
41° to 122° F (5° to 50° C)
Relative Humidity
10% to 90%
Environmental
(all conditions
non-condensing)
Maximum Wet Bulb
Temperature
86° F (30° C)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Removable Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 26
Size
3.5 in (8.89 cm)
LED Indicators (front
panel)
Green
Read/Write Capacity
per Diskette
(high/low)
1.44 MB/720 KB
Drive Height
One-third
Drive Rotation
300 rpm
Transfer Rate
(high/low)
500/250 KB/s
Bytes/Sector
512
Sectors/Track
(high/low)
18/9
Tracks/Side
(high/low)
80/80
Track-to-Track
(high/low)
3/6 ms
Average
(high/low)
94/173 ms
Settling Time
15 ms
Access Times
Latency Average
100 ms
Cylinders (high/low)
80/80
HP 1.44-
MB Diskette
Drive
Read/Write Heads
Two
USB interface
USB 2.0 High-speed device via PCI card or pass -through via internal
USB port of system board
Advance protocol
support
• Supports hardware ECC (Error Correction Code) function
• Supports hardware CRC (Cyclic Redundancy Check) function
• Supports MS 4-bit parallel transfer mode
• Supports MS-PRO 4-bit parallel transfer mode
• Supports SD 4-bit parallel transfer mode
• Supports high-speed 50 MHz SD 4-bit card (version 1.1)
• Support high-speed 52 MHz MMC 8-bit card (version 4.x)
HP 16-in-1 Media
Card Reader
Supported media
types
• Supports CompactFlash Card Type I (CF I), CompactFlash
Card Type II (CF II),MicroDrive (MD)
• Supports 3.3V SmartMedia Card (SM), SmartMedia ROM (SM
ROM), xD-Picture Card (xD)
• Supports Secure Digital Card (SD), Secure Digital ROM Card
(SD ROM), miniSD, MultiMediaCard (MMC), Secure
MultiMediaCard (Secure MMC), ROM Type MultiMediaCard
(MMC ROM), Reduced Size MultiMediaCard (RS MMC),
MultiMediaCard 4.0 (MMC Plus), Reduced Size
MultiMediaCard 4.0 (MMC Mobile)
QuickSpecs
HP Compaq dx2480 Microtower Business PC
Technical Specifications - Removable Storage
DA – 13004 Worldwide — Version 1 — March 17, 2008 Page 27
• Support Memory Stick (MS), Memory Stick ROM (MS ROM),
MagicGate Memory Stick (MG), Memory Stick Select, Memory
Stick Duo (MS Duo), Memory Stick PRO (MS-PRO), Memory
Stick PRO Duo (MS PRO Duo)
Length (3.5")
124.7 cm
Width (3.5")
101.6 cm
Height (3.5")
25.4 cm
Length (5.25")
171.6 cm
Width (5.25")
148.9 cm
Mechanical
Height (5.25")
42.7 cm
Operational
environmental
extremes
Test Parameters/Conditions - Power applied,
unit operating on system ±5%
nominal supply voltage.
10°C 10% R.H. • 24 hours
10°C 90% R.H. • 24 hours
20°C 90% R.H. • 24 hours
30°C 90% R.H. • 24 hours
40°C 90% R.H. • 24 hours
50°C 90% R.H. • 24 hours
50°C 10% R.H. • 24 hours
Environmental
Storage
environmental
extremes
Test Parameters/Conditions
60°C @ 80% R.H. for 96 hours
-30°C @ 20% R.H. for 48 hours
No power applied
Delta °C < 1.0°C/min
Delta % R.H. < 1.5% R.H./min
Approvals
USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only
Transport Specification Rev. 1.0, Compliant Intel Front Panel I/O
Connectivity Design Guide V. 1.2
FCC, CE, BSMI, C-Tick, VCCI, MIC, cUL, TUV-T
© Copyright 2008 Hewlett-Packard Development Company, L.P.
All rights reserved.
The information contained herein is subject to change without notice.
Intel and Pentium are U.S. registered trademarks of Intel Corporation. Microsoft and Windows are U.S. registered
trademarks of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Loading...
