HP dx2400 User Manual

Download
QuickSpecs

Overview

HP Compaq dx2400 Microtower Business PC
HP recommends Windows Vista® Business
Microtower
1.
(2) external 5.25” drive bays for optional optical drives
2.
(1) external 3.5” drive bay for optional media reader or diskette drive
3.
(2) USB 2.0 ports, audio ports
4.
300-watt max power supply
5.
(4) USB 2.0 ports, (2) PS/2, (1) RJ-45, (1) VGA, (1) audio in – (1) audio out – (1) MIC
6.
7.
(2) internal 3.5” drive bays
8.
PS/2 Scroll Mouse
9.
HP Standard Keyboard
10.
Monitor (sold separately)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 1
QuickSpecs
HP Compaq dx2400 Microtower Business PC
Overview
At A Glance
Intel® Core™ 2 processors, Intel Pentium® processors, or Intel Celeron® processors Choice of operating systems:
Genuine Windows Vista Business 32 Genuine Windows Vista Home Basic 32 Genuine Windows Vista Business downgrade to Genuine Windows XP Professional installed Genuine Windows Vista Ultimate 32 (English Only)
FreeDOS Intel G33 Express Chipset Intel I/O Controller Hub 9 (ICH9R)* Intel Graphics Media Accelerator 3100 PCI and PCI Express I/O buses Serial ATA controller USB 2.0 support Realtek 8111C-GR Gigabit Ethernet controller Choice of hard drives and optical drives DDR2 SDRAM system memory Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
* RAID mode not supported
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 2
QuickSpecs

Standard Features and Configurable Components

HP Compaq dx2400 Microtower Business PC
Processor and Speed
One of the following
Intel Celeron Processors
Intel Celeron 420 Processor (1.60-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron 430 Processor (1.80-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron 440 Processor (2.00-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron Dual Core E1200 Processor (1.60-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Pentium Processors
Intel Pentium Dual Core E2140 Processor (1.60-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual Core E2160 Processor (1.80-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual Core E2200 Processor (2.20-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Core 2 Processors
Intel Core 2 Duo E4500 Processor (2.20-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E4600 Processor (2.40-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E4700 Processor (2.60-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Core 2 Duo E6550 Processor (2.33-GHz, 4-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E6750 Processor (2.66-GHz, 4-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E6850 Processor (3.00-GHz, 4-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8200 Processor (2.66-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8400 Processor (3.00-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8500 Processor (3.16-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9300 Processor (2.50-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9450 Processor (2.66-GHz, 12-MB L2 cache, 1333-MHz FSB)
NOTE:
differentiate features within each processor family, not across different processor families.
Intel processor numbers are not a measure of performance. Processor numbers
Operating Systems and Application Software
(availability varies by region)
Genuine Windows Vista Ultimate 32 (English Only) *
Genuine Windows Vista Business 32*
Genuine Windows Vista Home Basic 32*
Genuine Windows Vista Business downgrade to Genuine Windows XP Professional installed*†
Free DOS
* Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx http://www.microsoft.com/windowsvista/getready/capable.mspx
Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit:
† Windows Vista Business disk also included for future upgrade if desired. To qualify for this downgrade an end user must be a business (including governmental or educational institutions) and is expected to order annually at least 25 customer systems with the same custom image.
Microsoft Office 2007 Basic
Microsoft Office 2007 Small Business
Microsoft Office 2007 Professional
Microsoft Works 8.5
Roxio Easy Media Creator 9.x**
Intervideo WinDVD Player 5.x**
Symantec AntiVirus 10
Sun Java Runtime Environment
http://www.windowsvista.com/upgradeadvisor
and
for details. Windows Vista
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 3
QuickSpecs
Standard Features and Configurable Components
AOL Toolbar
** Supporting software available with certain optical drive configurations
HP Compaq dx2400 Microtower Business PC
Hard Drives
System Memory
Storage
One or more of the following (see Storage section below)
–
80-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
160-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
250-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
500-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
512-MB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 512MB)
1-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 1GB)
2-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 1GB)
2-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (1 x 2GB)
3-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (3 x 1GB)
4-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (4 x 1GB)
4-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (2 x 2GB)
8-GB DDR2 Synch DRAM PC2-6400 (800-MHz) Non-ECC (4 x 2GB)
NOTE:
memory may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
Diskette Drive
1.44-MB Diskette Drive
Media Reader
HP 16-in-1 Media Reader and additional USB 2.0 port
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
SATA CD-RW/DVD-ROM Combo Drive
SATA SuperMulti LightScribe DVD Writer Drive
For systems configured with more than 3 GB of memory and a 32-bit operating system, all
Input Devices
Audio
Keyboard
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
Mouse
PS/2 2-Button Optical Scroll Mouse
USB 2-Button Optical Scroll Mouse
USB 2-Button Laser Mouse
Realtek ALC888S High Definition audio codec
3D audio compliant and HD Audio compatible
Internal PC speaker
– One of the following
– One of the following
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 4
QuickSpecs
Standard Features and Configurable Components
HP Compaq dx2400 Microtower Business PC
Communication
Graphics
Miscellaneous
Integrated Realtek 8111C-GR GbE Ethernet Controller
Intel PRO/1000 PT Gigabit PCIe Controller (full height) – optional
Agere 56K PCI Modem – optional
HP Wireless A+G PCI Card (full height)
Intel Graphics Media Accelerator 3100 – integrated
NVIDIA GeForce 8400 GS (256MB) Single Head PCIe x16 – optional*
HP ADD2 SDVO PCIe x16 DVI-D Adapter – optional
ATI Radeon HD 2400XT (256MB DH) PCIe x16 – optional
* 1GB of system memory required. Graphics cards use part of the total system memory to enhance graphics performance.
HP FireWire / IEEE 1394 PCI Card (full height)
HP Serial/Parallel PCI Card (full height)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 5
QuickSpecs

System Details

HP Compaq dx2400 Microtower Business PC
Base Unit
Slots
Bays
Micro ATX microtower chassis, including power supply and front bezel Five (5) drive bays and four expansion slots Microsoft operating system CD – optional Active type heatsink 92 x 92 x 25 mm chassis fan System board with Intel G33 Express chipset, Intel I/O Controller Hub 9R (ICH9R), Realtek RTL8111C-GR GbE Ethernet controller, Intel GMA 3100 graphics, and Realtek audio, (1) full-height PCI 2.3 slot, (2) PCI Express x1 slots, (1) PCI Express x16 slot, (4) DDR2 DIMM memory slots, (4) Serial ATA data connectors Product documentation on CD HP system restore CD – optional Power cord
PCI
Memory Expansion
NOTE:
memory may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
Internal
External
For systems configured with more than 3 GB of memory and a 32-bit operating system, all
One (1) full-height PCI 2.3 slot on PCA Two (2) full-height PCI Express x1 slots on PCA One (1) full-height PCI Express x16 slot on PCA (for graphic cards)
Four (4) DDR2 SDRAM DIMM slots (8 GB maximum memory support)
Two (2) 3.5”
Two (2) 5.25” One (1) 3.5”
USB Support
Interfaces
Weight & Dimensions
(Legacy)
EHCI high-speed USB 2.0 controller
Two (2) front ports; Four (4) rear ports, Two (2) internal ports on motherboard
One (1) PS/2 keyboard port
One (1) PS/2 mouse port
One (1) analog VGA video port
One (1) line in; one (1) line out; one (1) mic in
One (1) RJ45 network port
Chassis Dimensions
(H x W x D)
Packaged Dimensions
(L x W x H)
System Weight
Shipping Weight
15.16 x 7.28 x 16.38 in. with bezel (385 x 185 x 416 mm)
14.88 x 6.50 x 16.10 in. without bezel (378 x 165 x 409 mm)
19.13 x 21.875 x 10.13 in 490 x 556 x 257 mm
22.4 lb (10.2 kg)
30.8 lb (14.0 kg)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 6
QuickSpecs
System Details
HP Compaq dx2400 Microtower Business PC
Technology and Features
Chassis
Memory Type
NOTE:
memory may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
Hard Drive Interfaces Supported
Front Panel
Cooling Solutions Supported
Slots Supported
Front I/O
Rear I/O
Drive Bays
Internal Speaker
Security
Power Supply
For systems configured with more than 3 GB of memory and a 32-bit operating system, all
PC2-6400 DDR2 SDRAM (800MHz) non-ECC Up to 8-GB maximum system memory supported
Serial ATA
Power button Power On LED HDD Activity LED
Power Supply Fan (variable speed) Active heatsink (variable speed) Chassis fan
Four (4) full-height expansion slots
Two (2) USB 2.0 ports
Standard Micro ATX I/O connectors, including four (4 ) USB 2.0 ports
Two (2) 5-1/4” external One (1) 3-1/2” external Two (2) 3-1/2” internal
Standard
Padlock loop Kensington Lock Support
300-watt ATX Power Supply – PFC/non-PFC with a 115v/230v line switch (varies by country/region)
Unit Environment and Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is operated within the specified operating range. Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow. Never restrict airflow into the computer by blocking any vents or air intakes. Do not stack computers on top of each other or place computers so near each other that they are subject to each other's re-circulated or preheated air. Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign matter can block the vents and limit the airflow. If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range
Relative Humidity
Maximum Altitude
(unpressurized)
NOTE:
Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 10,000 ft (3000 m) above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
50° to 95° F (10° to 35° C)
-22° to 140° F (-30° to 60° C)
10% to 90% (non-condensing at ambient)
5% to 95% (non-condensing at ambient)
10,000 ft (3048 m)
30,000 ft (9000 m)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 7
QuickSpecs
System Details
HP Compaq dx2400 Microtower Business PC
System Board
Processor
PWM
Chipset
Super I/O
Front Side Bus Frequency
Memory
Clock Generator
Integrated Graphics
Audio
LOM
Storage
Expansion Slots
BIOS
Industrial Standard
Rear Side I/O Ports
On Board I/O Interfaces
Board Size
Additional Features
Socket T; LGA775 industry standard Micro ATX form factor Support single Intel Core 2 Duo or Quad, Celeron 4xx or Dual Core
ON NCP5387 – 3 phase
Intel G33 Express Intel I/O Controller Hub 9 (ICH9)
ASUS F8000
800/1066/1333 MHz
DDR2 SDRAM 4 x DIMM slots
IDT CV1908PAG
Intel Graphics Media Accelerator (GMA) 3100
Realtek ALC888S HD Audio compatible codec with two channel audio 3D audio
Realtek RTL8111C-GR GbE Ethernet controller
Four Serial ATA interfaces
1 x PCI 2.3 slot 2 x PCI Express x1 slots 1 x PCI Express x16 slot
SPI EEPROM
PCI 2.3 compliant USB 2.0
1 x PS/2 keyboard port 1 x PS/2 mouse port 4 x USB 2.0 ports 1 x RJ-45 10/100/1000 port 1 x D-sub 15 pin analog VGA port 3 x audio ports
1 x ATX power connector 1 x +12V power connector 1 x Floppy connector 1 x Front panel connector, Switch, LED (ON/Flash/OFF) 2 x Fan headers for CPU, chassis, with voltage/fan speed control 1 x header to support 2 USB 2.0 ports at front side 1 x header to support 2 front (Headphone/Mic) audio ports 1 x header to support USB media reader
Micro-ATX, PCB Size: 9.6 x 9.0 in (24.38 x 22.86 cm) 4-layer PCB with green color
Bootable without keyboard, mouse or monitor Keyboard/mouse/USB wake up Support S1, S3, S4 and S5 ACPI status Hardware monitor capability CPU fan speed control
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 8
QuickSpecs
System Details
HP Compaq dx2400 Microtower Business PC
Network Interface
Wireless
Power Supply
Integrated Realtek 8111C-GR GbE Ethernet Controller
Intel PRO/1000 PT Gigabit PCIe Adapter
Wireless A+G PCI Card (full height bracket)
ATX Power Supply – Passive PFC/non-PFC with a 115v/230v line switch Passive Power Factor Correction (PFC) – with line switch set to 230V – No PFC in 115V line switch position 90 to 140VAC, or 180 to 264VAC operating voltage range 100 to 127VAC, or 200 to 240VAC rated voltage range 50-60 Hz rated line frequency 47-63 Hz operating line frequency range 300 watt maximum rated power 80-mm power supply fan – variable speed for optimum acoustics
Hardware Highlights
Features
Hardware Highlights
Features
PCIe x1 interface
10-Mbps, 100-Mbps and 1000-Mbps operation Crossover detection and auto-correction Wake-on-Lan and remote Wake-up
PCI Express interface
10-Mbps, 100-Mbps and 1000-Mbps operation
Power Conservation ‘Energy Saver‘
System Environmental Specs
APM 1.2 support Screen blanking Hard drive 'Idle' mode System Idle mode ~2 watt power consumption in ES mode – suspend to RAM (S3) (instantly available PC) Processor/Cache memory power-down (S3)
Values are subject to change without notification and are for reference only. Performance of system, options, and ancillary equipment will vary depending on the system configuration. Levels presented do not account for non-HP/Compaq installed hardware.
Ambient Air Temperature
Humidity
Altitude
Operating
Storage
Operating
Storage
Operating
50° to 95°F (10° to 35°C) at sea level with an altitude de-rating of 1.0°C per every 1000 ft (300 m) above sea level to a maximum of 8000 ft (2500 m), no direct sustained sunlight. Maximum rate of change is 77°F/Hr (25°C/Hr). The upper limit may be limited by the type and number of options installed.
-22° to 140°F (-30° to 60°C) – Maximum rate of change: 410°F/Hr (210°C/Hr).
10% to 90% relative humidity (Rh), 86°F (30°C) maximum wet bulb temperature, non­condensing
10% to 95% relative humidity (Rh), 101.66°F (38.7°C) maximum wet bulb temperature, non-condensing
0 to 10,000 feet (0 to 3048 meters) – This value may be limited by the type and number of options installed. Maximum allowable
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 9
QuickSpecs
System Details
Shock
Vibration
Acoustic Noise
HP Compaq dx2400 Microtower Business PC
altitude change rate is 1,000 ft/min (304.8 m/min).
Non-Operating
Listed are the levels of shock the product can withstand with NO damage being incurred. The values represent peak input acceleration during a 2 to 3 ms half-sine shock pulse, 11 ms trapezoidal shock pulse.
Non-Operating
Listed are the levels of vibration the product can withstand with NO damage being incurred. The values represent a flat random vibration input acceleration profile across the given frequency range.
Operating
Non-Operating
Listed are the declared A-WEIGHTED SOUND POWER LEVELS (LWAd) and declared average desktop seated operator position A­WEIGHTED SOUND PRESSURE LEVELS (LpAm) when the product is operating in a 73.4°F (23°C) ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109).
IDLE
(Fixed disk drive
spinning)
FIXED DISK
write)
CD-ROM
Reads)
(Random
(Sequential
0 to 30,000 feet (0 to 9,144 meters) – Maximum allowable altitude change rate is 1200 ft/min (365.76 m/min).
35G's (Half-sine Shock) 35G's (Trapezoidal Shock)
Random vibration at 5Hz@0.00025G2/Hz, 10Hz@0.01G2/Hz, 100Hz@0.01G2/Hz, 300Hz@0.00001G2/Hz 5Hz to 300Hz, (0.25G's nominal).
Random vibration at 0.008G²/Hz, 10Hz to 500Hz, (2 Grms nominal).
LWAd = 4.3 Bels, Desktop Average LpAm = 32 dBA
LWAd = 4.8 Bels, Desktop Average LpAm = 37dBA
LWAd = 5.0 Bels, Deskside Average LpAm = 39dBA
Service and Support
On-site Warrant business-day Global coverage another non-restricted country will remain fully covered under the original warranty and service offering. One-year onsite and labor are not available in all countries.
NOTE 1:
Other warranty variations may be offered in your region
NOTE 2:
authorized HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
NOTE 3:
qualified hardware and software. Toll-free calling and 24 x 7 support may not be available in some countries.
Terms and conditions may vary by country. Certain restrictions and exclusions apply.
On-site service may be provided pursuant to a service contract between HP and an
Technical telephone support applies only to HP-configured Compaq and third-party HP-
Note 1
Note 2
: One-year (1-1-1) limited warranty delivers one year of on-site, next
service for parts and labor and includes free telephone support
Note 2
ensures that any product purchased in one country and transferred to
Note 3
24 x 7.
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 10
QuickSpecs

After-Market Options

HP Compaq dx2400 Microtower Business PC
Communications
Hard Disk Drives
Removable Storage Devices
Input Devices
NICs
Intel PRO/1000 PT Gigabit PCIe Controller (full height)
Wireless LAN
HP Wireless A+G PCI Card (North America only)
HP Wireless A+G PCI Card (WW except North America)
Modems
Agere 2006 PCI High-Speed 56K International SoftModem
HP 500-GB SATA 3.0-Gb/s Hard Drive
HP 250-GB SATA 3.0-Gb/s Hard Drive
HP 160-GB SATA 3.0-Gb/s Hard Drive
HP 80-GB SATA 3.0-Gb/s Hard Drive
Diskette Drive
HP 1.44-MB Internal Diskette Drive
HP 1.44-MB USB Diskette Drive – External
16-in-1 Media Reader
Keyboards
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
Mice
HP USB 2-Button Laser Mouse
HP PS/2 2-Button Optical Scroll Mouse
HP USB 2-Button Optical Scroll Mouse
EH352AA
EA118AA
PZ928AA
EK694AA
PV943A
PY278AA
PY277AA
PY276AA
AG295AA
DC141B
EM718AA
DT527A
DT528A
GW405AA
EY703AA
DC172B
Memory
Audio
Graphics
Optical Drives
HP 2-GB PC2-6400 (DDR2-800 MHz) DIMM
HP 1-GB PC2-6400 (DDR2-800 MHz) DIMM
HP 512-MB PC2-6400 (DDR2-800 MHz) DIMM
HP Satellite Speakers
NVIDIA GeForce 8400 GS 256MB SH PCIe x16 Graphics Card*
ATI Radeon HD 2400 XT 256MB DH PCIe x16 Graphics Card
HP ADD2 SDVO DVI-D Adapter
* 1GB of system memory required. Graphics cards use part of the total system memory to enhance graphics performance.
HP SATA CD-RW/DVD-ROM Combo Drive
HP SATA DVD-ROM Drive
HP SATA SuperMulti LightScribe DVD Writer Drive
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
AH060AA
AH058AA
AH056AA
RD628AA
GJ119AA
KD060AA
DY674A
AH046AA
AH047AA
GF343AA
Page 11
QuickSpecs
After-Market Options
HP Compaq dx2400 Microtower Business PC
Security
Miscellaneous Accessories
Monitors*
HP Business PC Security Lock Kit
Kensington Security Lock
HP FireWire / IEEE 1394 PCI Card
CRTs
HP s7540 17” (16.0” vis) CRT Monitor
HP v7650 17” (16.0” vis) Flat-face CRT Monitor
TFTs
HP L1506 15” TFT Flat Panel Monitor – Analog only
HP L1710 17" TFT Flat Panel Monitor - Analog only
HP L1750 17" TFT Flat Panel Display - Analog/Digital
HP L1755 17" TFT Flat Panel Display - Analog/Digital
HP L1910 19" TFT Flat Panel Display - Analog only
HP L1950 19" TFT Flat Panel Display - Analog/Digital
HP L1955 19" TFT Flat Panel Display - Analog/Digital
HP L2065 20" TFT Flat Panel Display - Analog/Digital
HP LP2465 24" TFT Widescreen Flat Panel Display - Analog/Digital
GSA Monitors
HP L717g 17” GSA Flat Panel Monitor
HP L919g 19” GSA Flat Panel Monitor
Options
HP Flat Panel Speaker Bar
HP CRT Monitor Multimedia Base
*This is only representative, not an exhaustive list.
PV606AA
PC766A
PA997A
PF997AA#XXX
PF996AA#XXX
PX848AA#XXX
GS917AA#XXX
GF904AA#XXX
PL777AA#XXX
GS918AA#XXX
GG458AA#XXX
PD974AA#XXX
EF227A4#XXX
EF224A4#XXX
EE191AA#XXX
EE192AA#XXX
EE418AA
PM552AA
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 12
QuickSpecs
HP Compaq dx2400 Microtower Business PC

Memory

DDR SYNCH DRAM NON-ECC MEMORY
The Intel G33 Express chipset supports non-ECC DDR2 memory up to PC2-6400 (800-MHz). Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This chart does not represent all possible memory configurations.
CAUTION:
modules. Regardless of the power-on state, voltage is always supplied to the memory modules as long as the computer is plugged in to an active AC outlet. Adding or removing memory modules while voltage is present may cause irreparable damage to the memory modules or system board.
HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds. For dual-channel symmetric performance, the total amount of memory in each channel must be equal. If speeds are mixed, speed will default to the slowest DIMM.
STANDARD MEMORY
512-MB, 1-GB, 2-GB, or 4-GB DDR2 SYNCH DRAM
OPTIONAL MEMORY UPGRADES
Supports up to 8 GB of DDR2 SYNCH DRAM. Not all memory configurations possible are represented below.
NOTE:
available due to system resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
2-GB (dual-channel
4-GB (dual-channel
4-GB (dual-channel
8-GB (dual-channel
You must shut down the computer
For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be
DIMM Size
512-MB 512-MB
1-GB 1-GB
symmetric)
symmetric)
symmetric)
symmetric)
Slot 1 Slot 2 Slot 3 Slot 4
1-GB
1-GB 1-GB 1-GB 1-GB
2-GB
2-GB 2-GB 2-GB 2-GB
and disconnect the power cord
Channel A Channel B
before adding or removing memory
1-GB
2-GB
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 13
QuickSpecs

Storage

HP Compaq dx2400 Microtower Business PC
HP Compaq dx2400 Microtower Business PC
Drive Support
Diskette Drives
Media Reader
DVD-ROM Drives
CD-RW/Combo Drives
SuperMulti LightScribe DVD Writer Drives
3.5” Serial ATA Hard Drives
Maximum Quantity
Supported
1 3
1 3
2
2
2
2
Position Supported
1, 2
1, 2
1, 2
4,5
Controller
SIO
Internal USB 2.0 port
SATA
SATA
SATA
SATA
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 14
QuickSpecs

Technical Specifications - Audio

HP Compaq dx2400 Microtower Business PC
Integrated Realtek ALC888S Audio
Type
HD Audio compatible codec
Sampling
Audio Jacks
Power Support
Other
Integrated
Yes
Supports 48/96 KHz
Mic-In
Line-In
Line-Out / Headphone Out
Digital: 3.3V
Analog: 5V
Meets performance requirements for audio on PC99/2001 systems High-performance DACs with 97dB SNR(A-Weighting) ADCs with 90dB NR(A-Weighting)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 15
QuickSpecs

Technical Specifications - Communications

HP Compaq dx2400 Microtower Business PC
Integrated Realtek 8111C-GR GbE Ethernet Controller
Controller
Memory
Data rates supported
Compliance
Bus architecture
Data transfer mode
Hardware certifications
Power requirement
Boot ROM support
Network transfer rate
Dimensions
Management capabilities
8111C-CG
N/A
2.5GHz data rate with X1 link width
IEEE802.3, IEEE 802.3u, IEEE 802.3ab
PCIexpress 1.1
Hal/Full Duplex Operation
MS NDIS5, NDIS6, IPv4, IPv6, TCP, UDP
1000mbps (heavy traffic) max. 588.5mW 100mbps (heavy traffic) max. 322.3mW 10mbps (heavy traffic) max. 278.3mW S3 with Link 195.8mW Link Down @S0 78.1mW Link Down @S3/S5 51.7mW
EEPROM, 1Kb, 2Kb
10/100/1000Mbps over CAT.5
100/1000Mbps over CAT.3
10Mbps over CAT.3
9mm x 9mm
ACPI rev 2.0, PM rev 1.1, ASPM v1.0a
Intel PRO/1000 PT Gigabit PCIe Controller
Connector
Controller
Memory
Data rates supported
Compliance
Bus architecture
Data transfer mode
Hardware certifications
Power requirement
Boot ROM support
Network transfer rate
Environmental
Dimensions
Management capabilities
RJ-45
Intel 82572EI Gigabit Ethernet Controller
Integrated Dual 48K configurable transmit receive FIFO Buffers
10/100/1000 Mbps
IEEE 802.1P, 802,1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,
802.3x flow control
PCI Express 1.0a
Bus-master DMA
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for European Union
Aux 3.3V, 3.0 Watts in 1000base-T and 2.0 Watts in 100Base-T
Yes
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps (actual rate limited by PCI Bus)
Operating temperature
Operating humidity
6.4 x 2.6 x 0.8 in (16.3 x 6.6 x 1.9 cm)
ASF, WOL, PXE, DMI, WFM 2.0.
32° to 131°F (0° to 55° C)
85% at 131° F (55° C)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 16
QuickSpecs
Technical Specifications - Communications
HP Compaq dx2400 Microtower Business PC
HP Wireless A+G PCI
Dimensions
Weight
Controller system interface
Network standard
Frequency band
Operating Temperature
Storage temperature
Humidity
Operating voltage
Power consumption
Output power
(approximately)
Receive sensitivity
Data transfer rate
Spreading
Security
Antenna
Throughput
Certifications
Certifications for use by country
4.99 x 2.54 x 0.71 in (126.8 x 64.4 x 18.0 mm)
0.268 lb (65 g)
Atheros AR5414X chipset PCI Spec 2.2
IEEE 802.11a/b/g
5.1500 to 5.8500 GHz
2.4000 to 2.4835 GHz
2.4465 to 2.4835 GHz (Europe, Middle East, Asia and Asia Pacific – excluding Japan)
2.4000 to 2.4697 GHz (Japan)
32° to 140° F (0° to 60° C), operating
-4° to 176° F (-20° to 80° C), non-operating
10% to 85% non-condensing
5V ± 5%
Tx/Rx peak 560/250mA @ 3.3V (max.)
15 dBM ±2dB
-90dBm at 11 Mbps (typical)
Standard rates of 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 48, 54 and Super AG Mode108-Mbps
DSSS (Direct Sequence Spread Spectrum)
64(40h) bit, 128(104h) bit, WPA, IEEE802.1X, AES-OCB, AES-CCM, Microsoft PEAP,TKIP, WEP
External 5dBi antenna
108 Mbps
above router that supports 108 Mbps speed)
54 Mbps
11 Mbps
Wi-Fi certified
North America: United States, Canada
Europe: Austria, Belgium, Cyprus, Denmark, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Liechtenstein, Luxembourg, Netherlands, Norway, Portugal, Spain, Sweden, Switzerland, United Kingdom
Australia, New Zealand
(only with Belkin 54G or
200 ft (60.96 m) – Indoor
200 ft (60.96 m) – Indoor
200 ft (60.96 m) – Indoor
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 17
QuickSpecs
Technical Specifications - Communications
HP Compaq dx2400 Microtower Business PC
Agere 56K PCI Modem
Data Transmission
Data Speeds
Data Standards
Fax Speeds
Fax Mode Capabilities
Error Correction and Data Compression
Power Management
Upgradeability
Video
Other
Operating Temperature
Operating Humidity
Power
Chipset
Dimensions
Connection
Other Features
Safety
EMC
Telecom
Health
Other
(L X H)
56,000 Kbps maximum downstream data
NOTE:
requires compatible modems at server sites. Other conditions may limit modem speed. FCC limitations allow a maximum of 53 Kbps during download transmissions.
(Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/16,800/14,400/ 12,000/9,600/7,200/4,800/2,400/1,200/300
ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell 212A, and Bell 103
14,400/12,000/9,600/7,200/4,800/2,400/300 b/s
ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
V.44, 42bis, V.42 and MNP2-5
ACPI; PPMI 1.1 and wake support with PME and Vaux; meets PCI 2.3 requirements and PC 2001 requirements
Driver upgradeable for future enhancements
ITU-T V.80 video ready interface
TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel 16550a UART-compatible interface
Optional ring wakeup signal
32° to 158° F (0° to 70° C)
20% to 90%, non-condensing
Requires a 3.3-V auxiliary power rail on PCI bus
Uses only one PCI load (i.e., one grant/request pair), one shared IRQ, one electrical load
Agere Systems SV92PL – Integrated PCI interface with 5-V tolerant buffers and CardBus support
Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8 cm) and supports high- and low-profile brackets
Single RJ-11 connector
Digital line protection, call progress monitoring via on-board piezo device, support for high profile and low profile brackets, PnP ID support
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950 (TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO, DEMKO, SEMKO, CE mark
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN 61000-4-6, EN 61000-4-8
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals Not available in Korea or the Republic of South Africa.
Bare PCB material compliant to 94V-0 or better (marked as such)
PC 2001 compliant, PCI version 2.3, WHQL approved; ACPI compliant
56 Kbps technology refers to download speeds only and
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 18
QuickSpecs

Technical Specifications - Graphics

HP Compaq dx2400 Microtower Business PC
Integrated Graphics Media Accelerator 3100
Resolutions Supported
1
Modes listed are supported with a single active display. The supported mode list for multiple active displays is a subset of this list. Not all modes will support video playback and some supported modes may use software MC (motion compensation) rather than hardware MC. Not all modes will support 3D acceleration depending on the system configuration (e.g., resolution selected, size of frame buffer, number of installed memory modules, etc.).
NOTE:
1
Other resolutions and refresh rates may be selectable but are not recommended.
3D/2D Controller
VGA Controller
Bus Type
RAMDAC
Memory
Overlay Planes
Maximum Color Depth
Maximum Vertical Refresh Rate
Multi-display Support
Graphics/Video API Support
Resolution
640 x 480 800 x 600
1024 x 768 1280 x 1024 1600 x 1200 1920 x 1080 1920 x 1200 1920 x 1440 2048 x 1536
Microsoft DirectX® 9 based with support for Pixel Shader 2.0, 4:1 anisotropic filtering, Gaussian texture filtering, shadow maps, volumetric textures, double-sided stencil buffers, and 4 pixel pipes.
Integrated
PCI Express™ x16 (If an external graphics card is installed in a PCI or PCIe x1 slot, the internal graphics can be enabled or disabled using the system's BIOS setup utility. If a graphics card other than an SDVO/ADD2 card is installed in the PCI Express™ x16 slot, the internal graphics cannot be enabled).
Integrated, 350 MHz (2048x1536@75 Hz)
Graphics memory is shared with system memory. Graphics memory usage varies depending on the amount of system memory installed and system load. 8 MB is pre-allocated for graphics use at system boot time. Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an optimal balance between graphics and system memory use.
System memory equal or greater than 512 MB
8 MB pre-allocated + 248 MB DVMT = max frame buffer of 256 MB
Single overlay support with 5x3 filtering
32 bits/pixel
85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and configuration. See table below.
Support for one CRT via the motherboard's VGA connector on SFF and MT. Support for an additional display on SFF/MT can be accomplished with the addition of SDVO/ADD2 option installed in PCIe x16 slot.
Microsoft DirectX®9, DirectXVA®, VMR9, GDI/GDI+; OpenGL® 1.4.
Maximum Refresh Rate
Analog Monitor
85 85 85 85 85 85 85 85 75
(Hz)
Digital Monitor
60 60 60 60 60 60
60 N/A N/A
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 19
QuickSpecs
Technical Specifications - Graphics
HP Compaq dx2400 Microtower Business PC
NVIDIA GeForce 8400 GS (256 MB SH) PCIe x16 Graphics Controller
NVIDIA GeForce 8400 GS (256 MB SH) PCIe x16 Graphics Controller display resolutions and refresh rates
NOTE: Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.
Analog Resolution
Digital Resolution
1920 x 1200*
1920 x 1440**
2560 x 1600**
* Reduced blanking timings used when connected to a single-link DVI monitor ** Requires a dual-link DVI capable monitor
Bus type
Maximum vertical refresh rate
Display support
Display max resolution
Input/Output connectors
Board display options
Board configuration
Languages supported
Core power
640 x 480
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
1920 x 1080
1920 x 1200
1920 x 1440
2048 x 1536
640 x 480
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
PCI Express (x16 lanes)
85 Hz
Integrated 400 MHz RAMDAC
2048 x 1536 (analog), 2560 x 1600 (digital)
DVI-I (DVI port supports dual-link and HDCP) TV-out (4 pin S-video)
DVI-I + TV DVI-I supports analog CRT or flat panel or digital flat panel (using DVI-A, DVI-D or DVI-I connector) DVI-I supports analog CRT or flat panel (with VGA connector and DVI-I to VGA dongle)
TV connector is a 4-pin mini-DIN S-video connector
Specification
Graphics Chip
Core clock
Memory clock
Frame buffer
24 languages: English, Arabic, Chinese Simplified, Chinese Traditional, Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish
25 W (Max board power)
Maximum Refresh Rate
Maximum Refresh Rate
Description
NVIDIA GeForce 8400 GS
460 MHz
200 MHz
256 MB DDR2
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 20
QuickSpecs
Technical Specifications - Graphics
HP Compaq dx2400 Microtower Business PC
HP ADD2 SDVO PCIe x16 DVI-D Adapter
Models
Form Factor
DVI-D Connector
Dual Head Support
Display Devices Supported
NOTE:
VESA standards.
Color Depth
Host Interface Connector
Dot Clock
Display Modes
Resolution
Blanking
640 x 480
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
These graphics adapters offer optimal performance with any display that meets applicable
VGA
SVGA
XGA
SXGA
UXGA
HP ADD2 SDVO DVI-D Out Adapter
Low-profile card
Digital connection only
Yes, when used with the integrated VGA connector
HP L1750 HP L1950 HP L2045W HP LP1965
All modes support 8-bpp, 16-bpp, and 24-bpp color depths
Mechanically compliant with PCI-E standard Complies with the Intel ADD2 and Intel Serial Digital Video Output (SDVO) specifications
165 MHz maximum
Supports display modes that require up to 165-MHz bandwidth on the link, as shown in the following table.
60-Hz LCD
5% reduced
Yes Yes Yes Yes
Yes Yes Yes Yes
Yes Yes Yes Yes
Yes Yes
Yes Yes
60-Hz 75-Hz 85-Hz
GTF GTF GTF
No No
No No
ATI Radeon HD 2400XT (256MB DH) PCIe Graphics Card
Bus type
Maximum vertical refresh rate
Display support
Display max resolution
Board display options
Board configuration
Languages supported
Core power
Compliance standards
PCI Express (x16 lanes)
85 Hz
Integrated 400 MHz RAMDAC
2560 x 1600 digital, 2048 x 1536 analog
Supports two displays via included DMS-59 to dual VGA cable or 2 DVI monitors via optional DMS-59 to dual DVI cable kit part number: DL139A. 4-pin mini-DIN S-video connector for TV output
Specification
Graphics Chip
Core clock
Memory clock
Frame buffer
24 languages: English, Arabic, Chinese Simplified, Chinese Traditional, Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Thai, Turkish
21 W
EMC Emissions a) FCC Part 15, Subpart B – Unintentional Radiators, Class B Computing Devices for Home & Office Use b) CISPR22: 1997/EN 55022:1998 – Class B – Limits and methods of measurement of radio disturbance characteristics of
:
Description
RV610
650 MHz
500 MHz
256 MB DDR2, 128 bit wide
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 21
QuickSpecs
Technical Specifications - Graphics
ATI Radeon HD 2400XT (256MB DH) PCIe Graphics Card display resolutions and refresh rates
NOTE:
Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
Analog Resolution
640 x 480
800 x 600
1024 x 768
1280 x 768
1280 x 1024
1600 x 1024
1600 x 1200
1920 x 1080
1920 x 1200
1920 x 1440
2048 x 1536
Digital Resolution
640 x 480
800 x 600
1024 x 768
1280 x 768
1280 x 1024
1600 x 1024
1600 x 1200
1920 x 1200
HP Compaq dx2400 Microtower Business PC
Information Technology Equipment c) Canadian Standard ICES-003 is equivalent to CISPR22 d) Taiwanese Standard BSMI e) Japanese VCCI f) Australian C-Tick g) Korean (MIC) EMC Immunity CISPR 24:1997/EN 55024:1998 – Information Technology Equipment – Immunity Characteristics – Limits and Methods of Measurement.
:
Maximum Refresh Rate
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
85 Hz
75 Hz
85 Hz
75 Hz
Maximum Refresh Rate
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 22
QuickSpecs

Technical Specifications - Input Devices

HP Compaq dx2400 Microtower Business PC
HP PS/2 or USB Standard Keyboard
Physical characteristics
Electrical
Mechanical
Environmental
Approvals
Ergonomic compliance
Keys
Dimensions
Weight
Operating voltage
Power consumption
ESD
EMI – RFI
Microsoft
Languages
Keycaps
Switch actuation
Switch life
Switch type
Key-leveling mechanisms
Cable length
Microsoft PC 99 – 2001
Acoustics
Operating temperature
Non-operating temperature
Operating humidity
Non-operating humidity
Operating shock
Non-operating shock
Operating vibration
Non-operating vibration
Drop
(out of box)
Drop
(in box)
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
ANSI HFS 100, ISO 9241-4, and TUVGS
(L x W x H)
PC 99 – 2001
104, 105, 106, 107, 109 layout (depending upon country)
18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm)
2 lb (0.9 kg) minimum
+ 5VDC ± 5%
50-mA maximum (with three LEDs ON)
CE level 4, 15-kV air discharge
Conforms to FCC rules for a Class B computing device
Functionally compliant
38 available
Low-profile design
55-g nominal peak force with tactile feedback
20 million keystrokes (using Hasco modified tester)
Contamination-resistant switch membrane
For all double-wide and greater-length keys
6 ft (1.8 m)
Mechanically compliant
43-dBA maximum sound pressure level
50° to 122° F (10° to 50° C)
-22° to 140° F (-30° to 60° C)
10% to 90% (non-condensing at ambient)
20% to 80% (non-condensing at ambient)
40 g, six surfaces
80 g, six surfaces
2-g peak acceleration
4-g peak acceleration
26 in (66 cm) on carpet, six-drop sequence
42 in (107 cm) on concrete, 16-drop sequence
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 23
QuickSpecs
Technical Specifications - Input Devices
HP Compaq dx2400 Microtower Business PC
HP USB 2-Button Laser Mouse
Scroll Wheel
Maximum Rotation Speed
Switch Type
Switch Life
Environmental
Electrical
Mechanical
Regulatory Approvals
24
48 rats/sec
wheel
Button – 3,000,000 Wheel – 1,000,000 times Tilt switch – 500,000 times
Operating Temperature
Non-operating Temperature
Operating Humidity
Non-operating Humidity
Operating Shock
Non-operating Shock
Operating Vibration
Non-operating Vibration
Operating Voltage
Power Consumption
MTBF
ESD
EMI-RFI
PC98
Resolution
Tracking Speed
Acceleration
Switch Actuation
Switch Life
Cable Length
PC98-99
UL60950-1, UL 94, UL 746 (A-E), UL 796 TUV/GS: EN 60950-1, EN 60825-1 FCC Class B, UL 1950, cUL, TUV GS, CE, C-tick, VCCI, BSMI, RRL
32° to 104° F (0° to 40° C)
-4° to 140° F (-20° to 60° C)
10% to 90% (non-condensing at ambient)
20% to 80% (non-condensing at ambient)
40 g, six surfaces
80 g, six surfaces
2-g peak acceleration
4-g peak acceleration
+ 5VDC ± 5%
> 150,000 hrs
IEC-61000-4-2 criteria B, Contact discharge: +/- 4kV, Air discharge: +/- 8kV
FCC Class B
PC 99 Compliant
800dpi
25 cm/sec
0.5mm
0.6N (60gf)
Button – 3,000,000 Wheel – 1,000,000 times Tilt switch – 500,000 times
1850mm
PC99 compliant
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 24
QuickSpecs
Technical Specifications - Input Devices
HP Compaq dx2400 Microtower Business PC
HP PS/2 Optical Scroll Mouse
Dimensions
Weight
Environmental
Electrical
Mechanical
Scroll wheel
Regulatory approvals
(H x L x W)
3.95 x 6.21 x 11.7 cm (1.56 x 2.44 x 4.61 in)
4.44 oz (126 g)
Operating temperature
Non-operating temperature
Operating humidity
Non-operating humidity
Operating shock
Non-operating shock
Operating vibration
Non-operating vibration
Drop
(out of box)
Operating voltage
Power consumption
System consumption
ESD
EMI-RFI
Microsoft PC99 – 2001
Resolution
Tracking speed
Acceleration
Switch actuation
Switch life
Switch type
Tracking mechanism life
Cable length
Microsoft PC99 – 2001
Width
Diameter
Maximum rotation speed
Switch type
Switch life
Mechanical life
Compliant
-32° to 104°F (0° to 40° C)
-4° to 140°F ( -20° to 60° C)
10% to 90% (non condensing at ambient)
10% to 90% non condensing
40 g, 6 surfaces
80 g, 6 surfaces
2 g peak acceleration
4 g peak acceleration
80 cm height onto asphalt tile over concrete or equivalent, 5-drop in 5 direction except the cable face
5 VDC ± 10%
100mA
PS/2 mini-din connector
CE level 4, 15 kV air discharge
Conforms to FCC rules for a Class B computing device
Functionally compliant
400 ± 20% DPI
10 in/s (25.4 cm/s) maximum
100 in/s/s (2.54 m/s/s)
61 g nominal peak force
3,000,000 operations (using Hasco modified tester)
Low force micro-switches
155 mi (250 km) at average speed of 10 in/s
6 ft (1.8 m)
Mechanically compliant
8 mm
1.01 in (25.6 mm)
48 rats/sec
Light force micro-switch
1 million operations
Minimum 200,000 revolutions
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
HP USB Optical Scroll Mouse
Dimensions
Weight
Cable length
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
(H x L x W)
1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm)
0.27 lb (0.12 kg)
72.8 in (185 cm)
Page 25
QuickSpecs

Technical Specifications - Hard Drives

HP Compaq dx2400 Microtower Business PC
Serial ATA Hard Drives
(7200 rpm)
80 GB
160 GB
250 GB
Capacity
Height
Width
Interface
Synchronous Transfer Rate
(Maximum)
Buffer
Seek Time
reads, includes controller overhead, including settling)
Rotational Speed
Logical Blocks
Operating Temperature
Capacity
Height
Width
Interface
Synchronous Transfer Rate
Buffer
Seek Time
reads, includes controller overhead, including settling)
Rotational Speed
Logical Blocks
Operating Temperature
Capacity
Height
Width
Interface
Synchronous Transfer Rate
Buffer
Seek Time
reads, includes controller overhead, including settling)
Rotational Speed
Logical Blocks
Operating Temperature
(typical
(Maximum)
(typical
(Maximum)
(typical
80,026,361,856 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.9 cm) Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
3.0 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
156,301,488
32° to 140° F (0° to 60° C)
160,041,885,696 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
3.0 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
312,581,808
32° to 140° F (0° to 60° C)
250,059,350,016 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
3.0 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
488,397,168
41° to 131° F (5° to 55° C)
2.0 ms
11 ms
21 ms
2.0 ms
11 ms
21 ms
2.0 ms
11 ms
21 ms
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 26
QuickSpecs
Technical Specifications - Hard Drives
HP Compaq dx2400 Microtower Business PC
500 GB
Capacity
Height
Width
Interface
Synchronous Transfer Rate
(Maximum)
Buffer
Seek Time
reads, includes controller overhead, including settling)
Rotational Speed
Logical Blocks
Operating Temperature
(typical
500,107,862,016 bytes
1 in (2.54 cm)
Media diameter: 3.5 in (8.89 cm) Physical size: 4 in (10.2 cm)
Serial ATA (3.0 Gb/s)
3.0 Gb/s
8 MB
Single Track
Average
Full-Stroke
7,200 rpm
976,773,168
41° to 131° F (5° to 55° C)
2.0 ms
11 ms
21 ms
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 27
QuickSpecs

Technical Specifications - Optical Storage

HP Compaq dx2400 Microtower Business PC
SATA DVD-ROM Drive
Height
Orientation
Interface type
Disc capacity
Dimensions
Weight
Read speeds
Removable Storage ­Media Compatibility ­DVD-ROM
Access times
(typical reads, including setting)
Power
Environmental (all conditions non-condensing)
(W x H x D)
(max)
5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM) Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
2.6 lb (1.2 kg)
DVD+R/-R/+RW/
-RW/+R DL /-R DL
DVD-ROM
DVD-RAM
CD-ROM, CD-R
CD-RW
Media
CD-ROM
CD-R
CD-RW
DVD-ROM
DVD-ROM DL
DVD-RAM
DVD+R
DVD+R DL
DVD+RW
DVD-R
DVD-RW
DVD-R DL
Random
Full Stroke
Cache Buffer
Data Transfer Modes
Source
DC Power Requirement
DC Current
Temperature
Relative Humidity
Maximum Wet Bulb Temperature
Up to 8X
Up to 16X
Up to 4X
Up to 48X
Up to 32X
Read
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
DVD: < 140 ms (typical), CD: < 125 ms (typical)
DVD: < 250 ms (seek), CD: < 210 ms (seek)
2 MB (minimum)
ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA mode 2 (16.7 MB/s); ATA UltraDMA Mode 3 (44.4 MB/s -default)
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p
5 VDC - <1000 mA typical, < 1600 mA maximum 12 VDC -< 600 mA typical, < 1400 mA maximum
41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)
Write
No
No
No
No
No
No
No
No
No
No
No
No
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 28
QuickSpecs
Technical Specifications - Optical Storage
HP Compaq dx2400 Microtower Business PC
SATA CD-RW/DVD­ROM Combo Drive
Height
Orientation
Interface type
Disc capacity
Dimensions
Weight
Write speeds
Read speeds
Access times
(typical reads, including setting)
Power
Environmental (all conditions non-condensing)
(W x H x D)
(max)
5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI
Single layer: Up to 4.7 GB (6 times capacity of CD-ROM) Double layer: Up to 8.5 GB (12 times capacity of CD-ROM)
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
2.6 lb (1.2 kg)
CD-R
CD-RW
DVD+R/-R/+RW/
-RW/+R DL /-R DL
DVD-ROM
CD-ROM, CD-R
CD-RW
Random
Full Stroke
Source
DC Power Requirement
DC Current
Temperature
Relative Humidity
Maximum Wet Bulb Temperature
Up to 48X
Up to 32X
Up to 8X
Up to 16X
Up to 48X
Up to 32X
DVD: < 140 ms (typical), CD: < 125 ms (typical)
DVD: < 250 ms (typical), CD: < 210 ms (typical)
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p
5 VDC - <1000 mA typical, < 1600 mA maximum 12 VDC -< 600 mA typical, < 1400 mA maximum
41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)
HP SATA SuperMulti LightScribe DVD Writer Drive
Height
Orientation
Interface type
Disc capacity
Dimensions
Weight
Write speeds
Read speeds
(W x H x D)
(max)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
5.25-inch, half-height, tray-load
Either horizontal or vertical
SATA/ATAPI
8.5 GB DL or 4.7 GB standard
5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
2.6 lb (1.2 kg)
DVD-RAM
DVD+R
DVD+RW
DVD+R DL
DVD-R DL
DVD-R
DVD-RW
CD-R
CD-RW
DVD-RAM
DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 12X
Up to 16X
Up to 8X
Up to 8X
Up to 8X
Up to 16X
Up to 6X
Up to 48X
Up to 32X
Up to 12X
Up to 8X
Page 29
QuickSpecs
Technical Specifications - Optical Storage
HP Compaq dx2400 Microtower Business PC
Access times
(typical reads, including setting)
Power
Environmental
(all conditions non-condensing)
DVD-ROM DL
DVD-ROM, DVD+R, DVD-R
CD-ROM, CD-R
CD-RW
Random
Full Stroke
Source
DC Power Requirement
DC Current
Temperature
Relative Humidity
Maximum Wet Bulb Temperature
Up to 8X
Up to 16X
Up to 48X
Up to 32X
DVD: < 140 ms (typical), CD: < 125 ms (typical)
DVD: < 250 ms (seek), CD: < 210 ms (seek)
SATA DC power receptacle
5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p
5 VDC - <1000 mA typical, < 1600 mA maximum 12 VDC -< 600 mA typical, < 1400 mA maximum
41° to 122° F (5° to 50° C)
10% to 90%
86° F (30° C)
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 30
QuickSpecs

Technical Specifications - Removable Storage

HP Compaq dx2400 Microtower Business PC
1.44-MB Diskette Drive
HP 16-in-1 Media Card Reader
Size
LED Indicators
(front panel)
Read/Write Capacity per Diskette
Drive Height
Drive Rotation
Transfer Rate
Bytes/Sector
Sectors/Track
Tracks/Side
Access Times
Cylinders
Read/Write Heads
USB interface
Advance protocol support
Supported media types
Mechanical
Environmental
(high/low)
(high/low)
(high/low)
(high/low)
(high/low)
3.5 in (8.89 cm)
Green
1.44 MB/720 KB
One-third
300 rpm
500/250 KB/s
512
18/9
80/80
Track-to-Track
(high/low)
Average
Settling Time
Latency Average
80/80
Two
USB 2.0 High-speed device via PCI card or pass -through via internal USB port of system board
Length
Width
Height
Length
Width
Height
Operational environmental extremes
(high/low)
Supports hardware ECC (Error Correction Code) function Supports hardware CRC (Cyclic Redundancy Check) function Supports MS 4-bit parallel transfer mode Supports MS-PRO 4-bit parallel transfer mode Supports SD 4-bit parallel transfer mode Supports high-speed 50 MHz SD 4-bit card (version 1.1) Support high-speed 52 MHz MMC 8-bit card (version 4.x)
Supports CompactFlash Card Type I (CF I), CompactFlash Card Type II (CF II),MicroDrive (MD) Supports 3.3V SmartMedia Card (SM), SmartMedia ROM (SM ROM), xD-Picture Card (xD) Supports Secure Digital Card (SD), Secure Digital ROM Card (SD ROM), miniSD, MultiMediaCard (MMC), Secure MultiMediaCard (Secure MMC), ROM Type MultiMediaCard (MMC ROM), Reduced Size MultiMediaCard (RS MMC), MultiMediaCard 4.0 (MMC Plus), Reduced Size MultiMediaCard 4.0 (MMC Mobile) Support Memory Stick (MS), Memory Stick ROM (MS ROM), MagicGate Memory Stick (MG), Memory Stick Select, Memory Stick Duo (MS Duo), Memory Stick PRO (MS-PRO), Memory Stick PRO Duo (MS PRO Duo)
(3.5”)
(3.5”)
(3.5”)
(5.25”)
(5.25”)
(5.25”)
3/6 ms
94/173 ms
15 ms
100 ms
124.7 cm
101.6 cm
25.4 cm
171.6 cm
148.9 cm
42.7 cm
Test Parameters/Conditions – Power applied, unit operating on system ±5% nominal supply voltage.
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 31
QuickSpecs
Technical Specifications - Removable Storage
Storage environmental extremes
Approvals
USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only Transport Specification Rev. 1.0, Compliant Intel Front Panel I/O Connectivity Design Guide V. 1.2 FCC, CE, BSMI, C-Tick, VCCI, MIC, cUL, TUV-T
HP Compaq dx2400 Microtower Business PC
10°C 10% R.H. ≥ 24 hours 10°C 90% R.H. ≥ 24 hours 20°C 90% R.H. ≥ 24 hours 30°C 90% R.H. ≥ 24 hours 40°C 90% R.H. ≥ 24 hours 50°C 90% R.H. ≥ 24 hours 50°C 10% R.H. ≥ 24 hours
Test Parameters/Conditions 60°C @ 80% R.H. for 96 hours
-30°C @ 20% R.H. for 48 hours No power applied Delta °C < 1.0°C/min Delta % R.H. < 1.5% R.H./min
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 32
QuickSpecs

Technical Specifications - Environmental Data

HP Compaq dx2400 Microtower Business PC
Eco-Label Certifications & declarations
Hewlett-Packard Corporate Environmental Information
© Copyright 2008 Hewlett-Packard Development Company, L.P.
All rights reserved.
The information contained herein is subject to change without notice.
Intel and Pentium are U.S. registered trademarks of Intel Corporation. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html
DA - 12921 Worldwide QuickSpecs — Version 6 — 5.8.2008
Page 33
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
