HP dsj-100 Datasheet

affordable

professional

hp designjet 100

personal multi-format color printer

data sheet

Expand your personal color printing capabilities to include a wide range of common and large­format media sizes—at a purchase price that’s easy on your budget. The HP Designjet 100 Printer is
a personal color multiformat printer that produces professional, high quality results for all your office
or technical needs, from proposals to oversize drawings.

versatile • save time with convenient media handling system—the standard tray is for common and custom sizes

(up to 13 by 19 inches), the separate manual feed path loads larger sizes (up to 24 inches) without
unloading the standard tray, and the rear path accommodates thick media

• print using the media that will make you successful—supports a full range of media sizes (up to 24
inches, media thickness up to 0.4 mm, and media weight up to 300 g/m

2

) and media types (such as
coated, heavyweight coated, and glossy, and CAD media types such as bright white and coated
paper for line drawings, transparencies, natural tracing paper, and vellum)

• built-in features help get the job done right—a comprehensive set of office printing features including
number of copies, zoom, and custom sizing, as well as CAD features and color options—all from one
unified printer driver

budget-friendly • low-cost option that expands your printing capability—print common sizes and larger sizes up to

24 inches from a single low-cost device

• replace only the ink supplies you need—modular, individually replaceable supplies make color
cost effective

• single printing solution—print a variety of office, CAD, and oversize documents from proposals to
drawings from only one printer

• eliminates expensive outsourcing—anyone with occasional large-format needs can economically print
documents in-house

professional results • get consistently superb photo quality for all your professional documents—using specially formulated

inks, the 1200 dpi writing system, and hp color layering technology which provides a wide gamut of
vivid colors, continuous tones, and smooth color transitions

•fast results—print at up to 11 pages per minute (ppm) for letter size in fast mode and 90 seconds per
page for 2 by 3 feet drawing in Fast Mode

• print crisp, sharp lines and text—hp technology ensures precise dot placement for excellent image and
line quality for all your professional documents

•no compromising CAD results—AutoCAD

®

drivers provide the capability to print AutoCAD files in addition
to business documents and images; through the ADI driver, users can produce complex documents with
thick, stylistic lines, a variety of line widths, line ends and joins, annotations, and raster patterns

HP printing and imaging systems help you create powerful, professional communications easily.
Printers, supplies, accessories, and services are designed together to work together and invented to
meet your business needs.

hp designjet 100

personal multi-format color printer

small footprint allows
you to place printer
on your desktop or
common work area

cancel-print button
immediately terminates
print jobs, saving ink
and saving time

LCD printer status
indicator for ink supply
maintenance and print
messages alert

modular ink
system with four
independently
replaceable ink
cartridges so you
replace only the ink
colors you need

front manual feed
handles media up
to 24 inches wide

rear manual feed designed
to support extra thick media—
up to 80 lb and 300 g/m

2

—up to 24 inches

connect via EIO slot—
USB 1.1- and USB 2.0­compliant and Centronics
parallel IEEE 1284-compliant

standard media tray
handles media up to
13 by 19 inches and
can accommodate up
to 100 sheets

the personal multi-format color solution for technical and office printing

•multipurpose printing—3 by 5 inches to 13 by 19 inches from automatic paper tray and up to 24 by 64 inches from
rear paper path

•versatile printing—printer optimized to provide excellent office and CAD output—precise dot placement ensures crisp and
sharp lines and text as well as graphic output—photo quality achieved thanks to 1200 dpi writing system and hp color
layering technology

•flexible printing—support for a full range of media sizes (up to 24 inches wide), thickness (up to 80 lb), and types: coated,
heavyweight coated, glossy, and CAD medias like bright white, transparencies, or natural tracing paper

•fast printing—11 ppm for letter size in Fast mode and 90 seconds per page for 2 by 3 feet in Fast mode

•professional results—using 1200 dpi writing system and hp color layering technology

• smart office features—including number of copies, zoom, and custom sizing as well as CAD features and color options
via one unified printer driver

•low operation cost—modular, individually replaceable supplies make color cost effective

optional accessories:

•stand and media bin for added convenience

• hp jetdirect 615n network card

• hp care pack extends standard warranty to three years

versatility you can see

With the HP Designjet 100 Printer, you get a single solution
that yields a variety of professional results. Now you can switch
from letter-size to oversize media quickly, economically, and
easily. Use the HP Designjet 100 Printer to produce crisp, clear
line drawing, dynamic presentations, and professional quality
business communications such as reports, spreadsheets,
flowcharts, and meeting agendas without outsourcing,
taping, or hassle.

Using simple yet powerful drivers, Macintosh and Microsoft

®

Windows®users from various industries can discover how the
versatility of the HP Designjet 100 Printer enhances both their
productivity and effectiveness:

•interior designers can create detailed plans and final
presentations up to 24 inches wide as well as prepare
estimates, proposals, and invoices—all from a single printer

•architecture and engineering students can create full size
projects and school papers without leaving their dorm room
or apartment

•construction companies can cost-effectively add onsite
printing capability for plans and schematics

•finance, IT, and project management professionals can
review and update team members and managers with
small-format reports or large-format diagrams from
applications like Viso or Excel

And unlike some printers that produce great text but poor
pictures or vice-versa, the HP Designjet 100 Printers have
been optimized for a wide range of everyday printing needs:

•schematics and office documents look great because the
pigmented black ink and careful dot placement mean
sharp, accurate lines and crisp, clear text

•you get professional quality images and renderings thanks
to 1200 dpi resolution, small drop sizes, and hp color
layering technology

•fast and accurate technical drawings thanks to special CAD
print modes optimized for speed and a GDI interpreter that
easily handles the intricacies of AutoCAD printing

supplies complete the solution

The HP Designjet 100 Printers and supplies employ HP Smart
Printing Technology to produce excellent, efficient printing every
time. Smart printing features control the interaction between
the printheads, ink cartridges, and print media to optimize
print quality. By using a modular ink delivery system (four
separate ink cartridges), durable printheads, and a print mode
that conserves ink, the printer also saves you time and money
by reducing user intervention, extending supply life, and
allowing you to replace only the necessary components.

This versatile printer works on a wide variety of media to
ensure that your business can quickly and easily create
powerful, effective communications. The HP Designjet 100
supports a full range of printing materials and supports media
thickness up to 0.4 mm. Look to HP supplies for a complete
selection of media choices that not only deliver the look you
need but are designed specifically to work flawlessly with your
HP printer.

award winning support from hp

To ensure you get the most out of your HP Designjet 100
printer, your purchase is backed by an entire network of
HP-authorized technical professionals and by a wide array
of support services. Start with a one-year next business day
exchange warranty backed by the award winning phone
support from HP Customer Care—features include interactive
phone support during regular business hours and professionals
who answer questions or arrange for service, and 80 percent of
all customers problems are resolved with the first phone call.

Other support benefits include 24-hour support via our website.
Simply go to www.designjet.hp.com to find a variety of helpful
solutions including driver and software downloads, online
diagnostics for interactive troubleshooting, user forums with HP users
and technical experts, and e-mail option and subscription services.

To further guarantee trouble-free operation, to maximize the
potential of your HP Designjet printer, and to customize the
printer for your unique business profile, consider upgrading
service and support options.

add high quality

multi-format color output

for an affordable price

ordering information

number description

C7796A HP Designjet 100 Printer

service and support

U3423A/E HP Care Pack, 3-year, express exchange

supplies and accessories

Q1246A Stand & Bin

Print Cartridges
C4844A HP 10 Black Ink Cartridge
C4836A HP 11 Cyan Ink Cartridge
C4837A HP 11 Magenta Ink Cartridge
C4838A HP 11 Yellow Ink Cartridge

Media
Q1970A HP Proofing Gloss, B+, 50 sheets
Q1963A HP Proofing Gloss, C, 50 sheets
Q1964A HP Proofing Gloss, D, 50 sheets
Q1967A HP Proofing Matte, B+, 100 sheets
C7884A HP Proofing Semi Gloss, B+, 50 sheets
C6039A HP Premium Photo Paper, A, 15 sheets
C6979A HP Premium Photo Paper, A, 50 sheets
C6058A HP Premium Photo Paper, B, 20 sheets
Q1961A HP Coated Paper, C, 100 sheets
Q1962A HP Coated Paper, D, 100 sheets
51634Y HP Premium Paper, A, 200 sheets
C1855A HP Premium Paper, B, 100 sheets
C1852A HP Premium Heavyweight Coated Paper, A, 100 sheets
C6955A HP Brochure and Flyer Paper, Matte, A, 50 sheets
C6817A HP Brochure and Flyer Paper, Glossy, A, 50 sheets
C6820A HP Brochure and Flyer Paper, Two-Sided, Glossy, B, 50 sheets
C7007A HP Everyday Photo Paper, Matte, A, 100 sheets
C6983A HP Everyday Photo Paper, Two-Sided, Semi Gloss, A, 25 sheets
C1824A HP Bright White Inkjet Paper, A, 500 sheets
C5976B HP Bright White Inkjet Paper, A, 250 sheets
C1857A HP Bright White Inkjet Paper, B, 200 sheets
C7028A HP Premium Plus Inkjet Transparency Film, A, 50 sheets
C7030A HP Premium Plus Inkjet Transparency Film, A, 20 sheets

network and software

J6057A HP Jetdirect 615n Fast Ethernet Internal Print Server

For more information on the HP Designjet 100 Printer, visit our website at www.hp.com
and click on products and services. Here you will find information on products, supplies, and
accessories for all your computing needs. HP printers, personal computers, supplies, and
accessories are available at authorized HP resellers worldwide.

HP PCs use genuine Windows Operating Systems
www.microsoft.com/piracy/howtotell
For more information

Product: Visit www.hp.com
Purchase: HP business solutions, products, and supplies can be purchased at your local

HP partner (www.hp.com/go/locator), or bought directly from HP at www.buy.hp.com or
800-613-2222.
Finance: HP finance plans provide all the benefits of new technology without the risk or
cost of ownership. For details, call toll-free 888-999-HPTF (4783).
Accessibility: HP is committed to providing products and services that are accessible to
people with disabilities. For more information, please visit www.hp.com/accessibility or
call 888-259-5707.

ENERGY STAR is a U.S. registered service mark of the United States Environmental Protection Agency. As an ENERGY STAR
partner, HP has determined that this product meets the guidelines for energy efficiency. Microsoft, Windows, and Windows
NT are U.S. registered trademarks of Microsoft Corporation. AutoCAD is a U.S. registered trademark of Autodesk, Inc.
Pentium is a U.S. registered trademark of Intel Corporation. All other brand and product names are trademarks or registered
trademarks of their respective companies. The information contained in this document is subject to change with or without
notice. Hewlett-Packard makes no warranty of any kind with respect to this information. Hewlett-Packard specifically disclaims
the implied warranty of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for any direct,
indirect, incidental, consequential, or other damage alleged in connection with the furnishing or use of this information.

5981-1581ENUC

© Hewlett-Packard Company 2003

drivers

PCL3GUI Windows driver, Microsoft Window drivers (95, 98, NT 4.0, 2000, Me, XP)

including support for AutoCAD

®

2000 and AutoCAD 13–14 drivers, USB and ECP

drivers. Raster driver for Mac OS (9.x, OS X v10.1, 10.2)

environmental ranges

Operating temperatures: 41 to 104° F, Recommended temperature: 59 to 86° F
Storage temperatures: -4 to 131° F
Operating humidity: 20 to 80% RH, Recommended humidity: 25 to 75% RH
Storage humidity: 20 to 80% RH

acoustics

Per ISO 9614-1
Sound pressure: 50 dB(A)
Sound pressure, Standby: 37 dB(A)
Sound power: 6.2 B(A)

power requirements

Input voltage 100 to 240 VAC auto-ranging, 50/60 Hz, 2 amp maximum

power consumption

Printing: 47.5 watts
Idle: 17.9 watts
Standby: 13.9 watts
ENERGY STAR

®

compliant

power certification

Safety certifications: CSA Certified for USA and Canada
Electromagnetic compatibility: compliant with requirements for Class B ITE products

(Class A when connected to LAN cables), USA (FCC rules) Canada (DOC)

warranty

One-year next business day exchange

Technical Specifications

HP Designjet 100 Printer

Printheads
C4810A HP 11 Black Printhead
C4811A HP 11 Cyan Printhead
C4812A HP 11 Magenta Printhead
C4813A HP 11 Yellow Printhead

HP Designjet 100

C7796A

Print Performance

Print Speed* Fast Mode

Letter size: 11 ppm

2 x 3 feet: 90 sec

* Maximum mechanical printing speed.

Maximum Resolution 1200 x 600 dpi

Print Margins Top, left, and right: 5 mm; bottom: 12 mm

Media

Handling 100-sheet input tray: 3 x 5.6 to 24.5 x 64 in (used mainly for letter, tabloid, B+); Front bypass manual single-sheet feed: 4.3 x 8.1 to 24 x 64 in

(used mainly for C, D); Single-sheet rear path for thick media: 4.3 x 8.1 to 24.6 x 64 in (for thick media up to 80 lb (300 g/m

2

)

Types Paper (plain, coated, natural tracing, two-sided brochure paper, photo, glossy, heavyweight), transparencies, vellum, translucent bond

Weig ht 17.3 to 80 lb

Media Size Letter, legal, tabloid, executive, B, C, D, B+, C+, D+, envelopes (3.0 to 24.6 inch wide sheets)

Memory 16 MB

Print

Tech nology HP Color Thermal Inkjet

Tech nology Print Resolution PhotoREt

Cartridges Black (pigment, 69 ml); cyan, yellow, magenta (dye, 28 ml)

Types Connectivity

Languages PCL3GUI RGB-24 bit contone

Operating Systems Microsoft Windows (95, 98, Me, NT 4.0, 2000, XP), Macintosh (9.1, 9.2, 10.1, 10.2)

Network Operating Systems Microsoft Windows (XP, NT 4.0 server, 2000 server, 2002 server), Novell, Mac OS (with optional HP Jetdirect print server)

Interfaces USB 1.1 (Microsoft Windows 98 second edition, Me, 2000, and XP), USB 2.0 compliant, Centronics Parallel IEEE 1284-compliant, 1 EIO slot

Recommended System Requirements

Microsoft Windows 95, 98: Pentium®I 133 MHz, 64 MB RAM, 320 MB available hard disk space; Windows NT: Pentium III 733 MHz, 128 MB RAM, 2 GB available hard disk space;

Windows 2000: Pentium III 733 MHz, 256 MB RAM, 2 GB available hard disk space; Windows XP: Pentium IV 1 GHz, 256 MB RAM, 2 GB available hard disk space;

Mac: OS 9 v9.2, X v10.1

(and higher), G4 dual processor, 1 GHz, 512 MB RAM, 1 GB available hard disk space

Dimensions (w x d x h)

Printer 41 x 15.8 x 8.7 in

Maximum 41.3 x 31.5 x 8.7 in

Shipping 46.9 x 21.5 x 18.3 in

Printer Weight

Printer 43.6 lb

Shipping 70 lb

What’s in the Box

HP Designjet 100 printer, power cord, USB cable, printheads (4), print cartridges (4), input/output tray, Macroinstaller, drivers CD,

user documentation CD, setup poster, Quick Start Guide, unpacking instructions, media flyer
