HP Compaq Presario V3501XX, Compaq Presario V3523TU, Compaq Presario V3531TU, Compaq Presario V3532TU, Compaq Presario V3533TU User Guide

...

HP Compaq Presario V3501XX, Compaq Presario V3523TU, Compaq Presario V3531TU, Compaq Presario V3532TU, Compaq Presario V3533TU, Compaq Presario V3534TU, Compaq Presario V3600 CTO, Compaq Presario V3601AU, Compaq Presario V3601TU, Compaq Presario V3601XX, Compaq Presario V3602AU, Compaq Presario V3602TU, Compaq Presario V3602XX, Compaq Presario V3603TU, Compaq Presario V3603TX, Compaq Presario V3604AU, Compaq Presario V3606TU, Compaq Presario V3607AU, Compaq Presario V3607TU, Compaq Presario V3608TU, Compaq Presario V3609AU, Compaq Presario V3609TU, Compaq Presario V3610AU, Compaq Presario V3610TU, Compaq Presario V3611TX, Compaq Presario V3612AU, Compaq Presario V3612TX, Compaq Presario V3613AU, Compaq Presario V3613TX, Compaq Presario V3614TX, Compaq Presario V3615TX, Compaq Presario V3616TX, Compaq Presario V3617LA, Compaq Presario V3618LA, Compaq Presario V3619LA, Compaq Presario V3621AU, Compaq Presario V3621TU, Compaq Presario V3622TU, Compaq Presario V3623TU, Compaq Presario V3624TU, Compaq Presario V3625TU, Compaq Presario V3632AU, Compaq Presario V3633AU, Compaq Presario V3634AU, Compaq Presario V3635AU, Compaq Presario V3636AU, Compaq Presario V3637AU, Compaq Presario V3638AU, Compaq Presario V3639AU, Compaq Presario V3640AU, Compaq Presario V3642AU, Compaq Presario V3643AU, Compaq Presario V3644AU, Compaq Presario V3645AU, Compaq Presario V3646AU, Compaq Presario V3647AU, Compaq Presario V3651AU, Compaq Presario V3652AU, Compaq Presario V3653AU, Compaq Presario V3653TU, Compaq Presario V3654TU, Compaq Presario V3655TU, Compaq Presario V3656TU, Compaq Presario V3657TU, Compaq Presario V3658TU, Compaq Presario V3659TU, Compaq Presario V3661TU, Compaq Presario V3662TU, Compaq Presario V3663TU, Compaq Presario V3664TU, Compaq Presario V3665TU, Compaq Presario V3666TU, Compaq Presario V3667TU, Compaq Presario V3668TU, Compaq Presario V3669TU, Compaq Presario V3670TU, Compaq Presario V3671TU, Compaq Presario V3672TU, Compaq Presario V3673TU, Compaq Presario V3674TU, Compaq Presario V3675TU, Compaq Presario V3676TU, Compaq Presario V3677TU, Compaq Presario V3678TU, Compaq Presario V3679TU, Compaq Presario V3680TU, Compaq Presario V3700 CTO, Compaq Presario V3701AU, Compaq Presario V3701TU, Compaq Presario V3701VU, Compaq Presario V3701XX, Compaq Presario V3702TX, Compaq Presario V3702VU, Compaq Presario V3703TU, Compaq Presario V3703TX, Compaq Presario V3703VU, Compaq Presario V3704AU, Compaq Presario V3704TU, Compaq Presario V3704VU, Compaq Presario V3705AU, Compaq Presario V3705TU, Compaq Presario V3705VU, Compaq Presario V3706AU, Compaq Presario V3706TU, Compaq Presario V3707AU, Compaq Presario V3707TU, Compaq Presario V3707TX, Compaq Presario V3708AU, Compaq Presario V3708TU, Compaq Presario V3709AU, Compaq Presario V3709TU, Compaq Presario V3710AU, Compaq Presario V3710TU, Compaq Presario V3711AU, Compaq Presario V3711TU, Compaq Presario V3712TU, Compaq Presario V3713AU, Compaq Presario V3713TU, Compaq Presario V3714AU, Compaq Presario V3714TU, Compaq Presario V3715AU, Compaq Presario V3715LA, Compaq Presario V3715TU, Compaq Presario V3716AU, Compaq Presario V3716TU, Compaq Presario V3717LA, Compaq Presario V3717TU, Compaq Presario V3718LA, Compaq Presario V3718TU, Compaq Presario V3719AU, Compaq Presario V3719TU, Compaq Presario V3720AU, Compaq Presario V3720TU, Compaq Presario V3722AU, Compaq Presario V3723AU, Compaq Presario V3723TU, Compaq Presario V3724AU, Compaq Presario V3724TU, Compaq Presario V3725TU, Compaq Presario V3726AU, Compaq Presario V3726TU, Compaq Presario V3727TU, Compaq Presario V3728TU, Compaq Presario V3729TU, Compaq Presario V3730AU, Compaq Presario V3731TU, Compaq Presario V3732TU, Compaq Presario V3733TU, Compaq Presario V3734TU, Compaq Presario V3735TU, Compaq Presario V3736AU, Compaq Presario V3737AU, Compaq Presario V3738AU, Compaq Presario V3739AU, Compaq Presario V3740AU, Compaq Presario V3741AU, Compaq Presario V3741TU, Compaq Presario V3742AU, Compaq Presario V3743AU, Compaq Presario V3744TU, Compaq Presario V3745AU, Compaq Presario V3746AU, Compaq Presario V3746TU, Compaq Presario V3747AU, Compaq Presario V3747TU, Compaq Presario V3748TU, Compaq Presario V3749TU, Compaq Presario V3750AU, Compaq Presario V3750TU, Compaq Presario V3751TU, Compaq Presario V3751XX, Compaq Presario V3752TU, Compaq Presario V3752XX, Compaq Presario V3754TU, Compaq Presario V3755AU, Compaq Presario V3755TU, Compaq Presario V3756TU, Compaq Presario V3757TU, Compaq Presario V3758TU, Compaq Presario V3761TU, Compaq Presario V3762TU, Compaq Presario V3763TU, Compaq Presario V3764TU, Compaq Presario V3766TU, Compaq Presario V3767TU, Compaq Presario V3768TU, Compaq Presario V3769TU, Compaq Presario V3770TU, Compaq Presario V3774TU, Compaq Presario V3775TU, Compaq Presario V3778TU, Compaq Presario V3779TU, Compaq Presario V3781TU, Compaq Presario V3782TU, Compaq Presario V3783TU, Compaq Presario V3785TU, Compaq Presario V3787TU, Compaq Presario V3797TU, Compaq Presario V3798TU, Compaq Presario V3799TU, Compaq Presario V3801AU, Compaq Presario V3801TU, Compaq Presario V3801TX, Compaq Presario V3801XX, Compaq Presario V3802TU, Compaq Presario V3803AU, Compaq Presario V3804TU, Compaq Presario V3804TX, Compaq Presario V3805TU, Compaq Presario V3806TU, Compaq Presario V3808TX, Compaq Presario V3809TU, Compaq Presario V3810TU, Compaq Presario V3811TU, Compaq Presario V3812TU, Compaq Presario V3813AU, Compaq Presario V3813TU, Compaq Presario V3814AU, Compaq Presario V3815AU, Compaq Presario V3817AU, Compaq Presario V3818AU, Compaq Presario V3819TU, Compaq Presario V3820AU, Compaq Presario V3820TU, Compaq Presario V3823AU, Compaq Presario V3823TU, Compaq Presario V3824AU, Compaq Presario V3824TU, Compaq Presario V3825AU, Compaq Presario V3826AU, Compaq Presario V3826TU, Compaq Presario V3827TU, Compaq Presario V3828TU, Compaq Presario V3829TU, Compaq Presario V3830TU, Compaq Presario V3831TU, Compaq Presario V3832TU, Compaq Presario V3833TU, Compaq Presario V3834TU, Compaq Presario V3835TU, Compaq Presario V3838TU, Compaq Presario V3844TU, Compaq Presario V3846TU, Compaq Presario V3847TU, Compaq Presario V3848TU, Compaq Presario V3849TU, Compaq Presario V3851XX, Compaq Presario V3853TU, Compaq Presario V3854TU, Compaq Presario V3855TU, Compaq Presario V3856TU, Compaq Presario V3857TU, Compaq Presario V3901TU, Compaq Presario V3904TU, Compaq Presario V3904TX, Compaq Presario V3906AU, Compaq Presario V3906TU, Compaq Presario V3907AU, Compaq Presario V3907TU, Compaq Presario V3908TU, Compaq Presario V3909TU, Compaq Presario V3910TX, Compaq Presario V3914TU, Compaq Presario V3916TU, Compaq Presario V3919TU, Compaq Presario V3920TU, Compaq Presario V3921TU, Compaq Presario V3922TU, Compaq Presario V3923TU, Compaq Presario V3925TU, Compaq Presario V3926TU, Compaq Presario V3927TU, Compaq Presario V3928TU, Compaq Presario V3929TU, Compaq Presario V3930TU, Compaq Presario V3931TU, Compaq Presario V3932TU User Guide

Download

Drives

User Guide

Windows is a U.S. registered trademark of Microsoft Corporation.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Second Edition: August 2007

First Edition: April 2007

Document Part Number: 439819-002

Product notice

This user guide describes features that are common to most models. Some features may not be available on your computer.

iii

iv Product notice

Table of contents

1 Identifying installed drives

2 Handling drives

3 Using an optical drive

Inserting an optical disc (CD or DVD) .................................................................................................. 4

Removing an optical disc (CD or DVD) ................................................................................................ 5

When the disc tray opens .................................................................................................... 5

When the disc tray does not open ....................................................................................... 5

4 Improving hard drive performance

Using Disk Defragmenter ..................................................................................................................... 7

Using Disk Cleanup .............................................................................................................................. 7

5 Replacing the hard drive

Index ................................................................................................................................................................... 11

1 Identifying installed drives

To view the drives installed on the computer, select Start > Computer.

NOTE: Windows® includes the User Account Control feature to improve the security of your computer.

You may be prompted for your permission or password for tasks such as installing applications, running utilities, or changing Windows settings. Refer to Windows online Help for more information.

2 Handling drives

Drives are fragile computer components that must be handled with care. Refer to the following cautions before handling drives. Additional cautions are included with the procedures to which they apply.

CAUTION: To reduce the risk of damage to the computer, damage to a drive, or loss of information,

observe these precautions:

Before you move a computer or external hard drive from one location, initiate Sleep, and allow the screen to clear.

Before handling a drive, discharge static electricity by touching the unpainted metal surface of the drive.

Do not touch the connector pins on a removable drive or on the computer.

Handle a drive carefully; do not drop a drive or place items on it.

Before removing or inserting a drive, shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on and then shut it down through the operating system.

Do not use excessive force when inserting a drive into a drive bay.

Do not type on the keyboard or move the computer while the optical drive is writing to a disc. The write process is sensitive to vibration.

When the battery is the only source of power, be sure that the battery is sufficiently charged before writing to media.

Avoid exposing a drive to temperature or humidity extremes.

Avoid exposing a drive to liquids. Do not spray the drive with cleaning products.

Remove media from a drive before removing the drive from the drive bay, or traveling with, shipping, or storing a drive.

If a drive must be mailed, place the drive in a bubble-pack mailer or other suitable protective packaging and label the package “FRAGILE.”

Avoid exposing a drive to magnetic fields. Security devices with magnetic fields include airport walkthrough devices and security wands. The airport security devices that check carry-on luggage, such as conveyor belts, use x-rays instead of magnetism and will not damage a drive.

2 Chapter 2 Handling drives

3 Using an optical drive

An optical drive, such as a DVD-ROM drive, supports optical discs (CDs and DVDs). These discs store or transport information and play music and movies. DVDs have a higher storage capacity than CDs.

Optical drives can read from and select models can write to optical media as described in the following table.

Optical drive type

DVD/CD-RW Combo Drive

DVD±RW and CD-RW Combo Drive with Double-Layer support

LightScribe DVD±RW and CD-RW Combo Drive with Double-Layer support

NOTE: Some of the optical drives listed may not be supported by your computer. The listed drives are not

necessarily all of the supported optical drives.

Read CD and DVD-ROM media

Yes Yes No No No No

Yes Yes Yes Yes No Yes

Yes Yes Yes Yes Yes Yes

Write to CDRW media

Write to DVD ±RW/R media

Write to DVD +RW DL media

Write label to LightScribe CD or DVD ±RW/R

Write to DVDRAM media

CAUTION: To prevent possible audio and video degradation, or loss of audio or video playback

functionality, do not initiate Sleep or Hibernation while reading or writing to a CD or DVD.

To prevent loss of information, do not initiate Sleep or Hibernation when writing to a CD or DVD.

If Sleep or Hibernation is initiated during playback of drive media, you may experience the following behaviors:

Your playback may be interrupted.

●

You may see a warning message asking if you want to continue. If this message is displayed, click

●

No.

You may need to restart the CD or DVD to resume audio and video playback.

●

Inserting an optical disc (CD or DVD)

1. Turn on the computer.

2. Press the release button (1) on the drive bezel to release the disc tray.

3. Pull out the tray (2).

4. Hold the disc by the edges to avoid touching the flat surfaces and position the disc label-side up

over the tray spindle.

NOTE: If the tray is not fully accessible, tilt the disc carefully to position it over the spindle.

5. Gently press the disc (3) down onto the tray spindle until the disc snaps into place.

6. Close the disc tray.

NOTE: After you insert a disc, a short pause is normal. If you have not selected a media player, an

AutoPlay dialog box opens. It prompts you to select how you want to use the media content.

4 Chapter 3 Using an optical drive

Removing an optical disc (CD or DVD)

There are 2 ways to remove a disc, depending on whether the disc tray opens normally or not.

When the disc tray opens

1. Press the release button (1) on the drive bezel to release the disc tray, and then gently pull out the

tray (2) until it stops.

2. Remove the disc (3) from the tray by gently pressing down on the spindle while lifting the outer

edges of the disc. Hold the disc by the edges and avoid touching the flat surfaces.

NOTE: If the tray is not fully accessible, tilt the disc carefully as you remove it.

3. Close the disc tray and place the disc in a protective case.

When the disc tray does not open

1. Insert the end of a paper clip (1) into the release access in the front bezel of the drive.

2. Press in gently on the paper clip until the tray is released, and then pull out the tray (2) until it stops.

Removing an optical disc (CD or DVD) 5

3. Remove the disc (3) from the tray by gently pressing down on the spindle while lifting the outer

edges of the disc. Hold the disc by the edges and avoid touching the flat surfaces.

NOTE: If the tray is not fully accessible, tilt the disc carefully as you remove it.

4. Close the disc tray and place the disc in a protective case.

6 Chapter 3 Using an optical drive

4 Improving hard drive performance

Using Disk Defragmenter

As you use the computer, files on the hard drive become fragmented. Disk Defragmenter consolidates the fragmented files and folders on the hard drive so that the system can run more efficiently.

To run Disk Defragmenter:

1. Select Start > All Programs > Accessories > System Tools > Disk Defragmenter.

2. Click Defragment now.

NOTE: Windows® includes the User Account Control feature to improve the security of your

computer. You may be prompted for your permission or password for tasks such as installing applications, running utilities, or changing Windows settings. Refer to Windows online Help for more information.

For additional information, access the Disk Defragmenter online Help.

Using Disk Cleanup

Disk Cleanup searches the hard drive for unnecessary files that you can safely delete to free up disk space and help the computer to run more efficiently.

To run Disk Cleanup:

1. Select Start > All Programs > Accessories > System Tools > Disk Cleanup.

2. Follow the on-screen instructions.

Using Disk Defragmenter 7

5 Replacing the hard drive

CAUTION: To prevent information loss or an unresponsive system:

Shut down the computer before removing the hard drive from the hard drive bay. Do not remove the hard drive while the computer is on, in the Sleep state, or in Hibernation.

If you are not sure whether the computer is off or in Hibernation, turn the computer on by pressing the power button. Then shut down the computer through the operating system.

To remove the hard drive:

1. Save your work.

2. Shut down the computer and close the display.

3. Disconnect all external devices connected to the computer.

4. Unplug the power cord from the AC outlet.

5. Turn the computer upside down on a flat surface.

6. Remove the battery from the computer.

7. With the hard drive bay toward you, loosen the 2 hard drive cover screws (1).

8. Lift the hard drive cover away from the computer (2).

9. Remove the 2 hard drive screws (1).

8 Chapter 5 Replacing the hard drive

10. Pull the hard drive tab up (2), and then lift the hard drive away from the computer.

To install a hard drive:

1. Insert the hard drive into the hard drive bay.

2. Gently press the hard drive down until it snaps into place (1).

3. Replace the 2 hard drive screws (2).

4. Align the tabs (1) on the hard drive cover with the notches on the computer.

5. Close the cover (2).

6. Tighten the hard drive cover screws (3).

10 Chapter 5 Replacing the hard drive

Index

airport security devices 2

inserting 4 removing 5

CD drive 3

Disk Cleanup software 7 Disk Defragmenter software 7 disk performance 7 drives

caring for 2 hard 8, 9 optical 3
