Table of Contents
Setting Up Your Computer ........................................................................1
Putting Your Computer Together ...............................................................................1
Placing the computer in the proper location ..........................................................1
Using surge protection .......................................................................................2
Connecting to the computer ................................................................................2
Connecting a Digital Camera (Photo or Video)...........................................................4
Connecting Other Devices .......................................................................................5
Storing Documentation and Recovery Discs................................................................6
Adjusting the Monitor..............................................................................................6
Setting Up a Local Area Network ............................................................................. 6
Setting Up a Wired (Ethernet) Connection .................................................................8
WARNING: The power supply is preset for the country/region in which you
purchased your computer. If you move, please check the voltage requirements
before plugging your computer into an AC power outlet.
WARNING: Please read “Safety Information” in the Warranty and Support Guide before installing and connecting your computer to the electrical power
system.
Putting Your Computer Together
Follow the steps on the setup poster to set up your computer. Read the topics in this section
to learn more about the location of components and connectors on your computer, and to
learn about some setup alternatives.
Look in the computer box for printed details or updates regarding your computer.
Placing the computer in the proper location
When setting up your new computer, place it where ventilation openings are unobstructed.
Make sure all connections are secure and all cabling is out of the way. Do not place
cables in walkways or where it can be stepped on or damaged from placing
furniture on it.
Setting Up Your Computer1
Using surge protection
Help protect your monitor, computer, and accessories by connecting all power cords for
your computer and peripheral devices (such as a monitor, printer, or scanner) to a surge
protection device such as a power strip with surge protection or an uninterruptible power
supply (UPS). Many surge protection devices have surge protection inputs and outputs for
modem or telephone lines. Telephone lines are a common path for lightning spikes to get
into your system. Some surge protection devices have surge protection for television cable
connections as well. Use those if your computer has a television tuner installed.
Not all power strips provide surge protection; the power strip must be specifically labeled
as having this capability. Use a power strip whose manufacturer offers a damage
replacement policy that replaces your equipment if surge protection fails.
Connecting to the computer
Connect your main hardware devices, such as the monitor, keyboard, and mouse, to the
back of the computer. Other peripheral devices, such as a printer, scanner, or camera,
also plug into connectors on the back of your computer. Some computers also have
connectors on the front of the computer. The table shows some, but not all, connectors.
NOTE:
ConnectorIcon/labelDescription and function
The location, availability, and number of connectors on your computer may vary.
Mouse (PS/2 connector)
Keyboard (PS/2 connector)
Universal Serial Bus (USB) for mouse, keyboard,
digital cameras, or other devices with USB
connectors
Printer (parallel)
2Getting Started
ConnectorIcon/labelDescription and function (continued)
Monitor
Serial port for some digital cameras or other serial
devices
Serial
Audio Line Out (powered speakers)
Audio Line In
Headphones
Microphone
FireWire
®
(IEEE 1394) for video cameras or other
devices with very fast transfer rates
Digital audio in and digital audio out
Side speaker out
Setting Up Your Computer3
ConnectorIcon/labelDescription and function (continued)
Rear speaker out
Center/subwoofer
Connecting a Digital Camera (Photo or Video)
The following instructions apply only to digital photo cameras and digital video cameras.
NOTE: When connecting an analog video camera to the computer, use the Video and
Audio In connectors on the front or back of the computer.
Refer to the documentation that came with your digital photo camera or digital video
camera.
To connect a digital photo camera or a digital video camera:
1 Turn on the computer, and wait for Microsoft
to start.
®
Windows Vista™ operating system
NOTE: If a Digital Video Device Auto Play window appears when you connect your
camera, click Cancel.
2 Connect the 6-pin video camera transfer cable into the camera and then into an open
port on the front or back of the computer. Most digital video cameras use either the
FireWire (IEEE 1394) port or the USB port.
3 A Found New Hardware message appears. Wait 2 or 3 minutes for Windows Vista to
make the necessary settings for the new device. When installation is complete, a
message appears indicating the camera is ready to use.
4Getting Started
If the computer does not recognize the digital photo camera or the digital video camera:
1 Click the Windows Start Button
Control Panel.
2 Click System and Maintenance, and then click System.
3 Click Device Manager.
4 Click the plus sign (+) next to the camera port. If the name of the camera appears, the
device is ready. If the name is not there, try the following:
Click Action, and then click Scan for hardware changes. Look in Device
Manager for a new addition under the port.
Unplug the video camera transfer cable from the computer, and plug it into a
different port. Look in Device Manager for a new addition under the port.
Connecting Other Devices
Other peripheral devices can be connected to the front or back of your computer by using
USB or FireWire (IEEE 1394) ports. These peripheral devices include printers, scanners,
video cameras, digital photo cameras, memory card readers, and PDAs (personal digital
assistant) or handheld computers. Refer to the documentation that came with your device.
NOTE: Some peripheral devices are not included with the computer.
NOTE: You must use a 6-pin (not a 4-pin) FireWire (IEEE 1394) cable with the 6-pin
FireWire (IEEE 1394) connector on your computer.
®
on the taskbar, and then click
Setting Up Your Computer5
Storing Documentation and Recovery Discs
Store all computer user manuals and warranty information in an easy-to-find, safe location.
It is a good idea to store your system recovery discs with your documentation. This allows
easy access to all important computer documents and files.
Adjusting the Monitor
To change the screen resolution:
1 Right-click an empty area of the desktop, and then click Personalize.
2 Click the Display Settings.
3 If necessary, select the monitor, and then adjust the screen resolution.
4 Click Apply.
5 Click Yes, if it is present.
6 Click OK.
NOTE: You can connect more than one display device (CRT monitor, flat panel monitor,
TV, and so on) to the computer at a time (select models only). You can quickly change
which device displays the computer desktop by pressing Alt+F5. Each time you press
Alt+F5, the computer desktop appears on the next device. If pressing Alt+F5 does not
work, restart the computer and try again.
Setting Up a Local Area Network
Your home local area network (LAN) may consist of a wired or a wireless network that you
can use to connect your computer to other devices on the network, included other
computers. The network components may include a hub or a switch, which can connect
multiple devices to the network, or a router, which can connect computers or a broadband
Internet connection to the network. This network connection also enables you to share
data, and printers or other devices among your computers. The network connection to the
Internet is usually through a dial-up or cable modem.
A wired network uses Ethernet cables to connect the devices on the network. For example,
the Ethernet cable plugs into your computer network interface adapter and the router.
A wireless network uses radio waves to connect the devices on the network. For example,
both your computer and the router have an antenna and adapter that use the same Wi-Fi
industry standard: 802.11b, 802.11g, or 802.11a.
6Getting Started
The preceding illustration shows a home LAN. The desktop computer has a wired
connection to a wireless router. The desktop computer also has a printer that it shares with
the other computers on the network. Each notebook computer has a wireless connection to
the network router.
Setting Up Your Computer7
Setting Up a Wired (Ethernet) Connection
The Ethernet connection, which may be called network interface adapter, Network
Interface Card, or NIC, provides a high-speed or broadband connection to an Ethernet
(10BaseT) or Fast Ethernet (100BaseT) network. After you connect this interface to a
network, such as a LAN, you can connect to the Internet through the network.
1 Connect an Ethernet cable to the Ethernet connector (A) on the back of the computer,
and to the network router or LAN device.
NOTE: Your computer may not come with an Ethernet connector.
A Ethernet connector (RJ-45 port)
B Ethernet indicator lights
2 With the computer turned on, check the indicator lights (B) next to the Ethernet
connector for the status:
ACTIVITY — Lit yellow during network data transfer activity
LINK — Lit green when there is a valid network connection
NOTE: Your Ethernet connector may have only one indicator light.
Integrated Wireless Devices
Wireless technology transfers data across radio waves instead of wires. Your computer
may be equipped with one or more of the following integrated wireless devices:
Wireless local area network (WLAN) devices connect the computer to
wireless local area networks (commonly referred to as wireless networks, wireless
LANs, or WLANs) in corporate offices, your home, and public areas such as airports
and restaurants. In a WLAN, each mobile wireless device communicates with a
wireless access point, which can be several hundred feet away.
Computers with WLAN devices may support one or more of the three IEEE physical
layer industry standards: 802.11b, 802.11g, or 802.11a.
Bluetooth devices create a personal area network (PAN) to connect other
Bluetooth-enabled devices such as computers, phones, printers, headsets, speakers,
and cameras. In a PAN, each device communicates directly with the other devices,
and the devices must be relatively close together — within 33 feet (10 meters) of each
other.
8Getting Started
Wireless wide area networks (WWAN) devices provide access to
information anytime and anywhere you have cellular (data) coverage. In a WWAN,
each mobile device communicates to a public carrier’s base station. Public carriers
install networks of base stations (similar to cell phone towers) throughout large
geographic areas, effectively providing coverage across entire states, or even entire
countries/regions.
For more information about wireless technology, go to:
http://www.hp.com/go/techcenter/wireless
Connecting the Wireless LAN Device
(Select models only)
You can connect the computer to an 802.11b or 802.11g wireless network by using the
external antenna that was included with your system. This device enables you to establish
a wireless network using your computer as a wireless access point, or you can use your
computer as a wireless client (Station Mode) if you already have a wireless network
running.
You need an existing wireless LAN with an Internet connection (consult your Internet
Service Provider [ISP] for further information). An external antenna is supplied with your
system; you must connect it to the 802.11 module to increase the range and sensitivity of
the radio.
To connect the wireless LAN antenna:
1 Screw the wireless LAN antenna
cable into the wireless LAN
connector on the back of
the computer.
2 For the best wireless
performance, place the antenna
on the computer or in an elevated
and open area.
NOTE: The appearance of your wireless antenna may vary.
Setting Up Your Computer9
Checking the wireless LAN device installation
To set up your wireless network, verify that the integrated WLAN device is installed on your
computer correctly.
1 Click the Windows Start Button on the taskbar.
2 Type Device Manager into the Search box, and then click Device Manager to open
the Device Manager window.
3 Click Network adapters. Your WLAN device should be listed here. The WLAN
device may include the term wireless, wireless LAN, or 802.11.
NOTE: If no WLAN device is listed, either your computer does not have an integrated
WLAN device, or the driver for the device is not properly installed.
4 Click the Windows Start Button on the taskbar.
5 Type Network and Sharing Center into the Search box, and then click Network
and Sharing Center to open the Network and Sharing Center window.
6 Click Add a device to the network and follow any onscreen instructions.
For more information about setting up a wireless network:
Click the Windows Start Button on the taskbar, click Help and Support, and
then type Setting up a wireless network into the Search Help box.
Go to: http://www.hp.com/go/techcenter/wireless
Using wireless security features
When you set up a home WLAN or access an existing public WLAN, always enable
security features to protect your network from unauthorized access. The most common
security levels are Wi-Fi Protected Access Personal (WPA-Personal) and Wired Equivalent
Privacy (WEP).
When setting up a network, you should use one or more of the following security
measures:
Enable WPA-Personal or WEP security encryption on the router.
Change the default network name (SSID) and password.
Use a firewall.
Set security on your Web browser.
For more information about setting up wireless security features, go to:
http://www.hp.com/go/techcenter/wireless
10Getting Started
Connecting a Modem
For information on connecting to the Internet, see “Connecting to the Internet” in this guide.
The modem is used for connecting to an ISP that provides a telephone dial-up connection
to the Internet.
NOTE: Your computer may not come with a modem.
Before you can use telephone dial-up to connect to the Internet and send or receive e-mail
and faxes, you must connect your telephone service line to the modem (A), which is on the
back of the computer (B). The setup poster shows you how to plug a modem/telephone
cable into the computer modem connector and into your telephone service line wall jack
connector.
A Modem connector
B Back of computer
Setting Up Your Computer11
12Getting Started
Connecting Speakers or Microphone
NOTE: For cross-references, see “Configuring Speaker and Sound Options” in your product information on the HP Support Web site: go to http://www.hp.com/support
Using Speakers
Speakers are included with the monitor (select models only) or are sold separately. For
details on connecting stereo speakers to the computer, see the setup poster.
NOTE: Speakers may be passive (no power button and no power cord) or active (power
button or power cord). Your computer supports only active (powered) speaker systems; the
speaker system must have its own power cord.
A stereo speaker set is a left-right, two-channel speaker system. A multichannel audio speaker system is a system with more than two channels, and it may include a subwoofer.
For example, 5.1 channels, referred to as a six-speaker mode, uses two front speakers
(left-right), two rear speakers (left-right), a center speaker, and a subwoofer.
If your computer has multichannel audio speaker capacity (select models only), you can
connect four channels for four-speaker output or six channels for 5.1 speaker output.
Connect your speaker system to the computer and then configure the audio software for
sound output.
Connecting Speakers or Microphone13
Sound Connector Types
Your model may include one of three analog sound connector types on the back of
your computer:
Three connectors
Six connectors
Sound card
The connectors are 1/8-inch (3.5 mm) stereo mini-jacks that connect from the back of the
computer to speakers and microphones.
Your system may also have a separate Digital Out connection (select models only).
Software configuration is different for each connector type, as noted in the instructions.
Sound ConnectorIllustrationType
Three
connectors
Six
connectors
Sound card
connector
Your computer model may include
three sound connectors. You can
connect up to a 5.1 audio system to the
computer.
Your computer model may include six
sound connectors on the back of your
computer. You can connect up to a 7.1
audio system to the computer.
Your computer may include a sound
card. You can connect up to a 5.1
audio system (7.1 audio system for
select models) or digital speakers to the
sound card on the computer.
See the following
illustration.
3
6
S
14Getting Started
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
Use the sound connectors that match your computer model when installing cables, as
shown in the installation procedure steps.
The following table shows the sound connectors on the back panel of computer systems.
Sound connector
DescriptionType 3Type 6Type S
Line Side (gray) for side speakers in an
eight-speaker system (7.1).
ALine C/Sub (gold) for center/subwoofer speakers in
a multichannel audio configuration.
BLine Rear (black) for rear speakers in a multichannel
audio configuration.
CLine Out (lime green) for front speakers.
DMic (pink) connects to microphone.
ELine In (light blue) connects to an analog audio
FDigital Out (orange) connects to a digital audio
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
(Type 3 also functions as center/subwoofer Line Out
when a multichannel audio configuration is
activated.)
device such as a CD player for input into computer.
(Type 3 also functions as rear Line Out when a
multichannel audio configuration is activated.)
device with digital input (such as a home audio
receiver/amplifier) or digital speakers
(select models only).
Connecting Speakers or Microphone15
Connecting a Microphone
Your computer comes with one microphone connector in the back of the computer. Some
models have a second microphone connector in the front of the computer. Only one
microphone connector works at a time, and the back connector is ready to use unless you
have the multichannel audio speakers option. For computers with the multichannel audio
speakers option, the microphone connector in the front of the computer, if present, is ready
to use.
To use a microphone connected to the front of your computer (select models only), select
the working microphone. See “Selecting a Microphone.”
HP computers support many different audio options, sound connections, and speaker
configurations. You may set up your computer for two stereo speakers or for multichannel
audio speaker systems. Connect your speaker system to the computer, and then configure
the audio software for sound output. For more details about connecting stereo speakers to
the computer, see the setup poster.
This chapter describes the most typical options. Your system may have different
components.
Speakers are included with the monitor (select models only) or are sold separately.
NOTE: For additional information on connecting the speakers, refer to the setup poster
that came with the computer and the documentation that came with your speakers.
Speaker Configurations
You may set up your computer for the following supported configurations:
NameSpeaker systemSee
HeadphonesNone, muted.“Using Headphones”
2 (stereo)Left speaker, right speaker.“Connecting 2/2.1 (Two Speakers and
2.1Left speaker, right speaker,
and a subwoofer.
4.1Two front speakers, two
rear speakers, and a
subwoofer.
6/5.1Two front speakers, two
rear speakers, a center
speaker, and a subwoofer.
a Subwoofer) Audio Speakers”
“Connecting 2/2.1 (Two Speakers and
a Subwoofer) Audio Speakers”
“Connecting 4.1 (Four Speakers and a
Subwoofer) Audio Speakers”
“Connecting 5.1 (Five Speakers and a
Subwoofer) Audio Speakers”
16Getting Started
NameSpeaker system See (continued)
8/7.1Two front speakers, two
rear speakers, two side
speakers, a center
speaker, and a subwoofer
(select models only).
Home audio
system
Digital audioDigital speakers or digital
Multi-streaming
audio
Home stereo or home
theater audio system with
passive speakers.
input connector on audio
system.
Two front speakers, two
rear speakers, two side
speakers, a center
speaker, and a subwoofer
(select models only).
“Connecting 7.1 (Seven Speakers and
a Subwoofer) Audio Speakers”
“Connecting the Computer to a Home
Audio System”
“Connecting Digital Audio”
“Configuring Multi-streaming Audio”
Speaker types
Speakers may be included with the monitor (select models only) or are sold separately.
Refer to the product documentation for your speakers.
Your computer supports only an active (powered) speaker system. An active speaker
system must have its own power cord. A home audio system does not require active
speakers, because the receiver provides amplification.
A stereo speaker set is a left-right, two-channel speaker system. A multichannel audio
speaker system has a left-right front and left-right rear channel, and it may include a
subwoofer and a center speaker. Side speakers are included in more advanced systems. A
subwoofer provides enhanced bass sounds.
“.1” indicates a subwoofer. For example, 7.1 channels refers to an eight-speaker mode
and uses two front speakers (left-right), two side speakers (left-right), two rear speakers
(left-right), a center speaker, and a subwoofer.
Connecting Speakers or Microphone17
Connecting 2/2.1 (Two Speakers and a Subwoofer)
Audio Speakers
To connect simple left/right stereo active speakers or two speakers and a subwoofer for
two-channel (2.1 speaker) output:
1 Turn off the computer.
2 Connect the speaker cable to the lime green Audio Line Out connector that matches
the back of your computer.
3
6
S
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
3 Connect the cable to the audio system. For 2.1 speakers that were shipped with your
computer (select models only), connect the Audio Line Out connector to the subwoofer.
4 Connect the left and right speakers to the subwoofer. Refer to the speaker
documentation.
5 Turn on the computer.
NOTE: Always turn on the computer before you turn on the speaker system.
6 Plug in the speaker system power.
7 Turn on the speaker system.
Step 8 is optional for a two-speaker setup.
8 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model. See “Connecting Speakers or Microphone.”
Type 3: See “Configuring Audio Output with Multichannel Sound Manager.”
Type 6: See “Configuring Audio Output with Sound Effect Manager.”
Sound card: See “Configuring Audio Output with a Sound Card.”
18Getting Started
The following diagram shows a typical 2.1 audio installation:
OUT
Connecting 4.1 (Four Speakers and a Subwoofer)
Audio Speakers
To connect two front speakers, two rear speakers, and a subwoofer for four-channel
(4.1 speaker) output:
1 Turn off the computer.
2 Connect the front speaker cable to the lime green Audio Line Out connector that
matches the back of your computer.
3
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
3 Connect the rear speaker cable to the black connector that matches the back of
your computer.
36
For type 3-connector systems, the blue Audio Line In connector functions as a Rear Line
Out when a multichannel audio configuration is activated.
4 Connect the cables to the audio system.
5 Connect the front and rear speakers to the subwoofer. Refer to the speaker
documentation.
6 Turn on the computer.
6
S
S
NOTE: Always turn on the computer before you turn on the speaker system.
Connecting Speakers or Microphone19
7 Plug in the speaker system power.
8 Turn on the speaker system.
9 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model. See “Configuring Speaker and Sound
Options.”
Type 3: See “Configuring Audio Output with Multichannel Sound Manager.”
Type 6: See “Configuring Audio Output with Sound Effect Manager.”
Sound card: See “Configuring Audio Output with a Sound Card.”
The following diagram shows a typical 4.1 audio installation:
OUT
IN
Connecting 5.1 (Five Speakers and a Subwoofer)
Audio Speakers
To connect two front speakers, two rear speakers, a center speaker, and a subwoofer for
six-channel (5.1 speaker) output:
1 Turn off the computer.
2 Connect the front speaker cable to the lime green Audio Line Out connector that
matches the back of your computer.
3
6
S
NOTE:
Type 3 is three connectors.
Type 6 is six connectors.
Type S is sound card.
20Getting Started
3 Connect the rear speaker cable to the black connector that matches the back of
your computer.
3
6
S
For type 3-connector systems, the blue Audio Line In connector functions as a Rear Line
Out when a multichannel audio configuration is activated.
4 Connect the center/subwoofer speaker cable to the gold (or pink Mic) connector that
matches the back of your computer.
3
6
S
For type 3-connector systems, the pink Mic connector functions as a center/subwoofer
speaker Line Out when a multichannel audio configuration is activated.
5 Connect the cables to the audio system.
6 Connect the front, rear, and center speakers to the subwoofer. Refer to the speaker
documentation.
7 Turn on the computer.
NOTE: Always turn on the computer before you turn on the speaker system.
8 Plug in the speaker system power.
9 Turn on the speaker system.
10 After the speakers are connected to the computer, configure the audio software for
sound output for your computer model. See “Configuring Speaker and Sound
Options.”
Type 3: See “Configuring Audio Output with Multichannel Sound Manager.”
Type 6: See “Configuring Audio Output with Sound Effect Manager.”
Type 6 — multi-streaming: See “Configuring Audio Output with Sound Effect
Manager.”
Sound card: See “Configuring Audio Output with a Sound Card.”
Connecting Speakers or Microphone21
The following diagram shows a typical 5.1 audio installation:
OUT
IN
Connecting 7.1 (Seven Speakers and a Subwoofer)
Audio Speakers
(Select models only)
To connect two front speakers, two side speakers, two rear speakers, a center speaker,
and a subwoofer for eight-channel (7.1 speaker) output:
1 Turn off the computer.
2 Connect the front speaker cable to the lime green Audio Line Out connector on the
back of your computer.
3 Connect the rear speaker cable to the black connector on the back of your computer.
4 For type 6 connectors only, connect the side speaker cable to the gray connector on
the back of your computer.
5 Connect the center speaker and subwoofer speaker cable to the gold connector on the
back of your computer.
22Getting Started
Loading...
+ 110 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
