1.
Memory DIMMs
6.
PCI Riser Card
2.
CPU 0
7.
PCI Options
3.
CPU 1
8.
I/O Daughter Card
4.
Hard Drive
9.
Power Supply
5.
CD-ROM (optional)
At A Glance
At A GlanceAt A Glance
At A Glance
AlphaServer DS20L 1U Systems include:
1U dual Alpha processor module with 833-MHz CPUs with 4-MB onboard cache per processor
512-MB, 1-GB or 2-GB SDRAM memory - 2-GB maximum memory capacity
Onboard IDE controller for optional internal CD-ROM drive
Onboard U160 SCSI adapter for optional internal disk drive
Onboard dual 10/100 BaseT Ethernet ports
Two 2/3-length 64-bit PCI expansion slots
One 3.5-inch x 1-inch hard disk drive bay and optional CD-ROM drive
Internal storage capacity up to 72.8 GB (SCSI)
Integral remote system management console
Two serial ports
Bi-directional enhanced parallel port
425W (200-240V) power supply with auto-ranging AC input
Tru64 UNIX Factory Installed Software with 90-day software product warranty; Linux®-Ready systems available
Protected by HP Services, including one-year, on-site hardware with next business day response.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Overview
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 1
Processor
ProcessorProcessor
Processor
Two Alpha 21264A 833-MHz processor; 4-MB onboard cache per processor
Memory
MemoryMemory
Memory
(Two Banks, Four DIMM Slots
per Bank)
Standard
512 MB, 1 GB or 2 GB
Maximum
2 GB (Two 1-GB memory kits - each kit includes four industry-standard DIMMs with ECC support)
Network Controller
Network ControllerNetwork Controller
Network Controller
Two onboard 10/100 BaseT Ethernet ports, each port connection is limited to a 25-meter cable length
Expansion Slots
Expansion SlotsExpansion Slots
Expansion Slots
PCI slots
Two 2/3 length 64-bit slots, 33 MHz – accepts PCI cards up to 8.375-inches in length
Storage bays
Two storage bays - one 3.5-inch x 1-inch hard disk drive bay and optional CD-ROM drive
Storage Controller
Storage ControllerStorage Controller
Storage Controller
Onboard IDE controller for internal optional CD-ROM drive
Onboard Ultra3 SCSI controller for internal storage, choice of optional storage controller
Storage
StorageStorage
Storage
CD-ROM
Optional
Hard Drives
18.2-GB, 36.4-GB, and 72.8-GB Ultra160 disk drives
Expansion Ports
Expansion PortsExpansion Ports
Expansion Ports
Parallel
One bi-directional enhanced port
Serial
Two serial ports: COM1 port and COM 2 port are both full-duplex asynchronous
communications ports
Form Factor
Form FactorForm Factor
Form Factor
1U Rackmount (H x W x D) 1.75 x 17 x 20 in/4.44 x 43 x 50 cm, 21 lb/9.4 kg
Power Supply
Power SupplyPower Supply
Power Supply
425W Power Supply
Supported Options
Supported OptionsSupported Options
Supported Options
A detailed summary of options supported on the AlphaServer DS20L is available at:
http://h18002.www1.hp.com/alphaserver/options/asDS20L/asDS20L_options.html
NOTE:
NOTE: NOTE:
NOTE:
This website is available in English only.
OS Support
OS SupportOS Support
OS Support
AlphaServer DS20L Tru64 UNIX systems include pre-installed software (V5.1B IPK), 2-user Base license
AlphaServer DS20L Linux-Ready systems ship without system software; RedHat 7.2 may be purchased separately from a Linux
distributor.
Minimum OS support Tru64 UNIX V5.1A, New Hardware Delivery-5 (NHD-5) for Tru64 UNIX Version 5.1A, and the most
recent Tru64 UNIX V5.1A Patch Kit.
Refer to the following URL for recent updates:
http://h30097.www3.hp.com/products.html
NOTE:
NOTE: NOTE:
NOTE:
This website is available in English only.
Service and Support
Service and SupportService and Support
Service and Support
HP Services provides a wide range of service offerings including a one-year limited warranty fully supported by a worldwide
network of resellers and service providers; lifetime toll-free 7 x 24 hardware technical phone support.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Standard Features
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 2
Step 1 – Select system
Step 1 – Select systemStep 1 – Select system
Step 1 – Select system
AlphaServer DS20L systems require the mandatory selection of the following items:
To enable initial operating system boot, at least one AlphaServer DS20L per purchase order must include a slim CD-ROM drive (3X-PBXRZ-AA) or a
management station. The remainder of the systems in the configuration can be remotely booted via the CD-ROM drive or the management station.
A minimum of one AlphaServer DS20L Users Guide (EK-DS20L-UG) must be ordered per purchase order.
AlphaServer DS20L is a rackmount-only system. If a rack is unavailable onsite, one must be selected from Step 6.
For integration of more than 32 systems in a cabinet, contact CustomSystems (1-800-AT-COMPAQ).
Rackmount systems require PDU, PDU mounting kit, and power cords.
NOTES
NOTESNOTES
NOTES
: Rackmount system minimum for factory integration is four.
AlphaServer DS20L minimum OS support - Tru64 UNIX V5.1A, New Hardware Delivery-5 (NHD-5) for Tru64 UNIX Version 5.1A, and the most recent Tru64
UNIX V5.1A Patch Kit.
For system integration of options with 6-3 part numbers, contact CustomSystems (1-800-AT-COMPAQ).
AlphaServer DS20L Systems
AlphaServer DS20L SystemsAlphaServer DS20L Systems
AlphaServer DS20L Systems
OS
OSOS
OS
CPU
CPUCPU
CPU
Memory
MemoryMemory
Memory
PCI Slots
PCI SlotsPCI Slots
PCI Slots
Ultra3 SCSI
Ultra3 SCSIUltra3 SCSI
Ultra3 SCSI
Controller
ControllerController
Controller
2 Ethernet Ports
2 Ethernet Ports2 Ethernet Ports
2 Ethernet Ports
Hard Drive
Hard DriveHard Drive
Hard Drive
Order No.
Order No.Order No.
Order No.
Tru64 UNIX
2 x 833 MHz
512 MB
2
Onboard Onboard
Optional
DA-81BAA-EA
Tru64 UNIX
2 x 833 MHz
1 GB
2
Onboard Onboard
Optional
DA-81BAA-FA
Tru64 UNIX
2 x 833 MHz
2 GB
2
Onboard Onboard
Optional
DA-81BAA-GA
Linux-Ready
2 x 833 MHz
512 MB
2
Onboard Onboard
Optional
DJ-81BAA-EA
Linux-Ready
2 x 833 MHz
1 GB
2
Onboard Onboard
Optional
DJ-81BAA-FA
Linux-Ready
2 x 833 MHz
2 GB
2
Onboard Onboard
Optional
DJ-81BAA-GA
NOTE:
NOTE: NOTE:
NOTE:
512-MB and 1-GB systems include one memory option (memory bank 0 populated) — 2-GB systems have both memory banks 0 and 1 populated,
each with a 1-GB option.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Systems
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 3
Step 2 - Select Options
Step 2 - Select OptionsStep 2 - Select Options
Step 2 - Select Options
Step 2a - System Disk Drive
Step 2a - System Disk DriveStep 2a - System Disk Drive
Step 2a - System Disk Drive
Maximum one internal disk drive.
Internal support for 3.5-inch x 1-inch drives only
For multiple system configurations that share a system disk external to system enclosure, contact CustomSystems (1-800-AT-COMPAQ)
System Disk Cable
System Disk CableSystem Disk Cable
System Disk Cable
Configuration Rules
Configuration RulesConfiguration Rules
Configuration Rules
For systems configured with a SCSI hard disk, order the following:
For systems configured with a SCSI hard disk, order the following:For systems configured with a SCSI hard disk, order the following:
For systems configured with a SCSI hard disk, order the following:
One CK-DS20L-AA (one drop DS20L SCSI cable kit)
Internal SCSI Disk Drives
Internal SCSI Disk DrivesInternal SCSI Disk Drives
Internal SCSI Disk Drives
18.2-GB 10,000 rpm Ultra3 SCSI 80-pin SCA2 HDD DS20L drive
3X-RZ3ES-SA
36.4-GB 10,000 rpm Ultra3 SCSI 80-pin SCA2 HDD DS20L drive
3X-RZ3FS-SA
72.8-GB 10,000 rpm Ultra3 SCSI 80-pin SCA2 HDD DS20L drive
3X-RZ3GS-SA
Step 2b - Internal SCSI Adapter and Cable Kit -
Step 2b - Internal SCSI Adapter and Cable Kit - Step 2b - Internal SCSI Adapter and Cable Kit -
Step 2b - Internal SCSI Adapter and Cable Kit -
(Internal SCSI disks require a SCSI cable kit)
SCSI Adapters
SCSI AdaptersSCSI Adapters
SCSI Adapters
(for Internal Drives)
On-board PCI 1-channel Ultra3 SCSI adapter. Supports internal storage devices only.
Single-channel SCSI adapters may only be used for internal or external drive connections, not
both. Mixed cable types are not supported on the same SCSI bus.
PCI 1-channel Ultra2 LVD SCSI adapter, HD 68-pin
3X-KZPCA-AA
PCI 2-channel multimode Ultra3 LVD SCSI adapter, VHDCI (Tru64 UNIX only)
3X-KZPEA-DB
PCI combo card – PCI 2-channel UltraSCSI single-ended adapter and 10/100 Mbit Ethernet (Tru64
UNIX only)
KZPCM-DA
SCSI Cable Kit
SCSI Cable KitSCSI Cable Kit
SCSI Cable Kit
(required for SCSI disks)
One drop DS20L SCSI cable kit
CK-DS20L-AA
Step 3 - Memory - Optional
Step 3 - Memory - OptionalStep 3 - Memory - Optional
Step 3 - Memory - Optional
Maximum 2-GB memory
Systems include two memory banks, four DIMM slots per bank, four DIMMs per memory kit
512-MB memory kit, four 168-pin, PC100, 100-MHz, 128-MB DIMMs
3X-MS810-DA
1-GB memory kit, four 168-pin, PC100, 100-MHz, 256-MB DIMMs
3X-MS810-EA
Step 4 - Internal Storage - Optional
Step 4 - Internal Storage - OptionalStep 4 - Internal Storage - Optional
Step 4 - Internal Storage - Optional
600-MB 24X slim CD-ROM drive and installation kit
3X-PBXRZ-AA
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 4
Step 5 - Documentation - Optional
Step 5 - Documentation - OptionalStep 5 - Documentation - Optional
Step 5 - Documentation - Optional
AlphaServer DS20L Users Guide
EK-DS20L-UG
Step 6 - M-series Cabinets - Optional
Step 6 - M-series Cabinets - OptionalStep 6 - M-series Cabinets - Optional
Step 6 - M-series Cabinets - Optional
M-series cabinet enclosures support up to 32 AlphaServer DS20L systems (H9A15) and/or up to three StorageWorks shelves. For orders where more than 32
systems in a cabinet are required, contact CustomSystems (1-800-AT-COMPAQ). M-series enclosures require selection of the following items:
H9A10 or H9A15 Cabinet, 240V
Minimum four AlphaServer DS20L systems for rack configuration
Rack kit for each system (or quad rack for every four systems)
PDU, PDU mounting bracket, and power cords as needed according to configuration chart
Cabinet front door based on cabinet height
Factory integration
Ballast kit according to the configuration chart
Up to six DS-SL13R shelves are supported; shelves cannot be mounted behind AlphaServer DS20L systems.
Cabinet Configuration Chart for AlphaServer DS20L Rackmount Systems with BA356 (4U) or DS-SL13R (3U)
Cabinet Configuration Chart for AlphaServer DS20L Rackmount Systems with BA356 (4U) or DS-SL13R (3U)Cabinet Configuration Chart for AlphaServer DS20L Rackmount Systems with BA356 (4U) or DS-SL13R (3U)
Cabinet Configuration Chart for AlphaServer DS20L Rackmount Systems with BA356 (4U) or DS-SL13R (3U)
Disk shelves cannot be mixed in same cabinet
Minimum number of systems orderable in a rack is four
For every 12 systems, one PDU is required (H7602-DB/EB); H9A1x-ME/MF cabinets include one H7602-EB/D PDU – order additional PDUs if
required
For each system, one power cord is required (BN35S-4E)
NOTE:
NOTE: NOTE:
NOTE:
For additional configurations beyond those listed in the following charts, contact CustomSystems.
Cabinet
CabinetCabinet
Cabinet
Rack Kits
Rack KitsRack Kits
Rack Kits
3X-PBX01-BD quad
Rack kit
Rack kitRack kit
Rack kit
3X-PBX01-BE single
Systems 1U
Systems 1USystems 1U
Systems 1U
DS-SL13R Shelves
DS-SL13R ShelvesDS-SL13R Shelves
DS-SL13R Shelves
@ 3U
@ 3U@ 3U
@ 3U
H9A10, H9A15
H9A10, H9A15H9A10, H9A15
H9A10, H9A15
1 for each set of 4 systems
1 for each additional system
Per rack Per rack
H9A10-ME/MF
H9A10-ME/MFH9A10-ME/MF
H9A10-ME/MF
1 or 2
0 to 3
4-8
6
2 or 3
0 to 3
9-12
5
3 or 4
0 to 3
13-16
4
4 or 5
0 to 3
17-20
3
5 or 6
0 to 3
21-24
2
6 or 7
0 to 3
24-28
1
7 or 8
0 to 3
29-32
0
H9A15-ME/MF
H9A15-ME/MFH9A15-ME/MF
H9A15-ME/MF
1 or 2
0 to 3
5-8
6
2 or 3
0 to 3
9-12
5
3 or 4
0 to 3
13-16
4
4 or 5
0 to 3
17-20
3
5 or 6
0 to 3
21-24
3
6 or 7
0 to 3
25-28
3
7 or 8
0 to 3
29-32
2
NOTE:
NOTE: NOTE:
NOTE:
For
H9A10
H9A10H9A10
H9A10
cabinets: When four systems are ordered (minimum number of systems orderable), two ballast kits are required. When five or six systems
are ordered, one ballast kit is required. When seven systems or above are ordered, no ballast kits are required.
For
H9A15
H9A15H9A15
H9A15
cabinets: When four systems are ordered (minimum number of systems orderable), two ballast kits are required. When five, six, or seven systems
are ordered, one ballast kit is required. When eight systems or above are ordered, no ballast kits are required.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 5
H9A10 Cabinet
H9A10 CabinetH9A10 Cabinet
H9A10 Cabinet H9A15 Cabinet
H9A15 CabinetH9A15 Cabinet
H9A15 Cabinet
M-series Cabinet
M-series CabinetM-series Cabinet
M-series Cabinet
Descriptions
DescriptionsDescriptions
Descriptions
67-inch carbon black cabinet with 56-inch or 33U of usable vertical space, 200 to 240 dual-16A
controller, 16 IEC C13 outlets, two input power plug NEMA L620P, Americas, Asia Pacific; includes
rear door
H9A10-ME
67-inch carbon black cabinet with 56-inch or 33U of usable vertical space, 200 to 240 dual-16A
controller, 16 IEC C13 outlets, two input power plug IEC 309, 20A, Europe; includes rear door
H9A10-MF
79-inch carbon black cabinet with 68.25-inch or 40U of usable vertical space, 200 to 240V dual16A controller, 16 IEC C13 outlets, two input power plug NEMA L620P, Americas, Asia Pacific;
includes rear door
H9A15-ME
79-inch carbon black cabinet with 68.25-inch or 40U of usable vertical space, 200 to 240V dual16A controller, 16 IEC C13 outlets, two input power plug IEC 309, 20A, Europe; includes rear door
H9A15-MF
M-series Cabinet
M-series CabinetM-series Cabinet
M-series Cabinet
Rackmount Kits for
Rackmount Kits forRackmount Kits for
Rackmount Kits for
AlphaServer DS20L
AlphaServer DS20LAlphaServer DS20L
AlphaServer DS20L
(Refer to the Cabinet Configuration Charts above for configuration rules)
Single rack kit for AlphaServer DS20L
3X-PBX01-BE
Quad rack kit for AlphaServer DS20L
3X-PBX01-BD
M-series Cabinet PDU,
M-series Cabinet PDU,M-series Cabinet PDU,
M-series Cabinet PDU,
PDU mounting bracket
PDU mounting bracketPDU mounting bracket
PDU mounting bracket
and power cord
and power cordand power cord
and power cord
Power Distribution Unit (North America/Japan), 200 to 240V dual-16A controller, 16 IEC C13
outlets, two input power plug NEMA L620P
H7602-EB
Power Distribution Unit (International), 200 to 240V dual-16A controller, 16 IEC C13 outlets, two
input power plug IEC 309, 20A
H7602-DB
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 6
StorageWorks Shelves
StorageWorks ShelvesStorageWorks Shelves
StorageWorks Shelves
Supported in M-series
Supported in M-seriesSupported in M-series
Supported in M-series
Cabinets
CabinetsCabinets
Cabinets
- Optional
StorageWorks Model 4314R, 4314T and 4354R Ultra3 SCSI (LVD) single-bus and split-bus Universal
drive shelves; refer to StorageWorks Enclosure 4300 Family QuickSpecs when configuring shelves.
When selecting a DS-SL13R-xx split-bus shelf, two SCSI channels are required from selected storage
adapters. BN38C-05 cable is required per channel.
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount shelf, U.S. – no
support for Model 4314R single-bus shelves with 3X-KZPEA-DB adapter (190209-001)
DS-SL13R-AA
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount shelf, includes
one power supply, Japan - no support for Model 4314R single-bus shelves with 3X-KZPEA-DB adapter
(190209-291)
DS-SL13R-AJ
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount shelf, includes two
redundant power supplies, U.S. (190211-001)
DS-SL13R-BA
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount shelf, includes two
redundant power supplies, Japan (190211-291)
DS-SL13R-BJ
M-series Cabinet Rear
M-series Cabinet RearM-series Cabinet Rear
M-series Cabinet Rear
Cabinet Extender
Cabinet ExtenderCabinet Extender
Cabinet Extender
Requires selection of one cabinet extender for each H9A10 or H9A15 cabinet
Rear cabinet extender, carbon black, for H9A10-ME/MF cabinets
H9C10-ZE
Rear cabinet extender, carbon black, for H9A15-ME/MF cabinets
H9C15-ZE
M-series Cabinet Front
M-series Cabinet FrontM-series Cabinet Front
M-series Cabinet Front
Doors
DoorsDoors
Doors
Requires selection of door based on cabinet height
Front door, carbon black, for H9A10-ME/MF cabinet enclosure
H9C10-ZF
Front door, carbon black, for H9A15-ME/MF cabinet enclosure
H9C15-ZF
M-series Cabinet Joiner
M-series Cabinet JoinerM-series Cabinet Joiner
M-series Cabinet Joiner
Kit
KitKit
Kit
Joiner kit, H9A10 cabinet
H9C10-JD
Joiner kit, H9A15 cabinet
H9C15-JD
M-series Cabinet Factory
M-series Cabinet FactoryM-series Cabinet Factory
M-series Cabinet Factory
Integration
IntegrationIntegration
Integration
Factory integration required
Factory integration of systems and storage devices assembled and configured in cabinet enclosure in
H9A10 or H9A15 cabinet enclosures
YS-ASCAA-AA
M-series Cabinet Ballast
M-series Cabinet BallastM-series Cabinet Ballast
M-series Cabinet Ballast
Kits
KitsKits
Kits
Ballast is added to a cabinet at particular locations for specific configurations to meet safety
regulations for installation, operation, and service; see the Notes below the Cabinet
Configuration Charts in Step 5.
Two 35 to 40 lb/15.8 to 18 kg steel plates
H9C10-MC
M-series Cabinet
M-series CabinetM-series Cabinet
M-series Cabinet
Rackmount Power Cord
Rackmount Power CordRackmount Power Cord
Rackmount Power Cord
Used for both PDUs
U.S./Canada, Non-U.S. and Japan
BN35S-4E
CustomSystems Support
CustomSystems SupportCustomSystems Support
CustomSystems Support
Cabinets containing systems and storage must be assembled by qualified assemblers: HewlettPackard Manufacturing, CustomSystems, or an authorized Hewlett-Packard Certified
Integration Partner.
For custom integration of systems, options, cabinet expansion offerings, and additional and
third party devices, or for other cabinets, doors, and trim kits of a different color, contact
CustomSystems at 1-800-AT COMPAQ, or your local authorized Hewlett-Packard Certified
Integration Partner.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 7
Step 7 - External Storage - Optional
Step 7 - External Storage - OptionalStep 7 - External Storage - Optional
Step 7 - External Storage - Optional
UltraSCSI Configuration
UltraSCSI ConfigurationUltraSCSI Configuration
UltraSCSI Configuration
Rules
RulesRules
Rules
UltraSCSI configurations require UltraSCSI components (controllers, adapters, shelves, disks, and cables)
UltraSCSI adapters and RAID controllers support UltraSCSI disks at UltraSCSI speeds in UltraSCSI top
gun blue shelves (DS-BA356-xx)
Tabletop Tape Drives
Tabletop Tape DrivesTabletop Tape Drives
Tabletop Tape Drives
Tape drives require LVD or single-ended UltraSCSI adapter and country-specific power cord
12/24-GB 4-mm DAT narrow single-ended tabletop SCSI tape, includes 120V North American power
cord, requires BN31W-xx SCSI cable
DS-TLZ10-DB
20/40-GB 4-mm DAT LVD tabletop SCSI tape - North America (Tru64 UNIX only)
157770-001
20/40-GB 4-mm DAT LVD tabletop SCSI tape - International (Tru64 UNIX only)
157770-B31
20/40-GB 4-mm DAT LVD tabletop SCSI tape - Japan (Tru64 UNIX only)
157770-291
35/70-GB AIT LVD tabletop drive unit, U.S.
216885-001
35/70-GB AIT LVD tabletop drive unit, International
216885-B31
35/70-GB AIT LVD tabletop drive unit, Japan
216885-291
50/100-GB 8-mm AIT LVD tabletop SCSI tape drive – North America (Tru64 UNIX only)
157767-001
50/100-GB 8-mm AIT LVD tabletop SCSI tape drive – International (Tru64 UNIX only)
157767-B31
50/100-GB 8-mm AIT LVD tabletop SCSI tape drive – Japan (Tru64 UNIX only)
157767-291
35/70-GB SCSI (DLT 7000) tabletop tape drive (Tru64 UNIX only)
DS-TZ89N-TA
40- 80-GB SCSI LVD (DLT 8000) tabletop drive, Worldwide
146197-B21
40- 80-GB SCSI LVD (DLT 8000) tabletop drive, Japan
146197-291
110/220-GB SDLT Ultra2 LVD tabletop tape drive, U.S.
192103-001
110/220-GB SDLT Ultra2 LVD tabletop tape drive, International
192103-B31
110/220-GB SDLT Ultra2 LVD tabletop tape drive, Japan
192103-291
20/40-GB 4-mm DAT LVD hot plug tape
3R-A2780-AA
35/70-GB AIT LVD hot plug tape
3R-A2396-AA
50/100-GB AIT LVD hot plug tape
3R-A2779-AA
Storage Controllers/Adapters for External StorageWorks Shelves
Storage Controllers/Adapters for External StorageWorks ShelvesStorage Controllers/Adapters for External StorageWorks Shelves
Storage Controllers/Adapters for External StorageWorks Shelves
PCI controllers/adapters use one PCI slot
Maximum # Supported
Maximum # SupportedMaximum # Supported
Maximum # Supported
Tru64 UNIX
Tru64 UNIXTru64 UNIX
Tru64 UNIX
Linux
LinuxLinux
Linux
PCI-to-Fibre Channel host bus adapter
1
-
DS-KGPSA-CA
Fibre Channel cable; xx=02, 05, 15, 30, 50 meter
BNGBX-xx
PCI 2-port UltraSCSI single-ended adapter and 10/100 Mb Ethernet combo adapter;
includes internal 68-pin and 50-pin HD connectors and two external 68-pin VHDCI SCSI
connectors, requires BN37A-xx cable to connect to single-ended UltraSCSI shelf
2
-
KZPCM-DA
VHDCI male-to-VHDCI male UltraSCSI cable, xx = 02, 2E [2.5], 03, 05, 10, 20 meter
BN37A-xx
PCI 1-port Ultra2 SCSI (LVD) single-ended adapter, 68-pin HD connector, requires BN38C
cable (2 to 20 meter) to connect to single-ended UltraSCSI shelf
2 2
3X-KZPCA-AA
68-pin HD male-to-VHDCI male UltraSCSI cable; xx = 02, 03, 05, 10, 20 meter
BN38C-xx
PCI 2-channel LVD multimode Ultra3 SCSI adapter, VHDCI
2
-
3X-KZPEA-DB
PCI 1-port UltraSCSI differential adapter; includes external 68-pin HD connector, requires
BN38C-xx cable (2 to 25 meter) to connect adapter to differential UltraSCSI shelf or RAID
controller
2 2
3X-KZPBA-CC
68-pin HD male-to-VHDCI male UltraSCSI cable; xx = 02, 03, 05, 10, 20, 25 meter
BN38C-xx
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 8
StorageWorks Fibre
StorageWorks FibreStorageWorks Fibre
StorageWorks Fibre
Channel Switches
Channel SwitchesChannel Switches
Channel Switches
Fibre Channel SAN Switch, 8 ports with Fabric Operating Software (DS-DSGGB-AA)
158222-B21
Fibre Channel SAN Switch, 16 ports with Fabric Operating Software (DS-DSGGB-AB)
158223-B21
Fibre Channel SAN Switch 8-EL (DS-DSGGC-AA)
176219-B21
Fibre Channel SAN Switch 16-EL (DS-DSGGC-AB)
212776-B21
NOTE:
NOTE: NOTE:
NOTE:
For above switches, refer to
http://h18000.www1.hp.com/products/
quickspecs/Division/10490.html
for more information.
Removable Media Devices
Removable Media DevicesRemovable Media Devices
Removable Media Devices
for External StorageWorks
for External StorageWorksfor External StorageWorks
for External StorageWorks
Shelves
ShelvesShelves
Shelves
12/24-GB 4-mm DAT narrow SCSI tape drive in StorageWorks carrier
DS-TLZ10-VA
40/80-GB DLT tape drive in StorageWorks carrier
DS-TZ90N-VW
StorageWorks Universal
StorageWorks UniversalStorageWorks Universal
StorageWorks Universal
Drive Shelves – Model
Drive Shelves – ModelDrive Shelves – Model
Drive Shelves – Model
4314R
4314R4314R
4314R
(Ultra3)
StorageWorks Model 4314R Ultra3 rackmount single bus, U.S. and International
DS-SL13R-AA
Same as above, Japan
DS-SL13R-AJ
StorageWorks Universal
StorageWorks UniversalStorageWorks Universal
StorageWorks Universal
Drive Shelves – Model
Drive Shelves – ModelDrive Shelves – Model
Drive Shelves – Model
4354R
4354R4354R
4354R
(Ultra3)
StorageWorks Model 4354R Ultra3 rackmount dual bus, U.S. and International
DS-SL13R-BA
Same as above, Japan
DS-SL13R-BJ
StorageWorks Universal
StorageWorks UniversalStorageWorks Universal
StorageWorks Universal
Drive Shelves Single Bus –
Drive Shelves Single Bus –Drive Shelves Single Bus –
Drive Shelves Single Bus –
Model 4314T Tower
Model 4314T TowerModel 4314T Tower
Model 4314T Tower
(Ultra3)
StorageWorks Model 4314T, Ultra3, Universal Drive Shelves Single Bus, Tower, U.S.
DS-SL13T-AA
Same as above, Tower, International
DS-SL13T-AB
Same as above, Japan
DS-SL13T-AJ
StorageWorks Universal
StorageWorks UniversalStorageWorks Universal
StorageWorks Universal
Drive Shelves Single Bus –
Drive Shelves Single Bus –Drive Shelves Single Bus –
Drive Shelves Single Bus –
Model 4300 Upgrade I/O
Model 4300 Upgrade I/OModel 4300 Upgrade I/O
Model 4300 Upgrade I/O
Modules
ModulesModules
Modules
StorageWorks Model 4300 Ultra 160 single-port LVD I/O module
DS-SE3ZJ-DA
StorageWorks Model 4300 Ultra 160 dual-port LVD I/O module
DS-SE3ZJ-SA
Universal Disk Drives
Universal Disk DrivesUniversal Disk Drives
Universal Disk Drives
Supported in Model
Supported in ModelSupported in Model
Supported in Model
42xx/43xx Universal Drive
42xx/43xx Universal Drive42xx/43xx Universal Drive
42xx/43xx Universal Drive
Shelves
ShelvesShelves
Shelves
18.2-GB Ultra320 SCSI 15,000 rpm 1-inch Universal drive
3R-A3848-AA
36.4-GB Ultra320 SCSI 10,000 rpm 1-inch Universal drive
3R-A3838-AA
36.4-GB Ultra320 SCSI 15,000 rpm 1-inch Universal drive
3R-A3849-AA
72.8-GB Ultra320 SCSI 10,000 rpm 1-inch Universal drive
3R-A3839-AA
72.8-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive
3R-A3851-AA
146-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive
3R-A3841-AA
Step 8 - UltraSCSI RAID Array Controllers and UltraSCSI RAID Packaged Solutions - Optional
Step 8 - UltraSCSI RAID Array Controllers and UltraSCSI RAID Packaged Solutions - OptionalStep 8 - UltraSCSI RAID Array Controllers and UltraSCSI RAID Packaged Solutions - Optional
Step 8 - UltraSCSI RAID Array Controllers and UltraSCSI RAID Packaged Solutions - Optional
HSG80 External
HSG80 ExternalHSG80 External
HSG80 External
Controllers
ControllersControllers
Controllers
Fibre Channel controller (DS-HSG80-BJ), includes 2-MB cache expandable to 128 MB; requires
128697-B21 HSG80 ACS V8.4F software kit or 128698-B21 V8.4P software kit for each HSG80 ordered
380672-B21
Fibre Channel controller (DS-HSG80-BH), includes 64-MB cache expandable to 128 MB; requires
128697-B21 HSG80 ACS V8.4F software kit or 128698-B21 V8.4P software kit for each HSG80 ordered
380671-B21
ESA 12000, RAID Array
ESA 12000, RAID ArrayESA 12000, RAID Array
ESA 12000, RAID Array
8000
80008000
8000
Enterprise Storage Array 12000 and RAID Array 8000 (HSZ80) product set are supported on
AlphaServer DS20L systems
Supported SCSI adapter for HSZ80 - 3X-KZPBA-CC PCI 1-port UltraSCSI differential adapter
Supported Fibre Channel adapter for HSG80 - DS-KGPSA-CA/DA PCI 1-port Fiber-Channel
adapter
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 9
Step 9 - Networks and Communications - Optional
Step 9 - Networks and Communications - OptionalStep 9 - Networks and Communications - Optional
Step 9 - Networks and Communications - Optional
Systems include dual embedded 10/100 BaseT Ethernet ports, each port connection is limited to a 25-meter cable length
Additional Ethernet ports can be added using available PCI slots
Maximum # Supported
Maximum # SupportedMaximum # Supported
Maximum # Supported
Tru64 UNIX
Tru64 UNIXTru64 UNIX
Tru64 UNIX
Linux
LinuxLinux
Linux
PCI to dual-port 10/100 UTP Fast Ethernet adapter
2
-
3X-DE602-BB
Cable for 10BaseT Twisted Pair connection
BN25G-xx
Shielded cable for 10BaseT Twisted Pair connection
BN25M-xx
Dual-port 10/100 UTP daughter card for 3X-DE602-BB (3X-DE602-BB is a prerequisite)
2
-
3X-DE602-TA
PCI 2-port 10/100-Mb Ethernet adapter, UTP
1 1
3X-DE602-FA
PCI-X/PCI single-port 1000 Mbps (MMF with duplex-SC) Gigabit Ethernet; Tru64 UNIX
V5.1B/TruCluster V5.1B supports up to eight nodes and requires:
http://ftp1.support.compaq.com/public/unix/v5.1b/t64v51bb1-c0003000-16672-e-
20030130.README
Tru64 UNIX V5.1A/TruCluster V5.1A supports up to eight nodes and requires:
T64V51AAB21AS0004-20030206.tar
NOTE:
NOTE: NOTE:
NOTE:
Use BN34A, BN34B, or equivalent with SC connectors.
2
-
3X-DEGXA-SA
PCI-X/PCI single-port 10/100/1000 Mbps (Twisted-Pair Copper with RJ45) Gigabit
Ethernet; Tru64 UNIX V5.1B/TruCluster V5.1B supports up to eight nodes and requires:
http://ftp1.support.compaq.com/public/unix/v5.1b/t64v51bb1-c0003000-16672-e-
20030130.README
Tru64 UNIX V5.1A/TruCluster V5.1A supports up to eight nodes and requires:
T64V51AAB21AS0004-20030206.tar
NOTE:
NOTE: NOTE:
NOTE:
Use BN25G, BN26M, BN24Q, BN28Q twisted pair RJ45 cables.
2
-
3X-DEGXA-TA
PCI Gigabit Ethernet adapter, SC connectors, MMF, no boot support
2 2
DEGPA-SA
PCI Gigabit Ethernet adapter, UTP, no boot support
2 2
DEGPA-TA
SC-to-SC dual fiber optic cable
BN34B-xx
PCI FDDI adapter, single attachment station (SAS), multi-mode fiber (MMF), SC connector
2
-
3X-DEFPA-AC
PCI FDDI adapter, DAS, MMF, SC connector
2
-
3X-DEFPA-DC
MIC-SC dual fiber optic cable mm, pp xx = length in meters
BN34D-xx
SC-to-SC dual fiber optic cable mm, pp xx = length in meters
BN34B-xx
PCI FDDI adapter, SAS, TP-PMD, requires BN25H-03 cable
2
-
3X-DEFPA-UC
PCI FDDI dual adapter, DAS, TP-PMD, requires BN25H-03 cable
2
-
3X-DEFPA-MC
3 meter (9.8 ft) FDDI cross-over cable mm, pp xx = length in meters
BN25H-03
PCI 4-port asynchronous controller; maximum two PBXDA-xx controllers per system
2
-
PBXDA-BA
PCI 8-port asynchronous controller, cable included; maximum two PBXDA-xx controllers
per system
2
-
PBXDA-BB
PCI 16-port asynchronous controller, cable included; maximum two PBXDA-xx controllers
per system
2
-
PBXDA-AC
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 10
Step 10 - Console Terminal - Optional
Step 10 - Console Terminal - OptionalStep 10 - Console Terminal - Optional
Step 10 - Console Terminal - Optional
Any terminal can be used as a console device
Third-party console devices require an EIA-232 25-pin DSUB connector
VT510 video terminal; requires H8575-x cable, either male or female
VT510-xx
Console cable, female connector
H8575-A
Console cable, male connector
H8575-D
Console cable, male connector (IBM compatible)
H8975-E
Step 11 - Software - Required selection of media and online documentation kit for first system on site
Step 11 - Software - Required selection of media and online documentation kit for first system on siteStep 11 - Software - Required selection of media and online documentation kit for first system on site
Step 11 - Software - Required selection of media and online documentation kit for first system on site
Software Processor Code = E
Tru64 UNIX
Tru64 UNIXTru64 UNIX
Tru64 UNIX
Tru64 UNIX systems include Tru64 UNIX V5.1B IPK, 2-user Base license
When using Tru64 UNIX
When using Tru64 UNIXWhen using Tru64 UNIX
When using Tru64 UNIX
V5.0 or later
V5.0 or laterV5.0 or later
V5.0 or later
Tru64 UNIX media and online documentation kit on CD-ROM
QA-6ADAA-H8
Tru64 UNIX V5.1B IPK media and online documentation kit on CD-ROM
QA-MT4AX-H8
Tru64 UNIX V5.1A Patch Kit media and online documentation kit on CD-ROM
QA-MT4AW-H8
Tru64 UNIX full hard copy documentation
QA-6ADAA-GZ
TruCluster Plus Software package with licenses for TruCluster Server, StorageWorks Logical Storage
Manager and AdvFS Utilities
QP-6R9AC-AA
TruCluster Server license
QL-6BRAC-AA
AdvFS Utilities License
QL-0EGAE-AA
Logical Storage Manger License
QL-2GVAE-AA
Advanced Server for Tru64 UNIX, 25 client concurrent use license
QL-5U29M-3D
Advanced Server for Tru64 UNIX, 50 client concurrent use license
QL-5U29M-3E
Advanced Server for Tru64 UNIX, 100 client concurrent use license
QL-5U29M-3F
Advanced Server for Tru64 UNIX, 250 client concurrent use license
QL-5U29M-3G
Advanced Server for Tru64 UNIX, 500 client concurrent use license
QL-5U29M-3H
Layered products media and documentation for Tru64 UNIX on CD-ROM
QA-054AA-H8
DECnet/OSI end-system license for Tru64 UNIX
QL-MTJAE-AA
DECnet/OSI extended function license for Tru64 UNIX
QL-MTKAE-AA
Linux CD-ROM Kit
Linux CD-ROM KitLinux CD-ROM Kit
Linux CD-ROM Kit
RedHat Linux CD-ROM kit
QA-6M1AA-H8
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 11
Step 12 - Hardware and Software Supplemental Support Services
Step 12 - Hardware and Software Supplemental Support ServicesStep 12 - Hardware and Software Supplemental Support Services
Step 12 - Hardware and Software Supplemental Support Services
Systems include one-year hardware warranty, on-site, with 5 x 9, 24-hour response time
Select one of the optional HP Care Pack Service Packages described below that best supports the
customer's operational requirements for system availability.
Options ordered as part of "Initial System Sale" take on warranty of the enclosure; options added after
"Initial System Sale" take on warranty of enclosure until enclosure warranty ends
All unique AlphaServer DS20L options have a minimum of one-year Return-to-Hewlett-Packard warranty
HP Care Pack Services
HP Care Pack ServicesHP Care Pack Services
HP Care Pack Services
HP Care Pack Services are available for AlphaServer systems running Tru64 UNIX or OpenVMS operating systems.
HP Care Pack Services are designed for customers who require support beyond the basic warranty with coverage
for both Principal servers systems and SSPs (Subsequent System Packages) - that meet a full range of customer
support requirements.
Program Features – Principal Server
Program Features – Principal ServerProgram Features – Principal Server
Program Features – Principal Server
HP Support Plus
HP Support PlusHP Support Plus
HP Support Plus
13 x 5 HW/SW support
4-hour response on-site hardware support
2-hour response for Bronze software support
License Subscription for Hewlett-Packard O/S software and embedded L/P (i.e., EIS for OpenVMS,
unlimited users, and server extensions for Tru64 UNIX)
Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX and their layered
products. (Some layered products are not included on Consolidated Software Media Update Distribution
and can be ordered separately.)
HP Support Plus 24
HP Support Plus 24HP Support Plus 24
HP Support Plus 24
24 x 7 HW/SW support
Named HW engineer
4-hour response on-site hardware support
2-hour response for software support
License Subscription for Hewlett-Packard O/S software and embedded L/P (i.e., EIS for OpenVMS,
unlimited users, and server extensions for Tru64 UNIX)
Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX and their layered
products. (Some Layered products are not included on Consolidated Software Media Update Distribution
and can be ordered separately.)
Program Features –
Program Features –Program Features –
Program Features –
Additional Services
Additional ServicesAdditional Services
Additional Services
SSPs (Subsequent System Packages)
For HP Care Pack Support Plus and Support Plus 24
Hardware Support at same level as corresponding package for Principal server
License Subscription: Hewlett-Packard O/S (where applicable)
Telephone support through Principal server covered by full support package
Installation
Pre-installation review
Unpacking of equipment
Assemble and test
Basic product usage into
No software installation added
Installation & Startup Hewlett-Packard O/S
Pre-installation review
Unpacking of equipment
Assemble and test
Basic product usage info
Install operating systems
Product Configuration
Print & Network access
Orientation
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 12
Model/HP Care Pack
Model/HP Care PackModel/HP Care Pack
Model/HP Care Pack
Services
ServicesServices
Services
Principal Server
Principal ServerPrincipal Server
Principal Server
1 Year
1 Year1 Year
1 Year
Principal Server
Principal ServerPrincipal Server
Principal Server
3 Years
3 Years3 Years
3 Years
Subsequent Systems
Subsequent SystemsSubsequent Systems
Subsequent Systems
1 Year
1 Year1 Year
1 Year
Subsequent Systems
Subsequent SystemsSubsequent Systems
Subsequent Systems
3 Years
3 Years3 Years
3 Years
HP Support Plus
FP-A01LA-12 FP-A01LA-36 FP-A21LA-12 FP-A21LA-36
HP Support Plus 24
FP-A02LA-12 FP-A02LA-36 FP-A22LA-12 FP-A22LA-36
Installation
FP-AINST-LA FP-AINST-LA FP-AINST-LA FP-AINST-LA
Installation & Startup
FP-ASTAR-LA FP-ASTAR-LA FP-ASTAR-LA FP-ASTAR-LA
NOTES
NOTESNOTES
NOTES
:
AlphaServer DS20L systems include one-year hardware warranty with 5x9, on-site Next Business Day
response.
New Hewlett-Packard hardware options internal to the AlphaServer enclosure receive the same warranty or
service level as purchased with the server.
External storage devices/cabinets carry their own level of warranty and should be quoted separately for
uplifted warranty services.
In addition to the HP Care Pack shown above, other service packages are available for separate hardware
and software support. For more information on Hardware and Software Upfront Services and other HP
service options available for AlphaServers, please consult your Sales Account Manager, HP Services
Principal, or visit:
http://www.hp.com/hps/
NOTE:
NOTE: NOTE:
NOTE:
This Web site is available in English only.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
Options
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 13
Physical Characteristics
Physical CharacteristicsPhysical Characteristics
Physical Characteristics
Dimensions
DimensionsDimensions
Dimensions
(H x W x D)
17.5 x 20.5 x 1.75 in (44.5 x 52 x 4.5 cm)
Shipping Dimensions
Shipping DimensionsShipping Dimensions
Shipping Dimensions
23.6 x 21.7 x 10.1 in (60 x 55 x 26 cm)
Weight
WeightWeight
Weight
21 lb (9.4 kg)
H9A10 M-Series
H9A10 M-SeriesH9A10 M-Series
H9A10 M-Series H9A15 M-Series
H9A15 M-SeriesH9A15 M-Series
H9A15 M-Series
Cabinets
CabinetsCabinets
Cabinets
Dimensions
DimensionsDimensions
Dimensions
(H x W x D)
67 x 23.6 x 41.5 in
(170 x 60 x 105.4 cm)
79 x 23.6 x 41.5 in
(200 x 60 x 105.4 cm)
Shipping Dimensions
Shipping DimensionsShipping Dimensions
Shipping Dimensions
73 x 36 x 48 in
(185.5 x 91.5 x 122 cm)
85 x 36 x 48 in
(216 x 91.5 x 122 cm)
Weight
WeightWeight
Weight
Configuration dependent
1,000 lb (450 kg)
Shipping Weight
Shipping WeightShipping Weight
Shipping Weight
Configuration dependent, maximum
payload 1,000 lb
1,056 lb (550 kg) (normal)
1,408 lb (640 kg) (maximum)
System Unit
System UnitSystem Unit
System Unit
Environmental
EnvironmentalEnvironmental
Environmental
Temperature
TemperatureTemperature
Temperature
Operating (Tower, Rackmount)
50° to 95° F (10° to 35° C)
NOTE:
NOTE: NOTE:
NOTE:
Maximum operating temperature at sea level; reduce by 1.8° F
(1° C) for each 600m (2,000 ft) above sea level.
Non-operating
41° to 122° F (5° to 50° C)
Storage (60 days)
–40° to –151° F (–40 to –66° C)
Rate of change
20° F/hr (11° C/hr)
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity
Operating
10% to 90% RH
Non-operating
10% to 95%
Storage (60 days)
10% to 95%
Maximum Wet Bulb
Maximum Wet BulbMaximum Wet Bulb
Maximum Wet Bulb
Temperature
TemperatureTemperature
Temperature
Operating
82° F (28° C)
Non-operating
90° F (32° C)
Storage (60 days)
115° F(46° C)
Heat Dissipation
Heat DissipationHeat Dissipation
Heat Dissipation
Typical configuration
Typical configurationTypical configuration
Typical configuration
:
AlphaServer DS20L, 833 MHz
425W Power Supply
Main logic board with 2 EV6
CPUs
2-GB main memory
1 SCSI hard drive, 1 CD-ROM
2 PCI option cards
Input power = 275 Watts
Single Unit = 275W = 939
BTU/hr
Rack of 32 systems with 3
H7602 PDUs = ~11,560W
= 30,048 BTU/hr
Air Flow and Quality
Air Flow and QualityAir Flow and Quality
Air Flow and Quality
Intake location
Intake locationIntake location
Intake location
Front
Exhaust location
Exhaust locationExhaust location
Exhaust location
Rear
Particle size
Particle sizeParticle size
Particle size
N/A
Concentration
ConcentrationConcentration
Concentration
N/A
Altitude
AltitudeAltitude
Altitude
Operating
OperatingOperating
Operating
10,000 ft (3,048m)
Non-operating
Non-operatingNon-operating
Non-operating
40,000 ft (12,192m)
NOTE:
NOTE: NOTE:
NOTE:
Higher altitudes are possible if maximum operating temperature is reduced (see
Temperature); other restrictions may apply such as maximum permissible altitude for hard
drives.
Acoustics
AcousticsAcoustics
Acoustics
(Declared values per ISO 9296 and ISO 7779)
Acoustics
AcousticsAcoustics
Acoustics
NOTE:
NOTE: NOTE:
NOTE:
Current values for specific configurations are available from Hewlett-Packard,
note that 1 B = 10 dBA.
LLLL
WAd3
BBBB
LLLL
nAm5
dBA
dBAdBA
dBA
(bystander position)
Idle
6.7 51
Operating
6.7 51
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
TechSpecs
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 14
Vibration
VibrationVibration
Vibration
Operating
OperatingOperating
Operating
5-500 Hz at .1 G peak (limited by 0.02-in/ 0.5mm
double amplitude)
Non-operating
Non-operatingNon-operating
Non-operating
1.03 Grms 5-300 Hz
Shock
ShockShock
Shock
Operating
OperatingOperating
Operating
10 G 10ms half-sine
Electrical
ElectricalElectrical
Electrical
Electrical
ElectricalElectrical
Electrical
Nominal Voltage
Nominal VoltageNominal Voltage
Nominal Voltage
(VAC)
200 to 240
Voltage Range
Voltage RangeVoltage Range
Voltage Range
(VAC)
(temporary condition)
180 to 250
Power Source Phase
Power Source PhasePower Source Phase
Power Source Phase
Single
Nominal Frequency
Nominal FrequencyNominal Frequency
Nominal Frequency
(Hz)
50/60
Frequency Range
Frequency RangeFrequency Range
Frequency Range
(Hz)
49 to 51/59 to 61
RMS Current
RMS CurrentRMS Current
RMS Current
(maximum steady state)
Single power cord
Single power cordSingle power cord
Single power cord
2.3A
Apparent power VA
Apparent power VAApparent power VA
Apparent power VA
545
M-series Cabinet
M-series CabinetM-series Cabinet
M-series Cabinet
(configuration dependent)
Nominal PDU voltage
Nominal PDU voltageNominal PDU voltage
Nominal PDU voltage
(VAC)
220-240
Each PDU power cord
Each PDU power cordEach PDU power cord
Each PDU power cord
24A
Load per PDU power cord
Load per PDU power cordLoad per PDU power cord
Load per PDU power cord
16A
Power Cords
Power CordsPower Cords
Power Cords
Rackmount
RackmountRackmount
Rackmount
1 (14 ft 10 in (452 cm))
IEC 320 C13 to NEMA 5-15
(N. America) or
IEC 320 C13 to IEC 320
C14
(other countries)
Cabinet
CabinetCabinet
Cabinet
2 (10 ft 10 in (330 cm))
200V non-removable NEMA
L6-30P or 200-240V nonremovable IEC 309 @ 32A
Regulatory
RegulatoryRegulatory
Regulatory
Agency Approvals
Agency ApprovalsAgency Approvals
Agency Approvals
Series EA2014
UL: Listed to UL1950 (3rd edition)
CUL Listed: CAN/CSA-C22.2 No. 950-M95
FCC: Part 15.B Class A
IC ICES-003 Class A
CE: EN55022 :1998, EN55024 :1998, EN61000-33 :1995
VCCI V-3/97.04 Class A
BSMI: CNS13438 Class A
C-Tick: AS/NZS 3548:1995 Class A
Reviewed to
Reviewed toReviewed to
Reviewed to
AS/NZ 3260:1993 Australian/New Zealand Standard
EN 60950/A11: 1997 European Norm
IEC950 (2nd edition, 4th amend)
© Copyright 2003 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
UNIX is a registered trademark or trademark of The Open Group in the U.S. and/or other countries. The only warranties for HP products and services are set
forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained.
QuickSpecs
HP AlphaServer DS20L
HP AlphaServer DS20LHP AlphaServer DS20L
HP AlphaServer DS20L
TechSpecs
DA - 11054 Worldwide — Version 4 — October 6, 2003
Page 15
Loading...
