HP StorageWorks 600 All-in-One Storage System
QuickSpecs
Overview
Unbelievably simple. Uniquely affordable. Unquestionably reliable.
About HP All-in-One (AiO) Storage:
servers (iSCSI Target), enhanced file serving for end-user clients (NAS), backup target services for network data, and data
protection software to keep all of your data safe and secure; these are the key functions of HP All-in-One Storage and together,
they allow businesses to lower costs, increase efficiencies, and respond to rapid data growth. HP StorageWorks All-in-One Storage
Systems are radically simple, integrated, and affordable network storage solutions that enable small and mid-size companies to
easily manage, grow, and protect their data without requiring them to become storage experts. These systems are designed to be
deployed and managed by IT generalists with no storage expertise and deliver everything you need to lower the cost and
complexity of rapidly growing data storage environments.
The easy-to-use, All-in-One Storage Manager (ASM) interface reduces the time, expense, and expertise required to keep up with
rapidly growing applications like Microsoft Exchange. Busy IT Managers do not have time to learn complex storage technologies;
ASM eliminates this barrier by handling all underlying storage tasks and presenting network storage in application-centric terms,
giving administrators newfound levels of control. Data migration tools for Exchange 2003/2007 and SQL Server 2000/2005
include 'best practice' recommendations which allow any IT generalist to look like a storage expert. Tools for hosting 'user defined'
applications enable flexible deployment in many different environments.
Imagine having a single integrated solution that could provide shared storage for application
(AiO600)
ASM provides easy setup of shared folders, backup target areas, and iSCSI Target storage for hosts running Windows Server,
Linux, VMWare ESX, or any other standards-compliant iSCSI initiator. Administrators can quickly and easily setup or expand data
areas, migrate data from capacity constrained servers, manage disk based backup storage areas, implement disk and tape backup
policies, and more.
Now you can have a simple, affordable, and reliable network storage solution that provides many of the management,
consolidation, and data protection features typically reserved for higher-priced and more complex storage products.
About the AiO600:
file serving for end-user clients (NAS), and comprehensive data protection features. The AiO600 is an excellent solution for
customers looking for increased capacity, scalability, and hardware redundancy. The AiO600 is available in both SATA and Serial
Attached SCSI (SAS) configurations.
NOTE:
http://www.hp.com/go/AiOStorage
of software updates depending on the version of ASM installed on your system. Be sure to check for updates to make sure you are
using the latest version of the software. Critical updates for the Windows Storage Server 2003 R2 operating system can be
implemented using standard Windows Update functionality but you should disable any auto-restart options to avoid complications
with iSCSI connections. For other software components you should only update components as part of an All-in-One Storage
System update. Do not separately download or install individual updates for Data Protector Express as this may adversely affect the
management integration of these components.
Updates to the HP All-in-One Storage Manager (ASM) are posted to support links available at
This tower/rack solution provides shared storage expansion for application servers (iSCSI SAN), enhanced
. Some of the management features discussed in this document may require the installation
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 1
QuickSpecs
Highlights
HP StorageWorks 600 All-in-One Storage System
(AiO600)
Benefits of HP
StorageWorks
All-in-One
Storage Systems
Breakthrough simplicity
that lowers the cost and
complexity of data
management
Integrated and adaptive
storage solutions to
enable business growth
Affordable and cost
effective solution for
growing application
environments
Application-centric
storage management
simplifies operation and
lowers costs
'Best Practice' toolkit
makes every IT
Administrator look like a
storage expert
Shared storage for
growing application
servers (iSCSI SAN)
enables efficient use of
capacity
Enhanced file serving for
end-user clients (NAS) to
improve productivity and
collaboration
Comprehensive and
integrated data
protection to ensure easy
roll-back and disaster
recovery
Easy to deploy and
manage so you can
focus on your core
business
Award winning
warranty, support and
troubleshooting tools to
ensure worry-free
operation
The intuitive All-in-One Storage Manager interface radically simplifies the
growth, management, and protection of data by hiding complexity and
enabling storage to be a turnkey resource. Designed for IT generalists with
no storage expertise, these systems can be setup and actively serving files in
minutes.
A single storage solution that can respond to a wide variety of business
needs. HP All-in-One Storage Systems offer an incredible degree of utility
and flexibility by providing shared storage for multiple application servers,
file serving for end-user clients, disk based backup capabilities, and data
protection for both file and application data via snapshots and backup
software.
Managed through a single interface, HP All-in-One Storage provides shared
application storage (iSCSI Target), file serving (NAS), and data protection
below the cost of separate products and without the need to change your
infrastructure.
traffic and can be implemented using standard Ethernet hardware you
probably already have.
Easy to manage because it uses terms and functions familiar to application
administrators. Includes end-to-end iSCSI management for Windows Servers
plus iSCSI provisioning for other iSCSI initiators (Linux, VMWare ESX Server,
etc.). Provides data migration wizards for Microsoft Exchange 2003/2007
and SQL Server 2000/2005.
HP All-in-One Storage Systems include tools to easily migrate and manage
data using best practice settings. For example, iSCSI storage for a Microsoft
Exchange Storage Group can be expertly setup and migrated in less than
10 mouse clicks, saving you time and reducing the risk to your business.
Sharing storage between servers is more efficient and costs less to manage
over time when compared against adding additional drives to individual
servers. Sharing storage means that you maximize investments in additional
capacity while enabling easier growth and shorter backup windows. HP All-
in-One Storage Systems utilize the Microsoft iSCSI Software Target to
provide block-based access to network storage.
Tuned for faster file serving performance (20% faster than standard Windows
Server on the same hardware). Single Instance Storage (SIS) de-duplication
features can improve capacity utilization by 30% or more by eliminating
duplicate files within shared volumes. Full text search capabilities increase
the speed of end-user search. Support for heterogeneous environments
(CIFS/NFS) gives you the flexibility your changing business needs to serve
multiple operating environments.
Provides an easy mechanism to manage disk based snapshots for easy
rollback, integrated data protection software for offsite and archive, hot plug
disk drives (RAID), and hardware redundancy. Data can also be replicated
to another system for enhanced disaster recovery. Utilize your All-in-One
Storage pool as a disk based backup target for other systems in your
environment and manage Data Protector Express virtual library objects direct
from the All-in-One Storage Manager.
Uses standard tools and concepts familiar to server administrators to reduce
learning curve and barriers to network storage. The industry standard iSCSI
interface provides the benefits of shared SAN storage on a traditional
TCP/IP network. HP ProLiant hardware ensures reliability, low TCO, and
supportability. The All-in-One Storage Manager quickly walks administrators
through all major setup and management tasks.
HP All-in-One Storage Systems can send alerts for various events such as an
impending disk failure reducing the potential for downtime while HP's world
class support organization and partner network ensures that you can quickly
recover in the case of a problem.
NOTE:
A dedicated segment is recommended for your iSCSI
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 2
QuickSpecs
Highlights
HP StorageWorks 600 All-in-One Storage System
(AiO600)
Available Product
Configurations
HP StorageWorks 400
All-in-One Storage
System (AiO400)
HP StorageWorks 600
All-in-One Storage
System (AiO600)
HP StorageWorks 1200
All-in-One Storage
System (AiO1200)
This entry-level rackable solution provides shared storage expansion for
application servers (iSCSI SAN), enhanced file serving for end-user clients
(NAS), and comprehensive data protection features. The AiO400 is an
excellent solution for customers needing less than 1TB total raw capacity
without the performance requirements of SAS.
Sizing Guidelines: For Exchange environments, the AiO400 can be
used for smaller Storage Groups with less than 100 mailboxes when
using the Exchange ESRP implementation guidelines. Out of the box
implementations should only use the AiO400 for very few users or
archival Storage Groups. While it is certified for VMWare ESX iSCSI
connectivity, the AiO400 is not recommended in VMFS environments
due highly random read/write performance characteristics of VMFS.
This tower/rack solution provides shared storage expansion for application
servers (iSCSI SAN), enhanced file serving for end-user clients (NAS), and
comprehensive data protection features. The AiO600 is an excellent solution
for customers looking for increased capacity, scalability, and hardware
redundancy. The AiO600 is available in both SATA and Serial Attached
SCSI (SAS) configurations.
Sizing Guidelines: For Exchange environments, AiO600 SATA
configurations are appropriate for storage groups with less than 500
mailboxes while AiO600 SAS configurations support up to 1,000
mailboxes when using the Exchange ESRP implementation guidelines.
Out of the box implementations for the AiO600 will support approx
25% of these numbers. The AiO600 is certified with VMWare ESX for
iSCSI connectivity; due to the highly random read/write performance
characteristics of VMFS we recommend SAS HDDs and the AiO1200
SAS as the best performance option for use with VMWare ESX and
VMFS.
This high capacity all-in-one solution provides shared storage expansion for
application servers (iSCSI SAN), enhanced file serving for end-user clients
(NAS), and comprehensive data protection features. The AiO1200 is an
excellent solution for customers looking for increased performance and
capacity from 12 internal drives and a high performance RAID controller.
The AiO1200 is available in both SATA and Serial Attached SCSI (SAS)
configurations.
HP StorageWorks All-in-
One SB600c Storage
Blade (AiO SB600c)
Sizing Guidelines: For Exchange environments, AiO1200 SATA
configurations are appropriate for storage groups with less than 500
mailboxes while AiO1200 SAS configurations support up to 1,500
mailboxes when using the Exchange ESRP implementation guidelines.
Out of the box implementations for the AiO1200 will support approx
25% of these numbers. The AiO1200 is certified with VMWare ESX
for iSCSI connectivity; due to the highly random read/write
performance characteristics of VMFS we recommend SAS HDDs for
use with VMWare ESX and VMFS.
This half-height all-in-one storage blade solution was designed for HP c-class
BladeSystem environments and provides shared storage expansion for blade
servers (iSCSI SAN), enhanced file serving for end-user clients (NAS), and
comprehensive data protection features. The AiO SB600c is an excellent
solution for customers looking at c-3000 or c-7000 BladeSystem
deployments. The AiO SB600c is available a SAS configuration.
Sizing Guidelines: For Exchange environments, AiO SB600c SAS
configurations are appropriate for storage groups with less than 500
mailboxes. The AiO SB600c is certified with VMWare ESX for iSCSI
connectivity.
Software Feature
Specifications for the HP
All-in-One Storage
Family
All-in-One Storage
Management Interface
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
This single easy to use, integrated storage management tool can
manage many aspects of the storage environment.
Rapid startup tools for fast and easy installation and out-of-the
box configuration
Page 3
QuickSpecs
Highlights
Shared Application
Storage (Microsoft iSCSI
Software Target)
HP StorageWorks 600 All-in-One Storage System
Provides end-to-end management and provisioning of iSCSI
storage for 32-bit and 64-bit Windows Server 2003 hosts from
the iSCSI Target all the way through to the host
Provides management and provisioning of iSCSI storage for
standards-compliant non-Windows iSCSI initiators such as
VMWare, Linux, etc..
Application data hosting and migration wizard using HP and
Microsoft 'Best Practice' storage configurations for Microsoft
Exchange 2003/2007 Storage Groups and Microsoft SQL
Server 2000/2005 databases.
Application data hosting and iSCSI Setup wizard for other
'User Defined' Application (Oracle, mySQL, etc…)
File Share creation wizard with storage allocation and directory
quota management.
Data protection policy assignment (snapshots and backup)
integrated into application migration and share creation
wizards for data hosted on the system.
Data Protector Express virtual library device provisioning and
space management as well as support for Data Protector
Express D2D2Any add-on option.
Application-level capacity provisioning and online growth for
shares, SQL Server and Exchange. SQL Server support includes
data file and log directory provisioning and Exchange support
includes Mailstore, Publicstore and log directory provisioning.
Quota monitoring and alerting per share or application.
Remote management via Microsoft Internet Explorer or Terminal
Services.
Support for setup and management of both internal storage as
well as supported direct attached MSA storage enclosures
Supports management of tiered storage environments where
both SAS, parallel SCSI, or SATA hard drives are attached to
the All-in-One Storage System either internally or on externally
attached MSA storage enclosures.
Compliant with iSCSI industry standards and compatible with industry
standard iSCSI initiators. Interoperability has been verified for
Windows 2000, Windows Server 2003, VMware ESX Server 3,
SUSE Linux Enterprise Server 10, RedHat Enterprise Linux 5, and
Qlogic 4050c. For additional information please visit
http://www.microsoft.com/storage
MMC based console to setup iSCSI Target storage. This console can
be used to setup advanced storage options. Basic iSCSI Target setup
and management can be performed directly from the All-in-One
Storage Manager.
Support for advanced features such as TCP/IP offload with multi-
function network adapters (requires Microsoft Scaleable Network
Pack (SNP) and multi-pathing (MPIO).
Pack is not supported on the iSCSI Target.
The Microsoft iSCSI Target can be used as target storage behind a
Microsoft application cluster. For more information on this
implementation read the whitepaper on this topic found at
http://www.hp.com/go/AiOStorage
.
NOTE:
.
HP iSCSI Acceleration
(AiO600)
File/print serving
(NAS Operating System
- Windows Storage
Server 2003 R2
Standard Edition)
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Native CIFS file serving support - Windows based file serving
optimized for Windows clients
Microsoft Services for Network File System (NFS) to enable
heterogeneous file serving to non-Windows clients.
HP Enhanced, File Server Management Console
De-duplication via Single Instance Storage (SIS) to eliminate duplicate
files and maximize available capacity; SIS can improve capacity
utilization by 30% or more
Full-text indexing to maximize productivity and allow for fast data
retrieval.
File Server Resource Manager for quotas, file screening and storage
Page 4
QuickSpecs
Highlights
Integrated Data
Protection
Operating System
HP StorageWorks 600 All-in-One Storage System
reporting
Print Server management console with unlimited printer support
Unlimited Client Access License (CAL) included
Print Server support
Easy to use print management console
Unlimited printer support
RAID hard drive configurations (hot swappable drives)
Disk-based snapshots for easy roll-back
Scheduled or ad-hoc by application
Managed through HP All-in-One Storage Manager
Exchange and SQL Server aware snapshots ensure consistent
data sets for the applications.
512 snapshots per independent iSCSI/Application volume. 64
snapshots for file share volumes. (
shares are on a common volume the iSCSI snapshot limit is
448.
)
A fully integrated copy of HP StorageWorks Data Protector Express
software (v3.1SP4) provides enhanced backup and recovery
operations. (
Protector Express and does not include any add-on licenses for
features such as Bare Metal Recovery or Disk-to-Disk-to-Any
functionality. If using the All-in-One Storage System as a backup server
for a Data Protector Express backup domain all members of the
domain should be running the same version of Data Protector Express -
v3.1SP4
Microsoft Distributed File System Replication (DFS-R) to enable
replication of files to an alternate HP All-in-One Storage System,
including
Support for HP StorageWorks Storage Mirroring v4.5 (AiO Edition) to
enable replication and failover of both files and iSCSI LUNs.
Microsoft Windows Storage Server 2003 Release 2, Standard
Edition
NOTE:
)
Automatic discovery of tape devices
Software based Virtual Tape functionality
Disk-to-disk-to-any data protection
DFS Management Console
Configuration and Diagnostic Tools
A 60-day trial version of HP StorageWorks Storage Mirroring
software is included on most systems or can be downloaded
from
http://h18000.www1.hp.com/products/
storage/software/sm/index.html
This is the backup server LTU component of Data
NOTE:
If iSCSI LUNs and file
(AiO600)
HP All-in-One 600 Storage System configured with optional tower to rack conversion kit
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 5
QuickSpecs
Highlights
HP StorageWorks 600 All-in-One Storage System
(AiO600)
AiO600
Hardware
Specifications
Processor
Memory
Operating System
Network Controller
Storage Controller
Internal Storage
(varies by model)
Optical Drive
Expansion Slots
Power Supply
Cooling Fans
Remote Management
Form Factor
Warranty
SIM Support
Dual Core Intel Xeon 2.67 GHz/1333 MHz FSB with 4MB (1 x
4MB) L2 Cache;
1 GB of PC2-5300 Fully Buffered DIMMs; 2 x 512MB (AiO600 has
Eight PC2-5300 FB-DIMM (DDR2 667) sockets)
Up to 4GB supported
Windows Storage Server 2003, Release 2 Standard Edition
Embedded NC373i Multifunction Gigabit Network Adapter with
TCP/IP Offload Engine
Additional Dual port 10/100/1000T Adapter (NC360T)
NOTE:
shipped with the AiO600. These network adapters are functionally
equivalent in all respects and both adapters will continue to be fully
supported by HP. Support for units in the field, including replacement
parts, will be provided to both the NC7170 or NC360T.
Smart Array E200i Controller with 128MB BBWC included (RAID
0,1,10,5)
1.5TB SATA Model: 6 x 250GB front load, hot plug, 7200 RPM
SATA HDDs
3.0TB SATA Model: 6 x 500GB front load, hot plug, 7200 RPM
SATA HDDs
876GB SAS Model: 6 x 146GB front load, hot plug, 15,000 RPM
Serial Attached SCSI (SAS) HDDs
1.8TB SAS Model: 6 x 300GB front load, hot plug, 15,000 RPM
Serial Attached SCSI (SAS) HDDs
HP DVD+R/RW 16X Half Height
(3) x4 PCI-Express (x8 connectors) (
NC360T Network Card
(1) 64 bit, 133MHz 3.3V PCI-X
(2) 64 bit, 100MHz 3.3V PCI-X
Dual Hot-Plug redundant power supplies
Two system fans plus two redundant system fans
Remote system management User Interface (UI), Remote Desktop or
Telnet
Integrated Lights Out 2 (iLO2) with Advanced License Pack
5 U Tower or Rack with optional rack conversion
The AiO600 has a standard 3-3-3 warranty (3 years parts exchange,
three years labor, and three years on-site, next business day response)
which can be upgraded to same day support through HP Care Packs.
The AiO600 supports Insight Manager through SNMP. For more
information on HP Insight Manager please visit:
http://h18013.www1.hp.com/products/servers/
management/hpsim/index.html
The NC360T replaces the NC7170 NIC which previously
NOTE:
The AiO600 supports up to 2 processors
NOTE:
)
One slot occupied by
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 6
QuickSpecs
Highlights
HP StorageWorks 600 All-in-One Storage System
(AiO600)
Optional Software
to Enhance HP
All-in-One Storage
Systems
HP StorageWorks Storage Mirroring
software offers a host-based application that performs remote copy over an IP LAN/WAN. Key
features include asynchronous replication that can be scheduled to a fine granular level, Logical
Unit Number (LUN), file or byte level. Other features include multiple replication configuration
options including peer-to-peer and many-to-one. In addition, Storage Mirroring is a very cost
effective disaster recovery alternative from one host to another within a LAN, storage center, or
between direct attached storage in metro offices and regional centers. Additional configurations
allow replication from small office environments to ensure business continuity without an outside IT
staff.
For more information:
http://h18000.www1.hp.com/products/storage/software/sm/index.html
HP Data Protector Express optional extensions
features and reliability without compromising its ease of use. Features such as open file backup,
D2D2Any backup and recovery and bare metal disaster recovery minimize the impact of backup
and recovery operations. The D2D2Any feature extends the scale and capability of the D2D
backup (Virtual Library) to allow backups to be moved or copied from disk to other media such as
tape for longer term retention. Agents are available for the protection of networked file servers,
application servers, HP Data Protection Storage Server and Windows desktops. High
performance is delivered through the Data Protector Express three-tier architecture - unique in this
class of product - and self-tuning parallel backup streams that allows multiple jobs to run
concurrently.
(AiO Edition) - HP StorageWorks Storage Mirroring
- Data Protector Express delivers class leading
The HP All-in-One Storage System includes the backup server LTU which enables the backup and
recovery of file and iSCSI data on the AiO and the setup and management of virtual libraries; you
can consolidate the rest of your backup infrastructure and add advanced functionality by including
any of the optional extensions such as D2D2Any, bare metal recovery, or network agents for
backup of data stored locally on other servers.
For more information on Data Protector Express visit www.hp.com/go/dataprotectorexpress.
Click on the QuickSpec link for information on SKU's, options, and functional extensions.
HP Systems Insight Manager
platform. Now, from a single management console, administrators can manage their complete
HP server and storage environment with a feature rich, extensible and secure management tool
set.
HP SIM also serves as a central access point for ProLiant Essentials, Integrity Essentials, and
Storage Essentials software options that deliver targeted functionality for these platforms. For more
information:
Insight Management Agents
configuration information into HP Systems Insight Manager and the HP System Management
Homepage. The HP System Management Homepage aggregates systems data from Insight
Management Agents and other HP management tools, providing a consolidated browser-based
interface for managing individual servers.
http://h18013.www1.hp.com/products/servers/management/hpsim/index.html
- HP SIM 5.x is the first unified server and storage management
- Allow all HP servers to present system instrumentation, health and
HP Storage Essentials NAS Manager
(NAS) management capabilities for HP All-in-One Storage Systems. Visualize your distributed HP
All-in-One Storage Systems and centrally manage their capacity, performance, events, and
dependencies to ensure availability and performance and unify SAN and NAS management. For
more information on the complete line of HP Storage Essential products go to:
http://www.hp.com/go/storageessentials
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
- Provides comprehensive Network Attached Storage
Page 7
HP StorageWorks 600 All-in-One Storage System
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
HP Care Pack Services offer upgraded service levels to extend and expand your standard product warranty with easy to buy, easy
to use support packages that help you make the most of your hardware and software investments. They let you choose the support
levels that meet your business requirements. They help you contain total cost of ownership.
HP Care Pack warranty extensions can be purchased along with HP products to cost-effectively upgrade or extend your warranty.
For most HP products, including the AiO600, post-warranty HP Care Pack Services are available when your original warranty has
expired.
(AiO600)
Why purchase an HP
Care Pack service?
Your standard warranty protects against product defects during normal working hours. HP Care Pack
Services help you extend this protection to more coverage hours and more days per week. This can
increase uptime which can improve your productivity and profitability. These convenient service
packages:
Protect your investment in HP products
Provide consistent, predictable levels of support across your entire department or business
Ease budget planning with fixed-cost support that includes parts and labor
Give you direct access to proven technical and problem-solving expertise
Offer a choice of response-time and repair-time commitments
Deliver prompt, measurable results
Are available whenever and wherever you do business
HP Care Pack availability may vary by country and product.
The breadth, depth, and quality of HP hardware and software support services can help you improve
the performance of your IT support processes and resolve the complex software and hardware problems
that tax user productivity. HP Care Pack services help you increase IT environment stability, efficiency,
and agility from the desktop to the data center, and improve the productivity of your employees.
HP offers an optional migration service to assist the customer in moving to the newest product release.
This may be in the form of a defined kit and service, or may alternatively be performed on a time &
material basis.
Warranty and Services
Included with the
Product
HP Services allows the customer to leverage HP's experience in selecting and configuring the most
widely used security features, and provides an environment that is immediately more available due to
increased change control and significantly improved data security.
For more information on these and other service options, please contact any of our worldwide sales
offices or visit our web site at:
HP basic Software warranty provides that the Software media will be free of physical defects for a
period of ninety (90) days from delivery. In addition to this basic Software warranty HP also includes, as
part of the product, a 1 year, Software Support Carepack that provides phone in support for 9hrs/day,
5 days/week for all the bundled software including the WSS2003 R2 operating system including the
iSCSI functionality, the Data Protector Express software, and the enhanced All-in-One Storage Manager
(ASM) GUI. This AiO600 product support can be uplifted to 24x7 for up to 5 years.
The HP AiO600 comes with a 3-3-3 hardware warranty (3 years parts exchange, 3 years labor, and 3
years on-site, next business day response) for product hardware.
http://www.hp.com/hps/support
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 8
HP StorageWorks 600 All-in-One Storage System
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
(AiO600)
Available HP Care Pack
Services
Installation Services
Extend your product warranty with a choice of cost-saving support packages.
HP Care Pack Services are sold by HP and HP authorized enterprise and commercial resellers. Services
for customers purchasing via direct and enterprise resellers are quoted using HP order configuration
tools.
HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific
duration and hours of coverage.
HP Care Pack is not available for less than the product's warranty duration.
HP Care Pack is available for sale anytime during the warranty period for most products, but the
commencement date will be the same as the Warranty Start Date (delivery date to end user
customer). Proof of purchase may be required.
HP Care Pack services are prepaid.
For additional information on Product Services and HP Care Pack, as well as orderable part numbers,
please refer to the URL:
If you have specific questions about availability or how to obtain services contact your local HP
representative. Contact information for your local area can be found at:
http://www.hp.com/services
The Installation service deployment activities follow the AiO Quick Start Poster and include:
http://www.hp.com/hps/carepack/
.
.
Support Plus 24
CarePack
Unpacking the product, performing initial inspection, rack mounting if required, and setting up
product hardware and power connectivity and connecting customer provided cables
Working with the customer to determine if access to the AiO will be DHCP or networking
Configuring the AiO by running the Rapid Startup Wizard which sets such things as date, time,
user name and password, setting up integrated Lights Out (iLO) and simple network management
protocol (SNMP).
The AiO "Create a Shared Folder" Wizard is run to configure the AiO to share files, and access
is confirmed.
Finally, a product orientation of less than 10 minutes provides a brief overview of how the product was
set up, as well as how to find information within the product documentation.
HP Support Plus 24 provides all the benefits of the regular Support Plus Care Pack, but HP Services
engineers are available to work with your IT team to deliver onsite hardware support and over-the-phone
software support around-the-clock 365 days per year.
Three years of HP Support Plus 24 x 7
Improve coverage hours from 9x5 to 24x7
Improve HW response time from warranty of next business day to 4hrs same day
Extend coverage from 1 year to 3 years
Includes both AiO hardware and software
Improve the productivity of system managers and operators
Improve system performance and reduce downtime due to software defects
Expedite problem resolution through expert-level technical resources
Enjoy consistent service coverage across geographically dispersed sites
Access to patches for HP and selected third-party software and firmware
In short you enjoy all the benefits of HP Support Plus at any time or on any day you may need them.
Choose Support Plus 24 when you not only need all of the benefits of Support Plus, but also require
responsive hardware and software services available anytime.
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 9
HP StorageWorks 600 All-in-One Storage System
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
(AiO600)
Support Plus
CarePack
HP Support Plus helps you increase the performance and availability of your IT infrastructure with
comprehensive, consistent hardware and software services. HP Services engineers deliver onsite
hardware support and over-the-phone software support 13 hours per day, 5 days per week.
Three years of HP Support Plus 13x5
Extend basic coverage from 1 year to 3 years
Improve HW response time from warranty of next business day to 4hrs same day
Improve coverage hours from 9x5 to 13x5 (due to improved response time)
Includes both AiO hardware and software
Improve the productivity of system managers and operators
Improve system performance and reduce downtime due to software defects
Expedite problem resolution through expert-level technical resources
Enjoy consistent service coverage across geographically dispersed sites
Access to patches for HP and selected third-party software and firmware
Our Service coverage encompasses the HP AiO 400/600/1200 products, selected multi-vendor
hardware and provides trouble-shooting software problems which in turn range from the Windows
Storage Server 2003 operating system up to the available utilities. And Support Plus provides recovery
and re-configuration assistance of the base HP AiO400/600/1200 using the Quick Recovery disk
and your saved configuration file (application recovery not included).
Choose Support Plus when you need to:
eSupport
Improve uptime with responsive hardware and software services.
Enjoy consistent service coverage across geographically dispersed sites.
Update HP and selected third-party software with tested and certified patches.
HP eSupport is a portfolio of technology-based services that assist you with managing your business
environment - from the desktop to the data center.
Support Portal
The HP support portal provides one-stop access to the information, tools and services you need to
manage the daily operations of your IT environment.
Features include:
Access to self-solve tools (including search technical knowledge base)
Efficient logging and tracking of support cases
Collaboration with other business and IT professionals
Download of patches and drivers
Access to diagnostic tools
Proactive notification of relevant information
Access to certain features of the support portal requires an HP service agreement. To access the support
portal, visit
http://www.hp.com/support
Education Services
Financial Services
HP offers a variety of training methods to fit your needs including traditional instructor-led courses at one
of our 120 training centers worldwide, onsite training customized to your needs, in your facility, or even
Remotely Assisted Instruction Learning that combines the best of traditional classroom training (including
its live instructor and labs) with the best of online training (no traveling required). And if you like learning
on your own schedule, at your own pace, make use of e-learning opportunities on the award-winning
HP IT Resource Center, a "learning community" with extensive on-demand resources that can be
accessed 24x7. For more information on these services, contact your HP sales representative or visit:
http://www.hp.com/learn
HP Financial Services provides innovative financing and financial asset management programs to help
customers cost-effectively acquire, manage, and ultimately retire their HP solutions. For more information
on these services, please contact your HP sales representative or visit:
http://www.hp.com/go/hpfinancialservices
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
and click on "HP StorageWorks".
Page 10
HP StorageWorks 600 All-in-One Storage System
QuickSpecs
Product Configuration Wizard
In the following steps you will be guided through a series of steps to help you configure the best solution for your environment. You
will also be supplied with information about complementary products that can be ordered at the same time. It is important to note
that HP StorageWorks All-in-One Storage Systems include all of the software features and benefits listed above as standard features;
this means that there are no expensive upgrades or options required to achieve this integrated storage functionality and data
management.
NOTE:
integrated or configured and ship as separate components.
Step 1 - Order the desired HP All-in-One Storage System based on capacity, performance,
scalability, and redundancy requirements.
AiO600 Configurations
NOTE:
Rack Conversion Kit which includes face plate, rails, and all rack mount hardware. Part number AG546A.
HP StorageWorks
AiO600 Common
Specifications
The steps outlined below are intended only as a guide for the options available. All options chosen are not be factory
The AiO600 is configured as a tower but can easily be converted to a rackable array by installing the AiO600 Tower to
Processor
Memory
Operating System
Storage Controller
Optical Drive
Network Controller
Form Factor
Power Supply
Cooling Fans
Remote Management
Protocol Support
iSCSI Initiator Support
Dual Core Intel Xeon 2.67 GHz/1333 MHz FSB with 4MB (1 x 4MB) L2
Cache (Up to 2 processors supported)
1 GB of memory standard, expandable to 4 GB
Windows Storage Server 2003 Release 2, Standard Edition
Smart Array E200i Controller with 128MB BBWC
HP DVD+R/RW 16X Half Height internal
Embedded NC373i Multifunction Gigabit Network Adapter with TCP/IP
Offload Engine plus additional Dual port NC360T 10/100/1000T
5U tower or rack mount with optional conversion kit
Standard dual Hot-Plug redundant power supplies
Standard two system fans plus redundant set of two system fans
Remote management User Interface (UI), Remote Desktop, or Telnet.
Integrated Lights Out 2 (iLO2)
SMB/CIFS, NFS, NCP, AppleTalk, HTTP, FTP
Compliant with iSCSI industry standards and compatible with industry
standard iSCSI initiators. Interoperability has been verified for Windows
2000, Windows Server 2003, VMware ESX Server 3, SUSE Linux
Enterprise Server 10, RedHat Enterprise Linux 5, and Qlogic 4050c
(AiO600)
HP StorageWorks
AiO600 1.5TB SATA
Model
AG536A (Americas)
AG537A (AP)
AG538A (EMEA)
AG539A (Aust)
HP StorageWorks
AiO600 3.0TB SATA
Model
AG541A (Americas)
AG542A (AP)
AG543A (EMEA)
AG544A (Aust)
Internal Storage
Internal Storage
6 x 250GB front loading, hot plug, 7200 RPM SATA HDDs
6 x 500GB front loading, hot plug, 7200 RPM SATA HDDs
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 11
QuickSpecs
Product Configuration Wizard
HP StorageWorks 600 All-in-One Storage System
(AiO600)
HP StorageWorks
AiO600 876GB SAS
Model
AG547A (Americas)
AG548A (AP)
AG549A (EMEA)
AG550A (Aust)
HP StorageWorks
AiO600 1.8TB SAS
Model
AG725A (Americas)
AG726A (AP)
AG727A (EMEA)
AG728A (Aust)
Internal Storage
Internal Storage
Step 2 - Select expansion options
Additional Processor
Dual-Core Intel Xeon Processor 5150 (2.67 GHz, 1333 FSB)
6 x 146GB front loading, hot plug, 15,000 RPM Serial Attached SCSI
(SAS) HDDs
6 x 300GB front loading, hot plug, 15,000 RPM Serial Attached SCSI
(SAS) HDDs
416890-B21
Additional Memory
for AiO600
SCSI Host Bus
Adapter for backup
SAS Host Bus
Adapter for backup
SCSI Controllers for
External Drive/Storage
Support
(PCI-X)
NOTE:
memory and is expandable to OS limit of 4 GB
512 MB FBD PC2-5300 1 x 512 MB Kit
1 GB FBD PC2-5300 2 x 512 MB Kit
2 GB FBD PC2-5300 2 x 1 GB Kit
4 GB FBD PC2-5300 2 x 2 GB Kit
NOTE:
than one DIMM is installed. For interleaving, DIMMs must be configured in identical
pairs. The system will not boot properly if multiple DIMMs of varying density or type
are installed in the system.
HP 64-bit/133-MHz single channel Ultra320 SCSI host bus adapter G2
HP SC11Xe Host Bus Adapter
HP SC44Ge Host Bus Adapter
Smart Array 6402/128
NOTE:
Smart Array 6404/256
NOTE:
Smart Array 642
NOTE:
Every HP All-in-One 600 Storage System comes standard with 1 GB of
The HP AiO600 Storage System requires memory interleaving when more
Ultra320 SCSI. 4 external ports
Ultra320 SCSI. 2 external ports.
Ultra320 SCSI. 1 external port
413507-B21
397409-B21
397411-B21
397413-B21
374654-B21
412911-B21
416096-B21
273915-B21
273914-B21
291967-B21
SAS Controller for
External Drive Support
(PCI-e)
HP Smart Array P600 Controller
NOTE:
512 MB Battery-Backed Cache Upgrade
NOTE:
Array P600 Controller and the Smart Array 6400 series Controller.
HP Smart Array P800/512 BBWC Controller
For more information on these or other Smart Array controllers please visit
http://h18004.www1.hp.com/products/servers/proliantstorage/
arraycontrollers/index.html
Requires Mixed PCI-E/X riser cage.
This 512-MB Battery-Backed Cache Module upgrade kit supports the Smart
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
337972-B21
372538-B21
381513-B21
Page 12
QuickSpecs
Product Configuration Wizard
HP StorageWorks 600 All-in-One Storage System
(AiO600)
Networking
Communications
Embedded NC373i Multifunction Gigabit Server Adapter with TCP/IP Offload
Engine standard. Select additional cards for higher performance and further
redundancy.
NOTE:
Server 2003 Scalable Networking Pack (a free download from Microsoft) to enable
TCP Chimney offload (TOE), Receive-side Scaling (RSS), and Network Direct Memory
Access (NetDMA) features. The iSCSI Acceleration Pack component Multifunction
network adapters are not supported on the iSCSI Target.
HP NC110T PCI Express Gigabit Server Adapter
HP NC150T PCI 4-port Gigabit 1000T Combo Switch Adapter
HP NC310F PCI-X 1000SX Gigabit Server Adapter
HP NC340T PCI-X 4-port 1000T Gigabit Server Adapter
HP NC360T PCI Express Dual Port Gigabit Server Adapter
HP NC373T PCI Express Multifunction Gigabit Server Adapter
HP NC373F PCI Express Multifunction Gigabit Server Adapter
HP NC380T PCI Express Dual Port Multifunction Gigabit Server Adapter
HP NC510F PCIe 10 Gigabit Server Adapter
NOTE:
NC510F adapter.
HP NC510C PCIe 10 Gigabit Server Adapter
NOTE:
NC510C adapter.
NOTE:
redundancy with the embedded NC373i Multifunction Gigabit NIC. When teaming
with other NICs or with the embedded NIC, the lack of Jumbo Frames and LSO
features on the NC1020 will cause high end NICs to have those features disabled.
2006 Agere PCI high-speed international soft modem
Multifunction Server Adapters require installation of the Microsoft Windows
A minimum of 1 gigabyte (1 GB) of server memory is required per each
A minimum of 1 gigabyte (1 GB) of server memory is required per each
Any NIC (except the NC1020) on the option list can be used for
434905-B21
367132-B21
368169-B21
391661-B21
412648-B21
394791-B21
394793-B21
394795-B21
414126-B21
414129-B21
Tower to Rack
Conversion Kit
AiO600 Tower to Rack Conversion Kit
Shipping Bracket for Round Hole Racks
NOTE:
round hole rack.
This kit is required if the system will be configured and shipped within a
Step 3 - add optional Data Protector Express extensions
NOTE:
extensions are required to backup file or iSCSI block data but the following extensions can be added for advanced functionality.
(
NOTE:
such as Bare Metal Recovery or Disk-to-Disk-to-Any functionality)
Additional extensions are available if you are enabling network backup from clients or servers to the AiO as a backup target.
For more information on HP Data Protector Express please visit
Optional extensions
HP All-in-One Storage Systems ship with the HP StorageWorks Data Protector Express Backup server LTU. No functional
This is the backup server LTU component of Data Protector Express and does not include any add-on licenses for features
http://www.hp.com/go/dataprotectorexpress
HP StorageWorks Data Protector Express D2D2Any LTU
HP StorageWorks Data Protector Express Drive Expansion (1incremental drive) LTU
AG546A
371482-B21
.
BB130AA
BB133AA
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 13
HP StorageWorks 600 All-in-One Storage System
QuickSpecs
Product Configuration Wizard
Step 4 - add external storage disk array for additional capacity
(AiO600)
NOTE:
All-in-One Storage System as well as direct attached MSA storage enclosures. ASM also supports management of tiered storage
environments where both SCSI/SAS or SATA hard drives are attached to the All-in-One Storage System.
External storage enclosure support matrix for HP All-in-One Storage Systems
System
AiO600
AiO600
AiO600
NOTE:
http://h18006.www1.hp.com/storage/disk_storage/msa_diskarrays/drive_enclosures/index.html
HP StorageWorks
Modular Smart Array 20
The latest version of the HP All-in-One Storage Manager (ASM) does support management of both internal storage on the
Enclosure
MSA20
MSA30
MSA50
MSA70
MSA60
For more information on storage enclosures from HP, including product QuickSpecs, please visit
HP StorageWorks Modular Smart Array 20 (SATA)
NOTE:
redundant power supplies.
HP StorageWorks Modular Smart Array 20 Starter Kit
NOTE:
redundant power supplies. Includes Smart Array 6402/128 Controller.
NOTE:
3.5" Hot Plug Hard Drives.
Rack-mountable 12 (SATA) drive enclosure with U320 Host connectivity and
Rack-mountable 12 (SATA) drive enclosure with U320 Host connectivity and
The Modular Smart Array Enclosure 20 Family supports the SATA 1.5Gb/s
Quantity
Supported
1 per SCSI VHDCI connector
2 per connector (supports 1+1
cascading)
4 per connector (supports 1+3
cascading)
Host Controller or Adapter
Smart Array 642 Controller
Smart Array 6402/128 Controller
Smart Array 6404/256 Controller
HP Smart Array P600/256 BBWC
Controller
HP Smart Array P800/512 BBWC
Controller
HP Smart Array P800/512 BBWC
Controller
335921-B21
366172-B21
HP StorageWorks
Modular Smart Array 30
HP StorageWorks
Modular Smart Array 50
HP StorageWorks
Modular Smart Array 60
HP StorageWorks
Modular Smart Array 70
HP StorageWorks Modular Smart Array 30 SB (SCSI)
NOTE:
power supplies
HP StorageWorks Modular Smart Array 30 DB (SCSI)
NOTE:
power supplies
NOTE:
Ultra320 Hot Plug Hard Drives.
HP StorageWorks Modular Smart Array 50 (SAS)
NOTE:
Form Factor(SFF) SAS or Serial ATA(SATA) drives.
HP StorageWorks Modular Smart Array 60 (SAS)
NOTE:
Serial ATA (SATA) drives.
HP StorageWorks 70 Modular Smart Array
NOTE:
connectivity and redundant power supplies.
Rack-mountable 14 (SCSI) drive enclosure with single bus and redundant
Rack-mountable 14 (SCSI) drive enclosure with dual bus and redundant
The Modular Smart Array Enclosure 30 Family supports the Wide Ultra3 or
1U Serial Attach SCSI(SAS) disk drive storage enclosure supporting Small
High capacity 2U disk drive storage enclosure supporting 12 3.5" SAS or
Rack-mountable 25 drive (2.5" SAS/SATA) enclosure with 3Gb/s SAS host
302969-B21
302970-B21
364430-B21
418408-B21
418800-B21
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 14
QuickSpecs
Product Configuration Wizard
Step 5 - add tape backup solution
HP StorageWorks 600 All-in-One Storage System
(AiO600)
NOTE:
http://www.hp.com/go/tape
please visit:
detailed connectivity information.
Tape Drives
Tape Autoloaders
For more information on the complete HP StorageWorks tape backup portfolio, please visit
http://www.hp.com/go/connect
. For an up-to-date listing of the latest O/S and software support details for HP Ultrium tape drives,
. Please consult the EBS connectivity matrix at
HP StorageWorks Ultrium Tape Drive
HP StorageWorks Ultrium 960 Internal Tape Drive (800 GB compressed capacity)
HP StorageWorks Ultrium 960 External Tape Drive (800 GB compressed capacity)
HP StorageWorks Ultrium 960 Rack-Mount (800 GB compressed capacity)
- single drive installed in a 3U Rack-mount kit
HP StorageWorks Ultrium 920 Internal Tape Drive (800 GB compressed capacity)
HP StorageWorks Ultrium 920 External Tape Drive (800 GB compressed capacity)
HP StorageWorks Ultrium 920 Rack-Mount (800 GB compressed capacity)
- single drive installed in a 1U Rack-mount kit
HP StorageWorks Ultrium 448 Internal Tape Drive (400 GB compressed capacity)
HP StorageWorks Ultrium 448 External Tape Drive (400 GB compressed capacity)
HP StorageWorks 1/8 Tape Autoloader
HP 1/8 G2 Ultrium 920 Tape Autoloader
HP 1/8 G2 Ultrium 448 Tape Autoloader
1/8 Tape Autoloader Rackmount Kit
NOTE:
rackmount instructions
NOTE:
http://www.hp.com/go/automation
Required to install the unit in a standard 19-inch rack; includes rails and
Please reference the 1/8 Tape Autoloader QuickSpecs at
for additional information.
http://www.hp.com/go/ebs
for
Q1538A
Q1539B
Q1595B
EH841A
EH842A
EH903A
DW016A
DW017B
AH165A
AH164A
C9268R
Tape Libraries
HP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 1 Ultrium 960 Drive Library
HP StorageWorks MSL2024 1 Ultrium 448 Drive Library
HP StorageWorks MSL2024 2 Ultrium 448 Drive Library
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 1 Ultrium 448 Drive Library
HP StorageWorks MSL4048 2 Ultrium 448 Drive Library
HP StorageWorks MSL4048 1 Ultrium 920 SAS Drive Library
HP StorageWorks MSL4048 1 Ultrium 920 Drive Library
HP StorageWorks MSL4048 2 Ultrium 920 Drive Library
HP StorageWorks MSL4048 1 Ultrium 960 Drive Library
HP StorageWorks MSL4048 2 Ultrium 960 Drive Library
NOTE:
http://www.hp.com/go/automation
Please reference the MSL2024 and MSL4048 Tape Library QuickSpecs at
for additional information.
AG115A
AG116A
AG117A
AG320A
AG321A
AH560A
AH171A
AH172A
AG322A
AG323A
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 15
QuickSpecs
Product Configuration Wizard
Step 6 - add HP CarePack services
HP StorageWorks 600 All-in-One Storage System
(AiO600)
AiO600 CarePacks
HP 1y Support Plus AiO600 SVC
HP 1y Support Plus24 AiO600 SVC
HP 1y 6h 24x7 CTR AiO600 HW Supp
HP 3y Support Plus AiO600 SVC
HP 3y Support Plus24 AiO600 SVC
HP 3y 6h 24x7 CTR AiO600 HW Supp
HP 1y PW Support Plus AiO600 SVC
HP 1y PW Support Plus24 AiO600 SVC
HP Installation
UE981E
UE982E
UE983E
UE984E
UE985E
UE986E
UE987PE
UE988PE
UF285E
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 16
QuickSpecs
Additional Specifications
HP StorageWorks 600 All-in-One Storage System
(AiO600)
AiO600 Additional
Specifications
Dimensions
(with feet/bezel)
Weight
Shipping Size
Input Requirements
(per power supply)
Rated Line Frequency
BTU Rating
Power Supply Output
Power
(per power supply)
Temperature Range
Maximum Wet Bulb
Temperature
Relative Humidity
(non-condensing)
Acoustic Noise
(HxWxD)
(approximate)
18.43 x 8.66 x 25.2 in (46.8 x 22 x 64 cm)
60 lb (27.24 kg) (without hard drives)
35.13 x 23.63 x 15.75 in (89.23 x 60.02 x 40.01cm)
Rated Input Voltage
Rated Input Frequency
Input Power
Rated Input Current
50 to 60 Hz
4112BTU/hr
Rated Steady-State Power
Operating
Storage (up to one year)
82.4° F (28° C)
Operating
Non-operating
Idle
(Fixed Disk Drives
Spinning)
L
WAd (BELS)
L
pAm (dBA)
Operating
(Random Seeks to Fixed
Disks)
L
WAd (BELS)
L
pAm (dBA)
100-120 VAC / 200-240VAC
50 Hz to 60 Hz
<1000W @ 90VAC
<1050W @ 115VAC
<1205W @ 180VAC
10A(100VAC),6.7A(200VAC)
180VAC
800W at 120V or 1000W at 220V
50° to 95° F (10° to 35° C)
(No direct sustaining sunlight)
40° to 158° F (-40° to 70° C)
10% to 90%
5% to 90%
6.0
43
6.0
43
© Copyright 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel
Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
DA - 12786 Worldwide QuickSpecs — Version 3 — 9.12.2007
Page 17
Loading...
