HP 9470M User Manual
QuickSpecs
Overview
HP EliteBook Folio 9470m
1.
WLAN antennas (2)
2.
WWAN antennas (2)
3.
Dual-microphone array
4.
Webcam light (only with configurable webcam)
5.
Configurable 720p HD webcam
6.
Wireless on/off button with LED indicator
7.
Volume mute button with LED indicator
8.
RJ-45/Ethernet port
9.
Docking connector
DA - 14317 North America — Version 10 — August 15, 2013
10.
VGA/external monitor connector
11.
DisplayPort 1.1a
12.
(2) USB 3.0 ports
13.
Pointstick
14.
Pointstick pick buttons
15
Touchpad
16.
Touchpad pick buttons
17.
Power button
Page 1
QuickSpecs
HP EliteBook Folio 9470m
Overview
1.
Power connector
2.
Security lock slot
3.
USB 3.0 charging port
4.
Headphone/Microphone combo port
5.
Smart Card Reader
At A Glance
Windows 8 Pro, Windows 7 versions or FreeDOS
Magnesium display enclosure, magnesium-reinforced chassis, wear-resistant platinum-colored HP DuraFinish, HP DisplaySafe
frame, HP DuraKeys, precision metal-alloy hinges, aluminum keyboard deck, and chemically strengthened glass touchpad
Choice of 3rd Generation Intel® Core™ i7 and i5 with Turbo Boost Technology
Integrated Intel® HD Graphics 4000
14.0-inch diagonal HD or HD+ widescreen LED-backlit display
Choice of 7200 rpm user-removable hard drive (up to 500 GB) with HP 3D DriveGuard, 500 GB 7200 rpm Self Encrypting Hard
Drive, 256 GB Self Encrypting Solid State Drive, 240 GB Solid State Drive, 128 GB Solid State Drive, 180 GB Solid State Drive, or
256 GB mSATA Solid State Drive
Optional 32 GB mSATA Flash Cache module support for Intel Smart Response Technology. (Available only with standard non-SED
hard drive).
Built-in docking for a desktop-like experience
DisplayPort for high resolution support
SRS PRO Audio™ optimized for high fidelity audio during video conferencing and web-based training
4-cell (52 WHr) HP Long Life battery and 6-cell (60WHr) HP Long Life slice battery for extended battery life
Glass touchpad with chemically etched surface and pointstick
Integrated Smart Card Reader and configurable fingerprint reader for strong security authentication
HP Premier Image with Microsoft Security Essentials and without trialware
Flexible wireless connectivity options:
Optional integrated wireless mobile broadband 3G and 4G/LTE support (no Win 8 support)
Integrated Intel Centrino® 802.11 a/b/g/n 2x2 + BT Combo 4.0 HS, 802.11 a/b/g/n 2x2 + BT Combo 4.0 HS or 802.11 b/g/n
2x2 + BT Combo 4.0 HS
Low Halogen*, ENERGY STAR qualified (with Microsoft OS) and EPEAT Gold registered in the U.S. (with Microsoft OS). EPEAT
status varies by country- please see
epeat.net
.
* Meeting the industry definition of 'Low Halogen' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts
incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate
laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be Low Halogen.
External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable internal
component: ATT SIM card, are not Low Halogen.
DA - 14317 North America — Version 10 — August 15, 2013
Page 2
QuickSpecs
HP EliteBook Folio 9470m
Features
OPERATING SYSTEM
Preinstalled
Supported
Certified
* Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased
hardware, drivers and/or software to take full advantage of Windows 8 functionality. See
** This system is preinstalled with Windows® 7 Pro software and also comes with a license and media for Windows 8 Pro software.
You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one
version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating
systems to avoid loss of your data.
*** Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased
hardware to take full advantage of Windows 7 functionality. See
Windows 8 Pro 64*
Windows 8 64*
Windows 7 Professional 32 (available through downgrade rights from Windows 8 Pro 64)**
Windows 7 Professional 64 (available through downgrade rights from Windows 8 Pro 64)**
Windows 7 Professional 32***
Windows 7 Professional 64***
Windows 7 Home Premium 32***
Windows 7 Home Premium 64***
FreeDOS
Windows 7 Enterprise 32***
Windows 7 Enterprise 64***
Windows 7 Ultimate 32***
Windows 7 Ultimate 64***
Windows 7 Home Basic 64***
Windows XP Professional 32
SUSE Linux Enterprise Desktop 11
http://www.microsoft.com
microsoft.com/windows/windows-7/
for details.
for details.
PROCESSOR
3rd Generation Intel® Core™ i7-3667U (2.0 GHz, 4 MB L3 cache, 2 cores)*
Up to 3.20 GHz with Intel Turbo Boost Technology
3rd Generation Intel® Core™ i5-3427U (1.8 GHz, 3 MB L3 cache, 2 cores)*
Up to 2.80 GHz with Intel Turbo Boost Technology
3rd Generation Intel® Core™ i5-3317U (1.7 GHz, 3 MB L3 cache, 2 cores)* not available with Intel iAMT†
Up to 2.60 GHz with Intel Turbo Boost Technology
† Not available with vPro
* Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a computer system with a
processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not
operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your
hardware and software configurations. Intel's numbering is not a measurement of higher performance.
NOTE:
Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
CHIPSET
Mobile Intel QM77 Express
DA - 14317 North America — Version 10 — August 15, 2013
Page 3
QuickSpecs
HP EliteBook Folio 9470m
Features
INTEL CORE I5 WITH VPRO/CORE I7 WITH VPRO TECHNOLOGY CAPABLE
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with select
processors, an Intel Centrino® Advanced-N or Ultimate-N WLAN module and a preinstalled Windows operating system. It provides
advances in remote manageability, security, energy efficient performance, and wireless connectivity. Intel Active Management
Technology 8.0 (iAMT) offers built-in manageability and proactive security for networked notebook PCs, even when they are
powered off* or when the operating system is inoperable. It can help identify threats before they reach the network, isolate
infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-VPN)
corporate network connection which is either cable or wireless LAN.
NOTE:
Some functionality of Intel® Core i5 with vPro/Core i7 with vPro technology, such as Intel® Active Management technology
and Intel® Virtualization technology, requires additional third- party software in order to run. Availability of future "virtual
appliances" applications for Intel® Core i5 with vPro/Core i7 with vPro technology is dependent on third- party software providers.
Compatibility with future "virtual appliances" is yet to be determined.
GRAPHICS
Integrated:
Intel HD Graphics 4000
DISPLAY
Internal
14.0" diagonal LED-backlit HD 16:9 widescreen anti-glare (1366 x 768)
External
Up to 32-bit per pixel color depth
DisplayPort
Supports resolutions up to 2560 x 1600, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120
Hz
VGA
Port supports resolutions up to 2048 x 1536 at 75 Hz, and lower resolutions at up to 100 Hz
Internal
14.0" diagonal LED-backlit HD+ 16:9 widescreen anti-glare (1600 x 900) 3.0mm
External
Up to 32-bit per pixel color depth (250 nits)
DisplayPort
Supports resolutions up to 2560 x 1600, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120
Hz
VGA
Port supports resolutions up to 2048 x 1536 at 75 Hz, and lower resolutions at up to 100 Hz
NOTE:
Resolutions are dependent upon monitor capability, and resolution and color depth settings.
DA - 14317 North America — Version 10 — August 15, 2013
Page 4
QuickSpecs
HP EliteBook Folio 9470m
Features
FLASH CACHE MODULE
Optional 32 GB mSATA Flash cache module support for Intel Smart Response Technology. (Available only with standard non-SED
hard drive).
STORAGE AND DRIVES
Primary Storage Bay
Hard Drives
320/500GB 7200 rpm SMART SATA II
500 GB 7200 rpm SMART SATA II Self Encrypting Drive
HP 3D DriveGuard (Windows only)
The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive.
Solid State Drive
SATA 6 Gb/s 180 GB Solid State
SATA 6 Gb/s 240 GB Solid State
SATA 6 Gb/s 256 GB Solid State
mSATA module
256 GB mSATA module
NOTE:
For hard drives and solid state drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 7)
and up to 36 GB (for Windows 8) of system disk is reserved for the system recovery software.
NOTE:
The EliteBook Folio is available in standard thin and light configurations for customers who value the ultra-thin design but
prefer options such as a standalone HDD or require a self-encrypting hard drive. These configurations will not meet Intel's
definition of an Ultrabook.
MEMORY
Standard
DDR3 PC3-12800 SDRAM (1600 MHz)
Two SODIMM slots supporting dual-channel memory
Standard memory up to 8192 MB (2 GB, 4 GB, and 8 GB SODIMMs)
Maximum
Upgradeable to 16384 MB with optional 8192 MB SODIMMs in slots 1 and 2
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. With Windows Starter 32bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may
not be available due to system resource requirements.
DA - 14317 North America — Version 10 — August 15, 2013
Page 5
QuickSpecs
HP EliteBook Folio 9470m
Features
NETWORKING/COMMUNICATIONS
Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry
standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries. Wireless LAN
and integrated Bluetooth are also available (both are factory configurable only) and can be combined with any of the supported
wireless WAN options.
Broadband Wireless (WWAN)
HP hs2350 HSPA+ Mobile Broadband Module
HP un2430 EV-DO/HSPA Mobile Broadband Module
HP lt2522 LTE/EV-DO Mobile Broadband Module- U.S. only* (no Win 8 support)
HP lt2523 LTE/HSPA+Mobile Broadband Module- U.S. only* (no Win 8 support)
Integrated wireless LAN options
Intel Centrino Advanced-N 6205 802.11a/b/g/n (2x2)
Intel Centrino Advanced-N 6235 802.11a/b/g/n (2x2) + BT Combo 4.0 HS
802.11 b/g/n + BT (1x1)
802.11 a/b/g/n + BT (1x1)
Communications
Integrated Intel 82579LM Gigabit* Network Connection (vPro)
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network
infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do
not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.
(Win 8 WWAN support will not be available at Win 8 introduction)
AUDIO/MULTIMEDIA
Audio
SRS PRO Audio™
Integrated stereo speakers
Integrated dual-microphone array
Button for volume mute; function keys for volume up and down
Headphone/Microphone combo port
Webcam
720p HD webcam (configurable)
HD format (widescreen)
Supports videoconferencing and still image capture
High quality fixed focus lens
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and videoconferencing
Improved low light sensitivity
Improved dynamic range
DA - 14317 North America — Version 10 — August 15, 2013
Page 6
QuickSpecs
HP EliteBook Folio 9470m
Features
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
The HP spill-resistant, backlit keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that
funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components
underneath. The 101/102-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as the
isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, 12 function keys, and 19.05 x 19.05
mm key pitch (center-to-center spacing). U.S. and International key layouts are available. Other features include hot keys for
instant access to power conservation and brightness.
Pointing Devices
Glass Touchpad (with chemically etched surface) with on/off button, two finger scrolling, pinch zoom, rotating and three-finger
flick gestures, two pick buttons
Pointstick with two additional pointstick buttons (for a total of four)
Buttons and Function Keys
Discrete buttons provide easy access to the following features: wireless on/off, and volume mute. Function keys provide control
of the following features: sleep mode, external display switching, volume down, volume up, microphone mute, backlit keyboard,
and display brightness.
SOFTWARE AND SECURITY
Preinstalled Software with Windows Operating System
HP Wireless Hotspot (Windows 8 and web only)
HP Connection Manager (Windows 7 only)
HP Hotkey Support
HP ProtectTools for Central Management
HP ProtectTools Security Manager
HP Recovery Manager
HP Support Assistant
Adobe® Flash Player (Windows 7 only)
HP Premier Image
Cyberlink PowerDVD
Evernote
HP 3D DriveGuard
Microsoft Office 2010 60 days trial (Windows 8 only)
Microsoft Office Starter (Windows 7 only): reduced-functionality Word and Excel® only, with advertising. No PowerPoint® or
Outlook®. Buy Office 2010 to use the full-featured software.*
Buy Microsoft Office to activate Office Software on this PC.
PDF Complete Corporate Edition
Supports UEFI specification 2.3
WinZip Basic (Windows 7 only)
NOTE:
HP Recovery Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if
important system files are accidentally deleted. Up to 30 GB (for Windows 7) and up to 36 GB (for Windows 8) of system disk is
reserved for the system recovery software.
* Includes reduced functionality versions of Word and Excel. Purchase of Product Key required to activate full Office 2010 suite
available at participating resellers/retailers and
Security
Standard
DA - 14317 North America — Version 10 — August 15, 2013
http://www.office.com
.
Page 7
QuickSpecs
Features
HP Client Security (Windows 8 only),
Central Management for HP ProtectTools*
Credential Manager for HP ProtectTools
Device Access Manager w/ JITA
Drive Encryption (will be web-only ready at Win8 GA date)
Enhanced Pre-Boot Security
Face Recognition
File Sanitizer for HP ProtectTools (Windows 7 only)
HP BIOS Protection
HP ProtectTools
HP Spare Key (requires initial user setup)
Intel Rapid Start Technology* *
Intel Smart Response Technology***
Microsoft Defender
Microsoft Security Essentials (included with Microsoft Defender for Windows 8)
One Step Logon
Smart Card Reader
Security lock slot
TPM Embedded Security Chip 1. 2
HP Fingerprint Reader (configurable)
HP EliteBook Folio 9470m
Optional
Computrace (requires a subscription)
Intel Anti-Theft Technology (requires a Computrace subscription)
NOTE
: Computrace agent is shipped turned off, and must be activated by customers when they purchase a subscription.
Subscriptions can be purchased for terms ranging from one to five years. Service is limited, check with Absolute for availability
outside the U.S.
*In order to deploy and receive updated policies, the client needs to be connected to the network server and requires separately
purchased DigitalPersona Pro software. System access may not prevent users from logging into the system on the first attempt if
policy updates haven't yet been received and applied. Requires Microsoft Windows.
** Requires a compatible Intel® Core processor, Intel® Rapid Start software and BIOS update, and optional Solid State Drive (SSD)
or mSATA flash cache module. Depending on system configuration, results may vary.
***Requires a compatible Intel® Core processor, enabled chipset, Intel® Rapid Storage technology software and non-SED HDD +
optional mSATA SSD flash cache module. Intel® Smart Response Technology is only available on select 2012 HP systems.
Depending on system configuration, results may vary.
For more information on HP security solutions refer to:
http://www.hp.com/go/security
DA - 14317 North America — Version 10 — August 15, 2013
Page 8
QuickSpecs
HP EliteBook Folio 9470m
Features
POWER
Power Supply
Models with integrated graphics with dual-core processor:
External 45W HP Smart AC Adapter
Power cord included is 6-foot (1.8 meter).
Total length including external AC adapter is 12 feet (3.66 meter).
Primary Battery
HP 4-cell Lithium-Ion Long Life Battery (52 WHr)
Slice Battery
HP 6-cell Lithium-Ion Long Life Battery (60 WHr)
Battery Life*
HP EliteBook Folio 9470m (Hard Drive)
4-cell (52 WHr) Primary
4-cell (52 WHr) Primary and
6-cell (60 WHr) Slice
HP EliteBook Folio 9470m (Solid State Drive)
4-cell (52 WHr) Primary
4-cell (52 WHr) Primary and
6-cell (60 WHr) Slice
HP EliteBook Folio 9470m (mSATA module)
4-cell (52 WHr) Primary
4-cell (52 WHr) Primary and
6-cell (60 WHr) Slice
System Standby Time
Deep sleep enabled: with main battery - 3 weeks 2 days
*Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality
and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See
MobileMark07 battery benchmark
Power Conservation
Hibernation
Standby
ACPI compliance
Up to 8 hours and 30 minutes
Up to 19 hours
Up to 9 hours and 30 minutes
Up to 21 hours and 15 minutes
Up to 10 hours
Up to 21 hours and 45 minutes
http://www.bapco.com/products/mobilemark2007
for additional details.
DA - 14317 North America — Version 10 — August 15, 2013
Page 9
QuickSpecs
Features
ENVIRONMENTAL
ENERGY STAR qualified (with Microsoft OS)
BFR/PVC-free (does not cover adapters and power cords)
IT ECO Declaration
EPEAT Gold where HP registers commercial notebook products. See
NOTE:
This product has received or is in the process of being certified to the following approvals and may be labeled with one or
more of these marks.
WEIGHTS & DIMENSIONS
Weight
Starting at 3.56 lb (1.61 kg)
Dimensions
13.3 x 9.09 x 0.75 in
33.8 x 23.1 x 1.895 cm
NOTE:
Weight varies by configuration and components.
(w x d x h)
Weight varies by configuration and components. Weight includes 4-cell battery, mSATA solid state drive, and 4 GB memory.
epeat.net
HP EliteBook Folio 9470m
for registration status in your country.
PORTS/SLOTS
Ports
VGA – One
DisplayPort – One (v1.1a)
Headphone/Microphone combo port – One
Power Connector – One
Secondary Battery Connector – One
Docking Connector – One
RJ-45 (Ethernet) – One
USB 3.0 – Two
USB 3.0 charging port – One
Digital Media Slots
1 SD/MultiMediaCard slot (supported media include: SD, SDHC, SDXC, MultiMediaCard, MultiMediaCard+)
SERVICE AND SUPPORT
HP Services offers limited 1-year standard parts and labor limited warranty, pick-up or carry-in, and toll-free 7x24 hardware
technical phone support; 1 year limited warranty on primary battery. On-site service and extended service contracts are also
available.
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
hp.com/bizsupport/TechSupport/ProductRoot.jsp
DA - 14317 North America — Version 10 — August 15, 2013
Page 10
QuickSpecs
HP EliteBook Folio 9470m
Technical Specifications
SYSTEM UNIT
Stand-Alone Power
Requirements
Temperature
Relative Humidity
Shock
Random Vibration
Altitude
Planned Industry
Standard
Certifications
* Configurations of the HP EliteBook Folio that are ENERGY STAR qualified are identified as HP EliteBook Folio ENERGY STAR on HP
websites and on
** EPEAT registration varies by country. See
(AC Power)
(unpressurized)
energystar.gov
Nominal Operating
Voltage
Average Operating Power
Max Operating Power
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
UL
CSA
FCC Compliance
ENERGY STAR®
EPEAT
ICES
Australia /
NZ A-Tick Compliance
CCC
Japan VCCI Compliance
KC
BSMI
CE Marking Compliance
BNCI or BELUS
CIT
GOST
Saudi Arabian Compliance
(ICCP)
SABS
UKRSERTCOMPUTER
.
epeat.net
18.5 V
Windows 7 (32-bit) Windows 7 (64-bit)
6.06 W 6.18 W
< 45 W
32° to 95° F (0° to 35° C) (not writing optical)
-4° to 140° F (-20° to 60° C)
10% to 90%, non-condensing
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
40 G, 2 ms, half-sine
200 G, 2 ms, half-sine
0.75 grms
1.50 grms
-50 to 10,000 ft (-15.24 to 3,048 m)
-50 to 40,000 ft (-15.24 to 12,192 m)
Yes
Yes
Yes
Select models (Microsoft OS)*
Registered Gold in United States**
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
for registration status by country.
DA - 14317 North America — Version 10 — August 15, 2013
Page 11
QuickSpecs
Technical Specifications
EPEAT status listed above applies to U.S.
HP EliteBook Folio 9470m
For accessibility information on HP products, please visit:
DISPLAY
14.0-inch LED HD+ (1600 x
900) anti-glare
Dimensions
Diagonal Size
Surface Treatment
Contrast Ratio
Refresh Rate
Brightness
Pixel Resolution
Backlight
PPI
Viewing Angle
(W x H)
12.64 x 8.11 in (32.1 x 20.6 cm)
14.0 in (35.6cm)
Anti-glare
300
60 Hz
250 nit (typical)
Pitch
Format
Configuration
LED
131 ppi
±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
hp.com/accessibility
.
0.1935 mm
1600 x 900
RGB Stripe
14.0-inch LED HD+ (1600 x
900) anti-glare
Dimensions
Diagonal Size
Surface Treatment
Contrast Ratio
Refresh Rate
Brightness
Pixel Resolution
Backlight
PPI
Viewing Angle
STORAGE AND DRIVES
(W x H)
12.64 x 8.11 in (32.1 x 20.6 cm)
14.0 in (35.6cm)
Anti-glare
300
60 Hz
250 nit (typical)
Pitch
Format
Configuration
LED
131 ppi
±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
0.1935 mm
1600 x 900
RGB Stripe
DA - 14317 North America — Version 10 — August 15, 2013
Page 12
Loading...
