HP 7000 Reference Guide

SROS Command Line Interface

Reference Guide

Software Version J.02.01 or Greater

April 2005 61195880L1-35B

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.

Publication Number

5991-2114 January 2005

Applicable Products

ProCurve Secure Router 7102dl (J8752A) ProCurve Secure Router 7203dl (J8753A)

Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. CompactFlash is a U.S. registered trademark of the CompactFlash Association. AOL Instant Messenger (AIM) is a U.S. registered trademark of American Online, Inc. Quake is a U.S. registered trademark of id Software, Inc. ICQ is a U.S. registered trademark of ICQ, Inc. pcAnywhere is a U.S. trademark of Synamtec Corporation.

Disclaimer

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

Warranty

See the Customer Support/Warranty booklet included with the product.

A copy of the specific warranty terms applicable to your HewlettPackard products and replacement parts can be obtained from your HP Sales and Service Office or authorized dealer.

SROS Command Line Interface Reference Guide

Table of Contents

Basic Mode Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Enable Mode Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Global Configuration Mode Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

DHCP Pool Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355

IKE Policy Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373

IKE Policy Attributes Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 386

IKE Client Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 392

Crypto Map IKE Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 396

Crypto Map Manual Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405

Radius Group Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 416

CA Profile Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 418

Certificate Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 429

Ethernet Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 433

DDS Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 486

Serial Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 494

T1 Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 504

DSX-1 Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 520

E1 Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 530

G.703 Interface Configuration Command set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 545

Modem Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 552

BRI Interface Configuration Command set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 556

Frame Relay Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 567

Frame Relay Sub-Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 587

ATM Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 644

ATM Sub-Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 647

ADSL Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 701

BGP Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 705

BGP Neighbor Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 711

PPP Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 715

Tunnel Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 778

HDLC Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 811

Loopback Interface Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 847

Line (Console) Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 876

Line (Telnet) Interface Config Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 887

Router (RIP) Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 894

Router (OSPF) Configuration Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 903

Quality of Service (QoS) Map Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 917

Common Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 922

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 936

Command Reference Guide CLI Introduction

REFERENCE GUIDE INTRODUCTION

This manual provides information about the commands that are available with all of the ProCurve Secure routers.

If you are new to the Operating System’s Command Line Interface (CLI), take a few moments to review the information provided in the section which follows (CLI Introduction).

If you are already familiar with the CLI and you need information on a specific command or group of commands, proceed to Command Descriptions on page 9 of this guide.

CLI INTRODUCTION

This portion of the Command Reference Guide is designed to introduce you to the basic concepts and strategies associated with using the Operating System’s Command Line Interface (CLI).

Accessing the CLI from your PC

All products using the are initially accessed by connecting a VT100 terminal (or terminal emulator) to the

CONSOLE port located on the rear panel of the unit using a standard DB-9 (male) to DB-9 (female) serial

cable. Configure the VT100 terminal or terminal emulation software to the following settings:

• 9600 baud

• 8 data bits

• No parity

• 1 stop bit

• No flow control

Note

For more details on connecting to your unit, refer to the Quick Configuration Guides and Quick Start Guides located on the Secure Router OS Documentation CD provided with your unit.

Understanding Command Security Levels

The has two command security levels — Basic and Enable. Both levels support a specific set of commands. For example, all interface configuration commands are accessible only through the Enable security level. The following table contains a brief description of each level.

Level Access by... Prompt With this level you can...

Basic beginning an SROS session.

• display system information

• perform traceroute and ping functions

• open a Telnet session

Command Reference Guide Understanding Configuration Modes

Level Access by... Prompt With this level you can...

Enable

Note

entering Basic command security level as follows:

enable

while in the

To prevent unauthorized users from accessing the configuration functions of your product,

• manage the startup and running configurations

• use the debug commands

• enter any of the configuration modes

immediately install an Enable-level password. Refer to the Quick Configuration Guides and Quick Start Guides located on the Secure Router OS Documentation CD provided with your unit for more information on configuring a password.

Understanding Configuration Modes

The Secure Router OS has four configuration modes to organize the configuration commands – Global, Line, Router, and Interface. Each configuration mode supports a set of commands specific to the configurable parameters for the mode. For example, all Frame Relay configuration commands are accessible only through the Interface Configuration Mode (for the virtual Frame Relay interface). The following table contains a brief description of each level.

Mode Access by... Sample Prompt With this mode you

can...

Global

entering command security level prompt. For example:

config

while at the Enable

>enable

config term

(config)#

• set the system’s Enable-level password(s)

• configure the system global IP parameters

• configure the SNMP parameters

• enter any of the other configuration modes

Line specifying a line (console or Telnet)

while at the Global Configuration Mode prompt. For example:

(config-con0)#

>enable #config term (config)#

line console 0

• configure the console terminal settings (datarate, login password, etc.)

• create Telnet logins and specify their parameters (login password, etc.)

Command Reference Guide Using CLI Shortcuts

Mode Access by... Sample Prompt With this mode you

can...

Router

entering

router ospf

Configuration Mode prompt. For example:

router rip router or

while at the Global

>enable #config term (config)#

Interface specifying an interface (T1, Ethernet,

Frame Relay, ppp, etc.) while in the Global Configuration Mode. For example:

router rip

>enable

(config-rip)#

(config-eth 0/1)#

(The above prompt is for the Ethernet on the rear panel of the unit.)

LAN

interface located

• configure RIP or OSPF parameters

• suppress route updates

• redistribute information from outside routing sources (protocols)

•configure parameters for the available LAN and WAN interfaces

#config term (config)#

int eth 0/1

Using CLI Shortcuts

The provides several shortcuts which help you configure your Secure Router OS product more easily. See the following table for descriptions.

Shortcut Description

Up arrow key To re-display a previously entered command, use the up arrow key. Continuing to press

the up arrow key cycles through all commands entered starting with the most recent command.

Tab key Pressing the <Tab> key after entering a partial (but unique) command will complete the

command, display it on the command prompt line, and wait for further input.

? The CLI contains help to guide you through the configuration process. Using the question

mark, do any of the following:

• Display a list of all subcommands in the current mode. For example:

(config-t1 1/1)#

coding ?

ami - Alternate Mark Inversion b8zs - Bipolar Eight Zero Substitution

• Display a list of available commands beginning with certain letter(s). For example:

(config)#

ip d?

default-gateway dhcp-server domain-lookup domain-name domain-proxy

• Obtain syntax help for a specific command by entering the command, a space, and then a question mark (?). The CLI displays the range of values and a brief description of the next parameter expected for that particular command. For example:

(config-eth 0/1)#

mtu ?

<64-1500> - MTU (bytes)

Command Reference Guide Performing Common CLI Functions

Shortcut Description

<Ctrl> + A Jump to the beginning of the displayed command line. This shortcut is helpful when using

the

form of commands (when available). For example, pressing <Ctrl + A> at the

following prompt will place the cursor directly after the

(config-eth 0/1)#

<Ctrl> + E Jump to the end of the displayed command line. For example, pressing <Ctrl + E> at the

following prompt will place the cursor directly after the

(config-eth 0/1)#

<Ctrl> + U Clears the current displayed command line. The following provides an example of the <Ctrl

+ U> feature:

(config-eth 0/1)#

ip address 192.33.55.6

(Press <Ctrl + U> here)

(config-eth 0/1)#

auto finish You need only enter enough letters to identify a command as unique. For example,

entering configuration parameters for the specified T1 interface. Entering would work as well, but is not necessary.

int t1 1/1

at the Global configuration prompt provides you access to the

interface t1 1/1

Performing Common CLI Functions

The following table contains descriptions of common CLI commands.

Command Description

The do command provides a way to execute commands in other command sets without taking the time to exit the current and enter the desired one. The following example shows the interface configuration while currently in the T1 interface command set:

(config)#

command used to view the Frame Relay

interface t1 1/1

(config-t1 1/1)#

To undo an issued command or to disable a feature, enter

before the command.

For example:

no shutdown t1 1/1

copy running-config startup-config

When you are ready to save the changes made to the configuration, enter this command. This copies your changes to the unit’s nonvolatile random access memory (NVRAM). Once the save is complete, the changes are retained even if the unit is shut down or suffers a power outage.

do show interfaces fr 7

show running config

Displays the current configuration.

Command Reference Guide Understanding CLI Error Messages

Command Description

debug

undebug all

Caution

The overhead associated with the debug command takes up a large portion of your

Use the may be experiencing on your network. These commands provide additional information to help you better interpret possible problems. For information on specific debug commands, refer to the section

Set

To turn off any active debug commands, enter this command.

debug

on page 20.

command to troubleshoot problems you

Enable Mode Command

product’s resources and at times can halt other processes. It is best to only use the debug command during times when the network resources are in low demand (non-peak hours, weekends, etc.).

Understanding CLI Error Messages

The following table lists and defines some of the more common error messages given in the CLI.

Message Helpful Hints

%Ambiguous command %Unrecognized Command

The command may not be valid in the current command mode, or you may not have entered enough correct characters for the command to be recognized. Try using the “?” command to determine your error. See

CLI Shortcuts

on page 6 for more information.

Using

%Invalid or incomplete command

%Invalid input detected at “^" marker

The command may not be valid in the current command mode, or you may not have entered all of the pertinent information required to make the command valid. Try using the “?” command to determine your error. See

Using CLI Shortcuts

The error in command entry is located where the caret (^) mark appears. Enter a question mark at the prompt. The system will display a list of applicable commands or will give syntax information for the entry.

on page 6 for more information.

Command Reference Guide Command Descriptions

COMMAND DESCRIPTIONS

This portion of the guide provides a detailed listing of all available commands for the CLI (organized by command set). Each command listing contains pertinent information including the default value, a description of all sub-command parameters, functional notes for using the command, and a brief technology review. To search for a particular command alphabetically, use the Index. To search for information on a group of commands within a particular command set, use the linked references given below:

Basic Mode Command Set

on page 10

Enable Mode Command Set on page 20 Global Configuration Mode Command Set on page 200 DHCP Pool Command Set on page 355 IKE Policy Command Set on page 373 IKE Policy Attributes Command Set on page 386 IKE Client Command Set on page 392 Crypto Map IKE Command Set on page 396 Crypto Map Manual Command Set on page 405 Radius Group Command Set on page 416 CA Profile Configuration Command Set on page 418 Certificate Configuration Command Set on page 429 Ethernet Interface Configuration Command Set on page 433 DDS Interface Configuration Command Set on page 486 Serial Interface Configuration Command Set on page 494 T1 Interface Configuration Command Set on page 504 DSX-1 Interface Configuration Command Set on page 520 E1 Interface Configuration Command Set on page 530 G.703 Interface Configuration Command set on page 545 Modem Interface Configuration Command Set on page 552 BRI Interface Configuration Command set on page 556 Frame Relay Interface Config Command Set on page 567 Frame Relay Sub-Interface Config Command Set on page 587 ATM Interface Config Command Set on page 644 ATM Sub-Interface Config Command Set on page 647 ADSL Interface Config Command Set on page 701 BGP Configuration Command Set on page 705 BGP Neighbor Configuration Command Set on page 711 PPP Interface Configuration Command Set on page 715 Tunnel Configuration Command Set on page 778 HDLC Command Set on page 811 Loopback Interface Configuration Command Set on page 847 Line (Console) Interface Config Command Set on page 876 Line (Telnet) Interface Config Command Set on page 887 Router (RIP) Configuration Command Set on page 894 Router (OSPF) Configuration Command Set on page 903 Common Commands on page 922

SROS Command Line Interface Reference Guide Basic Mode Command Set

BASIC MODE COMMAND SET

To activate the Basic Mode, simply log in to the unit. After connecting the unit to a VT100 terminal (or terminal emulator) and activating a terminal session, the following prompt displays:

Router>

The following command is common to multiple command sets and is covered in a centralized section of this guide. For more information, refer to the section listed below:

exit on page 930

All other commands for this command set are described in this section in alphabetical order.

enable on page 11

logout on page 12

ping <address> on page 13

show clock on page 15

show snmp on page 16

show version on page 17

telnet <address> on page 18

traceroute <address> on page 19

SROS Command Line Interface Reference Guide Basic Mode Command Set

enable

Use the enable command (at the Basic Command Mode prompt) to enter the Enable Command Mode. Use the disable command to exit the Enable Command Mode. See the section enable on page 11 for more information.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

> Basic Command Mode

Functional Notes

The Enable Command Mode provides access to operating and configuration parameters and should be password protected to prevent unauthorized use. Use the Configuration) to specify an Enable Command Mode password. If the password is set, access to the Enable Commands (and all other “privileged” commands) is only granted when the correct password is entered.

enable password

command (found in the Global

Usage Examples

The following example enters the Enable Command Mode and defines an Enable Command Mode password:

enable

configure terminal

(config)#

At the next login, the following sequence must occur:

enable

Password: #

enable password password

******

SROS Command Line Interface Reference Guide Basic Mode Command Set

logout

Use the logout command to terminate the current session and return to the login screen.

Syntax Description

No subcommands.

Default Values

No defaults necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Usage Examples

The following example shows the logout command being executed in the Basic Mode:

logout

Session now available

Press RETURN to get started.

SROS Command Line Interface Reference Guide Basic Mode Command Set

ping <address>

Use the ping command (at the Basic Command Mode prompt) to verify IP network connectivity.

Syntax Description

<address> Optional.

with no specified address prompts the user with parameters for a more detailed configuration. See

Specifies the IP address of the system to ping. Entering the

Functional Notes

(below) for more information.

ping

command

ping

Default Values

No default value necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Functional Notes

The

ping

command helps diagnose basic IP network connectivity using the Packet InterNet Groper program to repeatedly bounce Internet Control Message Protocol (ICMP) Echo_Request packets off a system (using a specified IP address). The Secure Router OS allows executing a standard address or provides a set of prompts to configure a more specific

The following is a list of output messages from the ! Success

Destination Host Unreachable $ Invalid Host Address X TTL Expired in Transit ? Unknown Host * Request Timed Out

ping

command:

ping

request to a specified IP

configuration.

The following is a list of available extended Target IP address: Specifies the IP address of the system to ping. Repeat Count: Number of ping packets to send to the system (valid range: 1 to 1000000). Datagram Size:

ping

fields with descriptions:

SROS Command Line Interface Reference Guide Basic Mode Command Set

Size (in bytes) of the ping packet (valid range: 1 to 1448). Timeout in Seconds:

If a ping response is not received within the timeout period, the ping is considered unsuccessful (valid range: 1 to 5 seconds).

Extended Commands:

Specifies whether additional commands are desired for more ping configuration parameters. Source Address (or interface): Specifies the IP address to use as the source address in the ECHO_REQ packets. Data Pattern: Specify an alphanumerical string to use (the ASCII equivalent) as the data pattern in the ECHO_REQ packets. Sweep Range of Sizes: Varies the sizes of the ECHO_REQ packets transmitted. Sweep Min Size: Specifies the minimum size of the ECHO_REQ packet (valid range: 0 to 1448). Sweep Max Size: Specifies the maximum size of the ECHO_REQ packet (valid range: Sweep Min Size to 1448). Sweep Interval: Specifies the interval used to determine packet size when performing the sweep (valid range: 1 to 1448). Verbose Output: Specifies an extended results output.

Usage Examples

The following is an example of a successful

ping

Target IP address: Repeat count[1-1000000]: Datagram Size [1-1000000]: Timeout in seconds [1-5]: Extended Commands? [y or n]:

192.168.0.30 5

100

Type CTRL+C to abort. Legend: '!' = Success '?' = Unknown host '$' = Invalid host address '*' = Request timed out '-' = Destination host unreachable 'x' = TTL expired in transit

Pinging 192.168.0.30 with 100 bytes of data: !!!!! Success rate is 100 percent (5/5) round-trip min/avg/max = 19/20.8/25 ms

ping

command:

SROS Command Line Interface Reference Guide Basic Mode Command Set

show clock

Use the show clock command to display the system time and date entered using the clock set command.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Usage Examples

The following example displays the current time and data from the system clock:

show clock

23:35:07 UTC Tue Aug 20 2002

SROS Command Line Interface Reference Guide Basic Mode Command Set

show snmp

Use the show snmp command to display the system Simple Network Management Protocol (SNMP) parameters and current status of SNMP communications.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Usage Examples

The following is an example output using the default Chassis and Contact parameters:

show snmp

Chassis: Chassis ID Contact: Customer Service 0 Rx SNMP packets 0 Bad community names 0 Bad community uses 0 Bad versions 0 Silent drops 0 Proxy drops 0 ASN parse errors

show snmp

command for a system with SNMP disabled and the

SROS Command Line Interface Reference Guide Basic Mode Command Set

show version

Use the show version command to display the current Secure Router OS version information.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Usage Examples

The following is a sample

show version

ProCurve Secure Router 7203dl SROS Version: J02.01.01 Checksum: 5509EBDC, built on: Mon Mar 21 14:48:04 2005 Boot ROM version J02.01.01 Checksum: 9C0F, built on: Mon Mar 21 14:48:24 2005 Copyright (c) 2005-2005, Hewlett-Packard, Co. Platform: ProCurve Secure Router 7203dl Serial number US449TS029 Flash: 33554432 bytes DRAM: 268435455 bytes

System uptime is 0 days, 21 hours, 27 minutes, 0 seconds

Current system image file is "CFLASH:/J02_01_01.biz" Boot system image file is "CFLASH:/J02_01_01.biz" Primary system configuration file is "startup-config" System booted up using configuration file: "startup-config"

show version

output:

SROS Command Line Interface Reference Guide Basic Mode Command Set

telnet <address>

Use the telnet command to open a Telnet session (through the Secure Router OS) to another system on the network.

Syntax Description

<address> Specifies the IP address of the remote system.

Default Values

No default value necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Usage Examples

The following example opens a Telnet session with a remote system (10.200.4.15):

telnet 10.200.4.15

User Access Login

Password:

SROS Command Line Interface Reference Guide Basic Mode Command Set

traceroute <address>

Use the traceroute command to display the IP routes a packet takes to reach the specified destination.

Syntax Description

<address> Specifies the IP address of the remote system to trace the routes to

Default Values

No default value necessary for this command.

Command Modes

> or # Basic or Enable Command Mode

Usage Examples

The following example performs a traceroute on the IP address 192.168.0.1:

traceroute 192.168.0.1

Type CTRL+C to abort. Tracing route to 192.168.0.1 over a maximum of 30 hops

1 22ms 20ms 20ms 192.168.0.65 2 23ms 20ms 20ms 192.168.0.1 #

SROS Command Line Interface Reference Guide Enable Mode Command Set

ENABLE MODE COMMAND SET

To activate the Enable Mode, enter the enable command at the Basic Mode prompt. (If an enable password has been configured, a password prompt will display.) For example:

Router>enable Password: XXXXXXX Router#

The following commands are common to multiple command sets and are covered in a centralized section of this guide. For more information, refer to the section listed below:

bind <#> <from interface> <slot/port> <tdm-group#> <to interface> <slot/port> on page 924

description on page 927

exit on page 930

ping <address> on page 931

show running-config on page 933

All other commands for this command set are described in this section in alphabetical order.

clear commands begin on page 22

clock auto-correct-dst on page 48

clock set <time> <day> <month> <year> on page 50

clock timezone <text> on page 51

configure on page 53

copy <source> <destination> on page 54

copy console <filename> on page 55

copy flash <destination> on page 56

copy <filename> interface <interface> <slot/port> on page 57

copy tftp <destination> on page 58

copy xmodem <destination> on page 59

debug commands begin on page 60

dir on page 98

disable on page 99

erase [<filename> | startup-config] on page 100

events on page 101

logout on page 102

reload [cancel | in <delay>] on page 103

show commands begin on page 104

telnet <address> on page 194

SROS Command Line Interface Reference Guide Enable Mode Command Set

terminal length <text> on page 195

traceroute <address> on page 196

undebug all on page 197

wall <message> on page 198

write [erase | memory | network | terminal] on page 199

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear access-list <listname>

Use the clear access-list command to clear all counters associated with all access lists (or a specified access list).

Syntax Description

<listname> Optional. Specifies the name (label) of an access list

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears all counters for the access list labeled MatchAll:

>enable #clear access-list MatchAll

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear arp-cache

Use the clear arp-cache command to remove all dynamic entries from the Address Resolution Protocol (ARP) cache table.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example removes all dynamic entries from the ARP cache:

>enable #clear arp-cache

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear arp-entry <address>

Use the clear arp-entry command to remove a single entry from the Address Resolution Protocol (ARP) cache.

Syntax Description

<address> Specifies the IP address of the entry to remove

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example removes the entry for 10.200.4.56 from the ARP cache:

>enable #clear arp-entry 10.200.4.56

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear bridge <group#>

Use the clear bridge command to clear all counters associated with bridging (or for a specified bridge-group).

Syntax Description

<group#> Optional.

Specifies a single bridge group (1-255).

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears all counters for bridge group 17:

>enable #clear bridge 17

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear buffers max-used

Use the clear buffers max-used command to clear the maximum-used statistics for buffers displayed in the show memory heap command.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

>enable #clear buffers max-used

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear counters <interface>

Use the clear counters command to clear all interface counters (or the counters for a specified interface).

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears all counters associated with the Ethernet 0/1 interface:

>enable #clear counters ethernet 0/1

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear crypto ike sa <policy priority>

Use the clear crypto ike sa command to clear existing IKE security associations (SAs), including active ones.

Syntax Description

<policy priority> Optional.

This number is assigned using the

Clear out all existing IKE SAs associated with the designated policy priority.

crypto ike policy

command.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears the entire database of IKE SAs (including the active associations):

>enable #clear crypto ike sa

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear crypto ipsec sa

Use the clear crypto ipsec sa command to clear existing IPSec security associations (SAs), including active ones.

Variations of this command include the following:

clear crypto ipsec sa clear crypto ipsec sa entry <ip address> ah <SPI> clear crypto ipsec sa entry <ip address> esp <SPI> clear crypto ipsec sa map <map name> clear crypto ipsec sa peer <ip address>

Syntax Description

entry

<SPI>

esp

<SPI>

map

peer

Clear only the SAs related to a certain destination IP address. Clear only a portion of the SAs by specifying the AH (authentication header)

protocol and a security parameter index (SPI). You can determine the correct SPI value using the show crypto ipsec sa command.

Clear only a portion of the SAs by specifying the ESP (encapsulating security payload) protocol and a security parameter index (SPI). You can determine the correct SPI value using the show crypto ipsec sa command.

Clear only the SAs associated with the crypto map name given. Clear only the SAs associated with the far-end peer IP address given.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear dump-core

The clear dump-core command clears diagnostic information appended to the output of the show version command. This information results from an unexpected unit reboot.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears the entire database of IKE SAs (including the active associations):

>enable #clear dump-core

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear event-history

Use the clear event-history command to clear all messages logged to the local event-history.

Warning

Messages cleared from the local event-history (using the clear event-history command) are no longer accessible.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears all local event-history messages:

>enable #clear event-history

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear ip bgp [* | <as-number> | <ip address>] [in | out | soft]

Use the clear ip bgp command to clear BGP neighbors as specified.

Syntax Description

* Clears all BGP neighbors.

<as-number> Clears all BGP neighbors with the specified AS number. Range is 1 to 65,535. <ip address> Clears the BGP neighbor with the specified IP address.

in Causes a “soft” reset inbound with a neighbor, reprocessing routes advertised by

that neighbor.

out Causes a “soft” reset outbound with a neighbor, re-sending advertised routes to

that neighbor.

soft Causes a “soft” reset both inbound and outbound.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Functional Notes

The clear ip bgp command must be issued to re-initialize the BGP process between the peers matching the given arguments. Most neighbor changes, including changes to prefix-list filters, do not take effect until the clear command is issued. A hard reset clears the TCP connection with the specified peers which results in clearing the table. This method of clearing is disruptive and causes peer routers to record a route flap for each route.

The out version of this command provides a soft reset out to occur by causing all routes to be re-sent to the specified peer(s). TCP connections are not torn down so this method is less disruptive. Output filters/policies are re-applied before sending the update.

The in version of this command provides a soft reset in to occur by allowing the router to receive an updated table from a peer without tearing down the TCP connection. This method is less disruptive and does not count as a route flap. Currently all of the peer's routes are stored permanently, even if they are filtered by a prefix list. The command causes the peer's routes to be reprocessed with any new parameters.

Usage Examples

The following example causes a hard reset with peers with an AS number of 101:

#clear ip bgp 101

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear ip igmp group [<group-address> | <interface>]

Use the clear ip igmp group command to clear entries from the Internet Group Management Protocol (IGMP) tables. If no address or interface is specified, all non-static IGMP groups are cleared with this command.

Syntax Description

<group-address> Optional. <interface> Optional.

type slot/port

Specifies the multicast IP address of the multicast group. Designates the clearing of parameters for a specific interface (in the format

). For example: eth 0/1.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example shows output for the show igmp groups command before and after a clear ip igmp group command is issued. This example clears the IGMP entry that was registered

dynamically by a host. Interfaces that are statically joined are not cleared:

#show ip igmp groups IGMP Connected Group Membership Group Address Interface Uptime Expires Last Reporter

172.0.1.50 Loopback100 01:22:59 00:02:46

172.23.23.1

172.1.1.1 Ethernet0/1 00:00:14 00:02:45

1.1.1.2

172.1.1.1 Loopback100 01:22:59

SROS Command Line Interface Reference Guide Enable Mode Command Set

00:02:46

172.23.23.1 #clear ip igmp group

#show ip igmp groups IGMP Connected Group Membership Group Address Interface Uptime Expires Last Reporter This version of the command clears all dynamic groups that have the specified output interface (Ethernet

0/1):

#clear ip igmp group ethernet 0/1

This version of the command clears the specified group on all interfaces where it is dynamically registered:

#clear ip igmp group 172.1.1.1

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear ip policy-sessions

Use the clear ip policy-sessions command to clear policy class sessions. You may clear all the sessions or a specific session. Refer to the show ip policy-sessions for a current session listing. The following lists the complete syntax for the clear ip policy-sessions commands:

clear ip policy-sessions clear ip policy-sessions <classname> [ahp | esp | gre | icmp | tcp | udp | <protocol>] <source ip>

clear ip policy-sessions <classname> [ahp | esp | gre | icmp | tcp | udp | <protocol>] <source ip>

<source port><dest ip><dest port> [destination | source] <nat ip><nat port>

Syntax Description

<classname> Alphanumeric descriptor for identifying the configured access policy (access

policy descriptors are not case-sensitive).

<protocol> A specific protocol (valid range: 0-255). <source ip> Specifies the source IP address (format is A.B.C.D). <source port> Specifies the source port (in hexadecimal format for ahp, esp, and gre; decimal for

all other protocols).

<dest ip> Specifies the destination IP address (format is A.B.C.D). <dest port> Specifies the destination port (in hex format for ahp, esp, and gre; decimal for all

other protocols).

[destination | source] For NAT sessions, this specifies whether to select a NAT source or NAT

destination session.

<nat ip> For NAT sessions, this specifies the NAT IP address (format is A.B.C.D). <nat port> For NAT sessions, this specifies the NAT port (in hex format for ahp, esp, and gre;

decimal for all other protocols).

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Functional Notes

The second half of this command, beginning with the source IP address may be copied and pasted from a row in the show ip policy-sessions table for easier use.

SROS Command Line Interface Reference Guide Enable Mode Command Set

Usage Examples

The following example clears the Telnet association (TCP port 23) for policy class "pclass1" with source IP address 192.22.71.50 and destination 192.22.71.130:

>enable #clear ip policy-sessions pclass1 tcp 192.22.71.50 23 192.22.71.130 23

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear ip policy-stats <classname> entry <policy class #>

Use the clear ip policy-stats command to clear statistical counters for policy classes

Syntax Description

<classname> Optional.

are cleared for all policies.

entry Optional. Use this optional keyword to clear statistics of a specific policy class

entry

<policy class #> Optional. Specifies the policy class entry number.

Specifies the policy class to clear. If no policy class is specified, statistics

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears statistical counters for all policy classes:

>enable #clear ip policy-stats

The following example clears statistical counters for the policy class MatchALL:

>enable #clear ip policy-stats MatchALL

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear ip prefix-list <listname>

Use the clear ip prefix-list command to clear the IP prefix list hit count shown in the show ip prefix-list detail output.

Syntax Description

<listname> Specifies of the IP prefix list to clear.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example clears the hit count statistics for prefix list test:

>enable #clear ip prefix-list test

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear ip route

Use the clear ip route command to remove all learned routes from the IP route table. Static and connected routes are not cleared by this command.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example removes all learned routes from the route table:

>enable #clear ip route *

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear lldp counters

Use the clear lldp counters command to reset all LLDP packet counters to 0 on all interfaces.

Syntax Description

No subcommands.

Default Values

There are no default settings for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example resets all LLDP counters:

>enable #clear lldp counters

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear lldp counters interface <interface>

Use the clear lldp counters interface command to reset all LLDP packet counters to 0 for a specified interface.

Syntax Description

<interface> Clears the information for the specified interface. Type clear lldp counters

interface ? for a complete list of applicable interfaces.

Default Values

No default values are necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example resets the counters on a PPP interface:

>enable #clear lldp counters interface ppp 1

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear lldp neighbors

Use the clear lldp neighbors command to remove all neighbors from this unit’s database. As new LLDP packets are received, the database will contain information about neighbors included in those frames.

Syntax Description

No subcommands.

Default Values

There are no default settings for this command.

Command Modes

# Enable Command Mode

Functional Notes

This command generates output indicating the names of any neighbors deleted from the database and the name of the interface on which the neighbor was learned.

Usage Examples

The following example clears LLDP neighbor Switch_1 from the Ethernet interface 0/1:

>enable #clear lldp neighbors LLDP: Deleted neighbor “Switch_1” on interface eth 0/1 #

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear pppoe <interface id>

Use the clear pppoe command to terminate the current PPPoE client session and cause the Secure Router OS to try and re-establish the session.

Syntax Description

<interface id> PPP interface number.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example ends the current PPPoE client session for ppp 1:

>enable #clear pppoe 1

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear process cpu max

Use the clear process cpu max command to clear the maximum CPU usage statistic which is visible in the show process cpu command.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example resets the CPU maximum usage statistics:

>enable #clear process cpu max

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear qos map

Use the clear qos map command to clear the statistics for all defined QoS maps or to view detailed information for maps meeting user-configured specifications.

Variations of this command include the following:

clear qos map <map name> clear qos map <map name> <sequence number> clear qos map <interface>

Syntax Description

<map name> Enter the name of a defined QoS map. <sequence number> Enter one of the map’s defined sequence numbers. <interface> Specify an interface to clear QoS map statistics for just that interface (e.g.,

frame-relay, ppp).

Default Values

No default value necessary for this command.

Command Modes

# Enable mode

Usage Examples

clears statistics for all defined QoS map: #clear qos map

clears statistics for all entries in the “priority” QoS map: #clear qos map priority

clears statistics in entry “10” of the “priority” QoS map: #clear qos map priority 10

clears QoS statistics for a specified interface: #clear qos map interface frame-relay 1

Note

The clear counters command clears ALL interface statistics (including QoS map interface statistics).

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear spanning-tree counters [interface <interface>]

The clear spanning-tree counters command clears the following counts: BPDU transmit, BPDU receive, and number of transitions to forwarding state.

Syntax Description

interface <interface> Optional.

complete list of interfaces.

Specifies a single interface. Enter

clear spanning-tree counters ?

Default Values

No default value necessary for this command.

Command Modes

# Enable mode

Usage Examples

The following example clears the spanning tree counters for Ethernet 0/1:

>enable

#clear spanning-tree counters interface eth 0/1

for a

SROS Command Line Interface Reference Guide Enable Mode Command Set

clear spanning-tree detected-protocols [interface ethernet

<interface id>]

Use the clear spanning-tree detected-protocols command to restart the protocol migration process.

Syntax Description

interface Optional.

<interface id> Optional.

Choose the Enter a valid interface ID (e.g.,

ethernet

interface.

0/1

for Ethernet 0/1).

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Functional Notes

The ProCurve Secure Router has the ability to operate using the rapid spanning-tree protocol or the legacy

802.1D version of spanning-tree. When a BPDU (bridge protocol data unit) of the legacy version is detected on an interface, the ProCurve Secure Router automatically regresses to using the 802.1D spanning-tree protocol for that interface. Issue the clear spanning-tree detected-protocols command to return to rapid spanning-tree operation.

Usage Examples

The following example re-initiates the protocol migration process on eth 0/2:

>enable #clear spanning-tree detected-protocols interface ethernet 0/2

The following example re-initiates the protocol migration process on all interfaces: >enable #clear spanning-tree detected-protocols

SROS Command Line Interface Reference Guide Enable Mode Command Set

clock auto-correct-dst

The clock auto-correct-dst command allows the automatic one-hour correction for Daylight Saving Time (DST). Use the clock no-auto-correct-dst command to disable this feature.

Syntax Description

No subcommands.

Default Values

By default this command is enabled.

Command Modes

# Enable mode

Usage Examples

The following example allows for automatic DST correction:

>enable #clock auto-correct-DST

SROS Command Line Interface Reference Guide Enable Mode Command Set

clock no-auto-correct-dst

The clock no-auto-correct-dst command allows you to override the automatic one-hour correction for Daylight Saving Time (DST).

Syntax Description

No subcommands.

Default Values

No default value is necessary for this command.

Command Modes

# Enable mode

Functional Notes

Many time zones include an automatic one-hour correction for daylight saving time at the appropriate time. You may override it at your location using this command.

Usage Examples

The following example overrides the one-hour offset for DST:

>enable #clock no-auto-correct-DST

SROS Command Line Interface Reference Guide Enable Mode Command Set

clock set <time> <day> <month> <year>

Use the clock set command to configure the system software clock. For the command to be valid, all fields must be entered. See the Usage Example below for an example.

Syntax Description

<time> Sets the time of the system software clock in the format HH:MM:SS

(hours:minutes:seconds).

<day> Sets the current day of the month (valid range: 1 to 31). <month> Sets the current month (valid range: January to December). You need only enter

enough characters to make the entry unique. This entry is not case-sensitive.

<year> Sets the current year (valid range: 2000 to 2100).

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example sets the system software clock for 3:42 pm, August 22 2004:

>enable #clock set 03:42:00 22 Au 2004

SROS Command Line Interface Reference Guide Enable Mode Command Set

clock timezone <text>

The clock timezone command sets the unit’s internal clock to the timezone of your choice. This setting is based on the difference in time (in hours) between Greenwich Mean Time (GMT) or Central Standard Time (CST) and the timezone for which you are setting up the unit. Use the no form of this command to disable this feature.

Syntax Description

<text> Specifies the difference in time (in hours) between Greenwich Mean Time (GMT)

or Central Standard Time (CST) and the timezone for which you are setting up the unit.

Default Values

No default value is necessary for this command.

Command Modes

# Enable mode

SROS Command Line Interface Reference Guide Enable Mode Command Set

Functional Notes

The following list shows sample cities and their timezone codes.

clock timezone +1-Amsterdam clock timezone +1-Belgrade clock timezone +1-Brussels clock timezone +1-Sarajevo clock timezone +1-West-Africa clock timezone +10-Brisbane clock timezone +10-Canberra clock timezone +10-Guam clock timezone +10-Hobart clock timezone +10-Vladivostok clock timezone +11 clock timezone +12-Auckland clock timezone +12-Fiji clock timezone +13 clock timezone +2-Athens clock timezone +2-Bucharest clock timezone +2-Cairo clock timezone +2-Harare clock timezone +2-Helsinki clock timezone +2-Jerusalem clock timezone +3-Baghdad clock timezone +3-Kuwait clock timezone +3-Moscow clock timezone +3-Nairobi clock timezone +3:30 clock timezone +4-Abu-Dhabi clock timezone +4-Baku clock timezone +4:30 clock timezone +5-Ekaterinburg clock timezone +5-Islamabad

clock timezone +5:30 clock timezone +5:45 clock timezone +6-Almaty clock timezone +6-Astana clock timezone +6-Sri-Jay clock timezone +6:30 clock timezone +7-Bangkok clock timezone +7-Kranoyarsk clock timezone +8-Bejing clock timezone +8-Irkutsk clock timezone +8-Kuala-Lumpur clock timezone +8-Perth clock timezone +8-Taipei clock timezone +9-Osaka clock timezone +9-Seoul clock timezone +9-Yakutsk clock timezone +9:30-Adelaide clock timezone +9:30-Darwin clock timezone -1-Azores clock timezone -1-Cape-Verde clock timezone -10 clock timezone -11 clock timezone -12 clock timezone -2 clock timezone -3-Brasilia clock timezone -3-Buenos-Aires clock timezone -3-Greenland clock timezone -3:30 clock timezone -4-Atlantic-Time clock timezone -4-Caracus

Usage Examples

The following example sets the timezone for Santiago, Chile.

>enable #clock timezone -4-Santiago

SROS Command Line Interface Reference Guide Enable Mode Command Set

configure

Use the configure command to enter the Global Configuration Mode or to configure the system from memory. See Global Configuration Mode Command Set on page 200 for more information.

Syntax Description

terminal Enter the Global Configuration Mode. memory Configure the active system with the commands located in the default

configuration file stored in NVRAM.

network Configure the system from a TFTP network host. overwrite-network Overwrite NVRAM memory from a TFTP network host.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example enters the Global Configuration Mode from the Enable Command Mode:

>enable #configure terminal (config)#

SROS Command Line Interface Reference Guide Enable Mode Command Set

copy <source> <destination>

Use the copy command to copy any file from a specified source to a specified destination.

Syntax Description

<source> Specifies the current location of the file.

Valid sources include: running-config (current running configuration file), startup-config (configuration file located in NVRAM), or a filename (located in FLASH memory).

<destination> Specifies the destination of the copied file.

Valid destinations include: running-config (current running configuration file), startup-config (configuration file located in NVRAM), or a filename (located in FLASH memory).

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following provides various sample copy commands:

>enable

Creates a copy of the file myfile.biz (located in FLASH memory) and names it newfile.biz: #copy myfile.biz newfile.biz

Creates a backup copy of the startup configuration file (and places in FLASH memory): #copy startup-config backup.bak

Copies the current running-configuration file to the startup configuration file located in NVRAM: #copy running-config startup-config

SROS Command Line Interface Reference Guide Enable Mode Command Set

copy console <filename>

Use the copy console command to copy the console’s input to a text file. To end copying to the text file, type <Ctrl+D>. The file will be saved in the SROS root directory.

Syntax Description

<filename> Specify destination file for console input.

Default Values

No default is necessary for this command.

Command Modes

# Enable Command Mode

Functional Notes

The copy console command works much like a line editor. Prior to pressing <Enter>, changes can be made to the text on the line. Changes can be made using <Delete> and <Backspace> keys. The text can be traversed using the arrow keys, <Ctrl+A> (to go to the beginning of a line), and <Ctrl+E> (to go to the end of a line). To end copying to the text file, type <Ctrl+D>. The file will be saved in the Secure Router OS root directory. Use the dir command to see a list of files in the root directory.

Usage Examples

The following example copies the console input into the file config, located in the Secure Router OS root directory:

>enable #copy console config

SROS Command Line Interface Reference Guide Enable Mode Command Set

copy flash <destination>

Use the copy flash command to copy a file located in flash memory to a specified destination.

Syntax Description

<destination> Specifies the destination of the copied file. Valid destinations include tftp and

xmodem.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example copies the contents of the unit’s flash memory to a TFTP server:

>enable #copy flash tftp

SROS Command Line Interface Reference Guide Enable Mode Command Set

copy <filename> interface <interface> <slot/port>

Use the copy interface command to copy a file to a specified interface.

Syntax Description

<filename> Specify file name of source file. <interface> Specify interface to be upgraded. <slot/port> Specify slot and port number of interface

Default Values

No default is necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example upgrades the ADSL interface with the firmware file configfile:

>enable #copy configfile interface adsl 0/1

SROS Command Line Interface Reference Guide Enable Mode Command Set

copy tftp <destination>

Use the copy tftp command to copy a file located on a network Trivial File Transfer Protocol (TFTP) server to a specified destination.

Syntax Description

<destination> Specifies the destination of the file copied from the TFTP server.

Valid destinations include: flash (FLASH memory), startup-config (the configuration file stored in NVRAM), or running-config (the current running configuration file).

After entering copy tftp and specifying a destination, the Secure Router OS prompts for the following information:

Address of remote host: IP address of the TFTP server. Source filename: Name of the file to copy from the TFTP server. Destination filename: Specifies the filename to use when storing the copied file to FLASH memory.

(Valid only for the copy tftp flash command.)

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example copies myfile.biz from the TFTP server (10.200.2.4) to flash memory and labels it newfile.biz:

#copy tftp flash

Address of remote host?10.200.2.4 Source filename myfile.biz Destination filename newfile.biz Initiating TFTP transfer... Received 45647 bytes. Transfer Complete! #

SROS Command Line Interface Reference Guide Enable Mode Command Set

copy xmodem <destination>

Use the copy xmodem command to copy a file (using the XMODEM protocol) to a specified destination. XMODEM capability is provided in terminal emulation software such as HyperTerminal™.

Syntax Description

<destination> Specifies the destination of the copied file.

Valid destinations include: flash (FLASH memory), startup-config (the configuration file stored in NVRAM), or running-config (the current running configuration file).

After entering copy xmodem and specifying a destination, the Secure Router OS prompts for the following information:

Destination filename: Specifies the filename to use when storing the copied file to FLASH memory.

(Valid only for the copy flash command.)

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example copies a .biz file to flash memory and labels it newfile.biz:

#copy xmodem flash Destination filename newfile.biz Begin the Xmodem transfer now... Press CTRL+X twice to cancel CCCCCC

The Secure Router OS is now ready to accept the file on the CONSOLE port (using the XMODEM protocol). The next step in the process may differ depending on the type of terminal emulation software you are using. For HyperTerminal, you will now select Transfer > Send File and browse to the file you wish to copy. Once the transfer is complete, information similar to the following is displayed:

Received 231424 bytes. Transfer complete.

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug aaa

Use the debug aaa command to activate debug messages associated with authentication from the AAA subsystem. Debug messages are displayed (real-time) on the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the SROS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug aaa events include connection notices, login attempts, and session tracking.

Usage Examples

The following is sample output for this command:

>enable #debug aaa AAA: New Session on portal 'TELNET 0 (172.22.12.60:4867)'. AAA: No list mapped to 'TELNET 0'. Using 'default'. AAA: Attempting authentication (username/password). AAA: RADIUS authentication failed. AAA: Authentication failed. AAA: Closing Session on portal 'TELNET 0 (172.22.12.60:4867)'.

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug access-list <listname>

Use the debug access-list command to activate debug messages (for a specified list) associated with access list operation. Debug messages are displayed (real-time) on the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

<listname> Specifies a configured access list

Default Values

By default, all debug messages in the SROS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug access-list command provides debug messages to aid in troubleshooting access list issues.

Usage Examples

The following example activates debug messages for the access list labeled MatchAll:

>enable #debug access-list MatchAll

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug atm events

Use the debug atm events command to display events on all ATM ports and all virtual circuits. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates ATM event messages:

>enable #debug atm events

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug atm oam <vcd> loopback [end-to-end | segment] <LLID>

Use the debug atm oam command to display Operation, Administration, and Maintenance (OAM) packets for a ATM virtual circuit descriptor (VCD). Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable debug messages.

Variations of this command include the following:

debug atm oam <vcd> debug atm oam <vcd> loopback [end-to-end | segment] debug atm oam <vcd> loopback [end-to-end | segment] <LLID>

Syntax Description

<vcd> Shows OAM packets for a specific VCD.

loopback Configures an OAM loopback. end-to-end Configures an end-to-end OAM loopback. segment Configures a segment loopback.

<LLID> Specifies 16 byte OAM loopback location ID (LLID).

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates ATM OAM debug messages for VCD 1:

>enable #debug atm oam 1

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug atm packet [interface atm | vc] < ATM port | VPI/VCI> vcd <vcd

number>

Use the debug atm packet command to activate debug messages associated with packets on ATM ports and virtual circuits. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Variations of this command include the following:

debug atm packet . debug atm packet [interface atm | vc] <port id> debug atm packet interface atm <port id> vcd <port>

Syntax Description

interface atm Shows packets on a specific ATM port and on all virtual circuits. vc Shows packets on a specific virtual circuit.

<ATM port> Specifies ATM port number. <VPI/VCI> Specifies virtual path identifier and virtual channel identifier (VPI/VCI).

vcd Shows packets on specific virtual circuit descriptors (VCD).

<vcd number> Specifies a VCD port number.

Default Values

By default, all debug messages in the SROS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates debug ATM packet debug messages on ATM port 1:

>enable #debug atm packet interface atm 1

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug bridge

Use the debug bridge command to display messages associated with bridge events. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates bridge debug messages:

#debug bridge

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug crypto [ike | ike negotiation | ike client authentication |

ike client configuration | ipsec | pki]

Use the debug crypto command to activate debug messages associated with IKE and IPSec functions. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

ike Displays all IKE debug messages. ike negotiation Displays only IKE key management debug messages (e.g., handshaking). ike client authenticationDisplays IKE client authentication messages as they occur. ike client configurationDisplays mode-config exchanges as they take place over the IKE SA. It is

enabled independently from the ike negotiation debug described previously. ipsec Displays all IPSec debug messages. pki Displays all PKI (public key infrastructure) debug messages.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates the IPSec debug messages:

>enable #debug crypto ipsec

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug backup

Use the debug backup command to activate debug messages associated with backup operation. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug backup command activates debug messages to aid in the troubleshooting of backup links.

Usage Examples

The following example activates debug messages for backup operation:

>enable #debug backup

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug dialup-interfaces

Use the debug dialup-interfaces command to generate debug messages used to aid in troubleshooting problems with all dialup interfaces such as the modem or the BRI cards. Use the no version of this command to disable it.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

When enabled, these messages provide status information on incoming calls, dialing and answering progress, etc. These messages also give information on why certain calls are dropped or rejected. It is beneficial to use this command when troubleshooting backup (in addition to the debug backup command).

Usage Examples

The following example activates the debug messages for dialup interfaces:

>enable #debug dialup-interfaces

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug dynamic-dns [verbose]

Use the debug dynamic-dns command to display debug messages associated with dynamic DNS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

verbose Turns on verbose messaging.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates dynamic DNS debug messages:

>enable #debug dynamic-dns verbose

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug firewall

Use the debug firewall command to activate debug messages associated with the Secure Router OS firewall operation. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug firewall command activates debug messages to provide real-time information about the Secure Router OS stateful inspection firewall operation.

Usage Examples

The following example activates the debug messages for the Secure Router OS stateful inspection firewall:

>enable #debug firewall

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug frame-relay [events | llc2 | lmi]

Use the debug frame-relay command to activate debug messages associated with the Frame Relay operation. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

events Activates debug messages for generic Frame Relay events (such as Frame Relay

interface state)

llc2 Activates debug messages for the logical link control layer lmi Activates debug messages for the local management interface (such as DLCI

status signaling state, etc.)

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug frame-relay command activates debug messages to aid in the troubleshooting of Frame Relay links.

Usage Examples

The following example activates all possible debug messages associated with Frame Relay operation:

>enable #debug frame-relay events #debug frame-relay llc2 #debug frame-relay lmi

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug frame-relay multilink <interface>

Use the debug frame-relay multilink command to activate debug messages associated with Frame Relay multilink operation. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

<interface> Optional. Activates debug messages for the specified interface. Type debug

frame-relay multilink ? for a complete list of applicable interfaces.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates debug messages associated with multilink operation for all Frame Relay interfaces:

>enable #debug frame-relay multilnk

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug hdlc [errors | verbose]

Use the debug hdlc command to activate debug messages associated with the HDLC interface. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

errors Enables protocol error and statistic messages. verbose Enables detailed debug messages.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates detailed debug messages associated with the HDLC interface:

>enable #debug hdlc verbose

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug interface < interface >

Use the debug interface command to activate debug messages associated with the specified interface. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

< interface > Activates debug messages for the specified interface. Type debug interface ? for

a complete list of applicable interfaces.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug interface command activates debug messages to aid in the troubleshooting of physical interfaces.

Usage Examples

The following example activates all possible debug messages associated with the Ethernet port:

>enable #debug interface ethernet

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug interface adsl events

Use the debug interface adsl events command to activate debug messages associated with ADSL events. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates debug messages for ADSL events:

>enable #debug interface adsl events

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip bgp [events | in | out | keepalives | updates]

Use the debug ip bgp command to activate debug messages associated with IP BGP. Debug messages are displayed (real time) on the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

events Displays significant BGP events such as a neighbor state change. in/out Displays the same information as debug ip bgp, but limits messages to the

specified direction (in or out).

keepalives Displays BGP keepalive packets. updates Displays BGP updates for all neighbors.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

If no arguments are given, the debug ip bgp command displays general BGP events such as sent/received message summaries, route processing actions, and results. Keepalive packets are not debugged with this command.

Usage Examples

The following example enables debug messages on general outbound BGP messages and events:

#debug ip bgp out #07:42:39: BGP OUT 10.15.240.1[2]: Transmitting msg, type=UPDATE (2), len=142

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip dhcp-client

Use the debug ip dhcp-client command to activate debug messages associated with DHCP client operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug ip dhcp-client command activates debug messages to provide information on DHCP client activity in the Secure Router OS. The Secure Router OS DHCP client capability allows interfaces to dynamically obtain an IP address from a network DHCP server.

Usage Examples

The following example activates debug messages associated with DHCP client activity:

>enable #debug ip dhcp-client

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip dhcp-server

Use the debug ip dhcp-server command to activate debug messages associated with DHCP server operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug ip dhcp-server command activates debug messages to provide information on DHCP server activity in the Secure Router OS. The Secure Router OS DHCP server capability allows the Secure Router OS to dynamically assign IP addresses to hosts on the network.

Usage Examples

The following example activates debug messages associated with DHCP server activity:

>enable #debug ip dhcp-server

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip dns-client

Use the debug ip dns-client command to activate debug messages associated with DNS (domain naming system) client operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug ip dns-client command activates debug messages to provide information on DNS client activity in the Secure Router OS. The IP DNS capability allows for DNS-based host translation (name-to-address).

Usage Examples

The following example activates debug messages associated with DNS client activity:

>enable #debug ip dns-client

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip dns-proxy

Use the debug ip dns-proxy command to activate debug messages associated with DNS (domain naming system) proxy operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug ip dns-proxy command activates debug messages to provide information on DNS proxy activity in the Secure Router OS. The IP DNS capability allows for DNS-based host translation (name-to-address).

Usage Examples

The following example activates debug messages associated with DNS proxy activity:

>enable #debug ip dns-proxy

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip icmp [send | recv]

Use the debug ip icmp command to show all ICMP messages as they come into the router or are originated by the router. If an optional keyword (send or recv) is not used, all results are displayed. Use the no form of this command to disable the debug messages.

Syntax Description

send

recv

Optional keyword which allows you to only display ICMP messages sent by the router. Optional keyword which allows you to only display ICMP messages received by the

router.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates the debug ip icmp send and receive messages for the Secure Router OS:

>enable #debug ip icmp

ICMP SEND: From (0.0.0.0) to (172.22.14.229) Type=8 Code=0 Length=72 Details:echo request ICMP RECV: From (172.22.14.229) to (10.100.23.19) Type=0 Code=0 Length=72 Details:echo reply ICMP SEND: From (0.0.0.0) to (172.22.14.229) Type=8 Code=0 Length=72 Details:echo request ICMP RECV: From (172.22.14.229) to (10.100.23.19) Type=0 Code=0 Length=72 Details:echo reply ICMP RECV: From (172.22.255.200) to (10.100.23.19) Type=11 Code=0 Length=36 Details:TTL equals 0

during transit ICMP RECV: From (172.22.14.229) to (10.100.23.19) Type=3 Code=3 Length=36 Details:port

unreachable ICMP RECV: From (172.22.14.229) to (10.100.23.19) Type=3 Code=3 Length=36 Details:port

unreachable

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip igmp <group-address>

Use the debug ip igmp command to enable debug messages for IGMP transactions (including helper activity).

Syntax Description

<group-address> Optional.

IP address of a multicast group.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example enables IGMP debug messages for the specified multicast group:

>enable #debug ip igmp 224.1.1.1

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip ospf

Use the debug ip ospf command to activate debug messages associated with OSPF routing operations. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

adj Display OSPF adjacency events database-timer Display OSPF database timer events Display OSPF events flood Display OSPF flooding hello Display OSPF hello events lsa-generation Display OSPF link state advertisement generation packet Display OSPF packets retransmission Display OSPF retransmission events spf Display OSPF shortest-path-first calculations tree Display OSPF database tree

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip rip [events]

Use the debug ip rip command to activate debug messages associated with Routing Information Protocol (RIP) operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

events Optional.

Use this optional keyword to display only RIP protocol events.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Functional Notes

The debug ip rip command activates debug messages to provide information on Routing Information Protocol (RIP) activity in the Secure Router OS. RIP allows hosts and routers on a network to exchange information about routes.

Usage Examples

The following example activates debug messages associated with RIP activity:

>enable #debug ip rip

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip tcp events

Use the debug ip tcp events command to activate debug messages associated with significant TCP events such as state changes, retransmissions, session aborts, etc., in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Note

These debug events are logged for packets that are sent or received from the router. Forwarded TCP packets are not included.

Syntax Description

No default value necessary for this command.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

In the debug ip tcp events information, TCB stands for TCP task control block. The numbers which sometimes appear next to TCB (e.g., TCB5 in the following example) represent the TCP session number. This allows you to differentiate debug messages for multiple TCP sessions.

Usage Examples

The following is sample output for this command:

>enable #debug ip tcp events

2003.02.17 07:40:56 IP.TCP EVENTS TCP: Allocating block 5

2003.02.17 07:40:56 IP.TCP EVENTS TCB5: state change: FREE->SYNRCVD

2003.02.17 07:40:56 IP.TCP EVENTS TCB5: new connection from 172.22.75.246:3473 to

10.200.2.201:23

2003.02.17 07:40:56 IP.TCP EVENTS TCB5: state change: SYNRCVD->ESTABLISHED [172.22.75.246:3473]

2003.02.17 07:41:06 IP.TCP EVENTS TCB5: Connection aborted -- error = RESET

2003.02.17 07:41:06 IP.TCP EVENTS TCB5: De-allocating tcb

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip tcp md5

Use the debug ip tcp md5 command to activate debug messages that detail the results of each incoming TCP packet’s MD5 authentication with an internal route in the Secure Router OS. Debug messages are displayed (real time) to the terminal (or Telnet) screen. Use the no form of this command to disable debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

Debug messages will only be generated for TCP ports that have MD5 authentication enabled.

Usage Examples

The following example activates the display of these debug messages:

#debug ip tcp md5

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ip udp

Use the debug ip udp command to activate debug messages associated with UDP send and receive events in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Note

These debug events are logged for packets that are sent or received from the router. Forwarded UDP packets are not included.

Caution

The overhead associated with this command takes up a large portion of your router’s resources and at times can halt other router processes. It is best to only use the command during times when the network resources are in low demand (non-peak hours, weekends, etc.).

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

In the debug ip udp information, the message no listener means that there is no service listening on this UDP port (i.e., the data is discarded).

Usage Examples

The following is sample output for this command:

>enable #debug ip udp

2003.02.17 07:38:48 IP.UDP RX: src=10.200.3.236:138, dst=10.200.255.255:138, 229 bytes, no listener

2003.02.17 07:38:48 IP.UDP RX: src=10.200.2.7:138, dst=10.200.255.255:138, 227 bytes, no listener

2003.02.17 07:38:48 IP.UDP RX: src=10.200.201.240:138, dst=10.200.255.255:138, 215 bytes, no listener

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug isdn events

Use the debug isdn events command to activate debug messages associated with ISDN events in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Mode

Functional Notes

Usage Examples

The following example activates debug messages associated with ISDN activity:

>enable #debug isdn events

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug lldp [rx | tx] verbose

Use the debug lldp command to display debug output for all LLDP receive and transmit packets.

Syntax Description

rx Shows information about received packets. tx Shows information about transmitted packets. verbose Shows detailed debugging information.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates all possible debug messages associated with LLDP operation:

#debug lldp rx

#debug lldp tx

#debug lldp verbose

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug port-auth [general | packet [both | rx | tx] | supp-sm]

Use the debug port-auth command to generate debug messages used to aid in troubleshooting problems during the port authentication process. Use the no version of this command to disable the messages.

Syntax Description

general Optional. Displays configuration changes to the port authentication system. packet Optional. Displays information for packet exchange in transmit-only, receive-only

or both directions.

both Optional. Displays packet exchange information in both receive and transmit

directions.

rx Optional. Displays packet exchange information in the receive-only direction. tx Optional. Displays packet exchange information in the transmit-only direction. supp-sm Optional. Displays information pertaining to the supplicant state machine.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates port authentication debug information on received packets:

>enable #debug port-auth packet rx Received EAPOL Start for session 1 on interface eth 0/2

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug ppp [authentication | errors | negotiation | verbose]

Use the debug ppp command to activate debug messages associated with point-to-point protocol (PPP) operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

authentication Activates debug messages pertaining to PPP authentication (CHAP, PAP, EAP,

etc.).

errors Activates debug messages that indicate a PPP error was detected (mismatch in

negotiation authentication, etc.).

negotiation Activates debug messages associated with PPP negotiation. verbose Activates detailed debug messages for PPP operation.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Functional Notes

The debug ppp command activates debug messages to provide information on PPP activity in the system. PPP debug messages can be used to aid in troubleshooting PPP links.

Usage Examples

The following example activates debug messages associated with PPP authentication activity:

>enable #debug ppp authentication

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug pppoe client

Use the debug pppoe client command to activate debug messages associated with point-to-point protocol over Ethernet (PPPoE) operation in the Secure Router OS. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Mode

Functional Notes

Usage Examples

The following example activates debug messages associated with PPPoE activity:

>enable #debug pppoe client

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug radius

Use the debug radius command to enable debug messages from the RADIUS subsystem. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug radius messages show the communication process with the remote RADIUS servers.

Usage Examples

The following is an example output for the debug radius command:

>enable #debug radius RADIUS AUTHENTICATION: Sending packet to 172.22.48.1 (1645). RADIUS AUTHENTICATION: Received response from 172.22.48.1.

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug sntp

Use the debug sntp command to enable debug messages associated with the Simple Network Time Protocol (SNTP). All SNTP Packet Exchanges and time decisions are displayed with these debugging events enabled. Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Functional Notes

The debug sntp command activates debug messages to aid in troubleshooting SNTP protocol issues.

Usage Examples

The following is an example output for the debug sntp command:

>enable #debug sntp #config term (config)#sntp server timeserver.localdomain

2002.12.11 15:06:37 SNTP.CLIENT sent Version 1 SNTP time request to 63.97.45.57

2002.12.11 15:06:37 SNTP.CLIENT received SNTP reply packet from 63.97.45.57

2002.12.11 15:06:37 SNTP.CLIENT setting time to 12-11-2002 15:06:02 UTC

2002.12.11 15:06:37 SNTP.CLIENT waiting for 86400 seconds for the next poll interval

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug spanning-tree [config | events | general | root]

Use the debug spanning-tree command to enable the display of spanning-tree debug messages.

Syntax Description

config Enables the display of spanning-tree debug messages when configuration

changes occur.

events Enables the display of debug messages when spanning-tree protocol events

occur.

general Enables the display of general spanning-tree debug messages. root Enables the display of debug messages related to the spanning-tree root.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example enables the display of general spanning-tree debug messages:

>enable #debug spanning-tree general

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug spanning-tree bpdu [receive | transmit | all]

Use the debug spanning-tree bpdu command to display BPDU (bridge protocol data unit) debug messages. When enabled, a debug message is displayed for each BPDU packet that is transmitted or received by the unit.

Syntax Description

receive Displays debug messages for BPDU packets received by the unit. transmit Displays debug messages for BPDU packets transmitted by the unit. all Displays debug messages for BPDU packets that are transmitted and received by

the unit.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example displays debug messages for BPDU packets that are transmitted and received by the unit:

>enable #debug spanning-tree bpdu all

SROS Command Line Interface Reference Guide Enable Mode Command Set

debug system

Use the debug system command to enable debug messages associated with system events (i.e., login, logouts, etc.). Debug messages are displayed (real-time) to the terminal (or Telnet) screen. Use the no form of this command to disable the debug messages.

Syntax Description

No subcommands.

Default Values

By default, all debug messages in the Secure Router OS are disabled.

Command Modes

# Enable Command Mode

Usage Examples

The following example activates debug messages associated with system information:

>enable #debug system

SROS Command Line Interface Reference Guide Enable Mode Command Set

dir

Use the dir command to display a directory list of files on the system.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following is sample output from the dir command:

>enable #dir 4206603 HP7203A-08-00-23b-HP1-E.biz 3818 startup-config 3850 startup-config.bak 284007 HP7203B-boot-08-01-01-HP.biz 4234845 HP7203A-08-01-01-HP-E.biz 284238 HP7203B-boot-08-01-02-HPatp.biz 4038590 HP7203A-08-01-02-HPatp-E.biz 285416 J01_01_02-boot.biz 4039977 J01_01_02.biz 4043024 J01_01_03.biz 2649600 ericcode.biz 2896 EUT2bindcfg.txt 24208408 bytes used, 4915176 available, 29123584 total

SROS Command Line Interface Reference Guide Enable Mode Command Set

disable

Use the disable command to exit the Enable Command Mode and enter the Basic Command Mode.

Syntax Description

No subcommands.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example exits the Enable Command Mode and enters the Basic Command Mode:

#disable >

SROS Command Line Interface Reference Guide Enable Mode Command Set

erase [<filename> | startup-config]

Use the erase command to erase the specified file.

Syntax Description

startup-config Erases the startup configuration file stored in NVRAM.

Specifies the name of the file (located in FLASH memory) to erase.

Default Values

No default value necessary for this command.

Command Modes

# Enable Command Mode

Usage Examples

The following example erases the startup configuration file stored in NVRAM:

>enable #erase startup-config

If a new startup-configuration file is not specified before power-cycling the unit, the Secure Router OS will initialize using a default configuration.

HP 7000 Reference Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

CLI INTRODUCTION

Accessing the CLI from your PC

Understanding Command Security Levels

Understanding Configuration Modes

Using CLI Shortcuts

Performing Common CLI Functions

Understanding CLI Error Messages

COMMAND DESCRIPTIONS

SROS Command Line Interface Reference Guide Basic Mode Command Set

SROS Command Line Interface Reference Guide Enable Mode Command Set
