HP 5920, 5900 Command Reference Manual

Download

HPE 5920 & 5900 Switch Series

Layer 3—IP Services

Command Reference

Part number: Software version: Release 24 Document version: 6W101-20170622

5998-6643s

22P01

Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s standard commercial license.

Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise website.

Acknowledgments

Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the United States and other countries.

Microsoft® and Windows® are trademarks of the Microsoft group of companies. Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated. Java and Oracle are registered trademarks of Oracle and/or its affiliates. UNIX® is a registered trademark of The Open Group.

ARP commands ···············································································1

arp check enable ··················································································································· 1 arp check log enable ·············································································································· 1 arp max-learning-num ············································································································ 2 arp max-learning-number ········································································································ 3 arp multiport ························································································································· 4 arp static ······························································································································ 5 arp timer aging ······················································································································ 6 display arp ··························································································································· 6 display arp ip-address ············································································································ 8 display arp entry-limit ············································································································· 9 display arp timer aging ··········································································································· 9 display arp vpn-instance ······································································································· 10 reset arp ···························································································································· 11

Gratuitous ARP commands ······························································ 12

arp ip-conflict log prompt ······································································································· 12 arp send-gratuitous-arp ········································································································ 12 gratuitous-arp-learning enable ······························································································· 13 gratuitous-arp-sending enable ······························································································· 14

Proxy ARP commands ···································································· 15

display local-proxy-arp ········································································································· 15 display proxy-arp ················································································································· 15 local-proxy-arp enable ·········································································································· 16 proxy-arp enable ················································································································· 17

ARP snooping commands ································································ 18

arp snooping enable ············································································································ 18 display arp snooping ············································································································ 18 reset arp snooping ··············································································································· 19

ARP fast-reply commands ································································ 21

arp fast-reply enable ············································································································ 21

IP addressing commands ································································· 22

display ip interface ··············································································································· 22 display ip interface brief ········································································································ 24 ip address ·························································································································· 25 ip address unnumbered ········································································································ 27

DHCP commands ·········································································· 28

Common DHCP commands ········································································································· 28

dhcp dscp ·························································································································· 28 dhcp enable ······················································································································· 28 dhcp select ························································································································ 29

DHCP server commands ············································································································· 30

address range ···················································································································· 30 bims-server ························································································································ 31 bootfile-name ····················································································································· 31 class ································································································································· 32 dhcp class·························································································································· 33 dhcp server always-broadcast ······························································································· 34 dhcp server apply ip-pool ······································································································ 35 dhcp server bootp ignore ······································································································ 35 dhcp server bootp reply-rfc-1048 ···························································································· 36 dhcp server forbidden-ip ······································································································· 36

dhcp server ip-pool ·············································································································· 37 dhcp server ping packets ······································································································ 38 dhcp server ping timeout ······································································································· 39 dhcp server relay information enable ······················································································· 39 display dhcp server conflict ··································································································· 40 display dhcp server expired ··································································································· 41 display dhcp server free-ip ···································································································· 42 display dhcp server ip-in-use ································································································· 43 display dhcp server pool ······································································································· 44 display dhcp server statistics ································································································· 46 dns-list ······························································································································ 48 domain-name ····················································································································· 48 expired ······························································································································ 49 forbidden-ip ························································································································ 50 gateway-list ························································································································ 50 if-match ····························································································································· 51 nbns-list ····························································································································· 53 netbios-type ······················································································································· 53 network ····························································································································· 54 next-server ························································································································· 55 option ································································································································ 56 reset dhcp server conflict ······································································································ 57 reset dhcp server expired ······································································································ 58 reset dhcp server ip-in-use ···································································································· 58 reset dhcp server statistics ···································································································· 59 static-bind ·························································································································· 59 tftp-server domain-name ······································································································· 60 tftp-server ip-address ··········································································································· 61 voice-config ························································································································ 61

DHCP relay agent commands ······································································································ 62

dhcp relay check mac-address ······························································································· 62 dhcp relay check mac-address aging time ················································································ 63 dhcp relay client-information record ························································································ 64 dhcp relay client-information refresh························································································ 64 dhcp relay client-information refresh enable·············································································· 65 dhcp relay information circuit-id ······························································································ 66 dhcp relay information enable ································································································ 68 dhcp relay information remote-id ···························································································· 68 dhcp relay information strategy ······························································································ 69 dhcp relay release ip ············································································································ 70 dhcp relay server-address ····································································································· 71 display dhcp relay check mac-address ···················································································· 71 display dhcp relay client-information ······················································································· 72 display dhcp relay information ································································································ 73 display dhcp relay server-address ·························································································· 74 display dhcp relay statistics ··································································································· 75 reset dhcp relay client-information ·························································································· 76 reset dhcp relay statistics ······································································································ 77

DHCP client commands ·············································································································· 77

dhcp client dad enable ········································································································· 77 dhcp client dscp ·················································································································· 78 dhcp client identifier ············································································································· 78 display dhcp client ··············································································································· 79 ip address dhcp-alloc ··········································································································· 81

DHCP snooping commands ········································································································· 82

dhcp snooping binding database filename ················································································ 82 dhcp snooping binding database update interval ······································································· 84 dhcp snooping binding database update now ··········································································· 84 dhcp snooping binding record ································································································ 85 dhcp snooping check mac-address ························································································· 85 dhcp snooping check request-message ··················································································· 86 dhcp snooping deny ············································································································· 87

dhcp snooping enable ·········································································································· 87 dhcp snooping information circuit-id ························································································ 88 dhcp snooping information enable ·························································································· 90 dhcp snooping information remote-id ······················································································ 90 dhcp snooping information strategy························································································· 91 dhcp snooping log enable ····································································································· 92 dhcp snooping max-learning-num ··························································································· 93 dhcp snooping rate-limit ········································································································ 93 dhcp snooping trust ············································································································· 94 display dhcp snooping binding ······························································································· 95 display dhcp snooping binding database ·················································································· 96 display dhcp snooping information ·························································································· 96 display dhcp snooping packet statistics ··················································································· 98 display dhcp snooping trust ··································································································· 98 reset dhcp snooping binding ·································································································· 99 reset dhcp snooping packet statistics ······················································································ 99

BOOTP client commands ·········································································································· 100

display bootp client ············································································································ 100 ip address bootp-alloc ········································································································ 101

DNS commands ··········································································· 102

display dns domain ············································································································ 102 display dns host ················································································································ 102 display dns server ············································································································· 104 display ipv6 dns server ······································································································· 105 dns domain ······················································································································ 105 dns dscp ·························································································································· 106 dns proxy enable ··············································································································· 107 dns server ························································································································ 107 dns source-interface ·········································································································· 108 dns spoofing ····················································································································· 109 dns trust-interface·············································································································· 110 ip host ····························································································································· 111 ipv6 dns dscp ··················································································································· 111 ipv6 dns server ················································································································· 112 ipv6 dns spoofing ·············································································································· 113 ipv6 host ·························································································································· 114 reset dns host ··················································································································· 115

DDNS commands ········································································ 116

ddns apply policy ··············································································································· 116 ddns dscp ························································································································ 117 ddns policy ······················································································································· 117 display ddns policy ············································································································ 118 interval ···························································································································· 119 method ···························································································································· 120 password ························································································································· 121 ssl-client-policy ················································································································· 122 url··································································································································· 123 username ························································································································ 125

Basic IP forwarding commands ······················································· 126

display fib ························································································································ 126 ip forwarding-table save ······································································································ 128

Load sharing commands ································································ 129

display ip load-sharing path ································································································· 129 ip load-sharing local-first enable ··························································································· 130 ip load-sharing mode per-flow ······························································································ 131 ip load-sharing symmetric enable ························································································· 132

iii

Fast forwarding commands ···························································· 133

display ip fast-forwarding aging-time ····················································································· 133 display ip fast-forwarding cache ··························································································· 133 display ip fast-forwarding fragcache ······················································································ 134 ip fast-forwarding aging-time ······························································································· 135 ip fast-forwarding load-sharing ····························································································· 136 reset ip fast-forwarding cache ······························································································ 136

IRDP commands ·········································································· 138

ip irdp ······························································································································ 138 ip irdp address ·················································································································· 138 ip irdp lifetime ··················································································································· 139 ip irdp interval ··················································································································· 140 ip irdp multicast ················································································································· 140 ip irdp preference ·············································································································· 141

IP performance optimization commands ············································ 143

display icmp statistics ········································································································· 143 display ip statistics ············································································································· 144 display rawip ···················································································································· 145 display rawip verbose ········································································································· 146 display tcp························································································································ 148 display tcp statistics ··········································································································· 149 display tcp verbose ············································································································ 151 display udp ······················································································································ 153 display udp statistics ·········································································································· 154 display udp verbose ··········································································································· 155 ip forward-broadcast ·········································································································· 157 ip icmp error-interval ·········································································································· 158 ip icmp fragment discarding ································································································· 159 ip icmp source ·················································································································· 159 ip mtu ······························································································································ 160 ip redirects enable ············································································································· 161 ip ttl-expires enable ··········································································································· 161 ip unreachables enable ······································································································ 162 reset ip statistics ··············································································································· 163 reset tcp statistics ·············································································································· 163 reset udp statistics ············································································································· 163 tcp mss ··························································································································· 164 tcp path-mtu-discovery ······································································································· 165 tcp syn-cookie enable ········································································································ 165 tcp timer fin-timeout ··········································································································· 166 tcp timer syn-timeout ·········································································································· 167 tcp window ······················································································································· 167

UDP helper commands ································································· 169

display udp-helper interface ································································································ 169 reset udp-helper statistics ··································································································· 170 udp-helper broadcast-map ·································································································· 170 udp-helper enable ············································································································· 171 udp-helper port ················································································································· 171 udp-helper server ·············································································································· 172

IPv6 basics commands ·································································· 174

display ipv6 fib ·················································································································· 174 display ipv6 icmp statistics ·································································································· 175 display ipv6 interface ········································································································· 176 display ipv6 interface prefix ································································································· 180 display ipv6 neighbors ········································································································ 181 display ipv6 neighbors count ······························································································· 183 display ipv6 neighbors entry-limit ·························································································· 183

display ipv6 neighbors vpn-instance ······················································································ 184 display ipv6 pathmtu ·········································································································· 185 display ipv6 prefix ·············································································································· 186 display ipv6 rawip ·············································································································· 187 display ipv6 rawip verbose ·································································································· 188 display ipv6 statistics ········································································································· 190 display ipv6 tcp ················································································································· 192 display ipv6 tcp verbose ····································································································· 193 display ipv6 udp ················································································································ 196 display ipv6 udp verbose ···································································································· 197 ipv6 address ····················································································································· 199 ipv6 address anycast ········································································································· 200 ipv6 address auto ·············································································································· 201 ipv6 address auto link-local ································································································· 201 ipv6 address eui-64 ··········································································································· 202 ipv6 address link-local ········································································································ 203 ipv6 hop-limit ···················································································································· 204 ipv6 hoplimit-expires enable ································································································ 205 ipv6 icmpv6 error-interval ···································································································· 205 ipv6 icmpv6 multicast-echo-reply enable ················································································ 206 ipv6 icmpv6 source ············································································································ 207 ipv6 mtu ·························································································································· 207 ipv6 nd autoconfig managed-address-flag ·············································································· 208 ipv6 nd autoconfig other-flag ······························································································· 209 ipv6 nd dad attempts ·········································································································· 209 ipv6 nd ns retrans-timer ······································································································ 210 ipv6 nd nud reachable-time ································································································· 211 ipv6 nd ra halt ··················································································································· 212 ipv6 nd ra hop-limit unspecified ···························································································· 212 ipv6 nd ra interval ·············································································································· 213 ipv6 nd ra no-advlinkmtu ····································································································· 213 ipv6 nd ra prefix ················································································································ 214 ipv6 nd ra router-lifetime ····································································································· 215 ipv6 nd router-preference ···································································································· 216 ipv6 neighbor ···················································································································· 216 ipv6 neighbor link-local minimize ·························································································· 218 ipv6 neighbor stale-aging ···································································································· 218 ipv6 neighbors max-learning-num ························································································· 219 ipv6 option drop enable ······································································································ 220 ipv6 pathmtu ···················································································································· 220 ipv6 pathmtu age ··············································································································· 221 ipv6 prefer temporary-address ····························································································· 222 ipv6 prefix ························································································································ 222 ipv6 redirects enable ·········································································································· 223 ipv6 temporary-address ······································································································ 224 ipv6 unreachables enable ··································································································· 225 local-proxy-nd enable ········································································································· 225 proxy-nd enable ················································································································ 226 reset ipv6 neighbors ·········································································································· 226 reset ipv6 pathmtu ············································································································· 227 reset ipv6 statistics ············································································································ 228

DHCPv6 commands ····································································· 229

Common DHCPv6 commands ···································································································· 229

display ipv6 dhcp duid ········································································································ 229 ipv6 dhcp dscp ·················································································································· 229 ipv6 dhcp select ················································································································ 230

DHCPv6 server commands ········································································································ 231

address range ·················································································································· 231 display ipv6 dhcp pool ········································································································ 232 display ipv6 dhcp prefix-pool ······························································································· 233 display ipv6 dhcp server ····································································································· 234

display ipv6 dhcp server conflict ··························································································· 235 display ipv6 dhcp server expired ·························································································· 236 display ipv6 dhcp server ip-in-use ························································································· 237 display ipv6 dhcp server pd-in-use ························································································ 239 display ipv6 dhcp server statistics ························································································· 241 dns-server························································································································ 242 domain-name ··················································································································· 243 ipv6 dhcp pool ·················································································································· 243 ipv6 dhcp prefix-pool ·········································································································· 244 ipv6 dhcp server ················································································································ 245 ipv6 dhcp server apply pool ································································································· 246 ipv6 dhcp server forbidden-address ······················································································ 247 ipv6 dhcp server forbidden-prefix ·························································································· 248 network ··························································································································· 249 option ······························································································································ 250 prefix-pool ························································································································ 251 reset ipv6 dhcp server conflict ······························································································ 252 reset ipv6 dhcp server expired ····························································································· 252 reset ipv6 dhcp server ip-in-use ··························································································· 253 reset ipv6 dhcp server pd-in-use ·························································································· 253 reset ipv6 dhcp server statistics ··························································································· 254 sip-server························································································································· 254 static-bind ························································································································ 255 temporary address range ···································································································· 256

DHCPv6 relay agent commands ································································································· 257

display ipv6 dhcp relay server-address ·················································································· 257 display ipv6 dhcp relay statistics ··························································································· 258 ipv6 dhcp relay server-address ···························································································· 260 reset ipv6 dhcp relay statistics ····························································································· 261

DHCPv6 client commands ········································································································· 262

display ipv6 dhcp client ······································································································· 262 display ipv6 dhcp client statistics ·························································································· 264 ipv6 address dhcp-alloc ······································································································ 265 ipv6 dhcp client duid ·········································································································· 266 ipv6 dhcp client dscp ·········································································································· 266 ipv6 dhcp client pd ············································································································· 267 ipv6 dhcp client stateless enable ·························································································· 268 reset ipv6 dhcp client statistics ····························································································· 268

DHCPv6 snooping commands ···································································································· 269

display ipv6 dhcp snooping binding ······················································································· 269 display ipv6 dhcp snooping binding database ········································································· 270 display ipv6 dhcp snooping packet statistics ··········································································· 271 display ipv6 dhcp snooping trust ··························································································· 271 ipv6 dhcp snooping binding database filename ······································································· 272 ipv6 dhcp snooping binding database update interval ······························································· 273 ipv6 dhcp snooping binding database update now ··································································· 274 ipv6 dhcp snooping binding record························································································ 274 ipv6 dhcp snooping check request-message ·········································································· 275 ipv6 dhcp snooping deny ···································································································· 276 ipv6 dhcp snooping enable ·································································································· 276 ipv6 dhcp snooping log enable ····························································································· 277 ipv6 dhcp snooping max-learning-num ·················································································· 277 ipv6 dhcp snooping option interface-id enable ········································································· 278 ipv6 dhcp snooping option interface-id string ·········································································· 279 ipv6 dhcp snooping option remote-id enable ··········································································· 279 ipv6 dhcp snooping option remote-id string············································································· 280 ipv6 dhcp snooping rate-limit ······························································································· 281 ipv6 dhcp snooping trust ····································································································· 282 reset ipv6 dhcp snooping binding ························································································· 282 reset ipv6 dhcp snooping packet statistics ·············································································· 283

IPv6 fast forwarding commands······················································· 284

display ipv6 fast-forwarding aging-time ·················································································· 284 display ipv6 fast-forwarding cache ························································································ 284 ipv6 fast-forwarding aging-time ···························································································· 286 ipv6 fast-forwarding load-sharing ·························································································· 286 reset ipv6 fast-forwarding cache ··························································································· 287

Tunneling commands ···································································· 288

bandwidth ························································································································ 288 default ····························································································································· 288 description ······················································································································· 289 destination ······················································································································· 289 display interface tunnel ······································································································· 290 interface tunnel ················································································································· 294 mtu ································································································································· 295 reset counters interface ······································································································ 295 service ···························································································································· 296 shutdown ························································································································· 296 source ····························································································································· 297 tunnel dfbit enable ············································································································· 298 tunnel discard ipv4-compatible-packet ··················································································· 299 tunnel tos ························································································································· 299 tunnel ttl ·························································································································· 300

GRE commands ·········································································· 301

keepalive ························································································································· 301

Document conventions and icons ···················································· 302

Conventions ···························································································································· 302 Network topology icons ············································································································· 303

Support and other resources··························································· 304

Accessing Hewlett Packard Enterprise Support·············································································· 304 Accessing updates ··················································································································· 304

Websites ························································································································· 305 Customer self repair ·········································································································· 305 Remote support ················································································································ 305 Documentation feedback ···································································································· 305

Index ························································································· 307

vii

ARP commands

arp check enable

Use arp check enable to enable dynamic ARP entry check. Use undo arp check enable to disable dynamic ARP entry check.

Syntax

arp check enable undo arp check enable

Default

Dynamic ARP entry check is enabled.

Views

System view

Predefined user roles

network-admin

Usage guidelines

Dynamic ARP entry check disables a device f rom supporting dynamic ARP entries with multicast MAC addresses. The device cannot learn dynamic ARP entries containing multicast MAC addresses. You cannot manually add static ARP entries that contain multicast MAC addresses.

When this function is disabled, ARP entries containing multicast MAC addresses are supported. The device can learn dynamic ARP entries containing multicast MAC address es obta in ed f r om the ARP packets sourced from a unicast MAC address. You can also manually add static ARP entries containing multicast M AC addresses.

Examples

# Enable dynamic ARP entry check.

<Sysname> system-view [Sysname] arp check enable

arp check log enable

Use arp check log enable to enable the ARP logging function. Use undo arp check log enable to disable the ARP logging function.

Syntax

arp check log enable undo arp check log enable

Default

ARP logging is disable d.

Views

System view

Predefined user roles

network-admin

•

Usage guidelines

This function enables a device to log ARP events when ARP cannot resolve IP addresses correctly. The device can log the following ARP events:

On a proxy ARP-disabled interface, the target IP address of a received ARP packet is not one of

the following IP addresses:

 The IP address of the receiving interface.  The virtual IP address of the VRRP group.  The public address after NAT.

The sender IP address of a received ARP reply conflicts with one of the following IP addresses:

 The IP address of the receiving interface.  The virtual IP address of the VRRP group.  The public address after NAT.

The device sends ARP log messages to the information center. Y ou can use the info-center source command to specify the log output rules for the information center. For more information about information center, see Network Manage men t and Mo nitoring Configuration Guid e.

The device can gener ate a large am ount of ARP logs . To conserve system resources, enab le ARP logging only when you are troubleshooting or debugging ARP events.

Examples

# Enable ARP logging.

<Sysname> sy stem-view [Sysname] ar p check log enable

arp max-learning-num

Use arp ma x-learning-num to s et th e m axim um number of dynamic ARP entries that an i nterfac e can learn.

Use undo arp max-learning-num to restore the default.

Syntax

arp max-learning-num number undo arp max-learning-num

Default

An interface can learn a maximum of 16384 dynamic ARP entries.

Views

Layer 2 Ethernet interface view, Layer 3 Ethernet interface view, Layer 3 Ethernet subinterface view, VLAN interface view, Layer 2 aggregate interf ace view, Layer 3 aggr egate interface view, Layer 3 aggregate subinterface view, S-channel interface view, S-channel aggregate interface view

Predefined user roles

network-admin

Parameters

number: Specifies the maximum number of dynamic ARP entries for an interface. The value range is 0 to 16384.

Usage guidelines

An interface can dynamically learn ARP entries. To prevent an interface from holding too many ARP entries, you can set the maximum number of dynamic ARP entries that the interface can learn. When the maximum number is reached, the interface stops learning ARP entries.

When the number argument is set to 0, the interface is disabled from learning dynamic ARP entries.

Examples

# Specify VLAN-interface 40 to learn a maximum of 500 dynamic ARP entries.

<Sysname> system-view [Sysname] interface vlan-interface 40 [Sysname-Vlan-interface40] arp max-learning-num 500

# Specify T en-GigabitEthernet 1/0/1 to learn a maximum of 1000 dynamic ARP entries.

<Sysname> system-view [Sysname] interface Ten-GigabitEthernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] arp max-learning-num 1000

# Specify Layer 2 aggreg ate interface bridg e-aggregation 1 to learn a m aximum of 1000 d ynamic ARP entries.

<Sysname> sy stem-view [Sysname] inte rface bridge-aggregation 1 [Sysname-Bridge-Aggregation1] arp max-learning-num 1000

# Specify Layer 3 aggregate interface route-aggregation 1 to learn a maximu m of 1000 dynamic ARP entries.

<Sysname> sy stem-view [Sysname] interface route-aggregation 1 [Sysname-Route-Aggregation1] arp max-learning-num 1000

arp max-learning-number

Use arp max-learning-number to set the m axim um num ber of dynamic ARP entries that a device can learn.

Use undo arp max-learning-number to restore the default.

Syntax

arp max-learning-number number slot slot-number undo arp max-learning-number slot slot-number

Default

A device can learn a maximum of 16384 dynamic ARP entries.

Views

System view

Predefined user roles

network-admin

Parameters

number: Specifies the maximum number of dynamic ARP entries for a device. The value range is 0 to 16384.

slot slot-number: Specifies an IRF m ember device by its member ID or a PEX by its virtual slot number.

Usage guidelines

A device can dynamically learn ARP entries. T o prevent a device from holding too many ARP entries, you can set the maxim um number of dynamic ARP entries that the d evice can learn. When the maximum number is reached, the device stops learning ARP entries.

When the number argument is set to 0, the device is disabled from learning dynamic ARP entries.

Examples

# Set the IRF member device in slot 1 to learn a maximum of 64 dynamic ARP entries.

<Sysname> sy stem-view [Sysname] ar p max-learning-number 64 slot 1

arp multiport

Use arp multiport to configure a multiport ARP entry. Use undo arp to remove an ARP entry.

Syntax

arp multiport ip-address mac-address vlan-id [ vpn-instance vpn-instance-name ] undo arp ip-address [ vpn-instance-name ]

Default

No multiport ARP entries are configured.

Views

System view

Predefined user roles

network-admin

Parameters

ip-address: Specifies an IP address for the multiport ARP entry. mac-address: Specifies a MAC address for the multiport ARP entry, in the format of H-H-H. vlan-id: Specifies a VLAN for the multiport ARP entry, in the range of 1 to 4094.

vpn-instance vpn-instance-name: Specifies an MPL S L3V PN instance for the multiport ARP entry. The vpn-instance-name argument is a case-sensitive string of 1 to 31 characters. The specified VPN instance must already exist. Without this option, the multiport ARP entry belongs to the public network.

Usage guidelines

The specified VLAN must already exist. If the VLAN or the corresponding VLAN interface is removed, the multiport ARP entry is also removed.

The specified IP address must reside on the sam e subnet as the VLAN i nterface of the specified VLAN. Otherwise, the multiport ARP entry does not take effect.

To use the multiport ARP entry, you must configur e a multicast or multiport unicas t MAC address entry to specify multiple output interfaces. The MAC address entry must have the same MAC address and VLAN ID as the multiport ARP entry.

Examples

# Configure a multiport ARP entry that comprises IP address 202.38.10.2 and MAC address 00e0-fc01-0000 in VLAN 10.

<Sysname> system-view [Sysname] ar p multiport 202.38.10.2 00e0-fc01-0000 10

Related commands

display arp multiport reset arp multiport

arp static

Use arp static to configure a static ARP entry. Use undo arp to remove an ARP entry.

Syntax

arp static ip-address mac-address [ vlan-id interface-type interface-number ] [ vpn-instance

vpn-instance-name ]

undo arp ip-address [ vpn-instance-name ]

Default

No static ARP entries are configured.

Views

System view

Predefined user roles

network-admin

Parameters

ip-address: Specifies an IP address for the static ARP entry. mac-address: Specifies a MAC addr es s for the static ARP entry, in the format of H-H-H. vlan-id: Specifies the ID of a VLAN t o which the static ARP entry belongs. The va lue range is 1 to

4094. The VLAN and VLAN interface must already exist. interface-type interface-number: Specifies an interface by its type and number. Make sure the

interface belongs to the specified VLAN.

vpn-instance vpn-instance-name: Specifies an MPLS L3VPN for the static ARP entry. The vpn-instance-name argument is a case-sensitive string of 1 to 31 characters. T he VPN instance

must already exist. To specify a static ARP entry on the public network, do not specify this option.

Usage guidelines

A static ARP entry is manually configured and maintained. It does not age out and cannot be overwritten by any dynamic ARP entry.

Static ARP entries ca n be clas s if ied int o l on g an d s hor t st atic ARP entr i es. A short static ARP entry contains an IP-to-MAC mapping. A long static ARP entry contains an IP-to-MAC mapping, a VL AN, and an output interface.

A static ARP entry is effective when the device works correctly. When the VLAN or VLAN inter f ace is deleted, long sta tic ARP entr ies i n the VLA N ar e del eted , and

resolved short static ARP entries in the VLAN become unresolved. A resolved short static ARP entry becomes unresolved upon cer tain ev ents, f or exam ple, when the

output interface goes down. A long static ARP entry is ineffective when the corresponding VLAN interface or output i nterface is

down. An ineffective long static ARP entry cannot be used to for ward pac kets. If you specify both the vlan-id and ip-address arguments, the IP address of the corresponding VLAN

interface must be on the same network as the specified IP address.

If you do not specify a VPN, the undo arp command removes ARP entries only for the public network.

Examples

# Configure a static ARP entry that comprises IP address 202.38.10.2, MAC address 00e0-fc01-0000, and output interface Ten-GigabitEthernet 1/0/1 in VLAN 10.

<Sysname> system-view [Sysname] ar p static 202.38.10.2 00e0-fc01-0000 10 Ten-GigabitEthernet 1/0/1

Related commands

display arp reset arp

arp timer aging

Use arp timer aging to set the aging timer for dynamic ARP entries. Use undo arp timer aging to restore the default.

Syntax

arp timer aging aging-time undo arp timer aging

Default

The aging timer for dynamic ARP entries is 20 minutes.

Views

System view

Predefined user roles

network-admin

Parameters

aging-time: Sets the aging t imer for dynamic ARP entries, in the range of 1 to 1440 minutes.

Usage guidelines

Each dynamic ARP entr y in the ARP table has a limited lifetim e, called an aging timer. The aging timer of a dynamic ARP entr y is reset each tim e the dynam ic ARP entr y is updated. D ynamic ARP entries that are not updated before their aging timers expire are deleted from the ARP table.

Set the aging timer for dynamic ARP entries as needed. For exam ple, when you configure proxy ARP, set a short aging time so that invalid dynamic ARP entries can be deleted in time.

Examples

# Set the aging timer for dynamic ARP entries to 10 minutes.

<Sysname> system-view [Sysname] ar p timer aging 10

Related commands

display arp timer aging

display arp

Use display arp to display ARP entries.

Syntax

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

all: Displays all ARP entries. dynamic: Disp lays dynamic ARP entries. multiport: Displays multiport ARP entries. static: Displays static ARP entries. slot slot-number: Specif ies an IRF member device by its member ID or a PEX by its virtual slot

number. vlan vlan-id: Disp lays th e ARP entries f or the spec ified VLAN. T he VLAN I D is in the range of 1 to

4094. interface interface-type interface-number: Displays the ARP entries for the interface specified by the

argument interface-type interface-number.

count: Displays the number of ARP entries. verbose: Displays detailed information about ARP entries.

Usage guidelines

This command displa ys information a bout ARP entries, including the IP addres s, MAC address, VLAN ID, output interface, entry type, and aging timer.

If you do not specify any parameters, the command displays all ARP entries.

Examples

# Display all ARP entries.

<Sysname> di splay arp all Type: S-Static D-Dynamic O-Openflow M-Multiport I-Invalid IP Address MAC Address VLAN Interface Aging Type

20.1.1.1 00e0-fc00-0001 N/A N/A N/A S

193.1.1.70 00e0-fe50-6503 100 XGE1/0/1 N/A IS

192.168.0.115 000d -88f7-9f7d 1 XGE1/0/2 18 D

192.168.0.39 0012 -a990-2241 1 XGE1/0/3 20 D

22.1.1.1 000c-299d-c041 10 N/A N/A M

# Display detailed information about all ARP entries.

<Sysname> di splay arp all verbose Type: S-Static D-Dynamic O-Openflow M-Multiport I-Invalid IP Address MAC Address VLAN Interface Aging Type Vpn Instance

20.1.1.1 00e0-fc00-0001 N/A N/A N/A S [No Vrf]

193.1.1.70 00e0-fe50-6503 100 XGE1/0/1 N/A IS [No Vrf]

Field

Description

To obtain the output interface inform atio n of the multiport ARP entry, look

192.168.0.115 000d -88f7-9f7d 1 XGE1/0/2 18 D [No Vrf]

192.168.0.39 0012 -a990-2241 1 XGE1/0/3 20 D [No Vrf]

22.1.1.1 000c-299d-c041 10 N/A N/A M [No Vrf]

# Display the number of all ARP entries.

<Sysname> display arp all count Total number of entries : 5

Table 1 Command output

IP Address IP address in an ARP entry. MAC Address MAC address in an ARP entry.

VLAN

Interface

Aging

Type

Vpn Instance

Total number of entries Number of ARP entries.

Related commands

ID of the VLAN to which the ARP entry belongs. This field displays either of the following situations:

• The ARP entry is an unresolved short static ARP entry.

• The output interface of the ARP entry does not belong to the VLAN.

Output interface in an ARP entry. This field displays following situations:

• The ARP entry is an unresolved short static ARP entry.

• The ARP entry is a multiport ARP entry and has no output interface

information. up the MAC address table according to the MAC address in the ARP

entry.

Aging time for a dynami c ARP entry in minutes. time or no aging time.

ARP entry type:

• D—Dynamic.

• S—Static.

• O—OpenFlow.

• M—Multiport.

• I—Invalid.

Name of VPN instance. for the ARP entry.

[No Vrf]

is displayed if no VPN in stan ce is configured

N/A

in either of the

N/A

means unknown aging

N/A

arp static reset arp

display arp ip-address

Use display arp ip-address to display the ARP entry for an IP address.

Syntax

display arp ip-address [ slot slot-number ] [ verbose ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

ip-address: Displays the ARP entry for the specified IP address. slot slot-number: Specif ies an IRF member device by its member ID or a PEX by its virtual slot

number. verbose: Displays the detailed inform ation abo ut the specified ARP entry.

Usage guidelines

The ARP entry information inclu des the IP addres s , M AC ad dr ess , VLA N ID, out p ut int erface, entry type, and aging timer.

Examples

# Display the ARP entry for the IP address 20.1.1.1.

<Sysname> display arp 20.1.1.1 Type: S-Static D-Dynamic O-Openflow M-Multiport I-Invalid IP address MAC address VLAN Interf ace Aging Type

20.1.1.1 00e0-fc00-0001 N/A N/A N/A S

Related commands

arp static reset arp

display arp entry-limit

Use display arp entry-limit to display the maximum number of ARP entries that a device supports.

Syntax

display arp entry-limit

Views

Any view

Predefined user roles

network-admin network-operator

Examples

# Display the maximum number of ARP entries that the device supports.

<Sysname> display arp entry-limit ARP entries: 16384

display arp timer aging

Use display arp timer aging to display the aging timer of dynamic ARP entries.

Syntax

display arp timer aging

Views

Any view

Predefined user roles

network-admin network-operator

Examples

# Display the aging timer of dynamic ARP entries.

<Sysname> disp lay arp timer aging Current ARP ag ing time is 10 minute(s)

Related commands

arp timer aging

display arp vpn-instance

Use display arp vpn-instance to displa y the ARP entries for a VPN instance.

Syntax

display arp vpn-instance vpn-instance-name [ count ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

vpn-instance-name: Specifies an MPLS L3VPN instance by its name, a case-sensitive string of 1 to 31 characters.

count: Displays the number of ARP entries.

Usage guidelines

This command displays information about ARP entries for a VPN instance, including the IP address, MAC address, VLAN ID, output interface, entry type, and aging timer.

Examples

# Display ARP entries for the VPN instance named test.

<Sysname> display arp vpn-instance test Type: S-Static D-Dynamic O-Openflow M-Multiport I-Invalid IP address MAC address VLAN ID Int erface Aging Type

20.1.1.1 00e0-fc00-0001 N/A N/A N/A S

Related commands

arp static reset arp

reset arp

Use reset arp to clear ARP entries from the ARP table.

Syntax

reset arp { all | dynamic | interface interface-type interface-number | multiport | slot slot-number | static }

Views

User view

Predefined user roles

network-admin

Parameters

all: Clears all ARP entries. dynamic: Clears all dynamic ARP entries. multiport: Clears all multiport ARP entries. static: Clears all static ARP entries. slot slot-number: Specif ies an IRF member device by its member ID or a PEX by its virtual slot

number. interface interface-type interface-number: Clears the ARP entries for the interface specif ied b y the

argument interface-type interface-number.

Usage guidelines

This command can separately clear static ARP entries, dynamic ARP entries, multiport ARP entries, or ARP entries on specified interfaces.

When the interface interface-type interf ace-number option is specif ied, this com mand clears onl y dynamic ARP entries for the specified interface.

When the slot slot-number option is specified, this com mand clears only d ynamic ARP entries for the specified IRF member device or PEX.

Examples

# Clear all static ARP entries.

<Sysname> re set arp static

Related commands

arp static display arp

Gratuitous ARP commands

arp ip-conflict log prompt

Use arp ip-conflict log prompt to enable IP conflict notification without conflict confirmation. Use undo arp ip-conflict log prompt to restore the default.

Syntax

arp ip-conflict log prompt undo arp ip-conflict log prompt

Default

IP conflict notification is disabled. The receiving device sends a gratuitous ARP request, and it displays an error message after it receives an ARP reply about the conflict.

Views

System view

Predefined user roles

network-admin

Examples

# Enable IP conflict notification on the device.

<Sysname> system-view [Sysname] ar p ip-conflict log prompt

arp send-gratuitous-arp

Use arp send-gratuitous-arp to e nable periodic sending of grat uitous ARP packets and set th e sending interval on an interface.

Use undo arp send-gratuitous-arp to disable the interface from periodicall y sending gratuitous ARP packets.

Syntax

arp send-gratuitous-arp [ interval milliseconds ] undo arp send-gratuitous-arp

Default

Periodic sending of gratuitous ARP is disabled.

Views

Layer 3 Ethernet interf ace view, Layer 3 Ethernet subinterface view, Layer 3 aggregate interface view, Layer 3 aggregate subinterface view, VLAN interface view

Predefined user roles

network-admin

Parameters

interval milliseconds: Sets the interval at which gratuitous ARP packets are sent, in the range of 200

to 200000 milliseconds. The default value is 2000 milliseconds.

•

Usage guidelines

This function takes effect only when the enabled interface is up and an IP address has been assigned to the interface.

This function c an se nd gratuitous ARP requ ests only f or a V RRP virtual IP addres s, or the s endi ng interface's primary IP address or manually configured secondary IP address. The primary IP address can be configured manually or automatically , whereas the secondary IP address must be configured manually.

If you change the interval for sending gratuitous ARP packets, the conf iguration takes effect at the next sending interval.

The frequency of sending gratuitous ARP packets might be much lower than expected when any of the following conditions exist:

This function is enabled on multiple interfaces. Each interface is configured with multiple secondary IP addresses. A small sending interval is configured in the preceding cases.

Examples

# Enable VLAN-interface 2 to send gratuitous ARP packets every 300 milliseconds.

<Sysname> sy stem-view [Sysname] in terface vlan-interface 2 [Sysname-Vlan-interface2] ar p send-gratuitous-arp interval 300

gratuitous-arp-learning enable

Use gratuitous-arp-learning enable to enable learning of gratuitous ARP packets. Use undo gratuitous-arp-learning enable to disable learning of gratuitous ARP packets.

Syntax

gratuitous-arp-learning enable undo gratuitous-arp-learning enable

Default

Learning of gratuitous ARP packets is enabled.

Views

System view

Predefined user roles

network-admin

Usage guidelines

The learning of gratuitous ARP packets function allows a device to maintain its ARP table by creating or updating ARP entries based on received gratuitous ARP packets.

When this functio n is disabled, the de vice uses r ecei ve d gratuitous ARP pack ets to update existing ARP entries only. ARP entries are not created based on the received gratuitous ARP packets, which saves ARP table space.

Examples

# Enable learning of gratuitous ARP packets.

<Sysname> system-view [Sysname] gratuitous-arp-learning enable

gratuitous-arp-sending enable

Use gratuitous-arp-sending enable to ena ble sending of gratuitous ARP packets upon receiving ARP requests whose sender IP address is on a different subnet.

Use undo gratuitous-arp-sending enable to restore the default.

Syntax

gratuitous-arp-sending enable undo gratuitous-arp-sending enable

Default

A device does not send gratuitous ARP p ackets when it receives ARP requ ests whose sender IP address is on a different subnet.

Views

System view

Predefined user roles

network-admin

Examples

# Disable a device from sending gratuitous ARP packets upon receiving ARP requests whose sender IP address is on a different subnet.

<Sysname> sy stem-view [Sysname] undo gratuitous-arp-sending enable

Proxy ARP commands

display local-proxy-arp

Use display local-proxy-arp to display the local proxy ARP status.

Syntax

display local-proxy-arp [ interface interface-type interface-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

interface interface-type interface-number: Displays the local proxy ARP status for the specified

interface.

Usage guidelines

You can use this command to check whether local proxy ARP is enabled or disabled. If an interface is specified, this command displays the local proxy ARP status for the specified

interface. If no interface is specified, this command displays the local proxy ARP status for all interfaces.

Examples

# Display the local proxy ARP status for VLAN-interface 2.

<Sysname> display local-proxy-arp interface vlan-interface 2 Interface Vl an-interface2 Local Proxy ARP st atus: enabled

Related commands

local-proxy-arp enable

display proxy-arp

Use display proxy-arp to displ a y the proxy ARP status.

Syntax

display proxy-arp [ interface interface-type interface-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

interface interface-type interface-number: Displays the proxy ARP status for the specified interface.

Usage guidelines

You can use this command to check whether proxy ARP is enabled or disabled. If an interface is specified, this command displays proxy ARP status for the specified interface. If no interface is specified, this command displays proxy ARP status for all interfaces.

Examples

# Display the proxy ARP status on VLAN-interface 1.

<Sysname> display proxy-arp interface Vlan-interface 1 Interface Vl an-interface1 Proxy ARP status : disabled

Related commands

proxy-arp enable

local-proxy-arp enable

Use local-proxy-arp enable to enable local proxy ARP. Use undo local-proxy-arp enable to disable local proxy ARP.

Syntax

local-proxy-arp enable [ ip-range startIP to endIP ] undo local-proxy-arp enable

Default

Local proxy ARP is disabled.

Views

VLAN interface view, Layer 3 Et hernet interf ace view, Layer 3 Ethernet subinterface vie w, Layer 3 aggregate interface view, Layer 3 aggregate subinterface view

Predefined user roles

network-admin

Parameters

ip-range startIP to endIP: Specifies the IP address range for which local proxy ARP is enabled. The

start IP address must be lower than or equal to the end IP address.

Usage guidelines

Proxy ARP enables a device on a net work to answer ARP requests f or an IP address not on that network. With proxy ARP, hosts in different broadcast domains can communicate with each other as they do on the same network.

Proxy ARP includes common proxy ARP and local proxy ARP. Common proxy ARP allows communication between hosts that connect to different Layer 3

interfaces and reside in different broadcast domains. Local proxy ARP allows com munication between hosts that c onnect to the same La yer 3 interface

and reside in different broadcast domains. Only one IP address range can be specified by using the ip-range keyword on an interface.

Examples

# Enable local proxy ARP on VLAN-interface 2.

<Sysname> system-view

[Sysname] interface vlan-interface 2 [Sysname-Vlan-interface2] lo cal-proxy-arp enable

# Enable local proxy ARP on VLAN-interface 2 for an IP address range.

<Sysname> sy stem-view [Sysname] in terface vlan-interface 2 [Sysname-Vlan-interface2] lo cal-proxy-arp enable ip-range 1.1.1.1 to 1.1.1.20

Related commands

display local-proxy-arp

proxy-arp enable

Use proxy-arp enable to enable proxy ARP. Use undo proxy-arp enable to disable prox y ARP.

Syntax

proxy-arp enable undo proxy-arp enable

Default

Proxy ARP is disabled.

Views

VLAN interface view, Layer 3 Ethern et interface vi ew, Layer 3 Ethernet subinterface view, Layer 3 aggregate interface view, Layer 3 aggregate subinterface view

Predefined user roles

network-admin

Usage guidelines

Proxy ARP includes common proxy ARP and local proxy ARP. Common proxy ARP allows communication between hosts that connect to different Layer 3

interfaces and reside in different broadcast domains. Local proxy ARP allows com munication between hosts that c onnect to the same La yer 3 interface

and reside in different broadcast domains.

Examples

# Enable proxy ARP on VLAN-interface 2.

<Sysname> system-view [Sysname] interface vlan-interface 2 [Sysname-Vlan-interface2] pr oxy-arp enable

Related commands

display proxy-arp

ARP snooping commands

arp snooping enable

Use arp snooping enable to enable ARP snooping. Use undo arp snooping enable to disable ARP snooping.

Syntax

arp snooping enable undo arp snooping enable

Default

ARP snooping is disabled.

Views

VLAN view

Predefined user roles

network-admin

Examples

# Enable ARP snooping on VLAN 2.

<Sysname> sy stem-view [Sysname] vlan 2 [Sysname-vlan2] arp snooping enable

display arp snooping

Use display arp snooping to display ARP snooping entries.

Syntax

display arp snooping [ vlan vlan-id ] [ slot slot-number ] [ count ] display arp snooping ip ip-address [ slot slot-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

vlan vlan-id: Displays ARP snooping entries for a VLAN. The vlan-id argument is in the range of 1 to

4094.

count: Displays the number of the current ARP snooping entries. ip ip-address: Displays the ARP snooping entry for the specified IP address. slot slot-number: Specif ies an IRF member device by its member ID or a PEX by its virtual slot

number.

Field

Description

Usage guidelines

If you do not specify any keywords or arguments, the command displays all ARP snooping entries.

Examples

# Display ARP snooping entries for VLAN 2.

<Sysname> disp lay arp snooping vlan 2 IP Address MAC Address VLAN ID Interface Aging Status

3.3.3.3 0003-0003-0003 2 XGE1/0/1 20 Valid

3.3.3.4 0004-0004-0004 2 XGE1/0/2 5 Invalid

# Display the number of the current ARP snooping entries.

<Sysname> disp lay arp snooping count Total entries: 2

Table 2 Command output

IP Address IP address in an ARP snoopin g entry. MAC Address MAC address in an ARP snoo ping entry . VLAN ID ID of the VLAN to which the ARP snooping entry belongs. Interface Input interface in an ARP snoo ping entr y . Aging Aging time for an ARP snoopi ng entry in minutes. Status Total entries Number of ARP snooping entries.

Related commands

reset arp snooping

reset arp snoopin g

Use reset arp snooping to remove ARP snooping entries.

Syntax

reset arp snooping [ ip ip-address | vlan vlan-id ]

Views

User view

Predefined user roles

network-admin

Parameters

Status of an ARP snooping entry:

Valid, Invalid, Collision

ip ip-address: Removes the ARP entry for the specified IP address. vlan vlan-id: Removes the ARP entries for the specified VLAN. The vlan-id argument is in the range

of 1 to 4094.

Usage guidelines

If you do not specify any keywords or arguments, the command removes all ARP snooping entries.

Examples

# Remove ARP snooping entries for VLAN 2.

<Sysname> rese t arp snooping vlan 2

Related commands

display arp snooping

ARP fast-reply commands

arp fast-reply enab le

Use arp fast-reply enable to enable ARP fast-reply for a VLAN. Use undo arp fast-reply enable to disable ARP fast-reply for a VLAN.

Syntax

arp fast-reply enable undo arp fast-reply enable

Default

ARP fast-reply is disabled on a VLAN.

Views

VLAN view

Predefined user roles

network-admin

Examples

# Enable ARP fast-reply for VLAN 2.

<Sysname> system-view [Sysname] vlan 2 [Sysname-vlan2] arp fast-reply enable

•

IP addressing commands

The IP addresses in this chapter refer to IPv4 addresses unless otherwise specified. The term "interface" in this chapter collectively refers to Layer 3 interfaces, including VLAN

interfaces and La yer 3 Ethernet interf aces. You can set an Ethernet port as a Layer 3 int erface by using the port link-mode route command (see Layer 2—LAN Switching Configuration Guide).

display ip interface

Use display ip interface to display IP configuration and statistics for the specified Layer 3 interface or all Layer 3 interfaces.

Syntax

display ip interface [ interface-type interface-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

interface-type interface-number: Specifies an interface by its type and number.

Usage guidelines

Use the display ip interface com mand to display IP configuration and statis tics for the specified Layer 3 interface. The statistics include the following information:

The number of unicast packets, bytes, and multicast packets the interface has sent and

received.

The number of TTL-invalid packets and ICMP packets the interface has received. The packet statistics helps you locate a possible attack on the network. If you do not specify an interface, the command displays information about all Layer 3 interfaces.

Examples

# Display IP configuration and statistics for VLAN-interface 10.

<Sysname> displ ay ip interface vlan-interface 10 Vlan-interfac e10 current stat e : DOWN Line protoco l current state : DOWN Internet Addres s is 1.1.1.1/8 Primary Broadcast ad dress : 1.255.255.255 The Maximum Tr ansmit Unit : 1500 bytes input packet s : 0, bytes : 0, multicas ts : 0 output packets : 0, bytes : 0, multicasts : 0 TTL invalid packet number: 0 ICMP packet in put number: 0 Echo reply: 0 Unreachable: 0 Source quench : 0

Field

Description

Routing redire ct: 0 Echo request: 0 Router advert : 0 Router solicit: 0 Time exceed: 0 IP header bad: 0 Timestamp request: 0 Timestamp reply: 0 Information request: 0 Information reply: 0 Netmask request: 0 Netmask reply: 0 Unknown type: 0

Table 3 Command output

Current physical state of the interface:

• Administrative DOWN—The interface is shut down with the

current state

shutdown command.

• DOWN—The interface is administratively up but its physical state is down, which might be caused by a connection or link failure.

• UP—Both the administrativ e and phy sical states of the interface a re up.

Current state of the link layer protocol:

• DOWN—The protocol state of the interface is down.

Line protocol current state

• UP—The protocol state of the interface is up.

• UP (spoofing)—The protocol state of the interface pretends to be up.

However, no corresponding link is present, or the corresponding link is not present permanently but is established as needed.

IP address of an interface followed by:

• Primary—A primary IP address.

• Sub—A secondary IP addr es s .

• DHCP-Allocated—An IP address obtained through DHCP.

Internet Address

• BOOTP-Allocated—An IP address obtained through BOOTP.

• Cluster—A cluster IP address.

• Mad—A MAD IP address.

• IRF-Member—IP address of the management Ethernet port of an IRF

member device.

Broadcast address Broadcast address of the subnet attached to an interfac e. The Maximum Transmit Unit Maximum transmission units on the interface, in bytes. input packets, bytes,

multicasts output packets, bytes,

Unicast packets, bytes, and multicast packets received on an interface (statistics start at the device startup).

multicasts

TTL invalid packet number

Number of TTL-invalid packets received on the interface (statistics start at the device startup).

ICMP packet input number: Echo reply: Unreachable: Source quench:

Total number of ICMP packets received on the interface (statistics start at the device startup):

• Echo reply packets.

• Unreachable packets.

• Source quench packets.

Field

Description

• Routing redirect packets.

Routing redirect: Echo request: Router advert: Router solicit: Time exceed: IP header bad: Timestamp request: Timestamp reply: Information request: Information reply: Netmask request: Netmask reply: Unknown type:

Related commands

display ip interface brief ip address

• Echo request packets.

• Router advertisement packets.

• Router solicitation packets.

• Time exceeded packets.

• IP header bad packets.

• Timestamp request packets.

• Timestamp reply packets.

• Information request packets.

• Information reply packets.

• Netmask request packets.

• Netmask reply packets.

• Unknown type packets.

display ip interface brief

Use display ip interface brief to display brief IP configuration information for the specified Layer 3 interface or all Layer 3 interfaces.

Syntax

display ip interface [ interface-type [ interface-number ] ] brief

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

interface-type: Specifies the interface type. interface-number: Specifies the interface number.

Usage guidelines

Use the display ip interface brief command to display brief IP configuratio n information, including the state, IP address, and description of the physical and link layer protocols, for the specified Layer 3 interface or all Layer 3 interfaces.

If you do not specify the in terface type and interface number, the command displays the brief IP configuration information for all Layer 3 interfaces.

If you specify only the interface type, the command displays the brief IP configuration information for all Layer 3 interfaces of the specified type.

If you specify both the interface type and interface number, the command displays the brief IP configuration information for the specified interface.

Field

Description

Examples

# Display brief IP configuration information for VLAN interfaces.

<Sysname> display ip interface vlan-interface brief *down: administ ratively down (s): spoofing ( l): loopback Interface Physical Protocol IP Address Description Vlan10 down down 6.6.6.1 Vlan-inte... Vlan2 down down 7.7.7.1 Vlan-inte...

Table 4 Command output

*down: administratively down

(s) : spoofing

Interface Interface name.

Physical

Protocol

IP Address

Description

Related commands

The interface is administratively shut down with the

Spoofing attribute o f the interface. It ind ica tes th at an interface might have no link present even when its link layer protocol is up or the link is established only on demand.

Physical state of the interface:

• *down—The interface is administratively shut down with the shutdown command.

• down—The interface is administratively up but its physical state is down (possibly because of poor connection or line failure).

• up—Both the administrative and physical states of the interface are up.

Link layer protocol state of the interface:

• down—The protocol state of the interface is down (typically when no IP address is configured for the interface).

• up—The protocol state of the interface is up.

• up(s)—The protocol state of the interface is up (spoofing).

IP address of the interface. If no IP address is configured, displayed.

Interface description informat i on. A maximum of 12 characters can be displayed. If there are more than 12

characters, only the first 9 characters are displayed.

shutdown

unassigned

command.

display ip interface ip address

ip address

Use ip address to assign an IP address to the interface. Use undo ip address to remove the IP address from the interface.

Syntax

ip address ip-address { mask-length | mask } [ irf-member member-id | sub ] undo ip address [ ip-address { mask-length | mask } [ irf-member member-id | sub ] ]

Default

No IP address is assigned to an interface.

Views

Interface view

Predefined user roles

network-admin

Parameters

ip-address: Specifies the IP address of the interface, in dotted decimal notation. mask-length: Specifies the subnet mask length in the range of 1 to 31. For a loopback interface, the

value range is 1 to 32. mask: Specifies the subnet mask in dotted decimal notation. irf-member member-id: Assigns an IP address to the managem ent Ethernet port of the spec ified

IRF member device. The member-id argument specifies an IRF member device by its member ID in the range of 1 to 10.

sub: Assigns a secondary IP address to the interface.

Usage guidelines

Use the command to conf igure a primary IP address for an interfac e. If the interface connects to multiple subnets, configure primary and secondary IP addresses on the interface so the subnets can communicate with each other through the interface.

An interface can have only one primary IP address. A newly configured primary IP address overwrites the previous address.

You cannot assign secondary IP addresses to an interface that obtains an IP address through BOOTP, DHCP, or IP unnumbered.

The undo ip address command removes all IP addresses from the interface. The undo ip address

ip-address { mask | mask-length } command removes the primary IP address. The undo ip address ip-address { mask | mask-length } sub command removes a secondary IP address. Before removing

the primary IP address, remove all secondary IP addresses. The primary and sec ondary IP address es you assign to the interfac e can be located on the same

network segment, but different interfaces on your device must reside on different network segments. The IP addresses assigned to the management Ethernet ports of all IRF member devices must be in

the same subnet. In an IRF fabric, only the IP address assigned to the management Ethernet port of the master takes effect. Make sure no IP address conflict exists when you assign IP addresses to the management Ethernet ports of subord inates. The system does not warn of an IP address conflict because the IP addresses as signe d to the management Et hern et ports of subordi nates d o n ot t ak e effect. After an IRF fabric split, the IP addresses assigned to the management Ethernet ports of the new masters (original subordinates) take effect.

Examples

# Assign VLAN-interface 10 a primary IP address 129.12.0.1 and a secondary IP address

202.38.160.1, with subnet masks both 255.255.255.0.

<Sysname> system-view [Sysname] interface vlan-interface 10 [Sysname-Vlan-interface10] ip address 129.12.0 .1 255.255.255.0 [Sysname-Vlan-interface10] ip address 202.38.160 .1 25 5.255.255.0 sub

Related commands

display ip interface display ip interface brief

ip address unnumbered

Use ip address unnumbered to config ure the c ur rent interface as IP unnumbered to borro w an IP address from the specified interface.

Use undo ip address unnumbered to disable IP unnumbered on the interface.

Syntax

ip address unnumbered interface interface-type interface-number undo ip address unnumbered

Default

The interface does not borrow IP addresses from other interfaces.

Views

Tunnel interface view

Predefined user roles

network-admin

Parameters

interface interface-type interface-number: Specifies an interfac e from which the current interface

can borrow an IP address.

Usage guidelines

Typically, you assign an IP address to an interface either manually or through DHCP. If the IP addresses are not enough, or the interface is used only occasionally, you can configure an interface to borrow an IP address from other interfaces. This is called IP unnumbered, and the interface borrowing the IP address is called IP unnumbered interface.

Multiple interfaces c an use the same unnumber ed IP addres s . If an inter f ac e has multiple manually configured IP addresses, only the primary IP address manually configured can be borrowed.

You cannot enable a dynamic routing protocol on the interface that has no IP address configured. To enable the interface to communicate with other devices, you must configure a static route to the peer device on the interface.

Before entering tunnel interface view, make sure the tunnel interface has been created. For information about tunnel interface, see Layer 3—IP Services Configuration Guide.

Examples

# Configure the interface Tunnel 1 to borrow the IP address of VLAN-interface 100.

<Sysname> system-view [Sysname] interface tunnel 1 [Sysname-Tunn el1] ip address un numbered interface vlan-interface 100

DHCP commands

Common DHCP commands

dhcp dscp

Use dhcp dscp to set the DSCP valu e for DHCP packets sent b y the DHCP server or the DHCP relay agent.

Use undo dhcp dscp to restore the def au lt.

Syntax

dhcp dscp dscp-value undo dhcp dscp

Default

The DSCP value in DHCP packets is 56.

Views

System view

Predefined user roles

network-admin

Parameters

dscp-value: Sets the DSCP value for DHCP packets, in the range of 0 to 63.

Usage guidelines

The DSCP value of a packet specifies th e priority level of the pack et and affects the tra nsmission priority of the packet. A bigger DSCP value represents a higher priority.

Examples

# Set the DSCP value for DHCP packets to 30.

<Sysname> sy stem-view [Sysname] dh cp dscp 30

dhcp enable

Use dhcp enable to enable DHCP. Use undo dhcp enable to disable DHCP.

Syntax

Default

Views

dhcp enable undo dhcp enable

DHCP is disabled.

System view

Predefined user roles

network-admin

Usage guidelines

Enable DHCP before you perform DHCP server or relay agent configurations.

Examples

# Enable DHCP.

<Sysname> sy stem-view [Sysname] dhcp en able

dhcp select

Use dhcp select to enable the DHCP server or DHCP relay agent on an interface. Use undo dhcp select to disable the DHCP server or DHCP relay agent on an interface. The

interface discards DHCP packets.

Syntax

dhcp select { relay | server } undo dhcp select { relay | server }

Default

The interface operates in DHCP server mode and res ponds to DHCP requests with c onfiguration parameters.

Views

Interface view

Predefined user roles

network-admin

Parameters

relay: Enables the DHCP relay agent on the interface. server: Enables the DHCP server on the interface.

Usage guidelines

Before changing the DHC P server mode to the DHCP relay agent m ode on an interface, use the reset dhcp server ip -in-use command to rem ove address bindi ngs and authori zed ARP entries. These bindings might conflict with ARP entries that are created after the DHCP relay agent is enabled.

Examples

# Enable the DHCP relay agent on VLAN-interface 2.

<Sysname> sy stem-view [Sysname] in terface vlan-interface 2 [Sysname-Vlan-interface2] dhcp select relay

Related commands

reset dhcp server ip-in-use

DHCP server commands

The term "interface" in this section collectively refers to Layer 3 interfaces, including VLAN interfaces and Layer 3 Ethernet i nterfaces. You can set an Ethernet port as a La yer 3 interface b y using the port link-mode route command (see Layer 2—LAN Switching Configuration Guide).

address range

Use address range to configure an IP address range in a DHCP address pool for dynamic allocation.

Use undo address range to remove the IP address range in the DHCP address pool.

Syntax

address range start-ip-address end-ip-address undo address range

Default

No IP address range is configured.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

start-ip-address: Specifies the start IP address. end-ip-address: Specifies the end IP address.

Usage guidelines

If no IP address range is specified, all IP addresses in the subnet specified by the network command in address pool view are assignable. If an IP address range is specified, only the IP addresses in the IP address range are assignable.

After you use the address range command, you cannot use the network secon dary command to specify a secondary subnet in the address pool.

If you use the command multiple times, the most recent configuration takes effect. The address range specified by the address range command must be within the subnet specified by

the network command, and the addresses out of the address range cannot be assigned.

Examples

# Specify an address range of 192.168.8.1 through 192.168.8.150 in address pool 1.

<Sysname> system-view [Sysname] dh cp server ip-pool 1 [Sysname-dhcp-pool-1] address ra nge 192.168.8.1 192.168.8.150

Related commands

class dhcp class display dhcp server pool network

bims-server

Use bims-server to specif y the IP address, por t number, and s hared key of the BIMS server in a DHCP address pool.

Use undo bims-server to remove the specified BIMS server information.

Syntax

bims-server ip ip-address [ port port-number ] sharekey { cipher | simple } key undo bims-server

Default

No BIMS server information is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip ip-address: Specifies the IP address of the BIMS server. port port-number: Specifies the port number of the BIMS server, in the range of 1 to 65534. cipher: Sets a ciphertext key. simple: Sets a plaintext key.

key: Specifies the k ey string. This argument is c ase sensitive. If simple is specified, it must be a string of 1 to 16 characters. If cipher is specified, it must be a ciphertext string of 1 to 53 characters. The DHCP client uses the shared key to encrypt packets sent to the BIMS server.

Usage guidelines

If you use this command multiple times, the most recent configuration takes effect. For security purposes, all passwords, including passwords configured in plaintext, are saved in

ciphertext.

Examples

# Specify the BIMS server I P address 1.1.1.1, p ort num ber 80, and shar ed key aabbcc in addr ess pool 0.

<Sysname> sy stem-view [Sysname] dhcp server ip-pool 0 [Sysname-dhcp-pool-0] bims-server ip 1.1.1.1 port 80 sharekey simple aabbcc

Related commands

display dhcp server pool

bootfile-name

Use bootfile-name to specify a configuration file name or URL. Use undo bootfile-name to remove the configuration file name or URL.

Syntax

bootfile-name { bootfile-name | url } undo bootfile-name

Default

No configuration file name or URL is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

bootfile-name: Specifies the configuration file name, a case-sensitive s tri ng of 1 to 63 characters. url: Specifies the conf igurat ion f il e URL in the format of http://. It is a case-sensitive string of 1 to 63

characters.

Usage guidelines

If you use the bootfile-name command multiple times, the most recent configuration takes effect. If the configuration file is on a TFTP server, specify the configuration file name, and the IP address or

name of the TFTP server. If the configuration file is on an HTTP server, specify the configuration file URL.

Examples

# Specify the boot file name boot.cfg in DHCP address pool 0.

<Sysname> sy stem-view [Sysname] dhcp server ip-pool 0 [Sysname-dhcp-pool-0] bootfile-nam e boot.cfg

# Specify the URL http://10.1.1.1/boot.cfg for the remote boot file in DHCP address pool 0.

<Sysname> sy stem-view [Sysname] dhcp se rver ip-pool 0 [Sysname-dhcp-pool-0] bootfile-name http://1 0.1.1.1/boot.cfg

Related commands

display dhcp server pool next-server tftp-server domain-name tftp-server ip-address

class

Use class to specify an IP address range for a DHCP user class. Use undo class to remove the IP address range for the DHCP user class.

Syntax

Default

Views

class class-name range start-ip-address end-ip-address undo class class-name

No IP address range is specified for a DHCP user class.

DHCP address pool view

Predefined user roles

network-admin

Parameters

class-name: Specifies the name of a DHCP user class, a case-insensitive string of 1 to 63 characters. If the specified user class does not exist, the DHCP server will not assign the addresses in the address range specified for the user class to any client.

start-ip-address: Specifies the start IP address. end-ip-address: Specifies the end IP address.

Usage guidelines

The class command enables you to divide an address range into multiple address ranges for different DHCP user classes. The address range for a user class must be within the primary subnet specified by the network com mand. If the DH CP client does not matc h any DHCP user class, the DHCP server selects an address in the IP address range specified by the address range command. If the address range has no assignable IP addresses or no address range is configured, the address allocation fails.

Yo u can specif y only one addr ess range f or a DHCP user clas s in an addres s pool. If you use the class command multiple times for a DHCP user class, the most recent configuration takes effect.

After you specify an address range for a user class, you cannot use the network secondary command to specify a secondary subnet in the address pool.

Examples

# Specify an IP address range of 192.168.8.1 through 192.168.8.150 for the DHCP user class user in DHCP address pool 1.

<Sysname> sy stem-view [Sysname] dh cp server ip-pool 1 [Sysname-dhcp-pool-1] class user range 192.168.8.1 192.168.8.150

Related commands

address range dhcp class display dhcp server pool

dhcp class

Use dhcp class to create a DHCP user class and enter the DHCP user class view. Use undo dhcp class to remove the specified DHCP user class.

Syntax

dhcp class class-name undo dhcp class class-name

Default

No DHCP user class exist s.

Views

System view

Predefined user roles

network-admin

Parameters

class-name: Specifies the name of a DHCP user class, a case-insensitive string of 1 to 63 characters.

Usage guidelines

You can also use this command to enter the view of an existing DHCP user class. In the DHCP user class view, use the if-match command to configure a match rule to match specific

clients. Then use the class command to specify an IP address range for the matching clients.

Examples

# Create a DHCP user class test and enter DHCP user class view.

<Sysname> sy stem-view [Sysname] dhcp class test [Sysname-dhcp-class-test]

Related commands

address range class if-match

dhcp server always-broadcast

Use dhcp server always-broadcast to enable the DHCP server to broadcast all responses. Use undo dhcp server always-broadcast to restore the default.

Syntax

dhcp server always-broadcast undo dhcp server always-broadcast

Default

The DHCP server reads t he broadcast flag in a DHCP request to decide whether to broadcast or unicast the response.

Views

System view

Predefined user roles

network-admin

Usage guidelines

This command enables the DHCP server to ignore the broadcast flag in DHCP requests and broadcast all responses.

If a DHCP request is from a DHCP client that has an IP address (the ciaddr field is not 0), the DHCP server always unicasts a response (the destination address is ciaddr) to the DHCP client regardless of whether this command is executed.

If a DHCP request is f rom a DH CP rela y ag ent (t he giaddr field is not 0), t he DHCP serv er a lwa ys unicasts a response (the destination address is giaddr) to the DHCP relay agent regardless of whether this command is executed.

Examples

# Enable the DHCP server to broadcast all responses.

<Sysname> sy stem-view

[Sysname] dh cp server always-broadcast

dhcp server apply ip-pool

Use dhcp server apply ip-pool to apply an addr ess pool on an interf ac e. Use undo dhcp server apply ip-pool to remove the configuration.

Syntax

dhcp server apply ip-pool pool-name undo dhcp server apply ip-pool

Default

No address pool is applied on an interface

Views

Interface view

Predefined user roles

network-admin

Parameters

pool-name: Specifies the name of a DHCP address pool, a case-insensitive string of 1 to 63 characters.

Usage guidelines

Upon receiving a DHCP request from the interface, the DHCP server searches for a static binding for the client from all address pools. If no static binding is found, the server assigns configuration parameters from the addres s pool appl ied on t he interf ace to the c lient. If the add ress pool has no assignable IP address or does not exist, the DHCP client cannot obtain an IP address.

If you use the command multiple times, the most recent configuration takes effect.

Examples

# Apply DHCP address pool 0 on VLAN-interface 2.

<Sysname> system-view [Sysname] interface vlan-interface 2 [Sysname-Vlan-interface2] dhcp server appl y ip-pool 0

Related commands

dhcp server ip-pool

dhcp server bootp ignore

Use dhcp server bootp ignore to configure the DHCP server to ignore BOOTP requests. Use undo dhcp server bootp ignore to restore the default.

Syntax

Default

dhcp server bootp ignore undo dhcp server bootp ignore

The DHCP server does not ignore BOOTP requests.

Views

System view

Predefined user roles

network-admin

Usage guidelines

The lease duration of IP addresses obtained by BOOTP clients is unlimited. For scenarios that do not allow unlimited leases, you can configure the DHCP server to ignore BOOTP requests.

Examples

# Configure the DHCP server to ignore BOOTP requests.

<Sysname> system-view [Sysname] dhcp se rver bootp ignore

dhcp server bootp reply-rfc-1048

Use dhcp server bootp reply-rfc-1048 to enab le the DHCP server to send BOOT P responses in RFC 1048 format when it receives RFC 1048-incompliant BOOTP requests for statically bound addresses.

Use undo dhcp server bootp reply-rfc-1048 to disable this feature.

Syntax

dhcp server bootp reply-rfc-1048 undo dhcp server bootp reply-rfc-1048

Default

This feature is disabled.

Views

System view

Predefined user roles

network-admin

Usage guidelines

Not all BOOTP clients can send requests com pliant with RFC 1048. By default, the DHCP server does not process t he Vend field of RFC 1048-incompliant requests but c opies the Vend field into responses.

Use this command to enable the DHCP server to fill in the Vend field using the RFC 1048-compliant format in DHCP respons es to RFC 10 48-incom pliant r equests sent b y BOOT P clients that request statically bound addresses.

Examples

# Enable the DHCP server to send BO OT P responses in RFC 1 048 format upon rec ei ving BO OTP requests incompliant with RFC 1048.

<Sysname> system-view [Sysname] dhcp server bootp reply-rfc-1048

dhcp server forbid den-ip

Use dhcp server forbidden-ip to exclude specific IP addresses from dynamic allocation. Use undo dhcp server forbidden-ip to remove the configuration.

Syntax

dhcp server forbidden-ip start-ip-address [ end-ip-address ] undo dhcp server forbidden-ip start-ip-address [ end-ip-address ]

Default

No IP addresses are excluded from dynamic allocation.

Views

System view

Predefined user roles

network-admin

Parameters

start-ip-address: Specifies the start IP address. end-ip-address: Specifies the end IP address, which cannot be lower than the start-ip-address. If you

do not specify this argument, only the start-ip-address is excluded from dynamic allocation.

Usage guidelines

The IP addresses of som e devices such as the gateway and FTP server cannot be as signed to clients. Use this command to exclude such addresses from dynamic allocation.

You can exclude multiple IP address ranges from dynamic allocation. If the excluded IP address is in a static binding, the address can be still assigned to the client. The address or address range specified in the undo form of the command must be the same as the

address or address range specified in the command. To remove an IP address that has been specified as part of an address range, you must remove the entire address range.

Examples

# Exclude the IP addresses of 10.110.1.1 through 10.110.1.63 from dynamic allocation.

<Sysname> system-view [Sysname] dhcp server forbidden-ip 10.110.1.1 10.110.1.63

Related commands

forbidden-ip static-bind

dhcp server ip-pool

Use dhcp server ip-pool to create a DHCP address pool and enter its view. Use undo dhcp server ip-pool to remove the specified DHCP address pool.

Syntax

dhcp server ip-pool pool-name

Default

Views

undo dhcp server ip-pool pool-name

No DHCP address pool is created.

System view

Predefined user roles

network-admin

Parameters

pool-name: Specifies the name for the DHCP addres s pool, a case-insensitive string of 1 to 63 characters used to uniquely identify this pool.

Usage guidelines

You can also use this command to enter the view of an existing DHCP address pool. A DHCP address pool is used to store the configuration parameters to be assigned to DHCP clients.

Examples

# Create a DHCP address pool named pool1.

<Sysname> system-view [Sysname] dh cp server ip-pool pool1 [Sysname-dhcp-pool-pool1]

Related commands

dhcp server apply ip-pool display dhcp server pool

dhcp server ping packets

Use dhcp server ping packets to specify the maximum number of ping packets. Use undo dhcp server ping packets to restore the default.

Syntax

dhcp server ping packets number undo dhcp server ping packets

Default

The maximum number of ping packets is 1.

Views

System view

Predefined user roles

network-admin

Parameters

number: Specifies the maximum number of ping packets, in the range of 0 to 10. A value of 0 indicates that the DHCP server does not perform address conflict detection.

Usage guidelines

To avoid IP address conflicts, the DHCP server pings an IP address before as signing it to a DH CP client.

If a ping attempt succ eeds, the server considers th at the IP address is in use an d picks a new IP address. If all the ping attempts are failed, the server assigns the IP address to the requesting DHCP client.

Examples

# Specify the maximum number of ping packets as 10.

<Sysname> system-view

[Sysname] dhcp se rver ping packets 10

Related commands

dhcp server ping timeout display dhcp server conflict reset dhcp server conflict

dhcp server ping timeout

Use dhcp server ping timeout to configure the ping response timeout time on the DHCP server. Use undo dhcp server ping timeout to restore the default.

Syntax

dhcp server ping timeout milliseconds undo dhcp server ping timeout

Default

The ping response timeout time is 500 milliseconds.

Views

System view

Predefined user roles

network-admin

Parameters

milliseconds: Specifies the timeout time in the range of 0 to 10000 milliseconds. To disable the ping operation for address conflict detection, set the value to 0 milliseconds.

Usage guidelines

To avoid IP address conflicts, the DHCP server pings an IP address bef ore assigni ng it to a DHCP client.

If a ping attempt succ eeds, the server considers th at the IP address is in use and pick s a new IP address. If all the ping attempts are failed, the server assigns the IP address to the requesting DHCP client.

Examples

# Specify the response timeout time as 1000 milliseconds.

<Sysname> system-view [Sysname] dhcp server ping timeout 1000

Related commands

dhcp server ping packets display dhcp server conflict reset dhcp server conflict

dhcp server relay information enable

Use dhcp server relay information enable to enable the DHCP server to handle Option 82. Use undo dhcp server relay information enable to configure the DHCP server to ignore Option

82.

•

Syntax

dhcp server relay information enabl e undo dhcp server relay information en able

Default

The DHCP server handles Option 82.

Views

System view

Predefined user roles

network-admin

Usage guidelines

Upon receiving a DHCP request that contains Option 82, the server copies the original Option 82 into the response. If the server is configured to ignore Option 82, the response will not contain Option 82.

Examples

# Configure the DHCP server to ignore Option 82.

<Sysname> sy stem-view [Sysname] undo dhcp server relay in formation ena ble

display dhcp ser v er conflict

Use display dhcp server conflict to display information about IP address conflicts.

Syntax

display dhcp server conflict [ ip ip-address ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

ip ip-address: Displays conflict information about the specified IP address. If you do not specify this

option, this command displays information about all IP address conflicts.

Usage guidelines

The DHCP server creates IP address conflict information in the following conditions:

Before assigning an IP address to a DHCP client, the DHCP server pings the IP address and

discovers that it has been used by other host.

The DHCP client sends a DECLINE packet to the DHCP server to inform the server of an IP

address conflict.

The DHCP server discovers that the only assignable address in the address pool is its own IP

address.

Examples

# Display information about all IP address conflicts.

<Sysname> disp lay dhcp server conflict IP address Detect time

Field

Description

Field

Description

4.4.4.1 Apr 25 16:57:20 2007

4.4.4.2 Apr 25 17:00:10 2007

Table 5 Command output

IP address Conflicted IP address. Detect time Time when the conflict was discovered.

Related commands

reset dhcp server conflict

display dhcp ser v er expired

Use display dhcp server expired to display the lease expiration information.

Syntax

display dhcp server expired [ ip ip-address | pool pool-name ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

ip ip-address: Displays lease expiration information about the specified IP address. pool pool-name: Displays leas e expiration infor mation about th e specified addres s pool. The pool

name is a case-insensitive string of 1 to 63 characters.

Usage guidelines

If you do not specify an y parameter s, this command displa ys lease expir ation inf orm ation about all address pools.

DHCP assigns these expired IP addresses to DHCP clients when all available addresses have been assigned.

Examples

# Display all lease expiration information.

<Sysname> disp lay dhcp server expired IP address Client-identifier/Hard ware address Lease ex piration

4.4.4.6 3030-3066-2e65-3230-302e-3130-3234 Apr 25 17:10:47 2007

-2d45-7468-6572-6e65-7430-2f31

Table 6 Command output

IP address Expired IP address. Client-identifier/Hardware address Client ID or MAC address. Lease expiration Time when the lease expired.

Field

Description

Related commands

reset dhcp server expired

display dhcp ser v er free-ip

Use display dhcp server free-ip to display information about assignable IP addresses.

Syntax

display dhcp server free-ip [ pool pool-name ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

pool pool-name: Displays assignable IP addresses in the specified address pool. The pool name is a

case-insensitive string of 1 to 63 c haracters. If you do not specif y an address pool, this com mand displays all assignable IP addresses for all address pools.

Examples

# Display assignable IP addresses in all address pools.

<Sysname> display dhcp server free-ip Pool name: 1 Network: 10.0.0.0 mask 255.0.0.0 IP ranges from 10.0.0.10 to 10.0.0.100 IP ranges fro m 10.0.0.105 to 10.0.0.255 Secondary networ ks:

10.1.0.0 mask 255.255.0.0 IP ranges from 10.1.0.0 to 10.1.0.255

10.2.0.0 mask 255.255.0.0 IP Ranges from 10.2.0.0 to 10.2.0.255

Pool name: 2 Network: 20.1.1.0 mask 255.255 .255.0 IP ranges fro m 20.1.1.0 to 20.1.1.255

Table 7 Command output

Pool name Name of the address pool. Network Assignable network. IP ranges Assignable IP address range. Secondary networks Assignable secondary network s.

Related commands

address range dhcp server ip-pool

Field

Description

network

display dhcp server ip-in-use

Use display dhcp server ip-in-use to display binding information about assigned IP addresses.

Syntax

display dhcp server ip-in-use [ ip ip-address | pool pool-name ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

ip ip-address: Displays binding information about the specified IP address. pool pool-name: Displays binding information about the specified IP address pool. The pool name is

a case-insensitive string of 1 to 63 characters.

Usage guidelines

If you do not specify any parameters, this command displays binding information about all assigned DHCP addresses.

If the lease deadline exceeds the year 2100, the lease expiration time is displayed as After 2100. The client binding inf or mation can be used b y other security modules s uc h as IP s our ce gu ar d o nly

when the DHCP server is configured on the gateway of DHCP clients.

Examples

# Display binding information about all assigned DHCP addresses.

<Sysname> disp lay dhcp server ip-in-use IP address Client identifier/ Lease expiration Type Hardware address

10.1.1.1 4444-4444-4444 Not used Static(F)

10.1.1.2 3030-3030-2e30-3030- May 1 14:02:49 2009 Auto(C) 662e-3030-3033-2d45 7468-6572-6e65-74

10.1.1.3 1111-1111-1111 After 2100 Static(C)

Table 8 Command output

IP address IP address assigned. Client identifier/Hardware

address

Client ID or hardware address.

Lease expiration

Lease expiration time:

• Exact time (May 1 14:02:49 2009 in this example) —Time when the lease will expire.

• Not used—The IP address of the static bind ing has not bee n assigned to the specific client.

• Unlimited—Infinite lease expiration time.

• After 2100—The lease will expire after 2100.

Field

Description

Binding types:

• Static(F)—A free static binding whose IP address has not been assigned.

• Static(O)—An offered static binding whose IP address has been selected and sent by t h e DH CP server in a DHCP-OFFER pack et to the

Type

client. Static(C)—A committed static binding whose IP address has been assigned to the DHCP client.

• Auto(O)—An offered temporary dynamic bin ding w hose I P ad dres s has been dynamically selected by the DHCP server and sent in a DHCP-OFFER packet to the DHCP client.

• Auto(C)—A committed dynamic binding whose IP address has been dynamically assigned to the DHCP client.

Related commands

reset dhcp server ip-in-use

display dhcp ser v er pool

Use display dhcp server pool to display information about a DHCP address pool.

Syntax

display dhcp server pool [ pool-name ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

pool-name: Displays information about the specified address pool. The pool name is a case-insensitive string of 1 to 63 characters. If you do no t specify the pool-name argument, this command displays information about all address pools.

Examples

# Display information about all DHCP address pools.

<Sysname> di splay dhcp server pool Pool name: 0 Network 20.1. 1.0 mask 255.255 .255.0 class a range 20.1.1.50 20.1.1.6 0 bootfile-name ab c.cfg dns-list 20.1.1.66 20 .1.1.67 20.1.1.68 domain-name www.aabbcc.com bims-server ip 192 .168.0.51 sharekey cipher $c$3$K13OmQPi791YvQoF2Gs1E+65LOU= option 2 ip-address 1.1.1.1 expired 1 2 3 0

Pool name: 1 Network 20.1. 1.0 mask 255.255 .255.0 secondary netw orks:

Field

Description

20.1.2.0 mask 255.255.255.0

20.1.3.0 mask 255.255.255.0 bims-server ip 192.168 .0.51 port 50 sharekey cipher $c$3$K13OmQPi791YvQoF2Gs1E+65LOU= forbidden-ip 20.1.1.22 20.1.1.36 20.1.1.37 forbidden-ip 20.1.1.22 20.1.1.23 20.1.1.24 gateway-list 1.1.1.1 2.2.2.2 4.4.4.4 nbns-list 5.5.5.5 6.6.6.6 7.7.7.7 netbios-type m-node option 2 ip-address 1.1.1.1 expired 1 0 0 0

Pool name: 2 Network 20.1. 1.0 mask 255.255 .255.0 address range 20 .1.1.1 to 20.1.1.15 class depart mentA range 20.1.1.20 to 20.1.1.29 class departme ntB range 20.1.1.30 to 20.1.1.40 next-server 20.1.1.33 tftp-server domain-name www.dian.org.cn tftp-server ip-address 192.168.0.120 voice-config ncp-ip 10.1.1.2 voice-config as-ip 10.1.1 .5 voice-config voice-vlan 3 enable voice-config fail-over 10.1.1.1 123* option 2 ip-address 1.1.1.3 expired 1 0 0 0

Pool name: 3 static bindings: ip-address 10.10.1 .2 mask 255.0.0.0 hardware-address 00e0-00fc-0001 ethernet ip-address 10.10.1 .3 mask 255.0.0.0 client-identifier aaa a-bbbb expired unlimi ted

Table 9 Command output

Pool name Name of an address pool. Network Assignable network. secondary networks Assignable secondary network s. address range Assignable address range. class class-name range static bindings Static IP-to-MAC/client ID bindings. option Customized DHCP option.

expired

bootfile-name Boot file name

DHCP user class and its addr ess rang e.

Lease duration: 1 2 3 4 in this example refers to 1 day 2 hours 3 minutes 4 seconds.

Field

Description

dns-list DNS server IP address. domain-name Domain name suffix. bims-server BIMS server information. forbidden-ip IP addresses excluded from dynamic allocation. gateway-list Gateway addresses. nbns-list WINS server addresses. netbios-type NetBIOS node type. next-server Next server IP address. tftp-server domain-name TFTP server name. tftp-server ip-address TFTP server address. voice-config ncp-ip Primary network calling processor address. voice-config as-ip Backup network calling processor address. voice-config voice-vlan Voice VLAN. voice-config fail-over Failover route.

display dhcp ser v er statistics

Use display dhcp server statistics to display the DHCP server statistics.

Syntax

display dhcp server statistics [ pool pool-name ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

pool pool-name: Specifies an address pool by its name, a case-insensitive string of 1 to 63

characters. If you do not specify this option, th is comm and displays information about all address pools.

Examples

# Display the DHCP server statist ics.

<Sysname> disp lay dhcp server statistics Pool number: 1 Pool utilization: 0.39% Bindings: Automatic: 1 Manual: 0 Expired: 0 Conflict: 1 Messages re ceived: 10

Field

Description

DHCPDISCOVER: 5 DHCPREQUEST: 3 DHCPDECLINE: 0 DHCPRELEASE: 2 DHCPINFORM: 0 BOOTPREQUEST: 0 Messages se nt: 6 DHCPOFFER: 3 DHCPACK: 3 DHCPNAK: 0 BOOTPREPLY: 0 Bad Messages: 0

Table 10 Command output

Pool number

Pool utilization

Bindings

Conflict

Messages received

Total number of address pools. This field is not displayed wh en you display statistics for a specific address pool.

Pool utilization rate:

• If you display statistics for all address pools, this field displays the utilization rate of all address pools.

• If you display statistics for an address pool, this field displays the pool utilization rate of the specified address pool.

Bindings include the following types:

• Automatic—Number of dynamic bindings.

• Manual—Number of static bindings.

• Expired—Number of expired bindings.

Total number of conflict addresses. This field is not displayed if you display statistics for a specific address pool.

DHCP packets received from clients:

• DHCPDISCOVER.

• DHCPREQUEST.

• DHCPDECLINE.

• DHCPRELEASE.

• DHCPINFORM.

• BOOTPREQUEST.

This field is not displayed if you display statistics for a specific address pool.

Messages sent

Bad Messages

Related commands

reset dhcp server statistics

DHCP packets sent to clients:

• DHCPOFFER.

• DHCPACK.

• DHCPNAK.

• BOOTPREPLY.

This field is not displayed if statistics about a specific address pool are displayed.

Number of bad messages. This field is not displayed if you di splay statistics for a specific address pool.

dns-list

Use dns-list to specify DNS server addresses in a DHCP address pool. Use undo dns-list to remove DNS server addresses from a DHCP address pool.

Syntax

dns-list ip-address&<1-8> undo dns-list [ ip-address&<1-8> ]

Default

No DNS server address is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip-address&<1-8>: S pecifies DNS servers. &<1-8> ind icates that you can s pecify up to eight DNS server addresses separated by spaces.

Usage guidelines

If you use the dns-list command multiple times, the most recent configuration takes effect. If you do not specify any parameters, the undo dns-list command deletes all DNS server addresses

in the DHCP address pool.

Examples

# Specify the DNS server address 10.1.1.254 in DHCP address pool 0.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] dns-list 10.1.1.254

Related commands

display dhcp server pool

domain-name

Use domain-name to specify a domain name in a DHCP address pool. Use undo domain-name to remove the specified domain name.

Syntax

domain-name domain-name undo domain-name

Default

No domain name is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

•

Parameters

domain-name: Specifies the domain name, a case-sensitive string of 1 to 50 characters.

Usage guidelines

If you use the command multiple times, the most recent configuration takes effect.

Examples

# Specify the domain name company.com in address pool 0.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] domain-name company.com

Related commands

display dhcp server pool

expired

Use expired to specify the lease duration in a DHCP address pool. Use undo expired to restore the default lease duration for a DHCP address pool.

Syntax

expired { day day [ hour hour [ minute minute [ second second ] ] ] | unlimited } undo expired

Default

The lease duration of a dynamic DHCP address pool is one day.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

day day: Specifies the number of days, in the range of 0 to 365. hour hour: Specifies the number of hours, in the range of 0 to 23. minute minute: Specifies the number of minutes, in the range of 0 to 59. second second: Specifies the number of seconds, in the range of 0 to 59. unlimited: Specifies the unlimited lease duration, which is ac tu al l y 136 years.

Usage guidelines

The DHCP server assigns an IP address together with the lease duration to the DHCP client. Before the lease expires, the DHCP client must extend the lease duration.

If the lease extension operation succeeds, the DHCP client can continue to use the IP address. If the lease extension operation does not succeed, both of the following events occur:

 The DHCP client cannot use the IP address after the lease duration expires.  The DHCP server will label the IP address as an expired address.

Examples

# Specify the lease duration as 1 day, 2 hours, 3 minutes, and 4 seconds in DHCP address pool 0.

<Sysname> system-view

[Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] expire d day 1 hour 2 minute 3 seco nd 4

Related commands

display dhcp server expired display dhcp server pool reset dhcp server expired

forbidden-ip

Use forbidden-ip to exclude IP addresses from dynamic allocation in an address pool. Use undo forbidden-ip to cancel the configuration.

Syntax

forbidden-ip ip-address&<1-8> undo forbidden-ip [ ip-address&<1-8> ]

Default

No IP addresses are excluded from dynamic allocation in an address pool.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip-address&<1-8>: Specifies exclude d IP addresses. &<1-8> indicates that you c an specify up to eight IP addresses, separated by spaces.

Usage guidelines

The excluded IP addresses in an address pool are still assignable in other address pools. You can exclude a maximum of 4096 IP addresses in an address pool. If you do not spec ify any parameters, the undo forbidden-ip command delet es all excluded IP

addresses.

Examples

# Exclude IP address es 192.168.1.3 and 192.168.1.10 f rom dynamic allocati on in DHCP address pool 0.

<Sysname> sy stem-view [Sysname] dhcp se rver ip-pool 0 [Sysname-dhcp-pool-0] forbidden-ip 192.168.1.3 1 92.168.1.10

Related commands

dhcp server forbidden-ip display dhcp server pool

gateway-list

Use gateway-list to specify gateway addresses in a DHCP address pool or a DHCP secondar y subnet.

Use undo gateway-list to remove the specified gateway addresses from a DHCP address pool or a DHCP secondary subnet.

Syntax

gateway-list ip-address&<1-8> undo gateway-list [ ip-address&<1-8> ]

Default

No gateway address is configured in a DHCP address pool or a DHCP secondary subnet.

Views

DHCP address pool view, DHCP secondary subnet view

Predefined user roles

network-admin

Parameters

ip-address&<1-8>: Specifie s gateways. &<1-8> indicates that you can specif y up to eight g ateway addresses separated by spaces. Gateway addresses must reside on the same subnet as the assignable IP addresses.

Usage guidelines

If you use this command multiple times, the most recent configuration takes effect. If you do not specify any parameters, the undo gateway-list command deletes all gateway

addresses. If you specify gatewa ys in both address pool view and secondary subn et view, DHCP assigns the

gateway addresses in the secondary subnet view to the clients on the secondary subnet. If you specify gat eways in address p ool view but not in secon dary subn et view, DHCP assigns the

gateway addresses in address pool view to the clients on the secondary subnet.

Examples

# Specify the gateway address 10.1.1.1 in DHCP address pool 0.

<Sysname> system-view [Sysname] dhcp se rver ip-pool 0 [Sysname-dhcp-pool-0] gateway-list 10.1.1.1

Related commands

display dhcp server pool

if-match

Use if-match to configure a match rule for a DHCP user class. Use undo if-match to remove the match rule for a DHCP user class.

Syntax

Default

if-match rule rule-number option option-code [ hex hex-string [ mask mask | offset offset length length ] ]

undo if-match rule rule-number

No match rule is configured for the DHCP user class.

•

Views

DHCP user class view

Predefined user roles

network-admin

Parameters

rule rule-number: Assigns the match rule an ID in the range of 1 to 16. A smaller ID r epresents a

higher match priority.

option option-code: Matches a DHCP option by a number in the range of 1 to 254. hex hex-string: Matches the specified hexadecimal string in the option. The length of the

hexadecimal string must be an even number in the range of 2 to 256. If you do not specify this option, the DHCP server only checks whether the specified option exists in the received packets.

mask mask: Specifies the mask used to match the option content. The mask argument is a hexadecimal string, whos e length is an even num ber in the range of 2 to 256. The length of mask must be the same as that of hex-string.

offset offset: Specifies the offs et us ed to match the option, in t h e rang e of 0 to 254 bytes. If you do not specify this option, the server matches the entire option with the rule.

length length: Matches the specified length of the option, in the range of 1 to 128 bytes. The specified length must be the same as the hex-string length.

Usage guidelines

Y ou can configure multiple match rules for a DHCP user class. Each match rule is uniquely identified by a rule ID. Different match rules can include the same option code, but they cannot have the same matching criteria.

The DHCP server compares DHCP requests against the match rules. A DHCP client matches a DHCP user class when its request matches one of the specified match rules.

The match operation follows these guidelines:

If only the option-code argument is specified in the rule, packets containing the option match the

rule.

If the option-code and hex-string arguments are specified in the rule, packets that have the

specified hexadecimal string in the specified option match the rule.

If the option-code, hex-string, offset and length arguments are specified in the rule, packets

match the rule as long as their content from offset+1 bit to offset+length bit in the specified option is the same as the specified hexadecimal string.

If the option-code, hex-string, and mask arguments are specified in the rule, the DHCP server

ANDs the content from the first bit to the mask-1 bit in the specified option with the mask. Then the server compares the result with the result of the AND operation between hex-string and mask. If the two results are the same, the received packet matches the rule.

Examples

# Configure match rule 1 to match DHCP requests that contain Option 82 for DHCP user class exam.

<Sysname> sy stem-view [Sysname] dhcp class exam [Sysname-dhcp-class-exam] if-match rule 1 opti on 82

# Configure m atch rule 2 to m atch DHCP requests that contain Option 82. Option 82's first three bytes are 0x13ae92 for the DHCP user class exam.

<Sysname> sy stem-view [Sysname] dhcp class exam [Sysname-dhcp-class-exam] if-match rule 2 opti on 82 hex 13ae92 offset 0 length 3

# Configure match rule 3 to match DHCP requests that contain Option 82. Option 82's highest bit of the fourth byte is 1 for the DHCP user class exam.

<Sysname> sy stem-view [Sysname] dhcp class exam [Sysname-dhcp-class-exam] if-match rule 3 opti on 82 hex 00000080 mask 00000080

Related commands

dhcp class

nbns-list

Use nbns-list to specify WINS server addresses in a DHCP address pool. Use undo nbns-list to remove the specified WINS server addresses.

Syntax

nbns-list ip-address&<1-8> undo nbns-list [ ip-address&<1-8> ]

Default

No WINS server address is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip-address&<1-8>: Specifies WINS server IP addresses. &<1-8> indicates that you can specify up to eight WINS server addresses separated by spaces.

Usage guidelines

If you use this command multiple times, the most recent configuration takes effect. If you do not specify any parameters, the undo nbns-list command deletes all WINS server

addresses.

Examples

# Specify the WINS server IP address 10.1.1.1 in DHCP address pool 0.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] nbns-list 10.1.1.1

Related commands

display dhcp server pool netbios-type

netbios-type

Use netbios-type to specify the NetBIOS node type in a DHCP address pool. Use undo netbios-type to remove the specified NetBIOS node type.

Syntax

netbios-type { b-node | h-node | m-node | p-node } undo netbios-type

Default

No NetBIOS node type is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

b-node: Specifies the broadcast node. A b-node client sends the destination nam e in a broadcast

message to get the name-to-IP mapping from a server. h-node: Specifies the hybrid node. An h-node client unicasts the destination name to a WINS server.

If it does not receive a response, the h-node client broadcasts the destination name to get the mapping from a server.

m-node: Specifies the mixed node. An m-node client broadcasts the destination name. If it does not receive a response, the m-node cl ient u nicasts the des tination n am e to th e W INS serv er t o get the mapping.

p-node: Specifies the peer -to-peer node. A p-node cli ent sends the des tination nam e in a unicast message to get the mapping from the WINS server.

Usage guidelines

If you use the command multiple times, the most recent configuration takes effect.

Examples

# Specify the NetBIOS node type as p-node in DHCP address pool 0.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] netbios-type p-node

Related commands

display dhcp server pool nbns-list

network

Use network to specify the subnet for dynamic allocation in a DHCP address pool. Use undo network to remove the specified subnet.

Syntax

network network-address [ mask-length | mask mask ] [ secondary ]

Default

Views

undo network network-address [ mask-length | mask mask ] [ secondary ]

No subnet is specified in a DHCP address pool.

DHCP address pool view

Predefined user roles

network-admin

Parameters

network-address: Specifies the subnet for dynamic allocation. If no mask length or mask is specified, the natural mask will be used.

mask-length: Specifies the mask length in the range of 1 to 30.

mask mask: Specifies the mask in dotted decimal format. secondary: Specif ies the subnet as a sec ondary subnet. If you do not specify this ke yword, this

command specifies the primary subnet. If th e addresses in the primar y subnet are used up, the DHCP server can select addresses from a secondary subnet for clients.

Usage guidelines

Yo u can use the secondary keyword to s pecif y a secondar y subn et and e nter it s view, where you can specify gateways by using the gateway-list command for DHCP clients in the secondary subnet.

You can specify only one primary subnet for a DHCP address pool. If you use the network command multiple times, the most recent configuration takes effect.

You can specify up to 32 secondary subnets for a DHCP address pool. The primary subnet and secondary subnets in a DHCP address pool must not have the same

network address and mask. If you have used the address range or class comm and in an addr ess pool, you cannot sp ecify a

secondary subnet in the same address pool. Modifying or rem oving the network configuration d eletes t he ass igned ad dresses f rom the c urrent

address pool.

Examples

# Specify primar y subnet 192.168.8.0/24 and secondary subne t 192.16 8.10.0/ 24 in D HCP address pool 0.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] network 192.168.8.0 mask 255.255.255.0 [Sysname-dhcp-pool-0] network 192.168.10.0 mask 255.255.255.0 secondary [Sysname-dhcp-pool-0-secondary]

Related commands

display dhcp server pool gateway-list

next-server

Use next-server to specify the IP address of a server in a DHCP address pool. Use undo next-server to remove the server's IP address from the DHCP address pool.

Syntax

Default

next-server ip-address undo next-server

No server's IP address is specified in an address pool.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip-address: Specifies the IP address of a server.

Usage guidelines

Upon s tartup, the DHCP cli ent obtains an IP addres s and the specified s erver IP address. Then it contacts the specified server, such as a TFTP server, to get other boot information.

If you use the next-server command multiple times, the most recent configuration takes effect.

Examples

# Specify a server's IP address 10.1.1.254 in DHCP address pool 0.

<Sysname> sy stem-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] next-server 10.1.1.254

Related commands

display dhcp server pool

option

Use option to customize a DHCP option. Use undo option to remove a customized DHCP option.

Syntax

option code { ascii ascii-string | hex hex-string | ip-address ip-address&<1-8> } undo option code

Default

No DHCP option is customized.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

code: Specifies the number of the customized option, in the range of 2 to 254, excluding 50 through 54, 56, 58, 59, 61, and 82.

ascii ascii-string: Specifies an ASCII string of 1 to 255 characters as the option content. hex hex-string: Specifies a hexadecimal string of even numbers from 2 to 256 as the option content. ip-address ip-address&<1-8>: Specifies the IP addresses as the op tion content. &<1-8> indicates

that you can specify up to eight IP addresses separated by spaces.

Usage guidelines

The DHCP server fills the cus tom ized option with the s pecif ied ASCI I strin g, hexa decim al string, o r IP addresses, and sends it in a response to the client.

•

If you use the option command with t he sam e code specified, the most r ecent conf iguration takes effect.

You can customize options for the following purposes:

If a DHCP option is specified by both the dedicated command and the option command, the DHCP server assigns the content specified by the dedicated command. For example, if a DNS server address is specified by t he dns-list command and the option 6 com mand, the server uses the address specified by dns-list command.

Examples

# Configure Option 7 to specify the log server address 2.2.2.2 in address pool 0.

<Sysname> sy stem-view [Sysname] dhcp server ip-pool 0 [Sysname-dhcp-pool-0] option 7 ip-address 2.2.2.2

Add newly released options. Add options for which the vendor defines the contents, for example, Option 43. Add options for which the CLI does not provide a dedicated configuration command. For

example, you can use the option 4 ip-address 1.1.1.1 command to define the time server address 1.1.1.1 for DHCP clients.

Add all option values if the actual requirement exceeds the limit for a dedicated option

configuration command. For example, the dns-list command can specify up to eight DNS servers. To specify more than eight DNS server, you must use the option 6 command to define all DNS servers.

Related commands

display dhcp server pool

reset dhcp server conflict

Use reset dhcp server conflict to clear IP address conflict information.

Syntax

reset dhcp server conflict [ ip ip-address ]

Views

User view

Predefined user roles

network-admin

Parameters

ip ip-address: Clears conf lict inform ation about the specif ied IP address. If you d o not specify this

option, this command clears all address conflict information.

Usage guidelines

Address conflicts occur when dynamically assigned IP addresses have been statically configured for other hosts. After you modify the address pool configuration, the conflicted addresses might become assignable. To assign these addresses, use the r eset dhcp serv er conflict command to clear t he conflict information first.

Examples

# Clear all IP address conflict information.

<Sysname> rese t dhcp server conflict

Related commands

display dhcp server conflict

reset dhcp server expired

Use reset dhcp server expired to clear binding information about expired IP addresses.

Syntax

reset dhcp server expired [ ip ip-address | pool pool-name ]

Views

User view

Predefined user roles

network-admin

Parameters

ip ip-address: Clears binding information about the specified expired IP address. pool pool-name: Clears binding information about the expired IP addresses in the specified address

pool. The pool name is a case-insensitive string of 1 to 63 characters.

Usage guidelines

If you do not specif y an y par am eters, this com m and clears bin ding inform ation a bout al l expir ed IP addresses.

Examples

# Clear binding information about all expired IP addresses.

<Sysname> reset dhcp server expired

Related commands

display dhcp server expired

reset dhcp server ip-in-use

Use reset dhcp serv er i p-in-use to clear binding information about assigned IP addresses.

Syntax

reset dhcp server ip-in-use [ ip ip-address | pool pool-name ]

Views

User view

Predefined user roles

network-admin

Parameters

ip ip-address: Clears binding information about the specified assigned IP address. pool pool-name: Clears binding inf ormation about the s pecified address poo l. The pool name is a

case-insensitive string of 1 to 63 characters.

Usage guidelines

If you do not specify any parameters, this command clears binding information about all assigned IP addresses.

If you use this command to c lear information about an assigned static binding, the static binding becomes an unassigned static binding.

Examples

# Clear binding information about the IP address 10.110.1.1.

<Sysname> rese t dhcp server ip-in-use ip 10.110.1.1

Related commands

display dhcp server ip-in-use

reset dhcp server statistics

Use reset dhcp server statistics to clear DHCP server statistics.

Syntax

reset dhcp server statistics

Views

User view

Predefined user roles

network-admin

Examples

# Clear DHCP server statistics.

<Sysname> rese t dhcp server statistics

Related commands

display dhcp server statistics

static-bind

Use static-bind to statically bind a client ID or MAC address to an IP address. Use undo static-bind to remove a static binding.

Syntax

static-bind ip-address ip-address [ mask-length | mask mask ] { client-identifier client-identifier | hardware-address hardware-address [ ethernet | token-ring ] }

undo static-bind ip-address ip-address

Default

No static binding is specified in a DHCP address pool.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip-address ip-address: Specifies the IP address of the static binding. The natural mask is used if no

mask length or mask is specified. mask-length: Specifies the mask length in the range of 1 to 30. mask mask: Specifies the mask, in dotted decimal format.

client-identifier client-identifier: S pecifies the client ID of the static bi nding, a string of 4 to 254 characters that can contain only hexadecimal numbers and hyphen (-), in the format of H-H-H…., in which the last H can be a two -digit or four -digit hex ad ecim al num ber while the ot her Hs m ust be all four-digit hexadecimal numbers. For example, aabb-cccc-dd is a correct ID, while aabb-c-dddd and aabb-cc-dddd are incorrect IDs.

hardware-address hardware-address: Specifies the client hardware address of the static binding, a string of 4 to 79 characters that can contain only hexadecimal numbers and hyphen (-), in the format of H-H-H…, in which the last H can be a t wo-dig it or four-digit hexadecimal number while the other Hs must be all four -digit hexadecim al numbers. For exam ple, aabb-cccc-dd is a correc t hardware address, while aabb-c-dddd and aabb-cc-dddd are incorrect hardware addresses.

ethernet: Specifies the client hardware address type as Ethernet. The default type is Ethernet. token-ring: Specifies the client hardware address type as token ring.

Usage guidelines

The IP address of a static binding must not be an interface address of the DHCP server. Otherwise, an IP address conflict occurs, and the bound client cannot obtain the IP address.

You can specify multiple static bindings in an address pool. The total number of static bindings in all address pools cannot exceed 8192.

Yo u cann ot m odif y bindings. To change the binding for a DHCP client, you m ust delete the exis ting binding first and create a new binding.

Examples

# Bind the IP address 10.1.1.1/24 to the client ID 00aa-aabb in DHCP address pool 0.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] static-bind ip-address 10.1.1.1 mask 255.255. 25 5.0

client-identifier 00aa-aabb

Related commands

display dhcp server pool

tftp-server domain-name

Use tftp-server domain-name to specify a TFTP server name in a DHCP address pool. Use undo tftp-server domain-name to remove the TFTP server name from a DHCP address pool.

Syntax

tftp-server domain-name domain-name undo tftp-server domain-name

Default

No TFTP server name is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

domain-name: Specifies the TFTP server name, a case-sensitive string of 1 to 63 characters.

Usage guidelines

If you use this command multiple times, the most recent configuration takes effect.

Examples

# Specify the TFTP server name aaa in DHCP address pool 0.

<Sysname> system-view [Sysname] dhcp server ip-pool 0 [Sysname-dhcp-pool-0] tftp-server do main-name aaa

Related commands

display dhcp server pool tftp-server ip-address

tftp-server ip-address

Use tftp-server ip-address to specify a TFTP server address in a DHCP address pool. Use undo tftp-server ip-address to remove the TFTP server address from a DHCP address pool.

Syntax

tftp-server ip-address ip-address undo tftp-server ip-address

Default

No TFTP server address is specified.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

ip-address: Specifies the IP address of a TFTP server.

Usage guidelines

If you use this command multiple times, the most recent configuration takes effect.

Examples

# Specify the TFTP server address 10.1.1.1 in DHCP address pool 0.

<Sysname> system-view [Sysname] dhcp server ip-pool 0 [Sysname-dhcp-pool-0] tftp-server ip -address 10.1.1.1

Related commands

display dhcp server pool tftp-server domain-name

voice-config

Use voice-config to configure the content for Option 184 in a DHCP address pool. Use undo voice-config to remove the Option 184 content from a DHCP address pool.

•

Syntax

voice-config { as-ip ip-address | fail-over ip-address dialer-string | ncp-ip ip-address | voice-vlan vlan-id { disable | enable } }

undo voice-config [ as-ip | fail-over | ncp-ip | voice-vlan ]

Default

No Option 184 content is configured in a DHCP address pool.

Views

DHCP address pool view

Predefined user roles

network-admin

Parameters

as-ip ip-address: Specifies the IP address of the backup network calling processor. fail-over ip-address dialer-string: Specifies the failover IP address and dialer string. The dialer-string

is a string of 1 to 39 characters, which can include numbers 0 through 9 and asterisk (*).

ncp-ip ip-address: Specifies the IP address of the primary network calling processor. voice-vlan vlan-id: Specifies the voice VLAN ID in the range of 2 to 4094.

disable: Disables the specified VLAN. DHCP clients will not take this VLAN as their voice

VLAN.

enable: Enables the specified VLAN. DHCP clients will take this VLAN as their voice VLAN.

Usage guidelines

If you use the command multiple times, the most recent configuration takes effect.

Examples

# Configure Option 184 in DHCP address pool 0. The primary and backup network calling processors are at 10.1.1.1 and 10.2.2.2, resp ec ti ve ly. The voice VLAN 3 is ena bl ed. T he f ailo ver IP address is 10.3.3.3. The dialer string is 99*.

<Sysname> system-view [Sysname] dh cp server ip-pool 0 [Sysname-dhcp-pool-0] voice-config ncp-ip 10.1.1.1 [Sysname-dhcp-pool-0] voice-config as-ip 10.2.2.2 [Sysname-dhcp-pool-0] voice-config voice-vlan 3 enable [Sysname-dhcp-pool-0] voice-config fail-over 10.3.3.3 99*

Related commands

display dhcp server pool

DHCP relay agent commands

dhcp relay check mac-address

Use dhcp relay check mac-address to enable MAC address check on the relay agent. Use undo dhcp relay check mac-address to disable MAC address check on the relay agent.

Syntax

dhcp relay check mac-address undo dhcp relay check mac-address

Default

The MAC address check feature is disabled.

Views

Interface view

Predefined user roles

network-admin

Usage guidelines

This feature enables the DHCP relay agent to compare the chaddr field of a received DHCP request with the source MAC addres s in the frame header. If they are the same, the DHCP relay agent forwards the request t o th e DHCP ser ver. If they are n ot the s am e, the DHCP relay agent d iscar ds the request.

The MAC address check feature takes effect only when the dhcp select relay command has already been configured on the interf ac e.

Enable the MAC a ddress check feature only on the DHCP relay agent directl y connected to the DHCP clients. A DHCP relay agent changes the source MAC address of DHCP packets before sending them. If you enable this feature on an intermediate relay agent, it might discard valid DHCP packet, and the sending clients will not obtain IP addresses.

Examples

# Enable MAC address check on the relay agent.

<Sysname> system-view [Sysname] in terface vlan-interface 10 [Sysname-Vlan-interface10] dhcp relay chec k mac-address

Related commands

dhcp select relay

dhcp relay check mac-address aging time

Use dhcp relay check mac-address aging time to c onfigure the aging time for MAC a ddress check entries on the DHCP relay agent.

Use undo dhcp relay check mac-address aging time to restore the default.

Syntax

dhcp relay check mac-address aging-time time undo dhcp relay check mac-address aging-time

Default

The aging time is 30 seconds.

Views

System view

Predefined user roles

network-admin

Parameters

time: Specifies the aging time for MAC address check entries in seconds, in the range of 30 to 600.

Usage guidelines

This command takes effect only after you execute the dhcp relay check mac-address command.

Examples

# Set the aging time for MAC address check entries on the DHCP relay agent to 60 seconds.

<Sysname> sy stem-view [Sysname] dhcp relay check mac-address aging-time 60

dhcp relay client-information record

Use dhcp relay client-information record to enable recording client information in relay entries. A relay entry contains information about a client such as the client's IP and MAC addresses.

Use undo dhcp relay client-information record to disable the feature.

Syntax

dhcp relay client-information record undo dhcp relay client-information record

Default

The DHCP relay agent does not record client information in relay entries.

Views

System view

Predefined user roles

network-admin

Usage guidelines

Disabling recording of client information deletes all recorded relay entries. Client information is rec orded only when the DHCP relay agent is configured o n the gateway of

DHCP clients.

Examples

# Enable recording of relay entries on the relay agent.

<Sysname> system-view [Sysname] dhcp re lay client-information record

Related commands

dhcp relay client-information refresh dhcp relay client-information refresh enable

dhcp relay client-information refresh

Use dhcp relay client-information refresh to configure the interval at which the DHCP relay agent periodically refreshes relay entries.

Use undo dhcp relay client-information refresh to restore the default.

Syntax

dhcp relay client-information refresh [ auto | interval interval ]

undo dhcp relay client-information refresh

Default

The refresh interval is automatically calculated based on the number of relay entries.

Views

System view

Predefined user roles

network-admin

Parameters

auto: Automatically calcul ates the refresh interval. The m ore the entries, the shorter the refresh

interval. The shortest interval must not be less than 500 ms.

interval interval: Specifies the refresh interval in the range of 1 to 120 seconds.

Usage guidelines

If you use this command multiple times, the most recent configuration takes effect.

Examples

# Set the refresh interval to 100 seconds.

<Sysname> system-view [Sysname] dhcp re lay client-information refresh interval 100

Related commands

dhcp relay client-information record dhcp relay client-information refresh enable

dhcp relay client-information refresh enable

Use dhcp relay client-information refresh enable to enab le the DHCP rela y agent to periodically refresh dynamic relay entries.

Use undo dhcp relay client-information refresh enable to disable the DHCP relay agent to periodically refresh dynamic relay entries.

Syntax

dhcp relay client-information refresh enable undo dhcp relay client-information refresh enable

Default

The DHCP relay agent periodically refreshes relay entries.

Views

System view

Predefined user roles

network-admin

Usage guidelines

A DHCP client unicasts a DHCP-RELEASE message to the DHCP server to release its IP address. The DHCP relay agent conveys the message to the DHCP server and does not remove the IP-to-MAC entry of the client.

With this feature, the DHCP relay agent uses the IP address of a client and the MAC address of the DHCP relay interface to periodically send a DHCP-REQUEST message to the DHCP server.

•

If the server returns a DHCP-ACK message or does not return any message within an interval,

the DHCP relay agent performs the following operations:

 Removes the relay entry.  Sends a DHCP-RELEASE message to the DHCP server to release the IP address.

If the server returns a DHCP-NAK message, the relay agent keeps the entry.

With this feature disabled, the DHCP relay agent does not remove relay entries automatically . After a DHCP client releases its IP address, you must use the reset dhcp relay client-information on the relay agent to remove the corresponding relay entry.

Examples

# Disable periodic refresh of relay entries.

<Sysname> system-view [Sysname] un do dhcp relay client-information refresh enable

Related commands

dhcp relay client-information record dhcp relay client-information refresh reset dhcp relay client-information

dhcp relay information circuit -id

Use dhcp relay information circuit-id to conf igure the padd ing m ode and pad ding form at for the Circuit ID sub-option of Option 82.

Use undo dhcp relay information circuit-id to restore the default.

Syntax

dhcp relay information circuit-id { string circuit-id | { normal | verbose [ node-identifier { mac | sysname | user-defined node-identifier } ] } [ format { ascii | hex } ] }

undo dhcp relay information cir cuit-id

Default

The padding mode is normal and the padding format is hex.

Views

Interface view

Predefined user roles

network-admin

Parameters

string circuit-id: Specifies the string mode that uses a case-sensitive string of 3 to 63 characters as

the content of the Circuit ID sub-option. normal: Specifies the normal mode, in which the padding content consists of the VLAN ID and port

number. verbose: Specifies the verbose mode. The padding content includes the VLAN ID and interf ace

number. node-identifier { mac | sysname | user-defined node-identifier }: Specifies the access node

identifier. The padding con tent includes the node identifier, Ethernet type (f ixed to eth), interface number, and VLAN ID. The node identifier varies by keyword mac, sysname, and user-defined.

mac: Uses the MAC addr e ss of the access node as the node identifier. It is the default node

identifier.

•

NOTE:

is used as the node identifier, do not include any space when you set the device name.

Otherwise, the DHCP relay agent fails to add or replace the Option 82.

•

is specified

format is ascii

sysname: Uses the device name as the node identifier. You can set the device name by using

the sysname command in system view. The padding format for the device name is always ASCII regardless of the specified padding format.

sysname

user-defined node-identifier: Uses a case-sensitive string of 1 to 50 characters as the node

identifier. The padding format for the specified character string is always ASCII regardless of the specified padding format.

format: Specifies the padding format for the Circuit ID sub-option. ascii: Specifies the padding format as ASCII. hex: Specifies the padding format as hex.

Usage guidelines

The Circuit ID sub-option cannot carry information about interface splitting or subinterfaces. For more information about interface splitting and subinterfaces, see Interface Configuration Guide.

If you use this command multiple times, the most recent configuration takes effect. The padding form at for the user-defined str ing, the normal m ode, or the verbose modes varies by

command configuration. Table 11 shows how the padding format is determined for different modes.

Table 11 Padding format for different modes

Examples

# Specify the padding mode as verbose, node identifier as the device name, and the padding format as ASCII for the Circuit ID sub-option.

<Sysname> system-view [Sysname] in terface vlan-interface 10 [Sysname-Vlan-interface10] dhcp relay information enable [Sysname-Vlan-interface10] dhcp relay information strategy replace [Sysname-Vlan-interface10] dhcp relay information circuit-id verbose node-identifier

sysname format ascii

Keyword (mode)

string

circuit-id

normal

verbose

If no padding format

You cannot specify a padding format, and the padding format is always ASCII.

Hex. ASCII. Hex. Hex for the VLAN ID.

ASCII for the node identifier, Ethernet type, and interface number.

If the padding

N/A N/A

ASCII.

If the padding format is hex

ASCII for the node identifier and Ethernet type.

Hex for the interface number and VLAN ID.

Related commands

dhcp relay information enable dhcp relay information strategy display dhcp relay information

dhcp relay information enable

Use dhcp relay information enable to enable the relay agent to support Option 82. Use undo dhcp relay information enable to disable Option 82 support.

Syntax

dhcp relay information enable undo dhcp relay information enable

Default

The DHCP relay agent does not support Option 82.

Views

Interface view

Predefined user roles

network-admin

Usage guidelines

This command enables the DHCP relay agent to add Option 82 to DHCP requests that do not contain Option 82 before f orwarding the req uests to the DHCP server. The content of Option 82 is determined by the dhcp relay information circuit-id and dhcp relay information remote-id commands. If the DHCP requests contain Option 82, the relay agent handles the requests according to the strategy configured with the dhcp relay information strategy command.

If this feature is disabled, the relay agent forwards requests that contain or do not contain Option 82 to the DHCP server.

Examples

# Enable Option 82 support on the relay agent.

<Sysname> system-view [Sysname] in terface vlan-interface 10 [Sysname-Vlan-interface10] dhcp relay information enable

Related commands

dhcp relay information circuit-id dhcp relay information remote-id dhcp relay information strategy display dhcp relay information

dhcp relay information remote-id

Use dhcp relay information remote-id to configure the padding mode and padding f orm at for the Remote ID sub-option of Option 82.

Use undo dhcp relay information remote-id to restore the default.

Syntax

Default

dhcp relay information remote-id { normal [ format { ascii | hex } ] | string remote-id | sysname } undo dhcp relay information remote-id

The padding mode is normal and the padding format is hex.

Views

Interface view

Predefined user roles

network-admin

Parameters

normal: Specifies the normal mode in which the padding content is the MAC address of the

receiving interface. format: Specif ies the padding for mat for the Rem ote ID sub-option. The def ault padding f ormat is

hex.

ascii: Specifies the padding format as ASCII. hex: Specifies the padding format as hex. string remote-id: Specifies the string mode that uses a case-sensitive string of 1 to 63 characters as

the content of the Remote ID sub-option. sysname: Specifies the sysname mode that uses the device name as the content of the Remote ID

sub-option. You can set the device name by using the sysname command.

Usage guidelines

The padding form at for the specified character strin g (string) or the device name (sysname) is always ASCII. The padding format for the normal mode is determined by the command.

If you use the command multiple times, the most recent configuration takes effect.

Examples

# Specify the padding content for the Remote ID sub-option of Option 82 as device001.

<Sysname> system-view [Sysname] in terface vlan-interface 10 [Sysname-Vlan-interface10] dhcp relay info rmation enable [Sysname-Vlan-interface10] dhcp relay information strategy replace [Sysname-Vlan-interface10] dhcp relay information remote-id string device001

Related commands

dhcp relay information enable dhcp relay information strategy display dhcp relay information

dhcp relay information strategy

Use dhcp relay information strategy to configure the strategy for the DHCP relay agent to handle messages containing Option 82.

Use undo dhcp relay information strategy to restore the default handling strategy.

Syntax

Default

dhcp relay information strategy { drop | keep | replace } undo dhcp relay information strategy

The handling strategy for messages that contain Option 82 is replace.

Views

Interface view

Predefined user roles

network-admin

Parameters

drop: Drops DHCP messages that contain Option 82 messages. keep: Keeps the original Option 82 intact. replace: Replaces the original Option 82 with the configured Option 82.

Usage guidelines

This command takes effect only on DHCP requests that contain Option 82. When enabled to support Option 82, the DHCP relay agent always adds Option 82 into DHCP

requests that do not contain Option 82 before forwarding the requests to the DHCP.

Examples

# Specify the handling strategy for Option 82 as keep.

<Sysname> system-view [Sysname] interface vlan-interface 10 [Sysname-Vlan-interface10] dhcp relay information enable [Sysname-Vlan-interface10] dhcp relay information strategy keep

Related commands

dhcp relay information enable display dhcp relay information

dhcp relay releas e ip

Use dhcp relay release ip to release a specific client IP address.

Syntax

dhcp relay release ip client-ip [ vpn-instance vpn-instance-name ]

Views

System view

Predefined user roles

network-admin

Parameters

client-ip: Specifies the IP address to be released. vpn-instance vpn-instance-name: Specifies the MPLS L3VPN instance of the IP address. The

vpn-instance-name is a case-sensitive string of 1 to 31 character s. If you do not specify a VPN

instance, this command releases the IP address in the public network.

Usage guidelines

After you execute th is command, the rel ay agent sends a DHCP -RELEASE packet to th e DHCP server and removes the relay entry of the IP address. Upon receiving the packet, the server removes binding information about the specified IP address to release the IP address.

Examples

# Release the IP address 1.1.1.1.

<Sysname> system-view [Sysname] dhcp relay release ip 1.1.1.1

dhcp relay server-address

Use dhcp relay server-address to specify DHCP servers on the DHCP relay agent. Use undo dhcp relay server-address to remove DHCP servers.

Syntax

dhcp relay server-address ip-address undo dhcp relay server-address [ ip-address ]

Default

No DHCP server is specified on the DHCP relay agent.

Views

Interface view

Predefined user roles

network-admin

Parameters

ip-address: Specifies the IP address of a DHCP server. The DHCP relay agent forwards DHCP packets received from DHCP clients to this DHCP server.

Usage guidelines

The specified IP address of the DHCP server must not reside on the same subnet as the IP address of the DHCP relay agent interface. Otherwise, the DHCP clients might fail to obtain IP addresses.

You can specify a maximum of eight DHCP servers on an interface. The DHCP relay agent forwards the packets from the clients to all the specified DHCP servers.

If you do not specif y an IP address, the undo dhcp relay server-address com mand removes all DHCP servers on the interface.

Examples

# Specify the DHCP server 1.1.1.1 on the relay agent interface VLAN-interface 10.

<Sysname> system-view [Sysname] interface vlan-interface 10 [Sysname-Vlan-interface10] dhcp relay server-address 1.1.1.1

Related commands

dhcp select relay display dhcp relay interface

display dhcp relay check mac-address

Syntax

Views

Use display dhcp relay check mac-address to dis play MAC addres s check entries on the re lay agent.

display dhcp relay check mac-address

Any view

Field

Description

Predefined user roles

network-admin network-operator

Examples

# Display MAC address check entries on the DHCP relay agent.

<Sysname> display dhcp relay check mac-address Source-MAC Interface Aging-time 23f3-1122-adf1 XGE1/0/1 10 23f3-1122-2230 XGE1/0/2 30

Table 12 Command output

Source MAC Source MAC address of the attacker. Interface Interface where the attack comes from. Aging-time Aging time of the MAC address check entry, in seconds.

display dhcp relay client-information

Use display dhcp relay client-information to display relay entries on the relay agent.

Syntax

display dhcp relay client-information [ interface interface-type interface -number | ip ip-address [ vpn-instance vpn-instance-name ] ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

interface interface-type interface-number: Displays relay entries on the specified interface. ip ip-address: Displays the relay entry for the specified IP address. vpn-instance vpn-instance-name: Displays the relay entry for the specified IP address in the

specified MPLS L3VPN instance. The vpn-instance-name is a case-sensitive string of 1 to 31 characters.

Usage guidelines

The DHCP relay agent rec ords r elay entr ies onl y when the dhcp relay client-information record command has been issued.

If you do not specify any parameters, the display dhcp relay client-information command displays all relay entries on the relay agent.

Examples

# Display all relay entries on the relay agent.

<Sysname> disp lay dhcp relay client-information Total number of client-information item s: 2 Total number of dynamic items: 1

Field

Description

Total number of temporary items: 1 IP address MAC address Type Interface VPN name

10.1.1.1 00e0-0000-0001 Dynamic Vlan1 VPN1

10.1.1.5 00e0-0000-0000 Temporary Vla n2 VPN2

Table 13 Command output

Total number of client-information items Total number of relay entries. Total number of dynamic items Total number of dynamic relay entries. Total number of temporary items Total number of temporary relay entries. IP address IP address of the DHCP client. MAC address MAC address of the DHCP client.

Relay entry type:

• Dynamic—The relay agent creates a dynamic relay entry

Type

upon receiving an ACK response from the DHCP server.

• Temporary—The relay agent creates a temporary relay entry upon receiving a REQUEST packet from a DHCP client.

Interface

Layer 3 interface connected to the DHCP client. displayed for relay entries without interface information.

Related commands

dhcp relay client-information record reset dhcp relay client-information

display dhcp relay information

Use display dhcp relay information to displa y Option 82 conf iguration inf ormation for the DHCP relay agent.

Syntax

display dhcp relay information [ interface interface-type interface-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

N/A

interface interface-type interface-number: Displays Option 82 configuration information for the specified interface. If you do not specify an interface, this command displays Option 82 configuration information about all interfaces.

Examples

# Display Option 82 configuration information for all interfaces.

<Sysname> displ ay dhcp relay information Interface: Vlan-interface100 Status: Enable

Field

Description

Strategy: Replace Circuit ID Pattern: Verbos e Remote ID Pattern : Sysname Circuit ID format-type: Undefined Remote ID format-type: ASCII Node identifier : aabbcc Interface: Vlan-interface200 Status: Enable Strategy: Replace Circuit ID Pattern: User Defined Remote ID Pattern: User Defined Circuit ID format-type: ASCII Remote ID format-type: ASCII User defined: Circuit ID: vlan100 Remote ID: device 001

Table 14 Command output

Interface Interface name.

Option 82 states:

Status

Strategy

Circuit ID Pattern

Remote ID Pattern

Circuit ID format-type Remote ID format-type Node identifier Access node identifier. User defined Content of the user-defined sub-options. Circuit ID User-defined content of the Circuit ID sub-option. Remote ID User-defined content of the Remote ID sub-option.

• Enable—DHCP relay agent support for Option 82 is enabled.

• Disable—DHCP relay agent support for Option 82 is disabled.

Handling strategy for request messages containing Option 82,

Keep

Padding content m ode of the Circuit ID sub-option,

User Defined

Padding content mode of the Remote ID sub-option, or

Padding format of the Circuit ID sub-option, Padding format of t he Remote ID sub-option,

Replace

, or

User Defined

display dhcp relay server-address

Drop

Verbose, Normal

Sysname, Normal

ASCII, Hex, or Undefined

, or

Use display dhcp relay server-address to display DHCP server addresses configured on an interface.

Syntax

display dhcp relay server-address [ interface interface-type interface-number ]

Views

Any view

Field

Description

Predefined user roles

network-admin network-operator

Parameters

interface interface-type interface-number: Displays DHCP server addresses on the specified

interface. If you do not spec ify an interface, this comm and displays DHCP serv er addresses on all interfaces operating in DHCP relay agent mode.

Examples

# Display DHCP server addresses on all interfaces.

<Sysname> display dhcp relay server-address Interface nam e Server IP address Vlan1 2.2.2.2

Table 15 Command output

Interface name Interface name. Server IP address DHCP server IP address.

Related commands

dhcp relay server-address

display dhcp relay statistics

Use display dhcp relay statistics to display DHCP packet statistics on the DHCP relay agent.

Syntax

display dhcp relay statistics [ interface interface-type interface-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Parameters

interface interface-type interface-number: Displays DHCP packet statistics on the specified

interface. If you do not specify an interface, this command displays all DHCP packet statistics on the DHCP relay agent.

Examples

# Display all DHCP packet statistics on the DHCP relay agent.

<Sysname> dis play dhcp relay st atistics DHCP packets dropped: 0 DHCP packets received from clie nts: 0 DHCPDISCOV ER: 0 DHCPREQUEST: 0 DHCPINFORM : 0 DHCPRELEASE: 0

DHCPDECLINE: 0 BOOTPREQUE ST: 0 DHCP packets received from serv ers: 0 DHCPOFFER: 0 DHCPACK: 0 DHCPNAK: 0 BOOTPREPLY : 0 DHCP packets relayed to servers : 0 DHCPDISCOV ER: 0 DHCPREQUEST: 0 DHCPINFORM : 0 DHCPRELEASE: 0 DHCPDECLINE: 0 BOOTPREQUE ST: 0 DHCP packets relayed to clients : 0 DHCPOFFER: 0 DHCPACK: 0 DHCPNAK: 0 BOOTPREPLY : 0 DHCP packets sent to servers: 0 DHCPDISCOV ER: 0 DHCPREQUEST: 0 DHCPINFORM : 0 DHCPRELEASE: 0 DHCPDECLINE: 0 BOOTPREQUE ST: 0 DHCP packets sent to clients: 0 DHCPOFFER: 0 DHCPACK: 0 DHCPNAK: 0 BOOTPREPLY : 0

Related commands

reset dhcp relay statistics

reset dhcp relay client-information

Use reset dhcp relay client-information to clear relay entries on the DHCP relay agent.

Syntax

reset dhcp relay client-information [ interface interface-type interface-number | ip ip-address [ vpn-instance vpn-instance-name ] ]

Views

User view

Predefined user roles

network-admin

Parameters

interface interface-type interface-number: Clears relay entries on the specified interface.

ip ip-address: Clears the relay entry for the specified IP address. vpn-instance vpn-instance-name: Clears the relay entry for the specified IP address in the specified

MPLS L3VPN instance. The vpn-instance-name is a c ase-sensitive s tring of 1 to 31 characters. If you do not specify a VPN instance, this command clears the relay entry in the public network.

Usage guidelines

If you do not specify any parameters, this command clears all relay entries on the DHCP relay agent.

Examples

# Clear all relay entries on the DHCP relay agent.

<Sysname> rese t dhcp relay client-information

Related commands

display dhcp relay client-information

reset dhcp relay statistics

Use reset dhcp relay statistics to clear relay agent statistics.

Syntax

reset dhcp relay statistics [ interface interface-type interface-number ]

Views

User view

Predefined user roles

network-admin

Parameters

interface interface-type interface-number: Clears DHCP relay agent statistics on the specified

interface. If you do not specify an interface, this command clears all DHCP relay agent statistics.

Examples

# Clear all DHCP relay agent statistics.

<Sysname> rese t dhcp relay statistics

Related commands

display dhcp relay statistics

DHCP client commands

dhcp client dad enable

Use dhcp client dad enable to enable duplicate address detection.

Syntax

Default

Use undo dhcp client dad enable to disable duplicate address detection.

dhcp client dad enable undo dhcp client dad enable

Duplicate address detection is enabled on an interface.

Views

System view

Predefined user roles

network-admin

Usage guidelines

DHCP client detects IP address conflict through ARP packets. An attacker can act as the IP address owner to send an ARP reply, which makes the client unable to use the IP addr ess assigned by the server. As a best practice, disable duplicate address detection when ARP attacks exist on the network.

Examples

# Disable the duplicate address.

<Sysname> system-view [Sysname] undo dh cp client dad enable

dhcp client dscp

Use dhcp client dscp to set the DSCP value for DHCP packets sent by the DHCP client. Use undo dhcp client dscp to restore the default.

Syntax

dhcp client dscp dscp-value undo dhcp client dscp

Default

The DSCP value in DHCP packets is 56.

Views

System view

Predefined user roles

network-admin

Parameters

dscp-value: Sets the DSCP value for DHCP packets, in the range of 0 to 63.

Usage guidelines

The DSCP value of a packet specifies th e priority level of the pack et and affects the tra nsmission priority of the packet. A bigger DSCP value represents a higher priority.

Examples

# Set the DSCP value for DHCP packets sent by the DHCP client to 30.

<Sysname> sy stem-view [Sysname] dhcp client dscp 30

dhcp client identifier

Use dhcp client identifier to configure a DHCP client ID for an interface. Use undo dhcp client identifier to restore the default.

•

Syntax

dhcp client identifier { ascii string | hex string | mac interface-type interface-number } undo dhcp client identifier

Default

An interface generates an ASCII c haracter string as the DHCP client ID bas ed on its MAC a ddres s and the interface name.

Views

Interface view

Predefined user roles

network-admin

Parameters

ascii string: Specifies a case-sensitive ASCII string of 1 to 63 characters as the client ID. hex string: Specifies a hexadecimal string of 4 to 64 characters as the client ID. mac interface-type interface-number: Uses the MAC addr ess of the s pecified inte rfac e as a DHCP

client ID. The interface-type interface-number argument specifies an interface by its type and number.

Usage guidelines

A DHCP client ID is added to the DHCP option 61. A DHCP server can specify IP addres ses for clients based on the DHC P client ID. You can specify a DHCP client ID by perf orming one of the following operations:

Naming an ASCII string or hexadecimal string as the client ID. Using the MAC address of an interface to generate a client ID.

Whichever method you use, make sure the IDs for different DHCP clients are unique.

Examples

# Specify the hexadecimal string of FFFFFFF as the client ID for VLAN-interface 10.

<Sysname> system-view [Sysname] interface vlan-interface 10 [Sysname-Vlan-interface10] dhcp client identifier hex FFFFFFFF

Related commands

display dhcp client

Use display dhcp client to display DHCP client information.

Syntax

display dhcp client [ verbose ] [ interface interface-type interface-number ]

Views

Any view

Predefined user roles

network-admin network-operator

Field

Description

Parameters

verbose: Displays verbose DHCP client information. interface interface-type interface-number: Specifies an interface by its type and number.

Usage guidelines

If you do not specify an interface, this command displays DHCP client information about all interfaces.

Examples

# Display DHCP client information about all interfaces.

<Sysname> display dhcp client Vlan-interface10 DHCP client in formation: Current state: BOUND Allocated IP: 40 .1.1.20 255.25 5.255.0 Allocated lease: 259200 seconds, T1: 129600 seconds, T2: 226800 seconds DHCP server: 40.1.1.2

# Display verbose DHCP client information.

<Sysname> disp lay dhcp client verbose Vlan-interface10 DHCP client in formation: Current state: BOUND Allocated IP: 40 .1.1.20 255.25 5.255.0 Allocated lease: 259200 seconds, T1: 129600 seconds, T2: 226800 seconds Lease from May 21 19:00:29 2012 to May 31 19: 00:29 2012 DHCP server: 40.1.1.2 Transaction ID : 0x1c09322d Default router: 40.1.1.2 Classless stat ic routes: Destination: 1.1.0.1, Mask: 255.0.0.0, NextHop: 192.168.40.16 Destinatio n: 10.198.122.63, Mask: 255. 255.255.255, NextHop: 192.16 8.40.16 DNS servers: 44.1.1.11 44.1.1.12 Domain name: ddd.com Boot servers: 200.200.200.200 1.1.1.1 Client ID type: ac sii(type value =00) Client ID value: 000c.29d3.8659-Vlan1 Client ID (with ty pe) hex: 0030-3030-632e-3239 6433-2e38-3635-392d 4574-6830-2f30-2f32 T1 will timeout in 1 day 11 hours 58 mi nutes 52 seconds.

Table 16 Command output

Vlan-interface10 DHCP client information

Current state

Information about the interface that acts as the DHCP client.

Current state of the DHCP client:

• HALT—The client stops applying for an IP address.

• INIT—The initialization state.

• SELECTING—The client has sent out a DHCP-DISCOVER

message in search for a DHCP server and is waiting for the response from DHCP servers.

Field

Description

• REQUESTING—The client has sent out a

DHCP-REQUEST message requesting for an IP address and is waiting for the response from DHCP servers.

• BOUND—The client has re cei ved the DH CP-ACK message from a DHCP server and obtained an IP addres s successfully.

• RENEWING—The T1 timer expires.

• REBOUNDING—The T2 timer expires.

Allocated IP IP address allocated by the DHCP server. Allocated lease Allocated lease time. T1 1/2 lease time (in seconds) of the DHCP client IP address. T2 7/8 lease time (in seconds) of the DHCP client IP address. Lease from….to…. Start and end time of the lease. DHCP server DHCP server IP address that assigned the IP address.

Transaction ID

Default router Gateway address assigned to the client. Classless static r ou tes Classless static r ou tes assigned to the client. Static routes Classful static routes assigned to the client. DNS servers DNS server address assigned to the client. Domain name Domain name suffix assigned to the client .

Boot servers

Client ID type

Client ID value Value of the DHCP client ID. Client ID (with type) hex DHCP client ID with the type field, a hexadecimal string. T1 will timeout in 1 day 11 hours 58

minutes 52 seconds.

Related commands

Transaction ID, a random nu m ber ch ose n by the c lie nt to identify an IP address allocation.

PXE server addresses (up to 16 addresses) specified for the DHCP client, which are obtained through Option 43.

DHCP client ID type:

• If an ASCII str ing is used as the client ID value, the type value is 00.

• If the MAC address of a specific interface is used as the client ID value, the type value is 01.

• If a hexadecimal string is used as the client ID value, the type value is the first two characters in the string.

How long the T1 (1/2 lease time) timer will timeout.

dhcp client identifier ip address dhcp-alloc

ip address dhcp-alloc

Use ip address dhcp-alloc to configure an interface to use DHCP for IP address acquisition. Use undo ip address dhcp-alloc to cancel an interface from using DHCP.

Syntax

ip address dhcp-alloc undo ip address dhcp-alloc

Default

An interface does not use DHCP for IP address acquisition.

Views

Interface view

Predefined user roles

network-admin

Usage guidelines

When you execute the undo ip address dhcp-alloc command, the interface sends a DHCP-RELEASE message to release the IP address obtained through DHCP. If the interf ace is down, the message cannot be sent out.

For a subinterface that obtained an IP address through DHCP , using the shutdown command on its primary interface does not make the subinterf ace send a DHCP-REL EASE message for releasing the subinterface's IP address.

Examples

# Configure VLAN-interface 10 to use DHCP for IP address acquisition.

<Sysname> system-view [Sysname] in terface vlan-interface 10 [Sysname-Vlan-interface10] ip address dhcp-alloc

DHCP snooping commands

DHCP snooping works between the DHCP client and the DHCP server or between the DHCP client and the relay agent. DHCP snooping does not work between the DHCP server and the DHCP relay agent.

dhcp snooping binding database filename

Use dhcp snooping binding database filename to configure the D HCP snoopin g device to back up DHCP snooping entries to a file.

Use undo dhcp snooping binding database filename to disable the auto backup and remove the backup file.

Syntax

dhcp snooping binding databas e filename { filename | url url [ username username [ password { cipher | simple } key ] ] }

undo dhcp snooping binding database filename

Default

The DHCP snooping device does not back up DHCP snooping entries.

Views

System view

Predefined user roles

network-admin

•

Parameters

filename: Specifies the name of a local file. For information about the filename argument, see Fundamentals Configuration Guide.

url url: Specif ies the URL of a rem ote file. Do not incl ude any usernam e or password in t he URL. Case sensitivity and the supported path format type vary by server.

username username: Specifies the username for logging in to the remote device. cipher: Sets a ciphertext password. simple: Sets a plaintext pass word.

key: Specifies the k ey string. This argument is c ase sensitive. If simple is specified, it must be a string of 1 to 32 characters. If cipher is specified, it must be a ciphertext string of 1 to 73 characters.

Usage guidelines

For security purposes, all passwords, including passwords configured in plaintext, are saved in ciphertext.

With this command executed, the DHCP snooping device backs up DHCP snooping entries immediately and runs a uto backup. The command automatically creates the file if you specif y a non-existent file. The DHCP snooping device, by default, waits 300 seconds after a DHCP snooping entry change to update the backup file. To change the waiting period, use the dhcp snooping binding database update interval command. If no DHCP snooping entry changes, the backup file is not updated.

When the file is o n a remote device, follow thes e restrictions and guidel ines to specify the URL, username, and password:

Examples

# Configure the DHCP snooping device to back up DHCP snooping entries to the file database.dhcp.

<Sysname> system-view [Sysname] dhcp sn ooping binding database file name database. dhcp

# Configure the DHCP snooping device to back up DHCP snooping entries to the file database.dhcp in the working directory of the FTP server at 10.1.1.1.

<Sysname> sy stem-view [Sysname] dhcp snooping binding database filenam e url ftp://10.1.1.1/database.dhcp

username 1 passwo rd simple 1

If the file is on an FTP server, enter URL in the following format: ftp://server address:port/file

path, where the port number is optional.

If the file is on a TFTP server, enter URL in the following format: tftp://server address:port/file

path, where the port number is optional.

The username and password must be the same as those configured on the FTP or TFTP

server. If the server authenticates only the username, the password can be omitted. For example, enter URL ftp://1.1.1.1/database.dhcp username admin to specify the URL and username options at the CLI.

If the IP address of the server is an IPv6 address, enclose the address in a pair of brackets, for

example, ftp://[1::1]/database.dhcp.

You can also specify the DNS domain name for the server address field, for example,

ftp://company/database.dhcp.

# Configure the DHCP snooping device to back up DHCP snooping entries to the file database.dhcp in the working directory of the TFTP server at 10.1.1.1.

<Sysname> sy stem-view [Sysname] dhcp sn ooping binding database file name tftp://10.1.1.1/database.dhcp

Related commands

dhcp snooping binding database upda te interval

dhcp snooping binding database update interval

Use dhcp snooping binding database update interval to set the waiting time after a DHCP snooping entry change for the DHCP snooping device to update the backup file.

Use undo dhcp snooping binding database update interval to restore the default.

Syntax

dhcp snooping binding database upda te interval seconds undo dhcp snooping binding databas e update interval

Default

The DHCP snooping de vice waits 300 sec on ds af ter a DH CP snoo pi ng entry change to up dat e t he backup file. If no DHCP snooping entry changes, the backup file is not updated.

Views

System view

Predefined user roles

network-admin

Parameters

seconds: Sets the waiting time in seconds, in the range of 60 to 864000.

Usage guidelines

When a DHCP snooping entry is learned, updated, or removed, the waiting period starts. The DHCP snooping device updates the backup file when the waiting perio d is reached. All changed entries during the period will be saved to the backup file.

The waiting time does not take effect if you do not configure the DHCP snooping entry auto backup by using the dhcp snooping binding database filename command.

Examples

# Set the waiting time to 600 seconds for the DHCP snooping device to update the backup file.

<Sysname> system-view [Sysname] dhcp sn ooping binding database upda te interval 600

Related commands

dhcp snooping binding database filename

dhcp snooping binding databa se update now

Use dhcp snooping binding database upd ate now to manuall y save DHCP snooping entri es to the backup file.

Syntax

dhcp snooping binding database update now

Views

System view

Predefined user roles

network-admin

Usage guidelines

This command does not take effect if you do not configure the DHCP snooping entry auto backup by using the dhcp snooping binding database filename command.

Examples

# Manually save DHCP snooping entries to the backup file.

<Sysname> system-view [Sysname] dhcp sn ooping binding database upda te now

Related commands

dhcp snooping binding database filename

dhcp snooping binding record

Use dhcp snooping binding record to enable recording of client inf ormation in DHCP snooping entries.

Use undo dhcp snooping binding record to disable recording of client information in DHCP snooping entries.

Syntax

dhcp snooping binding record undo dhcp snooping binding record

Default

DHCP snooping does not record client information.

Views

Layer 2 Ethernet interface/Layer 2 aggregate interface view S-channel interface/S -c hannel aggr egat e interface view VSI interface/VSI aggregate interface view

Predefined user roles

network-admin

Usage guidelines

This command enables DHCP snooping on the port directly connecting to the clients to record client information in DHCP snooping entries.

Examples

# Enable recording of client information in DHCP snooping entries.

<Sysname> system-view [Sysname] interface Ten-GigabitEthernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping binding record

dhcp snooping c heck mac-address

Use dhcp snooping check mac-address to enable MAC address check for DHCP snooping. Use undo dhcp snooping check mac-address to disable MAC address check for DHCP snooping.

Syntax

dhcp snooping check mac-address undo dhcp snooping check mac-address

Default

MAC address check for DHCP snooping is disabled.

Views

Layer 2 Ethernet interface/Layer 2 aggregate interface view S-channel interface/S -channel aggregate interface view VSI interface/VSI aggregate interface view

Predefined user roles

network-admin

Usage guidelines

With MAC address check enabled, DHCP snooping compares the chaddr field of a received DHCP request with the source MAC address field in the frame header. If they are the same, DHCP snooping considers this req uest vali d and f orwards it to the DH CP server. If they are not the s am e, DHCP snooping discards the DHCP request.

Examples

# Enable MAC address check for DHCP snooping.

<Sysname> system-view [Sysname] in terface Ten-GigabitEthernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping check mac-address

dhcp snooping check request-message

Use dhcp snooping check request-message to enable DHCP-REQUEST check for DHCP snooping.

Use undo dhcp snooping check request-message to disable DHCP-REQUEST check for DHCP snooping.

Syntax

dhcp snooping check request-message undo dhcp snooping check request-message

Default

DHCP-REQUEST check is disabled for DHCP snooping.

Views

Layer 2 Ethernet interface/Layer 2 aggregate interface view S-channel interface/S -channel aggregate interface view VSI interface/VSI aggregate interface view

Predefined user roles

network-admin

Usage guidelines

DHCP-REQUEST packets include lease renewal packets, DHCP-DECLINE packets, and DHCP-RELEASE pack ets. This feature prevent s unauthorized c lients that forge DHCP-REQUEST packets from attacking the DHCP server.

With this feature enabled, DHCP snooping looks for a matching DHCP snooping entr y for each received DHCP-REQUEST message.

•

If a match is found, DHCP snooping compares the entry with the message. If they have

consistent information, DHCP snooping considers the packet valid and forwards it to the DHCP server. If they have different information, DHCP snooping considers the message invalid and discards it.

If no match is found, DHCP snooping forwards the message to the DHCP server.

Examples

# Enable DHCP-REQUEST check for DHCP snooping.

<Sysname> system-view [Sysname] in terface Ten-GigabitEthernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping check request-message

dhcp snooping deny

Use dhcp snooping deny to configure a port as DHCP packet blocking port. Use undo dhcp snooping deny to restore the default.

Syntax

dhcp snooping deny undo ipv6 dhcp snooping deny

Default

A port does not block DHCP packets.

Views

Layer 2 Ethernet interface view, Layer 2 aggregate interface view

Predefined user roles

network-admin

Usage guidelines

DHCP clients connected to DHCP packet blocking ports cannot obtain IP addresses and other configuration parameters from the DHCP server.

Do not configure a port as both a trusted port and a DHCP packet blocking port.

Examples

# Configure Layer 2 Ethernet interface Ten-GigabitEthernet 1/0/1 as a DHCP packet blocking port.

<Sysname> system-view [Sysname] interface Ten-GigabitEthernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping deny

dhcp snooping enable

Use dhcp snooping enable to enable DHCP snooping.

Syntax

Default

Use undo dhcp snooping enable to disable DHCP snooping.

dhcp snooping enable undo dhcp snooping enable

DHCP snooping is disabled.

•

Views

System view

Predefined user roles

network-admin

Usage guidelines

Use the DHCP snooping feature together with trusted port configur ation. Before truste d ports are configured, all ports on the DHCP snooping device are untrusted and the device discards all responses sent from DHCP servers.

When DHCP snooping is disabled, the device forwards all responses from DHCP servers.

Examples

# Enable DHCP snooping.

<Sysname> system-view [Sysname] dhcp snooping enable

dhcp snooping information circuit-id

Use dhcp snooping information circuit-id to configure the padding mode and padding format for the Circuit ID sub-option.

Use undo dhcp snooping information circuit-id to restore the default.

Syntax

dhcp snooping information circuit-id { [ vlan vlan-id ] string circuit-id | { normal | verbose [ node-identifier { mac | sysname | user-defined node-identifier } ] } [ format { ascii | hex } ] }

undo dhcp snooping information circuit-id [ vlan vlan-id ]

Default

The padding mode is normal and the padding format is hex.

Views

Layer 2 Ethernet interface view, Layer 2 aggregate interface view

Predefined user roles

network-admin

Parameters

vlan vlan-id: Specifies a VLAN ID for the Circuit ID sub-option. string circuit-id: Specifies the string mode, in which the padding content for the Circuit ID sub-option

is a case-sensitive string of 3 to 63 characters. normal: Specifies the normal mode. The padding content includes the VLAN ID and interface

number.

verbose: Specifies the verbose mode. node-identifier { mac | sysname | user-defined node-identifier }: Specifies the access node

identifier. The padding con tent includes the node identifier, Ethernet type (f ixed to eth), interface number, and VLAN ID. The node identifier varies by keyword mac, sysname, and user-defined.

mac: Uses the MAC addre s s of the access node as the node identifier. It is the default node

identifier.

sysname: Uses the device name as the node identifier. You can set the device name b y using

the sysname command in system view. The padding format for the device name is always ASCII regardless of the specified padding format.

NOTE:

is used as the node identifier, do not include any space when you set the device name.

Otherwise, the DHCP snooping device fails to add or replace the Option 82.

•

is specified

format is ascii

sysname

user-defined node-identifier: Uses a case-sensitive string of 1 to 50 characters as the node

identifier. The padding format for the specified character string is always ASCII regardless of the specified padding format.

format: Specifies the padding format for the Circuit ID sub-option. ascii: Specifies the padding format as ASCII. hex: Specifies the padding format as hex.

Usage guidelines

The Circuit ID sub-option cannot carry information about interface splitting or subinterfaces. For more information about interface splitting and subinterfaces, see Interface Configuration Guide.

If you use this command multiple times, the most recent configuration takes effect. The padding form at for the user-defined str ing, the normal m ode, or the verbose modes varies by

command configuration. Table 17 shows how the padding format is determined for different modes.

Table 17 Padding format for different modes

If replace is configured as the handling strategy for DHCP requests that contain Option 82, you must specify the padding mode and padding format for the Circuit ID sub-option. If the handling strategy is keep or drop, you do n ot need to s pecify the pad ding mode and padding format f or the Circuit ID sub-option.

Examples

# Configure verbos e as the padding mode, device nam e as the node identifier, and ASCII as the padding format for the Circuit ID sub-option.

<Sysname> sy stem-view [Sysname] in terface Ten-GigabitEthernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping information en able [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping information strategy replace [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping information circuit-id verbose

node-identifi er sysname forma t ascii

Keyword (mode)

string

circuit-id

normal

verbose

If no padding format

You cannot specify a padding format, and the padding format is always ASCII.

Hex. ASCII. Hex. Hex for the VLAN ID.

ASCII for the node identifier, Ethernet type, and interface number.

If the padding

N/A N/A

ASCII.

If the padding format is hex

ASCII for the node identifier and Ethernet type.

Hex for the interface number and VLAN ID.

Related commands

dhcp snooping information enable dhcp snooping information strategy display dhcp snooping information

dhcp snooping information enable

Use dhcp snooping information enable to enable DHCP snooping to support Option 82. Use undo dhcp snooping information enable to disable this feature.

Syntax

dhcp snooping information enable undo dhcp snooping information enable

Default

DHCP snooping does not support Option 82.

Views

Layer 2 Ethernet interface view, Layer 2 aggregate interface view

Predefined user roles

network-admin

Usage guidelines

This command enables DH CP snooping to add Option 82 in to DHCP request pack ets that do not contain Option 82 before f orwarding the req uests to the DHCP server. The content of Option 82 is determined by the dhcp snooping information circuit-id and dhcp snooping information remote-id comm ands. If the received DHCP request pack ets contain Option 82, DHCP snoop ing handles the packets according to the strategy configured with the dhcp snooping information strategy command.

If this feature is disabled, DHCP snooping forwards requests that contain or do not contain Option 82 to the DHCP server.

Examples

# Enable DHCP snooping to support Option 82.

<Sysname> system-view [Sysname] interface Ten-GigabitEthernet1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping information enable

Related commands

dhcp snooping information circuit-id dhcp snooping information remote-id dhcp snooping information strategy

dhcp snooping information remote-id

Use dhcp snooping information remote-id to configure the padding mode and padding format for the Remote ID sub-option.

Use undo dhcp snooping information remote-id to restore the default.

Syntax

dhcp snooping information remote-id { normal [ format { ascii | hex } ] | [ vlan vlan-id ] { string remote-id | sysname } }

Default

undo dhcp snooping information remote-id [ vlan vlan-id ]

The padding mode is normal and the padding format is hex.

Views

Layer 2 Ethernet interface view, Layer 2 aggregate interface view

Predefined user roles

network-admin

Parameters

vlan vlan-id: Specifies the VLAN ID as the Remote ID sub-option. string remote-id: Specifies the string mode that uses a case-sensitive string of 1 to 63 characters as

the content of the Remote ID sub-option. sysname: Specifies the s ysname mode that uses the device name as the R emote ID sub-option.

You can configure the device name by using the sysname command in system view. normal: Specifies the normal mode. The padding content is the MAC address of the receiving

interface. format: Specifies th e padding form at for the Remote ID s ub-option. The defau lt padding form at is

hex.

ascii: Specifies the padding format as ASCII. hex: Specifies the padding format as hex.

Usage guidelines

DHCP snooping uses ASCII to pad the specified string or device name for the Remote ID sub-option. The padding format for the normal padding mode is determined by the command configuration.

If you use this command multiple times, the most recent configuration takes effect.

Examples

# Pad the Remote ID sub-option with the character string device001.

<Sysname> sy stem-view [Sysname] interface Ten-GigabitEth ernet 1/0/1 [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping information enable [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping information strategy replace [Sysname-Ten-GigabitEthernet1/0/1] dhcp snooping in formation remote-id string device001

Related commands

dhcp snooping information enable dhcp snooping information strategy display dhcp snooping information

dhcp snooping information strategy

Use dhcp snooping information strategy to configure the handling strategy for Option 82 in request messages.

Syntax

Default

Use undo dhcp snooping information strategy to restore the default.

dhcp snooping information strategy { drop | keep | replace } undo dhcp snooping information strategy

The handling strategy for Option 82 in request messages is replace.

HP 5920, 5900 Command Reference Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Acknowledgments

Contents

ARP commands

arp check enable

arp check log enable

arp max-learning-num

arp max-learning-number

arp multiport

arp static

arp timer aging

display arp

display arp ip-address

display arp entry-limit

display arp timer aging

display arp vpn-instance

reset arp

Gratuitous ARP commands

arp ip-conflict log prompt

arp send-gratuitous-arp

gratuitous-arp-learning enable

gratuitous-arp-sending enable

Proxy ARP commands

display local-proxy-arp

display proxy-arp

local-proxy-arp enable

proxy-arp enable

ARP snooping commands

arp snooping enable

display arp snooping

reset arp snooping

ARP fast-reply commands

arp fast-reply enab le

IP addressing commands

display ip interface

display ip interface brief

IP Address

ip address unnumbered

DHCP commands

Common DHCP commands

dhcp dscp

dhcp enable

dhcp select

DHCP server commands

address range

bims-server

bootfile-name

class

dhcp class

dhcp server always-broadcast

dhcp server apply ip-pool

dhcp server bootp ignore

dhcp server bootp reply-rfc-1048

dhcp server forbid den-ip

dhcp server ip-pool

dhcp server ping packets

dhcp server ping timeout

dhcp server relay information enable

display dhcp ser v er conflict

display dhcp ser v er expired

display dhcp ser v er free-ip

display dhcp server ip-in-use

display dhcp ser v er pool

display dhcp ser v er statistics

dns-list

domain-name

expired

forbidden-ip

gateway-list

if-match

nbns-list

netbios-type

network

next-server

option

reset dhcp server conflict

reset dhcp server expired
