Hp 5740 User Manual
HP Oicejet 5740 e-All-in-One series
Table of contents
1 How do I? ...................................................................................................................................................... 1
2 Get started .................................................................................................................................................... 2
Printer parts ........................................................................................................................................................... 3
Control panel and status lights ............................................................................................................................. 5
Paper basics ........................................................................................................................................................... 7
Load media .......................................................................................................................................................... 10
Load original ........................................................................................................................................................ 14
Open the HP printer software (Windows) ............................................................................................................ 15
Sleep mode .......................................................................................................................................................... 16
Accessibility ......................................................................................................................................................... 17
3 Print ........................................................................................................................................................... 18
Print photos ......................................................................................................................................................... 19
Print documents .................................................................................................................................................. 21
Print on both sides (duplexing) ........................................................................................................................... 22
Print using Near Field Communication (NFC) ...................................................................................................... 23
Print with AirPrint ................................................................................................................................................ 24
Tips for print success ........................................................................................................................................... 26
4 Use Web Services ......................................................................................................................................... 28
What are Web Services? ....................................................................................................................................... 29
Set up Web Services ............................................................................................................................................. 30
Print with HP ePrint ............................................................................................................................................. 32
Use HP Printables ................................................................................................................................................ 34
Use the HP Connected website ............................................................................................................................ 35
Remove Web Services .......................................................................................................................................... 36
Tips for using Web Services ................................................................................................................................. 37
5 Copy and scan .............................................................................................................................................. 38
Copy documents .................................................................................................................................................. 39
ENWW iii
Scan ...................................................................................................................................................................... 40
Tips for copy and scan success ............................................................................................................................ 45
6 Fax ............................................................................................................................................................. 46
Send a fax ............................................................................................................................................................ 47
Receive a fax ........................................................................................................................................................ 52
Set up phone book contacts ................................................................................................................................ 58
Change fax settings ............................................................................................................................................. 61
Fax and digital phone services ............................................................................................................................ 65
Fax over Internet Protocol ................................................................................................................................... 66
Use reports .......................................................................................................................................................... 67
7 Work with cartridges ................................................................................................................................... 71
Check the estimated ink levels ............................................................................................................................ 72
Replace the cartridges ......................................................................................................................................... 73
Order ink supplies ................................................................................................................................................ 75
Use single-cartridge mode .................................................................................................................................. 76
Cartridge warranty information .......................................................................................................................... 77
Anonymous usage information storage .............................................................................................................. 78
Tips for working with cartridges ......................................................................................................................... 79
8 Connect Your Printer .................................................................................................................................... 80
Set up the printer for wireless communication ................................................................................................... 81
Change network settings ..................................................................................................................................... 86
Advanced printer management tools (for networked printers) ......................................................................... 88
Tips for setting up and using a networked printer ............................................................................................. 90
9 Solve a problem ........................................................................................................................................... 91
Jams and paper-feed issues ................................................................................................................................ 92
Ink cartridge issues .............................................................................................................................................. 97
Printing issues ..................................................................................................................................................... 99
Copy issues ........................................................................................................................................................ 107
Scan issues ........................................................................................................................................................ 108
Fax issues ........................................................................................................................................................... 109
Network and connection issues ........................................................................................................................ 118
Printer hardware issues ..................................................................................................................................... 120
HP support ......................................................................................................................................................... 121
Appendix A Technical information ................................................................................................................. 123
Hewlett-Packard Company notices ................................................................................................................... 124
iv ENWW
Specications ..................................................................................................................................................... 125
Environmental product stewardship program .................................................................................................. 127
Regulatory information ..................................................................................................................................... 131
Appendix B Additional fax setup .................................................................................................................... 141
Set up faxing (parallel phone systems) ............................................................................................................ 142
Serial-type fax setup ......................................................................................................................................... 162
Test fax setup .................................................................................................................................................... 163
Index ........................................................................................................................................................... 187
ENWW v
vi ENWW
1 How do I?
Learn how to use your HP Oicejet 5740 series
●
Get started on page 2
●
Print on page 18
●
Use Web Services on page 28
●
Copy and scan on page 38
●
Fax on page 46
●
Work with cartridges on page 71
●
Connect Your Printer on page 80
●
Technical information on page 123
●
Solve a problem on page 91
ENWW 1
2 Get started
This section contains the following topics:
●
Printer parts
●
Control panel and status lights
●
Paper basics
●
Load media
●
Load original
●
Open the HP printer software (Windows)
●
Sleep mode
●
Accessibility
2 Chapter 2 Get started ENWW
Printer parts
Front view
Figure 2-1 Front and top views of HP Oicejet 5740 e-All-in-One series
Feature Description
1 Lid
2 Lid-backing
3 Scanner glass
4 Printer model name
5 Cartridge access door
6 Memory device area
7 Cartridge access area
8 Ink cartridges
9 Photo tray
10 On button (also referred to as the Power button)
11 Wireless status light
12 Control panel
13 Output tray
14 Color graphics display (also referred to as the display)
15 Automatic output tray extender (also referred to as the tray extender)
16 Memory card slot
17 Memory device light
18 Front universal serial bus (USB) port
19 Paper tray
ENWW Printer parts 3
Back view
Figure 2-2 Rear view of HP Oicejet 5740 e-All-in-One series
Feature Description
1 Document feeder
2 Power light. The green light indicates the power cord is installed correctly.
3 Ethernet network port
4 Rear USB port
5 Power connection. Use only the power cord supplied by HP.
6 Fax ports: 2-EXT (top) and 1-LINE (bottom)
4 Chapter 2 Get started ENWW
Control panel and status lights
Overview of buttons and lights
The following diagram and related table provides a quick reference to the printer control panel features.
Label Name and Description
1 Wireless light: Indicates the status of the printer wireless connection.
●
Solid blue light indicates that wireless connection has been established and you can print.
●
Slow blinking light indicates that wireless is on, but the printer is not connected to a network. Make sure your printer is
within the range of wireless signal.
●
Fast blinking light indicates wireless error. Refer to the message on the printer display.
●
If wireless is turned o, the wireless light is o and the display screen shows Wireless O.
2 On button: Turns the printer on or o.
3 Back button: Returns to the previous screen.
4 Help button: Opens the Help menu for the current operation.
5 Home button: Returns to the Home screen, the screen that is displayed when you rst turn on the printer.
6 Control panel display: Touch the screen to select menu options, or scroll through the menu items.
7 Near Field Communication (NFC) button: Indicates the area where you can print documents and images from a mobile device
(such as a smartphone or tablet) by touching the device on the printer.
Control panel display icons
Icon Purpose
Copy : Opens the Copy menu where you can select a copy type or change the copy settings.
ENWW Control panel and status lights 5
Icon Purpose
Scan : Opens the Scan menu where you can select a destination for your scan.
HP Printables: Provides a quick and easy way to access and print information from the web, such as coupons,
coloring pages, puzzles, and more.
Photo : Opens the Photo menu where you can view and print photos, or reprint a printed photo.
Fax : Displays a screen where you can send a fax, or change fax settings.
Setup : Opens the Setup menu where you can change preferences and use tools to perform maintenance
functions.
Help : Opens the Help menu where you can view How To videos, printer feature information, and tips.
Near Field Communication (NFC) button: Indicates the area where you can print documents and images from a
mobile device (such as a smartphone or tablet) by touching the device on the printer.
ePrint icon: Opens the Web Services Summary menu, where you can check ePrint status details, change ePrint
settings, or print an Info page.
Wi-Fi Direct icon: Opens the Wi-Fi Direct menu where you can turn on Wi-Fi Direct, turn o Wi-Fi Direct, and
display the Wi-Fi Direct name and password.
Wireless icon: Opens the Wireless Summary menu where you can check wireless status and change wireless
settings. You can also print a wireless test report, helping diagnose network connection issues.
NOTE: (Ethernet) and (Wireless) will not be displayed at the same time. Showing the Ethernet icon or
the wireless icon depends on the way your printer is connected to the network. If the network connection of the
printer has not been set up, by default, the printer control panel display shows
Ethernet icon: Shows that an Ethernet network connection exists and also provides easy access to the the
network status screen.
ECO icon: Displays a screen where you can congure some of the printer environmental features.
Fax Status icon: Displays status information for the Auto Answer function, fax logs, and the fax sound volume.
Ink icon: Shows estimated ink levels by cartridge. Displays a warning symbol if the ink level is less than the
minimum expected ink level.
(Wireless).
NOTE: Ink level warnings and indicators provide estimates for planning purposes only. When you receive a low-
ink warning message, consider having a replacement cartridge available to avoid possible printing delays. You do
not need to replace cartridges until the print quality becomes unacceptable.
6 Chapter 2 Get started ENWW
Paper basics
The printer is designed to work well with most types of oice paper. It is best to test a variety of print paper
types before buying large quantities. Use HP paper for optimum print quality. Visit the HP website at
www.hp.com for more information about HP paper.
HP recommends plain papers with the ColorLok logo for printing everyday documents. All
papers with the ColorLok logo are independently tested to meet high standards of
reliability and print quality, and produce documents with crisp, vivid color, bolder blacks,
and that dry faster than ordinary plain papers. Look for papers with the ColorLok logo in
a variety of weights and sizes from major paper manufacturers.
This section contains the following topics:
●
Recommended papers for printing
●
Order HP paper supplies
●
Tips for selecting and using paper
Recommended papers for printing
If you want the best print quality, HP recommends using HP papers that are specically designed for the type
of project you are printing.
Depending on your country/region, some of these papers might not be available.
Photo printing
●
●
●
HP Premium Plus Photo Paper
HP Premium Plus Photo Paper is HP’s highest-quality photo paper for your best photos. With HP
Premium Plus Photo Paper, you can print beautiful photos that are instant-dry so you can share them
right o the printer. It is available in several sizes, including A4, 8.5 x 11 inches, 4 x 6 inches (10 x 15
cm), 5 x 7 inches (13 x 18 cm), and 11 x 17 inches (A3), and in two nishes - glossy or soft gloss (semigloss). Ideal for framing, displaying, or gifting your best photos and special photo projects. HP Premium
Plus Photo Paper delivers exceptional results with professional quality and durability.
HP Advanced Photo Paper
This thick photo paper features an instant-dry nish for easy handling without smudging. It resists
water, smears, ngerprints, and humidity. Your prints have a look and feel comparable to a storeprocessed photo. It is available in several sizes, including A4, 8.5 x 11 inches, 10 x 15 cm (4 x 6 inches),
13 x 18 cm (5 x 7 inches), and two nishes – glossy or soft-gloss (satin matte). It is acid-free for longer
lasting documents.
HP Everyday Photo Paper
Print colorful, everyday snapshots at a low cost, using paper designed for casual photo printing. This
aordable photo paper dries quickly for easy handling. Get sharp, crisp images when you use this paper
with any inkjet printer. It is available in glossy nish in several sizes, including A4, 8.5 x 11 inches, and
10 x 15 cm (4 x 6 inches). It is acid-free for longer lasting documents.
●
HP Photo Value Packs
ENWW Paper basics 7
HP Photo Value Packs conveniently package original HP ink cartridges and HP Advanced Photo Paper to
save you time and take the guesswork out of printing aordable, lab-quality photos with your HP
printer. Original HP inks and HP Advanced Photo Paper have been designed to work together so your
photos are long lasting and vivid, print after print. Great for printing out an entire vacation's worth of
photos or multiple prints to share.
Business documents
●
HP Premium Presentation Paper 120g Matte
This paper is a heavy two-sided matte paper perfect for presentation, proposals, reports, and
newsletters. It is heavyweight for an impressive look and feel.
●
HP Brochure Paper 180g Glossy or HP Professional Paper 180 Glossy
These papers are glossy-coated on both sides for two-sided use. They are the perfect choice for nearphotographic reproductions and business graphics for report covers, special presentations, brochures,
mailers, and calendars.
●
HP Brochure Paper 180g Matte or HP Professional Paper 180 Matt
These papers are matte-coated on both sides for two-sided use. They are the perfect choice for nearphotographic reproductions and business graphics for report covers, special presentations, brochures,
mailers, and calendars.
Everyday printing
All the papers listed for everyday printing feature ColorLok Technology for less smearing, bolder blacks, and
vivid colors.
●
HP Bright White Inkjet Paper
HP Bright White Inkjet Paper delivers high-contrast colors and sharp text. It is opaque enough for twosided color usage with no show-through, which makes it ideal for newsletters, reports, and yers.
●
HP Printing Paper
HP Printing Paper is a high-quality multifunction paper. It produces documents that look and feel more
substantial than documents printed on standard multipurpose or copy paper. It is acid-free for longer
lasting documents.
●
HP Oice Paper
HP Oice Paper is a high-quality multifunction paper. It is suitable for copies, drafts, memos, and other
everyday documents. It is acid-free for longer lasting documents.
●
HP Oice Recycled Paper
HP Oice Recycled Paper is a high-quality multifunction paper made with 30% recycled ber.
Order HP paper supplies
The printer is designed to work well with most types of oice paper. Use HP paper for optimum print quality.
To order HP papers and other supplies, go to www.hp.com . At this time, some portions of the HP website are
available in English only.
HP recommends plain papers with the ColorLok logo for printing and copying of everyday documents. All
papers with the ColorLok logo are independently tested to meet high standards of reliability and print quality,
8 Chapter 2 Get started ENWW
and produce documents with crisp, vivid color, bolder blacks and dry faster than ordinary plain papers. Look
for papers with the ColorLok logo in a variety of weights and sizes from major paper manufacturers.
Tips for selecting and using paper
For the best results, observe the following guidelines.
●
Load only one type of paper at a time into a tray or document feeder.
●
When loading the tray and document feeder, make sure the paper is loaded correctly.
●
Do not overload the tray or document feeder.
●
To prevent jams, poor print quality, and other printing problems, avoid loading the following paper in the
tray or document feeder:
—
Multipart forms
—
Media that is damaged, curled, or wrinkled
—
Media with cutouts or perforations
—
Media that is heavily textured, embossed, or does not accept ink well
—
Media that is too lightweight or stretches easily
—
Media that contains staples or clips
ENWW Paper basics 9
Load media
Select a paper size to continue.
To load small-size paper
1. Pull out the photo tray.
If you do not see the photo tray, remove the output tray from the printer.
2. Load paper.
●
Insert a stack of photo paper into the photo tray print side down.
●
3. Push the photo tray back in.
4. Change or retain the paper settings on the printer display.
To load full-size paper
1. Pull out the paper tray, slide the paper-width guides outward, and then remove any previously loaded
media.
2. Load paper.
Slide the photo paper forward until it stops.
10 Chapter 2 Get started ENWW
●
●
●
3. Push the paper tray back in.
4. Change or retain the paper settings on the printer display.
To load legal paper
Insert a stack of paper into the paper tray with the short edge forward and the print side down.
Slide the paper forward until it stops.
Slide the paper-width guides inward until they stop at the edges of the paper.
1. Pull out the paper tray, slide the paper-width guides outward, and then remove any previously loaded
media.
2. Unlock and open the front side of the paper tray.
3. Load paper.
ENWW Load media 11
●
Insert a stack of paper into the paper tray with the short edge forward and the print side down.
●
Slide the paper forward until it stops.
●
Slide the paper-width guides inward until they stop at the edges of the paper.
4. Push the paper tray back in.
5. Change or retain the paper settings on the printer display.
To load envelopes
1. Pull out the paper tray, slide the paper-width guides outward, and then remove any previously loaded
media.
2. Load envelopes
●
Insert one or more envelopes in the center of the paper tray. The print side should face down. The
ap should be on the left side and facing up.
12 Chapter 2 Get started ENWW
●
Slide a stack of envelopes inward until it stops.
●
Slide the paper-width guides inward against the stack of envelopes until they stop.
3. Push the paper tray back in.
4. Change or retain the paper settings on the printer display.
ENWW Load media 13
Load original
To load original on the scanner glass
1. Lift the scanner lid.
2. Load the original print side down on the right front corner of the glass.
3. Close the scanner lid.
To load an original in the document feeder
1. Slide paper-width guides outwards.
2. Load original print-side up in the document feeder.
3. Slide paper-width guides inward until they stop at the edge of paper.
14 Chapter 2 Get started ENWW
Open the HP printer software (Windows)
After installing the HP printer software, depending on your operating system, do one of the following:
●
Windows 8.1: Click the down arrow in lower left corner of the Start screen, and then select the printer
name.
●
Windows 8: Right-click an empty area on the Start screen, click All Apps on the app bar, and then select
the printer name.
●
Windows 7, Windows Vista, and Windows XP: From the computer desktop, click Start, select All
Programs
, click HP, click the folder for the printer, and then select the icon with the printer's name.
ENWW Open the HP printer software (Windows) 15
Sleep mode
●
Power usage is reduced while in the Sleep mode.
●
After initial setup of printer, the printer will enter the Sleep mode after ve minutes of inactivity.
●
The time to the Sleep mode can be changed from the control panel.
To set the Sleep mode time
1.
From the Home screen, touch ( Setup ).
2. Touch Preferences .
3. Scroll through the options, and then touch Sleep Mode.
4. Touch After 5 minutes or After 10 minutes, or After 15 minutes.
16 Chapter 2 Get started ENWW
Accessibility
The printer provides a number of features that make it accessible for people with disabilities.
Visual
The HP software provided with the printer is accessible for users with visual impairments or low vision by
using your operating system's accessibility options and features. The software also supports most assistive
technology such as screen readers, Braille readers, and voice-to-text applications. For users who are color
blind, colored buttons and tabs used in the HP software have simple text or icon labels that convey the
appropriate action.
Mobility
For users with mobility impairments, the HP software functions can be executed through keyboard
commands. The HP software also supports Windows accessibility options such as StickyKeys, ToggleKeys,
FilterKeys, and MouseKeys. The printer doors, buttons, paper trays, and paper-width guides can be operated
by users with limited strength and reach.
Support
For more details about the accessibility of this printer and HP's commitment to product accessibility, visit HP's
website at www.hp.com/accessibility.
For accessibility information for Mac OS X, visit the Apple website at www.apple.com/accessibility.
ENWW Accessibility 17
3 Print
Most print settings are automatically handled by the software application. Change the settings manually only
when you want to change print quality, print on specic types of paper, or use special features.
This section contains the following topics:
●
Print photos
●
Print documents
●
Print on both sides (duplexing)
●
Print using Near Field Communication (NFC)
●
Print with AirPrint
●
Tips for print success
18 Chapter 3 Print ENWW
Print photos
Make sure photo paper is loaded into the photo tray.
To print photos from a memory device
1. Insert a memory device into the slot.
2. On the printer display, select a photo that you want to print and touch Continue.
3. Specify the number of photos to print.
4.
Touch (Edit) to change brightness, crop, or rotate the selected photo, or touch (Print Settings) to
use such features as
5. Touch Continue and preview the selected photo.
6. Touch Print to begin printing.
Red Eye Removal or Photo Fix.
To print a photo from the printer software
1. From your software, select Print.
2. Make sure your printer is selected.
3. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup,
Printer Properties, Printer, or Preferences.
4. Select the appropriate options.
●
On the Layout tab, select Portrait or Landscape orientation.
●
On the Paper/Quality tab, select the appropriate paper type from the Media drop-down list in the
Tray Selection area, and then select the appropriate print quality in the Quality Settings area.
●
Click Advanced to select the appropriate paper size from the Paper Size drop-down list.
5. Click OK to return to the Properties dialog box.
6. Click OK, and then click Print or OK in the Print dialog box.
NOTE: After the printing is nished, remove unused photo paper from the photo tray. Store the photo paper
so it does not start to curl, which could reduce the quality of your printout.
ENWW Print photos 19
To print a photo from the computer (OS X)
1. Load paper in the tray. For more information, see Load media on page 10.
2. From the File menu in your software, choose Print.
3. Make sure your printer is selected.
4. Set the print options.
If you do not see options on the Print dialog, click Show Details.
NOTE: The following options are available for a USB connected printer. Locations for the options can
vary from one application to another.
a. Choose the appropriate paper size in the Paper Size pop-up menu.
NOTE: If you change the Paper Size ensure that you have loaded the correct paper and set the
paper size on the printer control panel to match.
b. Select an Orientation.
c. From the pop-up menu, choose Paper Type/Quality, and then choose the following settings:
●
Paper Type: The appropriate photo paper type
●
Quality: Best or Maximum dpi
●
Click the Color Options disclosure triangle, and then choose the appropriate Photo Fix
option.
—
O: applies no changes to the image.
—
Basic: automatically focuses the image; moderately adjusts image sharpness.
5. Select any other print settings you want, and then click Print.
20 Chapter 3 Print ENWW
Print documents
Make sure paper is loaded into the paper tray.
To print a document
1. From your software, select Print.
2. Make sure your printer is selected.
3. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup,
Printer Properties, Printer, or Preferences.
4. Select the appropriate options.
●
On the Layout tab, select Portrait or Landscape orientation.
●
On the Paper/Quality tab, select the appropriate paper type from the Media drop-down list in the
Tray Selection area, and then select the appropriate print quality in the Quality Settings area.
●
Click Advanced to select the appropriate paper size from the Paper Size drop-down list.
5. Click OK to close the Properties dialog box.
6. Click Print or OK to begin printing.
To print documents (OS X)
1. Load paper in the tray. For more information, see Load media on page 10.
2. From the File menu in your software, choose Print.
3. Make sure your printer is selected.
4. Specify the page properties.
If you do not see options on the Print dialog, click Show Details.
NOTE: The following options are available for a USB connected printer. Locations for the options can
vary from one application to another.
●
Choose the paper size.
NOTE: If you change the Paper Size ensure that you have loaded the correct paper and set the
paper size on the printer control panel to match.
●
Select the orientation.
●
Enter the scaling percentage.
5. Click Print.
NOTE: If your printed documents are not aligned within the margins of the paper, make sure that you have
selected the correct language and region. On the printer display, select Settings, and then select Preferences.
Select your language, and then region from the options provided. The correct language and country/region
settings ensure that the printer will have the appropriate default paper size settings.
ENWW Print documents 21
Print on both sides (duplexing)
To print on both sides of the page
You can print on both sides of a sheet of paper automatically by using the automatic two-sided printing
mechanism (duplexer).
1. From your software, select Print.
2. Make sure your printer is selected.
3. Click the button that opens the Properties dialog box.
Depending on your software application, this button might be called Properties, Options, Printer Setup,
Printer Properties, Printer, or Preferences.
4. Select the appropriate options.
●
On the Layout tab, select Portrait or Landscape orientation, and select Flip on Long Edge or Flip
on Short Edge from the Print on Both Sides drop-down list.
●
On the Paper/Quality tab, select the appropriate paper type from the Media drop-down list in the
Tray Selection area, and then select the appropriate print quality in the Quality Settings area.
●
Click the Advanced button, in the Paper/Output area, select the appropriate paper size from the
Paper Size drop-down list.
NOTE: If you change the Paper Size ensure that you have loaded the correct paper and set the
paper size on the printer control panel to match.
5. Click OK to print.
NOTE: After one page of the document has been printed, wait for the printer to reload the paper
automatically to print on the other side. You do not need to take any action.
To print on both sides of the page (OS X)
1. From the File menu in your software, choose Print.
2. In the Print dialog, choose Layout from the pop-up menu.
3. Choose the type of binding you want for your two-sided pages, and then click Print.
22 Chapter 3 Print ENWW
Print using Near Field Communication (NFC)
With near eld communication (NFC), you can quickly print documents and images from a mobile device (such
as a smartphone or tablet) just by touching the device on the printer. Look for on the front of the printer,
near the printer control panel, and then touch your mobile device to this area to print—no additional setup
required.
NOTE: This feature is available with some models of the printer.
To use this feature, make sure your mobile device supports NFC and make sure NFC is turned on in the printer.
ENWW Print using Near Field Communication (NFC) 23
Print with AirPrint
Printing using Apple’s AirPrint is supported for iOS 4.2 and Mac OS X 10.7 or later. Use AirPrint to print
wirelessly to the printer from an iPad (iOS 4.2), iPhone (3GS or later), or iPod touch (third generation or later)
in the following mobile applications:
●
Mail
●
Photos
●
Safari
●
Supported third-party applications, for example Evernote
To use AirPrint, ensure the following:
●
The printer and the Apple device must be connected to the same network as your AirPrint enabled
device. For more information about using AirPrint and about which HP products are compatible with
AirPrint, go to www.hp.com/go/mobileprinting .
●
Load paper that matches the paper settings of the printer.
24 Chapter 3 Print ENWW
Loading...
