QuickSpecs
HP Engage One Prime Barcode Scanner
Overview
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 1
HP Engage One Prime Barcode Scanner
Models
HP Engage One Prime Barcode Scanner
4VW58AA/AT
HP Engage One Prime White Barcode Scanner
4VW64AA/AT
Introduction
Deliver an efficient customer experience with the breathtaking HP Engage One Prime Barcode Scanner, HP’s smallest, slimmest
barcode scanner, designed to complement the HP Engage One Prime System. It reads mobile wallets, digital coupons, and printed
barcodes and can be used by hand or in presentation mode
QuickSpecs
HP Engage One Prime Barcode Scanner
Overview
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 2
Service and Support
Rest easy that your IT investment is supported by a one-year standard limited warranty.
QuickSpecs
HP Engage One Prime Barcode Scanner
Technical Specifications
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 3
Scanner Type 2D Linear Imager
Light source White LED
Resolution
≥4 mil
Depth of Field Typical Performance *
Narrow Width Depth of Field
Code 39 50mm-125mm (1.9in-4.9in) (5 mils)
35mm-250mm (1.4in-9.8in) (10 mils)
EAN-13 60mm-230mm (2.4in-9.1in) (13 mil)
PDF417 55mm-75mm (2.2in-2.9in) (6.7 mils)
20mm-145mm (.78in-5.7in) (10 mils)
QR Code 25mm-80mm (.98in-3.1in) (10 mils)
10mm-135mm (.4in-5.3in) (15 mils)
Datamatrix 35mm-75mm (1.4in-2.9in) (10 mils)
15mm-115mm (.59in-4.5in) (15 mils
Symbol Contrast 25% minimum reflectance
Roll (tilt) 360°
Pitch
± 45°
Skew
± 40°
1D decode symbologies
EAN-8
EAN-13
UPC-E
UPC-A
Code 128
UCC/EAN 128 I2Of5
ITF14
ITF6
Matrix 25
CodaBar Code 39
Code 93
ISSN ISBN
Industrial 25
Standard 25
2D decode symbologies Plessey Code 11
MSI Plessey UCC/EAN
Composite GS1
Databar
China Post 25
Code 49
Code 16K
PDF417
QR Code Micro
QR Data
Matrix Aztec
Maxicode
Chinese Sensible Code
GM Code MicroPDF417
Code One
QuickSpecs
HP Engage One Prime Barcode Scanner
Technical Specifications
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 4
Postal decode symbologies
USPS Postnet
Royal Mail KIX Post
Austrailian Postal
Mechanical
Dimensions (L x W x H) 145 x 101 x 68 mm (5.7 x 3.97 x 2.7 in)
Weight
115 g (4.1 oz)
Cable length 1.8 m (6.5 ft)
Color
Black
Interface/Connection
Interface
USB
Temperature
Operating
-4 to 140 °F (-20 to 60 °C)
Storage/transport
-40 to 158 °F (-40 to 70 °C)
Humidity (non-condensing) 5 ~ 95%
Power
Standby Current
58.6mA
Operating
165.8mA (typical), 170.2mA (max)
Drivers
Windows UBB HID-KB and OPOS & JPOS (via USB-COM mode drivers)
Environmental
Operating Temperature
-20°C to 60°C (-4°F to 140°F)
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Humidity
5% ~ 95% (non-condensing)
ESD
±8 KV (direct discharge); ±15 KV (air discharge)
Drop
1.2m
Sealing
IP42
QuickSpecs
HP Engage One Prime Barcode Scanner
Technical Specifications
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 5
Operating System Compatible with:
Windows 10 (32-bit)
Windows 10 (64-bit)
Windows 10 IoT (32-bit)
Windows 10 IoT (64-bit)
Windows 8.1 Professional (32-bit)
Windows 8.1 Professional (64-bit)
Windows Embedded 8.1
Windows 7 Business (64-bit)
Windows Embedded POS Ready 7 (64-bit)
Windows Embedded POS Ready 2009
Agency Certifications
FCC Part15, Class B, CE EMC Class B, IEC62471, RoHS
Option Kit Contents
HP Engage One Prime Barcode Scanner, Scanner Stand, USB Cable.
QuickSpecs
HP Engage One Prime Barcode Scanner
Summary of Changes
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 6
Date of change:
Version History:
Description of change:
From v1 to v2
Warranty updated
May 13, 2020
From v2 to v3
Specs updated
March 9, 2021
From v3 to v4
Environmental section
QuickSpecs
HP Engage One Prime Barcode Scanner
c06207719 — 16394 Worldwide — Version 4 — March 9, 2021
Page 7
© Copyright 2021 HP Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
