Datasheet
HP Healthcare Edition HC271 Clinical
Review Monitor
A clinician companion for consistent images and clean workspaces.
Deploy a display optimized for patient
rooms, nurses stations, medical carts, and
public areas with the HP Healthcare Edition
HC271. It’s built for easy, repeatable
sanitization after every patient
engagement and is DICOM Part 14
compliant for accurate viewing of medical
images.
Promote patient safety
Be ready for the next patient or user with a display and optional stand that are sanitizable with germicidal wipes. The display is IEC 60601-1-2: 2014 compliant for use
near patients and staff and the front is IP 32 rated against water ingress.
Out-of-the box image accuracy
Help ensure accurate, consistent image viewing between healthcare professionals and for patient consultations and image verification with a DICOM Part 14 compliant
display. View up to 60% more content at one time on the Quad HD 27” diagonal screen.
Create an efficient workspace for high-traffic areas
Attach select HP PCs behind the display for a compact, integrated solution that’s perfect for busy and shared spaces like nurses or charting stations. Mount on a medical
cart, wall or arm with the VESA pattern.
Featuring
Connect PCs and specialty devices with HDMI, DisplayPort™, VGA, and USB ports.
Get the reassurance of a display that’s built for a long life, rigorously tested, and backed by the stringent HP Zero Bright Dot Guarantee.
Work comfortably with adjustable tilt, height, and swivel settings on the optional, sanitizable stand.
Rest assured that your IT investment is supported by a three-year standard limited warranty, and optional HP Care service.
1
2
3 1 2
4
2 5
6 6
Page 2
Data sheet | HP Healthcare Edition HC271 Clinical Review Monitor
HP Healthcare Edition HC271 Clinical Review Monitor Specifications Table
Display type
AHVA with LED backlight
Display size (diagonal)
68.47 cm (27")
Viewing angle
178° horizontal; 178° vertical
Brightness
350 cd/m²
Contrast ratio
1000:1 static
Response Ratio
12 ms gray to gray
Product colour
White
Aspect ratio
16:9
Native resolution
QHD (2560 x 1440 @ 60 Hz)
Resolutions supported
1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 768; 1280 x 800; 1280 x 960; 1366 x 768; 1440 x 900; 1600 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 2560 x
1440; 640 x 480; 720 x 480; 800 x 600
Display features
Anti-glare; Language selection; On-screen controls; Plug and Play; User programmable
User controls
Brightness; Color control; Contrast; Image control; Information; Management; Menu; OK; Power; Power control; Input control; Menu control; Sanitization
Input signal
1 DisplayPort™ 1.2 (with HDCP support); 1 HDMI 1.4 (with HDCP support); 1 VGA
Ports and Connectors
3 USB 2.0 (2 downstream, 1 upstream)
Environmental
Operating temperature: 5 to 35°C
Operating humidity: 20 to 80% non-condensing
Power
Input voltage 100 to 240 VAC
Power consumption
55 W (maximum), 45 W (typical), 0.5 W (standby)
Dimensions
64.4 x 5.1 x 39.3 cm
Weight
5 kg
Physical security features
Security lock-ready
Certification and compliance
CB; CCC; CSA; DICOM Part14; FCC; Microsoft WHQL Certification (Windows 10); WEEE; IEC 60950; China Energy Label (CEL) Grade 3; IEC 60601-1-2; EN 60601-1-2;
IP32 (front)
Environmental specifications
Arsenic-free display glass; Low halogen; Mercury-free display backlights
What's in the box
AC power cord; DisplayPort™ cable; Documentation; HDMI cable; USB cable; VGA cable
1,4
1
1
1
3
2
Page 3
Data sheet | HP Healthcare Edition HC271 Clinical Review Monitor
HP Healthcare Edition HC271 Clinical Review Monitor
Accessories and services (not included)
HP Business PC Security Lock v3 Kit
Help prevent chassis tampering and secure your PC and display in workspaces and public
areas with the affordable HP Business PC Security Lock v3 Kit.
Product number: 3XJ17AA
HP HC271 Stand
Deploy your HP Healthcare Edition HC271 Clinical Review Monitor in a range of settings with
the white HP HC271 Stand that’s sanitizable with germicidal wipes to promote patient safety.
Find your most comfortable view with adjustable height, tilt, and swivel settings and portrait
mode.
Product number: 4BX34AA
HP Single Monitor Arm
The HP Single Monitor Arm is the perfect desk accessory for your work life. Sleek and
streamlined, the HP Single Monitor Arm is designed to complement the way you work.
Product number: BT861AA
HP PC Mounting Bracket for
Monitors
Customize an altogether better solution with the HP PC Mounting Bracket for Monitors, which
lets you attach your HP Desktop Mini, HP Chromebox, or select HP Thin Client directly behind
select HP Z Displays and EliteDisplays. Customize an altogether better solution with the HP PC
Mounting Bracket for Monitors, which lets you attach your HP Desktop Mini, HP Chromebox, or
select HP Thin Client directly behind select HP Z Displays and EliteDisplays.
Product number: N6N00AA
HP LCD Speaker Bar
Attach seamlessly to the front bezel of your monitor to add full multimedia support features,
including stereo speakers with full sound range and an external jack for headphones. Attach
seamlessly to the front bezel of your monitor to add full multimedia support features,
including stereo speakers with full sound range and an external jack for headphones.
Product number: NQ576AA
HP 3 year Next business day Onsite
Standard Monitor Hardware Support
Receive 3 years of next business day onsite HW Support from an HP-qualified technician for
your computing device, if the issue cannot be solved remotely.
Product number: UD950E
1
Page 4
Data sheet | HP Healthcare Edition HC271 Clinical Review Monitor
HP Healthcare Edition HC271 Clinical Review Monitor
Messaging Footnotes
See user guide for cleaning instructions.
The HP Healthcare Edition HC271 is a general-purpose computing device and is not intended for use in the diagnosis, cure, treatment or prevention of disease or other medical conditions.
HP HC271 Stand Kit sold separately.
IP 32 test results are not a guarantee of future performance under these test conditions. Damage under the test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack. See user guide for
cleaning instructions.
Compared to a WUXGA display.
Optional HC271 Stand Kit and HP PC Mounting Bracket for Monitors required to attach HP Desktop Mini, HP Elite Slice, HP Z2 Mini Workstation or HP Thin Client. Accessories and PCs sold separately. See Bracket QuickSpecs for exact
compatibility. VESA mounting hardware for wall or arm mounting sold separately. Arm sold separately.
The HP Pixel Policy allows no bright sub-pixel defects for this display. For complete details, see http://support.hp.com/us-en/document/c00288895.
HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
www.hp.com/go/cpc. HP Services are governed by the applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws,
and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.
Technical Specifications Footnotes
All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.
Lock is sold separately.
350 cd/m² with Anti-glare cover glass.
Sign up for updates hp.com/go/getupdated
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries. USB Type-C™ is a trademark of USB
Implementers Forum.
