HP 2 SP4 User Manual

application notes
hp OpenView
using storage area manager on the storage
management appliance
Product Versions: 2.0 SP4; 2.1
Second Edition (October 2003)
Part Number: AA-RTEDB-TE
This document describes how to use HP OpenView Storage Area Manager versions 3.0 or 3.1 with the Storage Management Appliance hardware and software (v2.0 SP4 or v2.1). It also includes installation and configuration information expressly for HP and other certified service professionals.
Additional information and other HP OpenView documentation are available at:
http://h18006.www1.hp.com/storage/software.html
.
© Copyright 2003 Hewlett-Packard Development Company, L.P. Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard. The information contained in this document is subject to change without notice.
Compaq Computer Corporation is a wholly-owned subsidiary of Hewlett-Packard Company. Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in the U.S. and/or other countries. Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The information is provided
“as is” without warranty of any kind and is subject to change without notice. The warranties for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products. Nothing herein should be construed as constituting an additional warranty.
Printed in the U.S.A.
Using Storage Area Manager on the Storage Management Appliance Application Notes Second Edition (October 2003) Part Number: AA-RTEDB-TE
2 Using Storage Area Manager on the Storage Management Appliance Application Notes

About this Document

These Application Notes provide information about using HP OpenView Storage Area Manager software on the HP OpenView Storage Management Appliance (SMA). The purpose of this document is to provide supplemental information that is not available in either the Storage Area Manager or SMA documentation sets. It does not describe all aspects of installation and configuration for either product. Therefore, it is important that you have access to and be familiar with the respective product documentation sets in combination with these Application Notes.
This section contains general information about these Application Notes, including:
Application Notes Contents
Intended Audience
Other Related Documentation

Application Notes Contents

These Application Notes cover the following major topics:
Overview, page 5
Storage Area Manager and SMA Implementation, page 7
Installing and Uninstalling Storage Area Manager on the SMA, page 12
SMA Configuration Guidelines, page 20
About this Document

Intended Audience

The first two sections of this document, “Overview” and “Storage Area Manager and SMA
Implementation,” are primarily intended for customers who want to use the SMA as the server
platform for the Storage Area Manager software. The remaining sections, on installation and configuration, contain instructions that are needed
by HP service personnel and third-party partners who are certified to install Storage Area Manager on customer systems.
Note: Storage Area Manager must be installed and configured on customer systems by HP or other
certified service professionals. Customer installation is not supported.

Other Related Documentation

To follow these Application Notes, you should also have the following documents from the Storage Management Appliance software v2.0 or v2.1 documentation sets:
HP OpenView Storage Management Appliance Software Update Installation Card
HP OpenView Storage Management Appliance Software User Guide
HP OpenView Storage Management Appliance Software Release Notes
HP OpenView Storage Management Appliance Software Online Help
3Using Storage Area Manager on the Storage Management Appliance Application Notes
About this Document
If you are using Storage Management Appliance software v2.0, you should also have the following documents:
HP OpenView Storage Management Appliance Software v2.0 Service Pack 4 Read Me
First
HP OpenView Storage Management Appliance Software v2.0 Service Pack 4 Installation
Instructions
You should also have the following documents from the Storage Area Manager documentation set:
HP OpenView Storage Area Manager Installation Guide
HP OpenView Storage Area Manager Administrator’s Guide
HP OpenView Storage Area Manager Release Notes
HP OpenView Storage Area Manager Online Help
The following are optional documents that are necessary only if you have the devices or software they apply to:
HP StorageWorks HSV Controller Device Plug-In Installation Instructions
HP StorageWorks Modular Data Router Device Plug-In Installation Instructions
HP StorageWorks MSA1000 and RA4100 Controller Device Plug-In Installation
Instructions
HP SANworks Network View Version 2.0 Installation Guide
The lists above contain only a portion of all the documentation available for the two products. The cited documents and other SMA documentation, such as white papers and specification documents, are available on the SMA website at:
http://h18006.www1.hp.com/products/sanworks/managementappliance/documentation.html
.
Storage Area Manager documentation is available on the SAM website at:
http://h18006.www1.hp.com/p roducts/storage/software/sam/index.html
and the eCare website at:
http://support.openview.hp.com
.
4 Using Storage Area Manager on the Storage Management Appliance Application Notes

Overview

It is now possible to employ the powerful storage management features of HP OpenView Storage Area Manager on the HP OpenView Storage Management Appliance. These two products provide diverse management capabilities for your storage area network (SAN).
Storage Management Appliance software v2.0 supports Storage Area Manager v3.0; Storage Management Appliance software v2.1 supports Storage Area Manager v3.0 or v3.1.

HP OpenView Storage Area Manager

HP OpenView Storage Area Manager is a client/server software suite that provides centralized storage monitoring and management capabilities.
The Storage Area Manager environment includes a management server, one or more clients, and one or more SAN hosts. The management server software can be installed on a Windows 2000 server, including now a Storage Management Appliance. The management client is a Windows 2000, Windows XP, HP-UX, Linux, or Sun Solaris host on which the Storage Area Manager user interface is installed. You access and run Storage Area Manager from the management clients. The host agent software is installed on each SAN host to which an interconnect or storage device is connected. The host agent enables communication between the server and the storage devices. Host agent software can be installed on Windows NT, Windows 2000, HP-UX, Tru64 UNIX, IBM AIX, Sun Solaris, and Linux hosts. In addition, Storage Area Manager v3.1 host agents are available for Windows 2003, Open VMS, and Netware.
Overview
The Storage Area Manager software suite consists of five applications that provide storage resource and infrastructure management:
HP OpenView Storage Node Manager for device management
HP OpenView Storage Builder for capacity management
HP OpenView Storage Optimizer for performance management
HP OpenView Storage Accountant for metering and billing
HP OpenView Storage Allocater for access control and storage allocation
More information on Storage Area Manager is available on the SAM website at:
http://h18006.www1.hp.com/products/storage/software/sam/inde x.html
and the eCare website at:
http://support.openview.hp.com
.

HP OpenView Storage Management Appliance

The HP OpenView Storage Management Appliance is a centralized, appliance-based monitoring and management solution for the SAN. You can access the SMA software from anywhere in the SAN through a supported Web browser (Internet Explorer or Netscape). The SMA software lets you organize, configure, and monitor storage components from a single Web-based navigation point. The SMA software also provides a launch site for a variety of core and optional HP storage management applications, including:
Command View EVA (previously named HSV Element Manager) for managing and
configuring RAID array systems that are based on HSV controllers
HSG Element Manager for managing and configuring RAID array systems that are based
on HSG controllers
5Using Storage Area Manager on the Storage Management Appliance Application Notes
Overview
Enterprise Volume Manager or Business Copy EVA for managing controller-based clone
and snapshot operations
Continuous Access EVA for real-time replication between HP StorageWorks enterprise
virtual arrays
Secure Path Manager for protecting and managing paths between hosts and storage
systems
Storage Provisioner for automated provisioning and monitoring of storage usage
Proactive Remote Service for automatically notifying HP Customer Support in the event
of component failure or expected component failure
In addition, the Storage Management Appliance supports a large number of industry-standard applications from HP and third-party vendors, which can optionally be installed on the SMA. These include products in the following software categories:
Backup and Restore
Antivirus Protection
Uninterruptible Power Supply
System Management
For more information about these qualified products, refer to the appropriate documents at:
http://h18006.www1.hp.com/products/sanworks/managementappliance/documentation.html
.

Network View and Storage Allocation Reporter Transition

Network View and Storage Allocation Reporter (SAR) are two value-added applications that run on the SMA. HP is transitioning its SAR and Network View customers to the Storage Area Manager suite. Table 1 lists HP SANworks software products and their equivalent HP OpenView software products.
Table 1: HP SANworks Applications and HP OpenView Replacement Applications
HP SANworks
Storage Allocation Reporter (SAR) Storage Accountant Network View Storage Node Manager and
Note: Prior to the Storage Area Manager installation process, Network View and Storage
Allocation Reporter, if present, must be uninstalled so that you can begin using the Storage Area Manager applications.
HP OpenView
Storage Optimizer
6 Using Storage Area Manager on the Storage Management Appliance Application Notes

Storage Area Manager and SMA Implementation

Storage Area Manager and SMA Implementation
The Storage Area Manager and Storage Management Appliance solution is delivered by Storage Area Manager Implementation Service professionals, who install and configure the software suite on the SMA. The service provides for trained, experienced, HP-certified professionals to conduct the planning, implementation, verification, and demonstration of Storage Area Manager within your SAN environment. This ensures that the software is set up and configured correctly so you can start managing your storage efficiently in the shortest possible time.
This section discusses special considerations for running Storage Area Manager on the SMA, including:
Hardware and Software Requirements, page 7
Accessing Storage Area Manager, page 8
Event Notification, page 9
Licensing, page 9
Security, page 10
Databases, page 10
Discovery, page 10
Performance Considerations, page 10
Compatibility Between Storage Area Manager and SMA Components, page 10
Storage Management Appliance software v2.0 supports Storage Area Manager v3.0; Storage Management Appliance software v2.1 supports Storage Area Manager v3.0 or v3.1. This document clearly identifies the configuration procedures required for each version.

Hardware and Software Requirements

To successfully install and run Storage Area Manager on the SMA, you need the following:
Storage Management Appliance II, with an additional 1 GB of memory or
Storage Management Appliance III
Storage Area Manager v3.0 (v03.00.03.0021 or later) or v3.1
Storage Management Appliance software v2.0, with Service Pack 4 or
Storage Management Appliance software v2.1 See “Installation Prerequisites” on page 12 for additional requirements. When installing Storage Area Manager on an SMA, the maximum recommended
configuration is 50 hosts and 10,000 host-LUNs.
Note: The first generation Storage Management Appliance (previously called SANworks
Management Appliance) cannot be upgraded to run Storage Area Manager. Storage Area Manager installation can be performed only on a Storage Management Appliance II or later.
7Using Storage Area Manager on the Storage Management Appliance Application Notes
Storage Area Manager and SMA Implementation

Connecting to the SMA

After Storage Area Manager is installed on the SMA, you can connect to the SMA, either by using Terminal Services from a remote system, or by attaching a monitor, keyboard, and mouse directly to the SMA. This might be necessary when you need to access the Storage Area Manager management server; for example, to perform troubleshooting activities or to install required patches and device plug-ins (DPIs).
Terminal Services is a Microsoft communications program that is enabled on the Storage Management Appliance so that you can gain access to it. You should also install Microsoft Terminal Services client on your workstation. See the Microsoft website,
http://www.microso ft.com/window s2000/technologies/terminal
installing and using the Terminal Services client.

Accessing Storage Area Manager

After Storage Area Manager is installed on the SMA, and clients and hosts are configured, you access and use Storage Area Manager in the usual way by connecting to the server from a client. In this way, you have access to all Storage Area Manager functionality. Although you cannot use the SMA software to start Storage Area Manager, the SMA interface provides access to some Storage Area Manager features, described below.
When Storage Area Manager is installed, an application icon and description appear on the SMA Tool s page, as shown in Figure 1.
, for more information on

Figure 1: Storage Management Appliance Tools page

Clicking the Storage Area Manager icon connects you to the Storage Area Manager GUI downloads page. The GUI downloads page is a feature of Storage Area Manager that lets you
download client and Manager of Managers software, as well as specify authentication information.
8 Using Storage Area Manager on the Storage Management Appliance Application Notes
