HP 23-b025ef User Manual [fr]

12” (30cm)

http://www.hp.com/go/contactHP

http://welcome.hp.com/country/us/en/wwcontact_us.html

The only warranties for Hewlett-Packard products and services are set forth in the express statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

HP assumes no responsibility for the use or reliability of its software on equipment that is not furnished by HP.

This document contains proprietary information that is protected by copyright. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of HP.

Hewlett-Packard Company

P.O. Box 4010

Cupertino, CA 95015-4010

USA

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and other countries.

HP supports lawful use of technology and does not endorse or encourage the use of our products for purposes other than those permitted by copyright law.

The information in this document is subject to change without notice.

Warranty Print on Demand Statement

You can find the expressly provided HP Limited Warranty applicable to your product in the start menu on your PC and/or in the CD/DVD provided in the box. For some countries/regions, a printed HP Limited Warranty is provided in the box. In countries/regions where the warranty is not provided in printed format, you may request a printed copy from

hp.com/go/orderdocuments or write to HP at: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, U.S.A.; Hewlett Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507. Please include your product name, warranty period, name, and postal address.

1 Getting information

Type of information Where to find

Set up your computer. Quick Setup (this Guide)

●

Use the computer.

●

Connect to the Internet.

●

Recover factory settings. Troubleshooting and Maintenance Guide on your computer. At the bottom

●

See how-to videos about using

●

the features of your computer.

Learn how to use the Microsoft

●

Windows 7 operating system.

Find Windows 7 password

●

information.

Find links to driver updates.

●

Read frequently asked

●

questions.

Troubleshoot the most common

●

computer hardware and software issues.

Find electronic user guides

●

and specifications for your computer model.

Order parts and find

●

additional troubleshooting help.

Quick Setup (this Guide)

of your screen, click on Start, then click HP Help and Support and HP User Manuals.

http://www.hp.com/supportvideos (English only)

Visit

Help and Support

Click Start, and then click Help and Support or visit http://www.hp.com/go/win7.

Windows 7 troubleshooting tools

1. Click Start, click Control Panel, and then click System and Security.

2. Under Action Center, click Find and fix problems (troubleshooting).

Troubleshooting and Maintenance Guide on your computer. At the bottom of your screen, click on Start, then click HP Help and Support and HP User Manuals.

HP Support website:

http://www.hp.com/go/contactHP

Upgrade or replace

●

components of your computer.

Upgrading and Servicing Guide

HP Support website:

http://www.hp.com/go/contactHP

Type of information Where to find

Find computer warranty

●

information.

Get technical support.

●

Get up-to-date information and

●

help from the Windows community.

Connect to a TV. Watching and Recording TV

●

Get special utilities for

●

computer owners.

Maintain your computer. HP Support Assistant — Maintains your computer performance and resolve

●

Limited Warranty and Support Guide or the Warranty and Support Information included with your computer.

Click Start, click All Programs, and then click HP User Manuals.

http://www.hp.com/support/consumer-forum

Click Start, click All Programs, and then click HP User Manuals.

If the guide is not available there, visit

PC Help & Tools folder

Click Start, click All Programs, and then click PC Help & Tools.

problems faster by using automated updates, on-board diagnostics, and guided assistance.

Click Start, click All Programs, click HP, and then click HP Support Assistant.

Troubleshooting and Maintenance Guide

Click Start, click HP Help and Support, and then click HP User Manuals.

Maintaining Your Computer (this Guide)

http://www.hp.com/go/contactHP

Find safety and regulatory

●

notices.

Find ergonomic information. Safety & Comfort Guide

●

Safety & Regulatory Information

Click Start, click HP Help and Support, and then click HP User Manuals or visit

2 Chapter 1 Getting information

http://www.hp.com/go/contactHP.

http://www.hp.com/ergo.

2 Setting up your computer

WARNING! To reduce the risk of electrical shock or damage to your

equipment:

• Place the computer in a location away from water, dust, moisture, and soot. These can increase the inside temperature, or can cause fire or electrocution.

• Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

• Plug the power cord in a grounded (earthed) outlet that is easily accessible at all times.

• Disconnect power from the equipment by unplugging the power cord from the electrical outlet. To prevent direct exposure to laser beam, do not try to open the enclosure of the CD or DVD drives.

• The power supply is preset for the country/region in which you purchased your computer. If you move, check the voltage requirements for your new location before plugging the computer into an AC power outlet.

The computer may be heavy; be sure to use ergonomically correct lifting procedures when moving the computer.

To reduce the risk of serious injury read the Safety & Comfort Guide. The guide is located on the web at

1. Place the computer so that all ventilation openings are unobstructed and cabling is not in a walkway or where it can be stepped on or damaged by placing furniture on it.

2. Connect all power cords from the monitor, computer, and accessories to a power surge protection device that is specifically labeled as having surge protection, an uninterruptible power supply (UPS), or a similar device. If the computer has a television tuner, or a modem or telephone connection, protect the computer by using surge protection with these signal inputs as well. Connect the television cable or the telephone line cord to the surge protection device, and then connect the device to the computer.

3. Download and install operating system updates. a. Find out what operating system and version your computer is currently

running. (Click Start > Control Panel and double-click System. The operating

system and version are shown under Windows edition.)

b. Open your internet browser and go to

contactHP.

c. Select your country and language, if necessary, and click Support &

Drivers.

http://www.hp.com/ergo.

http://www.hp.com/go/

d. Select Download drivers and software (and firmware), type

your computer model name and number in the product field, and press Enter.

e. If necessary, select your computer model from Product search

results. f. Select your computer operating system. g. Click Download next to each update you wish to download. h. Follow the on-screen instructions to install each downloaded update.

4. Look in the computer box for additional printed details or updates.

5. Read the Safety and Regulatory Information document in the HP User Manuals

folder.

6. Read the Safety & Comfort Guide for proper workstation setup, posture, health and work habits, and electrical and mechanical safety information. Click Start, click All Programs, and then click HP User Manuals or visit http://www.hp.com/ergo.

After you complete the initial computer setup, you might want to install additional software programs or hardware devices. Check the operating system, memory, and other requirements listed before purchasing new software or hardware for your computer. Follow the software manufacturer's directions to install the new software.

NOTE: Use only licensed original software. Installing copied software could result in an unstable installation, infect the computer with a virus, or be illegal.

Security solutions can deter theft, mishandling, and software attacks, but cannot prevent them.

Connecting to the Internet

Steps to connect to the Internet:

1. Connect the hardware as shown on the setup view.

2. Get Internet service.

●

account with an ISP, skip this step and follow the instructions provided by the ISP.

If you did not set up the computer for Internet service during the initial

●

setup, do so now by using Online Services: a. Click Start, click All Programs, click Online Services, and

then click Get Online.

b. Follow the on-screen instructions to select an ISP and set up Internet

service.

4 Chapter 2 Setting up your computer

NOTE: Online Services provides a list of ISPs; however, you might choose another ISP or transfer an existing account to this computer. To transfer existing accounts, follow the instructions provided by the ISP.

3. Using your Internet connection through your ISP, open a web browser and browse the Internet.

NOTE: If you have issues connecting to the Internet, see Internet access on page 14.

Connecting to the Internet

3 Setting up additional features

Using Beats Audio™ (select models only)

Your HP TouchSmart PC features audio connectors (headphone and Audio Out ) that are optimized for Beats Audio™ headphones and external audio systems (purchased separately). Select HP TouchSmart PC models also include four Beatsoptimized internal speakers and a Beats toggle button

Your computer comes ready for you to experience music with Beats enabled. To disable Beats, press the Beats toggle button; the Beats-off icon appears on the screen. To turn Beats on, press the Beats toggle button again. If your keyboard does not contain the Beats toggle button, press Fn+B to enable and disable Beats. Tap the Beats icon on the system tray to view the Beats user interface.

All you need to do is plug the Beats Audio headphones into the side headphone connector to experience crisp and clear sound separation. To experience the full capability of BEATS audio using the internal speakers, HP recommends connecting a matching HP subwoofer to the Sub connector on the back panel. If you are using an external audio system, plug it into the Audio Out connector on the back panel.

Using the HDMI port controls (select models only)

The right side of your computer may contain an HDMI port and volume control buttons. Unless a device is plugged into the HDMI port, the volume controls have no functionality. The HDMI controls are only intended to control the settings of the device plugged into that port, and do not control any other media devices on the system.

To use the HDMI port controls, plug a device into the HDMI port. Press the menu button (the top button displayed). A new on-screen menu displays. Using the +/buttons, select brightness, volume, contrast, or color balance.

on the keyboard.

When a device is plugged into the HDMI port, the volume on the computer is muted. Pressing the +/- buttons on the side panel does not change the volume of the computer.

6 Chapter 3 Setting up additional features

4 Maintaining your computer

Cleaning procedures

Keeping your computer system free of dust, dirt, and heat will prolong its life.

Dust, pet hair, and other particles can build up, creating a blanket effect; as a result, components can

●

overheat or, in the case of the keyboard and mouse, not work smoothly and effectively.

Check your system once a month for visible signs of dust and debris, and clean it about once every three

●

months.

www.hp.com/go/contactHP for additional cleaning instructions.

Visit

●

Cleaning the computer vents

Air vents keep the computer cool. Keep these vents clean by using a small, batterypowered vacuum cleaner. (A battery-powered vacuum cleaner eliminates the risk of electric shock.)

1. Vacuum the vents on the computer case.

2. Remove any debris that has accumulated in and around the computer

connectors (for example, the Ethernet and USB connectors).

Cleaning procedures

Cleaning the keyboard and mouse

When cleaning the keyboard keys, use a low setting on a battery-powered vacuum cleaner, to avoid removing key caps and springs.

1. Vacuum between the keys of the keyboard and along the grooves.

2. Use a clean, dry cloth and isopropyl (rubbing) alcohol to clean buildup on the

keyboard keys and along its edges.

3. Wipe the body of the mouse and the mouse cord by using cleaning wipes.

If you have a roller-ball mouse, clean the ball and rollers inside:

1. Turn the mouse upside down, and rotate the ball-cover ring counterclockwise to remove the ring and release the roller ball.

2. Rinse the roller ball with soap and warm water.

3. Clean the rollers inside the mouse with a cotton swab dampened with

isopropyl (rubbing) alcohol.

4. After the roller ball and rollers are completely dry, replace the ball and ballcover ring.

Cleaning the touch screen (AiO models only)

Follow these steps to clean the touch screen:

1. Turn off the computer. Tap the Start button, and then tap Shut Down.

2. Disconnect the power cord from the wall.

3. Spray a small amount of mild glass cleaner on a soft cloth to clean the touch

screen.

4. Wipe the surface and left and right side of the touch screen to remove any dirt, fingerprints, or other debris that could hinder the touch recognition of the screen.

CAUTION:

cleaner into the cloth, and then wipe the sides and surface of the touch screen.

Do not use an abrasive cleaner or cloth when cleaning the sides or the surface of the screen, because this could cause damage to the touch screen.

Do not spray or place the cleaner directly on the screen; spray the

8 Chapter 4 Maintaining your computer

5 Troubleshooting

Refer to the documentation provided by the product manufacturer for information about peripheral-specific problems, such as issues with a monitor or a printer. The following tables present some issues you might encounter while installing, starting up, or using your computer and possible solutions.

For more information or for additional troubleshooting options, see information on page 1.

Computer does not start

Symptom Possible solution

Getting

Error message: Hard disk drive error.

Computer will not turn on or start.

Restart the computer.

1. Press the Ctrl+Alt+Delete keys on the keyboard simultaneously.

2. Click the Arrow button next to the red Shut Down button, and then click Restart.

Or, press and hold the Power button on the computer for 5 or more seconds to turn off the computer, and then press the Power button to restart the computer.

3. If Windows opens, immediately back up all important data to a backup hard disk drive.

4. Contact Support, whether it was possible or not to start up Windows.

Either the hard disk drive or the system board may need to be replaced.

Ensure that the cables connecting the computer to the external power source are plugged in properly. When the cables connecting the computer to the external power source are plugged in properly, and the wall outlet is functioning, the green power supply light on the back of the computer should be on; if it is not, contact Support.

Test the wall outlet by connecting a different electrical device to it.

Computer does not start

Symptom Possible solution

Computer seems to be locked up and is not responding.

Error message: Invalid system disk or NonSystem disk or Disk error.

Use the Windows Task Manager to close any programs not responding, or restart the computer:

1. Press the Ctrl+Alt+Delete keys on the keyboard simultaneously.

2. Click Start Task Manager.

3. Select the program that is not responding, and then click End Task.

If closing programs does not work, restart the computer:

1. Press the Ctrl+Alt+Delete keys on the keyboard simultaneously.

2. Click the Arrow button next to the red Shut Down button, and then click Restart.

Or, press and hold the Power button on the computer for 5 or more seconds to turn off the computer, and then press the Power button to restart the computer.

When drive activity stops, remove the disc and press the spacebar on the keyboard. The computer should start up.

10 Chapter 5 Troubleshooting

Power

Symptom Possible solution

Computer does not turn off when the Power button is pressed.

Computer shuts down automatically.

Press and hold the Power button until the computer turns off. Check Power Settings.

The computer might be in an exceedingly hot environment. Let it cool down.

●

Ensure that computer air vents are not blocked and that the internal fan is running — see :

●

Cleaning procedures on page 7. (Your computer might not have an internal fan.)

Display (monitor)

Symptom Possible solution

Screen is blank. Press the space bar on the keyboard or move the mouse to make the screen display visible

again.

Press the Sleep button (select models only), or Esc on the keyboard, to resume from Sleep mode.

Press the Power button to turn on the computer.

Power

Keyboard and mouse (general)

Symptom Possible solution

Keyboard commands and typing are not recognized by the computer.

Mouse (with cable) does not work or is not detected.

Cursor does not move using the arrow keys on the number keypad.

Cursor does not respond to mouse movement.

Use the mouse to turn off the computer, unplug and reconnect the keyboard to the back of your computer, and then restart your computer.

Unplug and reconnect the mouse cable to your computer.

If the mouse is still not detected, turn off the computer, unplug and reconnect the mouse cable, and then restart the computer.

Press Num Lock on the keyboard to turn off Num Lock, so that the arrow keys on the number keypad can be used.

Use the keyboard to save changes in all open programs, and then restart your computer:

1. Press the Alt+Tab keys simultaneously to navigate to an open program.

2. Press Ctrl+S simultaneously to save your changes in the selected program (Ctrl+S is

the keyboard shortcut for Save on most—not all—programs).

3. Repeat step 1 and step 2 to save changes in all open programs.

4. After saving changes in all open programs, press the Ctrl+Esc keys on the keyboard

simultaneously to display the Windows Start menu.

5. Use the arrow keys to select the Arrow button that is next to Shut Down. Select Shut Down, and then press Enter.

6. After the shutdown is complete, unplug and reconnect the mouse connector to the

back of your computer, and then restart your computer.

12 Chapter 5 Troubleshooting

+ 36 hidden pages
