Page 1
Datasheet
HP Z24n G2 60.96 cm (24”) Display
Color consistency and performance for the project perfectionist
Be a productive powerhouse with
the sleek WUXGA HP Z24n G2
60.96 cm (24”) Display. This
virtually seamless display is
factory-tested for reliability and
longevity with integrated color
calibration, uninterrupted
multi-screen1tiling, and expansive
device connections, including
USB-C™.
Multi-screen productivitywith nodisruptions
Streamline multi-tasking on multiple displays1with a 3-sided micro-edge bezel, and daisy chain up to 3 displays
●
per workstation with DisplayPort™. Get stunning visuals from 1920 x 1200 resolution2, 16:10 aspect ratio, and
over 3 million pixels.
Out-of-this-world color rightout of the box
Consistent, accurate color between displays and from project to project is easier than ever with factory color
●
calibration from the very first time you power on.
Quality from the start
We rigorously test each HP Z Display to help ensure it’s a reliable, long-life visual solution, and back it up with the
●
HP Zero Bright Dot Guarantee3, HP’s most stringent pixel policy, which replaces the screen if even one bright
sub-pixel fails.
Future-ready connectivity
Keep it clean with a single USB-C™ cable video and data connection that’s ready for future generations of HP
●
Workstations. VGA, HDMI, and DisplayPort™ are multi-generation compatible, and a three-port USB 3.0 hub
supports convenient device connectivity.
Featuring
Make the most of your available workspace by mounting powerful machines like the HP Z2 Mini Workstation
●
directly behind the display for a compact, efficient, single-footprint solution.
Work comfortably with customizable tilt, swivel and up to 150 mm height adjustment. Simplify your workflow
●
with automatic content rotation between portrait and landscape modes.
Design the screen for how you work with HP Display Assistant software, which enables screen partitioning and
●
helps deter theft by dimming a display that’s disconnected without approval.
Reduce power consumption and help lower costs with an intelligent, energy-efficient, low-halogen display that is
●
ENERGY STAR® certified, TCO qualified, and EPEAT® Gold registered with mercury-free display backlights and
arsenic-free display glass.
Build a complete solution with optional HP accessories designed and tested to work with your display.
●
4
5
6
7,8
9
Page 2
Datasheet
HP Z24n G2 60.96 cm (24”) Display
Specifications Table
Product Number 1JS09A4; 1JS09AT
Product Color Black
Display size (diagonal) 60.96 cm (24”)
Display Type IPS w/LED backlight
Panel Active Area 51.84 x 32.4 cm;
Viewing Angle 178° horizontal; 178° vertical
Brightness 300 cd/m²
Contrast Ratio 1000:1 static; 10000000:1 dynamic
Response Ratio 5 ms gray to gray
Aspect Ratio 16:10
Native Resolution WUXGA (1920 x 1200 @ 60 Hz)
Resolutions Supported 1920 x 1200; 1920 x 1080; 1680 x 1050; 1600 x 900; 1440 x 900; 1280 x 1024; 1280 x 800; 1280 x 720; 1024 x 768; 800 x 600; 720 x 480; 640 x
Display Features Anti-glare; In plane switching; Language selection; LED Backlights; On-screen controls; Pivot rotation; Plug and Play; User programmable; Low Haze
User Controls Brightness; Contrast; Color Control; Input Control; Image Control; Power; Menu; Management; Language; Information; Exit; OK
Input signal 1 DVI-D; 1 HDMI 1.4; 1 DisplayPort™ 1.2
Ports and Connectors 1 analog audio output; 3 USB 3.0 (downstream); 1 USB 3.1 Type-C™ (side, downstream, power delivery up to 10 W); 1 USB 3.1 Type-C™ (rear,
Input power Input voltage: 100 to 240 VAC
Power consumption Panel Active Area: 51.84 x 32.4 cm; On-mode power consumption: 36 W; Annual energy consumption: 53 kWh; Power consumption (standby): 0.5
Dimensions with Stand (W x
D x H)
Dimensions without Stand
(W x D x H)
Weight 7.2 kg (With stand)
Ergonomic features Tilt: -5 to +22°; Swivel: ±45°; Pivot rotation: 90°; Height: 150 mm
Certification and Compliance BSMI; CB; CCC; CE; CEL; cTUVus; CU; ErP; FCC; ICES; ISC; ISO 9241-307; Mexico CoC; Microsoft WHQL Certification (Windows 10 and Windows 7); MSIP;
Environmental Arsenic-free display glass; Mercury-free display backlights; Low halogen
Energy Efficiency
Compliance
What's in the box Monitor; AC power cord; USB Type-C™ to A cable; DisplayPort™ 1.2 cable; CD (includes User Guide, warranty, drivers); HP Display Assistant; VESA
Warranty 5 years Next Business Day Onsite Support. HP support includes HP 3-year limited warranty plus a 5-year HP Onsite Care Pack support, as of date of
480
with HDCP support on DisplayPort™ and HDMI
downstream and upstream, power delivery up to 15 W)
W; Power consumption (off-mode): 0.3 W; Power consumption Description: 92 W (maximum), 40 W (typical), 0.5 W (standby); Screen resolution:
WUXGA (1920 x 1200 @ 60 Hz)
53.2 x 21.4 x 50.3 cm
53.2 x 4.68 x 35.1 cm
RCM; SmartWay Transport Partnership - NA only; VCCI; WEEE
ENERGY STAR® certified; EPEAT® Gold
mount adapter
purchase of the hardware product. Onsite support is offered if the problem cannot be handled over the phone. Delivery of support services outside
of the applicable HP coverage areas may be subject to longer response times.
1
1
1,3
1
2
Page 3
Datasheet
HP Z24n G2 60.96 cm (24”) Display
Accessories and services (not included)
HP B300 PC Mounting
Bracket
HP S100 Speaker Bar
HP Single Monitor Arm
HP Integrated Work
Center for Desktop Mini
and Thin Client
Customize an altogether better solution with the HP B300 PC Mounting Bracket, which lets you attach your HP
Workstation, HP Desktop Mini, HP Chromebox or select HP Thin Client directly behind select 2017 and 2018 HP
EliteDisplays and HP Z Displays.
1
Product number: 2DW53AA
Add rich stereo audio to select 2017 and 2018 HP ProDisplays, HP EliteDisplays, and HP Z Displays1without crowding
your desk with the HP S100 Speaker Bar, which fits neatly underneath the display head and connects through USB.
Product number: 2LC49AA
The HP Single Monitor Arm is the perfect desk accessory for your work life. Sleek and streamlined, the HP Single Monitor
Arm is designed to complement the way you work.
Product number: BT861AA
Make the most of small work spaces with an HP IWC Desktop Mini/Thin Client that lets you create a compact desktop
solution by combining a display1with an HP Desktop Mini, HP Thin Client or HP Chromebox1and giving you convenient
front access to all of its inputs.
Product number: G1V61AA
HP Business PC Security
Lock v2 Kit
Help prevent chassis tampering and secure your PC and display in workspaces and public areas with the HP Business PC
Security Lock v2 Kit.
Product number: N3R93AA
Page 4
Datasheet
HP Z24n G2 60.96 cm (24”) Display
Messaging Footnotes
1
Additional displays required and sold separately.
2
All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
3
The HP Pixel Policy allows no bright sub-pixel defects for this display. For complete details, see http://support.hp.com/us-en/document/c00288895.
5
Workstation sold separately. Requires HP B300 PC Mounting Bracket for Monitors, sold separately.
6
For optimal use, pair with HP Display Assistant and a device running a Windows operating system. See user guide for exact instructions.
7
External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.
8
EPEAT® registered where applicable. EPEAT registration varies by country. See w ww.epeat.net for registration status in your country. Search keyword generator on HP’s 3rd party option store for solar generator
accessories at www.hp.com/go/options.
9
Each sold separately.
Technical specifications disclaimers
1
All specifications represent the typical specifications provided by HP's component manufacturers, actual performance may vary either higher or lower.
2
External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.
3
Product default is 14.0ms response time and can be adjusted to as low as 5.4ms in the display menu. See user guide for more information.
