1 of 6
MATERIAL SAFETY DATA SHEET
11.. PPRROODDUUCCTT // CCOOMMPPAANNYY IIDDEENNTTIIFFIICCAATTIIOONN
PRODUCT IDENTIFICATION
Samsung SDI Lithium-Ion Cell/Battery
Samsung SDI Sterling(Platinum)
SDI P/N : P12P11-02-N01
HP P/N : 459723-001
Issue Date : 06/03/2008
Reference # : SDI20080306-
It
em Nominal Value Remark
Nominal Voltage 3.7V
Nominal Capacity 2220mAh
Lithium Contents 0.666g
MANUFACTURER
Samsung SDI Corporation
508 Sungsung-Dong Cheonan City
Chungchongnam-Do, Korea
Telephone : 82-41-560-3650
Fax : 82-41-560-3697
e-mail : jmin.chung@samsung.com
003
2. CCOOMMPPOOSSIITTIIOONN IINNFFOORRMMAATTIIOONN
INGREDIENTS
Aluminum Foil 2-10 7429-90-5
Metal Oxide (propietary) 20-50 Confidential
Polyvinylidene Fluoride (PVDF)
Styrene Butadiene Rubber(SBR)
Copper Foil 2-10 7440-50-8
Carbon (proprietary) 10-30 7440-44-0
Electrolyte (proprietary) 10-20 Confidential
Aluminum and inert materials Remainder N/A
N
33.. HHAAZZAARRDDSS IIDDEENNTTIIFFIICCAATTIIOON
PRIMARY ROUTES OF ENTRY
Skin contact, Skin absorption, Eye contact, Inhalation, and Ingestion : NO
% CAS NUMBER
<5
<5
24937-79-9
9003-55-8
This Sheet is provided as technical information only. The information and recommendations set forth
are made in good faith and believed to be accurate as of the date of preparation. SAMSUNG SDI
Corp. makes no warranty, expressed or implied, with respect to this information and disclaims all
liabilities from reliance on it
SYMPTOMS OF EXPOSURE
Skin contact, Skin absorption, Eye contact, Inhalation
→ No effect under routine handling and use.
REPORTED AS CARCINOGEN
NOT APPLICABLE
44.. FFIIRRSSTT AAIIDD MMEEAASSUURREES
INHALATION, EYE CONTACT, and SKIN CONTACT: Not a health hazard.
INGESTION
If swallowed, obtain medical attention immediately.
If exposure to internal materials within cell due to damaged outer casing, the following actions
are recommended.
INHALATION
Leave area immediately and seek medical attention.
EYE CONTACT
Rinse eyes with water for 15 minutes and seek medical attention.
SKIN CONTACT
Wash area thoroughly with soap and water and seek medical attention.
INGESTION
Drink milk/water and induce vomiting; seek medical attention.
55.. FFIIRREE FFIIGGHHTTIINNGG MMEEAASSUURREES
GENERAL HAZARD
Cell is not flammable but internal organic material will burn if the cell is incinerated.
Combustion products include, but are not limited to hydrogen fluoride, carbon monoxide and
carbon dioxide.
EXTINGUSHING MEDIA
Use extinguishing media suitable for the materials that are burning.
SPECIAL FIREFIGHTING INSTRUCTIONS
If possible, remove cell(s) from fire fighting area. If heated above 125°C, cell(s) can
explode/vent.
FIREFIGHTING EQUIPMENT
Use NIOSH/MSHA approved full-face self-contained breathing apparatus (SCBA) with full
protective gear.
This Sheet is provided as technical information only. The information and recommendations set forth
are made in good faith and believed to be accurate as of the date of preparation. SAMSUNG SDI
Corp. makes no warranty, expressed or implied, with respect to this information and disclaims all
liabilities from reliance on it
S
S
2 of 6
66.. AACCCCIIDDEENNTTAALL RREELLEEAASSEE MMEEAASSUURREES
ON LAND
Place material into suitable containers and call local fire/police department.
IN WATER
If possible, remove from water and call local fire/police department.
77.. HHAANNDDLLIINNGG AANNDD SSTTOORRAAGGE
HANDLING
No special protective clothing required for handling individual cells.
STORAGE
Store in a cool, dry place.
E
S
88.. EEXXPPOOSSUURREE CCOONNTTRROOLLSS//PPEERRSSOONNAALL PPRROOTTEECCTTIIOON
ENGINEERING CONTROLS
Keep away from heat and open flame. Store in a cool dry place.
PERSONAL PROTECTION
Respirator: Not required during normal operations. SCBA required in the
event of a fire.
Eye/face protection: Not required beyond safety practices of employer.
Gloves: Not required for handling of cells.
Foot protection: Steel toed shoes recommended for large container handling.
99.. PPHHYYSSIICCAALL AANNDD CCHHEEMMIICCAALL PPRROOPPEERRTTIIEES
State Solid Odor N/A
PH N/A Vapor pressure N/A
Vapor density N/A Boiling point N/A
Solubility in water Insoluble Specific gravity N/A
Density N/A
1100.. SSTTAABBIILLIITTYY AANNDD RREEAACCTTIIVVIITTY
Y
S
N
3 of 6
This Sheet is provided as technical information only. The information and recommendations set forth
are made in good faith and believed to be accurate as of the date of preparation. SAMSUNG SDI
Corp. makes no warranty, expressed or implied, with respect to this information and disclaims all
liabilities from reliance on it
REACTIVITY
None
INCOMPATIBILITIES
None (during normal operation). Avoid exposure to heat, open flame, and corrosives.
HAZARDOUS DECOMPOSITION PRODUCTS
None (during normal operating conditions). If cells are opened, hydrogen fluoride and
carbon monoxide may be released.
CONDITIONS TO AVOID
Avoid exposure to heat and open flame
1111.. TTOOXXIICCOOLLOOGGIICCAALL IINNFFOORRMMAATTIIOON
This product does not elicit toxicological properties during routine handling and use.
Sensitization: NO Teratogenicity: NO Reproductive toxicity: NO Acute toxicity: NO
This product does not contain any kinds of the following substances and halogen-type flame
retardants including Chlorine and Bromide type harmful flame retardants which are listed in
Appendix of TCO documents and relevant international ECO requirements:
Polybromated Biphenyls (PBB)
Polybromated Biphenyl Ethers (PBBE)
Polybromated Biphenyl Oxides (PBBO)
Polybromated Diphenylethers (PBDE)
Polychlorinated Biphenyl (PCB)
Polychloronated Diphenylethers (PCDE)
Tetrabromphisphenol A (TBBPA)
Asbestos, Antimonytrioxide, Dioxine
None of the following substances will be exposed, leaked, or emitted during transportation,
storage or any operation and any temperature condition:
Chlorinated Fluorohydrocarbon (FCKW)
Acrylonitride
Styrol
Phenol
Benzol
Mercury of greater than 0.0001 wt% for alkaline battery
Mercury of greater than 0.0005 wt% for other battery
Lithium content of greater than 0.5g/cell, 1.5g/battery
Cadmium, lead, and other harmful heavy metal
This product does not contain mercury, cadmium and lithium-metal.
. Do not puncture, crush or incinerate.
N
4 of 6
This Sheet is provided as technical information only. The information and recommendations set forth
are made in good faith and believed to be accurate as of the date of preparation. SAMSUNG SDI
Corp. makes no warranty, expressed or implied, with respect to this information and disclaims all
liabilities from reliance on it
Mercury content:
Lithium-metal : N/A
Cadmium content:
If the cells are opened through misuse or damage, discard immediately. Internal components of
cell are irritants and sensitizers.
1122.. EECCOOLLOOGGIICCAALL IINNFFOORRMMAATTIIOON
Some materials within the cell are bioaccumulative. Under normal conditions, these materials are
contained and pose no risk to persons or the surrounding environment.
N/A
N/A
N
5 of 6
N
N
1133.. DDIISSPPOOSSAALL CCOONNRRIIDDEERRAATTIIOON
CALIFORNIA REGULATED DEBRIS
RCRA Waste Code: Non-regulated
Dispose of according to all federal, state, and local regulations.
1144.. RREEGGUULLAATTOORRYY IINNFFOORRMMAATTIIOONN
OSHA hazard communication standard (29 CFR 1910.1200)
Hazardous a Non-hazardous
1155.. TTRRAANNSSPPOORRTT IINNFFOORRMMAATTIIOON
Lithium ion batteries containing no more than 1.5g/cell and 8g/battery pack of lithium can be
treated as “Non-dangerous goods” under the United Nations Recommendations on the Transport
of Dangerous Goods, Special Provision 188, provided that packaging is strong and prevent the
products from short-circuit.
With regard to air transport, the following regulations are cited and considered:
- The International Civil Aviation Organization (ICAO) Technical Instructions (2006-
2007 Edition),
- The International Air Transport Association (IATA) Dangerous Goods Regulations (49th
Edition, Special Provisions A45, A88, A99 and A154)
- The International Maritime Dangerous Goods (IMDG) Code (2002 Edition),
- The US Hazardous Materials Regulation (HMR) pursuant to a final rule issued by RSPA
(Part 49 CFR Sections 100-185),
- The Office of Hazardous Materials Safety within the US Department of Transportation’s
(DOT) Research and Special Programs Administration (RSPA), and
This Sheet is provided as technical information only. The information and recommendations set forth
are made in good faith and believed to be accurate as of the date of preparation. SAMSUNG SDI
Corp. makes no warranty, expressed or implied, with respect to this information and disclaims all
liabilities from reliance on it
- The UN Recommendations on the Transport of Dangerous Goods Model
Regulations and the Manual of Tests and Criteria.
Our products are properly classified, described, packaged, marked, and labeled, and are in proper
condition for transportation according to all the applicable international and national
governmental regulations, not limited to the above mentioned. We further certify that the
enclosed products have been tested and fulfilled the requirements and con ditions in accordance
with UN Recommendations (T1 – T8) on the Transport of Dangerous Goods Mod el Regulations
and the Manual of Testes and Criteria that can be treated as “Non-Dangerous Goods”.
Test results of the UN Recommendation on the Transport of Dangerous Goods
Manual of Test and Criteria(38.3 Lithium battery) Test Results Remark
No Test item
T1 Altitude Simulation Pass
T2 Thermal Test Pass
T3 Vibration Pass
T4 Shock Pass
T5 External Short Circuit Pass
T6 Impact Pass
T7 Overcharge Pass For pack only
T8 Forced Discharge Pass For cell only
1166.. OOTTHHEERR IINNFFOORRMMAATTIIOONN
For further information, please contact SAMSUNG SDI sales representative.
6 of 6
This Sheet is provided as technical information only. The information and recommendations set forth
are made in good faith and believed to be accurate as of the date of preparation. SAMSUNG SDI
Corp. makes no warranty, expressed or implied, with respect to this information and disclaims all
liabilities from reliance on it
