Page 1
Hozelock 7L Pressure Sprayer - 4507
Hozelock UK Garden Irrigation & Automatic Watering Systems
Page 2
4505
4507
4510
5, 7 & 10
?
www.hozelock.com
1
Year guarantee
Ans de garantie
Jahre garantie
Jaat garantie
Años de garantia
Xρόνια εγγ ύησ η
Hozelock Ltd.
Midpoint Park, Birmingham,
B76 1AB. England
Tel: +44 (0) 121 313 1122
www.hozelock.com
33880-000
Page 3
Contents • Contenu • Inhalt • Inhoud • Contenidos • Innehåll • Innhold • Sisältö • Indhold • Indice • Conteúdo
Zawartość • Περιεχόμενα • İçindekiler • Tartalom • Obsah • Содержание • Sisukord • Saturs • Turinys
Cuprins • Зміст • Vsebina
Assembly • Assemblage • Montage • Samenstelling • Montaje • Montering • Montering • Kokoaminen • Montering
Montaggio • Montagem • Montaż • Συγκρότημα • Montaj • Összeszerelés • Sestava • Сборка • Koostamine
Montāža • Surinkimas • Ansamblu • Монтаж • Sestav
x1 x1 x1 x1
GB
Thank you for choosing a Hozelock quality sprayer, you can be
assured of many years of reliable service from this product.
Instructions & Warnings
• This sprayer is intended for use with water-based solutions
of: insecticides, fungicides, weedkillers and fertilizers.
• Always follow the chemical suppliers instructions, as well as
the instructions supplied with this sprayer.
• Make sure all nuts are screwed hand tight before use.
• If the sprayer has been used with chemicals, discard safely
any unused solution after use.
• Always use eye protection when replacing valves, seals or
springs.
•Beforecarryingoutanymaintenanceonthissprayer
itisessentialtodepressurisethebottle,byliftingthe
pressurereleaseknob.
Always wear protective clothing, goggles,
face mask and gloves.
Avoid inhaling spray mist.
Avoid skin contact with chemicals.
Always work in a well ventilated area.
Take care to protect children, pets & fish from exposure to
chemicals.
Always wash hands thoroughly after use & especially
before eating.
Always wash any contaminated clothing.
Seek medical attention if spray gets in your eyes or you
develop any symptoms after spraying.
Do not spray near food or food preparation areas. When
spraying crops, pay particular attention to the chemical
manufacturers advice on time before crops can be eaten.
Do not spray any solvent e.g. White spirit.
Spray only thin watery solutions; thicker mixtures will clog
the nozzle.
Powdered chemicals can be sprayed successfully if they
are completely soluble in water. If they are not, or the
solution tends to settle, spraying can still be successful if
the mixture is continually agitated.
If the material to be sprayed contains sediment, strain the
liquid into the sprayer bottle.
Do not over pressurize the bottle. The pressure release
valve is designed to release excess pressure, and must not
be tampered with, or forced to remain closed.
Winter use – drain liquid from all parts and loosen pump
assembly.
Annual maintenance – At least once per year thoroughly
clean the whole sprayer and apply silicone grease to all
moving parts & seals. Test with water, and if any washer or
seal has perished it must be replaced.
This sprayer is made from many different types of plastic,
and although the liquid you wish to spray may be packed
in plastic, this does not guarantee it will not damage the
sprayer. If you have any doubt about compatibility
contact Hozelock consumer services.
When filling the sprayer ensure that the maximum fill level
is not exceeded.
1 2
654
3
x1
Page 4
Ensure that the pump is screwed into the bottle tightly.
After use with chemicals, fill sprayer with warm water
(not hot), re-assemble the sprayer and spray some of the
contents. Repeat; check that the nozzle is free from
sediment.
If necessary repeat the process until the sprayer is clean.
NB: Do not use detergent.
Operation
See illustrations for use, printed on bottle.
Guarantee
• Hozelock guarantees this sprayer against any defect arising
from faulty materials or workmanship for a period of 1 year
from the date of purchase, provided that it has only been
used in accordance with these instructions. The guarantee
is limited to the repair or replacement of any defective or
faulty item. Proof of purchase must be retained.
• The Hozelock guarantee also covers ‘O’ rings and seals for
a 12-month period, as these are wearing parts, they are
available as spares from the retailer or from Hozelock direct.
Troubleshooting
Please go to www.hozelock.com for full instructions, details
of spares and accessories available.
Consumerhelpline:01213131122
