Howard McCray R-CDS32E-4C-LS User Manual

32E Series – Endless Design

Curved Glass – Single Duty – Deli

• PRODUCT SPECIFICATIONS SHEETS

• Specification subject to change without notice

Self-Contained SC-CDS32E-4C-LS SC-CDS32E-6C-LS SC-CDS32E-8C-LS
Remote R-CDS32E-4C-LS R-CDS32E-6C-LS R-CDS32E-8C-LS

Length with (2) ends 50" 74" 98"
Length without ends 48" 72" 96"
Height with ends 50-1/2" 50-1/2" 50-1/2"
Height without ends 50" 50" 50"
Depth with ends 30-1/2" 30-1/2" 30-1/2"
Depth without ends 30" 30" 30"
Endless Design YES YES YES

(Dimensions are +/- 1/4")

• Cases are designed to operate at 75 degrees Fahrenheit and 55% relative humidity

32E Series – Endless Design

Curved Glass – Single Duty – Deli

Standard Specifications and Optional Features

OPTIONAL FEATURES

A Division of HMC Enterprises LLC • 2501 Grant Avenue • Philadelphia, PA 19114 USA

[phone] • 1-800-344-8222 • Fax [phone] • E-Mail: [e-mail] • www.howardmccray.com

UL Classified to ANSI/NSF 7
Foamed in place CFC free foam
Double pane coated and insulated curved glass
Heavy gauge steel super structure
Single duty display
Endless design allows for continuous line up
Drain is included for cleaning

Satin finish extrusion on doors and door tracks
Designer white exterior front and ends
Stainless steel mirror trim
Stainless steel heavy gauge top – 16" W
Rear of unit is stainless steel brush finish at top
Bottom rear is designer white aluminum

CONSTRUCTION FINISHES

INTERIOR REFRIGERATION

EXTERIOR LIGHTING

ELECTRICAL REQUIREMENTS

Stainless steel mirrored upper ends
Stainless steel heavy gauge lighted mezzanine shelf
(1 row)
White aluminum floor-main deck area
Epoxy coated main deck shelves
Air insulated baffle (prevents moisture from drip-

ping into display area)

Copevap system (eliminates need for
condensate pan)

R134a expansion valve system
Gravity coil located at inside top of unit
Self contained system
Automatic defrost controlled by time clock-(self

contained units only)

Pressure control maintains constant temperatures
Remotes available

Double pane rear removable doors
Newly designed rear compression door jamb
Removable front grille allows for cleaning
Removable rear grille for easy servicing
1" removable end panels

1 Row of T12 lighting at top of unit
1 Row of lighting on mezzanine shelf

115V/60Hz/1Ph
Unit must be hard wired
UL/CUL listed
115V-12AMP general purpose receptacle (wired

separately)

Stainless steel, laminate or paint
Mirrored doors
Extra row of mezzanine shelf
Digital Thermometer

Front bumper 1" or 3"
Ice pans
Sandwich rack
Door Locks

Important Note: All refrigerated cases are
designed to operate in an environment of
75 degrees and 55% relative humidity.

Important Note:

Product must be cooled

before being displayed within the case.
