Howard Industries CW44 Series Specifications
Specification Sheet
2/22/2015
4’ Fluorescent Wrap
Commercial Grade
Four Lamps
Fluorescent Wrap
Applications
Hallway/Corridor
Schools
Shops/Sheds
Dimensions
9-3/4
24
4-1/2
13
2-1/4
2-1/2
3-1/2
1
4-light Prismatic Diffuser
Office
Residential
Utility Areas
48
1-5/8
CW44 Series
2-1/4
3-1/2
11-1/4
20-3/4
Project:
Catalog#:
Approved by:
Description
CW44 series is a narrow bodied, versatile, and
durable fluorescent wrap fixture. This fixture
operates four lamps and as a standard feature
comes with a Howard ballast.
Features
Construction
• Die-formed code-gauge steel
• High gloss, baked enamel finish
• High quality lamp holders
• NEC compliant luminaire power disconnect
standard
Diffuser
• Prismatic 100% Acrylic wrap-around lens
• Injection Molded
• Industry Standard #8 Pattern minimizes lamp
image for more uniform appearance
• Ribbed side prisms control surface brightness
• Interlocking attachment prevents accidental
removal
• Diffuser designed to hinge from either side
allowing for easy maintenance
Installation
• Shipped fully wired with Howard ballast
• Shipped fully assembled
• Easy access to wiring compartment and ballast
via tool-free removable ballast cover
• Numerous knockouts on fixture top surface and
endcaps
• Flexible mounting options: surface mount,
pendant mount, individual or continuous run
Ballast
• Electronic, Inherent Thermal Protection, Class P,
Sound rated A
• UL Listed
Fixture Listing
• UL Listed
Specifications subject to change without notice.
Howard Lighting Products | 580 Eastview Drive | Laurel, MS 39443
(toll free) 800.956.3456 | (direct) 601.422.0033 | (fax) 601.422.1652
www.HowardLightingProducts.com
Specification Sheet
CW44 Series
4’ Fluorescent Wrap
Commercial Grade
Project:
Catalog#:
Four Lamps
Approved by:
Ordering Information
T
BAPackaging
Fluorescent Wrap
Model
Family
Reflector/Lens
No. of
Lamps
Lamp Type/
Wattage
(1)
Ballast Input Volts
Factory Installed
Options
Cordset Options
CW44 0 4 32 SE MV 000 01 0 I
CW44 0: Reflective White Front (86%) 4 32A: F32T8
(2)
SE: SBF High Eff
LE: LBF High Eff
(3)
MV: 120-277v 000: No FIOs
(3)
B: Emergency Ballast
00: Standard Disconnect
(4)
01: 6’ SJT 18/3, no plug
02: 10’ SJT 18/3, no plug
03: 6’ SJT 18/3 L5-15, twist lock 120v
04: 10’ SJT 18/3 L5-15twist lock 120v
05: 6’ SJT 18/3 5-15non twist lock 120v
06: 10’ SJT 18/3 5-15non twist lock 120v
07: 6’ SJT 18/3 L7-15 twist lock 277v
08: 10’ SJT 18/3 L7-15 twist lock 277v
11: 16/3, no plug specify length
17: 18/3, no plug specify length
22: 6’ SJT 16/3 L7-20 twist lock 277v
23: 6’ SJT 18/3 L6-15 twist lock 240v
*Other cordsets available, consult customer
service
I: Single
(1) Lamp installation not available.
(2) 32A Option will also run 30 & 28W T8 Energy Saving lamps, but the actual ballast will be the same.
(3) High Efficiency ballasts are CEE Listed.
(4) Please specify Emergency Ballast (120-277v only) lumen requirements at time of request.
SE Standard Ballast Factor High Efficiency Instant Start T8 Ballast
HE High Ballast Factor High Efficiency Instant Start T8 Ballast
LE Low Ballast Factor High Efficiency Instant Start T8 Ballast
Specifications subject to change without notice.
Howard Lighting Products | 580 Eastview Drive | Laurel, MS 39443
(toll free) 800.956.3456 | (direct) 601.422.0033 | (fax) 601.422.1652
Sample Ordering Number:
CW44 0 4 32A SE MV 000 01 0 I
CW44 Series 4-Foot Fluorescent Wrap
Reflective White Front
4-lamps (lamps not provided)
F32T8 Standard Ballast Factor Instant Start
High Efficiency Ballast
Multi-volt (120-277v)
6’ SJT 18/3 cord, no plug
Single Packaging
RAPID SHIP MODEL
AVAILABLE FOR NEXT DAY SHIPMENT
•CW440432ASEMV
