Page 1
AIR200G & AIR400G
Air Supply
TABLE OF CONTENTS
User Manual
Symbol References .........................................................2
Intended Use and Precautions ........................................2
Part Identification ...........................................................3
Product Specifications ....................................................3
Cleaning and Preventive Maintenance ...........................4
Warranty Statement........................................................4
Returns and Repairs ........................................................4
Page 2
AIR200G & AIR400G User Manual
Symbol Reference
REFER TO MANUAL
TYPE BF APPLIED PART
THIS END UP
TEMPERATURE LIMITATION
ALTERNATING CURRENT HUMIDITY LIMITATION
MANUFACTURER DATE OF MANUFACTURE
GENERAL WARNING SIGN KEEP DRY
FUNCTIONAL EARTH GROUND
CAUTION
CSA C22.2 No. 601.1, UL-60601-1
Intended Use and Precautions
The Air200G and Air400G are single-speed air supplies used to inflate
HoverTech’s HoverMatt® Air Transfer Mattresses and HoverJack® Air
Patient Lifts.
INTENDED USE
• The caregiver/operator is the person handling the equipment.
• The patient is not the intended operator.
CAUTIONS
• Route the power cord in a manner to ensure freedom from hazard.
• Avoid blocking the air intakes of the air supply.
• Never leave patient unattended on an inflated device.
2 | HoverTech International Air200G/Air400G Manual Rev. D
• Use this product only for its intended purpose as described in this
manual. Only use attachments and/or accessories that are authorized
by HoverTech International.
• When using the air supply in the MRI environment, a 25 ft. specialty
MRI hose is required (available for purchase).
• Avoid electric shock. Do not open air supply.
• Reference product-specific user manuals for additional operating
instructions.
• Warning: To avoid the risk of electric shock, this equipment must only
be connected to a supply main with protective earth.
INTENDED CARE SETTINGS
Hospitals, long-term or extended care facilities and ambulance/transport.
Page 3
AIR200G & AIR400G User Manual
Part Identification
ASWH-100 Webbed handle
AS-HOOK Metal hook with webbing
ELC-100 Electrical cord
ASCB Cord clamp with screws
AS-Hose 5 foot hose
(includes BC-100
and AS-Cu)
CAUTION:
WITH THE EXCEPTION OF FILTERS AS DESCRIBED IN
THE CLEANING AND PREVENTIVE MAINTENANCE
SECTION, THERE ARE NO OTHER USER SERVICABLE
PARTS.
BC-100 Blower coupler
BA-100 Blower adapter
ASPH100 Plastic handle
HS-100 Handle screw
RG-100 Rubber grommet
AS-Cu VacuFlex hose cu
Product Specifications
Dimensions: 9 DIA x 16 H inches (22.8 cm x 40.6 cm)
Weight: 11 lbs. (5 kg)
Material: Lexan/Stainless Steel
Power Cord
Length:
Type: SJT 16 AWG*3C
Service Life: 5 years
Power Input:
Model #Air200G – 800W
Model #Air400G – 1100W
LATEX FREE
15 feet (457 cm)
120 V~, 60 Hz, 10 A
CLASSIFICATION
Not for use in the presence of flammable anesthetics or in a hyperbaric
chamber or oxygen tent.
Type of protection against electric shock: CLASS I EQUIPMENT
Degree of protection against electric shock: TYPE BF APPLIED PART
Protection against ingress of water: Ordinary (not protected).
Mode of operation: CONTINUOUS OPERATION
To remove supply mains, unplug equipment from wall.
Use Temperature: 50° to 104° F (10° to 40° C)
Use Humidity: 10% to 70% Non-Condensing
Storage/Shipping Temperature: -40° to 176° F (-40° to 80° C)
Storage/Shipping Humidity: 10% to 70% Non-Condensing
Air200G/Air400G Manual Rev. D www.HoverMatt.com | 3
Page 4
AIR200G & AIR400G User Manual
Cleaning
Between patient use, clean and disinfect the surface of the air supply by
wiping it down with EPA approved hospital-grade disinfectant wipes or
disinfectant cleaner sprayed on a cleaning cloth. Follow disinfectant manufacturer’s directions for dwell time and other instructions for use.
NOTE: DO NOT SPRAY CLEANERS/LIQUIDS DIRECTLY ON THE AIR SUPPLY.
PREVENTIVE MAINTENANCE
Prior to use, a visual inspection should be performed on the air supply to
ensure the power cord is not frayed or nicked and that there is no visual
damage that would render the air supply unusable.
If any damage is found that would cause the air supply not to function
as intended, the air supply should be removed from use and returned to
HoverTech International for repair.
The air supply has an air filter over the motor housing. This filter can be
accessed by removing the three small screws holding the canister to the
motor. It is recommended that the air filter is assessed per your facility’s
preventive maintenance schedule or annually. Filter should be cleaned if
visibly dirty. Remove the filter from the air supply and hold it under warm
Warranty Statement
HoverTech International Air Supplies are warranted to be free from defects
in materials and workmanship for (1) one year. Warranty begins on date of
in-service by a HoverTech International representative or shipment date. In
the unlikely event that a problem arises as a result of a defect in materials or
workmanship, we will promptly repair your item or replace it if we feel that
it cannot be repaired – at our expense and discretion using current models
or parts performing the equivalent function – upon receipt of the original
item to our repair department.
Lead time for repairs is approximately 2 weeks. Please refer to the Returns
and Repairs section of this Manual for return instructions.
This warranty is not an unconditional guarantee for the life of the product.
Our warranty does not cover product damage that may result from use
contrary to Manufacturer’s instructions or specifications, misuse, abuse,
tampering, or damage due to mishandling.
Equipment that has been neglected, improperly maintained, repaired or
altered by someone other than an authorized representative of Manufacturer, or operated in anyway contrary to the operating instructions, shall
void this warranty.
This warranty does not cover normal “wear and tear.” Component parts,
particularly any optional equipment, valve caps, their attachments and
cords, will show wear with use over time and eventually may need to be
running water. Allow the air filter to dry prior to placing back in the air
supply.
The filter should be replaced when it is clogged with debris that does not
break free when it is washed. The filter should also be replaced if it begins
to lose its shape or deteriorate.
INFECTION CONTROL
When a HoverTech air supply is used in a patient room where isolation protocols are being observed, the hospital should employ the same protocols/
procedures it utilizes for other equipment used in that patient room.
Between use with an airborne isolation patient, the air supply filter can be
removed and disinfected or replaced if hospital protocol requires. If the air
filter is disinfected, allow it to dry prior to placing back in the air supply.
An air hose cover is available. These covers are disposable and come in a
box of 25 (Model #ASHC).
refurbished or replaced. This normal type of wear is not covered by our
warranty, but we will provide prompt, high quality repair service and parts
at a nominal cost.
HoverTech International’s liability under this warranty and on any claim of
any kind for any loss or damage arising out of, connected with, or resulting
from the design, manufacture, sale, delivery, installation, repair or operation of its products, whether in contract or tort, including negligence, shall
not exceed the purchase price paid for the product and upon expiration of
the applicable warranty period, all such liability terminates. The remedies
which this warranty provides are exclusive and HoverTech International
shall not be liable for any incidental or consequential damages.
There are no warranties, expressed or implied, which extend beyond this
warranty statement. The provisions of these warranty clauses are in lieu of
all other warranties, expressed or implied, and of all other obligations or
liabilities on HoverTech International’s part and they neither assume nor
authorize any other person to assume for HoverTech International any other liability in connection with Manufacturer sale or lease of said products.
HoverTech International makes no warranty of merchantability or fitness for
a particular purpose. By accepting the goods, the buyer acknowledges that
buyer has determined the goods are suitable for the buyer’s purposes.
MANUFACTURER’S SPECIFICATIONS ARE SUBJECT TO CHANGE.
NOTE: IF AIR SUPPLY NEEDS TO BE DISPOSED, CHECK YOUR LOCAL / STATE / FEDERAL / INTERNATIONAL GUIDELINES BEFORE
DISPOSAL.
Returns and Repairs
All products being returned to HoverTech International (HTI) must have a
Return Goods Authorization (RGA) number issued by the company. Please
call 800-471-2776 and ask for a member of the RGA Team, who will issue
you an RGA number.
HTI’s warranty covers manufacturer’s defects in material and workmanship.
If a repair is not covered under warranty, a repair fee of $40 per hour, for
each item, plus parts, will be assessed. The return shipping charge will also
be added. A Purchase Order for the repair charge should be provided by
the facility at the time the RGA number is issued, should the repair not be
covered under warranty. Lead-time for repairs is approximately 1-2 weeks,
not including shipping time.
Returned products should be sent to:
HoverTech International
Attn: RGA number____________
4482 Innovation Way
Allentown, PA 18109
4 | HoverTech International Air200G/Air400G Manual Rev. D
4482 Innovation Way
Allentown, PA 18109
800.471.2776
Fax 610.694.9601
www.HoverMatt.com
[email protected]
