Hover-1 H1 HY-H1 User Manual

H1

ELECTRIC SCOOTER

WITH BLUETOOTH SPEAKER & APP

HELMETS
SAVE
LIVES!

Always wear a properly tted helmet that
complies with CPSC or CE safety standards
when you ride your scooter.

Correct Fitting:

Make sure your helmet
covers your forehead.

Incorrect Fitting:

Forehead is exposed
and vulnerable to
serious injury.

WARNING!

PLEASE READ THE USER MANUAL THOROUGHLY.

Failure to follow the basic instructions and safety precautions listed in
the user manual can lead to damage to your device, other property

damage, serious bodily injury, and even death.

Thank you for purchasing the Hover-1 H1 Electric Scooter. Please
read all instructions carefully before using and retain this manual for
future use and reference.

This manual applies to the H1 Scooter.

• In order to avoid dangers that are caused by collisions, falls, and
loss of control, please learn how to ride the H1 safely.

• You can learn operating skills by reading the product manual and
watching videos.

• This manual includes all operating instructions and precautions,
and users must read it carefully and follow the instructions.

• Hover-1 can not be held liable for damage or injury caused by
failure to understand and follow the warnings and instructions in this
manual.

ATTENTION

1. Use only the supplied charger with this scooter.
Charger Manufacturer: SHENZHEN FUYUANDIAN POWER CO LTD
Model: FY0634201500

2. The operating temperature range of the H1 is 32-104° F (0-40° C).

3. Do not ride on icy or slippery surfaces.

4. Read the user manual and warning labels before riding.

5. Store the H1 in a dry, ventilated environment.

6. When transporting the H1, avoid violent crashes or impact.

1

LOW TEMPERATURE WARNING

Low temperature will affect the lubrication of moving parts inside
the H1 scooter, increasing internal resistance. At the same time, in
low temperatures, the discharge capacity and the capacity itself
of the battery will be significantly decreased.

Use caution when riding the H1 in cold temperatures (below 40
degrees F).

Doing so may increase the risk of mechanical failures of the
scooter, which may lead to damage to your device, other
property damage, serious bodily injury and even death.

SAFETY INSTRUCTIONS

• Keep the device away from heat sources, direct sunlight,
humidity, water and any other liquids.

• Do not operate the device if it has been exposed to water,
moisture or any other liquids to prevent against electric shock,
explosion and/or injury to yourself and damage to the device.

• Do not use the device if it has been dropped or damaged in
any way.

• Repairs to electrical equipment should only be performed by
the manufacturer. Improper repairs voids the warranty and may
place the user at serious risk.

• Do not puncture or harm the exterior surface of the product in
any way.

• Keep the device free from dust, lint, etc.

• Do not use this device for anything other than its intended use or
purpose. Doing so may damage the device or lead to property
damage, injury or death.

• This product is not a toy. Keep out of reach of children.

• Do not expose batteries, battery pack, or batteries installed to
excessive heat, such as direct sunlight, or open flame.

• Do not allow hands, feet, hair, body parts, clothing or similar
articles to come in contact with moving parts, wheels or drive
train, while the engine is running.

2

• Do not operate or allow others to operate the H1, until the user
understands all instructions, warnings and safety features described
in this manual.

• Check with your doctor if you have a medical condition that
could affect your ability to use the H1.

• Persons with head, back or neck ailments or prior surgeries to
those areas of the body are not recommended to use the H1.

• Do not operate if you are pregnant, have a heart condition, or
have both.

• Persons with any mental or physical conditions that may make
them susceptible to injury or impair their physical or mental
capabilities to recognize, understand and perform all of the
safety instructions and to be able to assume the hazards inherent
in unit use, should not use the H1.

NOTES:

In this manual, the above symbol with the word “NOTES” indicates
instructions or relevant facts the user should remember prior to using
the device.

CAUTION!

In this manual, the above symbol with the word “CAUTION”
indicates a hazardous situation which, if not avoided, can cause
minor or moderate injury.

WARNING!

In this manual, the above symbol with the word “WARNING”
indicates a hazardous situation which, if not avoided, can cause
death or serious injury.

SERIAL NUMBER

Please keep the serial number on file for warranty claims as well as
proof of purchase.

WARNING!

WARNING: Prolonged Exposure to UV Rays, Rain and the Elements
May Damage the Enclosure Materials.
Store Indoors When Not in Use.

3

INTRODUCTION

The Hover-1 H1 is a personal transporter. Our technology and
production processes are developed with strict testing for each H1
scooter. Operating the H1 without following the contents of this
manual may lead to damage to your H1, or bodily injury.

This manual is designed to give you the information you need for the
safe operation and maintenance of your H1. Please read it
thoroughly before riding your H1.

PACKAGE CONTENTS

• Hover-1 H1 Electric Scooter

• 3-pin Charge Cable

• Operation Manual

1 1

2

7

6

7 7

8 9

3

4

5

10

FEATURES/PARTS

1. Fender 6. Tire

2. Left Foot Mat 7. LED Light

3. Running Indicator 8. Charge Port (located in rear)

4. Battery Indicator 9. Power Button (located in rear)

5. Right Foot Mat 10. Wireless Speaker

7

6

4

OPERATING PRINCIPALS

The device uses digital electronic gyroscopes and acceleration
sensors to control balance and motion, depending on the user's
center of gravity. The device also uses a control system to drive the
motors that are located within the wheels. The device has a built-in
inertia dynamic stabilization system that can help assist with balance
when moving forward and backwards, but not while turning.

TIP – To increase your stability, you must shift your weight in order to
overcome the centrifugal force during turns, especially when
entering a turn at higher speeds.

WARNING

Any Hover-1 H1 that does not work properly
can cause you to lose control and fall.
Inspect the entire device thoroughly before
every ride, and do not ride it until any
problems have been corrected.

SPECIFICATIONS

Model: HY-H1
Net Weight: 22.04 lbs (10 kg)
Load: 44-265 lbs (20-120 kg)
Max Speed: Up to 9 mph (14.4 km/h)
Max Distance Range: Up to 9 miles (14.4 km)
Max Incline Angle: 15°
Minimum Turning Radius: 0°
Battery Type: Lithium-ion
Battery Voltage: 36 V
Battery Capacity: 4.0 Ah
Power Requirement: AC 100-240V, 50-60 Hz
Wheel Size: 6.5 Inches (16.51 cm)
Tire Type: Non-Pneumatic Solid Tires
IP Rating: IPX4
Bluetooth Range: Up to 33ft
Bluetooth Speaker: V2.0 with stereo sound quality
UL Certification: UL 2272 approved
FCC ID: 2AANZH1
BT ID: D037690

5

CONTROLS AND DISPLAY

PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY

TURNING YOUR DEVICE ON/OFF

Power On: Take your device out of the box and place it flat on the
floor. Press the power button (located on the rear of your device)
once. Check the LED indicator (located in the center of your
device). The battery indicator light should be lit, indicating the device
is powered on.

Power Off: Press the power button once.

MAT SENSOR

There are four sensors under the foot mats on your H1. When the user
steps off the scooter mats, it will automatically initiate self-calibration.

When riding the scooter, you must ensure you are stepping on the
foot mats. Do not step or stand on any other area of your scooter.

The H1 may vibrate or spin in one direction, if weight and pressure are
applied to only one foot mat.

BATTERY INDICATOR

The display board is located in the middle of the H1 scooter.

• Green LED light indicates the device is charged above 20 percent.

• Yellow LED light indicates the power is under 20 percent.

• Red LED light indicates the power is down to 10 percent or lower.

When the LED light turns red, please recharge the device.

RUNNING INDICATOR

When the operator triggers the foot mats, the Running Indicator LED
will light up, which means that the system enters the running state.

When the system has an error during operation, the running LED light
will turn red (for more details see SAFETY ALERTS).

6

BLUETOOTH SPEAKER

The H1 has a powerful built-in wireless speakers so you can play your
music while riding.

PAIRING THE SPEAKER

1) Turn on your H1 and the speakers will “Ping” to announce that it’s
waiting for a Bluetooth® connection. This will indicate your H1 speaker
is now in pairing mode.

2) Place the H1 and the Bluetooth® device to which you would like to
pair it within the operating distance. We recommend keeping the
two devices no further than 3 feet apart during pairing.

3) Ensure Bluetooth® is enabled on your phone or music device. Refer
to manufacturer’s instructions for how to enable Bluetooth® on your
device.

4) Once you have activated Bluetooth® on your device, select the
option “HY-H1” from the list of available Bluetooth® devices.

5) If required, enter the PIN code "000000" and confirm the entry.

6) The H1 will say “Paired” when successfully paired.

7) Please note, pairing mode on the H1 will last for two minutes. If no
devices are paired after two minutes, the H1 speaker will
automatically return to standby mode.

8) If pairing is unsuccessful, turn off the H1 first and re-pair following
the aforementioned steps.

9) If your smart phone is out of range, or the battery is low on your H1,
your speaker may disconnect from your smart device, and the H1 will
say “Disconnected.” To reconnect, follow the aforementioned steps,
or recharge your scooter.

NOTE: Once you have paired the H1 speaker with a device, the
speaker will remember this device and will pair automatically when
the device’s Bluetooth® is activated and in range. You do not need
to re-pair any previously connected devices.

Your scooter can pair up to two multi-point devices. You can
reconnect a previously paired device without going through the
pairing or PIN process on up to two devices.

LISTENING TO MUSIC

Once the H1 Bluetooth speaker is paired to your device, you can
stream music wirelessly through it. Only one speaker will play music as
the other speaker is strictly for safety alerts from your Hover-1. Select
the track you wish to listen to on your device to listen via the speaker.
All volume and track controls will be made using your music device.
Should you encounter any problems while streaming, please refer to
your device’s user manual.

7
