Page 1
OPERATION MANUAL
HY-HSK
POWER-ASSISTED SKATEBOARD
CRUZE
Page 2
1
HELMETS
SAVE
LIVES!
Always wear a properly tted helmet that
complies with CPSC or CE safety standards
when you ride your bicycle.
Correct Fitting:
Make sure your helmet
covers your forehead.
Incorrect Fitting:
Forehead is exposed
and vulnerable to
serious injury.
Page 3
2
PLEASE READ THE USER MANUAL THOROUGHLY.
Failure to follow the basic instructions and safety precautions listed in
the user manual can lead to damage to your device, other property
damage, serious bodily injury, and even death.
Thank you for purchasing the Hover-1 Cruze Power-Assisted
Skateboard. Please read all instructions carefully before using and
retain this manual for future use and reference.
This manual applies to the Hover-1 Cruze.
• In order to avoid dangers that are caused by collisions, falls, and loss
of control, please learn how to ride the Cruze safely.
• You can learn operating skills by reading the product manual and
watching videos.
• This manual includes all operating instructions and precautions, and
users must read it carefully and follow the instructions.
• All users are responsible for any consequences caused by violating
warning contents or prompt operations. Hover-1 can not be held
liable.
ATTENTION
1. Use only the supplied charger with this skateboard.
Charger Manufacturer: Jin Xin Yu Power (Shenzhen) Supply Co., Ltd.
Model: XVE-2940100
2. The operating temperature range of the charger is -4° F-122° F
(-20-50° C).
3. The operating temperature range of the Cruze is 32-104° F (0-40° C).
4. Do not ride on icy or slippery surfaces.
5. Read the user manual and warning labels before riding.
6. Store the Cruze in a dry, ventilated environment.
7. When transporting the Cruze, avoid violent crashes or impact.
WARNING!
LOW TEMPERATURE WARNING
Low temperature will affect the lubrication of moving parts inside
the Cruze, increasing internal resistance. At the same time, in low
temperatures, the discharge capacity and the capacity itself of
the battery will be significantly decreased.
Use caution when riding the Cruze in cold temperatures (below 40
degrees F).
Doing so may increase the risk of mechanical failures of the
skateboard, which may lead to damage to your device, other
property damage, serious bodily injury and even death.
SAFETY INSTRUCTIONS
• Keep the device away from heat sources, direct sunlight,
humidity, water and any other liquids.
• Do not operate the device if it has been exposed to water,
moisture or any other liquids to prevent against electric shock,
explosion and/or injury to yourself and damage to the device.
• Do not use the device if it has been dropped or damaged in
any way.
• Repairs to electrical equipment should only be performed by
the manufacturer. Improper repairs voids the warranty and may
place the user at serious risk.
• Do not puncture or harm the exterior surface of the product in
any way.
• Keep the device free from dust, lint, etc.
• Do not use this device for anything other than its intended use or
purpose. Doing so may damage the device or lead to property
damage, injury or death.
• This product is not a toy. Keep out of reach of children.
• Do not expose batteries, battery pack, or batteries installed to
excessive heat, such as direct sunlight, or open flame.
• Do not allow hands, feet, hair, body parts, clothing or similar
articles to come in contact with moving parts, trucks, wheels or
drivetrain, while the engine is running.
Page 4
3
• Do not operate, or allow others to operate the Cruze, until the user
understands all instructions, warnings and safety features described in
this manual.
• Check with your doctor if you have a medical condition that could
affect your ability to use the Cruze.
• Persons with head, back or neck ailments or prior surgeries to
those areas of the body are not recommended to use this Cruze.
• Persons with any mental or physical conditions that may make
them susceptible to injury or impair their physical or mental
capabilities to recognize, understand and perform all of the
safety instructions and to be able to assume the hazards inherent
in unit use, should not use the Hover-1 Cruze.
In this manual, the above symbol with the word “NOTES” indicates
instructions or relevant facts the user should remember prior to using
the device.
In this manual, the above symbol with the word “CAUTION” indicates
a hazardous situation which, if not avoided, can cause minor or
moderate injury.
In this manual, the above symbol with the word “WARNING”
indicates a hazardous situation which, if not avoided, can cause
death or serious injury.
Please keep the serial number on file for warranty claims as well as
proof of purchase.
LOW TEMPERATURE WARNING
Low temperature will affect the lubrication of moving parts inside
the Cruze, increasing internal resistance. At the same time, in low
temperatures, the discharge capacity and the capacity itself of
the battery will be significantly decreased.
Use caution when riding the Cruze in cold temperatures (below 40
degrees F).
Doing so may increase the risk of mechanical failures of the
skateboard, which may lead to damage to your device, other
property damage, serious bodily injury and even death.
SAFETY INSTRUCTIONS
• Keep the device away from heat sources, direct sunlight,
humidity, water and any other liquids.
• Do not operate the device if it has been exposed to water,
moisture or any other liquids to prevent against electric shock,
explosion and/or injury to yourself and damage to the device.
• Do not use the device if it has been dropped or damaged in
any way.
• Repairs to electrical equipment should only be performed by
the manufacturer. Improper repairs voids the warranty and may
place the user at serious risk.
• Do not puncture or harm the exterior surface of the product in
any way.
• Keep the device free from dust, lint, etc.
• Do not use this device for anything other than its intended use or
purpose. Doing so may damage the device or lead to property
damage, injury or death.
• This product is not a toy. Keep out of reach of children.
• Do not expose batteries, battery pack, or batteries installed to
excessive heat, such as direct sunlight, or open flame.
• Do not allow hands, feet, hair, body parts, clothing or similar
articles to come in contact with moving parts, trucks, wheels or
drivetrain, while the engine is running.
Page 5
4
The Cruze is a personal transporter. Our technology and production
processes are developed with strict testing for each Cruze. Operating
the Cruze without following the contents of this manual may lead to
damage to your Cruze, or bodily injury.
This manual is designed to give you the information you need for the
safe operation and maintenance of your new Cruze. Please read it
thoroughly before riding your Cruze.
PACKAGE CONTENTS
• Hover-1 Cruze Electric Skateboard
• Charging Cable
• Operation Manual
FEATURES/PARTS
1. Foot Pad Sensor 5. Mode Button
2. Handle 6. Mode Indicator
3. Brushless Motor 7. Power Button
4. Battery Indicator 8. Wheel Truck
9. Charging Port
• Do not operate, or allow others to operate the Cruze, until the user
understands all instructions, warnings and safety features described in
this manual.
• Check with your doctor if you have a medical condition that could
affect your ability to use the Cruze.
• Persons with head, back or neck ailments or prior surgeries to
those areas of the body are not recommended to use this Cruze.
• Persons with any mental or physical conditions that may make
them susceptible to injury or impair their physical or mental
capabilities to recognize, understand and perform all of the
safety instructions and to be able to assume the hazards inherent
in unit use, should not use the Hover-1 Cruze.
In this manual, the above symbol with the word “NOTES” indicates
instructions or relevant facts the user should remember prior to using
the device.
In this manual, the above symbol with the word “CAUTION” indicates
a hazardous situation which, if not avoided, can cause minor or
moderate injury.
In this manual, the above symbol with the word “WARNING”
indicates a hazardous situation which, if not avoided, can cause
death or serious injury.
Please keep the serial number on file for warranty claims as well as
proof of purchase.
WARNING!
SERIAL NUMBER
CAUTION!
NOTES:
Page 6
5
OPERATING PRINCIPALS
The Cruze uses a sensor that drives the motor that is located within the
wheel. Before riding, the user must select Standard Mode or
Acceleration Mode by pressing the Mode Button on the right side of
the skateboard as shown in FEATURES/PARTS. Next, the Cruze must first
be set in motion manually, then activate the motor by covering the
foot pad sensor with your back foot. Once the motor has been
activated, the user will be able to ride using the selected mode.
Model: HY-HSK
Net Weight: 8.38 lbs (3.8 kg)
Max Supported Weight: 198 lbs (90 kg)
Max Speed: Up to 11.18 mph (17.99 km/h)
Max Distance Range: Up to 5 miles (8 km)
Minimum Turning Radius: 0°
Battery Type: Lithium-ion
Motor Power: 150W Brushless Motor
Battery Voltage: 25.55 V
Battery Capacity: 2.15 Ah
Power Requirement: AC 100-240V, 50-60 Hz
Product Dimension: 27.56 in. x 8.66 in. x 4.53 in.
Product Weight: 8.38 lbs
Profile: High
Board Size: 27.6 in. x 8.07 in.
Axle: 8.27 in
Wheel Size: 2.5 in (70mm)
The Cruze is a personal transporter. Our technology and production
processes are developed with strict testing for each Cruze. Operating
the Cruze without following the contents of this manual may lead to
damage to your Cruze, or bodily injury.
This manual is designed to give you the information you need for the
safe operation and maintenance of your new Cruze. Please read it
thoroughly before riding your Cruze.
PACKAGE CONTENTS
• Hover-1 Cruze Electric Skateboard
• Charging Cable
• Operation Manual
FEATURES/PARTS
1. Foot Pad Sensor 5. Mode Button
2. Handle 6. Mode Indicator
3. Brushless Motor 7. Power Button
4. Battery Indicator 8. Wheel Truck
9. Charging Port
INTRODUCTION
4 5
6
7
2
1
8
3
9
Page 7
6
OPERATING PRINCIPALS
The Cruze uses a sensor that drives the motor that is located within the
wheel. Before riding, the user must select Standard Mode or
Acceleration Mode by pressing the Mode Button on the right side of
the skateboard as shown in FEATURES/PARTS. Next, the Cruze must first
be set in motion manually, then activate the motor by covering the
foot pad sensor with your back foot. Once the motor has been
activated, the user will be able to ride using the selected mode.
Model: HY-HSK
Net Weight: 8.38 lbs (3.8 kg)
Max Supported Weight: 198 lbs (90 kg)
Max Speed: Up to 11.18 mph (17.99 km/h)
Max Distance Range: Up to 5 miles (8 km)
Minimum Turning Radius: 0°
Battery Type: Lithium-ion
Motor Power: 150W Brushless Motor
Battery Voltage: 25.55 V
Battery Capacity: 2.15 Ah
Power Requirement: AC 100-240V, 50-60 Hz
Product Dimension: 27.56 in. x 8.66 in. x 4.53 in.
Product Weight: 8.38 lbs
Profile: High
Board Size: 27.6 in. x 8.07 in.
Axle: 8.27 in
Wheel Size: 2.5 in (70mm)
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
TURNING YOUR DEVICE ON/OFF
Power ON: Take your device out of the box and place it flat on the
floor. Press the power switch (located on the right of your device)
once. Check the LED indicator (located in the center of your device).
The battery indicator light should be lit, indicating the device is
powered on.
Power OFF: Press the power switch once in the OFF position.
SENSOR
There is one foot pad sensor on the rear of your skateboard, indicated
by the dot pattern. Once the Cruze is manually set in motion, cruise
control is activated when the user steps and holds their foot on the
sensor.
BATTERY INDICATOR
The display board is located in the middle of the Cruze.
The green LED light indicates battery levels of 20%, 50%, 75%, and
100% respectively. Please refer to the diagram below. When the
battery level is low, the LED light will flash, indicating the device should
be charged.
SPECIFICATIONS
WARNING
Any Cruze that does not work properly
can cause you to lose control and fall.
Inspect the entire device thoroughly
before every ride, and do not ride it until
any problems have been corrected.
Page 8
7
PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY
TURNING YOUR DEVICE ON/OFF
Power ON: Take your device out of the box and place it flat on the
floor. Press the power switch (located on the right of your device)
once. Check the LED indicator (located in the center of your device).
The battery indicator light should be lit, indicating the device is
powered on.
Power OFF: Press the power switch once in the OFF position.
SENSOR
There is one foot pad sensor on the rear of your skateboard, indicated
by the dot pattern. Once the Cruze is manually set in motion, cruise
control is activated when the user steps and holds their foot on the
sensor.
BATTERY INDICATOR
The display board is located in the middle of the Cruze.
The green LED light indicates battery levels of 20%, 50%, 75%, and
100% respectively. Please refer to the diagram below. When the
battery level is low, the LED light will flash, indicating the device should
be charged.
CONTROLS AND DISPLAY
Battery Indicator Mode Indicator Light
Mode Button
Page 9
8
When riding the Cruze you must ensure your feet are firmly placed on
the skateboard to help with balance and control.
Do not put items on the skateboard while you are using it. Doing so will
increase the probability of collision and cause injury to people, riders,
or damage the device.
It is important that you fully understand all elements of your Cruze. If
these elements are not used correctly, you will not have full control of
your Cruze. Before you ride, learn the functions of the various
mechanisms on your skateboard.
Practice using your Cruze at slower speeds in a flat, open area before
taking the device out in public areas.
PRE-RIDE CHECKLIST
Ensure that your Cruze is in proper working order each and every time
you ride. If a part of the skateboard does not function correctly,
please contact our Customer Support Center.
• Ensure the battery is fully charged before riding your skateboard.
• The Cruze can be stored at full power for approximately 3 months. If
not In use, it is recommended that you recharge the battery once a
month to maintain battery life.
• Please wear all appropriate safety and protective gear as
previously mentioned in the Operation Manual before using your
device.
• Make sure to wear comfortable clothes and flat closed-toe shoes
when operating your device.
• Please carefully read the Operation Manual, which will assist in
explaining the basic working principles and provide tips on how to
BEFORE RIDING
WARNING
Any Cruze that does not work properly
can cause you to lose control and fall.
Do not ride a Cruze with a part that is
damaged; replace the damaged part
before riding.
Page 10
9
best enjoy your experience.
The first rule in safe riding is to use common sense.
Different localities and countries have different laws governing riding
on public roads, and you should check with local officials to ensure
you are complying with these laws.
Hover-1 is not liable for tickets or violations given to riders who do not
follow local laws and regulations.
• For your safety, always wear a helmet that meets CPSC or CE safety
standards. In the event of an accident, a helmet can protect you
from serious injury and in some cases, even death.
• Obey all local traffic laws. Obey red and green lights, one-way
streets, stop signs, pedestrian crosswalks, etc.
• Ride with traffic, not against it.
• Ride defensively; expect the unexpected.
• Give pedestrians the right-of-way.
• Do not ride too close to pedestrians and alert them if you intend to
pass them from behind.
• Slow down at all street intersections and look to the left and right
before crossing.
Your Cruze is not equipped with reflectors. It is not recommended that
you ride in conditions of low visibility.
SAFETY PRECAUTIONS
WARNING
When you ride in low-visibility conditions
such as fog, dusk, or night, you might be
diicult to see, which could lead to a
collision. To increase your level of safety,
be sure wear bright, reective clothing
when riding in poor lighting conditions.
Page 11
10
Think about safety when you ride. Below is a helpful checklist for riders.
SAFETY CHECKLIST
• Do not ride above your skill level. Ensure you have had enough
practice with all functions and features of your Cruze.
• Do not ride too fast -- with increased speed comes increased risk. If
you are moving at a higher speed, small bumps can turn into large
impacts, leading to a higher risk of injury if an accident occurs.
• Do not ride with pets.
• Before stepping on your Cruze, make sure it is placed flat on level
ground, the power is on, and the Running Indicator light is green. Do
not step on if the Running Indicator light is red.
• Do not try to open or modify your Cruze. Doing so voids the
manufacturer warranty and may cause your Cruze to fail.
• Do not use the Cruze in a manner that would put people or
property in danger.
• If you and your friend(s) are riding Cruzes together, be sure to keep
a safe distance between each other to prevent collisions, property
damage, serious injuries or even death.
• Do not operate the Cruze while under the influence of drugs and/or
alcohol.
• Do not operate the Cruze when you are restless or sleepy.
• Use your best judgment to keep yourself out of dangerous situations
with your Cruze.
• It is not recommended to use your Cruze in a skate park.
• Do not ride your Cruze off of curbs, ramps, empty pools, or similar
terrain. Misuse of your Cruze voids the manufacturer warranty and
may lead to injury or damage.
• Do not continuously spin in place, it will cause dizziness and
increases risk of injury.
• Do not abuse your Cruze, doing so can damage your unit and
cause failure to the operating system leading to injury. Physical
Page 12
11
abuse, including dropping your Cruze, voids the manufacturer
warranty.
• Do not operate in or near puddles of water, mud, sand, stones,
gravel, debris or near rough and rugged terrain.
• The Cruze can be used on paved surfaces that are flat and even. If
you encounter uneven pavement, please carry your Cruze over and
past the obstruction.
• Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads
or in extreme heat or cold.
• Bend your knees when riding on bumpy or uneven pavement to
absorb the shock and vibration and help you keep your balance.
• If you are unsure if you can safely ride on a specific terrain, step off
and carry your Cruze. ALWAYS BE ON THE SIDE OF CAUTION.
• Do not attempt to ride over bumps or objects greater than ½ in.
even when prepared and bending your knees.
• PAY ATTENTION - look at where you are riding and be conscious of
the road conditions, people, places, property and objects around
you.
• Do not operate the Cruze in crowded areas.
• Operate your Cruze with extreme caution when indoors, especially
around people, property, and narrow spaces.
• Do not operate the Cruze while talking, texting, or looking at your
phone.
• Do not ride your Cruze where it is not permitted.
• Do not ride your Cruze near motor vehicles or on public roads.
• Do not travel up or down steep hills.
• The Cruze is intended for use by a single individual, DO NOT attempt
to operate the Cruze with two or more people.
• Do not carry anything while riding the Cruze.
• Individuals with lack of balance should not attempt to operate the
Cruze.
Page 13
12
• Pregnant women should not operate the Cruze.
• Young children and the elderly should not operate the Cruze.
• At higher speeds, always take into consideration longer stopping
distances.
• Do not step forward off of your Cruze.
• Do not attempt to jump on or off your Cruze.
• Do not attempt any stunts or tricks with your Cruze.
• Do not ride the Cruze in dark or poorly lit areas.
• Do not ride the Cruze near or over potholes, cracks or uneven
pavement or surfaces.
• Do not operate your Cruze off-road.
• Do not turn sharply, especially at high speeds.
• Do not exceed the maximum or minimum weight limits.
• Avoid riding the Cruze in unsafe places, including near areas with
flammable gas, steam, liquid, dust, fiber, which could cause fire and
explosion accidents.
Page 14
13
FAILURE TO FOLLOW ANY OF THE FOLLOWING SAFETY PRECAUTIONS
CAN AND MAY LEAD TO DAMAGE TO YOUR DEVICE, VOID YOUR
MANUFACTURER WARRANTY, LEAD TO PROPERTY DAMAGE, CAUSE
SERIOUS BODILY INJURY, AND CAN LEAD TO DEATH.
OPERATING YOUR DEVICE
Make sure the device is fully charged before the first initial use.
Before
turning on your Cruze, ride it like a normal skateboard to get
comfortable with the board style.
When comfortable with the board, turn on your Cruze. For the
power-assisted motor to activate, you must start riding, then place
your back foot on the board sensor so it’s covering at least 5 orange
circles. The motor will maintain your current speed until you lift your
foot off the sensor. To go faster, you will need to push the ground
manually.
Cruze is equipped with a built-in 150 Watt Brushless Motor which
allows you remain in cruise control (up to 11.18 mph).
RIDING MODES
When the Cruze is powered on, it will be in Cruising Mode by default.
Press the Mode Button to alternate between modes.
A. Cruising Mode - While Cruising you will need to stop manually using
your feet.
B. Braking Mode – While cruising, lift foot off sensor for 1.5 seconds and
the Cruze motor will apply brakes to slow you down gradually.
Look at the Mode indicator light, if it's on then it's in Cruising Mode. If
flashing quickly then it's in Braking Mode.
WEIGHT AND SPEED LIMITATIONS
Speed and weight limits are set for your own safety. Please do not
exceed the limits listed here in the manual.
• Maximum Weight: 198 lbs
• Minimum Weight: 44 lbs
• Maximum Speed: Up to 11.18 mph
RIDING YOUR CRUZE
OPERATING RANGE
In ideal conditions, the Cruze can travel up to 5 miles on a fully
charged battery. The following are some of the major factors that will
affect the operating range of your device.
• Terrain: Riding distance is highest when riding on a smooth, flat
surface. Riding uphill and/or on rough terrain will reduce distance
significantly.
• Weight: A lighter user will have further range than a heavier user.
• Ambient temperature: Please ride and store the device under
recommended temperatures, which will increase driving distance,
battery life, and overall performance of your device.
• Speed and Riding Style: Maintaining a moderate and consistent
speed while riding produces maximum distance. Traveling at high
speeds for extended periods, frequent starts and stops, idling and
frequent acceleration or deceleration will decrease overall distance.
While riding your Cruze, if there is a system error or illegal operation
performed, the device will prompt the user in a variety of ways.
You will notice the Running Indicator Light will turn RED and you will
hear a beep sound alerting you to take precaution and cease
operation, which may make the device stop suddenly.
The following are common occurrences where you will hear the Safety
Alerts. These notices should not be ignored, but appropriate action
should be taken to correct any illegal operation, failure or errors.
• Unsafe riding surfaces (uneven, too steep, etc.)
• Battery voltage is too low.
• The device is still charging.
• Overheating, or motor temperature is too high.
• If any or both tires are blocked, the device will stop after 2 seconds.
• When the battery level has depleted below protection mode, the
device engine will power off and stop after 15 seconds.
WARNING
Overweight exertion on the device may
increase possibility of injury or product damage.
Page 15
14
SAFETY ALERTS
OPERATING RANGE
In ideal conditions, the Cruze can travel up to 5 miles on a fully
charged battery. The following are some of the major factors that will
affect the operating range of your device.
• Terrain: Riding distance is highest when riding on a smooth, flat
surface. Riding uphill and/or on rough terrain will reduce distance
significantly.
• Weight: A lighter user will have further range than a heavier user.
• Ambient temperature: Please ride and store the device under
recommended temperatures, which will increase driving distance,
battery life, and overall performance of your device.
• Speed and Riding Style: Maintaining a moderate and consistent
speed while riding produces maximum distance. Traveling at high
speeds for extended periods, frequent starts and stops, idling and
frequent acceleration or deceleration will decrease overall distance.
While riding your Cruze, if there is a system error or illegal operation
performed, the device will prompt the user in a variety of ways.
You will notice the Running Indicator Light will turn RED and you will
hear a beep sound alerting you to take precaution and cease
operation, which may make the device stop suddenly.
The following are common occurrences where you will hear the Safety
Alerts. These notices should not be ignored, but appropriate action
should be taken to correct any illegal operation, failure or errors.
• Unsafe riding surfaces (uneven, too steep, etc.)
• Battery voltage is too low.
• The device is still charging.
• Overheating, or motor temperature is too high.
• If any or both tires are blocked, the device will stop after 2 seconds.
• When the battery level has depleted below protection mode, the
device engine will power off and stop after 15 seconds.
WARNING
When the Cruze turns off during a Safety Alert, all operation
systems will halt. Do not continue attempting to ride the Cruze
when the system initiates a stop. Turn your Cruze off and back
on to unlock it from a Safety Lock.
Page 16
15
CHARGING YOUR CRUZE
BATTERY CARE / MAINTENANCE
CHARGING THE DEVICE
• Ensure that the charging port is clean and dry.
• Make sure that there is no dust, debris or dirt inside the port.
• Plug the charger into a grounded wall outlet.
• Connect the cable with the power supply (100V ~ 240V; 50, 60 Hz).
• Ensure the light on the charger is lit GREEN.
• Align and connect the 3-pin charging cable into the charging port
of the Cruze. DO NOT FORCE THE CHARGER INTO THE CHARGE PORT,
AS THIS MAY CAUSE THE PRONGS TO BREAK OFF OR CAUSE
PERMANENT DAMAGE TO THE CHARGE PORT.
• The charging indicator light should change to RED, indicating that
your device is now being charged.
• When the RED indicator light on your charger turns to GREEN, then
your device is fully charged.
• A full charge may take up to 2.5 hours.
• After fully charging your Cruze, unplug the charger from your
device and from the power outlet.
BATTERY SPECIFICATIONS
Battery Type: Rechargeable lithium-ion battery
Charge Time: Up to 2.5 hours
Voltage: 25.9 V
Initial Capacity: 2.15 AH
Working Temperature: 32°F - 113°F
Charging Temperature: 50°F - 77°F
Storage Time: 1 year
Storage Temperature: -4°F - 122°F
Storage Humidity: 5% - 95%
BATTERY MAINTENANCE
The lithium-ion battery is built into the device. Do not disassemble the
device to remove the battery or attempt to separate it from the
device.
• The Cruze can be stored at full power for approximately 3 months.
If not In use, it is recommended that you recharge the battery once
a month to maintain battery life.
• Use only the charger and charging cable supplied by Hover-1. Use
of any other charger or cable may lead to damage to the product,
overheating and risk of fire. Use of any other charger or cable voids
the manufacturer warranty.
• Do not connect or attach the device or the battery to a power
supply plug or directly to a car’s cigarette lighter.
• Do not place the device or batteries near a fire, or into direct sunlight.
Heating the device and/or the battery can cause additional heating,
breaking, or ignition of the battery inside the device.
• Do not continue charging the battery if it does not recharge within
the specified charging time. Doing so may cause the battery to
overheat, rupture, or ignite.
To preserve natural resources, please recycle or dispose of batteries
properly. This product contains lithium-ion batteries. Local, state, or
federal laws may prohibit disposal of lithium-ion batteries in ordinary
trash. Consult your local waste authority for information regarding
available recycling and/or disposal options.
• Do not attempt to modify, change, or replace your battery.
• Do not use your device if the battery begins to emit odor,
overheats, or begins to leak.
• Do not touch any leaking materials or breathe fumes emitted.
• Do not allow children or animals to touch the battery.
• The battery contains dangerous substances, do not open the
battery, or insert anything into the battery.
• Please only use the charger provided by Hover-1.
• Do not attempt to charge the device if the battery has discharge
or emits any substances. In that case, immediately distance yourself
from the battery in case of fire or explosion.
• Lithium-ion batteries are considered to be hazardous materials.
Please follow all local, state and federal laws in regards to recycling,
handling and disposing of Lithium-ion batteries.
Page 17
16
WARNING
Failure to follow the safety precautions
listed below could lead to serious
bodily injury and/or death.
the manufacturer warranty.
• Do not connect or attach the device or the battery to a power
supply plug or directly to a car’s cigarette lighter.
• Do not place the device or batteries near a fire, or into direct sunlight.
Heating the device and/or the battery can cause additional heating,
breaking, or ignition of the battery inside the device.
• Do not continue charging the battery if it does not recharge within
the specified charging time. Doing so may cause the battery to
overheat, rupture, or ignite.
To preserve natural resources, please recycle or dispose of batteries
properly. This product contains lithium-ion batteries. Local, state, or
federal laws may prohibit disposal of lithium-ion batteries in ordinary
trash. Consult your local waste authority for information regarding
available recycling and/or disposal options.
• Do not attempt to modify, change, or replace your battery.
• Do not use your device if the battery begins to emit odor,
overheats, or begins to leak.
• Do not touch any leaking materials or breathe fumes emitted.
• Do not allow children or animals to touch the battery.
• The battery contains dangerous substances, do not open the
battery, or insert anything into the battery.
• Please only use the charger provided by Hover-1.
• Do not attempt to charge the device if the battery has discharge
or emits any substances. In that case, immediately distance yourself
from the battery in case of fire or explosion.
• Lithium-ion batteries are considered to be hazardous materials.
Please follow all local, state and federal laws in regards to recycling,
handling and disposing of Lithium-ion batteries.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Please note that changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC INSTRUCTIONS FOR A CLASS B DIGITAL DEVICE OR
PERIPHERAL
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Page 18
17
FCC STATEMENT
WARNING
SEEK IMMEDIATE MEDICAL ASSISTANCE IF
YOU ARE EXPOSED TO ANY SUBSTANCE
THAT IS EMITTED FROM THE BATTERY.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Please note that changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC INSTRUCTIONS FOR A CLASS B DIGITAL DEVICE OR
PERIPHERAL
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Do not expose the device to liquid, moisture, or humidity to avoid
damage to the product's internal circuitry.
• Do not use abrasive cleaning solvents to clean the device.
• Do not expose the device to extremely high or low temperatures as
this will shorten the life of the electronic device, destroy the battery,
and/or distort certain plastic parts.
• Do not dispose of the device in fire as it may explode or combust.
• Do not expose the device to contact with sharp objects as this will
cause scratches and damage.
• Do not let the device fall from high places, as doing so may
damage the internal circuitry.
• Do not attempt to disassemble the device.
Page 19
18
CARE & MAINTENANCE
WARNING
Avoid using water or other liquids for
cleaning. If water or other liquids enter
the Cruze, it will cause permanent
damage to the internal components.
CAUTION
Users who disassemble the Cruze
skateboard without permission will void
the warranty.
• Do not expose the device to liquid, moisture, or humidity to avoid
damage to the product's internal circuitry.
• Do not use abrasive cleaning solvents to clean the device.
• Do not expose the device to extremely high or low temperatures as
this will shorten the life of the electronic device, destroy the battery,
and/or distort certain plastic parts.
• Do not dispose of the device in fire as it may explode or combust.
• Do not expose the device to contact with sharp objects as this will
cause scratches and damage.
• Do not let the device fall from high places, as doing so may
damage the internal circuitry.
• Do not attempt to disassemble the device.
Page 20
19
WARRANTY
This product comes with a 30 day limited replacement warranty
for manufacturer’s defects. This includes defects to the motor,
sensor battery, etc.
This product comes with a 120 day parts and labor warranty.
Shipping & handling costs are not included.
The condition of this warranty and our responsibilities under this
warranty are as follows:
Manufacturer's warranty is non-transferable. And this warranty is
limited to the original purchaser only.
* You must be able to prove the date of original purchase of the
device with a dated receipt.
* Warranty period begins on date of purchase, not date of first
use.
* The warranty is not applicable if the product has been subject to
physical abuse, improper installation, modification or repair by
unauthorized third party.
* The responsibility of manufacturer shall be limited to the repair or
replacement of the product at its sole discretion.
* Specifically exempt from any warranty are limited-life
consumable components subject to normal wear and tear such
as tires, decorates and other accessories.
* The manufacturer will not take any responsibility if the failure of
the unit has resulted from accident, abuse, misuse, or any
unauthorized repair, modification or disassembly.
* Modification and repair of the device should be done by
authorized and qualified service personnel or the manufacturer.
* This warranty gives you specific legal rights, and you may also
have other rights which vary under local laws.
The following conditions comprise the requirements and scope of
our warranty conditions and do not affect our legal and
contractual warranty obligations.
Page 21
20
We offer a warranty on our products in accordance with the
following conditions:
1) The warranty does not cover over-charging, or damages due
to improperly maintaining lithium-ion battery installed in unit. The
warranty does not cover wheels and other parts, which are
considered consumables, parts that break easily such as glass or
plastic or defects based on normal wear and tear. There is not
warranty obligation in the event of marginal differences
compared to the target appearance and workmanship provided
these have a negligible effect on the product’s fitness for use, in
the event of damage caused by chemical or electrochemical
effects, by water or generally from abnormal conditions.
2) The warranty will be performed in such a way that we shall
decide whether to repair the defective parts or to replace them
with working parts free of charge. Hover-1 reserves the right to
exchange the product for a replacement product of equal value
if the product sent in cannot be repaired within a reasonable time
or at a reasonable cost. All repairs are performed at a Hover-1
facility. Parts that have been replaced or exchanged become
property of Hover-1.
3) The warranty claim does not apply if repairs or other work is
carried out by unauthorized persons or if our products are
equipped with additional parts or accessories that are not
approved for the Cruze.
4) Warranties that have been activated do not cause the
warranty period to be extended, nor do they trigger a new
warranty period. The warranty period for any replacement parts
installed ends with the warranty period for the entire product.
5) Any other further claims are excluded, especially those for
replacement due to damage caused to the outside of the
product, provided there is no obligatory legal liability.
We therefore accept no liability for accidental, indirect or other
consequential damage of any kind, which leads to usage
restrictions, data loss, and loss of earnings or interruption to
business.
Asserting a warranty claim:
1) To make use of the warranty services, you must contact the
Hover-1 Service Center by visiting www.Hover-1.com or emailing
Page 22
21
support@hover-1.com
2) Hover-1 will try to diagnose and solve your problem. If it is
determined that a warranty claim exists, you will be given an RMA
number (Return Material Authorization) and will be asked to send
the product to Hover-1.
IMPORTANT: Hover-1 will only accept parcels that have an RMA
number.
Please observe the following when sending the product:
1) Send the product suitably packaged with carriage and
insurance paid. The charger MUST be included. Use only a carrier
that provides tracking.
2) Mark the RMA number on the outside of the package in such a
way that is visible and clearly legible.
3) You must enclose a copy of the receipt as proof of purchase.
4) Once Hover-1 has received the product, it will meet its warranty
obligations in accordance with the warranty conditions and will
return the product to the sender. Outbound return shipping will be
paid by Hover-1.
SERVICE OUTSIDE OF WARRANTY
Hover-1 can refuse any service claim made that is not covered by
the warranty. Please contact support@hover-1.com for pricing
and availability of repairs, outside of warranty.
If Hover-1 agrees to provide a service outside the warranty, the
customer will be invoiced for all repair and transport costs.
Hover-1 will not accept any packages that have not first been
approved by Hover-1 by means of an RMA (Return Material
Authorization).
Contact us with questions at:
support@Hover-1.com
www.Hover-1.com
Hover-1
Edison, NJ 08837
Affix Serial Number Label Here:
Page 23
PERFORMANCE
DESIGN
The Cruze is a power-assisted skateboard equipped with a
150 Watt brushless motor. It provides a convenient, smooth
form of transportation allowing you to travel up to 5 miles
with a max speed of 11.18 mph.
Cruze is designed to be easily controlled, providing a safe
stable form of travel. The Cruze only requires 2.5 hours of
charging for a full charge.
• TRAVEL UP TO 5 MILES
• MAXIMUM SPEED UP TO 11.18 MPH
• SUPPORTS UP TO 198 LBS
• FULLY CHARGES IN 2.5 HOURS
Loading...
