Operation Manual HY-H1-BGY
*Images used in this manual may vary slightly from
the product and are for reference purposes only.
IMPORTANT: KEEP FOR FUTURE REFERENCE
Even if you have ridden a scooter for years, it is important for you
and every rider to read this manual before using this product.
1
HELMETS SAVE LIVES!
Always wear a properly tted helmet that complies with CPSC or CE safety standards
when you ride your scooter.
WARNING
Correct Fitting:
Make sure your helmet
covers your forehead.
Incorrect Fitting:
Forehead is exposed
and vulnerable to
serious injury.
2
This manual is designed to give you the information you need for the safe operation and maintenance of your
new Hover-1 Buggy. Please read it thoroughly before riding your Hover-1 Buggy.
Section One of this manual involves safety and Hover-1 Buggy care. Understanding and following this
Information will help you and your Hover-1 Buggy avoid injury or damage.
Section Two of this manual gives assembly and installation instructions for your Hover-1 Buggy.
Section Three of this manual covers specic safety and operating instructions for your Hover-1 Buggy. Even if
you are an experienced rider, you should review this section before your rst ride.
Section Four of this manual covers warranty specications of your Hover-1 Buggy.
INTRODUCTION
WARNING
Make sure you read this complete manual before riding
your Hover-1 Buggy. Failure to do so, or failure to follow its
guidelines could lead to serious injury or death.
3
HOVER-1 BUGGY DIAGRAM
SPECIFICATIONS
1. Seat
2. Handle Bars
3. Pedal Mounts
4. Adjustable Strap
5. Seat Frame
6. Locker
7. Frame
8. Foot Rests
9. Front Wheel
Compatibility: Most self-balancing scooters
Max Load: See max load of your self-balancing scooter
Tire Size: 4” swivel caster
Seat Material: PP
4
1
2
3
4
5
6
7
8
9
2
3
4
6
8
PARTS LIST
(1) Seat
(1) Seat Frame
(1) Frame
(1) Left Handle Bar
(1) Right Handle Bar
(2) Strap with velcro
(1) Wrench
(4) Small Foam pad
(1) Allen Wrench
(2) Locker
(2) 8*35 Screw
(4) M6*16 Screw
(4) Spare strap
with velcro
(2) 8mm Nut
5
ASSEMBLING YOUR HOVER-1 BUGGY
If you have questions or concerns about any of these steps, please feel free to contact our Customer Service
Team at support@Hover-1.com. Someone will be in touch to walk you through these steps.
Carefully follow the steps shown on the following pages for assembling the Hover-1 Buggy.
Remove all Hover-1 Buggy contents from the box. Ensure all contents from the “Parts List” section are
accounted for.
1. Locate the 4 foam pads and both handle bars. Remove the adhesive backing from each foam pad and
center to each side of the papal mounts as shown below. Ensure all of the foam pads are prosperity adhered
to pedal mounts.
6
2. Locate the provided 8*35 Screw and 8mm Nut. Attach the left and right handle bars to the seat frame as shown
below.
3. Insert the frame into the seat frame. Adjust the frame and the seat frame to your preferred size. Secure the frame
in place using the locker.
7
Seat Frame
4. Align the holes of the seat with the seat frame. Secure the seat in place by M6*16 screws using allen wrench.
5. Your Hover-1 Bubby is now completely assembled and should look like the below image.
8
INSTALLING YOUR HOVER-1 BUGGY
If you have questions or concerns about any of these steps, please feel free to contact our Customer Service
Team at support@Hover-1.com. Someone will be in touch to walk you through these steps.
Carefully follow the steps shown on the following pages for installing the Hover-1 Buggy onto your electric
scooter. Read the remainder of this manual before riding your Hover-1 Buggy.
Your Hover-1 Buggy should be completely assembled prior to installing it onto your electric scooter. Please
refer to the “Assembling your Hover-1 Buggy” section for assembling procedures.
1. Place the pedal mounts onto the foot pedals of your self-balancing scooter with the front wheel facing
forward. Ensure the pedal mounts are centered on the foot pedals of your scooter as much as possible.
9
2. Secure your Hover-1 Buggy to your self-balancing scooter using both adjustable straps with Velcro. With the
velcro side facing away from your scooter, attach one hook of each adjustable strap to the back of each
pedal mount.
3. Wrap both adjustable straps under your self-balancing scooter and attach the second hook of each
adjustable strap to the front of each pedal mount.
10
4. Adjust both adjustable straps so that they are secured tightly around your scooter.
5. Your Hover-1 Buggy should be properly installed onto your scooter as shown below.
11
HOVER-1 BUGGY OPERATION
It is important that you fully understand all elements of your Hover-1 buggy. If these elements are not used
correctly, you will not have full control of your Hover-1 Buggy. Before you ride fast, or outside of a controlled
environment, learn the functions of the various mechanisms on your Hover-1 Buggy.
Practice using the elements of your Hover-1 Buggy at slower speeds in a at, open area before taking the Hover-1
Buggy on public roads.
BEFORE RIDING
WARNING
Any scooter that does not work properly can cause you to
lose control and fall. Inspect the entire device thoroughly
before every ride, and do not ride it until any problems have
been corrected.
WARNING
Do not ride a Hover-1 Buggy with a part that is damaged;
replace the damaged part before riding.
12
Ensure that your Hover-1 Buggy and scooter are in proper working order each and every time you ride. If a part of
the Hover-1 Buggy does not function correctly, please contact our Customer Support Center.
• Ensure your tire pressure is at the suggested PSI level for your scooter before riding.
• Ensure the battery of your scooter is fully charged before riding your Hover-1 Buggy.
• Ensure that the screws on the Hover-1 Buggy are locked rmly before each ride.
• Check to ensure the tires of your scooter are not worn.
• Check to ensure all connections are maintained on your scooter.
PRE-RIDE HOVER-1 BUGGY CHECKLIST
13
SAFETY PRECAUTIONS
The rst rule in safe riding is to use common sense. A Hover-1 Buggy is vulnerable; it cannot protect you in a crash,
against impact, or loss of control the way driving a car can. A Hover-1 Buggy can tip over sideways or pitch you
over the front wheel. It moves faster than a typical scooter. It does not have bumpers or airbags as a car does. This
section is a guide of safe riding practices for operation. Make sure you are using your Hover-1 Buggy properly.
Dierent localities and countries have dierent laws governing riding on public roads, and you should check with
local oicials to ensure you are complying with these laws.
Hover-1 is not liable for tickets or violations given to riders who do not follow these regulations.
• For your safety, always wear a helmet that meets CPSC or CE safety standards. In the event of an accident, a
helmet can protect you from serious injury and in some cases, even death.
• Obey all local laws, stop signs, pedestrian crosswalks, etc.
• If riding with friends and multiple Hover-1 Buggys, ride single le in a straight line.
• Have a satisfactory signaling device (bell, horn, etc.) to warn drivers and pedestrians of your approach.
• Ride defensively; expect the unexpected.
• Give pedestrians the right-of-way.
• Do not ride too close to pedestrians and alert them if you intend to pass them from behind.
14
• Slow down at all street intersections and look to the left and right before crossing.
•Obey all traic signals.
• Always use proper hand signals for turning and stopping. Give signals 100ft before stopping or turning and
always return both hands to the handle bars before stopping or turning.
• Watch for cars pulling out into traic and for the sudden opening of car doors.
• Avoid potholes, drainage grates or other hazards.
• Cross railroad tracks at a right angle.
• Be careful when riding on soft road edges, gravel, sand and uneven surfaces. Ride slowly and avoid quick turns
when riding on these surfaces.
• Never hitch onto other vehicles.
• Do not “stunt” ride or race in traic.
• Do not weave in and out of traic or swerve from side to side.
• A crash can put extraordinary stress on Hover-1 Buggy components, possibly causing them to fatigue
prematurely. Components suering from stress fatigue can fail suddenly, causing loss of control or serious injury.
CAUTION: RIDING IN WET WEATHER
Brakes do not work as well under wet conditions as they do when dry. It is recommended that you do not ride your
Hover-1 Buggy in wet weather, as there are electronic components in your scooter that may be damaged if
exposed to water.
15
1. This product is strictly forbidden to use on roads and highways, unless your local laws state otherwise. You must
wear a safety helmet, knee and elbow pads and other necessary protective gear when riding your Hover-1
Buggy.
2. Due to the particularity of the product, the assembly pieces are to be checked before every ride to avoid an
accident while riding.
3. Do not make sharp turns as you may drift and over-turn the Hover-1 Buggy, which can result in injury to yourself
and/or damage the unit.
4. Do not operate near swimming pools or other bodies of water.
To reduce the risk of injury, adult supervision is required.
Never use in roadways, near motor vehicles, on or near
steep inclines or steps, swimming pools or other bodies of
water; always wear shoes, and never allow more than one rider.
WARNING:
16
RIDING YOUR HOVER-1 BUGGY
Ensure your Hover-1 Buggy is fully assembled and correctly installed onto your scooter with all straps and
screws secured in place. Ensure your scooter is properly maintained as well. Failure to do so may result in
serious bodily harm or death and damage to the unit.
After reviewing the pre-ride checklist, follow the steps below to begin riding your Hover-1 Buggy.
1. Turn on your scooter.
2. Sit comfortably in the Hover-1 Buggy seat.
2. Place your feet onto the foot rests.
3. Firmly grip both handle bars and slowly push them downward simultaneously to move forward.
4. When riding, slowly pull both handle bars upwards simultaneously to brake.
5. To reverse, slowly pull both handle bars upwards simultaneously.
6. To turn right, push the right handle bar down while holding the left handle bar in neutral position.
7. To turn left, push the left handle bar down while holding the right handle bar in neutral position.
17
This product comes with a 30 day limited replacement warranty for manufacturer’s defects. This includes defects
to the seat, wheel, etc.
This product comes with a 120 day parts and labor warranty. Shipping & handling costs are not included.
The condition of this warranty and our responsibilities under this warranty are as follows:
Manufacturer's warranty is non-transferable. And this warranty is limited to the original purchaser only.
* You must be able to prove the date of original purchase of the Buggy with a dated receipt.
* Warranty period begins on date of purchase, not date of rst use.
* The warranty is not applicable if the product has been subject to physical abuse, improper installation,
modication or repair by unauthorized third party.
* The responsibility of manufacturer's products shall be limited to the repair or replacement of the product at its
sole discretion.
* Specically exempt from any warranty are limited-life consumable components subject to normal wear and
tear such as tires, decorates and other accessories.
WARRANTY
18
*The manufacturer will not take any responsibility if the failure of the unit has resulted from accident, abuse,
misuse, or any unauthorized repair, modication or disassembly.
* Modication and repair of the Buggy should be done by authorized and qualied service personnel or
manufacturer.
* This warranty gives you specic legal rights, and you may also have other rights which vary under local laws.
The following conditions comprise the requirements and scope of our warranty conditions and do not aect our
legal and contractual warranty obligations.
We oer a warranty on our products in accordance with the following conditions:
1) The warranty does not cover tires and other parts, which are considered consumables, parts that break easily
such as glass or plastic or defects based on normal wear and tear. There is not warranty obligation in the event
of marginal dierences compared to the target appearance and workmanship provided these have a
negligible eect on the product’s tness for use, in the event of damage caused by chemical or
electrochemical eects, by water or generally from abnormal conditions.
2) The warranty will be performed in such a way that we shall decide whether to repair the defective parts or to
replace them with working parts free of charge. Hover-1 reserves the right to exchange the product for a
replacement product of equal value if the product sent in cannot be repaired within a reasonable time or at a
reasonable cost. All repairs are performed at a Hover-1 facility. Parts that have been replaced or exchanged
become property of Hover-1.
3) The warranty claim does not apply if repairs or other work is carried out by unauthorized persons or if our
products are equipped with additional parts or accessories that are not approved for the Buggy.
4) Warranties that have been activated do not cause the warranty period to be extended, nor do they trigger a
new warranty period. The warranty period for any replacement parts installed ends with the warranty period for
19
the entire product.
5) Any other further claims are excluded, especially those for replacement due to damage caused to the
outside of the product, provided there is no obligatory legal liability.
We therefore accept no liability for accidental, indirect or other consequential damage of any kind, which
leads to usage restrictions, data loss, and loss of earnings or interruption to business.
Asserting a warranty claim:
1) To make use of the warranty services, you must contact the Hover-1 Service Center by visiting
www.Hover-1.com or emailing support@hover-1.com
2) Hover-1 will try to diagnose and solve your problem. If it is determined that a warranty claim exists, you will be
given an RMA number (Return Material Authorization) and will be asked to send the product to Hover-1.
IMPORTANT: Hover-1 will only accept parcels that have an RMA number.
Please observe the following when sending the product:
1) Send the product suitably packaged with carriage and insurance paid. Use only a carrier that provides
tracking.
2) Mark the RMA number on the outside of the package in such a way that is visible and clearly legible.
3) You must enclose a copy of the receipt as proof of purchase.
4) Once Hover-1 has received the product, it will meet its warranty obligations in accordance with the warranty
conditions and will return the product to the sender. Outbound return shipping will be paid by Hover-1.
20
SERVICE OUTSIDE OF WARRANTY
Hover-1 can refuse any service claim made that is not covered by the warranty. Please contact
support@hover-1.com for pricing and availability of repairs, outside of warranty.
If Hover-1 agrees to provide a service outside the warranty, the customer will be invoiced for all repair and
transport costs. Hover-1 will not accept any packages that have not rst been approved by Hover-1 by means
of an RMA (Return Material Authorization).
Contact us with questions at:
support@Hover-1.com
www.Hover-1.com
Hover-1
Edison, NJ 08837
21
@hypehover_1
Facebook.com/hover1tranz
www.Hover-1.com
Loading...
