ASSEMBL
W
ARNING:
Electrical Danger T
urn Power Off
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
Y
ou will need 5-Candelabra Base Bulb
40Watts Recommended 60 W
atts Max.
USE LED BULBS FOR EXTENDED USE
How to Install
1.Do a complete inventory of all parts and
components before you start installing
2.After safely attaching fixture into outlet box,
install candle sleeve,bulbs and proceed to
connecting the power
.
3.When you begin to dress the fixture, start with
packet labeled (A)
4.IMPOR
TANT: Apply crystal sets in alphabetical
order
A. (14mm+50mm)x44sets
Crystal Sets
B. (14mmx1pc+40mm ball)x1set
C. (14mmx2pcs+40mm ball)x1set
A
B
C
U
L
The fixture is damp rated
Y
INSTRUCTION
A
B. (2)-Outlet Box Screws
A. (1)-Mounting Plate
C. (3)-Wire Connector
D. (2)-Screw
E. (1)-Ground Screw
F
. (5)-Metal Sleeve (H2.36" ) XEH5930CHMCDL2.36IN
G. (5)-Plastic Sleeve (H2.36") XEH5930PCDL2.36IN
H. (2)-Ball Nuts XEH5930CHBANUT
I. (1)-Frame
Part Numbers
Part Number
B
E
C
Outlet Box
F
G
H
I
D
ASSEMBL
Y
INSTRUCTION
