Hotpoint Ariston SA2540HIX Daily Reference Manual
EN
1
PRODUCT DESCRIPTION
DAILY REFERENCE
GUIDE
CONTROL PANEL
Before using the appliance carefully read the Health and Safety guide.
1. Control panel
2. Fan
3. Lamp
4. Accessory guides
(the level is indicated on the wall of
the cooking compartment)
5. Door
6. Upper heating element/grill
7. Identification plate
(do not remove)
8. Lower heating element
(not visible)
1. SELECTION KNOB
For switching the oven on by
selecting a function.
Turn to the
position to switch
the oven off.
2. LIGHT
With the oven switched on, press
to turn the oven compartment
lamp on or off.
3. SETTING THE TIME
For accessing the cooking time
settings, delayed start and timer.
For displaying the time when the
oven is off.
4. D I SPLAY
5. ADJUSTMENT BUTTONS
For changing the cooking time
settings.
6. THERMOSTAT KNOB
Turn to select the temperature you
require when activating manual
functions. Automatic functions use
0/A.
1 32 4 5 6
THANK YOU FOR PURCHASING AN
HOTPOINT PRODUCT
To receive more comprehensive help and
support, please register your product at
www. hotpoint. eu/ register
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website www . hotpoint . eu and following
the instructions on the back of this booklet.
1
2
3
4
5
7
8
6
2
CONVENTIONAL*
For cooking any kind of dish on one shelf only.
CONVECTION BAKE
For cooking on a maximum of two shelves at
the same time. It is a good idea to swap the position
of the baking trays halfway through cooking.
GRILL
For grilling steaks, kebabs and sausages,
cooking vegetables au gratin or toasting bread.
When grilling meat, we recommend using a drip tray
to collect the cooking juices: Position the pan on any
of the levels below the wire shelf and add 200 ml of
drinking water.
TURBO GRILL
For roasting large joints of meat (legs, roast
beef, chicken). We recommend using a drip tray to
collect the cooking juices: Position the pan on any
of the levels below the wire shelf and add 200 ml of
drinking water.
ECO CONVECTION BAKE*
For cooking roasts and stuffed roasting joints
on a single shelf. Food is prevented from drying out
excessively by gentle, intermittent air circulation.
When this ECO function is in use, the light will
remain switched off during cooking but can be
switched on again by pressing
.
BREAD AUTO
This function automatically selects the ideal
temperature and baking time for bread. For best
results, carefully follow the recipe
WWW
. Activate the
function when the oven is cold.
ACCESSORIES
Download the Use and Care Guide from
www.hotpoint.eu for more information
WWW
WIRE SHELF BAKING TRAY
The number of accessories may vary depending on which model is purchased.
Other accessories can be purchased separately from the After-sales Service.
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
. Insert the wire shelf onto the level you require
by holding it tilted slightly upwards and resting
the raised rear side (pointing upwards) down first.
Then slide it horizontally along the runners as far as
possible.
. Other accessories, like the baking tray, are to be
inserted horizontally, letting them slide on the
runners.
DESSERTS AUTO
This function automatically selects the ideal
temperature and baking time for cakes. Activate the
function when the oven is cold.
DIAMOND CLEAN
The action of the steam released during this
special low-temperature cleaning cycle allows dirt
and food residues to be removed with ease. Pour 200
ml of drinking water on the bottom of the oven and
only activate the function when the oven is cold.
FUNCTIONS
Download the Use and Care Guide from
www.hotpoint.eu for more information
WWW
* Function used as reference for the energy eciency
declaration in accordance with Regulation (EU) No. 65/2014
EN
3
1. SETTING THE TIME
You will need to set the time when you switch on the
appliance for the first time: Press
until the
icon and the two digits for the hour start flashing on
the display.
Use or to set the hour and press to confirm.
The two digits for the minutes will start flashing. Use
or to set the minutes and press to confirm.
Please note: When the icon is ashing, for example
following lengthy power outages, you will need to reset the
time.
2. HEATING THE OVEN
A new oven may release odours that have been left
behind during manufacturing: This is completely
normal.
Before starting to cook food, we therefore
recommend heating the oven with it empty in order
to remove any possible odours.
Remove any protective cardboard or transparent film
from the oven and remove any accessories from inside
it.
Heat the oven to 250 °C for about one hour,
preferably using the “Convection Bake” function. The
oven must be empty during this time.
Follow the instructions for setting the function
correctly.
Please note: It is advisable to air the room after using the
appliance for the rst time.
USING THE APPLIANCE FOR THE FIRST TIME
1. SELECT A FUNCTION
To select a function, turn the selection knob to the
symbol for the function you require: The display will
light up and an audible signal will sound.
2. ACTIVATE A FUNCTION
MANUAL
To start the function you have selected, turn the
thermostat knob to set the temperature you require.
Please note: During cooking you can change the function
by turning the selection knob or adjust the temperature by
turning the thermostat knob.
The function will only start if the thermostat knob is on 0 °C.
You can set the cooking time, cooking end time (only if you
set a cooking time) and a timer.
AUTOMATIC
To start the automatic function you have selected
(“Bread” or “Cakes”), keep the thermostat knob at the
position for automatic functions (0/A).
To finish cooking, turn the selection knob to position 0.
Please note: You can set the cooking end time and timer.
3. PREHEATING
Once the function starts, an audible signal and a
flashing icon
on the display indicate that the
preheating phase has been activated.
At the end of this phase, an audible signal and the
fixed icon
on the display will indicate that the oven
has reached the set temperature: At this point, place
the food inside and proceed with cooking.
Please note: Placing the food in the oven before preheating
has nished may have an adverse eect on the nal cooking
result.
. PROGRAMMING COOKING
You will need to select a function before you can start
programming cooking.
DURATION
Keep pressing until the icon and “00:00” start
flashing on the display.
Use or to set the cooking time you require, then
press
to confirm.
Activate the function by turning the thermostat knob
to the temperature you require: An audible signal will
sound and the display will indicate that cooking is
complete.
Please note: To cancel the cooking time you have set, keep
pressing until the icon starts ashing on the display,
then use to reset the cooking time to “00:00”.
This cooking time includes a preheating phase.
DAI LY USE
