Hotpoint WF100 Guide
Washing Machine Programme Guide
6kg
Aquarius
Aquarius
+
Wash Labels Explained
2
GB
The number inside the wash tub shows the maximum water temperature,
in ˚C.
If there are no bars, the garment can be spun and rinsed as normal.
One bar indicates a reduced spin speed programme should be used.
Two bars mean the clothes need a mild wash action, but can be spun and
rinsed normally. Such items should not be wrung out by hand.
If the tub contains a hand, wash the item on a Hand Wash programme.
A triangle means that you can safely use a cold, dilute solution of bleach.
A triangle with a cross over it means the item cannot be bleached.
A circle inside a square means you can tumble dry the garment.
The dots indicate temperature
- one dot for lower heat.
- two dots for higher heat.
A cross over this symbol shows you should not tumble dry the garment.
A circle means the garment is suitable for dry-cleaning.
A letter inside the circle is to tell the dry-cleaner which chemical wash and
method to use.
Contents
Wash Labels Explained, 2
Washing Machine Description, 4-5
Aquarius
Aquarius
+
Programmes and Option Modifiers, 6-11
Special features
Option modifiers
Programme table
Starting a wash programme
A typical wash load
Automatic features
Troubleshooting, 12-13
Problems and solutions
Safety Advice, 14
Disposal of old electrical appliances
Technical Details, 15
Service, 16
Before calling for assistance
Spare parts
Key Contacts
3
Wash Labels
Explained
Contents Description
Programmes and
Option Modifiers Troubleshooting
Safety
Advice
Technical
Details Service
GB
WASHING MACHINE
Washing Machine
Description
Aquarius
GB
Programme listing
Detergent dispenser
drawer
Option
buttons
Status indicator
lights
Variable Temperature
dial*
Variable Spin Speed
Start/Cancel
button
Programme selector
dial
dial*
Aquarius control panel features
●
Programme listing: To consult a straight forward chart of the different programmes available.
●
Option buttons: To select the options available (see Programme Table and Option Modifiers).
●
Variable Temperature dial: To reduce the selected programmes wash temperature*.
●
Variable Spin Speed dial: To reduce the selected programmes spin speed*.
●
On/Off button: To turn the washing machine on and off.
●
Start/Cancel button: To start the programme or to cancel it, if incorrect settings were selected.
●
Programme selector dial: To select the programme you require. The knob stays still during the cycle.
●
Status indicator lights: Shows if the door is locked (when lit, the door cannot be opened) and the stage of
the programme that the machine has reached (wash, rinse or spin).
On/Off
button
*Note: Depending on the model purchased, your washing machine control panel may differ from the above and have
only one variable dial, either the Variable Temperature or the Variable Spin Speed dial.
4
Washing Machine
Description
Aquarius
+
Programme listing
Option
buttons
Status indicator
lights
Start/Cancel
button
Digital display
Detergent dispenser
drawer
Variable Temperature
button
Programme selector
dial
Variable Spin Speed
button
Aquarius+control panel features
●
Programme listing: To consult a straight forward chart of the different programmes available.
●
Option buttons: To select the options available (see Programme Table and Option Modifiers).
●
Variable Temperature button: To reduce the selected programmes wash temperature.
●
Variable Spin Speed button: To reduce the selected programmes spin speed.
●
Digital display: Shows time remaining, wash temperature and spin speed for the selected programme.
●
On/Off button: To turn the washing machine on and off.
●
Start/Cancel button: To start the programme or to cancel it, if incorrect settings were selected.
●
Programme selector dial: To select the programme you require. The knob stays still during the cycle.
●
Status indicator lights: Shows if the door is locked (when lit, the door cannot be opened) and the stage of
the programme that the machine has reached (wash, rinse or spin).
On/Off
button
GB
Wash Labels
Explained
Contents Description
Programmes and
Option Modifiers Troubleshooting
Advice
Safety
Technical
Details Service
5
