Washers
Hotpoint.com
Safety Instructions . . . . . . . . . . . . 2
Control Panels . . . . . . . . . . . . . . .3–5
Control Settings . . . . . . . . . . . . . 4, 6
Features . . . . . . . . . . . . . . . . . . . . . .7
Loading and Using
the Washer . . . . . . . . . . . . . . . . . .8, 9
Troubleshooting Tips . . . . . . 10–12
Consumer Support . . . . . Back Cover
Product Registration . . . . . . . . 13, 14
Warranty . . . . . . . . . . . . . . . . . . . . 15
Write the model and serial numbers here:
Model #__________________________
Serial # __________________________
You can find them behind the control panel on the back of your washer.
Owner’s Manual
VVSR1070
VBXR1090
VBSR3100
VWSR4150
VLXR1020
175D1807P347 39-90016 06-01 JR
Operating Instructions
Troubleshooting Tips
Consumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on all hot water faucets and allowing them to run for several minutes. Do this before using any electrical appliance which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located |
■ Install or store where it will not be exposed to |
in accordance with the Installation Instructions before |
temperatures below freezing or exposed to |
it is used. If you did not receive an Installation |
the weather. |
Instructions sheet, you can receive one by visiting |
■ Properly ground washer to conform with all |
Hotpoint.com, or by calling 800.GE.CARES (800.432.2737). |
|
|
governing codes and ordinances. Follow details |
|
in Installation Instructions. |
YOUR LAUNDRY AREA
■ Keep the area underneath and around your |
■ Close supervision is necessary if this appliance is |
appliances free of combustible materials such |
used by or near children. Do not allow children to |
as lint, paper, rags, chemicals, etc. |
play on, with, or inside this or any other appliance. |
WHEN USING THE WASHER |
|
Use this appliance only for its intended purpose as described in this Owner’s Manual.
■Never reach into washer while it is moving. Wait until the machine has completely stopped before opening the lid.
■Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover. Mixing different chemicals can produce
a toxic gas which may cause death.
■Do not wash or dry articles that have been cleaned in, washed in, soaked in, or spotted with combustible or explosive substances (such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents, kerosene, etc.) which may ignite or explode. Do not add these substances to the wash water. Do not use or place these substances around your washer or dryer during operation.
■The laundry process can reduce the flame retardancy of fabrics. To avoid such a result, carefully follow the garment manufacturer’s wash and care instructions.
■To minimize the possibility of electric shock, unplug this appliance from the power supply or disconnect the washer at the household distribution panel by removing the fuse or switching off the circuit breaker before attempting any maintenance or cleaning. NOTE: Turning the Cycle Selector knob to an off position or pressing PAUSE does NOT disconnect the appliance from the power supply.
■Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.
WHEN NOT IN USE
■Turn off water faucets to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur. Check the condition of the fill hoses; they should be replaced every 5 years.
■Before discarding a washer, or removing it from service, remove the washer lid to prevent children from hiding inside.
■Do not attempt to repair or replace any part of this appliance unless specifically recommended in this Owner’s Manual, or in published user-repair instructions that you understand and have the skills to carry out.
■Do not tamper with controls.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
2
About the washer control panel.
(models VVSR1070, VBXR1090, VBSR3100, and VLXR1020) |
Hotpoint.com |
You can locate your |
. |
• Add detergent |
|
• Add diluted fabric |
• Close lid |
softener (on models |
Quick Start Guide |
with a fabric |
|
softener dispenser) |
Model VVSR1070
Model VBXR1090
Model VBSR3100
3
Instructions Safety
Instructions Operating
Tips Troubleshooting
Support Consumer
Safety Instructions
Operating Instructions
Troubleshooting Tips
Consumer Support
About the washer control panel (cont.)
Model VLXR1020
OFF |
warm wash |
|
|
|
cold wash |
Control settings.
Load Size
Loosely load clothes no higher than the top row of holes in the washer tub. The water level should just cover the clothes. Adjust the load size accordingly.
Temperature
Select the water temperature for the wash and rinse cycles. On some models, the temperature is controlled by the wash cycle knob. Always follow fabric manufacturer’s care label or instructions when laundering.
Wash Cycle (on some models)
The wash cycle controls the length of the washing process. The chart below will help you match the wash cycle setting with your clothing.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
WRINKLE FREE For easy care, wrinkle-free and permanent press items.
KNITS Specially designed for normally soiled knits.
DELICATES For lingerie and special-care fabrics with light to normal soil.
4
About the washer control panel.
(model VWSR4150) Hotpoint.com
|
|
• Select load size and |
|
• Add detergent |
• Add clothes |
other wash options |
|
• Select wash cycle |
|
||
• Add diluted fabric |
|
• Close lid |
|
|
|
||
softener (on models |
|
|
• Pull knob |
with a fabric |
Quick Start Guide |
|
|
softener dispenser) |
|
Model VWSR4150
5
