Installation and Use

Contents

Build-under

Electric double oven

GB

English, 1

UCL 08 CB

Warnings,2

Introduction, 3

Safety Information, 4

Installation, 5

The main parts of your Double Oven , 8

Temperature Conversion Chart, 9

Controls,10

Multifunction Selection Switch , 11

The electronic programmer, 12

Grill Pan and Handle, 13

Operation when using the Top Oven for Grilling, 14

Using the Top Oven for Solarplus Grilling, 15

Using the Top Oven as a Convection Oven, 16

Operation when using the Top Oven as a Convection Oven, 17

Oven Temperature Charts, 18

Main Oven - Fan Grilling, 20

Main Oven - Fan Grilling Roasting Chart , 21

Using the Main Oven for Other Functions, 22

Main Oven - Conventional Oven , 23

Main Oven - Fan Oven , 24

Main Oven - Fan Oven Cookery Notes, 26

Main Oven Temperature Charts, 27

Main Oven - Circulaire Roasting 29

Main Oven - Circulaire Roasting Chart , 30

Using the Main Oven for Other Functions, 31

Main Oven Grilling , 32

Care and Cleaning , 33

If something goes wrong..., 36

Disposal of the appliance, 38

Guarantee Information, 39

Service Information, 40

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

Warnings

GB

• WARNING: The appliance and
its accessible parts become hot
during use.

• Care should be taken to avoid
touching heating elements.

• Children less than 8 years of
age shall be kept away unless
continuously supervised.
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.

• Do not use harsh abrasive
cleaners or sharp metal scrapers
to clean the oven door glass since
they can scratch the surface,
which may result in shattering of
the glass.

• Never use steam cleaners
or pressure cleaners on the
appliance.

• WARNING: Ensure that the
appliance is switched off before
replacing the lamp to avoid the
possibility of electric shock.

•

! When you place the rack inside,
make sure that the stop is directed
upwards and in the back of the cavity.

! VERY HOT SURFACES

! VERY HOT SURFACES! VERY HOT SURFACES

FOOD OR GREASE ON THESE
SURFACES COULD CAUSE
SMOKE AND POSSIBLY EVEN BURN

YOU MUST KEEP THE OVEN
AND GRILL CAVITIES CLEAN

! ATTENTION

! ATTENTION! ATTENTION

WHEN USING THE MAIN OVEN
YOU MUST ENSURE THAT THE

BASE OF THE CAVITY IS NOT
COVERED WITH ALUMINUM
FOIL, UTENSIL OR ANY OTHER
FORM OF COVERING. FAILURE
TO DO THIS MAY RESULT IN
THE CAVITY BEING DAMAGED.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

2

Introduction

To the Installer:

Before installation, fill in the product details on the back
cover of this book.
The information can be found on the rating plate.

To the User:

You must read the instructions prior to installing and
using the appliance and then retain them for future
reference.

! Before operating your new appliance please read
this instruction booklet carefully. It contains important
information concerning the safe operation, installation
and maintenance of the appliance.

! Please keep these operating instructions for future
reference. Pass them on to possible new owners of the
appliance.

Retention of this Instruction Book

This Instruction Book must be kept handy for reference
as it contains important details on the safe and proper
use of the appliance.

If you sell or pass the appliance to someone else, or
move house and leave it behind, make sure this Book
is also provided so the new owner can become familiar
with the appliance and safety warnings.

(a) Has been used solely in accordance with the

Users Instruction Book.

(b) Has been properly connected to a suitable

supply voltage as stated on the rating plate
attached to this equipment.

(c) Has not been subjected to misuse or accident

or been modified or repaired by any person
other than the authorised employee or agent.

(d) Has been correctly installed.

This appliance conforms with the following European
Economic Community directives:

- 2006/95/EC of 12/12/06 (Low Voltage) and subse­quent modifications;

- 2004/108/EC of 15/12/04 (Electromagnetic Compati­bility) and subsequent modifications;

- 90/396/EEC of 29/06/90 (Gas) and subsequent mo­difications (only for models which use gas);

- 93/68/EEC of 22/07/93 and subsequent modifications.

- 2002/96/EC

Technical Characteristics

GB

Your new appliance is guaranteed* and will give
lasting service. This guarantee is only applicable if the
appliance has been installed in accordance with the
installation instructions detailed in this booklet.
To help make best use of your cooking equipment,
please read this booklet carefully.
The appliance is designed specifically for domestic
use and responsibility will not be accepted for use in
any other installation.

When the cooker is first used an odour may be
emitted, this will cease after a period of use

To help remove the ‚new’ smell, heat up the empty
ovens to maximum temperature for a minimum of two
or three hours, keeping the oven doors closed. Ensure
that the room is well ventilated (e.g. open a window
or use an extractor fan) and that persons who may be
sensitive to the odour avoid any fumes.
It is suggested that any pets be removed from the
room until the smell has ceased.

This odour is due to temporary finish on oven liners
and elements and also any moisture absorbed by the
insulation.

Top Oven

ENERGY LABEL

ENERGY LABEL

Regulation (EU) No 65/2014 supplemen-

Regulation (EU) No 65/2014 supplemen­ting Directive 2010/30/EU.

ting Directive 2010/30/EU.
Regulation (EU) No 66/2014 implementing

Regulation (EU) No 66/2014 implementing
Directive 2009/125/EC.

Directive 2009/125/EC.
Standard EN 60350-1

Standard EN 60350-1
Standard EN 50564.

Standard EN 50564.

and ECODESIGN

and ECODESIGN

Usable Volume: 33 Litres

Declared energy consumption for
Natural convection Class

Main Oven

ENERGY LABEL

ENERGY LABEL

Regulation (EU) No 65/2014 supplemen-

Regulation (EU) No 65/2014 supplemen­ting Directive 2010/30/EU.

ting Directive 2010/30/EU.
Regulation (EU) No 66/2014 implementing

Regulation (EU) No 66/2014 implementing
Directive 2009/125/EC.

Directive 2009/125/EC.
Standard EN 60350-1

Standard EN 60350-1
Standard EN 50564.

Standard EN 50564.

and ECODESIGN

and ECODESIGN

heating mode: Conventional

Usable Volume: 59 Litres

Declared energy consumption for
Forced convection Class

heating mode: Fan Oven

Hob

ECODESIGN

Regulation (EU) No 66/2014 implementing
Directive 2009/125/EC.
Standard EN 60350-2.
Standard EN 50564.

* The guarantee is subject to the provisions that the

Voltage and Frequency

230-240V~ 50Hz

appliance:

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

3

For Your Safety

GB

When used properly your appliance is completely
safe but as with any electrical product there are
certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW
BEFORE USING YOUR APPLIANCE.

Always

 Always make sure you remove all packaging

and literature from inside the oven and grill
compartments before switching on for the first time.

 Always make sure you understand the controls

prior to using the appliance.

 Always keep children away from the appliance

when in use as the surfaces will get extremely hot
during and after cooking.

 Always make sure all controls are turned off when

you have finished cooking and when not in use.

 Always stand back when opening an oven door to

allow any build up of steam or heat to disperse.

 Always use dry, good quality oven gloves when

removing items from the oven/grill.

 Always take care to avoid heat/steam burns when

operating the controls.

 Always turn off the electricity supply at the wall

switch before cleaning and allow the appliance to
cool.

 Always make sure the shelves are in the correct

position before switching on the oven.

 Always keep the oven and grill doors closed when

the appliance is not in use.

 Always take care when removing utensils from

the top oven when the main oven is in use as the
contents may be hot.

 Always keep the appliance clean as a build up of

grease or fat from cooking can cause a fire.

 Always follow the basic principles of food handling

and hygiene to prevent the possibility of bacterial
growth.

 Always keep ventilation slots clear of obstructions.
 Always refer servicing to a qualified appliance

service engineer.

 During use the oven becomes hot. Care should be

taken to avoid touching heating elements inside
the oven.

SAFETY ADVICE

IN THE EVENT OF A CHIP PAN OR ANY OTHER
PAN FIRE:

1. TURN OFF THE COOKER APPLIANCE AT THE
WALL SWITCH.

2. COVER THE PAN WITH A FIRE BLANKET OR
DAMP CLOTH, this will smother the flames and
extinguish the fire.

3. LEAVE THE PAN TO COOL FOR AT LEAST 60
MINUTES BEFORE MOVING IT. Injuries are often

caused by picking up a hot pan and rushing
outside with it. NEVER USE A FIRE EXTINGUISHER
TO PUT OUT A PAN FIRE as the force of the
extinguisher is likely to tip the pan over. Never use
water to extinguish oil or fat fires.

Never

 Never leave children unsupervised where a

cooking appliance is installed as all cooking
surfaces will be hot during and after use.

 Never allow anyone to sit or stand on any part of

the appliance.

 Never store items above the appliance that

children may attempt to reach.

 Never remove the oven shelves whilst the oven is

hot.

 Never heat up unopened food containers as

pressure can build up causing the container to
burst.

 Never store chemicals, food stuffs or pressurised

containers in or on the appliance, or in cabinets
immediately above or next to the appliance.

 Never operate the grill with the door closed as this

will cause the appliance to overheat.

 Never use the appliance as a room heater.
 Never use the grill to warm plates.
 Never dry any items on the oven doors.
 Never install the appliance next to curtains or other

soft furnishings.

 Never allow children to play with the appliance

controls.

 Never use 'steam cleaners'.

This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental cpabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.

Children should be supervised to ensure that they do
not play with the appliance.

The appliance must be used by adults only for
the preparation of food, in accordance with the
instructions outlined in this booklet. Any other
use of the appliance (e.g. for heating the room)
constitutes improper use and is dangerous.
The manufacturer may not be held liable for any
damage resulting from improper, incorrect and
unreasonable use of the appliance.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

4

Installation

Electrical Requirements

For your own safety, we recommend that your cooker
is installed by a competent person such as one who is
registered with NICEIC (National Inspection Council for
Electrical Installation Contracting). The cooker should
be installed in accordance with the latest edition of the
IEE Regulations.

Warning: This appliance must be earthed.

Electrical Connections

The installer must check that the voltage shown on
the rating plate corresponds with the house electricity
supply. The cooker must be supplied via a suitable
double pole isolating switch, having a contact
separation of at least 3mm in all poles placed in a
readily accessible position adjacent to the cooker. If
the cooker is to be wired into a connector unit, this
may be positioned behind the cooker providing the
following requirements are met:

i) The connector unit must not project from the wall

more than 25mm.

ii) The top of the connector must not be more than

130mm above floor level.

Remove the terminal cover at the rear base of the
cooker. Pass the cable through the cable clamp and
connect to the appropriate terminals provided.
Allow sufficient cable for any future servicing.
Tighten the screws on the cable clamp and replace the
cover. Make main connections in the connector unit or
cooker control unit. This appliance conforms to B.S. EN
55014 regarding suppression of Radio and Television
reception interference.
A double Pole control switch having a minimum rating
of 32 amps should be used to feed the cooker using
a suitably rated cable. Where a hob is fitted adjacent
to or over the cooker, a 45 amp Double Pole control
switch should be used to feed both units via separate
suitably rated cables.
We recommend a minimum of 4mm2 PVC insulated
twin and earth cable conforming to B.S. 6004 for
connection of each appliance.

In all cases adhere to routing details (see fig. 5).

This appliance must not be installed over any other
appliance that generates heat such as a plinth heater.

Note; This cooker must not be fitted on a platform.

GB

FINAL INSTALLATION

a. Ensure that the adjacent cabinets and the gap

between them have dimensions in accordance with
the diagram.

b. Assemble the plastic plugs provided into the fixing

brackets. See diagram.

c. Fix the fixing brackets to the sides of the adjacent

cabinets so that the centre line of the brackets are
570mm above the top of the plinth line and the front
face of the plastic plug is level with the front face
of the cabinet sides. See diagram.

d. Adjust the feet on the cooker to their minimum

position, i.e. fully screwed in.

e. Slide the cooker centrally into the space between

the cabinets ensuring the following:
i) The gap between the cabinet sides and the

cooker is even along the length of the cabinet
sides.

ii) The cable is routed away from any vents in the

rear panel and is not trapped between the co­oker and the wall, adjacent cabinets or under
the feet

f. Adjust the feet using an open ended spanner until

the bottom of the cooker door is in line with the top
of the plinth. Using a spirit level, check that the
cooker is level in all directions.

g. Check that the plinth can be fitted. If necessary re

- adjust the feet and check that the cooker is level.
Then lock the feet into position by tightening the
lock nut using an open ended spanner.

h. Open the top oven door and fix the cooker to the

brackets through the holes in the side trims.
i. Fix the plinth in position.
j. Ensure that there is a minimum gap of 1mm betwe-

en the cooker side trim and the adjacent cabinet

doors or drawer fronts.
k. If a hob is to be installed directly above the cooker

it must not project downwards more than 20mm

below the underside of the work top. Any projection

of more than 10mm must not project more than

500mm from the wall.

Fig. 5

Note: Due to many different types of installation, a
mains cable is not supplied with this product. The
installer will fit the correct type and length of cable.

GENERAL

The appliance is designed to be mounted on a floor
between two adjacent cabinets.
The cabinets must be securely fixed to the wall and the
cooker securely fixed to the cabinets.
This cooker must not be used free standing.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

5

GB

Installation

597mm min

720mm min

570mm

870mm Min

890mm Max

570 min

150mm min
170mm max

570mm

to top of plinth

A minimum distance of 25mm should be maintained between the front face of the cabinet side and the front face of
the plinth.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

6

Installation

GB

Wall

Fixing Bracket

Cooker

Top View

Hob Cable

2

2.5mm

heat resistant cable

BS 6141 Table 15

85°C

to

1mm min

Double pole

control switch

Cable size to suit

current rating of

appliance/s

Connector

Cabinet Doors

box

2

4mm

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

Cable

7

The main parts of your
Double Oven

GB

WARNING: DO NOT TOUCH THE GLASS DOORS WHEN THE OVEN IS IN USE AS
THESE AREAS CAN BECOME HOT.

Grill Control

Stay Clean
Liner

Rod

Shelf
Inner
Door
Glass

Oven
Light

Oven
Fan

Stay Clean
Liner

Top Oven

Temperature Control

Top

Oven

Grill

Pilot

Pilot

Light

Light

Timer

Main Oven

Temperature Control

Main

Oven

Pilot

Light

Multifunction
Selector

Model &
Serial number

High Speed Grill Element

Top Oven Light

(not all models)
Grill Pan, Food support and
Anti-Splash Tray

Top Oven Door

Fan Grill Element

Oven Shelves

Inner Door
Glass

Main Oven Door

NEVER line the shelves, floor or sides of the oven or grill with aluminium foil as
overheating and damage may result.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

8

Temperature Conversion Chart

The chart below gives details of comparisons of oven
settings for gas conventional ovens and fan oven in
degrees °F and °C

Conventional Oven Fan Oven

Gas Mark

°F °C °C

½ 250 120 100

1 275 140 120

2 300 150 130

3 325 160 140

4 350 180 160

5 375 190 170

GB

6 400 200 180

7 425 220 200

8 450 230 210

9 475 240 220

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

9

The Controls

GB

Top
Grill
Pilot

Light

Oven

Pilot

Light

A B C D

Grill

Control

IMPORTANT
Before using your oven in the ordinary way,
ALWAYS make sure that the timer has been set to
MANUAL operation. Unless this is done, the main
oven cannot heat up. Before seeking assistance,
make sure this is done (refer to oven timer
operation).

MULTIFUNCTION SELECTOR

Rotate the control knob in either direction to the
required function. Many of the functions will also
require the main oven thermostat to be set before the
oven will heat up.

MAIN OVEN TEMPERATURE CONTROL

This is used in addition to the multifunction selector.
This is used for the functions: fan oven, fan grill, half
grill and full grill and conventional oven.
Turn the control clockwise to set the oven thermostat to
the required temperature.
If the timer is set correctly and the selector switch set
to a suitable function an indicator light will illuminate.
This will remain on until the oven reaches the required
temperature. This light will then cycle on and off as the
thermostat maintains control of the oven temperature.

Top Oven

Temperature

Control

Timer Main Oven

Main

Oven

Pilot

Light

Multifunction

Temperature

Control

TOP OVEN TEMPERATURE CONTROL

Turn the control clockwise to set the top oven
thermostat to the required temperature. An indicator
light will illuminate. This will remain on until the oven
reaches the required temperature. This light will then
cycle on and off as the thermostat maintains control of
the oven thermostat.

GRILL CONTROL

The grill control is designed to provide variable heat
control of either both grill elements on together or the
single left-hand grill element only.
To set the grill power turn the grill control to any setting
MIN (1) - MAX (4), clockwise for FULL grill and anti­clockwise for HALF grill.

COOLING FAN

A gentle flow of air will be blown below the control
panel when the grill control is used and after a short
period of time when the ovens are used.
Note: Whenever the appliance has been used, the
cooling fan may run on or restart itself after all the
controls have been turned off. This indicates that the
appliance is still warm.

Selector

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

10

Multifunction Selector Switch

The Multifunction selector switch is used when
operating the main oven.
With the exception of the O position the main oven
light will remain on when this selector switch is
used.

Off

With the selector in this position the main oven will not
heat up. The timer will still operate.

Fan Oven

The oven fan and a rear element are controlled when
this function is selected.
Use the main oven thermostat control to set the
required temperature.

Conventional Oven

Top and base elements are controlled when this
function is selected.
Use the main oven thermostat to set the required
temperature.

Full Grill

Both left and right hand grill elements will be on in this
position.
Use the oven thermostat control to set the required
temperature.

Oven door must be open for grilling.

Fan Grill

The oven fan and fan grill element are controlled when
this function is selected.
Use the oven thermostat control to set the required
temperature.

Oven door must be closed for fan grilling.

Fan Only

The oven fan will operate when this function is
selected.

The oven thermostat control must be set in the off
position.

Light Only

GB

Half Grill

With this function selected only the left hand side of the
grill will be on.
Use the oven thermostat control to set the required
temperature.

Oven door must be open for grilling.

This function switches on the oven light only.

! Do not use the oven lamp as/for ambient lighting

After selecting any of the oven programs, the
parameter setting of the product is activated. It
optimizes the performance of cooking, but could result
in a delayed ignition of fan and heating elements.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

11

The electronic programmer

GB

DISPLAY

END OF

COOKING icon

DURATION

icon

DECREASE TIME

button

•• ••

SET TIME

button

CLOCK icon

TIMER icon

INCREASE TIME

button

! The Top Oven and Main Oven can be controlled by
the automatic timer. When the timer control has been
set for one oven, it is possible to use the other oven
only during the same automatic cooking programme.

! NEVER operate the grill when the ovens are set
to cook automatically because the oven cavity can
become warm and this may cause bacterial growth
in food.

Setting the clock

! The clock may be set when the oven is switched off or
when it is switched on, provided that a the end time of
a cooking cycle has not been programmed previously.
After the appliance has been connected to the mains,

Programming cooking

! A cooking mode must be selected before
programming can take place.

Programming the cooking duration

1. Press the
and the three digits on the DISPLAY begin to flash.

2. Use the “+” and “-” buttons to set the desired
duration; if you press and hold either button, the
display will scroll through the values more quickly,
making it quicker and easier to set the value.

3. Wait for 10 seconds or press the
finalise the setting.

4. When the set time has elapsed, the text END
appears on the DISPLAY, the oven will stop cooking
and a buzzer sounds. Press any button to stop the
buzzer and turn all control knobs to 0 position.

• For example: it is 9:00 a.m. and a time of 1 hour
and 15 minutes is programmed. The programme
will stop automatically at 10:15 a.m.

Setting the end time for a cooking mode

! A cooking duration must be set before the cooking
end time can be scheduled.

button several times until the icon

button again to

or after a blackout, the

icon and the four numerical

digits on the DISPLAY will begin to flash.

1. Press the

button several times until the icon

and the four digits on the display begin to flash.

2. Use the “+” and “-” buttons to adjust the time; if you
press and hold either button, the display will scroll
through the values more quickly, making it quicker and
easier to set the desired value.

3. Wait for 10 seconds or press the

button again to

finalise the setting.

Setting the minute minder

! This function does not interrupt cooking and does not
affect the oven; it is simply used to activate the buzzer
when the set amount of time has elapsed.

1. Press the button several times until the icon
and the three digits on the display begin to flash.

2. Use the “+” and “-” buttons to set the desired time; if
you press and hold either button, the display will scroll
through the values more quickly, making it quicker and
easier to set the value.

3. Wait for 10 seconds or press the
finalise the setting.
The display will then show the time as it counts down.
When this period of time has elapsed the buzzer will be
activated.

button again to

1. Follow steps 1 to 3 to set the duration as detailed

above.

2. Next, press the

button until the icon and the

four digits on the DISPLAY begin to flash.

3. use the “+” and “-” buttons to adjust the cooking end

time; if you press and hold either button, the display
will scroll through the values more quickly, making it
quicker and easier to set the desired value.

4. Wait for 10 seconds or press the

button again to

finalise the setting.

5. When the set time has elapsed, the text END

appears on the DISPLAY, the oven will stop cooking
and a buzzer sounds.
Programming has been set when the

Press any button to stop it.

and
buttons are illuminated. The DISPLAY shows the
cooking end time and the cooking duration alternately.

• For example: It is 9:00 a.m. and a duration of 1

hour has been programmed. 12:30 is scheduled
as the end time. The programme will start
automatically at 11:30 a.m.

Cancelling a programme

To cancel a programme:

• press the

button until the icon corresponding to
the setting you wish to cancel and the digits on the
display are flashing. Press the “-” button until the
digits 00:00 appear on the display.

• Press and hold the “+” and “-” buttons; this
will cancel all the settings selected previously,
including timer settings.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

12

Grill Pan and Handle

T

ENSURE SHELVES ARE

FITTED CORRECT WAY UP.

DO NOT PLACE FOOD/UTENSILS

DIRECTLY ON THE OVEN FLOOR

3

2

1

3
2
1

Using the grill pan kit

The grill pan handle is detachable from the pan to
facilitate cleaning and storage. Fix the pan handle
securely before use:

1. Fit the handle to the grill pan so that the external
‘hooks’ embrace the edge of the pan (fig. 1)

2. Make sure that the middle part of the handle fits
exactly the protruding support of the pan (fig .2)
and holds the pan from the bottom.

The food must be placed on the rack in the grill pan.
Position the grill pan on top of the oven rack. The best
results are achieved by placing the oven rack on the
uppermost shelves. Pouring a little water into the grill
pan will make the collection of grease particles more
efficient and prevent the formation of smoke.

1

Grill Pan, Food Support and Anti-Splash Tray

GRILL PAN

2

ANTI-SPASH
TRAY

NOTE:

- Preheat the grill if indicated on grill chart.

- The grill pan must be placed on the correct shelf

- Leave the control at MAX for toast, and for fast

- For thicker foods requiring longer cooking, turn the

- DO NOT line the grill pan with aluminium foil, as

- After use always return the grill control to the OFF

GB

and positioned centrally under the grill element.

cooking of foods.

switch to a lower setting after the initial sealing on
both sides at MAX. The thicker the food, the lower
the control should be set.

this increases the amount of fat spitting which can
cause a fire.

(0) position.

GRILL PAN

Note: To stop fat splashing onto the grill mesh, it is
important to use the ant-splash tray as shown in the
grilling chart. Always clean the grill pan, anti-splash
tray and food support after each use.

Top Oven Shelf Positioning for Grilling

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

FOOD SUPPOR

13

Operation when using
the Top Oven for Grilling

GB

Top
Grill
Pilot

Light

Oven

Pilot

Light

A B C D

Grill

Control

Step 1 Ensure oven timer is set to manual. Place

the shelf in the correct position (see Gril­ling Guide). Place the food/grill pan on
the shelf, positioned centrally under the
grill element. Leave the top oven door fully
open.

Step 2 Turn knob (A), clockwise for FULL grill or

anti-clockwise for HALF grill, to select the
grill setting MIN (1) MAX (4). NOTE: MIN
(1) = Low, MAX (4) = High.

Top Oven

Temperature

Control

GB

Timer

Grill Controls Example:

or = High Grill Setting (depending on model)

NOTE: Do not grill with

the grill/top oven
door closed.

Step 3 After use, turn the

grill control (A) to
the off position (0).

! The Grill Pilot Light is lit when grill is used.

! Ensure knob (B) is in „0 position”. The grill and
the top oven cannot work simultaneously

DO NOT allow young children near to the appliance
when the grill is in use as the surfaces get
extremely hot.

DOOR POSITION

FOR GRILLING

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

14

Using the Top Oven for
Solarplus Grilling

Your cooker is not fitted with a conventional grill.
Hotpoint have developed a Solarplus high speed grill
which is designed to reduce your grilling times. It is
quicker because it takes less time to warm up from
cold. Conventional grills require 5 minutes pre-heat
before food can be placed beneath them, but for
normal grilling the Solarplus grill can be used directly
from cold without any pre-heat.
However, when toasting, optimum performance is
achieved by pre-heating the grill for about 1 minute.

NOTE: You will notice that the grill elements are
protected by a wire mesh. This stops you from
touching live parts.

Guide to Solarplus Grilling

DO NOT under any circumstances insert objects
into the grill mesh as this could damage the
element wire, break the glass tubes or if the grill is
on, cause electric shock.

During use, the wire mesh may become soiled. DO
NOT attempt to clean it while the grill is still on. Turn off
at the control and allow to cool before cleaning. Care
must be taken to ensure the grill mesh is not distorted ­do not store the grill pan handle on the food grid when
the shelf is in the highest position.

IMPORTANT:
Grilling should never be undertaken with the grill/
top oven door closed.

GB

PREHEAT

FODD

Toasting of Bread

Products

Small cuts of

meat, Sausage,

Bacon

Chops etc.

Gammon steaks

Whole

Fish:

potato products

Fillets
Fingers

Pre-cooked

Pizzas None 3 or 2

FOR ONE

MINUTE

Setti ng

MAX

None 3 or 2

None 2

None
None
None

None 3 or 2

SHELF POSITION
FROM THE BASE

OF THE OVEN

3 or 2 Setting MAX (4) 3 - 5 minutes

2
3
3

SETTING

Setting MAX (4)

for 4 minutes then

reduce to lower

setting

Setting MAX (4)

for 6-8 minutes

then reduce to

lower setting

Setting MAX (4)

Setti ng between
MEDIUM (2) and
MAX (4) position

Setti ng between
MEDIUM (2) and
MAX (4) position

COOKING TIME

APPROXIMATE

10 - 15 minutes

25 - 30 minutes

6 - 8 minutes
10 - 15 minutes
10 - 15 minutes

10 - 12 minutes

10 - 12 minutes

PAN TO BE

USED

Grill pan and food

support

Grill pan,

antisplash tray

and food support

Grill pan,

antisplash tray

and food support

Grill pan and food

support

Grill pan and food

support

Grill pan and food

support

Browning of food

eg. Cauliflower

Cheese

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

Setti ng

MAX

3 or 2 Setting MAX (4) 5 - 10 minutes

Dish placed

directly on the

shelf

15

Using the Top Oven as

ENSURE SHELVES ARE

FITTED CORRECT WAY UP.

DO NOT PLACE FOOD/UTENSILS

DIRECTLY ON THE OVEN FLOOR

3

2

1

3
2
1

a Convection Oven

GB

The top oven should be used to cook small quantities
of food. The oven is designed so that the grill element
operates at a reduced heat output, this is combined
with a heating element situated underneath the floor
of the oven. To ensure even cooking of the food it is
important that cooking utensils are positioned correctly
on the oven shelf so that the element is directly
above. As a guide, the front of the utensil should be
approx.100mm (4”) from the front of the shelf.

Note: Charts are a guide only, to suit personal taste
and requirements, it may be necessary to increase
or decrease temperatures by 10°C. It may also be
necessary to increase or decrease cooking times.

SHELF POSITIONING

There should always be at least 25mm (1 inch)
between the top of the food and the grill element.

WARNING: Items stored in the top oven will get hot
when the main oven is in use.

DO NOT allow young children near to the appliance
when the top oven is in use as the surfaces get
extremely hot.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

16

Operation when using the
Top Oven as a Convection

A B C D

TOP OVEN TEMPERATURE

CONTROL

Step 1 Check that the timer is in manual.
Step 2 Place the shelf in the correct position (see

Oven Temperature Charts).

Step 3 Select the required cooking temperature

(100 *C-MAX) using control (B) (see Top Oven
Temperature Charts). The pilot light (·) will
immediately come on, and remain on until the oven
reaches the required temperature. The light will
then automatically go off and on during cooking
as the oven thermostat maintains the correct
temperature.

Step 4 Place the food on the shelf directly below

the element ensuring the oven door is
closed.

TIMER

GB

PLATE WARMING

Place the plates/dishes on shelf position 1 from the
base of the top oven, and turn top oven temperature
control (B) to 100°C for 10-15 minutes.

Never use the grill setting control (A) when warming
plates.

TOP OVEN UTENSILS

Do Not use: Meat Pans and Baking Trays larger than
225mm x 300mm (9”x12”)

DO NOT use the grill pan or main oven meat pan as
a meat pan in the top oven, as the air circulation will
be seriously restricted.

NOTE: At the end of your cooking, always return
control (B) to the OFF (O) position.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

17

GB

Oven Temperature
Charts - Baking

Top Oven Cooking

Baking Pre-heat Temperature °C Time in mins. Position in Oven

Scones Yes 210/220 10-15 Runner 2 from bottom of oven

Small Cakes Yes 180/190 20-25 Runner 2 from bottom of oven

Victoria Sandwich Yes 170/180 20-30 Runner 2 from bottom of oven

Sponge Sandwich (fatless) Yes 180/190 20-25 Runner 2 from bottom of oven

Swiss Roll Yes 200/210 10-15 Runner 2 from bottom of oven

Semi-rich Fruit cakes Yes 150/160 60-75 7 inch Runner 2 from bottom of oven

Rich Fruit Cakes Yes 140/150

Shortcrust Pastry Yes 190/200

Puff Pastry Yes 200/210

Yorkshire Pudding Yes 190/200 30-40 Runner 1 or 2 from bottom of oven

Individual Yorkshire Pudding Yes 200/210 20-30 Runner 1 from bottom of oven

Milk Pudding Yes 140/150 90-120 Runner 1 from bottom of oven

Baked Custard Yes 150/160 40-50 Runner 1 from bottom of oven

Bread Yes 200/210 30-45 Runner 1 from bottom of oven

Meringues Yes 100 150-180 Runner 2 from bottom of oven

Time Dependent on

size

Time Dependent on

recipe

Time Dependent on

recipe

Runner 1 or 2 from bottom of oven

Runner 1 from bottom of oven

Runner 1 from bottom of oven

Fan Oven Cooking

Baking Pre-heat Temperature °C Time in mins.

Scones Yes 210/220 9-12

Small Cakes No 170/180 15-20

Victoria Sandwich No 160/170 20-25

Sponge Sandwich (fatless) Yes 190/200 15-20

Swiss Roll Yes 190/200 10-15

Semi-rich Fruit cakes No 140/150 1¼ - 1½ hrs

Rich Fruit Cakes No 130/140 Depending on size

Shortcrust Pastry No 190/200 Depending on size

Puff Pastry No 190/200 Depending on size

Yorkshire Pudding Yes 180/190 40-45

Individual Yorkshire Pudding Yes 190/200 20-25

Milk Pudding No 130/140 1½ - 2 hrs

Baked Custard No 140/150 35-45

Bread Yes 200/210 30-35

Meringues No 80-90 3 - 4 hrs

Note: If soft margarine is used for cake making, temperatures recommended by the manufacturers should be
followed. Temperatures recommended in this chart refer to cakes made with block margarine only.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

18

Oven Temperature
Charts - Meat

Top Oven Cooking

Meat Pre-heat Temperature °C Time (approx.) Position in Oven

Beef/ Lamb
(slow roasting)

Beef/ Lamb
(foil covered)

Pork
(slow roasting)

Pork
(foil covered)

Veal
(slow roasting)

Veal
(foil covered)

Poultry/Game
(slow roasting)

Poultry/Game
(foil covered)

Casserole
Cooking

Yes 170/180 35 mins per 450g (1lb) + 35 mins over.

Yes 190/200 35-40 mins per 450g (1lb)

Yes 170/180 40 mins per 450g (1lb) + 40 mins over

Yes 190/200 40 mins per 450g (1lb)

Yes 170/180 40-45 mins per 450g (1lb) + 40 mins over

Yes 190/200 40-45 mins per 450g (1lb)

Yes 170/180 25-30 mins per 450g (1lb) + 25 mins over

Yes 190/200 25-30 mins per 450g (1lb)

Yes 150 2-2½ hrs

If using aluminium foil, never:

1.Allow foil to touch sides of oven. 2.Cover oven interior with foil. 3.Cover shelves with foil.

Runner 1 from

bottom of oven.

GB

Fan Oven

Meat Pre-heat Temperature °C Ti me (approx.) Position in Oven

Beef No 160/180 20-25 mins per 450g (1lb) + 20 mins extra.

Lamb No 160/180 20-30 mins per 450g (1lb) +25 mins extra.

Pork No 160/180 25-30 mins per 450g (1lb) +25 mins extra.

Veal No 160/170 25-30 mins per 450g (1lb) +25 mins extra.

Chicken/Turkey
up to 4kg (8lb)

Turkey 4 to 5.5kg
(8 to 12lb)

Turkey 4 to 5.5kg
(8 to 12lb)

Casserole Cooking No 140-150 1½ - 2 hrs

1.Allow foil to touch sides of oven. 2.Cover oven interior with foil. 3.Cover shelves with foil.

No 160/180 18-20 mins per 450g (1lb) + 20 mins extra.

13-15 mins per 450g (1lb) at 150/160°C

No

allow 12 mins per 450g (1lb) at 150°C

If using aluminium foil, never:

Runner 1 from

bottom of oven.

The most accurate method of testing the readiness of joints of meat or whole poultry is to insert a meat thermometer
into the thickest part of a joint, or the thickest part of poultry thighs, during the cooking period.The meat thermometer
will indicate when the required internal temp has been reached.
Beef - Rare: 60°C Lamb: 80°C Poultry: 90°C
Medium: 70°C Pork: 90°C
Well Done: 75°C Veal: 75°C

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

19

Main Oven - Fan Grilling

GB

Fan grilling is a combination of heat from the grill
element and the oven fan circulating the hot air around
the food.
Joints of meat and poultry will be browned as if
they were cooked on a rotisserie or spit but more
economically as the door left closed.
If required, fan grilling can be timed using the Oven
Auto timer.
Follow the timer instructions before selecting fan grill
and the required temperature.

If Manual fan grilling is required always ensure the
timer is set to Manual.

Operating Instruction

1. Open the oven door.

2. Select the correct shelf position, as stated in chart.

3. Turn the selector switch to the Fan grill position.

4. Turn the oven thermostat control to the required
temperature (see Fan Grilling Roasting Chart, next
page).

5. Position the meat pan centrally under the grill ele­ments.

6. Close the oven door.

7. After use always return both controls to the off
position.

8. If the oven timer was used, reset to Manual.

As with the fan oven cooking there is no need to pre­heat the oven yet another economy feature. Also you
can cook more than one thing at a time even up to 4
small chickens.

Temperatures

These will be similar to those used for the more
traditional form of roasting but the guide will give
you an indication of which temperature to set the
Thermostat. But remember that because of the way
the oven is heated this is a more economical way of
roasting.

General Recommendations

Most types of meat and poultry cooked by this method
will have an all over brownness and crispness on the
outside. The only exceptions are very lean joints, such
as veal, which, because of its low fat content, is better
cooked using conventional heating.

1. Always place the pan on the shelf position recom­mended. (See Chart).

2. There is no need to preheat the oven before cooking
and all fan grilling should be carried out with the
oven door closed, this saves energy. The cooking
temperatures and times are calculated from a cold
oven.

3. After rinsing and drying meat, place on the food
roasting support rack over the pan supplied.

4. Position meat in oven as recommended in the
roasting chart.

5. Fan grilling is ideally suited for cooking all types of
poultry and larger joints of meat (e.g.stuffed, rolled
joints and legs of pork and lamb). Results will be
as if you had cooked the food on a rotisserie. If you
use frozen meat or poultry it must be completely
defrosted before it is cooked.

6. When cooking a joint always grill it with the fat side
uppermost in order to crisp it. For bigger joints or
where there is little bone, grill at the lower tempe­rature given in the table and cook for a longer time
per kg.

7. When cooking any type of poultry, start grilling the
underside uppermost and turn breast uppermost
about a third to halfway through the cooking pe­riod. If cooking stuffed poultry allow slightly longer
cooking time.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

20

Main Oven - Fan Grilling
Roasting Chart

Shelf positions are counted from the base upwards ie: lowest shelf position is 1.

Type of Meat or Poultry

PORK
Pork C hop - thick

Gammon Steaks

Pork - any type of joint 1.0

LAMB
Lamb chop - thick

Lamb - any type of joint 1.0

BEEF
Beef - joints which have

an outside layer of fat

eg. Rib, Rolled, Sirloin

CHICKEN

Chicken joints

DUCK 1.5

Weight

kg

1.5

2.0

2.5

over 2.5

1.5

2.0

2.5

0ver 2.5

1.0

1.5

2.0

2.5

over 2.5

1.0

1.5

2.0

2.5

over 2.5

less than

1kg each

2.0

2.5

Temp °C

170

160

160-170
150-170
140-150
140-150

140

170

160-170
160-170
150-160
150-160

150

170-180
170-180
160-170
160-170

160

180
180
170
170

160-170

180

180
180
180

Time

(min/kg)

25

30

60-70
60-70
65-75
65-75
70-75

25

30-40
35-40
35-45
40-45
45-50

40-50
40-50
40-50
45-50
45-50

30
30
35
35
40
30

30
30
35

Plus Extra

Time (mi n s )

45
45
50
50
50

45
45
50
50
50

20
20
20
30
40

30
30
30
30
30
30

30
30
30

Total Cooking Time

(mins)

Dependente on size

Dependente on size

105-120
130-150
180-230
220-240

Dependent on size

78-88

90-110
120-140
150-170

60-70

80-90
100-110
140-150

115-130

-

-

-

60

75
100
115

-

60

75

90

GB

Tips

Season. Grill on shelf
position 3. Turn over after 15
mins. Grill on shelf position 3
Turn after 15 mins. Score fat
with sharp knife and rub on
salt. Pork should always be
thoroughly cooked. So
overcook rather than
undercook. Grill on shelf
position 1.

Season. Grill on shelf
position 3. Turn over after 15
mins. Score fat. Season with
pepper and rosemary. If you
prefer the lamb pink choose
the shorter time Grill on shelf
position 1.

Season. If joint preferred rare
grill for the shorter time. If
preferred well done grill for
the longer time. Grill on shelf
position 1.

Season and brush over with
melted butter to give nicely
browned skin. Grill on shelf
position 1. Shelf 1.

Dry thoroughly and lightly
salt. Grill on shelf position 1.

GOOSE up to 4

TURKEY up to 5

GAME
Grouse
Partridge
Pheasant

Beefburgers

Sausages

Bacon

Mixed Grill

4-5

6 -8

Any
Any
Any

450g(lb)

450g(lb)

450g(lb)

170-190
160-170

170
150

170-180
170-180
170-180

170

170

170

170

40
45

-

-

30-50
40-50
40-50

25mins per

450g (lb)

25mins per

450g (lb)

25mins per

450g (lb)

40
40

-

-

-

-

-

-

-

150-165
165-175

-

-

-

30

Can be stuffed. Grill on shelf
position 1

Season and brush over with
melted butter to give nicely
browned skin. Grill on shelf
position 1.

Well hung meat will require
less cooking time. grill on
position 1.

Shelf 3.
Shelf 3.
Prick sausages before
cooking.
Shelf 3.
Roll up bacon before
cooking. 4 pieces of steak,
sausages, chops, bacon,
tomatoes & mushrooms.
Cook sausages, chops,
bacon for 10 mins. add steak,
cook for further 20 mins.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

21

Using the Main Oven for
Other Functions

GB

FAN ONLY SETTING

DEFROSTING FROZEN MEAT & POULTRY

Joints of meat and whole birds should be defrosted
slowly, preferably in a refrigerator (allowing 5-6 hours
per lb.) or at room temperature (allowing 2-3 hours
per lb.). Frozen meat or poultry must be completely
defrosted before cooking in the oven. However, to
decrease the amount of time required to defrost food
items, a nonheating fan only setting may be selected
for the main oven only.

OPERATION: TO ASSIST IN DEFROSTING:

Place food in the oven and close the oven door.
Turn the Multifunction Control (D) clockwise to the FAN
ONLY setting.

NOTES: DO NOT defrost meat and poultry by
warming the food through.

Foods ideally suited to defrosting using the fan only
setting are cream/cream cakes, butter cream filled
cakes, gateaux, cheese cakes, iced cakes, quiches,
pastries, biscuits, bread, croissants, fruit and many
delicate frozen foods. If fish, meat and poultry are to
be defrosted using the fan only setting, where possible
it is recommended that the food should be small and
thin.
The items should be placed so that the maximum
amount of surface area is exposed to the circulating
air, and that they are turned regularly to ensure even
defrosting.
Larger cuts of meat and poultry may be defrosted by
using the fan only setting up to a maximum weight of 2
kg (4lb 8oz).
It is important to wash both meat and poultry and
cooking utensils immediately after defrosting and
before cooking. Food should be cooked immediately
after defrosting.

After selecting any of the oven programs, the parameter
setting of the product is activated. It optimizes the
performance of cooking, but could result in a delayed
ignition of fan and heating elements.

It is very important to strictly adhere to the basic
principles of food handling and hygiene to prevent
the possibility of bacterial growth.

LIGHT ONLY SETTING

When the Multifunction Control (D) is turned clockwise
to the LIGHT ONLY setting, the main oven light only will
illuminate.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

22

Main Oven - Conventional
Oven

Important

NEVER line the shelves, the floor or the sides of the
oven with aluminium foil as overheating and damage
may result.
The oven is heated by elements at the top of the oven
and underneath the floor of the oven.

Food should not be placed on the floor of the oven

Operating Procedure

1. Ensure Oven Timer is set to Manual.

2. Position rod shelf as recommended in the chart for
food being cooked.

3. Position food centrally under grill element.

4. Turn the selector switch to the conventional oven
position.

5. Turn the oven thermostat control to the required
temperature setting (see oven temperature charts).
The oven light will remain on. The oven indicator
light will remain on until the oven reaches the set
temperature. This light will then automatically cycle
on and off during cooking as the oven temperature
is controlled.

6. After use always return both controls to the off
position and close the oven door.

GB

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

23

Main Oven - Fan Oven

GB

Important

NEVER line the shelves, the floor or the sides of the
oven with aluminium foil as overheating and damage
may result.
The oven is heated by elements at the rear of the oven.
A fan at the rear of the oven operates to circulate
heated air within the oven.

Operating Procedure

1. Ensure Oven Timer is set to Manual.

2.

- Turn the selector switch to the fan oven position.

- Turn the oven thermostat control to the requi­red temperature setting (see oven temperature
charts).

3 The oven light will remain on. The oven indicator

light will remain on until the oven reaches the set
temperature. This light will then automatically cycle
on and off during cooking as the oven temperature
is controlled.

4. After use always return all controls to the off position
and close the oven door.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

24

Main Oven - Fan Oven
Cookery Notes

Since a fan oven heats up more quickly, and generally
cooks food at a lower temperature than a conventional
oven, pre-heating the oven is often unnecessary.
However, foods such as bread, scones, Yorkshire
pudding, do benefit from being placed in a pre-heated
oven.

The charts are a guide only, giving approximate
cooking temperatures and times. To suit personal taste
and requirements, it may be necessary to increase or
decrease temperatures by 10°C.

Because the fan oven cooks so efficiently, we
recommend that when cooking any recipes not
designed for a fan oven, you reduce the temperature
by about 25°C and the time by about 10 minutes in
the hour. If large quantities are being cooked it will be
necessary to increase the cooking time somewhat to
compensate for the extra oven load.

Unless otherwise indicated in the charts, food is placed
in a cold oven, i.e. without preheating.
If food is placed in an already hot oven, the suggested
cooking time should be reduced, depending on the
type and quantity of food being cooked.

there may be a momentary puff of steam when the
oven door is opened, this will disperse in a few
seconds and is a perfectly normal characteristic of an
oven with a good door seal.

Oven Positions

Since the distribution of heat in the fan oven is very
even, most foods will cook satisfactorily on any shelf
position, but the shelves should be evenly spaced:

To ensure even circulation do not use meat pans larger
than 390x300mm (15ins x 12ins) and baking trays no
larger than 330 x 255mm (13ins x 10ins), these should
be positioned centrally on the oven shelf.

Do not fit shelves upside down.
Never use more than 3 shelves in the oven as air

circulation will be restricted.

Food or cooking utensils should not be placed on

the floor of the oven. To avoid unnecessary clea­ning, rod shelves which are not in use should be
removed from the oven.

GB

It should be noted that at the end of a cooking period

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

25

Main Oven - Fan Oven
Cookery Notes

GB

Temperature and Time

The oven is provided with two shelves. A third is
available as an optional extra, contact Genuine Parts
and Accessories Hotline (see back page) for further
information.
If three shelves are used to cook large quantities of
food for home freezing or parties, it may be necessary
to increase the cooking times given in the charts by
a few minutes, to allow for the loss of heat due to the
extra time taken to load the oven, and the larger mass
of food.
Baking trays should allow an equal gap on all sides of
the oven.

To prepare meat and poultry for Roasting in your
Fan Oven

(a) Wipe the meat or poultry, dry well and weigh it.

Meat which has for been stored in a refrigerator
should be allowed to come to room temperature
before cooking, and frozen meat or poultry must be
completely defrosted before placing in the oven.

(b) The weight of any stuffing used should be added

before calculating the cooking time.

(c) Place meat/poultry in the main oven meat pan

supplied with your cooker. Small joints weighing
less than 1.75kg (31/2 lbs) should be roasted in a
smaller meat pan/tin or they may be ‚pot roasted’ a
small joint or a large meat pan causes unnecessary
oven splashing and evaporation of meat juices.

(d) Additional fat should not be added, except for

veal, very lean meat or poultry which can either be
‚larded’ with fat bacon or brushed very sparingly
with cooking oil or melted fat.

(e) Beef, lamb, mutton and poultry may be dusted

lightly with seasoned flour to give a crisp outer
surface. The skin of duck and goose should be
pricked to release excess fat during cooking, and
the rind of pork should be scored, brushed lightly
with oil, and rubbed with salt to give crisp crackling.

(f) Meat and poultry wrapped in, or covered with a tent

of aluminium foil will be juicy and tender. Roasting
bags offer the same advantages. Always follow the
manufacturer’s pack instructions, and remember
to reduce the temperatures given for conventional
ovens by approximately 25°C and the time by ap­proximately 10 minutes per hour.

(g) Potatoes for roasting only require to be brushed

with cooking oil or melted fat.

(h) It is not necessary to baste when roasting in an elec-

tric oven and stock or liquid should not be added to
the meat pan since this only causes unnecessary
soiling, steam and condensation.

slowly, preferably in a domestic refrigerator (allowing
5-6 hours per 450g,1 lb), or at room temperature
(allowing 2-3 hours per 450g, 1 lb).

Frozen meat or poultry must be completely defrosted
before placing in the oven.

It is essential to wash thoroughly and cook meat and
poultry immediately after defrosting.

WARNING! The oven is
provided with a stop sys­tem to extract the racks
and prevent them from
coming out of the oven.(1)
As shown in the drawing,
to extract them comple­tely, simply lift the racks,
holding them on the front

part, and pull (2).

Frozen Meat and Poultry

Joints of meat and whole birds should be defrosted

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

26

Main Oven
Temperature Chart

Conventional Oven

It is not necessary to pre-heat the fan oven before roasting. Note: Where times are stated, they are approximate only.

Meat Pre-heat Temperature °C Time (approx.) Position in Oven

Beef/ Lamb

(slow roasting)

Beef/ Lamb

(foil covered)

Pork

(slow roasting)

Pork

(foil covered)

Veal
(slow roasting)

Veal
(foil covered)

Poultry/Game

(slow roasting)

Poultry/Game

(foil covered)

Casserole
Cooking

Yes 170/180 35 mins per 450g (1lb) + 35 mins over.

Yes 190/200 35-45 mins per 450g (1lb)

Yes 170/180 40 mins per 450g (1lb) + 40 mins over

Yes 190/200 40 mins per 450g (1lb)

Yes 170/180 40-45 mins per 450g (1lb) + 40 mins over

Yes 190/200 40-45 mins per 450g (1lb)

Yes 170/180 25-30 mins per 450g (1lb) + 25 mins over

Yes 190/200 25-30 mins per 450g (1lb)

Yes 150 2-2½ hrs

1.Allow foil to touch sides of oven. 2.Cover oven interior with foil. 3.Cover shelves with foil.

If using a lumin ium fo il, never:

Fan Oven

Runner 2 or 3 from

bottom of oven.

GB

It is not necessary to pre-heat the fan oven before roasting. Note: Where times are stated, they are

Meat Pre-heat

Beef No 160/180 20-25 mins per 450g (1lb) + 20 mins extra.

Lamb No 160/180 20-30 mins per 450g (1lb) +25 mins extra.

Pork No 160/180 25-30 mins per 450g (1lb) +25 mins extra.

Veal No 160/170 25-30 mins per 450g (1lb) +25 mins extra.

Chicken/Turkey
up to 4kg (8lb)

Turkey 4 to 5.5kg
(8 to 12lb)

Casserole Cooking No 140-150 1½ - 2 hrs

1.Allow foil to touch sides of oven. 2.Cover oven interior with foil. 3.Cover shelves with foil.

No 160/180 18-20 mins per 450g (1lb) + 20 mins extra.

No

Temperature

approximate only.

°C

150/160

or 150

If us ing a lumin ium foil, n ever:

12-14 mins per 450g (1lb) at plus 12 mins extra

*For every 450g (1lb) over 5.5kg (12lb) allow 10 mins

per 450g (1lb) and roast at 150°C

Time (approx.)

The most accurate method of testing the readiness of joints of meat or whole poultry is to insert a meat thermometer
into the thickest part of a joint, or the thickest part of poultry thighs, during the cooking period.The meat thermometer
will indicate when the required internal temp has been reached.
Beef - Rare: 60°C Lamb: 80°C Poultry: 90°C
Medium: 70°C Pork: 90°C
Well Done: 75°C Veal: 75°C

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

27

Main Oven
Temperature Chart

GB

Baking Conevntional Oven
Food Pre-heat Temperature °C Time in mins. Shelf Position

Scones Yes 220/230 10-15 2nd from bottom

Small Cakes Yes 180/190 15-25 3nd from bottom

Victoria Sandwich Yes 160/170 20-30 3nd from bottom

Sponge Sandwich (fatless) Yes 170/180 15-20 3nd from bottom

Swiss Roll Yes 190/200 8-12 3nd from bottom

Semi-rich Fruit cakes Yes 150/160 1¼ hrs. 7" 2nd from bottom

Rich Fruit Cakes Yes 130/140 Depending on recipe and size 2nd from bottom

Shortcrust Pastry Yes 180/190 Depending on use 2nd or 3rd from bottom

Puff Pastry Yes 190/200 Depending on use 2nd or 3rd from bottom

Yorkshire Pudding Yes 190/200 40-45 3nd from bottom

Individual Yorkshire Pudding Yes 200/210 20-30 3nd from bottom

Milk Pudding Yes 140/150 1¼ - 2 hrs. 2nd from bottom

Baked Custard Yes 130/140 40-50 3nd from bottom

Bread Yes 190/200 25-35 3nd from bottom

Meringues Yes 80/90 3 - 3½ hrs. 3nd from bottom

Baking Fan Oven
Food Pre-heat Temperature °C Time in mins.

Scones Yes 210/220 9-12 approx.

Small Cakes No 170/180 15-25 approx.

Victoria Sandwich No 160/170 20-30 approx.

Sponge Sandwich (fatless) Yes 180/190 15-20 approx.

Swiss Roll Yes

Semi-rich Fruit cakes No 140/150 1¼ - ½ hrs. approx.

Rich Fruit Cakes No 130/140 Depending on size

Shortcrust Pastry No 190/200 Depending on size

Puff Pastry No 190/200 Depending on size

Yorkshire Pudding Yes 180/190 40-50 approx.

Individual Yorkshire Pudding Yes 190/200 20-25 approx.

Milk Pudding No 130/140 1½ - 2 hrs. approx.

Baked Custard No 140/150 35-45 approx.

Bread Yes 200/210 30-35 approx.

Meringues No 80/90 3 - 4 hrs. approx.

190/200 12-15 approx.

Note: If soft tub margarine is used for cake making, we would recommend using the all in one method and to reduce
the temperature by 10°C.
Temperatures recommended in this chart refer to cakes made with block margarine or butter only.

Note: Where times are stated, they are approximate only.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

28

Main Oven - Circulaire
Roasting

CIRCULAIRE ROASTING

Circulaire roasting - food is placed on the roasting
rack, this allows the oven fan to circulate the hot air
around the food, making it suitable for thin foods, such
as chops, steaks, sausages as well as meat joints and
poultry, as it will cook both sides at the same time.
it is possible to cook on any shelf position, as the
temperature in the oven is evenly distributed. Also, the
oven heats up more quickly and generally will cook
food at a lower temperature than a conventional oven,
so pre-heating is not necessary for most foods. For a
guide on „cooking times” and „cooking temperatures”
see „Circulaire Roasting Chart”, next page.
If required, circulaire roasting can be timed using
the Oven Timer. Follow the timer instructions before
selecting Fan Oven function and the required
temperature.
Note: It is also possible to cook food on the roasting
rack on one shelf, while cooking different types of food
at the same temperature, on other shelf positions (three
shelves maximum).

Operating Instructions:

STEP 1. Ensure the Oven Timer is set to manual.

Ensure that the oven shelf is in the posi­tion you require. Place the food centrally
on the roasting rack. Position the roasting
rack on top of the grill/meat pan. Place the
grill/meat pan centrally on the oven shelf.
Ensure the oven door is fully closed.

STEP 2. Turn the control knob (D) clockwise to the

fan oven function. Turn the control knob (C)
clockwise and select the required cooking
temperature. The pilot light () will imme­diately come on and will remain on until the
oven reaches the required temperature.
The light will then automatically go off and
on during cooking as the oven thermostat
maintains the correct temperature.

STEP 3. After use, turn controls (C) and (D) to the

Off (O) position.

Note: At the end of a cooking period there may
be a momentary puff of steam when the door is
opened. This will disperse in a few seconds and is
a perfectly normal characteristic of an oven with a
good door seal.

GB

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

29

GB

Main Oven - Circulaire
Roasting Chart

Type of Meat & Poultry Temperature °C Time (approximate)

BEEF

Beef - any type of joint

PORK

Pork - any type of joint

160/180 20-25 minutes per 450g (1lb)

+ 20 minutes extra

160/180

25 minutes per 450g (1lb)
+ 25 minutes extra

Pork - Chops

LAMB

Lamb - any type of joint

Lamb - Chops

CHICKEN/TURKEY

up to 4kg (8lb)

STEAKS

GAMMON STEAKS

SAUSAGES

Note: The above chart is only a guideline. The times and temperatures may be increased or decreased
depending on personnal taste.

170

160/180

170

160/180 18-20 minutes per 450g (1lb)

170 30-45 minutes

170 30-45 minutes

170 30-45 minutes

30-45 minutes

25 minutes per 450g (1lb)
+ 25 minutes extra

20-30 minutes

+ 20 minutes extra

PLACE FOOD ON

ROASTING RACK, THEN

POSITION ABOVE THE

MEAT PAN.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

30

Using the Main Oven
for Other Functions

‚S’ SLOW COOK SETTING

This is used for slow cooking, keeping food warm and
warming plates for short periods.
Extra care should be taken when warming bone china,
as it may be damaged in a hot oven.

DO NOT place food or plates directly on the oven
floor as this could damage both the oven lining and
the plates which are being warmed.

ADVANTAGES OF SLOW COOKING ARE:

The oven stays cleaner because there is less
splashing. Timing of food is not as critical, so there is
less fear of overcooking. Inexpensive joints of meat are
tenderised. Fully loading the oven can be economical.
Cooking times can be extended in some cases by up
to 2 hours.

OPERATION:

1. Place the prepared food in the main oven and
ensure the door is fully closed.

2. Select Slow Cooking Temperature ‚S’ by turning the
Main Oven Temperature Control (C) and Multifun­ction Control (D) clockwise to Fan Oven mode.

2. Select Slow Cooking Temperature ‚S’ by turning
Main Oven Temperature Control (C).

STORAGE & RE-HEATING OF FOOD:

1. If food is to be frozen or not used immediately,
place it in a clean container and cool as soon as
possible.

2. Always thaw frozen food completely in the refrige­rator before re-heating.

3. Always reheat food thoroughly and ensure it is
piping hot before serving.

4. Only re-heat food once.

2. All dishes cooked on the slow setting will require a
minimum of 6 hours, however, if they are cooked
for 1-2 hours longer then deterioration in their ap­pearance may be noticed.

3. Never cook joints of meat over 2.7kg (6 lb) or poultry
over 2.0kg (4lb 8oz). We do not recommend that
joints of meat or poultry are stuffed before cooking
on the slow setting.

4. To seal in the meat juices, always cook meat or
poultry at 170°C for 30 minutes before wrapping in
foil and placing on a rack over a tin (to allow good
air circulation) before turning the control to the slow
setting and cooking immediately.

5. Always ensure that joints of pork and poultry are
thoroughly cooked by checking with a meat ther­mometer before serving.

6. Always thaw frozen foods completely before coo­king. We do not recommend placing frozen food
in the oven to cook.

7. Always bring soups, liquids and casseroles to the
boil before placing in the oven.

8. Ensure that casserole dishes have a good seal (not
airtight) and cover to the top with foil to prevent loss
of moisture.

9. Ensure that fruit and vegetables are cut into even
sized small pieces to cook properly.

10. Always adjust seasoning before serving.

11. If using dried red kidney beans it is important
that the beans are soaked and then boiled for a
minimum of 10 minutes before using in any dish to
destroy any toxins.

12. When cooking fish or egg dishes it may be neces­sary to check during cooking to avoid overcooking.

GB

POINTS TO CONSIDER WHEN PREPARING FOOD
FOR SLOW COOKING

1. Make sure that the dishes to be used will fit into the
oven ensuring enough room for air to circulate.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

31

Main Oven Grilling

GB

DO NOT allow young children near the appliance when
the grill is in use as the surfaces can get extremely hot.

GRILLING SHOULD NEVER BE UNDERTAKEN WITH
THE DOOR CLOSED.

- Do Not line the grill pan with aluminium foil.

- Ensure that the grill pan is cleaned after every use.
Excess fat build-up in the bottom of the pan could
cause a fire hazard.

- Preheat the grill on the required setting for 5 minutes

Grilling Procedure:

1. Open the main oven door fully and position the rod
shelf as recommended in the grilling chart (see
below) for the food being cooked.

2. Turn the multifunction selector switch to HALF grill
or FULL grill and then turn the Main Oven tempe­rature control to the required setting to pre-heat for
approximately 5 minutes.

3. Position the grill pan centrally under the grill element
and push back as far as the location stops on the
rod shelf.

4. Leave the oven thermostat at setting MAX for toast
and for fast cooking of foods. For thicker foods
requiring longer cooking turn the thermostat to a
lower setting, after initial sealing on both sides at
MAX. The thicker the food, the lower the thermo­stat should be set. If excessive smoke is emitted,
reduce the setting.

5. After use always return both controls to their OFF
(O) position.

Food

Toasting of bread products 6 MAX 2-5 mins

Small cuts of meat,

sausages, bacon etc.

Chips, gammon steaks etc. 5

Fish:

Whole / Fillets

Fingers

Pizza's 5 170 10-15 mins

Browning of food 5 MAX 5-10 mins

Shelf Position

from base of oven

5 or 6

5
6

Setting Required Temp °C Cooking Time

MAX for 4- 6 mins then reduce to

setting 170

MAX for 4- 6 mins then reduce to

setting 170

170

MAX

10-20 mins

20-30 mins

15-20 mins
10-15 mins

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

32

Care and Cleaning

L

&

Warning: Before cleaning, please ensure that the
electricity supply to the appliance is switched off
and the appliance is fully cold.

! Never use steam cleaners or pressure cleaners on
the appliance.

Clean the glass part of the oven door using a sponge

!

and a non-abrasive cleaning product, then dry
thoroughly with a soft cloth. Do not use rough abrasive
material or sharp metal scrapers as these could
scratch the surface and cause the glass to crack.

! The accessories can be washed like everyday

crockery (even in your dishwasher).

1. „STAYCLEAN” OVEN LINERS
(Top Oven Sides, Main Oven Sides and
Rear Panel)*

TOP OVEN SIDES

DO NOT use biological washing powder, harsh
abrasives or chemical oven cleaners of any kind as
this could damage the „Stayclean” oven liners.

2. CLEANING GRILL, TOP OVEN AND
MAIN OVEN

GRILL
PAN

OVEN
SHELVES

MAIN
OVEN
BASE

(a) Base & Rear of Top Oven and Base of Main
Oven.

Wipe out the oven with a damp soapy cloth. For more
stubborn stains on the base of the oven use a well
soaped fine steel wool soap pad.

(b) Grill Pan, Meat Pan & Oven Shelves.

To prevent stains from being burnt on to the grill pan,
food support and rod shelf, always wash immediately
after use in warm soapy water.
Use a well soaped fine steel wool soap pad to remove
stubborn stains from the rod shelves, grill pan, meat
pan and the base of the oven.

BASE
REAR

MEAT
PAN

GB

MAIN OVEN SIDES AND REAR PANE

(a) How „Stayclean” works.

The surfaces of the „Stayclean” oven liners (Main
Oven rear panel) are treated with a special vitreous
enamel which absorbs cooking soils. At temperatures
of 220°C (425°F) or above, the special surface enables
these soils to be slowly destroyed. The higher the
temperature the more effective it is.

(b) Cleaning.

In most cases normal cooking operations at 220°C
(425°F) will permit this cleaning operation to
proceed during cooking. However if higher cooking
temperatures are not used regularly, it may be
necessary, in order to prevent heavy soiling, to run
the ovens without shelves or meat pan, at a maximum
setting for a couple of hours (Fan Oven mode only).
It should not normally be necessary to clean the
„Stayclean” panels with water. If the user feels it is
desirable to do so, wipe them over with a clean, soapy
cloth, followed by a wipe with a clean damp cloth.

DO NOT use aerosol cleaners on this oven as
they could adversely affect the fan motor unit, and
cannot be wiped off the fan blade.

(c) Solarplus Grill.

To clean the Solarplus Grill, use a clean, damp, soapy
cloth and wipe over. If stubborn stains remain, gently
clean with a well soaped nylon scouring pad and wipe
over with a damp cloth.

DO NOT use metal cleaning utensils, wire wool
or proprietary oven cleaners on the grill element
mesh.

*Available only in certain models.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

33

Care and Cleaning

S

GB

3. OVEN DOORS

CONTROL PANEL

OVEN
DOOR

(a) Control Panel

Regularly wipe with a clean, damp cloth and polish
with a clean, dry cloth.

(b) Inner Door Panels & Glass

Open the door fully. The glass panel may now be
washed. Stubborn stains can be removed by using a
well soaped, fine steel wool soap pad.

TOP OVEN LAMP

MAIN OVEN LAMP

Warning: To avoid electric shocks - please ensure
that the electricity supply to the appliance is
switched off and the appliance is fully cold, before
cleaning lamp lens.

Open the oven door and remove the oven shelves.
Using a thick cloth, grip the lamp lens, unscrew
anticlockwise and remove.
Clean with a non-abrasive cleansing cream and refit
lamp lens.

DO NOT use scouring pads, or abrasive powder,
which will scratch the glass lens

DO NOT use scouring pads, or abrasive powder,
which will scratch the glass.

4. REPLACEMENT OF THE OVEN LAMP

TOP OVEN LAMP

MAIN OVEN LAMP

Warning: To avoid electric shocks - please ensure
that the electricity supply to the appliance is
switched off and the appliance is fully cold, before
removing the lamp lens.

Open the oven door and remove the oven shelves.
Using a thick cloth, grip the lamp lens, unscrew
anticlockwise and remove the lens.
Carefully unscrew the bulb anti-clockwise.
Fit replacement bulb (25W 300°C SES) and refit lens.

5. HOW TO CLEAN THE LAMP LENS

Catalitic Cleaning

In some models, the most exposed internal vertical
sides of the oven are coated with porous enamel,
which is called catalytic enamel. When heated, this
enamel destroys fat particles given off by the food.
This „oxidation” of the fat particles occurs when the
temperature of the sides exceeds 170°C. The porous
quality of the catalytic enamel increases the surface
area where the exchange vital to the oxidation of the
fats takes place.

If there is still grime on the catalytic surfaces after
the cooking programme has ended, leave the empty
oven on with the door shut, turning the temperature
adjustment knob to its maximum setting. Leave the
oven like this for a period of time between 60 and 90
minutes, according to how much dirt was left inside.
The cleaning process for more stubborn food residues
may be quickened by using hot water and a soft brush.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

34

Care and Cleaning

DROP DOWN DOORS
Remove the door inner glass as follows.

Remove screws from both side of door

GB

Gently ease the top trim away from door

Gently ease glass upwards and remove from door

NEVER OPERATE THE COOKER WITHOUT THE
INNER DOOR GLASS IN POSITION.

Refit the door inner glass as follows.

1. Open the door fully.

2. Locate the inner door glass into its slots. The inner
door glass has a special reflective coating on one
side, in order to minimise surface temperatures
and energy consumption during use, it is
important it is fitted correctly.

3. Carefully slide the glass into its slots as far as it
will go and replace the top filler cap.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

35

If something
goes wrong...

GB

Before calling a Service Engineer, please check through the following lists.
THERE MAY BE NOTHING WRONG.

Problem Check

Slight odour or

small amount of
smoke when grill /
oven used for first
time

Nothing works

Timer Display
shows '0.00' with

"Auto" Flashing

Main oven and Top

ovens do not work,

but the grill works

This is normal and should cease after a short period.

If you find that the timer display is blank, then it is likely that there is no electricity supply to
your oven. Check:
(i) That the main cooker wall is switched on
(ii) Other appliances, to see if you have had a power cut
(iii) The main circuit breaker for the property

The power supply to your oven has possibly been interrupted, but has now come back on
again. Reset the timer to the correct day and "Manual" operation using the instructions given
in the timer section of the book.

Your timer may be set for an Auto Cooking programme: Check the timer to see whether
'Auto' is lit or flashing. If it is then please follow the instructions given in the Timer section of
this book to return the timer to Manual operation.

Top oven and grill
do not work, but
Main oven works.

Grill keeps turning

on and off

Timer buzzer /

audible tone

operates
continually

Oven temperatures

too high or low

Oven does not
cook evenly

Operating the cooker under the following conditions may cause a safety device to operate:
(a) Grilling with the door closed - Always grill with the door fully open
(b) Grilling for an excessively long period at maximum setting - see Grilling guide.
Switch off appliance and allow to cool for approx 30 mins.
Switch the cooker back on and check that the Grill / Top oven is now operating.

When the Grill control is operating at less than its maximum setting, the Grill will cycle on
and off, this is normal and not

To cancel the audible tone, press the minute minder button.

Check temperature and shelf positions are as recommended in the Oven Temperature
Charts.
It may be necessary to increase or decrease the recommended temperature slightly to suit
your taste.

Check:
(a) Temperature and shelf positions are as recommended in the Oven Temperature

(b) Oven utensils being used allow sufficient air flow around them.

a fault.

Charts.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

36

If something
goes wrong...

Problem Check

Grilling is uneven. Ensure that Grill pan has been positioned as stated in the Grilling section of this book.

Oven lamp does
not work.

Condensation on

the wall at the rear
of the cooker.

Steam /
Condensation in

the oven after use.

The oven lamp is not covered by the guarantee. The part is easily changed (see the section
on oven lamp replacement) A new lamp may be obtained from our Genuine Parts &
Accessories Hotline (see back page).

Steam and / or condensation may appear from the vent at the rear of the appliance when
using an oven particularly for foods with a high water content e.g. frozen chips, roast
chicken etc. This is normal, and any excess should be wiped off.

Steam is a by - product of cooking any food with a high water contact. To help minimise

always:
a) Try to avoid leaving food in the oven to cool after being cooked.

b) Use a covered container, wherever possible.

GB

If you have been through the above list and there is still a problem, contact Service (see back page).

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

37

GB

Disposal of your product

To minimise the risk of injury to children please dispose
of your product carefully and safely. Remove all doors
and lids. Remove the mains cable (where fitted) by
cutting off flush with the appliance and always ensure
that no plug is left in a condition where it could be
connected to the electricity supply.
To help the environment, Local Authority instructions
should be followed for the disposal of your product.

Disposal of old electrical appliances

Assembling the sliding rack kit

To assemble the sliding racks:

1. Remove the two
frames, lifting them away
from the spacers A (see

A

 gure).

The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE), requires
that old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected separately
in order to optimise the recovery and recycling of
the materials they contain and reduce the impact on
human health and the environment.
The crossed out „wheeled bin” symbol on the product
reminds you of your obligation, that when you dispose
of the appliance it must be separately collected.
Consumers should contact their local authority or
retailer for information concerning the correct disposal
of their old appliance.

Respecting and conserving the
environment

• Whenever possible, avoid pre-heating the oven
and always try to fill it. Open the oven door as little
as possible because heat is lost every time it is
opened. To save a substantial amount of energy,
simply switch off the oven 5 to 10 minutes before the
end of your planned cooking time and use the heat
the oven continues to generate.

• Keep gaskets clean and tidy to prevent any door
energy losses

• If you have a timed tariff electricity contract, the “delay
cooking” option will make it easier to save money by
moving operation to cheaper time periods.

Left
guide rail

Right guide
rail

2. Choose which shelf
to use with the sliding
rack. Paying attention
to the direction in which

B

D

C

i

re

o

c

f

t

extrac

ion

t

i

on

the sliding rack is to be
extracted, position joint
B and then joint C on the
frame.

3. Secure the two frames
with the guide rails
using the holes provided
on the oven walls (see
diagram). The holes
for the left frame are

D

situated at the top, while
the holes for the right
frame are at the bottom.

4. Finally, fit the frames on the spacers A.
! Do not place the sliding racks in position 5.

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

38

Guarantee

12 months Parts and Labour Guarantee

Your appliance has the benefit of our manufacturer’s guarantee, which covers the cost of

breakdown repairs for twelve months from the date of purchase.

This gives you the reassurance that if, within that time, your appliance is proven to be

defective because of either workmanship or materials, we will, at our discretion, either repair

or replace the appliance at no cost to you.

The guarantee is subject to the following conditions:

- The appliance has been installed and operated correctly and in accordance with our ope­rating and maintenance instructions.

- The appliance is only used on the electricity or gas supply printed on the rating plate.

- The appliance has been used for normal domestic purposes only.

- The appliance has not been altered, serviced, maintained, dismantled or otherwise interfered
with by any person not authorised by us.

- Any repair work must be undertaken by us or our appointed agent.

- Any parts removed during repair work or any appliance that is replaced become our property.

- The appliance is used in the United Kingdom or Republic of Ireland.

GB

The guarantee does not cover:

- Damage resulting from transportation, improper use, neglect or interference or as a result
of improper installation.

- Replacement of any consumable item or accessory. These include but are not limited to:
plugs, cables, batteries, light bulbs, fluorescent tubes and starters, covers and filters.

- Replacement of any removable parts made of glass or plastic.

THE GUARANTEE WILL NOT APPLY IF THE APPLIANCE HAS BEEN USED IN

COMMERCIAL OR NON-DOMESTIC PREMISES.

5 Year Parts Guarantee

Hotpoint also offers you a FREE 5 year parts guarantee. This additional guarantee is

conditional on you registering your appliance with us and the parts being fitted by one of our

authorised engineers. There will be a charge for our engineer’s time. To activate the extra

parts warranty on your appliance, simply call our registration line on 08448 24 24 24 (ROI 01

230 0800)

Extended Guarantees

We offer a selection of protection plans that enable you to fully cover yourself against the

expense of repair bills for the life of your policy. To find the ideal plan for you please call our

advice line on 08448 226 226 (ROI 01 230 0233)

Free Helpdesk Service

We have a dedicated team who can provide free advice and assistance with your appliance

if you experience any technical difficulties within the first 90 days of ownership.

Simply call our Hotpoint Service Hotline on 08448 224 224 (ROI 0818 313 413) for telephone

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

39

Indesit Company S.P.A.

Viale Aristide Merloni,47
60044 Fabriano (AN)
www.hotpoint.co.uk

04/2014- 195121672.00

XEROX FABRIANO

GB

After Sales Service

No one is better placed to care for your Hotpoint appliance during the course of its working

life than us - the manufacturer.

Essential Contact Information

Hotpoint Service

We are the largest service team in the country offering you access to 400 skilled telephone

advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local

service.

UK: 08448 224 224

Republic of Ireland: 0818 313 413

www.hotpoint.co.uk

Please note: Our advisors will require the following information:

Model number

Serial number

Parts & Accessories

We supply a full range of genuine replacement parts as well as accessory products that

protect and hygienically clean your appliance to keep it looking good and functioning

efficiently throughout its life.

UK: 08448 225 225

Republic of Ireland: 0818 313 413

www.hotpointservice.co.uk

Appliance Registration

We want to give you additional benefits of Hotpoint ownership. To activate your FREE 5 year

parts guarantee you must register your appliance with us.

UK 08448 24 24 24

Republic of Ireland: 01 230 0800

www.hotpointservice.co.uk

As part of Hotpoint’s continued commitment to helping the environment, Hotpoint reserves

the right to use quality, recycled components to keep down customer costs and minimise

material wastage.

Indesit Company UK Limited, Morley Way, Peterborough, PE2 9JB

Indesit Company, Unit 49 Airways Industrial Estate, Dublin 17

PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24

40
