Hotpoint SE861X User Manual

Instructions for Installation and Use

Electric Oven

Models: SE861X

To the Installer

Before installation fill in the product details on the back cover of this book.

The information can be found on the rating plate.

To the User

You must read the instructions prior to installing and using the appliance and

then retain them for future reference.

Operating Instructions

OVEN

GB

Retention of this Instruction Book

This Instruction Book must be kept handy for

reference as it contains important details on the safe

and proper use of the appliance.

If you sell or pass the appliance to someone else, or

move house and leave it behind, make sure this Book

is also provided so the new owner can become

familiar with the appliance and safety warnings.

If the Book is lost or damaged a copy may be

obtained from:

Merloni Elettrodomestici LTD., Morley Way,

Peterborough, PE2 9JB

Contents

Introduction, 3

Installation, 4

Positioning

Electrical connection, 5

Data plate

Description of the appliance, 6

Overall view

Control panel

Start-up and use, 7

Starting the oven

The electronic cooking programmer, 8

Cooking modes, 9-11

Cooking modes

Practical cooking advice

Cooking advice table

Precautions and tips, 12

General safety

Disposal

Respecting and conserving the environment

Maintenance and care, 13

Switching the appliance off

Cleaning the appliance

Cleaning the oven door

Replacing the light bulb

Sliding Rack Kit assembly

After Sales Service, 14

Hotpoint Guarantee, 15

Key Contacts, Back Cover

2

Introduction

Your new electric oven is guaranteed* and will give

lasting service. This guarantee is only applicable if

the appliance has been installed in accordance with

the installation instructions detailed in this booklet.

To help make best use of your cooking equipment,

please read this booklet carefully.

The oven is designed specifically for domestic use

and responsibility will not be accepted for use in any

other installation.

! When the oven is first used, an odour may be

omitted - this will cease after a short period of use.

To help remove the 'new' smell, heat the empty oven

to maximum temperature for a minimum of two to three

hours, keeping the door/s closed. Ensure that the

room is well ventilated (eg. open a window or use an

extractor fan) and that persons who may be sensitive

to the odour avoid any fumes. It is suggested that any

pets be removed from the room until the smell has

ceased.

This odour is due to any temporary finish on oven

linings and elements and any moisture absorbed by

the insulation.

! The guarantee is subject to the provisions that

the appliance:

(a) Has been used solely in accordance with this

booklet.

(b) Has been properly connected to a suitable

supply voltage as stated on the rating plate,

attached to the appliance.

(c) Has not been subjected to misuse or accident

or been modified or repaired by any person

other than the manufacturers authorised

employee or agent.

(d) Has been correctly installed.

GB

3

Installation

GB

! Before placing your new appliance into operation

please read these operating instructions carefully.

They contain important information for safe use, for

installation and for care of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of

the appliance.

Positioning

! Keep packaging material out of the reach of
children. It can become a choking or suffocation

hazard. see Precautions and tips).

! The appliance must be installed by a qualified

person in compliance with the instructions provided.

Incorrect installation may cause harm to persons,

animals or may damage property.

Fitting the appliance

Use the appropriate cabinet to ensure that the

appliance functions properly.

 The panels adjacent to the oven must be made of

heat-resistant material.

Ventilation

To ensure good ventilation, the back panel of the

cabinet must be removed. It is advisable to install the

oven so that it rests on two strips of wood, or on a

completely flat surface with an opening of at least 45 x

560 mm (see diagrams).

45 mm.

560 mm.

Centring and fastening

Position the 4 tabs on the side of the oven according

to the 4 holes of the outer frame. Adjust the tabs

according to the thickness of the cabinet side panel,

as shown below:

thickness of 20 mm: take off

the removable part of the tab

(see diagram)

 Cabinets with a veneer exterior must be assembled

with glues which can withstand temperatures of up

to 100°C.

 To install the oven under the counter (see diagram)

and in a kitchen unit, the cabinet must have the

following dimensions:

567 mm.

45 mm.

558 mm.

593 mm.

23 mm.

595 mm.

5 mm.

595 mm.

545 mm.

24 mm.

! The appliance must not come into contact with

electrical parts once it has been installed.

The consumption indications on the data plate have

been calculated for this type of installation.

thickness of 18 mm: use the

first groove, which has already

been set in the factory (see

diagram)

thickness of 16 mm: use the

second groove (see diagram)

Secure the appliance to the cabinet by opening the

oven door and putting 4 screws into the 4 holes of the

outer frame.

! All parts which ensure the safe operation of the

appliance must not be removable without the aid of a

tool.

4

Electrical Connection

Electrical connection

The electrical connection to the mains must be made

on the appliance. The power voltage and frequency

are as indicated on the rating plate.

! THIS APPLIANCE MUST BE EARTHED.

Connecting the power supply cable

To open the terminal board:

 Using a screwdriver, press on the tabs situated on

each side of the terminal board cover.

 Pull open the terminal board cover.

To connect the power supply cable, proceed as

follows:

 Unscrew the cable clamp screw and the contact

screws L-N-6.

 Fasten the wires beneath the screwheads using the

following colour scheme: Blue (N) Brown (L)

Yellow-Green 6

 Fasten the power supply cable in the

corresponding cable clamp and close the cover.

Electrical Connection:

Power cable supply connection to the electrical

mains:

We recommend you use a power supply cable which

is long enough to allow you to take the oven out of its

recess in the event of maintenance operations (only

use HAR - H 05 - RRF quality cables fitted with a plug

conforming to the regulations in force.

The plug must be accessible at all times.

Unplug the appliance before all operations, even

when replacing the oven lamp.

Using the appliance without correct earthing is

highly dangerous.

! After connecting the appliance to the flexible

cable, tighten all the screws on the terminal board.

DATA PLATE

width cm 37.5

Dimensions

Volume

height cm 32
depth cm 41.5

lt. 50

GB

Voltage Frequency: 230

V-1+N 50Hz

Fuse Section: 16A

Supply cable: 3x1.5mm

4 2

N L

You can connect your oven to the system means of a

terminal board. Refer to above information for the

minimal cable sections and the calibration of the

protective elements according to the connection.

If the appliance is installed with a junction box, an

omnipolar circuit breaker - with a minimum contact

opening of 3mm - should be installed between the

appliance and the mains.

Electrical
connections

2

ENERGY LABEL

voltage: 230-240V ~ 50Hz
maximum power absorbed
2800W-3000W

Directive 2002/40/EC on the label
of electric ovens.
Standard EN 50304

Energy consumption for Natural
convection – heating mode:
Convection mode.

Declared energy consumption for
Forced convection Class – heating
mode: Baking.

This appliance conforms to the
following European Economic
Community directives:
73/23/EEC of 19/02/73 (Low
Voltage) and subsequent
amendments;

- 89/336/EEC of 03/05/89
(Electromagnetic Compatibility) and
subsequent amendments;

- 93/68/EEC of 22/07/93 and
subsequent amendments.

5

Description of the appliance

GB

Overall view

Control panel

Control panel

GRILL

DRIPPING PAN

GUIDES for the

sliding racks

position 5
position 4
position 3
position 2
position 1

SELECTOR

Knob

Indicator light

THERMOSTAT

ELECTRONIC

programmer

THERMOSTAT

Knob

6

Start-up and use

! The first time you use your appliance, heat the empty

oven with its door closed at its maximum temperature

for at least half an hour. Ensure that the room is well

ventilated before switching the oven off and opening

the oven door. The appliance may produce a slightly

unpleasant odour caused by the burning away of

protective substances used during the manufacturing

process.

Starting the oven

1. Select the desired cooking mode by turning the

SELECTOR knob.

2. Select the desired temperature with the

THERMOSTAT knob. See the Cooking advice table for

cooking modes and the suggested cooking

temperatures (see Cooking Modes).

3. When lit, the THERMOSTAT indicator light indicates

that the oven is heating up to the temperature set.

4. You may do the following during cooking:

- change the cooking mode by turning the SELECTOR

knob.

- change the temperature by turning the

THERMOSTAT knob.

- stop cooking by turning the SELECTOR knob to the

0 position.

Cooling ventilation

In order to cool down the external temperature of the

oven, some models are fitted with a cooling fan that

blows out air between the control panel and the oven

door.

! Once the cooking has been completed, the cooling

fan remains on until the oven has cooled down

sufficiently.

Oven light

It goes on when selecting

knob. It stays on when a cooking mode is selected.

with the SELECTOR

GB

! Never put objects directly on the oven bottom to

avoid damaging the enamel coating.

! Always place cookware on the rack(s) provided.

7

The electronic cooking programmer

GB

This feature allows you to program the oven or the grill

as follows:

 delayed cooking time for a specified period;

 immediate start for a specified period;

 timer.

Button Functions:

: Timer with hours and minutes;

H

: cooking time;

$

: end cooking time;

%

: Manual change;

(

: set cooking time (to count down);

)

: set cooking time (to start from zero)

*

How to reset the digital clock

After the appliance has been connected to the power

supply, or after a power cut, the clock display will

automatically reset to 0:00 and begin to blink.
 Press the $ and % buttons consecutively and

then reset the time (within 4 seconds) using the

) and * buttons.
The button * advances the hours.
The button ) decreases the hours.

The time can also be changed in the following two

ways:

1. Repeat all of the steps above.

2. Press the ( button, and then use the ) and *

buttons to reset the time.

Manual operation of the oven

Once the time has been set, the programmer

automatically switches to manual mode.

Note: Press the ( button to restore the manual mode

after every Automatic cooking session.

Delayed cooking time for a specified period

The total cooking time as well as the time at which the

cooking will finish must be set. If we assume that the

time display reads10:00:

1. Turn the oven control knob to the setting and tempe-

rature desired (example: static oven mode at 200°C).

2. Press the button $ and then set the cooking time
(within four seconds) using the ) and * buttons.

Supposing the cooking time is set to 30 minutes, the

display will read as follows:

+

Release the button, and within 4 seconds, the current time

will reappear with the m symbol along with the word auto

3. Press the button % and then use the ) and * buttons

to set the time for when the cooking program should

end. Let us imagine this time to be 1:00 p.m.

=

4. After the button has been released, the current time

will be displayed after approximately 4 seconds:

When auto is on, it indicates that the length of

cooking time and the time it is due to finish have been

programmed in automatic mode. At this point, the

oven will turn on automatically at 12:30 and turn off

after 30 minutes. When the oven is turned on, the

symbol m will be displayed for the entire cooking time.

The cooking duration can be displayed at any time by

pressing the button $ , and the time it is due to finish
may be displayed by pressing the button % .

Once cooking is completed, the timer will ring; to turn

it off, simply press any button except the ) and *

buttons.

Immediate start for a specified period

By programming just the duration (points 1 and 2 of the

Delayed cooking time for specified period section),

cooking will begin immediately.

To cancel a cooking schedule already programmed

Press the $ button, and use the ) button to set the time

to:

,

then press the manual cooking mode button (.

Timer Feature

The timer feature allows you to enter a specific amount

of time and begins to count down. This feature does not

turn the oven on or off; it merely sounds when the time

has elapsed.

When the button  has been pressed, the display will

read as follows:

,

Then use the * and ) buttons to set the desired time.

As soon as the button has been released, the timer will

start to count down and the current time will be

displayed.

.

After the time has expired, an audible signal will be

emitted, which can be turned off by pressing any button

(except the * and ) buttons). At this point the symbol H

will also turn off.

Correction/Cancellation of data

 The data entered can be changed at any time by

pressing the corresponding button and the * or )

buttons.

 When the data for the cooking duration is cancelled,

the data for the time cooking is due to end is also

cancelled automatically, and vice versa.

 If the oven has already been programmed, it will not

accept times for the end of cooking which are before

the start of the programmed cooking process.

?

8

Cooking modes

Cooking modes

! A temperature value can be set for all cooking

modes between 60°C and Max, except for

 BARBECUE (recommended: set only to MAX power

level);

 GRATIN (recommended: do not exceed 200°C).

LEAVENING mode

The oven reaches and maintains a temperature of

40°C irrespective of the position of the THERMOSTAT

knob. This mode is ideal for leavening dough made

with yeast.

TRADITIONAL OVEN mode

Both the top and bottom heating elements will come

on. With this traditional cooking mode, it is best to use

one cooking rack only: if more than one rack is used,

the heat distribution will be uneven.

BAKING mode

The rear heating element and the fan come on,

guaranteeing the distribution of heat delicately and

uniformly throughout the oven. This mode is ideal for

baking and cooking temperature sensitive foods such

as cakes that need to rise and to prepare certain

tartlets on 3 shelves simultaneously.

PIZZA mode

The heating elements (bottom and circular) and the

fan come on. This combination heats the oven rapidly

by producing a considerable amount of heat,

particularly from the bottom element. If you use more

than one rack simultaneously, switch the position of

the dishes halfway through the cooking process.

BARBECUE mode

The top heating element come on. The high and direct

temperature of the grill is recommended for food that

requires high surface temperature. Always cook in this

mode with the oven door closed.

GRATIN mode

The top heating element as well as the fan come on.

This combination of features increases the

effectiveness of the unidirectional thermal radiation of

the heating elements through forced circulation of the

air throughout the oven.

This helps prevent food from burning on the surface,

allowing the heat to penetrate right into the food.

Always cook in this mode with the oven door closed.

GB

FAST COOKING mode

The heating elements and the fan come on,

guaranteeing the distribution of heat consistently and

uniformly throughout the oven.

Pre-heating is not necessary for this cooking mode.

This mode is especially recommended for cooking

pre-packed food quickly (frozen or pre-cooked). The

best results are obtained if you use one cooking rack

only.

MULTI-COOKING mode

All the heating elements (top, bottom and circular), as

well as the fan, will come on. Since the heat remains

constant throughout the oven, the air cooks and

browns food uniformly. A maximum of two racks may

be used at the same time.

9

GB

Practical cooking advice

! Do not place racks in position 1 and 5 during fan-

assisted cooking. Excessive direct heat can burn

temperature sensitive foods.

! In the BARBECUE and GRATIN cooking modes,

particularly when using the rotisserie, place the

dripping pan in position 1 to collect cooking residues

(fat and/or grease).

MULTI-COOKING

 Use position 2 and 4, placing the food that requires

more heat on 2.

 Place the dripping pan on the bottom and the rack

on top.

BARBECUE

 Insert the rack in position 3 or 4. Place the food in

the centre of the rack.

 We recommend that you set the maximum power

level. The top heating element is regulated by a

thermostat and may not always be on.

PIZZA MODE

 Use a light aluminium pizza pan. Place it on the

rack provided.

For a crispy crust, do not use the dripping pan

(prevents crust from forming by extending cooking

time).

 If the pizza has a lot of toppings, we recommend

adding the mozzarella cheese on top of the pizza

halfway through the cooking process.

10

Cooking advice table

Cooking

modes

Leavening

Traditional

Oven

Baking

Mode

Fast

cooking

Multi-

cooking

Pizza Mo d e

Barbecue

Gratin

Foods Weight

Leavening process of dough made with
yeast or baking powder (brioches, bread,
sugar pie, croissants, etc.)

Duck
Roast veal or beef
Pork roa s t
Biscuits (short pastry)
Tarts

Tarts
Fruit cakes
Plum ca ke
Sponge cake
Stuffed pancakes (on 2 racks)
Sma ll cake s (o n 2 ra c ks)
Cheese puffs (on 2 racks)
Cream puffs (on 3 racks)
Biscuits (on 3 racks)
Meringues (on 3 racks)

Frozen food

Pizza
Courgette and prawn pie
Country style spinach pie
Turnovers
Lasagne
Golden Rolls
Chicken morsels

Pre-cooked food

Golden chicken wings 0.4 2 - 200 20-25

Fresh Food

Biscuits (short pastry)
Plum ca ke
Cheese puffs

Pizza (on 2 racks)
Lasagne
Lamb
Roast chicken + potatoes
Mackerel
Plum ca ke
Cream puffs (on 2 racks)
Biscuits (on 2 racks)
Sponge cake (on 1 rack)
Sponge cake (on 2 racks)
Savoury pies

Pizza
Roast veal or beef
Chicken

Soles and cuttlefish
Squid and prawn kebabs
Cuttlefish
Cod filet
Grilled vegetables
Veal steak
Sausages
Hamburgers
Mackerels
Toasted sandwiches (or toast)

Gr il le d c hic k en
Cuttlefish

(in kg )

1
1
1

-

1

0.5
1

0.7

0.5

1.2

0.6

0.4

0.7

0.7

0.5

0.3

0.4

0.5

0.3

0.5

0.4

0.4

0.3

0.6

0.2
1

1
1

1+1

1
1

0.5

0.5

0.5
1

1.5

0.5
1
1

0.7

0.6

0.6

0.8

0.4

0.8

0.6

0.6
1

4 and 6

1.5

1.5

Rack Position Pre-heating

time

(min utes)

3
3
3
3
3

3

2 or 3

3

3
2 and 4
2 and 4
2 and 4

1 and 3 and 5
1 and 3 and 5
1 and 3 and 5

2

2

2

2

2

2

2

2

2

2
2 and 4

3

2
2 and 4

2

2
2 and 4
2 and 4

2
2 and 4

3

3

2

2 or 3

4

4

4

4

3 or 4

4

4

4

4

4

2

2

15
15
15
15
15

15
15
15
15
15
15
15
15
15
15

-

-

-

-

-

-

-

-

-

-

15
10
10
15
10
10
10
10
10
10
15

15
10
10

-

-

-

-

-

-

-

-

-

­10
10

Recommended

temperature

200
200
200
180
180

180
180
180
160
200
190
210
180
180

90

250
200
220
200
200
180
220

200
180
210

230
180
180
200
180
170
190
180
170
170
200

220
220
180

Max
Max
Max
Max
Max
Max
Max
Max
Max
Max

200
200

GB

Cooking

time

(min utes)

65-75
70-75
70-80
15-20
30-35

20-30
40-45
40-50
25-30
30-35
20-25
15-20
20-25
20-25

180

12
20

30-35

25

35
25-30
15-20

15-18

45
10-12

15-20
30-35
40-45
60-70
30-35
40-50
20-25
10-15
15-20
20-25
25-30

15-20
25-30
60-70

10-12

8-10
10-15
10-15
15-20
15-20
15-20
10-12
15-20

3-5
55-60
30-35

11

Precautions and tips

GB

! The appliance was designed and manufactured in

compliance with international safety standards. The

following warnings are provided for safety reasons

and must be read carefully.

General safety

 The appliance was designed for domestic use

inside the home and is not intended for commercial

or industrial use.

 The appliance must not be installed outdoors, even

in covered areas. It is extremely dangerous to leave

the appliance exposed to rain and storms.

 When handling the appliance, always use the

handles provided on the sides of the oven.

 Do not touch the appliance with bare feet or with

wet or moist hands and feet.

 The appliance must be used to cook food by adults

only and according to the instructions in this

manual.

 When the appliance is in use, the heating

elements and some parts of the oven door

become extremely hot. Make sure you don't

touch them and keep children well away.

 When unplugging the appliance always pull the

plug from the mains socket, do not pull on the

cable.

 Never carry out any cleaning or maintenance work

without having unplugged the plug from the mains.

 In the case of a malfunction, under no

circumstances should you attempt to repair the

appliance yourself. Repairs carried out by

inexperienced persons may cause injury or further

malfunctioning of the appliance. Contact a Service

Centre (see Assistance).

 Do not rest heavy objects on the open oven door.

Disposal

 Observe local environmental standards when

disposing packaging material for recycling

purposes. Observe existing legislation when

disposing of the old appliance.

 Contact your Local Organisation in charge of waste

disposal.

 Make the appliance unusable by cutting off the

electrical cable before disposal.

 Ensure that the power supply cable of other

electrical appliances does not come into contact

with the hot parts of the oven.

 The openings used for ventilation and dispersion of

heat must never be covered.

 Always grip the oven door handle in the centre: the

ends may be hot.

 Always use oven gloves to place cookware in the

oven or when removing it.

 Do not use aluminium foil to line the bottom of the

oven.

 Do not place flammable materials in the oven: if the

appliance is switched on by mistake, it could catch

fire.

 Always make sure the knobs are in the l/

position when the appliance is not in use.

¡

Respecting and conserving the

environment

 By using the appliance in the hours between late

afternoon and early morning, you can help reduce

the work load placed on electrical companies.

 Always keep the oven door closed when using the

BARBECUE and GRATIN modes: to attain best

results and to save energy (approximately 10%).

 Regularly check the door seals and wipe clean to

ensure they are free of debris so that they stick

properly to the door and do not allow heat to

disperse.

12

Maintenance and care

Switching the appliance off

Disconnect your appliance from the electricity supply

before carrying out any work on it.

Cleaning the appliance

 The stainless-steel or enamel-coated external parts

as well as the rubber seals may be cleaned using a

sponge that has been soaked in lukewarm water

and neutral soap. If these stains are difficult to

remove, use only specialised products. After

cleaning, rinse and dry thoroughly. Do not use

abrasive powders or corrosive substances.

 Ideally, the inside of the oven should be cleaned

after each use, when it is still lukewarm. Use hot

water and detergent, rinse and dry with a soft cloth.

Do not use abrasive products.

 The accessories can be washed like everyday

crockery (even in your dishwasher).

Cleaning the oven door

Clean the glass door using non-abrasive products and

sponges and dry it with a soft cloth.

To clean more thoroughly, you can remove the oven

door.

1. Open the oven door fully (see diagram).

2. Lift up and turn the small levers located on the two

hinges (see diagram).

Replacing the light bulb

To replace the oven light bulb:

1. Remove the glass cover of the lamp-holder.

2. Remove the

light bulb and

replace it with a

similar one:

Wattage 25 W,

cap E 14.

3. Replace the

glass cover (see

diagram).

Sliding Rack Kit Assembly

To assemble the sliding racks:

1. Remove the two

frames, lifting them

away from the spacers

A

A (see figure).

GB

F

3. Grip the door on the two

external sides and close it

approximately half way. Unlock

the door by pressing on the

clamps F, then pull the door

F

towards you lifting it out of its

seat (see diagram).

To replace the door, reverse

this sequence.

Inspecting the seals

Check the door seals around the oven periodically. If

the seals are damaged, please contact your nearest

After-sales Service Centre (see Assistance). We

recommend not using the oven until the seals have

been replaced.

Left
guide rail

4. Finally, fit the frames on spacer A.

B

Right guide
rail

Direction

C

of extraction

D

2. Choose which shelf to

use with the sliding

rack. Paying attention to

the direction in which

the sliding rack is to be

extracted, position joint

B and then joint C on

the frame.

3. Secure the two

frames with the guide

rails using the holes

provided on the oven

walls (see diagram). The

holes for the left frame

are situated at the top,

while the holes for the

right frame are at the

bottom.

13

After Sales Service

"No company is better positioned to offer an after sales service on a

Hotpoint appliance than us - the manufacturer"

As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive

parts and labour guarantee for the first 12 months. In addition to this you also have the advantage of

free

replacement parts for the first 5 years when fitted by a Hotpoint

engineer. When the 12 months parts and labour guarantee expires we offer the following after sales

service options:

Repair Service and Information Help Desk

UK: 08709 066066

www.hotpointservice.co.uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the Model number and the Serial number of your appliance

Available 364 days a year with a fast, effective and value for money service. We have the largest

white goods repair service in the UK with over 1000 of our own fully trained engineers. All repairs

include a parts and labour guarantee for 12 months from the date of the repair.

If you require any information or have any questions about your appliance, our operators are on

hand with help and advice.

All this ensures that you will receive the best available after sales service possible.

Extended Warranties

UK: 08709 088 088

www.hotpointservice.co.uk

Republic of Ireland: 1850 502 200

Whether you have just one or a number of Hotpoint appliances in your kitchen, we offer two service

cover plans to give you total peace of mind.

l Repair Protection Plan - FREE service repairs for a single Hotpoint appliance during the period of

cover.

l Kitchen Cover - FREE service repairs for all your Hotpoint appliances less than 8 years old.

Genuine Parts and Accessories UK: 08709 077 077

www.hotpointservice.co.uk

Republic of Ireland: [phone]

A wide range of genuine parts and accessories are available from our hotline or through our web

site.

Genuine parts and accessories, extended warranties and service repairs are all

available on our web-site at:

www.hotpointservice.co.uk

Guarantee

"Satisfaction guaranteed or your money back"

We give you a unique 'satisfaction guaranteed' promise - valid for 90 days - after you have

purchased your Hotpoint appliance. If there is a technical problem simply call Hotpoint Repair

service or visit our web-site at www.hotpointservice.co.uk and where necessary, we will arrange for

an engineer to call. If the technical problem is not resolved under this guarantee, we will replace

your machine or, if you prefer, give you your money back.

All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free

replacement parts for the first 5 years provided that they are fitted by a Hotpoint engineer.

Guarantee terms and conditions

Your guarantee is only applicable in the United Kingdom or Republic of Ireland and is subject to the

following provisions that your appliance:

l Has been installed and used correctly in accordance with this instruction booklet.

l Has been used solely for domestic purposes and is located on domestic premises (ie. not for

commercial or trade use).

l Has been properly connected to a suitable electrical supply voltage as stated on the appliance

rating plate.

l Has not been subject to misuse, accident, modified or repaired by anyone other than one of our

own service engineers.

For pre purchase information on any other Hotpoint product call: 08701 50 60 70

or visit: www.hotpointservice.co.uk

Recycling & Disposal Information

As part of Hotpoint's continued commitment to helping the environment, Hotpoint reserves the right to

use quality recycled components to keep down customer costs and minimise material wastage.

Please dispose of packaging and old appliances carefully.

To minimise risk of injury to children, remove the door, plug and cut mains cable off flush with the

appliance. Dispose of these parts separately to ensure that the appliance can no longer be plugged

into a mains socket, and the door cannot be locked shut.

Key Contacts

After Sales Service

Over 1200 trained specialists, directly employed by us, ensure that you can have complete

confidence in both the appliances and services we offer.

Repair Service and Information Desk

UK: 08709 066 066

(Open 8 to 8 Mon - Fri, 8.30 to 5.30 Sat, 10 to 4 Sun & Bank Holidays)

www.hotpointservice.co.uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the following information:

Model number:

Serial number:

Extended Warranties

UK: 08709 088 088

(Open 8 to 8 Mon - Sun)

www.hotpointservice.co.uk

Republic of Ireland: 1850 502 200

Genuine Parts and Accessories

UK: 08709 077 077

(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)

www.hotpointservice.co.uk

Republic of Ireland: [phone]

Merloni Elettrodomestici UK Ltd, Morley Way, Peterborough, PE2 9JB.

195.047.275.00 11-2004 Part no. FP139 - 01
