Hotpoint HS63X, HS93I, HS93X, HS73X User Manual

Instructions

MorleyWay,Peterborough,PE29JB,England

www.hotpoint.co.uk

Hood

Instructions for use

HOOD

GB

English

HS 63 X
HS 73 X
HS 93 X
HSD 93I

Contents

GB

Installation, 2-3

Assembly

Technical information, 4

Electrical connection
Power cable
Technical data

Description, 5

Filtering version
Ducting version

Operation, 6

Controls

Maintenance,7

Cleaning the hood
Cleaning the grease filters
Replacing the charcoal filter
Replacing the lamps

Precautions and tips, 8

General safety
Air vent
Disposal

Installation

GB

Assembly

Before proceeding with the assembly operations,
remove the grease filters so that the hood is easier to
handle (for the instructions see the paragraph

“Cleaning the grease filters” in the chapter on
“Maintenance”).

Fixing to the wall

1) Draw a line on the wall along the vertical axis of the
hob. Mark the 2 holes (A) to be made in the wall
respecting the measurements indicated in the figure
below.

2) Drill the holes (8 mm ø) and fit the 2 screw anchors
(provided).

3) Fix the metal bracket (B) to the wall with 2 screws
using the 2 holes drilled. Use the 2 triangles cut into
the bracket to position it exactly along the vertical
axis of the hood.

4) Then hook the hood onto the metal bracket.Adjust
the horizontal position by moving the hood to the
right or left as required to align it with the wall units.
If the hood also needs to be adjusted in height,
operate on the adjusting screws (C).

5) Once adjusted, finally fix the hood with a further 4
screws (D): Mark the 4 holes to be drilled on the
wall, unhook the hood and drill the holes marked (8
mm diameter); then use the screw anchors and the
screws provided for final fixing.

6) For the hoods in filtering version, fit the reducer (E).

Securing the decorative flue

1) Assemble the support bracket of the decorative flue
and adjust the width with the 2 screws (F).
Then, using the screw anchors and the screws (G),
secure it to the ceiling in such a way that it is in line
with the hood.

2) For the filtering version, the air vent grilles (H) must
be positioned at the top. For the ducting version,
turn the upper flue upside down so that the air vent
grilles are at the bottom.

2
