HFF3114UK
HFF31014UK
KHFF3114UK
English
Operating Instructions
REFRIGERATOR/FREEZER COMBINATION
Contents
Operating Instructions, 1
Assistance, 2
Description of the appliance, 3
Energy Saving, 3
Description of the appliance, 4
Installation, 5
Start-up and use, 6
Maintenance and care, 7
Precautions and tips, 8
Troubleshooting, 9
Product Guarantee and
Repair Information
Guarantee
12 Months Parts and Labour Guarantee
Your appliance has the benefit of our manufacturer’s guarantee,
which covers the cost of breakdown repairs for twelve months
from the date of purchase.
This gives you the reassurance that if, within that time, your
appliance is proven to be defective because of either
workmanship or materials, we will, at our discretion, either repair
or replace the appliance at no cost to you:
This guarantee is subject to the following conditions:
- The appliance has been installed and operated correctly and in
accordance with our operating and maintenance instructions.
- The appliance is used only on the electricity or gas supply printed
on the rating plate.
- The appliance has been used for normal domestic purposes only.
- The appliance has not been altered, serviced, maintained,
dismantled, or otherwise interfered with by any person not
authorised by us.
- Any repair work must be undertaken by us or our appointed
agent.
- Any parts removed during repair work or any appliance that is
replaced become our property.
- The appliance is used in the United Kingdom or Republic of
Ireland.
The guarantee does not cover:
- Damage resulting from transportation, improper use, neglect or
interference or as a result of improper installation.
- Replacement of any consumable item or accessory. These
include but are not limited to: plugs, cables, batteries, light
bulbs, fluorescent tubes and starters, covers and filters.
- Replacement of any removable parts made of glass or plastic.
THIS GUARANTEE WILL NOT APPLY IF THE APPLIANCE HAS
BEEN USED IN COMMERCIAL OR NON-DOMESTIC PREMISES.
Recycling and Disposal Information
As part of Hotpoint’s continued commitment to helping the
environment, Hotpoint reserves the right to use quality, recycled
components to keep down customer costs and minimise material
wastage.
Please dispose of packaging and old appliances carefully. To
minimise the risk of injury to children, remove the door, plug, and
cut the mains cable off flush with the appliance. Dispose of these
parts separately to ensure that the appliance can no longer be
plugged into mains socket, and the door cannot be locked shut.
Repairs and After Sales
For product help and advice, repairs, spare parts or accessories,
we’re here to help.
For local repair engineers - 03448 111 606
ROI - 0818 313 413
UK standard local rate applies
ROI local Irish rate applies
For Parts and Accessories visit:
parts.hotpoint.co.uk/shop
Please remember to register your appliance at
www.hotpointservice.co.uk to activate your 10 year parts
guarantee.
Please note, our advisors will require the following information:
model number, serial number
- model - serial number
2
Description of the appliance
Control panel
1. ON/OFF
The whole product (both fridge and freezer compartments)
can be turned on by pressing this button for 2 seconds.
The last set value is indicated on the interface. Press this button
to turn off the device. An audible signal will confirm the “off
commutation of the product”.
2. FRIDGE temperature indicator
It shows the temperature of the fridge compartment.
3. FRIDGE temperature setting
It allows you to change the fridge temperature value, in a
cyclical way; it also confirms the selected temperature on the
interface.
4 QUICK FREEZE indicator light (rapid freezing)
illuminates when the QUICK FREEZE button is pressed.
5 QUICK FREEZE button (rapid freezing)
To be used to freeze fresh foods. When it is pressed, the QUICK
FREEZE indicator light illuminates (see Start-up and use).
2
1
4
53
3
Description of the appliance
Overall view
The instructions contained in this manual are applicable to different
model refrigerators. The diagrams may not directly represent the
appliance purchased. For more complex features, consult the
following pages.
1 STORAGE compartment *
2 FREEZER and STORAGE compartment
3 FRUIT and VEGETABLE bin *
4 Food Care Zone / ‘‘Food Care Zone 0°C”/ Safe Defrost*
5 WINE RACK *
6 SHELVES *
7 LAMP (see Maintenance). *
8 Removable multipurpose SHELVES *
9 BOTTLE shelf
10 FRESH BOX *
11 ACTIVE OXYGEN *
12 AIR *
* Varies by number and/or position, available only on certain
models.
4
Installation
! Before placing your new appliance into operation please read
these operating instructions carefully. They contain important
information for safe use, for installation and for care of the
appliance.
! Please keep these operating instructions for future reference.
Pass them on to possible new owners of the appliance.
Disposing of the plug
Cut off and dispose of the supplied plug if it does not fit your socket.
The cable should be cut as close as possible to the moulded plug.
Remove the fuse.
WARNING:
To avoid a shock hazard do not insert the discarded plug
into a socket anywhere else.
GB
Positioning and connection
Positioning
1.Place the appliance in a well-ventilated humidity-free room.
2.Do not obstruct the rear fan grills. The compressor and
condenser give off heat and require good ventilation to operate
correctly and save energy.
3.Ensure the appliance is away from any sources of heat (direct
sunlight, electric stove, etc.).
Electrical connections
After the appliance has been transported, carefully place it
vertically and wait at least 3 hours before connecting it to the
electricity mains. Before inserting the plug into the electrical socket
ensure the following:
• The appliance is earthed and the plug is compliant with the law.
• The socket can withstand the maximum power of the appliance,
which is indicated on the data plate located on the bottom left
side of the fridge (e.g. 150 W).
• The voltage must be in the range between the values indicated
on the data plate located on the bottom left side (e.g. 220-
240V).
• The socket is compatible with the plug of the appliance. If
the socket is incompatible with the plug, ask an authorised
technician to replace it (see Assistance). Do not use extension
cords or multiple sockets.
! Once the appliance has been installed, the power supply cable
and the electrical socket must be easily accessible.
! The cable must not be bent or compressed.
! The cable must be checked regularly and replaced by authorised
technicians only (see Assistance).
! The manufacturer declines any liability should these safety
measures not be observed.
Fitting a new plug
IMPORTANT:
WIRES IN THE MAINS LEAD ARE COLOURED IN ACCORDANCE
WITH THE FOLLOWING CODE...
Green and Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the wires in the mains lead may not correspond
with the coloured markings identifying the terminals in your plug,
proceed as follows:
- Connect Green and Yellow wire to terminal marked ‘E’ or
or coloured Green and Yellow.
- Connect Brown wire to terminal marked ‘L’ or coloured red or
brown.
- Connect Blue wire to terminal marked ‘N’ or coloured Black
or Blue.
If a 13amp plug (BS 1363) is used it must be fitted with a 13amp fuse.
WARNING:
THIS APPLIANCE MUST BE EARTHED.
Replacing fuse covers:
When replacing a faulty fuse, a 13amp ASTA approved fuse to BS
1362 should always be used and the fuse cover re-fitted.
If the fuse cover is lost, the plug must not be used until a
replacement is obtained.
Replacement fuse covers:
If a replacement fuse cover is fitted, it must be of the correct
colour as indicated by the coloured marking or the colour that is
embossed in words on the base of the plug.
Changing the plug:
Removing the plug
If your appliance has a non-rewireable moulded plug and you
should wish to remove it to add a longer cable or to re-route the
mains cable through partitions, units etc. please ensure that either:
- The plug is replaced by a fused 13amp re-wireable plug
bearing the BSI mark of approval.
or
- The mains cable is wired directly into a 13amp cable outlet,
controlled by a switch (in compliance with BS 5733) which is
accessible without moving the appliance.
If you are in any doubt about the electrical supply to your
machine, consult a qualified electrician before use.
CE Marking certifies that this appliance conforms to the
following EEC directives:
Low Voltage Equipment - 73/23/EEC & 93/68 EEC
Electromagnetic Compatibility 89/336/EEC, 92/31/EEC &
93/68/EEC
Start-up and use
Starting the appliance
! Before starting the appliance, follow the installation
instructions (see Installation).
! Before connecting the appliance, clean the compartments and
accessories well with lukewarm water and bicarbonate.
! The appliance comes with a motor protection control system
which makes the compressor start approximately 8 minutes
after being switched on. The compressor also starts each time
the power supply is cut off whether voluntarily or involuntarily
(blackout).
5
1. Insert the plug into the socket and make sure that the
A
B
GB
TEMPERATURE indicator light illuminates. If the temperature
indicator light doesn’t illuminate, press the ON/OFF button.
2. Set the TEMPERATURE indicator lights to an average value .
AIR *
It is recognizable due to the presence of the mechanism on the
top part of the refrigerator compartment (see diagram).
AIR maximises air circulation, improving the efficiency of the
evaporator and helping to achieve the optimal temperature inside
the refrigerator as quickly as possible each time it has been
opened. The blown air (A) is cooled when it comes into contact
with the cold wall, whereas the hotter air (B) is sucked up (see
diagram).
ACTIVE OXYGEN *
This device releases ozone molecules inside the refrigerator;
ozone is a natural substance which combats bacteria and
microorganisms, reducing their proliferation while limiting
unpleasant odours.
Automatically defines the amount of ozone required for prolonging
the freshness of foodstuffs, eliminating odours and preventing
bacteria build-up.
There may be a slight distinctive odour inside the refrigerator.
The very same smell can sometimes be detected during a storm,
due to the ozone produced as the charge in the lightning bolts
is released; this is completely normal. The amount produced by
the device is very small and abates quickly as the antibacterial
action takes place.
Device is activated pressing the dedicated switch located in right
side of the Oxigen device.
SHELVES: with or without grill.
Due to the special guides the shelves are removable and the
height is adjustable (see diagram), allowing easy storage of large
containers and food. Height can be adjusted without complete
removal of the shelf.
Food Care Zone *
Area dedicated to the storage of fresh food, such as meat and
fish. Thanks to the low temperature inside the compartment, the
Food Care Zone extends the period of time for which the food
can be stored, keeping it fresh for up to a week.
FOOD CARE ZONE 0°C / Safe Defrost*:
In the “FOOD CARE ZONE 0°C” compartment there are lower
temperatures than in the fridge. Temperatures can go below 0°C.
This compartment is the ideal spot to store meat and fish. You
can also store milk, dairy products, fresh pasta, cooked food or
leftovers.
This compartment is also suitable to defrost foods in a healthy
way, because the defrosting process at low temperatures inhibits
the micro organisms proliferation.
This compartment is not suitable for vegetables, salad and salads.
The 0°C can be obtained in normal conditions and when the
fridge compartment is set to 4° and the freezer is set to -18° C.
When you decrease the fridge temperature you also decrease
the temperature of the “FOOD CARE ZONE 0°C” compartment.
FRESH BOX *
This is the new container, designed to keep various foods (such
as cheese and cold meats) fresher for longer. If it is not needed, it
can easily be removed from the refrigerator compartment. If there
is a Bottle Shelf, more internal space can be created by placing
the Fresh Box directly inside it.
TEMPERATURE Indicator light*: to identify the coldest area in
the refrigerator.
With the Active Oxigen switched on, the device will operate
a repeted cycle until the key is pressed again. There will be
an Ozone emission noticed by the switching on of the green
led located on the Active Oxigen device located in the fridge
compartment and a stand-by cicle (without zone emission) noticed
by blue light.
Using the refrigerator to its full potential
• Adjust the temperature using the display.
• Place only cold or lukewarm foods in the compartment, never
hot foods (see Precautions and tips).
• Remember that cooked foods do not last longer than raw foods.
• Do not store liquids in open containers: they will increase the level
of humidity in the refrigerator and cause condensation to form.
* Varies by number and/or position, available only on certain
models.
6
1. Check that OK appears clearly on the indicator light (see
diagram).
2. If the word “OK” does not appear it means that the temperature
is too high: adjust the REFRIGERATOR OPERATION knob to a
higher position (colder) and wait approximately 10 hours until
the temperature has been stabilised.
3. Check the indicator light again: if necessary, readjust it following
the initial process. If large quantities of food have been added
or if the refrigerator door has been opened frequently, it is
normal for the indicator not to show OK. Wait at least 10 hours
before adjusting the REFRIGERATOR OPERATION knob to a
higher setting.
LED *
Thanks to the powerful light it emits, the new LED lighting system
offers a clear view of all foods, with no shadowy areas. If the LED
needs to be replaced, please contact the Technical Assistance
Service.
Using the freezer to its full potential
• Use the TEMPERATURE CONTROL button to set the
temperature value.
We recommend, however, a medium position.
• Do not re-freeze food that is defrosting or that has
already been defrosted. These foods must be cooked
and eaten (within 24 hours).
• Fresh food that needs to be frozen must not come into
contact with food that has already been defrosted.
Fresh food must be stored in the FREEZER and
STORAGE compartment.
• Do not place glass bottles which contain liquids, and
which are corked or hermetically sealed in the freezer
because they could break.
• The maximum quantity of food that may be frozen daily is
indicated on the plate containing the technical properties
located within the freezer (for example: Kg/24h: 4).
• To freeze (if the freezer is already operating):
- for small quantities which are less than those
indicated on the data plate, press the rapid freezing
QUICK FREEZE button (corresponding indicator light
illuminates), insert the food and close the door. The
function is disabled automatically after 24 hours.
2.Pull the plug out of the socket.
! If this procedure is not followed, the alarm may sound. This alarm
does not indicate a malfunction. To restore normal operation,
hold the ON/OFF button down for more than two seconds. To
disconnect the appliance, follow points 1 and 2 above.
Cleaning the appliance
• The external and internal parts, as well as the rubber seals may
be cleaned using a sponge that has been soaked in lukewarm
water and bicarbonate of soda or neutral soap. Do not use
solvents, abrasive products, bleach or ammonia.
• The removable accessories may be soaked in warm water and
soap or dishwashing liquid. Rinse and dry them carefully.
• The back of the appliance may collect dust which can be
removed by delicately using the hose of a vacuum cleaner set
on medium power. The appliance must be switched off and
the plug must be pulled out before cleaning the appliance.
Avoiding mould and unpleasant odours
• The appliance is manufactured with hygienic materials which
are odour free. In order to maintain an odour free refrigerator
and to prevent the formation of stains, food must always be
covered or sealed properly.
• If you want to switch the appliance off for an extended period
of time, clean the inside and leave the doors open.
Defrosting the appliance
! Follow the instructions below.
Do not speed up the defrosting process by using any devices
or tools other than the scraper provided, you may damage the
refrigeration circuit.
Defrosting the refrigerator compartment
The refrigerator has an automatic defrosting function: water is
ducted to the back of the appliance by a special discharge outlet
(see diagram) where the heat produced by the compressor causes
it to evaporate. It is necessary to clean the discharge hole regularly
so that the water can flow out easily.
GB
• In order to obtain a greater amount of space in
the freezer compartment, you may remove the
bins (except the lowest bin and the special COOL
CARE ZONE bin (if exists), which has an adjustable
temperature) and place the food directly onto the
supplied rack.
! To avoid blocking the air circulation inside the
freezer compartment, it is advisable not to obstruct the
ventilation holes with food or containers.
! Do not open the door during freezing.
! If there is a power cut or malfunction, do not open the freezer
door. This will help maintain the temperature inside the freezer,
ensuring that foods are conserved for at least 9 -14 hours.
! If the room temperature drops below 14°C for an extended period
of time, the ideal temperature will not be reached in the freezer
compartment and food preservation will be reduced.
Maintenance and care
Switching the appliance off
During cleaning and maintenance it is necessary to disconnect
the appliance from the electricity supply:
1.Press the ON/OFF button to switch off the appliance.
* Varies by number and/or position, available only on certain
models.
Defrosting the freezer compartment
If the frost layer is greater than 5 mm, it is necessary to defrost
manually:
1. The day before defrosting, press the QUICK FREEZE
button to further cool the food. The function is automatically
disabled after 24 hours, or it may be disabled at any
moment by pressing the QUICK FREEZE button again. Press
the ON/OFF button to switch off the appliance.
2. Wrap frozen foods in newspaper and place them in another
freezer or in a cool place.
3. Leave the door open until the frost has melted completely. This
can be made easier by placing containers with lukewarm water
in the freezer compartment.
4. Clean and dry the freezer compartment carefully before
switching the appliance on again.
Replacing the light bulb *
To replace the light bulb in the refrigerator compartment, pull out
7
the plug from the electrical socket. Follow the instructions below.
GB
Access the light bulb by removing the cover as indicated in the
diagram. Replace it with a similar light bulb within the power range
indicated on the cover.
Disposal
• Observe local environmental standards when disposing
packaging material for recycling purposes.
• The European Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal
unsorted municipal waste stream. Old appliances must be
collected separately in order to optimise the recovery and
recycling of the materials they contain and reduce the impact
on human health and the environment. The crossed out
“wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance it must be
separately collected. Consumers should contact their local
authority or retailer for information concerning the correct
disposal of their old appliance.
Precautions and tips
! The appliance was designed and manufactured in compliance
with international safety standards. The following warnings are
provided for safety reasons and must be read carefully.
This appliance complies with the following Community Directives:
- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent amendments;
-89/336/EEC of 03.05.89 (Electromagnetic Compatibility) and
subsequent amendments;
- 2002/96/CE.
General safety
• The appliance was designed for domestic use inside the home
and is not intended for commercial or industrial use.
• The appliance must be used to store and freeze food products
by adults only and according to the instructions in this manual.
• The appliance must not be installed outdoors, even in covered
areas. It is extremely dangerous to leave the appliance
exposed to rain and storms.
• Do not touch the appliance with bare feet or with wet or moist
hands and feet.
• Do not touch the internal cooling elements: this could cause
skin abrasions or frost/freezer burns.
• When unplugging the appliance always pull the plug from the
mains socket, do not pull on the cable.
• Before cleaning and maintenance, always switch off the
appliance and disconnect it from the electrical supply. It is not
sufficient to set the temperature adjustment knobs on ON/OFF
(appliance off) to eliminate all electrical contact.
• In the case of a malfunction, under no circumstances should
you attempt to repair the appliance yourself. Repairs carried
out by inexperienced persons may cause injury or further
malfunctioning of the appliance.
• Do not use any sharp or pointed utensils or electrical equipment
- other than the type recommended by the manufacturer - inside
the frozen food storage compartments.
• Do not put ice cubes taken directly from the freezer into your
mouth.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or lack of experience
and knowledge unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
• Keep packaging material out of the reach of children! It can
become a choking or suffocation hazard.
Respecting and conserving the
environment
• Install the appliance in a fresh and well-ventilated room. Ensure
that it is protected from direct sunlight and do not place it near
heat sources.
• Try to avoid keeping the door open for long periods or opening
the door too frequently in order to conserve energy.
• Do not fill the appliance with too much food: cold air must
circulate freely for food to be preserved properly. If circulation
is impeded, the compressor will work continuously.
• Do not place hot food directly into the refrigerator. The internal
temperature will increase and force the compressor to work
harder and will consume more energy.
• Defrost the appliance if ice forms (see Maintenance). A thick
layer of ice makes cold transference to food products more
difficult and results in increased energy consumption.
Troubleshooting
If the appliance does not work, before calling for Assistance (see
Assistance), check for a solution from the following list.
The interface is off.
• The plug is not inserted in the outlet, or it is not powerful enough
to create a contact, or there is no electricity in the house.
The motor does not start.
• The appliance comes with a motor protection control (see
Start-up and use).
The interface is weakly on.
• Pull out and reverse the plug before putting it back in the socket.
a) The alarm sounds.
a) The refrigerator door has remained open for more than two
minutes (the buzzer will stop sounding when you shut the door)
or the correct switching-off procedure was not followed (see
Maintenance).
The refrigerator and the freezer do not cool well.
• The doors do not close properly or the seals are damaged.
• The doors are opened too frequently.
• The FRIDGE TEMPERATURE is not correct (see Description).
• The refrigerator or the freezer have been over-filled.
The food inside the refrigerator is beginning to freeze.
• The FRIDGE TEMPERATURE is not correct (see Description).
• The food is in contact with the back inside wall of the
refrigerator.
The motor runs continuously.
• The QUICK FREEZE button was pressed: the yellow QUICK
FREEZE indicator is on (see Description).
8
• The door is not closed properly or is continuously opened.
• The outside ambient temperature is very high.
The appliance makes a lot of noise.
• The appliance has not been installed on a level surface (see
Installation).
• The appliance has been installed between cabinets that vibrate
and make noise.
• The internal refrigerant makes a slight noise even when the
compressor is off. This is not a defect, it is normal.
The back wall of the refrigerator unit is covered in frost or
droplets of water
• This shows the appliance is operating normally.
GB
9
GB
10
GB
11
GB
19512752701
03/2015
12
Loading...
