Hotpoint C 30 N1 User Manual

Operating Instructions

COOKER AND OVEN

FRGB

English, 1 Français, 11

C 30 N1 EX

AR

Contents

GB

Installation, 2-3

Positioning and levelling

Electrical connection

Technical data

Description of the appliance, 4

Overall view

Control panel

Start-up and use, 5-7

Starting the oven

Cooking modes

Practical cooking advice

Oven cooking advice table

Using the electric hob, 8

Practical advice on using the electric hotplates

Precautions and tips, 9

General safety

Disposal

Respecting and conserving the environment

Care and maintenance, 10

Switching the appliance off

Cleaning the appliance

Replacing the oven light bulb

Assistance

V

1

2

3

N

A

B

Installation

GB

! Before operating your new appliance please read

this instruction booklet carefully. It contains important

information concerning the safe installation and

operation of the appliance.

! Please keep these operating instructions for future

reference. Make sure that the instructions are kept with

the appliance if it is sold, given away or moved.

! The appliance must be installed by a qualified

professional according to the instructions provided.

! Any necessary adjustment or maintenance must be

performed after the appliance has been disconnected

from the electricity supply.

Positioning and levelling

! It is possible to install the appliance alongside

cupboards whose height does not exceed that of the

hob surface.

! Make sure that the wall in contact with the back of

the appliance is made from a non-flammable, heat-

resistant material (T 90°C).

To install the appliance correctly:

 Place it in the kitchen, dining room or the bed-sit

(not in the bathroom).

 If the top of the hob is higher than the cupboards,

the appliance must be installed at least 200 mm

away from them.

 If the cooker is

HOOD

Min. mm.

600

mm.

420

Min.

 Do not position blinds behind the cooker or less

than 200 mm away from its sides.

 Any hoods must be installed according to the

instructions listed in the relevant operating manual.

Levelling

installed underneath a wall

cabinet, there must be a

minimum distance of 420

mm between this cabinet

mm. with hood

and the top of the hob.

420

mm. without hood

650

700

Min. mm.

This distance should be

min.

min.

increased to 700 mm if

the wall cabinets are

flammable (see figure).

If it is necessary to level the

appliance, screw the adjustable

feet* into the places provided on

each corner of the base of the

cooker (see figure).

The legs* provided with the

appliance fit into the slots on the

underside of the base of the

cooker.

Electrical connection

Fitting the power supply cable

The cable should be suited to the type of electrical

connection used, according to the following

connection diagram:

H05RR-F 5x2.5 CEI-UNEL 35363

400 3N

400V 2N

H05RR-F 4x2.5 CEI-UNEL 35363

230V 1N

H07RN-F 3x4 CEI-UNEL 35364

1 2

R

S

12345

R

1

2

To install the power supply cable correctly:

1. Loosen the screw V in

the terminal board and

pull the cover to open it

(see figure).

2. Position the

connection support A

(see figure) according

to the connection

diagram shown above.

The terminal board is

designed for single-

phase 230 V

connection: terminals 1,

2 and 3 are connected

to each other; jumper 4-5 is located in the lower area

of the terminal board.

3. Position wires N and

6 according to the diagram

(see figure) and perform the connection by tightening

the terminal board screws as much as possible.

4. Position the remaining wires on terminals 1-2-3 and

tighten the screws.

5. Fix the power supply cable in place by fastening

the cable clamp screw.

3

T

S

3

R

4

N

4

5

N

5

N

2

6. Close the terminal board cover by tightening the

screws V.

Connecting the supply cable to the mains

Install a standardised plug corresponding to the

load indicated on the data plate located on the

appliance.

The appliance must be directly connected to the

mains using an omnipolar circuit-breaker with a

minimum contact opening of 3 mm installed between

the appliance and the mains. The circuit-breaker

must be suitable for the charge indicated and must

comply with current electrical regulations (the

earthing wire must not be interrupted by the circuit-

breaker). The supply cable must be positioned so

that it does not come into contact with temperatures

higher than 50°C at any point.

Before connecting the appliance to the power

supply, make sure that:

 The appliance is earthed and the plug is compliant

with the law.

 The socket can withstand the maximum power of

the appliance, which is indicated by the data

plate.

 The voltage is in the range between the values

indicated on the data plate.

 The socket is compatible with the plug of the

appliance. If the socket is incompatible with the

plug, ask an authorised technician to replace it.

Do not use extension cords or multiple sockets.

TECHNICAL DATA
Oven dimensions
(HxWxD)
Volume
Useful
measurements
relating to the oven
compartment
Power supply
voltage and
frequency
Electric hob

Front left
Back left
Back right
Front right
Maximum absorption
of the electric hob

ENERGY LABEL

34x39x44 cm
58 l
width 42 cm

depth 44 cm
height 18 cm

see data plate

1000 W
1500 W
1500 W
1500 W

5500 W
Directive 2002/40/EC on the
label of electric ovens. Standard
EN 50304

Declared energy consumption
for Natural convection Class –

Static

heating mode:
EC Directives: 73/23/EEC dated

19/02/73 (Low Voltage) and
subsequent amendments ­89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent amendments ­93/68/EEC dated 22/07/93 and
subsequent amendments ­2002/96/EC.

a

GB

! Once the appliance has been installed, the power

supply cable and the electrical socket must be

easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced

by authorised technicians only.

! The manufacturer declines any liability should

these safety measures not be observed.

Only available in certain models.

*

3

Description of the appliance

GB

Overall view

ELECTRIC HOTPLATE

Control panel

GRILL

DRIPPING pan

Adjustable foot

Containment surface
for spills

GUIDE RAILS

for the sliding racks

position 5
position 4
position 3
position 2
position 1

Adjustable foot

Control panel

SELECTOR

THERMOSTAT

knob

TIMER

knob*

knob

THERMOSTAT

indicator light

ACTIVE HOTPLATE

indicator light

ELECTRIC HOTPLATE

control knobs

4

Start-up and use

! The first time you use your appliance, heat the empty

oven with its door closed at its maximum temperature

for at least half an hour. Ensure that the room is well

ventilated before switching the oven off and opening

the oven door. The appliance may emit a slightly

unpleasant odour caused by protective substances

used during the manufacturing process burning

away.

Starting the oven

1. Select the desired cooking mode by turning the

SELECTOR knob.

2. Select the recommended temperature for the

cooking mode or the desired temperature by turning

the THERMOSTAT knob.

A list detailing cooking modes and suggested

cooking temperatures can be found in the relevant

table (see Oven cooking advice table).

During cooking it is always possible to:

 Change the cooking mode by turning the

SELECTOR knob.

 Change the temperature by turning the

THERMOSTAT knob.

 Set the total cooking time and the cooking end

time (see below).

 Stop cooking by turning the SELECTOR knob to

the 0 position.

THERMOSTAT indicator light

When this is illuminated, the oven is generating heat. It

switches off when the inside of the oven reaches the

selected temperature. At this point the light illuminates

and switches off alternately, indicating that the

thermostat is working and is maintaining the

temperature at a constant level.

Oven light

This is switched on by turning the SELECTOR knob to

any position other than 0. It remains lit as long as the

oven is operating. By selecting

light is switched on without any of the heating

elements being activated.

with the knob, the

8

GB

! Never put objects directly on the bottom of the

oven; this will avoid the enamel coating being

damaged. Only use position 1 in the oven when

cooking with the rotisserie spit.

! Always place cookware on the rack(s) provided.

5

GB

Cooking modes

! A temperature value can be set for all cooking

modes between 50°C and MAX, except for the

GRILL programme, for which only the MAX power

level is recommended.

STATIC OVEN mode

a

Both the top and bottom heating elements will come

on. When using this traditional cooking mode, it is

best to use one cooking rack only. if more than one

rack is used, the heat will be distributed unevenly.

OVEN BOTTOM mode

y

The lower heating element is activated. This position

is recommended for perfecting the cooking of

dishes (in baking trays) which are already cooked on

the surface but require further cooking in the centre,

or for desserts with a covering of fruit or jam, which

only require moderate colouring on the surface. It

should be noted that this function does not allow the

maximum temperature to be reached inside the oven

(250°C) and it is therefore not recommended that

foods are cooked using only this setting, unless you

are baking cakes (which should be baked at a

temperature of 180°C or lower).

Lower compartment*

There is a compartment

underneath the oven

that may be used to

store oven accessories or

deep dishes. To open

the door pull it

downwards (see figure).

! Do not place flammable materials in the lower oven

compartment.

Practical cooking advice

! In the GRILL cooking mode, place the dripping pan

in position 1 to collect cooking residues (fat and/or

grease).

GRILL

 Insert the rack in position 3 or 4. Place the food in

the centre of the rack.

GRILL mode

c

The top heating element is activated. The extremely

high and direct temperature of the grill makes it

possible to brown the surface of meats and roasts

while locking in the juices to keep them tender.

d DOUBLE GRILL mode

The top heating element is activated. The grill is also

highly recommended for dishes that require a high

surface temperature: beef steaks, veal, rib steak,

fillets, hamburgers etc...

! The GRILL and DOUBLE GRILL cooking modes must

be performed with the oven door shut.

Timer*

To activate the Timer proceed as follows:

1. Turn the TIMER knob in a clockwise direction 4

for almost one complete revolution to set the buzzer.

2. Turn the TIMER knob in an anticlockwise direction

5 to set the desired length of time.

 We recommend that the power level is set to

maximum. The top heating element is regulated

by a thermostat and may not always operate

constantly.

PIZZA

 Use a light aluminium pizza pan. Place it on the

rack provided.

For a crispy crust, do not use the dripping pan as

it prevents the crust from forming by extending

the total cooking time.

 If the pizza has a lot of toppings, we recommend

adding the mozzarella cheese on top of the pizza

halfway through the cooking process.

* Only available in certain models.

6

Oven cooking advice table

Cooking
modes

Static

Oven bottom

Grill

Double Grill

Lasagne
Cannelloni
Baked past a
Veal
Chicken
Duck
Rabbit
Pork
Lamb
Mackerel
Mackerel
Trout baked in f oil
Neapolitan-style pizza
Biscuits and small cake s
Sweet unleavened flans and desserts
Savoury p ies
Leavened cakes
Fruit cakes
Perfecting cooking
Sole and cuttlefish
Squid and prawn keba bs
Cod fillet
Grilled vegetables
Veal steak
Chops
Hamburgers
Mackerel
Toast

Foods Weight

(in kg)

2.5

2.5

2.0

1.7

1.5

1.8
2

2.1

1.8

1.1

1.5
1
1

0.5

1.1
1

0.5
1

1
1
1
1
1

1.5
1
1

4 pcs

Rack

position

2
3
3
2
3
3
3
3
3
2
2
2
2
3
3
3
3
3

4
4
4

3/4

4
4
3
4
4

Preheating time

(min)

5
5

5
10
10
10
10
10
10

5

5

5
15
10
10
10
10
10

5

5

5

5

5

5

5

5

5

Recommended

Temperature

(°C)

200
200
200
180
200
180
180
180
180
180
180
180
220
180
180
180
160
170

Max
Max
Max
Max
Max
Max
Max
Max
Max

GB

Cooking

time

(minutes)

45-50
30-35
30-35
60-70
80-90

90-100

70-80
70-80
70-80
30-40
30-35
25-30
15-20
10-15
25-30
30-35
25-30
25-30

8
4

10

8-10

15-20

20

7

15-20

5

7

Using the electric hob

GB

!The position of the corresponding electric hotplate is

shown on every knob.

Electric hotplates

The corresponding knob may be turned clockwise or

anti-clockwise and set to any of the six different

positions:

Setting Normal or Fast Plate

0 Off
1

Low

2 - 5 Medium

6

High

When the selector knob is in any position other than

the off position, the on light is illuminated.

Practical advice on using the electric

hotplates

To avoid heat loss and damage to the hotplates use

pans with a flat base, whose diameter is no less

than that of the hotplate itself.

Setting Normal or Fast Plate

0

Off

1 Cooking vegetables, fish

Cooking potatoes (using steam) soups,

2

chickpeas, beans.
Continuing the cooking of large quantities

3

of food, minestrone

4

For roasting (average)

5

For roasting (above average)
For browni ng and r eac hing a boil in a

6

short time.

! Before using the hotplates for the first time, you

should heat them at maximum temperature for

approximately 4 minutes, without placing any pans

on them. During this initial stage, their protective

coating hardens and reaches its maximum

resistance.

8

Precautions and tips

! This appliance has been designed and

manufactured in compliance with international safety

standards.

The following warnings are provided for safety

reasons and must be read carefully.

General safety

 These instructions are only valid for the

countries whose symbols appear in the manual

and on the serial number plate.

 The appliance was designed for domestic use

inside the home and is not intended for

commercial or industrial use.

 The appliance must not be installed outdoors,

even in covered areas. It is extremely dangerous

to leave the appliance exposed to rain and

storms.

 Do not touch the appliance with bare feet or with

wet or damp hands and feet.

 The appliance must be used by adults only for the

preparation of food, in accordance with the

instructions provided in this booklet.

 The instruction booklet accompanies a class 1

(insulated) or class 2 - subclass 1 (recessed

between 2 cupboards) appliance.

 Keep children away from the oven.

 Make sure that the power supply cables of other

electrical appliances do not come into contact

with the hot parts of the oven.

 The openings used for the ventilation and

dispersion of heat must never be covered.

 Do not place unstable or misshapen pans on the

electric hotplates; this will help to avoid spills.

Position them on the hob with the handles turned

towards the centre of the appliance.

 Always use oven gloves when placing cookware

in the oven or when removing it.

 Do not use flammable liquids (alcohol, petrol,

etc...) near the appliance while it is in use.

 Do not place flammable material in the lower

storage compartment or in the oven itself. If the

appliance is switched on accidentally, it could

catch fire.

 Always make sure the knobs are in the 0 position

when the appliance is not in use.

 When unplugging the appliance, always pull the

plug from the mains socket; do not pull on the

cable.

 Never perform any cleaning or maintenance work

without having disconnected the appliance from

the electricity mains.

 If the appliance breaks down, under no

circumstances should you attempt to repair the

appliance yourself. Repairs carried out by

inexperienced persons may cause injury or further

malfunctioning of the appliance. Contact

Assistance.

 Do not rest heavy objects on the open oven door.

Disposal

 When disposing of packaging material: observe

local legislation so that the packaging may be

reused.

 The European Directive 2002/96/EC relating to

Waste Electrical and Electronic Equipment

(WEEE) states that household appliances should

not be disposed of using the normal solid urban

waste cycle. Exhausted appliances should be

collected separately in order to optimise the cost

of re-using and recycling the materials inside the

machine, while preventing potential damage to

the atmosphere and to public health. The

crossed-out dustbin is marked on all products to

remind the owner of their obligations regarding

separated waste collection.

Exhausted appliances may be collected by the

public waste collection service, taken to suitable

collection areas in the area or, if permitted by

current national legislation, they may be returned

to the dealers as part of an exchange deal for a

new equivalent product.

All major manufacturers of household appliances

participate in the creation and organisation of

systems for the collection and disposal of old and

disused appliances.

Respecting and conserving the

environment

 You can help to reduce the peak load of the

electricity supply network companies by using the

oven in the hours between late afternoon and the

early hours of the morning.

 Always keep the oven door closed when using the

GRILL and DOUBLE GRILL modes. This will

achieve better results while saving energy

(approximately 10%).

 Check the door seals regularly and wipe them

clean to ensure they are free of debris so that

they adhere properly to the door, thus avoiding

heat dispersion.

GB

9

Care and maintenance

GB

Switching the appliance off

Disconnect your appliance from the electricity

supply before carrying out any work on it.

Cleaning the appliance

! Do not use abrasive or corrosive detergents such

as stain removers, anti-rust products, powder

detergents or sponges with abrasive surfaces: these

may scratch the surface beyond repair.

! Never use steam cleaners or pressure cleaners on

the appliance.

 The stainless steel or enamel-coated external

parts and the rubber seals may be cleaned using

a sponge that has been soaked in lukewarm water

and neutral soap. Use specialised products for

the removal of stubborn stains. After cleaning,

rinse and dry thoroughly. Do not use abrasive

powders or corrosive substances.

 The inside of the oven should ideally be cleaned

after each use, while it is still lukewarm. Use hot

water and detergent, then rinse well and dry with

a soft cloth. Do not use abrasive products.

 Clean the glass door using non-abrasive products

and sponges and dry it with a soft cloth.

Inspecting the oven seals

Check the door seals around the oven regularly. If

the seals are damaged, please contact your nearest

After-sales Service Centre. We recommend that the

oven is not used until the seals have been replaced.

Replacing the oven light bulb

1. After disconnecting the

oven from the electricity

mains, remove the glass lid

covering the lamp socket (see

figure).

2. Remove the light bulb and

replace it with a similar one:

voltage 230 V, wattage 25 W,

cap E 14.

3. Replace the lid and reconnect the oven to the

electricity supply.

Assistance

Please have the following information to hand:

 The appliance model (Mod.).

 The serial number (S/N).

This information can be found on the data plate

located on the appliance and/or on the packaging.

 The accessories can be washed like everyday

crockery, and are even dishwasher safe.

 Dirt and grease should be removed from the

control panel using a non-abrasive sponge or a

soft cloth.

 Stainless steel can be marked by hard water that

has been left on the surface for a long time, or by

aggressive detergents containing phosphorus.

After cleaning, rinse well and dry thoroughly. Any

remaining drops of water should also be dried.

10
