Hoshizaki F-1000MLF Parts List

Download
NO.
ISSUED:
REVISED:
71138
DEC. 9, 1998
OCT. 22, 2001
HOSHIZAKI
MODULAR FLAKER
MODEL
PARTS LIST
HA
F-1000MAF H-0 MARCH, 1998
J-0 DEC., 1998 K-0 DEC., 1999
F-1000MAF-C H-0 AUG., 1998
J-0 DEC., 1998 K-0 DEC., 1999
F-1000MWF H-0 MARCH, 1998
J-0 FEB., 1999 K-0 JAN., 2000 K-1 JUNE, 2000
F-1000MWF-C H-0 AUG., 1998
J-0 APRIL, 1999 K-0 JAN., 2000 K-1 JUNE, 2000
F-1000MRF H-0 MARCH, 1998
J-0 MARCH, 1999 K-0 DEC., 1999 K-1 JUNE, 2000
F-1000MRF-C H-0 NOV., 1998
J-0 MARCH, 1999 K-0 DEC., 1999
F-1000MLF H-0 MARCH, 1998
J-0 FEB., 1999 K-0 JAN., 2000 K-1 JUNE, 2000
F-1000MLF-C J-0
2
HA
MATERIAL ABBREVIA TIONS
ALUMINUM AL = Aluminum
COPPER CU = Copper
PLASTIC
ABS = Acrylonitrile -butadiene - styrene AC = Polyacetal EVA = Ethylene vinyl acetate PA = Polyamide = Nylon PC = Polycarbonate PE = Polyethylene PES = Polyester PETP = Polyethylene terephthalate = Tetlon PP = Polypropylene PS = Polystyrene PIFE = Polytetrafluoroethylene = Teflon PUR = Polyurethane PVC = Polyvinyl chloride
RUBBER
VN = Vinyl Nitrile EPDM = EP rubber NBR = Nitrile butadiene rubber NR = Natural rubber NP = Neoprene SI.R = Silicone rubber SY.R = Synthetic rubber EPH = Epichlorohydrin
STEEL
GS = Galvanized steel SS = Stainless steel PS = Plated steel PAS = Primed steel
AUXILIARY CODE
Ex.1 K-0
Parts are the same as in the preceding (Note) - = Part deleted. year.
x = Part deleted and replaced "K" is the tenth in alphabetical order with "I" by "o" part. skipped. So, "K" indicates "1990".
o = New part for "x"
Ex.2 A-1 in the same auxiliary code.
"A" is the first in alphabetical order. So, "A" indicates "1991".
Ex.3 A- 2
Each time a part is changed in a year, this number advances.
3
HA
FASTENER ABBREVIA TION LIST
ST Phillips Truss Machine Screw SP Phillips Pan Head Machine Screw SF Phillips Flat Head Machine Screw SS Phillips Pan Head Machine Screw with Split Lock Washer SW Phillips Pan Head Machine Screw with Split Lock Washer
and Flat Washer T1 Phillips Truss Head Tapping Screw (Correspond to Type A) T2 Phillips Truss Head Tapping Screw (Correspond to Type B) T3 Phillips Truss Head Tapping Screw (Correspond to Type C) FT Phillips Truss Head Tapping Screw (Special) BH Hexagon Head Bolt BC Socket Head Cap Screw BS Hexagon Bolt with Split Washer BW Hexagon Bolt with Split Washer and Flat Washer BF Hexagon Flange Bolt BR Cross-Recessed Hexagon Head Bolt BRW Cross-Recessed Hexagon Head Bolt with Split Lock Washer
and Flat Washer WL Split Lock Washer WT External Tooth Washer WF Flat Washer WS Spring Washer NH Hexagon Nut NF Hexagon Flange Nut NC Hexagon Cap Nut NS Square Nut NW Wing Nut
Ex. ST0308S (Phillips Truss Head Machine Screw
3x8, made of stainless steel)
Material None: Plated Steel Length (mm) S: Stainless Steel Nominal Diameter (mm) B: Brass Form of Head P: Plastic Description
(Note) Second character is numerical except toe list.
Ex. S1, S2, B3 etc.
And abbreviations and names are shown under the illustration.
4
HA F-1000MAF/-C A. ICE FLAKER ASSEMBLY H-0, J-0, K-0
27
ST0408S
26
BL0890S
WL08S
T20512 ST0408
16
15
13
12
B
NW06S
14
21
33
18
F
17
8
23
2D
24
4
3
T20408
21
T20408
G
30
29
9
28
6
5
ST0408
22
ST0408
BH0812S
E
10
ST0408
20
34
1
11
C
7
25
19
23
ST0408
5
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A01 1 1 1
C REFRIGERATION UNIT - 2A0969A01 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1
E CONTROL BOX ASSEMBLY - 2A1045A01 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1
G LABEL LOCATION - 2A1039A01 1 1 1
DESCRIPTION MATERIAL OR
F-1000MAF
:
TITLE
MODEL NUMBER
A. ICE FL AKER ASSEMB LY
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
6
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A02 1 1 1
C REFRIGERATION UNIT - 2A0969A01 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1
E CONTROL BOX ASSEMBLY - 2A1045A01 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1
G LABEL LOCATION - 2A1039A05 1 1 1
DESCRIPTION MATERIAL OR
F-1000MAF-C
:
TITLE
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
7
HA
MODEL
INDEX
NO.
1 CHASSIS G.S 2A1176G01 1 1 1
2 REAR PANEL G.S 2A1008G01 1 1 1
3 JUNCTION BOX COVER G.S 433410-01 1 1 1
4 SIDE FRAME (R) G.S 2A1047G01 1 1 1
5 FRONT FRAME G.S 3A0324G01 1 1 1
6 BRACKET-RESERVOIR G.S 2A1060-01 1 1 1
7 DRAIN PAN ABS 323765G02 1 1 1
8 STRAP G.S 4A1474-01 1 1 1
9 TAPPING SCREW - BLACK STEEL,4X8 433954-01 2 2 2
10 CLAMP WS75-75-C 4A0337-12 3 3 3
11 BUSHING SB-562-7 420470-09 1 1 1
12 RING PA 432661-02 1 1 1
13 “O” RING G70 7616-G070 1 1 1
14 PACKING-SPOUT EPDM 321037-01 1 1 1
15 SPOUT PC 104797-01 1 1 1
16 THUMBSCREW S.S,ABS 415949G04 3 3 3
17 STRAP S.S 321038G02 1 1 1
18 STRAP S.S 328703-02 1 1 1
19 BUSHING SB-1500-21 420470-06 3 3 3
20 BARRIER G.S 4A0688-01 1 1 1
21 BUSHING SR-30-1 420472-03 2 2 2
22 WIRE SADDLE LWS-2NS 4A0338-02 5 5 5
23 WIRE SADDLE LWS-4NS 4A0338-04 4 4 4
24 SCREW-GROUNDING BRASS 433304-02 1 1 1
25 SIDE PANEL (RIGHT) S.S 2A0324G01 1 1 1
26 SIDE PANEL (LEFT) S.S 2A1014G02 1 1 1
27 TOP PANEL S.S 2A1051-02 1 1 1
28 FRONT PANEL S.S 3A0325-01 1 1 1
29 LOUVER (B) P.P 103121-03 2 2 2
F-1000MA F /-C
:
DESCRIPTION MATERIAL OR
TITLE
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0
30 AIR FILTER (B) - 208283G03 2 2 2
31 CABLE TIE CV-150 7920-0003 1 1 1
8
HA
MODEL
INDEX
NO.
32 SQUARE WASHER BRASS 433537-02 1 1 1
33 BRACKET-CHUTE S.S 4A1712-01 1 1 1
34 BRACKET - GEAR MOTOR G.S 3A0396G01 1 1 1
F-1000MAF/-C
:
DESCRIPTION MATERIAL OR
TITLE
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
9
HA
F-1000MWF/-C A. ICE FLAKER ASSEMBLY H-0, J-0, K-0, K-1
27
ST0408S
22
26
BL0890S
WL08S
T20512
ST0408
15
14
12
11
B
NW06S
13
21
31
17
F
16
8
D
2
23
24
4
3
T20408
21
G
10
18
28
6
5
ST0408
22
ST0408
BH0812S
E
9
ST0408
20
30
1
T20408
C
7
25
19
29
ST0408
10
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A01 1 1 1 1
C REFRIGERATION UNIT - 2A1021A01 1 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1 1
E CONTROL BOX ASSEMBLY - 2A1045A02 1 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1 -
G LABEL LOCATION - 2A1039A02 1 1 1 1
DESCRIPTION MATERIAL OR
F-1000MWF
:
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
TITLE
:
PART
NUMBER
2A1705A02 1
REQUIRED NUMBER
H-0 J-0 K-0 K-1
11
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A02 1 1 1 1
C REFRIGERATION UNIT - 2A1021A01 1 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1 1
E CONTROL BOX ASSEMBLY - 2A1045A02 1 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1 -
G LABEL LOCATION - 2A1039A06 1 1 1 1
F-1000MWF-C
:
DESCRIPTION MATERIAL OR
TITLE
MODEL NUMBER
A. ICE FLAKER ASSEM B LY
:
PART
NUMBER
2A1705A02 1
REQUIRED NUMBER
H-0 J-0 K-0 K-1
12
HA
MODEL
INDEX
NO.
1 CHASSIS G.S 2A1176G01 1 1 1 1
2 REAR PANEL G.S 2A1008G01 1 1 1 1
3 JUNCTION BOX COVER G.S 433410-01 1 1 1 1
4 SIDE FRAME (R) G.S 2A1047G01 1 1 1 1
5 FRONT FRAME G.S 3A0324G01 1 1 1 1
6 BRACKET-RESERVOIR G.S 2A1059-01 1 1 1 1
7 DRAIN PAN ABS 323765G02 1 1 1 1
8 STRAP G.S 4A1474-01 1 1 1 1
9 CLAMP WS75-75-C 4A0337-12 3 3 3 3
10 LOUVER (B) P.P 103121-03 2 2 2 2
11 RING PA 432661-02 1 1 1 1
12 “O” RING G70 7616-G070 1 1 1 1
13 PACKING-SPOUT EPDM 321037-01 1 1 1 1
F-1000MWF/-C
:
DESCRIPTION MATERIAL OR
TITLE
MODEL NUMBER
A. ICE FLAKER ASSEMBL Y
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0 K-1
14 SPOUT PC 104797-01 1 1 1 1
15 THUMBSCREW S.S,ABS 415949G04 3 3 3 3
16 STRAP S.S 321038G02 1 1 1 1
17 STRAP S.S 328703-02 1 1 1 1
18 TAPPING SCREW - BLACK STEEL, 4 x 8 433954-01 1 1 1 1
19 BUSHING SB-1500-21 420470-06 3 3 3 3
20 BARRIER G.S 4A0688-01 1 1 1 1
21 BUSHING SR-30-1 420472-03 2 2 2 2
22 WIRE SADDLE VWS42105-C 4A0338-02 5 5 5 5
23 SQUARE WASHER BRASS 433537-02 1 1 1 1
24 SCREW-GROUNDING BRASS 433304-02 1 1 1 1
25 SIDE PANEL (RIGHT) S.S 2A0324G01 1 1 1 1
26 SIDE PANEL (LEFT) S.S 2A1014G01 1 1 1 1
27 TOP PANEL S.S 2A1051-02 1 1 1 1
28 FRONT PANEL S.S 3A0325-01 1 1 1 1
29 WIRE SADDLE VWS42105-C 4A0338-04 4 4 4 4
30 BRACKET - GEAR MOTOR G.S 3A0396G01 1 1 1 1
31 BRACKET-CHUTE S.S 4A1712-01 1 1 1 1
13
HA
F-1000MRF/-C A. ICE FLAKER ASSEMBLY H-0, J-0, K-0, K-1
27
ST0408S
22
26
BL0890S
WL08S
T20512 ST0408
15
14
12
11
B
NW06S
13
21
31
17
F
16
8
D
2
23
24
4
3
T20408
21
G
10
18
28
6
5
ST0408
22
ST0408
BH0812S
E
ST0408
T20408
C
7
9
30
25
20
1
19
29
ST0408
14
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A01 1 1 1 1
C REFRIGERATION UNIT - 2A1022A01 1 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1 1
E CONTROL BOX ASSEMBLY - 2A1045A02 1 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1 -
G LABEL LOCATION - 2A1039A03 1 1 1 1
DESCRIPTION MATERIAL OR
F-1000MRF
:
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
TITLE
:
PART
NUMBER
2A1705A02 1
REQUIRED NUMBER
H-0 J-0 K-0 K-1
15
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A02 1 1 1
C REFRIGERATION UNIT - 2A1022A01 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1
E CONTROL BOX ASSEMBLY - 2A1045A02 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1
G LABEL LOCATION - 2A1039A07 1 1 1
DESCRIPTION MATERIAL OR
F-1000MRF-C
:
TITLE
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
16
HA
F-1000MRF/-C
:
TITLE
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 CHASSIS G.S 2A1176G02 1 1 1 1
2 REAR PANEL G.S 2A1010G01 1 1 1 1
3 JUNCTION BOX COVER G.S 433410-01 2 2 2 2
4 SIDE FRAME (R) G.S 2A1047G01 1 1 1 1
5 FRONT FRAME G.S 3A0324G01 1 1 1 1
6 BRACKET-RESERVOIR G.S 2A1059-01 1 1 1 1
7 DRAIN PAN ABS 323765G02 1 1 1 1
8 STRAP G.S 4A1474-01 1 1 1 1
9 CLAMP WS75-75-C 4A0337-12 5 5 5 5
10 LOUVER (B) P.P 103121-03 1 1 1 1
11 RING PA 432661-02 1 1 1 1
12 """O""RING" G70 7616-G070 1 1 1 1
13 PACKING-SPOUT EPDM 321037-01 1 1 1 1
A. ICE FLAKER ASSEMBLY
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0 K-1
14 SPOUT PC 104797-01 1 1 1 1
15 THUMBSCREW S.S,ABS 415949G04 3 3 3 3
16 STRAP S.S 321038G02 1 1 1 1
17 STRAP S.S 328703-02 1 1 1 1
18 TAPPING SCREW - BLACK STEEL, 4 x 8 433954-01 1 1 1 1
19 BUSHING SB-1500-21 420470-06 3 3 3 3
20 BARRIER G.S 4A0688-01 1 1 1 1
21 BUSHING SR-30-1 420472-03 3 3 3 3
22 WIRE SADDLE VWS42105-C 4A0338-02 5 5 5 5
23 SQUARE WASHER BRASS 433537-02 2 2 2 2
24 SCREW-GROUNDING BRASS 433304-02 2 2 2 2
25 SIDE PANEL (RIGHT) S.S 2A0324G01 1 1 1 1
26 SIDE PANEL (LEFT) S.S 2A1014G01 1 1 1 1
27 TOP PANEL S.S 2A1051-02 1 1 1 1
28 FRONT PANEL S.S 3A0325-01 1 1 1 1
29 WIRE SADDLE VWS42105-C 4A0338-04 4 4 4 4
30 BRACKET - GEAR MOTOR G.S 3A0396G01 1 1 1 1
31 BRACKET-CHUTE S.S 4A1712-01 1 1 1 1
17
HA
F-1000MLF/-C A. ICE FLAKER ASSEMBLY H-0, J-0, K-0, K-1
27
ST0408S
22
26
BL0890S
WL08S
T20512 ST0408
15
14
12
11
B
NW06S
13
21
31
17
F
16
8
D
2
32
24
4
3
T20408
21
G
10
18
28
6
5
ST0408
22
ST0408
BH0812S
E
ST0408
T20408
C
7
9
30
25
20
1
19
29
ST0408
18
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A01 1 1 1 1
C REFRIGERATION UNIT - 2A1023A01 1 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1 1
E CONTROL BOX ASSEMBLY - 2A1066A01 1 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1 -
G LABEL LOCATION - 2A1039A04 1 1 1 1
DESCRIPTION MATERIAL OR
F-1000MLF
:
MODEL NUMBER
A. ICE FLAKER ASSEMBLY
TITLE
:
PART
NUMBER
2A1705A02 1
REQUIRED NUMBER
H-0 J-0 K-0 K-1
19
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A02 1 1 1
C REFRIGERATION UNIT - 2A1023A01 1 1 1
D WATER CIRCUIT HS-0112 2A0968A01 1 1 1
E CONTROL BOX ASSEMBLY - 2A1066A01 1 1 1
F CHUTE ASSEMBLY HS-0093 2A0941A02 1 1 1
G LABEL LOCATION - 2A1039A08 1 1 1
DESCRIPTION MATERIAL OR
F-1000MLF-C
:
MODEL NUMBER
A. ICE FLAKER ASSEM B LY
TITLE
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
20
HA
F-1000MLF/-C
:
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 CHASSIS G.S 2A1176G03 1 1 1 1
2 REAR PANEL G.S 2A1119G01 1 1 1 1
3 JUNCTION BOX COVER G.S 433410-01 1 1 1 1
4 SIDE FRAME (R) G.S 2A1047G01 1 1 1 1
5 FRONT FRAME G.S 3A0324G01 1 1 1 1
6 BRACKET-RESERVOIR G.S 2A1059-01 1 1 1 1
7 DRAIN PAN G.S 323765G02 1 1 1 1
8 STRAP G.S 4A1474-01 1 1 1 1
9 CLAMP WS75-75-C 4A0337-12 4 4 4 4
10 LOUVER (B) P.P 103121-01 1 1 1 1
11 RING PA 432661-02 1 1 1 1
12 """O""RING" G70 7616-G070 1 1 1 1
13 PACKING-SPOUT EPDM 321037-01 1 1 1 1
A. ICE FLAKER ASSEMBLY
TITLE
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0 K-1
14 SPOUT PC 104797-01 1 1 1 1
15 THUMBSCREW S.S,ABS 415949G04 3 3 3 3
16 STRAP S.S 321038G02 1 1 1 1
17 STRAP S.S 328703-02 1 1 1 1
18 TAPPING SCREW - BLACK STEEL, 4 x 8 433954-01 1 1 1 1
19 BUSHING SB-1500-21 420470-06 3 3 3 3
20 BARRIER G.S 4A0688-01 1 1 1 1
21 BUSHING SR-30-1 420472-03 2 2 2 2
22 WIRE SADDLE VWS42105-C 4A0338-02 5 5 5 5
23 SQUARE WASHER BRASS 433537-02 1 1 1 1
24 SCREW-GROUNDING BRASS 433304-02 1 1 1 1
25 SIDE PANEL (RIGHT) S.S 2A0324G01 1 1 1 1
26 SIDE PANEL (LEFT) S.S 2A1014G01 1 1 1 1
27 TOP PANEL S.S 2A1051-02 1 1 1 1
28 FRONT PANEL S.S 3A0325-01 1 1 1 1
29 WIRE SADDLE VWS42105-C 4A0338-04 4 4 4 4
30 BRACKET - GEAR MOTOR G.S 3A0396G01 1 1 1 1
31 BRACKET-CHUTE S.S 4A1712-01 1 1 1 1
21
HA
F-1000MAF, MWF, MRF, MLF B. ICE MAKING UNIT H-0, J-0, K-0, K-1
BH1030S
WL10S
13
7
12
9
BH0620S
WS06S
11
10
6
8
5
4
WL08S
FT0408
BC0812S
3
2
1
22
HA
MODEL
INDEX
NO.
1 GEAR MOTOR V06695-ACAA 4A1296-01 1 1 x1
2 BARRIER - GEAR MOTOR G.S 3A1037-01 1 1 1 1
3 COUPLING - SPLINE S.S 4A1297-01 1 1 1 1
4 HOUSING BRASS 2A0947G01 1 1 1 1
5 “O” RING G65 7616-G065 1 1 1 1
6 MECHANICAL SEAL HK9A-MN 432492-01 1 1 1 1
7 AUGER S.S 2A0932G02 1 1 1 1
8 EVAPORATOR - 2A1227G01 1 1 1 1
9 EXTRUDING HEAD / 70F S.S 327097G01 1 1 1 1
10 SOCKET HEAD CAP SCREW S.S, M10 x 15 429121-01 4 4 4 4
11 WASHER S.S 427184-01 4 4 4 4
12 CUTTER S.S 317071-02 1 x1
F-1000MAF, MWF, MRF, MLF
:
DESCRIPTION MATERIAL OR
MODEL NUMBER
- 4A2194-01 o1 1
TITLE
B. ICE MAKING UNIT
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0 K-1
SS 3A1395-02 o1 1 1
13 DOWEL PIN S.S, 4 x 16 713S-0416 1 1 1 1
23
HA
F-1000MAF-C, MWF-C, MRF-C, MLF-C B. ICE MAKING UNIT H-0, J-0, K-0, K-1
BH1030S
WL10S
13
7
12
9
BH0620S
WS06S
11
10
6
8
5
4
WL08S
FT0408
BC0812S
3
2
1
24
HA
MODEL
INDEX
NO.
1 GEAR MOTOR - 4A1296-01 1 1 x1
2 BARRIER - GEAR MOTOR G.S 3A1037-01 1 1 1 1
3 COUPLING - SPLINE S.S 4A1297-01 1 1 1 1
4 HOUSING BRASS 2A0947G01 1 1 1 1
5 “O” RING G65 7616-G065 1 1 1 1
6 MECHANICAL SEAL HK9A-MN 432492-01 1 1 1 1
7 AUGER S.S 2A0932G02 1 1 1 1
8 EVAPORATOR - 2A1227G01 1 1 1 1
9 EXTRUDING HEAD / 70N S.S 216531G01 1 1 1 1
10 SOCKET HEAD CAP SCREW S.S, M10 x 15 429121-01 4 4 4 4
11 WASHER S.S 427184-01 4 4 4 4
12 CUTTER S.S 327145-01 1 1 1 1
F-1000MAF-C, MWF-C, MRF-C, MLF-C
:
DESCRIPTION MATERIAL OR
MODEL NUMBER
- 4A2194-01 o1 1
TITLE
B. ICE MAKING UNIT
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0 K-1
13 DOWEL PIN S.S, 5 x 22 713S-0416 1 1 1 1
25
HA
F-1000MAF/-C C. REFRIGERATION UNIT H-0, J-0, K-0
T20408
4
3
22
16
12
24
9
25
17
T20408
23
15
18
14
2
1
20
21
26
13
11
28
19
10
FT0408
27
8
7
FT0408
5
6
BW0512S
26
HA
MODEL
INDEX
NO.
1 COMPRESSOR RS70-CIE-PFV 4A1322-01 1 1 1
2 BOLT 8 x 45 437889-01 4 4 4
3 CONDENSER-AIR COOLED 967307C 211663-02 1 1 1
4 SHROUD G.S 2A0449-01 1 1 1
5 FAN MOTOR BRACKET G.S 3A0341-01 1 1 1
6 FAN MOTOR U90B17190-1031 440911-01 1 1 1
7 FAN BLADE AD12CW25 4A0197-01 1 1 1
8 DRIER ATCH-032S 4A1113-01 1 1 1
9 COPPER TUBE (A) - HIGH SIDE COPPER 3A0928G01 1 1 1
10 COPPER TUBE (B) -HIGH SIDE COPPER 3A0921-01 1 1 1
11 COPPER TUBE-PROCESS COPPER 4A1365-01 1 1 1
12 CLAMP 08 443461-01 1 1 1
13 COPPER TUBE - HEAT EXCHANGER COPPER 3A0894G01 1 1 1
DESCRIPTION MATERIAL OR
F-1000MAF/-C
:
TITLE
MODEL NUMBER
C. REFRIGERATION UNIT
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0
14 EXPANSION VALVE AN-1-SC 4A1117-01 1 1 1
15 EXP. VALVE COVER PE FOAM 4A1168-01 1 1 1
16 COPPER TUBE-ACCESS VALVE COPPER 4A1364G01 2 2 2
17 PRESSURE SWITCH ACB-2UB04 433441-05 1 1 1
18 PRESSURE SWITCH BRACKET G.S 434938-01 1 1 1
19 CABLE TIE CV-150 7920-0003 10 10 10
20 GROMMET 027-0073-00 434403-01 4 4 4
21 SPACER 027-0072-02 434404-01 4 4 4
22 INSULATION TUBE L=130 7762-2943 1 1 1
23 INSULATION TUBE L=170 7762-1330 1 1 1
24 INSULATION TUBE L=30 7762-0717 1 1 1
25 HOLDER/EXP.VALVE-1/2 S.S 3A0112-01 1 1 1
26 SELF- LOCKING NUT NO-8-32 7N21I0832 4 4 4
27 DRIER BRACKET G.S 445847-01 1 1 1
28 TEE 111-2 436000-01 1 1 1
27
HA
F-1000MWF/-C C. REFRIGERATION UNIT H-0, J-0, K-0, K-1
T20408
17
25
15
BW0512S
28
11
23
2
19
30
3
ST0406
ST0408
18
13
9
24
8
14
29
27
10
20
FT0408
6
16
1
21
22
26
5
7
12
28
HA
F-1000MWF/-C
:
TITLE
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 COMPRESSOR R570CIE-PFV 4A1322-01 1 1 1 1
2 CONDENSER-WATER COOLED (S-0725) 215545G01 1 1 1 1
3 WATER REGULATOR V46EA-7 4A0911-04 1 1 1 1
4- - -
5 DRIER ATCH-032S 4A1113-01 1 1 1 1
6 COPPER TUBE (A) - HIGH SIDE COPPER 3A0920G01 1 1 1 1
7 COPPER TUBE (B) - HIGH SIDE COPPER 3A0921-01 1 1 1 1
8 COPPER TUBE - ACCESS VALVE COPPER 4A1364G01 1 1 1 1
9 CLAMP 08 443461-01 1 1 1 1
10 COPPER TUBE - HEAT EXCHANGER COPPER 3A0894G01 1 1 1 1
11 EXPANSION VALVE AN-1-SC 4A1117-01 1 1 1 1
12 DRIER BRACKET G.S 445847-01 1 1 1 1
13 COPPER TUBE-DRIER COPPER 3A0891-01 1 1 1 1
14 COPPER TUBE-PROCESS COPPER 4A1365-01 1 1 1 1
C. REFRIGERATION UNIT
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0 K-1
15 EXP. VALVE COVER PE FOAM 4A1168-01 1 1 1 1
16 PRESSURE SWITCH ACB-2UB04 433441-05 1 1 1 1
17 PRESS. SWITCH BRACKET G.S 434938-01 1 1 1 1
18 COPPER TUBE-WATER INLET COPPER 3A1095G01 1 1 1 1
19 COPPER TUBE-WATER OUTLET COPPER 3A0930G01 1 1 1 1
20 CABLE TIE CV-150 7920-0003 14 14 14 14
21 GROMMET 027-0073-00 434403-01 4 4 4 4
22 SPACER 027-0072-02 434404-01 4 4 4 4
23 BOLT 8 x 45 437889-01 1 1 1 1
24 INSULATION TUBE L=130 7762-2943 1 1 1 1
25 INSULATION TUBE L=170 7762-1330 1 1 1 1
26 INSULATION TUBE L=30 7762-0717 1 1 1 1
27 HOLDER/EXP. VALVE-1/2 S.S 3A0112-01 1 1 1 1
28 WASHER - 4A0655-03 3 3 3 3
29 TEE 111-2 436000-01 1 1 1 1
30 MALE CONNECTOR 48F-8-6 4A1087-01 1 1 1 1
29
HA
F-1000MRF/-C C. REFRIGERATION UNIT H-0, J-0, K-0, K-1
19
18
10
23
16
T20408
17
25
11
14
15
8
27
FT0408
1
28
29
2
13
24
12
T20408
22
20
6
3
21
7
9
4
5
FT0408
26
30
HA
F-1000MRF/-C
:
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 COMPRESSOR RS70CIE-PFV 4A1322-01 1 1 1 1
2 CLAMP 08 443461-01 1 1 1 1
3 CRANKCASE HEATER 018-0038-
0045W,120V
4 RECEIVER TANK 6813 437652-01 1 1 1 1
5 DRIER ATCH-053S 4A1338-01 1 1 1 1
6 COPPER TUBE(A)- HIGH SIDE COPPER 3A0923G01 1 1 1 1
7 COPPER TUBE (B) - HIGH SIDE COPPER 3A0924G01 1 1 1 1
8 COPPER TUBE(C)- HIGH SIDE COPPER 3A1222G01 1 1 1 1
9 COPPER TUBE(D)- HIGH SIDE COPPER 4A1368-01 1 1 1 1
10 COUPLING COPPER 433751G01 1 1 1 1
11 CABLE TIE CV-150 7920-0003 9 9 9 9
12 TUBE HOLDER - S G.S. 438246-01 1 1 1 1
13 COPPER TUBE - HEAT EXCHANGER COPPER 3A0927G01 1 1 1 1
C. REFRIGERATION UNIT
TITLE
:
PART
NUMBER
434186-01 1 1 1 1
REQUIRED NUMBER
H-0 J-0 K-0 K-1
14 EXPANSION VALVE AN-1-SC 4A1117-01 1 1 1 1
15 EXP. VALVE COVER PE FOAM 4A1168-01 1 1 1 1
16 PRESSURE SWITCH ACB-2UB04 433441-05 1 1 1 1
17 PRESSURE SWITCH BRACKET G.S. 434938-01 1 1 1 1
18 COUPLING (MALE) BRASS 434132G01 1 1 1 1
19 TUBE HOLDER-L G.S. 438245-01 1 1 1 1
20 GROMMET 027-0073-00 434403-01 4 4 4 4
21 SPACER 027-0072-02 434404-01 4 4 4 4
22 BOLT 8 x 45 437889-01 4 4 4 4
23 COPPER TUBE - ACCESS VALVE COPPER 4A1364G01 1 1 1 1
24 INSULATION TUBE L=130 7762-2943 1 1 1 1
25 INSULATION TUBE L=170 7762-1330 1 1 1 1
26 DRIER BRACKET G.S 4A1348-01 1 1 1 1
27 HOLDER/EXP.VALVE-1/2 S.S 3A0112-01 1 1 1 1
28 TERMINAL COVER - 4A1322F01 1 1 1 1
29 SPRING CLIP - 4A1322F02 1 1 1 1
31
HA
F-1000MLF/-C C. REFRIGERATION UNIT H-0, J-0, K-0, K-1
2
35
18
1
T20408
20
11
14
34
12
13
16
21
15
23
22
33
6
8
19
ST0408
3
37
4
24
10
32
30
27
ST0408
5
29
T20408
26
38
9
33
31
34
36
28
17
32
25
7
HA
MODEL
INDEX
NO.
1 EPR VALVE 4A1384-01 1 1 1 1
2 EPR VALVE COVER PE - FOAM 340434-01 1 1 1 1
3 COPPER TUBE - (OUT) COPPER 3A0951G01 1 1 1 1
4 COPPER TUBE - (IN) COPPER 3A0953G01 1 1 1 1
5 COPPER TUBE-HEAT EXCHANGER COPPER 3A0956-01 1 1 1 1
6 SOLENOID VALVE SLHE 1/2 446873-01 1 1 1 1
7 HEAT EXCHANGER 4A1374-01 1 1 1 1
8 EXPANSION VALVE AN-1-SC 4A1117-01 1 1 1 1
9 EXPANSION VALVE COVER PE FOAM 4A1168-01 1 1 1 1
10 HOT GAS VALVE BRACKET G.S. 4A1400-01 1 1 1 1
11 VALVE BODY 70 440352-01 1 1 1 1
12 COIL - VALVE ABS-25-1-HD-2 440353-01 1 1 1 1
13 BOLT 440353F01 1 1 1 1
14 COUPLING-(MALE) COPPER 434132G01 1 1 1 1
15 COUPLING COPPER 433751G01 1 1 1 1
16 STRAINER 625007 4A1385-01 1 1 1 1
17 BRACKET (B) VALVE G.S. 446871-01 1 1 1 1
18 CABLE TIE CV-150 7920-0003 23 35 35 35
19 HOLDER / EXP. VALVE - 1/2 S.S. 3A0112-01 1 1 1 1
20 TUBE HOLDER - L G.S. 438245-01 1 1 1 1
21 TUBE HOLDER - S G.S. 438246-01 1 1 1 1
22 CLAMP 08 443461-01 1 1 1 1
23 INSULATION TUBE L=130 7762-2943 1 1 1 1
24 INSULATION TUBE L=850 7762-1330 1 1 1 1
25 INSULATION TUBE L=310 7762-2040 1 1 1 1
26 INSULATION TUBE L=600 7762-1330 1 1 1 1
27 COPPER TUBE - VALVE COPPER 3A0955-01 1 1 1 1
28 COPPER TUBE - EXP. VALVE COPPER 3A0957-01 1 1 1 1
29 COPPER TUBE - EPR COPPER 3A0954-01 1 1 1 1
30 INSULATION TUBE L=250 7762-2040 1 1 1
DESCRIPTION
F-1000MLF/-C
:
TITLE
C. REFRIGERATION UNIT
:
MATERIAL OR MODEL NUMBER
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0 K-1
33
HA
MODEL
INDEX
NO.
31 INSULATION TUBE L=200 7762-2040 1 1 1
32 INSULATION TUBE L=150 7762-1030 1 1 1
33 INSULATION TUBE L=100 7762-1030 1 1 1
34 INSULATION TUBE L=400 7762-1330 2 2 2
35 INSULATION TUBE L=170 7762-1330 1 1 1
36 INSULATION TUBE L=740 7762-0717 1 1 1
37 INSULATION TUBE L=170 7762-1330 1 1 1
38 INSULATION TUBE L=505 7762-1030 1 1 1
DESCRIPTION
F-1000MLF/-C
:
MATERIAL OR MODEL NUMBER
C. REFRIGERATION UNIT
TITLE
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0 K-1
34
HA F-1000MAF(-C), MWF(-C), MRF(-C), MLF(-C) D. WATER CIRCUIT H-0
T20408
6
7
2
3
1
T20408
8
T20408
16
5
4
13
T20408
19
T20408S
12
10
18
22
20
11
17
14
9
15
T20408
21
35
HA
F-1000MAF(-C), MWF(-C), MRF(-C), MLF(-C) D. WATER CIRCUIT J-0, K-0, K-1
36
HA
MODEL
INDEX
NO.
1 WATER SUPPLY PIPE COPPER 4A0891G01 1 1 1 1
2 WASHER K-59963 4A0867-01 1 1 1 1
3 WATER VALVE S-30 4A0865-01 1 1 1 1
4 RESERVOIR P.P. 2A0753-01 1 1 1 1
5 SEPARATOR-RESERVOIR ABS 4A1255-01 1 1 1 1
6 FLOAT SWITCH TW-1221-101 435490-01 1 1 1 1
7 RESERVOIR COVER P.P. 214810-01 1 1 1 1
8 INLET- RESERVOIR SI.R. 4A0869-01 1 1 1 1
9 WATER VALVE S-60N 4A0866-01 1 1 x1
- 4A2077-01 o1 1
10 VINYL HOSE L=50 7725-0912 1 1 x1
L=40 7716-0913 o1 1
11 CLAMP SK-18.3 435934-06 1 -
12 CLAMP MH-30N 421642-04 2 -
13 CABLE TIE CV-150 7920-0003 8 4 4 4
14 CLAMP SK-17 435934-05 1 1 1 1
15 FITTING COPPER 4A0776G01 1 1 1 1
16 WATER VALVE BRACKET G.S 3A0553-01 1 1 1 1
17 WATER VALVE BRACKET (D) G.S 3A0554-01 1 1 1 1
18 SILICONE HOSE L=410 7730-1822 1 1 1 1
19 SILICONE HOSE L=225 7730-0912 1 1 x1
L=225
20 VINYL HOSE L=430 7725-1923 1 1 1 1
21 VINYL HOSE L=390 7716-2025 1 1 1 1
22 RESERVOIR HOSE EPDM 4A1165-01 1 1 1 1
23 HOSE CLAMP - 4A2017-04 4 x4
- 4A2017-08 o4 4
24 HOSE CLAMP - 4A2017-05 1 1 1
25 HOSE CLAMP - 4A2017-06 1 1 1
26 HOSE CLAMP - 4A2017-01 1 1 1
27 HOSE CLAMP - 4A2017-02 1 1 1
F-1000MAF (- C), MWF( - C), MRF (- C), MLF( - C)
:
DESCRIPTION
MATERIAL OR MODEL NUMBER
TITLE
PART
NUMBER
7730I3896
D. WATER CIRCUIT
:
REQUIRED NUMBER
H-0 J-0 K-0 K-1
o1 1
37
HA
F-1000MAF/-C E. CONTROL BOX ASSEMBLY H-0, J-0, K-0
5
28
29
5
24
18
15
14
T20408
6
1
13
4
23
25
5
10
11
21
12
22
T20408
20
3
17
16
15
19
8
26
27
2
9
7
38
HA
MODEL
INDEX
NO.
1 CONTROL BOX G.S 2A0229G04 1 1 1
2 COVER-CONTROL BOX G.S 3A0411-01 1 1 1
3 RELAY LY-1F, AC120V 418271-03 1 1 1
4 RELAY LY-2F, AC24V 406132-03 1 1 1
5 TAPPING SCREW 3 x 8 431415-01 8 8 8
6 TRANSFORMER BE1416225GEK
7 STRAP G.S 434580-07 1 1 1
8 TIMER BOARD H2AA144C01 437305-01 1 1 1
9 BOARD SUPPORT CBLS37-N 4A0336-03 4 4 4
10 TOGGLE SWITCH 7599K1 4A0567-01 1 1 x1
- 4A2332-01 o1
11 FUSE HOLDER HTB921, 250V, 1A 4A0892-01 1 1 1
12 FUSE AGC-1, 250V, 1A 4A0893-01 1 1 1
13 9P PLUG HOUSING 3191-09P 412832-02 1 1 1
14 6P PLUG HOUSING 3191-06P 412832-03 1 1 1
15 4P PLUG HOUSING 3191-04P 412832-05 2 2 2
16 3P PLUG HOUSING 3191-03P 412832-06 1 1 1
17 STARTER 3ARR3CT24S5 4A0875-01 1 1 x1
- 4A1107-13 o1
18 TIMER 9816-2 4A0889-01 1 1 1
19 CAPACITOR (GM) 12MFD, 330VAC 4A0894-01 1 1 1
20 CAPACITOR (FM) 5MFD 443192-02 1 1 1
21 FUSE GMD1.5A 4A0893-04 1 1 1
22 FUSE HOLDER HTB92M 4A0892-02 1 1 1
23 RELAY LY-4F,AC24V 406133-04 1 1 1
24 RELAY LY1F-HSD,
25 ROCKER SWITCH 62111929-0-0-N 4A0558-01 1 1 1
26 CAPACITOR - STARTING
27 CAPACITOR X386S(HG02) 439943-02 1 1 1
F-1000MAF(-C)
:
DESCRIPTION
E. CONTROL BOX ASSEMBLY
TITLE
:
MATERIAL OR MODEL NUMBER
120/24V, 1A
AC220/240V
3535B5A0108A250B8
PART
NUMBER
4A0557-01 1 1 1
418271-05 1 1 1
3A0076-02 1 1 1
REQUIRED NUMBER
H-0 J-0 K-0
39
HA
MODEL
INDEX
NO.
28 CONNECTOR - 4A0899-02 1 1 1
29 SCREW 32 x 3/8 4A0898-01 2 2 2
F-1000MAF(-C)
:
DESCRIPTION
E. CONTROL BOX ASSEMBLY
TITLE
:
MATERIAL OR MODEL NUMBER
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
40
HA F-1000MWF(-C), MRF(-C) E. CONTROL BOX ASSEMBLY H-0, J-0, K-0, K-1
27
5
28
5
23
18
15
14
T20408
6
1
13
4
22
24
5
10
11
20
12
21
T20408
3
19
17
16
8
25
26
2
9
7
41
HA
MODEL
INDEX
NO.
1 CONTROL BOX G.S 2A0229G04 1 1 1 1
2 COVER-CONTROL BOX G.S 3A0411-01 1 1 1 1
3 RELAY LY-1F, AC120V 418271-03 1 1 1 1
4 RELAY LY-2F, AC24V 406132-03 1 1 1 1
5 TAPPING SCREW 3 x 8 431415-01 8 8 8 8
6 TRANSFORMER BE1416225GEK
7 STRAP G.S 434580-07 1 1 1 1
8 TIMER BOARD H2AA144C01 437305-01 1 1 1 1
9 BOARD SUPPORT CBLS37-N 4A0336-03 4 4 4 4
10 TOGGLE SWITCH 7599K1 4A0567-01 1 1 1 x1
11 FUSE HOLDER HTB921, 250V, 1A 4A0892-01 1 1 1 1
F-1000MWF(-C), MRF(-C)
:
DESCRIPTION MATERIAL OR
TITLE
MODEL NUMBER
120/24V, 1A
- 4A2332-01 o1
E. CONTROL BOX ASSEMBLY
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0 K-1
4A0557-01 1 1 1 1
12 FUSE AGC-1, 250V, 1A 4A0893-01 1 1 1 1
13 9P PLUG HOUSING 3191-09P 412832-02 1 1 1 1
14 6P PLUG HOUSING 3191-06P 412832-03 1 1 1 1
15 4P PLUG HOUSING 3191-04P 412832-05 2 2 2 2
16 3P PLUG HOUSING 3191-03P 412832-06 1 1 1 1
17 STARTER 3ARR3CT24S5 4A0875-01 1 1 1 x1
- 4A1107-13 o1
18 TIMER 9816-2 4A0889-01 1 1 1 1
19 CAPACITOR (GM) 12MFD, 330VAC 4A0894-01 1 1 1 1
20 FUSE GMD1.5A 4A0893-04 1 1 1 1
21 FUSE HOLDER HTB92M 4A0892-02 1 1 1 1
22 RELAY LY-4F,AC24V 406133-04 1 1 1 1
23 RELAY LY1F-HSD,
AC220/240V
24 ROCKER SWITCH 62111929-0-0-N 4A0558-01 1 1 1 1
25 CAPACITOR - STARTING
26 CAPACITOR X386S(HG02) 439943-02 1 1 1 1
3535B5A0108A250B8
418271-05 1 1 1 1
3A0076-02 1 1 1 1
42
HA
MODEL
INDEX
NO.
27 CONNECTOR - 4A0899-02 1 1 1 1
28 SCREW 32 x 3/8 4A0898-01 2 2 2 2
F-1000MWF(-C), MRF(-C)
:
DESCRIPTION MATERIAL OR
TITLE
MODEL NUMBER
E. CONTROL BOX ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0 K-1
43
HA
F-1000MLF(-C) E. CONTROL BOX ASSEMBLY H-0, J-0, K-0, K-1
6
5
20
T20408
21
18
14
T20408
1
12
4
5
19
9
10
16
11
17
3
15
13
7
2
8
44
HA
MODEL
INDEX
NO.
F-1000MLF(-C)
:
TITLE
DESCRIPTION MATERIAL OR
MODEL NUMBER
1 CONTROL BOX G.S 2A0229G04 1 1 1 1
2 COVER-CONTROL BOX G.S 3A0411-01 1 1 1 1
3 RELAY LY-2F, AC120V 406132-07 1 1 1 1
4 RELAY LY-2F, AC24V 406132-03 1 1 1 1
5 TAPPING SCREW 3 x 8 431415-01 6 6 6 6
6 TRANSFORMER BE1416225GEK
120/24V, 1A
7 TIMER BOARD H2AA144C01 437305-01 1 1 1 1
8 BOARD SUPPORT CBLS37-N 4A0336-03 4 4 4 4
9 TOGGLE SWITCH 7599K1 4A0567-01 1 1 1 x1
- 4A2332-01 o1
10 FUSE HOLDER 250V, 1A 4A0892-01 1 1 1 1
11 FUSE 250V, 1A 4A0893-01 1 1 1 1
E. CONTROL BOX ASSEMBLY
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0 K-1
4A0557-01 1 1 1 1
12 9P PLUG HOUSING 3191-09P 412832-02 1 1 1 1
13 3P PLUG HOUSING 3191-03P 412832-06 1 1 1 1
14 TIMER 9816-2 4A0889-01 1 1 1 1
15 CAPACITOR (GM) 12MFD, 330VAC 4A0894-01 1 1 1 1
16 FUSE GMD1.5A 4A0893-04 1 1 1 1
17 FUSE HOLDER HTB-92M 4A0892-02 1 1 1 1
18 RELAY LY1F-HSD,
AC220/240V
19 ROCKER SWITCH 62111929-0-0-N 4A0558-01 1 1 1 1
20 CONNECTOR - 4A0899-02 1 1 1 1
21 SCREW 32 x 3/8 4A0898-01 2 2 2 2
418271-05 1 1 1 1
45
HA
F-1000MAF(-C), MWF(-C), MRF(-C), MLF(-C) F. CHUTE ASSEMBLY H-0, J-0, K-0, K-1
12
11
10
14
13
15
6
1
2
5
NW04S
8
9
7
4
3
46
HA
MODEL
INDEX
NO.
F-1000MAF(-C), MWF(-C), MRF(-C), MLF(-C)
:
DESCRIPTION MATERIAL OR
MODEL NUMBER
1 CHUTE PE 2A1057-01 1 1 1 1
2 INSULATION-CHUTE PE FOAM 213304-02 1 1 1 1
3 TIE PA 436531G01 3 3 3 3
4 BAFFLE-CHUTE (A) S.S 3A0400G01 1 1 1 1
5 BAFFLE-CHUTE (B) S.S 3A0399G01 1 1 1 1
6 BIN CONTROL S.S 338043G02 1 1 1 -
S.S 3A1535G01 x1
S.S 3A1744G01 o1
7 ACTUATOR S.S 436848G01 1 1 1 1
8 SHAFT S.S 436851-01 1 1 1 1
9 SNAP PIN S.S,SSP-5 715S-0005 2 2 2 2
10 PROXIMITY SWITCH RS-601 427223-01 1 1 1 -
E00901 4A2033-01 1
TITLE
PART
NUMBER
F. CHUTE ASSEMBLY
:
REQUIRED NUMBER
H-0 J-0 K-0 K-1
11 COVER-SWITCH S.S 451870-01 1 1 1 1
12 THUMBSCREW ABS,S.S 415949G04 2 2 2 2
13 PLATE S.S 438336-01 1 1 1 -
S.S 4A2039-01 1
14 THUMBSCREW ABS,S.S 415949G09 2 2 2 2
15 PACKING EPDM 441217-01 1 1 1 1
47
HA
F-1000MAF(-C) G. LABEL LOCATION H-0, J-0, K-0
1
8
7
12
13
16
14
10
17
4
11
6
2
3
5
9
15
6
48
HA
F-1000MAF
:
TITLE
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-03 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1
5 RATING LABEL PES FILM 3A1122-01 1 1 1
6 LABEL-AIR FILTER PETP FILM 426177-01 2 2 2
7 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1
8 LABEL-CLEANING PVC FILM 326370-01 1 1 1
9 NAMEPLATE PES FILM 3A0970-01 1 1 1
10 TAG-WARNING:ELECTRICAL
CONNECTION
11 CONTROL LABEL PVC FILM 4A1613-01 1 1 1
12 LABEL-R404A PES FILM 4A0960-01 1 1 1
PAPER 428430-01 1 1 1
G. LABEL LOCATION
:
PART
NUMBER
H-0 J-0 K-0
REQUIRED NUMBER
13 CAUTION LABEL (E) PVC FILM 439145-01 1 1 1
14 WIRING LABEL PVC FILM 2A1393-01 1 1 1
15 INSTRUCTION SHEET PAPER 433523-01 1 1 1
16 CAUTION LABEL (H) PVC FILM 439148-01 1 1 1
17 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1
49
HA
F-1000MAF-C
:
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-07 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1
5 RATING LABEL PES FILM 3A1122-05 1 1 1
6 LABEL-AIR FILTER PETP FILM 426177-01 1 1 1
7 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1
8 LABEL-CLEANING PVC FILM 326370-01 1 1 1
9 NAMEPLATE PES FILM 3A0970-05 1 1 1
10 TAG-WARNING:ELECTRICAL
CONNECTION
11 CONTROL LABEL PVC FILM 4A1613-01 1 1 1
12 LABEL-R404A PES FILM 4A0960-01 1 1 1
13 CAUTION LABEL (E) PVC FILM 439145-01 1 1 1
PAPER 428430-01 1 1 1
G. LABEL LOCATION
TITLE
:
PART
NUMBER
REQUIRED NUMBER
H-0 J-0 K-0
14 WIRING LABEL PVC FILM 2A1393-01 1 1 1
15 INSTRUCTION SHEET PAPER 433523-01 1 1 1
16 CAUTION LABEL (H) PVC FILM 439148-01 1 1 1
17 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1
50
HA
F-1000MWF(-C) G. LABEL LOCATION H-0, J-0, K-0, K-1
1
8
7
12
13
4
11
2
3
10
14
15
5
9
16
6
51
HA
MODEL
INDEX
NO.
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-04 1 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1 1
5 RATING LABEL PES FILM 3A1122-02 1 1 1 1
6 INSTRUCTION SHEET PAPER 433523-01 1 1 1 1
7 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1 1
8 LABEL-CLEANING PVC FILM 326370-01 1 1 1 1
9 NAMEPLATE PES FILM 3A0970-02 1 1 1 1
10 TAG-WARNING:ELECTRICAL
CONNECTION
11 CONTROL LABEL PVC FILM 4A1613-01 1 1 1 1
12 LABEL-R404A PES FILM 4A0960-01 1 1 1 1
DESCRIPTION MATERIAL OR
F-1000MWF
:
TITLE
MODEL NUMBER
PAPER 428430-01 1 1 1 1
G. LABEL LOCATION
:
PART
NUMBER
H-0 J-0 K-0 K-1
REQUIRED NUMBER
13 CAUTION LABEL (E) PVC FILM 439145-01 1 1 1 1
14 WIRING LABEL PVC FILM 2A1393-01 1 1 1 1
15 CAUTION LABEL (H) PVC FILM 439148-01 1 1 1 1
16 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1 1
52
HA
F-1000MWF-C
:
MODEL
TITLE
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-08 1 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1 1
5 RATING LABEL PES FILM 3A1122-06 1 1 1 1
6 INSTRUCTION SHEET PAPER 433523-01 1 1 1 1
7 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1 1
8 LABEL-CLEANING PVC FILM 326370-01 1 1 1 1
9 NAMEPLATE PES FILM 3A0970-06 1 1 1 1
10 TAG-WARNING:ELECTRICAL
CONNECTION
11 CONTROL LABEL PVC FILM 4A1613-01 1 1 1 1
12 LABEL-R404A PES FILM 4A0960-01 1 1 1 1
PAPER 428430-01 1 1 1 1
G. LABEL LOCATION
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0 K-1
13 CAUTION LABEL (E) PVC FILM 439145-01 1 1 1 1
14 WIRING LABEL PVC FILM 2A1393-01 1 1 1 1
15 CAUTION LABEL (H) PVC FILM 439148-01 1 1 1 1
16 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1 1
53
HA
F-1000MRF(-C) G. LABEL LOCATION H-0, J-0, K-0, K-1
1
8
7
2
12
14
15
4
6
11
13
3
9
10
17
12
19
20
5
54
18
16
HA
F-1000MRF
:
TITLE
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-05 1 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1 1
5 RATING LABEL PES FILM 3A1122-03 1 1 1 1
6 LABEL-CHARGE PES FILM 4A1399-02 1 1 1 1
7 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1 1
8 LABEL-CLEANING PVC FILM 326370-01 1 1 1 1
9 NAMEPLATE PES FILM 3A0970-03 1 1 1 1
10 TAG-WARNING: ELECTRICAL
CONNECTION
11 CONTROL LABEL PVC FILM 4A1613-01 1 1 1 1
12 LABEL-R404A PES FILM 4A0960-01 1 1 1 1
PAPER 428430-01 1 1 1 1
G. LABEL LOCATION
:
PART
NUMBER
H-0 J-0 K-0 K-1
REQUIRED NUMBER
13 WIRING LABEL PVC FILM 2A1393-01 1 1 1 1
14 CAUTION LABEL(E) PVC FILM 439145-01 1 1 1 1
15 CAUTION LABEL(H) PVC FILM 439148-01 1 1 1 1
16 INSTRUCTION SHEET PAPER 433523-01 1 1 1 1
17 TAG-FAN MOTOR LEADS PAPER 4A1494-01 1 1 1 1
18 CAUTION - REMOTE LABEL PVC FILM 4A1491-01 1 1 1 1
19 CAUTION TAPE - 404A TAPE 4A1535L01 1 1 1 1
20 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1 1
55
HA
F-1000MRF-C
:
MODEL
TITLE
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-09 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1
5 RATING LABEL PES FILM 3A1122-07 1 1 1
6 LABEL-CHARGE PES FILM 4A1399-02 1 1 1
7 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1
8 LABEL-CLEANING PVC FILM 326370-01 1 1 1
9 NAMEPLATE PES FILM 3A0970-07 1 1 1
10 TAG-WARNING: ELECTRICAL
CONNECTION
11 CONTROL LABEL PVC FILM 4A1613-01 1 1 1
12 LABEL-R404A PES FILM 4A0960-01 1 1 1
PAPER 428430-01 1 1 1
G. LABEL LOCATION
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0
13 WIRING LABEL PVC FILM 2A1393-01 1 1 1
14 CAUTION LABEL(E) PVC FILM 439145-01 1 1 1
15 CAUTION LABEL(H) PVC FILM 439148-01 1 1 1
16 INSTRUCTION SHEET PAPER 433523-01 1 1 1
17 TAG-FAN MOTOR LEADS PAPER 4A1494-01 1 1 1
18 CAUTION - REMOTE LABEL PVC FILM 4A1491-01 1 1 1
19 CAUTION TAPE - 404A TAPE 4A1535L01 1 1 1
20 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1
56
HA
F-1000MLF(-C) G. LABEL LOCATION H-0, J-0, K-0, K-1
1
7
6
2
4
3
11
13
14
9
8
12
10
16
15
5
57
HA
F-1000MLF
:
TITLE
MODEL
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-06 1 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1 1
5 RATING LABEL PES FILM 3A1122-04 1 1 1 1
6 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1 1
7 LABEL-CLEANING PVC FILM 326370-01 1 1 1 1
8 NAMEPLATE PES FILM 3A0970-04 1 1 1 1
9 TAG-WARNING: ELECTRICAL
CONNECTION
10 CONTROL LABEL PVC FILM 4A1613-01 1 1 1 1
11 LABEL-R404A PES FILM 4A0960-01 1 1 1 1
12 WIRING LABEL PVC FILM 2A1394-01 1 1 1 1
PAPER 435005-01 1 1 1 1
G. LABEL LOCATION
:
PART
NUMBER
H-0 J-0 K-0 K-1
REQUIRED NUMBER
13 CAUTION LABEL(E) PVC FILM 439145-01 1 1 1 1
14 CAUTION LABEL(H) PVC FILM 439148-01 1 1 1 1
15 INSTRUCTION SHEET PAPER 433523-01 1 1 1 1
16 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1 1
58
HA
F-1000MLF-C
:
MODEL
TITLE
INDEX
NO.
MODEL
DESCRIPTION MATERIAL OR
NUMBER
1 INSTRUCTION SHEET PAPER 2A1054-01 1 1 1
2 EMBLEM PETP FILM 4A0560-01 1 1 1
3 MODEL NUMBER LABEL PETP FILM 4A1321-10 1 1 1
4 LABEL-PENGUIN-HA-R PETP FILM 4A0526-01 1 1 1
5 RATING LABEL PES FILM 3A1122-08 1 1 1
6 INSTRUCTION LABEL PVC FILM 326371-01 1 1 1
7 LABEL-CLEANING PVC FILM 326370-01 1 1 1
8 NAMEPLATE PES FILM 3A0970-08 1 1 1
9 TAG-WARNING: ELECTRICAL
CONNECTION
10 CONTROL LABEL PVC FILM 4A1613-01 1 1 1
11 LABEL-R404A PES FILM 4A0960-01 1 1 1
12 WIRING LABEL PVC FILM 2A1394-01 1 1 1
13 CAUTION LABEL(E) PVC FILM 439145-01 1 1 1
PAPER 435005-01 1 1 1
G. LABEL LOCATION
:
PART
REQUIRED NUMBER
NUMBER
H-0 J-0 K-0
14 CAUTION LABEL(H) PVC FILM 439148-01 1 1 1
15 INSTRUCTION SHEET PAPER 433523-01 1 1 1
16 LABEL (GM) - FUSE PVC FILM 4A1614-01 1 1 1
59
HA
MODEL
INDEX
NO.
1 INSTRUCTION MANUAL PAPER 91A2CA10B 1 1 1 1
2 LABEL-FASTENER PAPER 427122-01 1 1 1 1
3 UNIVERSAL BRACE G.S 4A0363-01 2 2 2 2
F-1000MAF(-C), MWF(-C), MRF(-C), MLF(-C)
:
DESCRIPTION MATERIAL OR
MODEL NUMBER
PART
NUMBER
H. ACCESSORIES
TITLE
:
REQUIRED NUMBER
H-0 J-0 K-0 K-1
60
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
