Instruction Manual
Commercial Series
Refrigerated Kitchen Equipment
Models
Reach-In S-Series
hoshizakiamerica.com
Issued: 3-31-2016
WARNING
Only qualied service technicians should install and service the appliance. To
obtain the name and phone number of your local Hoshizaki Certied Service
Representative, visit www.hoshizaki.com. No installation or service should be
undertaken until the technician has thoroughly read this Instruction Manual.
Likewise, the owner/manager should not proceed to operate the appliance until the
installer has instructed them on its proper operation. Failure to install, operate, and
maintain the appliance in accordance with this manual may adversely affect safety,
performance, component life, and warranty coverage. Proper installation is the
responsibility of the installer. Product failure or property damage due to improper
installation is not covered under warranty.
Hoshizaki provides this manual primarily to assist qualied service technicians in the
installation, maintenance, and service of the appliance.
Should the reader have any questions or concerns which have not been satisfactorily
addressed, please call, send an e-mail message, or write to the Hoshizaki Technical
Support Department for assistance.
Phone: 1-800-233-1940; (770) 487-2331
Fax: 1-800-843-1056; (770) 487-3360
E-mail: techsupport@hoshizaki.com
HOSHIZAKI AMERICA, INC.
618 Highway 74 South
Peachtree City, GA 30269
Attn: Hoshizaki Technical Support Department
Web Site: www.hoshizaki.com
NOTE: To expedite assistance, all correspondence/communication MUST include the
following information:
• Model Number
• Serial Number
• Complete and detailed explanation of the problem.
2
IMPORTANT
This manual should be read carefully before the appliance is installed and
operated. Read the warnings and guidelines contained in this booklet carefully as
they provide essential information for the continued safe use and maintenance of
the appliance. Retain this booklet for any further reference that may be necessary.
CONTENTS
Important Safety Information ................................................................................................. 4
I. Installation Instructions ....................................................................................................... 7
A. Location ........................................................................................................................ 7
B. Checks Before Installation ............................................................................................. 7
C. Setup ............................................................................................................................. 8
D. Door Reversal................................................................................................................ 9
E. Unit Leveling ................................................................................................................. 9
F. Electrical Connection ................................................................................................... 10
G. Final Checklist .............................................................................................................11
II. Operating Instructions ...................................................................................................... 12
A. Important Notes About Usage .................................................................................... 12
B. Startup ........................................................................................................................ 13
C. Controls and Adjustments ........................................................................................... 14
1. Temperature Display ............................................................................................... 14
2. Adjusting the Temperature Setpoint ....................................................................... 14
3. Changing the Temperature Display Scale (°F or °C) ............................................. 15
4. Light Switch for Glass Door Models ....................................................................... 15
D. Control Module Icons .................................................................................................. 15
E. Defrost ......................................................................................................................... 16
F. Food Storage ............................................................................................................... 16
G. Alarm Safeties ............................................................................................................. 17
H. Safety Devices ............................................................................................................ 18
I. Cooling Performance .................................................................................................... 18
J. Cabinet Condensation ................................................................................................. 18
III. Cleaning and Maintenance Instructions .......................................................................... 19
A. Cleaning ...................................................................................................................... 19
1. Exterior ................................................................................................................... 19
2. Cabinet Interior ...................................................................................................... 19
3. Door Gaskets ......................................................................................................... 19
4. Shelves .................................................................................................................. 19
5. Glass Door ............................................................................................................. 19
B. Maintenance/Troubleshooting ..................................................................................... 20
1. Condenser .............................................................................................................. 20
2. Condensate Drain Boot ......................................................................................... 20
3. Power Supply Connection ...................................................................................... 21
IV. Preparing the Appliance for Periods of Non-Use ............................................................ 22
V. Disposal ........................................................................................................................... 23
3
Important Safety Information
Throughout this manual, notices appear to bring your attention to situations which could
result in death, serious injury, damage to the appliance, or damage to property.
,
WARNING Indicates a hazardous situation which could result in death or
serious injury.
NOTICE Indicates a situation which could result in damage to the
appliance or property.
IMPORTANT Indicates important information about the use and care of the
appliance.
WARNING
This appliance should be destined only to the use for which it has been expressly
conceived. Any other use should be considered improper and therefore dangerous.
The manufacturer cannot be held responsible for injury or damage resulting
from improper, incorrect, and unreasonable use. Failure to install, operate, and
maintain the appliance in accordance with this manual will adversely affect safety,
performance, component life, and warranty coverage.
To reduce the risk of death, electric shock, serious injury, or re, follow basic
precautions including the following:
• Only qualied service technicians should install and service this appliance.
• This appliance must be installed in accordance with applicable national, state, and
local codes and regulations.
• To reduce the risk of electric shock, do not touch the power switch or plug with
damp hands.
• Make sure the power switch is in the "OFF" position before plugging in or
unplugging the appliance to reduce the risk of electric shock.
• Before servicing, move the power switch to the "OFF" position. Unplug the
appliance from the electrical outlet.
• This appliance requires an independent power supply of proper capacity. See
the nameplate for electrical specications. Failure to use an independent power
supply of proper capacity can result in a tripped breaker, blown fuse, damage to
existing wiring, or component failure. This could lead to heat generation or re.
• 115VAC Models: THIS APPLIANCE MUST BE GROUNDED: This appliance
is equipped with a NEMA5-15 three-prong grounding plug
risk of potential shock hazards. It must be plugged into a properly grounded,
independent 3-prong wall outlet. If the outlet is a 2-prong outlet, it is your personal
responsibility to have a qualied electrician replace it with a properly grounded,
independent 3-prong wall outlet. Do not remove the ground prong from the plug
and do not use an adapter plug. Failure to follow these instructions may result in
death, electric shock, or re.
to reduce the
4
WARNING, continued
• 208-230VAC Models: THIS APPLIANCE MUST BE GROUNDED: This appliance
is equipped with a NEMA L14-20 four-prong locking, grounding plug
the risk of potential shock hazards. It must be plugged into a properly grounded,
independent 4-prong wall outlet. If the outlet is a 3-prong outlet or a 4-prong
non-locking outlet, it is your personal responsibility to have a qualied electrician
replace it with a properly grounded, independent 4-prong locking wall outlet. Do
not remove the ground prong from the plug and do not use an adapter plug. After
plugging in, twist the plug clockwise to lock it into place. Failure to follow these
instructions may result in death, electric shock, or re.
• Do not use an extension cord.
• Do not use an appliance with a damaged power cord. The power cord should not
be altered, jerked, bundled, weighed down, pinched, or tangled. Such actions could
result in electric shock or re. To unplug the appliance, be sure to pull the plug, not
the cord, and do not jerk the cord. Before unplugging a 4-prong plug, rotate the plug
counter-clockwise to unlock it.
• The GREEN ground wire in the factory-installed power cord is connected to the
appliance. If it becomes necessary to remove or replace the power cord, be sure to
connect the power cord's ground wire.
to reduce
• Do not splash, pour, or spray water directly onto or into the appliance. This might
cause short circuit, electric shock, corrosion, or failure.
• Do not make any alterations to the appliance. Alterations could result in electric
shock, injury, re, or damage to the appliance.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be properly supervised around this appliance.
• Do not climb, stand, or hang on the appliance or door or allow children or animals to
do so. Do not climb into the appliance or allow children or animals to do so. Death or
serious injury could occur or the appliance could be damaged.
• Be careful not to pinch ngers when opening and closing the doors. Be careful when
opening and closing the doors when children are in the area.
• Open and close the doors with care. Doors opened too quickly or forcefully may
cause injury or damage to the appliance or surrounding equipment.
• Do not use combustible spray or place volatile or ammable substances in or near
the appliance. They might catch re.
• Keep the area around the appliance clean. Dirt, dust, or insects in the appliance
could cause harm to individuals or damage to the equipment.
• Do not throw anything onto the shelves or load any single shelf with more than
120lb. (54.5 kg) of product. They might fall off and cause injury.
• Do not place anything on top of the appliance. Foreign objects or moisture could
enter the appliance and result in electric shock or re.
5
WARNING, continued
• This appliance is designed only for temporary storage of food. Employ sanitary
methods. Use for any other purposes (for example, storage of chemicals or medical
supplies such as vaccine and serum) could cause deterioration of stored items.
• Do not block the cabinet air inlet or outlet, otherwise cooling performance may be
reduced.
• Do not tightly pack the cabinet. Allow some space between items to ensure good air
ow. Also allow space between items and interior surfaces.
• Do not place any product on the oor of the cabinet. All product must be placed on
properly installed shelves.
• Do not put warm or hot foods in the cabinet. Let them cool rst, or they will raise the
cabinet temperature and could deteriorate other foods in the cabinet or overload the
appliance.
• All foods should be wrapped in plastic lm or stored in sealed containers. Otherwise
foods may dry up, pass their smells onto other foods, cause frost to develop, result
in poor appliance performance, or increase the likelihood of cross-contamination.
Certain dressings and food ingredients, if not stored in sealed containers, may
accelerate corrosion of the evaporator, resulting in failure.
• Do not store items near the air outlet. They might freeze up and crack or break
causing a risk of injury or contamination of other food.
NOTICE
• Protect the oor when moving the appliance to prevent damage to the oor.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction. Do not place anything on top of the appliance. Blockage of
airow could negatively affect performance and damage the appliance.
• To prevent deformation or cracks, do not spray insecticide onto the plastic parts or
let them come into contact with oil.
• To avoid damage to the gasket, use only the door handle when opening and closing.
6
I. Installation Instructions
WARNING
• This appliance must be installed in accordance with all applicable national, state,
and local regulations.
• Appliance is heavy. Use care when lifting or positioning. Work in pairs when
needed to prevent injury or damage.
• Do not tilt the appliance more than 45°.
A. Location
WARNING
• This appliance is not intended for outdoor use.
• Normal operating ambient temperature:
– Refrigerators and Solid Door Freezers 45°F to 100°F (7°C to 38°C)
– Glass Door Freezers 45°F to 80°F (7°C to 27°C)
Operation of the appliance, for extended periods, outside of this normal
temperature range may affect appliance performance.
For best operating results:
• The appliance should not be located next to ovens, grills, or other high heat producing
equipment.
• The location should provide a rm and level foundation for the appliance.
• The appliance should not be located in a corrosive environment.
• Minimum Clearance:
Side Top Rear
3" (8 cm) 12" (31 cm) 1" (3 cm)
B. Checks Before Installation
WARNING
Refer to the nameplate for electrical specications. The nameplate is located on
the right side wall of the cabinet interior. For more electrical connection details, see
"I.F. Electrical Connection." We reserve the right to make specication and design
changes without prior notice.
Nameplate
7
• Visually inspect the exterior of the shipping package and immediately report any damage
to the carrier. Upon opening the package, any concealed damage should also be
immediately reported to the carrier.
• Remove the shipping carton, tape, and packing material. Remove the protective plastic
lm from the exterior panels on all models and from the interior door panels on solid
door models. If the appliance is exposed to the sun or to heat, remove the lm after the
appliance cools.
• Remove all accessory containers before discarding the packing materials. Dispose of all
packing materials in a proper and environmentally responsible manner.
• Check for missing or damaged accessories.
C. Setup
1. Remove the Appliance from the Pallet and Install the Casters
1) Move as close to the nal location as
possible.
2) Remove the 2 bolts securing the unit to
the pallet, then remove the unit from the
pallet. Block the unit securely at a height of
8" (20cm) off the oor. Do not lay the unit
down. NOTICE! Do not allow the door(s)
to bear the weight of the appliance.
Door
3) Attach the casters to the bottom of the unit.
Locking casters should be attached to the
front of the unit. See Fig. 1.
4) While supporting the appliance to keep it
Locking Casters in Front
Fig. 1
from tipping, lower the casters to the oor.
2. Check the Refrigeration Circuit
• Visually check that the refrigerant lines do not rub or touch other lines or surfaces and
that the condenser fan blade turns freely.
• Check that the compressor is snug on all mounting pads.
3. Position the Appliance and Lock the Front Casters
The front casters on the appliance are lockable. After positioning the appliance in its nal
location, lock the front casters.
4. Install the Shelves
Pilaster
Shelf
Shelf support clips are provided in the accessory pack.
1. Place the shelf support clips into the pilasters (4 shelf support
clips per shelf). Indexing holes are provided on the pilasters
in evenly spaced intervals to assist you in positioning the
support clips at the same height. See Fig. 2.
2. Place the shelves in position on the shelf support clips.
Indexing
Holes
Fig. 2
Shelf
Support
Clip
8
D. Door Reversal
This appliance is provided with a cabinet design which, after being delivered to the
installation location, permits changing of the door swing from left to right or right to left.
To change the door swing, an HS kit from your local Hoshizaki distributor is required.
See the table below. NOTICE! Improper installation of the HS kit may result in the
doors not closing completely and/or the gaskets not sealing correctly. For further
details, contact your local Hoshizaki distributor or Hoshizaki Technical Support at
1-800-233-1940.
Door Type Convert HS Kit Number
Glass
Full Door
Solid
Full Door
Solid
Half Door
Right Hinge to Left Hinge HS-5176
Left Hinge to Right Hinge HS-5177
Right Hinge to Left Hinge HS-3726
Left Hinge to Right Hinge HS-3725
Right Hinge to Left Hinge HS-3725
Left Hinge to Right Hinge HS-3726
E. Unit Leveling
If necessary, use the shim kit and shim kit instructions provided to level the unit.
9
F. Electrical Connection
WARNING
• Electrical connection must meet national, state, and local electrical code
requirements. Failure to meet these code requirements could result in death,
electric shock, serious injury, re, or severe damage to equipment.
• This appliance requires an independent power supply of proper capacity. See
the nameplate for electrical specications. Failure to use an independent power
supply of proper capacity can result in a tripped breaker, blown fuse, damage to
existing wiring, or component failure. This could lead to heat generation or re.
• 115VAC Models: THIS APPLIANCE MUST BE GROUNDED: This appliance
is equipped with a NEMA 5-15 three-prong grounding plug
risk of potential shock hazards. It must be plugged into a properly grounded,
independent 3-prong wall outlet. If the outlet is a 2-prong outlet, it is your personal
responsibility to have a qualied electrician replace it with a properly grounded,
independent 3-prong wall outlet. Do not remove the ground prong from the plug
and do not use an adapter plug. Failure to follow these instructions may result in
death, electric shock, or re.
• 208/230VAC Models: THIS APPLIANCE MUST BE GROUNDED: This appliance
is equipped with a NEMA L14-20 four-prong locking, grounding plug
the risk of potential shock hazards. It must be plugged into a properly grounded,
independent 4-prong wall outlet. If the outlet is a 3-prong outlet or a 4-prong
non-locking outlet, it is your personal responsibility to have a qualied electrician
replace it with a properly grounded, independent 4-prong locking wall outlet. Do
not remove the ground prong from the plug and do not use an adapter plug. After
plugging in, twist the plug clockwise to lock it into place. Failure to follow these
instructions may result in death, electric shock, or re.
to reduce the
to reduce
• To reduce the risk of electric shock, do not touch the power switch or plug with
damp hands.
• Make sure the power switch is in the "OFF" position before plugging in or
unplugging the appliance to reduce the risk of electric shock.
• Do not use an extension cord.
• Do not use an appliance with a damaged power cord. The power cord should not
be altered, jerked, bundled, weighed down, pinched, or tangled. Such actions
could result in electric shock or re. To unplug the appliance, be sure to pull the
plug, not the cord, and do not jerk the cord.
• The GREEN ground wire in the factory-installed power cord is connected to the
appliance. If it becomes necessary to remove or replace the power cord, be sure
to connect the power cord's ground wire.
• Usually an electrical permit and services of a licensed electrician are required.
• The maximum allowable voltage variation is ±10 percent of the nameplate rating.
10
G. Final Checklist
1) Is the appliance level?
2) Have the front casters been locked?
3) Is the appliance in a site where the ambient temperature is as specied below all year
around?
– Refrigerators and Solid Door Freezers 45°F to 100°F (7°C to 38°C)
– Glass Door Freezers 45°F to 80°F (7°C to 27°C)
4) Have the minimum clearance requirements specied below been met?
Side Top Rear
3" (8 cm) 12" (31 cm) 1" (3 cm)
5) Have the shipping carton, tape, and packing material been removed from the
appliance? Hasthe protective plastic lm been removed from the exterior panels on all
models and from the interior door panels on solid door models?
6) Have the appliance and accessories been checked for shipping damage?
7) Has the power supply voltage been checked or tested against the nameplate rating?
Is the power supply a properly grounded, independent wall outlet? Does the electrical
connection meet all national, state, and local code and regulation requirements.
8) Have the refrigerant lines been checked to make sure they do not rub or touch other
lines or surfaces? Has the condenser fan blade been checked to make sure it turns
freely? Is the compressor securely attached?
9) Have the shelves been properly installed?
10) Has the end user been given the instruction manual, and instructed on how to operate
the appliance and the importance of the recommended periodic maintenance?
11) Has the end user been given the name and telephone number of an authorized service
agent?
12) Has the warranty card been lled out and forwarded to the factory for warranty
registration?
11
II. Operating Instructions
A. Important Notes About Usage
WARNING
• Only qualied service technicians should install and service this appliance.
• Failure to install, operate, and maintain the appliance in accordance with this
manual may adversely affect safety, performance, component life, and warranty
coverage.
• To reduce the risk of electric shock, do not touch the power switch or plug with
damp hands.
• Do not splash, pour, or spray water directly onto or into the appliance. This might
cause short circuit, electric shock, corrosion, or failure.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be properly supervised around this appliance.
• Do not climb, stand, or hang on the appliance or door or allow children or animals
to do so. Do not climb into the appliance or allow children or animals to do so.
Death or serious injury could occur or the appliance could be damaged.
• Be careful not to pinch ngers when opening and closing the door. Be careful
when opening and closing the door when children are in the area.
• Open and close the doors with care. Doors opened too quickly or forcefully may
cause injury or damage to the appliance or surrounding equipment.
• Do not use combustible spray or place volatile or ammable substances in or near
the appliance. They might catch re.
• Keep the area around the appliance clean. Dirt, dust, or insects in the appliance
could cause harm to individuals or damage to the equipment.
• Do not throw anything onto the shelves or load any single shelf with more than
120 lb. (54.5 kg) of product. They might fall off and cause injury.
• Do not place anything on top of the appliance. Foreign objects or moisture could
enter the appliance and result in electric shock or re.
• This appliance is designed only for temporary storage of food. Employ sanitary
methods. Use for any other purposes (for example, storage of chemicals or
medical supplies such as vaccine and serum) could cause deterioration of stored
items.
• Do not block the cabinet air inlet or outlet, otherwise cooling performance may be
reduced.
• Do not tightly pack the cabinet. Allow some space between items to ensure good
air ow. Also allow space between items and interior surfaces.
• Do not place any product on the oor of the cabinet. All product must be placed on
properly installed shelves.
12
WARNING, continued
• Do not put warm or hot foods in the cabinet. Let them cool rst, or they will raise
the cabinet temperature and could deteriorate other foods in the cabinet or
overload the appliance.
• All foods should be wrapped in plastic lm or stored in sealed containers.
Otherwise foods may dry up, pass their smells onto other foods, cause frost
to develop, result in poor appliance performance, or increase the likelihood of
cross-contamination. Certain dressings and food ingredients, if not stored in
sealed containers, may accelerate corrosion of the evaporator, resulting in failure.
• Do not store items near the air outlet. They might freeze up and crack or break
causing a risk of injury or contamination of other food.
NOTICE
• Protect the oor when moving the appliance to prevent damage to the oor.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction. Blockage of airow could negatively affect performance and
damage the appliance.
• To prevent deformation or cracks, do not spray insecticide onto the plastic parts or
let them come into contact with oil.
• To avoid damage to the gasket, use only the door handle when opening and
closing.
• Do not leave the doors open.
B. Startup
WARNING
All parts are factory-adjusted. Improper adjustments may adversely affect safety,
performance, component life, and warranty coverage.
IMPORTANT
At startup, there is a slight delay before the compressor starts.
1) Reach over the front panel to access the power switch—located on the front of the
control box. See Fig. 3. Make sure the power switch is in the "OFF" position.
WARNING! To reduce the risk of electric shock, do not touch the power switch or
plug with damp hands.
2) Plug the appliance into the electrical outlet.
3) Move the power switch to the "ON" position
to start the cool-down process.
4) Allow the appliance to cool down prior to
loading it with food products.
Fig. 3
Power
Switch
13
Front Panel
C. Controls and Adjustments
1. Temperature Display
The cabinet temperature is displayed on the control module. See Fig. 4. The display
default is °F, but it can be changed to read °C. To change, see "II.C.3. Changing the
Temperature Display Scale (°F or °C)."
Manual
Defrost
Button
SC
Button
Control Module
Compressor Icon
ECO
SC
Defrost
Icon
Evaporator Fan
Motor Icon
°C
°F
Alarm
Icon
Up
Button
V
V
Down
Button
Front
Panel
Fig. 4
2. Adjusting the Temperature Setpoint
The temperature setpoint is the value for the average cabinet temperature. The
temperature differential for the compressor to turn on and off is ±3°F (±1.7°C) of the
temperature setpoint. For example, for a refrigerator temperature setpoint of 36°F (2°C),
the compressor comes on at 39°F (3.7°C), and the compressor goes off at 33°F (0.3°C).
If necessary, adjust the temperature setpoint temperature as follows:
1) To change the temperature setpoint, press and hold the up button briey and then
release. The current temperature setpoint appears. Press the up or down button until
the desired value is displayed. After a few seconds, the display returns to the current
cabinet temperature and the temperature setpoint is saved. NOTICE! Do not adjust
the temperature setpoint more than 2°F (1°C) at a time. Allow the temperature to
stabilize for a minimum of 8hours before making further temperature setpoint
adjustments.
• For refrigerators, the temperature setpoint is adjustable between 31°F and 52°F
(-0.5°C and 11°C). The factory default is 33°F (1°C).
• For freezers, the temperature setpoint is adjustable between -10°F and +12°F (-24°C
and -11°C). The factory default is -4°F (-20°C).
14
3. Changing the Temperature Display Scale (°F or °C)
EHE
To change the temperature display scale, follow the steps below. The factory default is °F.
1) Press and hold both the up and down buttons for 5 seconds. "PAS" appears briey in
the display, then "000" appears.
2) Press the up button to change the display to "001".
3) Press the SC button. "
" appears in the display. Press the up or down button until
"diS" is displayed.
4) Press the SC button. "CFu" appears in the display. Press the SC button again. The
current temperature display scale setting appears. Press the up or down button to
change the temperature display scale.
5) Press the SC button to save the setting. Wait 1 minute or press the manual defrost
button twice to return to the temperature display.
4. Light Switch for Glass Door Models
Glass door models feature lights that are controlled by a light switch located on the
bottom of the front panel. See Fig. 5.
Front Panel
Fig. 5
Light Switch for
Glass Door Models
D. Control Module Icons
Control module icons inform you of energized components and if the appliance is in
alarm.
Control Module Icons
Icon Meaning
Compressor
Compressor running.
Defrost
Appliance is in defrost cycle. See "II.E. Defrost" for details.
Evaporator Fan Motor
Evaporator fan motor is running. Evaporator fan motor de-energizes when door is open.
Alarm
Appliance is in alarm. See "II.G. Alarm Safeties" for details.
15
E. Defrost
1. Refrigerators
Refrigerators use an off-cycle, time-initiated defrost and defrost once every 2 hours.
When the defrost thermistor warms to44°F (6.6°C), defrost terminates. The minimum
defrost time is 20 minutes and the maximum defrost time is 1 hour. Cabinet temperature
is displayed during defrost.
2. Freezers
Freezers use a heated, temperature/time-initiated defrost. Once the defrost thermistor
cools to 32°F (0°C), the 4-hour cumulative compressor run timer starts. When the 4-hour
cumulative compressor run timer terminates, defrost begins. Cabinet temperature is not
displayed during defrost; "dEF" is displayed in its place. When the defrost thermistor
warms to 59°F (15°C), defrost terminates. A 3-minute compressor delay timer, a 7-minute
evaporator fan motor delay timer, and an 18-minute temperature display delay timer start.
As the delay timers terminate, the related components energize. Note that the 7-minute
evaporator fan motor delay time is a maximum; if the defrost thermistor cools to 25°F
(-3.9°C) before the 7-minute evaporator fan motor delay timer terminates, the evaporator
fan motor will energize. Freezers have a minimum defrost interval of 4 hours. The
minimum defrost time is 5 minutes and the maximum defrost time is 1 hour.
3. Manual Defrost
To initiate a manual defrost, press the manual defrost button.
F. Food Storage
WARNING
• This appliance is designed only for temporary storage of food. Employ sanitary
methods. Use for any other purposes (for example, storage of chemicals or
medical supplies such as vaccine and serum) could cause deterioration of stored
items.
• Do not block the cabinet air inlet or outlet, otherwise cooling performance may be
reduced.
• Do not tightly pack the cabinet. Allow some space between items to ensure good
air ow. Also allow space between items and interior surfaces.
• Do not place any product on the oor of the cabinet. All product must be placed on
properly installed shelves.
• Do not put warm or hot foods in the cabinet. Let them cool rst, or they will raise
the cabinet temperature and could deteriorate other foods in the cabinet or
overload the appliance.
• All foods should be wrapped in plastic lm or stored in sealed containers.
Otherwise foods may dry up, pass their smells onto other foods, cause frost
to develop, result in poor appliance performance, or increase the likelihood of
cross-contamination. Certain dressings and food ingredients, if not stored in
sealed containers, may accelerate corrosion of the evaporator, resulting in failure.
• Do not store items near the air outlet. They might freeze up and crack or break
causing a risk of injury or contamination of other food.
16
G. Alarm Safeties
Alarm signals are designed to protect the appliance and food product. These alarms
give information or warnings in the event the appliance is operating out of acceptable
parameters. Should one of the alarms occur, follow the instructions in the table below to
address the alarm. The alarm code and alarm icon ash with audible alarm.
Alarm Signals
Alarm Code Problem Corrective Action/Reset Details
Cabinet Thermistor Malfunction Alarm
Call a qualied service technician.
E01
E02
Hi
Lo
Cabinet thermistor has failed.
Defrost Thermistor Malfunction Alarm
Defrost thermistor has failed.
High Temperature Alarm
Refrigerator: Cabinet temperature has
remained above 57°F (13.9°C) for more
than 2hours.
Freezer: Cabinet temperature has
remained above 26°F (-3.3°C) for more
than 2hours.
Low Temperature Alarm
Refrigerator: Cabinet temperature has
remained below 26°F (-3.3°C) for more
than 2hours.
Freezer: Cabinet temperature has
remained below -23°F (-30.6°C) for more
than 2hours.
Beeps for 10 seconds, then silent for 50 seconds. To
silence the alarm, press and release the up button.
Appliance cycles 5 min. on, 5 min. off.
Call a qualied service technician.
Beeps for 10 seconds, then silent for 50 seconds. To
silence the alarm, press and release the up button.
Appliance cycles on and off with cabinet thermistor.
If obvious corrections such as closing doors and
cleaning the air lter and/or condenser do not bring
temperature back in range, call a qualied service
technician.
Beeps for 10 seconds, then silent for 50 seconds.
To silence the alarm and clear "Hi" from the display,
press and release the up button. The alarm icon
stays on.
Automatically resets when temperature returns to
normal.
If obvious corrections do not bring the temperature
back in range, call a qualied service technician.
Beeps for 10 seconds, then silent for 50 seconds.
To silence the alarm and clear "Lo" from the display,
press and release the up button. The alarm icon
stays on.
Automatically resets when temperature returns to
normal.
17
H. Safety Devices
1. Compressor External or Internal Overload
If combined temperature/amperage value is above the limit specied by the
compressor manufacturer, the compressor overload operates independently to turn
off the compressor. The compressor overload de-energizes the compressor until the
temperature/amperage value returns to an acceptable level.
2. Short-Cycle Protection
There is a 2-minute minimum off-time and on-time for the compressor.
Note: Time may vary with compressor overload or high-pressure switch activation.
3. High-Pressure Switch
If pressure on the high-side of the appliance exceeds Hoshizaki specications, the
high-pressure switch activates and interrupts the compressor circuit, de-energizing the
compressor until the pressure returns to an acceptable level.
I. Cooling Performance
Be sure the appliance is properly installed and located for optimum cooling performance.
If cooling performance is not at its optimum level, check the following items:
• Door(s) opened too often.
• Door(s) left open. Close.
• Cabinet too tightly packed or cabinet air inlet/outlet blocked. Allow some space between
items to ensure good air ow.
• Warm or hot foods inside. Take them out until they cool down more.
• Ambient temperature too high. Avoid installation near high heat producing equipment or
exposure to direct sunlight.
• Temperature setpoint too high. Readjust it to a lower temperature.
• Appliance in defrost cycle. The cabinet temperature may rise temporarily during the
defrost cycle, but this will not affect the food inside.
J. Cabinet Condensation
In the event condensation develops on the cabinet exterior, check the following items:
• Door(s) left open. Close.
• Ambient humidity too high. In high humidity areas it may be necessary to wipe off the
cabinet frame occasionally.
18
III. Cleaning and Maintenance Instructions
A. Cleaning
WARNING
• Before cleaning the appliance, move the power switch to the "OFF" position and
unplug the appliance to prevent electric shock by unexpected entrance of water
into the appliance or injury by moving parts. To reduce the risk of electric shock,
do not touch the power switch or plug with damp hands.
• Before cleaning the appliance, move all foods into another clean refrigerator or
freezer.
• Do not splash water directly onto the appliance. This might cause short circuit,
electric shock, corrosion, or failure.
• Carefully follow instructions provided with cleaning and sanitizing products.
NOTICE
• To prevent damage to the plastic surfaces, do not use the following: hot water,
thinner, benzine, alcohol, petroleum, soap powder, polishing powder, alkaline
cleaner, acid, scouring pad and especially those strong cleaners for use on a
ventilating fan or a cooking range.
• To prevent corrosion and damage to stainless steel surfaces, use only products
formulated for use on stainless steel appliances. Do not use steel wool, abrasive
products, or products containing sodium hypochlorite (chlorine bleach).
• Use a clean cloth for cleaning.
1. Exterior
Wipe the exterior occasionally with a clean, soft cloth. Use a damp cloth containing
a neutral cleaner to wipe off oil or dirt buildup. Clean any rust colored spots using a
non-abrasive cleanser.
2. Cabinet Interior
Spills should be wiped up promptly to avoid unpleasant odors. The cabinet interior should
be cleaned periodically with a mild soap or detergent and warm water. NOTICE! Do not
use hot water to clean the cabinet interior.
3. Door Gaskets
Door gaskets should be cleaned regularly with mild soap and warm water to remove dirt
and grease.
4. Shelves
Remove and clean regularly.
5. Glass Door
Wipe occasionally with a clean, soft cloth. Use a damp cloth containing a neutral cleaner
to wipe off oil or dirt buildup.
19
B. Maintenance/Troubleshooting
The appliance must be maintained in accordance with the instruction manual. Consult
with your local Hoshizaki Certied Service Representative about maintenance service.
Failure to maintain the appliance in accordance with this manual may adversely affect
safety, performance, component life, and warranty coverage.
WARNING
• Only qualied service technicians should service the appliance.
• Move the power switch to the "OFF" position and unplug the appliance before
performing maintenance or troubleshooting to prevent electric shock or injury by
moving parts. To reduce the risk of electric shock, do not touch the power switch
or plug with damp hands.
• Before performing maintenance or troubleshooting, move all foods into another
clean refrigerator or freezer.
Troubleshooting
Problem Possible Solution
Insufficient cooling; compresssor protector or
high-pressure switch tripping
Water or ice in the bottom of the cabinet Clean the condensate drain boot. See "III.B.2. Condensate
See "II.I. Cooling Performance." If the items listed do not
resolve the problem, clean the condenser. See "III.B.1
Condenser" below.
Drain Boot" below.
1. Condenser
The condenser must be cleaned at least once a year. More frequent cleaning may be
required in some conditions. Use a brush or vacuum cleaner to clean the condenser as
required.
2. Condensate Drain Boot
The condensate drain boot must be cleaned at least once a year. More frequent cleaning
may be required in some conditions to maintain proper ow. Follow the steps below.
1) Unplug the appliance from the electrical outlet. WARNING! To reduce the risk of
electric shock, do not touch the plug with damp hands.
2) Remove the drain boot from the drain hose. See Fig. 6. WARNING! On freezer models,
be careful not to affect the position of the drain heater.
3) Clean the drain boot.
4) Replace the drain boot in its correct position.
NOTICE! Be sure the drain boot is positioned into the condensate pan.
WARNING! On freezer models, be careful not to affect the position of the drain
heater.
5) Plug the appliance back in.
20
Drain Heater
(Freezer)
Drain Hose
Spring
Fig. 6
Condensate Pan
Drain Boot
3. Power Supply Connection
If the plug or power cord is damaged, contact your local Hoshizaki service representative
or local Hoshizaki distributor immediately and ask for repairs.
All other maintenance or service on this appliance should be performed in accordance
with the Hoshizaki Service Manual by a qualied service technician.
21
IV. Preparing the Appliance for Periods of Non-Use
When shutting down the appliance for periods of non-use, follow the instructions below.
WARNING
Prevent the doors from closing to reduce the risk of children getting trapped.
NOTICE
Clean the appliance. See "III.A. Cleaning" for details.
1) Before shutting down the appliance, move the stored food into another refrigerator or
freezer.
2) Move the power switch to the "OFF" position and unplug the appliance.
WARNING! To reduce the risk of electric shock, do not touch the power switch or
plug with damp hands.
22
V. Disposal
When disposing of the appliance, follow the instructions below.
WARNING
Remove the door to reduce the risk of children getting trapped. Leave the shelves in
place so that children may not easily climb inside.
This appliance contains refrigerant and must be disposed of in accordance with
applicable national, state, and local codes and regulations. Refrigerant must be
recovered by properly certied service personnel.
23
